Quick Setup Guide
|
NS-HFMOC101
Flex Mesh Oce Chair
PACKAGE CONTENTS
Before using your new product, please read these instructions to prevent any damage.
ASSEMBLING YOUR CHAIR
Insert the wheels (D) into the star base (C). Keep pushing the wheels in until the metal rims touch the star
base.
Place the seat plate (G) on the seat bottom assembly as shown. Insert four 1/4 × 20 mm screws (H) with
four washers (J) into the seat plate. Tighten them with the Allen wrench. You may need to use the
short side of the wrench to get more leverage.
Place the chair assembly onto the gas lift until it is fully inserted.
Quick Setup Guide
FEATURES
• Adjustable height
• Lockable chair back
Place the star base cover (A) over the star base (C), then insert the gas lift (B) into the star base. Push the
gas lift in so that it is secure.
4
Allen wrench (1)
Screws
1/4 × 20 mm (4)
Screws
1/4 × 40 mm (4)
Washers
φ6 mm (4)
Caps
(4)
Seat plate (1)
Wheels (5)
Back (1)
Arms and seat bottom (1)
Star base (1)Gas lift (1)Star base cover (1)
3
