• PRODUCT OVERVIEW
• Exterior Parts
• Interior Parts
• Accessories
• INSTALLATION
• Installation Parts and Tools
• Installation Overview
• Product Dimensions
• Product Specifications
• Final Installation Check
• OPERATION
• Using the Appliance
• Control Panel
• Cycles
• Options
• Cycle/Option Guide
• Loading the Dishwasher
• Adding Cleaning Agents
• SMART FUNCTIONS
• LG SmartThinQ Application
• Smart DiagnosisTM Function
• MAINTENANCE
• TROUBLESHOOTING
• FAQs: Frequently Asked Questions
• User Support Videos
• Before Calling for Service
• LIMITED WARRANTY
• FOR USA
• LIMITED WARRANTY

Preparing Cabinet Opening

This dishwasher is designed to fit a standard dishwasher opening. An opening may be needed on both sides to route plumbing and electrical connections.

• To ensure proper drainage, install the dishwasher no more than 12 ft. (3.65 m) from the sink.
• The location must have sufficient space for the dishwasher door to open easily and provide at least 0.1” (2 mm) between the dishwasher and the cabinet sides.
• If installing the dishwasher in a corner, leave a minimum of 2” (50 mm) between the dishwasher and the adjacent wall.
• The adjacent wall must be free of obstructions.

Electrical Connection

• Use a time-delay fuse or circuit breaker.
• Operate this appliance with the correct voltage as shown in this manual and on the rating plate.
• The wiring must be grounded properly. If in doubt, have it checked by a qualified electrician.
• Connect the appliance using 3-wires, including a ground wire.
• The appliance and outlet must be positioned so that the plug is easily accessible.
• Do not use an extension cable or adapter with this dishwasher.
• Do not overload the outlet with more than one appliance.
• The included 16AWG wire nuts should be used.
• It is the personal responsibility and obligation of the product owner to have a proper outlet installed by a qualified electrician.

OPERATION

• Repair or immediately replace all power supply lines that have become frayed or otherwise damaged. Do not use a power supply line that shows cracks or abrasion damage along its length or at either end.
• If you detect a strange sound, a chemical or burning smell, or smoke coming from the appliance, unplug it immediately, and contact an LG Electronics customer information center.
• Never unplug the appliance by pulling on the power supply line.
• Do not use an extension cable or adapter with this appliance.
• Do not grasp the power supply line or touch the appliance controls with wet hands.
• Do not modify or extend the power cable.
• If the product has been submerged, contact an LG Electronics customer information center for instructions before resuming use.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
• Keep the area underneath and around your appliances free of combustible materials (lint, paper, rags, etc.), gasoline, chemicals and other flammable vapors and liquids.

MAINTEANNCE

• Do not repair or replace any part of the appliance. All repairs and servicing must be performed by qualified service personnel unless specifically recommended in this Owner’s Manual. Use only authorized factory parts.
• Do not disassemble or repair the appliance by yourself.
• Remove any dust or foreign matter from the power supply line.
• Disconnect this appliance from the power supply before cleaning and attempting any user maintenance.
• Turning the controls to the OFF position does not disconnect this appliance from the power supply.
• Remove the door before the appliance is removed from service or discarded to avoid the danger of children or small animals getting trapped inside.
• Unplug the appliance before cleaning to avoid the risk of electric shock.
• Before discarding the appliance, cut off the power supply line and destroy the appliance's control panel.

Attaching Installation Brackets

• For countertops made of wood or other material that will not be damaged by drilling, use the metal installation brackets provided.
• For countertops made of granite, marble, or other materials that could be damaged by drilling, use the wood screws to attach the dishwasher to the cabinet. See installation instructions in Securing Dishwasher to Cabinet Opening.
