CMT-X5CD/CMT-X5CDB (GB) 4-528-304-12(1)
WARNING
To reduce the risk of fire, do not cover the
ventilation opening of the appliance with
newspapers, tablecloths, curtains, etc.
Do not expose the appliance to naked flame
sources (for example, lighted candles).
To reduce the risk of fire or electric shock, do not
expose this appliance to dripping or splashing,
and do not place objects filled with liquids, such
as vases, on the appliance.
As the main plug is used to disconnect the unit
from the mains, connect the unit to an easily
accessible AC outlet. Should you notice an
abnormality in the unit, disconnect the main
plug from the AC outlet immediately.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
Do not expose batteries or appliances with
battery-installed to excessive heat, such as
sunshine and fire.
The unit is not disconnected from the mains as
long as it is connected to the AC outlet, even if
the unit itself has been turned off.
This equipment has been tested and found
to comply with the limits set out in the EMC
Directive using a connection cable shorter than
3 meters.
The nameplate is located on the bottom exterior.
CAUTION
The use of optical instruments with this product
will increase eye hazard.
This appliance is
classified as a CLASS
1 LASER product. This
marking is located on
the bottom exterior.
CAUTION
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
For customers in Australia and New
Zealand
This equipment should be installed and operated
with at least 20 cm and more between the
radiator and person’s body (excluding
extremities: hands, wrists, feet and ankles).
For customers in Europe
Notice for customers: the following
information is only applicable to
equipment sold in countries applying
EU directives.
This product has been manufactured by or on
behalf of Sony Corporation, 1-7-1 Konan Minato-
ku Tokyo, 108-0075 Japan. Inquiries related to
product compliance based on European Union
legislation shall be addressed to the authorized
representative, Sony Deutschland GmbH,
Hedelfinger Strasse 61, 70327 Stuttgart, Germany.
For any service or guarantee matters, please
refer to the addresses provided in the separate
service or guarantee documents.
Hereby, Sony Corp., declares that this equipment
is in compliance with the essential requirements
and other relevant provisions of Directive
1999/5/EC. For details, please access the
following URL:
http://www.compliance.sony.de/
For customers in Europe and Australia
Disposal of Old Electrical &
Electronic Equipment
(Applicable in the European
Union and other European
countries with separate
collection systems)
This symbol on the product or on its packaging
indicates that this product shall not be treated
as household waste. Instead it shall be handed
over to the applicable collection point for the
recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product.
The recycling of materials will help to conserve
natural resources. For more detailed information
about recycling of this product, please contact
your local Civic Office, your household waste
disposal service or the shop where you
purchased the product.
Europe Only
Disposal of waste batteries
(applicable in the European
Union and other European
countries with separate
collection systems)
This symbol on the battery or on the packaging
indicates that the battery provided with this
product shall not be treated as household waste.
On certain batteries this symbol might be used
in combination with a chemical symbol. The
chemical symbols for mercury (Hg) or lead (Pb)
are added if the battery contains more than
0.0005% mercury or 0.004% lead.
By ensuring these batteries are disposed of
correctly, you will help prevent potentially
negative consequences for the environment
and human health which could otherwise be
caused by inappropriate waste handling of the
battery. The recycling of the materials will help to
conserve natural resources.
In case of products that for safety, performance
or data integrity reasons require a permanent
connection with an incorporated battery, this
battery should be replaced by qualified service
staff only. To ensure that the battery will be
treated properly, hand over the product at end-
of-life to the applicable collection point for the
recycling of electrical and electronic equipment.
For all other batteries, please view the section
on how to remove the battery from the product
safely. Hand the battery over to the applicable
collection point for the recycling of waste
batteries.
For more detailed information about recycling
of this product or battery, please contact your
local Civic Office, your household waste disposal
service or the shop where you purchased the
product.
Unit (back)
Listening to a CD
Playing a CD-DA/MP3 disc
1 Press FUNCTION to select “CD.”
2 Insert a CD to the disc slot at the top of the
unit.
Load a CD with the label side (printed side)
toward you.
Label side
(printed side)
(eject)
Plays back automatically. If you switch the
function to “CD” from another function when
a CD is already inserted in the slot, press
after “READING” has disappeared from the
display window .
The button of the remote or the unit enables
you to fast-rewind/fast forward, select a track,
file or folder (for MP3 disc), etc.
To eject the CD
Press (eject) on the unit.
Note
ˎ8 cm CD cannot be used with this system.
ˎDo not load a CD with non-standard shapes (e.g., heart,
square, star). Doing this may cause irreparable damage to
the system.
ˎDo not use a CD with tape, stickers or paste on it as this
may cause malfunction.
ˎWhen you remove a CD, do not touch the surface of the
disc.
To change the play mode
Play mode enables you to playback the same
music repeatedly or shuffle-play.
Play mode
1 Press to stop playback.
If you select “REPEAT” in step 4, you do not
have to stop playback.
2 Press MENU .
3 Press / to select “CD MENU”, then press
.
4 Press / to select “PLAYMODE” or
“REPEAT,” then press
.
5 Press / to select the play mode, then
press
.
You can select the following play modes.
PLAYMODE
Play mode Effect
NORMAL Plays a track or file.
FOLDER* Plays all tracks in the selected
folder. “FLDR” lights up in the
display window .
SHUFFLE Plays all tracks or files in
random order. “SHUF” lights
up in the display window .
FLDR.SHUF* Plays all tracks or files in the
selected folder in random
order. “FLDR. SHUF” lights up
in the display window .
PROGRAM Plays the programmed tracks
or files. “PGM” lights
up in the display window .
For details, see “Creating your
own program (Program Play)”.
* This play mode is applicable only for playing an MP3 disc.
REPEAT
Play mode Effect
ALL (Repeat
plays all tracks)
The system plays all tracks in a
disc or folder repeatedly.
“
” lights up in the display
window .
ONE (Repeat
plays one track)
The system plays the selected
track repeatedly. “
1” lights
up in the display window .
OFF Cancels repeat playback.
Note on playing MP3 discs
ˎDo not save unnecessary folders or files on a disc that has
MP3 files.
ˎFolders that have no MP3 files are not recognized on the
system.
ˎThe system can only play MP3 files that have a file
extension of “.mp3.”
Even when file name has the “.mp3” file extension, if it is
not an audio MP3 file, playing this file may generate a loud
noise, which could cause damage of the system.
ˎThe maximum number of MP3 folders and files compatible
with this system is:
999* folders (including the root folder)
999 files
250 files in a single folder
8 folder levels (in the tree structure of files)
*
This include f
olders that have no MP3 or other files. The
number of folders that the system can recognize may
be less than actual number of folders, depending on the
folder structure.
ˎC
ompatibility with all MP3 encoding/writing software,
CD-R/RW drive and recording media cannot be
guaranteed. Incompatible MP3 discs may produce noise or
interrupted audio or may not play at all.
Creating your own program
(Program Play)
Plays the programmed track or file in a CD.
1 Select “PROGRAM” in step 5 of “To change the
play mode” , then press
.
2 When using an MP3 disc, press +/– to
select the folder containing the tracks or files
that you want to program.
If you want to play all tracks or files in the
folder, press
.
3 Press / to select a desired track or
file, then select
.
Total playing time
of the selected
track or file
Selected track
or file number
Repeat the steps above to program additional
tracks or files.
4 Press
.
Your program of tracks or files starts playback.
To cancel program play
In step 1, select “NORMAL” for “PROGRAM,” then
press
.
To delete a programmed track or file
Press CLEAR while the play is stopped. Each
time you press the button, the last programmed
track or file will be deleted.
When all the programmed tracks or files are
deleted, “NO STEP” appears.
Tip
ˎUp to 25 tracks or files can be programmed. If you attempt
to program more than 25 tracks or files, “FULL” will be
displayed. In this case, delete unnecessary tracks.
ˎTo play the same program again, press .
Note
ˎWhen the disc is ejected or the power cord is
disconnected after programming, all the programmed
tracks and files are deleted.
Listening to the radio
Tuning in a radio station
1 Press FUNCTION to select “FM” or “DAB*”
(CMT-X5CDB).
2 Press and hold PRESET +/– until the
frequency indication in the display window
starts changing, then release the button.
Tuning stops automatically when a FM stereo
broadcast is received (Automatic Scanning).
“ST” lights up in the display window .
* DAB is for CMT-X5CDB only.
Manual tuning
Press PRESET +/– repeatedly to tune-in the
desired station.
Note on DAB/DAB+ stations (CMT-X5CDB
only)
ˎWhen you tune in a station that provides RDS services,
information such as the service name or station name is
provided by broadcasts.
ˎWhen tuning in a DAB/DAB+ station, it may take a few
seconds before you hear any sound.
ˎPrimary service is automatically received when secondary
service ends.
ˎThis tuner does no
t support data services.
Tip
ˎIf reception of an FM stereo broadcast is noisy, press MENU
and select “TUNE:MENU,” “FM MODE” and “MONO” in
turn, to select monaural reception. This reduces noise.
Presetting radio stations
You can preset your desired radio stations.
1 Tune in the desired station, then press MENU
.
2 Press / to select “TUNE:MENU,” then
press
.
3 Press / to select “MEMORY,” then press
.
4 Press / to select “OK,” then press .
5 Press / to select the preset number,
then press
.
Preset number
“COMPLETE” appears in the display window
and the radio station is registered with the
preset number.
Repeat the steps above to register further
radio stations.
6 Press / to turn off the power, then press
/ again to turn on the power.
Tip
ˎYou can preset up to 20 FM, or 20 DAB/DAB+ and 20 FM
stations (CMT-X5CDB).
ˎIf you select an already-registered preset number in step
5, the preset radio station is replaced by the currently
tuned-in radio station.
(USB) port
Connect a USB device.
Note
ˎYou can use your iPhone/iPod with this system via
Bluetooth or connection only.
AUDIO IN (external input) jack
Connect optional external equipment with an
audio connecting cable (not supplied).
~ AC IN (220-240V AC) input
Connect the power cord (supplied) to the wall
outlet.
FM ANTENNA
(for CMT-X5CD only)
DAB/FM ANTENNA
(for CMT-X5CDB only)
Connect the FM or DAB/FM antenna.
* The illustration above is for CMT-X5CD.
Note
ˎFind a location and an orientation that provide good
reception, and then fix the antennas to a stable surface
(window, wall, etc.).
ˎSecure the end of the FM lead antenna with adhesive
tape.
Reception of DAB/DAB+ radio station
(CMT-X5CDB only)
When you turn on the system for the first time
after you purchase the system, DAB Automatic
Scan starts automatically and creates a list of
available services. During the DAB Automatic
Scan, “********” appears. Do not press any button
on the unit or the remote during DAB Automatic
Scan. Scanning is interrupted and service list
may not be created properly. To run the DAB
Automatic Scan manually, perform the procedure
of “Running the DAB Automatic Scan
manually.” If you have moved to another area,
perform the DAB Automatic Scan manually and
re-register the contents of broadcasts.
Getting Started
Location of Controls
Note
This manual mainly explains operations using the remote, but the same operations can also be
performed using the buttons on the unit having the same or similar names.
Front
Top
Unit (front/top)Remote
When you use the remote for the first time
The battery is factory-installed in the remote.
Before using the remote for the first time,
remove the insulation sheet attached to the
battery holder. For details, see “Changing the
battery”.
Listening to music with
optional audio components
Playing back the music of
optional audio components
You can play a track of optional audio
components connected to the unit.
Note
ˎBeforehand, press the VOL – to turn down the volume.
1 Press FUNCTION to select “AUDIO IN.”
2 Connect its audio connecting cord to the
AUDIO IN jack on the rear of the unit and
the output terminal of the optional external
equipment.
3 Start playback of the connected component.
Adjust the volume on the connected
component during playback.
4 Press VOL +/
on the remote to adjust the
volume.
Note
ˎThe system may enter Standby mode automatically if the
volume level of the connected component is too low. For
details, see “Setting the Automatic Standby function.”
Listening to music through
a BLUETOOTH connection
Pairing the system with a
BLUETOOTH device and listening
to music
You can listen to music from BLUETOOTH device
over a wireless connection.
Before using the BLUETOOTH function, perform
pairing to register your BLUETOOTH device.
Note
ˎPlace the BLUETOOTH device to be connected within one
meter of the system.
ˎIf your BLUETOOTH device is compliant with touch (NFC),
skip the next procedure. See “Listening to music by one-
touch action (NFC).”
1 Press FUNCTION to select “BT AUDIO.”
2 Press MENU .
3 Press / to select “BT MENU,” then press
.
4 Press / to select “PAIRING,” then press
.
5 Press / to select “OK” then press .
When “PAIRING” starts flashing in the display
window , the system changes to pairing
mode.
6 Search for this system with the BLUETOOTH
device.
A list of the devices found may appear on the
BLUETOOTH device display.
7 Select [SONY:CMT-X5CD] or [SONY:CMT-
X5CDB] (this system).
If prompted to enter a passkey on the
BLUETOOTH device, enter “0000.”
If this system is not shown in the display of
the device, proceed from step 1 again.
When pairing is completed, the display
changes to the connected BLUETOOTH device
name from “PAIRING” and the BLUETOOTH
indicator lights up.
8 Press .
Starts playback.
Depending on the BLUETOOTH device, press
again. Also, you may have to start up a
music player on the BLUETOOTH device.
9 Press VOL +/– to adjust the volume.
If the volume cannot be changed on the
system, adjust it on your BLUETOOTH device.
Operation such as fast-rewind/fast-forward,
selecting music and selecting a folder can be
operated with the remote or buttons of the
unit.
Tip
ˎYou can perform a pairing operation or attempt to make a
BLUETOOTH connection with another BLUETOOTH device
while the BLUETOOTH connection is established with one
BLUETOOTH device. The currently established BLUETOOTH
connection is canceled when BLUETOOTH connection with
another device is successfully established.
Note
ˎThe operations described above may not be available
for certain BLUETOOTH devices. In addition, the actual
operations may differ depending on the connected
BLUETOOTH device.
ˎOnce a pairing operation is performed, it does not have
to be performed again. In the following cases, however, a
pairing operation must be performed again:
Pairing information was erased when the BLUETOOTH
device was repaired.
You attempt to pair the system with more than 10
BLUETOOTH devices.
This system can pair with up to 9 BLUETOOTH devices.
If you pair another BLUETOOTH device after pairing
with 9 devices was performed, pairing information of
the device that was connected with the system first is
overwritten with that of the new device.
Pairing registration information of this system is erased
from the connected device.
If you initialize the system or erase the pairing history
with the system, all the pairing information will be
erased.
ˎThe sound of this system cannot be sent to a BLUETOOTH
speaker.
ˎ“Passkey” may be called “Passcode,” “PIN code,” “PIN
number” or “Password,” etc.
To check the address of a connected
BLUETOOTH device
Press DISPLAY , while the name set on the
connected BLUETOOTH device is shown in the
display window . The BLUETOOTH device
address appears in two lines on the system
display window for 8 seconds.
To cancel the connection with a
BLUETOOTH device
Disconnect the BLUETOOTH connection on the
BLUETOOTH device. “BT AUDIO” appears in the
display window .
To erase the pairing registration
information
1 Select “DEL LINK” after step 3 on “Pairing
the system with a BLUETOOTH device and
listening to music,” then press
.
2 Press
/
to select “OK,” then press .
“COMPLETE” appears in the display window
and all the pairing information is erased.
Note
ˎIf you have erased the pairing information, you cannot
make a BLUETOOTH connection unless pairing is
performed again.
Listening to music through a
registered device
After step 1 on “Pairing the system with a
BLUETOOTH device and listening to music,”
operate the BLUETOOTH device to connect with
the system, then press of the unit to start
playback.
Listening to music by one-touch
action (NFC)
NFC is a technology for short-range wireless
communication between various devices such as
a mobile phone and IC tag.
Just touch your smartphone/tablet on the
system. The system is turned on automatically,
and pairing and BLUETOOTH connection are
established.
Beforehand, turn the NFC settings to on.
1 Touch your smartphone/tablet on the N-mark
on the unit.
Touch the smartphone/tablet on the unit and
maintain contact until the smartphone/tablet
vibrates.
Refer to the user’s guide of your smartphone
for the part of your smartphone/tablet used
as touch contact.
2 After completing the connection, press .
Starts playback.
To disconnect the established connection,
touch your smartphone/tablet on the N-Mark
on the unit.
Tip
ˎCompatible smartphones are those equipped with the NFC
function (compatible operating system: Android version
2.3.3 or later with the exception of Android 3.x).
Check the website below for information on compatible
devices.
For customers in Europe:
http://support.sony-europe.com/
For customers in other countries/regions:
http://www.sony-asia.com/support
ˎIf the smartphone/tablet does not respond
even though it is touched to the unit, download
“NFC Easy Connect” to your smartphone/tablet
and run it. Then touch to the unit again. “NFC
Easy Connect” is a free application for exclusive
use with Android™. Scan the following 2D
Code.
ˎWhen you touch an NFC-compliant
smartphone/tablet on the unit while another
BLUETOOTH device is connected with this
system, the BLUETOOTH device is disconnected
and the system is connected with the
smartphone/tablet.
Note
ˎIn some countries and regions, NFC-compliant
application may not be downloaded.
ˎFor some smartphones/tablets, this function
may be available without downloading “NFC
Easy Connect.” In this case, the operation
and specifications of the smartphone/tablet
may be different from the description in this
manual.
For details, refer to the user’s guide supplied
with your smartphone/tablet.
To tune in to a preset radio station
Press PRESET +/– to select the preset number
to which the desired station is registered.
Running the DAB Automatic Scan
manually (CMT-X5CDB only)
Before you can tune in DAB/DAB+ stations, you
must perform a DAB Initial Scan.
When you have moved to another area, also
perform the DAB Initial Scan manually to update
the DAB/DAB+ service information.
1 Press MENU .
2 Press / to select “TUNE:MENU,” then
press
.
3 Press / to select “INIT:SCAN,” then press
.
4 Press / to select “OK,” then press .
Scanning begins. The scanning progress is
indicated by asterisks (*******). Depending on
the DAB/DAB+ services available in your area,
scanning may take a few minutes.
Note
ˎIf your country or region does not support DAB/DAB+
broadcast, “NO SERV” appears.
ˎThis procedure clears all previously stored presets.
ˎBefore unplugging the DAB/FM lead antenna, make sure
the system is turned off to preserve your own DAB/DAB+
settings.
Listening to a file on a USB
device
Playing a file on a USB device
You can play audio files stored on a USB device
such as WALKMAN® or digital media player, on
this system by connecting a USB device to the
system.
For details on compatible USB devices, see
“Compatible devices and versions.”
1 Press FUNCTION to select “USB.”
2 Connect the USB device to the (USB) port
on the rear of the unit.
Connect the USB device directly, or via the USB
cable supplied with the USB device, to the
(USB) port .
Wait until “READING” disappears.
3 Press .
Starts playback.
You can operate fast-rewind/fast-forward,
selecting a track or file or selecting folder with
the remote or the button of the unit.
To change the play mode
When playing the USB device, the play mode
can be selected. Press MENU , then select
“USB MENU.” Select “PLAYMODE” or “REPEAT.”
For details, see “To change the play mode” of
“Listening to a CD.” When a file on a USB device
is playing, programmed playback cannot be
played.
Tip
ˎIf a USB device is connected to the unit, battery charging
starts automatically. Even when the system is off, the USB
device can be charged.
ˎIf the USB device cannot be charged, disconnect and
reconnect it. For details on the charging status of the USB
device, see the operating manual of the USB device.
Note
ˎThe playback order for the system may differ from the
playback order of the connected digital music player.
ˎBe sure to turn off the system before removing the USB
device. Removing the USB device while the system is
turned on may corrupt the data on the USB device.
ˎWhen USB cable connection is necessary, connect the
USB cable supplied with the USB device to be connected.
For details on connection, refer to the operation manual
supplied with the USB device to be connected.
ˎIt may take time before “READING” appears after
connecting, depending on the type of USB device
connected.
ˎDo not connect the USB device through a USB hub.
ˎWhen the USB device is connected, the system reads all
the files on the USB device. If there are many folders or
files on the USB device, it may take a long time to finish
reading the USB device.
ˎWith some connected USB devices, it may take a long time
to transmit signals from the system or to finish reading the
USB device.
ˎCompatibility with all encoding/writing software cannot
be guaranteed. If audio files on the USB device were
originally encoded with incompatible software, those files
may produce noise or, may malfunction.
ˎThe maximum number of folders and files on the USB
device compatible with this system is:
1,000* folders (including the root folder)
3,000 files
250 files in a single folder
8 folder levels (in the tree structure of files)
* This includes folders that have no playable audio file and
empty folders. The number of folders that the system
can recognize may be less than actual number of folders,
depending on the folder structure.
ˎThe syst
em does not necessarily support all the functions
provided in a connected USB device.
ˎF
olders that have no audio files are not recognized.
ˎThe audio f
ormats that you can listen to with this system
are as follows:
MP3:
file extension “.mp3”
WMA*:
file extension “.wma”
AA
C*: file extension “.m4a,” “mp4” or “.3gp”
Note that even when file name has the correct file
extension, if the actual file differs, the system may
produce noise or may malfunction.
*
Files with DRM (Digit
al Rights Management) copyright
protection or files downloaded from an online music
store cannot be played on this system. If you try to play
one of these files, the system plays the next unprotected
audio file.
Before operating this system
Malfunctions that occur during the normal
use of the system will be repaired by Sony in
accordance with the conditions defined in the
limited warranty for this system. However, Sony
will not be liable for any consequences arising
from a failure to play caused by a damaged or
malfunctioning system.
Music discs encoded with copyright
protection technologies
This product is designed to playback discs that
conform to the Compact Disc (CD) standard.
Recently, various music discs encoded with
copyright protection technologies are marketed
by some record companies. Please be aware
that among those discs, there are some that do
not conform to the CD standard and may not be
playable by this product.
Note on DualDiscs
A DualDisc is a two sided disc product which
mates DVD recorded material on one side
with digital audio material on the other side.
However, since the audio material side does
not conform to the Compact Disc (CD) standard,
playback on this product is not guaranteed.
License and Trademark Notice
ˎWindows Media is either a registered trademark
or trademark of Microsoft Corporation in the
United States and/or other countries.
ˎThis product is protected by certain intellectual
property rights of Microsoft Corporation. Use or
distribution of such technology outside of this
product is prohibited without a license from
Microsoft or an authorized Microsoft subsidiary.
ˎMPEG Layer-3 audio coding technology and
patents licensed from Fraunhofer IIS and
Thomson.
ˎ“WALKMAN” and “WALKMAN” logo are
registered trademarks of Sony Corporation.
ˎ© 2013 CSR plc and its group companies. The
aptX® mark and the aptX logo are trade marks
of CSR plc or one of its group companies and
may be registered in one or more jurisdictions.
ˎThe BLUETOOTH® word mark and logos are
registered trademarks owned by BLUETOOTH
SIG, Inc. and any use of such marks by Sony
Corporation is under license.
ˎThe NMark is a trademark or registered
trademark of NFC Forum, Inc. in the United
States and in other countries.
ˎAndroid and Google Play are trademarks of
Google Inc.
ˎThe system names and product names
indicated in this manual are generally the
trademarks or registered trademarks of the
manufacturer. ™ and ® marks are omitted in
this manual.
ˎApple, the Apple logo, iPad, iPhone, iPod,
iPod classic, iPod nano and iPod touch are
trademarks of Apple Inc., registered in the U.S.
and other countries. App Store is a service mark
of Apple Inc.
ˎ“Made for iPod” and “Made for iPhone”
mean that an electronic accessory has been
designed to connect specifically to iPod and
iPhone, respectively, and has been certified
by the developer to meet Apple performance
standards. Apple is not responsible for the
operation of this device or its compliance with
safety and regulatory standards. Please note
that the use of this accessory with iPod or
iPhone may affect wireless performance.
ˎ“Xperia” and “Xperia Tablet” are trademarks of
Sony Mobile Communications AB.
Setting the clock
1 Press
to turn on the system.
2 Press TIMER
.
If “PLAY SET” is displayed, press /
to
select “CLOCK,” then press
.
3 Press /
to set the hour, then press
.
4 Press /
to set the minutes, then press
.
Note
ˎThe clock settings are reset when you disconnect the
power cord or if a power failure occurs.
To display the clock when the system is off
Press DISPLAY
repeatedly to display the clock.
The clock is displayed for about 8 seconds.
If the system is in BLUETOOTH Standby mode,
the clock does not appear by pressing DISPLAY
.
4-528-304-12(1)
Personal Audio System
GB
Operating Instructions
©2014 Sony Corporation Printed in China
CMT-X5CD/CMT-X5CDB
Loading ...
