L32H4
G4 SERIES
Contents
Warning...........................….....................………………………........................1
Safety instructions…………………………………….....…………....................5
Main Unit Control............................................................................................6
Connection and setup.................................................................................... 8
Getting Started………………………..……………...………………..….….......10
Installing Batteries in the Remote Control……..……………..…….................10
Using the Remote Control........…………………...........…………...................10
Battery Replacement...........……………………………………….……............10
Remote Control.…………………………………………………........................11
Basic Operation.............................................................................................13
Turning on and off the TV..............................................................................13
First Time Setup.............................................................................................13
Choosing a TV channel..................................................................................14
Changing the input source.............................................................................14
Volume adjustment........ ................. ............ ............ .......... ....... .......... .............14
Menu Operation.............................................................................................15
How to Navigate Menus.................................................................................15
Channel menu................................................................................................16
Picture menu..................................................................................................17
Sound menu..................................................................................................18
Timer menu...................................................................................................19
Lock menu.................................................................................................... 19
Option menu................................................................................................. 20
Hotel mode....................................................................................................24
USB Operation..............................................................................................24
Important Unique Buttons............................................................................28
Channel List.................................................................................................. 28
PROGRAMME GUIDE…………………………………………………………...28
Favorite List...................................................................................................29
Teletext...........................................................................................................30
Troubleshooting...........................................................................................31
Troubleshooting Guide……..………..............................……..………..…..…31
Maintenance................................................................................................32
PVR Function Operation Instruction............................................................. 21
Warning
DEAR CUSTOMER:
Before operating, please read all these safety and operating instructions completely and
then retain this manual for future reference.
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product.
REGULATORY INFORMATION
This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communication. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
a. Relocate the receiving antenna.
b. Increase the separation between the equipment and receiver.
c. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
d. Consult the dealer or experienced radio/TV technician for help.
CAUTION
※ Do not attempt to modify this product in any way without written authorization
from supplier. Unauthorized modification could void the user's authority to operate
this product.
※ Figures and illustrations in this User Manual are provided for reference only and
may differ from actual product appearance. Product design and specifications may be
changed without notice.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the products enclosure that may be of sufficient magnitude to constitute
a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
1
Warning
IMPORTANT WARNINGS AND CAUTIONS!
Electrical energy can perform many useful functions, but it can also cause
personal injuries and property damage if improperly handled. This product has
been engineered and manufactured with the highest priority on safety. BUT
IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE
HAZARD. In order to prevent potential danger, please observe the following
instructions when installing, operating and cleaning the product.
1. Attachments---Only use attachments/accessories specified by the manufacturer. Do
not use attachments not recommended by the manufacturer. Use of improper
attachments can result in accidents.
2. Water---
To reduce the risk of fire or electric shock, do not expose this apparatus to rain
or moisture. The apparatus shall not be exposed to dripping or splashing and that
objects filled with liquids, such as vases, shall not be placed on apparatus.
3. Fire or explosion---Do not use or store flammable or combustible materials near the
unit. Doing so may result in fire or explosion. Do not place any naked flame sources,
such as lit candles, cigarettes or incense sticks on top of the TV set.
Warning: To prevent the spread of fire, keep candles or other open flames away from
this product at all times.
4. Ventilation---When you install your TV, maintain a distance of at least 4 inches
between the TV and other objects (walls, cabinet sides, etc.) to ensure proper
ventilation. Failing to maintain proper ventilation may result in a fire or a problem with
the product caused by an increase in its internal temperature.
5.
This equipment is a Class Ⅱ
designed in such a way that it does not require a safety connection to electrical earth.
6. Power source---This product is intended to be supplied by a listed power supply
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company.
7. Overloading---Do not overload wall outlets, extension cables, or convenience
receptacles on other equipment as this can result in a risk of fire or electric shock.
8. Voltage---Before installing this TV set, make sure your outlet voltage corresponds to
the voltage stated on the appliance rating label.
9. Power plug --- Do not defeat the safety purpose of the polarized or grounding-type
plug. Most appliances recommend they be placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that appliance and has no additional outlets or
branch circuits.
or double insulated electrical appliance. It has been
2
Warning
10. The MAINS plug of the apparatus is used as the disconnect device, the disconnect
device shall remain readily operable.
11. Wall mounting---When mounting the product on a wall, be sure to install the product
according to the method recommended by the manufacturer. This is a safety feature.
12. Stand--- Do not place the product on an unstable trolley, stand, tripod or table. Placing
the product on an unstable base can cause the product to fall, resulting in serious
personal injuries as well as damage to the product.
Always place the TV on furniture that can safely support the TV. Make sure the ends of
the TV do not overhang the edge of the supporting furniture.
13. Entering of objects and liquids---Never insert an object into the product through
vents or openings. High voltage flows in the product, and inserting an object can cause
electric shock and/or short internal parts. For the same reason, do not spill water or
liquid on the product.
14. Damage requiring service--- This unit should only be serviced by an authorized and
properly trained technician. Opening the cover or other attempts by the user to service
this unit may result in serious injury or death from electrical shock, and may increase
the risk of fire.
15. Replacement parts---In case the product needs replacement parts, make sure that the
service person uses replacement parts specified by the manufacturer, or those with the
same characteristics and performance as the original parts. Use of unauthorized parts
can result in fire, electric shock and/or other danger.
16. Safety checks---Upon completion of service or repair work, request the service
technician to perform safety checks to ensure that the product is in proper operating
condition.
17. Children ---Do not allow young children to play with the plastic bag that came with the
television when you unpacked it. Failure to do so can result in suffocation, causing
injury.
18. Batteries---The batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
19. Antenna ---Install the antenna away from high-voltage power lines and communication
cables and make sure it is installed securely. If the antenna touches a power line,
contact with the antenna could result in fire, electric shock or serious injury.
20. Panel protection---
The panel used in this product is made of glass. Therefore, it can
break when the product is dropped or impacted upon by other objects. Be careful not to
be injured by broken glass pieces in case the panel breaks.
21.
Storage Temperature: -15℃ to 45℃ Storage Humidity: ≤90%
Operating Temperature: 5℃ to 35℃ Operating Humidity: ≤80%
※
~
: It Indicates alternating current.
※ : It Indicates direct current.
2.
3
Warning
a.
b.
c.
d.
e.
f.
g.
IMPORTANT INFORMATION
If a television is not positioned in a sufficiently stable location, it can be potentially
hazardous due to falling. Many injuries, particularly to children, can be avoided by
taking simple precautions such as:
Using cabinets or stands recommended by the manufacturer of the television.
Only using furniture that can safely support the television.
Ensuring the television is not overhanging the edge of the supporting furniture.
Not placing the television on tall furniture (for example, cupboards or bookcases)
without anchoring both the furniture and the television to a suitable support.
Not standing the televisions on cloth or other materials placed between the
television and supporting furniture.
Educating children about the dangers of climbing on furniture to reach the
television or its controls.
The television must to be positioned in a horizontal, stable, un-slippery plane to
avoid sliding.
4
Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
7. Do not block any ventilation
openings. Ventilation should not be
impeded by covering the ventilation
openings with items such as
newspapers, table-cloths, curtains
etc.
5. Do not use this apparatus near water.
8. Do not install near any heat source
such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.
6. Clean only with a dry cloth. Unplug this
product from the wall outlet before
cleaning. Do not use liquid cleaners or
aerosol cleaners.
9. Do not defeat the safety purpose of
the polarized or grounding type plug.
A polarized plug has two blades with
one wider than other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or
the third prong is provided for your
safety. When the provided plug does
not fit into your outlet, consult an
electrician for replacement of the
obsolete outlet.
5
Safety Instructions
NOTE:
※ Disposal of this product must be carried out in accordance to the regulations of
your local authority. Do not dispose of this product with general household
waste disposal.
※ Occasionally, a few non-active pixels may appear on the screen as a fixed
point of blue, green or red. Please note that this does not affect the
performance of your product.
※ Avoid touching the screen or holding your finger(s) against it for long periods of
time. Doing so may produce some temporary distortion effect on the screen.
※ It is not recommended to keep a certain still image displayed on the screen for
a long time as well as displaying extremely bright images on screen, reduce the
‘brightness’ and ‘contrast’ when displaying still images.
10. Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles,
and the point where they exit from
the apparatus.
13. For added protection for this
product during a lightning storm, or
when it is left unattended and
unused for long periods of time,
unplug it from the wall outlet and
disconnect the cable system.
11. Educate children about the dangers
of climbing on furniture to reach TV
controls.
14. Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such as
power supply cord or plug is
damaged, liquid has been spilled or
objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been
dropped.
12. When a cart is used, use caution
when moving the cart/apparatus
combination to avoid injury from
tip-over. Sudden stops, excessive
force and uneven floor surfaces can
cause the product to fall from the
trolley.
6
Main Unit Control
Front Panel
Remote sensor
Power Indicator
7
Main Unit Control
HDMI1supports ARC function).
Antenna input
5. USB port
1. HDMI1/2 port (
2.
NOTE: Input / Output connectivity options may change from model to model.
Rear & Sides Panel
Digital audio out
通孔
通孔
通孔
通孔
CH＋
CH－
VOL＋
VOL－
MENU
TV/AV
8
3.
4. AV input
1
2
3
4
5
Before the installation and use, please read carefully the relevant content in “Warning
and Safety instructions”.
HDMI: Support AV devices with an HDMI connector (such as set top box, DVD player,
digital TV set, etc.).HDMI is also called as high definition multimedia interface, and it
can transmit digital audio and video signal with one cable.
NOTE:
HDMI 1 (supports ARC function)
ARC: (Audio Return Channel) Adopted in TV output of digital audio, can be connected
to the device supporting ARC, transmit the TV sound to the device.
ANT: Used to connect the antenna and receive signals of the external antenna.
USB: Connect a USB Storage device and multimedia file playback.
NOTE:
※ The range of power input for the TV is 100-240V~ 50/60Hz; Do not connect the
TV power input port with the power cable out of the above range.
※ Before connecting to an external device, please firstly make sure that the TV set
and the external device have been turned off. When connecting, please make
reference to the interface name and the interface color to connect the signal cable.
※ Please hold the insulated part of the plug when you are unplugging the power cable,
do not touch directly the metallic part of the cable.
Connection Installation
Connection and setup
Digital Audio Output
port.
DIGITAL AUDIO OUT: Sending the TV's digital audio signal to external audio
equipment via the
AV IN: The output AV terminal of DVD can be connected with the AV input port of the
TV through AV cable.
9
:
Short press to turn on the TV, then short press to open the Source Menu,
Long press to turn off the TV.
NOTE:
If AV works as mini terminal, please choose to use a one-to-three audio & video
cable.
Getting Started
When using the remote control, aim it at remote sensor on the television. If there is an
object between the remote control and the remote sensor on the unit, the unit may not
operate.
Point the remote control at the REMOTE SENSOR located on the television.
When using this television in a very brightly lit area, the infrared REMOTE CONTROL
SENSOR may not work properly.
The recommended effective distance for using the remote control is about 7 meters.
1. Open the cover at the back of the remote control.
2. Install two AAA size batteries. Make sure to match
the “+” and “-” ends of the batteries with the
diagram inside the compartment.
3. Replace the cover.
You will need to install the batteries into the remote control to make it operate following
the instruction below.
When the batteries become weak, the operating distance of the remote control will be
greatly reduced and you will need to replace the batteries.
Notes on Using Batteries:
The use of the wrong type of batteries may cause chemical leakage and/or explosion.
Please note the following:
Always ensure that the batteries are inserted with the + and - terminals in the correct
direction as shown in the battery compartment.
Different types of batteries have different characteristics. Do not mix different types.
Do not mix old and new batteries. Mixing old and new batteries will shorten battery
life and/or cause chemical leakage.
Replace batteries as soon as they do not work.
Chemicals which leak from batteries may cause skin irritation. If any chemical matter
seeps out of the batteries, wipe it up immediately with a dry cloth.
The batteries may have a shorter life expectancy due to storage conditions. Remove
the batteries whenever you anticipate that the remote control will not be used for an
extended period.
The batteries (battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.
CAUTION:
It may result in an explosion if batteries are replaced incorrectly.
Only replace batteries with the same or equivalent type.
Installing Batteries in the Remote Control
Battery Replacement
Using the Remote Control
10
Remote Control
The buttons of the original remote control are as following:
Definition of the buttons on remote control:
1. : Power, Press to enter or exit the
standby mode.
.
: Mute or restore sound.
. NUMBER BUTTONS: Choose channels
or password importation.
. SOURCE: Press to select signal source
. MENU: Press to display/disappear the on
screen menus or to quit some operations.
.EXIT: Quit the current interface.
9. ▲/▼/◄/►: Press the direction buttons to
select menu options or settings.
ENTER: Select or confirm menu item.
1.
LIST: Press to call up the channel lis
t
.
Press again to exit it.
1.
CH/CH: Press to select channels in
ascending or descending order.
15.
VOL+/VOL-: Press to adjust the volu
me
level up or down.
16.
SLEEP: Press to set the sleep timer.
When the preset length of time has
passed, the TV set enters standby m
ode.
.
10.
EPG:Electronic Program Guide, use
in
the DTV mode.
: Return to last viewed program.
: Switch on/off the favorite programs
list.
12.
: Reveal the hidden information of
some teletext pages.
INDEX: Change the list by TIMER or
CHANNEL. (In PROGRAMME GUIDE
menu)
1.
1 2
3
4
5
6
7 8 9
0
VOL
CH
MENU
EXIT
DMP
EPG
LIST
SLEEP
SUBTITLE
INDEX
ENTER
STILL
SOURCE
INFO
RADIO
AUDIO
1
3
4
6
8
13
16
10
15
20
21
24
25
2
5
9
11
12
14
7
19
22
17
23
18
26
DMP:Press to switch to the Media source.
.
27
Press to enter the Recorded list. (In DTV
mode)
11
Remote Control
NOTE:
※ The buttons not mentioned here are not used.
※ All pictures in this manual are examples, only for reference, actual product may
differ from the pictures.
COLOR BUTTONS: Red/green/yellow/
blue key navigation link.
: Fast reverse (in Media mode)
Fast forward (in Media mode)
: Next (in Media mode)
: Change size of teletext screen in
display mode.
SUBTITLE: Enter the subtitle menu.
: Enter subtitle mode or subpage.
: Cancel the teletext but not to exit
teletext, press again show teletext.
: Press to select different images sizes.
: Previous (in Media mode)
19.
2.
2.
2.
2
.
.,NFO: display the current program
information on the screen.
: Go to the
index page.
1 2
3
4
5
6
7 8 9
0
VOL
CH
MENU
EXIT
DMP
EPG
LIST
SLEEP
SUBTITLE
INDEX
ENTER
STILL
SOURCE
INFO
RADIO
AUDIO
1
3
4
6
8
13
16
10
15
20
21
24
25
2
5
9
11
12
14
7
19
22
17
23
18
26
26. AUDIO(∞I/II): Press to select the NICAM
modes in Analog TV mode.Press to select
desired audio language in Digital TV
Mode.
27
: Hold the teletext page on display,
press again to release.
: Enter the Teletext, press again for MIX
mode, press this button again to exit.
: Play / Pause (in Media mode).
STILL: Press to hold the picture.
: Stop (in Media/PVR mode).
20.
2.
2.
RADIO: Press to interchange Radio and
program (In DTV mode). DTV programs
when there is Radio.
: Press
button to start recording. (In
DTV mode).
12
Basic Operation
• Turn on the TV
Connect the TV to your mains socket.
If TV has a power switch, turn it on firstly. In standby mode, press Power button on
the remote to turn on the TV.
• Turn off the TV
Press the button on the remote control to enter standby mode.
Do not leave your TV in standby mode for long periods of time. It is best to unplug the
power cord.
NOTE:
If there is an accident power off, the TV will be in standby mode automatically after
re-supply the power. To ensure the normal use of the TV, the frequent turning on and
off is forbidden, when there is an accident power off, it is recommended to unplug the
power cable from the power socket.
If this is the first time you run the TV, the Initial Setup Menu will appear in the picture,
and the items of this menu also exist in other menus, so you are able to change the
values after you set them up.
Tips: Make sure that the antenna connection is made.
■ Set you desired language
Press ▲/▼buttons to select the language to be used for menus and message.
■ Select your country
Press the ▲/▼ buttons to select the country you are living in, and then press the
button.
■
Select your time zone.
Press the ▲/▼ buttons to select a time zone, and then press the
■ Select your TV environment.
Press the ▲/▼ buttons to select the Home Mode or Store Mode and then press the
• Home is the recommended setting to produce the best energy efficiency. If you want
to set Store Mode, a message appears asking you to confirm your choice.
■ Auto Tuning
Press the button to start the auto searching.
First tuning DTV, press Menu and left arrow button to skip DTV tuning.
NOTE:
• If the TV doesn't receive any channels, please check your aerial connection or the
country you selected, and then try an auto search again.
• If the TV just receives some of the channels, it means the aerial's reception isn't good
enough and an antenna service is recommended
.
First Time Setup
Turning on and off the TV
►
button.
►
►
button.
►
13
Basic Operation
on the remote control.
Press CH to increase channel number.
Press CH to decrease channel number.
/
• Using 0-9 digital buttons.
You can select the channel number by pressing 0 to 9.
Additionally, when TV is in some mode, the TV will work in TV mode and play the
corresponding channel if any number button is pressed.
• Example
To select - channel (e.g. Channel 5): Press 5.
To select -- channel (e.g. Channel 20): Press 2 and 0 in a short time.
• Press the on the panel of TV or +/- on the remote control to adjust the volume.
• If you want to switch the sound OFF, press the
.
• You can release mute by pressing the
or increase the volume.
You can select the input source by pressing the SOURCE button on the remote control.
Press the▲/▼buttons to cycle through the input source, and press the ENTER button
to confirm your choice.
Changing the Input Source
Volume Adjustment
Choosing a TV channel
• Using the
on the panel of TV or CH/
Move
Select
ATV
HDMI1
HDMI2
DTV
Input Source
AV
USB
14
VOL+/-
Menu Operation
Before using the TV follow the steps below to learn how to navigate the menu in order
to select and adjust different functions. The access step may differ depending on the
selected menu.
1. Press the MENU button to display the main menu.
2. Press the ◄/►buttons to cycle through the main menu. You can choose between
Channel, Picture, Sound, Timer, Lock and Option.
3. Press the ENTER button to access the submenu page.
4. Press the ▲/▼ buttons to select the preferred option.
5. Press the ◄/► buttons to adjust the value.
6. Press the MENU button to return to the previous menu.
7. Press the EXIT button to exit the entire menu.
NOTE:
When an item in MENU is displayed gray, it means that the item is not available or
cannot be adjusted.
Some items in the menus may be hidden depending on modes or signal sources
used.
Buttons on the TV have the same function as corresponding buttons on the remote
control. If your remote control is lost or couldn’t work, you may use the buttons on
the TV to select menus. This manual focuses on operation of the remote control.
How to Navigate Menus
CHANNEL
PICTURE SOUND TIMER
LOCK OPTION
15
Menu Operation
.
■ Auto tuning: Select the ENTER button to start Auto Tuning.
1. Select the country and tune type for channels.
2. The TV will begin memorizing all of the available channels.
Once the progress bar is full, the found channels will be stored and the unit will
proceed to the search for TV, DTV and Radio.
If you press the MENU button in TV searching, the Channel Tuning will skip to DTV
searching as the suggestive picture shows.
■ DTV Manual Tuning: Press the ENTER button.
Press the ◄/►button to select channel, then press the ENTER button to search.
When a channel is found, the searching process will stop, the channel will be saved
with current channel number.
If the program is not your expected one, please press the ◄/►button to continue
the searching. Press the
EXIT button to exit.
.
Channel Menu
CHANNEL
DTV Manual Tuning
ATV Manual Tuning
Dynamic Rescan
Programme Edit
LCN Enable
On
Off
Auto Tuning
Move
Select
Return
■ ATV Manual Tuning: Manual store for ATV channels.
Storage To 1: Store the searched channel to 1
(you can adjust the channel number
by◄/►).
: Select the sound Standard.
: Select the Video Standard.
Current CH 1: Select the current channel.
Search: Press the ◄ button to search down from the current frequency, and press
the ► button to search up.
Fine-Tune: Adjust the frequency of the channel finely.
Press the red button to save it. Press the EXIT to exit.
■ LCN Enable
Press the ENTER button to select On or Off.
■
Switch the Dynamic Rescan function On or Off.
Sound_Standard
Video_Standard
Dynamic Rescan (In DTV mode)
Signal Information
■ Programme Edit
Press the▲/▼ buttons select the Programme Edit,
then press the ENTER button to enter sub-menu.
First press the▲/▼buttons to highlight the channel
you want to delete, skip, or Move, then:
Delete Favorite
2 ADOM TV
6 ROCK TV
4 4KIDS
5 DOMINION TV
3 JOY NEWS
7 CINE PLUS
1 JOY PRIME
8 RESER VE2
Programme Edit
1 / 2
9 OB TV
10 PENT TV
Page up Page down
OK
Return
Move
Skip
16
Menu Operation
Delete: Press the RED button to delete the channel.
Move: Press the YELLOW button to set the channel to moving state, and then
press the ▲/▼buttons to move it to the position you want to put.
Skip: Press the BLUE button to skip the channel.
(Your TV set will skip the channel
automatically when
using CH+/- to view the channels.)
Favorite: Press the
button to set the favorite
channel
.
(One or more groups can be
select.)
■ Picture Mode: You can select the type of picture which best corresponds to your
viewing requirements. Contrast, Brightness, Color, Sharpness, and Tint (NTSC)
can be adjusted when the picture mode is set to User.
– Contrast: Adjust the white level of the picture.
– Brightness: Adjust darkness of black sections in the picture.
– Color: Adjust the color intensity of the picture.
– Sharpness: Object edges are enhanced for picture detail.
– Tint: Adjust the hue of the picture. (valid only for NTSC signals).
■ Color Temperature: Select the color temperature that you feel comfortable.
■ Aspect Ratio: You can select the picture size which best corresponds to your
viewing requirements.
Picture Menu
Aspect Ratio
Dynamic Contrast
NR
OverScan
Picture Mode
Color Temperature
Home
Move
Select
Return
Picture Reset
16:9
Middle
Off
Normal
Standard
■ Signal Information(Only available when there is signal under DTV)
Press the▲/▼buttons to select the Signal Information, then press the ENTER
button to see the detail information.
■ Dynamic Contrast: Adjusts the contrast to the optimal level according to the
image's brightness.
■ NR: Reduces screen noise without compromising video quality.
NOTE:
The manufacture’s recommendation
mode is Home.
17
Menu Operation
■ Balance: Adjust the level of sound coming from the left and right speakers.
■ AVL(Auto Volume Level): Auto Volume automatically remains on the same level
of volume if you change programmes. Because each broadcasting station has its
own signal conditions, volume adjustment may be needed every time when the
channel is changed. This feature allows users to enjoy stable volume levels by
making automatic adjustments for each program.
■ Surround: The surround sound can be enabled or disabled according to the needs
to experience unique audio effects.
■ SPDIF Mode: You can select a desired SPDIF Output mode.
■ AD Switch (In DTV mode): * this is only available in some countries, mainly in
North America and Europe. This is an auxiliary audio function that provides an
additional audio track for visually challenged persons. This function handles the
Audio Stream for the AD (Audio Description), when it is sent along with the Main
audio from the broadcaster.
■ Audio Delay: Correct audio-video sync problems, when watching TV and when
listening to audio output using an external device such as an audio receiver
(0ms~250ms).
■ Sound Reset: Reset all sound settings to the factory defaults.
Sound Menu
■ Sound Mode: You can select a sound mode to suit your personal preferences.
Treble and Bass can be adjusted when the sound mode is set to User.
- Treble: Adjust the high frequency sounds.
- Bass: Adjust the low frequency sounds.
SOUND
AVL
Audio Delay
SPDIF Mode
AD Switch
Surround
Sound Reset
Sound Mode
Balance
0
Off
Off
PCM
Standard
Move
Select
Return
■ OverScan (In DTV mode): The picture reproduction rate is adjusted.
■ Picture Reset: Reset all picture settings to the factory defaults.
■ Game Mode (In HDMI mode): Switch Game Mode function On or Off.
■ PC Mode (In HDMI mode): Switch PC Mode function On or Off.
18
Menu Operation
■
Auto Sync: If set it to ON, the TV will sync the local clock according to the DTV
broadcasting time automatically.
■ Clock: Display either the DTV signal stream time or set the time manually.
■ Sleep Timer: Sleep Timer switches the TV to standby after a defined period of
time. To cancel the Sleep Timer, set to "Off ".
■ Auto Sleep: Select the Auto Sleep time you want. The TV will enter into standby
mode automatically when there is no any operation in set time.
■
No Signal Power Off: Switch No Signal Power Off function On or Off.
■ Time Zone: Select your time zone (When the Auto Sync is set On, the Time Zone
can be adjusted).
■
On-Screen Menu remains display after your last operation.
■ Lock System: The feature can prevent unauthorized operating the TV set, unless
entering 4-digit password.
The default password is 0000.
NOTE:
If you forget your password, the super password of 1225 still is valid.
■ Set Password:
Press the ENTER button to access the submenu.
Lock Menu
OSD Timeout: Select the time in seconds (15s, 30s, 60s, off) that you want the
Timer Menu
You can set your private password. Press the number buttons on the remote
control to set the new password. When the new password has been input twice,
TIME
Sleep Timer
No Signal Power Off
Time Zone
Auto Sleep
Auto Sync
Clock
Move
Select
Return
OSD Timeout
Off
On
00:25
4Hours
On
30S
LOCK
Block Program
Parent Lock
Lock System
Set Password
None
On
Move
Select
Return
1HZ6RXWK:DOHV GMT
the setting is finished successfully.
19
Menu Operation
■ Block Program (In ATV/DTV mode): Press the YELLOW button to lock the
available channel you want. Press the YELLOW button again to unlock it. To watch
a locked channel, enter your 4 digit password number when input screen displays.
■ Parent Lock (In DTV mode): This feature can prevent children watching adult’s
TV programmes, according to the rating limit set. This function appears according
to information from broadcasting station. Therefore if the signal has incorrect
information, this function does not operate.
■ Language: Select your preferred On Screen Display language.
■ Audio Languages: Select you’re preferred audio language. (Available for digital
channels if multiple audio languages are broadcasted.)
■ Subtitle: Switch the Subtitle function On or Off.
channels if multiple subtitle languages are broadcasted.)
■ Hearing Impaired:
When hearing Impaired is ON, the TV screen will give some
information to the people whose hearing are impaired when Hearing Impaired is
Off, the information will be hidden.
■ Country: Display the current country.
■ Environment Select:
Select the Environment Select Home or Store. Store mode
is the optimal setting for store environment.
■ Energy Saving: When the Environment Select is set Home, the Energy Saving
can be adjusted. Switch the Energy Saving function On or Off.
■ Health Remind: Switch the Health Remind function On or Off. While Health
Remind
■
sub-menu.
– ARC: To enable the audio through an AV receiver using HDMI (ARC). Press
ENTER buttons to switch the HDMI ARC function on or off.
– Auto Standby: When the user turns off the TV, all active CEC enabled devices
■ Subtitle Languages: Select your preferred subtitle Language. (Available for digital
Option Menu
: Press▲/▼buttons to select HDMI CEC, press ENTER to enter
HDMI_CEC
– : Press ENTER buttons to switch the HDMI CEC on or off.
HDMI_CEC
on the HDMI input will go to standby. Press ENTER buttons to switch the auto
standby function on or off.
OPTION
Subtitle
Environment Select
Hearing Impaired
Country
Subtitle Languages
Energy Saving
Language
Audio Languages
1 / 2
Off
English
English
Off
Home
English
Off
Move
Select
Return
OPTION
Power On Logo
Software Version
DivX(R) VOD
Installation Guide
Default
Software Update (USB)
Health Remind
HDMI_CEC
2 / 2
On
Off
Move
Select
Return
Australia
20
Menu Operation
connected to, will become the active input device for the TV.
– Device List: Display devices that are connected to TV.
■ Power On Logo: Switch the Power On Logo function On or Off.
■ Default: Restore the system settings to the factory default. When the restore is
complete, the TV will enter standby mode.
■ DivX(R) VOD: When entering this option, you can view the registration code
relevant information about the DivX
®.
■ Installation Guide: This is an installation guide to help you to setup the TV.
command the device to play, turn the TV on, and the HDMI input, that the device is
■ Software Update (USB): Update the software using the USB memory device.
Please be careful not to disconnect the power or remove the USB drive until
updates are complete.
■
Software Version: Display current software version information.
– Auto Power On: Pushing the "Play" button on the CEC enabled device will
How to use PVR function?
Preparing
Plug USB flash drive or USB hard disk into USB slot on the left hand side of the TV
set.
NOTE:
• USB disk should have capacity at least 512MB.
• USB device must support USB 2.0 high-speed specification.
Turn TV in to DTV mode by pressing SOURCE button on remote, the PVR
function can only be used in DTV mode;
Then press MENU button on the remote to bring the main menu up, press ◄/►
button to highlight Option menu, and then press the ENTER button;
Press ▲/▼ buttons to highlight PVR File System (In DTV mode), then press
ENTER button to go into submenu.
Setting
– Select Disk: Select a disk used for PVR.
NOTE:
• Some models have two USB input and several
disk can be used when two USB devices are
plugged in.
– Check PVR File System: Check the disk and
test the speed of the system.
– USB Disk: USB activated or not.
– Format: Format USB disk.
NOTE:
• Before formatting, please back up all important files.
• During the device formatting, do not disconnect the device or turn off the power. If
your USB device can't be formatted or fail to be checked by the system, it means
PVR Function Operation Instruction
USB Disk
Format
Time Shift Size
Speed
Check PVR File System Start
Free Record Limit 6 Hr.
Select Disk C:
MENU
21
Menu Operation
the device isn't compatible with the TV or is damaged. The larger USB device will
take longer time to format please be patient until the formatting finishes.
– Time Shift Size: You can select the memory size for Time Shift function.
– Speed: Press ENTER to check the speed of the storage device.
– Free Record Limit: Select the recording duration.
Recording
There are two types of recording: Instant Recording and Schedule Recording.
Instant Recording can record the current TV programmes, while Schedule Recording
can start at a specified time and record the TV programmes automatically on the day,
time and duration you choose.
– Instant Recording
Select the channel you want, then press
button to start recording.
Press
button to display/hide the recording menu.
It will keep recording until
(stop) button is pressed or the memory is full. A
menu will come up on the screen when TV start recording.
– Schedule Recording
The unit is able to do schedule recording when TV is turned on or in standby mode.
Press EPG button to bring up EPG menu.
Then press red button will active timer recording submenu. You can set up time
and record mode in the menu.
Press ▲/▼ button to highlight different setting and press ◄/► button to change
setting. After you have finished adjusting settings to desired options, press the
ENTER button to save the scheduled recording.
NOTE:
• You can set up several schedule programmes to record. To do this you will need
to press the yellow button in the EPG mode which will show you the entire list.
Different schedules should not overlap and there must be at least a 1 minute time
gap to set up between two schedules.
• When recording starts in standby mode, the front indicators will change color and
there will be no picture or sound from the unit. You can press
button to turn on
the screen.
8 MOVIN G1
Sto p
Pau se
Nex t 30sPre v.30 s
FFFB
Pla y
[00:0 0:10]
20.00
(0005:58:33 )
22
Menu Operation
Playing the Recorded Programmes
Option1:
After recording has finished, press the INDEX button to display the Recorded list.
Press the ▲/▼ button to select the recorded file, and then press the ENTER
button to play the file.
Press the red button to delete the file you no longer require.
Press the EXIT button to quit the menu.
Option2:
Also you can play the recorded programme in USB mode.
Press SOURCE button to display the input source menu.
Press ▲/▼ button to highlight USB, then press ENTER.
Use the ◄/► button to select MOVIE, then press ENTER.
Use the arrow buttons and ENTER button to enter the desired disk.
Use the arrow buttons and ENTER button to open the folder.
Use the arrow buttons to highlight the file. Use the ENTER button to mark or
unmark a file. Press
button to play the selected files. If no file is marked, all
the files in the folder will be played in sequence after you press
button.
Press the
button to stop the playing file.
Press the EXIT button to return to the USB main menu screen.
Time Shift Function
This function allows the TV to automatically record live TV and make it available for
viewing at any time. With the Time shift turned on, you may rewind normal TV
viewing at any time without missing any of the live broadcast.
Press the
button to activate Time Shift function. The TV stores the channel
from the point of view you want to record.
If an USB device dedicated to recording is disconnected, Time Shift files that were
saved will automatically be deleted.
[-00:00:06/00 :1 0: 00]
8 MOVING1
Stop
Pause
Next 30sPrev.30s
FFFB
Play
S
20.00
23
Menu Operation
enter into the Hotel Mode to adjust the relative settings.
Press the buttons to select Hotel Mode, and then
press button to set On or Off.
NOTE:
The following settings work only when Hotel Mode is
set to be On.
- On Source
Set the default signal source by pressing the ◄/► buttons.
(The default signal source will be displayed when the TV
is
turned
on.)
- On Channel
Set the default channel by pressing the ◄/► buttons.
(The default channel will be displayed when the TV is
turned
on.).
- On Volume
Set the default volume by pressing the ◄/► buttons. (The default volume is the
volume when the TV is turned on. Remember the default volume should be less than
the maximum volume).
Set max volume by pressing the ◄/► buttons. When the max volume is lower than
the default volume, the max volume is the priority.
- Export to USB
You can export all current channel information (including channel number, channel
name, frequency, etc.) into the U disk, as the channel information backup for this unit.
Hotel Mode
- Import from USB
If you cannot restore the initial channel information after sort, move, skip, lock etc.
operations, you can import the channel information from the USB.
Press the SOURCE button to display the Source Menu, then press 2012 to
Select
Return
Hotel Mode
On
On Channel
On Volume
On Source
2
60
Air
30
Import from USB
Export to USB
- Hotel Mode
- Max Volume
Max Volume
◄
/
►
◄/►
• First, insert a USB memory device into the USB port.
• Press the SOURCE button to call up the signal source selection menu. Use the ▲/▼
to highlight USB, and the press ENTER button to access the USB mode. (Alternatively,
Press the DMP button on the remote control to enter the USB mode)
• You may also use the signal source selection menu to exit from the USB mode.
NOTE:
Special USB device may be not or well supported.
USB max. Load: DC5V 500mA.
USB Operation
24
Menu Operation
• The formats supported
Media File Ext.
Codec
Remark
Video Audio
Movie
.mpeg, .mpg MPEG1/2,MPEG4,VC1
MPEG1/2
Layer1,MPEG1/2
Layer2,MPEG1/2
Layer3,AAC,AC3,
EAC3,HEAAC
1.Max resolution 1080P 30fps
2.MPEG-4 V2 not support
.vob, .dat MPEG1/2
.ts, .tp, .trp
MPEG1/2,H.264,MVC,
VC1,HEVC
.avi
MPEG1/2,MPEG4,
H.263, H.264, VC1,
XviD
MPEG1/2
Layer1,MPEG1/2
Layer2,MPEG1/2
Layer3,WMA,AAC,AC3
,HEAAC
.mp4，.mov
MPEG1/2,MPEG4,
D,H.263,H.264
HEVC
MPEG1/2
Layer3,AAC,AC3,
EAC3,HEAAC
.mkv
MPEG1/2,MPEG4,
HEVC,
MPEG1/2
Layer1,MPEG1/2
Layer2,MPEG1/2
Layer3,AAC,WMA,
AC3,HEAAC
.flv H.264,VC1
MPEG1/2
Layer3,AAC,HEAAC
.asf
MPEG1/2,MPEG4,
MPEG1/2
Layer1,MPEG1/2
Layer2,MPEG1/2
Layer3,WMA
H.263,H.264,
VC1,
H.264,VC1,
Music
.mp3 --
MPEG1/2 Layer1
MPEG1/2 Layer2
MPEG1/2 Layer3
Max Bit Rate 384Kbps
.m4a --
MPEG1/2 Layer3
AAC
.wav --
MPEG1/2 Layer1
MPEG1/2 Layer2
MPEG1/2 Layer3
IMA-ADPCM
.aac -- AAC
25
Menu Operation
.jpg,
.jpeg
Progressive JPEG Max Resolution: 1024
×
768
Baseline JPEG
Max Resolution:15360×8640
(1920x8 x 1080x8)
.bmp
--
Max Resolution: 9600
×
6400
.png
Non-Interlaced
Max Resolution: 9600
×
6400
Interlaced Max Resolution:1200×800
Text .txt
TM Player
File Size：Max 1MB
NOTE:
Special algorithm documents may not be or well be supported by the Media.
The Media
supports the format mentioned above, if the file format is not supported, change it to the
given format.
• Main Operating Interface
• Basic operation
1. Use the ◄/► buttons to select PHOTO, Music, Movie or TEXT. Press ENTER
button enter into sub-menu.
2. Use the arrow buttons and ENTER button to enter the desired disk. Press ENTER
to open the folder.
3. Use the arrow buttons to highlight the file. Use the ENTER button to mark or
unmark a file. Press
button to play the selected files. If no file is marked, all the
files in the folder will be played in sequence after you press
button.
4. Press the
to stop the playing files.
5. Press EXIT button to return to the previous menu and exit menu to quit.
C
1 / 1
Select
/
MXVLF
MRYLH
TEXT
When playing Photo files:
Press the INFO/ENTER button on the remote control to display the on-screen toolbar.
＊ Use the◄/► buttons, then press ENTER to select a function such as Previous,
Next, Rotate, Enlarge from the on-screen toolbar.
＊ Press
or EXIT buttons to exit playback & go back to file list page.
Pause Prev. Next
Stop
Repeat...
Play List
Info
Rotate Rotate Zoom In Zoom.. Move V...
Slide S...
26
Menu Operation
When playing Music files:
＊ Use the◄/► buttons, then press ENTER to select a function such as Previous,
Next, play, pause the on-screen toolbar.
＊ Press
or EXIT buttons to exit playback & go back to file list page.
When playing Movie files:
Press the INFO/ENTER button on the remote control to display the on-screen toolbar.
＊ Use the◄/► buttons, then press ENTER to select a function such as play, pause,
previous file, next file, from the on-screen toolbar.
＊
Press
or EXIT
buttons to exit playback & go back to file list page.
00:00:37 / 00:05:19
Pause
FB FF
Prev. Next
Stop
Repeat...
Play List
Info
Prev. Next
Stop
Repeat...
Play List
Info
Zoom In
Zoom..
Move V...
00:00:37 / 00:05:19
FB FF
Slow Fo.. Goto Ti..set A
Pause
When playing Text files:
Press the INFO/ENTER button on the remote control to display the on-screen toolbar.
＊ Use the◄/► buttons, then press ENTER to select a function such as play, pause,
previous file, next file, from the on-screen toolbar.
＊
Press
or EXIT buttons to exit playback & go back to file list page.
NOTE:
To play your multimedia files, make sure you have selected the correct icon in the
main media playback menu.
Prev. Next
Stop
Play List
Info
Prev Pa ... Next Pa...
27
Important Unique Buttons
Channel List
PROGRAMME GUIDE (In DTV mode)
Press EPG button to display the Programme Guide menu. This function let you know
the detailed information of the channel, indicating the time of the program playing. From
the Programme Guide it is possible to check the program information for the next eight
days (If the information is available from the
broadcaster).
• Press the▲/▼buttons to select a different channel in
the list and press ENTER to active the channel.
• Info: Press green button to see the detailed
information of the current channel.
• Schedule: Press the yellow button to display the
Schedule list.
Press LIST button to display the Channel List.
Press the ▲/▼ buttons to select the channel and press
ENTER to watch it.
button to page up or down the Channel list.
Press EXIT button to exit the channel list.
Press CH/
Index
Info
Schedule
Reminder
Programme Guide
TIMER
01 Jan 2017 00:32
2 ADOM TV
6 ROCK TV
4 4KIDS
5 DOMINION TV
3 JOY NEWS
7 CINE PLUS
1 JOY PRIME
NO Information
NO Information
NO Information
NO Information
NO Information
NO Information
8 RESER VE2
NO Information
NO Information
Move
Select
Move
Select
2 ADOM TV
6 ROCK TV
4 4KIDS
5 DOMINION TV
3 JOY NEWS
7 CINE PLUS
1 JOY PRIME
8 RESER VE2
Channel List
1 / 2
9 OB TV
10 PENT TV
Page up Page down
5HFRUGHU
• Recorder: Press the red/
button to set the
parameters for recording. You can choose the time of
the appointment to record you want, different
schedules should not overlap. The unit is able to do
schedule recording when TV is turning on or in
standby mode. When recording starts in standby
mode, there will be no picture or sound from the unit.
• Reminder: If you find the desired program which will be shown in the future. Press the
blue button to book program.
• Time/Channel: Press Index button to select the top of items, and press the ◄/►
button to change the list by Time or Channel.
• Press the EPG or EXIT button to exit
28
Important Unique Buttons
Favorite List
Press
button to display the Favorite List.
Press red, green, yellow, blue button to select the desired
favorite group.
Press the ▲/▼ buttons to select the channel and press
ENTER to watch it.
button to page up or down the Favorite list.
Press EXIT button to exit the Favorite List.
Press CH/
Move
Select
2 ADOM TV
6 ROCK TV
4 4KIDS
5 DOMINION TV
3 JOY NEWS
1 JOY PRIME
Favorite List
1 / 1
Page up Page down
Fav C
Fav B Fav A
Fav D
29
Teletext
• Display teletext
1. Select a TV station with a teletext signal.
2. Press the
button to enter teletext mode.
3. Press the
button 2nd to enter Mix mode, this function enables you to
superimpose the teletext page over the TV program.
4. Press the
button 3rd return or exit to the normal TV/DTV mode.
• Page selection
1. Enter the page number (three digits) using the number buttons. If you press a
wrong number during input, you must complete the three digit number and then
reenter the correct page number.
2. The button can be used to select the preceding or following page.
• Hold
You can press the
button to hold a page, and press it again to release the page.
• Index
Press the
i
button to enter the main index page directly.
• Enlarging Text
When a page is displayed, you can double the size of the text to make it easier to
read.
1. Press the
button to enlarge the top half of the page.
2. Press the
button again to enlarge the bottom half of the page.
3. Press the
button once more to return to the normal display.
• Reveal mode
You can display concealed teletext information (e.g. Answer to puzzles or riddles etc.)
by pressing
?
button. Press
?
button again to remove the information from the
display.
• Subpage
Some teletext may contain several sub-pages which are automatically paged in a
certain cycle by the TV station.
1. Yon can enter into a certain sub page by pressing the
button directly and
select the page number with number buttons. Enter the sub page number (e.g. 0003)
for the third sub page.
2. Press the button again to exit the sub page mode.
• Color buttons (Red, Green, Yellow and blue)
Press these buttons to access directly to the corresponding color pages displayed at
the lower part of the teletext screen.
Using the teletext feature
CH /CH
30
Troubleshooting Guide
When you meet the following common problems, you might diagnose and get the
solutions without contacting with the technicians.
Symptoms Possible Reason Solutions
No picture, no sound,
and no indicator light on
1.The power cord is not plugged in
2.The power is off
1.Plug the power cord in
2.Turn the power on
Picture and sound with
abnormity
1.Contrast, sharpness, and color
are set improperly
2.Color system is set improperly
3.Sound system is set improperly
1.Adjust the value of
Contrast, sharpness, and
colour
2.Set the Color system to
the country broadcasting
standard
3.Set the Sound system to
the country broadcasting
standard
Picture is spotted or with
snow
Signal source is low-grade or the
signal cord is in a lower quality
Use the qualified signal cord
No picture, no sound
and indicator light is
green/blue
Volume is in the minimum value or
TV is in mute mode.
Adjust the value of volume
The signal cable is not correctly
connected.
Connect the signal cable
correctly
Blue screen, AV is
displayed
There is no signal input or the video
cable is not connected or
incorrectly connected
Connect the video cable
correctly
No sound
There is no audio signal input or
audio cable is not connected
correctly
Connect the audio cable
correctly
HDMI source, with snow
pixel of full screen
The source generate is not
standard
Plug the HDMI cable again
Troubleshooting
31
The remote control does
not work
Batteries are improperly installed or
exhausted
1. Make sure the positive
and the negative
polarities are correct.
2.Check if there is a loose
contact between the
batteries and the springs
3.Replace the batteries
Troubleshooting Guide
Early malfunctions can be prevented. Careful and regular cleaning can extend the life
of your new TV. Be sure to turn the power off and unplug the power cord before you
begin any cleaning.
Cleaning the screen
1. Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in a
mixture of lukewarm water and a little fabric softener or dish washing detergent. Wring
the cloth until it’s almost dry, and then used it to wipe the screen.
2. Make sure the excess water is off the screen, and then let it air-dry before you turn
on your TV.
Cleaning the cabinet
To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth. Please be sure
not to use a wet cloth.
Extended Absence
If you expect to leave your TV dormant for a long time (such as a vacation), it’s a
good idea to unplug the power cord to protect against possible damage from
lightning or power surges.
Disposal of old electrical appliances
The European directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE), requires that old household electrical appliances must
not be disposed of in the normal unsorted municipal waste stream. Old
appliances must be collected separately in order to optimize the recovery
and recycling of the materials they contain, and reduce the impact on human
health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance, it must be separately
collected.
Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.
Maintenance
32
L32H4
G4 SERIES
