1
www.napoleon.com
N415-0346-AU FEB 23.21
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
DANGER! CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide, which has no odor. Using it in an
enclosed space can kill you. Never use this appliance in an enclosed space such as a
camper, tent, car or home.
OUTDOOR GAS FIREPLACE
GSS48 / GSS48ST
WARNING!
• Hot glass will cause burns.
• Do not touch glass unl cooled.
• Never allow children to touch glass.
NOTE! LED Light instrucons are located on page 24.
WARNING
Do not try to light this appliance without reading the
“LIGHTING” instrucons secon of this manual.
DO NOT PLACE ARTICLES ON OR AGAINST THIS
APPLIANCE.
DO NOT USE OR STORE FLAMMABLE MATERIALS
NEAR THIS APPLIANCE.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS
APPLIANCE WHILE IT IS IN OPERATION.
An L.P. cylinder not connected for use must not be
stored in the vicinity of this or any other appliance.
If the informaon in these instrucons is not
followed exactly, a re or explosion may result,
causing property damage, personal injury or death.
DANGER
IF YOU SMELL GAS:
• Shut o gas to the appliance.
• Exnguish any open ame.
• If odor connues, keep away from the
appliance and immediately call your gas
supplier or re department.
WARNING! For Outdoor Use Only.
Wolf Steel Ltd.
214 Bayview Drive,
Barrie, Ontario, CANADA L4N 4Y8
!
!
!
2
www.napoleon.com
N415-0346-AU FEB 23.21
Should deterioration of parts occur to the degree of non-performance (rusted
through or burnt through) within the duration of the warranted coverage, a
replacement part will be provided. The replacement component is the sole
responsibility of NAPOLEON defined by this Limited Warranty; in no event will
NAPOLEON be responsible for installation, labor or any other costs or expenses
related to the re-installation of a warranted part, for any incidental,
consequential, or indirect damages or for any transportation charges, labor costs
or export duties.
This Limited Warranty is provided in addition to any rights afforded to you by local
laws. Accordingly, this Limited Warranty imposes no obligation upon NAPOLEON
to keep parts in stock. Based on the availability of parts, NAPOLEON may at its
discretion discharge all obligations by providing a customer a prorated credit
towards a new product. After the first year, with respect to this Limited Warranty
NAPOLEON may, at its discretion, fully discharge all obligations with respect to
this warranty by refunding to the original warranted purchaser the wholesale price
of any warranted but defective part(s).
The bill of sale or copy will be required together with a serial number and a model
number when making any warranty claims from NAPOLEON.
NAPOLEON reserves the right to have its representative inspect any product or part
prior to honoring any warranty claim. You must contact NAPOLEON Customer Service
or an authorized NAPOLEON dealer to obtain the benefit of the warranty coverage.
www.napoleon.com
NNaappoolleeoonn PPrreessiiddeenntt’’ss 33 YYeeaarr LLiimmiitteedd WWaarrrraannttyy
NAPOLEON products are designed with superior components and materials, and are assembled by trained
craftsmen who take great pride in their work. This product has been thoroughly inspected by a qualified
technician before packaging and shipping to ensure that you, the customer, receive the quality product you
expect from NAPOLEON.
NAPOLEON warrants that components in your new NAPOLEON product will be free from defects in material and
workmanship from the date of purchase, for the following period:
* Conditions and Limitations
This Limited Warranty creates a warranty period as specified in the
aforementioned table, for any product purchased through an authorized NAPOLEON
dealer, and entitles the original purchaser to the specified coverage in respect of
any component replaced within the warranty period, either by NAPOLEON or an
authorized NAPOLEON dealer, to replace a component of such product that has
failed in normal private use as a result of a manufacturing defect. The “50% off”
indicated in the table means the component is made available to the purchaser at
a 50% discount off the regular retail price of the component for the period
indicated. This Limited Warranty does not cover accessories or bonus items.
For greater certainty, “normal private use” of a product means that the product:
has been installed by a licensed, authorized service technician or contractor, in
accordance with the installation instructions included with the product and all
local and national building and fire codes; has been properly maintained; and has
not been used as a communal amenity or in a commercial application.
Similarly, “failure” does not include: over-firing, blow outs caused by
environmental conditions such as strong winds or inadequate ventilation,
scratches, dents, corrosion, deterioration of painted and plated finishes,
discoloration caused by heat, abrasive or chemical cleaners or UV exposure,
chipping of porcelain enameled parts, or damages caused by misuse, accident,
hail, grease fires, lack of maintenance, hostile environments such as salt or
chlorine, alterations, abuse, neglect or parts installed from other manufacturers.
Aluminum table top and pedestal ...................................................... 3 years
Stainless steel housing ......................................................................3 years
Stainless steel burner assembly ........................................................ 3 years
All other parts .................................................................................... 2 years
3
www.napoleon.com
N415-0346-AU FEB 23.21
WARNING! For Outdoor Use Only.
WARNING! Improper installaon, adjustment, alteraon, service or maintenance can cause injury
or property damage. Read the installaon, operang and maintenance instrucons thoroughly before
installing or servicing this gas appliance.
Safe Operang Pracces
• This appliance is hot when operang and can cause severe burns if contacted.
• This appliance is to be protected from rain.
• Installaon and repair should be done by a qualied service person. The appliance should be inspect-
ed before use and at least annually by a qualied service person. More frequent cleaning may be
required as necessary. It is imperave the control compartment, burners and circulang air passage-
ways of the appliance be kept clean.
• Do not operate appliance before reading and understanding operang instrucons. Failure to operate
appliance according to operang instrucons could cause re or injury.
• Risk of burns. The appliance should be turned o and cooled before servicing.
• Do not install damaged, incomplete or substute components.
• Young children should be carefully supervised when they are in the area of the appliance. Toddlers,
young children and others may be suscepble to accidental contact burns. A physical barrier is recom-
mended if there are at risk individuals in the vicinity. To restrict access to an appliance or stove, install
an adjustable safety gate to keep toddlers, young children and other at risk individuals out of the
vicinity and away from hot surfaces.
• Ensure you have incorporated adequate safety measures to protect infants/toddlers from touching
hot surfaces.
• Under no circumstances should this appliance be modied.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As
with all plasc bags, these are not toys and should be kept away from children and infants.
• Do not leave appliance unaended when in use.
• For outdoor use only.
• This appliance must not be used for cooking.
• This unit is not for use with solid fuel.
• Improper installaon, adjustment, alteraon, service, or maintenance can cause injury or property
damage. Read the installaon, operang and maintenance instrucons thoroughly before installing or
servicing this equipment.
• This appliance shall be used only outdoors in a well-venlated space and shall not be used inside a
building, garage, or any other enclosed area.
• Cylinders must be stored outdoors in a well-venlated area out of reach of children. Disconnected
cylinders must have threaded valve plugs ghtly installed and must not be stored in a building, garage
or any other enclosed area.
• If it is evident there is excessive abrasion or wear, or the hose is cut, it must be replaced prior to the
appliance being put into operaon.
• Clothing or other ammable materials should not be hung from the appliance or placed on or near
the appliance.
• Any guard or other protecve device removed for servicing the appliance must be replaced prior to
operang the appliance.
• Inspect the fuel supply connecon for signs of leakage (including the hose for lp models) before each
use of the appliance.
• The lp gas cylinder supply system must be arranged for vapor withdrawal.
• To extend the life of your appliance, protect and cover it from the elements when not in use.
• Not suitable for installaon in a marine vessel or recreaonal vehicle.
• Remove all transit protecon before installaon.
• Certain materials or items, when stored under or near the appliance, will be subjected to radiant heat
and could be seriously damaged.
• Note: not intended for replace insert.
• The glass guard is ed to this appliance to reduce the risk of re or injury from burns and no part of
it should be permanently removed. For protecon of young children or the inrm, a secondary guard
is required.
• Do not modify this appliance.
• Primarily a decorave appliance - not cered as a space heater.
!
4
www.napoleon.com
N415-0346-AU FEB 23.21
Geng Started
1. Remove all of the parts from the carton. Use the parts list to ensure all necessary parts are included.
2. Do not destroy packaging unl the appliance has been installed and operates to your sasfacon.
3. Choose a locaon that meets the clearance to combusbles as outlined in this manual. Take into consideraon
the need for clear and easy access to the on/o valve AFTER the appliance is installed and connected to the gas
supply in order to safely turn o the burner.
4. Most stainless steel parts are supplied with a protecve plasc coang that must be removed prior to using the
appliance. The protecve coang has been removed from some of the parts during the manufacturing process
and may have le behind a residue that can be perceived as scratches or blemishes. To remove the residue,
vigorously wipe the stainless steel in the same direcon as the grain.
5. Read and follow all instrucons in this manual before installing or servicing this gas appliance.
If you have any quesons about assembly or appliance operaon, or if there are damaged or missing parts please
call our Customer Soluons Department at 1-866-820-8686 between 9 AM and 5 PM (Eastern Standard Time).
WARNING! This appliance is designed for non-combusble enclosures only, and must be installed
and serviced by a qualied installer to local codes.
CAUTION! During unpacking and assembly we recommended you wear work gloves and safety
glasses for your protecon. Although we make every eort to make the assembly process as problem
free and safe as possible, it is characterisc of fabricated steel parts that the edges and corners might be
sharp and could cause cuts if handled incorrectly.
General Informaon
This appliance shall be installed by authorised persons only and in accordance with these installaon
instrucons, AS5601.1, local gas ng regulaons, municipal building codes, electrical wiring regulaons,
local water supply regulaons and any other statutory regulaons.
The appliance and its individual shut o valve must be disconnected from the gas supply piping system
during any pressure tesng of the system at test pressures in excess of 1/2 psig (3.5kPa).
This appliance must be isolated from the gas supply piping system by closing its individual manual shut
o valve during any pressure tesng of the gas supply piping system at test pressures equal to or less
than 1/2 psig (3.5kPa).
• Always keep the appliance area clear and free from combusble materials, gasoline, and other
ammable vapours and liquids.
• Do not locate appliance where it can get excessively wet.
• Do not use this appliance if any part has been under water. Immediately call a qualied service
technician to inspect the unit and to replace any part of the control system and any gas control, which
has been underwater.
INPUT
MODEL FUEL ORIFICE SIZE MAX. INPUT MJ/Hr TEST POINT GAS PRESSURE
GSS48 Natural Gas #25 (3.8mm) 55 1.0 kPa
GSS48 Propane Gas #43 (2.26mm) 65 2.75 kPa
!
!
5
www.napoleon.com
N415-0346-AU FEB 23.21
Dimensions
TOP VIEW
(without trim)
17 5/16”
(440mm)
19 9/32”
(490mm)
TOP VIEW
(with trim)
17 5/16”
(440mm)
20” to 22 1/2”
(508mm to 572mm)
1 1/2” to 4”
(38mm to 102mm)
GSS48
FRONT VIEW
(without trim)
50 1/2”
(1283mm)
47 1/2”
(1207mm)
16 1/2”
(419mm)
24 1/2”
(622mm)
3 1/2”
(89mm)
1/8” Edge Thickness
(3mm)
Nailing Tab
FRONT VIEW
(with trim)
52 7/16”
(1332mm)
46 7/16”
(1180mm)
16 1/2”
(419mm)
25 1/2”
(648mm)
21 7/16”
(545 mm)
6
www.napoleon.com
N415-0346-AU FEB 23.21
Dimensions
GSS48ST
FRONT VIEW
(without trim)
50 1/2”
(1283mm)
47 1/2”
(1207mm)
16 1/2”
(419mm)
24 1/2”
(622mm)
3 1/2”
(89mm)
1/8” Edge Thickness
(3mm)
Nailing Tab
FRONT VIEW
(with trim)
52 7/16”
(1332mm)
46 7/16”
(1180mm)
16 1/2”
(419mm)
25 1/2”
(648mm)
21 7/16”
(545 mm)
TOP VIEW
(with trim)
1 1/2” to 4”
(38mm to 102mm)
1 1/2” to 4”
(38mm to 102mm)
21 1/8”
(537 mm)
25 1/8” to 30 1/8”
(638 mm to 765 mm)
TOP VIEW
(without trim)
21 1/8”
(537mm)
24”
(610mm)
7
www.napoleon.com
N415-0346-AU FEB 23.21
Locaon
This appliance should be covered or protected in wet weather. Not suitable for use in wet or windy
weather.
Locang Your Outdoor Appliance
It is important when selecng a locaon for your appliance to ensure clearances to adjacent combusbles
are met. This appliance is intended for installaon on an outdoor pao or in your yard. It is highly
recommended that this appliance be installed in a sheltered area (following the guidelines outlined
below). Direct wind will cause an errac ame and possible burner outage. An errac ame could also
lead to excessive carboning (black soot), this condion is not a safety issue but is visually undesirable.
Note: When choosing a locaon for your appliance, care must be taken to avoid areas where excessive
moisture or running water may be a problem.
This appliance shall only be used in an above ground open-air situaon with natural venlaon, without
stagnant areas, where gas leakage and products of combuson are rapidly dispersed by wind and natural
convecon.
Any enclosure in which the appliance is used shall comply with one of the following:
An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead
cover.
Within a paral enclosure that includes an overhead cover and no more than two walls.
Within a paral enclosure that includes an overhead cover and more than two walls, the following shall
apply:
• at least 25% of the total wall area is completely open, and
• at least 30% of the remaining wall area is open and unrestricted.
In the case of balconies, at least 20% of the total wall area shall be and remain open and unrestricted.
8
www.napoleon.com
N415-0346-AU FEB 23.21
Framing
FRONT VIEW
REAR VIEW
2 X 4 STEEL STUDS
2 X 6 STEEL STUD
24 3/4” (629mm)
Including 1/8”
(3mm) clearance
per side.
6”
(152mm)
minimum
to oor
6”
(152mm)
minimum
6”
(152mm)
minimum
1/2” (13 mm) CEMENT BOARD
50 3/4” (1289mm)
(Including 1/8” (3mm)
clearance per side)
2 X 4 STEEL STUDS
2 X 6 STEEL STUD
18 7/16”
(468mm)
18 7/16”
(468mm)
6”
(152mm)
minimum
1/2” (13 mm) CEMENT BOARD
36” (914 mm) minimum to
combusble ceiling. If no ceiling
is present the wall may end
directly above the unit and must
be nished with non combusble
material.
NOTE! Minimum clearance to the ceiling does not apply when the
unit is installed with no over head construcon.
!
9
www.napoleon.com
N415-0346-AU FEB 23.21
Installaon
Clearance to Combusbles
WARNING! Minimum clearance to combusbles must be maintained or a serious re hazard could
result.
Minimum Clearance To Combustibles
Clearance Dimension
A From Ground or other surface 6” (152mm)
B From Sides 6” (152mm)
C From Ceiling 36” (915mm)
D Alcove Width 60” (1524mm) Minimum
E Alcove Depth 24” (610mm) Maximum
A
B
C
D
E
TO BE INSTALLED ONLY BY AN AUTHORIZED PERSON. THIS APPLIANCE SHALL NOT BE
INSTALLED OR USED INDOORS.
Nailing Tabs
To install the appliance face ush with the nished surface, posion the framework to accommodate the
thickness of the nished surface. Screw the nailing tabs to either side of the appliance and secure to the
2 x 4 steel framing. The tabs will facilitate the installaon of either a 1/2”(13mm) or 3/4”(19mm) nished
surface thickness.
!
10
www.napoleon.com
N415-0346-AU FEB 23.21
Minimum Enclosure Clearances
WARNING! Use only non-combusble materials (cered to ASTM E-136) such as steel studs,
cement board, ceramic le, marble, paint etc. When adding nishing materials to the appliance. Do
not use wood or drywall.
WARNING! You must have clear and easy access to the on/o valve AFTER the appliance is installed
and connected to the gas supply in order to safely turn o the burner.
GSS48 (ONE SIDED)
6” (152mm)
(Minimum
clearance to
combusbles)
1 1/2”
(38mm)
All material in shaded
area must be Non
Combusble. (including
framing, sheeng and
nishing materials).
Cered to ASTM E-136
NON COMBUSTIBLE
36”
(914mm)
minimum
to ceiling.
6”
(152mm)
minimum to
oor
1/2”(13mm)
Cement Board
6”(152mm)
Steel Stud
NOTE! Ensure top of cabinet is closed to
prevent rain and debris from falling on top of
the appliance.
6”
(152mm)
Nailing Tabs (4 per side)
50 3/4” (1289mm)
(Including 1/8” (3mm)
clearance per side)
Gas and electrical lines protude from the
boom of the appliance located on the
right side.
NON COMBUSTIBLE
All material in shaded
area must be Non
Combusble. (including
framing, sheeng and
nishing materials).
Cered to ASTM E-136
36”
(914mm)
minimum
to ceiling.
24 3/4” (629mm)
Including 1/8”
(3mm) clearance
per side.
60 3/4”
(1543mm)
minimum
to ceiling.
6”
(152mm)
6”
(152mm)
6”
(152mm)
minimum to
oor
!
!
11
www.napoleon.com
N415-0346-AU FEB 23.21
6”
(152mm)
Nailing Tabs (4 per side)
50 3/4” (1289mm)
(Including 1/8” (3mm)
clearance per side)
Gas and electrical lines protude from the
boom of the appliance located on the
right side.
NON COMBUSTIBLE
All material in shaded
area must be Non
Combusble. (including
framing, sheeng and
nishing materials).
Cered to ASTM E-136
36”
(914mm)
minimum
to ceiling.
24 3/4” (629mm)
Including 1/8”
(3mm) clearance
per side.
60 3/4”
(1543mm)
minimum
to ceiling.
6”
(152mm)
6”
(152mm)
6”
(152mm)
minimum to
oor
Minimum Enclosure Clearances
WARNING! Use only non-combusble materials (cered to ASTM E-136) such as steel studs,
cement board, ceramic le, marble, paint etc. When adding nishing materials to the appliance. Do
not use wood or drywall.
WARNING! You must have clear and easy access to the on/o valve AFTER the appliance is installed
and connected to the gas supply in order to safely turn o the burner.
GSS48ST (SEE THROUGH)
NOTE! Ensure top of cabinet is closed to
prevent rain and debris from falling on top of
the appliance.
21” (533mm) to
outside of steel
studs.
Trim depth can be
altered depending on
nishing material.
All material in shaded area must
be Non Combusble. (including
framing, sheeng and nishing
materials). Cered to ASTM E-136
NON COMBUSTIBLE
36”
(914mm)
minimum
to ceiling.
6”
(152mm)
minimum to
oor
!
!
12
www.napoleon.com
N415-0346-AU FEB 23.21
Minimum Mantel Clearances
WARNING! Mantel temperatures will rise above normal temperatures and may be hot to the
touch.
We recommend that all mantels are made from non-combusble material. If using combusble materials,
follow the chart below.
Note: When using paint or lacquer to nish the mantel, the paint or lacquer must be heat resistant to
prevent discolouraon.
GSS48 / GSS48ST
8” (203mm) Mantle
6”(152mm)
4”(102mm)
2”(51mm)
Top of Fireplace
24”
(610mm)
26”
(660mm)
22”
(559mm)
20”
(508mm)
23”
(584mm)
6”(152mm)
All material in shaded
area must be Non
Combusble. (including
framing, sheeng and
nishing materials).
NON COMBUSTIBLE
Drain Installaon (Recommended)
Although this replace is designed to operate outdoors safely, rain and other sources of moisture may
enter the replace area, which will cause water to collect inside the base of the unit within the replace
enclosure. When choosing a locaon for your replace, care must be taken to avoid areas where excessive
moisture or running water may be a problem.
To prevent moisture or water from collecng underneath the replace, the builder must provide a means
to drain water from under the replace, before posioning the replace in its locaon. It is recommended
that a sealed corrosion resistant drain pan with provisions for drainage be posioned underneath
the replace. The drain pan can be constructed from corrosion resistant metal, or other suitable
materials such as an ice and water shield membrane. A means of drainage out of the drain pan such as
piping or weep holes must also be provided. A slope of 1/4” (6mm) per foot towards the drain port is
recommended.
Note: When planning for the installaon of the replace the framing height must be increased to
accommodate a drain pan and any addional drainage piping required.
Note: The replace must be installed on a level surface to ensure proper drainage.
13
www.napoleon.com
N415-0346-AU FEB 23.21
Trim Installaon (Oponal)
NOTE! Most stainless steel parts are supplied with a protecve plasc coang that must be removed
prior to using the appliance.
The trim is designed to work with facing material that protrude between 1 1/2” (38mm) to 4” (102mm)
from the front of the appliance.
Trim Assembly
Front of Unit
Finishing Material
1 1/2” (38mm) Minimum
4” (102mm) Maximum
Finishing Material
1 1/2” (38mm) Minimum
4” (102mm) Maximum
Front of Unit
Trim Assembly
GSS48
GSS48ST
SIDE VIEW
FRONT VIEW
WARNING! When installing the oponal trim kit the installer must leave 5/8” (16mm) gap in
cement board and nnishing materials on both sides to allow access to slots for frame.
Trim Assembly
Serrated
Side Up
Serrated
Side Up
Serrated
Side Up
!
!
14
www.napoleon.com
N415-0346-AU FEB 23.21
CAUTION! Assemble the trim pieces on a clean, non-abrasive surface to avoid damaging the
stainless steel nish.
1. Peel protecve coang from front trim pieces.
2. Assemble the trim pieces using (8) #8-32 x 3/8” screws as illustrated.
3. Open the front access door on the appliance and loosen the thumb screws (do not remove). Li up
on the thumb screws and ghten in posion at top of slot.
Tighten in
posion at
top of slot.
Serrated
Side Up
!
15
www.napoleon.com
N415-0346-AU FEB 23.21
4. Line up the brackets on the trim with the slots on the side of the base and insert as illustrated pushing
unl trim sits ush against front surface. The brackets have been designed with mulple slots (1/4” (6mm)
increments to accommodate dierent nishing materials.
5. Loosen the thumb screw and lower unl it stops. Reghten thumb screw, and close the access door.
Tighten in posion.
Serrated Side Up
NOTE! If using facing
materials in excess of
2.5” (63.5mm) a gap
will be visible between
the brick ledge and the
trim.
!
16
www.napoleon.com
N415-0346-AU FEB 23.21
Natural Gas Hook-Up
The gas appliance is designed to operate with natural gas or propane gas. The piping up to the appliance
is the responsibility of the installer. A exible metal connector of 1/2 inch male is included to simplify the
installaon of the appliance. Ensure that the exible connector is protected from damage. The gas supply
pipe must be suciently sized to supply the MJ/h specied on the rang plate, based on the length of
the piping run.
The Natural Gas regulator supplied with the appliance must be connected to the gas connecon inlet.
Purge the gas supply line of any trapped air prior to the rst ring of the appliance.
WARNING!
• Risk of re, explosion or asphyxiaon, ensure there are no ignion sources such as sparks or open
ames.
• The installaon must be performed by a licensed gas er, and all connecons must be leak tested
before operang the appliance.
• The gas er must test the operaon of the appliance before leaving.
• All gas connecons must be contained within the appliance when complete.
• High pressure will damage the valve, disconnect gas supply piping before tesng gas line at test
pressures above 1/2 psig.
• Leak test all the connecons by brushing on a soap and water soluon. These connecons can be
accessed by removing the burner. (See burner removal instrucons.)
NG REGULATOR 1.00 kPa
Gas Hook-Up Instrucons
GAS CONNECTION
!
17
www.napoleon.com
N415-0346-AU FEB 23.21
Conversion to LP (Propane) Gas
WARNING! To avoid the possibility of burns conversions should only be done when the appliance
is cool. Ensure the burner is turned o. Turn the gas o at source and disconnect the appliance before
beginning conversion.
WARNING! Glass embers may have sharp edges wear safety glasses and gloves when handling.
WARNING! This conversion must be performed by a licensed gas er, and all connecons must
be leak tested before operang the appliance.
Your replace can be easily converted to LP (Propane) Gas by following these steps:
1. Remove the glass embers from the tray.
2. Remove the glass tray from the replace by removing the (8) screws that hold the tray in place.
3. Carefully li the glass tray from the replace and set aside. Take care not to damage or kink the
thermocouple wire.
4. Disconnect the stainless steel ex connector from the orice using (2) wrenches.
5. Unscrew the natural gas orice from the inside of the burner as illustrated.
6. Replace the natural gas orice with the LP (Propane) orice supplied.
Note: The air shuer has been factory set closed for Natural Gas and must be adjusted to full open for
propane.
!
!
18
www.napoleon.com
N415-0346-AU FEB 23.21
7. Reconnect the stainless steel ex connector to the orice and ghten using (2) wrenches.
8. Place the glass tray over the burner and fasten to the repace with the screws removed in step 2.
9. Remove the NG regulator (if ed). Connect the test point to the inlet ng.
10. Fill out the conversion label included with your replace and apply it to the inside of the control panel
access door.
11. A leak test must be performed according to the leak tesng instrucons found in the manual.
WARNING! If these instrucons are not followed exactly, a re causing death or serious injury
may occur.
Connecon to Propane Gas Supply
This replace may be connected to Propane in accordance with AS5601.1.
The following secon incorporates guidelines for Propane supply via LPG cylinder.
Enclosures For LP (Propane) Gas Supply Systems
If you build an enclosure for an LP gas cylinder, follow these recommended specicaons. You must also
follow local codes.
An enclosure for an LP-gas cylinder shall be venlated by openings at both the upper and lower levels of
the enclosure.
This shall be accomplished by one of the following:
One side of the enclosure shall be completely open;
OR
For an enclosure having four sides, a top, and a boom:
a) At least two venlaon openings shall be provided in the sidewall of the enclosure. The upper opening
shall be located within 5 in (127 mm) of the top of the enclosure. The lower opening shall be provided at
oor level of the enclosure.
b) The boom of the lower opening shall be 1 in (25.4 mm) or less from the oor level and the upper edge
no more than 5 in (127 mm) above the oor level.
c) Every opening shall have minimum dimensions so as to permit the entrance of a 1/8 inch (3.2mm)
diameter rod.
d) The boom of the low level (set of) opening(s) shall be at the enclosure base with the upper edge no
more than 125mm above the base.
PRESSURE TEST POINT FITTING
!
19
www.napoleon.com
N415-0346-AU FEB 23.21
Venlaon openings in sidewalls shall not communicate directly with other enclosures of the appliance.
Cylinder valves shall be readily accessible for hand operaon. A door on the enclosure to gain access to
the cylinder valve is acceptable, provided it is non-locking and can be opened without the use of tools.
Designs using a cover to gain access to the cylinder and cylinder valve shall be provided with handles or
equivalent at a minimum of 180 degrees apart to facilitate liing of the cover.
There shall be a minimum clearance of 2 inches (50.8mm) between the lower surface of the oor of the LP
gas supply cylinder enclosure and the ground.
The design of the enclosure shall be such that (1) the LP gas supply cylinder(s) can be connected,
disconnected and the connecons inspected and tested outside the cylinder enclosure; and (2) those
connecons which could be disturbed when installing the cylinder(s) in the enclosure can be leak tested
inside the enclosure.
The enclosure for the LP-gas cylinder shall isolate the cylinder from the burner compartment to provide:
a. Shielding from radiaon;
b. A ame barrier; and
c. Protecon from foreign material.
Be certain to mount or set the LP gas cylinder on a at surface and restrain it using a cylinder retaining
bracket to prevent it from pping.
The LPG supply must incorporate an approved pressure regulator with 2.75kPa outlet pressure.
5” (127mm)
MAXIMUM
1” (25.4mm)
MAXIMUM
OPENING
A
OPENING
B
2” (51mm)
MINIMUM
PARTITION TO ISOLATE CYLINDER
FROM APPLIANCE
34” (864mm)
RECOMMENDED
5” (127mm)
MAXIMUM
NON LOCKING DOOR
Propane Enclosure
CYLINDER SIZE OPENING A AREA OPENING B AREA
9kg
100cm
2
60cm
2
20
www.napoleon.com
N415-0346-AU FEB 23.21
Cylinder Retaining Bracket
1. Fasten the bracket to the boom of the propane bole using bolt and nut supplied.
2. Tighten the lag screw into the mounng surface leaving
approximately 1/4” (6mm) of thread above the surface.
3. Slide propane bole into posion so that the bracket slides
under the head of the lag screw.
4. Tighten the lag screw onto the bracket.
5. For fastening to a concrete surface a concrete anchor will be
required. (Not supplied)
LP (Propane) Gas Cylinder Mounng
To Prevent the LP-gas cylinder from pping over, ensure the cylinder support ring is on a level surface.
Place the cylinder into the support ring and ghten the thumb screw to secure.
Cylinder Connecon: Ensure the gas regulator hose is
kink free. Remove the cap or plug from the cylinder fuel
valve. Insert the POL regulator nipple onto the Cylinder
valve. Tighten an-clockwise. Leak test all joints prior
to using the appliance. A leak test must be performed
annually and each me a cylinder is hooked up or if a part
of the gas system is replaced.
If this appliance is to be connected directly to a house
propane gas supply line, ensure a 2.75kPa regulator is
incorporated into the gas system.
CAUTION!
• Make sure cylinder valve is in its full o posion.
• Check cylinder valve features to ensure it has proper
external mang threads.
• Inspect hose thoroughly for damage. Never aempt to use damaged or plugged equipment. See
your local LP Gas Dealer for repairs.
• Locate the hose out of pathways where people may trip over it or in areas where the hose may be
subject to accidental damage.
• Open cylinder valve fully (counter-clockwise). Turn the on/o valve at the unit slowly to the on
posion and use a soapy water soluon to check all connecons for leaks as indicated in the
diagrams before aempng to light the appliance. If a leak is found, turn tank valve o and do not
use the appliance unl repairs can be made.
WARNING! A re will result if the gas supply hose makes contact with the underside of the
appliance.
!
!
21
www.napoleon.com
N415-0346-AU FEB 23.21
Finishing
ENSURE NO GLASS IS PLACED ON THE IGNITION PORTION OF THE BURNER,
DIFFICULTIES IN LIGHTING MAY RESULT.
Glass Ember Installaon
WARNING! Do not use the appliance without the glass embers in place.
WARNING! Glass embers may have sharp edges, wear safety glasses and gloves when handling.
Do not change or substute the glass ember material provided with this appliance. If replacing, use
only replacement glass embers available from your local authorized dealer / distributor.
WARNING! Glass embers may have a ne oil residue that needs to be cleaned prior to installaon.
Clean the glass with mild dish soap, drain, rinse thoroughly and dry before installing.
1. Carefully pour the glass embers onto the appliance ember tray as shown.
2. Spread the glass embers over the tray and burner. The distribuon of clear glass over the burner will
inuence ame height.
3. The glass embers must cover the mesh area of the burner tray while ensuring no glass is placed on
the ignion poron of the burner as illustrated below.
ENSURE NO ROCK IS PLACED ON THE IGNITION PORTION OF THE BURNER,
DIFFICULTIES IN LIGHTING MAY RESULT.
MEK Rock Installaon (Oponal)
WARNING! Real rocks must not be used in this appliance. Heat will cause them to explode.
Place the refactory rocks on top of the glass ember bed and around the burner tray as desired, making
sure not to cover any burner ports or the ignion poron of the burner.
!
!
22
www.napoleon.com
N415-0346-AU FEB 23.21
Dl45 driwood log set installaon (oponal)
WARNING! Discard the bag of sand included with this kit. It cannot be used with the gss48.
WARNING! Failure to posion the logs in accordance with these diagrams or failure to use only
logs specically approved with this appliance may result in property damage or personal injury.
WARNING! Logs must be placed in their exact locaon in the appliance. Do not modify the proper
log posions, since appliance may not funcon properly, and delayed ignion may occur.
WARNING! The logs are fragile and should be handled with care.
NOTE! Log colors may vary. during the inial use of the appliance, the colors will become more
uniform as color pigments burn in during the heat acvated curing process. Place the logs on top of
the glass ember bed and around the burner tray as shown, making sure not to cover any burner ports
or the ignion poron of the burner.
Complete Layout of Log Set
Step by Step Guide
• Install the glass embers as described in the previous secon.
• Place the logs as shown in the following gures and refer to the diagram above for the idencaon
number of each log.
FIG 1.
1
2
3
4
5
8
DO NOT COVER
!
!
23
www.napoleon.com
N415-0346-AU FEB 23.21
FIG 2.
FIG 3.
FIG 4.
24
www.napoleon.com
N415-0346-AU FEB 23.21
FIG 5.
FIG 6.
FIG 7.
25
www.napoleon.com
N415-0346-AU FEB 23.21
Lighng Instrucons
Open Cover
Lights Burner Control
Igniter
WARNING! Keep face and body away from burner area when lighng.
WARNING! Ensure burner controls are in the o posion. Slowly turn on the gas supply valve.
1. Press and hold electronic igniter buon ( ).
2. Turn the burner control to the high posion, press and hold in. When the burner
lights, release the electronic igniter buon.
3. Connue to depress the burner control knob for 30 seconds and then release. If
the ame goes out, repeat the procedure.
4. If the burner will not light with the electronic igniter, hold a lit long match or lit
long butane lighter to the ignion area of the burner and connue with step 2.
5. To shut down the burner turn the burner control knob clockwise to the o
posion. Then turn the gas o at the source (propane cylinder valve or natural gas
shut o valve).
WARNING! If the burner does not light within 10 seconds, turn the valve o and wait 5 minutes
for any gas to dissipate before repeang the procedure.
If lighng the unit with a match, clip the match into the supplied lighng rod.
!
!
26
www.napoleon.com
N415-0346-AU FEB 23.21
WARNING!
• Children and adults should be alerted to the hazards of high surface temperatures and should stay
away from the appliance to avoid burns or clothing ignion.
• Children should be carefully supervised when they are in the area of the appliance.
• Clothing or other ammable materials should not be hung from the appliance, or placed on or near
the appliance. The area above the enclosure may be extremely hot. Direct contact with these
surfaces should be avoided in order to prevent burns or clothing ignion.
• THE GUARD IS FITTED TO THIS APPLIANCE TO REDUCE THE RISK OF FIRE OR INJURY FROM BURNS
AND NO PART OF IT SHOULD BE REMOVED.
• Installaon and repair should be done by a qualied service person. The appliance should be
inspected before each use and at least annually by a qualied service person. More frequent
cleaning may be required as necessary. It is imperave that the control compartment, burners and
circulang air passageways of the appliance be kept clean.
WARNING!
• Never use the appliance while it is raining.
• Always turn the appliance o when raining.
• Never splash any liquid on the glass / glass embers when the appliance is operang.
• The glass / glass embers will be extremely hot while operang, never try to touch them.
• Always ensure the appliance stands rmly on level ground.
• Never use the appliance if the burner is damaged. Inspect the burner before each use. Ensure that
no debris such as leaves; grass or other objects have entered or are on the appliance. If the burner
is damaged it must be replaced prior to using the appliance with a replacement burner specied by
your Napoleon dealer.
• Inspect the hose assembly before each use. If there is evidence of excessive abrasion or wear, or
if the hose is damaged it must be replaced prior to using the appliance with a replacement hose
assembly specied by your Napoleon dealer.
NOTE! The appliance has been designed with several safety features, which include a safety valve.
If the burner ame is exnguished the appliance will automacally shut down.
WARNING! Any modicaon to the appliance may compromise the safety of this appliance.
Special concern is as follows.
• Do not bypass thermocouple safety.
• Do not operate the appliance if any part has been under water. Immediately call a qualied
service technician to inspect the appliance and replace any part of the control system and any gas
control, which has been underwater.
Operaon
Inial Lighng: When lit for the rst me, the appliance emits a slight odor. This is a normal temporary
condion caused by the “burn-in” of internal paints and lubricants used in the manufacturing process and
does not occur again. Simply run the main burner on high for approximately one-half hour.
WARNING! You must have clear and easy access to the on/o valve AFTER the appliance is installed
and connected to the gas supply in order to safely turn o the burner.
WARNING! Never use this appliance for other than the intended use. Do not use this appliance
to prepare food.
!
!
!
!
!
!
27
www.napoleon.com
N415-0346-AU FEB 23.21
LED Lights: Your appliance has been equipped with a LED (light) strip which is programmed with three
colour modes. Plug the LED power supply into a GFI protected electrical outlet.
Turn on the light switch located under the access panel and toggle the switch o and on to cycle through
to desired Mode.
Mode 1 - Simulated White.
Mode 2 - Connuous 2 colour shi. Takes 8-10 seconds to smoothly ramp up one colour to 100%, as the
other fades o from 100% to 0. Connually shis in colour (17 seconds per colour, up and back down.)
Mode 3 - Freeze Mode Colour stops the colour shi on whichever colour it was on in Mode 2 at the me it
was turned o, does not connue to shi.
NOTE! Switch o for 10 seconds to reset to beginning colour mode.
WARNING! Glass embers may have sharp edges, wear safety glasses and gloves when handling.
Do not change or substute the glass ember material provided with this appliance. If replacing, use
only replacement glass embers available from your local authorized dealer / distributor.
WARNING! To avoid the possibility of burns, maintenance should be done only when the
appliance is cool. Avoid unprotected contact with hot surfaces. Ensure burner is turned o. Turn gas o
at source and disconnect the appliance before servicing. Clean the appliance in an area where cleaning
soluons will not harm decks, lawns, or paos. Do not use ammable, corrosive or abrasive cleaners.
Maintenance / Cleaning Instrucons
WARNING! Hose: Check for abrasions, melng, cuts, and cracks in the hose. If any of these
condions exist, do not use the appliance. Have the part replaced by your Napoleon dealer or qualied
gas installer.
Cleaning Inside The Appliance: While washing your appliance, be sure to keep the area around the
burner and pilot assembly dry at all mes.
WARNING! If the gas control is exposed to water in any way, DO NOT try to use the appliance.
The gas control must be replaced.
AC Connector
AC
Transformer
240V AC 12 vAC
Threaded
Power
Connector
FLAG
CONNECTORS
Digital Control Unit for
LED Colour switching
MD6
Connector
MD6
Connector
Strip Light
Strip Light
Note: Stainless steel tends to oxidize or stain in the presence of chlorides and suldes, parcularly in
coastal areas and other harsh environments, such as the warm, highly humid atmosphere around pools
and hot tubs. These stains could be perceived as rust, but can be easily removed or prevented. To provide
stain prevenon and removal, wash all stainless steel and chrome surfaces every 3-4 weeks or as oen as
required with fresh water and/or stainless steel cleaner.
Control Panel: The control panel text is printed directly on the stainless steel and with proper mainte-
nance will remain dark and legible. To clean the panel, use only warm soapy water. Never apply abrasive
cleaners on any stainless surfaces, especially the printed poron of the control panel or the prinng will
gradually rub o.
!
!
!
!
28
www.napoleon.com
N415-0346-AU FEB 23.21
Burner: The burner is made from heavy wall 304 stainless steel, but extreme heat and a corrosive
environment can cause surface corrosion to occur. This can be removed with a brass wire brush. Inspect
the burner at least annually for cracks, insect nests, excessive corrosion or any other damage. If the
burner is damaged, it must be replaced with a burner specied by the manufacturer before the appliance
is put into operaon.
CAUTION! Beware of Spiders.
Spiders and insects are aracted to the smell of propane and natural gas. The burner is equipped with an
insect screen on the air shuer, which reduces the likelihood of insects building nests inside the burner
but does not enrely eliminate the problem. A nest or web can cause the burner to burn with a so
yellow or orange ame or cause a re (ashback) at the air shuer underneath the control panel. Other
warning signs that may indicate a problem are:
• Strong or unusual odor coming from the appliance.
• Connued diculty or delayed ignion.
• Flame appears either very short or very long.
• Flame only burns part way across the burner.
• Excessive soot building up on the glass embers.
To clean the inside of the burner, it must be removed from the appliance: Remove the front glass shield
and the glass embers and examine the burner. If dirty, clean with a wire brush. Remove the screws that
aach the glass ember tray and the wind shield.
Cleaning: Use a exible venturi tube brush to clean the inside of the burner. Shake any loose debris from
the burner through the gas inlet. Check the burner ports and valve orices for blockages. Burner ports can
close over me due to debris and corrosion, use an opened paperclip or a drill bit to clean them The ports
are easier to clean if the burner is removed from the appliance, but it can also be done with the burner
installed.
Li the glass tray from the replace, pushing from the top, disengage the thermocouple and igniter from
the glass tray.
Remove the ex hose and the orice from the burner and completely remove the glass tray from the
replace.
29
www.napoleon.com
N415-0346-AU FEB 23.21
NORMAL
ABNORMAL
Cleaning The Outer Appliance Surface: Do not use abrasive cleaners or steel wool on any painted, or
stainless steel parts of your Napoleon Appliance. Doing so will scratch the nish. Exterior surfaces should
be cleaned with warm soapy water. To clean stainless surfaces, use a stainless steel or a non-abrasive
cleaner. Always wipe in the direcon of the grain. Over me, stainless steel parts discolor when heated,
usually to a golden or brown hue. This discoloraon is normal and does not aect the performance of the
appliance.
WARNING! The appliance area must be clear and free from materials, gasoline and other
ammable vapors and liquids. Do not obstruct the ow of combuson and venlaon air. Keep the
venlaon opening of the cylinder enclosure free and clear of debris.
More frequent cleaning may be required as necessary.
Maintenance Schedule: We recommend this appliance is inspected by a gas er annually to check the
operaon is sasfactory and perform any necessary maintenance.
Once the glass tray is removed from the replace ip the glass tray upside down and remove the nuts
from the boom of the burner.
Reinstallaon: Reverse the procedure to reinstall the burner ensuring that the holes on the gasket
between the burner bracket and glass tray are lined up during re-assembly. Check that the orice enters
the burner when installing. Replace the glass embers and the front glass shield. When the appliance is
put back in service, compare the burner ame paern to the images below to verify that the appliance is
operang correctly.
!
30
www.napoleon.com
N415-0346-AU FEB 23.21
Troubleshoong
Problem Possible Causes Soluon
Low heat / Low ame when
valve turned to high.
For propane - improper
lighng procedure.
For natural gas - undersized
supply line.
Ensure lighng procedure is followed
carefully. The valve must be in the
o posion when the tank valve is
turned on. Turn tank on slowly to
allow pressure to equalize. See lighng
instrucons.
Pipe must be sized according to
installaon code.
Burners burn with yellow
ame, accompanied by the
smell of gas.
Possible spider web or other
debris.
Thoroughly clean burner venturi. See
general maintenance instrucons.
Burner will not light with
the igniter, but will light
with a match.
Dead baery / or installed
incorrectly.
Loose electrode wire or switch
terminal wires.
Improper gap at electrode p.
Replace with heavy duty baery.
Check that electrode wire is rmly
pushed onto the terminal on the back
of the igniter. Check that the lead
wires from the module to the ignion
switch (if equipped) are rmly pushed
onto their respecve terminals.
The gap can be adjusted by bending
the p in or out. Unl a spark is
achieved.
If, aer carrying out these checks, the appliance does not operate safey and correctly,
contact Napoleon for further further informaon.
31
www.napoleon.com
N415-0346-AU FEB 23.21
KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE YOUR WARRANTY.
Ordering Replacement Parts
Warranty Informaon
MODEL:
DATE OF PURCHASE:
SERIAL NUMBER:
(Record informaon here for easy reference)
For replacement parts and warranty claims, contact the Napoleon dealer where the product was purchased.
Before contacting the dealer, check the Napoleon Grills Website for more extensive cleaning, maintenance,
troubleshooting and parts replacement instructions at www.napoleon.com.
To process a claim, the following informaon is required:
1. Model and serial number of the unit.
2. Part number and descripon.
3. A concise descripon of the problem (‘broken’ is not sucient).
4. Proof of purchase (photocopy of the invoice).
In some cases, Napoleon could request to have the parts returned to the factory for inspecon before
providing replacement parts.
Before contacng Napoleon dealer, please note that the following items are not covered by the warranty:
• Costs for transportaon, brokerage or export dues.
• Labour costs for removal and reinstallaon.
• Costs for service calls to diagnose problems.
• Discolouraon of stainless steel parts.
• Part failure due to lack of cleaning and maintenance, or use of improper cleaners (oven
cleaner or other harsh chemicals).
32
www.napoleon.com
N415-0346-AU FEB 23.21
Item Part # Descripon GSS48
1 N010-0761 base assembly rebox x
2 N010-0779 tray burner / glass x
N300-0002 glass embers - topaz 2 x 7.5lb x
3 N570-0008 #8 x 1/2" screw x
4 N570-0020 #8-32x3/8 screw x
5 N010-0925 regulator n
6 N255-0066 ng bsp n
7 N080-0274 bracket electrode - thermocouple x
8 N680-0001-SER thermocouple x
9 N240-0028 electrode c/w lead x
10 N350-0075 electrical housing x
11 N585-0077 wind shield x
12 N325-0074 handle glass tray x
13 N455-0066 orice natural #25 (3.8 mm) n
W455-0076 orice propane #43 (2.26 mm) p
14 N720-0062 ex connector 30" X 3/8" x
15 N725-0059 safety valve x
N450-0038 nut safety valve x
16 N357-0013 igniter 1 spark - AAA 1.5V x
17 N043-0002 baery, AAA 1.5V x
18 N660-0002 switch light x
19 N380-0020-RD burner control knob x
20 N500-0057 juncon box plate x
21 N750-0026 led wiring x
W160-0095 clip wire x
22 N510-0002 silicone bumper x
23 N300-0003 glass tempered x
24 N665-0012 nailing tab x
25 N190-0002 controller led x
26 N720-0044 ex connector 12" X 3/8" x
27 W445-0031 ng 3/8" - 1/2" x
28 N200-0098 cover control panel x
N570-0096 thumb screw x
29 N707-0008 transformer x
30 LT48SS trim kit - 1 per side ac
31 N080-0445 valve support bracket x
N555-0097 lighng rod x
GSS48COV stainless steel cover ac
MEGA glass embers - amber 1lb ac
MEGB glass embers - blue 1lb ac
MEGK glass embers - black 1lb ac
MEGR glass embers - red 1lb ac
MKGA glass embers - amber 6lb ac
MKGC glass embers - clear 6lb ac
Parts List
33
www.napoleon.com
N415-0346-AU FEB 23.21
x - standard p - propane units only
n - natural gas units only ac - accessory
Item Part # Descripon GSS48
MKGK glass embers - black 6lb ac
MKGB glass embers - blue 6lb ac
MKGR glass embers - red 6lb ac
MKRY grey river rocks ac
MKRM mulcoloured river rocks ac
DL45 driwood log set ac
Parts List
34
www.napoleon.com
N415-0346-AU FEB 23.21
12
1
9
7
22
21
15
16
18
8
13
19
24
2
30
26
23
27
14
28
25
3
4
17
11
20
10
29
5
6
31
GSS48 Parts Diagram
Item Part # Descripon GSS48ST
1 N010-0762 base assembly rebox x
2 N010-0779 tray burner / glass x
N300-0002 glass embers - topaz 2 x 7.5lb x
3 N570-0008 #8 x 1/2" screw x
4 N570-0020 #8-32x3/8 screw x
5 N010-0925 regulator n
6 N255-0066 ng bsp n
7 N080-0274 bracket electrode - thermocouple x
8 N680-0001-SER thermocouple x
9 N240-0028 electrode c/w lead x
10 N350-0075 electrical housing x
11 N585-0077 wind shield x
12 N325-0074 handle glass tray x
13 N455-0066 orice natural #25 (3.8 mm) n
W455-0076 orice propane #43 (2.26 mm) p
14 N720-0062 ex connector 30" X 3/8" x
15 N725-0059 safety valve x
N450-0038 nut safety valve x
16 N357-0013 igniter 1 spark - AAA 1.5V x
17 N043-0002 baery, AAA 1.5V x
18 N660-0002 switch light x
19 N380-0020-RD burner control knob x
20 N500-0057 juncon box plate x
21 N750-0026 led wiring x
W160-0095 clip wire x
22 N510-0002 silicone bumper x
23 N300-0003 glass tempered x
24 N665-0012 nailing tab x
25 N190-0002 controller led x
26 N720-0044 ex connector 12" X 3/8" x
27 W445-0031 ng 3/8" - 1/2" x
28 N200-0098 cover control panel x
N570-0096 thumb screw x
29 N707-0008 transformer x
30 LT48SS trim kit - 1 per side ac
31 N080-0445 valve support bracket x
N555-0097 lighng rod x
GSS48COV stainless steel cover ac
MEGA glass embers - amber 1lb ac
MEGB glass embers - blue 1lb ac
MEGK glass embers - black 1lb ac
MEGR glass embers - red 1lb ac
MKGA glass embers - amber 6lb ac
MKGC glass embers - clear 6lb ac
35
www.napoleon.com
N415-0346-AU FEB 23.21
Item Part # Descripon GSS48ST
1 N010-0762 base assembly rebox x
2 N010-0779 tray burner / glass x
N300-0002 glass embers - topaz 2 x 7.5lb x
3 N570-0008 #8 x 1/2" screw x
4 N570-0020 #8-32x3/8 screw x
5 N010-0925 regulator n
6 N255-0066 ng bsp n
7 N080-0274 bracket electrode - thermocouple x
8 N680-0001-SER thermocouple x
9 N240-0028 electrode c/w lead x
10 N350-0075 electrical housing x
11 N585-0077 wind shield x
12 N325-0074 handle glass tray x
13 N455-0066 orice natural #25 (3.8 mm) n
W455-0076 orice propane #43 (2.26 mm) p
14 N720-0062 ex connector 30" X 3/8" x
15 N725-0059 safety valve x
N450-0038 nut safety valve x
16 N357-0013 igniter 1 spark - AAA 1.5V x
17 N043-0002 baery, AAA 1.5V x
18 N660-0002 switch light x
19 N380-0020-RD burner control knob x
20 N500-0057 juncon box plate x
21 N750-0026 led wiring x
W160-0095 clip wire x
22 N510-0002 silicone bumper x
23 N300-0003 glass tempered x
24 N665-0012 nailing tab x
25 N190-0002 controller led x
26 N720-0044 ex connector 12" X 3/8" x
27 W445-0031 ng 3/8" - 1/2" x
28 N200-0098 cover control panel x
N570-0096 thumb screw x
29 N707-0008 transformer x
30 LT48SS trim kit - 1 per side ac
31 N080-0445 valve support bracket x
N555-0097 lighng rod x
GSS48COV stainless steel cover ac
MEGA glass embers - amber 1lb ac
MEGB glass embers - blue 1lb ac
MEGK glass embers - black 1lb ac
MEGR glass embers - red 1lb ac
MKGA glass embers - amber 6lb ac
MKGC glass embers - clear 6lb ac
Parts List
36
www.napoleon.com
N415-0346-AU FEB 23.21
Item Part # Descripon GSS48ST
MKGK glass embers - black 6lb ac
MKGB glass embers - blue 6lb ac
MKGR glass embers - red 6lb ac
MKRY grey river rocks ac
MKRM mulcoloured river rocks ac
DL45 driwood log set ac
Parts List
x - standard p - propane units only
n - natural gas units only ac - accessory
37
www.napoleon.com
N415-0346-AU FEB 23.21
23
24
15
16
7
8
9
14
27
18
19
2
3
12
4
11
1
13
28
22
30
21
26
17
25
20
10
29
5
6
21
31
GSS48ST Parts Diagram
38
www.napoleon.com
N415-0346-AU FEB 23.21
Notes
39
www.napoleon.com
N415-0346-AU FEB 23.21
Notes
N415-0346-AU
