User Manual Lutron L-BDG2-WH Caseta Wireless Smart Bridge

Documents for Lutron L-BDG2-WH

The following documents are available:
User Manual Specification
  • Specification Sheet - (English) Download
Photos
L-BDG2-WH photo

User Manual

For L-BDG2-WH.

2
Download the Lutron® app and walk through setup
www.casetawireless.com/LutronApp
Lutron
TM
Search for “Lutron Caseta”
Apple is a trademark of Apple Inc.,
registered in the U.S. and other countries.
App Store is a service mark of Apple Inc.,
registered in the U.S. and other countries.
Quick-start guide
Lutron® Smart BridgeTM
Please read before installing
Double your warranty
Love LutronR products? Have ideas
for making them better? Tell us what
you think and we’ll extend your
warranty by 1 year.
www.casetawireless.com/register
Lutron® Smart BridgeT
(L-BDG) *
5 V- 300 mA
Power Supply
(T-5DC-USB)
5 V- 1000 mA
Ethernet Cable
Contents supplied:
* L-BDG is to be connected to a
Class 2, LPS, or SELV, limited energy
(<15 W) power source only.
1
Install the Lutron® Smart BridgeTM
P/N 0301784 REV A
Warranty
For warranty information, please visit www.casetawireless.com/warranty
)Lutron and Lutron are registered trademarks and Smart Bridge and
Lutron
TM
are trademarks of
Lutron Electronics Co., Inc. Google and the Google logo are registered trademarks of
Google Inc., used with permission.
© 2014 – 2015 Lutron Electronics Co., Inc.
A. Connect the Smart BridgeTM
to your Wi-Fi router using the
Ethernet cable.
B. Connect the power cord to the
Smart BridgeTM and plug it into an
outlet.
Smart
BridgeTM
Smart
BridgeTM
Ethernet
cable
Router
Router
Power
cord
Outlet
Accessory
Setup Code
Loading ...
Loading ...
Loading ...

Specifications

Lutron L-BDG2-WH Questions and Answers

#1 Is it possible to control lights in multiple homes via one Smart Bridge - e.g. a primary residence and a vacation home?

Assuming your primary residence and vacation home are not located next to each other, you will require two bridges (and internet connectivity). You will need a bridge at each location. Most likely your app will be able to control both locations from your phone.

#2 Can I add some device to the network to allow occupancy sensing to these switches? I want the lights to turn off automatically when everyone leaves.

No occupancy sensors available when using the SmartBridge or SmartBridge Pro.

#3 Can someone tell me the color of the switches?

Mine were white. You can look at the model id for that. WH implies white. They have other colors but you would need to check lutrons side for model numbers. Definately not the cream/ivory found in a lot of houses so double-check.

#4 Can the dimmer be used to control the speed of a ceiling fan?

No, this is a dimmer for light fixtures either CFL, MLV, LED, and incandescent. I believe the Caseta family has a ceilingn fan control, but it's not sold in a bundle.

#5 Can it work with echo? Does in wall dimmer switch require a neutral wire?

It works great with my Echo and integrates easily. These dimmers do not require a neutral wire, they only have two black wires and one green ground wire. The other lutron switches (the ones that don't dim but are on/off) require a neutral wire. I have used both types in my house because they are for different lights.

#6 Can these work with LED rope lights?

Check with the manufacturer of the LED rope lights. There are too many brands out there to know for sure.
