User Manual Haier HDY-E60 Dryer

• Owner's manual - (English)

User Manual for Haier HDY-E60

Table of Contents

• OPERATING INSTRUCTIONS
• IDENTIFICATION OF PARTS
• OPERATING INSTRUCTIONS
• CONTROL PANEL
• CLEANING AND MAINTENANCE
• INSTALLATION INSTRUCTIONS
• UNPACKING YOUR DRYER
• FREE STANDING INVERTED WALL MOUNTING
• STACKING INSTALLATION
• CHANGE THE VENTING MODE
• INSTALL THE FLEXIBLE HOSE
• TROUBLESHOOTING AND SPECIFICATIONS
• TROUBLESHOOTING
• WIRING DIAGRAM
• SPECIFICATIONS

OPERATING INSTRUCTIONS

Attention:

• 1.Before operation, clean off any dust and dirt inside the drum of the dryer with a damp towel.
• 2.Clean off any debris on the lint filter and in the duct to increase the drying efficiency.

Turning on power

Before turning on the power of the dryer check whether the supply voltage is in accordance with the value indicated on the name plate.

Preparation of laundry load

- The dryer can only dry laundry which has been spun dry. Do not put in laundry which is still dripping wet or has excess water.

- Make sure all pockets are empty before placing laundry in the dryer.

- Pull up zippers, mend loosened fasteners and tie up ribbons to prevent the laundry from being entangled. If necessary, put small items in a laundry bag.

- To achieve a better drying result ensure the clothes are separated before loading into the dryer.

1. Power up

Insert the power plug into an appropriate power outlet that is properly installed and grounded. Operating power supply: 220-240V~50Hz.

2. Laundry loading

Open the door and load the laundry into the drum of the dryer. For a more energy efficient and better drying result, make sure the load has been spun dry. Try to loosen the load when placing in the dryer.

Note: Check labels on clothing before placing them in the dryer. Some articles are not suitable for machine dry. High temperature may damage the fabric.

3.Setting drying program

Turn the program knob to set your desired drying program.

4.Delay setting.

You may choose to start the dryer after a preset time. The delay range is between 0.5 and 24 hours.

5. Program operation

After a program is set, gently touch the “START/PAUSE” button to start the program. Drum reversal: The dryer is designed to rotate in each direction, clockwise and anti-clockwise in a certain period to minimize tangling and ensure clothes dry efficiently.
