P/N - - Rev CYRL SLKFTSINSTL FUL
1
®
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN DAMAGE TO
THE PRODUCT AND VOID THE FACTORY WARRANTY
Yale Assure Lock
®®
SL
Key Free Touchscreen Deadbolt
Installation and Programming Instructions
( 256/ 456)YRD YRD
x4
x2
x3
#8-32 x 5/16"
Machine screws
#7 wood & #8-32
machine x 20mm
Combination screws
M6x55mm
PPHMS
(2-1/4" )
Optional
Network Module
ORx2
M6x44mm
PPHMS
(1-3/4-2" )
OR
x2
M6x36mm
PPHMS
(1-3/8" )
Before you begin
for step-by-step installation
instructions & to register
your product
DOWNLOAD
THE BILT APP
