*BBMB445
Refrigerator
User manual
EN
5774451172/AA
1.Refrigerator
2.SAFETY INSTRUCTIONS
2.1 Intention of Use
2.2 Safety of Children,Vulnerable
Persons and Pets
2.3 Electrical Safety
2.4 Handling Safety
2.5 Installation Safety
2.6 Operational Safety
2.7 Food Storage Safety
2.8 Maintenance and Cleaning Safety
2.9 Disposal of the Old Product
3.ENVIRONMENTAL INSTRUCTIONS
3.1 Compliance with WEEE regulations
and Waste Disposal
3.2 Packaging Information
4.INSTALLATION
4.1 Before Installation
4.2 Appropriate installation location
4.3 Inset installations -Adjusting the Legs
4.4 Electrical connection
4.5 Adjusting the feet
4.6 Illumination lamp
4.7 Door/Drawer Open Warning
4.8 Transportation of the product
1
1
1
1
2
2
2
3
4
4
5
5
5
5
6
7
7
7
7
8
8
8
8
5.PREPARATION
5.1 What To Do For Energy Saving
5.2 First Use
5.3 Climate Class and Definitions
6.USING THE CONTROLS
6.1 Indicator panel
7.FOOD STORAGE AND COMPARTMENT
USAGE
7.1 Freezing fresh food
7.2 Recommendations for preserving frozen
food
7.3 Placing the food
7.4 Deep-freeze information
7.5 Removing door shelves
7.6 Glass shelves
7.7 Crisper bins (in some models)
7.8 Deli Drawer
7.9 Humidity controlled crisper (EverFresh+)
7.10 Harvest Fresh
7.11 Odor filter
8.MAINTENANCE AND CLEANING
9.TROUBLESHOOTING
10
10
10
10
11
11
12
12
12
12
12
12
13
13
13
13
13
13
14
15
Please read this user manual First!
Dear Customer
Please read this manual before using the product.
Thank you for choosing this Arçelik product. We would like you to achieve the optimal efficiency from
this high quality product which has been manufactured with state of the art technology. To do this,
carefully read this manual and any other documentation provided before using the product and keep it
as a reference. Heed all information and warnings in the user manual. This way, you will protect
yourself and your product against the dangers that may occur.
Keep the user manual. Include this manual with the unit if you hand it over to someone else.
Content
The following symbols are used in the user manual:
Hazard that may result in death or injury.
Important information or useful tips on operation.
Risk of electric shock.
The product’s packaging is made of recyclable materials, in accordance with the National
Environment Legislation.
NOTICE A hazard that may cause material damage to the product or its surroundings
This section includes the safety instructions
necessary to prevent the risk of personal injury
or material damage.
Our company shall not be held responsible for
damages that may occur if these instructions are
not observed.
2.1 Intention of Use
This product is not suitable for commercial
use and should not be used for a purpose other
than its intended use.
This product is intended for operating
interiors, such as households or similar.
For example; In the staff kitchens of the stores,
offices and other working environments, In farm
houses, In the units of hotels, motels or other
resting facilities that are used by the customers,
In hostels, or similar environments, In catering
services and similar non-retail applications.
This product shall not be used in open or
enclosed external environments such as
vessels, camper vans, balconies or terraces.
Exposing the product to rain, snow, sunlight and
wind may cause risk of fire.
2.2 Safety of Children,Vulnerable Persons
and Pets
This product may be used by children aged 8
years and older and persons with underdevel-
oped physical, sensory or mental capabilities or
lack of experience and knowledge if they are
being supervised or have been given instruction
concerning use of the appliance
in a safe way and the
hazards involved.
Children between 3 and 8 years are allowed to
put and take out food into/from the cooler
product.
Electrical products are dangerous for children
and pets. Children and pets must not play with,
climb on, or enter the product.
Cleaning and user maintenance should not be
performed by children unless there is someone
overseeing them.
Keep the packaging materials away from
children. Risk of injury and suffocation.
Before disposing of old products that shall not be
used any more:
1. Unplug the power cord from the mains socket.
2. Cut the power cable and remove it from the
appliance together with the plug.
EN 1
1. Fridge Compartment
2. Freezer Compartment
3. *Wifi Board
4. Celing Display
5. Adjustable Glass Shelf
6. *Wine Shelf
7. Crisper
8. Chiller
9. Half Door Shelf
10. Gallon Door Shelf
11. Top Drawer
12. Bottom Drawer
13. *Ice box / Ice-Making
(in Freezer Compartment)
*Option
1.REFRIGERATOR
2.SAFETY INSTRUCTIONS
Figures that take place in this instruction manual are schematic and may not
correspond exactly withyour product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
Installation and repair operations shall always be
performed by authorized service.
Use original spare parts and accessories only.
Do not repair or replace any component of the
product unless it is clearly specified in the user
manual.
Do not perform any modifications on the product.
1
*3
4
5
7
8
9
10
11
12
*13
*6
2
2 EN
2.SAFETY INSTRUCTIONS
3. Do not remove the racks and drawers from the
product to prevent children from getting inside the
appliance.
4. Remove the doors.
5. Store the product so that it shall not be tipped
over.
6. Do not allow children to play with the scrapped
product.
Do not dispose of the product by throwing it into
fire. Risk of explosion.
If there is a lock available on the product’s door,
keep the key out of children's reach.
2.3 Electrical Safety
The product shall not be plugged into the outlet
during installation, maintenance, cleaning, repair,
and transportation operations.
If the power the cable is damaged, it shall be
replaced by authorized service only to avoid any
risk that may occur.
Do not tuck the power cord under the product
or to the rear of the product. Do not put heavy
items on the power cord. The power cable should
not be bent, crushed, and come into contact with
any heat source.
Do not use an extension cord, multi-plug or
adaptor to operate your product.
Portable multi-plugs or portable power supplies
may overheat and cause fire. Thus, do not have a
multi-plug behind or in the vicinity of the product.
Do not plug the product’s power cord in a loose
or damaged power outlet. These types of
connections may overheat and cause fire.
The plug shall be easily accessible. If this is not
possible, a mechanism that meets the electrical
legislation and that disconnects all terminals from
the mains (fuse, switch, main switch, etc.) shall be
available on the electrical installation.
Do not touch the plug with wet hands.
When unplugging the appliance, don’t hold the
power cord, but the plug.
2.4 Handling Safety
This product is heavy, do not handle it by
yourself.
Do not hold the product from its door while
handling the product.
Be careful not to damage the cooling system
and the pipes while handling the product. Do
not operate the product if the pipes are damaged,
and contact an authorized service.
2.5 Installation Safety
Contact the Authorized Service for the
product's installation. To prepare the product for
use, see the information in the user manual and
make sure the electric and water utilities are as
required. If not, call a qualified electrician and
plumber to arrange the utilities as necessary.
Failure to do so may result in electric shock,
fire, problems with the product, or injury.
Check for any damage on the product before
installing it. Do not have the product installed
if it is damaged.
Place the product on a clean, level and hard
surface and balance it with the adjustable legs.
Otherwise, the refrigerator may tip over and cause
injuries.
The product shall be installed in a dry and
ventilated environment. Do not keep carpets,
rugs or similar covers under the product. This may
cause risk of fire as a result of inadequate
ventilation!
Do not block or cover ventilation holes.
Otherwise, power consumption increases and
your product may be damaged.
The product must not be connected to supply
systems such as solar power supply. Otherwise,
your product may be damaged due to sudden
voltage changes!
When positioning the appliance, ensure the
supply cord is not trapped or damaged.
The more refrigerant a refrigerator contains, the
bigger its installation room should be. In very
small rooms, a flammable gas-air mixture may
occur in case of a gas leak in the cooling system.
At least 1 m³ of volume is required for each 8
grams of refrigerant. The amount of the refrigerant
available in your product is specified in the Type
Label.
The installation place of the product shall not
EN 3
2.SAFETY INSTRUCTIONS
be exposed to direct sunlight and it shall not be in
the vicinity of a heat source such as stoves, etc. If
you cannot prevent installation of the product in the
vicinity of a heat source, use a suitable insulation
plate and make sure the minimum distance to the
heat source is as specified below:
– At least 30 cm away from heat sources such as
stoves, ovens, heating units and heaters, etc.,
– And at least 5 cm away from electrical ovens.
Your product has the protection class of I.
Plug the product in a grounded socket that
conforms with the Voltage, Current and Frequency
values specified in the type label. The socket must
have a 10A – 16A fuse. Our firm will not assume
responsibility for any damages due to usage without
earthing and without power connection in
compliance with local and national regulations.
The product’s power cable must be unplugged
during installation. Otherwise, risk of electric shock
and injury may occur!
Do not plug the product’s power cord in loose,
dislocated, broken, dirty, oily power outlets which
have a risk of water contact. These types of
connections may cause overheating and fire.
Place the power cable and hoses (if any) of the
product so that they shall not cause a risk of
tripping over.
Penetration of humidity to live parts or to the
power cord may cause short circuit. Thus, do not
use the product in humid environments or in areas
where water may splash (e.g. garage, laundry
room, etc.) If the refrigerator is wet by water,
unplug it and contact an authorized service.
Do not ever connect your refrigerator to power
saving devices. These systems are harmful for the
product
2.6 Operational Safety
Do not ever use chemical solvents on the
product. These materials contain an explosion risk.
In case of a failure of the product, unplug it and
do not operate until it is repaired by the authorized
service. There is a risk of electric shock!
Do not place a source of flame (e.g. candles,
cigarettes, etc.) on the product or in the vicinity of it.
Do not get on the product. Risk of falling and
injury!
Do not cause damage to the pipes of the
cooling system using sharp and piercing tools.
The refrigerant that sprays out in case of
puncturing the gas pipes, pipe extensions or
upper surface coatings may cause irritation of
skin and injury to the eyes.
Do not place and operate electrical appliances
inside the refrigerator/ freezer unless it is advised
by the manufacturer.
Do not jam any parts of your hands or your
body to the moving parts inside the product. Be
careful to prevent jamming of your fingers
between the refrigerator and its door. Be careful
while opening or closing the door if there are
children around.
Do not put ice cream, ice cubes or frozen food
to your mouth as soon as you take them out of
the freezer. Risk of frostbite!
Do not touch the inner walls, metal parts of the
freezer or food kept inside the freezer with wet
hands. Risk of frostbite!
Do not place soda cans or cans and bottles
that contain fluids that may be frozen to the
freezer compartment. Cans or bottles may
explode. Risk of injury and material damage!
Do not use or place materials sensitive against
temperature such as flammable sprays,
flammable objects, dry ice or other chemical
agents in the vicinity of the refrigerator. Risk
of fire and explosion!
Do not store explosive materials such as
aerosol cans with flammable materials inside the
product.
Do not place cans containing fluids over the
product an open state. Splashing of water on an
electrical part may cause the risk of an electric
shock or a fire.
This product is not intended for storage and
cooling of medicines, blood plasma, laboratory
preparations or similar materials and products
that are subject to the Medical Products
Directive.
4 EN
2.SAFETY INSTRUCTIONS
If the product is used against its intended
purpose, it may cause damage to or deterioration
of the products kept inside.
If your refrigerator is equipped with blue light, do
not look at this light with optical devices. Do not
stare directly at UV LED light for a long time.
Ultraviolet rays may cause eye strain.
Do not fill the product with more food than its
capacity. Injuries or damages may occur if the
contents of the refrigerator fall when the door is
opened. Similar problems may also occur when an
object is placed over the product.
Ensure that you have removed any ice or water
that may have fallen to the floor to prevent injuries.
Change the locations of the racks/bottle racks on
the door of your refrigerator only when the racks
are empty. Danger of injury!
Do not place objects that may fall/tip over on the
product. These objects may fall while opening or
closing the door and cause injuries and/or material
damages.
Do not hit or exert excessive pressure on glass
surfaces. Broken glass may cause injuries and/or
material damages.
The cooling system in your product contains
R600a refrigerant. The refrigerant type used in the
product is specified in the type label. This gas is
flammable. Therefore, be careful not to damage the
cooling system and the pipes while operating the
product. In case of damage to the pipes;
1. Do not touch the product or the power cable.
2. Keep the product away from potential sources of
fire that may cause the product to catch fire.
3. Ventilate the area where the product is placed.
Do not use a fan.
4. Contact Authorized Service.
5. If the product is damaged and you observe gas
leak, please stay away from the gas. Gas may
cause frostbite if it contacts your skin.
2.7 Food Storage Safety
Please pay attention to the following warnings to
avoid food spoilage:
Leaving the doors open for a long time may
cause the temperature inside the product to rise.
Regularly clean the accessible drainage systems
in contact with food.
Clean the water tanks that have not been used
for 48 hours and mains-fed water systems that
have not been used for more than 5 days.
Store raw meat and fish products in appropriate
compartments within the product. Thus, it does not
drip on or come into contact with other foods.
Two-star freezer compartments are used for
storing prefilled foods, making and storing ice and
ice cream.
One, two and three-star compartments are not
appropriate for freezing fresh food.
If the cooling product has been left empty for a
long time, turn off the product, defrost, clean,
and dry the product in order to
protect the housing of the
product.
2.8 Maintenance and Cleaning Safety
Unplug the refrigerator before cleaning it or
starting to perform maintenance.
Do not pull by the door handle if you shall move
the product for cleaning purposes. Handle may
cause injuries if it is pulled too hard.
Do not put your hands etc. under the refrigerator.
Jamming may occur or any sharp edge may cause
personal injuries.
Do not clean the product by spraying or pouring
water on the product and inside the product. Risk
of electric shock and fire.
When cleaning the product, do not use sharp
and abrasive tools or household cleaning agents,
detergent, gas, gasoline, thinner, alcohol, varnish,
and similar substances. Use only cleaning and
maintenance agents that are not harmful for food
inside the product.
Do not ever use steam or steamed cleaning
materials for cleaning the product and thawing the
ice inside it. Steam con tacts the live areas in your
refrigerator and causes short circuit or electric
shock.
Do not use any mechanical tools or any other
tools than the recommendations of the
manufacturer to speed up the defrost operation.
EN 5
2.SAFETY INSTRUCTIONS
3.ENVIRONMENTAL INSTRUCTIONS
Take care to keep water away from the
ventilation holes, electronic circuits or lighting of
the product.
Use a clean, dry cloth to wipe the dust or foreign
material on the tips of the plugs. Do not use a wet
or damp piece of cloth to clean the plug.
Otherwise, risk of fire or electric shock may occur.
2.9 Disposal of the Old Product
When disposing of your old product follow the
instructions below:
To prevent children from accidentally locking
themselves into the product, if there is door lock,
make it deactivated.
Splash of coolant is harmful to the eyes. Do not
damage any part of the cooling system while
disposing of the product.
It may be fatal if the compressor oil is swallowed
or if it penetrates the respiratory tract.
3.1 Compliance with WEEE regulations and
Waste Disposal
This product does not contain hazardous and
prohibited substances specified in the "Regulations
for Supervision of Waste Electrical and Electronic
Equipment" published by Turkish Ministry of
Environment and Urban Planning.
3.2 Packaging Information
Complies with WEEE Regulation.
This product was manufactured
from recyclable and reusable high
quality parts and materials.
Therefore, do not dispose of this
product with other domestic wastes at the end of its
life cycle. Take it to a collection point for electrical
and electronic equipment. Please ask your local
authorities regarding these collection areas.
You can help protect the environment and natural
resources by delivering the used products for
recycling.
The product's packaging is made of
recyclable materials, in accordance with
the National Legislation. Do not dispose
of the packaging waste with the
household waste or other wastes,
dispose it to the packaging collection
areas specified by local authorities.
Cooling system of your product includes R600a
gas as specified in the type label. This gas is
flammable. Do not dispose of the product by
throwing it into fire. Risk of explosion!
R600a
This symbol denotes the
precaution on flammable
refrigerants.
WARNING : Keep ventilation openings,
in the appliance enclosure or in the built-in
structure, clear of obstruction
Minimum Clearances - 50 mm on the top,
12.5 mm on each side, and 30 mm in the back.
6 EN
4.INSTALLATION
Top View
(620 mm)
Cabinet
(650 mm)
Countertop
Recessed
electrical outlet
12.5 mm on EACH side.
Allow 30 mm, clearance at rear
for proper air circulation and
water/electrical connections
Allow 50 mm.
clearance between
the top of refrigerator
and bottom of cabinetry.
“
”
130
786 mm
513 mm
784 mm
650 mm
1820 mm
EN 7
4.INSTALLATION
4.1 Before Installation
Before installing, be sure the opening
measurements are sufficient to receive the product
and that the appropriate electrical and plumbing
connections are present.
4.2 Appropriate installation location
Install the product at least 12”(30 cm) away from
heat sources such as cooktops, ovens, space
heaters, radiators and stoves at least 2” (5 cm)
away from electrical ovens. Product must not be
subjected to direct sun light and kept in humid
places after installation.
Do not place the product on the materials such
as rugs or carpets.
Place the product on an even floor surface to
prevent wobbling.
Do not install the product in places where the
temperature falls below 50F°/10ºC.
Make sure that sufficient room is provided
around the appliance to ensure free air circulation.
For proper functionality, there should be a gap of
at least 1 3/8” (35 mm) between the refrigerator
and the rear wall.
To ensure this, attach the gray, circular buffers, to
be installed on the rear back metal cover of the
refrigerator.
These are shipped inside the crisper drawer in the
Fresh Food compartment.
4.3 Inset installations
If the product will be installed within surrounding
cabinetry or in an alcove, be sure there is
adequate airflow around the product for proper
functionality. This refrigerator requires at least 2”
from the top of the unit to the ceiling or enclosure,
1/2” on each side and 1 3/16” in the back.
the spacer is shipped with the product
4.4 Electrical connection
220VAC, 50Hz, Dedicated 15Amp Circuit.
GFCI outlets will provide added protection, but
any failure of the GFCI could cause food spoilage,
which is not covered by the manufacturer’s
warranty.
Preparation of the location and electrical
installation at the place of installation is the
customer's responsibility.
Plumbing: The refrigerator should only be
connected to the cold water line.
If two refrigerators are to be installed side
by side, there should be at least 4 cm
1 1/2”distance between them.
WARNING:Installation and electrical
connections of the product must be carried
out by the AuthorizedService Agent.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorised persons.
WARNING:Prior to installation, visually
check if the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
Unscrew before installing the spacer.
Install the spacer and screw.
Rear of unit with installed spacers.
1
2
3
8 EN
4.INSTALLATION
Electrical connection must comply with national
regulations.
Power cable plug must be within easy reach
after installation.
Do not make connections via extension cables
or multi-plu gs.
4.5 Adjusting the feet
After moving the refrigerator into place, we
recommend lowering the feet to secure the product
in place. You can also adjust the feet if the product
is not balanced. Twist the feet in the desired
direction according to the illustration below.
4.6 Illumination lamp
Do not attempt to repair yourself but call the
Authorized Service Agent if the LED lights do not
go on or are out of order. The lights used in this
appliance is not suitable for household room
illumination. The intended purpose of this lights is
to assist the user to place foodstuffs in the
refrigerator/freezer in a safe and comfortable way.
4.7 Door/Drawer Open Warning
An audio warning signal will be given when the
door of your product is left open for 1 minute. This
warning will be muted when the door is closed.
WARNING : Damaged power cord
must be replaced by the Authorized Service
Agents.
WARNING : If the product has a
failure, it should not be operated unless it is
repaired by the Authorized Service Agent!
There is the risk of electric shock!
WARNING : First unplug the product.
Product must not be plugged in when
adjusting the feet. There is the risk of
electric shock!
EN 9
4.INSTALLATION
4.8 Transportation of the product
1. Unplug the product before transporting it.
2. Remove water connections.
3. Secure the shelves, accessories, crisper and
etc. in the refrigerator by adhesive tape before
repackaging it.t
Points to be paid attention to when the
relocation of the refrigerator
1. Your refrigerator should be unplugged.Before
transportation of your refrigerator, it should be
emptied and cleaned.
2. Before it is re-packaged, shelves, accessories,
crisper, etc. inside your refrigerator should be
fixed with adhesive tape and secured against
impacts. Package should be bound with a thick
tape or sound ropes and the transportation rules
on the package should be strictly observed.
3. Original packaging and foam materials should
be kept for future transportations or moving.
WARNING : Packaging materials are
dangerous for the children. Keep packaging
materials in a safe place away from reach
of the children.
Packaging must be tied with thick tape or
strong ropes and the rules of transportation
printed on the package must be followed.
This refrigerating appliance is not intended to
be used as a built in appliance.
Do not keep the refrigerator doors open for
long periods.
Do not place hot food or beverages into
the refrigerator.
5.1 What To Do For Energy Saving
Do not overfill the refrigerator; blocking the
internal air flow will reduce cooling capacity.
Depending on the product’s features;
defrosting frozen foods in the cooler compartment
will ensure both energy saving and preserve food
quality.
Food shall be stored using the drawers in the
cooler compartment in order to ensure energy
saving and protect food in better conditions.
Make sure the foods are not in contact with the
cooler compartment temperature sensor shown
below.
Since hot and humid air will not directly
penetrate into your product when the doors are
not opened, your product will optimize itself in
conditions sufficient to protect your food. Under
these circumstances, functions and components
such as compressor, fan, heater, defrost, lighting,
display and so on will operate according to the
needs by consuming minimum energy.
In case that multiple options are present, glass
shelves must be placed so that the air outlets at
the rear wall are not blocked and preferably, in a
way that air outlets remain below the glass shelf.
This combination may help improving air
distribution and energy efficiency.
5.2 First Use
Before using your refrigerator, make sure
the necessary preparations are made in line
with the instructions in "Safety and Environmental
Instructions" and "Installation" sections.
Keep the product running without placing any
food inside for 12 hours and do not open the door,
unless absolutely necessary.
5.3 Climate Class and Definitions
Please refer to the Climate Class on the rating
plate of your device. One of the following
information is applicable to your device
according to the Climate Class.
SN: Long Term Temperate Climate: This cooling
device is designed for use at ambient temperatures
between 10 °C and 32 °C.
N: Temperate Climate: This cooling device is
designed for use at ambient temperatures between
16°C and 32 °C.
ST: Subtropical Climate: This cooling device is
designed for use at ambient temperatures between
16°C and 38°C.
T: Tropical Climate: This cooling device is
designed for use at ambient temperatures between
16°C and 43°C.
10
EN
5.PREPARATION
Read the “Safety Instructions” section first! A sound will be heard when the
compressor is engaged. It is normal for
the product to make noise even if the
compressor is not running, as fluid and
gas may be compressed in the cooling
system.
It is normal for the front edges of the
refrigerator to be warm. These areas
are designed to warm up in order to
prevent condensation.
For some models, indicator panel turns
off automatically 1 minute after the door
closes. It will be reactivated when the
door is opened or any button is pressed.
EN 11
6.USING THE CONTROLS
6.1 Indicator panel
Touch-control indicator panel allows you to set the temperature and control the other functions of the
refrigerator. Just press the relevant buttons for function settings.
1.On/Off Function: This function ( ) allows you
to make the Fridge turn off when pressed for 3
seconds. The fridge could be turned on by pressing
On/Off button for 3 seconds again. When the
function is active, all indicators turn off.
*2. Wireless connection (*optional) key: A long
press on the button(3seconds) starts the product’s
first introduction to the homenetwork.During the
connection establishment process, the wireless
network icon ( ) will flash at 0.5 sec intervals.
When the connection to the home network is
successful,the wireless network icon lights up
continuously. After the first connection has been
established, the connection can be activated/
deactivated by briefly pressing this button. After
turning the power off and on, it will automatically
remember and establish a connection to your
network. The wireless network icon will flash briefly
(at 0.2 sec intervals) until the connection is
established.
*3. Nutrifreeze button: Press "Nutrifreeze" to
activate Nutrifreeze temperature, Nutrifreeze
indicator will turn on and Fridge compartment
temperature indicator will show "1". Press
"Nutrifreeze" button again to deactivate."or press
"fridge compartment temperature" button ( ),
then Nutrifreeze function will be off as well"
Nutrifreeze indicator will turn off and product will
return to its normal setting.
4. Fresh Food Compartment Temperature
Setting Key: Allows setting of temperature for
Fresh Food Compartment Pressing this key will
enable the Fresh Food Compartment temperature
to be set at 1, 2, 3...8 Celcius
*5. Nutrifreeze Symbol: The Nutrifreeze is
displayed on the screen when this symbol is
active.
6. Fresh Food Compartment Symbol: The
temperature values of the cooling compartment
is displayed on the screen when this symbol is active.
7.
Freezing Compartment Symbol: The temperature
values of the freezing compartment is displayed on
the screen when this symbol is active.
8. Freezing Compartment Temperature Setting Key:
Temperature setting is made for cooler compartment.
Pressing this key will enable the freezer compartment
temperature to be set at -15, -16, -17, -18....-24
Celcius
9.Quick Freezing Key: When the quick reeze key is
pressed, the quickfreeze symbol ( ) shall be
illuminated and the quickfreeze function shall be
activated. Freezing compartment temperature is set to
16 Fahrenheit. Function is cancelled when the key is
pressed again. The quick freezing function shall be
automatically cancelled after 24 hours. To freeze a
large amount of fresh food, press the quick freeze key
before placing the food in the freezer compartment.
*10. Sabbath Mode: Press the Fresh Food Temp Set
Function key for 3 seconds to activate or deactivate
the Sabbath Mode. When Sabbath Mode is activated,
the display, alarm, door opening or light buttons will
not function. "SA"
will appear in the display. The cooling algorithm is set
according to the sabbath fashion.
1 12 *3 4 *5
6
7 8 9 *10
11
*2
(*Optinal)
11. Fault Condition Indicator: This indicator
( ) shall be active when your refrigerator cannot
perform adequate cooling or in case of any sensor
error. “E” shall be displayed on
12. Vacation Function Key:
Press the key for 3 seconds to activate the vacation
function. Vacation mode is activated and the vacation
symbol ( ) is illuminated. “- -” shall be displayed on the
Fresh Food Compartment temperature indicator and the
Fresh Food Compartment does not actively perform cooling.
You shall not keep your food in the Fresh Food Compart-
ment when this function is activated. The Freezer
Comparment will continue to operate at its set temperature.
Press the key for 3 seconds again to cancel this function.
7.FOOD STORAGE AND COMPARTMENT USAGE
7.1 Freezing fresh food
Wrap the food or place them in a covered
container before putting them in the refrigerator.
Hot food and beverages must cool down to
room temperature before putting them in the
refrigerator.
The food that you want to freeze must be fresh
and in good quality.
Pack the food in an airtight manner to prevent
them from drying even if they are going to be
stored for a short time.
Materials to be used for packaging must be
tear-proof and resistant to cold, humidity, oils and
acids and they must also be airtight. All packaging
must be completely sealed.
Frozen food must be used immediately after
they are thawed and they should never be
refrozen.
Do not freeze excessively large quantities of
food at one time.The quality of the food is best
preserved when it is frozen right through to the
core as quickly as possible.
Placing warm food into the freezer
compartment causes the cooling system to
operate continuously until the food is frozen solid.
7.2 Recommendations for preserving frozen
food
To ensure the quality achieved by the frozen food
manufacturer and food retailler is maintained,
follow the steps listed below:
1. Put packets in the freezer as quickly as
possible after purchase.
2. Make sure that contents of the package are
labelled and dated.
3. Check whether the "Use By" and "Best Before"
dates on he packaging are exceeded or not.
7.4 Deep-freeze information
You can keep the freshness of food for many months
(at -15°C or lower temperatures in the deep freeze).
Material necessary for packaging
Coldresistant adhesive tape
Self adhesive label
Rubber rings
Pen
7.5 Removing door shelves
You can remove the door shelves to clean them.
Push the desired shelf up to remove it. Do not remove
the door shelf when there is food in it. First, empty the
food inside them.
7.3 Placing the food
Various frozen food such as meat,
fish, ice cream,vegetables and
etc.
Food in pans, covered plates and
closed containers
Small and packaged food or
beverage (such as milk, fruit juice,
beer and etc.)
Vegetables and fruits
Delicatessen products
(cheese,butter, salami and etc.
Freezer
compartment
shelves
Fridge
compartment
shelves
Fridge
compartment
door shelves
Fresh zone
compartment
Crisper
Divided the food into portions according
to your family’s daily or meal based
consumption needs.
Pack the food in an airtight manner to
prevent them from drying even if they
are going to be stored for a short time.
12
EN
7.FOOD STORAGE AND COMPARTMENT USAGE
7.6 Glass shelves
You can remove the glass shelves to clean them.
Be careful when removing the shelves since they
are heavy.
7.7 Crisper bins (in some models)
Crisper bins allow you to prepare the food for
freezing. You can also use these compartments to
store your food at a temperature a few degrees
below the fridge compartment.
You can increase the inner volume of your refrigerator
by removing any of the chiller compartments:
1. Pull the compartment towards yourself until it stops.
2. Lift the compartment about 1cm up and pull
towards yourself to remove it from its seating.
7.8 Deli Drawer
The Deli Drawer is designed with cool air
circulation intensified around it. This allows for
items stored in the drawer to be generally fresh
food compartment than average Fresh Food
temperatures. If required, remove door shelves
prior to Deli Drawer removal
7.9 Humidity controlled crisper (EverFresh+)
Humidity levels of the vegetables and fruit are
kept under control with the feature of
humiditycontrolled crisper and the food is
ensured to stay fresh longer.We recommend
you to place the leafy vegetables such as
lettuce, spinach and the vegetables which are
sensitive to humidity loss, in a horizontal
manner as much as possible inside the crisper,
not on their roots in a vertical position. While
the vegetables are being placed, individual
weights of the vegetables should be taken into
consideration. Heavy and hard vegetables
should be put at the bottom of the crisper and
the lightweight and soft vegetables should be
placed on top. Never leave vegetables inside
the crisper in their bags. This will cause them to
decompose prematuraly. If you wish to keep
vegetables separate, use perforated paper
bags or similar materials to do so.
Certain fruits such as pears, apricots, peaches
or apples generate high levels of ethylene gas.
Do not place them with other fruits and
vegetables which do not, as this will cause
them to decompose faster.
7.10 Harvest Fresh
Crispers of the refrigerator are illuminated with
blue light. Food stored in the crispers continue
their photosynthesis by means of the
wavelength effect of blue light and thus,
preserve their freshness and preserves their
vitamin content.
7.11 Odor filter
Odor filter in the air duct of the fridge
compartment prevents build-up of unpleasant
odors in the refrigerator.
EN 13
Do not use sharp or abrasive tools to clean the
product. Do not use materials such as household
cleaning agents, soap, detergents, gas, gasoline,
thinner, alcohol, wax, etc.
The dust shall be removed from the ventilation
grill on the rear of the product at least once a
year (without opening the cover). Clean the
product with a dry cloth.
Take care to keep water away from the lamp's
cover and other electrical parts.
Clean the door with a damp cloth. Remove all
contents to remove the door and body racks.
Remove the door racks by lifting them upwards.
Clean and dry the shelves, then attach back in
place by sliding from above.
Do not use chlorinated water or cleaning
products on the exterior surface and
chromecoated parts of the product. Chlorine will
cause rust on such metallic surfaces.
Do not use sharp and abrasive tools, soap,
house cleaning materials, detergents, gas,
gasoline, varnish and similar substances to
prevent deformation of the plastic part and
removal of prints on the part. Use warm water
and a soft cloth for cleaning, and then dry it.
On the products without a No-Frost feature,
water droplets and icing up to a thickness of a
finger may occur on the rear wall of the freezer
compartment. Do not clean, and never apply oils
or similar materials.
Use a mildly dampened micro-fibre cloth to
clean the external surface of the product.
Sponges and other types of cleaning clothes may
cause scratches.
To clean all removable components during the
cleaning of the interior surface of the product,
wash these components with a mild solution
consisting of soap, water and carbonate. Wash
and dry thoroughly.
Prevent contact of water with illumination
components and the control panel.
Stainless Steel External Surfaces
Use a non-abrasive stainless steel cleaning
agent and apply it with a soft lint-free cloth.
To polish, gently wipe the surface with a
microfibre cloth dampened with water and use
dry polishing chamois. Always follow the veins of
the stainless steel.
Preventing Odours
The product is manufactured free of any odorous
materials. However, keeping the food in
inappropriate sections and improper cleaning of
internal surfaces may lead to odours.
To avoid this, clean the inside with carbonated
water every 15 days.
Keep the foods in sealed holders, as
microorganisms arising from foods kept in
unsealed containers will cause bad odour.
Do not keep expired and spoilt foods in the
refrigerator.
Protecting Plastic Surfaces
Oil spilled on plastic surfaces may damage
the surface and must be cleaned immediately
with warm water.
This product is equipped with a lighting source of
the "G" energy class.
The lighting source in this product shall only be
replaced by professional repairers.
8.MAINTENANCE AND CLEANING
WARNING:Read the “Safety Instructions”
section first!
WARNING:Unplug the refrigerator before
cleaning it.
CAUTION:Do not use vinegar, rubbing
alcohol or other alcohol based cleaning
agents on any interior surface.
Tea is one of the most effective odour
removers. Place the pulp of the brewed
tea in the product inside an open
container and remove it after 12 hours at
the latest. If you keep the tea pulp inside
the product for longer than 12 hours, it will
collect the organisms that cause the
odour so it can be the source of odour
itself.
14
EN
Check this list before contacting the service.
Doing so will save you time and money. This list
includes frequent complaints that are not related
to faulty workmanship or materials. Certain
features mentioned herein may not apply to your
product.
The refrigerator is not working.
The power plug is not fully settled. >>> Plug it
in to settle completely into the socket.
The fuse connected to the socket powering
the product or the main fuse is blown. >>> Check
the fuse.
Condensation on the side wall of the cooler
compartment (MULTI ZONE, COOL CONTROL
and FLEXI ZONE).
The door is opened too frequently. >>> Take
care not to open the product's door too
frequently.
The environment is too humid. >>> Do not
install the product in humid environments.
Foods containing liquids are kept in unsealed
holders. >>> Keep the foods containing liquids in
sealed holders.
The product's door is left open. >>> Do not
keep the product's door open for long periods.
The thermostat is set to a very cool
temperature. >>> Set the thermostat to an
appropriate temperature.
Compressor is not working.
In case of sudden power failure or pulling the
power plug off and putting back on, the gas
pressure in the product's cooling system is not
balanced, which triggers the compressor thermic
safeguard. The product will restart after
approximately 6 minutes. If the product does not
restart after this period, contact the service.
Defrosting is active. >>> This is normal for a
fully-automatic defrosting product. The defrosting
is carried out periodically.
The product is not plugged in. >>> Make sure
the power cord is plugged in.
The temperature setting is incorrect. >>>
Select the appropriate temperature setting.
The power is out. >>> The product will
continue to operate normally once the power is
restored.
The refrigerator's operating noise is
increasing while in use.
The product's operating performance may vary
depending on the ambient temperature
variations. This is normal and not a malfunction.
The refrigerator runs too often or for too long.
The new product may be larger than the
previous one. Larger products will run for longer
periods.
The room temperature may be high. >>> The
product will normally run for long periods in
higher room temperature.
The product may have been recently plugged
in or a new food item is placed inside. >>> The
product will take longer to reach the set
temperature when recently plugged in or a new
food item is placed inside. This is normal.
Large quantities of hot food may have been
recently placed into the product. >>> Do not
place hot food into the product.
The doors were opened frequently or kept
open for long periods. >>> The warm air moving
inside will cause the product to run longer. Do not
open the doors too frequently.
The freezer or cooler door may be ajar.
>>> Check that the doors are fully closed.
The product may be set to a temperature that
is too low. >>> Set the temperature to a higher
degree and wait for the product to reach the
adjusted temperature.
The cooler or freezer door washer may be
dirty, worn out, broken or not properly settled.
>>> Clean or replace the gasket. Damaged / torn
door washer will cause the product to run for
longer periods to preserve the current
temperature.
The freezer temperature is very low, but the
cooler temperature is adequate.
The freezer compartment temperature is set to
a very low degree. >>> Set the freezer
compartment temperature to ahigher degree and
check again.
9.TROUBLESHOOTING
EN 15
The cooler temperature is very low, but the
freezer temperature is adequate.
The cooler compartment temperature is set to
a very low degree. >>> Set the cooler
compartment temperature to a higher degree and
check again.
The food items kept in cooler compartment
drawers are frozen.
The cooler compartment temperature is set to
a very low degree. >>> Set the cooler
compartment temperature to a higher degree and
check again.
The temperature in the cooler or the freezer is
too high.
The cooler compartment temperature is set to
a very high degree. >>> Temperature setting of
the cooler compartment has an effect on the
temperature in the freezer compartment. Wait
until the temperature of relevant parts reach the
sufficient level by changing the temperature
of cooler or freezer compartments.
The doors were opened frequently or kept
open for long periods. >>> Do not open the doors
too frequently.
The door may be ajar. >>>Fully close the door.
The product may have been recently plugged
in or a new food item is placed inside. >>> This is
normal. The product will take longer to reach the
set temperature when recently plugged in or a
new food item is placed inside.
Large quantities of hot food may have been
recently placed into the product. >>> Do not
place hot food into the product.
Shaking or noise.
The surface is not flat or durable >>> If the
product is shaking when moved slowly, adjust the
stands to balance the product. Also make sure
the ground is sufficiently durable to bear the
product.
Any items placed on the product may cause
noise. >>> Remove any items placed on the
product.
The product is making noise of liquid flowing,
spraying etc.
The product's operating principles involve
liquid and gas flows. >>> This is normal and not a
malfunction.
There is sound of wind blowing coming from
the product.
The product uses a fan for the cooling process.
This is normal and not a malfunction. There is
condensation on the product's internal walls.
Hot or humid weather will increase icing and
condensation. This is normal and not a
malfunction.
The doors were opened frequently or kept
open for long periods. >>> Do not open the doors
too frequently; if open, close the door.
The door may be ajar. >>> Fully close the
door.
There is condensation on the product's
exterior or between the doors.
The ambient weather may be humid, this
is quite normal in humid weather. >>> The
condensation will dissipate when the humidity is
reduced.
The interior smells bad.
The product is not cleaned regularly. >>>
Clean the interior regularly using sponge, warm
water and carbonated water.
Certain holders and packaging materials may
cause odour. >>> Use holders and packaging
materials without free of odour.
The foods were placed in unsealed holders.
>>> Keep the foods in sealed holders.
Microorganisms may spread out of unsealed food
items and cause bad odour.
Remove any expired or spoilt foods from
the product.
The door is not closing.
Food packages may be blocking the door. >>>
Relocate any items blocking the doors.
The product is not standing in full upright
position on the ground. >>> Adjust the stands to
balance the product.
The surface is not flat or durable >>> Make
sure the surface is flat and sufficiently durable to
bear the product.
9.TROUBLESHOOTING
16 EN
The crisper is jammed.
The food items may be in contact with the
upper section of the drawer. >>> Reorganize
the food items in the drawer.
Temperature on the product surface.
High temperature may be observed between
two doors, on the side panels and on the rear grill
area while your product is operated. This is
normal and it does not require servicing.
Fan continues to operate when the door is
opened.
Fan may continue to operate when the freezer
door is open.
WWW.Beko.com
9.TROUBLESHOOTING
WARNING:If the problem persists after
following the instructions in this section,
contact your vendor or an Authorized
Service. Do not try to repair the product.
This is normal.
EN 17
