Microwave Oven
MS23J5133A*
User manual
Please be advised that the Samsung warranty does NOT cover
service calls to explain product operation, correct improper
installation, or perform normal cleaning or maintenance.
MS23J5133A_EU_DE68-04328C-00_EN.indd 1 2015-01-21 6:22:57
2
English
Contents
Contents
Using this user manual 4
The following symbols are used in this User Manual: 4
Safety instructions 5
Important safety instructions 5
Installation & wiring instructions 13
Wiring instructions 14
Cooking instructions on food packaging 15
Cooking instructions 16
Installation 17
Accessories 17
Installation site 18
Turntable 18
Maintenance 19
Cleaning 19
Replacement (repair) 21
Care against an extended period of disuse 21
Quick look-up guide 22
Oven features 23
Oven 23
Control panel 24
Oven use 25
How a microwave oven works 25
Checking that your oven is operating correctly 26
Setting the time 27
Cooking/Reheating 28
Power levels 29
Adjusting the cooking time 29
Setting the energy save mode 30
Stopping the cooking 30
Using the healthy cooking features 31
Using the my plate features 34
Using the power defrost features 35
Using the soften/melt features 37
Using the keep warm features 38
Using the memory cook features 39
To use the memory cook setting 39
Using the deodorisation features 40
MS23J5133A_EU_DE68-04328C-00_EN.indd 2 2015-01-21 6:22:57
4
English
Using this user manual
Using this user manual
You have just purchased a SAMSUNG microwave oven. Your Owner’s Instructions contains
valuable information on cooking with your microwave oven:
• Safety precautions
• Suitable accessories and cookware
• Useful cooking tips
• Cooking tips
The following symbols are used in this User Manual:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
NOTE
Useful tips, recommendations, or information that helps users manipulate the product.
Using this user manual
MS23J5133A_EU_DE68-04328C-00_EN.indd 4 2015-01-21 6:22:58
English
5
Safety instructions
Safety instructions
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
MAKE SURE THAT THESE SAFETY PRECAUTIONS ARE OBEYED AT ALL
TIMES.
BEFORE USING THE OVEN, CONFIRM THAT THE FOLLOWING
INSTRUCTIONS ARE FOLLOWED.
Microwave function only
WARNING: If the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person.
WARNING: It is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the removal of a
cover which gives protection against exposure to microwave energy.
WARNING: Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
This appliance is intended to be used in household only and it is not
intended to be used such as:
• staff kitchen areas in shops, ofces and other working environments;
• farm houses;
• by clients in hotels, motels and other residential environments;
• bed and breakfast type environments.
WARNING: Only allow children to use the oven without supervision
when adequate instructions have been given so that the child is able to
use the oven in a safe way and understands the hazards of improper
use.
MS23J5133A_EU_DE68-04328C-00_EN.indd 5 2015-01-21 6:22:58
6
