www.lg.com
OWNER'S MANUAL
DRYER
Copyright © 2019 LG Electronics Inc. All Rights Reserved
MFL71424304
Rev.00_050319
Before beginning installation, read these instructions carefully. This will simplify
installation and ensure that the product is installed correctly and safely. Leave
these instructions near the product after installation for future reference.
FDJ608W
EN ENGLISH
TABLE OF CONTENTS
This manual may contain images or content
different from the model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS ..............................................................3
IMPORTANT SAFETY INSTRUCTIONS ..........................................................3
Disposal of Your Old Appliance .........................................................................8
INSTALLATION ...............................................................................9
Specifications ....................................................................................................9
Accessories (Optional) ......................................................................................9
Installation Place Requirements......................................................................10
Stacking Installation Instructions (Optional) .................................................... 11
Reversing the door .......................................................................................... 13
OPERATION .................................................................................15
Using the Appliance ........................................................................................15
Sorting Laundry ............................................................................................... 16
Control Panel ..................................................................................................17
Programme Table ............................................................................................ 18
Option Programme .......................................................................................... 20
Rack Dry (Optional) .........................................................................................21
SMART FUNCTIONS ....................................................................22
Using LG SmartThinQ Application ..................................................................22
Using Smart Diagnosis™ ................................................................................25
MAINTENANCE ............................................................................ 26
Cleaning the Lint Filter ....................................................................................26
Emptying the Water Container ........................................................................27
Cleaning the Cool Air Inlet Grill .......................................................................27
Wiping the Moisture Sensor ............................................................................27
TROUBLESHOOTING .................................................................. 28
Diagnosing Problems ......................................................................................28
Error Codes ..................................................................................................... 32
WARRANTY .................................................................................. 33
OPERATING DATA .......................................................................34
3
EN
SAFETY INSTRUCTIONS
The following safety guidelines are intended to prevent unforeseen risks
or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as
described below.
This symbol is displayed to indicate matters and operations
that can cause risk. Read the part with this symbol carefully
and follow the instructions in order to avoid risk.
WARNING
This indicates that the failure to follow the instructions can cause
serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can cause the
minor injury or damage to the product.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of explosion, fire, death, electric shock,
injury or scalding to persons when using this product, follow
basic precautions, including the following:
Children in the Household
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not
play with the appliance.
4
EN
For use in Europe:
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
Children of less than 3 years should be kept away unless continuously
supervised.
Installation
• Make sure the appliance is properly installed, grounded, and
adjusted by qualified service personnel according to the installation
instructions.
• Never attempt to operate the appliance if it is damaged,
malfunctioning, partially disassembled, or has missing or broken
parts, including a damaged cord or plug.
• This appliance should only be transported by two or more people
holding the appliance securely.
• Do not install the appliance in a damp and dusty place. Do not install
or store the appliance in any outdoor area, or any area that is subject
to weathering conditions such as direct sunlight, wind, or rain or
temperatures below freezing.
• Tighten the drain hose to avoid separation.
• If the power cord is damaged or the hole of the socket outlet is loose,
do not use the power cord and contact an authorized service centre.
• Do not plug multiple socket outlets, an extension power cable or
adapter with this appliance.
• Items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed articles and clothes or pillows fitted with foam
rubber pads should not be dried in the appliance.
5
EN
• This appliance must not be installed behind a lockable door, a
sliding door or a door with a hinge on the opposite side to that of the
appliance, in such a way that a full opening of the appliance door is
restricted.
• This appliance must be grounded. In the event of malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current.
• This appliance is equipped with a power cord having an equipment-
grounding conductor and a grounding power plug. The power plug
must be plugged into an appropriate socket outlet that is installed and
grounded in accordance with all local codes and ordinances.
• Improper connection of the equipment-grounding conductor can
result in risk of electric shock. Check with a qualified electrician or
service personnel if you are in doubt as to whether the appliance is
properly grounded.
• Do not modify the power plug provided with the appliance. If it
does not fit the outlet, have a proper outlet installed by a qualified
electrician.
• The appliance must not be supplied through an external switching
device, such as a timer, or connected to a circuit that is regularly
switched on and off by a utility.
Operation
• Do not attempt to separate any panels or disassemble the appliance.
Do not apply any sharp objects to the control panel in order to
operate the appliance.
• Do not repair or replace any part of the appliance. All repairs
and servicing must be performed by qualified service personnel
unless specifically recommended in this Owner’s Manual. Use only
authorized factory parts.
• Keep the area underneath and around the appliance free of
combustible materials such as lint, paper, rags, chemicals, etc.
• Do not put animals, such as pets into the appliance.
• Do not leave the appliance door open. Children may hang on the
door or crawl inside the appliance, causing damage or injury.
6
EN
• Never reach into the appliance while it is operating. Wait until the
drum has completely stopped.
• Do not put in, wash or dry articles that have been cleaned in, washed
in, soaked in, or spotted with combustible or explosive substances
(such as wax, oil, paint, gasoline, degreasers, drycleaning solvents,
kerosene, vegetable oil, cooking oil, etc.). Improper use can cause
fire or explosion.
• In case of flood, disconnect the power plug and contact the LG
Electronics customer information centre.
• Do not push down the door excessively, when the appliance door is
open.
• Use new hose or hose-set supplied with the appliance. Reusing old
hoses can cause a water leak and subsequent property damage.
• Do not touch the door during a high temperature programme.
• Do not use flammable gas and combustible substances (benzene,
gasoline, thinner, petroleum, alcohol, etc.) near the appliance.
• If the drain hose or inlet hose is frozen during winter, use it only after
thawing.
• Keep all washing detergents, softener and bleach away from children.
• Do not touch the power plug or the appliance controls with wet hands.
• Do not bend the power cable excessively or place a heavy object on
it.
Maintenance
• Securely plug the power plug in the socket outlet after completely
removing any moisture and dust.
• Disconnect the appliance from the power supply before cleaning the
appliance. Setting the controls to the OFF or stand by position does
not disconnect this appliance from the power supply.
• Do not spray water inside or outside the appliance to clean it.
• Never unplug the appliance by pulling on the power cable. Always
grip the power plug firmly and pull straight out from the socket outlet.
7
EN
Technical Safety for Using the Dryer
WARNING - To avoid a fire
Risk of Fire and Flammable Materials
• In the appliance enclosure or in the built-in structure, keep ventilation
openings clear of obstruction. If not, it can result in a fire.
• This appliance contains R290, a refrigerant that is environmentally
friendly but flammable. Do not damage the refrigerant circuit, keep
open flame and ignition sources away from the appliance.
• Do not dry unwashed items in the appliance.
• Fabric softeners, or similar products, should be used as specified by
the fabric softener instructions.
• Remove all objects from pockets such as lighters and matches.
• Never stop the appliance before the end of the drying cycle unless
all items are quickly removed and spread out so that the heat is
dissipated.
• The appliance is not to be used if industrial chemicals have been
used for cleaning.
• Items that have been soiled with substances such as cooking oil,
vegetable oil, acetone, alcohol, petroleum, kerosene, spot removers,
turpentine, waxes and wax removers should be washed in hot water
with an extra amount of detergent before being dried in the appliance.
• Do not drink the condensed water. Failure to do so may result in food-
borne illnesses.
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agents or similarly qualified person in
order to avoid a hazard.
• The lint trap has to be cleaned frequently.
• Lint must not to be allowed to accumulate around the appliance.
• Do not spray dry cleaning detergent directly onto the appliance or use
the appliance to dry clothes left with dry cleaning detergent.
8
EN
• Do not dry clothes stained with oil substances. Oil substances
(including edible oils) stained on clothes cannot be completely
removed even after washing with water.
• The appliance must not be supplied through an external switching
device, such as a timer, or connected to a circuit that is regularly
switched on and off by a utility.
• Remove clothes from the appliance immediately when drying is
complete or the power is turned off during the drying process.
Leaving clothes that have been dried in the appliance unattended
could result in fire. Clothes removed from the appliance after drying
could result in fire. Remove clothes immediately after drying, and
then hang or lay the clothes flat to cool.
Disposal
• Before discarding an old appliance, unplug it. Cut off the cable
directly behind the appliance to prevent misuse.
• Dispose of all packaging materials (such as plastic bags and
styrofoam) away from children. The packaging materials can cause
suffocation.
• Remove the door before disposing of or discarding this appliance to
avoid the danger of children or small animals getting trapped inside.
Disposal of Your Old Appliance
• This crossed-out wheeled bin symbol indicates that waste electrical and electronic
products (WEEE) should be disposed of separately from the municipal waste stream.
• Old electrical products can contain hazardous substances so correct disposal
of your old appliance will help prevent potential negative consequences for the
environment and human health. Your old appliance may contain reusable parts that
could be used to repair other products, and other valuable materials that can be
recycled to conserve limited resources.
• You can take your appliance either to the shop where you purchased the product,
or contact your local government waste office for details of your nearest authorised
WEEE collection point. For the most up to date information for your country please
see www.lg.com/global/recycling.
This dryer contains the refrigerant R290 : 0.145 kg Hermetically sealed.
9
EN
Specifications
a
Water container
b
Control panel
c
Door
Model FDJ608W
Power supply 220 - 240 V~, 50 Hz
Size 600 mm (W) X 690 mm (D) X 850 mm (H)
Product weight 56 kg
Allowable temperature 5 - 35 °C
Max. capacity 8 kg
• Appearance and specifications may vary without notice to improve the quality of the appliance.
Accessories (Optional)
Please contact LG Electronics Customer Information Centre or visit the LG Website at http://www.lg.com for
purchase.
Condensing Drain Hose and Hose
Holder
Dry Rack Stacking Kit
Model : DH1N
(Sold separately)
Model : DR1N
(Sold separately)
Model : DT1W
(Sold separately)
INSTALLATION
10
EN
Installation Place
Requirements
Location
5 cm 1 cm 1 cm
Level floor : Allowable slope under the entire
appliance is 1°.
Power outlet : Must be within 1.5 meters of either
side of the location of the appliance.
• Do not overload the outlet with more than one
appliance.
Additional Clearance : For the wall, 5 cm: rear /1
cm: right & left side
• Do not place or store laundry products on top
of the appliance at any time. These products
may damage the finish or controls.
WARNING
• This appliance contains R290, a refrigerant
that is environmentally friendly but flammable.
Do not damage the refrigerant circuit, keep
open flame and ignition sources away from the
appliance.
NOTE
• For better drying performance, please keep the
rear of the appliance away from wall.
• Do not install the appliance where there is a
risk of frost or dust.
• The appliance may not be able to operate
properly or may be damaged by freezing of
condensed water in the pump and drain hose.
• Do not install the appliance next to a high-
temperature appliance like refrigerator, oven
or stove etc, which can cause poor drying
performance and programme duration, and
adversely affect the proper functioning of the
compressor. The appliance performs best at a
room temperature of 23 °C.
Positioning
• Install the appliance on a flat hard floor.
• Make sure that air circulation around the
appliance is not impeded by carpets, rugs, etc.
• Never try to correct any unevenness in the
floor with pieces of wood, cardboard or similar
materials under the appliance.
• Do not install the appliance in rooms where
freezing temperatures may occur. Frozen
hoses may burst under pressure. The reliability
of the electronic control unit may be impaired at
temperatures below freezing point.
• If the appliance is delivered in winter and
temperatures are below freezing, place the
appliance at room temperature for a few hours
before putting it into operation.
• Please ensure that when the appliance is
installed, it is easily accessible for an engineer
in the event of a breakdown.
• With the appliance installed, adjust all four
feet using a spanner to ensure the appliance
is stable, and a clearance of approximately 20
mm is left between the top of the appliance and
the underside of any work-top.
Ventilation Requirement
WARNING
• In the appliance enclosure or in the built-in
structure, keep ventilation openings clear of
obstruction. If not, it can result in a fire.
• Alcove or under counter
− Ensure air flow of 3.17 m
3
/min through the
appliance
• Closet
− Closet door must have 2 (louvered)
openings, each having a minimum area of
387 cm
2
, located 8 cm from bottom and top
of door.
11
EN
WARNING
• Avoid installing the appliance around a heat
source. The rear side of the appliance must
be well ventilated. Failure to follow these
instructions may result in problems.
• The appliance should not be installed next to a
refrigeration appliance.
• The appliance is not designed for maritime
use or for use in mobile installations such as
caravans, aircraft etc.
Electrical Connection
• Do not use an extension cord or double
adapter.
• Always unplug the appliance after use.
• Connect the appliance to an earthed socket in
accordance with current wiring regulations.
• The appliance must be positioned so that the
plug is easily accessible.
Stacking Installation
Instructions (Optional)
Your dryer can be placed on top of an LG washing
machine and securely fixed with a stacking kit.
This installation must be conducted by qualified
service personnel to ensure it has been installed
correctly.
Stacking Kit
In order to stack this dryer, an LG stacking kit is
required.
Dryer
Washing
machine
This dryer may only be stacked on top of an LG
washing machine. Do not attempt to stack this
dryer on any other washing machine, as damage,
injury or property damage could result.
Shape and
assembly
direction
Washing Machine Top plate size
550 mm 600 mm
Installation Procedure
1
Place the LG dryer on the LG washing
machine.
2
Remove the two screws from the bottom of the
rear cover on each side as illustrated below.
3
Align the stacking kit holes and the rear cover
holes.
• 3-1) 600 mm
• 3-2) 550 mm
4
Fasten the two screws that were removed
earlier from the dryer to the stacking kit.
12
EN
5
Use the four screws in the accessory box (16
mm) to assemble the washing machine rear
cover and stacking kit.
6
The procedure for the opposite side will be the
same.
WARNING
• Incorrect installation can cause serious
accidents.
• The weight of the appliance and the height of
installation make the stacking procedure too
risky for one person. This procedure should
be performed by two or more qualified service
personnel.
• The appliance is not suitable for a built-in
installation. Please do not install as a built-in
appliance.
• Do not operate if the appliance is not properly
stacked.
Condensed Water Drain-out
(Optional)
Normally, condensed water is pumped up to the
water container where water is collected until
manually emptied. Water can also be drained out
directly to a mains drain, especially when the dryer
is stacked on top of a washing machine. With a
connecting kit for the mains drain hose, simply
change the water path and re-route to the drainage
facility as below:
1
Separate the anti-backflow lid(a) and the
water container hose(b) from the connecting
kit.
2
Attach the anti-backflow lid(a) to the head of
the connecting kit and then connect the drain
hose(c) to the opposite side of the connecting
kit.
CAUTION
• If the hose is installed in a way that leaves it
bent or pinched, drainage may not function
properly.
Leveling the appliance
Leveling the appliance prevents unnecessary
noise and vibration. Place the appliance on a solid,
level floor.
If the appliance is not properly level, adjust the
front leveling feet as necessary.
Turn them clockwise to raise and counter-
clockwise to lower until the appliance no longer
wobbles, both front-to-back and side-to-side and
corner-to-corner.
Adjustable Feet
Adjustable Feet
Adjustable Feet
Diagonal Check
• When pushing down the edges of the top plate
diagonally, the appliance should not move up
and down at all (Check both directions). If the
appliance rocks when pushing the top plate
diagonally, adjust the feet again.
13
EN
Reversing the door
You can reverse the door for your convenience.
WARNING
• Do not reverse the door while the appliance is
stacked on a washing machine.
• Before removing the hinge screws, have an
assistant support the weight of the door. The
door could fall on the floor due to the weight of
the door.
• For safety reasons, two or more people need to
work together to reverse the door.
NOTE
• The appearance of the screws varies and the
screws must be inserted differently depending
on the position. Make sure the screw is
properly selected before tightening.
1
Open the door and remove 2 screws on the
door hinge. After removing the screws, put the
door down carefully with the front side facing
down to the floor.
Door hinge
Cabinet
WARNING
• Remove the lower screw first. The door may
fall on to the floor due to its weight and the door
can be damaged.
2
Remove 8 screws on the hinge assembly from
the door.
• There are 6 screws on the front and 2
screws on the side.
Hinge
assembly
3
Remove the 3 screws from the door latch
assembly which is fixed between the door
and the hinge assembly, and then remove the
screw which is fixed on the door hook.
Door latch
assembly
4
Switch between the position the hinge
assembly and door latch assembly and then
tighten the screws in reverse order.
• Tighten the screw in proper position
referring from 2 to 4 steps.
Hinge
Assembly
Door latch
assembly
14
EN
5
Remove the door catch from the appliance
frame by removing 2 screws and then
assemble them on the opposite side.
Door catch
6
Remove the 2 decorative screws from the
appliance frame and then assemble them on
opposite side.
7
Install the door with the screws removed
in step 1 and then check the door closes
properly.
15
EN
Using the Appliance
Before the first cycle, set the appliance to dry for
five minutes to warm up the drum. Open the door
between loads the first few times you use the
appliance to allow any odours from the interior of
the appliance to disperse.
1
Ensure the lint filter and water container are
clean.
• The lint filter is inside the door rim. It needs
to be cleaned before each drying cycle.
• Open the door and ensure the lint filter is
clean. If it is not, please clean the lint filter.
• Also check if the water container needs to
be emptied for optimum drying results.
WARNING
• Do not drink the condensed water.
NOTE
• In some instances, LED window may display
D (Empty water symbol) and the appliance may
stop because the water container is full.
2
Place laundry into the drum after sorting.
• The clothes should be sorted by fabric type
and dryness level and all the strings and
belts of clothes should be well tied and fixed
before being put into the drum. Push the
laundry to the back to keep it away from
the door seal. Otherwise, the door seal and
clothes may be damaged. Close the door.
CAUTION
• Be careful not to trap laundry between the door
and rubber seal.
3
Turn the power on.
• Press the Power button. The indicator icon
above the button will become illuminated,
indicating that the appliance is all set to run.
4
Select the drying programme you want.
• You can choose a programme by turning
the programme selector knob until the
required programme is indicated.
• If you press the Start/Pause button without
choosing a programme, the appliance
will proceed with the Cotton programme.
Please refer to the programme table for the
detailed information.
5
Press the Start/Pause button.
• When you press the Start/Pause button,
the appliance ventilates the inside of the
drum for 10 seconds in order to get the
appliance ready for drying operation.
6
After the cycle has finished, open the door and
remove the laundry.
7
Turn off the appliance.
• Press the Power button.
OPERATION
16
EN
CAUTION
• Be careful! The drum inside may still be hot.
• The appliance must not be used for purposes
other than those for which it was designed.
NOTE
• The final part of a tumble dryer cycle occurs
without heat (cool down cycle) to ensure that
laundry is left at a temperature that ensures the
laundry will not be damaged.
• A high atmospheric temperature and a small
room may both increase drying time as well as
energy consumption.
Sorting Laundry
Clothes have their own wash care labels, so drying
according to the wash care label is recommended.
Not only that, the laundry must be sorted
according to size and type of fabric.
For the best drying performance and most efficient
energy usage, do not overload the appliance.
Woollens
• Dry woollens on the Wool programme. Be sure
to follow fabric care label symbols first. Wool
may not be completely dried from the cycle,
so do not repeat drying. Pull woollens to their
original shape and dry them flat.
Woven and Loopknit Materials
• Some woven and loopknit materials may
shrink, depending on quality.
Non-Iron and Synthetics
• Do not overload the appliance. Take out non-
Iron items as soon as the appliance stops to
reduce creases.
Baby Clothes and Night Gowns
• Always check fabric care labels.
Rubber and Plastics
• Do not dry any items made from or containing
rubber or plastics such as:
− Aprons, Bibs and Chair Covers
− Curtains and Table Clothes
− Bathmats
Fiberglass
• Do not dry fiberglass items in the appliance.
Glass particles left in the appliance may be
subsequently picked up by your clothes in later
cycles.
Icon Description
Dry
Tumble dry
Permanent Press /
Crease resistant
Gentle / Delicate
Do not tumble dry
Do not dry
High heating
Medium heating
Low heating
No Heating / Air
Line dry / Hang to dry
Drip dry
Dry flat
In the shade
17
EN
Control Panel
a
Power Button
• Press the Power button to turn power on
and off.
• Press the Power button to cancel the Delay
End function.
b
Programme Selector
• Programmes are available according to the
laundry type.
• The lamp will light up to indicate the
selected programme.
c
Start/Pause Button
• This Start/Pause button is used to start or
pause a dry cycle.
• When in Pause, the power is turned off
automatically after 14 minutes.
d
Additional Programme Buttons
• Use these buttons to select the desired
options for the selected programme.
• In order to use the Remote Start function,
refer to SMART FUNCTIONS.
e
Drying Progress Indicator
• The different indicator icon lights up
depending on the drying cycle progress.
− @ : This icon lights up when the
appliance is in drying progress.
− - : This icon lights up when the
appliance is in iron drying progress.
− + : This icon lights up when the
appliance is in cupboard drying progress.
− = : This icon lights up when the
appliance is in cooling progress.
Display
• K : This icon indicates that the lint filter
should be cleaned or is clogged.
− Cleaning notice: When you press the
Power button, the icon will become
displayed.
• D : This icon indicates that the water
container needs to be emptied or is full.
− Emptying notice: When you press the
Power button, this icon will become
displayed.
− Full water notice: The icon will become
displayed and a buzzer will sound while
the appliance is in operation.
• L : This icon indicates the lint filter
insertion status. If the lint filter is not
inserted, the appliance will not operate and
the icon will become displayed.
• I : This icon indicates the condenser auto
cleaning status. The icon will be displayed
during water sprays to the condenser.
18
EN
Programme Table
Drying Programme
Sensor Dry Programmes
Programme Laundry Type Detail Dry Level
Capacity
8 kg
Cotton
Towels, dressing gowns
and bed linen
For thick and quilted
fabrics
Extra 8 kg
Bath towels, tea towels,
underwear and cotton
socks
For fabrics that do not
need to be ironed
Cupboard 8 kg
Bed linen, table linen,
towels, T-shirts, polo shirts
and work clothes
For fabrics that need to be
ironed
Iron 8 kg
Mix
Bed linen, table linen,
tracksuits, anoraks and
blankets
For thick and quilted
fabrics that do not need to
be ironed
Extra
4 kg
Shirts and blouses
For fabrics that do not
need to be ironed
Cupboard
Trousers, dressers, skirts
and blouses
For fabrics that need to be
ironed
Iron
Easy Care
Shirts, T-shirts, trousers,
under-wear and socks
For polyamide, acrylic,
and polyester that do not
need to be ironed
Cupboard
3.5 kg
Shirts, T-shirts, under-wear,
anoraks and socks
For polyamide, acrylic,
polyester that do need to
be ironed
Iron
Duvet Beddings, bed sheets For bulky items - 2.5 kg
Towel Towels, Pillowcases
For cotton fabrics which
do not need to be ironed
- 4.5 kg
Allergy Care
Cotton, underwear, bed
sheets and baby clothes
Helps to remove allergens
such as house mites
- 4.5 kg
Quick 30
Light and small items less
than 3ea.
For small amount of
polyamide, acrylic and
polyester items
- 1 kg
Sports Wear Soccer kit and training wear For polyester material - 2 kg
Wool Wool For wool fabrics - 1 kg
Delicate Silk, fine fabrics and lingerie
For fabrics that are
heat-sensitive, such as
synthetic fabrics
- 1.5 kg
19
EN
Timed Drying Programmes
Programme Laundry Type Detail Dry Level
Capacity
8 kg
Rack Dry Silk, wool, delicate lingerie
Refreshes clothes without
tumble drying
- -
Cool Air
All fabrics that need
refreshing
Tumbles without heat - -
Warm Air
Bath towels, bath robes,
dishcloths and acrylic
quilted fabrics
Small Items & damp
clothing, Everyday items
suitable for heat drying
- -
CAUTION
• If the load is less than 1 kg, please use the Warm Air programme in Timed Drying programmes. Wool
items should be dried using the Wool programme and heat-sensitive fabrics including silk, underwear
and lingerie should be dried using the Delicate programme. Please comply with the recommended
laundry load when you select your desired programme. Otherwise, your clothes may be damaged.
NOTE
• Tested in accordance with EN61121 and Directive 932/2012
• Set programme at Cotton Cupboard Energy (Full & Half Load) for test in accordance in conformity with
EN61121 and Directive 932/2012
• Standard Cotton programme :
Option (Default) (This is the most efficient
programme in terms of the test conditions proposed by EN61121 and Directive 932/2012)
• It is suitable to dry normal wet cotton laundry and it is the most efficient programme in terms of energy
consumption for drying wet cotton laundry.
• The test results depend on room temperature, type and amount of load, water hardness and water inlet
temperature.
• If the appliance is installed as built under, it may cause performance degradation.
• If the laundry is not spun at a high speed during washing, energy consumption and drying time will
increase.
20
EN
Option Programme
Delay End
You can use the Delay End option to delay the
finishing time of the drying cycle. It allows you to
set delay time from 3 hours to 19 hours.
1
Turn the appliance on.
2
Select a programme.
3
Press the Delay End button.
4
Set delay hour(s) by pressing the More Time,
Less Time button.
5
Press the Start/Pause button.
Anti Crease _
The Anti Crease option prevents creases that
are formed when the laundry is not unloaded
promptly at the end of the drying cycle. When
Anti Crease is selected, the appliance repeatedly
runs and pauses, giving you two hours to unload
the laundry. If the door is opened during the Anti
Crease option, the option is cancelled.
Favorite r
The Favorite option allows you to store a
customized dry programme for future use.
1
Turn the appliance on.
2
Select a programme.
3
Select the option or additional programme.
(Anti Crease, EcoHybrid etc.)
4
Press and hold the Favorite option button for
three seconds.
The Favorite option is now stored for future use. To
reuse the stored programme, select the Favorite
option and press the Start/Pause button.
Drum Light
Whilst the appliance is running it is possible to
see inside the drum if you select the Drum Light
function.
• Press and hold the Dry Level button for 3
seconds to activate the Drum Light function.
• Light on : Door is opened.
• Light off : Door is closed. The light is turned off
automatically.
Dry Level
Use this button to select a dryness level for the
drying programme.
1
Turn the appliance on.
2
Select a programme.
3
Select a dryness level by pressing the
Dry Level button repeatedly.
EcoHybrid
This additional program offers the option of saving
energy or time.
• Energy: Energy saving option.
• Time: Time saving option.
Child Lock i
Use this option to disable the controls. This feature
can prevent children from changing cycles or
operating the appliance.
Locking the Control Panel
1
Press and hold the Favorite and Delay End
button simultaneously for three seconds.
2
A beeper will sound, and CL will appear on the
display.
• When the Child Lock is set, all buttons are
locked except the Power button.
21
EN
NOTE
• Turning off the power or completing all cycles
will not reset the child lock function. You must
deactivate child lock before you can access
any other functions.
Unlocking the Control Panel
Press and hold the Favorite and Delay End
button simultaneously for three seconds.
• A beeper will sound and the remaining time for
the current programme will reappear on the
display.
Buzzer q
This option enables you to turn the buzzer sound
on and off.
More Time / Less Time
Use these buttons with the Manual Dry
programmes to manually increase or reduce the
drying time.
Press the More Time button to increase the
selected programme time by five minutes.
Press the Less Time button to decrease the
selected programme time by five minutes.
Rack Dry (Optional)
The Rack Dry is designed for use with laundry
that must be dried flat, without tumbling, including
sweaters and delicate fabrics.
If you want to use Rack Dry option, a dry rack
should be purchased separately. A Dry Rack
(Model name : DR1N) is available for purchase
from LG Electronics Customer Information Centre
or our website at http://www.lg.com
1
Open the door.
2
Insert the hook to the drum centre.
3
Place the dryer rack on the structure above
the lint filter and press it to complete assembly.
4
Place wet items on top of the rack. Allow
space around items for air to circulate.
• The rack does not move, but the drum will
rotate.
5
Close the door.
6
Turn power on and select Rack Dry.
7
Press the Start/Pause button.
NOTE
• Check the lint filter and remove any lint
accumulated from items dried on the rack.
• The More Time / Less Time keys can be used
to finely adjust the drying time.
22
EN
Using LG SmartThinQ
Application
Things to check before using LG
SmartThinQ
• For appliances with the a or b logo
1
Check the distance between the appliance
and the wireless router (Wi-Fi network).
• If the distance between the appliance and
the wireless router is too far, the signal
strength becomes weak. It may take a long
time to register or installation may fail.
2
Turn off the Mobile data or Cellular Data on
your smartphone.
• For iPhones, turn data off by going to
Settings → Cellular → Cellular Data.
3
Connect your smartphone to the wireless
router.
NOTE
• To verify the Wi-Fi connection, check that
Wi-Fi f icon on the control panel is lit.
• The appliance supports 2.4 GHz Wi-Fi
networks only. To check your network
frequency, contact your Internet service
provider or refer to your wireless router manual.
• LG SmartThinQ is not responsible for any
network connection problems or any faults,
malfunctions, or errors caused by network
connection.
• If the appliance is having trouble connecting
to the Wi-Fi network, it may be too far from
the router. Purchase a Wi-Fi repeater (range
extender) to improve the Wi-Fi signal strength.
• The Wi-Fi connection may not connect or may
be interrupted because of the home network
environment.
• The network connection may not work properly
depending on the Internet service provider.
• The surrounding wireless environment can
make the wireless network service run slowly.
• The appliance cannot be registered due to
problems with the wireless signal transmission.
Unplug the appliance and wait about a minute
before trying again.
• If the firewall on your wireless router is enabled,
disable the firewall or add an exception to it.
• The wireless network name (SSID) should be
a combination of English letters and numbers.
(Do not use special characters.)
• Smartphone user interface (UI) may vary
depending on the mobile operating system
(OS) and the manufacturer.
• If the security protocol of the router is set
to WEP, you may fail to set up the network.
Please change it to other security protocols
(WPA2 is recommended) and register the
product again.
SMART FUNCTIONS
23
EN
Installing LG SmartThinQ
Search for the LG SmartThinQ application from
the Google Play Store or Apple App Store on a
smartphone. Follow instructions to download and
install the application.
Wi-Fi Function
• For appliances with the a or b logo
Communicate with the appliance from a
smartphone using the convenient smart features.
Dryer Cycle (Remote Start, Download
Cycle)
Set or download any preferred cycle and operate
by remote control.
Smart Diagnosis™
This function provides useful information for
diagnosing and solving issues with the appliance
based on the pattern of use.
Push Alert
When the cycle is complete or the appliance has
problems, you have the option of receiving push
notifications on a smartphone.
Energy Monitoring
The dryer energy usage is affected by the cycle
and options so you may see some changes in
energy usage from one cycle to another.
Settings
Set the product nickname and delete product.
NOTE
• If you change your wireless router, Internet
service provider, or password, delete the
registered appliance from the LG SmartThinQ
application and register it again.
• The application is subject to change for
appliance improvement purposes without
notice to users.
• Functions may vary by model.
Using Dryer Cycle
Remote Start w
Use a smartphone to control your appliance
remotely. You can also monitor your cycle
operation so you know how much time is left in the
cycle.
To Use Remote Start:
1
Press the Power button.
2
Put the laundry in drum.
3
Press and hold the Buzzer button for 3
seconds to enable the Remote Start function.
4
Start a cycle from the LG SmartThinQ
application on your smartphone.
NOTE
• Once the Remote Start mode is enabled, you
can start a cycle from the LG SmartThinQ
smartphone application. If the cycle is not
started, the machine will wait to start the
cycle until it is turned off remotely from the
application or the Remote Start mode is
disabled.
• If the door is open, Remote Start is disabled.
To Disable Remote Start:
When Remote Start is activated, press and hold
the Buzzer button for 3 seconds.
24
EN
Download Cycle
Download new and special cycles that are not
included in the basic cycles on the appliance.
Appliances that have been successfully registered
can download a variety of specialty cycles specific
to the appliance.
Only one cycle can be stored on the appliance at
a time.
Once cycle download is completed in the
appliance, the product keeps the downloaded
cycle until a new cycle is downloaded.
Wireless LAN Module Specifications
Model LCW-004
Frequency
Range
2412 to 2472 MHz
Output Power
(Max)
IEEE 802.11b:17.82 dBm
IEEE 802.11g:17.72 dBm
IEEE 802.11n:16.61 dBm
Wireless function S/W version : V 1.0
For consideration of the user, this device should be
installed and operated with a minimum distance of
20 cm between the device and the body.
Standby power consumption 0.18 W
Network standby power
consumption
2.0 W
The period of time after which
the power management
function, or a similar function,
switches the equipment
automatically into standby
and/or off mode and/or
the condition providing
networked standby
20 min.
Declaration of Conformity
Hereby, LG Electronics declares that the radio
equipment type Dryer is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the
following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
LG Electronics European Shared Service Centre
B.V.
Krijgsman 1
1186 DM Amstelveen
The Netherlands
Open Source Software Notice
Information
To obtain the source code under GPL, LGPL, MPL,
and other open source licenses, that is contained
in this product, please visit http://opensource.lge.
com.
In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices
are available for download.
LG Electronics will also provide open source code
to you on CD-ROM for a charge covering the cost
of performing such distribution (such as the cost of
media, shipping, and handling) upon email request
to [email protected]. This offer is valid for a
period of three years after our last shipment of this
product. This offer is valid to anyone in receipt of
this information.
Smart Diagnosis™ Using a
Smartphone
• For appliances with the c or d logo
Use this function if you need an accurate diagnosis
by an LG Electronics customer information centre
when the appliance malfunctions or fails.
Smart Diagnosis™ can not be activated unless the
appliance is connected to power. If the appliance
is unable to turn on, then troubleshooting must be
done without using Smart Diagnosis™.
25
EN
Using Smart Diagnosis™
Smart Diagnosis™ Through the
Customer Information Centre
Use this function if you need an accurate diagnosis
by an LG Electronics customer information centre
when the appliance malfunctions or fails. Use this
function only to contact the service representative,
not during normal operation.
1
Press the Power button to turn on the
appliance. Do not press any other buttons or
turn the programme selector knob.
2
When instructed to do so by the call centre,
place the mouthpiece of your phone close to
the Smart Diagnosis™ icon.
Max.
10 mm
3
Press and hold the More Time button for three
seconds, while holding the phone mouthpiece
to the icon and Power button.
4
Keep the phone in place until the tone
transmission has finished. Time remaining for
data transfer is displayed.
• For best results, do not move the phone
while the tones are being transmitted.
• If the call centre agent is not able to get an
accurate recording of the data, you may be
asked to try again.
5
Once the countdown is over and the tones
have stopped, resume your conversation with
the call centre agent, who will then be able to
assist you using the information transmitted for
analysis.
NOTE
• The Smart Diagnosis™ function depends on
the local call quality.
• The communication performance will improve
and you can receive better service if you use
the home phone.
• If the Smart Diagnosis™ data transfer is poor
due to poor call quality, you may not receive the
best Smart Diagnosis™ service.
26
EN
WARNING
• Remove the power plug when you clean the
appliance. Not removing the plug may result in
electric shock.
Cleaning the Lint Filter
Clean the lint filter before each drying cycle.
Cleaning the lint filter will reduce drying time and
energy consumption.
1
Open the door.
2
Remove the first lint filter.
3
Remove the second lint filter.
4
Open both lint filters and remove all the lint.
• Open the first lint filter.
• Open the second lint filter.
5
Rinse away the lint under warm, running
water.
6
Dry the lint filters completely, close them and
reinsert both lint filters.
NOTE
• Remove moisture from the mesh. Otherwise,
the lint filter may be clogged due to water film
and the appliance may not operate.
• If the lint filter is not in the appliance, you can
not operate the appliance.
MAINTENANCE
27
EN
Emptying the Water
Container
Condensed water is collected in the water
container.
Empty the water container after every use. Not
doing so will affect the drying performance.
If the water container is full, the D icon glows
and the buzzer sounds while the appliance is
operating. If this should occur, the water container
needs to be emptied within the next hour.
1
Pull out the water container.
2
Empty the water container in the sink.
3
Push it back into the appliance.
4
Press the Start/Pause button.
Cleaning the Cool Air Inlet
Grill
Vacuum the Cool Air Inlet grill 3 - 4 times a year
to make sure there is no build-up of lint or dirt that
may cause improper air flow.
NOTE
• Warm air is expelled through the ventilation
grill.
• Adequate ventilation should be provided to
avoid the back flow of gases into the room from
units burning other fuels, such as open fires.
Wiping the Moisture
Sensor
This device senses the moisture level of the
laundry during operation, which means it must be
cleaned regularly to remove any build-up of lime
scale on the surface of the sensor.
Wipe the sensors inside the drum.
CAUTION
• Do not wipe the moisture sensor with abrasive
materials. Always clean the sensor with a
rough sponge.
28
EN
TROUBLESHOOTING
The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at
an early stage. If the appliance does not function properly or does not function at all, check the following
before you call for service:
Diagnosing Problems
Symptoms Reason Solution
Appliance will not turn
on.
Power cord is not
properly plugged in.
• Make sure that the plug is securely plugged
into a grounded outlet matching the appliance’s
rating plate.
House fuse is blown,
circuit breaker has
tripped, or power
outage has occurred.
• Reset circuit breaker or replace fuse. Do not
increase fuse capacity. If the problem is a
circuit overload, have it corrected by a qualified
electrician.
Appliance does not
heat.
House fuse is blown,
circuit breaker has
tripped, or power
outage has occurred.
• Reset circuit breaker or replace fuse. Do not
increase fuse capacity. If the problem is a
circuit overload, have it corrected by a qualified
electrician.
Clothes take too long
to dry.
Load is not properly
sorted.
• Separate heavy items from lightweight items.
Larger and heavier items take longer to dry.
Light items in a load with heavy items can fool
the sensor because the light items dry faster.
Large load of heavy
fabrics.
• Heavy fabrics take longer to dry because they
tend to retain more moisture. To help reduce and
maintain more consistent drying times for large
and heavy fabrics, separate these items into
smaller loads of a consistent size.
Appliance controls are
not set properly.
• Use the appropriate control settings for the type
of load you are drying. Some loads may require
an adjustment of the dry level setting for proper
drying.
Lint filter needs to be
cleaned.
• Remove the lint from the lint filter before every
cycle. With the lint removed, hold the lint filter
up to a light to see if it is dirty or clogged. With
some loads that produce high amounts of lint,
such as new bath towels, it may be necessary
to pause the cycle and clean the filter during the
cycle.
29
EN
Symptoms Reason Solution
Clothes take too long
to dry.
House fuse is blown,
circuit breaker has
tripped, or power
outage has occurred.
• Reset circuit breaker or replace fuse. Do not
increase fuse capacity. If the problem is a
circuit overload, have it corrected by a qualified
electrician.
Appliance is
overloaded.
• Divide extra large loads into smaller loads for
better drying performance and efficiency.
Appliance is
underloaded.
• If you are drying a very small load, add a few
extra items to ensure proper tumbling action.
If the load is very small and you are using
Sensor Dry programmes, the electronic control
cannot properly sense the dryness of the load
and may shut off too soon. Use Timed Drying
programmes or add some extra wet clothes to
the load.
Drying time is not
consistent.
Heat settings, load
size, or dampness
of clothing is not
consistent.
• The drying time for a load will vary depending
on the type of heat used (electric), the size of
the load, the type of fabrics, the wetness of
the clothes, and lint filter. Even an unbalanced
load in the appliance can cause poor spinning,
resulting in wetter clothes which will take longer
to dry.
Greasy or dirty spots
are left on clothes.
Fabric softener is used
incorrectly.
• When washing laundry that is to be dried in
the appliance, use the correct amount of fabric
softener as recommended by the manufacturer
of the fabric softener.
Clean and dirty
clothes are being dried
together.
• Use the appliance to dry only clean items. Soil
from dirty clothes can transfer to the clean
clothes in the same or later loads.
Clothes were not
properly cleaned
or rinsed before
being placed in the
appliance.
• Stains on dried clothes could be stains that were
not removed during the washing process. Make
sure that clothes are being completely cleaned
or rinsed according to the instructions for your
washing machine and detergent. Some difficult
soils may require pre-treating prior to washing.
30
EN
Symptoms Reason Solution
Clothes are wrinkled.
Clothes have dried too
long (overdried).
• Over drying a load of laundry can lead to
wrinkled clothes. Try a shorter drying time.
Clothes have been left
in the appliance for too
long after cycle ends.
• Use the Anti crease option.
Clothes are shrinking.
Garment care
instructions are not
being followed.
• To avoid shrinking your clothes, always consult
and follow fabric care instructions. Some fabrics
will naturally shrink when washed. Other fabrics
can be washed but will shrink when dried in the
appliance. Use a low or no heat setting.
Lint is left on clothes.
Lint filter has not been
cleaned properly.
• Remove the lint from the lint filter before every
cycle. With the lint removed, hold the lint filter
up to a light to see if it is dirty or clogged. If it
looks dirty, follow the cleaning instructions. With
some loads that produce high amounts of lint, it
may be necessary to clean the lint filter during
the cycle.
Laundry has not been
sorted properly.
• Some fabrics are lint producers (i.e., a fuzzy
white cotton towel) and should be dried
separately from clothes that are lint trappers
(i.e., a pair of black linen pants).
Appliance is
overloaded.
• Divide extra large loads into smaller loads for
drying.
Tissue, paper, etc., has
been left in pockets.
• Check pockets thoroughly before drying clothes.
Excess static in
clothes after drying.
Clothes have dried for
too long (overdried).
• Overdrying a load of laundry can cause a
buildup of static electricity. Adjust settings and
use a shorter drying time, or use Sensor Dry
programmes.
Drying synthetics,
non-Iron, or synthetic
blends.
• These fabrics are naturally more prone to static
buildup. Try using fabric softener, or use shorter
Timed Drying time settings.
31
EN
Symptoms Reason Solution
Water leaks.
The water container
hose or the drain
hose is not connected
correctly.
• Connect the water container hose or the drain
hose correctly.
The door is closed
while laundry or
foreign substance is
caught in the door.
• Check if laundry or foreign substance is caught
in the door before using the appliance. If water
leaks continuously, contact the LG Electronics
Customer Information Centre.
Clothes have damp
spots after a Sensor
Dry programme.
Very large load or very
small load. Single large
item such as a blanket
or comforter.
• If items are too tightly packed or too sparse
the sensor may have trouble reading the
dryness level of the load. Use a Timed Drying
programme for very small loads.
• Large, bulky items such as blankets or
comforters can sometimes wrap themselves into
a tight ball of fabric. The outside layers will dry
and register on the sensors, while the inner core
remains damp. When drying a single bulky item,
it may help to pause the cycle once or twice and
rearrange the item to unwrap and expose any
damp areas.
• To dry a few remaining damp items from a very
large load or a few damp spots on a large item
after a Sensor Dry programme has completed,
empty the lint trap, then set a Timed Drying
programme to finish drying the item(s).
Your home appliance
and smartphone is not
connected to the Wi-Fi
network.
The password for the
Wi-Fi that you are
trying to connect to is
incorrect.
• Find the Wi-Fi network connected to your
smartphone and remove it, then register your
appliance on LG SmartThinQ.
Mobile data for your
smartphone is turned
on.
• Turn off the Mobile data of your smartphone
and register the appliance using the Wi-Fi
network.
The wireless network
name (SSID) is set
incorrectly.
• The wireless network name (SSID) should be a
combination of English letters and numbers. (Do
not use special characters.)
The router frequency is
not 2.4 GHz.
• Only a 2.4 GHz router frequency is supported.
Set the wireless router to 2.4 GHz and connect
the appliance to the wireless router. To check
the router frequency, check with your Internet
service provider or the router manufacturer.
The distance between
the appliance and the
router is too far.
• If the distance between the appliance and the
router is too far, the signal may be weak and
the connection may not be configured correctly.
Move the location of the router so that it is closer
to the appliance.
32
EN
Error Codes
Symptoms Reason Solution
dE
The door has been
opened while the
appliance is in
operation or the
appliance is being
operated without the
door being closed
properly.
• Close the door completely.
• If dE is not released, call for service.
dE4
Door switch detection
is not working
properly.
• Unplug the power plug and call for service.
tE1
Temperature Sensor
has malfunctioned.
• Unplug the power plug and call for service.tE2
tE4
F1
The temperature inside
the drum has risen
suddenly.
• Unplug the power plug and call for service.
LE1
The motor has stopped
suddenly.
• Check if the amount of laundry exceeds the
maximum load.
• Unplug the power plug and call for service.
LE2
The compressor has
stopped suddenly.
• Unplug the power plug and call for service.
AE
OE
The drain pump motor
has malfunctioned.
• Unplug the power plug and call for service.
The surrounding
temperature for
installation is below
zero.
• The recommended surrounding temperature for
installation is 5 - 35 °C.
33
EN
THIS LIMITED WARRANTY DOES NOT COVER:
• Service trips to deliver, pick up, or install or repair the product; instruction to the customer on operation
of the product; repair or replacement of fuses or correction of wiring or plumbing, or correction of
unauthorized repairs/installation.
• Failure of the product to perform during power failures and interruptions or inadequate electrical
service.
• Damage caused by leaky or broken water pipes, frozen water pipes, restricted drain lines, inadequate
or interrupted water supply or inadequate supply of air.
• Damage resulting from operating the Product in a corrosive atmosphere or contrary to the instructions
outlined in the Product’s owner’s manual.
• Damage to the Product caused by accidents, pests and vermin, lightning, wind, fire, floods, or acts of
God.
• Damage or failure caused by unauthorized modification or alteration, or if it is used for other than the
intended purpose, or any water leakage where the product was not properly installed.
• Damage or failure caused by incorrect electrical current, voltage, or plumbing codes, commercial
or industrial use, or use of accessories, components, or consumable cleaning products that are not
approved by LG.
• Damage caused by transportation and handling, including scratches, dents, chips, and/or other damage
to the finish of your product, unless such damage results from defects in materials or workmanship.
• Damage or missing items to any display, open box, discounted, or refurbished Product.
• Products with original serial numbers that have been removed, altered, or cannot be readily
determined. Model and Serial numbers, along with original retail sales receipt, are required for warranty
validation.
• Increases in utility costs and additional utility expenses.
• Repairs when your Product is used in other than normal and usual household use or contrary to the
instructions outlined in the Product’s owner’s manual.
• Costs associated with removal of your Product from your home for repairs.
• The removal and reinstallation of the Product if it is installed in an inaccessible location or is not
installed in accordance with published installation instructions, including LG’s owner’s and installation
manuals.
• Damage resulting from misuse, abuse, improper installation, repair, or maintenance. Improper repair
includes use of parts not approved or specified by LG.
• Noise or vibration that is considered normal, for example, water drain sound, spin sound or warning
beeps.
Filter is clogged.
- Not heating, long dry time
Clean the lint filter.
Improperly connected power cord
or electrical outlet issue.
- No power
- Not heating
Reconnect power cord, replace
house fuse or reset breaker. If
outlet is issue, electrician may be
required.
WARRANTY
34
EN
Product fiche_commission Delegated Regulation(EU) No 392/2012
Supplier’s name or trade mark LG Electronics
Supplier’s model identifier FDJ608W
Rated capacity in kg of cotton laundry for the standard cotton programme at full load 8 kg
Dryer type
Condenser
Household
Tumble Dryer
Energy efficiency class A+++
Energy consumption “X” kWh per year, based on 160 drying cycles of the standard
cotton programme at full and partial load, and the consumption of the low-power
modes. Actual energy consumption per cycle will depend on how the appliance is
used
176 kWh/year
Automatic tumble drier Yes
Awarded an "EU Ecolabel" under Regulation (EC) No 66/2010 No
Energy consumption of the standard cotton programme at full load (E
dry
) 1.47 kWh
Energy consumption of the standard cotton programme at partial load (E
dry1/2
) 0.80 kWh
Power consumption of the off-mode for the standard cotton programme at full load
(P
o
)
0.18 W
Power consumption of the left-on mode for the standard cotton programme at full
load (P
l
)
0.18 W
Duration of the left-on mode (T
l
) 10 min
The ‘ ’ used at full and partial load is the standard drying programme to which the
information in the label and the fiche relates, that this programme is suitable for drying normal wet cotton
laundry and that it is the most efficient programme in terms of energy consumption for cotton.
The weighted programme time (T
t
) of the ‘standard cotton programme at full and
partial load'
150 min
The programme time of the ‘standard cotton programme at full load’ (T
dry
) 196 min
The programme time of the ‘standard cotton programme at partial load’ (T
dry1/2
) 115 min
Condensation efficiency class ‘X’ on a scale from G (least efficient) to A (most
efficient)
A
Average condensation efficiency C
dry
of the standard cotton programme at full load 91 %
Average condensation efficiency C
dry1/2
of the standard cotton programme at partial
load
91 %
The weighted condensation efficiency (C
t
) for the ‘standard cotton programme at full
and partial load'
91 %
The sound power level 64 dB(A)
Free Standing
OPERATING DATA
Memo
