1
24" STEEL CAULDRON FIRE PIT
MODEL #OFW194R-M
MENARDS SKU #259-5085
Questions, problems, missing parts? Before returning to your retailer,
call our customer service department at 1-877-447-4768,
8:00 a.m. – 4:30 p.m., CST, Monday – Friday or email us at
30-10-195 10/29/2019
2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Mesh Cover 1
B Fire Bowl 1
C Outer Support Ring 1
D Lower Ring 1
E Leg 4
F Poker 1
A
B
C
D
E
F
HARDWARE CONTENTS
AA
M6x6mm Bolt
Qty: 8
3
Please read and understand this entire manual before attempting to assemble, operate or install
the product. If you have any questions regarding the product, please call customer service at
1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST, Monday – Friday.
WARNINGS:
• DO NOT allow children or pets near the re pit without supervision.
• DO NOT touch surface of re pit while in use.
• FOR OUTDOOR USE ONLY! Burning wood or charcoal indoors can kill you. It gives off carbon
monoxide, which has no odor.
• NEVER burn in vehicles, tents, garages, other enclosed areas or indoors. CARBON MONOXIDE
HAZARD.
• NEVER LEAVE FIRE UNATTENDED!
• NEVER place a storage cover on re pit when in use. Ensure the re pit and mesh cover have
cooled before placing a storage cover over the re pit.
• When the re pit is in use, the poker bracket on the mesh cover can reach extreme temperatures
that can cause serious injury to an unprotected hand. Use a poker when handling.
• DO NOT use under overhead cables or power lines.
CAUTIONS:
• Adequate re extinguishing material should be readily available.
• Always ensure that the mesh cover is secured over re bowl while in use.
• Burn only seasoned hard wood or re logs in the re pit.
• DO NOT attempt to move the re pit while it is hot or in use.
• DO NOT use gasoline or kerosene to start the re in your re pit.
• DO NOT use this outdoor re pit under any overhead or near any unprotected combustible
constructions. Avoid using near or under overhanging trees and shrubs. DO NOT use this unit on
long or dry grass and/or leaves.
• Always use this outdoor re pit on a hard, level, non-combustible surface such as concrete, rock or stone.
An asphalt or blacktop surface may not be acceptable for this purpose. DO NOT use on wooden decks.
• Place the re pit no closer than 10 feet / 3.05 meters from walls or combustibles during use.
• Poker bracket may become hot during and after use.
• Use heat-resistant gloves to handle hot tools.
SAFETY INFORMATION
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list above. If any part is missing or damaged, do not attempt to assemble the product.
Contact customer service for replacement parts.
Estimated Assembly Time: 15 minutes
Tools Required for Assembly:
Phillips Screwdriver (Not Included)
4
ASSEMBLY INSTRUCTIONS
1. Align a hole of the Lower Ring (D) with a hole
in one of the Legs (E). Using a screwdriver,
loosely attach the Leg (E) to the Ring (D)
with a M6x6mm Bolt. Repeat this step for the
remaining three legs. Do not tighten at this time.
1
E
AA
D
2
2. Turn the leg assembly right side up.
Align the holes of the Upper Support Ring (C)
with the side holes on each Leg (E). Using a
screwdriver, attach each Leg (E) to the Upper
Support Ring with a M6x6mm bolt.
Once the base assembly is completed, securely
tighten all bolts with a screwdriver.
C
AA
E
3. Place the Fire Bowl (B) into the base assembly.
Then, place the Mesh Cover (A) onto the
Fire Bowl (B).
3
D
A
B
Hardware Used
AA
M6x6mm Bolt x4
Hardware Used
AA
M6x6mm Bolt x4
5
ASSEMBLY INSTRUCTIONS
4. The re pit is ready to use. Keep the Poker (F)
on hand for use as needed.
4
E
F
CARE AND MAINTENANCE
1-YEAR LIMITED FRAME WARRANTY
If within one year from the date of original purchase, this item fails due to a defect in material
or workmanship, we will replace or repair at our option, free of charge. To order parts or to
obtain warranty service, call 1-877-447-4768, Monday - Friday, 8:00 a.m. - 4:30 p.m. CST. This
warranty does not cover defects resulting from improper or abnormal use, misuse, accident,
or alteration. Failure to follow all instructions in the owner's manual will also void this warranty.
The manufacturer will not be liable for incidental or consequential damages, or common
erosion of outdoor products. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you. This warranty gives you
specic legal rights, and you may also have other rights which vary from state to state.
GHP Group Inc., 6440 W. Howard St., Niles, IL, USA 60714-3302, USA
• Allow the re pit to cool completely before moving it.
• To extend the life of your re pit, clean it after each use.
• To protect the re pit nish, use a soft cloth to wipe the re pit and poker.
• Do not attempt to clean while hot.
• Store in a cool, clean, dry place.
• Use gloves in lieu of bare hands while handling.
• Place a storage cover over the re pit once it has cooled.
6
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m.,
CST, Monday – Friday.
Printed in China
PART DESCRIPTION PART #
A Mesh Cover 30-01-294
B Fire Bowl 30-01-295
C Outer Support Ring 30-01-296
D Lower Ring 30-01-297
E Leg 30-01-298
F Poker 40-04-409
N/A Instruction Manual 30-10-195
AA Hardware Pack 30-09-549
A
B
C
D
E
F
AA
