OWNER'S MANUAL
DISHWASHER
Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times.
LDT780#** LDP770*** LDT680*** LDP680*** LDPS684***
OPERATION.
Using the Appliance.
Before Using the Appliance.
• Read the Important Safety Instructions.
• Connect to the hot water supply only. The water supply temperature should be a minimum of 120°F (49°C) for better washing performance and shorter cycle time.
• Follow the instructions for loading the dishwasher to ensure effective cleaning.
• Remove insoluble items such as bones, toothpicks, and pieces of paper while loading the dishwasher.
When loading the dishwasher.
1. Only load items that are dishwasher-safe.
2. Remove solid, burned-on scraps from dishes prior to loading in the dishwasher.
3. Place items with deep dish bottoms at an angle to help water run off and speed the drying process.
NOTE.
• Do not load utensils that are not heat-resistant or have decorative metal trim.
Quick Start
1. Load the Dishes.
Scrape the dishes free of excess food, bones, and any other hard, non-soluble residue. Pull each rack out and load the dishes as described in this manual.
2. Measure the Detergent
Using the guidelines in this manual, fill the detergent cup with the recommended amount of detergent and close the lid. If a prewash is desired, the recess on top of the lid should also be filled with detergent.
3. Close the Door.
4. Turn on the Dishwasher
To turn on the display panel, press the Power button.
5. Check the Rinse Aid.
The Rinse Aid icon will flash if the level of rinse aid in the dishwasher is low. Add rinse aid if the level is low to maintain the effectiveness of the dry cycle.
LDT780#** LDP770***
LDT680*** LDP680***
LDPS684***
MFL69261722 Rev.09_042919
See other models: LSWC307ST LRE3061BD LSE4617ST LRE3194ST LWD3063ST
Copyright © 2018 - 2019 LG Electronics Inc. All Rights Reserved.
2 TABLE OF CONTENTS
3 PRODUCT FEATURES
4 SAFETY INSTRUCTIONS
4 IMPORTANT SAFETY INSTRUCTIONS
9 PRODUCT OVERVIEW
9 Exterior Parts 10 Interior Parts 10 Accessories
11 INSTALLATION
11 Installation Parts and Tools 12 Installation Overview 12 Product Dimensions 12 Product Specifications 13 Preparing Cabinet Opening 14 Preparing Water and Electrical Connections 15 Preparing Dishwasher 16 Attaching Installation Brackets 17 Sliding Dishwasher into Cabinet Opening 19 Connecting Water Supply Line and Power 21 Connecting Drain Hose 23 Leveling Dishwasher 25 Securing Dishwasher to Cabinet Opening 26 Final Installation Check
27 OPERATION
27 Using the Appliance 28 Control Panel 30 Cycles 31 Options 32 Cycle/Option Guide 33 Loading the Dishwasher 33 Loading the Lower Rack 35 Loading the Silverware Basket 36 Loading the Upper Rack 39 Loading the Cutlery Rack (On Some Models) 41 Adding Cleaning Agents
43 SMART FUNCTIONS
43 LG SmartThinQ Application 46 Smart DiagnosisTM Function
47 MAINTENANCE
47 Cleaning the Exterior 47 Cleaning the Interior 47 Seasonal Maintenance and Storage 48 Clogged Drain Air Gap or In-Sink Disposal 49 Cleaning the Filters 50 Cleaning the Spray Arms
51 TROUBLESHOOTING
51 FAQs: Frequently Asked Questions 53 User Support Videos 54 Before Calling for Service
58 LIMITED WARRANTY
58 FOR USA
63 LIMITED WARRANTY
63 FOR CANADA
3 PRODUCT FEATURES
PRODUCT FEATURES
QuadWashTM System
Multi-Motion lower spray arm shoots water in various directions and at optimized intensities to reach every area of the tub. This system provides more powerful and complete cleaning coverage.
Inverter Direct Drive Motor
LG's experience in motor technology results in extraordinary functionality, with advanced features like the Dual Zone option, whisper-quiet operation, energy efficiency, and durability. The simple design and high build quality of the motor make it so reliable that it's covered for 10 years under the warranty.
EasyRack Plus
This easy-to-use system of adjustable tines and rack height provides more flexibility and versatility when loading dishes of various shapes and sizes.
Hybrid Drying System
This efficient drying system does not use a heating element during the drying process resulting in superior energy efficiency and gentle care for dishes.
SmartThinQTM
Download the new LG smart phone app to set options, self-diagnose and troubleshoot problems with the appliance, and other useful features. This function uses Wi-Fi.
TrueSteamTM Technology
Tiny drops of purified water coat the surfaces of every dish from the steam that fills the tub, resulting in sparkling clean dishes.
4 SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages.
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages will follow the safety alert symbol and either the word WARNING or CAUTION. These words mean:
WARNING You may be killed or seriously injured if you do not follow instructions.
CAUTION You may be slightly injured or cause damage to the product if you do not follow instructions. All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what may happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons when using this product, follow basic precautions, including the fo
