User Manual

This is the main product document for model IPS235T-BN.

The file format is pdf, 26 pages, you can download this manual here .

background
www.lg.com
OWNER'S MANUAL
LCD MONITOR
IPS225T
IPS235T
Please read this manual carefully before operating
your set and retain it for future reference.
LCD MONITOR MODEL
ENGLISH
background
2
ENG
ENGLISH
TABLE OF CONTENTS



3 Unpacking
4 Partsandbuttons
6 SettinguptheMonitorset
6 - AttachingtheStandBase
6 - DetachingtheStandBase
7 - Mountingonatable
8 - Mountingonawall
 
10 ConnectingtoaPC
10 - D-SUBconnection
10 - DVI-Dconnection
 
12 AccessingTheMainMenus
13 CustomizingSettings
13 - MenuSettings
14 -PICTURE
15 -COLOR
16 -DISPLAY
17 -OTHERS
18 MODESetting
19 DUALPACKAGESetting
 
 
22 IPS225T
23 IPS235T
24 PresetModes(Resolution)
24 Indicator
background
3
ENG
ENGLISH
ASSEMBLING AND PREPARING


Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct
andaccessories.
Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.
Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.
Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.
Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
Usershoulduseshieldedsignalinterfacecables(D-SUBcable/DVI-Dcable)withferritecoresto
maintainstandardcompliancefortheproduct.







(Thissignalcablemaybeattached
tothisproductbeforeshippingout.)

(Thiscableisnotincludedinall
countries.)

background
4
ENG
ENGLISH
ASSEMBLING AND PREPARING




Connectionpanel(Seep.10)
Button(Seep.13)
(PowerButton)
background
5
ENG
ENGLISH
ASSEMBLING AND PREPARING
 
MENU Accessesthemainmenus.(Seep.13)


Thisfunctionallowsyoutolockthecurrentcontrolsettings,so
thattheycannotbeinadvertentlychanged.
PressandholdtheMENUbuttonforseveralseconds.
Themessage"OSDLOCKED"shouldappear.
YoucanunlocktheOSDcontrolsatanytimebypushing
theMENUbuttonforseveralseconds.Themessage"OSD
UNLOCKED"shouldappear.
MODE UsethisbuttontoenterUSER,MOVIE,TEXT,PHOTO,sRGBmenus.(Seep.18)
DUAL UsethisbuttontoenterDUALMONITORandDUALWEBmenus.(Seep.19)
AUTO Whenadjustingyourdisplaysettings,alwayspresstheAUTObuttonontheMONITOR
SETUPOSD.(OnlysupportedinAnalogMode)
 1920x1080
INPUT Youcanchoosetheinputsignal.
• Whentwoinputsignalsareconnected,youcanselecttheinputsignal(D-SUB/DVI)
youwant.
• Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsettingis
D-SUB.
EXIT ExittheOSD(OnScreenDisplay).
(PowerButton)
Turnsthepoweronoroff.
 Thepowerindicatorstaysblueifthedisplayisrunning
properly(OnMode).IfthedisplayisinSleepMode,thepower
indicatorblinksblue.
background
6
ENG
ENGLISH
ASSEMBLING AND PREPARING


1
PlacetheMonitorsetwiththescreenside
downonaflatandcushionedsurface.
Layafoammatorsoftprotectivecloth
onthesurfacetoprotectthescreenfrom
damage.
Thisillustrationdepictsthegeneralmodelof
connection.Yourmonitormaydifferfromthe
itemsshowninthepicture.
Donotcarrytheproductupsidedownholding
onlythestandbase.Theproductmayfall
andgetdamagedorinjureyourfoot.



1
PlacetheMonitorsetwiththescreenside
downonaflatandcushionedsurface.
2
Turnthescrewtotheleft,andthenpulloutthe
fromthe.
2
Attachtheandthentightenthe
screwtotherightwitha.


background
7
ENG
ENGLISH
ASSEMBLING AND PREPARING

1
LiftandtilttheMonitorsetintoitsupright
positiononatable.
Leavea10cm(minimum)spacefromthewall
forproperventilation.
2
Connectthetoawalloutlet.
3
Press (Power)buttononthefrontswitch
paneltoturnthepoweron.
10 cm
10 cm
10 cm
10 cm
Whenyouadjusttheangle,donotholdthe
bottomoftheMonitorsetframeasshownon
thefollowingillustration,asmayinjureyour
fingers.
Donottouchorpressthescreenwhen
adjustingtheangleofthemonitor.

Unplugthepowercordbeforemovingthe
Monitortoanotherlocation.Otherwiseelectric
shockmayoccur.
Tiltfrom+15to-5degreesupordowntoadjust
theangleoftheMonitorsettosuityourview.


 
15- 5
background
8
ENG
ENGLISH
ASSEMBLING AND PREPARING

Forproperventilation,allowaclearanceof10cm
oneachsideandfromthewall.Detailed
instructionsareavailablefromyourdealer,seethe
optionalTiltWallMountingBracketInstallationand
SetupGuide.
WhenyouinstalltheMonitorsetusingawall
mountinginterface(optionalparts),attachit
carefullysoitwillnotdrop.
PleaseuseVESAstandardasbelow.
784.8mm(30.9inch)andunder
*WallMountPadThickness:2.6mm
*Screw:Φ4.0mmxPitch0.7mmx
Length10mm
787.4mm(31.0inch)andabove
*PleaseuseVESAstandardwallmountpad
andscrews.
10 cm
10 cm
10 cm
10 cm
UsingtheKensingtonsecuritysystem
TheKensingtonsecuritysystemconnectoris
locatedatthebackoftheMonitorset.Formore
informationofinstallationandusing,refertothe
manualsuppliedwiththeKensingtonsecurity
systemorvisit
http://www.kensington.com
.
ConnecttheKensingtonsecuritysystemcable
betweentheMonitorsetandatable.
TheKensingtonsecuritysystemisoptional.
Youcanobtainitfrommostelectronicsstores.

background
9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Disconnectthepowercordfirst,andthen
moveorinstalltheMonitorset.Otherwise
electricshockmayoccur.
IfyouinstalltheMonitorsetonaceilingor
slantedwall,itmayfallandresultinsevere
injury.
UseonlyanauthorizedLGwallmount
andcontactthelocaldealerorqualified
personnel.
Donotovertightenthescrewsasthismay
causedamagetotheMonitorsetandvoid
yourwarranty.
Useonlyscrewsandwallmountsthat
meettheVESAstandard.Anydamages
orinjuriesbymisuseorusinganimproper
accessoryarenotcoveredbythewarranty.
UsethescrewsthatarelistedontheVESA
standardscrewspecifications.
Thewallmountkitwillincludeaninstallation
manualandnecessaryparts.
Thewallmountbracketisoptional.Youcan
obtainadditionalaccessoriesfromyourlocal
dealer.
Thelengthofscrewsmaydifferdepending
onthewallmount.Besuretousetheproper
length.
Formoreinformation,refertothe
instructionssuppliedwiththewallmount.



IPS225T/IPS235T
 100x100
 M4
 4
background
10
ENG
ENGLISH
USING THE MONITOR SET


YourMonitorsetsupportsPlug&Play*.
*Plug&Play:APCrecognizesaconnected
devicethatusersconnecttoaPCandturn
on,withoutdeviceconfigurationoruser
intervention.

TransmitsanalogvideofromyourPCtothe
Monitorset.ConnectthePCandtheMonitorset
withthesuppliedD-sub15pinsignalcableas
showninthefollowingillustrations.

ForAppleMacintoshuse,aseparateplug
adapterisneededtochangethe15pin
highdensity(3row)D-SUBVGAconnector
onthesuppliedcabletoa15pin2row
connector.
WhenusingaD-Subsignalinputcable
connectorforMacintosh


TransmitsadigitalvideosignalfromyourPCto
theMonitorset.ConnectthePCandtheMonitor
setwithaDVIcableasshowninthefollowing
illustrations.
background
11
ENG
ENGLISH
USING THE MONITOR SET
WhenyouwanttousetwoPCinourMonitor,
pleaseconnectthesignalcable(D-SUB/
DVI-D)respectivelyinMonitorset.
IfyouturntheMonitorsetonwhileitiscold,
thescreenmayflicker.Thisisnormal.
Somered,green,orbluespotsmayappear
onthescreen.Thisisnormal.

Thisfunctionprovidestheuserwithoptimal
displaysettings.Whentheuserconnects
themonitorforthefirsttime,thisfunction
automaticallyadjuststhedisplaytooptimal
settingsforindividualinputsignals.(Only
supportedinAnalogMode)

Whenyouencounterproblemssuchas
blurryscreen,blurredletters,screenflicker
ortiltedscreenwhileusingthedeviceor
afterchangingscreenresolution,pressthe
AUTOfunctionbuttontoimproveresolution.
(OnlysupportedinAnalogMode)


Connectthesignal
inputcableandtighten
itbyturningthescrews
clockwise.
Donotpressthescreenwithyourfingerfor
alongtimeasthismayresultintemporary
distortiononthescreen.
Avoiddisplayingafixedimageonthe
screenforalongperiodoftimetoprevent
imageburn.Useascreensaverifpossible.

SelfImageSettingFunction
Pressthepowerbuttononthefrontpaneltoturn
thepoweron.Whenmonitorpoweristurnedon,
theFunctionisexecuted
automatically.(OnlysupportedinAnalogMode)
background
12
ENG
ENGLISH
CUSTOMIZING SETTINGS


1
PressanybuttononthefrontoftheMonitorsettodisplaytheOSDmenu.
2
Pressthedesiredmenuitem.
3
ChangethevalueofthemenuitembypressingthebuttonsonthefrontoftheMonitorset.
Toreturntotheuppermenuorsetothermenuitems,usetheuparrow(
)button.
4
SelecttoleavetheOSDmenu.

(Seep.13)
Setsthescreenoptions.
(Seep.19)
Setsthescreen.

ExitstheOSDmenu.

Setstheexternalinput.
(Seep.18)
Setsthemode.
(Seep.11)
Optimizestheresolution.
Differentmenuitemsareenableddependingonthetypeofinputsignal.
:MENU,MODE,DUAL,AUTO,INPUT,EXIT

background
13
ENG
ENGLISH
CUSTOMIZING SETTINGS


1
PressanybuttononthefrontoftheMonitorsettodisplaythe
OSDmenu.
2
PressthebuttontodisplaytheoptionsintheOSD
menu.
3
Settheoptionsbypressingthebuttonsonthefrontofthe
Monitorset.
4
SelecttoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,usethe
uparrow(
)button.
    
 


Toadjustthebrightness,contrastandsharpnessofthescreen



Tocustomizethecolorofthescreen


 

Toadjustthepositionofthescreen
 Toimprovetheclarityandstabilityofthescreen
 

Tocustomizethescreenstatusforauser'soperating
environment





D-SUB(Analogsignal)input.
DVI-D(Digitalsignal)input.
Theavailablepicturesettingsaredescribedbelow.
background
14
ENG
ENGLISH
CUSTOMIZING SETTINGS

1
PressanybuttononthefrontoftheMonitorsettodisplay
theOSDmenu.
2
PressthebuttontodisplaytheoptionsintheOSD
menu.
3
Selectbypressingthebuttonsonthefrontofthe
Monitorsetandsettheoptions.
4
SelecttoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,use
theuparrow(
)button.
Theavailablepicturesettingsaredescribedbelow.
 
 Toadjustthebrightnessofthescreen.
 Toadjustthecontrastofthescreen.
 Toadjusttheclearnessofthescreen.
background
15
ENG
ENGLISH
CUSTOMIZING SETTINGS

1
PressanybuttononthefrontoftheMonitorsettodisplay
theOSDmenu.
2
PressthebuttontodisplaytheoptionsintheOSD
menu.
3
Selectbypressingthebuttonsonthefrontofthe
Monitorsetandsettheoptions.
4
SelecttoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,use
theuparrow(
)button.
Theavailablepicturesettingsaredescribedbelow.
 
 
Selectthescreencolor.
Setthescreentowarmcolortemperature(morered).
Setthescreentomediumcolortemperature.
Setthescreentocoolcolortemperature(Moreblue).

 Setsandstoresthehueandsaturationforsixcolors(RED/GREEN/BLUE/
CYAN/MAGENTA/YELLOW)tosatisfythecolorrequirementsofauser.
HUE
Adjuststhescreenhue.
SATURATION
Adjuststhecolorsharpnessonthescreen.Lowervaluesmake
thecolorsharpnessweakerandcolorslighterwhilehigher
valuesmakethecolorsharpnessstrongerandcolorsdark.



Setyourownredcolorlevels.
Setyourowngreencolorlevels.
Setyourownbluecolorlevels.
 Setyourowngammavalue.:1.8/2.0/2.2/2.4/2.6Onthemonitor,highgammavaluesdisplay
whitishimagesandlowgammavaluesdisplayblackishimages.
 Resetsthecolorsettingstothefactorydefaultsettingsforthecurrentinputdevice.
background
16
ENG
ENGLISH
CUSTOMIZING SETTINGS

1
PressanybuttononthefrontoftheMonitorsettodisplay
theOSDmenu.
2
PressthebuttontodisplaytheoptionsintheOSD
menu.
3
Selectbypressingthebuttonsonthefrontofthe
Monitorsetandsettheoptions.
4
SelecttoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,use
theuparrow(
)button.
Theavailablepicturesettingsaredescribedbelow.
 
 Tomoveimageleftandright.
 Tomoveimageupanddown.
 Tominimizeanyverticalbarsorstripesvisibleonthescreenbackground.Thehorizontalscreen
sizewillalsochange.
 Toadjustthefocusofthedisplay.Thisitemallowsyoutoremoveanyhorizontalnoiseandclearor
sharpentheimageofcharacters.
background
17
ENG
ENGLISH
CUSTOMIZING SETTINGS

1
PressanybuttononthefrontoftheMonitorsettodisplaythe
OSDmenu.
2
PressthebuttontodisplaytheoptionsintheOSDmenu.
3
Selectbypressingthebuttonsonthefrontofthe
Monitorsetandsettheoptions.
4
SelecttoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,usetheup
arrow(
)button.
Theavailablepicturesettingsaredescribedbelow.
 
 Tochoosethelanguageinwhichthecontrolnamesaredisplayed.


UsethisfunctiontosetthepowerindicatoronthefrontsideofthemonitortoONorOFF.Ifyouset
OFF,itwillgooff.
IfyousetONatanytime,thepowerindicatorwillautomaticallybeturnedon.


Iftheoutputofthevideocardisdifferenttherequiredspecifications,thecolorlevelmaydeteriorate
duetovideosignaldistortion.Usingthisfunction,thesignallevelisadjustedtofitintothestandard
outputlevelofthevideocardinordertoprovidetheoptimalimage.Activatethisfunctionwhen
whiteandblackcolorsarepresentinthescreen.
 WIDE
Switchtofullscreenmodeaccordingtoinputimagesignal.
ORIGINAL
Changetheinputimagesignalratiotooriginal.
*ThisfunctionworksonlyifinputresolutionislowerthanMonitorsetratio(16:9).


SetstheSUPERENERGYSAVINGfunction.
ON
EnablesSUPERENERGYSAVINGyoucansaveenergywiththisenergy-efficientfunction
OFF DisablesSUPERENERGYSAVING.
RESET ResetsthevaluesoftotalenergyconsumptionreductionandCO2emissionreduction
estimates.


Restoreallfactorydefaultsettingsexcept"LANGUAGE."Pressthe

,
buttonstoreset
immediately.
:Howmuchpowerissavedwhileusingthemonitor.
:ChangetheTOTALPOWERREDUCTIONtoCO2.

545mm(21.5inch) 584mm(23inch)
SUPERSAVING 4W/h 5W/h
LEDSAVING 15W/h 12W/h
SavingDatadependsonthePanel.So,thosevaluesshouldbedifferentfromeachpanelandpanel
vendor.
LGcalculatedthesevaluesbyusing
LEDSavingreferstohowmuchpowercanbesavedusingaWLEDPanelinsteadofCCFLpanel.
SUPERSAVINGreferstohowmuchpowercanbesavedusingtheSUPERENERGYSAVING
function.

background
18
ENG
ENGLISH
CUSTOMIZING SETTINGS

1
PressanybuttononthefrontoftheMonitorsettodisplaytheOSDmenu.
2
PressthebuttontodisplaytheoptionsintheOSDmenu.
3
SettheoptionsbypressingthebuttonsonthefrontoftheMonitorset.
4
SelecttoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,usetheuparrow(
)button.
Theavailablepicturesettingsaredescribedbelow.
 
 Itisamodethattheusercanadjusteachelement.ItcanadjustthecolormodeoftheMainMenu.
 Itisamodethatthescreenisadjustedtothebesttoviewthevideos.
 Itisamodethatthescreenisadjustedtothebestforthetextworks.
 Itisamodethatthescreenisadjustedtothebesttoviewpictures.
 ItisamodethatthescreenisadjustedtothestandardsRGB.
background
19
ENG
ENGLISH
CUSTOMIZING SETTINGS
Theavailablepicturesettingsaredescribedbelow.

WhenmonitorgoestoPowerSavingModewithPCpowersavingoption,onpressinganybuttonand
selectingDualoptionusercanbringbackmonitortonormalmode.

1
PressanybuttononthefrontoftheMonitorsetto
displaytheOSDmenu.
2
Pressthebuttontodisplaytheoptionsinthe
OSDmenu.
3
Settheoptionsbypressingthebuttonsonthefrontof
theMonitorset.
4
SelecttoleavetheOSDmenu.
Toreturntotheuppermenuorsetothermenuitems,
usetheuparrow(
)button.
*Beforeusingbelowfunctions,pleaseinstallDUALPACKAGEprogramme.
 
 OFF IfselectOFF,DUALMONITORoff
EXTENDED ByselectingEXTENDED,usercanusesecondarymonitorasextendedmodeof
primarymonitor.
CLONE ByselectingCLONE,usercanusesecondarymonitorasdonemodeofprimary
monitor.
 ON Helpusertobrowsewebefficientlybydividinginhalf.Helptoarrangeand
movewindowsonscreen.Helpusertocontroldividedwindowsratio.
OFF IfselectOFF,DUALWEBisoff.

background
20
ENG
ENGLISH
TROUBLESHOOTING



Isthepowercordofthedisplay
connected?
Checkandseeifthepowercordisconnectedproperlytothepower
outlet.
Isthepowerindicatorlighton?
PressthePowerbutton.
Isthepoweronandthepower
indicatorblueorgreen?
Adjustthebrightnessandthecontrast.
Isthepowerindicatorflickering?
Ifthedisplayisinpowersavingmode,trymovingthemouseor
pressinganykeyonthekeyboardtobringupthescreen.
TrytoturnonthePC.
Doyouseean"OUTOFRANGE"
messageonthescreen?
ThismessageappearswhenthesignalfromthePC(videocard)is
outofhorizontalorverticalfrequencyrangeofthedisplay.Seethe
'Specifications'sectionofthismanualandconfigureyourdisplay
again.
Doyouseea"CHECKSIGNAL
CABLE"messageonthescreen?
ThismessageappearswhenthesignalcablebetweenyourPCand
yourdisplayisnotconnected.Checkthesignalcableandtryagain.

Doyousee“OSDLOCKED”when
youpushMENUbutton?
Youcansecurethecurrentcontrolsettings,sothattheycannotbe
inadvertentlychanged.YoucanunlocktheOSDcontrolsatanytime
bypushingtheMENUbuttonforseveralseconds:themessage“OSD
UNLOCKED”willappear.

DisplayPositionisincorrect.
Pressthebuttontoautomaticallyadjustyourdisplayimageto
theidealsetting.
Onthescreenbackground,vertical
barsorstripesarevisible.
Pressthebuttontoautomaticallyadjustyourdisplayimageto
theidealsetting.
Anyhorizontalnoiseappearingin
anyimageorcharactersarenot
clearlyportrayed.
Pressthebuttontoautomaticallyadjustyourdisplayimageto
theidealsetting.
Checkandadjustthedisplay
totherecommendedresolutionoradjustthedisplayimagetotheideal
setting.Setthecolorsettinghigherthan24bits(truecolor).
background
21
ENG
ENGLISH
TROUBLESHOOTING

Thescreencolorismonoor
abnormal.
Checkifthesignalcableisproperlyconnectedanduseascrewdriver
tofastenifnecessary.
Makesurethevideocardisproperlyinsertedintheslot.
Setthecolorsettinghigherthan24bits(truecolor)at
.
Thescreenblinks.
Checkifthescreenissettointerlacemodeandifyes,changeittothe
recommendresolution.

Haveyouinstalledthedisplay
driver?
BesuretoinstallthedisplaydriverfromthedisplaydriverCD(or
diskette)thatcomeswithyourdisplay.Or,youcanalsodownloadthe
driverfromourwebsite:http://www.lg.com.
MakesuretocheckifthevideocardsupportsPlug&Playfunction.
Checkandseeifthefrequencyortheresolutionwere
changed.Ifyes,readjustthevideocardtotherecommendresolution.
Iftherecommendedresolution(optimalresolution)isnotselected,lettersmaybeblurredandthe
screenmaybedimmed,truncatedorbiased.Makesuretoselecttherecommendresolution.
ThesettingmethodcandifferbycomputerandO/S(OperationSystem),andresolutionmentioned
abovemaynotbesupportedbythevideocardperformance.Inthiscase,pleaseasktothecomputer
orthevideocardmanufacturer.

background
22
ENG
ENGLISH
SPECIFICATIONS

  54.5cm(21.5inch)FlatPanelActivematrix-TFT
LCDAnti-Glarecoating
Visiblediagonalsize:54.5cm
 0.247mmx0.247mm(PixelPitch)
  30kHzto83kHz(Automatic)
 56Hzto75Hz(D-SUB,DVI-D)
 SeparateSync.Digital
  15pinD-SUBConnector/DVI-DConnector(Digital)
 RGBAnalog(0.7Vp-p/75ohm),Digital
  D-SUB(Analog):1920x1080@60Hz
DVI(Digital):1920x1080@60Hz
 VESA1920x1080@60Hz
 DDC2B(Analog,Digital)
 OnMode:33W(Typ.)
SleepMode≤0.3W
OffMode≤0.3W
 AC100-240V~50/60Hz1.0A


 51.3cmx39.8cmx19.1cm
 51.3cmx31.2cmx5.9cm
 3.2kg
 -5°to15°




10°Cto35°C
10%to80%


-20°Cto60°C
5%to90%non-Condensing
 Attached(),Detached(O)
 Wall-outlettype
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.

background
23
ENG
ENGLISH
SPECIFICATIONS

  58.4cm(23inch)FlatPanelActivematrix-TFTLCD
Anti-Glarecoating
Visiblediagonalsize:58.4cm
 0.265mmx0.265mm(PixelPitch)
  30kHzto83kHz(Automatic)
 56Hzto75Hz(D-SUB,DVI-D)
 SeparateSync.Digital
  15pinD-SUBConnector/DVI-DConnector(Digital)
 RGBAnalog(0.7Vp-p/75ohm),Digital
  D-SUB(Analog):1920x1080@60Hz
DVI(Digital):1920x1080@60Hz
 VESA1920x1080@60Hz
 DDC2B(Analog,Digital)
 OnMode:36W(Typ.)
SleepMode≤0.3W
OffMode≤0.3W
 AC100-240V~50/60Hz1.0A


 54.7cmx41.7cmx19.1cm
 54.7cmx33.1cmx5.9cm
 3.6kg
 -5°to15°




10°Cto35°C
10%to80%


-20°Cto60°C
5%to90%non-Condensing
 Attached(),Detached(O)
 Wall-outlettype
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.

background
24
ENG
ENGLISH
SPECIFICATIONS







720x400 31.468 70 -/+
640x480 31.469 60 -/-
640x480 37.500 75 -/-
800x600 37.879 60 +/+
800x600 46.875 75 +/+
1024x768 48.363 60 -/-
1024x768 60.123 75 -/-
1152x864 67.500 75 +/+
1280x1024 63.981 60 +/+
1280x1024 79.976 75 +/+
1680x1050 65.290 60 -/+
1920x1080 67.500 60 +/+ RecommendMode

 
OnMode Blue
SleepMode BlinkingBlue
OffMode Off
background
background
Make sure to read the Safety Precautions before
using the product.
Keep the Owner’s Manual (CD) in an accessible
place for future reference.
The model and serial number of the SET is
located on the back and one side of the SET.
Record it below should you ever need service.
As an ENERGY STAR Partner LGE
U. S. A.,Inc. has determined that this
product meets the ENERGY STAR
guidelines for energy efficiency.
ENERGY STAR is a set of power-saving
guidelines issued by the U.S.Environmental
Protection Agency(EPA).
MODEL
SERIAL

Specifications

Indexed Terms: Monitor

LG Electronics IPS235T-BN Questions and Answers

Find answers or ask new question.
Questions and Answers

Related Products

No image
LG Electronics IPS237L-BN 23” Class Slim IPS LED Monitor with MHL (23" diagonal)
2020-01-05 2 docs
Product LG Electronics 27MP37HQ image
LG Electronics 27MP37HQ IPS LED COMPUTER MONITOR
2020-12-12 3 docs
Product LG Electronics 24MP55HQ P image
LG Electronics 24MP55HQ-P IPS LED Monitor
2020-09-08 3 docs
Product LG Electronics 27EA63V image
LG Electronics 27EA63V - 27'' Ips Led Lcd Monitor
2020-12-13 1 docs
No image
LG Electronics 32QK500 31.5'' Qhd Ips Led Monitor
2020-10-27 2 docs
Product LG Electronics 27EA53V image
LG Electronics 27EA53V Lg - 27'' Lg Ips Led Lcd Monitor
2020-12-13 1 docs
