RCNE450K40ZW
RCNE450K40ZX
BBM450W
BBM450X
EN
Please read this guide first!
Dear Customer,
We'd like you to achieve the optimal efficiency from our product, which has been
manufactured in modern facilities with meticulous quality controls.
For this purpose, please fully read the user guide before using the product and keep
the guide as a reference source. If you turn the product over to another person,
provide this guide along with the product.
User guide ensure the quick and safe use of the product.
• Please read the user guide before installing and operating the product.
• Always observe the applicable safety instructions.
• Keep the user guide within easy reach for future use.
• Please read any other documents provided with the product.
Keep in mind that this user guide may apply to several product models. The guide
clearly indicates any variations of different models.
Symbols and Remarks
The following symbols are used in the user guide:
C
Important information and
useful tips.
A
Risk of life and property.
B
Risk of electric shock.
The product’s packaging
is made of recyclable ma-
terials, in accordance with
the National Environment
Legislation.
2 /32 EN
Refrigerator / User Guide
1 Safety and environment
instructions 3
1.1. General safety . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning . . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 For models with water dispenser 5
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . 6
1.3. Child safety . . . . . . . . . . . . . . . . . . . . . . 6
1.4. Compliance with WEEE Directive and
Disposing of the Waste Product. 7
1.5. Compliance with RoHS Directive 7
1.6. Package information . . . . . . . . . . . . 7
2 Your Refrigerator 8
3 Installation 9
4 Preparation 13
4.1. What to do for energy saving. . . 13
4.2. First Use . . . . . . . . . . . . . . . . . . . . . . . . 13
5 Using the product 14
5.1. Indicator panel. . . . . . . . . . . . . . . . . .14
5.2. Temperature adjustment button 16
5.3. Rapid freezing . . . . . . . . . . . . . . . . . .16
5.4. Vacation function . . . . . . . . . . . . . . 17
5.5. Indicator panel. . . . . . . . . . . . . . . . . .18
5.6. Ice bucket . . . . . . . . . . . . . . . . . . . . . . .22
5.7. Eggholder. . . . . . . . . . . . . . . . . . . . . . .22
5.8. Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.9. Vegetable bin . . . . . . . . . . . . . . . . . .22
5.10.Zero degree compartment. . . . .22
5.11. Moving door rack . . . . . . . . . . . . . . .23
5.12.Sliding storage box . . . . . . . . . . . . .23
5.13. Moisture controlled vegetable bin 24
5.14.Automatic ice machine . . . . . . . .24
5.15.Icematic and ice storage
container . . . . . . . . . . . . . . . . . . . . . . .25
5.16 Freezing fresh food. . . . . . . . . . . . .25
5.17. Recommendations for storing frozen
foods. . . . . . . . . . . . . . . . . . . . . . . . . . . .26
5.18 Deep freezer details. . . . . . . . . . . .26
5.19.Placing the food . . . . . . . . . . . . . . . .26
5.20.Door open alert . . . . . . . . . . . . . . . .27
5.21.Changing the opening direction of
the door. . . . . . . . . . . . . . . . . . . . . . . . .27
5.22 Interior light. . . . . . . . . . . . . . . . . . . . .27
6 Maintenance and cleaning 28
6.1. Avoiding bad odors . . . . . . . . . . . . .28
6.2. Protecting the plastic surfaces 28
6.3. Door Glasses . . . . . . . . . . . . . . . . . . .28
6 Maintenance and cleaning 29
7 Troubleshooting 30
Table of Contents
3/32 EN
Refrigerator / User Guide
This section provides
the safety instructions
necessary to prevent the
risk of injury and material
damage. Failure to observe
these instructions will
invalidate all types of
product warranty.
1.1. General safety
• This product should
not be used by
persons with physical,
sensory and mental
disabilities, without
sufficient knowledge
and experience or by
children. The device
can only be used by
such persons under
supervision and
instruction of a person
responsible for their
safety. Children should
not be allowed to play
with this device.
• In case of malfunction,
unplug the device.
• After unplugging, wait
at least 5 minutes before
plugging in again.
• Unplug the product
when not in use.
• Do not touch the plug
with wet hands! Do not
pull the cable to plug off,
always hold the plug.
• Wipe the power plug’s tip
with a dry cloth before
plugging in.
• Do not plug in the
refrigerator if the socket
is loose.
• Unplug the product
during installation,
maintenance, cleaning
and repair.
• If the product will not be
used for a while, unplug
the product and remove
any food inside.
• Do not use the product
when the compartment
with circuit cards located
on the upper back part
of the product (electrical
card box cover) (1) is
open.
1
1 Safety and environment instructions
Safety and environment instructions
4 /32 EN
Refrigerator / User Guide
1
• Do not use steam or
steamed cleaning
materials for cleaning
the refrigerator and
melting the ice inside.
Steam may contact the
electrified areas and
cause short circuit or
electric shock!
• Do not wash the
product by spraying
or pouring water on
it! Danger of electric
shock!
• In case of malfunction,
do not use the product,
as it may cause electric
shock. Contact the
authorized service
before doing anything.
• Plug the product into
an earthed socket.
Earthing must be
done by a qualified
electrician.
• If the product has LED
type lighting, contact
the authorized service
for replacing or in case
of any problem.
• Do not touch frozen
food with wet hands!
It may adhere to your
hands!
• Do not place liquids
in bottles and cans
into the freezer
compartment. They
may burst out!
• Place liquids in upright
position after tightly
closing the lid.
• Do not spray
flammable substances
near the product, as it
may burn or explode.
• Do not keep flammable
materials and products
with flammable gas
(sprays, etc.) in the
refrigerator.
• Do not place containers
holding liquids on
top of the product.
Splashing water on an
electrified part may
cause electric shock
and risk of fire.
Safety and environment instructions
5/32EN
Refrigerator / User Guide
• Exposing the product
to rain, snow, sunlight
and wind will cause
electrical danger. When
relocating the product,
do not pull by holding
the door handle. The
handle may come off.
• Take care to avoid
trapping any part of
your hands or body
in any of the moving
parts inside the
product.
• Do not step or lean on
the door, drawers and
similar parts of the
refrigerator. This will
cause the product to
fall down and cause
damage to the parts.
• Take care not to trap
the power cable.
1.1.1 HC warning
If the product comprises
a cooling system using
R600a gas, take care
to avoid damaging the
cooling system and its
pipe while using and
moving the product.
This gas is flammable.
If the cooling system
is damaged, keep the
product away from
sources of fire and
ventilate the room
immediately.
C
The label on the
inner left side
indicates the type
of gas used in the
product.
1.1.2 For models
with water
dispenser
• Pressure for cold water
inlet shall be maximum
120 psi (8 bar). If
your water pressure
exceeds 80 psi (5.5
bar), use a pressure
limiting valve in your
mains system. If you do
not know how to check
Safety and environment instructions
6 /32 EN
Refrigerator / User Guide
your water pressure,
ask for the help of a
professional plumber.
• If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment
in your installation.
Consult Professional
plumbers is you are not
sure that there is no
water hammer effect
in your installation.
• Do not install on the
hot water inlet. Take
precautions against
of the risk of freezing
of the hoses. Water
temperature operating
interval shall be 33°F
(0.6°C) minimum
and 100°F (38°C)
maximum.
• Use drinking water
only.
1.2. Intended use
• This product is
designed for home use.
It is not intended for
commercial use.
• The product should be
used to store food and
beverages only.
• Do not keep
sensitive products
requiring controlled
temperatures
(vaccines, heat
sensitive medication,
medical supplies, etc.)
in the refrigerator.
• The manufacturer
assumes no
responsibility for any
damage due to misuse
or mishandling.
1.3. Child safety
• Keep packaging
materials out of
children’s reach.
• Do not allow the
children to play with
the product.
• If the product’s door
comprises a lock,
keep the key out of
children’s reach.
Safety and environment instructions
7/32EN
Refrigerator / User Guide
1.4. Compliance
with WEEE Directive
and Disposing of
the Waste Product
This product complies with EU
WEEE Directive (2012/19/EU).
This product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high
quality parts and materials
which can be reused and
are suitable for recycling.
Do not dispose of the
waste product with normal
domestic and other wastes at the
end of its service life. Take it to the
collection center for the recycling of
electrical and electronic equipment.
Please consult your local authorities
to learn about these collection
centers.
1.5. Compliance with
RoHS Directive
• This product complies with EU
WEEE Directive (2011/65/EU).
It does not contain harmful and
prohibited materials specified in
the Directive.
1.6. Package
information
• Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging
materials together with the
domestic or other wastes. Take
them to the packaging material
collection points designated by the
local authorities.
8 /32 EN
Refrigerator / User Guide
1.
Cooler compartment door shelf
2.
Egg section
3.
Bottle shelf
4. Sliding storage box
5.
Adjustable legs
6.
Deep freezer compartment
7.
Quick freeze compartment
8.
Ice cube tray & Ice bank
9.
Vegetable bin
10.
Interior light
11.
Cooler compartment glass shelf
12.
Temperature adjustment button
13.
Cooler compartment
14.
Freezer compartment
2 Your Refrigerator
C
*optional: Pictures given in this manual are given as example figures and they
may not be exactly the same as your product. If your product does not comprise
the relevant parts, the information pertains to other models.
*1
*3
*3
2
*6
*7
5
5
*9
10
*12
13
14
*11
*8
*4
9/32 EN
Refrigerator / User Guide
3 Installation
3.1 Appropriate
installation location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
B
WARNING:Manufacturer
shall not be held liable for
damages that may arise
from procedures carried
out by unauthorized
persons.
B
WARNING:Product must
not be plugged in during
installation. Otherwise,
there is the risk of death or
serious injury!
B
WARNING:If the door
clearance of the room
where the product shall be
place is so tight to prevent
passing of the product,
remove the door of the
room and pass the product
through the door by
turning it to its side; if this
does not work, contact the
authorized service.
•Placetheproductonanevenfloor
surface to prevent jolts.
•Installtheproductatleast30cm
away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrical ovens.
•Productmustnotbesubjectedto
direct sun light and kept in humid
places.
•Appropriateairventilationmustbe
provided around your product in order
to achieve an efficient operation. If the
product is to be placed in a recess in
the wall, pay attention to leave at least
5 cm distance with the ceiling and side
walls.
•Donotinstalltheproductinplaces
where the temperature falls below
-5°C.
3.2 Installing the
plastic wedges
Plastic wedges supplied with the
product are used to create the distance
for the air circulation between the
product and the rear wall.
1.To install the wedges, remove the
screws on the product and use the
screws supplied together with the
wedges.
2.Insert the 2 plastic wedges onto the
rear ventilation cover as illustrated in
the figure.
Installation
10 /32 EN
Refrigerator / User Guide
3.3 Adjusting the feet
If the product stands unbalanced
after installation, adjust the feet on
the front by rotating them to the right
or left.
• Do not extension cords or cordless
multiple outlets between your product
and the wall outlet.
C
Hot Surface Warning!
Side walls of your product is
equipped with refrigerant
pipes to improve the cooling
system. Refrigerant with
high temperatures may
flow through these areas,
resulting in hot surfaces
on the side walls. This is
normal and does not need
any servicing. Please pay
attention while touching
these areas.
3.4 Electrical
connection
A
WARNING:Do not make
connections via extension
cables or multi-plugs.
B
WARNING:Damaged power
cable must be replaced by the
Authorized Service Agent.
C
If two coolers are to be
installed side by side, there
should be at least 4 cm
distance between them.
• Our company shall not be liable for
any damages that will arise when the
product is used without grounding and
electrical connection in accordance with
the national regulations.
• Power cable plug must be within easy
reach after installation.
• Connect your refrigerator to a grounded
outlet rated for a voltage value of 220-
240V /50 Hz. Outlet shall have 10 to
16A fuse.
Installation
11/32 EN
Refrigerator / User Guide
3.5. Reversing the doors
Proceed in numerical order .
45
11
10
3
9
9
2
1
5
6
7
8
12
13
14
15
17
18
19
16
21
4
20
20
Installation
12 /32 EN
Refrigerator / User Guide
3.6. Reversing the doors
Proceed in numerical order .
1
1
7
1
20
11
13
9
2
10
5
3
20
20
8
18
17
19
45 °
180°
(8) (13)
14
6
4
12
16
15
13/32 EN
Refrigerator / User Guide
4.1. What to do for
energy saving
A
Connecting the product to
electronic energy-saving systems
is harmful, as it may damage the
product.
• Do not keep the refrigerator doors
open for long periods.
• Do not place hot food or beverages
into the refrigerator.
• Do not overfill the refrigerator;
blocking the internal air flow will
reduce cooling capacity.
• In order to store the maximum
amount of food into the cooler
compartment of your refrigerator, you
should take out the upper drawers
and place it onto the glass rack. The
declared energy consumption of your
refrigerator was determined by taking
out the cooler, ice tray and upper
drawers in a way that will enable
maximum storage. Using the below
drawer when storing is strongly
recommended. Energy saving
function should be activated for best
energy consumption.
• You should not block the airflow by
putting food in front of the cooler
fan. A space of minimum 3cm must be
left in front of the protective fan wire
when placing food.
• Depending on the product’s features;
defrosting frozen foods in the cooler
compartment will ensure energy
saving and preserve food quality.
• Food should be stored using the
drawers in the cooler compartment
in order to ensure energy saving and
protect food in better conditions.
• Food packages should not be in direct
contact with the heat sensor located
in the cooler compartment. If they are
in contact with the sensor, energy
consumption of the appliance might
increase.
• Make sure the foods are not in
contact with the cooler compartment
temperature sensor described below.
4 Preparation
4.2. First Use
Before using your refrigerator, make sure
the necessary preparations are made
in line with the instructions in “Safety
and environment instructions” and
“Installation” sections.
• Keep the product running with no
food inside for 6 and do not open the
door, unless absolutely necessary.
C
A sound will be heard when the
compressor is engaged. It is
normal to hear sound even when
the compressor is inactive, due to
the compressed liquids and gasses
in the cooling system.
C
Front edges of the product might
heat up. This is normal. These
areas are designed to warm up in
order to prevent condensation.
C
In some models indicator panel
turns off automatically 5 minutes
after the door closes. It will be
reactivated when the door is open
or any button is pressed.
14 /32 EN
Refrigerator / User Guide
5.1. Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your product.
C
*optional: Pictures given in this manual are given as example figures and they
may not be exactly the same as your product. If your product does not comprise
the relevant parts, the information pertains to other models.
5 Usingtheproduct
45
7
6
8
9
1
2
3
1. Fridge Compartment
Indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature setting button
6. Compartment selection
button
7. Freezer compartment
indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
Using the product
15/32EN
Refrigerator / User Guide
1. Fridge compartment indicator
Fridge compartment light is
illuminated while the fridge
compartment temperature is set.
2. Error status indicator
If your refrigerator does not perform
enough cooling or in case of a sensor
fault, this indicator is activated.
When this indicator is activated,
“E” is displayed on the freezer
compartment temperature indicator,
and numbers such as “1,2,3...” are
displayed on the fridge compartment
temperature indicator. These
numbers on the indicator inform
service personnel about the error.
3. Temperature indicator
Indicates freezer, fridge compartment
temperature.
4. Vacation function button
Press on Vacation Button for 3
seconds to activate this function.
When the vacation function is
activated, “- -” is displayed on the
fridge compartment temperature
indicator and no active cooling
is performed on the fridge
compartment. It is not suitable
to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
button again.
5. Temperature setting button
Changes the temperature of the
relevant compartment between
-24°C... -18°C and 8°C...1°C.
6. Compartment selection button
Selection button: Press compartment
selection button to switch between
fridge and freezer compartments.
7. Freezer compartment indicator
Fridge compartment light is
illuminated while the freezer
compartment temperature is set.
8. Economy mode indicator
Indicates that the refrigerator
operates in energy saving mode.
This display shall be activated if the
freezer compartment temperature is
set to -18°C.
9. Vacation function indicator
Indicates that vacation is activated.
Using the product
16 /32EN
Refrigerator / User Guide
5.2. Temperature
adjustment button
Internal temperature of your refrigerator
varies depending on the following reasons:
• Seasonal temperatures,
• Opening the door frequently and
leaving it open for long periods,
• Meals put into the refrigerator
without being cooled to room
temperature, Location of the
refrigerator in the room (e.g.
exposed to sunshine).
• Internal temperature varying due to
these factors can be adjusted via the
adjustment button.
Numbers around the adjustment button
indicate temperature degrees as “°C”.
If the ambient temperature is 20°C, it
is recommended to use the refrigerator
temperature adjustment at 4°C. In other
ambient temperatures this value can be
customised.
5.3. Rapid freezing
If you want to freeze large amounts
of fresh food, switch the temperature
adjustment button to (
) position
before putting the food into the quick
freezing compartment.
It is recommended to keep the button
at this position for 24 hours to freeze
maximum amount of food indicated
as the freezing capacity. Pay special
attention not to mix food stolen as
frozen and fresh food.
C
*optional: Pictures given in this manual are given as example figures and they
may not be exactly the same as your product. If your product does not comprise
the relevant parts, the information pertains to other models.
Using the product
17/32EN
Refrigerator / User Guide
Remember to switch the temperature
adjustment button back to its
previous position.
5.4. Vacation function
If doors of the product is not ( )
opened for at least 12 hours after
adjusting the temperature setting
button to the highest, vacation
function is automatically activated.
Button setting must be changed to
cancel the function.
It is not recommended to store food
in the cooler compartment when
vacation function is activated.
• After setting is completed, you can
conceal the temperature setting
button by pressing it inside.
Using the product
18 /32EN
Refrigerator / User Guide
C
*Optional: The figures in this user guide are intended as drafts and may not
perfectly match your product. If your product does not comprise the relevant
parts, the information pertains to other models.
5.5. Indicator panel
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product. Just
press the inscriptions on relevant buttons for function settings.
1 2
3
45
6
789
*10
12
11
1. Power failure/High temperature /
error warning indicator
This indicator ( ) illuminates during
power failure, high temperature
failures and error warnings. During
sustained power failures, the
highest temperature that the freezer
compartment reaches will flash on the
digital display. After checking the food
located in the freezer compartment (
) press the alarm off button to clear the
warning.
Please refer to "remedies advised
for troubleshooting" section on
your manual if you observe that this
indicator is illuminated.
2. Energy saving function (display
off):
If the product doors are kept closed
for a long time energy saving
function is automatically activated
and energy saving symbol is
illuminated. ( )
Using the product
19/32EN
Refrigerator / User Guide
C
This function is not recalled
when power restores after a
power failure.
4. Fridge compartment
temperature setting button
Press this button to set the
temperature of the fridge
compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set
the fridge compartment temperature
to the desired value. ( )
5.Vacation Function
In order to activate vacation function,
press the this button (
) for 3
seconds, and the vacation mode
indicator (
) will be activated. When
the vacation function is activated,
“- -” is displayed on the fridge
compartment temperature indicator
and no active cooling is performed
on the fridge compartment. It is not
suitable to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
function button again.
6. Alarm off warning:
In case of power failure/high
temperature alarm, after checking
the food located in the freezer
compartment press the alarm off
button (
) to clear the warning.
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will
turn off. When the Energy Saving
function is activated, if any button is
pressed or the door is opened, energy
saving function will be canceled and
the symbols on display will return to
normal.
Energy saving function is activated
during delivery from factory and
cannot be canceled.
3.Quick fridge function
The button has two functions. To
activate or deactivate the quick cool
function press it briefly. Quick Cool
indicator will turn off and the product
will return to its normal settings. ( )
C
Use quick cooling function
when you want to quickly cool
the food placed in the fridge
compartment. If you want to
cool large amounts of fresh
food, activate this function
before putting the food into
the product.
C
If you do not cancel it, quick
cooling will cancel itself
automatically after 8 hours or
when the fridge compartment
reaches to the required
temperature.
C
If you press the quick cooling
button repeatedly with short
intervals, the electronic circuit
protection will be activated
and the compressor will not
start up immediately.
Using the product
20 /32EN
Refrigerator / User Guide
7. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key
lock symbol
(
) will light up and key lock mode
will be activated. Buttons will
not function if the Key lock mode
is active. Press key lock button
simultaneously for 3 seconds again.
Key lock symbol will turn off and the
key lock mode will be exited.
Press the
keylock button if you
want to prevent changing of
the temperature setting of the
refrigerator ( ).
8. Eco fuzzy
Press and hold eco fuzzy button
for 1 seconds to activate eco fuzzy
function. Refrigerator will start
operating in the most economic
mode at least 6 hours later and the
economic usage indicator will turn
on when the function is active (
). Press and hold eco fuzzy function
button for 3 seconds to deactivate
eco fuzzy function.
This indicator is illuminated after 6
hours when eco fuzzy is activated.
9. Freezer compartment
temperature setting button
Press this button to set the
temperature of the freezer
compartment to -18,-19,-20,-21,
-22, -23,-24, -18... respectively.
Press this button to set the freezer
compartment temperature to the
desired value.
( )
10. Icematic off indicator
Indicates whether the icematic is on
or off. (
)If On, then the icematic
is not operating. To operate the
icematic again press and hold the On-
Off button for 3 seconds.
C
Water flow from water tank
will stop when this function is
selected. However, ice made
previously can be taken from
the icematic.
11. Quick freeze function button/
icematic on-off button
Press this button to activate or
deactivate the quick freezing
function. When you activate the
function, the freezer compartment
will be cooled to a temperature lower
than the set value. ( )
To turn on and off the icematic press
and hold it for 3 seconds.
C
Use the quick freeze function
when you want to quickly
freeze the food placed in fridge
compartment. If you want to
freeze large amounts of fresh
food, activate this function
before putting the food into
the product.
C
If you do not cancel it, Quick
Freeze will cancel itself
automatically after 4 hours or
when the fridge compartment
reaches to the required
temperature.
C
This function is not recalled
when power restores after a
power failure.
Using the product
21/32EN
Refrigerator / User Guide
12. Economic usage indicator
Indicates that the product is running
in energy-efficient mode. ( )This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling
is being performed due to Eco-Extra
function.
C
Economic usage indicator is
turned off when quick cooling
or quick freeze functions are
selected.
Using the product
22 /32EN
Refrigerator / User Guide
5.6. Ice bucket
(Optional)
• Take the ice bucket from the
freezer compartment.
• Fill the ice bucket with water.
• Place the ice bucket into the
freezer compartment.
The ice will be ready after
approximately two hours. Take
the ice bucket from the freezer
compartment and bend in sightly
over the holder that you are going
to serve. Ice will easily pour into
the serving holder.
5.7. Eggholder
You can put the eggholder on the
door or body rack of your choice. If you
decide to put it on the body rack, it is
recommended to prefer the shelves
below as they are colder.
A
Do not put the eggholder into
the freezer compartment.
5.8. Fan
Fan was designed to distribute circu-
late the cold air inside your refrigera-
tor homogeneously. Operating time
of the fan might vary depending the
features of your product.
While in some products fan only oper-
ates with compressor, in others con-
trol system determines the operating
time based on the need for cooling.
5.9. Vegetable bin
(Optional)
Product’s vegetable bin is designed to
keep vegetables fresh by preserving
humidity. For this purpose, the overall
cold air circulation is intensified in the
vegetable bin.
5.10. Zero degree
compartment
(Optional)
Use this compartment to keep
delicatessen at lower temperatures
or meat products for immediate
consumption.
Zero degree compartment is the
coolest place where foods such
as dairy products, meat, fish and
chicken can be stored in ideal
storage conditions. Vegetables and/
or fruits should not be stored in this
compartment.
Using the product
23/32EN
Refrigerator / User Guide
5.11. Moving door rack
(Optional)
Moving door rack can be fixed in 3
different positions.
In order to move the rack, push the
buttons on the side evenly. Rack will
be movable.
Move the rack up or down.
When the rack is in the position that
you want, release the buttons. Rack
will be fixed again in the position
where you have released the
buttons.
5.12. Sliding
storage box
(Optional)
This accessory has been designed
to increase the usage volume of the
door racks.
Thanks to its ability to move
sideways, it enables you to easily
place long bottle, jar or boxes that you
put in the bottle rack below.
Using the product
24 /32EN
Refrigerator / User Guide
5.13. Moisture
controlled
vegetable bin
(Optional)
With moisture control feature,
moisture rates of vegetables and
fruits are kept under control and
ensures a longer freshness period for
foods.
It is recommended to store leafed
vegetables such as lettuce and
spinach and similar vegetables prone
to moisture loss not on their roots
but in horizontal position into the
vegetable bin as much as possible.
When placing the vegetables, place
heavy and hard vegetables at the
bottom and light and soft ones on the
top, taking into account the specific
weights of vegetables.
Do not leave vegetables in the
vegetable bin in plastic bags.
Leaving them in plastic bags causes
vegetables to rot in a short time. In
situations where contact with other
vegetables is not preferred, use
packaging materials such as paper
that has a certain porosity in terms of
hygiene.
Do not put fruits that have a high
ethylene gas production such as pear,
apricot, peach and particularly apple
in the same vegetable bin with other
vegetables and fruits. The ethylene
gas coming out of these fruits might
cause other vegetables and fruits
to mature faster and rot in a shorter
period of time.
5.14. Automatic
ice machine
(Optional)
Automatic ice machine enables you
to easily make ice in your refrigerator.
In order to obtain ice from the ice
machine, take out the water tank in
the cooler compartment, fill it with
water and fix it back.
First ice will be ready in about 2 hours
in the ice machine drawer in the
cooler compartment.
After placing the full water tank, you
can obtain about 60-70 cubes of ice
until it is fully empty.
If the water in the tank has waited for
2-3 weeks, it should be changed.
C
In products with automatic
ice machine, you might hear a
sound when pouring the ice.
This sound is normal and is not
a sign of failure.
Using the product
25/32EN
Refrigerator / User Guide
5.16. Freezing
fresh food
• To preserve food quality, the
food items placed in the freezer
compartment must be frozen as
quickly as possible, use the rapid
freezing for this.
• Freezing the food items when
fresh will extend the storage time
in the freezer compartment.
• Pack the food items in air-tight
packs and seal tightly.
• Make sure the food items are
packed before putting in the
freezer. Use freezer holders, tinfoil
and damp-proof paper, plastic
bag or similar packaging materials
instead of traditional packaging
paper.
C
Ice in the freezing
compartment thaws
automatically.
• Mark each food pack by writing
the date on the package before
freezing. This will allow you to
determine the freshness of each
pack every time the freezer is
opened. Keep the earlier food
items in the front to ensure they
are used first.
• Frozen food items must be used
immediately after defrosting and
should not be frozen again.
• Do not free large quantities of
food at once.
5.15. Icematic and ice
storage container
*optional
Using the Icematic
Fill the Icematic with water and place
it into its seat. Your ice will be ready
approximately in two hours. Do not
remove the Icematic from its seating
to take ice.
Turn the knobs on the ice reservoirs
clockwise by 90 degrees.
Ice cubes in the reservoirs will fall
down into the ice storage container
below.
You may take out the ice storage
container and serve the ice cubes.
If you wish, you may keep the ice
cubes in the ice storage container.
Ice storage container
Ice storage container is only intended
for accumulating the ice cubes. Do
not put water in it. Otherwise, it will
break.
Using the product
26 /32EN
Refrigerator / User Guide
Freezer
Compartment
Temperature
Setting
Cooler
Compartment
Temperature
Setting
Details
-18°C 4°C This is the default, recommended setting.
-20,-22 or
-24°C
4°C
These settings are recommended for ambient
temperatures exceeding 30°C.
Quick
Freeze
4°C
Use when you want to freeze your food in a short
time. When the process ends, the product will
regain its position.
-18°C or
colder
2°C
Use these settings if you believe the cooler
compartment is not cold enough due to ambient
temperature or frequently opening the door.
5.17. Recommendations for storing frozen foods
The compartment must be set to at least -18°C.
1.
Place the food items in the freezer as quickly as possible to avoid defrosting.
2.
Before freezing, check the “Expiry Date” on the package to make sure it is not
expired.
3.
Make sure the food’s packaging is not damaged.
5.18. Deep freezer details
As per the IEC 62552 standards, the freezer must have the capacity to freeze
4,5 kg of food items at -18°C or lower temperatures in 24 hours for each 100
litres of freezer compartment volume.
Food items can only be preserved for extended periods at or below
temperature of -18°C .
You can keep the foods fresh for months (in deep freezer at or below
temperatures of 18°C ).
The food items to be frozen must not contact the already-frozen food inside to
avoid partial defrosting.
Boil the vegetables and filter the water to extend the frozen storage time.
Place the food in air-tight packages after filtering and place in the freezer.
Bananas, tomatoes, lettuce, celery, boiled eggs, potatoes and similar food
items should not be frozen. In case this food rots, only nutritional values and
eating qualities will be negatively affected. A rotting threatening human
health is not in question.
5.19. Placing the food
Freezer
compartment
shelves
Various frozen goods
including meat, fish, ice
cream, vegetables etc.
Using the product
27/32EN
Refrigerator / User Guide
Cooler
compartment
shelves
Food items inside pots,
capped plate and capped
cases, eggs (in capped
case)
Cooler
compartment
door shelves
Small and packed food or
beverages
Vegetable bin Fruits and vegetables
Fresh food
compartment
Delicatessen (breakfast
food, meat products to be
consumed in short notice)
5.20. Door open alert
(Optional)
An audible alert will be heard if the
product's door remains open for at
least 1 minute. The audible alert will
stop when the door is closed or any
button on the display (if available) is
pressed.
Door open alert is indicated to the
user both audibly and visually. Interior
lighting will turn of if the warning
continues for 10 min.
5.21. Changing the
opening direction
of the door
You can change the direction of ope-
ning of your refrigerator depending
on the location where you use it.
When you need this, consult the clo-
sest Authorized Service.
The explanation above is a general
statement. You should check the war-
ning tag located inside the product
package about the changeability of
direction of the door.
5.22. Interior light
Interior light uses a LED type lamp.
Contact the authorized service for any
problems with this lamp.
Lamp(s) used in this appliance cannot
be used for house lighting. Intended
use of this lamp is to help the user
place food into the refrigerator /
freezer safely and comfortably.
28 /32 EN
Refrigerator / User Guide
6 Maintenance and cleaning
Service life of the product is increase if it
is regularly cleaned
B
WARNING:First unplug the product
before cleaning your refrigerator.
•
Never use any sharp and abrasive
tools, soap, household cleaners,
detergent and wax polish for cleaning.
•
Dissolve one teaspoon of carbonate
in half liter of water. Soak a cloth with
the solution and wrung it thoroughly.
Wipe the interior of the appliance with
this cloth and the dry thoroughly.
•
Make sure that no water enters the
lamp housing and other electrical
items.
•
Clean the door with a damp cloth.
To remove door and body shelves,
remove all of its contents. Remove
door shelves by moving them
upwards. After cleaning, slide them
from top to bottom to install.
•
Never use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
• Do not use sharp, abrasive tools,
soap, household cleaning agents,
detergents, kerosene, fuel oil,
varnish etc. to prevent removal and
deformation of the prints on the
plastic part. Use lukewarm water and
a soft cloth for cleaning and then
wipe it dry.
6.1. Avoiding bad odors
Materials that may cause odor are not
used in the production of our appliances.
However, due to inappropriate food
preserving conditions and not cleaning
the inner surface of the appliance as
required can bring forth the problem of
odor.
Therefore, clean the refrigerator with
carbonate dissolved in water every 15
days.
•
Keep the food in closed containers.
Microorganisms spreading out from
uncovered containers can cause
unpleasant odours.
•
Never keep the food that have expired
best before dates and spoiled in the
refrigerator.
6.2. Protecting the
plastic surfaces
Clean with arm water immediately as the
oil may cause damage on the surface
when it is poured on plastic surfaces.
6.3. Door Glasses
Remove the protective foil on the
glasses.
There is a coating on the surface of
the glasses.This coating minimizes the
stain build-up and helps to remove the
possible stains and dirt easily.Glasses
that are not protected with such a
coating may be subject to persistent
binding of air or water based organic or
inorganic dirt such as limescale, mineral
salts, unburned hydrocarbons, metal
oxides and silicones that can easily and
quickly cause stains or material damage.
Keeping the glass clean becomes too
difficult despite the regular cleaning.
Consequently, the appearance and the
transparency of the glass deteriorates.
Harsh and corrosive cleaning methods
and compounds will intensify these
defects and speed up the deterioration
process.
29/32 EN
Refrigerator / User Guide
Water-based cleaning products that are
not alkaline and corrosive must be used
for regular cleaning purposes.
Non-alkaline and non-corrosive
materials must be used for cleaning so
that the service life of this coating lasts
for a long time.
These glasses are tempered to increase
their durability against impacts and
breaking.A safety film is also applied to
their rear surfaces as an extra safety
measure in order to prevent them from
causing damage to their surrounding in
case of a breakage.
*Alkali is a base that forms hydroxide
ions (OH¯) when it is dissolved in water.
Li (Lithium), Na (Sodium), K (Potassium)
Rb (Rubidium), Cs (Cesium) and artificial
and radioactive Fr (Fan-sium) metals are
called ALKALI METALS.
6 Maintenance and cleaning
30 /32 EN
Refrigerator / User Guide
7 Troubleshooting
Check this list before contacting the service. Doing so will save you time and money.
This list includes frequent complaints that are not related to faulty workmanship or
materials. Certain features mentioned herein may not apply to your product.
The refrigerator is not working.
• The power plug is not fully engaged. >>> Push the plug completely into the
socket.
• The fuse connected to the socket powering the product or the main fuse is
blown. >>> Check the fuses.
Condensation on the side wall of the cooler compartment (MULTI ZONE, COOL,
CONTROL and FLEXI ZONE).
• The environment is too cold. >> Do not install the product in environments with
temperatures below -5°C.
• The door is opened too frequently >>> Take care not to open the product’s
door too frequently.
• The environment is too humid. >>> Do not install the product in humid
environments.
• Foods containing liquids are kept in unsealed holders. >>> Keep the foods
containing liquids in sealed holders.
• The product’s door is left open. >>> Do not keep the product’s door open for
long periods.
• The thermostat is set to too low temperature. >>> Set the thermostat to
appropriate temperature.
Compressor is not working.
• In case of sudden power failure or pulling the power plug off and putting back
on, the gas pressure in the product’s cooling system is not balanced, which
triggers the compressor thermic safeguard. The product will restart after
approximately 6 minutes. If the product does not restart after this period,
contact the Authorised Service Agent.
• Defrosting is active. >>> This is normal for a fully-automatic defrosting
product. The defrosting is carried out periodically.
• The product is not plugged in. >>> Make sure the power cord is plugged in.
• The temperature setting is incorrect. >>> Select the appropriate temperature
setting.
• The power is out. >>> The product will continue to operate normally once the
power is restored.
The refrigerator's operating noise is increasing while in use.
• The product’s operating performance may vary depending on the ambient
temperature variations. This is normal and not a malfunction.
The refrigerator runs too often or for too long.
31/32 EN
Refrigerator / User Guide
Troubleshooting
• The new product may be larger than your previous one. Larger products will run
for longer periods.
• The room temperature may be high. >>> The product will normally run for long
periods in higher room temperature.
• The product may have been recently plugged in or a new food item is placed
inside. >>> The product will take longer to reach the set temperature when
recently plugged in or a new food item is placed inside. This is normal
• Large quantities of hot food may have been recently placed into the product.
>>> Do not place hot food into the product.
• The doors were opened frequently or kept open for long periods. >>> The
warm air moving inside will cause the product to run longer. Do not open the
doors too frequently.
• The freezer or cooler door may be ajar. >>> Check that the doors are fully
closed.
• The product may be set to temperature too low. >>> Set the temperature to a
higher degree and wait for the product to reach the adjusted temperature.
• The cooler or freezer door washer may be dirty, worn out, broken or not
properly settled. >>> Clean or replace the washer. Damaged / torn door
washer will cause the product to run for longer periods to preserve the current
temperature.
The freezer temperature is very low, but the cooler temperature is adequate.
• The freezer compartment temperature is set to a very low degree. >>> Set the
freezer compartment temperature to a higher degree and check again.
The cooler temperature is very low, but the freezer temperature is adequate.
• The cooler compartment temperature is set to a very low degree. >>> Set the
freezer compartment temperature to a higher degree and check again.
The food items kept in cooler compartment drawers are frozen.
• The cooler compartment temperature is set to a very low degree. >>> Set the
freezer compartment temperature to a higher degree and check again.
The temperature in the cooler or the freezer is too high.
• The cooler compartment temperature is set to a very high degree. >>> Cooler
compartment temperature setting has an effect on the freezer compartment
temperature. Change the temperature of the cooler or freezer compartment
and wait until the temperature of the related compartments come to the
adequate level.
• The doors were opened frequently or kept open for long periods. >>> Do not
open the doors too frequently.
• The door may be ajar. >>> Fully close the door.
• The product may have been recently plugged in or a new food item is placed
inside. >>> This is normal. The product will take longer to reach the set
temperature when recently plugged in or a new food item is placed inside.
• Large quantities of hot food may have been recently placed into the product.
>>> Do not place hot food into the product.
Shaking or noise.
32 /32 EN
Refrigerator / User Guide
Troubleshooting
• The ground is not level or durable. >>> If the product is shaking when moved
slowly, adjust the stands to balance the product. Also make sure the ground is
sufficiently durable to bear the product.
• Any items placed on the product may cause noise. >>> Remove any items
placed on the product.
The product is making noise of liquid flowing, spraying etc.
• The product’s operating principles involve liquid and gas flows. >>> This is
normal and not a malfunction.
There is sound of wind blowing coming from the product.
• The product uses a fan for the cooling process. This is normal and not a
malfunction.
There is condensation on the product's internal walls.
• Hot or humid weather will increase icing and condensation. This is normal and
not a malfunction.
• The doors were opened frequently or kept open for long periods. >>> Do not
open the doors too frequently; if open, close the door.
• The door may be ajar. >>> Fully close the door.
There is condensation on the product's exterior or between the doors.
• The ambient weather may be humid, this is quite normal in humid weather. >>>
The condensation will dissipate when the humidity is reduced.
The interior smells bad.
• The product is not cleaned regularly. >>> Clean the interior regularly using
sponge, warm water and carbonated water.
• Certain holders and packaging materials may cause odour. >>> Use holders and
packaging materials without free of odour.
• The foods were placed in unsealed holders. >>> Keep the foods in sealed
holders. Microorganisms may spread out of unsealed food items and cause
malodour.
• Remove any expired or spoilt foods from the product.
The door is not closing.
• Food packages may be blocking the door. >>> Relocate any items blocking the
doors.
• The product is not standing in full upright position on the ground. >>> Adjust
the stands to balance the product.
• The ground is not level or durable. >>> Make sure the ground is level and
sufficiently durable to bear the product.
The vegetable bin is jammed.
• The food items may be in contact with the upper section of the drawer. >>>
Reorganize the food items in the drawer.
A
WARNING:If the problem persists after following the instructions in this
section, contact your vendor or an Authorised Service Agent. Do not try to repair
the product.
www.beko.com.tr
www.beko.com
.au
57 5754 0000/AK
EN
