User Manual GE GNE26GMDDES 26.3 Cu. Ft. French-Door Refrigerator

Documents for GE - General Electric GNE26GMDDES

The following documents are available:
User Manual Other Documents Photos
GNE26GMDDES photo
GEAppliances.com
Refrigerators
Bottom Freezer
239D4106P009 49-60683-3 04-14 GE
Safety Instructions ............2, 3
Operating Instructions
Features ..........................4, 5
Controls ..........................69
Dispenser* .........................10
Autofill* ............................11
Water Filter ........................12
Fresh Food Storage Options .....13,14
Climate Zone & Temperature
Controlled Drawer ...............15,16
Freezer ............................17
Automatic Ice maker ...............18
Care and Cleaning ................ 19
Replacing the Lights ................20
Installation Instructions
Preparing to Install the
Refrigerator ....................21, 22
Installing the Refrigerator .......23–33
Installing the Water Line ........34–36
Troubleshooting Tips ......38, 39
Normal Operating Conditions .......37
Truth or Myth ..................40, 41
Consumer Support
Warranty for U.S. Customers ........42
RPWF Water Filter Cartridge Limited
Warranty .........................43
Performance Data Sheet ...........44
State of California Water Treatment
Device Certificate .................45
Consumer Support ........Back Cover
Write the model and serial
numbers here:
Model # ____________________
Serial # ____________________
Find these numbers on a label
on the left side, near the middle
of the refrigerator compartment.
GE and GE Profilemodels
Models that start with PFE, GFE, DFE,
and GNE are Standard Depth Models (SD)
Models that start with PYE and PWE
are Counter Depth Models (CD)
Owner’s Manual and
Installation Instructions
Lock
Control
Water
Cubed
Auto
F
ill
Precise
Fill
Light
*Select Models Only
Loading ...
Loading ...
Loading ...

Specifications

GE - General Electric GNE26GMDDES Questions and Answers


#1 Can you tell me where I can locate the drain hole in this model ? I have water under the veggie basket and I’ve opened the freezer but I cannot find the drain hole ..thanks

We're so sorry you're seeing water pool under the vegetable bin. We're happy to offer some guidance here.

If you have a clogged drain tube, you might see ice and/or water inside on the freezer floor or on the floor in front of the freezer. You may also see water under the full width drawer in the fresh food section. These models require some disassembly to access the defrost drain tube, so we recommend that you contact service.

You can schedule an appointment with a GE Appliance technician by calling 1-800-432-2737 or schedule online at the web address below:
http://www.geappliances.com/ge/service-andsupport/service.htm

#2 Fridge has been moved to new location in redone kitchen. New floor and now doors are not level how do fix that

If the doors are uneven on a French-Door model, use the bottom fresh food hinges to align, following the below instructions:

1. Locate the adjusting screws found on the underside of the fresh food doors of the refrigerator. Refer to the owners manual/installation instructions for exact location. Download a copy of the Owner's Manual and/or Installation Instructions: http://products.geappliances.com/MarketingObjectRetrieval/Dispatcher?RequestType=PDF&Name=49-60683-3.pdf
2. Using a 1/4” or 4 mm wrench, turn the door adjusting screw to the right to raise the door, to the left to lower it. (A nylon plug, imbedded in the threads of the pin, prevents the pin from turning unless a wrench is used.)
3. After one or two turns of the wrench, open and close the refrigerator door and check the alignment at the top of the doors.
4. If necessary, please repeat the above steps until the doors are aligned.
