SPEAKER BOX
EP24650
USER’S MANUAL
d if
“0000”
1. Prior to switching on,turn volume down to minimum.
2. Connect the audio source to the appropriate input socket.
3. Connect to the mains supply..
4. Switch on the audio source,followed by the active speaker.
5. Set the volume with the applicable control.
6. Adjust the bass + treble.
7. Bluetooth connection instruction.
Select “BT” mode of the MP3.
Open Bluetooth function on your pairing device and find Bluetooth
Select Bluetooth to complete pairing.
Input passwor ask for.
Select the song and play through your mobile device.
1"
15"
Active 2-way full range
15"Speaker box
50Hz-18KHz
94dB(+/-2dB)
120V/240V 60~50Hz.
300W
1600W
RMS
Peak
10
4
POWER
CLIP
POWER
AC 120V 60Hz
AC 240V 50Hz
MIC1 IN
MIN MAX
LEVEL
MIC2 IN
MIN MAX
LEVEL
LINE IN
MIN MAX
LEVEL
VOLUME
MIN MAX
LINE OUT
60Hz
GRAPHIC E QUALIZER
+6
6
+12
12
480Hz
1K 4K
10K
120V
240V
0
LED
ON
OFF
IR
USB
SD card
MP3 CONTR OL DIGITAL DISPLAY
21
1.LCD screen
2.MP3 control
3.USB input
4.SD card input
5.5 Band EQ control
6.Mic 1 input level control
7.Mic 2 input level control
8.Line input level control
9.Volume control
10.Power LED indicator
11. Clip LED indicator
12.XLR microphone 1 input
13.6.35mm microphone 1 input
14. RCA(R+L) line input
15. 3.5mm input
16. XLR Line input
17. XLR line output (balanced)
18.LED switch(ON/OFF)
19. Fade in IEC mains
20. Power Switch
21.120/240V Switch
