EN
1
DAILY REFERENCE
GUIDE
THANK YOU FOR PURCHASING A
WHIRLPOOL PRODUCT
To receive more comprehensive help and
support, please register your product at
www.whirlpool.com.au
WWW
You can download the Safety Instructions
and the Use and Care Guide by visiting our
website
http://docs.whirlpool.eu and following
the instructions on the back of this booklet.
Before using the appliance carefully read the
Health and Safety guide.
Before using the machine, it is imperative that the
transport bolts are removed.
For more detailed instructions on how to remove
them, see the Installation Guide.
PRODUCT DESCRIPTION
CONTROL PANEL
APPLIANCE
1. On/O button
(Reset/Drain if pressed
and held down)
2. Programme button
3. Colours 15° button
4. Fresh Care button
5. Dosing Aid button
6. Knob (Turn to select/
Press to conrm)
7. Start delay button
8. Temperature button
9. Spin Speed button
10. Options button
(Key lock if pressed and
held down)
11. Start / Pause button
12. Display
13. Programmes area
1. Worktop
2. Detergent dispenser
3. Control panel
4. Door handle
5. Door
6. Water lter/
emergency drain hose
(if available) - behind
plinth -
7. Plinth (removable)
8. Adjustable feet (4)
MAX
30’
1. 7.2.
13. 12.
6. 8.4. 10.3. 9.5. 11.
1.
3.
2.
5.
7.
6.
8.
4.
