RC7793CML.AA1ULL_RV0011V_ENG
Before
connecting,
operating
or
adjusting
this
product,
please
read
this
owner's
manual
carefully
and
completely.
VCR
&
DVD
RECORDER
OWNER'S
MANUAL
MODEL:
LRY-517
Call
us
and
we
will
guide
you
through
your
first
recording,
for free.
1-800-243-0000
2
This
lightning
flash
with
arrowhead
symbol
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
uninsulated
dangerous
voltage
within
the
product's
enclosure
that
may
be
of
sufficient
magnitude
to
constitute
a
risk
of
electric
shock
to
persons.
The
exclamation
point
within
an
equilateral
trian-
gle
is
intended
to
alert
the
user
to
the
presence
of
important
operating
and
maintenance
(servic-
ing)
instructions
in
the
literature
accompanying
the
product.
WARNING:
Do
not
install
this
equipment
in
a
confined
space
such
as a
bookcase
or
similar
unit.
CAUTION:
This
product
employs
a
Laser
System.
To
ensure
proper
use
of
this
product,
please
read
this
owner's
manual
carefully
and
retain
it
for
future
reference.
Should
the
unit
require
maintenance,
contact
an
authorized
service
center.
Performing
controls,
adjustments,
or
carrying
out
proce-
dures
other
than
those
specified
herein
may
result
in
haz-
ardous
radiation
exposure.
To
prevent
direct
exposure
to
laser
beam,
do
not
try
to
open
the
enclosure.
Visible
laser
radiation
when
open.
DO
NOT
STARE
INTO
BEAM.
CAUTION:
The
apparatus
should
not
be
exposed
to
water
(dripping
or
splashing)
and
no
objects
filled
with
liquids,
such
as
vases,
should
be
placed
on
the
apparatus.
CAUTION:
CLASS
2M
VISIBLE
AND
INVISIBLE
LASER
RADIATION
WHEN
OPEN
AND
INTERLOCKS
DEFEATED
DO
NOT
STARE
INTO
THE
BEAM
OR
VIEW
DIRECTLY
WITH
OPTICAL
INSTRUMENTS
FCC
WARNING:
This
equipment
may
generate
or
use
radio
frequency
energy.
Changes
or
modifications
to
this
equipment
may
cause
harmful
interference
unless
the
modifications
are
expressly
approved
in
the
instruction
manual.
The
user
could
lose
the
authority
to
operate
this
equipment
if
an
unauthorized
change
or
modification
is
made.
REGULATORY
INFORMATION:
FCC
Part
15
This
epuipment
has
been
tested
and
found
to
comply
with
the
limits
for
a
Class
B
digital
device,
pursuant
to
Part
15
of
the
FCC
Rules.
These
limits
are
designed
to
provide
reasonable
protection
against
harmful
interference
when
the
product
is
operated
in
a
residential
installation.
This
product
generates,
uses,
and
can
radiate
radio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instruction
manual,
may
cause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
that
interference
will
not
occur
in
a
particular
installation.
If
this
product
does
cause
harmful
interference
to
radio
or
televi-
sion
reception,
which
can
be
determined
by
turning
the
product
off
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
the
following
measures:
?
Reorient
or
relocate
the
receiving
antenna.
?
Increase
the
separation
between
the
product
and
receiver.
?
Connect
the
product
into
an
outlet
on
a
circuit
differ-
ent
from
that
to
which
the
receiver
is
connected.
?
Consult
the
dealer
or
an
experienced
radio/TV
tech-
nician
for
help.
FCC
COMPLIANCE:
The
responsible
party
for this
prod-
uct's
compliance
is:
LG
Electronics
U.S.A.,
Inc.,1000
Sylvan
Avenue,
Englewood
Cliffs,
NJ.
Phone: 1-800-243-0000.
CAUTION
concerning
the
Power
Cord
Most
appliances
recommend
they
be
placed
upon
a
dedicated
circuit;
That
is,
a
single
outlet
circuit
which
powers
only
that
appli-
ance
and
has
no
additional
outlets
or
branch
circuits.
Check
the
specification
page
of
this
owner's
manual
to
be
certain.
Do
not
overload
wall
outlets.
Overloaded
wall
outlets,
loose
or
damaged
wall
outlets,
extension
cords,
frayed
power
cords,
or
damaged
or
cracked
wire
insulation
are
danger-
ous.
Any
of
these
conditions
could
result
in
electric
shock
or
fire.
Periodically
examine
the
cord
of
your
appliance,
and
if
its
appearance
indicates
damage
or
deterioration,
unplug
it,
discontinue
use
of
the
appliance,
and
have
the
cord
replaced
with
an
exact
replacement
part
by
an
authorized
servicer.
Protect
the
power
cord
from
physical
or
mechanical
abuse,
such
as
being
twisted,
kinked,
pinched,
closed
in
a
door,
or
walked
upon.
Pay
particular
attention
to
plugs,
wall
outlets,
and
the
point
where
the
cord
exits
the
appliance.
SERIAL
NUMBER:
You
can
find
the
serial
number
on
the
back
of
the
unit.
This
number
is
unique
to
this
unit
and
not
available
to
others.
You
should
record
requested
information
here
and
retain
this
guide
as a
permanent
record
of
your
purchase.
Model
No.
______________________________
Serial
No.
______________________________
CAUTION:
TO
REDUCE
THE
RISK
OF
ELECTRIC
SHOCK
DO
NOT
REMOVE
COVER
(OR
BACK)
NO
USER-SERVICEABLE
PARTS
INSIDE
REFER
SERVICING
TO
QUALIFIED
SERVICE
PERSONNEL.
WARNING:
TO
PREVENT
FIRE
OR
ELECTRIC
SHOCK
HAZARD,
DO
NOT
EXPOSE
THIS
PRODUCT
TO
RAIN
OR
MOISTURE.
CAUTION
RISK
OF
ELECTRIC
SHOCK
DO
NOT
OPEN
3
1.
Read
these
instructions.
-
All
these
safety
and
operating
instructions
should
be
read
before
the
product
is
operated.
2.
Keep
these
instructions.
-
The
safety,
operating
and
use
instructions
should
be
retained
for
future
reference.
3.
Heed
all
warnings.
-
All
warnings
on
the
product
and
in
the
operating
instructions
should
be
adhered
to.
4.
Follow
all
instructions.
-
All
operating
and
use
instruc-
tions
should
be
followed.
5.
Do
not
use
this
product
near
water.
--
For
example:
near
a
bath
tub,
wash
bowl,
kitchen
sink,
laundry
tub,
in
a
wet
basement;
or
near
a
swimming
pool;
and
other
areas
located
near
water.
6.
Clean
only
with
dry
cloth.
--
Unplug
this
product
from
the
wall
outlet
before
cleaning.
Do
not
use
liquid
cleaners.
7.
Do
not
block
any
ventilation
openings.
Install
in
accor-
dance
with
the
manufacturer
's
instructions.
-
Slots
and
openings
in
the cabinet
are
provided
for
ventilation
and
to
ensure
reliable
operation
of
the
product
and
to
protect
it
from
over-
heating.
The
openings
should
never
be
blocked
by
placing
the
product
on
a
bed,
sofa,
rug
or
other
similar
surface.
This
product
should
not
be
placed
in
a
built-in
installation
such
as a
bookcase
or
rack
unless
proper
ven-
tilation
is
provided
or
the
manufacturer's
instructions
have
been
adhered
to.
8.
Do
not
install
near
any
heat
sources
such
as
radia-
tors,
heat
registers,
stoves,
or
other
apparatus
(including
amplifiers)
that
produce
heat.
9.
Do
not
defeat
the
safety
purpose
of
the
polarized
or
grounding-type
plug.
A
polarized
plug
has
two
blades
with
one
wider
than
the
other.
A
grounding
type
plug
has
two
blades
and
a
third
grounding
prong.
The
wide
blade
or
the
third
prong
are
provided
for
your
safety.
If
the
provided
plug
does
not
fit
into
your
outlet,
consult
an
electrician
for
replacement
of
the
obsolete
outlet.
10.
Protect
the
power
cord
from
being
walked
on
or
pinched
particularly
at
plugs,
convenience
recepta-
cles,
and
the
point
where
they
exit
from
the
product.
11.
Only
use
attachments/accessories
specified
by
the
manufacturer.
12.
Use
only
with
the
cart,
stand,
tripod,
bracket,
or
table
specified
by
the
manufacturer,
or
sold
with
appara-
tus.
When
a
cart
is
used,
use
caution
when
moving
the
cart/product
combination
to
avoid
injury
from
tip-over.
13.
Unplug
this
product
during
lightning
storms
or
when
unused
for
long
periods
of
time.
14.
Refer
all
servicing
to
qualified
service
personnel.
Servicing
is
required
when
the
product
has
been
damaged
in
any
way,
such
as
power-supply
cord
or
plug
is
damaged,
liquid
has
been
spilled
or
objects
have
fallen
into
the
product,
the
product
has
been
exposed
to
rain
or
moisture,
does
not
operate
nor-
mally,
or
has
been
dropped.
IMPORTANT
SAFETY
INSTRUCTIONS
CAUTION:
PLEASE
READ
AND
OBSERVE
ALL
WARNINGS
AND
INSTRUCTIONS
IN
THIS
OWNER'S
MANUAL.
AND
THOSE
MARKED
ON
THE
PRODUCT.
RETAIN
THIS
BOOKLET
FOR
FUTURE
REFERENCE.
This
product
has
been
designed
and
manufactured
to
assure
personal
safety.
Improper
use can
result
in
electric
shock
or
fire
hazard.
The
safeguards
incorporated
in
this
product
will
protect
you
if
you
observe
the
following
procedures
for
installa-
tion,
use,
and
servicing.
This
product
does
not
contain
any
parts
that
can
be
repaired
by
the
user.
DO
NOT
REMOVE
THE
CABINET
COVER,
OR YOU
MAY
BE
EXPOSED
TO
DANGEROUS
VOLTAGE.
REFER
SERVIC-
ING
TO
QUALIFIED
SERVICE
PERSONNEL
ONLY.
4
INTRODUCTION
SymbolUsedinthisManual..............6
AbouttheSymbolDisplay.............6
NotesonDiscs........................6
MoistureCondensation..................6
RecordableandPlayableDiscs
. . . . . . . . . .
.7
The recommendable
recordable
DVD
discs
.
.7
PlayableDiscs.........................8
Regional
code
of
the
recorder
and
DVDs
. . .
.8
Restrictionsonvideorecording.
. . . . . . . . .
.9
Whatis'CPRM'?.......................9
Copyright.............................9
NoticeforProgressiveScanUse
. . . . . . . . .
.9
Carduseableonthisunit...............10
UsingMemoryCard....................10
AbouttheRemoteControl..............10
Disc-relatedterms.....................11
FrontPanel..........................12
FunctionDisplayWindow...............13
RemoteControl.......................14
RearPanel...........................15
HOOKUP
AND
SETTINGS
Connecting
an
Antenna
or
Cable
TV
. . . . .
.16
ConnectionstoyourTV..............16-17
OptionalTVConnections...............17
ConnectiontoanAmplifier
. . . . . . . . . .
.17-18
InitialSettings......................19-26
GeneralOperation....................19
GeneralSettings...................19-21
?T
uningBandSelect................19
?AutoChannelSet.................19
?T
o
Add
or
Erase
Channels
from
Memory.........................20
?ClockSet........................20
?TVAspect.......................20
?ProgressiveScan.................21
?PowerSaveMode.................21
?FactorySetting...................21
LanguageSettings....................21
?DisplayMenu.....................21
?
DiscMenu/Audio/Subtitle.
. . . . . . . .
.21
AudioSettings.......................22
?DolbyDigital/DTS/MPEG.
. . . . . . . .
.22
?
SamplingFreq.(Frequency).
. . . . . . . .
.22
?
DRC
(Dynamic
Range
Control)
. . . . . .
.22
?V
ocal...........................22
Lock
(Parental
Control)
Settings
. . . . . . . . .
.23
?Rating..........................23
?SetPassword....................23
?AreaCode.......................23
RecordingSettings....................24
?DiscRecordMode.................24
?VCRRecordMode................24
?DVRecordAudio..................24
?AutoChapter.....................24
DiscSettings......................24-26
?Initialize.........................24
?Finalize.........................25
?DiscLabel.......................25
?DiscProtect......................25
?PBC...........................26
?AutoPlay........................26
?DivXRegistrationCode.............26
General
Explanation
of
On-Screen
Display..............................27
Displaying
Information
While
Watching
TV
.
.27
Displaying
Disc
Information
on-screen
. . . .
.27
PLAYBACK
VCRTapePlayback.................28-29
BasicInstructions.....................28
AutoTracking........................28
ManualTracking......................28
Search.............................28
Still
and
Frame-by
Frame
Playback
.28
SlowMotion.........................28
CounterMemoryFunction..............29
S-VHSQuasiPlayback(SQPB).
. . . . . . . .
.29
PlayingaDVDorVideoCD
. . . . . . . . . .
.29-32
PlaybackSetup....................29-32
?MovingtoanotherTITLE.
. . . . . . . . .
.29
?
Moving
to
another
CHAPTER
/
TRACK
.29
?SlowMotion......................30
?Search..........................30
?T
imeSearch.....................30
?MarkerSearch...................30
?Random........................30
?
Still
and
Frame-by-Frame
Playback........................31
?Zoom...........................31
?Repeat.........................31
?RepeatA-B......................31
?T
itleMenu.......................31
?DiscMenu.......................31
?CameraAngle....................31
?Subtitles........................31
?
Changing
the
Audio
Soundtrack
. . . . . .
.32
?ChangingtheAudioChannel.
. . . . . . .
.32
?3DSurround.....................32
?LastConditionMemory.............32
?FindingLocationsonaDisc.
. . . . . . . .
.32
PlayingaDivXMovieFile.
. . . . . . . . . . .
.33-34
Notice
for
displaying
the
DivX
subtitle
. . . . .
.33
Moviemenuoptions...................33
AboutDivXmoviefiles.................34
Playing
an
Audio
CD
or
MP3/WMA
files
.
.35-36
AudioCDandMusicmenuoptions.
. . . . . .
.35
Audio
CD
and
MP3/WMA
file
Features
. . . .
.35
?Pause..........................35
?MovingtoanotherTrack.
. . . . . . . . . .
.35
?Repeat.........................35
?ChangingtheAudioChannel.
. . . . . . .
.36
?Random........................36
5
?RepeatA-B......................36
?Search..........................36
NotesonMP3/WMARecordings
. . . . . . . . . .
.36
?
MP3/WMA
disc
compatibility
with
this
unitislimitedasfollows:
. . . . . . . . . . .
.36
Program
Playback
with
Audio
CD
and
MP3/WMAfiles........................37
ProgramListmenuoptions..............37
?
RepeatProgrammedTracks
. . . . . . . .
.37
?
Erasing
a
Track
from
the
Program
List
.
.37
?
Changing
Track
Order
in
the
ProgramList.....................37
ViewingaJPEGfiles................38-39
Photomenuoptions................38-39
?Stillpicture.......................38
?SkipImages.....................38
?RotateImages....................38
?V
iewSlideShows.................39
AboutJPEGimagefiles................39
?
JPEG
disc
compatibility
with
this
recorderislimitedasfollows:
. . . . . . .
.39
RECORDING
AboutDVDrecording..................40
Disc
types
and
recording
formats,
modes,
and
settings............................40
Notesforrecording....................40
BasicRecordingfromaTV..............41
InstantTimerRecording.
. . . . . . . . . . . .
.41-42
CheckingtheRecordingTime.
. . . . . . . . . .
.41
ToExtendtheRecordingTime
. . . . . . . . . .
.41
ToPausetheRecording................41
To
record
one
TV
program
while
watching
another............................42
TimerRecording....................42-43
Checking
Timer
Recording
Details
. . . . . . .
.42
CancelingaTimerRecording.
. . . . . . . . . .
.42
Timer
Recording
Troubleshooting
. . . . . . . .
.43
Playingwhileyouarerecording.
. . . . . . . .
.43
DubbingfromDVDtoVCR..............44
DubbingfromVCRtoDVD..............44
Recording
from
External
Components
. . . .
.45
AdditionalInformation.................45
RecordingfromDVInput...............46
BeforeDVdubbing....................46
Recording
from
a
Digital
Camcorder
. . . . . .
.46
Troubleshooting......................46
EDITING
Title
List
and
Chapter
List
Menu
Overview
.47
VR
Mode:
Original
and
Playlist
Editing
. . .
.48
Titles,ChaptersandParts..............48
Is
editing
a
DVD
like
editing
a
video
tape?
.
.48
About
word
'Original'
and
'Playlist'
. . . . . . .
.48
AddingChapterMarkers................48
ChangingTitleThumbnails..............48
MakingaNewPlaylist..................49
Adding
Additional
Title/Chapters
to
the
Playlist..............................49
Deleting
an
Original
or
Playlist
Title/
Chapter.............................50
DeletingaPart........................50
NamingaTitle........................51
TimeSearch..........................51
DivideOneTitlesIntoTwo..............52
Combining
Two
Chapters
Into
One
. . . . . . .
.52
MovingaPlaylistChapter...............53
HideaChapter/Title....................53
ProtectaTitle........................53
OverwritingRecording.................54
Viewing
Title
List
menu
displayed
on
other
DVDRecordersorPlayers..............54
Playing
Your
Recordings
on
Other
DVD
Players(FinalizingaDisc)...............54
REFERENCE
Controlling
Your
TV
with
the
Supplied
Remote..............................55
LanguageCodeList...................56
AreaCodesList.......................56
Troubleshooting....................57-59
ResettheRecorder...................59
Specifications......................60-61
6
To
ensure
proper
use
of
this
product,
please
read
this
owner's
manual
carefully
and
retain
for
future
refer-
ence.
Symbol
Used
in
this
Manual
Indicates
hazards
likely
to
cause
harm
to
the
unit
itself
or
other
material
damage.
Note:
Indicates
special
notes
and
operating
fea-
tures.
Tip:
Indicates
tips
and
hints
for
making
the task
easier.
A
section
whose
title
has
one
of
the
following
sym-
bols
are
applicable
only
to
those
discs
represented
by
the
symbol.
DVD-RW
with
VR
recording
mode
DVD-RW
with
Video
recording
mode
DVD-RAM
disc
DVD+RW
disc
DVD-R
disc
DVD+R
disc
DVD-Video
disc
DivX
files
Video
CDs
Audio
CDs
MP3
files
WMA
files
JPEG
files
About
the
Symbol
Display
"
"
may
appear
on
your
TV
display
during
operation
and
indicates
that
the
function
is
not
permitted
by
this
unit
or
the
disc.
Notes
on
Discs
Handling
Discs
Do
not
touch
the
playback
side
of
the
disc.
Hold
the
disc
by
the
edges
so
that
fingerprints
do
not
get
on
the
surface.
Never
stick
paper
or
tape
on
the
disc.
Storing
Discs
After
playing,
store
the
disc
in
its
case.
Do
not
expose
the
disc
to
direct
sunlight
or
sources
of
heat
and
never
leave
it
in
a
parked
car
exposed
to
direct
sunlight.
Cleaning
Discs
Fingerprints
and
dust
on
the
disc
can
cause
poor
pic-
ture
quality
and
sound
distortion.
Before
playing,
clean
the
disc
with
a
clean
cloth.
Wipe
the
disc
from
the
center
out.
Do
not
use
strong
solvents
such
as
alcohol,
benzine,
thinner,
commercially
available
cleaners,
or
anti-static
spray
intended
for
older
vinyl
records.
JPEG
WMA
MP3
ACD
VCD
DivX
DVD
+R
-R
+RW
RAM
-RWVideo
-RWVR
Introduction
Moisture
Condensation
Never
operate
this
product
immediately
after
mov-
ing
it
from
a
cold
location
to
a
warm
location.
Leave
it
for
two
or
three
hours
without
operating
it.
If
you
use
this
product
in
such
a
situation,
it
may
damage
discs/tapes
and
internal
parts.
7
Recordable
and
Playable
Discs
DVD-RW
(DVD
-
ReWritable)
DVD-RW
discs
can
be
formatted
for
VR
mode
recording
or
Video
mode
recording.
These
Discs
can
be
recorded
on
repeatedly.
Recordings
can
be
erased,
then
you
can
record
again
on
the
same
Disc.
[VR
mode]
Recordings
can
be
extensively
edited
Playable
only
on
VR
mode
compatible
players
(after
finalization)
[Video
mode]
Playable
on
regular
DVD
players
(after
finalization)
Limited
editing
features
DVD-R
(DVD
-
Recordable)
These
Discs
can
be
recorded
only
once.
After
you
finalize
a
DVD-R,
you
cannot
record
on
it
or
edit
it.
DVD-R
discs
can
be
only
formatted
to
Video
mode.
Playable
on
regular
DVD
players
(after
finalization)
Limited
editing
features
DVD-RAM
(DVD
-
Random
Access
Memory)
DVD-RAM
discs
can
be
formatted
for
VR
mode
recording.
These
Discs
can
be
recorded
on
repeatedly.
Recordings
can
be
erased,
then
you
can
record
again
on
the
same
Disc.
Playable
on
DVD-RAM
compatible
players.
Recordings
can
be
extensively
edited.
Only
DVD-RAM
standard
Version
2.0,
2.1
and
2.2
discs
can
be
used
in
this
unit.
You
cannot
use
the
cartridge-type
DVD-RAM
disc
in
this
unit.
DVD+RW
(DVD+
ReWritable)
These
Discs
can
be
recorded
on
repeatedly.
Recordings
can
be
erased,
then
you
can
record
again
on
the
same
Disc.
Playable
on
DVD+RW
compatible
players
(automatically
finalization)
The
edited
contents
are
playable
on
DVD+RW
compatible
players only
after
finalization.
Recordings
can
be
edited
the
title/chapter
DVD+R
(DVD
+
Recordable)
These
Discs
can
be
recorded
only
once.
After
you
finalize
a
DVD+R,
you
cannot
record
on
it
or
edit
it
any
more.
Playable
on
DVD+R
compatible
players
(after
finalization)
Any
edited
contents
are
not
be
compatible
on
DVD+R
compatible
players.
(Hide,
chapter
combine,
added
chapter
mark,
etc.)
Limited
title/chapter
editing
features.
DVD+R
DL
(DVD
+
Recordable;
Double
Layer)
These
Discs
can
be
recorded
only
once.
After
you
finalize
a
DVD+R
DL,
you
cannot
record
on
it
or
edit
it
any
more.
Storage
space
is
nearly
doubled
with
double
layer
DVD+R
media,
allowing
consumers
to
record
up
to
8.5GB
of
video
on
a
single
DVD+R
DL
disc.
Playable
on
DVD+R
compatible
players
(after
finalization)
Any
edited
contents
are
not
be
compatible
on
DVD+R
DL
compatible
players.
(Hide,
chapter
combine,
added
chapter
mark,
etc.)
Limited
title/chapter
editing
features.
Recommended
recordable
DVD
discs
DVD-R
SONY
(8x,
16x)
TDK
(4x,
8x)
Verbatim
(4x,
8x)
Panasonic
(2x,
4x)
-
DVD+R
SONY
(2.4x,
4x, 8x,
16x)
TDK
(4x)
Mitsubishi
(4x,
8x)
Ricoh
(2x,
4x,
8x)
-
DVD-RW
Victor
(1x,
4x)
Maxell
(1x,
2x,
4x)
VerbatimTDK
(2x)
Mitsubishi
(2x)
-
DVD+RW
SONY
(2.4x)
TDK
(2.4x)
Philips
(4x)
Ricoh
(2.4x)
HP
(2.4x,
4x)
DVD+R(DL)
Mitsubishi
(2.4x)
Maxell
(2.4x)
-
-
-
DVD-RAM
Maxell
(3x,
5x)
-
-
-
-
8
Playable
Discs
DVD(8cm/12cmdisc)
Discs
such
as
movies
that
can
be
purchased
or
rented
Video
CD
(VCD)
(8
cm
/
12
cm
disc)
VIDEO
CDs
or
CD-Rs/CD-RWs
in
VIDEO
CD/Super
VIDEO
CD
format
AudioCD(8cm/12cmdisc)
Music
CDs
or
CD-Rs/CD-RWs
in
music
CD
format
that
can
be
purchased
CD-R/CD-RW
(8
cm
/
12
cm
disc)
CD-R/CD-RW
discs
that
contain
audio
titles,
MP3,
WMA,
JPEG
or
DivX
files.
Notes:
?
Depending
on
the
conditions
of
the
recording
equipment
or
the
CD-R/RW
(or
DVD±R/RW)
disc
itself,
some
CD-R/RW
(or
DVD±R/RW)
discs
cannot
be
played
on
the
unit.
?
Do
not
attach
any
seal
or
label
to
either
side
(the
labeled
side
or
the
recorded
side)
of
a
disc.
?
Do
not
use
irregularly
shaped
CDs
(e.g.,
heart-shaped
or
octagonal).
Doing
so
may
result
in
malfunctions.
?
Depending
on
the
recording
software
&
the
finalization,
some
recorded
discs
(CD-R/RW
or
DVD±R/RW)
may
not
be
playable.
?
DVD-R/RW,
DVD+R/RW
and
CD-R/RW
discs
recorded
using
a
personal
computer
or
a
DVD
or
CD
Recorder
may
not
play
if
the
disc
is
damaged
or
dirty,
or
if
there
is
dirt
or
condensation
on
the
Recorder's
lens.
?
If
you
record
a
disc
using
a
personal
computer,
even
if
it
is
recorded
in
a
compatible
format,
there
are
cases
in
which
it
may
not
play
because
of
the
settings
of
the
application
software
used
to
create
the
disc.
(Check
with
the
software
publisher
for
more
detailed
information.)
Region
code
of
the
recorder
and
DVDs
This
recorder
is
designed
and
manufactured
for
playback
of
Region
1
encoded
DVD
soft-
ware.
The
region
code
on
the
labels
of
some
DVD
discs
indicates
which
type
of
the recorder
can
play
those
discs.
This
unit
can
play
only
DVD
discs
labeled
1
or
ALL.
If
you
try
to
play
any
other
discs,
the
message
"Incorrect
region
code.
Can't
play
back"
will
appear
on
the
TV
screen.
Some
DVD
discs
may
not
have
a
region
code
label
even
though
their
playback
is
prohibited
by
area
limits.
Notes
on
DVDs
and
Video
CDs
Some
playback
operations
of
DVDs
and
Video
CDs
may
be
intentionally
fixed
by
software
manufacturers.
As
this unit
plays
DVDs
and
Video
CDs
according
to
disc
content
designed by
the
software
manufacturer,
some
playback
features
of
the
unit
may
not
be
available
or
other
functions
may
be
added.
Refer
also
to
the
instructions
supplied
with
the
DVDs
and
Video
CDs.
Some
DVDs
made
for
business
purpos-
es
may
not
be
played
on
the
unit.
1
ALL
9
Restrictions
on
video
recording
?Y
ou
cannot
record
copy-protected
video
using
this
recorder.
Copy-protected
video
includes
DVD-
Video
discs
and
some
satellite
broadcasts.
If
copy-protected
material
is
encountered
during
a
recording,
recording
will
pause
or
stop
automati-
cally
and
an
error
message
will
be
displayed
on-
screen.
?V
ideo
that
is
'copy-once
only'
can
only
be
record-
ed
using
a
DVD-RW
disc
in
VR
mode
or
DVD-
RAM
disc
with
CPRM
(see
below).
What
is
'CPRM'?
CPRM
is
a
copy
protection
system
(with
scramble
system)
only
allowing
the
recording
of
'copy
once'
broadcast
programs.
CPRM
stands
for
Content
Protection
for
Recordable
Media.
This
Recorder
is
CPRM
compatible,
which
means
that
you
can
record
copy-once
broadcast
programs,
but
you
cannot
then
make
a
copy
of
those
record-
ings.
CPRM
recordings
can
only
be
made
on
DVD-
RW
discs
formatted
in
VR
mode
or
DVD-RAM
discs,
and
CPRM
recordings
can
only
be
played
on
players
that
are
specifically
compatible
with
CPRM.
Copyright
?
Recording
equipment
should
be
used
only
for
law-
ful
copying
and
you
are
advised
to
check
carefully
what
is
lawful
copying
in
the
area
in
which
you
are
making
a
copy.
Copying
of
copyright
material
such
as
films
or
music
is
unlawful
unless
permit-
ted
by
a
legal
exception
or
consented
to
by
the
rights
owner.
?
This
product
incorporates
copyright
protection
technology
that
is
protected
by
method
claims
of
certain
U.S.
patents
and
other
intellectual
property
rights
owned
by
Macrovision
Corporation
and
other
rights
owners.
Use
of
this
copyright
protec-
tion
technology
must
be
authorized
by
Macrovision
Corporation,
and
is
intended
for
home
and
other
limited
viewing
uses
only,
unless
otherwise
authorized
by
Macrovision
corporation.
Reverse
engineering
or
disassembly
is
prohibited.
Notice
for
Progressive
Scan
Use
CONSUMERS
SHOULD
NOTE
THAT
NOT
ALL
HIGH
DEFINITION
TELEVISION
SETS
ARE
FULLY
COMPATIBLE
WITH
THIS
PRODUCT
AND
MAY
CAUSE
ARTIFACTS
TO
BE
DISPLAYED
IN
THE
PICTURE.
IN
CASE
OF
525
PROGRESSIVE
SCAN
PROBLEMS,
IT
IS
RECOMMENDED
THAT
THE
USER
SWITCH
THE
CONNECTION
TO
THE
'STANDARD
DEFINITION'
OUTPUT.
IF
THERE
ARE
QUESTIONS
REGARDING
YOUR
TV
SET
COMPATIBILITY
WITH
THIS
MODEL
525p
DVD+VCR
RECORDER,
PLEASE
CONTACT
OUR
CUSTOMER
SERVICE
CENTER.
10
Card
useable
on
this unit
Card
useable
on
this
unit
?
Compact
Flash
Card
(CF)
?
Micro
Drive
(MD)
?
Secure
Digital
Card
(SD)
?
Multi
Media
Card
(MMC)
?
SmartMedia
Card
(SMC)
?
xD-Picture
Card
(xD)
?
Memory
Stick
(MS)
?
Memory
Stick
Pro
(MS-Pro)
?
Compatible
with:
FAT
12,
FAT
16,
or
FAT
32
?
Only
use
the
memory
cards
recommended
above.
Regarding
Write
Protect
For
cards
that
have
a
write
protect
switch,
if
the
switch
is
on
it
will
not
be
possible
to
write
or
erase
the
card.
Inserting/Removing
the
Memory
Card
Inserting
the
card:
Insert
straight-in
until
it
fits
into
place.
Removing
the
card:
Withdraw
the
card
carefully.
Notes:
?
Keep
the
memory
card
out
of
reach
of
children.
If
swallowed,
seek
medical
advice
immediately.
?
Some
memory
card
may
not
work
in
this
recorder,
depending
on
the
formatting.
?
Do
not
extract
the
memory
card
while
operat-
ing
(play,
copy,
etc.).
Using
Memory
Card
Using
Memory
Card
1.
Insert
a
memory
card.
2.
Press
MEMORY
on
the
Remote
Control
while
in
the
DVD
Tuner
mode.
The
Memory
Card
slot
choice
menu
appears
on
the
TV
screen.
3.
Use
v/Vto
select
the
desired
Memory
Card
slot
then
press
ENTER.
The
or
Music
menu
appears
on
the
TV
screen.
4.
Press
RETURN
to
exit
the
or
Music
menu
for
memory
card.
Note:
For
details
on
each
operation
item,
refer
to
relevant
pages.
Insert
CF
or
MD
card
Insert
SD,
MMC,
SMC,
xD,
MS,
or
MS-Pro
card
About
the
Remote
Control
Operation
Range
Point
the
Remote
Control
at
the
remote
sensor
and
press
the
buttons.
Distance:
About
23
ft
(7
m)
from
the
front
of
the
remote
sensor.
Angle:
About
30°
in
each
direction
of
the
front
of
the
remote
sensor.
Battery
installation
Detach
the
battery
cover
on
the
rear
of
the
Remote
Control,
and
insert
two
(R03/AAA)
size
batteries
with
3
and
#
aligned
correctly.
Do
not
mix
old
and
new
batteries
and
never
mix
different
types
of
batteries
such
as
stan-
dard,
alkaline,
etc.
11
Disc-related
terms
DVD
+R
(Double
Layer)
Double
layer
recording
technology
offers
two
record-
able
layers
on
a
single
DVD
disc,
providing
nearly
double
the
capacity
of
4.7GB
single
layer
DVDs.
The
greatest,
most
valuable
benefit
of
double
layer
recording
technology
is
increased
capacity.
Storage
space
is
nearly
doubled
with
double
layer
DVD+R
media,
allowing
consumers
to
burn
up
to
8.5GB
of
video
on
a
single
DVD+R
disc.
DVD±R/DVD±RW
DVD
-R
and
DVD
+R
are
two
different
standards
for
recordable
DVD
drives
and
discs.
This
format
allows
information
to
be
recorded
onto
the
DVD
disc
only
once.
DVD
+RW
and
DVD
-RW
are
two
standards
for
re-writable
media,
meaning
the
DVD
content
can
be
erased
and
re-recorded.
Single-sided
discs
can
hold
4.7
GB
and
double-sided
discs
hold
twice
as
much.
DVD-RAM
DVD-RAM
disc
can
be
formatted
in
DVD-Video
Recording
format
(VR
mode).
This
type
of
disc
is
able
to
be
rewritten
and
edited.
VCD
(Video
CD)
A
VCD
holds
up
to
74
minutes
(650
MB
disc)
or
80
minutes
(700
MB
disc)
of
MPEG-1
full-motion
video
along
with
quality
stereo
sound.
MPEG
MPEG
is
an
international
standard
for
video
and
audio
compression.
MPEG-1
is
used
in
encoding
video
for
VCD
and
provides
for
multichannel
surround
sound
coding
such
as
PCM,
Dolby
Digital,
DTS
and
MPEG
audio.
MP3
MP3
is
a
popular
compression
format
used
for
digital
audio
files
that
yields
very
high
near-CD
quality.
WMA
Windows
media
audio
file.
A
type
of
coding
/
decod-
ing
developed
by
Microsoft
Corp.
JPEG
Joint
Pictures
Expert
Group.
JPEG
is
a
compressed
file
format
that
allows
you
to
save
images
with
no
limit
on
the
number
of
colors.
DivX
DivX
is
the
name
of
a
revolutionary
new
video
codec
which
is
based
on
the
new
MPEG-4
compression
standard
for
video.You
will
be
able
to
play
DivX
movies
using
this
recorder.
PBC:
Playback
Control
(Video
CD
only)
Playback
control
is
available
for
Video
CD
(VCD)
ver-
sion
2.0
disc
formats.
PBC
allows
you
to
interact
with
the
system
via
menus,
search
functions,
or
other
typi-
cal
computer-like
operations.
Moreover,
still
pictures
of
high
resolution
can
be
played
if
they
are
included
in
the
disc.
Video
CDs
not
equipped
with
PBC
(Version
1.1)
operate
in
the
same
way
as
audio
CDs.
Title
(DVD
video
discs
only)
A
title
is
generally
a
distinct
section
of
a
DVD
disc.
For
example
the
main
feature
could
be
title
1,
a
docu-
mentary
describing
how
the
film
was
made
could
be
title
2,
and
cast
interviews
could
be
title
3.
Each
title
is
assigned
a
reference
number
enabling
you
to
locate
it
easily.
Chapter
(DVD
video
discs
only)
A
chapter
is
a
segment
of
a
title
such
as
a
scene
in
a
film
or
one
interview
in
a
series.
Each
chapter
is
assigned
a
chapter
number,
enabling
you
to
locate
the
chapter
you
want.
Depending
on
the
disc,
chap-
ters
may
not
be
recorded.
Scene
(VCD)
On
a
video
CD
with
PBC
(playback
control)
functions,
moving
pictures
and
still
pictures
are
divided
into
sec-
tions
called
"scenes".
Each
scene
is
displayed
in
the
menu
screen
and
assigned
a
scene
number,
enabling
you
to
locate
the
scene
you
want.
A
scene
is
com-
posed
of
one
or
several
tracks.
Track
A
distinct
element
of
audiovisual
information,
such
as
the
or
sound
track
for
a
specific
language
(DVD),
or
a
musical
piece
on
a
video
or
audio
CD.
Each
track
is
assigned
a
track
number,
enabling
you
to
locate
the
track
you
want.
DVD
discs allow
one
track
of
video
(with
multiple
angles)
and
several
tracks
of
audio.
12
a
POWER
button
and
indicator
Switches
the
Recorder
ON
and
OFF.
Lights
green
when
the
Recorder
is
turned
on.
b
Disc
Tray
(DVD
deck)
Insert
a
disc
here.
c
Z
OPEN/CLOSE
Opens
or
closes
the
disc
tray.
d
Cassette
Compartment
(VCR
deck)
Insert
a
video
cassette
here.
e
Z
EJECT
Ejects
the
tape
in
the
VCR
deck.
fAV2IN
-
VIDEO
/AUDIO
(Left/Right)
Connect
the
audio/video
output
of
an
external
source
(Audio
system,
TV/
Monitor,
VCR,
Camcorder,
etc.).
-
S-VIDEO
IN
Connect
the
S-Video
output
of
an
external
source
(TV/
Monitor,
VCR,
Camcorder,
etc.).
g
DVIN
Connect
the
DV
output
of
a
digital
camcorder.
h
MEMORY
CARD
Slot
Insert
a
memory
card
(CF,
MD,
SMC,
MMC,
SD,
MS,
MS-Pro
or
XD-Picture).
i
Display
window
Shows
the
current
status
of
the
Recorder.
j
Remote
Sensor
Point
the
Recorder
Remote
Control
here.
k
DVD/VCR
indicator
Indicates
the
active
DVD
or
VCR
deck.
l
DVD/VCR
Toggles
control
between
the
DVD
deck
and
the
VCR
deck.
m
z
(REC)
Starts
recording.
Press
repeatedly
to
set
the
recording
time.
n
N
(PLAY)
To
play
back
a
disc
or
tape.
o
x
(STOP)
Stops
playback.
p
CH(v/V)
Scans
up
or
down
through
memorized
chan-
nels.
q
DUB
(DUBBING)
Press
to
copy
DVD
to
VCR
(or
VCR
to
DVD).
Front
Panel
ab
cd
e
fgh
ij
klmnop q
LOCK
function
The
Lock
feature
disables the
front
panel
buttons
to
prevent
children
from
tampering
with
this
unit.
Simply
press
LOCK
on
the
remote
control
to
toggle
this
feature
on
and
off.
13
Indicates
the
type
of
disc
loaded.
Indicates
when
Memory
Card
is
activated.
Indicates
repeat
mode.
Indicates
when
the recorder
is
in
timer
recording
or
a
timer
recording
is
programmed.
The
recorder
is
recording.
Programmed
playback
active.
Indicates
current
title.
A
disc
is
inserted
in
the
DVD
deck.
A
VHS
tape
is
inserted
in
the
VCR
deck.
Indicates
a
DVD-RW
disc
(VR
mode
only)
or
DVD-RAM
disc
is
inserted
in
the
DVD
deck.
Indicates
that
TV
mode
is
active.
Indicates
current
chapter
or
track
number
Indicates
that
a
DVD
to
VCR
(or
VCR
to
DVD)
dubbing
is
in
progress.
Indicates
when
the
Recorder
is
Locked.
Indicates
when
the
Recorder
is
playing
a
tape
in
Hi-Fi.
Indicates
a
stereo
broadcast
is
being
received.
Indicates
when
a
SAP
BILINGUAL
broadcast
is
being
received.
Indicates
clock,
total
playing
time,
elapsed
time,
remaining
time,
title
number,
chapter/track
number,
channel,
etc.
SAP
ST
Hi-Fi
DUB
TRK
CHP
TV
VR
TTL
PRG
AB
M.CARD
DVD
SVCD
Function
Display
Window
DVD
PRG
TTL
VR
TV
TRK
CHP DUB
Hi-Fi
ST
SAP
SVCD
M.CARD
AB
14
A-B
Repeats
sequence
between
two
points
(A
and
B)
ANGLE
Selects
a
DVD
camera
angle,
if
available.
AUDIO
Selects
an
audio
language
(DVD)
or
an
audio
channel
(CD).
BACKWARD
/
FORWARD
(m/M)
-
DVD:
Search
backward
or
forward.
-
VCR:
Rewinds/Advances
the
tape
during
the
STOP
mode,
for fast
reverse/
forward
search.
CHP
ADD
Inserts
a
chapter
marker
when
playing/
recording.
CH/TRK(v/V):
Selects
a
program.
Adjusts
manually
the
tape's
onscreen.
CLEAR
Removes
a
mark
on
the
Marker
Search
menu.
DISPLAY
Accesses
On-Screen
Display.
Displays
information
of
current
status.
DUBBING
Press
to
copy
DVD
to
VCR
(or
VCR
to
DVD).
DVD
Select
the
Recorder's
function
mode
to
DVD.
EJECT,
OPEN/CLOSE
-
Opens
and
closes
the
disc
tray.
-
Ejects
the
tape
in
the
VCR
deck.
ENTER
(
)
Confirms
menu
selections.
INPUT
Changes
the
input
to
use
for
recording
(Tuner,
AV1, AV2,
or
DV
IN).
LIST/DISC
MENU
Accesses
menu
on a
DVD
disc,
Title
List
or
Playlist
menu.
LOCK
Locks/unlocks
front
panel
buttons.
MARKER
Marks
any
point
during
playback.
MEMORY
Accesses
the
(or
Music)
menu
for
memory
card.
POWER
Turns
Recorder
ON
and
OFF.
PAUSE/STEP
(X)
Pause
playback
or
recording
temporarily.
Press
repeatedly
for
frame-by-frame
playback.
RETURN
(O)
-
Removes
the
menu.
-
Displays
the
menu
of
a
video
CD
with
PBC.
REPEAT
Repeat
chapter,
track,
title
or
all.
RANDOM
Plays
tracks
in
random
order.
REC
MODE
Selects
the
recording
mode:
-DVD:SP,LP,EPorXP.
-VCR:SPorSLP.
z
REC
Starts
recording.
Press
repeatedly
to
set
the
recording
time.
STOP
(x)
Stops
playback
or
recording.
SEARCH
Displays
Marker
Search
menu.
SETUP
Accesses
or
removes
the
Setup
menu.
SKIP(./>)
Go
to
next
chapter
or
track.
Returns
to
beginning
of
current
chapter
or
track
or
go
to
previous
chapter
or
track.
SUBTITLE
Selects
a
subtitle
language.
TITLE
Displays
the
disc's
Title
menu,
if
available.
THUMBNAIL
Selects
a
thumbnail
for
the
current
title
for
use
in
the
Title
List
or
Chapter
List
menu.
TIMER
REC
Displays
Timer
Record
menu.
TIME
SHIFT
To
play
the
title
being
recorded
and
also
currently
being
recorded
appears
as
PIP.
TV
Control
Buttons
See
page
55.
TV/VCR
To
view
channels
selected
by
the
VCR
tuner
or
by
the
TV
tuner.
VCR
Select
the
Recorder's
function
mode
to
VCR.
ZOOM
Enlarges
DVD
video
image.
0-9
numerical
buttons
-
Selects
numbered
options
in
a
menu.
-
Inputs
channel
numbers.
N
(PLAY)
Starts
playback.
bBvV(left/right/up/down)
Selects
menu
options.
Remote
Control
15
a
ANT.IN
Connect
the
antenna
to
this
terminal.
b
AC
Power
Cord
Plug
into
the
power
source.
c
AV
1
IN
(VIDEO
IN
/AUDIO
IN
(Left/Right))
Connect
the
audio/video
output
of
an
external
source
(Audio
system,
TV/Monitor,
VCR,
Camcorder).
d
AV
OUT
(VIDEO
OUT/AUDIO
OUT
(Left/Right))
Connect
to
a
TV
with
video
and
audio
inputs.
e
COMPONENT/PROGRESSIVE
SCAN
VIDEO
OUT
(Y
Pb
Pr)
Connect
to
a
TV
with
Y
Pb
Pr
inputs.
f
AUDIO
OUT
(Left/Right)
Connect
to
a
TV
or
other
equipment
with
audio
inputs.
g
Cooling
fan
h
RF.
OUT
Connect
to
a
TV
with
RF
coaxial
inputs.
i
OPTICAL
(DIGITAL
AUDIO
OUT
jack)
Connect
to
digital
(optical)
audio
equipment.
j
S-VIDEO
OUT
Connect
to
a
S-Video
Input
on
TV.
k
COAXIAL
(DIGITAL
AUDIO
OUT
jack)
Connect
to
digital
(coaxial)
audio
equipment.
ab
c
d
ef
g
hi
j k
Rear
Panel
Caution
Do
not
touch
the
inner
pins
of
the
jacks
on
the
rear
panel.
Electrostatic
discharge
may
cause
permanent
damage
to
the
unit.
Hookup
and
Settings
Depending
on
your
TV
and
other
equipment
there
are
various
ways
you
can
connect
the
recorder.
Please
refer
to
the
manuals
of
your
TV,
VCR,
Stereo
System
or
other
devices
as
necessary
for
additional
connection
information.
Notes:
?
Make
sure
the
Recorder
is
connected
directly
to
the
TV
and
tune
the
TV
to
the
correct
video
input
channel.
?
Do
not
connect
the
Recorder's
AUDIO
OUT
jack
to
the
phono
in
jack
(record
deck)
of
your
audio
system.
Do
not
connect
the
Recorder
via
another
VCR.
The
DVD
could
be
distorted
by
the
copy
protection
system.
?
The
and
sound
of
a
nearby
TV,
VCR,
or
radio
may
be
distorted
during
playback.
Position
the
units
away
from
each
other
or
turn
off
the
unit
after
removing
the
disc.
16
Connecting
an
Connecting
an
Antenna
Antenna
or
Cable
TV
or
Cable
TV
a
Antenna:
Disconnect
the
antenna
from
the
rear
of
the
TV
and
identify
the
antenna
cable.
If it
is
a
round
75
ohm
coaxial
cable
connect
it
directly
to
the
jack
marked
ANT.IN
on
your
Recorder.
If
your
antenna
cable
is
flat
connect
it
to
a
300-ohm
to
75-ohm
antenna
adaptor
(not
supplied)
and
slip
the
adaptor
over
the
ANT.IN
jack.
Don't
attempt
to
screw
it
into
to
the
Recorder.
b
Cable
TV:
If
your
cable
connection
has
no
converter
or
descrambler,
unscrew
the
cable
from
your
TV
and
attach
it
to
the
ANT.IN
jack
on
the
Recorder.
If
a
con-
verter
is
required
connect
a
coaxial
cable
from
the
wall
jack
to
the
IN
connector
on
the
converter,
and
a
coaxial
cable
from
the
OUT
connector
on
the
convert-
er
to
the
ANT.IN
on
your
Recorder.
This
cable
hookup
permits
both
TV
and
Recorder
operation.
To
view
or
record
a
CATV
channel
1.
Tune
the
TV
to
the
Recorder
output
channel
(CH
3or4).
2.
Set
the
Recorder
channel
selector
to
the
cable
output
channel.
(Example:
CH3)
3.
Select
a
channel
using
the
cable
converter.
Notes:
?
With
this
connection,
you
cannot
record
one
program
while
viewing
another.
?
If
you
are
using
a
cable
box
to
tune
channels,
it
is
not
necessary
to
do
Auto
Channel
Set.
Connections
to
your
TV
Connections
to
your
TV
Make
one
of
the
following
connections,
depending
on
the
capabilities
of
your
TV.
Rear
of
Recorder
Antenna
Antenna
OR
OR
a
b
AUDIO
INPUT
VIDEO
INPUT
ANTENNA
INPUT
Rear
of
TV
A1
V
R
Y
Pb
Pr
COMPONENT/PROGRESSIVE
SCAN
VIDEO
INPUT
AUDIO
INPUT
S-VIDEO
INPUT
Rear
of
TV
S
A2
C
Rear
of
Recorder
17
RF
coaxial
connection
Connect
the
RF.OUT
jack
on
the
Recorder
to
the
antenna
in
jack
on
the
TV
using
the
supplied
75-ohm
Coaxial
Cable
(R).
How
to
set
the
Recorder's
RF
output
channel
1.
When
the
Recorder
is
turned
off,
press
and
hold
CH
(V/v)
on
the
front
panel
for
more
than
five
seconds.
[RF-03]
or
[RF-04]
appears
in
the
dis-
play
window.
2.
Press
CH
(V/v)
to
change
the
RF
output
channel
(RF-03
or
RF-04).
3.
Tune
the
TV
to
this
channel.
Video
connection
Connect
the
DVD/VCR
VIDEO
OUT
jack
on
the
Recorder
to
the
video
in
jack
on
the
TV
using
the
video
cable
supplied
(V).
Note:
If
you
use
this
connection,
set
the
TV's
source
selector
to
VIDEO.
S-Video
connection
Connect
the
S-VIDEO
OUT
jack
on
the
Recorder
to
the
S-Video
in
jack
on
the
TV
using
the
optional
S-
Video
cable
(S).
Component
Video
/
Progressive
Scan
connection
If
your
television
is
a
high-definition
or
"digital
ready"
television,
you
may
take
advantage
of
the
Recorder's
progressive
scan
output
for
the
highest
video
resolu-
tion
possible.
Connect
the
COMPONENT/PROGRESSIVE
SCAN
VIDEO
OUT
jacks
on
the
Recorder
to
the
correspon-
ding
in
jacks
on
the
TV
using
an
optional
Y
Pb
Pr
cable
(C).
Notes:
?
Set
Progressive
Scan
option
to
[ON]
in
the
setup
menu,
see
page
21.
?
Progressive
Scan
does
not
work
with
the
RF,
Audio/Video
or
S-Video
connections.
?
If
your
TV
does
not
accept
the
Progressive
Scan
format,
the
will
appear
scrambled.
?
When
you
use
Component
Video
signal,
set
the
Progressive
Scan
to
[OFF]
on
the
setup
menu.
Audio
connection
Connect
the
Left
and
Right
DVD/VCR
AUDIO
OUT
jacks
on
the
Recorder
to
the
audio
left/right
in
jacks
on
the
TV
using
the
supplied
audio
cables
(A1
or
A2).
Connection
to
an
Connection
to
an
Amplifier
Amplifier
Connecting
to
an
amplifier
equipped
with
two
channel
analog
stereo
or
Dolby
Pro
Logic
II/Pro
Logic
Connect
the
Left
and
Right
AUDIO
OUT
(or
DVD/VCR
AUDIO
OUT)
jacks
on
the
Recorder
to
the
audio
left
and
right
in
jacks
on
your
amplifier,
receiv-
er,
or
stereo
system
using
the
audio
cables
(A)
sup-
plied.
Amplifier
(Receiver)
Rear
of
Recorder
A
X
O
AUDIO
INPUT
DIGITAL
INPUT
COAXIAL
DIGITAL
INPUT
OPTICAL
Manufactured
under
license
from
Dolby
Laboratories.
"Dolby",
"Pro
Logic",
and
the
double-D
symbol
are
trademarks
of
Dolby
Laboratories.
DTS
and
DTS
Digital
Out
are
trademarks
of
Digital
Theater
Systems,
Inc.
18
Connecting
to
an
amplifier
equipped
with
two
chan-
nel
digital
stereo
(PCM)
or
to
an
Audio/Video
receiv-
er
equipped
with
a
multi-channel
decoder
(Dolby
DigitalTM,
MPEG
2,
or
DTS)
1.
Connect
one
of
the
Recorder's
DIGITAL
AUDIO
OUT
jacks
(OPTICAL
O,
COAXIAL
X)
to
the
cor-
responding
in
jack
on
your
amplifier.
Use
an
optional
digital
(OPTICAL
O,
COAXIAL
X)
audio
cable.
2.
You
will
need
to
activate
the
Recorder
's
digital
output.
(See
[Audio
Settings]
on
page
22).
Digital
Multi-channel
sound
A
digital
multi-channel
connection
provides
the best
sound
quality.
For
this
you
need
a
multi-channel
Audio/Video
receiver
that
supports
one
or
more
of
the
audio
formats
supported
by
your
Recorder
(MPEG
2,
Dolby
Digital
and
DTS).
Check
the
receiver
manual
and
the
logos
on
the
front
of
the
receiver.
Caution:
Due
to
the
DTS
Licensing
agreement,
the
digital
output
will
be
in
DTS
digital
out
when
DTS
audio
stream
is
selected.
Notes:
?
If
the
audio
format
of
the
digital
output
does
not
match
the
capabilities
of
your
receiver,
the
receiver
will
produce
a
strong,
distorted
sound
or
no
sound
at
all.
?
Six
Channel
Digital
Surround
Sound
via
digital
connec-
tion
can
only
be
obtained
if
your
receiver
is
equipped
with
a
Digital
Multi-channel
decoder.
?T
o
see
the
audio
format
of
the
current
DVD
in
the
on-
screen
display,
press
AUDIO.
?
This
Recorder
does
not
perform
internal
(2
channel)
decoding
of
a
DTS
sound
track.
To
enjoy
DTS
multi
channel
surround,
you
must
connect
this
Recorder
to
a
DTS
compatible
receiver
via
one
of
this
Recorder's
digi-
tal
audio
outputs.
Accessory
Audio/Video
(A/V)
Connections
to
Recorder
ConnecttheAV1INorAV2INjacksonthe
Recorder
to
the
audio/video
out
jacks
on
your
acces-
sory
component,
using
the
optional
audio/video
cables.
(Refer
to
page
45
for
[Recording
from
External
Components].)
Note:
If
you
use
the
S-VIDEO
IN
jack
on
the
front
panel,
the
VIDEO
IN
jack
on
the
front
panel
is
not
available.
Connecting
a
Digital
Camcorder
Use
a
DV
cable
(not
supplied)
to
connect
the
DV
in/out
jack
of
your
DV
Digital
Camcorder
to
the
front
panel
DV
IN
jack
of
this
Recorder.
Note:
This
jack
is
for
connection
to
DV
equipment
only.
It
is
not
compatible
with
digital
satellite
tuners
or
D-VHS
video
decks.
Rear
of
Recorder
Front
of
Recorder
DV
Digital
Camcorder
Front
of
Recorder
DV
IN/OUT
19
Initial
Settings
Initial
Settings
In
this
menu
system,
there
are
several
ways
to
cus-
tomize
the
settings
provided.
Most
menus
consist
of
three
levels
to
set
up
the
options,
but
some
require
greater
depth
for
the
variety
of
settings.
General
Operation
1.
Press
SETUP
and
the
Setup
menu
appears.
2.
Use
v
/
V
to
select
the desired
option.
3.
While
the
desired
item
is
selected,
press
B
to
move
to
the
second
level.
4.
Use
v
/
V
to
select
the
second
desired
option.
5.
Press
B
to
move
to
the
third
level.
6.
Use
v
/
V
to
select
the desired
setting
then
press
ENTER
to
confirm
your
selection.
Some
items
require
additional
steps.
7.
Press
SETUP
to
exit
the
Setup
menu.
Note:
Press
b
to
go
back
to
the
previous
level.
General
Settings
Tuning
Band
Select
1.
Select
the
[Tuning
Band]
option
then
press
B
.
2.
Use
v
/
V
to
select
the
tuning
band
(TV
or
CATV)
option
then
press
ENTER.
TV:
If
you
are
using
a
standard
antenna
to
receive
channels.
CATV:
If
you
are
using
basic
cable
to
receive
channels.
Auto
Channel
Set
Connect
the
Recorder
to
the desired
type
of
antenna
or
cable
TV
system
as
shown
on
page
16.
This
Recorder
is
equipped
with
a
frequency
synthe-
sized
tuner
capable
of
receiving
up
to
181
channels.
These
include
VHF
channels
2-13,
UHF
channels
14-
69
and
CATV
channels
1-125.
1.
Select
the
[Auto
Channel
Set]
option.
2.
Press
B
to
move
to
the
third
level.
[Start]
icon
is
highlighted.
3.
Press
ENTER
to
begin
the
channel
search.
The
tuner
will
automatically
cycle
through
all
available
channels
in
the
area
and
place
them
in
the
tuner's
memory.
Note:
After
the
Auto
Channel
Set
proceeding
is
complete,
make
sure
the
Tuning
Band
is
set
appropriately
(TV
or
CATV)
on
tuning
band,
follow
steps
1~2
as
shown
previous
(Tuning
Band
Select)
to
choose
the
correct
Tuning
Band
(TV
or
CATV).
Hookup and
Settings
20
To
Add
or
Erase
Channels
from
Memory
This
feature
allows
you
to
add
to
or
erase
channels
from
memory
manually.
1.
Select
the
[CH.
Add/Del]
option.
2.
Press
B
to
move
to
the
third
level.
[Edit]
icon
is
highlighted.
3.
Press
ENTER
and
the
Channel
Edit
menu
appears.
4.
Use
v
/
V
or
number
buttons
to
select
a
channel
to
add
or
delete
then
press
B.
[Add]
or
[Delete]
icon
is
highlighted.
5.
Press
ENTER
to
confirm
your
setting.
6.
Repeat
steps
4-5
to
add
or
erase
additional
channels.
7.
Press
SETUP
or
RETURN
(O)
to
exit
the
menu.
Clock
Set
1.
Select
the
[Clock
Set]
option.
2.
Press
B
to
move
to
the
third
level.
Auto
The
Auto
option
is
set
at
the
factory.
In
the
Auto
option,
the
Recorder
looks
for
a
channel
carrying
XDS
(Extended
Data
Services)
information.
XDS
updates
the
clock
using
the
Coordinated
Universal
Time.
1.
Use
v
/
V
to
choose
your
Time
Zone
manually.
When
Timezone
is
set
to
Auto,
the
Recorder
will
use
XDS
information
to
determine
the
proper
setting.
2.
Use
B
to
choose
the
[Daylight
Savings]
option.
Use
v
/
V
to
choose
Auto,
On,
or
Off.
When
it
is
set
to
Auto,
the
Recorder
will
use
XDS
information
to
determine
the
proper
setting.
3.
Press
ENTER
to
confirm
your
setting.
Note
:
The
Auto
Clock
Feature
enables
the
Recorder
to
set
up
the
clock
when
the
Recorder
is
turned
off.
Manual
If
your
local
TV
station
does
not
send
date
and
time
information,
or
sends
incorrect
information,
you
can
set
the
clock
manually.
1.
Enter
the
necessary
information
for
year,
date
and
time.
b
/
B
(left/right):
Moves
the
cursor
to
the
previous
or
next
column.
v
/
V
(up/down):
Changes
the
setting
at
the
current
cursor
position.
2.
Press
ENTER
to
confirm
your
setting.
3.
Press
SETUP
to
exit
the
Setup
menu.
TV
Aspect
4:3
Letter
Box:
Select
when
a
standard
4:3
TV
is
connected.
Displays
theatrical
images
with
masking
bars
above
and
below
the
picture.
4:3
Pan
Scan:
Select
when
a
standard
4:3
TV
is
connected.
Displays
pictures
cropped
to
fill
your
TV
screen.
Both
sides
of
the
are
cut
off.
16:9
Wide:
Select
when
a
16:9
wide
TV
is
connected.
21
Progressive
Scan
Progressive
Scan
Video
provides
the
highest
quality
pictures
with
less
flickering.
[ON]
:
Using
the
COMPONENT/PROGRESSIVE
SCAN
VIDEO
OUT
jacks
for
connection
to
a
TV
or
monitor
that
is
compatible
with
a
progressive
scan
signal.
[OFF]
:
Using
the
COMPONENT/PROGRESSIVE
SCAN
VIDEO
OUT
jacks,
but
are
con-
necting
the
Recorder
to
a
standard
(ana-
log)
television.
Caution
Once
the
setting
for
Progressive
Scan
output
is
entered,
an
will
only
be
visible
on
a
Progressive
Scan
compatible
TV
or
monitor.
If
you
set
Progressive
Scan
to
[ON]
in
error,
you
must
reset
the
Recorder.
First,
remove
the
disc
or
tape
in
the
Recorder.
Next,
press
STOP
(x)
and
hold
it
for
five
seconds
before
releasing
it.
The
video
output
will
be
restored
to
the
standard
setting,
and
a
will
once
again
be
visible
on
a
conventional
analog
TV
or
monitor.
Power
Save
Mode
Set
Power
Save
Mode
to
[ON]
to
place
your
Recorder
into
an
economic
power
save
mode.
Factory
Setting
You
can
reset
the
Recorder
to
its
original
factory
settings.
Some
options
cannot
be
reset
(Rating,
Password,
Area
Code).
1.
Select
the
[Factory
Setting]
option.
2.
Press
B
to
select
[SET]
then
press
ENTER.
The
Initialize
menu
will
appear.
3.
Select
[Yes]
and
press
ENTER.
Language
Settings
Display
Menu
Select
a
language
for
the
Setup
menu
and
informa-
tion
display.
Disc
Menu
/
Audio
/
Subtitle
[Original]
:
Refers
to
the
original
language
in
which
the
disc
was
recorded.
[Others]
:
To
select
another
language,
press
number
buttons
then
ENTER
to
enter
the
corre-
sponding
4-digit
number
according
to
the
lan-
guage
code
list
in
the
reference
chapter
(see
p.
56).
If
you
enter
the
wrong
language
code,
press
CLEAR.
[OFF]
(for
Disc
Subtitle)
:
Turn
off
Subtitle.
Hookup and
Settings
22
Audio
Settings
Each
DVD
disc
has
a
variety
of
audio
output
options.
Set
the
Recorder's
Audio
Output
according
to
the
type
of
audio
system
you
use.
Dolby
Digital
/
DTS
/
MPEG
[Bitstream]:
Select
[Bitstream]
if
you
connect
the
DVD+VCR's
DIGITAL
AUDIO
OUT
jack
to
an
amplifier
or
other
equipment
with
a
Dolby
Digital,
DTS
or
MPEG
decoder.
[PCM]
(for
Dolby
Digital
/
MPEG):
Select
when
connected
to
a
two-channel
digital
stereo
amplifi-
er.
DVDs
encoded
in
Dolby
Digital
or
MPEG
will
be
automatically
downmixed
to
two-channel
PCM
audio.
[OFF]
(for
DTS):
If
you
select
[Off],
the
DTS
signal
is
not
output
through
the
DIGITAL
AUDIO
OUT
jack.
Sampling
Freq.
(Frequency)
If
your
receiver
or
amplifier
is
NOT
capable
of
han-
dling
96
kHz
signals,
select
48
kHz.
When
this
choice
is
made,
this unit
automatically
converts
any
96
kHz
signals
to
48
kHz
so
your
system
can
decode
them.
If
your
receiver
or
amplifier
is
capable
of
handling
96
kHz
signals,
select
96
kHz.
When
this
choice
is
made,
this unit
passes
each
type
of
signal
through
without
any
further
processing.
Check
the
documentation
for
your
amplifier
to
verify
its
capabilities.
DRC
(Dynamic
Range
Control)
With
the
DVD
format,
you
can
hear
a
program's
soundtrack
in
the
most
accurate
and
realistic
presen-
tation
possible,
thanks
to
digital
audio
technology.
However,
you
may
wish
to
compress
the
dynamic
range
of
the
audio
output
(the
difference
between
the
loudest
sounds
and
the
quietest
ones).
This
allows
you
to
listen
to
a
movie
at
a
lower
volume
without
los-
ing
clarity
of
sound.
Set
DRC
to
[ON]
for
this
effect.
Vocal
Set
Vocal
to
[ON]
only
when
a
multi-channel
karaoke
DVD
is
playing.
The
karaoke
channels
on
the
disc
will
mix
into
normal
stereo
sound.
23
Lock
(Parental
Control)
Settings
Rating
Some
movies
contain
scenes
that
may
not
be
suit-
able
for
children
to
view.
Many
of
these
discs
contain
parental
control
information
that
applies
to
the
com-
plete
disc
or
to
certain
scenes
on
the
disc.
Movies
and
scenes
are
rated
from
1
to
8,
depending
on
the
area.
DVD
video
discs
may
or
may
not
respond
to
the
parental
control
setting
if
the
Area
code
of
the
disc
is
set
wrongly.
Some
discs
offer
more
suitable
scenes
as an
alternative.
Ratings
are
area
depend-
ent.
The
parental
control
feature
allows
you
to
block
access
to
scenes
below
the
rating
you
input,
thereby
preventing
your
children
from
being
able
to
view
material
you
believe
is
unsuitable.
1.
Select
[Rating]
option
then
press
B.
2.
To
access
the
Rating,
Password
and
Area
Code
features,
you
must
input
the
4-digit
security
code
you
created.
If
you
have
not
yet
entered
a
security
code
you
are
prompted
to
do
so.
Input
a
4-digit
code.
Enter
it
again
to
verify.
If
you
make
a
mistake
press
CLEAR.
3.
Select
a
rating
from
1
to
8
using
the
v
/
V
buttons.
[1]-[8]
:
Rating
one
(1)
has
the
most
restrictions
and
rating
eight
(8)
is
the
least
restrictive.
[No
Limit]
:
If
you
select
[No
Limit],
parental
control
is
not
active
and
the
disc
plays
in
full.
4.
Press
ENTER
to
confirm
your
rating
selection,
then
press
SETUP
to
exit
the
menu.
5.
Press
OPEN/CLOSE
(Z)
to
activate
parental
control.
Note:
If
you
set
a
rating
for
the
recorder,
all
disc
scenes
with
the
same
rating
or
lower
are
played.
Higher
rated
scenes
are
not
played
unless
an
alternate
scene
is
available
on
the
disc.
The
alternative
must
have
the
same
rating
or
a
lower
one.
If
no
suitable
alternative
is
found,
playback
stops.
You
must
enter
the
4-digit
password
or
change
the
rating
level
in
order
to
play
the
disc.
Set
Password
You
can
enter
or
change
password.
1.
Select
[Set
Password]
option
then
press
B.
2.
Follow
step
2
as
shown
[Rating].
To
change
the
password,
select
the
[Change],
press
ENTER
and
input
the
new
4-digit
code.
Input
it
again
to
verify.
3.
Press
SETUP
to
exit
the
menu.
If
you
forget
your
password
If
you
forget
your
password
you
can
clear
it
using
the
following
steps:
1.
Press
SETUP
to
display
the
Setup
menu.
2.
Input
the
6-digit
number
[210499].
The
message
appears,
select
[Yes]
then
press
ENTER.
The
security
code
is
cleared.
3.
Enter
a
new
code
as
described
above.
Area
Code
Enter
the
Area
Code
whose
standards
were
used
to
rate
the
DVD
video
disc,
based
on
the
list
in
the
reference
chapter
(see
p.
56).
1.
Select
[Area
Code]
option
then
press
B.
2.
Follow
step
2
as
shown
[Rating].
3.
Select
the
first
character
using
v
/
V
buttons.
4.
Shift
the
cursor
using
B
buttons
and
select
the
second
character
using
v
/
V
buttons.
5.
Press
ENTER
to
confirm
your
area
code
selection,
then
press
SETUP
to
exit
the
menu.
Hookup and
Settings
24
Recording
Settings
Disc
Record
Mode
You
can
set
the
quality
for
recording;
XP
(Excellent
quality),
SP
(Standard
quality),
LP
(Low
quality),
EP
(Extend
quality).
1.
Select
the
[Disc
Record
Mode]
option
then
press
B.
2.
Use
v
/
V
to
select
a
desired
Disc
Record
Mode
(XP,
SP,
LP
or
EP).
3.
Press
ENTER
to
confirm
your
selection,
then
press
SETUP
to
exit
the
menu.
VCR
Record
Mode
You
can
set
the
quality
for
VCR
recording;
SP
(Standard
Play),
SLP
(Super
Long
Play).
DV
Record Audio
You
need
to
set
this
if
you
have
a
camcorder
using
32kHz/12-bit
sound
connected
to
the
front
panel
DV
IN
jack.
Some
digital
camcorders
have
two
stereo
tracks
for
audio.
One
is
recorded
at
the
time
of
shoot-
ing;
the
other
is
for
overdubbing
after
shooting.
On
the
Audio
1
setting,
the
sound
that
was
recorded
while
shooting
is
used.
On
the
Audio
2
setting,
the
overdubbed
sound
is
used.
Auto
Chapter
During
recording,
chapter
markers
are
added
auto-
matically
at
fixed
intervals.
You
can
set
this interval
to
5
minutes
or
10
minutes.
To
turn
off
automatic
chap-
ter
marking,
select
[None].
Disc
Settings
Initialize
If
you
load
a
completely
blank
disc,
the
recorder
will
initialize
the
disc.
?
DVD-R:
The
recorder
initialize
the
disc
to
Video
mode.
The
recording
mode
will
always
be
Video
mode.
?
DVD-RW:
The
Initialize
menu
will
appear.
Select
[VR
Mode]
or
[Video
Mode]
then
press
ENTER.
?
DVD+RW/DVD+R(DL)/DVD-RAM:
The
Initialize
menu
will
appears.
Select
[Yes]
then
press
ENTER.
Also,
you
can
reformat
the
DVD-RW/DVD+RW/
DVD-RAM
from
the
Setup
menu
as
below.
1.
Select
the
[Initialize]
option
then
press
B.
[Start]
icon
is
highlighted.
2.
Press
ENTER.
?
IncaseofDVD-RW,useb/Btoselecta
desired
Disc
Initialize
Mode
(VR
Mode
or
Video
Mode)
then
press
ENTER.
?
In
case
of
DVD+RW/DVD-RAM,
use
b
/
B
to
select
[OK],
and
press
ENTER.
It
takes
a
few
moments
to
format
the
disc.
Caution
If
you
want
to
change
the
disc
format,
everything
recorded
on
the
disc
will
be
erased.
25
Finalize
Finalizing
'fixes'
the
recordings
in
place
so
that
the
disc
can
be
played
on
a
regular
DVD
player
or
com-
puter
equipped
with
a
suitable
DVD-ROM
drive.
Finalizing
a
Video
mode
disc
creates
a
menu
screen
for
navigating
the
disc.
This
is
accessed
by
pressing
LIST/DISC
MENU
or
TITLE.
Caution
Once
you
have
finalized
a
DVD-R
and
DVD+R
(DL)
disc,
you
cannot
edit
or
record
anything
else
on
that
disc
except
DVD+RW.
However,
you
can
record
and
edit
a
DVD-RW
disc
by
choosing
[Unfinalize]
option.
1.
Select
the
[Finalize]
option
then
press
B.
2.
Press
ENTER
while
[Finalize]
is
selected.
Finalize
menu
appears.
3.
Select
[OK]
then
press
ENTER.
The
Recorder
starts
finalizing
the
disc.
Notes:
?
Finalization
can
take
up
to
3-4
minutes
or
more
depend-
ing
on
the
type
of
disc,
how
much
is
recorded
on
the
disc,
and
the
number
of
titles
on
the
disc.
?
DVD+R
DL
disc
can
take
up
to
30
minutes
to
finalize.
Tips:
?I
f
you
load
a
DVD-RW
that
has
already
been
finalized,
you
can
'Unfinalize'
it
by
choosing
[Unfinalize]
from
the
Finalize
menu.
After
doing
this,
you
can
edit
and
re-
record
onto
the
disc.
?Y
ou
cannot
unfinalize
a
DVD-R
and
DVD+R
(DL)
disc.
?
If
[Disc
Protect]
option
is
set
to
[ON],
the
finalize
is
not
available.
To
finalize,
set
[Disc
Protect]
option
to
[OFF].
Disc
Label
Use
the
Disc
Label
feature
to
enter
a
name
for
the
disc.
This
name
appears
when
you
load
the
disc
and
when
you
display
disc
information
on-screen.
?
The
Disc
label
can
be
up
to
32
characters
long.
?
For
discs
formatted
on
a
different
Recorder,
you
will
see
only
a
limited
character
set.
1.
Select
the
[Disc Label]
option
then
press
B.
[Edit]
icon
is
highlighted.
2.
Press
ENTER.
Keyboard
menu
appears.
To
enter
characters,
see
page
51.
Disc
Protect
Depending
on
the
type
of
disc
you
are
using,
Disc
Protect
allows
you
to
preserve
your
recordings
in
a
variety
of
ways:
?
DVD+RW
:
Prevents
editing,
erasing,
or
overwrit-
ing
of
existing
recordings.
Allows
regular
record-
ing.
?
DVD+R
:
Prevents
editing
or
erasing
of
existing
recordings.
Allows
regular
recording.
?
DVD-RW
(VR
mode)/DVD-RAM
:
Prevents
edit-
ing,
erasing,
and
regular
recording.
Notes:
?
Disc
Protect
is
not
compatible
with
DVD-RW
discs
in
Video
mode
or
DVD-R
discs.
?
If
you
need
to
unlock
a
disc
to
make
edits,
select
[OFF].
Hookup and
Settings
26
PBC
PBC
stands
for
Playback
Control
and
refers
to
special
menus
and
navigation
features
that
are
available
on
some
Video
CDs.
[ON]:
Video
CDs
are
played
according
to
the
PBC,
if
available.
[OFF]:
Video
CDs
are
played
the
same
way
as
Audio
CDs.
AutoPlay
When
you
load
a
DVD
with
AutoPlay
turned
on,
the
Recorder
will
bypass
the
Disc
menu
and
trailers
and
start
playing
the
movie
automatically.
Set
[AutoPlay]
to
[ON]
or
[OFF].
DivX
Registration
Code
We
provide
you
the
DivX
VOD
(Video
On
Demand
registration
code
that
allows
you
to
rent
and
purchase
videos
using
the
DivX
VOD
service.
For
more
infor-
mation,
visit
www.divx.com/vod.
1.
Select
[About
DivX(R)]
option
then
press
B.
2.
Press
ENTER
while
[Enter]
is
selected
and
the
registration
code
will
appear.
3.
Use
the
registration
code
to
purchase
or
rent
the
videos from
Divx
VOD
service
at
www.divx.com/vod.
Follow
the
instructions
and
download
the
video
onto
a
disc
for
playback
on
this
unit.
Note:
All
the
downloaded
videos
from
DivX
VOD
can
only
be
played
back
on
this
unit.
DivX
27
General
Explanation
of
General
Explanation
of
On-Screen
Display
On-Screen
Display
Some
DVDs
require
specific
operation
or
allow
only
limited
operation
during
playback.
When
this
occurs,
is
displayed,
action
prohibited
or
not
available.
Displaying
Information
While
Watching
TV
While
watching
TV,
press
DISPLAY
to
display/
remove
the
information
displayed
on-screen.
e.g.,
when
DVD-RW
in
VR
mode
is
inserted.
Changing
TV
Audio
Channel
Some
TV
programs
are
broadcast
with
both
a
main
and
a
Secondary
Audio
Program
(SAP).
You
can
change
the
TV
audio.
Press
AUDIO
repeatedly
to
change
the
TV
audio,
according
to
Broadcast
audio
signal
as
shown
below.
?
STEREO+SAP
Audio
Signal
Stereo
→
SAP
→
Mono
→
Stereo
?
STEREO
Audio
Signal
Stereo→L→R→Mono→Stereo
?
SAP
Audio
Signal
Mono
→
SAP
→
Mono
?
MONO
Audio
Signal
Mono
The
current
audio
channel
is
displayed
on-screen.
?
If
SAP
is
selected,
but
there
is
no
SAP
channel
being
broadcast,
you
will
still
hear
the
main
audio
(Mono
or
Stereo)
channel.
?
If
the
sound
is
poor
quality
when
set
to
Stereo,
you
can
often
improve
it
by
changing
to
Mono.
?
When
an
external
input
is
selected,
the
audio
channel
can
be
switched
only
to
Stereo.
Displaying
Disc
Information
on-screen
You
can
display
various
information
about
the
disc
or
tape
loaded
on-screen.
Some
items
can
be
changed
using
the
menu.
1.
Press
DISPLAY
once
to
show
current
status.
Example:
DVD-RW
in
VR
mode
2.
Press
DISPLAY
once
again
to
show
various
play-
back
information.
The
items
displayed
differ
depending
on
the
disc
type
or
playing
status.
3.
You
can
select
an
item
by
pressing
v
/
V
and
change
or
select
the
setting
by
pressing
b
/
B.
For
details
about
each
item,
see
the
pages
in
parentheses.
[Title]:
Current
title
(or
track)
number/total
num-
ber
of
titles
(or
tracks)
(page
29)
[Chapter]:
Current
chapter
number/total
number
of
chapters
(page
29)
[Time]:
Elapsed
playing
time
(page
30)
[Audio]:
Selected
audio
language
(DVD
VIDEO
only)
or
audio
channel
(page
32)
[Subtitle]:
Selected
subtitle
(page
31)
[Angle]:
Selected
angle/total
number
of
angles
(page
31)
[Sound]:
Selected
sound
mode
(page
32)
Note:
If
no
button
is
pressed
for
7
seconds,
the
on-screen
display
disappears.
Indicates
disc
name
and
format.
Indicates
channel
number
and
audio
input
signal
received
by
the
tuner.
Indicates
the record
mode,
free
space,
and
elapsed
time
progress
bar.
Indicates
current
date
and
time.
Indicates
operational
mode
of
the
recorder.
Indicates
output
audio
signal.
Hookup and
Settings
28
VCR
T
VCR
Tape
Playback
ape
Playback
Press
VCR
button
to
select
the
device
to
be
operated.
Basic
Instructions
1.
Insert
a
pre-recorded
video
cassette.
The
indicator
lights
and
the
Recorder
pow-
ers
on
automatically.
2.
If
the
(TIMER)
indicator
in
the
display
window
is
lit
press
POWER
once.
3.
If
a
tape
without
a
safety
tab
is
inserted
the
unit
starts
playback
automatically.
If
not,
press
N
(PLAY).
4.
Press
STOP
(x)
to
stop
playback.
STOP
appears
on
the
TV
screen.
If
the
tape
reaches
the
end
before
you
press
STOP
(x)
the
Recorder
auto-
matically
stops,
rewinds
and
ejects
the
tape.
Note:
It
is
not
necessary
to
select
the
tape
speed
for
playback
because
it
is
automatically
selected
by
the
Recorder.
Also,
during
playback
the
TV/VCR
selector
switches
to
VCR
mode
automatically.
Auto
Tracking
Automatic
tracking
adjusts
the
to
remove
snow
or
streaks
and
beings
when:
?A
tape
is
played
for
the
first
time.
?
The
tape
speed
(SP,
LP,
SLP)
changes.
?
Streaks
or
snow
appear
due
to
scratches
on
the
tape.
Manual
Tracking
To
manually
adjust
the
tracking
use
the
CH/TRK
(v/V)
buttons
on
the
Remote
Control
or
CH
(v/V)
on
the
front
panel
during
playback.
Notes:
?V
ertical
jitter
requires
a
very
fine
adjustment.
?T
racking
is
automatically
reset
to
normal
when
the
tape
is
ejected
or
the
power
cord
is
unplugged
for
more
than
3
seconds.
Search
This
function
lets
you
visually
search
for
a
tape
sec-
tion
in
either
direction:
forward
and
reverse.
During
the
high-speed
search
modes,
the
audio
is
muted
and
horizontal
lines
(noise
bars)
appear.
Also,
a
short
time
is
needed
to
stabilize
the
tape
speed
when
re-entering
the
PLAY
mode
so
slight
interfer-
ence
may
be
observed
during
this
time.
To
search:
1.
Press
BACKWARD
(m)
or
FORWARD
(M)
during
playback.
2.
To
return
to
playback,
press
N
(PLAY).
Note:
After
3
minutes
in
SEARCH
mode
the
Recorder
returns
to
PLAY
mode
to
protect
the
tape
and
video
heads.
Still
and
Frame-by-Frame
Playback
1.
Press
PAUSE/STEP
(X)
during
playback.
A
still
appears
on
the
TV
screen
and
the
audio
is
muted.
2.
If
the
still
vibrates
vertically,
stabilize
it
by
using
CH/TRK
(v/V)
on
the
Remote
Control.
3.
Press
PAUSE/STEP
(X)
repeatedly
to
advance
the
video
one
frame
at
a
time.
4.
To
return
to
playback,
press
N
(PLAY).
Note:
After
5
minutes
in
STILL
mode
the
Recorder
stops
to
protect
the
tape
and
video
heads.
Slow
Motion
During
slow
motion,
audio
is
muted
and
horizontal
lines
(noise
bars)
may
appear
on
the
TV
screen.
This
is
normal.
1
While
in
still
mode,
press
FORWARD
(M).
The
tape
is
played
at
a
speed
1/19
times
slower
than
the
normal
speed.
2.
Use
CH/TRK
(v/V)
on
the
Remote
Control
if
necessary
to
adjust
the
tracking.
3.
To
return
to
the
normal
speed,
press
N
(PLAY).
Note:
After
3
minutes
in
SLOW
MOTION
mode
the
Recorder
goes
back
to
PLAY
mode
to
protect
the
tape
and
video
heads.
Playback
29
Counter
Memory
Function
This
feature
is
useful
if
there
is
a
section
of
tape
you
want
to
view
immediately
after
recording
or
if
you
want
to
return
to
the
same
point
several
times.
1.
Begin
recording
or
playing
a
tape.
2.
Press
DISPLAY
until
the
real-time
counter
is
dis-
played
on
the
TV
screen.
3.
At
the
point
that
you
want
to
locate
later,
reset
the
real-time
counter
to
[0:00:00]
by
pressing
CLEAR.
4.
Continue
to
play
or
record.
5.
Press
STOP
(x)
when
recording
or
playback
finishes.
6.
Press
RETURN
(O).
The
tape
automatically
stops
when
the
tape
counter
returns
to
about
[0:00:00].
S-VHS
Quasi
Playback
(SQPB)
?T
his
Recorder
can
play
back
S-VHS
recorded
tapes,
however,
it
cannot
make
recordings
using
S-VHS
format
tapes.
?
SQPB
is
an
abbreviation
for
S-VHS
Quasi
Playback.
Playing
a
DVD
or
V
Playing
a
DVD
or
Video
CD
ideo
CD
Playback
Setup
1.
Press
OPEN/CLOSE
(Z)
to
open
the
disc
tray.
Load
your
chosen
disc
in
the
tray,
with
the
play-
back
side
down.
2.
Press
OPEN/CLOSE
(Z)
to
close
the
tray.
Playback
starts
automatically.
If
playback
does
not
start,
press
N
(PLAY).
In
some
cases,
the
disc
menu
might
appear
instead.
Use
the
bBvVbuttons
to
select
the
title/chap-
ter
you
want
to
view,
then
press
ENTER
to
start.
Press
TITLE
or
LIST/DISC
MENU
to
return
to
the
menu
screen.
Use
the
number
buttons
to
select
the
track
you
want
to
view
and
press
RETURN
to
return
to
the
menu
screen.
Menu
settings
and
operating
proce-
dures
may
differ.
Follow
the
instructions
on
each
menu
screen.
You
may
also
set
PBC
to
[OFF]
(See
page
26).
3.
To
stop
the
playback,
press
STOP
x.
The
unit
records
the
stopped
point,
depending
on
the
disc.
"Xx"
appears
on
the
screen
briefly.
Press
N
(PLAY)
to
resume
playback
(from
the
scene
point).
If
you
press
STOP
x
again
or
unload
the
disc
("x"
appears
on
the
screen.),
the
unit
will
clear
the
stopped
point.
Press
OPEN/CLOSE
(Z)
to
remove
the
disc.
Press
OPEN/CLOSE
(Z)
to
close
disc
tray
or
press
POWER
(1),
the
disc
tray
closes
automati-
cally
and
unit
turns
off.
Notes:
?
If
parental
control
is
set
and
the
disc
is
not
within
the
rating
settings
you
must
input
the
password.
(See
[Rating]
on
page
23).
?
DVDs
may
have
a
region
code.
Your
Recorder
will
not
play
discs
that
have
a
region
code
different
from
your
Recorder.
The
region
code
for this
player
is
1
(one).
?
Unless
stated
otherwise,
all
operations
described
use
the
Remote
Control.
Some
features
may
also
be
avail-
able
on
the
Setup
menu.
Moving
to
another
TITLE
When
a
disc
has
more
than
one
title,
you
can
move
to
another
title:
Press
DISPLAY
twice
then
use
v
/
V
to
select
the
title
icon.
Then,
press
the
appropriate
numbered
button
(0-9)
or
b
/
B
to
select
a
title
number.
Moving
to
another
CHAPTER
/
TRACK
When
a
title
on
a
disc
has
more
than
one
chapter
or
a
disc
has
more
than
one
track,
you
can
move
to
another
chapter/track
as
follows:
?
Press
SKIP
(>
or
.)
briefly
during
playback
to
select
the
next
chapter/track
or
to
return
to
the
beginning
of
the
current
chapter/track.
?
Press
SKIP
(.)
twice
in
quick
successions
to
step
back
to
the
previous
chapter/track.
?T
o
go
directly
to
any
chapter/track
during
playback,
press
DISPLAY
twice
and
use
v
/
V
to
select
the
chapter
or
track
(for
Video
CD)
icon.
Input
the
chapter/track
number
or
use
b
/
B.
Note:
On
a
Video
CD
with
PBC,
you
must
set
PBC
to
[OFF]
in
the
Setup
menu
to
use
this
function
(See
page
26).
30
Slow
Motion
1.
Press
BACKWARD
(m)
or
FORWARD
(M)
during
pause
mode.
2.
Use
the
BACKWARD
(m)
or
FORWARD
(M)
to
select
the
required
speed:
DVD
:
4
steps
(forward
and
backward)
Video
CD:
3
steps
(forward
only).
3.
To
exit
Slow
Motion
mode,
press
N
(PLAY).
Search
1.
Press
BACKWARD
(m)
or
FORWARD
(M)
during
playback.
2.
Press
BACKWARD
(m)
or
FORWARD
(M)
to
select
the
required
speed
(forward
and
backward):
DVD
;
5
steps
Video
CD
;
3
steps
3.
To
exit
SEARCH
mode,
press
N
(PLAY).
Time
Search
To
start
playing
at
any
chosen
time
on
the
disc:
1.
Press
DISPLAY
twice
during
playback.
The
time
search
box
shows
the
elapsed
playing
time.
2.
Press
v
/
V
to
select
the
time
clock
icon
and
[-:--:--]
appears.
3.
Input
the
required
start
time
in
hours,
minutes,
and
seconds
from
left
to
right.
If
you
enter
the
wrong
numbers,
press
b
/
B
to
move
the
under
bar
(_)
to
the
wrong
number.
Then
enter
the
cor-
rect
numbers.
4.
Press
ENTER
to
confirm.
Playback
starts
from
the
selected
time.
Marker
Search
To
enter
a
Marker
You
can
start
playback
from
up
to
six
memorized
points.
To
enter
a
marker,
press
MARKER
at
the
desired
point
on
the
disc.
The
Marker
icon
appears
on
the
TV
screen
briefly.
Repeat
to
enter
up
to
six
markers.
To
Recall
or
Clear
a
Marked
Scene
1.
During
disc
playback,
press
SEARCH.
The
marker
search
menu
appears
on
the
screen.
2.
Use
b/B/v/V
to
select
a
marker
scene
that
you
want
to
recall
or
clear.
3.
Press
ENTER
and
playback
starts
from
the
marked
scene.
Or,
Press
CLEAR
and
use
b
/
B
to
select
[Yes]
then
press
ENTER
to
delete
marked
scene
from
the
list.
4.
To
remove
the
Marker
Search
menu,
press
RETURN
(O)
Random
1.
Press
RANDOM
during
playback.
The
unit
automatically
begins
Random
Playback
and
[RANDOM]
appears
on
the
TV
screen.
2.
Press
RANDOM
again
to
normal.
Tip:
By
pressing
SKIP
(>)
during
Random
playback,
the
Recorder
selects
another
title
(track)
and
resumes
Random
playback.
Notes:
?
This
function
only
works
with
DVD
Karaoke
discs
or
video
CDs
without
PBC.
?
On
a
Video
CD
with
PBC,
you
must
set
PBC
to
[OFF]
in
the
setup
menu
to
use
the
this
function.
See
page
26.
VCD
Karaoke
DVD
VCD
DVD
+R
-R
+RW
RAM
-RWVideo
-RWVR
DivX
DVD
+R
-R
+RW
RAM
-RWVideo
-RWVR
VCD
DVD
+R
-R
+RW
RAM
-RWVideo
-RWVR
VCD
DVD
+R
-R
+RW
RAM
-RWVideo
-RWVR
31
Still
and
Frame-by-Frame
Playback
1.
Press
PAUSE/STEP
(X)
during
playback.
Advance
the
frame-by-frame
by
pressing
PAUSE/STEP
(X)
repeatedly.
2.
To
exit
still
motion
mode,
press
N
(PLAY).
Tips:
?
You
can
advance
or
back
up
the
frame-by-frame
by
pressing
b
/
B
repeatedly
during
PAUSE
mode.
?
The
frame-by-frame
in
reverse
is
not
available
for
Video
CD.
Zoom
Use
zoom
to
enlarge
the
video
image.
1.
Press
ZOOM
during
playback
or
still
playback
to
activate
the
Zoom
function.
2.
Each
press
of
the
ZOOM
button
changes
the
TV
screen
in
the
sequence:
X1
(normal
size)
→
X2
size
→
X4
size
→
X1
(normal
size)
3.
Use
the
bBvVbuttons
to
move
through
the
zoomed
picture.
4.
To
resume
normal
playback,
press
ZOOM
repeat-
edly
or
CLEAR
button.
Note:
The
Zoom
function
may
not
work
on
some
DVDs.
Repeat
Press
REPEAT
to
select
a
desired
repeat
mode.
?
[CHAPTER]
repeats
the
current
chapter.
(DVD
only)
?
[TITLE]
repeats
the
current
title.
(DVD
only)
?
[All]
repeats
the
all
titles/tracks.
(Video
CD,
DVD-RAM
or
VR
mode
DVD-RW
only).
?
[TRACK]:
repeats
the
current
track.
(Video
CD
only)
?
[OFF]
does
not
play
repeatedly.
Note:
On
a
Video
CD
with
PBC,
you
must
set
PBC
to
[OFF]
on
the
setup
menu
to
use
this
function
(See
page
26).
Repeat
A-B
To
repeat
a
sequence
during
playback.
1.
Press
A-B
at
your
chosen
starting
point.
[REPEAT
A
-
]
appears
briefly
on
the
TV
screen.
2.
Press
A-B
again
at
your
chosen
end
point.
[REPEAT
A
-
B]
appears
briefly
on
the
TV
screen
and
the
repeat
sequence
begins.
3.
Press
A-B
again
to
cancel.
Title
Menu
1.
Press
TITLE.
If
the
current
title
has
a
menu,
the
menu
appears
on
the
screen.
Otherwise,
the
disc
menu
may
not
appear.
2.
The
menu
offers
features
such
as
camera
angles,
spoken
language
and
subtitle
options,
and
chapters
for
the
title.
Disc
Menu
1.
Press
LIST/DISC
MENU
and
the
disc
menu
is
displayed.
2.
Press
LIST/DISC
MENU
again
to
exit.
Camera
Angle
If
the
disc
contains
scenes
recorded
at
different
camera
angles,
you
can
change
to
a
different
camera
angle
during
playback.
Press
ANGLE
then
press
b
/
B
repeatedly
during
playback
to
select
a
desired
angle.
Note
that
the
number
of
the
current
angle
appears
on
the
display.
Tip:
The
Camera
Angle
icon
is
displayed
on
the
TV
screen
when
alternate
angles
are
available.
Subtitles
Press
SUBTITLE
then
press
b
/
B
repeatedly
during
playback
to
see
the
different
subtitle
languages.
32
Changing
the
Audio
Soundtrack
Press
AUDIO
then
press
b
/
B
repeatedly
during
playback
to
hear
a
different
audio
language
or
audio
soundtrack
if
available.
Note:
Some
discs
feature
both
Dolby
Digital
and
DTS
soundtracks.
There
is
no
analog
audio
output
when
DTS
is
selected.
To
listen
to
the
DTS
soundtrack,
connect
this
recorder
to
a
DTS
decoder
via
one
of
the
digital
outputs.
See
page
17
for
connection
details.
Changing
the
Audio
Channel
Press
AUDIO
then
press
b
/
B
repeatedly
during
playback
to
hear
a
different
audio
channel.
With
DVD-RW
discs
recorded
in
VR
mode
that
have
both
a
main and
a
Bilingual
audio
channel,
you
can
switch
between
Main
(L),
Bilingual
(R),
or
a
mix
of
both
(Main
+
Bilingual)
by
pressing
AUDIO.
3D
Surround
This
unit
can
produce
a
3D
Surround
effect,
which
simulates
multi-channel
audio
playback
from
two
conventional
stereo
speakers,
instead
of
the
five
or
more
speakers
normally
required
to
listen
to
multi-
channel
audio
from
a
home
theater
system.
1.
Press
DISPLAY
twice
then
use
v
/
V
to
select
the
sound
icon.
Then,
use
b
/
B
to
select
[3D
SUR.].
2.
To
turn
off
the
3D
Surround
effect,
select
[NORMAL].
Last
Scene
Memory
This
Recorder
memorizes
last
scene
from
the
last
disc
that
is
viewed.
The
last
scene
remains
in
memo-
ry
even
if
you
remove
the
disc
from
the
Recorder
or
switch
off
the
Recorder.
If
you
load
a
disc
that
has
the
scene
memorized,
the
scene
is
automatically
recalled.
Notes:
?
Settings
are
stored
in
memory
for
use
any
time.
?
This
Recorder
does
not
memorize
settings
of
a
disc
if
you
switch
off
the
Recorder
before
commencing
to
play
it.
?
The
Last
Scene
Memory
function
may
not
work
on
some
DVDs.
?
Last
Scene
Memory
function
for
a
previous
DVD
title
is
erased
once
a
different
DVD
title
is
played.
Finding
Locations
on
a
Disc
You
can
directly
access
any
point
on
a
video
CD
using
this
function
within
95%
of
progress
bar.
Use
this
function
only
while
a
video
CD
is
playing.
Playback
jumps
to
the
point
specified.
1.
Press
SEARCH
during
playback.
The
progress
bar
appears
on
the
TV
screen.
2.
Use
b
/
B
to
find
the
desired
starting
position
for
playback.
3.
Press
ENTER
to
confirm
the
selected
position.
Playback
starts
from
the
selected
position.
Notes:
This
function
will
not
work
if
any
bookmarks
have
been
set;
see
page
30.
33
Playing
a
DivX
Movie
File
Playing
a
DivX
Movie
File
The
Recorder
can
play
Divx
files
on
CD-R/RW
or
DVD±R/RW
discs.
Before
playing
DivX
files,
read
"About
DivX
movie
files"
on
page
34.
1.
Use
v
/
V
to
select
a
folder,
and
press
ENTER
twice.
A
list
of
files
in
the
folder
appears.
2.
Use
v
/
V
to
select
a
file
then
press
N
(PLAY).
Playback
starts.
You
can use
variable
playback
functions.
Refer
to
pages
29-32.
3.
Press
STOP
(x)
to
stop
the
playback.
The
Movie
menu
appears.
Note:
This
recorder
cannot
play
back
the
DivX
file(s)
in
the
Memory
card.
Notice
for
displaying
the
DivX
subtitle
Please
refer
to
following
notice
when
the
DivX
subtitle
does
not
display
properly.
1.
Press
SETUP.
The
Setup
menu
appears.
2.
Usev/V/b/Btoselect[LANGUAGE]b[Disc
Subtitle]
then
find
a
suitable
language
for
the
DivX
subtitle.
Refer
to
[Disc
Menu/Audio/Subtitle]
on
page
21.
Tip:
If
the
subtitle
still
does
not
display
properly
after
the
steps
1-2
proceeded,
press
and
hold
SUBTITLE
about
3
seconds
then
use
b
/
B
to
select
another
language
code
during
playback
until
the
subtitle
is
displayed
properly.
Movie
menu
options
1.
Press
v
/
V
to
select
a
folder/file
on
the
Movie
menu
then
press
ENTER.
Movie
menu
options
appear.
2.
Press
v
/
V
to
select
an
option,
and
press
ENTER.
?
[Play]
Start
playback
the
selected
title.
?
[Open]
Opens
the
folder
and
a
list
of
files
in
the
folder
appears.
?
[Dubbing]
Dubs
the
DivX
movie
to
VCR.
(page
44)
Playback
34
About
DivX
movie
files
DivX
disc
compatibility
with
this
recorder
is
limit-
ed
as
follows:
Available
resolution
size
of
the
DivX
file
is
under
720x576
(W
x
H)
pixel.
The
file
name
of
the
DivX
subtitle
is
limited
to
char-
acters.
If
there
is
impossible
code
to
express
in
the
DivX
file,
it
may
be
displayed
as
"_"
mark
on
the
display.
The
total
number
of
files
and
folders
on
the
disc
are
free
but the
total
number
of
files
and
folders
on
the
folder
should
be
less
than
1999.
If
the
number
of
the
screen
frame
is
over
29.97
frames
per
second,
this
unit
may
not
operate
normally.
If
the
video
and
audio
structure
of
recorded
file
is
not
interleaved,
returns
to
the
menu
screen.
If
the
file is
recorded
with
GMC,
the
unit
sup-
ports
only
1-point
of
the
record
level.
*
GMC?
GMC
is
the
acronym
for
Global
Motion
Compensation.
It
is
an
encoding
tool
specified
in
MPEG4
standard.
Some
MPEG4
encoders,
like
DivX
or
Xvid,
have
this
option.
There
are
different
levels
of
GMC
encoding,
usually
called
1-point,
2-point,
or
3-point
GMC.
Playable
DivX
file
".avi",
".divx"
Playable
DivX
subtitle
".smi",
".srt
(SubRip
only)",
".sub
(Micro
DVD
format
only)",
DivX
subtitle
except
those
listed
above
is
not
displayed
on
the
TV
screen.
Playable
Codec
format
"DIV3", "DIV4",
"MP43",
"DIVX",
"XVID",
"DX50",
"DXSB".
Playable
Audio
format
"AC3",
"PCM",
"MP2", "MP3",
"WMA",
"DTS".
Sampling
frequency:
within
8
-
48
kHz
(MP3),
within
32
-
48kHz
(WMA)
Bit
rate:
within
8
-
320kbps
(MP3),
32
-
192kbps
(WMA)
35
Playing
an
Playing
an
Audio
CD
or
Audio
CD
or
MP3/WMA
MP3/WMA
files
files
The
Recorder
can
play
Audio
CDs
and
MP3/WMA
files
on
CD-ROM,
CD-R/RW,
DVD+R/RW,
DVD-R/RW,
DVD-RAM
discs
or
Memory
Card.
Before
playing
MP3/WMA
files,
read
[Notes
on
MP3/WMA
Recordings]
on
page
36.
Audio
CD
Once
you
insert
an
audio
CD
a
menu
appears
on
the
TV
screen.
Use
v
/
V
to
select
a
track
then
press
N
(PLAY)
and
playback
starts.
MP3
/
WMA
1.
Use
v
/
V
to
select
a
folder,
and
press
ENTER
twice.
A
list
of
files
in
the
folder
appears.
2.
Use
v
/
V
to
select
a
track
then
press
N
(PLAY)
and
Playback
starts.
Tips:
?Y
ou
can
view
TV
channel
or
video
input
source
by
pressing
RETURN
(O).
If
you
want
to
return
to
the
Music
menu,
press
LIST/DISC
MENU.
?
Press
DISPLAY
to
view
ID3-Tag
information
for
the
MP3
file.
If
ID3-Tag
information
is
not
present,
[MP3
ID3
tag
:None]
will
appear.
If
you
select
a
folder,
the
number
of
subfolders
and
number
of
MP3/WMA
files
in
the
folder
are
displayed.
Press
DISPLAY
again
to
remove
the
information
screen.
?
On
the
Music
menu,
you
can
display
the
folders
on
the
disc.
Use
vVbBto
select
the
"Folder"
icon
on
the
Music
menu
then
press
ENTER
twice.
?
On
CDs,
DVDs
or
Memory
Card
with
mixed
content
(Audio
tracks,
MP3/WMA
files,
DivX
files
or
JPEG
files),
you
can
select
among
the
Music
menu,
Movie
menu
and
menu
by
pressing
TITLE
repeatedly.
?
If
you
are
in
a
file
list
and
want
to
return
to
the
Folder
list,
use
the
v/V
to
highlight
and
press
ENTER
to
return
to
the
previous
menu
screen.
Audio
CD
and
Music
menu
options
1.
Press
v
/
V
to
select
a
track/file
or
folder
on
the
Audio
CD
or
Music
menu
then
press
ENTER.
2.
Use
v
/
V
to
select
an
option,
then
press
ENTER.
?
[Play]
Start
playback
the
selected
track
or
file.
?
[Open]
Opens
the
folder
and
a
list
of
files
in
the
folder
appears.
?
[Program
Add]
Adds
the
track(s)/file(s)
or
folder(s)
to
Program
List.
(page
37)
?
[Delete]
Deletes
the
file(s)
or
folder(s)
from
the
Memory
Card.
Audio
CD
and
MP3/WMA
file
Features
Pause
1.
Press
PAUSE/STEP
(X)
during
playback.
2.
To
return
to
playback,
press
N
(PLAY)
or
press
PAUSE/STEP
(X)
again.
Moving
to
another
Track
?
Press
SKIP
(>
or
.)
briefly
during
playback
to
go
to
the
next
track
or
to
return
to
the
beginning
of
the
current
track.
?
Press
SKIP
(.)
twice
in
quick
successions
to
go
back
to
the
previous
track.
?
On
an
Audio
CD,
to
go
directly
to
any
track,
enter
the
track
number
using
the
numbered
buttons
(0-9)during
playback.
Repeat
Press
REPEAT
to
select
a
desired
repeat
mode.
?
[TRACK]:
Repeats
the
current
track.
?
[ALL]
(CD):
Repeats
all
the
tracks
on
a
disc.
?
[FOLDER]
(MP3/WMA):
Repeats
all
the tracks
on
a
folder
of
a
disc.
?
[OFF](No
display):
Does
not
play
repeatedly.
Playback
36
Changing
the
Audio
Channel
Press
AUDIO
repeatedly
to
hear
a
different
audio
channel
(stereo,
left
or
right).
Random
1.
Press
RANDOM
during
playback
or
in
stop
mode.
Random
Playback
begins
immediately
and
[RANDOM]
appears
on
the
menu
screen.
2.
To
return
to
normal
playback,
press
RANDOM
repeatedly
until
[RANDOM]
disappears
from
the
menu
screen.
Tip:
By
pressing
SKIP
(.
or
>)
during
random
playback,
the
unit
selects
another
track
and
resumes
random
playback.
Repeat
A-B
1.
To
repeat
a
sequence
during
disc
playback.
Press
A-B
at
your
chosen
starting
point.
The
Repeat
icon
and
[A
-]
appear
on
the
menu
screen.
2.
Press
A-B
again
at
your
chosen
end
point.
The
Repeat
icon
and
[A-B]
appear
on
the
menu
screen,
and
the
sequence
begins
to
play
repeat-
edly.
3.
Press
A-B
again
to
cancel.
Search
1.
Press
BACKWARD
(m)
or
FORWARD
(M)
during
playback.
2.
Press
BACKWARD
(m)
or
FORWARD
(M)
to
select
the
required
speed
(3steps).
3.
To
exit
SEARCH
mode,
press
N
(PLAY).
Notes
on
MP3/WMA
Recordings
MP3/WMA
disc
compatibility
with
this
unit
is
limited
as
follows:
?
Sampling
frequency:
within
8
-
48
kHz
(MP3),
within
32
-
48
kHz
(WMA)
?
Bit
rate:
within
8
-
320
kbps
(MP3),
32
-
192
kbps
(WMA)
?
This
unit
cannot
read
an
MP3/WMA
file
that
has
a
file
extension
other
than
".mp3"
/
".wma".
?
CD-R
physical
format
should
be
"ISO
9660"
and
"JOLIET".
?
DVD±R/RW
physical
format
should
be
"ISO
9660
(UDF
Bridge
format)".
?
If
you
record
MP3
/
WMA
files
using
software
that
cannot
create
a
file
system
(eg.
Direct-
CD)
it
is
impossible
to
playback
MP3
/
WMA
files.
We
recommend
that
you
use
Easy-CD
Creator,
which
creates
an
ISO
9660
file
sys-
tem.
?
The
total
number
of
files
and
folders
on
the
disc
are
free
but the
total
number
of
files
and
folders
on
the
folder
should
be
less
than
1999.
This
unit
requires
discs
and
recordings
to
meet
cer-
tain
technical
standards
in
order
to
achieve
optimal
playback
quality.
Pre-recorded
DVDs
are
automati-
cally
set
to
these
standards.
There
are
many
differ-
ent
types
of
recordable
disc
formats
(including
CD-R
containing
MP3
or
WMA
files)
and
these
require
cer-
tain
pre-existing
conditions
(see
above)
to
ensure
compatible
playback.
Customers
should
note
that
permission
is
required
in
order
to
download
MP3
/
WMA
files
and
music
from
the
Internet.
Our
company
has
no
right
to
grant
such
permission.
Permission
should
always
be
sought
from
the
copyright
owner.
37
Program
Playback
with
Program
Playback
with
Audio
Audio
CD
and
MP3/WMA
CD
and
MP3/WMA
files
files
The
program
function
enables
you
to
store
your
favourite
tracks
from
any
disc
in
the
player
memory.
Program
can
contain
99
tracks
(Audio
CD)
or
256
tracks
(MP3/WMA).
1.
Use
v
/
V
to
select
a
track/file
or
folder
on
the
List
then
press
ENTER.
2.
Use
v
/
V
to
select
[Program
Add]
option
then
press
ENTER.
3.
Repeat
steps
1-2
to
place
additional
tracks
on
the
Program
list.
4.
Audio
CD
:
Use
B
to
move
to
the
Program
list.
The
programmed
track
you
selected
last
is
high-
lighted
on
the
program
list.
MP3/WMA
:
Go
to
next
step.
5.
Usev/Vtoselectthetrackorfileyouwantto
start
playing.
6.
Press
N
(PLAY)
to
start.
Playback
begins
in
the
order
in
which
you
pro-
grammed
the
tracks
and
[PRG]
indicator
appears
on
the
display
window.
Playback
stops
after
playing
the
last
programmed
track
on
the
program
list.
Tips:
?
Use
the
CLEAR
button
to
select
all
tracks/files
and
fold-
ers,
or
cancel
all
marked
tracks/files
and
folders.
?
Selecting
multiple
tracks/files
or
folders.
1.
Press
MARKER.
A
check
mark
appears
on
the
track/file
or
folder.
Press
MARKER
again
to
cancel
the
marked
track/file
or
folder.
2.
Repeat
step
1
to
mark
additional
track/file
(folders).
?
If
you
select
folder
for
Programmed
Playback,
all
tracks
in
the
folder
are
added
to
the
program
list.
?Y
ou
can
access
or
remove
the
Program
List
screen
by
pressing
LIST/DISC
MENU.
Program
List
menu
options
1.
Press
v
/
V
to
select
a
track/file
on
the
Program
List
then
press
ENTER.
The
menu
options
appear.
2.
Use
v
/
V
to
select
an
option
then
press
ENTER
to
confirm
your
selection.
?
[Play]
Playback
begins
in
the
order
in
which
you
programmed
the tracks
from
the selected
track.
?
[Move]
Moves
the
track(s)
to
change
the
pro-
gram
order.
?
[Delete]
Deletes
the
track(s)
from
the
Program
List
menu.
Repeat
Programmed
Tracks
Press
REPEAT
to
select
the
desired
Repeat
mode.
[TRACK]
Repeats
the
current
track.
[ALL]
Repeats
all
tracks
on
the
Program
List.
[OFF]
Cancels
Repeat
mode
(no
display).
Erasing
a
Track
from
the
Program
List
1.
Select
the
track
you
wish
to
erase
from
the
Program
List.
Use
MARKER
button
to
select
multiple
tracks.
2.
Press
ENTER.
The
menu
options
appears.
3.
Select
[Delete]
option
then
press
ENTER.
Changing
Track
Order
in
the
Program
List
1.
Select
the
track
you
wish
to
move
on
the
Program
List.
Use
MARKER
button
to
select
multiple
tracks.
2.
Press
ENTER.
The
menu
options
appears
3.
Select
[Move]
option
then
press
ENTER.
4.
Use
v
/
V
to
move
the
yellow
bar
to
the
desired
location,
then
press
ENTER.
Playback
38
V
V
iewing
a
JPEG
files
iewing
a
JPEG
files
This
unit
can
play
JPEG
files
on
CD-R/RW,
DVD+R/RW,
DVD-R/RW,
DVD-RAM
discs
or
Memory
Card.
Before
playing
JPEG
recordings,
read
"About
JPEG
files"
on
page
39.
1.
UsevVbBtoselectafileorfolderandpress
ENTER.
2.
Use
v
/
V
to
select
option
and
press
ENTER.
Example:
When
you
select
a
file.
3.
Use
v
/
V
to
select
[Full
Screen]
then
press
ENTER.
The
selected
is
displayed
in
full
screen.
4.
To
stop
viewing
at
any
time,
press
STOP.
Notes:
?
If
the
icon
displays
in
the
menu,
it
means
you
cannot
see
those
JPEG
files.
?Y
ou
can
view
TV
channel
or
video
input
source
by
pressing
RETURN
(O).
If
you
want
to
return
to
the
menu,
press
LIST/DISC
MENU.
?
If
you
are
in
a
file
list
and
want
to
return
to
the
Folder
list,
use
the
v/V
to
highlight
and
press
ENTER
to
return
to
the
previous
menu
screen.
?
On
CDs,
DVDs
or
Memory
Card
with
mixed
content
(Audio
tracks,
MP3/WMA
files,
DivX
files
or
JPEG
files),
you
can
select
among
the
Music
menu,
Movie
menu
and
menu
by
pressing
TITLE
repeatedly.
menu
options
1.
Use
v
V
b
B
to
select
a
file
then
press
ENTER.
The
menu
options
appear.
2.
Use
v
/
V
to
select
an
option
then
press
ENTER
to
confirm
your
selection.
?
[Open]
Opens
the
folder
and
a
list
of
files
in
the
folder
appears.
?
[Full
Screen]
Shows
the
selected
file
as
full
screen.
?
[Slide
Show]
Displays
Slide
Show
menu.
?
[Delete]
Deletes
the selected
file(s)
or
folder(s)
from
the
Memory
Card.
?
[Copy] Copies
the
file(s)
or
folder
to
Memory
Card.
Tip:
You
can
create
new
folder
in
the
Memory
Card.
Select
[New
Album]
option
then
press
ENTER.
[NONAME##]
folder
is
created.
Still
Use
PAUSE/STEP
(X)
while
showing
a
to
pause
mode.
Skip
Images
While
viewing
a
picture,
press
SKIP
(>
or
.)
once
to
advance
to
the
next
file
or
return
to
the
previous
file.
Rotate
Images
Use
v
/
V
while
viewing
a
to
flip
the
clockwise
or
counterclockwise.
Press
ENTER
to
appear
or
disappear
this
menu.
39
View
Slide
Shows
1.
Select
[Slide
Show]
option
on
the
menu.
2.
Press
ENTER.
3.Useb/B/v/Vtosettheoptions.
[Object]
option:
?
[Selected]
Views
slide
show
only
selected
files.
?
[All]
Views
slide
show
all
files.
[Speed]
option:
Sets
the
Slide
Show
speed
to
[Normal],
[Slow],
or
[Fast].
4.
Select
the
[Start]
option
then
press
ENTER
to
start
the
Slide
Show.
5.
Press
STOP
(x)
to
stop
the
Slide
Show
and
returns
to
the
menu.
Tips:
?
Use
the
CLEAR
button
to
select
all
files,
or
cancel
all
marked
files.
?
Selecting
multiple
files
1.
Press
MARKER.
A
check
mark
appears
on
the
file.
Press
MARKER
again
to
cancel
the
marked
file.
2.
Repeat
step
1
to
mark
additional
file.
About
JPEG
files
JPEG
disc
compatibility
with
this
recorder
is
limited
as
follows:
?
Depending
upon
the
size
and
number
of
JPEG
files,
it
could
take
a
long
time
for
the
recorder
to
read
the
files.
If
you
don't
see
an
on-screen
dis-
play
after
several
minutes,
some
of
the
files
may
be
too
large
---
reduce
the
resolution
of
the
JPEG
files
to
less
than
4M
pixels.
?
The
total
number
of
files
and
folders
on
the
disc
are
free
but the
total
number
of
files
and
folders
on
the
folder
should
be
less
than
1999.
?
Some
discs
may
be
incompatible
due
to
a
differ-
ent
recording
format
or
the
condition
of
disc.
?
Ensure
that
all
the
selected
files
have
the
".jpg"
extensions
when
copying
into
the
CD
layout.
?
If
the
files
have
".jpe"
or
".jpeg"
extensions,
please
rename
them
as
".jpg"
file.
?
File
names
without
".jpg"
extension
will
not
be
able
to
be
read
by
this
recorder.
Even
though
the
files
are
shown
as
JPEG
files
in
Windows
Explorer.
?
Progressive
and
lossless
compression
JPEG
files
are
not
supported.
Playback
40
About
DVD
recording
About
DVD
recording
Notes:
?
This
Recorder
cannot
record
CD-R
or
CD-RW
discs.
?
Fingerprints
and
small
scratches
on
a
disc
can
affect
playback
and/or
recording
performance.
Please
take
proper
care
of
your
discs.
?
The
company
does
not
hold
any
responsibility
to
compensate
the
contents
which
should
have
been
recorded,
and
any
losses
or
damages
(e.g.
losses
of
business
profit,
or
business
intermis-
sion)
that
may
arise
from
malfunction
of
this
recorder
(not
recording/editing
as
intended).
Disc
types
and
recording
formats,
modes,
and
settings
This
recorder
can
play
many
different
kinds
of
DVD
discs:
pre-recorded
DVD-Video
discs,
DVD-RW,
DVD-R,
DVD+RW,
DVD+R(DL)
and
DVD-RAM
discs.
The
disc
format
for
DVD-R,
DVD+R(DL),
DVD+RW
discs
is
always
"Video
format"---the
same
as
pre-
recorded
DVD-Video
discs.
This
means
that
once
finalized,
you
can
play
a
DVD-R,
DVD+R
(DL),
or
DVD+RW
in
a
regular
DVD
player.
The
DVD-RAM
disc
format
is
Video
Recording
(VR)
format.
The
DVD-RW
disc
format
is
Video
Recording
(VR)
format
or
Video
format.
You
can
change
Recording
format,
if
required.
(Reinitializing
the
disc
will
erase
the
contents
of
the
disc.)
The
recording
mode
is
closely
related
to
the
disc
for-
mat.
If
the
disc
format
is
Video
Recording
format,
then
the
recording
mode
is
VR
mode;
if
the
disc
for-
mat
is
Video
format,
then
the
recording
mode
is
Video
mode
(except
for
DVD-Video,
which
is
not
recordable,
and
so
does
not
have
a
recording
mode).
These
can
be
changed
as
required
for
each
record-
ing
and
determine
the
quality
and
how
much
space
the
recording
will
take
up
on
the
disc.
Notes
for
recording
Notes
for
recording
?
The
recording
times
shown
are
not
exact
because
the
recorder
uses
variable
bit-rate
video
compression.
This
means
that
the
exact
record-
ing
time
will
depend
on
the
material
being
record-
ed.
?
When
recording
a
TV
broadcast,
if
the
reception
is
poor
or
the
contains
interference,
the
recording
times
may
be
shorter.
?
If
you
record
still
pictures
or
audio
only,
the
recording
time
may
be
longer.
?
The
displayed
times
for
recording
and
time
remaining
may
not
always
add
up
to
exactly
the
length
of
the
disc.
?
The
recording
time
available
may
decrease
if
you
heavily
edit
a
disc.
?
If
using
a
DVD-RW
disc,
make
sure
you
change
the
recording
format
(Video
mode
or
VR
mode)
before
you
record
anything
on
the
disc.
See
page
24
(Initialize)
for
how
to
do
this.
?
When
using
a
DVD-R
or
DVD+R
disc,
you
can
keep
recording
until
the
disc
is
full,
or
until
you
finalize
the
disc.
Before
you
start
a
recording
session,
check
the
amount
of
recording
time
left
on
the
disc.
?
When
using
a
DVD-RW
disc
in
Video
mode,
recording
time
available
will
only
increase
if
you
erase
the
last
title
recorded
on
the
disc.
?
The
Delete
Title
option
in
the
Title
List
(Original)
menu
only
hides
the
title,
it
does
not
actually
erase
the
title
from
the
disc
and
increase
the
recording
time
available
(except
for
the
last
recorded
title
on
a
DVD-RW
disc
in
Video
mode).
?
Overwrite
recording
is
available
using
DVD+RW
discs.
?
When
using
a
DVD+R/RW,
the
recorder
will
exe-
cute
the
Menu-making
operation
to
update
the
new
title
and
editing
when
removing
the
disc
from
the
recorder.
Recording
41
Recording
Basic
Recording
from
a
TV
Basic
Recording
from
a
TV
Follow
the
instructions
below
to
record
a
TV
program.
Recording
starts
immediately
and
continues
until
the
disc
or
tape
is
full
or
you
stop
the
recording.
1.
Switch
on
the
Recorder,
select
the
device
(VCR
or
DVD)
for
Recording
and
load
a
recordable
disc
or
tape.
Also
make
sure
that
the
TV
input
is
set
to
this
recorder.
2.
Set
a
recording
mode
as
necessary
by
pressing
REC
MODE
repeatedly.
DVD:
XP,
SP,
LP,
EP.
VCR:
SP,
SLP.
3.
Select
the
TV
channel
to
record.
4.
Use
AUDIO
to
select
the
audio
channel
to
record.
The
table
below
shows
what
will
be
recorded
on
the
different
settings
for
different
types
of
broad-
cast.
The
last
column
(Monitor
Audio)
shows
what
you'll
hear
as
it
is
recording.
If
you
set
the
audio
channel
to
SAP,
but
there
is
no
SAP
channel
being
broadcast,
the
main
audio
(mono
or
stereo)
will
be
recorded.
5.
Press
z
REC
once
to
start
recording.
The
REC
indicator
lights
in
the
display
window.
6.
Press
STOP
(x)
to
stop
recording.
Notes:
?T
he
maximum
numbers
of
DVD
titles
are
as
show
below;
-
DVD-R/RW,
DVD-RAM
:
99
-
DVD+R(DL)/RW
:
49
?
If
the
Recorder
is
powered
off
during
DVD
recording,
the
recording
will
not
be
saved.
Instant
T
Instant
Timer
Recording
imer
Recording
Instant
Timer
Recording
allows
you
to
make
a
recording
easily
of
a
preset
length
without
using
the
program
timer.
1.
Follow
steps
1-4
as
shown
left
(Basic
Recording
from
a
TV).
2.
Press
z
REC
repeatedly
to
select
the
recording
time
length.
Recording
starts
after
the
first
press.
DVD:
Each
subsequent
press
increases
the
recording
time
by
10
minutes.
VCR:
Each
subsequent
press
increases
the
recording
time
by
30
minutes
(maximum
540
minutes).
Please
confirm
the
VHS
tape
has
enough
remaining
time
to
be
recorded
before
recording.
Instant
Timer
Record
Menu
Checking
the
Recording
Time
Press
z
REC
or
DISPLAY
once
to
check
the
record-
ing
time.
The
recalled
setting
will
automatically
return
to
the
TV
screen
for
a
moment.
Also,
remaining
time
of
recording
is
shown
in
the
dis-
play
window.
To
Extend
the
Recording
Time
The
recording
time
can
be
extended
anytime
by
pressing
z
REC.
Each
subsequent
press
increases
the
recording
time
by
10
minutes
(DVD)
or
30
minutes
(VCR).
To
Pause
the
Recording
1.
Press
PAUSE/STEP
(X)
to
pause
the
recording.
2.
When
you
want
to
continue
recording,
press
PAUSE/STEP
(X)
or
z
REC.
Notes:
?
If
you
press
PAUSE/STEP
(X)
during
the
Instant
Timer
Recording,
it
will
be
canceled.
?
The
Recorder
will
automatically
power
off
when
the
Instant
Timer
Recording
ends.
?
If
the
unit
is
DVD
mode
when
the
VCR
Instant
timer
recording
ends,
the
unit
will
not
automatically
power
off.
TV
Broadcast
Selected
Broadcast
Audio
Monitor
Audio
LChR
Ch
Audio
MONO MONO MONO
MONO
MONO
STEREO STEREO
L
R
STEREO
Left
L L
Left
Right
RR
Right
MONO MONO
MONO
MONO
MONO+SAP
MONO MONO MONO MONO
SAP SAP
SAP
SAP
STEREO STEREO
L
R
STEREO
+SAP
SAP SAP
SAP
SAP
MONO MONO
MONO
MONO
42
To
record
one
TV
program
while
watching
another
1.
Press
TV/VCR
to
select
the
TV
mode
during
recording.
The
TV
indicator
appears.
2.
Using
the
TV,
select
the
channel
to
be
viewed.
Tip
(VCR
mode
only)
Always
use
PAUSE/STEP
(X)
for
best
results
when
making
changes
during
recording
.
For
example:
To
change
channels
during
recording,
first
press
PAUSE/STEP
(X)
to
put
the
unit
in
pause
mode.
Then
select
the
desired
channel
on
the
Recorder,
and
press
PAUSE/STEP
(X)
again
to
resume
recording.
T
T
imer
Recording
imer
Recording
The
Timer
Recording
function
allows
you
to
record
up
to
8
programs
within
a
period
of
one
month.
1.
Press
TIMER
REC.
The
Timer
Record
menu
will
appear.
?
[Media]
--
Choose
a
media
(DVD
or
VCR).
?
[Ch.]
--
Choose
a
channel
(2-69
or
1-125
for
antenna
or
cable
channels
respectively,
excluding
skip
channels),
or
one
of
the
exter-
nal
inputs
from
which
to
record
(AV1
or
AV2).
?
[Date]
--
Choose
a
date
up
to
1
month
in
advance,
or
select
a
daily
or
weekly
program.
?
[Start
Time]
--
Set
the
recording
start
time.
?
[End
Time]
--
Set
the
recording
end
time.
?
[Mode]
--
Choose
a
record
mode.
DVD:
EP,
LP,
SP,
XP,
or
AT
(Auto)
VCR:
SP,
SLP,
or
AT
(Auto)
AT(Auto)
mode
determines
how
much
time
is
avail-
able
on
the
disc
or
tape
and
switches
record
mode,
if
necessary,
to
complete
recording
the
program.
2.
Enter
the
necessary
information
for
your
timer
recording(s).
?
b
/
B
(left/right)
--
Move
the
cursor
left/right
?
v
/
V
(up/down)
--
Change
the
setting
at
the
current
cursor
position
?
Press
RETURN
(O)
to
exit
the
Timer
Record
menu.
?
Press
TIMER
REC
to
display
Timer
Record
List.
3.
Press
ENTER
to
save
the
program.
The
Timer
Record
List
will
appear.
4.
Press
RETURN
(O)
to
exit
the
Timer
Record
List.
Notes:
?
The
Timer
indicator
lights
on
the
front
panel
dis-
play.
?
If
the
Disc
and
Tape
indicator
are
blinking,
either
no
disc
or
tape
is
loaded,
or
the
loaded
disc
is
not
recordable.
?
The
Recorder
will
record
the
audio
according
to
the
current
TV
tuner
setting
(Stereo,
Mono
or
SAP).
Use
the
AUDIO
button
to
set
the
audio
before
switching
the
Recorder
to
Standby
mode.
?
The
Recorder
will
automatically
power
off
when
the
Timer
Recording
ends.
?
If
the
unit
is
DVD
mode
when
the
VCR
timer
recording
ends,
the
unit
will
not
automatically
power
off.
?
There
is
a
short
delay
when
a
timer
recording
fin-
ishes
to
confirm
the
recorded
program.
If
two
timer
recordings
are
set
to
record
sequentially
(one
right
after
the
other),
the
very
beginning
of
the
later
program
may
not
be
recorded.
?Y
ou
must
press
STOP
(x)
to
stop
the
Timer
Recording.
Checking
Timer
Recording
Details
Programming
can
be
checked
whenever
the
Recorder
is
turned
on.
Press
TIMER
REC
twice.
?
Use
v
/
V
to
select
a
timer
recording.
?
Press
ENTER
to
edit
the
selected
program.
Timer
Record
menu
appears.
Canceling
a
Timer
Recording
You
can
clear
a
timer
setting
anytime
before
the
recording
actually
starts.
?
Use
v
/
V
to
select
a
program
you
want
to
erase
on
the
Timer
Recorder
List,
then
press
CLEAR
and
select
[Yes]
than
press
ENTER.
43
Recording
Timer
Recording
Troubleshooting
Even
though
the
timer
is
set,
the
recorder
will
not
record
when:
?
There
is
no
disc
(or
tape)
loaded.
?A
non-recordable
disc
(or
tape)
is
loaded.
?
Disc
Protect
is
set
to
ON
in
the
Disc
menu
(see
page
26).
?
There
are
already
99
titles
(DVD-RW,
DVD-R,
DVD-RAM),
49
titles
(DVD+RW,
DVD+R(DL))
recorded
on
the
disc.
You
cannot
enter
a
timer
program
when:
?A
recording
is
already
underway.
?
The
time
you're
trying
to
set
has
already
passed.
?
There
are
already
8
timer
programs
set.
If
two
or
more
timer
programs
overlap:
?
The
earlier
program
takes
priority.
?
When
the
earlier
program
finishes,
the
later
program
starts.
?
If
two
programs
are
set
to
start
at
exactly
the
same
time,
the
program
entered
first
takes
pri-
ority.
If
the
disc
is
damaged,
the
recording
may
not
complete
successfully.
In
this
case
even
though
the
Check
field
shows
[Rec.
OK],
it
may
not
be.
Playing
while
you
are
Playing
while
you
are
recording
recording
You
can
start
play
from
the
beginning
of
the
title
while
continuing
to
record
it.
While
recording
(in
DVD
mode)
1.
Press
N
(PLAY).
Start
play
of
the
title
you
are
recording.
2.
Press
STOP
(x)
to
return
to
the
current
recording
screen.
or
1.
Press
TIMESHIFT.
The
PIP(Picture-In-Picture)
window
appears
on
the
screen
as
shown
below.
What
is
currently
being
recorded
appears
as
a
PIP
and
you
will
hear
the
playback
audio.
2.
Press
STOP
(x)
to
return
to
the
current
recording
screen.
Notes:
?
Play
cannot
be
started
until
at
least
30
seconds
after
recording
starts.
?
This
function
does
not
work
in
VCR
Recording
mode.
RAM
44
Dubbing
from
DVD
to
VCR
Dubbing
from
DVD
to
VCR
You
can
copy
the
contents
of
a
DVD
to
a
VHS
tape
using
the
DUBBING
(or
DUB)
button.
1.
Insert
a
blank
VHS
videotape
into
the
VCR
deck.
2.
Insert
the
disc
you
wish
to
copy
in
the
DVD
deck
and
close the
disc
tray.
3.
Find
the
place
on
the
DVD
(or
Disc)
from
which
you
want
to
start
dubbing
using
the
PLAY,
FF,
REW
and
PAUSE
functions.
For
best
results,
pause
playback
at
the
point
from
which
you
want
to
record.
4.
Press
the
DUBBING
button
on
the
Remote
Control
or
DUB on
the
front
panel.
The
Dubbing
menu
appears.
5.
Usev/V/b/BtoselectthedesiredRecord
Mode:
SP
or
SLP
(3
times
SP).
6.
Select
[Dubbing]
then
press
ENTER
or
DUBBING
to
start
copying.
7.
To
stop
dubbing
at
any
other
time,
press
STOP
(x).
You
must
stop
the
dubbing
process
manually
when
the
DVD
movie
ends,
or
the
unit
may
replay
and
record
over
and
over
again.
Note:
If
the
DVD
(or
Discs)
you
are
attempting
to
copy
is
copy
protected,
you
will
not
be
able
to
copy
the
disc.
It
is
not
permitted
to
copy
Macrovision
encoded
DVDs
(or
Discs).
[Copy-protected.
Cannot
record.]
is
displayed
on
the
TV
screen.
Tip:
If
you
press
PAUSE
during
Dubbing
mode,
both
the
DVD
and
VCR
decks
go
into
Pause
mode
and
the
[DUB]
indicator
blinks
on
the
front
panel
display.
While
in
Pause
mode,
you
can
adjust
the
DVD
play-
back
position
using
PLAY,
REW,
FF,
PAUSE/STEP,
etc.
The
VCR
deck
will
remain
in
Pause
mode.
To
resume
Dubbing,
press
the
DUBBING
button
twice.
Dubbing
from
VCR
to
DVD
Dubbing
from
VCR
to
DVD
You
can
copy
the
contents
of
a
VHS
tape
to
a
DVD
using
the
DUBBING
(DUB)
button.
This
allows
you
to
archive
your
old
VHS
tapes
to
DVD.
1.
Insert
a
blank
DVD
disc
in
the
DVD
deck
and
close the
disc
tray.
2.
Insert
the
VHS
video
tape
you
wish
to
copy
into
the
VCR
deck.
3.
Find
the
place
on
the
VHS
tape
from
which
you
want
to
start
dubbing
using
the
PLAY,
FF,
REW
and
PAUSE
functions.
For
best
results,
pause
playback
at
the
point
from
which
you
want
to
record.
4.
Press
the
DUBBING
button
on
the
Remote
Control
or
DUB on
the
front
panel.
The
Dubbing
menu
appears.
5.
Usev/V/b/BtoselectthedesiredRecord
Mode:
EP,
LP,
SP
or
XP.
6.
Select
[Dubbing]
then
press
ENTER
or
DUBBING
to
start
copying.
7.
To
stop
dubbing
at
any
other
time,
press
STOP
(x).
Dubbing
will
stop
automatically
when
the
VHS
tape
ends.
Note:
If
the
VHS
video
tape
you
are
attempting
to
copy
is
copy
protected,
you
will
not
be
able
to
copy
the
tape.
It
is
not
permitted
to
copy
Macrovision
encoded
tapes.
Tip:
If
you
press
PAUSE
during
Dubbing
mode,
both
the
DVD
and
VCR
decks
go
into
Pause
mode
and
the
[DUB]
indicator
blinks
on
the
front
panel
display.
While
in
Pause
mode,
you
can
adjust
the
VCR
play-
back
position
using
PLAY,
REW,
FF,
PAUSE/STEP,
etc.
The
DVD
deck
will
remain
in
Pause
mode.
To
resume
Dubbing,
press
the
DUBBING
button
twice.
45
Recording
from
External
Recording
from
External
Components
Components
You
can
record
from
an
external
component,
such
as
a
camcorder
or
VCR,
connected
to
any
of
the
Recorder's
external
inputs.
1.
Make
sure
that
the
component
you
want
to
record
from
is
connected
properly
to
the
Recorder.
See
page
18.
2.
Press
INPUT
repeatedly
to
select
the
external
input
to
record
from.
?A
V1:
Audio/Video
Input
mounted
on
back
panel.
?A
V2:
Audio/Video
Input
mounted
on
front
panel.
?D
V:
DV
Input
mounted
on
front
panel.
3.
Load
a
recordable
disc
or
tape.
4.
Set
a
recording
mode
as
necessary
by
pressing
REC
MODE
repeatedly.
DVD:
XP,
SP,
LP
or
EP.
VCR:
SP
or
SLP
5.
Press
z
REC
once
to
start
recording.
The
REC
indicator
lights
in
the
display
window.
6.
Press
STOP
(x)
to
stop
recording.
Notes:
?
Check
that
the
Audio
In
settings
DV
Record
Audio
are
as
you
want
them.
See
page
24.
?
If
your
source
is
copy-protected
using
CopyGuard,
you
will
not
be
able
to
record
it
using
this
recorder.
See
Copyright
on
page
9
for
more
details.
?
Recording
continues
until
you
press
STOP
(x)
or
the
disc
is
full.
?
To
record
for
a
fixed
length
of
time,
see
[Instant
Timer
Recording]
on
page
41.
Additional
Information
Additional
Information
Simultaneous
Play
and
Record
You
can
play
or
record
a
DVD
during
the
VCR
play-
back,
press
DVD
to
change
DVD
mode
and
perform
the
DVD
playback
or
recording.
Notes:
?
You
cannot
play
or
record
both
DVD
and
VCR
at
the
same
time.
?
You
can
not
change
VCR
mode
during
the
DVD
recording
mode.
?
If
you
wish
VCR
playback
or
record
during
the
DVD
playback,
press
VCR
to
change
VCR
mode
and
perform
the
VCR
playback
or
recording.
46
Recording
from
DV
Input
Recording
from
DV
Input
Before
DV
dubbing
You
can
connect
a
DV-equipped
camcorder
to
this
recorder
using
a
single
DV
cable
for
input
and
output
of
audio,
video,
data
and
control
signals.
This
recorder
is
only
compatible
with
DV-format
(DVC-SD,
DV25)
camcorders.
Digital
satellite
tuners
and
Digital
VHS
video
recorders
are
not
compatible.
You
cannot
connect
more
than
one
DV
camcorder
at
a
time
to
this
recorder.
You
cannot
control
this
recorder
from
external
equipment
connected
via
the
DV
IN
jack
(including
two
recorders).
It
may
not
always
be
possible
to
control
the
con-
nected
camcorder
via
the
DV
IN
jack.
Digital
camcorders
can
usually
record
audio
as
stereo
16-bit/48kHz,
or
twin
stereo
tracks
of
12-
bit/32kHz.
This
recorder
can
only
record
one
stereo
audio
track.
Set
[DV
Record
Audio]
option
to
Audio
1
or
Audio
2
as
required
(see
page
24).
Audio
input
to
the
DV
IN
jack
should
be
32
or
48kHz
(not
44.1kHz).
disturbance
on
the
recording
may
occur
if
the
source
component
pauses
playback
or
plays
an
unrecorded
section
of
tape,
or
if
the
power
fails
in
the
source
component,
or
the
DV
cable
becomes
disconnected.
Recording
from
a
Digital
Camcorder
You
can
record
from
a
digital
camcorder
connected
to
the
DV
IN
jack
on
the
front
panel
of
this
recorder.
Using
the
recorder's
remote,
you
can
control
both
the
camcorder
and
this
recorder.
Before
recording,
make
sure
that
the
audio
input
for
the
DV
IN
jack
is
set
up
(see
page
24).
Tips:
?
The
source
signal
must
be
DVC-SD
format.
?
Some
camcorders
cannot
be
controlled
using
this
recorder's
remote.
?
If
you
connect
a
second
recorder
using
a
DV
cable,
you
cannot
control
the
second
DVD
from
this
one.
?
You
cannot
control
this unit
remotely
from
a
com-
ponent
connected
to
the
DV
IN
jack.
?
You
cannot
record
date
and
time
information
from
a
DV
cassette.
1.
Make
sure
your
digital
camcorder
is
connected
to
the
front
panel
DV
IN
jack.
See
page
18.
2.
Check
that
the
DV
audio
input
is
as
you
require.
You
can
choose
between
Audio
1
(original
audio)
and
Audio
2
(overdubbed
audio).
DV
Input
is
set
from
the
DV
Record
Audio
in
sub-menu
of
the
Setup
menu.
See
[DV
Record
Audio]
on
page
24
for
more
information.
3.
Press
INPUT
repeatedly
to
select
the
DV
input.
DV
appears
in
the
display
window
and
on
the
TV
screen.
4.
Find
the
place
on
the
camcorder
tape
that
you
want
to
the
recording
to
start
from.
For
best
results,
pause
playback
at
the
point
from
which
you
want
to
record.
Depending
on
your
camcorder,
you
can use
this
recorder's
remote
to
control
the
camcorder
using
the
STOP,
PLAY,
BACKWARD,
FOR-
WARD
and
PAUSE
functions.
5.
Press
z
REC
once
to
start
recording.
Recording
is
automatically
stopped
if
the
recorder detects
no
signal.
Yo
u
can
pause
or
stop
the
recording
by
press-
ing
PAUSE/STEP
(X)
or
STOP
(x).
Yo
u
cannot
control
the
camcorder
from
this
Remote
Control
during
recording.
In
Video
mode,
the
final
frame
of
the
recording
may
remain
displayed
on
screen
for
a
while
after
recording
stops.
Troubleshooting
If
you
cannot
get
a
and/or
audio
through
the
DV
IN
jack,
check
the
bullet
points:
Make
sure
the
DV
cable
is
properly
connected.
Try
switching
off
the
connected
equipment
then
switch
back
on.
Try
switching
the
audio
input.
Note:
Depending
on
the
connected
camcorder,
you
may
not
be
able
to
control
it
using
the
Remote
Control
supplied
with
this
recorder.
47
Editting
T
Title
List
and
Chapter
List
itle
List
and
Chapter
List
Menu
Overview
Menu
Overview
Using
the
Title
List
menu
you
can
edit
video
content.
The
editing
features
available
in
the
Title
List
menu
depend
on
whether
you
are
editing
video
on
DVD,
and
whether
you're
editing
Original
content,
or
a
Playlist.
There
are
two
ways
to
edit
VR
mode
DVD-RW
discs.
You
can
directly
edit
the
Original
content
of
the
disc,
or
you
can
create
and
edit
a
Playlist.
The
Playlist
doesn't
actually
change
any
of
the
content
on
the
disc,
but
just
controls
how
the
content
is
played
back.
1.
Press
LIST/DISC
MENU
to
display
the
Title
List
menu.
Playback
should
be
stopped
when
you
do
this.
When
selecting
titles,
use
the
v
/
V
buttons
to
display
the
previous/next
page
if
there
are
more
than
six
titles.
If
you
are
editing
a
VR
mode
disc,
press
LIST/DISC
MENU
to
switch
between
Original
and
Playlist
menu.
On
the
left
side
of
the
screen
are
the
menu
options.
The
main
part
of
the
screen
shows
thumbnails
of
the
titles
(or
chapter)
on
the
DVD.
You
can
change
these thumbnails
using
the
THUMBNAIL
button.
(see
[Changing
Title
Thumbnails]
on
page
48.)
Press
DISPLAY
to
display
the
information
of
selected
title
on
the
Title
List
menu.
After
selecting
a
title
or
chapter
on
the
Title
List
of
Chapter
List
menu,
then
press
ENTER.
The
menu
options
on
the
left
side
of
the
menu.
Use
v
/
V
to
select
a
option
then
press
ENTER
to
confirm
your
selection.
2.
To
exit
the
Title
List
menu,
press
RETURN
(O)
repeatedly.
1.
Menu
options:
To
display
menu
option,
select
a
title
or
chapter
then
press
ENTER.
The
options
displayed
differ
depending
on
the
disc
type.
?
[Play]
Start
playback
of
the
selected
title
or
chapter.
The
hidden
titles
and
chapters
on
the
DVD+R/RW
cannot
be
play
back.
?
[Search]
-
[Chapter]
;
Displays
Chapter
List
of
the
Title.
-
[Time]
;
Search
time
for
you
want
start
point
of
the
title
.
?
[Delete]
Deletes
the
title
or
chapter.
(page
50)
?
[Move]
Moves
chapter
position
on
[Chapter
List
-
Playlist]
menu
(page
53).
?
[Protect]
Protects
accidental
recording,
editing
or
deleting
of
the
title.(page
53)
?
[Edit]
Edits
or
Deletes
a
part
of
the
title.
-
[Title
Name]
Edits
the
title
name.
(page
51).
-
[Delete
Part]
Deletes
a
part
of
the
Title
(page
50).
-
[Divide]
Divides
a
title
into
two
(page
52).
-
[Hide
(Show)]
Hides
(or
Shows)
the selected
title
or
chapter.
(page
53)
?
[Playlist
Add]
Adds
the
title
or
chapter
to
the
Playlist.
(page
49)
?
[Dubbing]
Dubs
the
title
to
VCR.
?[T
itle]
Displays
Title
List
of
the
chapter.
?
[Combine]
Combines
two
titles
or
chapters
into
one
(page
52).
?
[Full
Play]
Starts
playback
of
the selected
title
includ-
ing
the
hidden
chapters.
2.
Indicates
the
record
mode,
free
space,
and
elapsed
time
progress
bar.
3.
Current
media.
4.
Currently
selected
title.
5.
Thumbnail.
6.
Shows
the
selected
title
number
and
total
number
of
titles.
7.
Shows
the
title
name,
recorded
date,
and
record-
ing
length.
123
45
67
Editing
48
VR
Mode:
Original
and
VR
Mode:
Original
and
Playlist
Editing
Playlist
Editing
Titles,
Chapters
and
Parts
Titles
in
the
disc's
original
content
contain
one
or
more
chapters.
When
you
insert
a
disc's
title
into
the
Playlist,
all
the
chapters
within
that
title
also
appear.
In
other
words,
chapters
in
the
Playlist
behave
exact-
ly
as
chapters
on
a
DVD-Video
disc
do.
Parts
are
sections
of
Original
or
Playlist
titles.
From
the
Original
and
Playlist
menu
you
can
add
or
delete
parts.
Adding
a
chapter
or
title
to
the
Playlist
creates
a
new
title
made
up
of
a
section
(ie.,
chapter)
of
an
Original
title.
Deleting
a
part
removes
part
of
a
title
from
the
Original
or
Playlist
menu.
Caution
When
editing
using
the
Delete,
Add
and
Move
func-
tions,
the
start
and
end
frames
may
not
be
exactly
as
set
in
the
start
and
end
point
display.
During
Playlist
playback,
you
may
notice
a
momen-
tary
pause
between
edits.
This
is
not
a
malfunction.
Is
editing
a
DVD
like
editing
a
video
tape?
No.
When
you
edit
a
video
tape
you
need
one
video
deck
to
play
the
original
tape
and
another
to
record
the
edits.
With
DVD,
you
edit
by
making
a
'Playlist'
of
what
to
play
and
when
to
play
it.
On
playback,
the
Recorder
plays
the
disc
according
to
the
Playlist.
About
word
'Original'
and
'Playlist'
Throughout
this
manual,
you
will
often
see
the
words
Original
and
Playlist
to
refer
to
the
actual
content
and
the
edited
version.
Original:
content
refers
to
what's
actually
recorded
on
the
disc.
Playlist:
content
refers
to
the
edited
version
of
the
disc
---
how
the
Original
content
is
to
be
played.
Adding
Chapter
Markers
Adding
Chapter
Markers
You
can
create
chapters
within
a
title
by
inserting
chapter
marks
at
the
desired
points.
Note:
Chapter
markers
are
inserted
at
regular
intervals
automatically.
You
can
change
this
interval
from
the
Initial
Setup
menu
(see
[Auto
Chapter]
on
page
24).
During
recording
or
playing
back,
at
the
point
you
want
to
start
a
new
chapter,
press
CHP
ADD.
A
chapter
marker
icon
appears
on
the
TV
screen.
Changing
T
Changing
Title
Thumbnails
itle
Thumbnails
Each
title
displayed
in
the
Title
List
menu
is
repre-
sented
by
a
thumbnail
taken
from
the
start
of
that
title
or
chapter.
If
you
prefer,
select
a
different
still
from
within
a
title.
Press
THUMBNAIL
to
make
the
currently
displayed
the
one
that
appears
in
the
Title
List
menu.
The
still
that
you
choose
appears
in
both
the
Original
or
Playlist
menu.
Tip:
You
can
also
change
the
thumbnail
of
the
title
on
the
Chapter
List
menu.
Select
a
chapter
on
the
Chapter
List
menu
then
press
THUMBNAIL.
The
thumbnail
of
the
title
that
includes
the
chapter
is
changed.
RAM
+R
+RW
-RWVR
RAM
+R
+RW
-RWVR
RAM
-RWVR
49
Editting
Making
a
New
Playlist
Making
a
New
Playlist
Use
this
function
to
add
an
Original
title
or
chapter
to
the
Playlist.
When
you
do
this,
the
whole
title
is
put
into
the
Playlist
(you
can
delete
bits
you
don't
need
later
-
see
[Deleting
an
Original
or
Playlist
title/chap-
ter]
on
page
50).
The
title
appears
in
the
Playlist
complete
with
the
chapter
markers
that
appear
in
the
Original.
However,
if
you
add
more
chapter
markers
to
the
Original
later,
these
are
not
automatically
copied
over
into
the
Playlist
title.
1.
Choose
a
title
or
chapter
on
the
[Title
List-Original]
menu
or
[Chapter
List-Original]
menu
to
put
into
the
Playlist,
then
press
ENTER.
The
menu
options
appears
on
the
left
side
of
the
menu.
2.
Use
v
/
V
to
select
[Playlist
Add]
option
then
press
ENTER.
3.
Select
[New
Playlist]
then
press
ENTER.
The
new
title
appears
in
the
updated
Playlist.
All
chapters
of
the
title
are
added
to
the
Playlist.
Adding
Adding
Additional
T
Additional
Title
/
itle
/
Chapters
to
the
Playlist
Chapters
to
the
Playlist
You
can
add
an
Original
title
or
chapter
to
add
to
a
Playlist
title
even
if it
is
already
registered.
1.
Choose
a
title
or
chapter
on
the
[Title
List-Original]
menu
or
[Chapter
List-Original]
menu
to
put
into
the
Playlist,
then
press
ENTER.
The
menu
options
appears
on
the
left
side
of
the
screen.
2.
Use
v
/
V
to
select
[Playlist
Add]
from
menu
options
then
press
ENTER.
3.
Choose
a
Title
List-Playlist
that
is
already
regis-
tered
to
insert
a
title
or
chapter,
then
press
ENTER.
4.
Repeat
steps
1-3
to
add
additional
title
or
chapter
on
the
Playlist.
You
can
view
the
added
chapters
on
the
[Chapter
List-Playlist]
menu.
5.
Press
RETURN
(O)
to
exit,
or
LIST/DISC
MENU
to
go
back
to
the
[Title
List-Original]
menu.
RAM
-RWVR
RAM
-RWVR
50
Deleting
an
Original
or
Deleting
an
Original
or
Playlist
T
Playlist
Title/Chapter
itle/Chapter
When
you
erase
a
title
or
chapter
from
the
Playlist
menu,
you
only
remove
it
from
the
Playlist;
the
title/chapter
remains
in
the
Original
menu.
If
you
choose
to
delete
a
title
or
chapter
from
the
Original
(title/chapter)
menu,
the
title
or
chapter
is
actually
deleted
from
the
disc
and
the
remaining
time
available
for
recording
increases.
Titles/chapters
deleted
from
the
Original
are
also
removed
from
the
Playlist.
Note:
It
may
not
be
possible
to
delete
chapters
that
are
less
than
5
seconds
long.
1.
Useb/B/v/Vtochooseachapterortitleyou
want
to
delete
on
the
[Title
List]
or
[Chapter
List]
menu
then
press
ENTER.
The
menu
options
appears
on
the
left
side
of
the
screen.
2.
Select
[Delete]
option
from
the
options
on
the
menu.
Example:
Title
List
(DVD-VR)
3.
Press
ENTER
to
confirm.
The
confirm
message
for
deleting
will
appear.
4.
Use
b
/
B
to
select
[Yes]
then
press
ENTER.
The
selected
chapter
or
title
is
deleted.
After
pressing
ENTER,
the
new,
updated
menu
is
displayed.
5.
Repeat
steps
1
-
4
to
continue
to
delete
from
the
menu.
6.
Press
RETURN
(O)
repeatedly
to
exit
the
menu.
Notes:
?
When
DVD+RW
recording,
the
deleted
title's
name
is
changed
to
[Deleted
Title].
?
If
more
than
two
titles
are
repeatedly
deleted,
the
titles
are
combined
into
one.
?
When
you
are
deleting
a
title
or
chapter,
only
the
last
one
on
DVD+R/RW
increases
remaining
recording
time.
Deleting
a
Part
Deleting
a
Part
You
can
delete
a
part
which
you
do
not
want
in
the
title.
1.
Useb/B/v/Vtochooseatitleyouwantto
delete
on
the
Title
List
menu
then
press
ENTER.
The
options
appears
on
the
left
side
of
the
menu.
2.
Select
[Delete
Part]
option
then
press
ENTER.
[Title
Edit
(Delete
Part)]
menu
appears
on
the
TV
screen.
[Start
Point]
icon
is
highlighted.
Example:
Title
Edit
(Delete
Part)
(DVD-VR)
3.
Starts
playback
and
use
pause
step,
search
and
slow-motion
to
find
the
starting
point.
4.
Press
ENTER
at
the
starting
point
of
the
section
you
want
to
delete.
[End
Point]
icon
is
highlighted.
The
part
is
indicated
on
the
Progress
Bar.
5.
Use
pause
step,
search
and
slow-motion
to
find
the
ending
point.
6.
Press
ENTER
at
the
ending
point
of
the
section
you
want
to
delete.
You
can
cancel
the
selected
point,
use
v
/
V
to
select
[Cancel]
icon
then
press
ENTER.
7.
If
you
finish
to
edit,
select
[Done]
icon
then
press
ENTER.
The
confirm
message
for
deleting
will
appear.
Use
b
/
B
to
select
[Yes]
then
press
ENTER.
The
selected
part
is
deleted
from
the
title
and
Title
List
menu
appears.
Notes:
?
It
may
not
be
possible
to
delete
parts
that
are
less
than
3
seconds
long.
?
If
you
select
[Cancel]
then
press
ENTER,
the
Recorder
will
go
to
previous
option
and
into
Pause
mode.
RAM
-RWVR
51
Editting
Naming
a
T
Naming
a
Title
itle
You
can
name
Original
and
Playlist
titles
independ-
ently.
1.
Choose
the
title
you
want
to
name
on
the
Title
List
menu,
then
press
ENTER.
The
menu
options
appears
on
the
left
side
of
the
menu.
2.
Use
v/V
to
select
[Title
Name]
option
then
press
ENTER.
Keyboard
menu
appears.
3.
Enteranameforthetitle.Useb/B/v/Vto
select
a
character
then
press
ENTER
to
confirm
your
selection.
?
Language
:
Selects
a
keyboard
type.
?
Space:
Inserts
a
space
at
the
cursor
position.
?
Delete:
Deletes
the
character
to
the
left
of
the
cursor
position.
?
b
/
B:
Moves
the
cursor
left
or
right.
?
OK:
Confirms
the
name
you
have
entered.
?
Cancel:
Deletes
all
characters
and
exits
the
Keyboard
menu.
Remote
control
buttons
for
entering
a
name
?
N
(PLAY):
Inserts
a
space
at
the
cursor
posi-
tion.
?
PAUSE/STEP
(X):
Deletes
the
character
to
the
right
of
the
cursor
position.
?
SKIP
(.
/
>):
Moves
the
cursor
left
or
right.
?
STOP
(x),
CLEAR:
Deletes
the
character
to
the
left
of
the
cursor
position.
?
0-9:
Enters
the
character
corresponding
to
the
selected
column.
?
LIST/DISC
MENU,
DISPLAY:
Switches
the
keyboard
type
(English/Latin
Capital,
English/Latin
Lowercase,
Symbol)
4.
Choose
[OK]
then
press
ENTER
to
fix
the
name
and
return
to
the
previous
menu
screen.
5.
Press
RETURN
(O)
repeatedly
to
exit
the
menu.
Notes:
?
Names
can
be
up
to
32
characters
long.
?
For
discs
formatted
on
a
different
recorder,
you
will
see
only
a
limited
character
set.
?
When
recording
on
DVD-R,
DVD+R
or
DVD+RW
discs,
the
entered
name
is
displayed
on
the
DVD
player
only
after
finalization.
T
T
ime
Search
ime
Search
You
can
select
start
point
of
the
title.
1.
Useb/B/v/VtochooseatitleontheTitleList
menu
then
press
ENTER.
The
options
appears
on
the
left
side
of
the
menu.
2.
Select
[Time]
option
then
press
ENTER.
Example:
Title
List
(DVD-VR)
3.
Press
ENTER.
[Time
Search]
menu
appears
on
the
TV
screen.
4.
Use
b
/
B
to
find
the
point
you
want
to
start.
The
point
increase
1
minute
step.
If
you
press
and
hold
b
/
B
then
the
point
increase
5
minute
step.
5.
Press
ENTER
to
start
seleted
point.
Current
Seleted
time
Start
time
Selected
point
End
time
52
Divide
One
T
Divide
One
Title
Into
T
itle
Into
Two
wo
Use
this
command
to
split
a
title
up
into
two
new
titles.
1.
On
the
Title
List
menu,
select
a
title
you
want
to
divide
then
press
ENTER.
The
menu
options
appears
on
the
left
side
of
the
screen.
2.
Select
[Divide]
option.
Example:
Title
List
(DVD+RW)
3.
Press
ENTER.
[Title
Edit
(Divide)]
menu
appears.
[Divide]
option
is
highlighted.
4.
Use
play,
pause
step,
search
and
slow-motion
to
find
the
point
you
want
to
divide
the
title.
5.
Select
[Divide]
option
then
press
ENTER
at
the
point.
To
reset
the
point,
select
[Cancel]
option
then
press
ENTER.
Repeat
from
step
3.
6.
Choose
[Done]
option
then
press
ENTER
to
fix
the
dividing
point.
The
title
is
divided
into
two
new
titles.
It
take
up
to
4
minutes
to
divide.
Note:
You
cannot
select
dividing
point
less
than
3
seconds.
Combining
T
Combining
Two
Chapters
wo
Chapters
Into
One
Into
One
Use
this
function
to
combine
two
adjacent
chapters
into
one.
1.
On
the
Chapter
List
menu,
select
the
second
chapter
of
the
two
chapters
you
want
to
combine
then
press
ENTER
The
menu
options
appears
on
the
left
side
of
the
screen.
2.
Use
v
/
V
to
select
[Combine]
option.
The
combine
indicator
appears
between
the
two
chapters
you
want
to
combine.
Example:
Title
List
(DVD+RW)
3.
Repeat
steps
1
-
2
to
continue
to
combine
from
the
menu.
4.
Press
RETURN
(
O)
repeatedly
to
exit
the
menu.
Notes:
This
function
cannot
operate
listed
as
below;
?
If
there
is
only
one
chapter
within
the
title.
?
If
you
select
first
chapter.
?
If
two
chapters
created
by
erasing
a
part
from
an
original
title.
?
If
two
chapters
created
from
different
titles.
?
If
two
chapters
created
by
moving
an
order
from
an
original
title.
RAM
+R
+RW
-RWVR
+RW
The
first
title's
thumbnail
Current
The
second
title's
thumbnail
53
Editting
Moving
a
Playlist
Chapter
Use
this
function
to
re-arrange
the
playing
order
of
Playlist
chapters
on
the
Chapter
List-Playlist
menu.
Note:
This
function
is
not
available
if
there
is
only
one
chapter.
1.
Select
a
chapter
on
the
Chapter
List-Playlist
menu.
2.
Press
ENTER.
The
menu
options
appears
on
the
left
side
of
the
menu.
3.
Use
v
/
V
to
select
[Move]
option
from
Playlist
options
then
press
ENTER.
4.
Useb/B/v/Vtochoosetheplaceyouwantto
move
the
chapter
then
press
ENTER.
After
pressing
ENTER,
the
updated
menu
is
dis-
played.
Hide
a
Chapter/T
Hide
a
Chapter/Title
itle
You
can
skip
playing
chapters
or
titles
without
delet-
ing
from
the
disc.
1.
Use
vVbBto
choose
a
chapter
or
title
you
want
to
hide
on
the
[Title
List]
or
[Chapter
List]
menu,
then
press
ENTER.
Options
appear
on
the
left
side
of
the
screen.
2.
Select
[Hide]
option.
Example:
Title
List
(DVD+RW)
3.
Press
ENTER
to
confirm.
The
chapter's
or
title's
thumbnail
will
dim.
Tip:
If
you
select
a
hidden
chapter
or
title
on
the
Title
List
or
Chapter
List
menu,
you
can
'show'
it
by
choosing
[Show]
option
on
the
menu.
After
doing
that,
you
are
able
to
see
the
chapter
or
title.
Protect
a
T
Protect
a
Title
itle
Use
this
function
to
protect
against
accidental
record-
ing,
editing
or
deleting
of
the
title.
1.
Press
LIST/DISC
MENU
to
display
the
[Title
List]
menu.
2.
Use
vVbBto
choose
a
title
you
want
to
protect
then
press
ENTER.
Options
appear
on
the
left
side
of
the
screen.
3.
Select
[Protect]
from
the
options.
Example:
Title
List
(DVD+RW)
4.
Press
ENTER
to
confirm.
The
lock
mark
will
appears
on
the
title's
thumbnail.
Tip:
If
you
select
a
title
that
has
already
been
protected
on
the
Title
List
menu,
you
can
'unprotect'
it
by
choosing
[Unprotect]
option
from
the
Title
List
menu
options.
After
doing
that,
you
can
edit
and
delete
the
title.
RAM
-RWVR
+R
+RW
+R
+RW
-RWVR
54
Overwriting
Recording
Overwriting
Recording
To
overwrite
a
new
video
recording
on
a
previously
recorded
title,
follow
these
steps.
This
feature
is
not
available
for
DVD+Rs,
that
always
record
at
the
end
of
the
Disc.
1.
Select
input
source
you
want
to
record
(TV
chan-
nel,
AV1-2,
DV).
2.
Press
LIST/DISC
MENU
to
display
the
Title
List
menu.
3.
Use
vVbBto
choose
a
title
you
want
to
over-
write.
4.
Press
z
REC
to
start
overwrite
recording.
Overwrite
recording
starts
from
the
start
point
of
the
title.
5.
Press
STOP
(x)
to
stop
the
overwrite
recording.
The
new
title
is
created
and
updated
menu
is
dis-
played.
Notes:
?
This
function
is
not
available
for
a
protected
title.
?
If
the
overwrite
is
longer
than
the
recording
length
of
the
current
title,
the
next
title
is
over-
written.
But
if
next
title
is
protected,
the
over-
writing
stops
at
the
starting
point
of
the
title.
?
If
the
selected
title's
recording
length
is
less
than
10
seconds,
the
next
title
is
overwritten.
But
if
the
next
title
is
protected,
overwriting
stops.
V
V
iewing
T
iewing
Title
List
menu
itle
List
menu
displayed
on
other
DVD
displayed
on
other
DVD
Recorders
or
Players
Recorders
or
Players
You
can
view
the
Title
List
menu
displayed
on
the
other
DVD
player
that
is
capable
of
playing
DVD+RW
or
DVD+R
discs.
1.
Insert
DVD+R
or
DVD+RW
disc
recorded
already.
2.
Press
TITLE
in
Play
mode
or
DVD
tuner
mode.
Title
List
menu
will
appear
as
shown
below.
3.
To
play
back
a
title,
select
the
title
you
want
then
press
ENTER
or
N
(PLAY).
Tip:
You
can
remove
the
Title
List
menu
by
pressing
STOP
(x).
Playing
Playing
Y
Your
Recordings
on
our
Recordings
on
Other
DVD
Players
Other
DVD
Players
(Finalizing
a
Disc)
(Finalizing
a
Disc)
Most
regular
DVD
players
can
play
finalized
discs
recorded
in
Video
mode,
finalized
DVD+R
or
DVD+RWs.
A
small
number
of
players
can
also
play
DVD-RW
discs
recorded
in
VR
mode,
finalized
or
not.
Check
the
manual
that
came
with
the
other
player
to
check
what
formats
of
discs
it
will
play.
Finalizing
'fixes'
the
recordings
and
editings
in
place
so
that
the
disc
can
be
played
on
a
regular
DVD
play-
er or
computer
equipped
with
a
suitable
DVD-ROM
drive.
Finalizing
a
Video
mode
disc
creates
a
menu
screen
for
navigating
the
disc.
The
menu
can
be
accessed
by
pressing
LIST/DISC
MENU
or
TITLE.
To
finalize
a
disc,
refer
to
[Finalize]
on
page
25.
Notes:
?
Unfinalized
DVD+RW
is
playable
on
regular
DVD
players.
?
The
edited
contents
of
a
DVD+RW
(DL)
disc
is
compatible
on
regular
DVD
players
only
after
finalization.
?
Any
edited
contents
of
the
DVD+R
disc
are
not
compatible
on
regular
DVD
players.
(Hide,
chapter
combine,
added
chapter
mark,
etc.)
?
How
long
finalization
takes
depends
on
the
type
of
disc,
how
much
is
recorded
on
the
disc,
and
the
number
of
titles
on
the
disc.
?
DVD+R
DL
disc
can
take
up
to
30
minutes
to
finalize.
+R
+RW
+RW
55
Controlling
Controlling
Y
Your
TV
with
the
our
TV
with
the
Supplied
Remote
Supplied
Remote
You
can
control
the
sound
level,
input
source,
and
power
switch
of
your
LG
TV
with
the
supplied
remote.
You
can
control
your
TV
using
the
buttons
below.
By
pressing
You
can
POWER
Turn
the
TV
on
or
off.
INPUT
Switch
the
TV's
input
source
between
the
TV
and
other
input
sources.
CH
+/--
Scans
up
or
down
through
memorized
channels.
VOL
+/--
Adjust
the
volume
of
the
TV.
MUTE
Turns
on
or
off
TV
sound.
Note:
Depending
on
the
unit
being
connected,
you
may
not
be
able
to
control
your
TV
using
some
of
the
buttons.
Controlling
other
TVs
with
the
remote
You
can
control
the
sound
level,
input
source,
and
power
switch
of
non-LG
TVs
as
well.
If
your
TV
is
list-
ed
in
the
table
below,
set
the
appropriate
manufactur-
er
code.
1.
While
holding
down
TV
POWER
button,
press
the
number
buttons
to
select
the
manufacturer
code
for
your
TV
(Refer
to
table
on
the
right
column).
2.
Release
TV
POWER
button.
Code
numbers
of
controllable
TVs
If
more
than
one
code
number
is
listed,
try
entering
them
one
at
a
time
until
you
find
the
one
that
works
with
your
TV.
Notes:
?
Depending
on
your
TV,
some
or
all
buttons
may
not
function
on
the
TV,
even
after
entering
the
correct
manufacturer
code.
?
If
you
enter
a
new
code
number,
the
code
number
previ-
ously
entered
will
be
erased.
?
When
you
replace
the
batteries
of
the
remote,
the
code
number
you
have
set
may
be
reset
to
the
default
set-
ting.
Set
the
appropriate
code
number
again.
Manufacturer
Code
Number
ADMIRAL
16,33,37,44,45
AIWA
70
AKAI
01
AMARK
09
AOC
01
BELL
&
HOWELL
33
BROKSONIC
18,19
CANDLE
51
CCE
07
CENTURION
08
CINERAL
43
CITIZEN
49,50,51,52,53,54,55
CORONADO
09
CROWN
09
CURTIS
MATHES
01,03,08,33,35,37,44
DAEWOO
16,38,39,40,41,42,43
DAYTRON
01,08
EMERSON
01,09,16,17,18,19
FISHER
28,29
FUNAI
46,47
GENERAL
ELECTRIC
03,10,11,13,37,44
GRADIENTE
01,56,57,63,67
HITACHI
09,14,15,43
JC
PENNEY
01,08,10,27,35
JVC
20,21,63,67
KIOTE
43
KMC
09
KTV
01,08,09,31
LG
(GOLDSTAR)
01,07,08,09,35,39,40
LODGENET
33
LOGIK
33
LXI
09,24,25,26,27,28,29
MAGNAVOX
01,02,04,05,06,
07,08,09,20,
34,35,43,51,61,62,65
MAJESTIC
33
MARANTZ
01,32
MEMOREX
33
MGA/MITSUBISHI
01,08,32,34
Manufacturer
Code
Number
MONTGOMERY
01,06,08,09
WARD
23,24,32,33,34
NEC
01,08
NOBLEX
07
PACKARD
BELL
43
PANASONIC
07,11,13,25,35,36
PHILCO
01,06,07,08,09,
15,38,43,58
PHILIPS
06,07,43,61,62,65
PIONEER
30
PORTLAND
09
PROSCAN
03,37,44
QUASAR
11,13
RADIO
SHACK
16,17,23
RCA
01,03,37,44,69
REALISTIC
16,17,23
SAMPO
08
SAMSUNG
01,08,09,25,68
SANYO
28,29
SCOTT
01,08
SEARS
09,25,26,27,28,29
SEMP
64
SHARP
09,22,23,24,60,66
SIGNATURE
2000
01,06,08,09,10,
23,24,33,34
SONY
12,62
SOUNDESIGN
51
SYLVANIA
01,04,05,06,07,
08,35,51
SYMPHONIC
46,47
TATUNG
11
TEKNIKA
07,09,16,33,51
TELERENT
09,33
THOMSON
69
YORX
08
TOSHIBA
01,25,26,27,64
WARDS
01,06,08,09,10,33,34
XR1000
48
ZENITH
01,
02,33,59
Reference
56
Area
Code
Afghanistan
AF
Argentina
AR
Australia
AU
Austria
AT
Belgium
BE
Bhutan
BT
Bolivia
BO
Brazil
BR
Cambodia
KH
Canada
CA
Chile
CL
China
CN
Colombia
CO
Congo
CG
Costa
Rica
CR
Croatia
HR
Czech
Republic
CZ
Denmark
DK
Ecuador
EC
Egypt
EG
El
Salvador
SV
Area
Code
Ethiopia
ET
Fiji
FJ
Finland
FI
France
FR
Germany
DE
Great
Britain
GB
Greece
GR
Greenland
GL
Islands
HM
Hong
Kong
HK
Hungary
HU
India
IN
Indonesia
ID
Israel
IL
Italy
IT
Jamaica
JM
Japan
JP
Kenya
KE
Kuwait
KW
Libya
LY
Luxembourg
LU
Area
Code
Malaysia
MY
Maldives
MV
Mexico
MX
Monaco
MC
Mongolia
MN
Morocco
MA
Nepal
NP
Netherlands
NL
Netherlands
Antilles
AN
New
Zealand
NZ
Nigeria
NG
Norway
NO
Oman
OM
Pakistan
PK
Panama
PA
Paraguay
PY
Philippines
PH
Poland
PL
Portugal
PT
Romania
RO
Russian
Federation
RU
Area
Code
Saudi
Arabia
SA
Senegal
SN
Singapore
SG
Slovak
Republic
SK
Slovenia
SI
South
Africa
ZA
South
Korea
KR
Spain
ES
Sri
Lanka
LK
Sweden
SE
Switzerland
CH
Taiwan
TW
Thailand
TH
Turkey
TR
Uganda
UG
Ukraine
UA
United
States
US
Uruguay
UY
Uzbekistan
UZ
Vietnam
VN
Zimbabwe
ZW
Area
Code
List
Choose
a area
code
from
this
list.
Language
Code
Abkhazian
6566
Afar
6565
Afrikaans
6570
Albanian
8381
Ameharic
6577
Arabic
6582
Armenian
7289
Assamese
6583
Aymara
6588
Azerbaijani
6590
Bashkir
6665
Basque
6985
Bengali;
Bangla
6678
Bhutani
6890
Bihari
6672
Breton
6682
Bulgarian
6671
Burmese
7789
Byelorussian
6669
Cambodian
7577
Catalan
6765
Chinese
9072
Corsican
6779
Croatian
7282
Czech
6783
Danish
6865
Dutch
7876
English
6978
Esperanto
6979
Estonian
6984
Faroese
7079
Language
Code
Fiji
7074
Finnish
7073
French
7082
Frisian
7089
Galician
7176
Georgian
7565
German
6869
Greek
6976
Greenlandic
7576
Guarani
7178
Gujarati
7185
Hausa
7265
Hebrew
7387
Hindi
7273
Hungarian
7285
Icelandic
7383
Indonesian
7378
Interlingua
7365
Irish
7165
Italian
7384
Japanese
7465
Javanese
7487
Kannada
7578
Kashmiri
7583
Kazakh
7575
Kirghiz
7589
Korean
7579
Kurdish
7585
Laothian
7679
Latin
7665
Latvian,
Lettish
7686
Language
Code
Lingala
7678
Lithuanian
7684
Macedonian
7775
Malagasy
7771
Malay
7783
Malayalam
7776
Maltese
7784
Maori
7773
Marathi
7782
Moldavian
7779
Mongolian
7778
Nauru
7865
Nepali
7869
Norwegian
7879
Oriya
7982
Panjabi
8065
Pashto,
Pushto
8083
Persian
7065
Polish
8076
Portuguese
8084
Quechua
8185
Rhaeto-Romance
8277
Rumanian
8279
Russian
8285
Samoan
8377
Sanskrit
8365
Scots
Gaelic
7168
Serbian
8382
Serbo-Croatian
8372
Shona
8378
Sindhi
8368
Language
Code
Singhalese
8373
Slovak
8375
Slovenian
8376
Somali
8379
Spanish
6983
Sudanese
8385
Swahili
8387
Swedish
8386
Tagalog
8476
Tajik
8471
Tamil
8465
Tatar
8484
Telugu
8469
Thai
8472
Tibetan
6679
Tigrinya
8473
Tonga
8479
Turkish
8482
Turkmen
8475
Twi
8487
Ukrainian
8575
Urdu
8582
Uzbek
8590
Vietnamese
8673
Volapuk
8679
Welsh
6789
Wolof
8779
Xhosa
8872
Yiddish
7473
Yoruba
8979
Zulu
9085
Language
Code
List
Use
this
list
to
input
your
desired
language
for
the
following
initial
settings:
Disc
Audio,
Disc
Subtitle,
Disc
Menu.
57
T
Troubleshooting
roubleshooting
Symptom
No
power.
No
picture.
No
sound.
The
playback
is
poor.
from
external
input
is
distorted.
Some
channels
are
skipped
over
when
using
CH
(v
/
V).
Cause
The
power
cord
is
disconnected.
The
TV
is
not set
to
receive
Recorder
signal
output.
The
video
cable
is
not
connected
securely.
The
Progressive
Scan
is
set
to
[ON]
on
the
setup
menu
but
is
connected
to
a
standard(analog)
television
with
compo-
nent
video
input.
Wrong
connection.
The
equipment
connected
with
the
audio
cable
is
not
set
to
receive
Recorder
signal
output.
The
audio
cables
are
not
connected
securely.
The
power
of
the
equipment
connected
with
the
audio
cable
is
turned
off.
The
AUDIO
options
are
set
to
the
wrong
position.
The
disc
is
dirty.
The
TV
channels
are
not
tuned
in
properly.
Tape
heads
are
dirty.
Tape
is
a
rental
or
was
recorded
on
another
VCR.
This
unit
can
only
output
525p
Progressive
scan
picture.
The
video
signal
from
the
external
component
is
copy-protected.
The
skipped
channels
were
deleted
with
the
CH.
Add/Del
feature.
Correction
Plug
the
power
cord
into
the
wall
out-
let
securely.
Select
the
appropriate
video
input
mode
on
the
TV
so
the
from
the
Recorder
appears
on
the
TV
screen.
Connect
the
video
cable
into
the
jacks
securely.
Set
Progressive
Scan
to
[OFF]
(see
page
21).
Check
the
connection.
Select
the
correct
input
mode
of
the
audio
receiver
so
you
can
listen
to
the
sound
from
the
Recorder.
Connect
the
audio
cable
into
the
jacks
securely.
Turn
on
the
equipment
connected
with
the
audio
cable.
Set
the
AUDIO
options
to
the
correct
position.
Clean
the
disc.
Check
tuning,
carry
out
tuning
again.
Clean
video
heads.
Use
CH/TRK
(v/V)
for
manual
tracking
adjustment
while
tape
is
playing.
Make
sure
that
your
TV
can
support
525p
Progressive
scan
or
set
Progressive
scan
to
off.
You
cannot
connect
via
the
Recorder.
Connect
the
component
directly
to
your
TV.
Use
the
CH.
Add/Del
feature
to
restore
channels.
See
[To
Add
or
Erase
Channels
from
Memory]
on
page
20.
Check
the
following
guide
for
the
possible
cause
of
a
problem
before
contacting
service.
58
Symptom
The
Recorder
does
not
start
playback.
Video
tape
cannot
be
inserted.
The
Remote
Control
does
not
work
properly.
Camcorder
is
not
shown.
Camcorder
via
A/V
input
or
DV
IN
to
Recorder
is
not
shown
on
TV
screen.
Timer
recording
is
not
possible.
Cause
No
disc
is
inserted.
No
tape
is
inserted.
An
unplayable
disc
is
inserted.
The
disc
is
placed
upside
down.
The
disc
is
not
placed
within
the
guide.
The
disc
is
dirty.
The
Rating
level
is
set.
Is
the
cassette
compartment
empty?
There
is
an
obstacle
in
the
path
of
the
Remote
Control
and
this
unit.
The
batteries
in
the
Remote
Control
are
exhausted.
The
Remote
Control
is
not
pointed
at
the
remote
sensor
of
the
Recorder.
The
Remote
Control
is
too
far
from
the
Recorder.
This
Remote
Control
use
the
same
buttons
for
VCR
and
DVD
functions
(ex.PLAY).
Camcorder
is
off.
The
recorder's
source
is
incorrect.
Clock
in
record
is
not set
to
correct
time.
Timer
has
been
programmed
incorrectly.
(TIMER
Record)
indicator
light
does
not
appear
after
programming
timer.
Correction
Insert
a
disc
or
tape.
(Check
that
the
disc
or
tape
indicator
in
the
display
window
is
lit.)
Insert
a
playable
disc.
(Check
the
disc
type
and
Regional
code.)
Place
the
disc
with
the
playback
side
down.
Place
the
disc
on
the
disc
tray
correctly
inside
the
guide.
Clean
the
disc.
Cancel
the
Rating
function
or
change
the
rating
level.
Eject
the
tape
in.
Remove
the
obstacle.
Replace
the
batteries
with
new
ones.
Point
the
Remote
Control
at
the
remote
sensor
of
the
Recorder.
Operate
the
Remote
Control
within
23ft
(7m).
When
using
a
VCR,
first
press
the
VCR
button.
When
using
a
DVD,
first
press
the
DVD
button.
Turn
camcorder
on
and
operate
properly.
Use
INPUT
to
select
input
channel
(AV1,
AV2
or
DV
IN).
Set
clock
to
correct
time.
Reprogram
Timer.
Reprogram
Timer
and
turn
record
off
to
enable
timer.
59
Symptom
or
sound
of
broadcasting
channel
is
weak
or
missing.
Can't
play
disc
recorded
on
this
Recorder
on
another
DVD
player.
Cannot
record
or
did
not
record
successfully.
Stereo
Audio
Record
and/or
Playback
not
present.
Cause
Antenna
or
cables
are
loose.
Wrong
Tuning
Band
is
selected
in
the
Recorder
Setup
menu.
The
disc
was
recorded
in
Video
mode.
Some
players
will
not
play
even
a
finalized
disc
recorded
in
Video
mode.
The
disc
was
recorded
in
VR
mode.
Discs
recorded
with
copy-once
materi-
al
cannot
be
played
on
other
players.
The
remaining
blank
space
on
the
disc
is
insufficient.
The
source
you
are
trying
to
record
is
copy-protected.
When
setting
the
recording
channel,
the
channel
is
tuned
on
the
TV's
own
tuner.
When
recording
to
a
Video
mode
disc,
programs
that
are
copy-once
protect-
ed
cannot
be
recorded.
TV
is
not
Stereo-compatible.
Broadcast
program
is
not
in
stereo
for-
mat.
Recorder
A/V
Out
jacks
are
not
connected
to
TV
A/V
In
jacks.
Recorder
Audio/Video
Out
is
not
selected
for
viewing
at
the
TV.
Recorder's
TV
audio
channel
is
set
to
SAP
or
MONO.
Correction
Tighten
connections
or
replace
cable.
Try [Tuning
Band
Select]
options;
see
page
19
for
details.
Finalize
the
disc;
see
page
25.
No
solution.
The
other
player
must
be
RW
compatible
in
order
to
play
it.
No
solution.
Use
another
disc.
You
cannot
record
the
source.
Select
the
channel
on
the
Recorder's
built-in
TV
tuner.
Use
a
VR
mode
formatted
disc
for
copy-once
material.
No
solution.
No
solution.
Make
A/V
connections.
Stereo
is
avail-
able
only
via
A/V
output
from
Recorder.
Select
AUX
or
A/V
source
as
TV
input.
Set
TV
audio
channel
mode
to
Stereo.
See
[Changing
TV
Audio
Channel]
on
page
27.
Reset
the
Recorder
If
you
observe
any
of
the
following
symptoms...
When
the
Recorder
is
plugged
in,
but
the
power
will
not
turn
on
or
off.
When
the
display
window
does
not
working.
When
the
Recorder
does
not
operate
normally.
You
can
reset
the
Recorder
as
follows
:
Press
and
hold
the
POWER
button
for
more
than
five
seconds.
This
will
force
the
Recorder
to
power
off.
Press
the
POWER
button
again
to
turn
the
Recorder
back
on.
Unplug
the
power
cord
and
then
plug
the
power
cord
again
after
more
than
five
sec-
onds.
60
General
Power
requirements
AC
120V,
60
Hz
Power
consumption
35W
Dimensions
(approx.)
430
X
78.5
X
354
mm
(16.9
x
3.1
x
13.9
inches)
(w
x
h
x
d)
Mass
(approx.)
6.8
kg
(14.96
lbs)
Operating
temperature
5˚C
to
35˚C
(41˚F
to
95˚F)
Operating
humidity
5
%
to
90
%
Signal
system
NTSC
RecordingRecording
format
DVD
VideoRecording,
DVD-VIDEO
Recordable
discs
DVD-ReWritable,
DVD-Recordable,
DVD+ReWritable,
DVD+Recordable
(Double
Layer),
DVD-Random
Access
Memory
Recordable
time
DVD
;
Approx.
1
hour
(XP
mode),
2
hours
(SP
mode),
4
hours
(LP
mode),
6
hours
(EP
mode)
DVD+R
DL
(8.5GB):
Approx.
1
hour
50
minutes
(XP
mode),
3
hours
40
minutes
(SP
mode),
7
hours
10
minutes
(LP
mode),
11
hours
(EP
mode)
VCR
;
SP:
2
HOURS
(T-120),
SLP:
6
HOURS
(T-120)/8
HOURS
(T-160)
Video
recording
format
Sampling
frequency
27MHz
Compression
format
MPEG
2
Audio
recording
format
Sampling
frequency
48kHz
Compression
format
Dolby
Digital
VCR
Specifications
Head
system
Four
head
helical
scan
azimuth
system
Timer
12-hour
display
type
with
AM,
PM
Tape
speed
SP:
33.35
mm/sec,
LP:
16.67
mm/sec,
SLP:
11.12
mm/sec
Tape
width
12.7
mm
Rewind
time
About
65
seconds
(T-120)
Antenna
75
ohms
(VHF/UHF)
VHF
output
signal
Channel
3
or
4
(Switchable)
Channel
coverage
VHF:
2-13,
UHF:
14-69,
CATV:
1-125
(4A,
A-W,
W+1
-
W+84,
A-5
-
A-1)
Frequency
range
20Hz
to
20kHz
Signal-to-noise
ratio
43dB
Dynamic
range
88
dB
Channel
separation
60
dB
Specifications
Specifications
61
DVD
Specifications
Laser
system
Semiconductor
laser,
wavelength
650
nm
Frequency
response
DVD
(PCM
48
kHz):
8
Hz
to
22
kHz,
CD:
8
Hz
to
20
kHz
Signal-to-noise
ratio
More
than
95dB
Harmonic
distortion
Less
than
0.008%
Dynamic
range
More
than
90
dB
Inputs
ANTENNA
IN
Antenna
or
CATV
input,
75
ohms
VIDEO
IN
(AV1,2)
1.0
Vp-p
75
ohms,
sync
negative,
RCA
jack
x
2
AUDIO
IN
(AV1,2)
-6
dBm
more
than
47
kohms,
RCA
jack
(L,
R)
x
2
S-VIDEO
IN
(Y)
1.0
V
(p-p),
75
Ω,
negative
sync,
Mini
DIN
4-pin
x
1
(C)
0.286
V
(p-p)
75
Ω
DV
IN
4
pin
(i.LINK/IEEE
1394
standard)
Outputs
VIDEO
OUT
1
Vp-p
75
Ω,
sync
negative,
RCA
jack
x
1
S-VIDEO
OUT
(Y)
1.0
V
(p-p),
75
Ω,
negative
sync,
Mini
DIN
4-pin
x
1
(C)
0.286
V
(p-p)
75
Ω
COMPONENT
VIDEO
OUT
(Y)
1.0
V
(p-p),
75
Ω,
negative
sync,
RCA
jack
x
1
(PROGRESSIVE
SCAN)
(Pb)/(Pr)
0.7
V
(p-p),
75
Ω,
RCA
jack
x
2
Audio
output
(digital
audio)
0.5
V
(p-p),
75
Ω,
RCA
jack
x
1
Audio
output
(optical
audio)
Optical
connector
x
1
Audio
output
(analog
audio)
1.1
Vrms
(1
kHz,
-6
dB),
600
Ω,
RCA
jack
(L,
R)
x
2
RF
OUT
Channel
3
or
4
(Switchable)
Accessory:
Videocable.............................1
Audiocable(L,R)................1
RF75-ohmCoaxialCable.................1
RemoteControl..................1
Batteries...............................2
Design
and
specifications
are
subject
to
change
without
notice.
This
LG
Electronics
product,
will
be
repaired
or
replaced,
at
LG's
option,
if it
proves
to
be
defective
in
material
or
workmanship,
under
normal
use,
during
the
warranty
period
("Warranty
Period")
listed
below,
effective
from
the
date
("Date
of
Purchase")
of
original
consumer
purchase
of
the
product.
This
warranty
is
good
only
to
the
original
pur-
chaser
of
the
product
and
effective
only
when
used
in
the
United
States,
excluding
U.S.
Territories.
THIS
WARRANTY
IS
IN
LIEU
OF
ANY
OTHER
WARRANTIES,
EXPRESS
OR
IMPLIED,
INCLUDING
WITHOUT
LIMITATION,
ANY
WARRANTY
OF
MERCHANTABILITY
OR
FITNESS
FOR
A
PARTICULAR
PURPOSE.
TO
THE EXTENT
ANY
IMPLIED
WARRANTY
IS
REQUIRED
BY
LAW,
IT
IS
LIMITED
IN
DURATION
TO
THE
EXPRESS
WARRANTY
PERIOD ABOVE.
LG
ELEC-
TRONICS
WILL
NOT
BE
LIABLE
FOR
ANY
INCIDENTAL,
CONSEQUENTIAL,
INDIRECT,
SPECIAL
OR
PUNITIVE
DAMAGES
OF
ANY
NATURE,
EVEN
IF
ADVISED
OF
THE
POSSIBILITY
OF
SUCH
DAMAGES,
INCLUDING
WITHOUT
LIMITATION,
LOST
REVENUES
OR
PROFITS,
LOST
OR
CORRUPTED
PROGRAMMING
OR
DATA,
OR
ANY
OTHER
DAMAGE
WHETHER
BASED
IN
CONTRACT,
TORT
OR
OTHERWISE.
Some
states
do
not
allow
the exclusion
or
limitation
of
incidental
or
consequential
dam-
ages
or
limitation
on
how
long
an
implied
warranty
lasts,
so
the
above
exclusion
or
limitation
may
not
apply
to
you.
This
warranty
gives
you
specific
legal
rights
and
you
may
also
have
other
rights
that
may
vary
from
state
to
state.
THIS
LIMITED
WARRANTY
DOES
NOT
APPLY
TO:
?
Damages
or
operating
problems
that
result
from
shipping,
installation,
adjustment
of
user
controls,
calibration,
maintenance
or
failure
to
maintain,
or
separate
system
components;
and
?
Damages
or
operating
problems
that
result
from
normal
wear
and
tear,
misuse,
abuse,
operation
outside
environmental
specifications
or
contrary
to
the
requirements
or
precautions
in
the
Operating
Guide,
accident,
lightning
strikes
or
other
natural
causes,
unauthorized
modification
or
alteration,
incorrect
electrical
current
or
voltage,
reception
problem
caused
by
inadequate
home
antenna
or
faulty
antenna
connections,
computer
software,
institutional
or
commercial
use,
or
other
causes
not
arising
out
of
defect
in
material
or
workmanship.
Therefore,
the
cost
of
repair
or
replacement
of
such
defective
product
shall
be
borne
by
the
consumer.
CUSTOMER
INTER-ACTIVE
CENTER
NUMBERS:
WARRANTY
PERIOD:
LABOR:
90
days
from
the
Date
of
Purchase.
PARTS:
One
Year
from
the
Date
of
Purchase.
*
Parts
replaced
are
warranted
for
the
remaining
portion
of
the
original
warranty
period.
HOW
SERVICE
IS
HANDLED:
Call
1-800-243-0000
for
instructions
on
getting
the
defective
unit
repaired
or
replaced.
Please
retain
dated
sales
receipt
and
your
box
to
return
the
unit
to
LG
for
repair
or
replacement.
Shipping
both
ways
will
be
paid
by
LG
during
the
Warranty
Period.
After
the
Warranty
Period,
you pay
inbound
shipping
charges
and
LG
pays
return
shipping
charges.
Visit
our
website
at:
http://www.lgservice.com
For
nearest
Authorized
Service
Center,
Where
to
buy,
Product
Assistance,
or
Customer
Assistance
Call
1-800-243-0000
(24
hours
a
day,
365
days
per
year)
and
select
appropriate options
from
the
menu.
Or
visit
our
website
at
http://www.lgservice.com
LG
ELECTRONICS
U.S.A.,
INC.
1000
SYLVAN
AVENUE
ENGLEWOOD
CLIFFS,
NJ
P/N
:
3835RV0011V
Issue
O
Printed
in
Korea
