F9 Instructions for Use
2
Table of contents
Your F9
Control elements 4
Important information 6
Proper use ......................................................................................................................................................6
For your safety ...............................................................................................................................................6
1 Preparing and using for the first time 10
JURA on the Internet ....................................................................................................................................10
Setting up the machine ..............................................................................................................................10
Filling the bean container ...........................................................................................................................10
First-time use ................................................................................................................................................10
Determining the water hardness ..............................................................................................................13
Connecting milk ...........................................................................................................................................14
Filling the water tank ...................................................................................................................................14
2 Preparation 15
Ways of preparing a beverage ...................................................................................................................15
Ristretto, espresso and coffee ....................................................................................................................16
Two ristretti, two espressi and two coffees .............................................................................................16
Latte macchiato, cappuccino and other speciality coffees with milk .................................................17
Ground coffee ...............................................................................................................................................18
Permanently setting the amount of water for the cup size .................................................................19
Adjusting the grinder .................................................................................................................................20
Hot water ......................................................................................................................................................20
3 Daily operation 21
Switching on the machine ..........................................................................................................................21
Daily maintenance .......................................................................................................................................21
Regular maintenance .................................................................................................................................22
Switching off the machine .........................................................................................................................22
4 Permanent settings in programming mode 23
Product settings ..........................................................................................................................................24
Adjusting the product settings .................................................................................................................24
Replacing products on the start screen ..................................................................................................25
Renaming a product ...................................................................................................................................26
Automatic switch-off .................................................................................................................................. 27
Energy-saving mode ..................................................................................................................................28
Maintenance settings .................................................................................................................................28
Setting the water hardness .......................................................................................................................29
Display settings ...........................................................................................................................................30
Unit for amount of water ...........................................................................................................................30
Restore factory settings ..............................................................................................................................31
Language .......................................................................................................................................................31
Querying information ................................................................................................................................32
3
Table of contents
Warnings
J WARNING
J CAUTION
Always take note of any information marked with the words CAUTION or
WARNING and a warning sign. The signal word WARNING draws your attention
to potential serious injury, and the signal word CAUTION to potential minor
injury.
CAUTION CAUTION draws your attention to potential damage to the machine.
Symbols used
T
Prompt to take action. This symbol means that you are being prompted to
perform some action.
E
Information and tips to make it even easier to use your F9.
‘Espresso’ Display
Symbol description
5 Maintenance 33
Rinsing the machine ................................................................................................................................... 33
Rinsing the milk system .............................................................................................................................34
Cleaning the milk system ..........................................................................................................................34
Dismantling and rinsing the dual spout .................................................................................................35
Inserting and activating the filter .............................................................................................................36
Changing the filter ......................................................................................................................................37
Cleaning the machine ................................................................................................................................39
Descaling the machine ..............................................................................................................................40
Descaling the water tank ...........................................................................................................................42
Cleaning the bean container .....................................................................................................................42
6 Display messages 43
7 Troubleshooting 44
8 Transport and environmentally friendly disposal 45
Transport/ Emptying the system .............................................................................................................45
Disposal .........................................................................................................................................................45
9 Technical data 46
10 Index 47
11 JURA contact details/ Legal information 52
4
Control elements
Control elements
2
7
1
4
3
6
5
14
13
12
11
10
8
9
1 Bean container with aroma preservation
cover
2 Water tank cover
3 Water tank
4 Power switch and mains cable
(back of the machine)
5 Coffee grounds container
6 Drip tray
7 Cup grille
8 Filler funnel cover
9 Filler funnel for ground coffee
10 Storage compartment cover
11 Grinder adjustment switch
12 Measuring spoon for ground coffee
13 Hot-water spout
14 Height-adjustable dual spout
5
Control elements
P
31 2
4
6
5
Top of the machine
1 Q On/Off button
2 g Rotary Switch
3 O P button (programming)
Front
4 Display
5 Multi-function buttons (button function
depends on what is shown in the display)
6 l Switch for hot water preparation
6
Important information
Important information
The machine is designed and intended for private
domestic use. It should only be used for coffee
preparation and to heat milk and water. Use for any
other purpose will be deemed improper. JURA
Elektroapparate AG cannot accept any responsibil-
ity for the consequences of improper use.
Before using the machine read these instructions
for use thoroughly and completely and comply
with the instructions they contain. A warranty ser-
vice is not applicable for damage or defects caused
by non-compliance with the instructions for use.
Keep these instructions for use close to the machine
and pass them on to the next user.
Please carefully read and observe the important
safety information set out below.
To avoid danger of potentially fatal electric shock:
U
Never use a machine which is damaged or has
a defective mains cable.
U
In the event of signs of damage, for example if
there is a smell of burning, unplug the machine
immediately from the mains supply and con-
tact JURA service.
U
If the mains cable of this machine is damaged,
it must be repaired either directly by JURA or
by an authorised JURA service centre.
U
Make sure that the F9 and the mains cable are
not located close to hot surfaces.
U
Be careful to ensure that the mains cable is not
trapped and does not rub against sharp edges.
Proper use
For your safety
J
7
Important information
U
Never open and repair the machine yourself.
Do not modify the machine in any way that is
not described in these instructions for use. The
machine contains live parts. If opened, there is
a danger of potentially fatal injury. Repairs
may only be carried out by authorised JURA
service centres, using original spare parts and
accessories.
U
To completely and safely disconnect the
machine from the power supply, first switch off
the F9 using the On/Off button and then at the
power switch. Only then should you remove
the mains plug from the power socket.
There is a risk of scalds or burns on the spouts.
U
Place the machine out of the reach of children.
U
Do not touch any hot parts. Use the handles
provided.
A defective machine is not safe and could cause
injury or fire. To avoid damage and any associated
risk of injury or fire:
U
Never allow the mains cable to loosely hang
down. The mains cable could pose a tripping
hazard or become damaged.
U
Protect the F9 from environmental influences
such as rain, frost and direct sunlight.
U
Do not immerse the F9, mains cable or
connections in water.
U
Do not put the F9 or any individual parts in the
dishwasher.
U
Switch your F9 off at the power switch before
any cleaning operation. Always wipe the F9
with a damp cloth rather than a wet one, and
protect it from prolonged exposure to water
splash.
8
Important information
U
Only connect the machine to the mains volt-
age in accordance with the information on the
rating plate. The rating plate is located on the
underside of your F9. Further technical data is
provided in these instructions for use (see
Chapter 9 ‘Technical data’).
U
Connect the F9 directly to a domestic power
socket. Using multi-socket adapters or exten-
sion cords may cause overheating.
U
Please only use original JURA maintenance
products. Use of products that are not explic-
itly recommended by JURA could damage the
F9.
U
Do not use any coffee beans treated with addi-
tives or caramelised coffee beans.
U
Only fill the water tank with fresh, cold water.
U
Switch the machine off at the power switch if
you are going to be absent for a longer period
of time.
U
Children may not clean or service the machine
unless supervised by a responsible person.
U
Do not allow children to play with the machine.
U
Keep children under the age of 8 away from
the machine, or supervise them constantly.
U
Children aged 8 and over may only operate
the machine without supervision if they have
been instructed in how to use it safely. Chil-
dren must be able to recognise and under-
stand the potential dangers arising from incor-
rect use.
9
Important information
People, including children, who
U
do not have the physical, sensory or mental
capabilities to use the machine safely or
U
are inexperienced or lack knowledge in how to
use the machine safely
must be supervised by a responsible person when
using it, or must be instructed in how to use it cor-
rectly.
Safety when handling the CLARIS Blue filter
cartridge:
U
Filter cartridges should be kept out of the
reach of children.
U
Store filter cartridges in a dry place in the
sealed packaging.
U
Protect cartridges from heat and direct sun-
light.
U
Do not use damaged filter cartridges.
U
Do not open filter cartridges.
10
1 Preparing and using for the first time
1 Preparing and using for the first time
Visit us on the Internet. You can download short operating instruc-
tions for your machine from the JURA website (www.jura.com). You
will also find interesting and up-to-date information on your F9 and
on every aspect of coffee.
When setting up your F9, please note the following:
U
Place the F9 on a horizontal surface that is not sensitive to
water.
U
Choose a spot for your F9 which protects the machine against
overheating. Ensure that the ventilation slots are not covered.
Coffee beans which have been treated with additives (e.g. sugar),
ground coffee or freeze-dried coffee will damage the grinder.
T Only use roasted, untreated coffee beans to fill the bean con-
tainer.
T Remove the aroma preservation cover.
T Remove any dirt or foreign objects from inside the bean
container.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
When using the machine for the first time, you can choose whether
you want to operate F9 with or without the CLARIS Blue filter
cartridge. If the water hardness is 10 °dH or more, we recommend
using the filter cartridge. If you do not know the hardness of your
water, you can find this out first (see Chapter 1 ‘Preparing and using
for the first time – Determining the water hardness’).
JURA on the Internet
Setting up the machine
Filling the bean container
CAUTION
First-time use
11
1 Preparing and using for the first time
If the machine is operated with a defective mains cable, there is a
danger of potentially fatal electric shock.
T Never use a machine which is damaged or has a defective
mains cable.
Precondition:The bean container has been filled.
T Insert the mains plug into a power socket.
3 T Switch on the F9 using the power switch on the back of the
machine.
Q T Press the On/Off button to switch the F9 on.
The display shows the languages you can choose from.
E To display more languages, press the
‘ > ’ button (bottom
right).
T Press the button that corresponds to the language you want,
e.g.
‘English’.
‘Saved’ appears briefly on the display to confirm the setting.
‘Use filter’
E Now decide whether you want to operate your F9 with or
without a CLARIS Blue filter cartridge.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Press the
‘Active’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Insert filter’
T Remove the water tank and rinse it with cold water.
T Open the filter holder and insert the filter cartridge into the
water tank, exerting slight pressure.
T Close the filter holder. It will click into place audibly.
E After two months, the filter will cease to work. Set the date on
the date plate on the filter holder in the water tank.
J
WARNING
First-time use with filter
cartridge activation
CAUTION
12
1 Preparing and using for the first time
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Press the
‘Next’ button.
‘Switch open’
T Place a receptacle under the hot-water spout and dual spout.
l T Turn the switch to them position.
‘Filter is being rinsed’, water flows out of the hot-water
spout.
E You can interrupt rinsing of the filter at any time. To do this,
turn the switch clockwise. Turn the switch anticlockwise to
continue rinsing the filter.
E The water may be slightly discoloured. This is not harmful to
health and does not affect the taste.
Rinsing of the filter stops automatically after approximately
300ml.
‘Switch close’ appears on the display.
y T Turn the switch to the °position.
‘System is filling’, the system fills up with water.
‘Machine is heating’, the machine heats up.
‘Machine is rinsing’, the system is rinsed. The rinse stops
automatically.
‘Please select product’ appears on the display.
Your F9 is ready for use.
E The display shows the products you can prepare.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Press the
‘Inactive’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Water hardness’
E If you do not know the hardness of your water, you must find
this out first (see Chapter 1 ‘Preparing and using for the first
time – Determining the water hardness’).
First-time use without filter
cartridge activation
CAUTION
13
1 Preparing and using for the first time
g T Turn the Rotary Switch to change the water hardness set-
ting, e.g. to
‘25°dH’.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Fill water tank.’
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘Switch open’
T Place a receptacle under the hot-water spout and dual spout.
l T Turn the switch to them position.
‘System is filling’, water flows out of the hot-water spout.
The operation stops automatically.
‘Switch close’ appears on
the display.
y T Turn the switch to the °position.
‘System is filling’, the system fills up with water.
‘Machine is heating’, the machine heats up.
‘Machine is rinsing’, the system is rinsed. The rinse stops
automatically.
‘Please select product’ appears on the display.
Your F9 is ready for use.
E The display shows the products you can prepare.
You can find out what the water hardness is by using the Aquadur®
test strip supplied as standard.
T Hold the test strip briefly (for 1second) under flowing water.
Shake off the water.
T Wait for about 1minute.
T You will then be able to read the degree of water hardness
from the discolouration of the Aquadur® test strip and the
description on the packaging.
Determining the water
hardness
14
1 Preparing and using for the first time
Your F9 creates fine, creamy, feather-light milk foam with a perfect
consistency. The most important requirement for frothing milk is a
milk temperature of 4–8°C. We would therefore recommend using
a milk cooler or a vacuum milk container.
T Remove the protective cover from the dual spout.
T Connect the milk pipe to the dual spout.
T Connect the other end of the milk pipe to a milk container
or immerse it in a milk carton.
Daily maintenance of the machine and hygiene when handling milk,
coffee and water are key to a perfect coffee result in the cup every
time. You should therefore change the water daily.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Open the water tank cover.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Close the water tank cover.
Connecting milk
Filling the water tank
CAUTION
15
2 Preparation
2 Preparation
E You can stop the machine at any time while a speciality coffee
or hot water is being prepared. Just press any button (for a
speciality coffee) or return the switch to its original position
(for hot water preparation).
E During the grinding operation you can select the coffee
strength of single products by turning the Rotary Switch g.
E During preparation, you can change the preset amount of
water or milk foam by turning the Rotary Switch g.
E You can follow the current status of preparation on the display.
Coffee tastes best served hot. A cold porcelain cup cools the bever-
age – and impairs the taste. We therefore recommend prewarming
the cups. The full coffee aroma can develop only in prewarmed cups.
You can purchase a JURA cup warmer from your specialised dealer.
You can make permanent settings for all products in programming
mode (see Chapter 4 ‘Permanent settings in programming mode –
Adjusting the product settings’).
The F9 offers various ways of preparing a speciality coffee, milk foam
or hot water:
U
Preparation using the start screen: Simply press the corre-
sponding preparation button for the product shown on the
display (start screen) that you want.
The following products are displayed as standard on the start
screen:
U
‘Espresso’
U
‘Coffee’
U
‘Flat white’
U
‘Latte macchiato’
U
Using the product selector view (Rotary Selection): Only
some of the products you can prepare are shown on the start
screen. As soon as you turn the Rotary Switch, more products
are displayed in a product selector view.
Turn the Rotary Switch to bring the product you want into
focus. Start preparation by pressing the Rotary Switch or the
‘Prepare’ button.
Ways of preparing a
beverage
16
2 Preparation
The following additional products are shown in the product
selector view:
U
‘Ristretto’
U
‘2 ristretti’
U
‘2 espressi’
U
‘2 coffees’
U
‘Special’
U
‘Cappuccino’
U
‘Macchiato’
U
‘Caffè latte’
U
‘Portion milk foam’
E The product selector view disappears automatically after
10seconds if no preparation is started.
E You have the option of replacing the four products on the start
screen with your personal favourites (see Chapter 4 ‘Perma-
nent settings in programming mode – Replacing products on
the start screen’). Please note that the descriptions provided
in the following sections always refer to the default settings.
Example:Proceed as follows to prepare one coffee.
Precondition:
‘Please select product’ is displayed.
T Place a cup under the dual spout.
T Press the
‘Coffee’ button.
Preparation starts.
‘Coffee’ and the coffee strength are dis-
played. The preset amount of water for coffee flows into the
cup.
Preparation stops automatically.
‘Please select product’
appears on the display.
There are several ways of preparing two speciality coffees.
U
Using the product selector view:
U
Bring one of the double products ‘2 ristretti’, ‘2 espressi’ or
‘2 coffees’ into focus and press the Rotary Switch or the but-
ton
‘Prepare’.
U
When preparing a single product:
U
Press the single product button twice within 2 seconds to
start preparing the relevant double product.
Ristretto, espresso and
coffee
Two ristretti, two espressi
and two coffees
17
2 Preparation
Example:Proceed as follows to prepare two coffees (using product
selector view).
Precondition:The start screen is displayed.
T Place two cups under the dual spout.
g T Turn the Rotary Switch to view the product selector.
g T Turn the Rotary Switch until the
‘2 coffees’ product is in
focus.
k T Press the Rotary Switch to start preparation.
Coffee preparation starts. The preset amount of water for
coffee flows into the cups. Preparation stops automatically.
Your F9 is once more ready for use.
Your F9 prepares latte macchiato, cappuccino, flat white and other
speciality coffees with milk at the touch of a button. There is no need
to move the glass or cup.
Example:Proceed as follows to prepare one latte macchiato.
Precondition:
‘Please select product’ is displayed. Milk is connected
to the dual spout.
T Place a glass under the dual spout.
T Press the
‘Latte macchiato’ button.
‘Latte macchiato’, the preset amount of milk foam flows into
the glass.
E There is a short interval while the hot milk separates from the
milk foam. This allows the typical layers of a latte macchiato
to form.
Coffee preparation starts. The preset amount of water for
espresso flows into the glass. Preparation stops automati-
cally.
‘Please select product’ appears on the display.
To ensure that the milk system in the dual spout always works prop-
erly, you must clean it daily (see Chapter 5 ‘Maintenance – Cleaning
the milk system’).
Latte macchiato,
cappuccino and other
speciality coffees with
m i l k
18
2 Preparation
You can choose to use a second coffee variety, for example decaf-
feinated coffee, with the filter funnel for ground coffee.
E Never add more than two level measuring spoons of ground
coffee.
E Use ground coffee which is not ground too finely. Very fine
coffee can block up the system so that the coffee only comes
out in drips.
E If you did not fill the machine with a sufficient amount of
ground coffee,
‘Not enough ground coffee’ is displayed and
the F9 stops the operation.
E The desired speciality coffee must be prepared within approx-
imately one minute after filling with the ground coffee. Oth-
erwise the F9 stops the operation and is once more ready for
use.
All speciality coffees with ground coffee are always prepared follow-
ing the same model.
Example:Proceed as follows to prepare one espresso using ground
coffee.
Precondition:
‘Please select product’ is displayed.
T Place an espresso cup under the coffee spout.
T Open the cover of the filler funnel for ground coffee.
‘Please add ground coffee’
T Place one level measuring spoon of ground coffee into the
filler funnel.
T Close the cover of the filler funnel.
‘Please select product’
T Press the ‘Espresso’ button.
Preparation starts.
‘Espresso’, the preset amount of water for
espresso flows into the cup.
Preparation stops automatically.
‘Please select product’
appears on the display.
Ground coffee
19
2 Preparation
It is easy to permanently adjust the amount of water for all single
products to the cup size. Adjust the amount once as shown in the
following example. Every time you prepare a drink in the future, this
amount will be dispensed.
Example: Proceed as follows to permanently set the amount of
water for one coffee.
Precondition:
‘Please select product’ is displayed.
T Place a cup under the dual spout.
T Press and hold the
‘Coffee’ button until ‘Enough coffee?
Press button’
appears.
T Release the
‘Coffee’ button.
Preparation starts and the coffee flows into the cup.
T Press any button as soon as there is sufficient coffee in the
cup.
Preparation stops.
‘Saved’ appears briefly on the display. The
set amount of water for one coffee is permanently stored.
‘Please select product’ appears on the display.
E You can alter this setting at any time by repeating the above
procedure.
E The amount can be permanently adjusted to the cup size for
the products shown in the product selector too. To do this,
press and hold the Rotary Switch k until
‘Enough coffee?
Press button’
appears.
E You can also permanently set the amount of water for all spe-
ciality coffees and hot water in programming mode (see
Chapter 4 ‘Permanent settings in programming mode –
Adjusting the product settings’).
Permanently setting the
amount of water for the
cup size
20
2 Preparation
You can adjust the grinder on a continuous scale to suit the degree
of roast of your coffee.
If you adjust the consistency of grind when the grinder is not oper-
ating, the grinder adjustment switch could be damaged.
T Only adjust the consistency of grind when the grinder is run-
ning.
The consistency of grind is correct if the coffee flows regularly from
the coffee spout. In addition a fine, thick crema forms.
Example: Proceed as follows to change the consistency of grind
during the preparation of an espresso.
T Place a cup under the coffee spout.
T Open the storage compartment cover.
T Press the
‘Espresso’ button to start preparation.
T Turn the grinder adjustment switch to the desired position
while the grinder is running.
The preset amount of water flows into the cup. Preparation
stops automatically.
T Close the storage compartment cover.
There is a danger of scalding from hot water splashes.
T Avoid direct contact with the skin.
Precondition:
‘Please select product’ is displayed.
T Place a cup under the hot-water spout.
l T Turn the switch to them position.
‘Hot water’, the preset amount of water flows into the cup.
Preparation stops automatically.
‘Switch close’
y T Turn the switch to the °position.
‘Please select product’ appears on the display.
Adjusting the grinder
CAUTION
Hot water
J
CAUTION
21
3 Daily operation
3 Daily operation
Daily maintenance of the machine and hygiene when handling milk,
coffee and water are key to a perfect coffee result in the cup every
time. You should therefore change the water daily.
Precondition:Your F9 is switched on at the power switch.
T Place a receptacle under the dual spout.
Q T Press the On/Off button to switch the F9 on.
‘Welcome to JURA’
‘Machine is heating’
‘Machine is rinsing’
, the system is rinsed. The rinse stops
automatically.
‘Please select product’ appears on the display.
Your F9 is ready for use.
To ensure that you get many years of reliable service out of your F9
and to guarantee the optimum coffee quality, the machine requires
daily maintenance.
T Pull out the drip tray.
T Empty the coffee grounds container and the drip tray. Rinse
them both with warm water.
E Always empty the coffee grounds container when the machine
is switched on. This is the only way of resetting the coffee
grounds counter.
T Refit the coffee grounds container and the drip tray.
T Rinse the water tank with clean water.
T Remove the milk pipe and rinse it thoroughly under running
water.
T Dismantle and rinse the dual spout (see Chapter 5 ‘Mainte-
nance – Dismantling and rinsing the dual spout’).
T Wipe the surface of the machine with a clean, soft, damp
cloth (e.g. microfibre cloth).
Switching on the
machine
Daily maintenance
22
3 Daily operation
Carry out the following maintenance actions regularly or as requi-
red:
U
In the interests of hygiene, we recommend changing the milk
pipe on a regular basis (approximately every 3 months).
Replacement pipes are available from specialised dealers
(JURA original accessory set for frothers).
U
Clean the inside of the water tank, e.g. with a brush. Further
information about the water tank is provided in these instruc-
tions for use (see Chapter 5 ‘Maintenance – Descaling the
water tank’).
U
Traces of milk and coffee may stick to the top and bottom of
the cup grille. If this happens, clean the cup grille.
When the F9 is switched off, the system is automatically rinsed if a
speciality coffee has been prepared.
Precondition:
‘Please select product’ is displayed (or ‘Rinse the milk
system’
if milk has been prepared).
T Place a receptacle under the dual spout.
Q T Press the On/Off button.
If milk has been prepared, the milk system is first rinsed
(
‘Milk system is being rinsed’).
‘Machine is rinsing’, the system rinses itself. The operation
stops automatically. Your F9 is switched off.
E When the F9 is switched off with the On/Off button, the
machine consumes less than 0.1 W of standby energy. The
machine can be completely disconnected from the power
supply using the power switch.
Regular maintenance
Switching off the
machine
23
4 Permanent settings in programming mode
4 Permanent settings in programming mode
Press the P button to enter programming mode. You can navigate
through the programme items and permanently save the required
settings simply by turning the Rotary Switch and using the multi-
function buttons. The following settings can be made:
Programme item Sub-item Explanation
‘Maintenance status’
(
‘1/7’ and ‘2/7’)
‘Clean’,
‘Change the filter’ (only
if filter is activated),
‘Descale’ (only if filter is
not activated),
‘Cappuccino cleaning’,
‘Rinse the coffee system’,
‘Rinse the milk system’
T Start the required maintenance pro-
gramme here.
‘Product settings’
(
‘3/7’)
‘Expert mode’,
‘Factory setting’
T Select your settings for speciality coffees
and hot water.
T Reset the settings for single products to
their factory setting.
‘Machine settings’
(
‘4/7’)
‘Choose language’,
‘Switch off after’,
‘Save energy’,
‘Factory setting’
T Select your language.
T Set the time after which the F9 should
switch off automatically.
T Select an energy-saving mode.
T Reset the machine to its factory setting.
‘Machine settings’
(
‘5/7’)
‘Units’,
‘Display’
T Select the unit for the amount of water.
T Change the display settings.
‘Maintenance settings’
(
‘6/7’)
‘Use filter’,
‘Water hardness’ (only if
filter is not activated),
‘Switch-on rinse’
T Indicate whether you are operating your F9
with or without a CLARIS Blue filter cartridge.
T Adjust the water hardness.
T Change the settings for switch-on rinse.
‘Information’ (‘7/7’) ‘Product counter’,
‘Maintenance counter’,
‘Version’
T Keep track of all products prepared and
view the number of maintenance pro-
grammes performed.
24
4 Permanent settings in programming mode
In the programme item ‘Product settings’ (‘3/7’) you can make the
following settings:
U
‘Expert mode’
U
Set individual settings for all speciality coffees, milk and hot
water (see Chapter 4 ‘Permanent settings in programming
mode – Adjusting the product settings’).
U
Replace the products on the start screen with your favour-
ites (see Chapter 4 ‘Permanent settings in programming
mode – Replacing products on the start screen’).
U
Change the names of individual products (see Chapter 4
‘Permanent settings in programming mode – Renaming a
product’).
U
‘Factory setting’
U
Reset the set values for individual products to their factory
setting.
In the programme item
‘Product settings’ (‘3/7’) / ‘Expert mode’ you
can make individual settings for all speciality coffees and hot water.
The following permanent settings can be made:
Product Coffee strength Amount More settings
Ristretto,
Espresso,
Coffee,
Special coffee
8 levels Amount of coffee:
25ml–240ml
Temperature
(normal, high),
Product name
2 ristretti,
2 espressi,
2 coffees
– Amount of coffee: The amount
set for the single product is
doubled.
Temperature (as for
single product),
Product name
Cappuccino,
Latte macchiato,
Espresso
macchiato,
Caffè latte,
Flat white
8 levels Amount of coffee:
25ml–240ml
Milk foam: 0sec.–120sec.
Interval: 0sec.–120sec. (not
for caffè latte and flat white)
Temperature
(normal, high),
Product name
Portion of milk
foam
– Milk foam: 0sec.–120sec. Product name
Hot water – Water: 25ml–450ml Temperature (low,
normal, high),
Product name
Product settings
Adjusting the product
settings
25
4 Permanent settings in programming mode
Permanent settings in programming mode always follow the same
model.
Example:Proceed as follows to change the coffee strength for one
coffee.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Product settings’ (‘3/7’) is dis-
played.
T Press the
‘Expert mode’ button.
‘Expert mode’
E Next select the button of the product for which you would like
to make settings. No product is prepared at this point.
T Press the
‘ > ’ button (bottom right) until ‘Coffee’ is dis-
played.
T Press the
‘Coffee’ button.
‘Coffee’
T Press the ‘Coffee strength’ button.
‘Coffee’ / ‘Coffee strength’
g T Turn the Rotary Switch to change the coffee strength set-
ting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Coffee’
O T Press the P button to exit programming mode.
‘Please select product’
You have the option of replacing the four products on the start
screen with your personal favourites.
Example: Proceed as follows to replace
‘Latte macchiato’ on the
start screen with
‘Macchiato’.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Product settings’ (‘3/7’) is dis-
played.
Replacing products on
the start screen
26
4 Permanent settings in programming mode
T Press the ‘Expert mode’ button.
‘Expert mode’
T Press the ‘ > ’ button (bottom right) several times until
‘Macchiato’ is displayed.
T Press the
‘Macchiato’ button.
‘Macchiato’
g T Press the ‘>’ button (bottom right) until ‘Add to favourites’
is displayed.
T Press the
‘Add to favourites’ button.
‘Select position’
T Press the ‘Latte macchiato’ button.
‘Select position’ / ‘Do you want to replace the current
product?’
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
‘Macchiato’
O T Press the P button to exit programming mode.
‘Please select product’
In the programme item ‘Product settings’ / ‘Expert mode’ you can
rename all of the products.
Example: Proceed as follows to change the product name of
‘Espresso’.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Product settings’ (‘3/7’) is dis-
played.
T Press the
‘Expert mode’ button.
‘Expert mode’
T Press the ‘>’ button (bottom right) until ‘Espresso’ is dis-
played.
T Press the
‘Espresso’ button.
‘Espresso’
T Press the ‘>’ button (bottom right) until ‘Product name’ is
displayed.
Renaming a product
27
4 Permanent settings in programming mode
T Press the ‘Product name’ button.
The available letters, numbers and special characters appear
on the display.
E By pressing the
‘abc/ABC’ button, you can switch between
lower and upper case letters.
g T Turn the Rotary Switch until the letter you want is high-
lighted.
k T Press the Rotary Switch to confirm the letter.
T Continue until the new product name you want is displayed.
E Please note that there is a maximum text length.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
The new product name is displayed.
O T Press the P button to exit programming mode.
‘Please select product’
By instructing your F9 to automatically switch itself off, you can cut
down your energy consumption. If this function is activated, your F9
switches off automatically after the preset time following the last
action on the machine.
You can set the automatic switch-off to 15minutes, 30minutes or
1–9hours.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Machine settings’ (‘4/7’) is dis-
played.
T Press the
‘Switch off after’ button.
‘Switch off after’
g T Turn the Rotary Switch to change the switch-off time (e.g. to
‘2hrs.’).
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Machine settings’
O T Press the P button to exit programming mode.
‘Please select product’
Automatic switch-off
28
4 Permanent settings in programming mode
In the programme item ‘Machine settings’ (‘4/7’) / ‘Save energy’ you
can permanently set an energy-saving mode (Energy Save Mode,
E.S.M.
©
):
U
‘Active’
U
Soon after the last preparation, the F9 stops heating up.
After about 5 minutes the message
‘Energy Save’ is dis-
played.
U
Before you can prepare a speciality coffee, speciality coffee
with milk, or hot water, the machine must heat up.
U
‘Inactive’
U
All speciality coffees, speciality coffees with milk and hot
water can be prepared without having to wait.
Example: Proceed as follows to change the energy-saving mode
from
‘Active’ to ‘Inactive’.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Machine settings’ (‘4/7’) is dis-
played.
T Press the
‘Save energy’ button.
‘Save energy’
T Press the ‘Inactive’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Machine settings’
O T Press the P button to exit programming mode.
‘Please select product’
In the programme item ‘Maintenance settings’ (‘6/7’) you can make
the following settings:
U
‘Use filter’
U
Activate the CLARIS Blue filter cartridge (see Chapter 5
‘Maintenance – Inserting and activating the filter’).
U
‘Water hardness’ (only if filter is not activated)
U
If you do not have a filter cartridge, you will need to set the
water hardness (see Chapter 4 ‘Permanent settings in pro-
gramming mode – Setting the water hardness’).
Energy-saving mode
Maintenance settings
29
4 Permanent settings in programming mode
U
‘Switch-on rinse’
U
‘Manual’: The switch-on rinse must be started manually.
U
‘Automatic’: The switch-on rinse is started automatically.
Example: Proceed as follows to specify that the switch-on rinse
should be started manually.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Maintenance settings’ (‘6/7’) is
displayed.
T Press the
‘Switch-on rinse’ button.
‘Switch-on rinse’
T Press the ‘Manual’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Maintenance settings’
O T Press the P button to exit programming mode.
‘Please select product’
E If you are using the CLARIS Blue filter cartridge and have acti-
vated it, it is not possible to set the water hardness.
The harder the water is, the more frequently the F9 needs to be
descaled. It is therefore important to set the water hardness accu-
rately.
The water hardness can be adjusted on a continuous scale between
1 °dH and 30 °dH.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Maintenance settings’ (‘6/7’) is
displayed.
T Press the
‘Water hardness’ button.
‘Water hardness’
g T Turn the Rotary Switch to adjust the water hardness.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Maintenance settings’
Setting the water
hardness
30
4 Permanent settings in programming mode
O T Press the P button to exit programming mode.
‘Please select product’
In the programme item ‘Machine settings’ (‘5/7’) / ‘Display’ you can
set the display brightness and contrast (as a percentage).
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Machine settings’ (‘5/7’) is dis-
played.
T Press the
‘Display’ button.
‘Display’
g T Turn the Rotary Switch to change the display setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Machine settings’
O T Press the P button to exit programming mode.
‘Please select product’
In the programme item ‘Machine settings’ (‘5/7’) / ‘Units’ you can
select the unit used for the amount of water.
Example:Proceed as follows to change the unit for the amount of
water from
‘ml’ to ‘oz’.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Machine settings’ (‘5/7’) is dis-
played.
T Press the
‘Units’ button.
‘Units’
T Press the ‘oz’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Machine settings’
O T Press the P button to exit programming mode.
‘Please select product’
Display settings
Unit for amount of water
31
4 Permanent settings in programming mode
In the programme item ‘Machine settings’ (‘4/7’) / ‘Factory setting’
the machine can be reset to its factory setting: All user settings
(apart from the ‘filter’ and ‘water hardness’) are reset to factory set-
tings. Your F9 then switches off.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Machine settings’ (‘4/7’) is dis-
played.
T Press the
‘Factory setting’ button.
‘Factory setting’ / ‘Reset the machine to the factory set-
tings?’
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
Your F9 is switched off.
In this programme item you can set the language used by your
F9.
Example:Proceed as follows to change the language from
‘English’
to
‘Deutsch’.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Machine settings’ (‘4/7’) is dis-
played.
T Press the
‘Choose language’ button.
‘Choose language’
E To display more languages, press the ‘ > ’ button (bottom
right).
T Press the
‘Deutsch’ button.
‘Gespeichert’ appears briefly on the display.
‘Geräteeinstellungen’
O T Press the P button to exit programming mode.
‘Bitte wählen’
Restore factory settings
Language
32
4 Permanent settings in programming mode
In the programme item ‘Information’ (‘7/7’) you can view the follow-
ing information:
U
‘Product counter’: Number of prepared speciality coffees,
speciality coffees with milk and hot water
U
‘Maintenance counter’: Number of maintenance programmes
performed (cleaning, descaling etc.)
U
‘Version’: Software version
Example:Proceed as follows to view the number of speciality cof-
fees prepared.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Information’ (‘7/7’) is displayed.
T Press the
‘Product counter’ button.
‘Product counter’
E Press the ‘>’ button (bottom right) to display the number of
additional speciality coffees.
O T Press the P button to exit programming mode.
‘Please select product’
Querying information
33
5 Maintenance
5 Maintenance
Your F9 has the following integrated maintenance programmes:
U
Rinsing the machine (‘Rinse the coffee system’)
U
Rinsing the milk system in the dual spout
(
‘Rinse the milk system’)
U
Cleaning the milk system in the dual spout (‘Cappuccino
cleaning’
)
U
Changing the filter (‘Change the filter’) (only if filter is acti-
vated)
U
Cleaning the machine (‘Clean’)
U
Descaling the machine (‘Descale’) (only if filter is not acti-
vated)
E Clean or descale the machine, rinse the milk system or change
the filter when you are prompted to do so.
E Press the P button to view a list of the maintenance pro-
grammes (
‘Maintenance status’). By referring to the bar you
can see which maintenance programme is due. When the bar
is completely filled with red, your F9 will prompt you to per-
form the appropriate maintenance programme.
E In the interests of hygiene, you should clean the milk system
daily when you have been preparing milk.
You can initiate the rinse operation manually at any time.
Precondition:
‘Please select product’ is displayed.
T Place a receptacle under the dual spout.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
g T Turn the Rotary Switch until
‘Maintenance status’ (‘2/7’) is
displayed.
T Press the
‘Rinse the coffee system’ button to initiate the
rinse operation.
‘Machine is rinsing’, water flows out of the dual spout.
The rinse stops automatically.
‘Please select product’
appears on the display.
Rinsing the machine
34
5 Maintenance
After each milk preparation, the F9 prompts you to perform a milk
system rinsing.
Precondition:
‘Rinse the milk system’ is displayed.
T Place a receptacle under the dual spout.
k T Press the Rotary Switch.
‘Milk system is being rinsed’, water flows out of the dual
spout.
The rinse stops automatically. Your F9 is once more ready for
use.
To ensure that the milk system in the dual spout always works prop-
erly, you must clean it daily when you have been preparing milk.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E JURA milk system cleaner is available from specialised dealers.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
T Press the
‘Cappuccino cleaning’ button.
T Press the
‘Start’ button.
T Press the
‘Start’ button again.
‘Cleaner for Cappuccino’
T Remove the milk pipe from the milk container or carton.
T Pour 250ml of fresh water into a receptacle and add one
capful of milk system cleaner.
T Immerse the milk pipe in the receptacle.
T Place another receptacle under the dual spout.
T Press the
‘Next’ button.
‘Cleaning Cappuccino’, the dual spout and the pipe are
cleaned.
‘Water for Cappuccino’
T Rinse the receptacle thoroughly, fill it with 250ml of fresh
water and immerse the milk pipe in the water.
Rinsing the milk system
Cleaning the milk system
CAUTION
35
5 Maintenance
T Empty the other receptacle and place it under the dual spout
again.
T Press the
‘Next’ button.
‘Cleaning Cappuccino’, the dual spout and the pipe are
rinsed with fresh water.
The operation stops automatically.
‘Milk system cleaning
complete’
appears briefly on the display.
Your F9 is once more ready for use.
The dual spout must be dismantled and rinsed daily if milk has been
prepared to make sure it functions perfectly and also in the interests
of hygiene.
T Remove the milk pipe and rinse it thoroughly under running
water.
T Press the releasing devices and pull the dual spout down and
off.
T Press the milk system down and take it out.
Dismantling and rinsing
the dual spout
36
5 Maintenance
T Dismantle the milk system into its individual parts.
T Rinse all the parts under running water. If there are severely
dried-on milk residues, firstly immerse the individual parts
in a solution of 250ml cold water and 1 capful of JURA milk
system cleaner. Then rinse the parts thoroughly.
T Fit the air intake pipe.
T Reassemble the milk system. When doing this, note the
numbering of the individual parts.
T Fit the assembled individual parts back in the dual spout and
press it firmly.
T Fit the dual spout on the machine. It will click into place audi-
bly.
Your F9 no longer has to be descaled if you are using the
CLARIS Blue filter cartridge. If you did not activate the filter cartridge
the first time you used the machine, you can do this now as follows.
E Perform the ‘inserting the filter’ operation without any inter-
ruptions. This will ensure that your F9 always produces its
best.
Precondition:
‘Please select product’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
1
2
3
Inserting and activating
the filter
37
5 Maintenance
g T Turn the Rotary Switch until ‘Maintenance settings’ (‘6/7’) is
displayed.
T Press the
‘Use filter’ button.
‘Use filter’
T Press the ‘Active’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Insert filter’
T Remove and empty the water tank.
T Open the filter holder and insert the filter cartridge into the
water tank, exerting slight pressure.
T Close the filter holder. It will click into place audibly.
E After two months, the filter will cease to work. Set the date on
the date plate on the filter holder in the water tank.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Press the
‘Next’ button.
‘Switch open’
T Place a receptacle under the hot-water spout.
l T Turn the switch to them position.
‘Filter is being rinsed’, water flows out of the hot-water
spout.
E You can interrupt rinsing of the filter at any time. To do this,
turn the switch clockwise. Turn the switch anticlockwise to
continue rinsing the filter.
E The water may be slightly discoloured. This is not harmful to
health and does not affect the taste.
Rinsing of the filter stops automatically after approximately
300ml.
‘Switch close’ appears on the display.
y T Turn the switch to the °position.
‘Please select product’ appears on the display. The filter is
now activated.
E After 50 litres of water have flowed through, the filter will
cease to work. Your F9 will automatically prompt you to
change the filter.
Changing the filter
38
5 Maintenance
E After two months, the filter will cease to work. Set the date on
the date plate on the filter holder in the water tank.
E If the CLARIS Blue filter cartridge is not activated in program-
ming mode, you will not be prompted to change the filter.
E CLARIS filter cartridges are available from specialised dealers.
Precondition:
‘Change the filter’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
T Press the
‘Change the filter’ button.
‘Change the filter’
T Press the ‘Start’ button.
T Press the
‘Start’ button again.
‘Change filter’
T Remove and empty the water tank.
T Open the filter holder and remove the old CLARIS Blue filter
cartridge.
T Insert a new CLARIS filter cartridge Blue into the water tank,
exerting slight pressure.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Place a receptacle under the hot-water spout.
T Press the
‘Next’ button.
‘Switch open’
l T Turn the switch to them position.
‘Filter is being rinsed’, water flows out of the hot-water
spout.
E You can interrupt rinsing of the filter at any time. To do this,
turn the switch clockwise. Turn the switch anticlockwise to
continue rinsing the filter.
E The water may be slightly discoloured. This is not harmful to
health and does not affect the taste.
Rinsing of the filter stops automatically after approximately
300ml.
‘Switch close’ appears on the display.
y T Turn the switch to the °position.
‘Please select product’ appears on the display.
39
5 Maintenance
After 200preparations or 80switch-on rinses, the F9 will prompt
you to clean it.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E The cleaning programme lasts approximately 20 minutes.
E Do not interrupt the cleaning programme. The quality of
cleaning will be impaired if you do so.
E JURA cleaning tablets are available from specialised dealers.
Precondition:
‘Clean machine’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
T Press the
‘Clean’ button.
‘Clean’
T Press the ‘Start’ button.
T Press the
‘Start’ button again.
‘Empty grounds’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Press the Rotary Switch’
T Place a receptacle under the dual spout.
k T Press the Rotary Switch.
‘Machine is being cleaned’, water flows out of the dual spout.
The operation is interrupted,
‘Add cleaning tablet’.
T Open the cover of the filler funnel for ground coffee.
T Insert a JURA cleaning tablet into the filler funnel.
T Close the cover of the filler funnel.
‘Press the Rotary Switch’
k T Press the Rotary Switch.
‘Machine is being cleaned’, water flows out of the dual spout
repeatedly.
The operation stops automatically.
‘Empty grounds’
Cleaning the machine
CAUTION
40
5 Maintenance
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Please select product’ appears on the display. Cleaning is
now complete.
The F9 builds up deposits of limescale over time and automatically
prompts you to descale it when necessary. The degree of calcifica-
tion depends on the hardness of your water.
E If you use a CLARIS Blue filter cartridge and this is activated,
you will not be prompted to descale.
If the descaling agent comes into contact with the skin or eyes, this
can cause irritation.
T Avoid contact with the skin or eyes.
T Rinse off the descaling agent with clean water. Should you get
any descaling agent in your eye, see a doctor.
If the wrong descaling agent is used, the machine could be dam-
aged and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
If the descaling operation is interrupted, there may be damage to
the machine.
T Allow the descaling programme to run to the end.
If the descaling agent comes into contact with sensitive surfaces
(e.g. marble), damage cannot be ruled out.
T Clean up any splashes immediately.
E The descaling programme lasts approximately 40minutes.
E JURA descaling tablets are available from specialised dealers.
Precondition:
‘Decalcify machine’ is displayed.
O T Press the P button.
‘Maintenance status’ (‘1/7’)
T Press the
‘Descale’ button.
‘Descale’
T Press the ‘Start’ button.
T Press the
‘Start’ button again.
‘Empty drip tray’
Descaling the machine
J
CAUTION
CAUTION
CAUTION
CAUTION
41
5 Maintenance
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Agent in tank’
T Remove and empty the water tank.
T Completely dissolve the contents of one blister (3JURA des-
caling tablets) in a receptacle holding 500ml of lukewarm
water. This may take several minutes.
T Pour the solution into the empty water tank and insert it into
the machine.
‘Switch open’
T Place a receptacle under the hot-water spout and dual spout.
l T Turn the switch to them position.
‘Machine is being descaled’, water flows out of the hot-water
spout repeatedly.
The operation is interrupted,
‘Switch close’.
y T Turn the switch to the °position.
‘Machine is being descaled’, the descaling operation is con-
tinued. Water flows out of the dual spout repeatedly.
The operation is interrupted,
‘Empty drip tray’.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Fill water tank.’
T Empty the receptacle and place it under the hot water and
dual spouts.
T Remove the water tank and rinse it thoroughly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘Switch open’
l T Turn the switch to them position.
‘Machine is being descaled’, the descaling operation is con-
tinued.
The operation is interrupted,
‘Switch close’.
y T Turn the switch to the °position.
‘Machine is being descaled’, the descaling operation is con-
tinued.
The operation is interrupted,
‘Machine is being descaled’.
Water flows out of the dual spout.
‘Empty drip tray’
42
5 Maintenance
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Please select product’ appears on the display. Descaling is
now complete.
E If the descaling operation stops unexpectedly, rinse the water
tank thoroughly.
Limescale deposits may form in the water tank. To ensure correct
function of the machine, descale the water tank from time to time.
T Remove the water tank.
T If you use a CLARIS Blue filter cartridge, remove this.
T Completely fill the water tank and dissolve 3 JURA descaling
tablets in it.
T Leave the water tank with the descaling solution for several
hours (e.g. overnight).
T Empty the water tank and rinse it thoroughly.
T If you use a CLARIS Blue filter cartridge, insert this again.
T Fill the water tank with fresh, cold water and reinsert the
tank.
Coffee beans may be covered with a slight oil film which remains on
the walls of the bean container. These traces may negatively affect
the coffee result. For this reason clean the bean container from time
to time.
Precondition:
‘Fill bean container’ is displayed.
Q T Switch the machine off with the On/Off button.
3 T Switch the machine off at the power switch.
T Remove the aroma preservation cover.
T Clean the bean container with a soft, dry cloth.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
Descaling the water tank
Cleaning the bean
container
43
6 Display messages
6 Display messages
Message Cause/Result Action
‘Fill water tank.’ The water tank is empty. You
cannot prepare any products.
T Fill the water tank (see Chapter 1
‘Preparing and using for the first time –
Filling the water tank’).
‘Empty grounds’ The coffee grounds container is
full. You cannot prepare any
products.
T Empty the coffee grounds container
and the drip tray (see Chapter 3 ‘Daily
operation – Daily maintenance’).
‘Drip tray not
fitted’
The drip tray is not inserted
correctly or is not inserted at all.
You cannot prepare any products.
T Fit the drip tray.
‘Fill bean
container’
The bean container is empty. You
cannot prepare any products.
T Fill the bean container (see Chapter 1
‘Preparing and using for the first time –
Filling the bean container’).
‘Rinse the milk
system’
The F9 requests a milk system
rinsing.
T Perform milk system rinsing (see
Chapter 5 ‘Maintenance – Rinsing the
milk system’).
‘Change the filter’ The filter cartridge no longer
works.
T Replace the CLARIS Blue filter cartridge
(see Chapter 5 ‘Maintenance –
Changing the filter’).
‘Clean machine’ The F9 is prompting you to clean
it.
T Perform cleaning (see Chapter 5
‘Maintenance – Cleaning the machine’).
‘Decalcify
machine’
The F9 is prompting you to
descale it.
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the machine ’).
‘Not enough
ground coffee’
There is insufficient ground
coffee in the machine; the F9
stops the operation.
T The next time you prepare a beverage,
add more ground coffee (see Chapter 2
‘Preparation – Ground coffee’).
‘Too hot’ The system is too hot to start a
maintenance programme.
T Wait for several minutes until the
system has cooled or prepare a special-
ity coffee or hot water.
44
7 Troubleshooting
7 Troubleshooting
Problem Cause/Result Action
Insufficient foam is
produced when the
milk is frothed, or milk
sprays from the dual
spout.
The dual spout is dirty.
T Clean the milk system in the dual spout
(see Chapter 5 ‘Maintenance – Cleaning
the milk system’).
T Dismantle and rinse the dual spout (see
Chapter 5 ‘Maintenance – Dismantling
and rinsing the dual spout’).
Coffee only comes out
in drips when it is
being prepared.
Coffee or ground coffee has
been ground too finely and
is blocking the system. The
same filter cartridge may
have been used several
times or the water hardness
set incorrectly in the
programming mode.
T Put the grinder on a coarser setting or
use coarser ground coffee (see Chapter 2
‘Preparation – Adjusting the grinder’).
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the machine ’).
Water hardness cannot
be adjusted.
The CLARIS Blue filter
cartridge is activated.
T Deactivate the filter cartridge in
programming mode.
‘Fill water tank.’ is
displayed although the
water tank is full.
The water tank float is
trapped.
T Descale the water tank (see Chapter 5
‘Maintenance – Descaling the water
tank’).
Grinder is making a
very loud noise.
There are foreign objects in
the grinder.
T Contact customer support in your
country (see Chapter 11 ‘JURA contact
details/ Legal information’).
‘Error2’ or ‘Error5’ is
displayed.
If the machine was exposed
to the cold for a long period
of time, heating is disabled
for safety reasons.
T Warm the machine at room tempera-
ture.
Other
‘Error’ messages
are displayed.
–
T Switch the F9 off at the power switch.
Contact customer support in your
country (see Chapter 11 ‘JURA contact
details/ Legal information’).
E If you were unable to solve the problem, contact customer
support in your country (see Chapter 11 ‘JURA contact details/
Legal information’).
45
8 Transport and environmentally friendly disposal
8 Transport and environmentally friendly disposal
Keep the packaging for your F9. It should be used to protect the
machine during transport.
In order to protect the F9 from frost during transport, the system
must be emptied.
Precondition:
‘Please select product’ is displayed.
T Remove the milk pipe from the dual spout.
T Place a receptacle under the hot-water spout.
g T Turn the Rotary Switch to view the product selector.
g T Turn the Rotary Switch until the
‘Portion milk foam’ product
is in focus.
k T Press the Rotary Switch.
‘Portion milk foam’, hot steam is discharged from the dual
spout.
T Remove and empty the water tank.
T Turn the Rotary Switch until
‘Amount of milk’ ‘60 sec.’ is dis-
played.
Steam will continue to be discharged from the dual spout
until the system is empty.
‘Fill water tank.’
Q T Press the On/Off button.
Your F9 is switched off.
Please dispose of old machines in an environmentally neutral way.
H
Old machines contain valuable, recyclable materials which should
be recycled. Please therefore dispose of old machines via suitable
collection systems.
Transport/ Emptying the
system
Disposal
46
9 Technical data
9 Technical data
Voltage 220–240V~, 50Hz
Power 1450W
Conformity mark
A
Energy consumption
‘Save energy’ / ‘Active’
approx. 5Wh
Energy consumption
‘Save energy’ / ‘Inactive’
approx. 16Wh
Pump pressure static, max. 15bar
Holding capacity of water tank 1.9l
Holding capacity of bean container 310g
Holding capacity of coffee grounds
container
max. 15 portions
Cable length approx. 1.1m
Weight approx. 9.8kg
Dimensions (W×H×D) 28.5 × 35.5 × 44.5cm
Information for testers (repeat test in accordance with DIN VDE
0701-0702): The central grounding point (CGP) is located on the
underside of the machine, right next to the mains cable's connec-
tion point.
47
10 Index
10 Index
A
Addresses 52
Adjusting the product settings 24
Aroma preservation cover
Bean container with aroma preservation
cover 4
Automatic switch-off 27
B
Bean container
Bean container with aroma preservation
cover 4
Cleaning 42
Filling 10
Bus bar
Technical data 46
Button
On/Off button 5
P button (programming) 5
C
Caffè latte 17
Cappuccino 17
Cappuccino frother cleaning
Cleaning the milk system 34
Cappuccino frother rinsing
Rinsing the milk system 34
Central grounding point 46
Changing a name 26
CLARIS Blue filter cartridge
Changing 37
Inserting and activating the filter 36
Classics 24
Cleaning
Bean container 42
Machine 39
Coffee 16
2 coffees 16
Coffee grounds container 4
Consistency of grind
Adjusting the grinder 20
Grinder adjustment switch 4
Contact details 52
Cover
Filler funnel for ground coffee 4
Storage compartment 4
Water tank 4
Cup grille 4
Customer support 52
D
Descaling
Machine 40
Water tank 42
Display 5
Display messages 43
Display settings 30
Disposal 45
Double product 16
Drip tray 4
Dual spout
Dismantling and cleaning 35
Height-adjustable dual spout 4
E
Emptying the system 45
Energy-saving mode 28
Errors
Troubleshooting 44
Espresso
2 espressi 16
Espresso 16
Espresso macchiato 17
Expert mode 24
F
Factory settings
Restore factory settings 31
Filler funnel
Filler funnel for ground coffee 4
Filling
Bean container 10
Water tank 14
Filter
Changing 37
Inserting and activating the filter 36
First-time use 10
With filter cartridge activation 11
Without filter cartridge activation 12
Flat white 17
48
10 Index
G
Grinder adjustment switch 4
Ground coffee 18
Measuring spoon for ground coffee 4
Grounding point 46
H
Hotline 52
Hot water 20
Hot water preparation
Switch for hot water preparation 5
Hot-water spout 4
I
Instant coffee
Ground coffee 18
Internet 10
J
JURA
Contact details 52
Internet 10
L
Language 31
latte macchiato 17
M
Machine
Cleaning 39
Descaling 40
Regular maintenance 22
Rinsing 33
Setting up 10
Switching off 22
Switching on 21
Mains cable 4
Maintenance 33
Daily maintenance 21
Regular maintenance 22
Maintenance settings 28
Measuring spoon for ground coffee 4
Messages, display 43
Milk
Connecting milk 14
Milk system
Cleaning 34
Rinsing 34
P
Permanently setting the water for the cup
size 19
Permanent settings in programming mode
23
Power switch 4
Preparation 15, 17
2 coffees 16
2 espressi 16
2 ristretti 16
At the touch of a button 15
Caffè latte 17
Cappuccino 17
Coffee 16
Espresso 16
Espresso macchiato 17
Flat white 17
Ground coffee 18
Hot water 20
Latte macchiato 17
Ristretto 16
Two speciality coffees 16
Using the product selector 15
Preparation options 15
Problems
Troubleshooting 44
Product selector view 15
Product settings 24
Adjusting 24
Programming mode 23
Automatic switch-off 27
Display settings 30
Energy-saving mode 28
Language 31
Maintenance settings 28
Product settings 24
Querying information 32
Renaming a product 26
Replacing products on the start screen
25
Restore factory settings 31
Setting the water hardness 29
Unit for amount of water 30
Proper use 6
Q
Querying information 32
49
10 Index
R
Regular maintenance 22
Renaming a product 26
Rinsing
Machine 33
Ristretto 16
2 ristretti 16
Rotary Selection 15
Rotary Switch 5
S
Safety 6
Safety information 6
Settings
Maintenance settings 28
Permanent settings in programming
mode 23
Setting up
Setting up the machine 10
Short operating instructions 10
Spout
Height-adjustable dual spout 4
Hot-water spout 4
Switch for hot water preparation 5
Switching off 22
Switching on 21
Switch-off
Automatic switch-off 27
Symbol description 3
T
Technical data 46
Tel 52
Transport 45
Troubleshooting 44
Two products 16
U
Unit for amount of water 30
Use, First-time 10
W
Water hardness
Determining the water hardness 13
Setting the water hardness 29
Water tank 4
Descaling 42
Filling 14
Website 10
50
51
52
11 JURA contact details/ Legal information
11 JURA contact details/ Legal information
JURA Elektroapparate AG
Kaffeeweltstrasse 10
CH-4626 Niederbuchsiten
Tel. +41 (0)62 38 98 233
@ You will find additional contact details for your country at
www.jura.com.
The machine complies with the following directives:
U
2014/35/EU– Low Voltage Directive
U
2014/30/EU– Electromagnetic Compatibility
U
2009/125/EC– Ecodesign Directive
U
2011/65/EU– RoHS Directive
We reserve the right to make technical changes. The diagrams used
in these instructions for use are for illustration purposes only and do
not represent the original colours of the machine. Some details of
your F9 may vary.
Your opinion is important to us! Use the contact details at
www.jura.com.
The instructions for use contain information which is protected by
copyright. It is not permitted to photocopy these instructions for use
or translate them into another language without the prior written
consent of JURA Elektroapparate AG.
Directives
Technical changes
Feedback
Copyright
J71806/F9/en/201703
