OWNER’S MANUAL
Smart 3D Blu-ray Disc
Player with Magic Remote
Please read this manual carefully before operating
your set and retain it for future reference.
BP730
P/NO : SAC35673402
1 Getting Started
Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: This product contains chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands
after handling.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION : CLASS 1M VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN. DO NOT VIEW DIRECTLY
WITH OPTICAL INSTRUMENTS
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
centre. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.
Getting Started 3
Getting Started
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
FCC Compliance Statement
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment o and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
y
Reorient or relocate the receiving antenna.
y
Increase the separation between the equipment
and receiver.
y
Connect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
y
Consult the dealer or an experienced radio/TV
technician for help.
CAUTION: Any changes or modications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.
FCC RF Radiation Exposure Statement : This
equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated
with minimum distance 20 cm between the
radiator and your body. End users must follow the
specic operating instructions for satisfying RF
exposure compliance. This transmitter must not be
co-located or operating in conjunction with any
other antenna or transmitter.
FCC Radio Frequency Interference
Requirements
This device is restricted to indoor use due to its
operation in the 5.15 to 5.25 GHz frequency range.
FCC requires this product to be used indoors for
the frequency range 5.15 to 5.25 GHz to reduce the
potential for harmful interference to co-channel
Mobile Satellite systems. High power radars are
allocated as primary users of the 5.25 to 5.35 GHz
and 5.65 to 5.85 GHz bands. These radar stations
can cause interference with and/or damage this
device. This device cannot be co-located with any
other transmitter.
CAUTION: Regulations of the FCC and FAA prohibit
airborne operation of radio-frequency wireless
devices because their signals could interfere with
critical aircraft instruments.
Responsible Party :
LG Electronics USA, Inc.1000 Sylvan Avenue
Englewood Clis, NJ 07632
TEL. : +1-800-243-0000
Getting Started4
Getting Started
1
Notes on Copyrights
y
Because AACS (Advanced Access Content
System) is approved as content protection
system for Blu-ray Disc format, similar to use of
CSS (Content Scramble System) for DVD format,
certain restrictions are imposed on playback,
analog signal output, etc., of AACS protected
contents. The operation of this product and
restrictions on this product may vary depending
on your time of purchase as those restrictions
may be adopted and/or changed by AACS after
the production of this product.
y
Furthermore, BD-ROM Mark and BD+ are
additionally used as content protection systems
for Blu-ray Disc format, which imposes certain
restrictions including playback restrictions for
BD-ROM Mark and/or BD+ protected contents.
To obtain additional information on AACS, BD-
ROM Mark, BD+, or this product, please contact
an authorized Customer Service Centre.
y
Many BD-ROM/DVD discs are encoded with
copy protection. Because of this, you should only
connect your player directly to your TV, not to a
VCR. Connecting to a VCR results in a distorted
picture from copy-protected discs.
y
This product incorporates copyright protection
technology that is protected by U.S. patents
and other intellectual property rights. Use of
this copyright protection technology must be
authorized by Rovi Corporation, and is intended
for home and other limited viewing uses only
unless otherwise authorized by Rovi Corporation.
Reverse engineering or disassembly is prohibited.
y
Under the U.S. Copyright laws and Copyright
laws of other countries, unauthorized recording,
use, display, distribution, or revision of television
programs, videotapes, BD-ROM discs, DVDs, CDs
and other materials may subject you to civil and/
or criminal liability.
y
Watching a 3D content for a long period
time may cause dizziness or tiredness.
y
It is not recommended to watch a movie
in 3D mode for inrm, child and pregnant
woman.
y
If you are experiencing headache, tiredness
or dizziness while viewing contents in 3D,
it is strongly recommended to stop the
playback and rest until you feel normal.
>
Caution
Getting Started 5
Getting Started
1
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold
with the apparatus. When a
cart is used, use caution when
moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Table of Contents6
Table of Contents
1 Getting Started
2 Safety Information
8 Introduction
8 – Playable discs and symbols used in
this manual
9 – About the “7” symbol display
9 – Regional code
10 Remote Control
11 – Magic remote control functions
12 Front Panel
12 Rear Panel
2 Connecting
13 Connecting to Your TV
14 – What is SIMPLINK?
14 – Resolution setting
15 Connecting to an Amplifier
16 – Connecting to an amplifier via HDMI
output
16 – Connecting to an amplifier via digital
audio output
17 Connecting to your Home Network
17 – Wired network connection
17 – Wired network setup
19 – Wireless network connection
19 – Wireless network setup
3 System Setting
22 Initial Setup
23 Settings
23 – Adjust the setup settings
23 – [NETWORK] menu
25 – [DISPLAY] menu
27 – [LANGUAGE] menu
27 – [AUDIO] menu
29 – [LOCK] menu
30 – [OTHERS] menu
4 Operating
31 Home Menu Display
31 – Using [HOME] menu
31 – Using the Smart Share
32 Playing the Linked Devices
32 – Playing a disc
32 – Playing Blu-ray 3D disc
33 – Playing a file on disc/USB device
34 – Playing a file on a network server
35 Using Home Network Server for PC
35 – Installing Nero MediaHome 4
Essentials
35 – Sharing files and folders
36 – About Nero MediaHome 4 Essentials
36 – System requirements
37 General Playback
37 – Basic operations for video and audio
content
37 – Basic operations for photo content
38 – Resume playback
38 – Last scene memory
39 On-Screen Display
39 – To control video playback
40 – To control photo view
41 Advanced Playback
41 – Repeat playback
41 – Repeating a specific portion
41 – Playing from selected time
42 – Selecting a subtitle language
42 – Hearing a different audio
42 – Watching from a different angle
42 – Changing the TV Aspect Ratio
43 – Changing subtitle Code Page
43 – Changing the Picture Mode
43 – Viewing content information
44 – Changing content list view
44 – Selecting a subtitle file
45 – Listening to music during slide show
45 – Converting 2D content to 3D
46 Advanced Features
46 – Wi-Fi Direct™
47 – Enjoying Miracast™
47 – Enjoying BD-Live™
48 – LG Tag On
48 – LG AV Remote
48 – Private Sound Mode
Table of Contents 7
1
2
3
4
5
6
49 – Viewing information from Gracenote
Media Database
50 Audio CD recording
51 Using the Premium
51 Using the LG Smart World
52 – Signing in
52 – Searching online content
53 Using the My Apps Menu
5 Troubleshooting
54 Troubleshooting
54 – General
55 – Network
56 – Picture
56 – Customer support
56 – Open source software notice
6 Appendix
57 About Magic Remote Control
58 Network Software Update
58 – Network update notification
58 – Software update
60 Additional Information
60 – File requirement
61 – AVCHD (Advanced Video Codec High
Definition)
62 – About DLNA
62 – Certain system requirements
62 – Compatibility notes
63 Audio Output Specifications
65 Area Code List
66 Language Code List
67 Trademarks and Licenses
70 Specifications
71 Maintenance
71 – Handling the unit
71 – Notes on discs
72 Important Information Relating to
Network Services
Some of the content in this manual may dier from your player depending on the software of the
player or your service provider.
Getting Started8
Getting Started
1
Introduction
Playable discs and symbols used in this manual
Media/Term Logo Symbol Description
Blu-ray
e
y
Discs such as movies that can be purchased or
rented.
y
“Blu-ray 3D” discs and “Blu-ray 3D ONLY” discs.
y
BD-R/RE discs that are recorded in BDAV format.
y
u
i
y
BD-R/RE discs that contain Movie, Music or
Photo les.
y
ISO 9660+JOLIET, UDF and UDF Bridge format
DVD-ROM
DVD-R
DVD-RW
DVD+R
DVD+RW
(12 cm)
r
y
Discs such as movies that can be purchased or
rented.
y
Movie mode and nalized only
y
Supports the dual layer disc also
o
Finalized AVCHD format
y
u
i
y
DVD±R/RW discs that contain Movie, Music or
Photo les.
y
ISO 9660+JOLIET, UDF and UDF Bridge format
DVD-RW (VR)
(12 cm)
r
VR mode and nalized only
Audio CD
(12 cm)
t
Audio CD
CD-R/RW
(12 cm)
y
u
i
y
CD-R/RW discs that contain Movie, Music or
Photo les.
y
ISO 9660+JOLIET, UDF and UDF Bridge format
Note –
,
Indicates special notes and operating features.
Caution –
>
Indicates cautions for preventing possible
damages from abuse.
Getting Started 9
Getting Started
1
y
Depending on the conditions of the
recording equipment or the CD-R/RW (or
DVD±R/RW) disc itself, some CD-R/RW (or
DVD±R/RW) discs cannot be played on the
unit.
y
Depending on the recording software & the
nalization, some recorded discs (CD-R/RW,
DVD±R/RW, BD-R/RE) may not be playable.
y
BD-R/RE, DVD±R/RW and CD-R/RW discs
recorded using a personal computer or a
DVD or CD Recorder may not play if the
disc is damaged or dirty, or if there is dirt or
condensation on the player’s lens.
y
If you record a disc using a personal
computer, even if it is recorded in a
compatible format, there are cases in which
it may not play because of the settings of
the application software used to create the
disc. (Check with the software publisher for
more detailed information.)
y
This player requires discs and recordings to
meet certain technical standards in order to
achieve optimal playback quality.
y
Pre-recorded DVDs are automatically set to
these standards. There are many dierent
types of recordable disc formats (including
CD-R containing MP3 or WMA les) and
these require certain pre-existing conditions
to ensure compatible playback.
y
Customers should note that permission
is required in order to download MP3 /
WMA les and music from the Internet.
Our company has no right to grant such
permission. Permission should always be
sought from the copyright owner.
y
You have to set the disc format option
to [Mastered] in order to make the discs
compatible with the LG players when
formatting rewritable discs. When setting
the option to Live System, you cannot use
it on LG player. (Mastered/Live File System :
Disc format system for windows Vista)
,
Note
About the “
7
” symbol display
“
7
” may appear on your TV display during
operation and indicates that the function explained
in this owner’s manual is not available on that
specic media.
Regional code
This unit has a regional code printed on the rear of
the unit. This unit can play only BD-ROM or DVD
discs labelled same as the rear of the unit or “ALL”.
Getting Started10
Getting Started
1
h
a
Remote Control Indicator:
(RF & Bluetooth transmitter)
Blinks when operating.
b
1
(POWER): Switches the
unit ON or OFF.
c
BACK (
1
): Exits the menu
or returns to the previous
screen.
d
HOME (
): Displays the
Home screen.
e
Direction buttons: Selects
an option in the menu.
If you press the navigation
button while moving the
pointer on the screen, the
pointer disappears, and the
Magic remote control works
as a regular remote control.
To display the pointer again,
shake the Magic remote
control from side to side.
f
Wheel (
): Selects menus
or options and conrms your
input ; Scrolls the screen to
search a menu on the web
browser.
g
N
(Play/Pause): Starts
playback.
/
Pauses playback.
Z
(Stop): Stops playback.
c/v
: Searches
backward or forward. (Press
and hold
C/V
)
C/V
: Moves previous/
next track or le.
m
(INFO/MENU): Displays or
exits On-Screen Display.
: If necessary, you
can use a virtual numbered
keypad. (Press and hold
m
(INFO/MENU))
h
Colored (R, G, Y, B) buttons:
Use to navigate BD-ROM
menus. They are also used as
shortcut buttons for specic
menus.
Remote Control
Getting Started 11
Getting Started
1
Magic remote control
functions
The Magic remote control operates by pairing with
your unit. Once you purchased the unit, please
register the Magic remote control as follows;
To register the Magic remote control
WHEEL
To use the Magic remote control, register it with
your unit rst.
1. Turn on the unit and wait for about 10 seconds
and then press and hold Wheel (
) button
while pointing the remote control at the unit.
2. The remote control is automatically registered
and registration completion message appears
on the screen.
If you failed to register the Magic remote
control, turn o the unit and try again.
,
Note
Battery installation
Open the battery cover at the bottom of the
Remote Control, and insert two (1.5 V AA ) alkaline
batteries with
4
and
5
matched correctly.
Do not mix old and new batteries, as this may
damage the remote control.
>
Caution
How to use Magic remote control
y
Shake the remote control slightly to make the
pointer appear on the screen.
y
Shake the Magic remote control slightly to the
right and left to make the pointer appear on the
center of screen.
y
The magic pointer disappears when the remote
control is not moved for ve seconds.
How to use Magic remote tip
y
When you press the wheel, it also functions as
Selection button.
y
You can scroll through menus using the Wheel.
y
Use your wrist to move the pointer more easily.
y
If the Magic remote control’s connection is
unstable or has any problems, cancel the
registration and try it again. (page 57)
y
Depending on the content, the pointing of
the magic remote control does not work.
For controlling, please use the direction keys
on the remote.
,
Note
Getting Started12
Getting Started
1
Front Panel
a
Disc Slot
b
Display Window
c
Remote Sensor
d
R
(OPEN / CLOSE)
e
T
(PLAY / PAUSE)
f
I
(STOP)
g
1/!
(POWER)
h
USB Port
Rear Panel
a
AC power cord
b
DIGITAL AUDIO OUT (OPTICAL)
c
LAN port
d
HDMI OUT
2 Connecting
Connecting 13
Connecting
2
Connecting to Your TV
If you have a HDMI TV or monitor, you can connect
it to this player using a HDMI cable (Type A, High
Speed HDMI™ Cable). Connect the HDMI jack on
the player to the HDMI jack on a HDMI compatible
TV or monitor.
Rear of the unit
TV
HDMI
cable
Set the TV’s source to HDMI (refer to TV’s Owner’s
manual).
Please refer to the manuals of your TV, Stereo
System or other devices as necessary to make
the best connections.
,
Note
Additional Information for HDMI
y
When you connect a HDMI or DVI compatible
device make sure of the following:
-
Try switching o the HDMI/DVI device and
this player. Next, switch on the HDMI/DVI
device and leave it for around 30 seconds,
then switch on this player.
-
The connected device’s video input is set
correctly for this unit.
-
The connected device is compatible with
720x480p, 1280x720p, 1920x1080i or
1920x1080p video input.
y
Not all HDCP-compatible HDMI or DVI devices
will work with this player.
-
The picture will not be displayed properly
with non-HDCP device.
y
If a connected HDMI device does not accept
the audio output of the player, the HDMI
device’s audio sound may be distorted or
may not output.
y
When you use HDMI connection, you can
change the resolution for the HDMI output.
(Refer to “Resolution Setting” on page 14)
y
Select the type of video output from the
HDMI OUT jack using [HDMI Color Setting]
option on the [Settings] menu (see page
26).
y
Changing the resolution when the
connection has already been established
may result in malfunctions. To solve the
problem, turn o the player and then turn it
on again.
y
When the HDMI connection with HDCP
is not veried, TV screen is changed to
black screen. In this case, check the HDMI
connection, or disconnect the HDMI cable.
y
If there are noises or lines on the screen,
please check the HDMI cable (length is
generally limited to 4.5 m).
,
Note
Connecting14
Connecting
2
What is SIMPLINK?
Some functions of this unit are controlled by the
TV’s remote control when this unit and LG TV’s with
SIMPLINK are connected through HDMI connection.
Controllable functions by LG TV’s remote control;
Play, Pause, Scan, Skip, Stop, Power O, etc.
Refer to the TV owner’s manual for the details of
SIMPLINK function.
LG TV’s with SIMPLINK function has the logo as
shown above.
Depending on the disc type or playing status,
some SIMPLINK operation may dier from your
purpose or not work.
,
Note
Resolution setting
The player provides several output resolutions for
HDMI OUT jack. You can change the resolution
using [Settings] menu.
1. Press HOME (
).
2. Use
a/d
to select the [Settings] and press
Wheel (
). The [Settings] menu appears.
3. Use
w/s
to select [DISPLAY] option then press
d
to move to the second level.
4. Use
w/s
to select the [Resolution] option then
press Wheel (
). to move to the third level.
4. Use
w/s
to select the desired resolution then
press Wheel (
) to confirm your selection.
Connecting 15
Connecting
2
y
If your TV does not accept the resolution
you have set on the player, you can set
resolution to 480p as follows:
1. Press HOME (
) to disappear the HOME
menu.
2. Press
I
(STOP) for more than 5 seconds.
y
If you select a resolution manually and then
connect the HDMI jack to TV and your TV
does not accept it, the resolution setting is
set to [Auto].
y
If you select a resolution that your TV
does not accept, the warning message
will appear. After resolution change,
if you cannot see the screen, please
wait 20 seconds and the resolution will
automatically revert back to the previous
resolution.
y
The 1080p video output frame rate may
be automatically set to either 24 Hz or
60 Hz depending both on the capability
and preference of the connected TV and
based on the native video frame rate of the
content on the BD-ROM disc.
,
Note
Connecting to an
Amplifier
Make one of the following connections, depending
on the capabilities of your existing equipment.
y
HDMI Audio connection (page 16)
y
Digital Audio connection (page 16)
Since many factors aect the type of audio output,
see “Audio Output Specications” for details (page
63).
About Digital Multi-channel sound
A digital multi-channel connection provides the
best sound quality. For this, you need a multi-
channel Audio/Video Receiver that supports one
or more of the audio formats supported by your
player. Check the logos on the front of the Audio/
Video receiver and the manual. (PCM Stereo, PCM
Multi-Ch, Dolby Digital, Dolby Digital Plus, Dolby
TrueHD, DTS and/or DTS-HD)
Connecting16
Connecting
2
Connecting to an amplifier via
HDMI output
Connect the player’s HDMI OUT jack to the
corresponding in jack on your amplier using a
HDMI cable.
HDMI cable
HDMI
cable
TV
Receiver/Amplier
Rear of the unit
Connect the amplier’s HDMI output jack to HDMI
input jack on your TV using a HDMI cable if your
amplier has HDMI output jack. (Refer to amplier’s
owner’s manual)
You will need to activate the player’s digital output.
(See “[AUDIO] Menu” on page 27)
Connecting to an amplifier via
digital audio output
Connect the player’s OPTICAL AUDIO OUT jack to
the corresponding in jack on your amplier using
an optional digital audio cable.
Optical
cable
Receiver/Amplier
Rear of the unit
You will need to activate the player’s digital output.
(See “[AUDIO] Menu” on page 27.)
Connecting 17
Connecting
2
Connecting to your
Home Network
This player can be connected to a local area
network (LAN) via the LAN port on the rear panel or
the internal wireless module.
By connecting the unit to a broadband home
network, you have access to services such as
software updates, BD-Live interactivity and on-line
content services.
Wired network connection
Using a wired network provides the best
performance, because the attached devices
connect directly to the network and are not subject
to radio frequency interference.
Please refer to the documentation for your network
device for further instructions.
Connect the player’s LAN port to the corresponding
port on your Modem or Router using a
commercially available LAN or Ethernet cable.
y
When plugging or unplugging the LAN
cable, hold the plug portion of the cable.
When unplugging, do not pull on the LAN
cable but unplug while pressing down on
the lock.
y
Do not connect a modular phone cable to
the LAN port.
y
Since there are various connection
congurations, please follow the
specications of your telecommunication
carrier or internet service provider.
y
If you want to access content from DLNA
servers, this player must be connected to
the same local area network with them via a
router.
y
To set your PC as a DLNA server, install the
supplied Nero MediaHome 4 on your PC.
(see page 35)
,
Note
Rear of the unit
Router
Broadband
service
DLNA certied servers
Wired network setup
If there is a DHCP server on the local area network
(LAN) via wired connection, this player will
automatically be allocated an IP address. After
making the physical connection, a small number of
home networks may require the player’s network
setting to be adjusted. Adjust the [NETWORK]
setting as follow.
Preparation
Before setting the wired network, you need to
connect the broadband internet to your home
network.
Connecting18
Connecting
2
1. Select [Connection Setting] option in the
[Settings] menu then press Wheel (
).
2. Read the preparations for the network settings
and then press Wheel (
) while [Start] is
highlighted.
Network will automatically be connected to the
unit.
Advanced Setting
If you want to set the network settings manually,
use
w/s
to select [Advanced Setting] on the
[Network Setting] menu and press Wheel (
).
1. Use
w/s
to select [Wired] and press Wheel
(
).
2. Use
w/s/a/d
to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.
y
If there is no DHCP server on the network
and you want to set the IP address manually,
select [Manual Input] then set [IP Address],
[Subnet Mask], [Gateway] and [DNS Server].
,
Note
3. Select [Next] and press Wheel ( ) to apply
network settings.
Network connection status is displayed on the
screen.
4. Press Wheel (
) while [OK] is highlighted to
finish the wired network settings.
Connecting 19
Connecting
2
Wireless network connection
Another connection option is to use an Access Point
or a wireless router. The network conguration and
connection method may vary depending on the
equipment in use and the network environment.
Wireless
Communication
DLNA certied servers
Access Point or
Wireless Router
Broadband
service
Refer to the setup instructions supplied with
your access point or wireless router for detailed
connection steps and network settings.
For best performance, a direct wired connection
from this player to your home network’s router or
cable/DSL modem is always the best option.
If you do chose to use the wireless option, note that
performance can sometimes be aected by other
electronic devices in the home.
Wireless network setup
For the wireless network connection, the player
needs to be set up for network communication.
This adjustment can be done from the [Settings]
menu. Adjust the [NETWORK] setting as follow.
Setting up the access point or the wireless router
is required before connecting the player to the
network.
Preparation
Before setting the wireless network, you need
to:
-
connect the broadband internet to the
wireless home network.
-
set the access point or wireless router.
-
note the SSID and security code of the
network.
1. Select [Connection Setting] option in the
[Settings] menu then press Wheel (
).
2. Read the preparations for the network settings
and then press Wheel (
) while [Start] is
highlighted.
If wired network is not connected to the unit, all
available networks are displayed on the screen.
3. Use
w/s
to select a desired SSID of wireless
network and press Wheel (
).
If you have security on your access point, you
need to input the security code as necessary.
If you use other characters than the english
alphabet or digits for the SSID name of your
access point or wireless router, it may be
displayed dierently.
,
Note
Connecting20
Connecting
2
y
WEP security mode generally have 4 keys
available on an access point setting. If your
access point or wireless router use WEP
security, enter the security code of the key
“No.1” to connect on your home network.
y
An Access Point is a device that allows you
to connect to your home network wirelessly.
,
Note
4. Use
w/s/a/d
to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.
If there is no DHCP server on the network and
you want to set the IP address manually, select
[Static] then set [IP Address], [Subnet Mask],
[Gateway] and [DNS Server].
,
Note
5. Select [Next] and press Wheel ( ) to apply
network settings.
Network connection status is displayed on the
screen.
6. Select [OK] and press Wheel (
) to complete
the network connection.
Advanced Setting
If you want to set the network settings manually,
use
w/s
to select [Advanced Setting] on the
[Network Setting] menu and press Wheel (
).
1. Use
w/s
to select [Wireless] and press Wheel
(
).
[AP List] - Scans all available access points or
wireless routers within range and display them
as a list.
[Network name (SSID)] – Your access point
may not be broadcasting its network name
(SSID). Check your access point settings through
your computer and either set your access
point to broadcast SSID, or manually enter the
network name in [Network name(SSID)].
[PBC] – If your access point or wireless
router that supports the PBC (Push Button
Configuration) method, select this option and
press the Push Button on your access point
within 120 counts. You do not need to know the
network name (SSID) and security code of your
access point.
[PIN] – If your access point supports the PIN
Code configuration method based on WPS(Wi-
Fi Protected Setup), select this option and
note the code number on the screen. And
then, enter the PIN number on a setting menu
of your access point to connect. Refer to the
documentation for your network device.
2. Follow the instructions of each connection
method on the screen.
To use PBC and PIN network connection,
security mode of your access point must be
set to OPEN or AES.
,
Note
Connecting 21
Connecting
2
Notes on network connection
y
Many network connection problems during
set up can often be xed by re-setting the
router or modem. After connecting the player
to the home network, quickly power o and/
or disconnect the power cable of the home
network router or cable modem. Then power on
and/or connect the power cable again.
y
Depending on the internet service provider (ISP),
the number of devices that can receive internet
service may be limited by the applicable terms
of service. For details, contact your ISP.
y
Our company is not responsible for any
malfunction of the player and/or the internet
connection feature due to communication
errors/malfunctions associated with your
broadband internet connection, or other
connected equipment.
y
The features of BD-ROM discs made available
through the Internet Connection feature are not
created or provided by our company, and our
company is not responsible for their functionality
or continued availability. Some disc related
material available by the Internet Connection
may not be compatible with this player. If you
have questions about such content, please
contact the producer of the disc.
y
Some internet contents may require a higher
bandwidth connection.
y
Even if the player is properly connected and
congured, some internet contents may not
operate properly because of internet congestion,
the quality or bandwidth of your internet service,
or problems at the provider of the content.
y
Some internet connection operations may not
be possible due to certain restrictions set by the
Internet service provider (ISP) supplying your
broadband Internet connection.
y
Any fees charged by an ISP including, without
limitation, connection charges are your
responsibility.
y
A 10 Base-T or 100 Base-TX LAN port is required
for wired connection to this player. If your
internet service does not allow for such a
connection, you will not be able to connect the
player.
y
You must use a Router to use xDSL service.
y
A DSL modem is required to use DSL service and
a cable modem is required to use cable modem
service. Depending on the access method of and
subscriber agreement with your ISP, you may not
be able to use the internet connection feature
contained in this player or you may be limited
to the number of devices you can connect at
the same time. (If your ISP limits subscription to
one device, this player may not be allowed to
connect when a PC is already connected.)
y
The use of a “Router” may not be allowed or its
usage may be limited depending on the policies
and restrictions of your ISP. For details, contact
your ISP directly.
y
The wireless network operate at 2.4 GHz
radio frequencies that are also used by other
household devices such as cordless telephone,
Bluetooth® devices, microwave oven, and can be
aected by interference from them.
y
Turn o all unused network equipment in
your local home network. Some devices may
generate network trac.
y
For the purpose of the better transmission,
placing the player from the access point as close
as possible.
y
In some instances, placing the access point or
wireless router at least 0.45 m above the oor
may improve the reception.
y
Move closer to the access point if possible or re-
orient the player so there is nothing between it
and the access point.
y
The reception quality over wireless depends on
many factors such as type of the access point,
distance between the player and access point,
and the location of the player.
y
Set your access point or wireless router to
Infrastructure mode. Ad-hoc mode is not
supported.
3 System Setting
System Setting22
System Setting
3
Initial Setup
When you turn on the unit for the rst time, the
initial setup wizard appears on the screen. Set the
display language and network settings on the initial
setup wizard.
1. Press
1
(POWER).
The initial setup wizard appears on the screen.
2. Use
w/s/a/d
to select a display language
and press Wheel (
).
3. Try the some features of your Magic remote
control by following the guide on the screen.
4. Read and prepare the preparations for the
network settings and then press Wheel (
)
while [Start] is highlighted.
If wired network is connected, the network
connection setting will automatically be
finished.
5. All available networks are displayed on the
screen. Use
w/s
to select [Wired Network]
or desired SSID of wireless network and press
Wheel (
).
If you have security on your access point, you
need to input the security code as necessary.
6. Use
w/s/a/d
to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.
7. Select [Next] and press Wheel ( ) to apply
network settings.
Network connection status is displayed on the
screen.
For details on network settings, refer to
“Connecting to your Home Network” on page
17.
8. Check all the settings that you have set in the
previous steps.
Press Wheel ( ) while [Finish] is highlighted
to finish the initial setup settings. If there is any
settings to be changed, use
w/s/a/d
to
select
1
and press Wheel (
).
System Setting 23
System Setting
3
Settings
Adjust the setup settings
You can change the settings of the player in the
[Settings] menu.
1. Press HOME (
).
2. Use
a/d
to select the [Settings] and press
Wheel (
). The [Settings] menu appears.
3. Use
s/w
to select the first setup option, and
move to the second level.
4. Use
a/d
to select a second setup option, and
press Wheel (
) to move to the third level.
5. Use
s/w
to select a desired setting, and press
Wheel (
) to conrm your selection.
[NETWORK] menu
The [NETWORK] settings are needed to use the
software update, BD-Live and on-line content
services.
Connection Setting
If your home network environment is ready to
connect the player, the player needs to be set the
wired or wireless network connection for network
communication. (See “Connecting to your Home
Network” on page 17.)
Connection Status
If you want to check the network status on this
player, select the [Connection Status] options and
press Wheel (
) to check whether a connection
to the network and the internet have been
established.
BD-LIVE connection
You can restrict Internet access when BD-Live
functions are used.
[Permitted]
Internet access is permitted for all BD-Live
contents.
[Partially permitted]
Internet access is permitted only for BD-
Live contents which have content owner
certicates. Internet access and AACS Online
functions are prohibited for all BD-Live contents
without a certicate.
[Prohibited]
Internet access is prohibited for all BD-Live
contents.
System Setting24
System Setting
3
Smart Service Setting
[Country Setting]
Select your area for displaying proper online
content service.
[Initialize]
Depending on the region, [Initialize] function
may not be available.
Device Name
You can make a network name using virtual
keyboard. This player will be recognised by the
name you are entering on your home network.
Wi-Fi Direct
This player is a Wi-Fi Direct™ certied device. Wi-
Fi Direct is the technology that devices to connect
each other without connecting to an Access point
or a router. Press Wheel (
) to display the Wi-
Fi Direct menu. Refer to page 46 for the device
connection.
Network Play
This function allows you to control the playback
of media streamed from DLNA media server by a
DLNA certied smartphone. Most DLNA certied
smartphone has a function to control the playback
media on your home network. Set this option to
[On] for allowing your smartphone to control this
unit. Refer to instructions of your DLNA certied
smartphone or the application for more detailed
information.
y
This unit and the DLNA certied
smartphone must be connected to the
same network.
y
To use the [Network Play] function using a
DLNA certied smartphone, press HOME
(
) to display the home menu before
connecting to this unit.
y
While controlling the unit using the
[Network Play] function, the remote control
may not work.
y
Available le formats described on page
60 are not always supported on [Network
Play] function.
,
Note
System Setting 25
System Setting
3
[DISPLAY] menu
TV Aspect Ratio
Select a TV aspect ratio option according to your TV
type.
[4:3 Letter Box]
Select when a standard 4:3 TV is connected.
Displays theatrical images with masking bars
above and below the picture.
[4:3 Pan Scan]
Select when a standard 4:3 TV is connected.
Displays pictures cropped to ll your TV screen.
Both sides of the picture are cut o.
[16:9 Original]
Select when a 16:9 wide TV is connected. The
4:3 picture is displayed with an original 4:3
aspect ratio, with black bars appearing at the
left and right sides.
[16:9 Full]
Select when a 16:9 wide TV is connected. The
4:3 picture is adjusted horizontally (in a linear
proportion) to ll the entire screen.
You cannot select [4:3 Letter Box] and
[4:3 Pan Scan] option when the resolution is
set to higher than 720p.
,
Note
Resolution
Sets the output resolution of the HDMI video signal.
Refer to page 14 for details about the resolution
setting.
[Auto]
If the HDMI OUT jack is connected to
TVs providing display information (EDID),
automatically selects the resolution best suited
to the connected TV.
[480p]
Outputs 480 lines of progressive video.
[720p]
Outputs 720 lines of progressive video.
[1080i]
Outputs 1080 lines of interlaced video.
[1080p]
Outputs 1080 lines of progressive video.
Ultra HD Upscaling
This feature allows the unit to up-scale the original
video resolution to Ultra HD resolution and output
via HDMI connection.
[Auto]
If you connect a display capable of displaying
Ultra HD resolution, this unit will output video
signals in Ultra HD resolution automatically.
[O ]
The unit will turn o the Up-scaling feature.
y
This unit will output video signals in Ultra
HD resolution when it plays BD-ROM disc
formatted in 24 Hz.
y
The playback pictures may be momentarily
interrupted when the resolutions switch.
,
Note
System Setting26
System Setting
3
1080p Display Mode
When the resolution is set to 1080p, select
[24 Hz] for smooth presentation of lm material
(1080p/24 Hz) with a HDMI-equipped display
compatible with 1080p/24 Hz input.
y
When you select [24 Hz], you may
experience some picture disturbance when
the video switches video and lm material.
In this case, select [60 Hz].
y
Even when [1080p Display Mode] is set to
[24 Hz], if your TV is not compatible with
1080p/24 Hz, the actual frame frequency of
the video output will be 60 Hz to match the
video source format.
,
Note
HDMI Color Setting
Select the type of output from the HDMI OUT jack.
For this setting, please refer to the manuals of your
display device.
[YCbCr]
Select when connecting to a HDMI display
device.
[RGB]
Select when connecting to a DVI display
device.
3D Mode
Select the type of output mode for Blu-ray 3D disc
playback.
[O ]
Blu-ray 3D disc playback will output as 2D
mode like a normal BD-ROM disc playback.
[On]
Blu-ray 3D disc playback will output as 3D
mode.
You cannot select [4:3 Letter Box] and
[4:3 Pan Scan] option when the resolution is
set to higher than 720p.
,
Note
Home Menu Guide
This function allows you to display or delete the
guide bubble on the Home Menu. Set this option
to [On] for displaying guide.
System Setting 27
System Setting
3
[LANGUAGE] menu
Display Menu
Select a language for the [Settings] menu and on-
screen display.
Disc Menu/Disc Audio/
Disc Subtitle
Select the language you prefer for the audio track
(disc audio), subtitles, and the disc menu.
[Original]
Refers to the original language in which the
disc was recorded.
[Other]
Press Wheel (
) to select another language.
Enter the corresponding 4-digit number
according to the language code list on page
66.
[O] (Disc Subtitle only)
Turn o Subtitle.
Depending on the disc, your language setting
may not work.
,
Note
[AUDIO] menu
Each disc has a variety of audio output options. Set
the player’s Audio options according to the type of
audio system you use.
Since many factors aect the type of audio
output, see “Audio Output Specications” on
page 63 for details.
,
Note
Digital Output
[PCM Stereo] (HDMI, OPTICAL)
Select if you connect this unit’s HDMI OUT or
DIGITAL AUDIO OUT jack to a device with two-
channel digital stereo decoder.
[PCM Multi-Ch] (HDMI only)
Select if you connect this unit’s HDMI OUT jack
to a device with multi-channel digital decoder.
[DTS Re-Encode] (HDMI, OPTICAL)
Select if you connect this unit’s HDMI OUT or
DIGITAL AUDIO OUT jack to a device with DTS
decoder.
[BitStream] (HDMI, OPTICAL)
Select if you connect this unit’s DIGITAL AUDIO
OUT and HDMI OUT jack to a device with
LPCM, Dolby Digital, Dolby Digital Plus, Dolby
TrueHD, DTS and DTS-HD decoder.
y
When [Digital Output] option is set to [PCM
Multi-Ch], the audio may output as PCM
Stereo if the PCM Multi-Ch information is
not detected from HDMI device with EDID.
y
If the [Digital Output] option is set to [DTS
Re-Encode], the DTS Re-Encode audio is
outputted for BD-ROM discs with secondary
audio and the original audio is outputted
for the other discs (like [BitStream]).
,
Note
System Setting28
System Setting
3
Sampling Freq.
(Digital Audio Output)
[48 kHz]
Select this if your A/V Receiver or Amplier is
not capable of handling 192 kHz and 96 kHz
signal. When this choice is made, this unit
automatically converts any 192 kHz and 96 kHz
signals to 48 kHz so your system can decode
them.
[96 kHz]
Select this if your A/V Receiver or Amplier is
not capable of handling 192 kHz signals. When
this choice is made, this unit automatically
converts any 192 kHz signals to 96 kHz so your
system can decode them.
[192 kHz]
Select this if your A/V Receiver or Amplier is
capable of handling 192 kHz signals.
Check the documentation for your A/V Receiver or
Amplier to verify its capabilities.
DRC (Dynamic Range Control)
This function allows you to listen to a movie at a
lower volume without losing clarity of sound.
[O ]
Turns o this function.
[On]
Compress the dynamic range of the Dolby
Digital, Dolby Digital Plus or Dolby TrueHD
audio output.
[Auto]
The dynamic range of the Dolby TrueHD audio
output is specied by itself.
And the dynamic range of the Dolby Digital
and Dolby Digital Plus are operated as same as
the [On] mode.
The DRC setting can be changed only when a
disc is not inserted or the unit is in complete
stop mode.
,
Note
DTS Neo:6
If the player is connected to the multi-channel
Audio Receiver by HDMI connection, set this option
to enjoy the multi-channel surround sound with
the 2-channel audio source.
[O ]
Outputs the stereo sound via front speakers.
[Music]
Outputs the multi-channel sounds that are
optimized for listening to music.
[Cinema]
Outputs the multi-channel sounds that are
optimized for watching movie.
y
This function is not available on an on-line
service.
y
Only the audio source with less than 48
kHz sampling frequency is available for this
function.
y
This function is available only when [Digital
Output] option is set to [PCM Multi-Ch].
,
Note
System Setting 29
System Setting
3
[LOCK] menu
The [LOCK] settings aect only BD-ROM and DVD
playback.
To access the any features in [LOCK] settings, you
must enter the 4-digit security code you have
created.
If you have not entered a password yet, you are
prompted to do so. Enter a 4-digit password twice,
and press Wheel (
) to create a new password.
Password
You can create or change the password.
[None]
Enter a 4-digit password twice, and press
Wheel (
) to create a new password.
[Change]
Enter the current password and press Wheel
(
). Enter a 4-digit password twice, and press
Wheel (
) to create a new password.
If you forget your password
If you forget your password, you can clear it using
the following steps:
1. Remove any disc that might be in the player.
2. Select [Password] option in the [Settings] menu.
3. Use colored buttons to enter “Red -> Green ->
Yellow -> Green -> Yellow -> Blue”.
The password is cleared.
DVD Rating
Blocks playback of rated DVD based on their
content. (Not all discs are rated.)
[Rating 1-8]
Rating one (1) has the most restrictions and
rating eight (8) is the least restrictive.
[Unlock]
If you select [Unlock], parental control is not
active and the disc plays in full.
Blu-ray Disc Rating
Set an age limit of BD-ROM play. Use number
buttons to input an age limit for BD-ROM viewing.
[255]
All BD-ROM can be played.
[0-254]
Prohibits play of BD-ROM with corresponding
ratings recorded on them.
y
The [Blu-ray Disc Rating] will be applied
only for the Blu-ray disc that containing the
Advanced Rating Control.
y
For the region using MPAA rating level, refer
to the table below as an example.
Blu-ray Disc Rating MPAA Rating
0 G
8 PG
13 PG-13
17 R
18 NC-17
255 Not restricted
,
Note
Area Code
Enter the code of the area whose standards were
used to rate the DVD video disc, based on the list
on page 65.
System Setting30
System Setting
3
[OTHERS] menu
Pointer
Sets the speed and size of the Magic remote
control’s magic pointer.
[Speed]
Sets the moving speed of the magic pointer.
[Size]
Chooses the size of the magic pointer.
Quick Start
This player can stay in standby mode with low
power consumption, so that the player can
instantly boot without delay when you turn on this
unit. Set this option to [On] for activating [Quick
Start] function.
y
If [Quick Start] option is set to [On] and an
AC power is accidently re-connected to
the player by power failure etc., the player
automatically boots itself to be the standby
status. Before operating the player, wait for a
while until the player is in standby status.
y
When [Quick Start] is set to [On], power
consumption will be higher than when
[Quick Start] is set to [O ].
,
Note
Auto Power Off
The screen saver appears when you leave the
player in Stop mode for about ve minutes. If
you set this option to [On], the unit automatically
turns o within 20 minutes since the Screen Saver
is displayed. Set this option to [O] to leave the
screen saver until the unit is operated by the user.
Initialize
[Factory Set]
You can reset the player to its original factory
settings.
[Blu-ray Storage Clear]
Initializes the BD-Live contents from the
connected USB storage.
If you reset the player to its original factory
settings using [Factory Set] option, you have
to set all the activation for the on-line services
and network settings again.
,
Note
Software
[Information]
Displays the current software version.
[Update]
You can update the software by connecting
the unit directly to the software update server
(see page 58).
4 Operating
Operating 31
Operating
4
Home Menu Display
Using [HOME] menu
The home menu appears when you press HOME
(
). Use
w/s/a/d
to select a category and
press
Wheel ( )
.
Depending on the region, the [LG Smart
World], [My Apps] service and [Search]
function may not be available.
,
Note
a
[Smart Share] - Displays Smart Share menu.
b
[Premium] - Displays the Premium home
screen. (page 51)
c
[LG Smart World] - Displays LG Apps titles
provided to the unit. (page 51)
d
[My Apps] - Displays the [My Apps] screen.
(page 53)
e
[Settings] - Adjusts the system settings.
f
[
] - Searches for desired LG Apps and other
content.
g
[
] - Displays login menu.
Using the Smart Share
You can play video, photo and audio content on
the unit by inserting a disc, connecting an USB
device or using home network (DLNA).
1. Press HOME (
) to display the home menu.
2. Select [Smart Share] and press
Wheel ( )
.
a
Displays all linked devices.
b
Displays video, photo or audio content.
c
Displays the le or folder on linked device.
Operating32
Operating
4
Playing the Linked
Devices
Playing a disc
erot
1. Insert a disc in the disc slot.
For the most Audio CD, BD-ROM and
DVD-ROM discs, playback starts automatically.
2. Press HOME (
) and then select [Smart Share].
3. Select disc icon.
y
Playback functions described in this manual
are not always available in every le and
media. Some functions can be restricted
depending on many factors.
y
Depending on the BD-ROM titles, a USB
device connection may be needed for the
proper playback.
y
Unnalized DVD-VR format discs may not
be played on this player.
y
Some DVD-VR discs are made with CPRM
data by DVD RECORDER. This unit cannot
support these kinds of discs.
,
Note
Playing Blu-ray 3D disc
e
This player can play Blu-ray 3D discs which contain
separate views for the left and the right eyes.
Preparation
In order to play Blu-ray 3D title in stereoscopic
3D mode, you need to:
y
Check your TV is 3D capable and has HDMI
input(s).
y
Wear 3D glasses to enjoy the 3D experience
if it is necessary.
y
Check whether the BD-ROM title is the Blu-
ray 3D disc or not.
y
Connect an HDMI cable (Type A, High
Speed HDMI™ Cable) between the player’s
HDMI output and TV’s HDMI input.
1. Press HOME ( ), and set the [3D Mode] option
on the [Settings] menu to [On] (page 26).
2. Insert a disc in the disc slot.
The playback starts automatically.
3. Refer to the owner’s manual of your 3D-ready
TV for the further instruction.
You may need to adjust the display settings and
focus on your TV’s setting for the improved 3D
eect.
y
Watching 3D content for a long period of
time may cause dizziness or tiredness.
y
It is not recommended for children,
pregnant women and the inrm to watch
movies in 3D mode.
y
If you are experiencing headache, tiredness
or dizziness while viewing contents in 3D,
it is strongly recommended to stop the
playback and rest until you feel normal.
>
Caution
Operating 33
Operating
4
Playing a file on disc/USB
device
yui
This player can play video, audio and photo les
contained in the disc or USB device.
1. Insert a data disc in the disc slot or connect an
USB device.
When you connect the USB device on the HOME
menu, the player plays an audio le contained in
the USB storage device automatically. If the USB
storage device is containing various types of les, a
menu for the le type selection will appear.
File loading may takes few minutes depending on
the number of content stored in the USB storage
device. Press Wheel (
) while [Cancel] is selected
to stop loading.
2. Press HOME (
).
3. Select [Smart Share] and press
Wheel ( )
.
4. Select the desired linked device in the category.
5. Select [Movie], [Photo] or [Music].
6. Select a file using
w/s/a/d
, and press
N
(Play/Pause) or
Wheel ( )
to play the file.
Notes on USB device
y
This player supports USB ash drive/external
HDD formatted in FAT32 and NTFS when
accessing les (music, photo, movie). However,
for BD-Live, use the USB ash drive / external
HDD formatted in FAT32.
y
This unit can support up to 4 partitions of the
USB device.
y
Do not extract the USB device during operation
(play, etc.).
y
An USB device which requires additional
program installation when you have connected
it to a computer, is not supported.
y
USB device: USB device that supports USB1.1
and USB2.0.
y
Video, audio and photo les can be played. For
details of operations on each le, refer to relevant
pages.
y
Regular back up is recommended to prevent
data loss.
y
If you use an USB extension cable, USB HUB or
USB Multi-reader, the USB device may not be
recognized.
y
Some USB device may not work with this unit.
y
Digital camera and mobile phone are not
supported.
y
USB Port of the unit cannot be connected to PC.
The unit cannot be used as a storage device.
Operating34
Operating
4
Playing a file on a network
server
yui
This player can play video, audio and photo les
located in a DLNA server through your home
network.
1. Check the network connection and settings
(page 17).
2. Press HOME (
).
3. Select [Smart Share] and press
Wheel ( )
.
4. Select a DLNA media server in the category.
5. Select [Movie], [Photo] or [Music].
6. Select a file using
w/s/a/d
, and press
N
(Play/Pause) or
Wheel ( )
to play the file.
y
The le requirements are described on page
60.
y
The thumbnail of the unplayable les can
be displayed, but those cannot be played
on this player.
y
The subtitle le name and video le name
have to be the same and located at the
same folder.
y
The playback and operating quality may be
aected by your home network condition.
y
You may experience connection problems
depending on your server’s environment.
y
To set your PC as a DLNA server, install the
supplied Nero MediaHome 4 on your PC.
(page 35)
,
Note
Operating 35
Operating
4
Using Home Network
Server for PC
DLNA stands for Digital Living Network Alliance,
which allows users to access video, photo and
audio les stored in server and enjoy them on TV
via home networking.
Before connecting to PC to play a le , Nero
MediaHome 4 Essentials program should be
installed on your PC.
Installing Nero MediaHome 4
Essentials
Windows
Start up your computer, and insert the supplied CD-
ROM disc into your computer’s CD-ROM drive. An
installation wizard will walk you through the quick
and uncomplicated installation process. To install
Nero MediaHome 4 Essentials, proceed as follows:
1. Close all Microsoft Windows programs and exit
any anti-virus software that may be running.
2. Insert the supplied CD-ROM disc into your
computer’s CD-ROM drive.
3. Click [Nero MediaHome 4 Essentials].
4. Click [Run] to start installation.
5. Click [Nero MediaHome 4 Essentials]. The
installation is prepared and the installation
wizard appears.
6. Click the [Next] button to display the serial
number input screen. Click [Next] to go to the
next step.
7. If you accept all conditions, click [I accept
the License Conditions] check box and click
[Next]. Installation is not possible without this
agreement.
8. Click [Typical] and click [Next]. The installation
process is started.
9. If you want to take part in the anonymous
collection of data, select the check box and click
the [Next] button.
10. Click the [Exit] button to complete the
installation.
MAC OS X
1. Start up your computer, and insert the supplied
CD-ROM disc into your computer’s CD-ROM
drive.
2. Browse the CD-ROM drive and open the
“MediaHome_4_Essentials_MAC” folder.
3. Double-click the “Nero MediaHome.dmg” image
le. The Nero MediaHome window is opened.
4. In the Nero MediaHome window, drag the Nero
MediaHome icon either to the Applications
folder within the window or to any other
desired location.
5. You can now start the application by double-
clicking the Nero MediaHome icon in the
location you dragged it to.
Sharing files and folders
On your computer, you must share the folder
contained video, audio and/or photo content to
play them on this player.
This parts explains the procedure for selecting the
shared folders on your computer.
1. Double-click the “Nero MediaHome 4 Essentials”
icon.
2. Click [Network] icon on the left and dene your
network name in the [Network name] eld. The
Network name you enter will be recognized by
your player.
3. Click [Shares] icon on the left.
4. Click [Local Folders] tab on the [Shares] screen.
5. Click [Add] icon to open the [Browse Folder]
window.
6. Select the folder containing the les you want
to share. The selected folder is added to the list
of shared folders.
7. Click [Start Server] icon to start the server.
y
If the shared folders or les are not displayed
on the player, click the folder on the [Local
Folders] tab and click [Rescan Folder] at the
[More] button.
y
Visit www.nero.com for more information
and software tools.
,
Note
Operating36
Operating
4
About Nero MediaHome 4
Essentials
Nero MediaHome 4 Essentials is a software for
sharing video, audio and photo les stored on your
computer to this unit as a DLNA-compatible digital
media server.
y
The Nero MediaHome 4 Essentials CD-
ROM is designed for PCs and should not
be inserted in this player or in any product
other than a PC.
y
The supplied Nero MediaHome 4 Essentials
CD-ROM is a customized software edition
only for sharing les and folders to this
player.
y
The supplied Nero MediaHome 4 Essentials
software does not support following
functions: Transcoding, Remote UI, TV
control, Internet services and Apple iTunes.
y
The supplied Nero MediaHome 4 Essentials
software can be downloaded at
-
Windows : http://www.nero.com/
download.php?id=nmhlgewin
-
Mac OS : http://www.nero.com/
download.php?id=nmhlgemac
y
This manual explains operations with
the English version of Nero MediaHome
4 Essentials as examples. Follow the
explanation referring to the actual
operations of your language version.
,
Note
System requirements
Windows PC
y
Windows® XP (Service Pack 2 or higher), Windows
Vista® (no Service Pack required), Windows® 7
(no Service Pack required), Windows® XP Media
Center Edition 2005 (Service Pack 2 or higher),
Windows Server® 2003
y
Windows Vista® 64-bit edition (application runs
in 32-bit mode)
y
Windows® 7 64-bit edition (application runs in
32-bit mode)
y
Hard drive space: 200 MB hard drive space for a
typical installation of Nero MediaHome stand-
alone
y
1.2 GHz Intel® Pentium® III or AMD
Sempron™ 2200+ processors
y
Memory: 256 MB RAM
y
Graphics card with at least 32 MB video memory,
minimum resolution of 800 x 600 pixels, and 16-
bit color settings
y
Windows® Internet Explorer® 6.0 or higher
y
DirectX® 9.0c revision 30 (August 2006) or higher
y
Network environment: 100 Mb Ethernet, WLAN
Macintosh
y
Mac OS X 10.5 (Leopard) or 10.6 (Snow Leopard)
y
Macintosh computer with an Intel x86 processor
y
Hard drive space: 200 MB hard drive space for a
typical installation of Nero MediaHome stand-
alone
y
Memory: 256 MB RAM
Operating 37
Operating
4
General Playback
Basic operations for video and
audio content
To stop playback
Press
Z
(STOP) during playback.
To pause playback
Press
N
(Play/Pause) during playback.
Press
N
(Play/Pause) to resume playback.
To scan forward or backward
Press and hold
C
or
V
to play fast forward or
fast reverse during playback.
You can change the various playback speeds by
pressing
c
or
v
repeatedly.
To slow down the playing speed
While the playback is paused, press
v
repeatedly
to play various speeds of slow motion.
To skip to the next/previous
chapter/track/file
During playback, press
C
or
V
to go to the
next chapter/track/le or to return to the beginning
of the current chapter/track/le.
Press
C
twice briey to step back to the previous
chapter/track/le.
In the le list menu of a server, there may have
many types of content in a folder together. In this
case, press
C
or
V
to go to the previous or
next content with same type.
Basic operations for photo
content
To play a slide show
Press
N
(Play/Pause) to start slide show.
To stop a slide show
Press
Z
(STOP) while slide show.
To pause a slide show
Press
N
(Play/Pause) while slide show.
Press
N
(Play/Pause) to re-start the slide show.
To skip to the next/previous photo
While viewing a photo in full screen, press
a
or
d
to go to the previous or next photo.
Operating38
Operating
4
Resume playback
eroyt
u
The unit records the point where you pressed the
Z
(STOP) depending on the disc.
If “
MZ
(Resume Stop)” appears on the screen
briey, press
N
(Play/Pause) to resume playback
(from the scene point).
If you press
Z
(STOP) twice or unload the disc,
“
Z
(Complete Stop)” appears on the screen. The unit
will clear the stopped point.
y
The resume point may be cleared when a
button is pressed (for example;
1
(POWER),
R
(OPEN/CLOSE), etc).
y
On BD-ROM discs with BD-J, the resume
playback function does not work.
y
If you press
Z
(STOP) once during BD-ROM
interactive title playback, the unit will be in
Complete Stop mode.
,
Note
Last scene memory
er
This unit memorizes the last scene from the last disc
that is viewed. The last scene remains in memory
even if you remove the disc from the unit or switch
o the unit. If you load a disc that has the scene
memorized, the scene is automatically recalled.
y
Last Scene Memory function for a previous
disc is erased once a dierent disc is played.
y
This function may not work depending on
the disc.
y
On BD-ROM discs with BD-J, the last scene
memory function does not work.
y
This unit does not memorize settings of
a disc if you switch o the unit before
commencing to play it.
,
Note
Operating 39
Operating
4
On-Screen Display
You can display and adjust various information and
settings about the content.
To control video playback
eroy
You can control playback and set options while
watching videos.
During playback, press INFO/MENU (
m
).
a Progress bar - Displays the current position
and total playing time.
b [Disc Menu] - Accesses menu on a disc.
c [Title/Popup] - Displays the DVD title menu
or BD-ROM’s pop-up menu, if available.
d [Option] - Displays playback information.
e [Music ID] - When connected to the network,
can provide information about the current
song during video playback.
f [Repeat] - Repeats a desired section or
sequence. (page 41)
g [3D] - Adjusts the 3D setting. (page 45)
Displaying content information on-
screen
eroy
1. During playback, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
a Title – Current title number/total number of
titles
b Chapter – Current chapter number/total
number of chapters
c Time – Elapsed playing time/total playback
time
d Audio – Selected audio language or channel
e Subtitle – Selected subtitle.
f Angle – Selected angle/total number of
angles
g TV Aspect Ratio – Selected TV aspect ratio
h Picture Mode – Selected picture mode
i Movie Information – Select this option and
press Wheel (
) to display movie information
from Gracenote Media Database (BD-ROM/
DVD only).
Operating40
Operating
4
y
If no button is pressed for a few seconds,
the on-screen display disappears.
y
A title number cannot be selected on some
discs.
y
Available items may dier depending on
discs or titles.
y
If an interactive Blu-ray Disc is playing back,
some setting information is displayed on
the screen but prohibited to be changed.
y
To use the [Movie Information] option, the
player must be connected to the broadband
internet for accessing the Gracenote Media
Database.
y
LG is a licensee of Gracenote technology
and is not responsible or liable for
information from the Gracenote Media
Database.
,
Note
To control photo view
Controls playback and sets options while viewing
pictures in full screen.
You can control playback and set options while
viewing pictures in full screen.
While viewing pictures, press INFO/MENU (
m
).
a [Slideshow] - Starts or pause slide show.
b [Music] - Select the background music for the
slide show.
c [Option] - Displays slide show options.
d [Rotate] - Rotates the photo clockwise.
e [Zoom] - Displays the [Zoom] menu.
Setting the slide show option
You can use various options during viewing a
photo in full screen.
1. While viewing pictures, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
a [Speed] - Use
a/d
to select a delaying
speed between photos in a slide show.
b [Eect] - Use
a/d
to select a transition
effect between photos in a slide show.
c [Music Select] – Select the background music
for the slide show (page 45).
Operating 41
Operating
4
Advanced Playback
Repeat playback
erotu
y
Blu-ray Disc / DVD / Video les
1. During playback, press INFO/MENU (
m
).
2. Select an [Repeat] using
a/d
, and press
Wheel ( )
A-B – Selected portion will be repeated continually.
Chapter – The current chapter will be played back
repeatedly.
Title – The current title will be played back
repeatedly.
All – All the titles or les will be played back
repeatedly.
O – Returns to normal playback.
Audio CDs/Audio les
During playback, select [Repeat] and press
Wheel
(
)
repeatedly to select a desired repeat mode.
– Selected portion will be repeated continually.
(Audio CD only)
Track– The current track or le will be played
back repeatedly.
All – All the tracks or les will be played back
repeatedly.
All – All the tracks or les will be played
back repeatedly in random order.
– The tracks or les will be played back in
random order.
This function may not work on some disc or
title.
,
Note
Repeating a specific portion
eroty
This player can repeat a portion you have selected.
1. During playback, press INFO/MENU (
m
).
2. Select an [Repeat] using
a/d
, and press
Wheel ( )
.
3. Select [A-B] and press
Wheel ( )
.
4. Press
Wheel ( )
at the beginning of the portion
you wish to repeat.
5. Press
Wheel ( )
at the end of the portion. Your
selected portion will be repeated continually.
y
You cannot select a portion less than 3
seconds.
y
This function may not work on some disc or
title.
,
Note
Playing from selected time
eroy
1. During playback, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
3. Select the [Time] option and then input the
required start time in hours, minutes, and
seconds from left to right.
For example, to nd a scene at 2 hours, 10
minutes, and 20 seconds, enter “21020”.
Press
a/d
to skip the playback 60 seconds
forward or backward.
4. Press Wheel (
) to start playback from selected
time.
y
This function may not work on some disc or
titles.
y
This function may not work depending on
the le type and ability of the DLNA server.
,
Note
Operating42
Operating
4
Selecting a subtitle language
eroy
1. During playback, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
3. Use
w/s
to select the [Subtitle] option.
4. Press
a/d
to select desired subtitle language.
By pressing
Wheel ( )
, you can set various
subtitle options.
5. Press BACK (
1
) to exit the On-Screen display.
Some discs allow you to change subtitle
selections only via the disc menu. If this is the
case, choose the appropriate subtitle from the
selections on the disc menu.
,
Note
Hearing a different audio
eroy
1. During playback, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
3. Use
w/s
to select the [Audio] option.
4. Use
a/d
to select desired audio language,
audio track or audio channel.
y
Some discs allow you to change audio
selections only via the disc menu. In this
case, choose the appropriate audio from the
selections on the disc menu.
y
Immediately after you have switched sound,
there may be a temporary discrepancy
between the display and actual sound.
y
On BD-ROM disc, the multi audio format
(5.1CH or 7.1CH) is displayed with [MultiCH]
in the on-screen display.
,
Note
Watching from a different
angle
er
If the disc contains scenes recorded at dierent
camera angles, you can change to a dierent
camera angle during playback.
1. During playback, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
3. Use
w/s
to select the [Angle] option.
4. Use
a/d
to select desired angle.
5. Press BACK (
1
) to exit the On-Screen display.
Changing the TV Aspect Ratio
eoy
You can change the TV aspect ratio setting during
playback.
1. During playback, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
3. Use
w/s
to select the [TV Aspect Ratio]
option.
4. Use
a/d
to select desired option.
5. Press BACK (
1
) to exit the On-Screen display.
Even if you change the value of the [TV Aspect
Ratio] option in On-Screen display, the [TV
Aspect Ratio] option in the [Settings] menu is
not changed.
,
Note
Operating 43
Operating
4
Changing subtitle Code Page
y
If the subtitle is displayed in broken letter, you can
change the subtitle code page to view the subtitle
le properly.
1. During playback, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
3. Use
w/s
to select the [Code Page] option.
4. Use
a/d
to select desired code option.
5. Press BACK (
1
) to exit the On-Screen display.
Changing the Picture Mode
eroy
You can change the [Picture mode] option during
playback.
1. During playback, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
3. Use
w/s
to select the [Picture Mode] option.
4. Use
a/d
to select desired option.
5. Press BACK (
1
) to exit the On-Screen display.
Setting the [User setting] option
1. During playback, press INFO/MENU (
m
).
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
3. Use
w/s
to select the [Picture Mode] option.
4. Use
a/d
to select the [User setting] option,
and press
Wheel ( )
.
5. Use
w/s/a/d
to adjust the [Picture Mode]
options.
Select [Default] option then press
Wheel ( )
to
reset the all video adjustments.
6. Use
w/s/a/d
to select the [Close] option,
and press
Wheel ( )
to nish setting.
Viewing content information
y
The player can display the content information.
1. Select a le using
w/s/a/d
.
2. Press INFO/MENU (
m
) to display the option
menu.
The le information appears on the screen.
The information displayed on the screen
may not correct comparing actual content
information.
,
Note
Operating44
Operating
4
Changing content list view
yui
On the [Smart Share] menu, you can change the
content list view.
Press red (R) colored button repeatedly.
Selecting a subtitle file
y
If the subtitle le name is dierent from the video
le name, you need to select the subtitle le on the
[Movie] menu before playing the movie.
1. Use
w/s/a/d
to select the subtitle le you
wish to play in the [Movie] menu.
2. Press
Wheel ( )
.
Press
Wheel ( )
again to deselect the subtitle
le. Selected subtitle le will be displayed when
you play the video le.
y
If you press
Z
(STOP) during playback, the
subtitle selection is cancelled.
y
This function is not available for playing le
on a server via home network.
,
Note
Operating 45
Operating
4
Listening to music during slide
show
i
You can display photo les while listening to audio
les.
1. While viewing a photo in full screen, press INFO/
MENU (
m
) to display the option menu.
2. Select an [Option] using
a/d
, and press
Wheel ( )
.
3. Use
w/s
to select [Music Select] option, and
press
Wheel ( )
to display the [Music Select]
menu.
4. Use
w/s
to select a device, and press
Wheel
(
)
.
Available device may differ depending on the
location of the current photo file.
Photo location Available Device
Disc, USB Disc, USB
DLNA server DLNA server
5. Use
w/s
to select a file or a folder you wish to
play.
Select
g
and press
Wheel ( )
to display the
upper directory.
When selecting audio le from a server, folder
selection is not available. Only le selection is
available.
,
Note
6. Use
d
to select [OK], and press
Wheel ( )
to
complete music selection.
Converting 2D content to 3D
eroy
This function allows you to convert 2D content to
3D. You can adjust 3D’s depth and distance on the
[3D] option while playing back.
1. During playback, press INFO/MENU (
m
).
2. Select an [3D], and press
Wheel ( )
.
3. Use
w/s/a/d
to select desired options.
Select [Default] option then press
Wheel ( )
to
reset the all adjustments.
4. Use
w/s/a/d
to select the [Close] option,
and press
Wheel ( )
to nish setting.
y
When you have set to Ultra HD resolution,
if you select the [On] in [3D], the Ultra HD
resolution is automatically changed to the
original resolution.
y
Movie les which is upper 30 fps (frame
rate) may not be converted to 3D.
,
Note
Operating46
Operating
4
Advanced Features
Wi-Fi Direct™
Connecting to a Wi-Fi Direct™
certified device
yui
This player can play movie, music and photo les
located in a Wi-Fi Direct™ certied device. The Wi-Fi
Direct™ technology make the player to be directely
connected to a Wi-Fi Direct™ certied device
without connecting to a network device such as an
access point.
On Wi-Fi Direct™ certied device
1. Turn on the Wi-Fi Direct™ certied device and
run its Wi-Fi Direct function.
2. Run DLNA application on the device.
On your player
3. Select [NETWORK] option in the [Settings]
menu then press
Wheel ( )
.
4. Select [Wi-Fi Direct] option, and press
Wheel
(
)
.
5. Select a Wi-Fi Direct™ device on the list using
w/s
, and press
Wheel ( )
.
Wi-Fi Direct™ connection will be proceeded.
follow the procedure on the screen.
If you want to rescan available Wi-Fi Direct™
device, Select the [Refresh List] and press
Wheel
(
)
.
To select a server from the device list, files or
folders must be shared by DLNA server from the
connected Wi-Fi Direct™ device.
6. Select [Movie], [Photo] or [Music] using
w/s/
a/d
, and press
Wheel ( )
.
7. Select a le using
w/s/a/d
, and press
Wheel ( )
to play the le.
y
For the purpose of the better transmission,
placing the player from the Wi-Fi Direct™
certied server as close as possible.
y
This unit can connect only 1 device at a
time. Multiple connection is not available.
y
If you try to connect wireless network while
a device is connected by Wi-Fi Direct™
function , Wi-Fi Direct™ connection will be
force disconnected.
y
If this player and a Wi-Fi Direct™ device
are connected to the different local area
network, Wi-Fi Direct™ connection may not
available.
y
If a Wi-Fi Direct™ certified device is not in
Wi-Fi direct standby mode, this product can
not find the device.
y
When you connect a Wi-Fi Direct™
certified device to your player, PIN network
connection is not supported.
y
This product cannot connect to a Wi-Fi
direct™ device which is in Group Owner
mode.
,
Note
Operating 47
Operating
4
Enjoying Miracast™
You can mirror Miracast certied device’s screen
and sound onto TV screen through your player
wirelessly.
On Miracast™ certied device
1. Turn on the Miracast certied device and run its
[Miracast] function.
On your player
2. Press HOME (
).
3. Select [Miracast] and press
Wheel ( )
.
4. Select a Miracast device on the list using
w/s
,
and press
Wheel ( )
.
Miracast function will be proceeded
automatically.
If you want to rescan available Miracast device,
select [Refresh List] and press
Wheel ( )
.
y
For the purpose of the better mirroring,
place Miracast certied device from the
player as close as possible.
y
This unit can connect only 1 device at a
time. Multiple connection is not available.
y
While mirroring, Wireless network or Wi-Fi
Direct cannot be used simultaneously.
y
If a Miracast certified device is not in
[Miracast] standby mode, this player cannot
find the device.
y
Depending on your wireless network
condition, mirroring may be unstable.
y
While mirroring, the screen may be cut o
depending on your TV’s setting. In this case,
please adjust the display settings on your
TV.
,
Note
Enjoying BD-Live™
e
BD-ROM supporting BD-Live that has a network
extension function allows you to enjoy more
functions such as downloading new movie trailers
by connecting this unit to the internet.
1. Check the network connection and settings
(page 17).
2. Insert an USB storage device to the USB port on
the front panel.
An USB storage device is needed to download
bonus content.
3. Press HOME (
), and set the [BD-LIVE
connection] option on the [Settings] menu
(page 23).
Depending on a disc, the BD-Live function may
not be operated if [BD-LIVE connection] option
is set to [Partially Permitted].
4. Insert a BD-ROM with BD-Live.
The operations may dier depending on the
disc. Refer to the manual supplied with the disc.
Operating48
Operating
4
Do not extract the connected USB device
while content is being downloaded or a Blu-
ray disc is still in the disc slot. Doing so may
damage the connected USB device and BD-
Live features may not operate properly with
the damaged USB device anymore. If the
connected USB device seems damaged from
such an action, you can format the connected
USB device from the PC and reuse it with this
player.
>
Caution
y
Some BD-Live content may be restrictively
accessed in some territories by content
provider’s own decision.
y
It may take up to several minutes to load
and start enjoying BD-Live content.
y
For BD-Live, use the USB ash drive /
external HDD formatted in FAT32 only.
,
Note
LG Tag On
LG Tag On allows you to install and open “LG AV
Remote” app to NFC-enabled phone.
1. Stick the supplied LG Tag On sticker on this
player.
We suggest you rst think carefully about
the sticker position, because it is dicult to
remove after sticking it once.
,
Note
2. Tag the back of your NFC-enabled phone over
the LG Tag On sticker.
-
If “LG AV Remote” app is not installed on your
NFC-enabled phone, the linked screen with
“LG AV Remote” app is displayed.
-
If “LG AV Remote” app is installed on your
NFC-enabled phone, “LG AV Remote” app is
activiated.
y
You must activate the NFC feature of your
NFC-enabled phone for Android 4.0 or later.
y
If your NFC-enabled phone’s screen is
locked, it will not read the LG Tag On sticker.
y
If your smart phone case is plated with
chrome, NFC is unavailable. Depending on
your case’s material or thickness, NFC may
not be read well.
,
Note
LG AV Remote
You can control this player with your iPhone
or Android phone via your home network. This
player and your phone must be connected to your
wireless network device such as access point. Visit
“Apple iTunes” or “Google Android Market (Google
Play Store)” for detailed information of “LG AV
Remote”.
Private Sound Mode
By downloading “LG AV Remote” application on
your smart phone or tablet, you can connect your
headsets, and enjoy the sound from your player on
your smart devices.
This feature transmits video signal to TV through
HDMI and Audio signal to smart phone or tablet
through Wi-Fi. For more detailed information,
please refer to the Help menu on “LG AV Remote”
application.
Operating 49
Operating
4
Viewing information from
Gracenote Media Database
The player can access the Gracenote Media
Database and load the music information so that
Track name, Artist Name, Genre and other text
information can be displayed on the list.
Audio CD
When you insert an Audio CD, the player starts
playback automatically and loads the music title
from the Gracenote Media Database.
If there is no music information from the database,
music titles will not appear on the screen.
Music file
Select a music le using
w/s/a/d
and press
INFO/MENU (
m
).
The player accesses to Gracenote Media Database
for the music information.
Blu-ray Disc/DVD/Movie file
1. While listening to a music from the movie being
played, press INFO/MENU (
m
).
2. Select a [Music ID] using
a/d
, and press
Wheel ( )
.
The player starts loading the music information
from the Gracenote Media Database.
y
The player must be connected to the
broadband internet for accessing the
Gracenote Media Database.
y
If the music information is not in the
Gracenote Media Database, message
appears on the screen.
y
Depending on the cases, it will takes a few
minutes to load music information from the
Gracenote Media Database.
y
Information may be displayed in broken
letters, if the language you selected is not
available on the Gracenote Media Database.
y
This function is not available for on-line
content and content in DLNA servers.
y
LG is a licensee of Gracenote technology
and is not responsible or liable for
information from the Gracenote Media
Database.
y
Audio CDs that users made for their only
private purposes cannot be supported in
this feature because they are not in the
Gracenote Media Database.
y
Supported music le extensions :
mp3, wma, m4a, wav
,
Note
Operating50
Operating
4
Audio CD recording
You can record one desired track or all of the tracks
in Audio CD to an USB storage device.
1. Insert an USB storage device to the USB port on
the front panel.
2. Insert an Audio CD into the player.
The playback starts automatically.
3. Press red (R) colored button to start [CD
Recording].
Stop mode
During
playback
Recording
track
All of the tracks playing track
Recording
time
4X speed
normal
speed.
y
For audio CD recording, use the USB ash
drive / external HDD formatted in FAT32
only.
y
Audio track is recorded to an audio le with
192 kbps.
y
Recording times in the table above are
approximate.
y
Actual recording time for USB storage
device varies depending on the USB storage
device’s ability.
y
Make sure that there is minimum of 50 MB
free space is needed when recording into
the USB storage device.
y
The length of the audio should be longer
than 20 seconds for the proper recording.
y
Do not turn o this player or extract the
connected USB storage device during Audio
CD recording.
,
Note
The recording or copying features on this
player are provided for your personal and
non-commercial use. The making of
unauthorized copies of copy-protected
material, including computer programs, les,
broadcasts and sound recordings, may be an
infringement of copyrights and constitute a
criminal oense. This equipment should not be
used for such purposes. LG expressly disclaims
any responsibility for illegal distribution or
use of unauthorized content in commercial
purpose.
Be Responsible
Respect Copyrights
>
Caution
Operating 51
Operating
4
Using the Premium
You can use various content services via Internet
with the Premium feature.
1. Check the network connection and settings
(page 17).
2. Press HOME (
).
3. Select the [Premium] using
a/d
, and press
Wheel ( )
.
4. Select an online service using
w/s/a/d
,
and press Wheel (
).
y
For detailed information of each service,
contact to the content provider or visit
support link of the service.
y
The content of Premium services and
service related information, including user
interface, is subject to changes. Please refer
to the web site of each service for most up-
to-date information.
y
Using Premium features with wireless
network connection may result in improper
streaming speed by interference from
household devices that are using radio
frequencies.
y
If you want to change the country setting,
go to [Settings] > [NETWORK] > [Smart
Service Setting] > [Country Setting]. Select
[Manual] and press
Wheel ( )
on [Country
Setting] menu.
,
Note
Using the LG Smart
World
You can use the LG application services on
this player via Internet. You can easily nd and
download various applications from LG Smart
World.
1. Check the network connection and settings
(page 17).
2. Press HOME (
).
3. Select the [LG Smart World], and press
Wheel
(
)
.
4. Select a category using
a/d
, and press
Wheel
(
)
.
5. Use
w/s/a/d
to select an application, and
press
Wheel ( )
to display the information.
6. Press
Wheel ( )
while [Install] icon is
highlighted. The application will be installed to
the player.
To install an application to the player, user
needs to sign in. Refer to page 52 for more
information of signning in.
7. Press red (R) colored button to display the [My
Apps] screen.
8. Select the installed application and press
Wheel
(
)
to excute it.
y
Depending on the region, the [LG Smart
World], [My Apps] service and [Search]
function may not be available.
y
To install a paid application, you need to be
a paid member. Visit www.lgappstv.com for
more information.
,
Note
Operating52
Operating
4
Signing in
To use the [LG Smart World] feature, you need to
sign in with your account.
1. On the home menu, select [
] icon and press
Wheel ( )
.
2. Fill the [ID] and [Password] field using the virtual
keyboard.
If you do not have an account, press red (R)
colored button to register.
3. Use
w/s/a/d
to select [OK], and press
Wheel ( )
to sign in with your account.
If you select the [Auto Sign In] check box,
your ID and password are remembered and
automatically signed in without entering them.
To view the information of your account and
applications, select [
] icon and press
Wheel
(
)
on the home menu, and select [My Page]
option.
,
Note
Searching online content
If you are having diculties nding specic content
from online services, you can use the all-in-one
search function by entering keywords in the [
]
menu.
1. Press HOME (
).
2. Select the [
] icon on the home menu using
w/s/a/d
, and press
Wheel ( )
.
The [
] menu appears on the screen.
3. Press
Wheel ( )
. The virtual keyboard appears
automatically.
4. Use
w/s/a/d
to select letters then press
Wheel ( )
to confirm your selection on the
virtual keyboard.
5. When you finish entering the keyword, select
[
] and press
Wheel ( )
to display search
result.
6. Use
w/s/a/d
to select a desired content,
and press
Wheel ( )
to move to the selected
content directly.
y
Depending on the region, the [LG Smart
World], [My Apps] service and [Search]
function may not be available.
y
The search function does not search
content in every online services. It works
only in certain online services.
,
Note
Operating 53
Operating
4
Using the My Apps
Menu
You can move or delete an installed application in
the [My Apps] menu.
1. Press HOME (
).
2. Select the [My Apps], and press
Wheel ( )
.
3. On the [My Apps] menu, press red (R) colored
button.
Move an application
1. Select an application, and press
Wheel ( )
to
display the options.
2. Use
w/s
to select [Move], and press
Wheel
(
)
.
3. Use
w/s/a/d
to select a position you want
to move to, and press
Wheel ( )
.
Delete an application
1. Select an application, and press
Wheel ( )
to
display the options.
2. Use
w/s
to select [Delete], and press
Wheel
(
)
.
3. Use
a/d
to select [OK], and press
Wheel ( )
to confirm.
Depending on the region, the [LG Smart
World], [My Apps] service and [Search]
function may not be available.
,
Note
5 Troubleshooting
Troubleshooting54
Troubleshooting
5
Troubleshooting
General
Symptom Cause & Solution
The Power does not turned on.
y
Plug the power cord into the wall outlet securely.
The unit does not start
playback.
y
Insert a playable disc. (Check the disc type, colour system, and
regional code.)
y
Insert the disc with the playback side down.
y
Clean the disc.
y
Cancel the Rating function or change the rating level.
The connected USB storage
device is not recognized.
y
Try using dierent USB cable, some USB cables may not support
enough current for normal USB operation.
y
If you use an USB extension cable or USB HUB, the USB devices may
not be recognized.
y
An USB device which requires additional program installation when
you have connected it to a computer is not supported.
y
This unit supports only USB Flash Drive and USB External HDD with
FAT32 or NTFS format.
The angle cannot be changed.
y
Multi-angles are not recorded on the DVD Video being played.
Cannot play movie, photo or
music les.
y
The les are not recorded in a format that the unit can play.
y
The unit does not support the codec of the movie le.
The remote control does not
work properly.
y
The remote control is not pointed at the remote sensor of the unit.
y
The remote control is too far from the unit.
y
There is an obstacle in the path of the remote control and the unit.
y
The batteries in the remote control are exhausted.
The unit is plugged in, but the
power will not turn on or o.
You can reset the unit as follows.
y
Unplug the power cord, wait at least ve seconds, and then plug it in
again.
The unit is not operating
normally.
Troubleshooting 55
Troubleshooting
5
Network
Symptom Cause & Solution
BD-Live feature does not work.
y
The connected USB storage may not have enough space. Connect
the USB storage with at least 1GB free space.
y
Ensure that the unit is correctly connected to the local area network
and can access the internet (see page 17).
y
Your broadband speed may not fast enough to use the BD-Live
features. Contact your Internet Service Provider (ISP) and increase the
broadband speed is recommended.
y
The [BD-LIVE connection] option in the [Settings] menu is set to
[Prohibited]. Set the option to [Permitted].
Streaming video services (such
as YouTube™, etc.) are often
stopped or “buer” during
playback.
y
Your broadband service speed may not be fast enough to stream
video services. Contact your Internet Service Provider (ISP) and
increase the broadband speed is recommended.
Media servers are not displayed
on the device list.
y
The rewall or anti-virus software on your media server is running.
Turn o the rewall or anti-virus software running on your media
server.
y
The player is not connected to the local area network that your media
server is connected.
Cannot connect the player to
the access point or wireless
LAN router.
y
The wireless communication may be interrupted from household
devices that are using radio frequencies. Move the player away from
them.
Access point is not displayed
on the “Access point name” list.
y
The access point or wireless LAN router may not broadcast its SSID.
Set your access point to broadcast its SSID through your computer.
y
Your network device such as access point may not set with available
frequency range and channel that this player can support.
Try setting the frequency range and channel on the network device
setting.
Troubleshooting56
Troubleshooting
5
Symptom Cause & Solution
There is no picture.
y
Select the appropriate video input mode on the TV so the picture
from the unit appears on the TV screen.
y
Connect the video connection securely.
y
Check the [HDMI Color Setting] in the [Settings] menu is set to the
appropriate item that conforms to your video connection.
y
Your TV may not support the resolution you have set on the player.
Change the resolution that your TV accepts.
y
The player’s HDMI OUT jack is connected to a DVI device that does
not support copyright protection.
Picture noise appears.
y
You are playing a disc recorded in a colour system that is dierent
from your TV.
y
Set the resolution which your TV accepts.
Blu-ray 3D disc playback does
not output 3D views.
y
Connect the player to your TV with HDMI cable (Type A, High Speed
HDMI™ Cable).
y
Your TV may not support “HDMI 3D mandatory format”.
y
The [3D Mode] option in the [Settings] menu is set to [O ].
Set the option to [On].
Customer support
You can update the Player using the latest software to enhance the products operation and/or add new
features. To obtain the latest software for this player (if updates have been made), please visit
http://www.lg.com/global/support or contact LG Electronics customer care centre.
Open source software notice
To obtain the corresponding source code under GPL, LGPL and other open source licenses, please visit
http://opensource.lge.com. All referred license terms, warranty disclaimers and copyright notices are
available to download with the source code.
6 Appendix
Appendix 57
Appendix
6
About Magic Remote
Control
To re-register the Magic remote
control
Press the HOME ( ) and BACK (
1
) buttons at the
same time for about 5 seconds. The Magic remote
control will be unpaired with your unit.
y
Press the BACK (
1
) button while pointing
the remote control at the unit for 5 seconds
to reset and re-register it.
y
Set the speed and the shape of the Magic
pointer that appears on the screen. Refer
to the setting of the Magic pointer (page
30).
y
If the Magic pointer has not been used for
a certain period of time, it will disappear.
When the Magic pointer disappears from
the screen, shake the Magic remote control
to the right and left. Then, it appears again.
y
If you press the navigation button while
moving the Magic pointer on the screen,
the Magic pointer disappears, and the
Magic remote control works as a regular
remote control.
,
Note
y
Use within an eective distance of 33 ft. (10
meters). Using the Remote Control from
greater distances or when obstructions
block the sight line may cause malfunctions.
y
Electronic devices nearby may cause
communication interference. Devices such
as microwave oven and wireless LAN use
the same frequency range (2.4 GHz) as the
Magic remote control, which may interfere
with the remote control.
y
The Magic remote control may be broken if
dropped or damaged in any other way.
y
Do not drop or subject the Magic remote
control to heavy impacts.
>
Caution
Appendix58
Appendix
6
Network Software
Update
Network update notification
From time to time, performance improvements
and/or additional features or services may be
made available to units that are connected to a
broadband home network. If there is new software
available and the unit is connected to a broadband
home network, the player will inform you about the
update as follows.
Option 1:
1. The update menu will appear on the screen
when you turn off the player.
2. Use
a/d
to select a desired option and then
press
Wheel ( )
.
[OK] Starts the software update.
[Cancel]
Exits the update menu and turns
the power o.
Option 2:
If the software update is available from the update
server, the “Update” icon appears in the Home
menu. Press blue (B) colored button to start the
update procedure.
Software update
You can update the player using the latest software
to enhance the products operation and/or add
new features. You can update the software by
connecting the unit directly to the software update
server.
y
Before updating the software in your player,
remove any disc and USB Device from the
player.
y
Before updating the software in your player,
turn the player o and then turn it back on.
y
During the software update procedure,
do not turn o the player or disconnect
AC power, or do not press any button.
y
If you cancel the update, turn o the power
and turn it on for stable performance.
y
This unit cannot be updated to previous
software version.
,
Note
1. Check the network connection and settings
(page 17).
2. Select [Software] option in the [Settings] menu
then press
Wheel ( )
.
3. Select [Update] option, and press
Wheel ( )
.
The player will check for the newest update.
y
Pressing
Wheel ( )
while checking for the
update will end the process.
y
If there is no update available, the Message,
“No update is found.” appears. Press
Wheel
(
)
to return to the [Home] menu.
,
Note
Appendix 59
Appendix
6
4. If newer version exists, the message “Do you
want to download it?” appears.
5. Select [OK] to start update. (Selecting [Cancel]
will end the update.)
6. The player starts downloading the newest
update from the server. (Downloading will
takes several minutes depending on your home
network condition)
7. When downloading is completed, the message,
“Download is complete. Do you want to
update?” appears.
8. Select [OK] to start updating. (Selecting [Cancel]
will end the update and downloaded file will
not be re-usable. To update software the next
time, the software update procedure has to be
started from the beginning again.)
Do not turn o the power during the software
update.
>
Caution
9. When update is completed, the power will be
turned off automatically in a few seconds.
10. Turn the power back on. The system now
operates with the new version.
The Software Update function may not
work properly depending on your internet
environment. In this case, you can obtain
the latest software from the authorized LG
Electronics Service Center then update your
player. Refer to “Customer support” on page
56.
,
Note
Appendix60
Appendix
6
Additional Information
File requirement
Video files
File
Location
File
Extension
Codec Format
Audio
Format
Subtitle
Disc,
USB
“.avi”, “.mpg”, “.mpeg”,
“.mkv”, “.mp4”, “.asf”,
“.wmv”, “.m4v” (DRM
free), “.vob”, “.3gp”,
“.mov”, “.trp”, “.m2t”,
“.mpe”, “.m1v”, “.m2v”,
“.wm”, ”.v”, “.ts”, “.dat”
XVID, MPEG1 SS, H.264/
MPEG-4 AVC, MPEG2
PS, MPEG2 TS, VC-1 SM
(WMV3)
Dolby
Digital,
DTS, MP3,
WMA, AAC,
AC3
SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt),
MicroDVD (.sub/.txt), VobSub
(.sub), SubViewer 1.0 (.sub),
SubViewer 2.0 (.sub/.txt),
TMPlayer (.txt), DVD Subtitle
System (.txt)
DLNA
“.avi”, “.mpg”, “.mpeg”,
“.mkv”, “.mp4”, “.asf”,
“.wmv”, “.m4v” (DRM
free), “.mov”, “.trp”,
“.m2t”, “.mpe”, “.m1v”,
“.m2v”, ”.v”, “.ts”
XVID, MPEG1 SS, H.264/
MPEG-4 AVC, MPEG2
PS, MPEG2 TS, VC-1 SM
(WMV3)
Dolby
Digital,
DTS, MP3,
WMA, AAC,
AC3
SubRip (.srt / .txt), SAMI
(.smi), SubStation Alpha
(.ssa/.txt), MicroDVD (.sub/.
txt), SubViewer 1.0 (.sub),
SubViewer 2.0 (.sub/.txt),
TMPlayer (.txt), DVD Subtitle
System (.txt)
Audio files
File
Location
File
Extension
Sampling Frequency Bitrate Note
Disc,
USB
“mp3”, “.wma”,
“.wav”, “.m4a”
(DRM free),
“.ac”
within 32 - 48 kHz
(WMA), within 16 - 48
kHz (MP3)
within 32 - 192 kbps
(WMA), within 32 - 320
kbps (MP3)
Some wav les are
not supported on
this player.
DLNA
“mp3”, “.wma”,
“.wav”, “.m4a”
(DRM free)
within 32 - 48 kHz
(WMA), within 16 - 48
kHz (MP3)
within 32 - 192 kbps
(WMA), within 32 - 320
kbps (MP3)
Some wav les are
not supported on
this player.
Photo files
File
Location
File
Extension
Recommended
Size
Note
Disc,
USB,
DLNA
“.jpg”, “.jpeg”,
“.png”, “.gif”
Less than 4,000 x 3,000 x 24 bit/pixel
Less than 3,000 x 3,000 x 32 bit/pixel
Progressive and lossless
compression photo image les
are not supported.
y
Supplied bundle DLNA server for Macintosh edition has limitations in le compatibility, such as ASF, WMA
and WMV.
Appendix 61
Appendix
6
y
The le name is limited to 180 characters.
y
Maximum les/Folder: Less than 2000 (total
number of les and folders)
y
Depending on the size and number of the
les, it may take several minutes to read the
content on the media.
y
File compatibility may dier depending on
the server.
y
Because the compatibility on DLNA server
are tested on the bundle DLNA server
(Nero MediaHome 4 Essentials Windows
edition) environment, le requirements and
playback functions may dier depending on
media servers.
y
The le requirements on page 60 are
not always compatible. There may have
some restrictions by le features and media
server’s ability.
y
Playing video subtitle les are only available
on DLNA media server created by supplied
Nero MediaHome 4 Essentials software on
this player package.
y
The les from removable media such as USB
drive, DVD-drive etc. on your media server
may not be shared properly.
y
This unit cannot support the ID3 Tag
embedded MP3 le.
y
The total playback time of audio le
indicated on the screen may not correct for
VBR les.
y
HD video les contained on the CD/DVD or
USB 1.0/1.1 may not played properly.
Blu-ray Disc or USB 2.0 are recommended to
play back HD video les.
y
This player supports H.264/MPEG-4 AVC
prole Main, High at Level 4.1. A le with
higher level may not be supported.
y
This player does not support les that are
recorded with GMC
*
1
or Qpel
*
2
.
*1 GMC – Global Motion Compensation
*2 Qpel – Quarter pixel
,
Note
y
A “avi” le which is encoded “WMV 9 codec”
is not supported.
y
This player supports UTF-8 les even it
contains Unicode subtitle content. This
player can not support the pure Unicode
subtitle les.
y
Depending on the types of le or ways of
recording, it may not play back.
y
A disc which was recorded by multi-session
on normal PC is not supported on this
player.
y
To be playback a video le, video le name
and Subtitle le name must be the same.
y
When you play a video le with a extension
such as “.ts”, “.m2ts”, “.mts”, “.tp”, “.Trp” or “.m2t”,
your player may not support subtitle les.
y
The total playback time of audio le
indicated on the screen may not correct for
VBR les.
y
Video / Audio codec compatibility may
dier depending on video le.
,
Note
AVCHD (Advanced Video
Codec High Definition)
y
This player can playback AVCHD format discs.
These discs are normally recorded and used in
camcorders.
y
The AVCHD format is a high denition digital
video camera format.
y
The MPEG-4 AVC/H.264 format is capable of
compressing images at higher eciency than
that of the conventional image compressing
format.
y
This player can playback AVCHD discs using
“x.v.Color” format.
y
Some AVCHD format discs may not play
depending on the recording condition.
y
AVCHD format discs need to be nalized.
y
“x.v.Color” oers a wider color range than normal
DVD camcorder discs.
Appendix62
Appendix
6
About DLNA
This Player is a DLNA Certied digital media player
that can display and play video, photo and audio
content from your DLNA-compatible digital media
server (PC and Consumer Electronics).
The Digital Living Network Alliance (DLNA) is a
cross-industry organization of consumer electronics,
computing industry and mobile device companies.
Digital Living provides consumers with easy sharing
of digital media through your home network.
The DLNA certication logo makes it easy
to nd products that comply with the DLNA
Interoperability Guidelines. This unit complies with
DLNA Interoperability Guidelines v1.5.
When a PC running DLNA server software or
other DLNA compatible device is connected to
this player, some setting changes of software or
other devices may be required. Please refer to the
operating instructions for the software or device for
more information.
Certain system requirements
For high denition video playback:
y
High denition display that has HDMI input jack.
y
BD-ROM disc with high denition content.
y
HDMI or HDCP capable DVI input on your display
device is required for some content (as specied
by disc authors).
For Dolby® Digital Plus, Dolby TrueHD and DTS-HD
multi-channel audio playback:
y
An amplier/receiver with a built-in (Dolby
Digital, Dolby Digital Plus, Dolby TrueHD, DTS or
DTS-HD) decoder.
y
Main, center, surround speakers and subwoofer
as necessary for chosen format.
Compatibility notes
y
Because BD-ROM is a new format, certain disc,
digital connection and other compatibility issues
are possible. If you experience compatibility
problems, please contact an authorized
Customer Service Center.
y
This unit allows you to enjoy functions such
as picture-in-picture, secondary audio and
Virtual packages, etc., with BD-ROM supporting
BONUSVIEW (BD-ROM version 2 Prole 1 version
1.1). Secondary video and audio can be played
from a disc compatible with the picture-in-
picture function. For the playback method, refer
to the instructions in the disc.
y
Viewing high-denition content and up-
converting standard DVD content may require a
HDMI-capable input or HDCP-capable DVI input
on your display device.
y
Some BD-ROM and DVD discs may restrict the
use of some operation commands or features.
y
Dolby TrueHD, Dolby Digital Plus and DTS-HD are
supported with maximum 7.1 channels if you
use HDMI connection for the audio output of the
unit.
y
You can use an USB device to store some disc
related information, including downloaded
online content. The disc you are using will
control how long this information is retained.
Appendix 63
Appendix
6
Audio Output Specifications
Jack/Setting
Source
OPTICAL (DIGITAL AUDIO OUT)
*
3
PCM Stereo
DTS Re-encode
*
4
BitStream
Dolby Digital PCM 2ch DTS Dolby Digital
Dolby Digital Plus PCM 2ch DTS Dolby Digital
Dolby TrueHD PCM 2ch DTS 2ch Dolby Digital
AAC PCM 2ch DTS AAC
DTS PCM 2ch DTS DTS
DTS-HD PCM 2ch DTS DTS
Linear PCM 2ch PCM 2ch DTS PCM 2ch
Linear PCM 5.1ch PCM 2ch DTS PCM 2ch
Linear PCM 7.1ch PCM 2ch DTS PCM 2ch
Jack/Setting
Source
HDMI OUT
PCM Stereo PCM
Multi-Ch
DTS Re-encode
*
4
BitStream
*
1
*
2
Dolby Digital PCM 2ch PCM 2ch DTS Dolby Digital
Dolby Digital Plus PCM 2ch PCM 2ch DTS Dolby Digital Plus
Dolby TrueHD PCM 2ch PCM 2ch
DTS 2ch
Dolby TrueHD
AAC PCM 2ch DTS AAC
DTS PCM 2ch PCM 5.1ch DTS DTS
DTS-HD PCM 2ch PCM 7.1ch DTS DTS-HD
Linear PCM 2ch PCM 2ch PCM 2ch DTS Linear PCM 2ch
Linear PCM 5.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 5.1ch
Linear PCM 7.1ch PCM 2ch PCM 7.1ch DTS Linear PCM 7.1ch
*1 The secondary and interactive audio may not
be included in the output bitstream if [Digital
Output] option is set to [BitStream]. (Except
LPCM Codec : the output always include
interactive and secondary audio.)
*2 This player automatically selects the HDMI audio
according to the decoding capability of the
connected HDMI device even though [Digital
Output] option is set to [BitStream].
*3 On the PCM audio output, the sampling
frequency of DIGITAL AUDIO OUT is limited to
96 kHz.
*4 If the [Digital Output] option is set to [DTS re-
encode], the audio output is limited to 48 kHz
and 5.1Ch. If the [Digital Output] option is set
to [DTS re-encode], the DTS Re-encode audio
is outputted for BD-ROM discs, and the original
audio is outputted for the other discs (like
[BitStream]).
y
If the HDMI OUT jack is connected to your TV
with High Speed HDMI™ Cable and Dolby Digital
Plus/Dolby TrueHD is outputted from HDMI OUT
jack, DIGITAL AUDIO OUT jack is limited to “PCM
2ch” (When the HDMI and DIGITAL AUDIO OUT
are connected simultaneously).
PCM 2ch
Appendix64
Appendix
6
y
The audio is outputted as PCM 48 kHz/16 bit for
MP3/WMA le and PCM 44.1kHz/16 bit for Audio
CD during playback.
y
You must select a digital audio output and
a maximum sampling frequency that your
Amplier (or AV receiver) accepts using [Digital
Output] and [Sampling Freq.] options on the
[Settings] menu (page 27).
y
With digital audio connection (DIGITAL AUDIO
OUT or HDMI OUT), Disc Menu button sounds of
BD-ROM may not be heard if the [Digital Output]
option is set to [BitStream].
y
If the audio format of the digital output does
not match the capabilities of your receiver, the
receiver will produce a strong, distorted sound
or no sound at all.
y
Multi-channel Digital Surround Sound via digital
connection can only be obtained if your receiver
is equipped with a Digital Multi-channel decoder.
Appendix 65
Appendix
6
Area Code List
Choose an area code from this list.
Area Code Area Code Area Code Area Code
Afghanistan AF
Argentina AR
Australia AU
Austria AT
Belgium BE
Bhutan BT
Bolivia BO
Brazil BR
Cambodia KH
Canada CA
Chile CL
China CN
Colombia CO
Congo CG
Costa Rica CR
Croatia HR
Czech Republic CZ
Denmark DK
Ecuador EC
Egypt EG
El Salvador SV
Ethiopia ET
Fiji FJ
Finland FI
France FR
Germany DE
Great Britain GB
Greece GR
Greenland GL
Hong Kong HK
Hungary HU
India IN
Indonesia ID
Israel IL
Italy IT
Jamaica JM
Japan JP
Kenya KE
Kuwait KW
Libya LY
Luxembourg LU
Malaysia MY
Maldives MV
Mexico MX
Monaco MC
Mongolia MN
Morocco MA
Nepal NP
Netherlands NL
Antilles AN
New Zealand NZ
Nigeria NG
Norway NO
Oman OM
Pakistan PK
Panama PA
Paraguay PY
Philippines PH
Poland PL
Portugal PT
Romania RO
Russian
Federation RU
Saudi Arabia SA
Senegal SN
Singapore SG
Slovak Republic SK
Slovenia SI
South Africa ZA
South Korea KR
Spain ES
Sri Lanka LK
Sweden SE
Switzerland CH
Taiwan TW
Thailand TH
Turkey TR
Uganda UG
Ukraine UA
United States US
Uruguay UY
Uzbekistan UZ
Vietnam VN
Zimbabwe ZW
Appendix66
Appendix
6
Language Code List
Use this list to input your desired language for the following initial settings: [Disc Audio],
[Disc Subtitle] and [Disc Menu].
Language Code Language Code Language Code Language Code
Afar 6565
Afrikaans 6570
Albanian 8381
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Aymara 6588
Azerbaijani 6590
Bashkir 6665
Basque 6985
Bengali; Bangla 6678
Bhutani 6890
Bihari 6672
Breton 6682
Bulgarian 6671
Burmese 7789
Byelorussian 6669
Chinese 9072
Croatian 7282
Czech 6783
Danish 6865
Dutch 7876
English 6978
Esperanto 6979
Estonian 6984
Faroese 7079
Fiji 7074
Finnish 7073
French 7082
Frisian 7089
Galician 7176
Georgian 7565
German 6869
Greek 6976
Greenlandic 7576
Guarani 7178
Gujarati 7185
Hausa 7265
Hebrew 7387
Hindi 7273
Hungarian 7285
Icelandic 7383
Indonesian 7378
Interlingua 7365
Irish 7165
Italian 7384
Japanese 7465
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kirghiz 7589
Korean 7579
Kurdish 7585
Laotian 7679
Latin 7665
Latvian, Lettish 7686
Lingala 7678
Lithuanian 7684
Macedonian 7775
Malagasy 7771
Malay 7783
Malayalam 7776
Maori 7773
Marathi 7782
Moldavian 7779
Mongolian 7778
Nauru 7865
Nepali 7869
Norwegian 7879
Oriya 7982
Panjabi 8065
Pashto, Pushto 8083
Persian 7065
Polish 8076
Portuguese 8084
Quechua 8185
Rhaeto-Romance 8277
Rumanian 8279
Russian 8285
Samoan 8377
Sanskrit 8365
Scots Gaelic 7168
Serbian 8382
Serbo-Croatian 8372
Shona 8378
Sindhi 8368
Singhalese 8373
Slovak 8375
Slovenian 8376
Spanish 6983
Sudanese 8385
Swahili 8387
Swedish 8386
Tagalog 8476
Tajik 8471
Tamil 8465
Telugu 8469
Thai 8472
Tonga 8479
Turkish 8482
Turkmen 8475
Twi 8487
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapük 8679
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 7473
Yoruba 8979
Zulu 9085
Appendix 67
Appendix
6
Trademarks and
Licenses
Blu-ray Disc™, Blu-ray™, Blu-ray 3D™, BD-Live™,
BONUSVIEW™ and the logos are trademarks of
the Blu-ray Disc Association.
“DVD Logo” is a trademark of DVD Format/Logo
Licensing Corporation.
Java is a trademark of Oracle and/or its aliates.
The terms HDMI and HDMI High-Denition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
“x.v.Colour” is a trademark of Sony Corporation.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535;
7,212,872; 7,333,929; 7,392,195; 7,272,567 & other
U.S. and worldwide patents issued & pending.
DTS-HD, the Symbol, & DTS-HD and the Symbol
together are registered trademarks & DTS-HD
Master Audio is a trademark of DTS, Inc. Product
includes software. © DTS, Inc. All Rights Reserved.
DLNA®, the DLNA Logo and DLNA CERTIFIED® are
trademarks, service marks, or certication marks
of the Digital Living Network Alliance.
The Wi-Fi CERTIFIED Logo is a certication mark
of the Wi-Fi Alliance.
The Wi-Fi Protected Setup Mark is a trademark of
the Wi-Fi Alliance.
“AVCHD” and the “AVCHD” logo are trademarks of
Panasonic Corporation and Sony Corporation.
Appendix68
Appendix
6
Gracenote®, Gracenote logo and logotype,
and the “Powered by Gracenote” logo are
either registered trademarks or trademarks of
Gracenote, Inc. in the United States and/or other
countries.
Music recognition technology and related data
are provided by Gracenote®.
Portions of the content is copyright © Gracenote
or its providers.
Gracenote® End User License Agreement
This application or device contains software from
Gracenote, Inc. of Emeryville, California
(“Gracenote”). The software from Gracenote (the
“Gracenote Software”) enables this application to
perform disc and/or le identication and obtain
music-related information, including name, artist,
track, and title information (“Gracenote Data”) from
online servers or embedded databases (collectively,
“Gracenote Servers”) and to perform other
functions. You may use Gracenote Data only by
means of the intended End-User functions of this
application or device.
You agree that you will use Gracenote Data, the
Gracenote Software, and Gracenote Servers for
your own personal non-commercial use only. You
agree not to assign, copy, transfer or transmit the
Gracenote Software or any Gracenote Data to any
third party. YOU AGREE NOT TO USE OR EXPLOIT
GRACENOTE DATA, THE GRACENOTE SOFTWARE,
OR GRACENOTE SERVERS, EXCEPT AS EXPRESSLY
PERMITTED HEREIN.
You agree that your non-exclusive license to use
the Gracenote Data, the Gracenote Software, and
Gracenote Servers will terminate if you violate
these restrictions. If your license terminates, you
agree to cease any and all use of the Gracenote
Data, the Gracenote Software, and Gracenote
Servers. Gracenote reserves all rights in Gracenote
Data, the Gracenote Software, and the Gracenote
Servers, including all ownership rights. Under no
circumstances will Gracenote become liable for
any payment to you for any information that you
provide. You agree that Gracenote, Inc. may enforce
its rights under this Agreement against you directly
in its own name.
The Gracenote service uses a unique identier to
track queries for statistical purposes. The purpose of
a randomly assigned numeric identier is to allow
the Gracenote service to count queries without
knowing anything about who you are. For more
information, see the web page for the Gracenote
Privacy Policy for the Gracenote service.
The Gracenote Software and each item of
Gracenote Data are licensed to you “AS IS.”
Gracenote makes no representations or warranties,
express or implied, regarding the accuracy of any
Gracenote Data from in the Gracenote Servers.
Gracenote reserves the right to delete data from
the Gracenote Servers or to change data categories
for any cause that Gracenote deems sucient. No
warranty is made that the Gracenote Software or
Gracenote Servers are error-free or that functioning
of Gracenote Software or Gracenote Servers will
be uninterrupted. Gracenote is not obligated to
provide you with new enhanced or additional data
types or categories that Gracenote may provide in
the future and is free to discontinue its services at
any time.
GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND
NON-INFRINGEMENT. GRACENOTE DOES NOT
WARRANT THE RESULTS THAT WILL BE OBTAINED
BY YOUR USE OF THE GRACENOTE SOFTWARE
OR ANY GRACENOTE SERVER. IN NO CASE WILL
GRACENOTE BE LIABLE FOR ANY CONSEQUENTIAL
OR INCIDENTAL DAMAGES OR FOR ANY LOST
PROFITS OR LOST REVENUES.
© Gracenote, Inc. 2009
Appendix 69
Appendix
6
Cinavia Notice
This product uses Cinavia technology to limit the
use of unauthorized copies of some commercially-
produced lm and videos and their soundtracks.
When a prohibited use of an unauthorized copy is
detected, a message will be displayed and playback
or copying will be interrupted.
More information about Cinavia technology
is provided at the Cinavia Online Consumer
Information Center at http://www.cinavia.com. To
request additional information about Cinavia by
mail, send a postcard with your mailing address
to: Cinavia Consumer Information Center, P.O. Box
86851, San Diego, CA, 92138, USA.
This product incorporates proprietary technology
under license from Verance Corporation and is
protected by U.S. Patent 7,369,677 and other U.S.
and worldwide patents issued and pending as well
as copyright and trade secret protection for certain
aspects of such technology. Cinavia is a trademark
of Verance Corporation. Copyright 2004-2012
Verance Corporation. All rights reserved by Verance.
Reverse engineering or disassembly is prohibited.
Appendix70
Appendix
6
Specifications
General
Power requirements Refer to main label on the rear panel.
Power consumption 16 W
Dimensions (W x H x D) Approx. 430 mm x 37.5 mm x 203 mm (17” x 1.5” x 8”)
Net Weight (Approx.) 1.6 kg (3.5 lbs)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Outputs
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL AUDIO OUT (OPTICAL) 3 V (p-p), Optical jack x 1
System
Laser Semiconductor laser
Wavelength 405 nm / 650 nm
Signal system Standard NTSC colour TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna)
Integrated IEEE 802.11n (5 GHz and 2.4 GHz bands) wireless
networking access, compatible with 802.11a/b/g Wi-Fi networks.
Bus Power Supply (USB) DC 5 V
0
500 mA
y
Design and specications are subject to change without notice.
Appendix 71
Appendix
6
Maintenance
Handling the unit
When shipping the unit
Please save the original shipping carton and
packing materials. If you need to ship the unit, for
maximum protection, re-pack the unit as it was
originally packed at the factory.
Cleaning the unit
To clean the player, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not
use strong solvents such as alcohol, benzine, or
thinner, as these might damage the surface of the
unit.
Keeping the exterior surfaces clean
y
Do not use volatile liquids such as insecticide
spray near the unit.
y
Wiping with strong pressure may damage the
surface.
y
Do not leave rubber or plastic products in
contact with the unit for a long period of time.
Maintaining the unit
The unit is a high-tech, precision device. If the
optical pick-up lens and disc drive parts are dirty
or worn, the picture quality could be diminished.
For details, please contact your nearest authorized
service centre.
Notes on discs
Handling discs
Do not touch the playback side of the disc. Hold
the disc by the edges so that ngerprints do not
get on the surface. Never stick paper or tape on the
disc.
Storing discs
After playing, store the disc in its case. Do not
expose the disc to direct sunlight or sources of heat
and never leave it in a parked car exposed to direct
sunlight.
Cleaning discs
Fingerprints and dust on the disc can cause poor
picture quality and sound distortion. Before playing,
clean the disc with a clean cloth. Wipe the disc from
the centre to out.
Do not use strong solvents such as alcohol,
benzine, thinner, commercially available cleaners,
or anti-static spray intended for older vinyl records.
Appendix72
Appendix
6
Important Information
Relating to Network
Services
All information, data, documents, communications,
downloads, les, text, images, photographs,
graphics, videos, webcasts, publications, tools,
resources, software, code, programs, applets,
widgets, applications, products and other content
(“Content”) and all services and oerings (“Services”)
provided or made available by or through any
third party (each a “Service Provider”) is the sole
responsibility of the Service Provider from whom it
originated.
The availability of and access to Content and
Services furnished by the Service Provider through
the LGE Device are subject to change at any time,
without prior notice, including, but not limited to
the suspension, removal or cessation of all or any
part of the Content or Services.
Should you have any inquiry or problem related
to the Content or Services, you may refer to the
Service Provider’s website for the most up-to-
date information. LGE is neither responsible nor
liable for customer service related to the Content
and Services. Any question or request for service
relating to the Content or Services should be made
directly to the respective Content and Service
Providers.
Please note that LGE is not responsible for any
Content or Services provided by the Service
Provider or any changes to, removal of, or cessation
of such Content or Services and does not warrant
or guaranty the availability of or access to such
Content or Services.
