1
KINGSBURY FIRE PIT
MODEL #OFW062G-M
MENARDS SKU #259-5179
Questions, problems, missing parts? Before returning to your retailer,
call our customer service department at 1-877-447-4768,
8:00 a.m. – 4:30 p.m., CST, Monday-Friday or email us at
30-10-191 05/12/20
2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Mesh Cover 1
B Cooking Grid 1
C Handle 3
D Handle Support 2
E Fire Bowl 1
F Leg 4
G Poker 1
A
B
C
D
E
F
G
3
HARDWARE LIST
Please read and understand this entire manual before attempting to assemble, operate or install
the product. If you have any questions regarding the product, please call customer service at
1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST, Monday – Friday.
WARNINGS:
• DO NOT allow children or pets near the re pit without supervision.
• DO NOT touch surface of re pit while in use.
• FOR OUTDOOR USE ONLY! Burning wood or charcoal indoors can kill you. It gives off carbon
monoxide, which has no odor.
• NEVER burn in vehicles, tents, garages, other enclosed areas or indoors. CARBON MONOXIDE
HAZARD.
• NEVER LEAVE FIRE UNATTENDED!
• NEVER place a storage cover on re pit when in use. Ensure the re pit and mesh cover have
cooled before placing a storage cover over the re pit.
• When the re pit is in use, the handle on the mesh cover can reach extreme temperatures
that can cause serious injury to an unprotected hand. Use a poker when handling.
• DO NOT use under overhead cables or power lines.
CAUTIONS:
• Adequate re extinguishing material should be readily available.
• Always ensure that the mesh cover is secured over re bowl while in use.
• Burn only seasoned hard wood or re logs in the re pit.
• DO NOT attempt to move the re pit while it is hot or in use.
• DO NOT use gasoline or kerosene to start the re in your re pit.
• DO NOT use this outdoor re pit under any overhead or near any unprotected combustible
constructions. Avoid using near or under overhanging trees and shrubs. DO NOT use this unit on
long or dry grass and/or leaves.
• Always use this outdoor re pit on a hard, level, non-combustible surface such as concrete, rock or stone.
An asphalt or blacktop surface may not be acceptable for this purpose. DO NOT use on wooden decks.
• Place the re pit no closer than 10 feet / 3.05 meters from walls or combustibles during use.
• Handles may become hot during and after use.
• Use heat-resistant gloves to handle hot tools.
• Burn only 8.8 lbs/4kg of charcoal, wood or re logs in the re pit.
SAFETY INFORMATION
M6x20mm Bolt
Qty. 12
BB
M6x12mm Bolt
Qty. 6
AA
4
PREPARATION
ASSEMBLY INSTRUCTIONS
1. Insert two M6x12mm bolts (AA) through the
cover (A) and into the handle (C). Tighten with a
Phillips screwdriver.
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents above. If any part is missing or damaged, do not attempt to
assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 20 minutes
Tools Required for Assembly: Phillips Screwdriver (Not Included)
1
A
C
2
E
Hardware Used
BB M6x20mm Bolt x 12
Hardware Used
AA M6x12mm bolt x 2
AA
BB
F
2. Insert three M6x20mm bolts (BB) through the re
bowl (E) and into one of the legs (F). Make sure the
leg is positioned as shown in Step 2. Tighten with a
phillips screwdriver. Repeat this step for the three
remaining legs.
5
6
3. Align a handle (C) with the holes in the re bowl
(E) and the holes in the handle support (D). Insert
two M6x12mm bolts (AA) through the handle
support (D), the re bowl (E) and the handle (C).
Use a Phillips screwdriver to tighten. Repeat on
the opposite side of the re bowl (E).
ASSEMBLY INSTRUCTIONS
6. For cooking grid use, the cooking grid can
be positioned in three different congurations.
Open the door of the mesh cover (A) and insert
the cooking grid (B) into the pre-drilled holes
in the desired position. See boxes 6A, 6B and
6C on the next page for illustrated cooking
grid positions.
D
C
AA
3
E
5. The re pit is ready to use. Keep the poker (G)
near the re pit for use as needed.
4. For re pit use, place the mesh cover (A) on
top of the re bowl (E).
A
B
Hardware Used
AA M6x12mm Bolt x 4
4
A
E
5
G
6
CARE AND MAINTENANCE
1-YEAR LIMITED FRAME WARRANTY
If within one year from the date of original purchase, this item fails due to a defect in material or
workmanship, we will replace or repair at our option, free of charge. To order parts or to obtain
warranty service, call 1-877-447-4768, Monday - Friday, 8:00 a.m. - 4:30 p.m. CST. This warranty
does not cover defects resulting from improper or abnormal use, misuse, accident, or alteration.
Failure to follow all instructions in the owner's manual will also void this warranty. The manufactur-
er will not be liable for incidental or consequential damages, or common erosion of outdoor prod-
ucts. Some states do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation may not apply to you. This warranty gives you specic legal rights, and
you may also have other rights which vary from state to state.
GHP Group Inc., 6440 W. Howard St., Niles, IL, USA 60714-3302, USA
• Allow the re pit to cool completely before moving it.
• To extend the life of your re pit, clean it after each use.
• To protect the re pit nish, use a soft cloth to wipe the re pit and poker.
• Do not attempt to clean while hot.
• Store in a cool, clean, dry place.
• Use gloves in lieu of bare hands while handling.
• Place a storage cover over the re pit once it has cooled.
• Do not douse the ame with water to extinguish. Use sand or dirt to snuff out the re if it cannot
burn out naturally.
• Rust can appear on the inside of your re bowl. Surfaces of the re bowl may need occasional
touch up. We recommend the use of commercially available black high temperature spray paint.
6B 6C6A
ASSEMBLY INSTRUCTIONS
6A. Cooking grid on the left. 6B. Cooking grid in the middle. 6C. Cooking grid on the right.
7
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m.,
CST, Monday – Friday.
Printed in China
PART DESCRIPTION PART #
A Mesh Cover 30-01-269
B Cooking Grid 30-01-270
C Handle 30-01-271
D Handle Support 30-01-272
E1 Fire Bowl 30-01-273
E2 M5 Nut 30-09-143
E3 Adjustable Air Vent 30-01-275
E4 M5x10mm Bolt 30-09-144
F Leg 30-01-274
G Poker 30-01-276
AA - BB Hardware Pack 30-09-547
N/A Instruction Manual 30-10-191
A
B
C
D
E1
F
G
E4
E2
E3
AA
BB
