Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote this
information to your dealer when you require service.
PLASMA TV
OWNER’S MANUAL
MODELS :
42PB4D 50PB4D
60PB4D
1
WARNING / CAUTION
WARNING / CAUTION
To prevent fire or shock hazards, do not expose
this product to rain or moisture.
FCC NOTICE
Class B digital device
This equipment has been tested and found to com-
ply with the limits for a Class B digital device, pur-
suant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not
occur in a particular installation. If this equipment
does cause harmful interference to radio or televi-
sion reception, which can be determined by turning
the equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment to an outlet on a circuit
different from that to which the receiver is con-
nected.
- Consult the dealer or an experienced radio/TV
technician for help.
Any changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
CAUTION
Do not attempt to modify this product in any way
without written authorization from LG Electronics.
Unauthorized modification could void the user’s
authority to operate this product
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of elec-
tric shock to persons.
The exclamation point within an equi-
lateral triangle is intended to alert the
user to the presence of important
operating and maintenance (servicing) instruc-
tions in the literature accompanying the
appliance.
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
WARNING/CAUTION
TO REDUCE THE RISK OF FIRE AND ELEC-
TRIC SHOCK, DO NOT EXPOSE THIS PRO-
DUCT TO RAIN OR MOISTURE.
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV sys-
tem installer’s attention to Article 820-40 of the
National Electric Code (U.S.A.). The code pro-
vides guidelines for proper grounding and, in
particular, specifies that the cable ground shall
be connected to the grounding system of the
building, as close to the point of the cable
entry
as practical.
2
SAFETY INSTRUCTION
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers)that produce heat.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has
two blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong, The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
Only use attachments/accessories specified by
the manufacturer.
Unplug this apparatus when unused for long
periods of time.
Important safety instructions shall be provided with each apparatus. This information shall be given in a separate
booklet or sheet, or be located before any operating instructions in an instruction for installation for use and
supplied with the apparatus.
This information shall be given in a language acceptable to the country where the apparatus is intended to be used.
The important safety instructions shall be entitled “Important Safety Instructions”. The following safety
instructions shall be included where applicable, and, when used, shall be verbatim as follows. Additional safety
information may be included by adding statements after the end of the following safety instruction list. At the
manufacturer’s option, a picture or drawing that illustrates the intent of a specific safety instruction may be
placed immediately adjacent to that safety instruction:
1
2
3
4
5
6
7
8
3
Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Never touch this apparatus or antenna during
a thunder or lighting storm.
Do not allow a impact shock or any objects to
fall into the product, and do not drop onto the
screen with something. (You may be injured or
the product can be damaged.)
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has exposed to rain or moisture,
does not operate normally, or has been
dropped.
CAUTION concerning the Power Cord :
Most appliances recommend they be placed
upon a dedicated circuit; that is, a single outlet
circuit which powers only that appliance and
has no additional outlets or branch circuits.
Check the specification page of this owner's
manual to be certain.
Do not overload wall outlets. Overloaded wall
outlets, loose or damaged wall outlets, extension
cords, frayed power cords, or damaged or
cracked wire insulation are dangerous. Any of
these conditions could result in electric shock
or fire. Periodically examine the cord of your
appliance, and if its appearance indicates dam-
age or deterioration, unplug it, discontinue use
of the appliance, and have the cord replaced
with an exact replacement part by an authorized
servicer. Protect the power cord from physical
or mechanical abuse, such as being twisted,
kinked, pinched, closed in a door, or walked
upon. Pay particular attention to plugs, wall
outlets, and the point where the cord exits the
appliance.
Outdoor use marking :
WARNING - To reduce the risk of fire or elec-
tric shock, do not expose this appliance to rain
or moisture.
Wet Location Marking : Apparatus shall not be
exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall
be placed on or over apparatus.
GROUNDING
Ensure that you connect the earth ground wire
to prevent possible electric shock. If grounding
methods are not possible, have a qualified
electrician install a separate circuit breaker.
Do not try to ground the unit by connecting it
to telephone wires, lightening rods, or gas pipes.
DISCONNECTING DEVICE FROM MAINS
Mains plug is the disconnecting device. The
plug must remain readily operable.
9
12
10
11
13
14
15
16
17
Power
Supply
Short-circuit
Breaker
4
CONTENTS
WARNING / CAUTION
. . . . . . . . . . . . . . . . . . . . . . . . . . .
1
SAFETY INSTRUCTION
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
TV GUIDE ON SCREEN
TM
NOTICES FOR
U.S.A/ DIGITAL CABLE COMPATIBILITY
. . . 6
FEATURES OF THIS TV . . . . . . . . . . . . . . . . . 7
PREPARATION
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Home Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front Panel Controls . . . . . . . . . . . . . . . . . . . . . 10
Back Panel Information . . . . . . . . . . . . . . . . . . . 11
Attaching the TV to a Wall . . . . . . . . . . . . . . . . . 12
Back Cover for Wire Arrangement . . . . . . . . . . . 13
Vesa Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . 14
Desktop Pedestal Installation . . . . . . . . . . . . . . . 15
Antenna or Cable Connection . . . . . . . . . . . . . . 16
CableCARD
TM
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
EXTERNAL EQUIPMENT SETUP
HD Receiver Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
VCR Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Other A/V Source Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
PC Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Audio Out Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
WATCHING TV / CHANNEL CONTROL
Remote Control Functions . . . . . . . . . . . . . . . . . .36
Turning on TV . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Channel Selection . . . . . . . . . . . . . . . . . . . . . . . 39
Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . 39
On-Screen Menus Selection . . . . . . . . . . . . . . . 40
Channel Setup
-Auto Scan ( EZ Scan) . . . . . . . . . . . . . . . . . . 41
- Add / Delete Channel ( Manual Scan) . . . . 42
- Channel Editing . . . . . . . . . . . . . . . . . . . . . . .43
Brief Info. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Input Source Selection. . . . . . . . . . . . . . . . . . . . 45
Auto Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
SimpLink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Input Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
DTV Signal Strength . . . . . . . . . . . . . . . . . . . . . . 50
TV GUIDE ON SCREEN
TM
SYSTEM
Setup of TV Guide On Screen
TM
. . . . . . . . . . . . 51
Functions of TV Guide On Screen
TM
. . . . . . . . . 55
-Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
-
Screen Components/Panel Menu
. . . . . . . . 56
-
Listings
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
-
Search
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
-
Recorded program list
. . . . . . . . . . . . . . . . . 63
-
Schedule
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
-
Change Setup
. . . . . . . . . . . . . . . . . . . . . . . . 66
-
Record
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
-
Remind
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
DVR (Digital Video Recording)
Timeshift ( Pause & Replay of Live TV) . . . . . . . 76
Instant Recording . . . . . . . . . . . . . . . . . . . . . . . . 79
Programmed Recording . . . . . . . . . . . . . . . . . . . 82
Recorded TV Program List . . . . . . . . . . . . . . . . . 83
Format Hard Disc . . . . . . . . . . . . . . . . . . . . . . . . 89
PICTURE CONTROL
Watching PIP ( Picture-in-Picture)/
POP( Picture-out-of-Picture)/Twin Picture . . . .90
Picture Size (Aspect Ratio) Control . . . . . . . . . .94
Preset Picture Settings
- EZ Picture - Preset . . . . . . . . . . . . . . . . . . 95
- Adaptive Picture Mode (APM). . . . . . . . . .96
- Color Tone - Preset . . . . . . . . . . . . . . . . . . .97
Manual Picture Adjustment
- EZ Picture - User Mode . . . . . . . . . . . . . . 98
- Color Tone - User Mode. . . . . . . . . . . . . . .99
XD - Picture Improvement Technology . . . . . . . . . 100
5
Advanced - Cinema 3:2 Pulldown Mode . . . . . 101
Advanced - Black( Darkness) Level . . . . . . . . . 102
Picture Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Image Sticking Minimization( ISM) Method . . . . . . 104
Low-Power Picture Mode . . . . . . . . . . . . . . . . . 105
SOUND & LANGUAGE CONTROL
Auto Volume Leveler ( EZ SoundRite) . . . . . . . 106
Preset Sound Settings( EZ Sound) . . . . . . . . . 107
Sound Setting Adjustment - User Mode . . . . . . . 108
Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
BBE - Sound Improvement Technology . . . . . . 111
Stereo / SAP Broadcast Setup . . . . . . . . . . . . . 112
TV Speakers On/ Off Setup . . . . . . . . . . . . . . . 113
Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . 114
On-Screen Menus Lanaguage Selection . . . . . . 115
Caption / Text . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Caption Option . . . . . . . . . . . . . . . . . . . . . . . . . .118
TIME SETTING
Clock Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Auto On/ Off Timer Setting . . . . . . . . . . . . . . . .121
Sleep Timer Setting . . . . . . . . . . . . . . . . . . . . . .122
Auto Shut-off Setting . . . . . . . . . . . . . . . . . . . . 123
PARENTAL CONTROL / RATINGS
Set Password & Lock System . . . . . . . . . . . . . . 124
Channel Blocking . . . . . . . . . . . . . . . . . . . . . . . 127
Movie & TV Rating . . . . . . . . . . . . . . . . . . . . . . 128
External Input Blocking . . . . . . . . . . . . . . . . . . . 131
APPENDIX
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .132
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . .135
Product Specifications . . . . . . . . . . . . . . . . . . . 136
Programming the Remote Control . . . . . . . . . 137
IR Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
External Control through RS-232C . . . . . . . . . 143
6
TM
This digital television is capable of receiving basic analog, digital basic and digital premium cable
television programming by direct connection to a cable system providing such programming. A
security card provided by your cable operator is required to view encrypted digital programming.
Cable operator enhanced program (For example, electronic program guide provided by the cable
operator), and data enhanced television service may require the use of a set top box. For more
information contact your local cable operator.
Trademark Notice
In the United States, TV GUIDE and other related marks are registered marks of Gemstar-TV Guide
International, Inc. and/or one of its affiliates. In Canada, TV GUIDE is a registered mark of
Transcontinental Inc., and is used under license by Gemstar-TV Guide International, Inc.
License Notice
The TV Guide On Screen
TM
system is manufactured under license from Gemstar-TV Guide
International, Inc. and/or one of its affiliates.
Patent Notice
The TV Guide On Screen
TM
system is protected by one or more of the following issued United
States patents 6,498,895, 6,418,556, 6,331,877; 6,239,794; 6,154,203; 5,940,073; 4,908,713;
4,751,578; 4,706,121.
Use of the CableCARD
TM
TradeMark.
“CableCARD
TM
is a trademark of Cable Television Laboratories, Inc.”
R
Official term for an HDTV that conforms to the plug-
and-play digital cable TV standard using POD (Point
of Deployment) access cards, also called
CableCARDs, that allow users to plug the cable
directly into an HDTV set and enjoy HDTV and digi-
tal cable without having to use a separate set-top
box.
is a trademark of SRS Labs, Inc.
TruSurround XT technology is incorporated under
license from SRS Labs, Inc.
A Digital Video Recorder (DVR) is a device that
empowers you to control what you watch, when you
watch it. It allows you to store and access TV pro-
grams - functioning like a VCR, but with no video-
tape. With a DVR, you can also pause live TV and
choose the shows you want to record through an
electronic program guide.
Manufactured under license from BBE Sound, Inc.
R
TruSurround XT
R
Manufactured under license from Dolby Laboratories.
“
Dolby
“and the double-D symbol are trademarks of
Dolby Laboratories.
High-definition television. High-resolution digital
television broadcast and playback system composed
of roughly a million or more pixels, 16:9 aspect-ratio
screens, and AC3 digital audio. A subset of digital
television, HDTV formats include 1080i and 720p
resolutions.
It has two HDMI ports that connect audio and video
devices with one cable and produces the highest
quality digital images and sound.
LG's own special digital image generator, consisting
of a full digital image processor, six different main
picture quality factors.
With HDMI CEC support of LG’s audio/video device
connected to the HDMI (high-definition multimedia
interface), LG TV with this logo works easily with one
remote control.
R
R
TruSurround XT
R
R
TV GUIDE ON SCREEN
TM
NOTICES FOR U.S.A.
DIGITAL CABLE COMPATIBILITY
R
7
FEATURES OF THIS TV
What is a Plasma TV ?
Using plasma is the best way to achieve flat panel
displays with excellent image quality and large screen
sizes that are easily viewable. The Plasma TV can be
thought of as a descendant of the neon lamp and or
a series of fluorescent lamps.
How does it work?
Plasma TV is an array of cells, known as pixels, which
are comprised of three sub-pixels, corresponding to
the colors red, green, and blue. Gas in a plasma state
is used to react with phosphors in each sub-pixel to
produce colored light (red, green, or blue). These
phosphors are the same types used in Cathode Ray
Tube (CRT) devices such as televisions and common
computer monitors.
Plasma TV offers a rich, dynamic display because
each sub-pixel is individually controlled by advanced
electronics to produce over 16 million different col-
ors. This means that you get perfect images that are
easily viewable in a display that is fewer than five
inches thick.
160° - Wide angle range of vision
Your flat panel plasma screen offers an exceptionally
broad viewing angle of over 160 degrees. This means
that the display is clear and visible to viewers any-
where in the room.
Wide Screen
The wide screen offers a theater-like experience in
your own home.
Multimedia
Connect your plasma display to a PC and use it for
conferencing, games, and Internet browsing. The
Picture-in-Picture feature allows you to view your PC
and video images simultaneously.
Versatile
The light weight and thin size makes it easy to install
your plasma display in a variety of locations where
conventional TVs do not fit.
The Plasma TV Manufacturing Process: a few
minute colored dots may be present on the
Plasma TV screen
The Plasma TV is composed of 0.9
to 2.2 million
cells. A few cell defects will normally occur in the
Plasma TV manufacturing process. Several tiny,
minute colored dots visible on the screen should be
acceptable. This also occurs in other Plasma TV
manufacturers' products. The tiny dots appearing
does not mean that this Plasma TV is defective. Thus
a few cell defects are not sufficient cause for the
Plasma TV to be exchanged or returned. Our pro-
duction technology minimizes these cell defects dur-
ing the manufacture and operation of this product.
Cooling Fan Noise (This feature is not available for all models.)
In the same way that a fan is used in a PC computer
to keep the CPU (Central Processing Unit) cool, the
Plasma TV is equipped with cooling fans to cool the
Monitor and improve its reliability. Therefore, a cer-
tain level of noise could occur while the fans are
operating and cooling the Plasma TV.
The fan noise doesn't have any negative effect on
the Plasma TV's efficiency or reliability. The noise
from these fans is normal during the operation of
this product. We hope you understand that a certain
level of noise from the cooling fans is acceptable and
is not sufficient cause for the Plasma TV to be
exchanged or returned.
PREPARATION
8
ACCESSORIES
MODE
DAY
-
D
A
Y
+
FLASHBK
APM
CC
AUTO DEMO
M/C EJECT
TV INPUT
TV/VIDEO
Owner's Manual
1.5V
1.5V
Owner’s Manual Batteries
75Ω Round Cable
Remote Control
PREPARATION
Ensure that the following accessories are included with your plasma display. If an accessory is missing, please
contact the dealer where you purchased the product.
User must use shielded signal interface cables(D-sub 15 pin cable) with ferrite cores to maintain standard
compliance for the product.
2- Wall brackets
2- TV brackets
F
For 60PB4D
2- TV Bracket Bolts
2- Wall brackets
For 42/50PB4D
2- eye-bolts
■
Slightly wipe stained spot on the exterior only with the polishing
cloth for the product exterior if there is stain or fingerprint on
surface of the exterior.
■
Do not wipe roughly when removing stain. Please be cautions of
that excessive power may cause scratch or discoloration.
Polishing Cloth
CD Manual
LCD TV PLASMA TV
Owner's Manual
http://www.lgusa.com
www.lg.ca
Copyright© 2007 LGE,
All Rights Reserved.
Power Cord
Option Extras
D-sub 15 pin Cable
This feature is not available for all models.
This feature is not available for all models.
PREPARATION
9
HOME MENU
This menu is a contents guide.
In HOME Menu, you can enter the recorded list of DVR, TV Guide,
Schedule of the TV Guide, Manual Record of DVR or TV Menu.
MODE
LIVE TV
DAY -
DAY +
INPUT
SIMPLINK
TV Guide
p.51
DVR
p.76
PREPARATION
10
PREPARATION
■
Here shown may be somewhat different from your TV.
■
If your product has a protection tape attached, remove the tape. And then wipe the product with a cloth (If a
polishing cloth is included with your product, use it).
Remote
Control Sensor
POWER
Button
TV
GUIDE
Button
INPUT
Button
MENU
Button
VOLUME
(
F
,
G
)Buttons
CHANNEL
(
E
,
D
)Buttons
Power/Standby Indicator
Illuminates red in standby
mode.
When the TV is turned on,
the indicator blinks white
and then illuminates white
before the picture is dis-
played.
FRONT PANEL CONTROLS
ANTENNA IN
Connect over-the air signals to this jack.
CABLE IN
Connect cable signals to this jack.
HDMI/DVI IN
Connect a HDMI signal to 1 or 2.
Or DVI(VIDEO)signal to the 1 or 2 port
with a DVI to HDMI cable.
COMPONENT IN
Connect a component video/audio device to
these jacks.
REMOTE CONTROL IN
Connect your wired remote control.
DIGITAL AUDIO OUT
Connect digital audio from various types of
equipment.
Note: In standby mode, these ports do not work.
AUDIO OUT
Connect analog audio to various types of
equipment.
AV (Audio/Video) IN 1
Connect audio/video output from an external
device to these jacks.
S-VIDEO
Connect S-Video out from an S-VIDEO device.
RS-232C IN (CONTROL & SERVICE) PORT
Connect to the RS-232C port on a PC.
RGB IN
Connect the monitor output from a PC to the
appropriate input port.
Power Cord Socket
For operation with AC power.
Caution :
Never attempt to operate the TV on DC power.
PREPARATION
11
S-VIDEO Input
Provides better picture
quality than the video
input.
AUDIO Input
Connections are available
for listening to stereo
sound from an external
device.
VIDEO Input
Connects the video signal
from a video device.
CableCARD
™
Used for
CableCARD
™
Cable Service
Provider.
BACK PANEL INFORMATION
AV IN 2
S-VIDEO
AV IN 2
S-VIDEO
AV IN 2AV IN 2
L/
MONO
R
AUDIO
VIDEO
S-VIDEOS-VIDEO
AV IN 2
S-VIDEO
AV IN 2
S-VIDEO
Cable CARD
Cable CARD
AV IN 2
S-VIDEO
AV IN 2
S-VIDEO
AV IN 2
AV IN 2
L/
MONO
R
AUDIO
VIDEO
S-VIDEO
S-VIDEO
42/50PB4D
60PB4D
PREPARATION
12
PREPARATION
ATTACHING THE TV TO A WALL
We recommend that you set up the TV close to a wall so it cannot fall over if pushed backwards.
Additionally, we recommend that the TV be attached to a wall so it cannot be pulled in a forward direction, poten-
tially causing injury or damaging the product.
Caution: Please make sure that children don’t climb on or hang from the TV.
■
Insert the eye-bolts (or TV brackets and bolts) to tighten the product to the wall as shown in the picture.
*Insert the eye-bolts and tighten them securely in the upper holes.
Secure the wall brackets with the bolts (not provided as parts of the product, must purchase separately )
on the wall. Match the height of the bracket that is mounted on the wall to the holes in the product.
Ensure the eye-bolts or brackets are tightened securely.
■
Use a sturdy rope (not provided as parts of the product, must purchase sepa-
rately) to tie the product. It is safer to tie the rope so it becomes horizontal
between the wall and the product.
42/50PB4D
60PB4D
■
This feature is not available for all models.
PREPARATION
13
BACK COVER FOR WIRE ARRANGEMENT
Hold the CABLE MANAGEMENT with both hands and pull it backward as shown.
Connect the cables as necessary.
To connect an additional equipment, see the External equipment Connections section.
1
2
Install the CABLE MANAGEMENT as shown.
3
CABLE MANAGEMENT
PREPARATION
14
PREPARATION
VESA WALL MOUNTING
This product accepts a VESA-compliant mounting interface pad. (optional)
There 4 threaded holes are available for attaching the bracket.
G
Screw length needed depends on the wall mount used. For further information, refer to the VESA
Wall Mounting Instruction Guide.
NOTE
400mm
600mm
PREPARATION
15
DESKTOP PEDESTAL INSTALLATION
For proper ventilation, allow a clearance of 4inches on all four sides from the wall.
CAUTION
Ensure adequate ventilation by following the clearance recommendations.
4 inches
4 inches
4 inches
4 inches
PREPARATION
16
PREPARATION
ANTENNA OR CABLE CONNECTION
1. Antenna (analog or digital)
Wall Antenna Socket or Outdoor Antenna without a Cable Box
Connections. For optimum picture quality, adjust antenna direction
if needed.
ANTENNA
IN
CABLECABLE
IN
CABLE
IN
CABLE
IN
ANTENNA
IN
CABLE
IN
CABLE
IN
CABLE
IN
ANTENNA
IN
CABLE
IN
CABLE
IN
2. Cable
3. Using both cable and antenna
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Outdoor
Antenna
(VHF, UHF)
Wall
Antenna
Socket
RF Coaxial Wire (75 ohm)
Bronze Wire
Be careful not to bend the bronze
wire when connecting the antenna.
Cable TV
Wall Jack
Antenna
Cable TV
Wall Jack
RF Coaxial Wire (75 ohm)
RF Coaxial Wire (75 ohm)
RF Coaxial Wire (75 ohm)
PREPARATION
17
The TV will let you know when the analog, cable, and digital channel scans are complete.
NOTE
CABLE
IN
ANTENNA
IN
CABLECABLE
IN
CABLECARD
TM
How to use
Insert the CableCARD
TM
from your cable service provider into the CableCARD
TM
slot on the back of your TV.
If pairing information about this TV and the CableCARD is displayed on the screen, contact your cable ser-
vice provider.
Cable CARD
■
To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly.
■
If the antenna needs to be split for two TV’s, install a 2-Way Signal Splitter.
■
If the antenna is not installed properly, contact your dealer for assistance.
Antenna
UHF
Signal
Amplifier
VHF
This TV supports CableCARD
TM
technology from
Motorola, Scientific Atlanta, and SCM.
NOTE
When removing, do not drop it as this may cause
damage to the CableCARD
TM
.
CAUTION
CableCARD
TM
Setup
PREPARATION
18
PREPARATION
CableCARD
TM
Function
Cable menu options
In case of Scientific Atlanta CableCARD
™
CableCARD
™
/ Host ID Screen
As shown, the pairing number means
your TV and CableCARDTM ID. For
further information regarding cable
TV service, contact your local cable
TV service provider(s).
Press the
MENU
button and then use
D
or
E
button
to select the
CABLE
menu.
Press the
G
button and then use
D
or
E
button to
select your desired item.
Press the
G
button.
Press
EXIT
button to return to TV viewing.
The Cable sub menu displays when inserting the CableCARD
TM
to the TV.
The CableCARD
TM
type is Motorola, Scientific Atlanta (SA), or
SCM etc. The OSD (On screen display) is different from your
TV according to your CableCARD
TM
type.
In this manual, the OSD (On Screen Display) may be different from your TV’s because it is just
example to help the TV operation.
CableCARD(tm) Message
In order to start service for
this device, please contact
customer service at
Ph#: 1-866-303-0422
CableCARD(tm): 0-010-405-698-001
HOST ID: 0-080-000-000-226
Exit
EXIT
2
3
4
1
MODE
LIVE TV
INPUT
DAY -
DAY +
SIMPLINK
SA CableCARD CP Screen
SA CableCARD Diag Screen
SA CableCARD Host ID Screen
G
PREPARATION
19
Scrambled channel
MODE
LIVE TV
INPUT
DAY -
DAY +
SIMPLINK
P
Please c all y our o per ato r and report a n inv ali d Cab leC ARD
T M
.
Insert the CableCARD
TM
. It takes about 1 minute to
exchange data between the TV and the CableCARD
TM
. The
screen displays information as shown to the right.
Let your cable TV service provider know the CableCARD
TM
ID and Host ID.
If your cable TV service provider registers the
CableCARD
TM
ID and Host ID, you can watch premium or
high value channel. If you are subscribed to them.
If you registered with the cable TV service provider, you can
watch premium or high value channel without a message.
If the certificates don’t match between the TV and the
CableCARD
TM
, the OSD
(
On screen display
)
displays as
shown right.
CableCARD™ Message
In order to start service for
this device, please contact
customer service at
Ph#: 1-866-303-0422
CableCARD(tm): 0-010-405-698-001
HOST ID: 0-080-000-000-226
Exit
EXIT
2
3
4
5
1
PREPARATION
20
PREPARATION
Cable Channel List
If you select
Channel Edit
after running the EZ Scan without a CableCARD
TM
, the cable channel list displays,
as in the picture below.
Insert the CableCARD
TM
. After a few minutes(about 2~3 minutes), the TV receives a new cable channel list .
(
Occasionally more time will be needed)
2
1
EZ Scan
G
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
EZ Scan
Manual Scan
Channel Edit
G
DTV Signal
Main Input
Sub Input
Input Label
Set ID
Selection (
G
or )
leads you to the EZ
scan screen.
Selection (
G
or ) leads
you to the channel edit
screen.
PREPARATION
21
Emergency Message Alert
If an emergency situation occurs while you are watching
the TV/DTV/CATV/CADTV, you may receive a message
from your cable TV service provider(s).
When receiving an emergency message, the message is
displayed on the screen as shown or the channel is
changed to one that maintains the emergency message.
When the broadcast is complete the TV returns to the
channel you were viewing.
Emergency A cti on No tif ica tio n
Hur ric ane w ill be co ming!!!
2
1
EXTERNAL EQUIPMENT SETUP
22
EXTERNAL EQUIPMENT SETUP
HD RECEIVER SETUP
This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you
do receive digital signals from a digital set-top box or other digital external device, refer to the figure as
shown below.
This TV supports HDCP
(
High-bandwidth Digital Contents Protection
)
protocol for Digital Contents.
Y L RPB PR
AUDIO
When connecting Component cable
1. How to connect
Connect the video outputs
(
Y, PB, PR
)
of the digital set
top box to the
COMPONENT IN VIDEO 1
jacks on
the set. Match the jack colors
(Y = green, P
B = blue, and PR = red).
Connect the audio output of the digital set-top box to
the
COMPONENT IN AUDIO 1
jacks on the set.
2. How to use
■
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
■
Select
COMPONENT 1
input source with using the
INPUT
button on the remote control.
■
If connected to
COMPONENT IN 2
input, select
COMPO-
NENT 2
input source.
Signal
480i
480p
720p
108 0 i
Component 1/2
Yes
Yes
Yes
Yes
RGB-DTV,
HDMI1/DVI, HDMI2
No
Yes
Yes
Yes
2
1
EXTERNAL EQUIPMENT SETUP
23
When connecting D-sub 15pin cable
L R
RGB OUTPUT
HDMI-DTV OUTPUT
AUDIOAUDIO
L
R
Connect the RGB output of the digital set-top box to
the
RGB
(
PC/DTV
)
jack on the set.
Connect the audio outputs of the set-top box to the
AUDIO
(
RGB/DVI
)
jack on the set.
1. How to connect
2. How to use
■
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
■
Select
RGB-DTV
input source with using the
INPUT
button
on the remote control.
When connecting HDMI cable
Connect the digital set-top box to
HDMI/DVI IN 1
or
2
jack on the set.
No separated audio connection is necessary.
1. How to connect
2. How to use
■
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
■
Select
HDMI1/DVI
or
HDMI2
input source with using the
INPUT
button on the remote control.
2
1
2
1
EXTERNAL EQUIPMENT SETUP
24
EXTERNAL EQUIPMENT SETUP
When connecting HDMI to DVI cable
AUDIOUDIO
L R
DVI-DTV OUTPUT
Connect the DVI output of the digital set-top box to the
HDMI/DVI IN 1
jack on the set.
Connect the audio output of the digital set-top box to the
AUDIO
(
RGB/DVI
)
jack on the set.
1. How to connect
■
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
■
Select
HDMI1/DVI
input source with using the
INPUT
button on the remote control.
2. How to use
2
1
EXTERNAL EQUIPMENT SETUP
25
DVD SETUP
Component Input ports
To get better picture quality, connect a DVD player to the component input ports as shown below.
Component ports on the TV
YPB PR
Video output ports
on DVD player
Y
Y
Y
Y
P
B
Pb
B-Y
Cb
PR
Pr
R-Y
Cr
Y L RPB PR
AUDIO
When connecting Component cable
Connect the video outputs
(
Y, PB, PR
)
of the DVD to
the
COMPONENT IN VIDEO1
jacks on the set.
Match the jack colors
(
Y = green, P
B = blue, and PR = red
)
.
Connect the audio outputs of the DVD to the
COMPONENT IN AUDIO1
jacks on the set.
1. How to connect
2. How to use
■
Turn on the DVD player, insert a DVD.
■
Select
COMPONENT 1
input source with using the
INPUT
button on the remote control.
■
If connected to
COMPONENT IN 2
input, select
COM-
PONENT 2
input source.
■
Refer to the DVD player's manual for operating instruc-
tions.
2
1
EXTERNAL EQUIPMENT SETUP
26
EXTERNAL EQUIPMENT SETUP
When connecting with an S-Video cable
AUDIOUDIO
L
R
HDMI-DVD OUTPUT
L R
S-VIDEO
AUDIO
AUDIO
Connect the S-VIDEO output of the DVD to the
S-VIDEO
input on the set.
Connect the audio outputs of the DVD to the
AUDIO
input jacks on the set.
1. How to connect
2. How to use
■
Turn on the DVD player, insert a DVD.
■
Select
AV1
input source with using the
INPUT
button on
the remote control.
■
If connected to
AV IN 2
, select
AV2
input source.
■
Refer to the DVD player's manual for operating instructions.
When connecting HDMI cable
Connect the HDMI output of the DVD to the
HDMI/DVI IN1
or
2
jack on the set.
No separated audio connection is necessary.
1. How to connect
2. How to use
■
Select
HDMI1/DVI
or
HDMI2
input source with using the
INPUT
button on the remote control.
■
Refer to the DVD player's manual for operating instruc-
tions.
2
1
2
1
EXTERNAL EQUIPMENT SETUP
27
VCR SETUP
When connecting with an antenna
■
To avoid picture noise
(
interference
)
, leave an adequate distance between the VCR and TV
■
Use the ISM feature in the Option menu to avoid having a fixed image remain on the screen for a long pe-
riod of time. If the 4:3 picture format is used; the fixed images on the sides of the screen may remain visible
on the screen.
L R
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
Wall Jack
Antenna
Connect the RF antenna out socket of the VCR to the
Antenna
socket on the set.
Connect the antenna cable to the RF antenna in socket of the VCR.
1. How to connect
■
Set VCR output switch to 3 or 4 and then tune TV to the same channel number.
■
Insert a video tape into the VCR and press PLAY on the VCR.
(
Refer to the VCR owner’s manual.
)
2. How to use
2
1
EXTERNAL EQUIPMENT SETUP
28
EXTERNAL EQUIPMENT SETUP
When connecting with a RCA cable
In the event that you connect both
Video and the S-Video cables, only
the S-Video will work.
CAUTION
L R
S-VIDEOVIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
L R
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
Connect the
AUDIO
/
VIDEO
jacks between TV and
VCR. Match the jack colors(Video = yellow, Audio Left =
white,and Audio Right = red)
1. How to connect
2. How to use
■
Insert a video tape into the VCR and press PLAY on the
VCR.
(
Refer to the VCR owner’s manual.
)
■
Select
AV1
input source with using the
INPUT
button on
the remote control.
■
If connected to
AV IN 2
, select
AV2
input source.
If you have a mono VCR, con-
nect the audio cable from the
VCR to the
AUDIO
L/MONO
jack of the set.
NOTE
When connecting with an S-Video
Connect the S-VIDEO output of the VCR to the
S -
VIDEO
input on the set. The picture quality is
improved; compared to normal composite
(
RCA cable
)
input.
Connect the audio outputs of the VCR to the
AUDIO
input jacks on the set.
1. How to connect
2. How to use
■
Insert a video tape into the VCR and press PLAY on the VCR.
(
Refer to the VCR owner’s manual.
)
■
Select
AV1
input source with using the
INPUT
button on the
remote control.
■
If connected to
AV IN 2
, select
AV2
input source.
1
2
1
EXTERNAL EQUIPMENT SETUP
29
OTHER A/V SOURCE SETUP
Camcorder
Video Game Set
Connect the
AUDIO
/
VIDEO
jacks between TV and
external equipment. Match the jack colors
.
(
Video = yellow, Audio Left = white, and Audio Right = red
)
1. How to connect
2. How to use
■
Select
AV1
input source with using the
INPUT
button on
the remote control.
■
If connected to
AV IN 2
input, select
AV2
input source.
■
Operate the corresponding external equipment.
1
AV IN 2
L/L/MONOMONO
R
AUDIOAUDIO
VIDEOVIDEO
S-VIDEO
L R
VIDEO
i.e) 42/50PB4D
EXTERNAL EQUIPMENT SETUP
30
EXTERNAL EQUIPMENT SETUP
PC SETUP
This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.
The TV perceives 640x480, 60Hz as DTV 480p based on the PC graphic card. If necessary, change the
screen scanning rate for the graphic card accordingly.
Check the image on your TV. There may be noise associ-
ated with the resolution, vertical pattern, contrast or
brightness in PC mode. If noise is present, change the PC
output to another resolution, change the refresh rate to
another rate or adjust the brightness and contrast on the
VIDEO menu until the picture is clear. If the refresh rate
of the PC graphic card can not be changed, change the
PC graphic card or consult the manufacturer of the PC
graphic card.
NOTE
AUDIO
AUDIO
RGB OUTPUT
When connecting D-sub 15 pin cable
Connect the RGB output of the PC to the
RGB
(
PC/DTV
)
jack on the set.
Connect the PC audio output to the
AUDIO
(
RGB/DVI
)
jack on the set.
1. How to connect
2. How to use
■
Turn on the PC and the set.
■
Select
RGB-PC
input source in main input option of SETUP
menu.(
p.45
)
■
Once you select
RGB-PC
in main input option of
SETUP
menu,
INPUT
button is also available for this purpose.
2
1
EXTERNAL EQUIPMENT SETUP
31
When connecting HDMI to DVI cable
HDMI2 source does not support DVI source.
If the PC has a DVI output and no HDMI output, a separated audio connection is necessary.
NOTE
AUDIOUDIO
DVI-PC OUTPUT
AUDIO
Connect the DVI output of the PC to the
HDMI/DVI IN 1
jack on the set.
Connect the PC audio output to the
AUDIO
(
RGB/DVI
)
jack on the set.
1. How to connect
■
Turn on the PC and the set
■
Select
HDMI1/DVI
input source with using the
INPUT
button on the remote control.
2. How to use
2
1
EXTERNAL EQUIPMENT SETUP
32
EXTERNAL EQUIPMENT SETUP
To get the the best picture quality, adjust the PC
graphics card to 1024x768, 60Hz.
Depending on the graphics card, DOS mode may
not work if a HDMI to DVI Cable is in use.
When Source Devices are connected with
HDMI/DVI Input, the output PC Resolution(VGA,
SVGA, XGA), Position and Size may not fit on the
Screen. As shown in the picture, press the
ADJUST button to adjust the screen Position of
the TV SET and contact a PC graphics card ser-
vice center.
When Source Devices connected with HDMI/DVI
Input, output TV SET Resolution
(
480p, 720p,
1080i) and TV SET Display fit EIA/CEA-861-B
Specification to Screen. If not, refer to the
Manual of HDMI/DVI Source Devices or contact
your service center.
If the HDMI/DVI Source Device is not connected
to the Cable or if there is a poor cable connec-
tion, "No signal" is displayed in the HDMI/DVI
Input. In this case, that Video Resolution is not
supported. If "Invalid Format" is displayed, refer
to the Source Device manual or contact your ser-
vice center.
Avoid keeping a fixed image on the screen for a
long period of time. The fixed image may become
permanently imprinted on the screen.
The synchronization input form for Horizontal
and Vertical frequencies is separate.
NOTES
EXTERNAL EQUIPMENT SETUP
33
Supported Display Specifications
(
RGB/HDMI-PC
)
Horizontal Vertical
Frequency
(
KHz
)
Frequency
(
Hz
)
31.468 70.09
31.469 70.08
31.469 59.94
37.861 72.80
37.500 75.00
35.156 56.25
37.879 60.31
48.077 72.18
46.875 75.00
48.363 60.00
56.476 70.06
60.023 75.02
47.776 59.870
47.720 59.799
Resolution
720x400
1360x768
640x350
* RGB-PC mode only: 640x350, 720X400
640x480
800x600
1024x768
Supported Display Specifications
(
RGB/HDMI-DTV
)
Horizontal Vertical
Frequency
(
KHz
)
Frequency
(
Hz
)
31.47 60
31.47 59.94
45.00 60.00
44.96 59.94
33.75 60.00
33.72 59.94
Resolution
720x480p
1280x720p
1920x1080i
1280x768
EXTERNAL EQUIPMENT SETUP
34
EXTERNAL EQUIPMENT SETUP
Screen Setup for PC mode
Overview
When RGB connect to PC output and select the RGB-PC in Main
Input, this function is used.
When HDMI IN 1(DVI) connect to PC output and select
HDMI1/DVI input, this function is used.
In RGB-DTV mode, SIZE and PHASE is not available.
Position
G
Size
Phase
Reset
Adjust Close
Position
Size
Phase
Reset
G
FLASHBK
APM
CC
Initialize Settings
Yes
No
Adjust Previous Move Select
Position
This function is to adjust picture
to left/right and up/down as you
prefer.
Size
This function is to minimize any
vertical bars or stripes visible on
the screen background. And the
horizontal screen size will also
change.
Phase
This function allows you to
remove any horizontal noise and
clear or sharpen the image of char-
acters. In HDMI/DVI-PC mode,
PHASE is not available.
Press the
ADJUST
button and then use
D
or
E
button to
select
Position
,
Size
, or
Phase
.
Press the
ENTER
button and then use
D
/
E
or
F
/
G
button to make appropriate adjustments.
■
The
Phase
adjustment range is
-16
~
+16
.
■
The
Size
adjustment range is
-30
~
+30
.
Press the
ENTER
button.
Adjustment for screen Position, Size, Phase, Reset
Press the
ADJUST
button and then use
D
or
E
button to
select
Reset
.
Press the
ENTER
button and then use
F
or
G
button to
select
Yes
.
Press the
ENTER
button.
Initializing
(
Reset to original factory values
)
2
3
1
2
3
1
To initialize the adjusted values.
EXTERNAL EQUIPMENT SETUP
35
AUDIO OUT SETUP
Send the TV’s audio to external audio equipment via the Audio Output
(
Optical
)
port.
When connecting with external audio equipment, such as
amplifers or speakers, please turn the TV speakers off.
(
p.113
)
NOTE
Do not look into the optical output port. Looking at the
laser beam may damage your vision.
CAUTION
L R
S-VIDEO
Connect audio outputs to the TV’s
AUDIO OUT
jacks.
Set the “TV Speaker option - Off” in the AUDIO menu.
(
G
p.113
). See the external audio equipment instruction
manual for operation.
1. How to connect
Connect one end of the optical or coaxial cable to the
TV’s
OPTICAL
or
COAXIAL
port of
DIGITAL AUDIO
OUT
.
Connect the other end of the optical or coaxial cable
to the digital audio input on the audio equipment.
Set the “TV Speaker option - Off” in the AUDIO menu.
(
G
p.113
). See the external audio equipment instruc-
tion manual for operation.
2
1
2
3
1
Analogue
Digital
WATCHING TV / CHANNEL CONTROL
36
WATCHING TV /CHANNEL CONTROL
REMOTE CONTROL FUNCTIONS
When using the remote control, aim it at the remote control sensor on the TV.
APM
CC
AUTO DEMO
M/C EJECT
SIM
PLINK
MODE
DAY+/DAY-
THUMBSTICK
(Up/Down/Left
Right/ENTER)
EXIT
MARK
INFO
SIMPLINK
VOLUME UP
/DOWN
MUTE
FAV
CHANNEL
UP/DOWN
PAGE UP/
PAGE DOWN
FLASHBK
— (DASH)
Select the remote operating mode: TV, DVD, VCR,
AUDIO, CABLE or STB.
■
Use for DVR record or trick play.
p
p.78, 86
■
Controls the mode.
■
For further details, see the
DVR
section.
Control video cassette recorders or DVD players.
Move the Listings Grid forward or backward in 24 hour
increments.
Displays the main menu. Enters or exits a Panel Menu
in the TV Guide On Screen system.
Displays the TV Guide On Screen system.
p .51
Enter to the mode.
Navigate the on-screen menus and adjust the system
settings to your preference.
Clear all on-screen displays and return to TV viewing from
any menu.
Enter the selected functions.
p.84
Enter the selected functions.
p.44
See a list of AV devices connected to TV.
When you toggle this button, the Simplink menu appears
at the screen.
Increase/decrease the sound level.
Switch the sound on or off.
p.39
Scroll through the programmed Favorite channels.
Select available channels.
Move from one full set of screen information
to the next one.
Tune to the last channel viewed.
Used to enter a program number for multiple
program channels such as 2-1, 2-2, etc.
mode control
buttons
NUMBER button
VCR/DVD
buttons
MENU
TV GUIDE
WATCHING TV / CHANNEL CONTROL
37
TIMER
RATIO
ADJUST
APM
CC
FLASHBK
POWER
LIVE TV
INPUT
Turns your TV or any other programmed equipment on or off, depending on the mode.
In AV 1-2, Component 1-2, RGB-DTV (or RGB-PC), HDMI1/DVI, and HDMI2 input sources,
screen returns to the last TV channel.
External input modes rotate in regular sequence: Antenna, Cable, AV1-2, Component 1-2, RGB-
DTV (or RGB-PC), HDMI1/DVI and HDMI2. (AV 1-2, Component 1-2, RGB-DTV (or RGB-PC),
HDMI1/DVI, and HDMI2 input sources are linked automatically, only if these are connected ).
Inside the Sliding Cover
PIP
PIPCH-/PIPCH+
PIP INPUT
SWAP
SAP
EZ PIC
APM
EZ SOUND
CC
Switches the sub picture PIP, POP, Twin pic-
ture or off mode.
p. 90
Changes the PIP channel.
p. 91
Select the connected input source for the
sub-picture.
p. 91
Exchange the main/sub images.
p. 92
Select MTS sound: Mono, Stereo, and SAP
analog mode. Change the audio language
DTV mode.
Adjust the factory preset picture depend
on the viewing environment.
Compare the Daylight, Normal, Night Time
and User1(or2) on the screen.
p. 96
Select the appropriate type of sound for
type of program.
Select closed caption.
p. 116
(*In DTV/CADTV modes
p. 117
)
Installing Batteries
■
Open the battery compartment cover on the
back side and install the batteries matching cor-
rect polarity
(
+with +,-with -
)
.
■
Install two 1.5V AA batteries. Don’t mix old or
used batteries with new ones.
■
Close cover.
MODE
D
A
Y
-
D
A
Y
+
LIVE TV
INPUT
■
Use a remote control up to 7 meters distance and 30
degree (left/right) within the receiving unit scope.
■
Dispose of used batteries in a recycle bin to pre-
serve environment.
Remote control effective range
Select the amount of time
before your TV turns off
automatically.
p.122
Change the aspect ratio.
p.94
Adjust the screen
position,size,and phase
in PC mode.
p.34
WATCHING TV / CHANNEL CONTROL
38
WATCHING TV /CHANNEL CONTROL
TURNING ON TV
NOTE
If you intend to be away on vacation, disconnect
the power plug from the wall power outlet.
After turning on the TV, it could take up to a
week for the TV Guide On Screen system to
receive full listings data.
First, connect power cord correctly.
At this moment, the TV switches to standby mode.
■
In standby mode, press the
(
or ON/OFF
)
,
INPUT
,
CH
(
D
or
E
)
button on the TV or press the
POWER
,
INPUT
,
LIVE TV
,
CH
(
D
or
E
)
,
Number
(
0
~
9
)
button on the remote control.
Select the viewing source by using the
INPUT
button on
the remote control.
■
This TV is programmed to remember which mode it was
last set to, even if you turn the TV off.
When finished using the TV, press the
POWER
button on
the remote control. The TV reverts to standby mode.
MODE
DAY -
DAY
+
FLASHBK
APM
CC
LIVE TV
INPUT
SIMPLINK
2
3
1
WATCHING TV / CHANNEL CONTROL
39
VOLUME ADJUSTMENT
CHANNEL SELECTION
Press the
CH
D
or
E
or
NUMBER
buttons to select a
channel number.
Press the
VOL
D
or
E
button to adjust the volume.
If you want to switch the sound off, press the
MUTE
but-
ton.
You can cancel the Mute function by pressing the
MUTE
or
VOL
D
or
E
button.
APM
CC
FLASHBK
SIMPLINK
Adjust the volume to suit your personal preference.
MODE
LIVE TV
DAY
-
DAY +
INPUT
SIMPLINK
2
3
1
1
WATCHING TV / CHANNEL CONTROL
40
WATCHING TV /CHANNEL CONTROL
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Auto Clock
Manual Clock
Off Timer
On Timer
Sleep Timer
Auto Off
ON-SCREEN MENUS SELECTION
Press the
MENU
button and then use
D
or
E
button to select each menu.
Press the
G
button and then use
D E F G
button to display the available menus.
Your TV's OSD
(
On Screen Display
)
may differ slightly from what is shown in this manual.
SETUP VIDEO
OPTIONLOCK
TIME
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
EZ Picture
Color Temperature
XD
Advanced
Video Reset
2
1
CABLE
AUDIO
Audio Language
EZ SoundRite
EZ Sound
Balance 0
TV Speaker
BBE
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
SA CableCARD CP Screen
G
SA CableCARD Diag Screen
SA CableCARD Host ID Screen
In case of Scientific Atlanta CableCARD™
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
TV Rating-English
TV Rating-French
Downloadable Rating
Input Block
For USA For Canada
WATCHING TV / CHANNEL CONTROL
41
EZ Scan
G
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
Selection (
G
or )
leads you to the EZ
scan screen.
AUTO SCAN (EZ SCAN)
MODE
LIVE TV
INPUT
DAY -
DAY +
SIMPLINK
Press the
MENU
button and then use
D
or
E
but-
ton to select the
SETUP
menu.
Press the
G
button and then use
D
or
E
button to
select
EZ Scan
.
Press the
ENTER
button to begin the channel
search. Allow
EZ Scan
to complete the channel
search cycle for
ANTENNA
and
CABLE
.
Automatically finds all channels available through antenna or
cable inputs, and stores them in memory on the channel list.
Run EZ Scan again after any Antenna/Cable connection
changes.
A password is required to gain access to EZ Scan menu if the
Lock System is turned on.
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
Selection (
G
or )
leads you to the EZ
scan screen.
2
3
1
NOTE
!
Analog TV signal
Digital DTV signal
Analog CATV signal
Digital CADTV signal
Processing EZ scan...
ANTENNA Ch.20
3channel(s) found
Press to stop the
current scan and start
CABLE channel scan.
MENU Previous
Next
WATCHING TV / CHANNEL CONTROL
42
WATCHING TV /CHANNEL CONTROL
EZ Scan
Manual Scan
G
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
ADD/DELETE CHANNEL (MANUAL SCAN
)
A password is required to gain access to Manual Scan
menu if the Lock System is turned on.
While using the CableCARD
TM
, CATV, CADTV is not work-
ing in Manual Scan.
Press the
MENU
button and then use
D
or
E
button
to select the
SETUP
menu.
Press the
G
button and then use
D
or
E
button to
select
Manual Scan
.
Press the
G
button and then use
D
or
E
button to
select TV, DTV, CATV, and CADTV.
Press the
G
button and then use
D
or
E
button to
select channel number you want to add or delete.
Press the
ENTER
button to add or delete for the
channel number.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
SIMPLINK
NOTE
This digital channel number is a physical channel
number, which is different from the normal channel
number shown in Channel Edit.
Select channel type and
RF-channel number.
TV 2
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
Select channel type and
RF-channel number.
TV
G
2
Press to delete the
channel
TV 2-0
D
E
4
5
6
2
3
1
WATCHING TV / CHANNEL CONTROL
43
CHANNEL EDITING
Press the
MENU
button and then use
D
or
E
button
to select the
SETUP
menu.
Press the
G
button and then use
D
or
E
button to
select
Channel Edit
.
Press the
G
button. You will now see a screen filled
with channel numbers and a preview picture.
Use button to select a channel and
then use the
ENTER
button to add or delete it.
Press
FAV
button to add the channel to the Favorite
List. The surfing icon will appear in front of that
channel number.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
SIMPLINK
From the default channel list created from the EZ Scan channel search, you can
create two different types of channel lists in memory: “custom list” and “favorite
channel list”.
A custom list can be created by toggling each channel on or off with ENTER but-
ton. The channels in the Custom List are displayed in black and the channels
deleted from the Custom List are displayed in gray. Once a channel is highlighted
you can add or delete the channel by referring to the small window at the top-
left corner of the screen.
You can create your own Favorite List. Use the
FAV
button on the remote control
when a channel is highlighted and then add or delete the channel to/from your
Favorite List.
EZ Scan
Manual Scan
Channel Edit
G
DTV Signal
Main Input
Sub Input
Input Label
Set ID
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
Selection (
G
or ) leads
you to the channel edit
screen.
4
5
2
3
1
WATCHING TV / CHANNEL CONTROL
44
WATCHING TV /CHANNEL CONTROL
What is Brief Info.?
: Brief Info shows the present screen information.
: On Watching with the upper Input signal, press the
INFO
button.
How To Use?
1. Press the
INFO
button to show the Brief Info on the screen.
2. Press the
INFO
button or
EXIT
button to exit.
BRIEF INFO.
Program title
Day, Month, Year
Program start time
Program progress bar
Program finish time
Present time
Program information
Banner information
Multilingual
: Press the SAP button to select your choice.
Caption
:Press the CC button to select wanted Closed caption.
Screen Ratio of Input Signal 4:3
Screen Ratio of Input Signal 16:9
Resolution of Input Signal 720x480i
Resolution of Input Signal 720x480p
Resolution of Input Signal 1280x720p
Resolution of Input Signal 1920x1080i
Input Signal have rating information. Refer to the <Lock Menu>.
D
(
Dialogue
)
, L
(
Language
)
, S
(
Sex
)
, V
(
Violence
)
, FV
(
Fantasy Violence
)
480i
480p
720p
108 0 i
4
:
3
16
:
9
CC
No description is available
MODE
LIVE TV
DAY -
DAY
+
INPUT
SI
M
PLINK
WATCHING TV / CHANNEL CONTROL
45
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
G
Sub Input
Input Label
Set ID
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
Antenna
Cable
AV1
AV2
Component1
Component2
RGB-PC
HDMI1/DVI
HDMI2
INPUT SOURCE SELECTION
Changes the picture source so you can watch your off-air TV,
cable TV, VCR, DVD, or any other devices that are connected to
your TV.
Press the
MENU
button and then use
D
or
E
button
to select the
SETUP
menu.
Press the
G
button and then use
D
or
E
button to
select
Main Input.
Press the
G
button and then use
D
or
E
button to
select the source: Antenna, Cable, AV1, AV2,
Component1, Component2, RGB-DTV (or RGB-PC),
HDMI1/DVI, HDMI2.
■
To toggle RGB-DTV and RGB-PC, select RGB-
DTV(or RGB-PC) and press
G
button.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Select sources for the
Sub Input
in the
SETUP
menu.
See Page 91 for selecting the input
source for the sub picture by pressing
the
PIP INPUT
button.
Sub Picture Source Selection
MODE
LIVE TV
INPUT
DAY -
DAY +
SIMPLINK
2
3
4
1
WATCHING TV / CHANNEL CONTROL
46
WATCHING TV /CHANNEL CONTROL
AUTO LINK
Antenna
: Select it when watching the TV/DTV.
Cable
: Select it when watching the CATV/CADTV.
AV 1, AV 2
: Select it when watching the VCR or external equipment.
Component 1-2
: Select it when using the DVD or the Digital set-top box depend on connector.
RGB-PC /RGB-DTV
: Select it when using PC or Digital set-top box depend on connector.
HDMI1 /DVI, HDMI2
: Select it when using DVD, PC or Digital set-top box depend on connector.
Antenna
Cable
AV 1
AV 2
Component1
E
Auto Link
AV 2
Press the
INPUT
button and then displays the connected
external equipment list on the screen.
Press the
ENTER
button to change the main input to the
active external equipment. Use the
D
or
E
button to
select the main input source.
MODE
LIVE TV
DAY -
DAY +
INPUT
SIMPLINK
■
You can also select
Main Input
in the
Setup
menu.
Antenna
Cable
When every external equipment is connected:
When any external equipment is not connected:
When some External Equipment is connected:
(ex: When connected only to AV 2)
Antenna Cable
AV1
Antenna Cable AV2
AV2 Component1
HDMI2 HDMI1/DVI RGB-DTV (or RGB-PC) Component2
2
3
1
WATCHING TV / CHANNEL CONTROL
47
This operates only for the devices with the
logo. Please check the logo.
This allows you to control and play other AV devices
connected to the display through HDMI cable without
additional cables and settings.
■
While simplink function is using, Timeshift function is not
operated in HDMI1/DVI or HDMI2 mode.
MODE
LIVE TV
DAY -
DAY +
INPUT
SIMPLINK
Connect the HDMI/DVI IN 1or 2 terminal of the TV
to the rear terminal (HDMI output) of the Simplink
device with the HDMI cable.
After connecting the HDMI jack for the home theater
with simplink function in the above method, connect
the DIGITAL AUDIO OUT OPTICAL on the back of
the TV to the DIGITAL AUDIO IN terminal on the
back of the simplink device with the Optical cable.
Press the
M
MENU
button and then use
D
or
E
button
to select the
OPTION
menu.
Press the
G
button and then use
D
or
E
button to
select
SimpLink
.
Press the
G
button and then use
D
or
E
button to
select
On
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
4
2
3
1
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
G
Off
On
NOTE
G
When operating the external device with Simplink, press the TV button among the MODE button on the
remote control.
G
When you switch the Input source with the INPUT button on the remote control, you can stop the
operation of device worked by Simplink.
G
When you select or operate the media device with home theater function, the speaker automatically
switches to home theater speaker (HT speaker).
G
When you execute ‘Recorded TV’ function during DVD playback included in home theater, DVD play-
back stops and the applicable function is executed after switching the input to TV.
SimpLink Preparations
5
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
WATCHING TV / CHANNEL CONTROL
48
WATCHING TV /CHANNEL CONTROL
SimpLink Functions
Direct Play
After connecting AV devices to TV, you can directly control the devices and play media
without additional settings.
Select AV device
Enables you to select one of AV devices connected to TV and play it.
Disc playback
Control connected AV devices by pressing the
, , , , , ,
,
DE
F G
,
ENTER
buttons and buttons for play, pause, stop, fast reverse, fast forward,
chapter skip.
Power off all devices
When you power off TV, all connected devices are turned off.
Switch audio-out
Offers an easy way to switch audio-out.
(A device, which is connected to TV through HDMI cable but does not support
Simplink, does not provide this function)
Note: To operate SIMPLINK, the HDMI cable over 1.2 Version with *CEC function should be used.
(*CEC: Consumer Electronics Control). Version 1.2 is the cable connected to No. 13 Pin and
is the line to exchange information between units.
SimpLink Menu
DISC playback
: Select and play discs.
When multiple discs are available, the
titles of the discs are conveniently dis-
played at the bottom of the screen.
VCR playback
: Play and control the
connected VCR.
HDD Recordings playback
: Play and
control recordings stored in HDD.
Audio Out to HT speaker/Audio
Out to TV
: Select HT speaker or TV
speaker for Audio Out.
TV viewing
: Switch to the previous TV
channel regardless of the current mode.
G
Selected Device
G
When no device is
connected (displayed in gray)
G
When a device is
connected (displayed in
bright color)
1
2
3
4
5
MODE
LIVE TV
DAY -
DAY +
INPUT
SIMPLINKSIMPLINK
After selecting the
T V
button of the MODE on the remote control,
press the
SIMPLINK
button.
Use
D E F G
button to select the desired device and then press
the
ENTER
button.
Control connected AV devices by pressing the
, , ,
,,,
,
DE
F G
,
ENTER
buttons.
2
1
3
1
2
3
4
5
WATCHING TV / CHANNEL CONTROL
49
INPUT LABEL
Sets a label to each input source which is not in use when you
press INPUT button.
Press the
MENU
button and then use
D
or
E
but-
ton to select the
SETUP
menu.
Press the
G
button and then use
D
or
E
button to
select
Input Label
.
Press the
G
button and then use
D
or
E
button to
select the source: AV1, AV2, Component1,
Component2, RGB, HDMI1/DVI or HDMI2.
Press the
D
or
E
button to select the label.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
SIMPLINK
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
G
Set ID
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
AV1 Cable Box
AV2 VCR
Component1 DVD
Component2 Set Top Box
RGB PC
HDMI1/DVI Game
HDMI2 Satellite
2
3
4
1
5
WATCHING TV / CHANNEL CONTROL
50
WATCHING TV /CHANNEL CONTROL
Press the
MENU
button and then use
D
or
E
but-
ton
to select the
SETUP
menu.
Press the
G
button and then use
D
or
E
button
select
DTV Signal.
View the on-screen signal strength monitor to see
the quality of the signal being received.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
DTV SIGNAL STRENGTH
This feature displays the DTV signal levels being received
and indicates whether you need to adjust your antenna or
digital cable input. The higher the signal strength, the less
likely you are to experience picture degradation.
DTV Signal: This function is only available when the input
signal is DTV or CADTV.
MODE
LIVE TV
INPUT
DAY -
DAY +
SIMPLINK
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
Bad Normal Good
2
3
4
1
TV GUIDE ON SCREEN
TM
SYSTEM
51
TV GUIDE ON SCREEN
TM
SYSTEM
SETUP OF TV GUIDE ON SCREEN
TM
The TV Guide On Screen system uses Setup information to provide you with show listings and lineups in your
area—which are updated several times a day.
Once you set up the TV according to manufacturer’s instructions, you are ready to set up the TV Guide On
Screen system.
NOTE
The TV Guide On Screen system provides listings for cable-ready, and digital cable services as well as
over-the-air broadcast. It does not provide listings for satellite services.
TV GUIDE ON SCREEN
TM
SYSTEM
52
TV GUIDE ON SCREEN
TM
SYSTEM
Ready to setup
Reminder Screen
The TV Guide On Screen system's Reminder Screen
appears:
■
After initial TV set up.
■
If you power Off the TV and then power it back On.
To make a selection, use the
D
or
E
button to highlight
an option, and press
ENTER
.
■
"Set up TV Guide On Screen now", displays the
Welcome Screen. Press
ENTER
button to begin Setup.
■
"Remind me to set up later" returns you to watching TV.
■
"Don't remind me again" returns you to watching TV
and stops the reminder screen from appearing upon
power On.
Welcome Screen
The TV Guide On Screen system's Welcome Screen
appears:
■
By pressing the
TV Guide
button
■
When you power On your TV if you previously skipped
"Set up TV Guide On Screen now" on the Reminder
Screen.
The Welcome Screen highlights features of the TV Guide
On Screen system.
Press
ENTER
to begin Setup.
2
1
TV GUIDE ON SCREEN
TM
SYSTEM
53
Using TV Guide
Screen 1: Country
■
This screen asks you the location of your TV.
■
Use the
D
or
E
button to highlight a country.
■
Press
ENTER
button to display Screen 2.
Screen 2: Enter ZIP or Postal Code
Option 1
■
If you selected USA in Screen 1, you see the ZIP Code
screen.
■
You input numbers by either pressing the number keys on
the remote or using the
D
or
E
button to display a num-
ber, and then the
F
or
G
button to move to another
field.
■
Press
ENTER
button to display Screen 3.
Option 2
■
If you selected Canada in Screen 1, you can see the
Postal Code screen.
■
You input characters by using the
D
or
E
button, and
then the
F
or
G
button to move to another field.
■
Press
ENTER
button to display Screen 3.
Screen 3: Do you have Cable Service connected?
■
If you select Yes, you see Screen 4.
■
If you select No, you see Screen 4.
1
2
3
TV GUIDE ON SCREEN
TM
SYSTEM
54
TV GUIDE ON SCREEN
TM
SYSTEM
Screen 4: Do you have an antenna connected?
■
If you select Yes, you see Screen 5.
■
If you select No, you see Screen 5.
Screen 5: Are your basic settings correct?
■
If you select Yes, you see Screen 6.
■
If you select No, you see Screen 1.
Screen 6: Congratulations
■
Press
ENTER
button to display Screen 7.
Screen 7: Helpful Information
■
This screen tells you valuable information on using your
Guide.
■
Press
ENTER
button to watch TV.
NOTE
If you selected No in Screen 3 then you must select Yes
in this screen to receive a channel lineup and listings.
NOTE
The TV Guide On Screen system receives program
listings data through your cable or over-the-air
video signal. In order to receive regular program list-
ings, please remember to do the following:
1. Turn OFF your TV when it is not in use.
(
Do not
unplug the power cord.
)
2. If you have more than one Cable system in your
area, you may be prompted to select which Cable
system’s program data to download. If so prompt-
ed, please follow the on-screen instructions.
Program listings are updated several times a day. It
may take up to 24 hours to begin to receive any TV
program listings. It may take up to one week to
receive all eight days of TV program listings.
4
5
6
7
TV GUIDE ON SCREEN
TM
SYSTEM
55
FUNCTIONS OF TV GUIDE ON SCREEN
TM
Overview
Your new TV contains the TV Guide On Screen Interactive Program Guide.
The TV Guide On Screen system has features that help you get the most out of your viewing experience.
TV Guide On Screen Overview
The TV Guide On Screen system has the following features:
■
Eight days of show listings
(
today plus seven days
)
.
■
Icons that indicate show rating, stereo, HDTV, new episode, etc.
■
Intuitive up/down/left/right navigation using your remote control.
■
Set shows to Record.
■
Schedule show Reminders.
■
Search shows by category
(
e.g., Movies, Sports, Children, etc.
)
.
■
Search for shows based on keywords or alphabetically by title.
■
Direct tuning to a channel.
■
Streamlined System Setup and default setting options.
■
Channel lineup customization.
■
Help screens while in the TV Guide On Screen system.
TV GUIDE ON SCREEN
TM
SYSTEM
56
TV GUIDE ON SCREEN
TM
SYSTEM
Screen Components
The screens displayed in the TV Guide On Screen system share many of the same components, as shown in
the following figure:
Video Window - Displays TV video while The TV
Guide On Screen system is displayed.
Service Bar - Provides access to the 5 main
Guide Services.
Current Service Label - Indented to indicate cur-
rent Service displayed.
Tile - Displays show title.
Highlight - Indicates an active tile.
INFO Box - Provides information for a highlight-
ed item.
INFO Button - Indicates you can cycle through
the various Info Box sizes.
Channel Logo - Identifies network.
Record/Remind Icons - Indicates a show is set to
Record or set as a Reminder.
Panel Ad - Location where show- or product-spe-
cific information appears (and also where Panel
Menu appears).
TV Guide logo Current Service Label Service bar
Time slot
Tile
INFO button
INFO box
Remind icon
Record iconHighlightChannel logo
Panel Ad
and
Panel
Menu Entry
Video
Window
TV GUIDE ON SCREEN
TM
SYSTEM
57
Panel Menu
■
A Panel Menu appears when the
MENU
button is pressed on a highlighted tile and additional options are
available. It also appears when you press
ENTER
button on a show starting in the future.
■
When a Panel Menu appears, the highlighted tile changes color to indicate the Panel Menu relates to this
tile.
■
The Panel Menu displays below the Video Window.
■
Help is available for a displayed Panel Menu by pressing the
INFO
button.
■
The
D
or
E
button move between the options within the Panel Menu.
■
The left and right arrows move to adjacent options unless the highlight is on an odometer, where these
arrows change the odometer choice.
■
Pressing
ENTER
button from an odometer or number entry box moves the highlight to the default com-
mand button of that Panel Menu, for example, Schedule Recording.
■
Pressing
ENTER
button from a highlighted command button executes the action and closes the Panel
Menu (e.g., Schedule Recording, Cancel).
■
Select Cancel to cancel any changes and press
ENTER
button to close the menu.
■
Pressing Menu is a shortcut to Cancel. Press
MENU
button to cancel any changes and close the menu.
■
If a Panel Menu contains more menu options than can be displayed on a single screen, the more
E
text
appears at the bottom of the menu. Simply scroll down to access additional options.
TV GUIDE ON SCREEN
TM
SYSTEM
58
TV GUIDE ON SCREEN
TM
SYSTEM
Main Services
Listings
Use the
D E F G
button to move the highlight within
Listings to:
■
View 8 days of show listings
■
Read show descriptions
■
Tune directly to a show currently airing
■
Set a show to Remind
■
Set a show to Record
■
Lock and Unlock the Video Window
■
Access Panel and Channel Ads
Access Listings by pressing the TV GUIDE button on your remote
or on the front panel of your TV.
Listings is always the first Service displayed in the Guide.
With Listings highlighted, press the INFO button to display a Help
screen. Press the INFO button again to close the screen.
NOTE
There may be times when the TV Guide On Screen system
could display partial or no program listings. The reasons
for this include:
■
Program schedule information was not provided to TV
Guide On Screen.
■
The transmission of the program listings was interrupted.
■
The phrase “No Listings” will be replaced with program
information during the next transmission, which should
occur within the next 24 hours.
■
Please remember to turn off your TV when not in use in
order to receive program listings.
1
TV GUIDE ON SCREEN
TM
SYSTEM
59
Search
From Search, use the
E
button to highlight Movies.
Search lets you find shows alphabetically, by category (Movies,
Sports, Children, Educational, News, Variety, Series, HDTV) or
by Keyword.
With Search highlighted, press the INFO button to display a
Help screen. Press the INFO button again to close the screen.
Category Search Example: Movies
1
TV GUIDE ON SCREEN
TM
SYSTEM
60
TV GUIDE ON SCREEN
TM
SYSTEM
Go to Service Bar - Closes the menu, changes no infor-
mation, and returns to the Search Service Bar.
Tune to Channel - Exits the Guide and tunes to the
channel of the highlighted show (show airs in the
future).
Set Recording - Displays the Record Options menu,
from which you can set frequency, start and end time,
etc.
Set Reminder - Displays the Remind Options menu, from
which you can set frequency, when, automatically power
On, and auto-tune the TV.
Cancel - Closes the menu, changes no information, and
returns to the highlighted show.
Use the
E
button to highlight a subcategory
(
for exam-
ple, All
)
.
Press
ENTER
button to display a list of all Movies, orga-
nized by date and time.
Highlight a show and press
ENTER
button to watch
(
if on
now
)
or the
MENU
button to display the Episode
Options menu.
You can choose to set a recording, a reminder, or tune to
the channel.
This option reads Watch Now if the show is currently
airing.
NOTE
2
3
4
5
TV GUIDE ON SCREEN
TM
SYSTEM
61
Keyword Search
Highlight the Keyword navigation label, and press
ENTER
button to display the Keyword Search menu.
Highlight New Search, and press
ENTER
button.
The Search Options menu is displayed.
Highlight Category, and use the
F
or
G
button to select a
category to search
(
e.g. All, HDTV, Children, Sports, etc.
)
.
When finished, use the
E
button to highlight Enter
Keyword.
Highlight Enter Keyword, and press
ENTER
button.
The keyboard is displayed.
Use the
D E F G
button to highlight a character, and
press
ENTER
button to display it. When complete, high-
light Done and press
ENTER
button.
Keyword search lets you enter a word(s) to look for a particular
show by category or for every show title that matches.
1
2
3
4
5
6
TV GUIDE ON SCREEN
TM
SYSTEM
62
TV GUIDE ON SCREEN
TM
SYSTEM
Go to Service Bar - Closes the menu, changes no infor-
mation, and returns to the Search Service Bar.
Edit Search - Displays the keyboard, where you can
change the keyword.
Delete Search - A Confirm menu is displayed.
■
Yes - Deletes the Search.
■
No - Closes the panel menu.
Cancel - Closes the menu, changes no information, and
returns to the highlighted show.
A list of all matching shows for that keyword is displayed.
You can highlight a show, and press
ENTER
button to dis-
play all airings. You can then highlight a specific listing and
press
ENTER
to watch
(
if On now
)
or the
MENU
button to
display the Episode Options menu.
From the Episode Options menu, choose to set a record-
ing, a reminder, or tune to the channel, as previously
described.
The TV Guide On Screen system stores all the keywords
you create. To edit or delete a keyword, highlight the key-
word and press the
MENU
button. A Search Options menu
is displayed.
7
TV GUIDE ON SCREEN
TM
SYSTEM
63
Recorded program list
With Recordings highlighted, press the
INFO
button to
display a Help screen. Press the
INFO
button again to
close the screen.
Choose the way Recordings are displayed by highlighting
Recordings on the Service Bar and then press the
MENU
button to display the Recordings Options menu. Use the
D
or
E
buttons to choose between the following:
■
In View As, use the
F
or
G
buttons to choose between
Group - Recorded shows are listed without listing
every recorded episode (see example in Screen A).
List - Displays a complete list of every recorded
episode for a show(see example in Screen B).
■
In Sort By, use the
F
or
G
buttons to choose between
Title - Shows are displayed in alphabetical order (see
example in Screen A).
Date - Shows are displayed by date and time, with
most recent date and time first (see example in
Screen B).
When finished, press
ENTER
button to highlight Done.
Press
ENTER
button again to close the menu and display
the Recordings with the selected options.
Recordings displays a list of previously recorded or currently recording shows on a
DVR.
Screen A
Screen B
1
2
3
TV GUIDE ON SCREEN
TM
SYSTEM
64
TV GUIDE ON SCREEN
TM
SYSTEM
In List View, highlight an episode and an Info box provides
show information. Press the
MENU
button to display the
Episode Options menu.
In Group View, highlight a show and press
ENTER
button
to view a summary for the all the recorded shows along
with the episode list (Press
ENTER
button again to col-
lapse the episode list).
Highlight a specific episode and press the
MENU
button
to display the Episode Options menu.
To view an episode, you can do one of the following:
■
Highlight an episode, and press
ENTER
button to view it
now.
Go to Service Bar - Close the menu, changes no informa-
tion, and returns to the Recordings Service Bar.
Play from beginning - View the episode from the begin-
ning in TV Mode.
Delete Episode - Deletes the episode from the
Recordings, A Confirm menu is displayed.
■
Yes - Deletes the episode.
■
No - Closes the panel menu.
Cancel - Closes the menu, changes no information, and
returns to the highlighted show.
4
5
6
TV GUIDE ON SCREEN
TM
SYSTEM
65
Schedule
Highlight an event, and press the
MENU
button for options.
(Note options vary depending on the type of event you select.)
Schedule lets you review, edit, or delete Record and Remind events that you set
previously.
With Schedule highlighted, press the INFO button to display a Help screen. Press
the INFO button again to close the screen.
An icon identifies the event type:
Remind
Once - Sets a show reminder one time.
Regularly - Sets a show reminder every time the show airs on
the same channel and starts at the same time.
Weekly - Sets a show reminder each time the show airs on the
same day of the week, on the same channel and starts at the
same time.
Off - Keeps the show in the list but will not remind the show
until the frequency is changed.
Go to Service Bar - Closes the menu, changes no information,
and returns to the Schedule Service Bar.
Tune to channel - Exits the TV Guide On Screen system and
tunes to the highlighted show.
Set Recording- Opens a menu from which you can set a recording
for the show. (Remind is not cancelled)
Set Reminder- Opens a menu from which you can set a Reminder
for the show. (Record is not cancelled)
Delete Recording- Removes the recording from the Schedule after
a Confirm screen.
Delete Reminder- Removes the reminder from the Schedule after
a Confirm screen.
Edit Recording- Opens a menu from which you can change exist-
ing recording information.
Edit Reminder- Opens a menu from which you can change exist-
ing reminder information.
Cancel- Closes the menu, changes no information, and returns to
the highlighted show.
Record
Once - Records the show one time.
Regularly - Records the show every time the show airs on the
same channel and starts at the same time.
Weekly - Records the show each time the show airs on the
same day of the week, on the same channel and starts at the
same time.
Off - Keeps the show in the list but will not record the show
until the frequency is changed.
TV GUIDE ON SCREEN
TM
SYSTEM
66
TV GUIDE ON SCREEN
TM
SYSTEM
Highlight a choice, press
ENTER
button, and follow the
on-screen instructions.
With Setup highlighted, press the
INFO
button to display
a Help screen. Press the
INFO
button again to close the
screen.
Change System Settings
This option appears after you have completed the initial
Guide Setup process.
Press
ENTER
button to display the Confirming Your
Settings screen. You can see your current settings.
Choose one of the options, press
ENTER
button, and fol-
low the on-screen instructions.
Change Setup
After you initially complete Guide Setup, you can make changes
to Guide settings in the following areas:
■
Change System Settings
■
Change Channel Display
■
Change Default Options
1
2
3
4
TV GUIDE ON SCREEN
TM
SYSTEM
67
Change Channel Display lets you edit channel information
that appears in Listings. With Change Channel Display
you can :
■
Re-order the position of the channel in Listings.
■
Change the tune channel number.
■
Switch a channel.
Press
ENTER
button to display the Channel Editor screen.
Then, highlight a channel and press
MENU
button. A Grid
Options menu is displayed.
Highlight Go Back to Setup to close the menu, change no
information, and return to the Setup Service Bar.
Or make changes and when finished, press
ENTER
button
to highlight Done. Press ENTER button again to close the
menu and accept the changes.
Highlight Cancel to close the menu, change no informa-
tion, and return to the highlighted channel.
Change Channel Display
On - The channel is always displayed.
Off - The channel is never displayed.
Auto-Hide - The channel is only displayed when
program information is available.
1
2
TV GUIDE ON SCREEN
TM
SYSTEM
68
TV GUIDE ON SCREEN
TM
SYSTEM
General Default Options
General Defaults lets you set defaults for the following:
■
The initial Info Box size when the TV Guide On Screen
system is entered.
Choices are No, Small, Large, and Last Used.
(
Default =
Last Used
)
■
The Info Box size rotation when the
INFO
button is
pressed while in the TV Guide On Screen system.
Choices are No only, Small only, Large only, No & Small,
No & Large, Small & Large, All.
(
Default = All
)
■
Automatic entry into the TV Guide On Screen system
(
Auto-Guide
)
when the TV is powered On. Choices are
On and Off.(Default = Off)
Highlight General Defaults, and press the
MENU
button
to display the General Defaults menu.
Highlight Go to Service Bar to close the menu, change no
information, and return to the Setup Service Bar.
When finished, press
ENTER
button to highlight Done.
Press
ENTER
button again to close the menu and accept
the changes.
Highlight Cancel to close the menu, change no informa-
tion, and return to the highlighted option.
Change Default Options
Change Default Options lets you change default settings in the
following categories:
■
General Defaults
■
Record Defaults
■
Remind Defaults
Highlight Change Default Options, and press
ENTER
button.
1
TV GUIDE ON SCREEN
TM
SYSTEM
69
Record Defaults
Record Defaults lets you set defaults for the following:
■
When to start the record event. Choices are 120 minutes
early to 120 minutes late, to On time.
(
Default = On time
)
■
When to end the record event. Choices are 120 minutes
early to 120 minutes late, to On time.
(
Default = On time
)
■
Recorder choice: Please choose HDD only. This TV does
not support other recording devices.
Highlight Record Defaults, and press the
MENU
button to
display the Record Defaults menu.
Highlight Go to Service Bar to close the menu, change no
information, and return to the Setup Service Bar.
Remind Defaults
Remind Defaults lets you set defaults for the following:
■
Power On the TV, if Off, when a Reminder is scheduled.
Choices are Yes and No.
(
Default = No
)
■
Automatically tune the TV to the channel
(
TV must be
On
)
, when a Reminder is scheduled. Choices are Yes and
No.
(
Default = No
)
■
When to display the reminder screen, choices are 30 se-
conds to 15 minutes early, to 30 seconds to 15 minutes
■
late, to On time.
(
Default = 1 min early
)
Highlight Remind Defaults, and press the
MENU
button to
display the Remind Defaults menu.
Highlight Go to Service Bar to close the menu, change no
information, and return to the Setup Service Bar.
When finished, press
ENTER
button to highlight Done.
Press
ENTER
button again to close the menu and accept
the changes.
Highlight Cancel to close the menu, change no information,
and return to the highlighted option.
2
3
TV GUIDE ON SCREEN
TM
SYSTEM
70
TV GUIDE ON SCREEN
TM
SYSTEM
Record And Remind Features
Using the Record Button on the Remote
■
Press the
Record
button on the remote to record the show
Once with current default settings (Start and End recording On
Time). Each time you press the
Record
button, you can change
the record frequency (but not the default settings) among Once
(default), Regularly, Weekly and then Cancel.
Record
You can set a show to Record in Listings, Search, and Schedule
or change Record settings for a show in Schedule.
There are 3 ways to set a show to Record:
Once - Records the show one time.
Regularly - Records the show every time the show airs
on the same channel and starts at the same time.
Weekly - Records the show each time the show airs on
the same day of the week, on the same channel and
starts at the same time.
Cancel (no icon displayed) - Does not record.
The proper Record icon appears on the show tile, as
the
Record
button is pressed.
NOTE
SIMPLINK
Highlight a show, and press
M
MENU
button to display the
Episode Options menu.
Highlight Set Recording, and press
ENTER
button to dis-
play the Record Options menu.
From a Panel Menu
1
2
TV GUIDE ON SCREEN
TM
SYSTEM
71
Highlight the Frequency option, and use the left and right
arrows to choose among Once, Regularly, Weekly, and Off,
as previously described.
Recorder choice: Please choose HDD only. This TV does
not support other recording devices.
When finished, press
ENTER
button to highlight Schedule
Recording.
Press
ENTER
button again to close the menu. You can see
a Record icon for the selected frequency next to the show
title.
Highlight Cancel to close the menu, change no informa-
tion, and return to the highlighted show.
Highlight the Schedule Service label, and press
MENU
button to display the Schedule Options menu.
Highlight New Manual Recording and press
ENTER
but-
ton to display the Record Options menu.
Current information (i.e., date, start and end times, chan-
nel, input) is displayed.
Use the
D E F G
button to move through the options.
Use the number or the
D E F G
button to change the
information, as necessary.
Recorder choice: Please choose HDD only. This TV does
not support other recording devices.
In Listings, use the
PIP
button to change the sta-
tus of the Video Window (locked or unlocked) .
NOTE
Manual Recording
3
4
1
2
3
4
5
TV GUIDE ON SCREEN
TM
SYSTEM
72
TV GUIDE ON SCREEN
TM
SYSTEM
Highlight Cancel to close the menu, change no informa-
tion, and return to the highlighted show.
Before a recording begins, a notification screen appears if
your TV is On. At that time, you can choose to start or
cancel recording. If the TV is not On, the recording occurs
as scheduled. If there is no activity for 3 minutes, the noti-
fication screen automatically closes and completes the
highlighted item.
Record Conflict
A conflict message appears for the following reasons:
■
A show set to Record overlaps with any part of another
show previously set to Record.
■
A show set to Record overlaps with a show previously set
to auto tune.
Select one of these options:
■
Record anyway - This show will override an existing show
set to Record or auto-tune.
■
Don't record this show - Cancel the Recording.
Highlight the Frequency option, and use the
F
or
G
button to
choose between Once, Daily, Weekly, and Off, as follows :
Once - Records the time, channel, input, recorder combi-
nation one time.
Daily - Records the time, channel, input, recorder combi-
nation Monday through Friday.
Weekly - Records the time, channel, input, recorder com-
bination once a week on this selected day of the week.
Off (not cancel) - Keeps the time, channel, input,
recorder combination in the list without recording until
the frequency is changed.
When finished, press
ENTER
button to highlight Schedule
Recording.
Press
ENTER
button again to close the menu. You can see
a Record icon for the selected frequency next to the
input and channel number.
6
7
8
TV GUIDE ON SCREEN
TM
SYSTEM
73
From a Panel Menu
Highlight a show, and press Menu button to display the
Episode Options menu.
Highlight Set Reminder, and press
ENTER
button to display
the Remind Options menu.
Highlight the Frequency option, and use the left and right
arrows to choose between:
Power On the TV, if Off, when a Reminder is scheduled.
Choices are Yes and No.
(
Default = No
)
Automatically tune the TV to the channel
(
TV must be
On
)
, when a Reminder is scheduled. Choices are Yes and
No.
(
Default =No
)
When to display the reminder screen. Choices are 30 se-
conds to 15 minutes early, to 30 seconds to 15 minutes
late, to On time.
(
Default = 1 min early
)
When finished, press
ENTER
button to highlight Schedule
Reminder. Press
ENTER
button again to close the menu.
You can see a Remind icon for the selected frequency next
to the show title. Highlight Cancel to close the menu,
change no information, and return to the highlighted show.
Remind
You can set a show Reminder in Listings, Search, and Schedule
or change Reminder settings for a show in Schedule.
There are 2 ways to set a show Reminder:
Once - Sets a show reminder one time.
Regularly - Sets a show reminder every time the
show airs on the same channel and starts at the
same time.
Weekly - Sets a show reminder each time the show
airs on the same day of the week, on the same
channel and starts at the same time.
Off - Keeps the show in the list but will not remind
until the frequency is changed.
1
2
3
4
5
6
7
TV GUIDE ON SCREEN
TM
SYSTEM
74
TV GUIDE ON SCREEN
TM
SYSTEM
Highlight the Schedule Service label, and press
MENU
button to display the Schedule Options menu.
Highlight New Manual Reminder and press
ENTER
button
to display the Remind Options menu.
Current information (i.e., date, start and end times, chan-
nel, input) is displayed.
Use the
D E F G
button to move through the options.
Use the number or the
D E F G
button to change the
information, as necessary.
Highlight the Frequency option, and use the
F
or
G
but-
ton to choose among Once, Daily, Weekly, and Off, as fol-
lows :
Power On the TV, if the TV is Off, when a Reminder is
scheduled. Choices are Yes and No.(Default =No)
Automatically tune the TV to the channel (TV must be
On), when a Reminder is scheduled. Choices are Yes and
No.(Default = No)
Manual Reminder
Once - Sets a show reminder for the time, channel,
input combination one time.
Daily - Reminds for the time, channel, input combi-
nation Monday through Friday.
Weekly - Sets a show reminder for the time, chan-
nel, input combination once a week on this selected
day of the week.
Off (not cancel) - Keeps the time, channel, input
combination in the list without reminding until the
frequency is changed.
1
2
3
4
5
6
7
TV GUIDE ON SCREEN
TM
SYSTEM
75
‘
Remind Conflict
A conflict message appears for the following reasons:
■
A show set with an Auto-Tune Reminder has the same start
time as an existing Auto-Tune Reminder.
■
A show set with an Auto-Tune Reminder overlaps with a
Recording already scheduled.
Select one of these options:
■
Auto-tune anyway - This show will override an existing
show set to auto-tune.
■
Proceed, no auto-tune - Set the show as a Reminder but
do not auto-tune.
■
Don't set this reminder - Cancel the Reminder.
When finished, press
ENTER
button to highlight Schedule
Reminder. Press
ENTER
button again to close the menu.
You can see a Remind icon for the selected frequency next
to the input and channel number.
Highlight Cancel to close the menu, change no information,
and return to the highlighted show.
If more than 2 reminders are set for the same
time, arrows appear on the Reminder screen. Use
the
D
or
E
button to view the shows.
NOTE
Based on your option settings, a notification screen will
appear, if your TV is On at the reminder time. Then you can
choose to hide the reminder, or highlight the show, and
press
ENTER
button to tune to the show. If there is no
activity for 3 minutes, the notification screen automatically
closes and completes the highlighted item (hide reminders).
If you choose Hide Reminders, the window closes for the
show or shows, but does not affect other Reminders you set.
8
9
10
DVR (DIGITAL VIDEO RECORDER)
76
DVR (DIGITAL VIDEO RECORDING)
Timeshift Mode
G
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Off
On
When timeshift mode is
on, DVR will automatically
buffer current TV program
up to 1 hour.
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
TIMESHIFT (PAUSE &REPLAY OF LIVE TV)
This function allows the unit to automatically record live
TV and make it available for reviewing at any time.
With Timeshift turned on, you may pause and rewind nor-
mal TV viewing at any time without missing any of the live
broadcast.
■
While simplink function is using, Timeshift function is not
operated in HDMI1/DVI or HDMI2 mode.
Press the
MENU
button and then use
D
or
E
button
to select the
OPTION
menu.
Press the
G
button and then use
D
or
E
button to
select the
Timeshift Mode
.
Press the
G
button and then use
D
or
E
button to
select
On
or
Off
.
MODE
DAY -
DAY +
LIVE TV
INPUT
SIMPLINKSIMPLINK
2
3
1
DVR (DIGITAL VIDEO RECORDER)
77
Progressing the Timeshift function
After selecting the
Timeshift Mode On
, press the
ENTER
button.
■
As soon as Timeshift starts, a progress bar indicating the
current recording status is displayed in the bottom of the
screen.
■
Press the
EXIT
button to hide the ‘Progress Bar’ or press
the
ENTER
button to display the 'Progress Bar'.
■
This function is preserved even change a channel on pro-
gressing the Timeshift.
When finishing the Timeshift function, enter the option
menu and turn
Timeshift Mode Off
.
NOTE
DVR
(
Digital Video Recorder
)
: A device which
records and plays broadcast program contents
onto a hard disk in TV or SET TOP BOX.
If available hard-disk space is low when Timeshift
is initiated, the oldest information is deleted.
In order to save hard-disk space, nothing is saved
when there is no signal.
The total storage space of the hard-disk is 160
GB. 10GB minimum is reserved for Timeshift.
When turning power on, it may take up to 3 mi-
nutes to initialize the HDD.
The Timeshift function will not initiate for a copy-
protected program.
Because an analog broadcast is transferred to a
digital signal, video that contains rapid movement
may show "cross stripes". This happens when the
analog signal is compressed and then restored in
the digital signal. The unit will attempt to reduce
this excessive picture noise.
When using the PIP/POP mode, Timeshift is
stopped.
Timeshift is available in AV1, AV2, Antenna, Cable
mode.
Timeshift is available in Component1,2, HDMI1,
2 mode.
Timeshift is not available for Audio only channels.
The timeshift may not work properly in some
audio streams.
2
1
The ‘Progress Bar’?
This function indicates a possible DVR reshowing
section, a current on-screen and real on-broad-
casting position, a section of section-recording.
Status of current displayed video.
Current save time.
15 minute intervals from Timeshift start time.
(Total - one hour).
Indicates current Timeshift position.
DVR (DIGITAL VIDEO RECORDER)
78
DVR (DIGITAL VIDEO RECORDING)
Progressing the Timeshift function, play
On progressing Timeshift, It can do a diversified playing.
Indicates that the current broadcast and displayed video differ.
When playing, press the
REW( ) or FF( )
button.
■
Press -> -> -> to speed up.
■
Pressing these buttons repeatedly increases the fast forward/reverse speed.
Press the or button to move back and forth within the current program.
■
Press the button to jump about 20 seconds forward.
■
Pressing the button to jump about 8 seconds backward.
During playback, press the
Pause( )
button.
■
Still screen is displayed.
■
Repeatedly press the
Pause( )
button to advance frame by frame.
■
Press the
Pause( )
button and then the
FF( )
button for slow motion
(as showing the . )
■
When using the
F
or
G
button during playback the cursor can be viewed on
the screen.
Press the
PLAY( )
button to return to normal playback.
If you want to return to the live broadcast, press the
LIVE TV
button.
Using the remote control
You can shift playback to any point within playing the recorded program.
Forth and Back +/- Directly View Stop Play
Frame by
Frame
Pause
LIVE TV
MODE
LIVE TV
INPUT
SI
MPLINK
Slow motion
DVR (DIGITAL VIDEO RECORDER)
79
Select the desired channel to record and then press the button.
During recording is displayed. Use this feature to record up to 2
hours of programming.
If you want to stop recording, press the button. And then recording will
stop.
You can add/subtract recording time by pressing the button while record-
ing. Press the
F
or
G
button repeatedly to add/subtract to the recording time.
Each time you press
F
or
G
button the recording duration changes as shown
below.
INSTANT RECORDING
Instant Record
Use this function to record the program you are watching on the main screen
(Analog or Digital broadcast.)
This function records the currently displayed channel.
+10min
-
> +20min
-
> +30min
-
> +40min
-
> +50min
-
> +1hr
-10min
-
> -20min
-
> -30min
-
> -40min
-
> -50min
-
> -1hr
No Change
■
While recording, if you press the button fewer than
10 seconds, this message is displayed.
■
If you press the button more than 10 seconds, this
message is displayed.
■
Do not subtract more than the current recorded time or you will receive
the following error message.
( For example, if you have recorded for 35 minutes, you cannot subtract
40 minutes. )
Reached possible minimum recording duration.
2
3
1
DVR (DIGITAL VIDEO RECORDER)
80
DVR (DIGITAL VIDEO RECORDING)
NOTE
When recording, if the available storage space
becomes low, the recording will be automatically
stopped.
Recordings of less than 10 seconds will not be
saved.
To save disk space while recording analog or di-
gital broadcasts, no data is saved if there is no
signal.
The recording function will not initiate for a
copy-protected program.
The displayed time slightly differ from the actual
time.
In no signal or film source, the displayed time
slightly differ from the actual time.
The recording can not be used with copy-pro-
tected programs on progressing Timeshift .
If you press Record while watching a broadcast
(with content-protected program) using the
Timeshift function, recording begins from that
point.
If you record for a long time, in a state of the
Analog signal is weak, remained recording time
may be short.
The extra recording time added to the existing setting
equals the final recording time.
After adjusting the recording time, select
OK
. The progress
bar will be displayed.
■
Press the
EXIT
button to hide the Progress Bar. Press the
ENTER
button to display the progress bar.
Recording stops when the selected duration is reached or
when you press the button.
Note: Although recording has stopped, the Timeshift fea-
ture remains active.
Elapsed recording time
Total recording duration
4
5
DVR (DIGITAL VIDEO RECORDER)
81
Watching & Record
screen being recorded
Watch & Record Input
While recording, you can change channels or inputs without dis-
turbing the recording. The broadcast being recorded can be
shown in the lower-right corner of the main screen.
After starting an Instant Record or Reserved Record,
change the channel or input.
■
You can check the show being recorded in the lower-right
corner the main screen (as shown below).
■
Press the
PIP
button to cancel or show the program being
recorded.
■
Press the
SWAP
button to return to the program being
recorded in Watch & Record.
■
When changing to the channel being recorded in Watch &
Record, the screen is changed to Instant Record state or
Reserved Record state.
NOTE
CAUTION
When a digital broadcast is being recorded, another
digital broadcast cannot be watched.
if you turn the power off on recording, this message is
displayed as shown below.
If you selects Yes, recording stops and then power is off.
If you selects No, recording continues and the power is
turned off.
Digital Analog AV1 AV2
Digital X 0 0 0
Analog 0 0 0 0
AV1 0 0 0 0
AV2 0 0 0 0
Component1 0 0 0 0
Component2 0 0 0 0
RGB-PC/DTV 0 0 0 0
HDMI1/DVI 0 0 0 0
HDMI2 0 0 0 0
Record
Watch
FLASHBK
APM
CC
1
Component1 Component2
Digital X X
Analog X X
AV1 X X
AV2 X X
Component1 X X
Component2 X X
RGB-PC/DTV X X
HDMI1/DVI X X
HDMI2 X X
Record
Watch
DVR (DIGITAL VIDEO RECORDER)
82
DVR (DIGITAL VIDEO RECORDING)
MODE
LIVE TV
INPUT
DAY -
D
AY +
SIMPLINK
Press the button to display
HOME
menu. Use the
D
or
E
button to select the
Manual Rec
and then use the
ENTER
or
G
button.
Manual Rec
screen is displayed as shown below.
Use the
D E F G
button to set the
Input
,
Channel
,
Date
,
Start Time
,
End Time
,
Frequency
.
After setting the
Manual Rec
, press the
ENTER
button.
Input
: Select the input source from the available options
(TV, DTV, CATV, CADTV, AV1, AV2, Component1,2).
Note: If the TV Guide On Screen is Setup only for antenna :
CATV and CADTV are not available, and if the TV Guide On
Screen is Setup only for cable : TV and DTV are not available.
Channel
: Select either the current channel or a scanned
channel.
Date
: You can select a date up to one month in the
future.
Start Time /End Time
: Ensure you have set AM or PM
correctly.
Frequency
: Choose among Once, Daily and Weekly.
NOTE
You can see scheduled detail
information on the SCHEDULE
menu of the TV Guide On
Screen.
• You can also set the manual
recording in the Schedule Options
panel menu of the SCHEDULE.
(
p.65)
2
3
1
This function is easy to register to reserved recording.
- In order to use this feature, you must first setup the TV Guide
On Screen system.
PROGRAMMED RECORDING
DVR (DIGITAL VIDEO RECORDER)
83
RECORDED TV PROGRAM LIST
You can watch the recorded program list at a glance.
Press the button to display
HOME
menu.
Use the
D
or
E
button to select the
Recorded TV
and then
use the
ENTER
or
G
button.
MODE
LIVE TV
INPUT
DAY -
DAY +
SI
MPLINK
Screen Components
Folder List
Current page/Total pages
Marked thumbnail photo
number
Direct Buttons
Usable HDD
1
DVR (DIGITAL VIDEO RECORDER)
84
DVR (DIGITAL VIDEO RECORDING)
Folder List
Select a desired folder in the folder list and then press the
ENTER
button to view the detailed menu.
Use the
CH
D
or
E
button for page up/down navigation.
Use the button to move or delete from the list. A
is displayed next to the thumbnail photo if an item is
marked.
Recorded program Selection and PopUp Menu
The thumbnail recorded list is shown above.
DAY -
D
AY +
SIM
PLINK
Create: Create new folder.
Delete: Delete folder (except ‘My TV’).
Rename: Edit folder name (except ‘My TV’).
Use the
D
D E F G
and
ENTER
button to edit folder
name.
Move the cursor to OK and press the
ENTER
button to
save.
Cancel: Close the detailed menu.
2
1
DVR (DIGITAL VIDEO RECORDER)
85
■
If the HDD has a problem performing a function
(Recording) related to the DVR, select
Yes
or
No
to ini-
tialize HDD.
If you select
Yes
, the Recorded List (Recording) will be
deleted. If you select
No
, the DVR may not function pro-
perly.
■
If the temperature is below zero (0°), a warning message
is displayed and you need to initialize the HDD.
Use
D E F G
button to navigate the appropriate thumb-
nail photo, then press the
ENTER
button to open the pop-
up menu.
Repeatedly, press
EXIT
button to return to TV viewing or
press button to return to the
HOME
menu.
Play
: Begin playback of selected recorded program.
Mark All
: mark all recorded programs on the screen.
Unmark All
: Change marked recorded programs to
unmarked recorded programs.
Move
: Move recorded program saved in HDD to a dif-
ferent folder.
Delete
: Delete the selected recorded programs.
Rename
: Edit recorded program title.
Cancel
: Close the Pop-up menu.
4
3
DVR (DIGITAL VIDEO RECORDER)
86
DVR (DIGITAL VIDEO RECORDING)
Playing recorded programs
You can play the selected program in the recorded program list.
Play a recorded program.
While playing, You can see a diversified playback screen as shown below.
■
At first, an icon showing current playback mode is displayed as marking
. Then press the
ENTER
button to display the progress bar.
■
To stop displaying the recorded programs icon, press the
EXIT
button.
The ‘Progress Bar’?
This function indicates a possible DVR
reshowing section, a current on-screen
and real on-broadcasting position, a
section of section-recording.
Indicates movement of recorded
program.
Indicates status of recorded pro-
gram.
Indicates elapsed playback time.
Indicates total playback time.
Indicates a quarter of program run-
time.
Indicates current playback position.
Using the remote control
You can shift playback to any point within the recorded program.
When playing, press the
REW( ) or FF( )
button.
■
Press -> -> -> to speed up.
■
Pressing these buttons repeatedly increases the fast forward/reverse speed.
Press the or button to move back and forth within the current program.
■
Press the button to jump about 20 seconds forward.
■
Pressing the button to jump about 8 seconds backward.
During playback, press the
Pause( )
button.
■
Still screen is displayed.
■
Repeatedly press the
Pause( )
button to advance frame by frame.
■
Press the
Pause( )
button and then the
FF( )
button for slow motion
(as showing the ).
■
After using
G
to rewind while playing, press the
F
button to return to the
prior screen.
Press the
PLAY( )
button to return to a normal playback.
■
If you want to return to the live broadcast, press the
LIVE TV
button.
■
If you press the
STOP( )
button, you can watch TV.
LIVE TV
2
1
DVR (DIGITAL VIDEO RECORDER)
87
At the point you wish to start editing, press the button.
■
The progress bar will show the edited section as red.
■
It is possible to search ( or ), and pause while editing the sec-
tion.
When you wish to stop, press the button.
■
Stop editing the section.
If you repeat steps 1,2, it is possible to edit more programs.
If you press the button to stop the recorded program playback, this
message is displayed as shown below.
NOTE
It is possible to play the recording / reserved
recording.
You may hear noise from the hard-disk during
playback of the recorded program. This is normal
and does not indicate a problem.
When saving the content of the edited section,
delete the portion not selected.
When power fails during editing, the program
may not be saved or edited. Press the
STOP
( )
button after checking the recording list.
You can edit up to 10 programs.
You must select at least 10 seconds for the edit-
ed portion to be saved.
MODE
LIVE TV
INPUT
SI
MPLINK
Editing a section
You can save the desired screen in the recorded program list after editing the
recorded program.
Undo
: Don't save contents of the edited section and finish the
playback of the recorded program.
Cancel
: The screen returns to playback.
Save
: Save contents of the edited
section and finish the playback of
the recorded program.
4
2
3
1
DVR (DIGITAL VIDEO RECORDER)
88
DVR (DIGITAL VIDEO RECORDING)
On playing the recorded program, repeat a section
MODE
LIVE TV
INPUT
SI
MPLINK
You can set the recording to repeat the same section.
At the point you wish to start, press the button.
■
The following symbol will appear: .
At the point you wish to finish, press the button.
■
The following symbol appears: .
■
Repeatedly play the marked section.
■
You can not make sections of less than 5 seconds.
■
The progress bar for the repeated section will be shown in blue.
Press the button to stop playing the repeat section.
NOTE
It is possible to search using ( / ).
Pause to edit a section while repeating.
2
3
1
DVR (DIGITAL VIDEO RECORDER)
89
FORMAT HARD DISC
Erases all programs and initializes the hard drive.
Press the
MENU
button and then use
D
or
E
button
to select the
OPTION
menu.
Press the
G
button and then use
D
or
E
button to
select
HDD Format
.
Press the
ENTER
or
G
button.
Select
Yes
or
No
to format HDD as shown below.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
SI
MPLINK
- If you select
Yes
, the Recorded List (Recording) will
be deleted. Even if you selects
Yes
, the DVR may not
function if there are problems with the hard drive.
2
3
4
1
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
G
SimpLink
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Selection (
G
or ) leads
you to delete all programs
from list and initialize
HDD.
TV 4-0
TV 6-0
PICTURE CONTROL
90
PICTURE CONTROL
APM
CC
Watching PIP/POP/Twin Picture
Press the PIP button to access the sub picture.
Each press of PIP changes the PIP options as shown below.
PIP Mode POP Mode
Twin picture Mode
PIP lets you view 2 different inputs (sources) on your TV screen
at the same time. One source will be large, and the other
source will show a smaller inset image.
Twin Picture mode splits the screen into two images, allowing
two picture sources to be shown on the TV screen at the same
time. Each source is given half the screen.
TV 2-0
PIP Off
WATCHING PIP (PICTURE-IN-PICTURE)/
POP(PICTURE-OUT-OF-PICTURE)/TWIN PICTURE
Moving the PIP sub picture
PICTURE CONTROL
91
Selecting an Input Signal Source for PIP/Twin Picture
Use the
PIP INPUT
button to select the input source for the sub picture. Each press of
PIP INPUT
button
changes the PIP source. You can also select sources for the
Sub Input
in the
SETUP
menu.
Main Picture Source Available Sub Picture Sources
DTV/CADTV Analog(TV/CATV), AV1, and AV2
TV/CATV, AV1, AV2, Component1,
Component2, RGB-PC/RGB-DTV, DTV/CADTV, Analog(TV/CATV), AV1, and AV2
HDMI1/DVI, HDMI2
TV Program selection for PIP
Press the
PIP
button.
Select the Antenna or Cable option on the Sub input menu
or with the
PIP INPUT
button.
Use the
PIPCH+
/
PIPCH-
button to select a channel for
the sub picture.
(You can’t select DTV for main and sub picture simulta-
neously).
In PIP mode, press the
D E F G
button to move the sub
picture to a different location on the screen.
2
1
1
PICTURE CONTROL
92
PICTURE CONTROL
Swapping the PIP/Twin Picture
Repeatedly, use the
SWAP
button to switch the main and sub pictures.
■
Component 1, Component 2, RGB-PC (or RGB-DTV), HDMI1/DVI, HDMI2 input sources for the main
picture can’t be used to swap the main and sub pictures.
Main Picture Sub Picture
Adjusting Main and Sub Picture Sizes for Twin Picture
Use the
D E F G
button to change main and sub picture
sizes in Twin Picture mode.
■
If screen is adjusted to the maximum size, the large screen
is filled with entire screen vertically as shown.
SWAP
PIP
Twin
1
1
SWAP
Main Picture Sub Picture
TV 4-0
TV 6-0
PICTURE CONTROL
93
POP (Picture-out-of-Picture : Channel Scan)
Press the
PIP
button to activate the
POP mode
while in
PIP
mode.
■
Channel selection
: Use
F
button to Enlarge the
selected channel being searched on the PIP screen to
shift it for viewing on the Main screen.
■
PIP selection
: Use
D
or
E
button to select one of 3
PIP screen pictures in
POP
mode.
■
When watching TV/CATV, TV/DTV or CATV/CADTV Sub
pictures are scanned. However, when watching
DTV/CADTV , only TV/CATV Sub pictures are scanned.
Press the
EXIT
button to cancel POP mode.
Use POP to search the programs of all the memorized channels
one-by-one on the 3 PIP screen display, (while the main picture
source remains the current channel). The pictures of all the
programmed channels are searched with the 3 POP screens.
NOTE
Run EZ Scan channel search before using POP mode.
When Sub pictures are changed from the TV/DTV to
CATV/CADTV in POP mode, you may hear a noise from
the Tuner switch.
2
1
TV 2-0
PICTURE CONTROL
94
PICTURE CONTROL
Set by program
Selects the proper picture proportion to match
the source’s image.
4:3
Choose 4:3 when you want to view a picture
with an original 4:3 aspect ratio.
16:9
Adjust the picture horizontally, in a linear pro-
portion to fill the entire screen.
Horizon
The screen size is, more enlarged at both sides,
to create a spectacular view.
Zoom 1
Choose Zoom 1 when you want to view the
picture without any alteration. However, the top
and bottom portions of the picture will be
cropped.
Zoom 2
Choose Zoom 2 when you want the picture to
be altered, both vertically extended and
cropped. The picture taking a halfway trade off
between alteration and screen coverage.
Cinema Zoom
Choose Cinema Zoom when you want to
enlarge the picture in correct proportion. Note:
When enlarging or reducing the picture, the
image may become distorted.
This feature lets you choose the way an analog picture with a 4:3 aspect ratio is dis-
played on your TV. When you receive an analog picture with a 4:3 aspect ratio on
your 16:9 TV, you need to specify how the picture is to be displayed.
■
RGB-PC/DVI-PC input source use 4:3 or 16:9 aspect ratio.
PICTURE SIZE (ASPECT RATIO)CONTROL
FLASHBK
APM
CC
Press the
RATIO
button repeatedly to select the desired picture format.
You can also adjust
Aspect Ratio
in the
OPTION
menu.
■
The adjustment range is 1-16.
1
Set By Program
4:3
16:9
Horizon
Zoom 1
Zoom 2
Cinema Zoom
D
1
Set By Program
(4:3 4:3)
(16:9 16:9)
95
EZ Picture - Preset
Press the
EZ PIC
button repeatedly to select the picture
appearance setup option as shown below :
Daylight
,
Normal
,
Night Time
,
User1
, and
User2
(your
own settings).
Press the
EXIT
button to save and return to TV viewing.
FLASHBK
APM
CC
EZ Picture adjusts the TV for the best picture appearance.
Select the preset value in the EZ Picture menu based on the
program category.
Daylight
,
Normal
,
Night Time
Settings are preset for optimum
picture quality at the factory and are not adjustable.
In the
User 1
, and
User 2
modes only, user can directly
adjust the contrast, brightness, color, sharpness, tint.
■
You can also use the
VIDEO
menu to adjust EZ Picture.
EZ Picture
G
Color Temperature
XD
Advanced
Video Reset
EZ Picture
Color Temperature
XD
Advanced
Video Reset
Daylight
Normal
Night Time
User 1
user 2
2
1
PRESET PICTURE SETTINGS
PICTURE CONTROL
PICTURE CONTROL
96
PICTURE CONTROL
Adaptive Picture Mode
(
APM
)
Press the
APM
button at once. As shown below, the screen
is divided to 4-split.
Use the
D E F G
button to navigate 4 EZ Pictures.
By pressing the
ENTER
button, you can select the desired
mode.
Press the
APM
button twice times. The 4-same screens are
displayed. You can easily compare with 4 modes.
Use the
D E F G
button to navigate 4 EZ Pictures.
By pressing the
ENTER
button, you can select the desired
mode.
Allows you to select your preferred picture mode after compar-
ing the four different picture (Daylight , Normal , Night Time ,
User 1 and User 2) settings.
FLASHBK
APM
CC
Daylight Normal
User 1
Night Time
EXIT
Navigate Select Exit
NOTE
While operating the 4-split, any button except
APM
,
ENTER
,
EXIT
,
VOLUME
or ,
MUTE
or
button on the remote control are not usable.
2
3
4
1
Daylight Normal
User 1Night Time
EXIT
Navigate Select Exit
PICTURE CONTROL
97
Color Tone -Preset
Choose one of three automatic color adjustments. Set to warm
to enhance hotter colors such as red, or set to cool to see less
intense colors with more blue.
When selecting EZ Picture options (Daylight, Normal and Night
Time),
Color Temperature
is automatically change.
When selecting EZ Picture options (User 1 and User 2), you
can choose the
Color Temperature
.
Press the
MENU
button and then use
D
or
E
button
to select the
VIDEO
menu.
Press the
G
button and then use
D
or
E
button to
select
Color Temperature
.
Press the
G
button and then use
D
or
E
button to
select either
Cool, Medium, Warm
or
User
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
EZ Picture
Color Temperature
G
XD
Advanced
Video Reset
EZ Picture
Color Temperature
XD
Advanced
Video Reset
Cool
Medium
Warm
User
2
3
4
1
PICTURE CONTROL
98
PICTURE CONTROL
EZ Picture -User Mode
MANUAL PICTURE ADJUSTMENT
Press the
MENU
button and then use
D
or
E
button
to select the
VIDEO
menu.
Press the
G
button and then use
D
or
E
button to
select
EZ Picture
.
Press the
G
button and then use
D
or
E
button to
select
User 1
or
User 2
.
Press the
G
button and then use
D
or
E
button to
select the desired picture option
(
Contrast,
Brightness, Color, Sharpness, or Tint
)
.
Press the
G
button and then use
F
or
G
button to
make appropriate adjustments.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Adjust the picture appearance to suit your preference and
viewing situations.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
2
3
4
5
6
1
EZ Picture
Color Temperature
XD
Advanced
Video Reset
Daylight
Normal
Night Time
User 1
G
User 2
Selection (
G
or ) leads you
to the detailed setting
screen.
Contrast 85
E
User1
Contrast 85
G
Brightness 50
Color 50
Sharpness 50
Tint 0
R G
Press to confirm.
MENU
EZ Picture
Color Temperature
XD
Advanced
Video Reset
PICTURE CONTROL
99
You can also adjust the detailed settings(Red, Green, Blue)
by selecting the
User
menu.
Press the
MENU
button and then use
D
or
E
button
to select the
VIDEO
menu.
Press the
G
button and then use
D
or
E
button to
select
Color Temperature
.
Press the
G
button and then use
D
or
E
button to
select
User
.
Press the
G
button and then use
D
or
E
button to
select
Red
,
Green
, or
Blue
.
Press the
G
button and then use
F
or
G
button to
make appropriate adjustments.
■
The adjustment range of
Red
,
Green
, or
Blue
is -20~ +20.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Red 0
E
EZ Picture
Color Temperature
XD
Advanced
Video Reset
EZ Picture
Color Temperature
XD
Advanced
Video Reset
Press to confirm.
MENU
Selection (
G
or ) leads you
to the detailed setting
screen.
Cool
Medium
Warm
User
G
User
Red 0
G
Green 0
Blue 0
2
3
4
5
6
1
Color Tone -User Mode
PICTURE CONTROL
100
PICTURE CONTROL
Press the
MENU
button and then use
D
or
E
button
to select the
VIDEO
menu.
Press the
G
button and then use
D
or
E
button to
select
XD
.
Press the
G
button and then use
D
or
E
button to
select
Auto
or
Manual
.
*
Selecting the Manual
1. Press the
G
button and then use
F
or
G
button to
select
XD Contrast, XD Color
or
XD Noise
.
■
XD Contrast :
Optimizing the contrast automatically
according to the brightness of the reflection.
■
XD Color :
Adjusting the colors of the reflec-
tion automatically to reproduce as closely as
possible to the natural colors.
■
XD Noise :
Removing the noise up to the point where it
does not damage the original picture.
2. Use the
D
or
E
button to select
O n
or
Off
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
XD is LG Electronics unique picture improving technology to display a real HD
source through an advanced digital signal processing algorithm.
When selecting EZ Picture options (Daylight, Normal and Night time), XD is
automatically change to Auto.
When selecting EZ Picture options (User 1 and User 2), you can choose the
Auto / Manual and when selecting Manual, you can adjust the XD Contrast,
XD color and XD Noise.
XD - PICTURE IMPROVEMENT TECHNOLOGY
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
EZ Picture
Color Temperature
XD
G
Advanced
Video Reset
EZ Picture
Color Temperature
XD
Advanced
Video Reset
Manual
XD Contrast On
XD Color On
XD Noise On
2
3
4
1
PICTURE CONTROL
101
ADVANCED -CINEMA 3:2 PULLDOWN MODE
Press the
MENU
button and then use
D
or
E
button
to select the
VIDEO
menu.
Press the
G
button and then use
D
or
E
button to
select
Advanced
.
Press the
G
button and then use
D
or
E
button to
select
Cinema 3:2 Mode
.
Press the
G
button and then use
D
or
E
button to
select
On
or
Off
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Set up the TV for the best picture appearance for viewing
movies.
When you operate Cinema (3:2 Pull-Down Mode or Cinema
Correction Mode), the TV will adjust 24 fps video from
movies to 30 fps video for display (This function is only
available in Analog, AV1, AV2, Component 480i mode.)
2
3
4
5
1
EZ Picture
Color Temperature
XD
Advanced
G
Video Reset
Cinema 3:2 Mode Off
Black Level Auto
EZ Picture
Color Temperature
XD
Advanced
Video Reset
PICTURE CONTROL
102
PICTURE CONTROL
ADVANCED-BLACK(DARKNESS) LEVEL
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Press the
MENU
button and then use
D
or
E
button
to select the
VIDEO
menu.
Press the
G
button and then use
D
or
E
button to
select
Advanced
.
Press the
G
button and then use
D
or
E
button to
select
Black level
.
Press the
G
button and then use
D
or
E
button to
select
Auto
,
Low
, or
High
.
■
Auto
Realizing the black level of the screen and set it to
High or Low automatically.
■
Low
The reflection of the screen gets darker.
■
High
The reflection of the screen gets brighter.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Adjusting the contrast and the brightness of the screen
using the black level of the screen.
This feature operates only in HDMI1/DVI, HDMI2 or AV1,
AV2 mode.
EZ Picture
Color Temperature
XD
Advanced
G
Video Reset
EZ Picture
Color Temperature
XD
Advanced
Video Reset
Cinema 3:2 Mode Off
Black Level Auto
2
3
4
5
1
PICTURE CONTROL
103
PICTURE RESET
Press the
MENU
button and then use
D
or
E
button
to select the
VIDEO
menu.
Press the
G
button and then use
D
or
E
button to
select
Video Reset
.
Press the
G
button to reset the Video menu options
to original values.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Use to quickly reset all the Video menu options to their original
factory preset values.
EZ Picture
Color Temperature
XD
Advanced
Video Reset
G
EZ Picture
Color Temperature
XD
Advanced
Video Reset
Selection (
G
or ) resets
to the factory settings
(default).
2
3
1
PICTURE CONTROL
104
PICTURE CONTROL
IMAGE STICKING MINIMIZATION(ISM)METHOD
Press the
MENU
button and then use
D
or
E
button
to select the
OPTION
menu.
Press the
G
button and then use
D
or
E
button to
select
ISM Method
.
Press the
G
button and then use
D
or
E
button to
select either
Normal
,
White wash
,
Orbiter
or
Inversion
.
■
Normal
If image sticking is never a problem, ISM is not ne-
cessary set to Normal.
■
White wash
White Wash removes permanent images from the
screen.
■
Orbiter
Orbiter may help prevent ghost images. However, it
is best not to allow any fixed image to remain on the
screen. To avoid a permanent image on the screen,
the image will move once per 2 minutes : Left
Right Upside Downside Right Left
Downside Upside.
■
Inversion
Inversion will automatically invert the plasma display
panel color every 30 minutes.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
SI
M
PLINK
A frozen still picture from a PC/video game displayed on the
screen for prolonged periods will result in a ghost image. Use
our unique method to minimize any fixed image on the screen.
NOTE
An excessive permanent image may be impossible
to clear entirely with White Wash. To return to
normal viewing, press any button.
2
3
4
1
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
G
Low Power
HDD Format
SimpLink
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Normal
White Wash
Orbiter
Inversion
PICTURE CONTROL
105
LOW-POWER PICTURE MODE
Low power reduces the plasma display power consumption.
Press the
MENU
button and then use
D
or
E
button
to select the
OPTION
menu.
Press the
G
button and then use
D
or
E
button to
select
Low power
.
Press the
G
button and then use
D
or
E
button to
select
On
or
Off
.
■
When you select On, the screen darkens.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
SI
M
PLINK
2
3
4
1
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
G
HDD Format
SimpLink
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Off
On
SOUND & LANGUAGE CONTROL
106
SOUND & LANGUAGE CONTROL
Scans for changes in sound levels during commercials, then
adjusts the sound to match the specified audio level. SoundRite
makes sure that the volume level remains consistent whether
you are watching a commercial or a regular TV program.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
AUTO VOLUME LEVELER
(
EZ SOUNDRITE
)
Press the
MENU
button and then use
D
or
E
button
to select the
AUDIO
menu.
Press the
G
button and then use
D
or
E
button to
select
EZ SoundRite
.
Press the
G
button and then use
D
or
E
button to
select
On
or
Off
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
2
3
4
1
Audio Language
EZ SoundRite
G
EZ Sound
Balance
TV Speaker
BBE
Off
On
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
SOUND & LANGUAGE CONTROL
107
EZ Sound lets you enjoy the best sound without any special
adjustment because the TV sets the appropriate sound options
based on the program content.
Normal, Stadium, News, Music and Theater are preset for good
sound quality at the factory and are not adjustable.
Press the
EZ SOUND
button repeatedly to select the appropriate
sound setup as shown below :
Normal, Stadium, News, Music,Theater
and
User
(your own settings).
Press
EXIT
button to return to TV viewing .
PRESET SOUND SETTINGS(EZ SOUND)
FLASHBK
APM
CC
■
You can also adjust EZ Sound in the
A
AUDIO
menu.
2
1
Audio Language
EZ SoundRite
EZ Sound
G
Balance
TV Speaker
BBE
Normal
Stadium
News
Music
Theater
User
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
SOUND & LANGUAGE CONTROL
108
SOUND &LANGUAGE CONTROL
SOUND SETTING ADJUSTMENT -USER MODE
Press the
MENU
button and then use
D
or
E
button
to select the
AUDIO
menu.
Press the
G
button and then use
D
or
E
button to
select
EZ Sound
.
Press the
G
button and then use
D
or
E
button to
select
User
.
Press the
G
button and then use
D
or
E
button to
select the desired sound option (
Treble, Bass ,
or
Front Surround
).
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Adjust the sound to suit your taste and room situations.
2
3
4
1
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
Selection (
G
or ) leads you
to the detailed setting
screen.
Normal
Stadium
News
Music
Theater
User
G
User
Treble 50
G
Bass 50
Front Surround Off
Press to confirm.
MENU
SOUND & LANGUAGE CONTROL
109
Press the
G
button and then use
F
or
G
button to
make appropriate adjustments.
*
Selecting the Front Surround
Press the
G
button and then use
F
or
G
button to
select
Off, 3D EchoSound System
or
SRS
(
Sound
Retrieval System)
TruSurround XT
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
front Surround 3D EchoSound System
SRS TruSurround XT
Takes advantage of any multi-channel format without
needing to add extra speakers or equipment. Dialog
clarity, bass enrichment, and the addition of stereo
audio enhancement produces an immersive sound
experience from standard stereo material.
3D EchoSound System
Creates a stunning simulated stereo effect from any
mono sound and a realistic three-dimensional sound
with a very wide and deep sound stage.
6
5
SOUND & LANGUAGE CONTROL
110
SOUND &LANGUAGE CONTROL
BALANCE
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Adjust the left/right sound of speaker to suit your taste and
room situations.
Press the
MENU
button and then use
D
or
E
button
to select the
AUDIO
menu.
Press the
G
button and then use
D
or
E
button to
select
Balance
.
Press the
G
button and then use
F
or
G
button to
make appropriate adjustments.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
2
3
4
1
L R
Balance 0
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
Audio Language
EZ SoundRite
EZ Sound
Balance 0
TV Speaker
BBE
L R
SOUND & LANGUAGE CONTROL
111
BBE -SOUND IMPROVEMENT TECHNOLOGY
Press the
MENU
button and then use
D
or
E
button
to select the
AUDIO
menu.
Press the
G
button and then use
D
or
E
button to
select
BBE
.
Press the
G
button and then use
D
or
E
button to
select
On
or
Off
.
Press
EXIT
button to return to TV viewing or press
ENTER
button to return to the previous menu.
BBE High Definition Sound restores clarity for better speech
intelligibility and musical realism.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
2
3
4
1
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
G
Off
On
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
SOUND & LANGUAGE CONTROL
112
SOUND &LANGUAGE CONTROL
STEREO/SAP BROADCAST SETUP
FLASHBK
APM
CC
This TV can receive MTS stereo programs and any SAP
(
Secondary Audio Program
)
that accompanies the stereo pro-
gram if the station transmits an additional sound signal as well
as the original one and when you select Stereo or SAP on the
remote control.
Mono sound is automatically received if the broadcast is only in
Mono; even though Stereo or SAP has been selected.
Select Mono if you want to listen to the mono sound in remote
areas during stereo/SAP broadcasting.
Stereo or SAP can be received in Analog channel.
Use the
S
SAP
button to select your desired MTS mode in analog signal. Each
time you press the
SAP
button, Mono, Stereo, or SAP appear in turn.
■
If other languages available on the digital signal, select them with the
SAP
button.
Press
EXIT
button to save and return to TV viewing.
2
1
SOUND & LANGUAGE CONTROL
113
TV SPEAKERS ON/OFF SETUP
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Press the
MENU
button and then use
D
or
E
button
to select the
AUDIO
menu.
Press the
G
button and then use
D
or
E
button to
select
TV Speaker
.
Press the
G
button and then use
D
or
E
button to
select
On
or
Off
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Turn the TV speakers off if using external audio equipment.
Feature turns the TV Speakers option On or Off.
2
3
4
1
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
G
BBE
Off
On
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
SOUND & LANGUAGE CONTROL
114
SOUND &LANGUAGE CONTROL
AUDIO LANGUAGE
Other languages may be available if a digital signal is provided
by the broadcasting station.
This feature operate only in DTV/CADTV mode.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Press the
MENU
button and then use
D
or
E
button
to select the
AUDIO
menu.
Press the
G
button and then use
D
or
E
button to
select
Audio Language
.
Press the
G
button and then use
D
or
E
button to
select : English, Spanish, or French.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Audio Language
G
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
English
Spanish
French
2
3
4
1
Audio Language
EZ SoundRite
EZ Sound
Balance
TV Speaker
BBE
SOUND & LANGUAGE CONTROL
115
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
G
ISM Method
Low Power
HDD Format
SimpLink
ON-SCREEN MENUS LANGUAGE SELECTION
Press the
MENU
button and then use
D
or
E
but-
ton to select the
OPTION
menu.
Press the
G
button and then use
D
or
E
button to
select
Language
.
Press the
G
button and then use
D
or
E
button
to select your desired language.
From this point on, the on-screen menus will be
shown in the selected language.
Press the
EXIT
button to return to TV viewing or
press
MENU
to return to the previous menu.
The menus can be shown on the screen in the selected
language. First select your language.
English
Español (Spanish)
Français (French)
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
2
3
4
1
SOUND & LANGUAGE CONTROL
116
SOUND &LANGUAGE CONTROL
CAPTION / TEXT
Use the
CC
button repeatedly to select Caption
Off
,
CC1
,
CC2
,
CC3
,
CC4
,
Text1
,
Text2
,
Text3
or
Text4
.
■
CAPTION
The term for the words that scroll across the bottom of the TV screen;
usually the audio portion of the program provided for the hearing impaired.
■
TEXT
The term for the words that appear in a large black frame and almost cover
the entire screen; usually messages provided by the broadcaster.
Press
EXIT
button to save and return to TV viewing.
■
You can also use the
OPTION
menu to select
Caption
/
Text
.
Analog Broadcasting System Captions
Select a caption mode for displaying captioning information if provided on a
program. Analog caption displays information at any position on the screen and
is usually the program's dialog.
Text displays information, usually at the bottom position and is used for a data
service, generally not program related. Caption/Text, if provided by the broad-
caster, would be available for both digital and analog channels on the
Antenna/Cable.
This TV is programmed to memorize the caption/text mode which was last set
when you turn the power off.
FLASHBK
APM
CC
2
1
Timeshift Mode
Aspect Ratio
Caption/Text
G
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Off
CC 1
CC 2
CC 3
CC 4
Text 1
Text 2
Text 3
Text 4
SOUND & LANGUAGE CONTROL
117
Press the
MENU
button and then use
D
or
E
button
to select the
OPTION
menu.
Press the
G
button and then use
D
or
E
button to
select
Caption
/
Text
.
Press the
G
button and then use
D
or
E
button to
select available caption languages :
English
,
Spanish
or
French
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Digital Broadcasting System Captions
Choose the language you want the DTV/CADTV Captions to
appear in.
Languages can be chosen for digital sources only if they are
included on the program.
2
3
4
1
Timeshift Mode
Aspect Ratio
Caption/Text
G
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Off
English
Spanish
French
SOUND & LANGUAGE CONTROL
118
SOUND &LANGUAGE CONTROL
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
CAPTION OPTION
Customize the DTV/CADTV captions that appear on your screen.
Press the
MENU
button and then use
D
or
E
but-
ton to select the
OPTION
menu.
Press the
G
button and then use
D
or
E
button to
select
Caption Option
.
Press the
G
button and then use
F
or
G
button to
select
Custom
.
Use
D
or
E
button to customize the Style, Font,
etc., to your preference.
A preview icon is provided at the bottom of the
screen, use it to see the caption language.
■
Size:
Set the size the words will appear in.
■
Font:
Select a typeface for the words.
■
Text Color:
Choose a color for the text.
■
Text Opacity:
Specify the opacity for the text color.
■
Bg (Background)Color:
Select a background color.
■
Bg (Background)Opacity:
Select the opacity for
the background color.
■
Edge Type:
Select an edge type.
■
Edge Color:
Select a color for the edges.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
2
3
4
1
5
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
G
Language
ISM Method
Low Power
HDD Format
SimpLink
Timeshift Mode
Aspect Ratio
Caption/Text
Caption Option
Language
ISM Method
Low Power
HDD Format
SimpLink
Style Custom
Size A Sta ndard
Font Font 0
Text Color White
Text Opacity
Solid
Bg Color Black
Bg Opacity Solid
Edge Type None
Edge Color Black
TIME SETTING
119
CLOCK SETTING
The time is set automatically from a digital channel signal.
The digital channel signal includes information for the cur-
rent time provided by the broadcasting station.
Set the clock manually if the current time is set incorrectly
by the auto clock function.
Note: When you set up the TV Guide On Screen system,
Auto Clock menu is not available.
Press the
MENU
button and then use
D
or
E
button
to select the
TIME
menu.
Press the
G
button and then use
D
or
E
button to
select
Auto Clock
.
Press the
G
button and then use
D
or
E
button to
select
On
.
Press the
G
button and then use
D
or
E
button to
select your viewing area time zone :
U.S.A :
Eastern
,
Central
,
Mountain
,
Pacific
,
Alaska
or
Hawaii
.
Canada :
Eastern
,
Central
,
Mountain
,
Pacific
,
New F.land
or
Atlantic
.
Press the
G
button and then use
D
or
E
button to
select
Auto
,
Off
,
On
, depending on whether or not
your viewing area observes Daylight Saving time.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
2
3
4
5
6
1
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
Auto Clock
G
Manual Clock
Off Timer
On Timer
Sleep Timer
Auto Off
Auto Clock
Manual Clock
Off Timer
On Timer
Sleep Timer
Auto Off
Off
On
Time Zone Eastern
Auto
Daylight
Saving
TIME SETTING
Auto Clock Setup
TIME SETTING
120
TIME SETTING
Press the
MENU
button and then use
D
or
E
button
to select the
TIME
menu.
Press the
G
button and then use
D
or
E
button to
select
Manual Clock
.
Press the
G
button and then use
F
or
G
button to
select either the year, date, or time option. Once
selected, use the
D
or
E
button to set the year, date,
and time options.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
If the current time setting is wrong, reset the clock manually.
When you set up the TV Guide On Screen system, the Manual
Clock menu is not available.
2
3
4
1
Auto Clock
Manual Clock
G
Off Timer
On Timer
Sleep Timer
Auto Off
Auto Clock
Manual Clock
Off Timer
On Timer
Sleep Timer
Auto Off
Year - - - -
Date - - / - -
Time - - : - - - -
Manual Clock Setup
TIME SETTING
121
AUTO ON/OFF TIMER SETTING
The timer function operates only if the current time has been set.
The Off-Timer function overrides the On-Timer function if they are
both set to the same time.
The TV must be in standby mode for the On-Timer to work.
If you do not press any button within 2 hours after the TV turns on
with the On Timer function, the TV will automatically revert to
standby mode.
Press the
MENU
button and then use
D
or
E
button
to select the
TIME
menu.
Press the
G
button and then use
D
or
E
button to
select
Off Timer
or
On Timer
.
Press the
G
button and then use
D
or
E
button to
select
On
.
■
To cancel
On/Off timer
function, select
Off
.
Press the
G
button and then use
D
or
E
button to
set the hour.
Press the
G
button and then use
D
or
E
button to
set the minutes.
Only On timer
Press the
G
button and then use
D
or
E
button to
select the channel at turn-on.
Press the
G
button and then use
D
or
E
button to
set the sound level at turn-on.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
2
3
4
5
6
7
1
Auto Clock
Manual Clock
Off Timer
On Timer
G
Sleep Timer
Auto Off
Auto Clock
Manual Clock
Off Timer
On Timer
Sleep Timer
Auto Off
Off
On
Time 6 : 30 AM
Ch. TV 2-0
Vol 17
TIME SETTING
122
TIME SETTING
SLEEP TIMER SETTING
Press the
TIMER
button repeatedly to select the number of minutes. First
the
Off
option appears on the screen, followed by the following sleep timer
options : 10, 20, 30, 60, 90, 120, 180, and 240 minutes.
When the number of minutes you want is displayed on the screen, press the
ENTER
button. The timer begins to count down from the number of minutes
selected.
To check the remaining minutes before the TV turns off, press the
TIMER
button once.
To cancel the Sleep Timer, press the
TIMER
button repeatedly to select
Off
.
FLASHBK
APM
CC
The Sleep Timer turns the TV off at the preset time.
Note that this setting is cleared when the TV is turned off.
You can also set up the Sleep Timer in the TIME menu.
■
You can also set up the Sleep Timer in the TIME menu.
2
3
4
1
Auto Clock
Manual Clock
Off Timer
On Timer
Sleep Timer
G
Auto Off
Auto Clock
Manual Clock
Off Timer
On Timer
Sleep Timer
Auto Off
Off
10 min
20 min
30 min
60 min
90 min
120 min
180 min
240 min
TIME SETTING
123
AUTO SHUT-OFF SETTING
If set to on and there is no input signal, the TV turns off auto-
matically after 10 minutes.
Press the
MENU
button and then use
D
or
E
button
to select the
TIME
menu.
Press the
G
button and then use
D
or
E
button to
select
Auto Off
.
Press the
G
button and then use
D
or
E
button to
select
On
or
Off
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
MODE
LIVE TV
INPUT
DAY -
DAY +
S
IMPL
IN
K
2
3
4
1
Auto Clock
Manual Clock
Off Timer
On Timer
Sleep Timer
Auto Off
G
Auto Clock
Manual Clock
Off Timer
On Timer
Sleep Timer
Auto Off
Off
On
TV will be automatically turned
off, in case of No Signal for
10 minutes.
PARENTAL CONTROL / RATING
124
PARENTAL CONTROL / RATINGS
Parental Control can be used to block specific channels, ratings and other viewing sources.
The Parental Control Function (V-Chip) is used to block program viewing based on the ratings
sent by the broadcasting station. The default setting is to allow all programs to be viewed.
Viewing can be blocked by choosing the type of the program and the categories. It is also possi-
ble to block all program viewing for a time period. To use this function, the following must be
done :
1. Set ratings and categories to be blocked.
2. Specify a password
3. Enable the lock
V-Chip rating and categories
Rating guidelines are provided by broadcasting stations. Most television programs and television
movies can be blocked by TV Rating and/or Individual Categories. Movies that have been shown
at the theaters or direct-to-video movies use the Movie Rating System
(
MPAA
)
only.
Ratings for Television programs including made-for-TV movies :
■
TV-G
(
General audience
)
■
TV-PG
(
Parental guidance suggested
)
■
TV-14
(
Parents strongly cautioned
)
■
TV-MA
(
Mature audience only
)
■
TV-Y
(
All children
)
■
TV-Y7
(
Children 7 years older
)
SET PASSWORD & LOCK SYSTEM
Set up blocking schemes to block specific channels, ratings, and
external viewing sources.
A password is required to gain access to this menu.
Press the
MENU
button and then use the
D
or
E
button to
select the
LOCK
menu. Then, press the
G
button.
■
Enter the password as requested.
■
The TV is set up with the initial
password “0-0-0-0”.
DAY -
DAY +
S
IMPL
IN
K
Enter Password
1
Setting up your Password
PARENTAL CONTROL / RATING
125
After inputting the password, use the
D
or
E
button
to choose
Set password
.
Press the
G
button and then choose any 4 digits for
your new password and enter the them on the
new
.
As soon as the 4 digits are entered, re-enter the same
4 digits on the
Confirm
.
Then your changed password has been memorized.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Change the password by inputting a new password twice.
2
3
1
Lock System
Set Password
G
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
New
Confirm
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
TV Rating-English
TV Rating-French
Downloadable Rating
Input Block
For USA For Canada
Set Password
PARENTAL CONTROL / RATING
126
PARENTAL CONTROL /RATINGS
Lock System
After inputting the password, use the
D
or
E
button
to choose
Lock System
.
Press the
G
button and then use the
D
or
E
to select
On
or
Off
.
■
When you select, the Lock System is enable.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Enables or disables the blocking scheme you set up previously.
DAY
DAY +
S
IMPL
IN
K
2
3
1
Lock System
G
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Off
On
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
TV Rating-English
TV Rating-French
Downloadable Rating
Input Block
For USA For Canada
PARENTAL CONTROL / RATING
127
CHANNEL BLOCKING
Blocks any channels that you do not want to watch or that
you do not want your children to watch.
After inputting the password, use the
D
or
E
button
to choose
Block Channel
.
Press the
G
button. You will now see a screen filled
with channel numbers and a preview picture.
Use
D E F G
button to select a channel and then
use the
ENTER
button to block or unblock it.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
2
3
4
1
Lock System
Set Password
Block Channel
G
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Selection (
G
or
) leads
you to the block channel
screen.
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
TV Rating-English
TV Rating-French
Downloadable Rating
Input Block
For USA For Canada
PARENTAL CONTROL / RATING
128
PARENTAL CONTROL /RATINGS
Movie Rating (MPAA) - for USA only
Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You
can set the ratings limit by blocking out all the movies with the ratings above a specified level. Keep in mind
that the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas.
After inputting the password, use the
D
or
E
button
to choose
Movie Rating
.
Press the
G
button and then use the
D
or
E
to
select
G
,
PG
,
PG-13
,
R
,
NC-17
or
X
.
■
G (General audiences)
■
PG (Parental guidance suggested)
■
PG-13 (Parents strongly cautioned)
■
R (Restricted)
■
NC-17 (No one 17 and under admitted)
■
X (Adult only)
■
Blocking Off (Permits all programs)
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
G
If you set PG-13 : G and PG movies will be available,
PG-13, R, NC-17 and X will be blocked.
2
3
1
Lock System
Set Password
Block Channel
Movie Rating
G
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Blocking off : permits
all programs
G
PG
PG-13
R
NC-17
X
Blocking Off
MOVIE & TV RATING
Downloadable Rating
After inputting the password, use the
D
or
E
button to
choose
Downloadable Rating
.
Press the
G
button and then use the
D
or
E
button
to select
Dim0
,
Dim1
,
Dim2
, or
Dim3
.
Press the
G
button and then use the
D
or
E
button
to select
D1L1
,
D1L2
, or
D1L3
.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
2
3
1
4
G
This function may become available in the future and
will be available only for digital channel signal.
G
This function operates only when TV has received
Region5 Rating data.
NOTE
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
G
Input Block
Downloadable Rating
1
2
Dim0
Dim1
Dim2
Dim3
G
Based on rating table, your TV's OSD
(
On
Screen Display
)
may differ slightly from what
is shown in this manual.
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
For USA
For Canada
Lock System
Set Password
Block Channel
TV Rating-English
TV Rating-French
Downloadable Rating
Input Block
PARENTAL CONTROL / RATING
129
After inputting the password, use the
D
or
E
button
to choose
TV Rating-Children
.
Press the
G
button and then use the
D
or
E
to select
Age
, or
Fantasy Violence
.
Press the
G
button and then use the
D
or
E
button
to select block options.
■
Age(applies to TV-Y, TV-Y7)
■
Fantasy Violence(applies to TV-Y7)
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
TV Rating Children - for USA only
Prevents children from watching certain children's TV programs, according
to the ratings limit set. The children rating does not apply to other TV pro-
grams. Unless you block certain TV programs intended for mature audiences
in the TV Rating - sub menu, your children can view those programs.
TV Rating General *for USA only
After inputting the password, use the
D
or
E
button
to choose
TV Rating-General
.
Press the
G
button and then use the
D
or
E
button
to select
Age
,
Dialogue
,
Language
,
Sex
or
Violence
.
Press the
G
button and then use the
D
or
E
button
to select block options.
■
Age(applies to TV-G,TV-PG,TV-14,TV-MA)
■
Dialogue-sexual dialogue(applies to TV-PG,TV-14)
■
Language-adult language(applies to TV-PG,TV-14,TV-MA)
■
Sex-sexual situations(applies to TV-PG,TV-14,TV-MA)
■
Violence(applies to TV-PG,TV-14,TV-MA)
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Based on the ratings, blocks certain TV programs that you
and your family do not want to view.
2
3
1
2
3
1
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
G
TV Rating-General
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
G
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Age
Fantasy Violence
Age
Dialogue
Language
Sex
Violence
PARENTAL CONTROL / RATING
130
PARENTAL CONTROL /RATINGS
TV Rating english - for CANADA only
After inputting the password, use the
D
or
E
button
to choose
TV Rating-English
.
Press the
G
button and then use the
D
or
E
button
to select
E
,
C
,
C8+
,
G
,
PG
,
14+
,
18+
, or
Blocking Off
.
■
E(Exempt)
■
C(Children)
■
C8+(Children eight years and older)
■
G(General programming, suitable for all audiences)
■
PG(Parental Guidance )
■
14+(Viewers 14 years and older)
■
18+(Adult programming)
■
Blocking Off(Permits all programs)
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Selecting canadian english language rating system.
After inputting the password, use the
D
or
E
button
to choose
TV Rating-French
.
Press the
G
button and then use the
D
or
E
button
to select
E
,
G
,
8 ans+
,
13 ans+
,
16 ans+
,
18 ans+
, or
Blocking Off
.
■
E(Exempt)
■
G(General)
■
8 ans+(General-Not convenient for little children)
■
13 ans+(Not convenient for children of 13 years and
younger)
■
16 ans+(Not convenient for children of 16 years and
younger)
■
18 ans+(This programs is only for adults)
■
Blocking Off(Permits all programs)
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
2
3
1
2
3
1
Lock System
Set Password
Block Channel
TV Rating-English
G
TV Rating-French
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
TV Rating-English
TV Rating-French
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
TV Rating-English
TV Rating-French
G
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
TV Rating-English
TV Rating-French
Downloadable Rating
Input Block
TV Rating french - for CANADA only
Selecting canadian french language rating system.
Blocking off : permits all
programs
E
C
C8+
G
PG
14+
18+
Blocking Off
Blocking off : permits
all programs
E
G
8 ans+
13 ans+
16 ans+
18 ans+
Blocking Off
PARENTAL CONTROL / RATING
131
EXTERNAL INPUT BLOCKING
Enables you to select a source to block from the external
source devices you have hooked up.
After inputting the password, use the
D
or
E
button
to choose
Input Block
.
Press the
G
button and then use the or to
select a source.
Press the
G
button and then use the
D
or
E
to
select
On
or
Off
on the each source.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
2
3
4
1
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
G
AV1 On
AV2 On
Component1 Off
Component2 On
RGB
Off
HDMI1/DVI On
HDMI2 Off
Lock System
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Lock System
Set Password
Block Channel
TV Rating-English
TV Rating-French
Downloadable Rating
Input Block
For USA For Canada
APPENDIX
132
APPENDIX
No picture & No sound
No or poor color
or poor picture
Poor reception on
some channels
Lines or streaks
in pictures
Horizontal/vertical bars
or picture shaking
Picture appears slowly
after switching on
■
Check whether the product is turned on.
■
Try another channel. The problem may be with the broadcast.
■
Is the power cord inserted into wall power outlet?
■
Check your antenna direction and/or location.
■
Test the wall power outlet, plug another product’s power cord into the outlet
where the product’s power cord was plugged in.
■
This is normal, the image is muted during the product startups process. Please
contact your service center, if the picture has not appeared after five minutes.
■
Adjust Color in menu option.
■
Keep a sufficient distance between the product and the VCR.
■
Try another channel. The problem may be with the broadcast.
■
Are the video cables installed properly?
■
Activate any function to restore the brightness of the picture.
■
Check for local interference such as an electrical appliance or power tool.
■
Station or cable product experiencing problems, tune to another station.
■
Station signal is weak, reorient antenna to receive weaker station.
■
Check for sources of possible interference.
■
Check antenna (Change the direction of the antenna).
TROUBLESHOOTING
The operation does not work normally.
The remote control
doesn’t work
Power is suddenly
turned off
■
Check to see if there is any object between the product and the remote control
causing obstruction. Ensure you are pointing the remote control directly at the TV.
■
Ensure that the batteries are installed with correct polarity (+ to +, - to -).
■
Ensure that the correct remote operating mode is set: TV, VCR etc.
■
Install new batteries.
■
Is the sleep timer set?
■
Check the power control settings. Power interrupted.
■
No broadcast on station tuned with Auto off activated.
The video function does not work.
APPENDIX
133
The audio function does not work.
There is a problem in PC mode. (Only PC mode applied)
■
Press the VOL or VOLUME button.
■
Sound muted? Press MUTE button.
■
Try another channel. The problem may be with the broadcast.
■
Are the audio cables installed properly?
■
Adjust Balance in menu option.
■
A change in ambient humidity or temperature may result in an unusual noise
when the product is turned on or off and does not indicate a fault with the
product.
Picture OK & No sound
Unusual sound from
inside
the product
No output from one
of the speakers
■
Adjust resolution, horizontal frequency, or vertical frequency.
■
Check the input source.
■
Work the Auto configure or adjust clock, phase, or H/V position. (Option)
■
Check the signal cable.
■
Reinstall the PC video card.
The signal is out of range
(Invalid format)
Screen color is unstable
or single color
Vertical bar or stripe on
background &
Horizontal Noise &
Incorrect position
APPENDIX
134
APPENDIX
■
You should begin to receive listings again within 24 hours.
■
You can correct them using Change Channel Display under the Setup menu.
■
Listings usually appear within 24 hours after a successful Setup.
■
It may take up to a week to fill the Listings grid with the full 8 days of listings.
■
If you see a Listings grid with the message "No Listings" displayed you should start to
receive updated program listings within 24 hours.
■
If the message "No data for this screen" is displayed:
- Check the connections between the TV, cable, antenna.
- Verify Setup information under Change System Settings.
- If this message is still displayed after multiple days, please contact the LG
®
Brand Customer
Support.
■
Check the Schedule menu and verify that the show is listed before recording begins.
■
Check the Schedule menu and verify that the show is listed as a Reminder.
■
Highlight the show under Listings and do the following:
- Press the Menu key on the remote.
- Use the down arrow to highlight Edit Reminder, and press
ENTER
.
- Verify the Auto-Tune option reads Yes.
■
The TV must be On at the scheduled time for Auto-Tune.
■
Check the Schedule menu and verify that the show is listed as a Reminder.
■
Highlight the show under Listings and do the following:
- Press the Menu key on the remote.
- Use the down arrow to highlight Edit Reminder, and press
ENTER
.
- Verify the Power On TV option reads Yes.
My Guide listings disap-
peared after a power failure
I have not received any
Guide listings.
I set a show to Auto-Tune
and it did not.
I set a show with the Power
On TV option and it did not
A show I set to Record did
not occur
Some channel numbers
in the Guide are incorrect.
There is a problem on the TV Guide On Screen
TM
function.
APPENDIX
135
MAINTENANCE
Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you can
enjoy your new TV.
Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning.
Cleaning the Screen
Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in a mixture of lukewarm
water and a little fabric softener or dish washing detergent. Wring the cloth until it’s almost dry, and then
use it to wipe the screen.
Make sure the excess water is off the screen, and then let it air-dry before you turn on your TV.
Cleaning the Cabinet
■
To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth.
■
Please be sure not to use a wet cloth.
Extended Absence
If you expect to leave your TV dormant for a long time (such as a vacation), it’s a good idea to unplug
the power cord to protect against possible damage from lightning or power surges.
CAUTION
2
1
APPENDIX
136
APPENDIX
PRODUCT SPECIFICATIONS
■
The specifications shown above may be changed without prior notice for quality improvement.
42PB4D
( 42PB4DT-UB)
Width x Height x Depth With Stand
(inches/mm)
Without Stand
Weight (pounds / kg) With Stand
Without Stand
Width x Height x Depth With Stand
(inches/mm)
Without Stand
Weight (pounds / kg) With Stand
Without Stand
Width x Height x Depth With Stand
(inches/mm)
Without Stand
Weight (pounds / kg) With Stand
Without Stand
50PB4D
( 50PB4DT-UB)
60PB4D
( 60PB4DT-UB)
Power requirement
Television System
Program Coverage
External Antenna Impedance
Operating Temperature Range
Operating Humidity Range
Storage Temperature Range
Storage Humidity Range
44.5x30.2x12.2 inches
1130.0x768.1x310.4 mm
44.5x28.1x3.3 inches
1130.0x715.0x85.0 mm
75.8 pounds / 34.4kg
68.0 pounds / 30.8kg
AC100-240V~ 50/60Hz
NTSC-M, ATSC, 64 & 256 QAM
VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
75 Ω
0 ~ 40°C
Less than 80%
-20 ~ 60°C
Less than 85%
60.9x41.8x17.6 inches
1548.0x1061.0x448.0 mm
60.9x38.9x3.9 inches
1548.0x988.0x98.5 mm
163.1 pounds / 74.0kg
135.6 pounds / 61.5kg
51.5x35.7x14.6 inches
1308.0x906.1x370.0 mm
51.5x33.3x3.5 inches
1308.0x845.0x89.5 mm
93.5 pounds / 42.4kg
83.1 pounds / 37.7kg
APPENDIX
137
PROGRAMMING THE REMOTE CONTROL
Programming a code into a remote mode
To find out whether your remote control can operate each device without programming, turn on the device
(such as a VCR) and press the corresponding mode button on the remote.
After that, press the
POWER
button. If the device is turned off and it responds properly the remote control
need not be programmed. If not, the remote should be programmed to operate the device. The program-
ming procedures are explained below.
Press the
MENU
and
MUTE
button continuously at the same time for two seconds; the currently selected
device button is illuminated.
If you don't press any button for 20 seconds, the light on the mode button will be turned off. In that case,
you have to repeat from step 2.
Enter the appropriate code from the code table on the following pages. When pressing the button, the light
blinks at a time. If the device turned off, the programming is successful.
Press the
MENU
button to store the code. After blinking twice, this code is stored.
Test the remote control functions to see if the device responds properly. If not, steps 2-5.
The provided universal remote control can be programmed to operate most remote-controllable devices.
Note that the remote may not control all models of other brands.
2
3
4
5
1
APPENDIX
138
APPENDIX
Remote control code
VCRs
Brand Codes Brand Codes Brand Codes
AIWA 034
AKAI 016 043 046 124
12 5 146
AMPRO 072
ANAM 031 033 103
AUDIO DYNAMICS
012 023 039 043
BROKSONIC 035 037 129
CANON 028 031 033
CAPEHART 108
CRAIG 003 040 135
CURTIS MATHES 031 033 041
DAEWOO 005 007 010 064
0 6 5 10 8 110 111
112 116 117 119
DAYTRON 108
DBX 012 023 039 043
DYNATECH 034 053
ELECTROHOME 059
EMERSON 006 017 025 027
029 031 034 035
036 037 046 101
129 13 1 138 153
FISHER 003 008 009 010
FUNAI 034
GE 031 033 063 072
10 7 10 9 14 4 14 7
GO VIDEO 132 136
HARMAN KARDON 012 045
HITACHI 004 018 026 034
043 063 137 150
INSTANTREPLAY 031 033
JCL 031 033
JCPENNY 012 013 015 033
040 066 101
JENSEN 043
JVC 012 031 033 043
048 050 055 060
130 15 0 152
KENWOOD 014 034 039 043
047 048
LG (GOLDSTAR) 001 012 013 020
101 10 6 114 123
LLOYD 034
LXI 003 009 013 014
017 034 101 106
MAGIN 040
MAGNAVOX 031 033 034 041
067 068
012 031 033 067
MARANTZ 069
MARTA 101
MATSUI 027 030
MEI 031 033
MEMOREX 003 010 014 031
033 034 053 072
101 102 13 4 139
MGA 045 046 059
MINOLTA 013 020
MITSUBISHI 013 020 045 046
049 051 059 061
151
MTC 034 040
MULTITECH 024 034
NEC 012 023 039 043
048
NORDMENDE 043
OPTONICA 053 054
PANASONIC 066 070 074 083
13 3 14 0 145
PENTAX 013 020 031 033
063
PHILCO 031 034 067
PHILIPS 031 033 034 054
067 071 101
PILOT 101
PIONEER 013 021 048
PORTLAND 108
PULSAR 072
QUARTZ 011 014
QUASAR 033 066 075 145
RCA 013 020 033 034
040 041 062 063
10 7 10 9 14 0 144
14 5 14 7
REALISTIC 003 008 010 014
031 033 034 040
053 054 101
RICO 058
RUNCO 148
SALORA 014
SAMSUNG 032 040 102 104
10 5 10 7 10 9 112
113 115 12 0 12 2
125
SANSUI 022 043 048 135
SANYO 003 007 010 014
10 2 134
SCOTT 017 037 112 129
131
SEARS 003 008 009 010
013 014 017 020
031 042 073 081
101
SHARP 031 054 149
SHINTOM 024
SONY 003 009 031 052
056 057 058 076
077 078 149
SOUNDESIGN 034
STS 013
SYLVANIA 031 033 034 059
067
SYMPHONIC 034
TANDY 010 034
TATUNG 039 043
TEAC 034 039 043
TECHNICS 031 033 070
TEKNIKA 019 031 033 034
101
THOMAS 034
TMK 006
TOSHIBA 008 013 042 047
059 082 112 131
TOTEVISION 040 101
UNITECH 040
VECTOR RESEARCH
012
VICTOR 048
VIDEO CONCEPTS
012 034 046
VIDEOSONIC 040
WARDS 003 013 017 024
031 033 034 040
053 054 131
YAMAHA 012 034 039 043
ZENITH 034 048 056
058 072 080 101
APPENDIX
139
Cable Box
Brand Codes Brand Codes Brand Codes
Brand Codes Brand Codes Brand Codes
HDSTB
ABC 003 004 039 042
046 052 053
AJIN 112
ANTRONIK 014
ARCHER 005 007 014 024
CABLE STAR 026
CENTURION 092
CENTURY 007
CITIZEN 007
COLOUR VOICE 065 090
COMBANO 080 081
COMTRONICS 019 030
DIAMOND 023
EAGLE 020 030 040
EASTERN 057 062 066
ELECTRICORD 032
GE 072
GEMINI 008 022 025 054
GI 052 074
GOLDEN CHANNEL
030
HAMLIN 049 050 055
HITACHI 052 055
HOSPITALITY 070 077
JERROLD 002 003 004 008
009 010 052 069
074
LG (GOLDSTAR) 001 106 101 005
M-NET 037
MACOM 033
MAGNAVOX 010 012 064 079
MEMOREX 100
MOVIE TIME 028 032
NSC 015 028 038 071
073
OAK 016 031 037 053
PANASONIC 044 047
PARAGON 100
PHILIPS 006 012 013 020
065 085 090
PIONEER 034 051 052 063
076
POST NEWS WEEK016
PRUCER 059
PTS 011 048 071 072
073 074
PULSAR 100
RCA 047
REGAL 049 050
REGENCY 057
REMBRANT 025
SAMSUNG 102 107 030 068
SCIENTIFIC ATLANTA
003 011 041 042
043 045 046
SHERITECH 022
SIGNAL 030
SIGNATURE 052
SL MARX 030
SPRUCER 047 078
STARCOM 002 004 008 009
STARGATE 008 030
TADIRAN 030
TAEKWANG 110
TAIHAN 105
TANDY 017
TEXSCAN 029
TOCOM 039 040 056
TOSHIBA 100
UNIKA 007 014 024
UNITED CABLE 004 053
UNIVERSAL 005 007 014 024
026 027 032 035
VIEWSTAR 012 015 018 086
087 088 089
ZENITH 100 114 060 093
ALPHASTAR DSR 123
AMPLICA 050
BIRDVIEW 051 126 129
CHANNEL MASTER
013 014 015 018
036 055
CHAPARRAL 008 009 012 077
CITOH 054
CURTIS MATHES 050 145
DRAKE 005 006 007 010
011 052 112 116
141
DX ANTENNA 024 046 056 076
ECHOSTAR 038 040 057 058
093 094 095 096
097 098 099 100
12 2
ELECTRO HOME 089
EUROPLUS 114
FUJITSU 017 021 022 027
13 3 134
GENERAL INSTRUMENT
003 004 016 029
031 059 101
HITACHI 139 140
HOUSTON TRACKER
033 037 039 051
057 104
HUGHES 068
JANIEL 060 147
JERROLD 061
KATHREIN 108
LEGEND 057
LG 001
LUTRON 132
LUXOR 062 144
MACOM 010 059 063 064
065
MEMOREX 057
NEXTWAVE 028 124 125
NORSAT 069 070
PACE SKY SATELLITE
14 3
PANASONIC 060 142
PANSAT 121
PERSONAL CABLE 117
PHILIPS 071
PICO 105
PRESIDENT 019 102
PRIMESTAR 030 110 111
PROSAT 072
RCA 066 106
REALISTIC 043 074
SAMSUNG 123
SATELLITE SERVICE CO
028 035 047 057
085
SCIENTIFIC ATLANTA
032 138
SONY 103
STARCAST 041
SUPER GUIDE 020 124 125
TEECOM 023 026 075 087
088 090 107 130
13 7
TOSHIBA 002 127
UNIDEN 016 025 042 043
044 045 048 049
078 079 080 086
101 135 136
VIEWSTAR 115
WINEGARD 128 146
ZENITH 081 082 083 084
091 120
APPENDIX
140
APPENDIX
Brand Codes Brand Codes Brand Codes
Brand Codes Brand Codes Brand Codes
DVD
Audio
AIWA 014 028 070 096
12 5 12 9 139 229
230
AKAI 163
ANAM 003 014 017 023
059 106 189 216
217 235 23 6
BURMECTER 252
CARVER 086
CLARION 199
DAEWOO 027 053 060 084
10 2 14 8 198 2 21
DENON 015 075 130 143
FANTASIA 071
FINEARTS 022
FISHER 089 099
LG(GOLDSTAR) 001 021 024 029
0 8 7 10 7 108 110
19 0 191 19 2 210
211 212 239
HAITAI 034 035 188 222
HARMAN/KARDON 068
JVC 004 013 141
K E C 18 5 186 187
KOHEL 030
NAD 045 046
KENWOOD 038 050 067 089
17 0 17 1 19 7 2 0 6
215 222
INKEL 037 058 062 069
078 079 095 121
12 2 14 9 15 0 15 1
15 2 153 15 4 15 5
15 7 158 159 16 0
18 9 2 07 2 22 224
225 226 227 243
247
LOTTE 014 016 036 098
10 0 17 2 173 174
17 5 176 177 17 8
179 18 0 18 1 183
201 202 208 213
214 219 223 232
238 240
LXI 103
MAGNAVOX 111
MARANTZ 002 018 020 025
034 041 081 090
097 112
MCINTOSH 049
MCS 104
MEMOREX 107
NAD 046
ONKYO 013 040 041 047
048 056 057 132
13 3 140
OPTIMUS 158
PANASONIC 007 033 064 113
14 2 22 0 2 41 2 51
PENNEY 104
PHILIPS 026 112 143
PIONEER 039 042 043 063
065 091 093 094
115 12 3 12 7 2 5 0
QUASAR 113
RCA 080
RCX 092
REALISTIC 103 106
SAMSUNG 124 145 146 182
19 3 19 4 19 5 2 0 3
204 244 245 246
SANSUI 011 135 138 144
SANYO 019 083 234
SCOTT 106 186
SHARP 031 032 051 052
072 082 117 119
156 184 199 200
206 209
SHERWOOD 005 006 158
SONY 044 045 109 114
118 12 6 24 8 2 4 9
TAEKWANG 012 020 073 074
076 077 105 161
16 2 163 16 4 16 5
166 167 16 8 16 9
205 231 233 242
TEAC 010 085 106 136
18 5 187 2 3 7
TECHNICS 101 113 128 134
14 7 218
TOSHIBA 137
THE 061
VICTOR 088 131
WARDS 089
YAMAHA 054 055 066 092
19 9
APEX DIGITAL 022
DENON 020 014
GE 005 006
HARMAN KARDON 027
JVC 012
LG 001 010 016 025
MAGNAVOX 013
MARANTZ 024
MITSUBISHI 002
NAD 023
ONKYO 008 017
PANASONIC 003 009
PHILIPS 013
PIONEER 004 026
PROCEED 021
PROSCAN 005 006
RCA 005 006
SAMSUNG 011 015
SONY 007
THOMPSON 005 006
TOSHIBA 019 008
YAMAHA 009 018
ZENITH 010 016 025
APPENDIX
141
IR CODES
■
Configuration of frame
1st frame
Repeat frame
■
Lead code
■
Repeat code
■
Bit description
■
Frame interval: Tf
The waveform is transmitted as long as a key is depressed.
C0
C1
C2
C3
C4
C5
C6
C
7
D
0
D
1
D
2
D
3
D
4
D
5
D
6
D
7
L
ead
code
L
o
w
custo
m
code
High custom cod
e
D
ata
code
D
ata
code
Re
p
eat cod
e
T
f
4.
5
m
s
9
ms
2.2
5
ms
9
ms
0
.
55
ms
0
.
56
m
s
1
.
12 m
s
0
.
56
m
s
2
.
24 m
s
Tf
Tf
Tf=1
08
ms @455KH
z
Bit ”0” Bit ”1”
1. How to Connect
■
Connect your wired remote control to the Remote Control port on the TV.
2. Remote Control IR Codes
■
Output waveform
Single pulse, modulated with 37.917KHz signal at 455KHz
T1
T
c
Carrier frequency
FCAR = 1/TC = fOSC/12
Duty ratio = T1/TC = 1/3
APPENDIX
142
APPENDIX
Code
Function Note
(Hexa)
Code
Function Note
(Hexa)
BF COMPONENT1 Discrete IR Code
(Component1 Input Selection)
D4 COMPONENT2 Discrete IR Code
(Component2 Input Selection)
D5 RGB-PC Discrete IR Code
(RGB-PC Input Selection)
D7 RGB-DTV Discrete IR Code
(RGB-DTV Input Selection)
C6 HDMI1/DVI Discrete IR Code
(HDMI1/DVI Input Selection)
CC HDMI2 Discrete IR Code
(HDMI2 Input Selection)
76 Ratio 4:3 Discrete IR Code
(Only 4:3 Mode)
77 Ratio 16:9 Discrete IR Code
(Only 16:9 Mode)
AF Ratio Zoom Discrete IR Code
(Only Zoom1 Mode)
70 POP Discrete IR Code
(Channel Search)
C4 POWER ON Discrete IR Code
(Only Power On)
C5 POWER OFF Discrete IR Code
(Only Power Off)
B0 PLAY R/C Button
BA PAUSE R/C Button
B1 STOP R/C Button
BD REC R/C Button
8F REW R/C Button
8E FF R/C Button
B2 GO TO PREV R/C Button
B3 GO TO NEXT R/C Button
A9 TV GUIDE R/C Button
92 APM R/C Button
7C X STUDIO R/C Button
7D MARK R/C Button
7E SIMPLINK R/C Button
9E LIVE TV R/C Button
0B INPUT R/C Button
08 POWER R/C Button (Power On/Off)
79 RATIO R/C Button
0E TIMER R/C Button
10-19 Number Key 0-9 R/C Button
4C - (Dash) R/C Button
1A FLASHBK R/C Button
09 MUTE R/C Button
02 VOL
D
R/C Button
03 VOL
E
R/C Button
00 CH
D
R/C Button
01 CH
E
R/C Button
1E FAV R/C Button
AA INFO R/C Button
39 CC R/C Button
40
D
R/C Button
41
E
R/C Button
07
F
R/C Button
06
G
R/C Button
44 ENTER R/C Button
43 MENU R/C Button
52 EZ SOUND R/C Button
4D EZ PIC R/C Button
5B EXIT R/C Button
60 PIP R/C Button
72 PIPCH - R/C Button
71 PIPCH + R/C Button
61 PIP INPUT R/C Button
63 SWAP R/C Button
0A SAP R/C Button
CB ADJUST R/C Button
D6 TV Discrete IR Code
(TV Input Selection)
5A AV1 Discrete IR Code
(AV1 Input Selection)
D0 AV2 Discrete IR Code
(AV2 Input Selection)
APPENDIX
143
EXTERNAL CONTROL THROUGH RS-232C
RS-232C Setup
Connect the RS-232C (serial port) input jack to an external control device (such as a comput-
er or an A/V control system) to control the product’s functions externally.
Connect the serial port of the control device to the RS-232C jack on the product back panel.
Note: RS-232C connection cables are not supplied with the product.
PC
Type of Connector; D-Sub 9-Pin Male
No. Pin Name
1 No connection
2 RXD
(
Receive data
)
3 TXD
(
Transmit data
)
4 DTR
(
DTE side ready
)
5 GND
6 DSR
(
DCE side ready
)
7 RTS
(
Ready to send
)
8 CTS
(
Clear to send
)
9 No Connection
APPENDIX
144
APPENDIX
Press the
MENU
button and then use
D
or
E
button
to select the
SETUP
menu.
Press the
G
button and then use
D
or
E
button to
select
SET ID
.
Press the
G
button and then use
D
or
E
button to
adjust
SET ID
to choose the desired TV ID number.
The adjustment range of SET ID is 1~99.
Press
EXIT
button to return to TV viewing or press
MENU
button to return to the previous menu.
Use this function to specify a TV ID number.
Refer to ‘Real Data Mapping 1’.
p.147
Set ID
DAY -
DAY +
S
IMPL
IN
K
Communication Parameters
■
Baud rate : 9600 bps
(
UART
)
■
Data length : 8 bits
■
Parity : None
■
Stop bit : 1 bit
■
Communication code : ASCII code
■
Use a crossed (reverse) cable.
RS-232C Configurations
7-Wire Configurations
(
Standard RS-232C cable
)
PC PDP
RXD 2 3 TXD
TXD 3 2 RXD
GND 5 5 GND
DTR 4 6 DSR
DSR 6 4 DTR
RTS 7 8 CTS
CTS 8 7 RTS
D-Sub 9 D-Sub 9
3-Wire Configurations
(
Not standard
)
PC PDP
RXD 2 3 TXD
TXD 3 2 RXD
GND 5 5 GND
DTR 4 6 DTR
DSR 6 4 DSR
RTS 7 7 RTS
CTS 8 8 CTS
D-Sub 9 D-Sub 9
2
3
4
1
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
G
EZ Scan
Manual Scan
Channel Edit
DTV Signal
Main Input
Sub Input
Input Label
Set ID
1
APPENDIX
145
Command Reference List
COMMAND1 COMMAND2
28. Channel Tuning
29. Channel Add/Del
30. Key
31. Input Select
32. PIP Input Select
DATA
(Hexadecimal)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
COMMAND1 COMMAND2
DATA0
(Hexadecimal)
DATA1
(Hexadecimal)
DATA2
(Hexadecimal)
DATA3
(Hexadecimal)
DATA4
(Hexadecimal)
DATA5
(Hexadecimal)
physical major major low minor high minor low attribute
program high program low
01. Power k a 0 ~ 1
02. Input Select k b 0 ~ 9
03. IInput Select
04. Aspect Ratio k c *
05. Screen Mute k d 0 ~ 1
06. Volume Mute k e 0 ~ 1
07. Volume Control k f 0 ~ 64
07. Contrast k g 0 ~ 64
08. Brightness k h 0 ~ 64
09. Color k i 0 ~ 64
10. Tint k j 0 ~ 64
11. Sharpness k k 0 ~ 64
12. OSD Select k l 0 ~ 1
13. Remote Control/
Key Lock
k m
m a
mb0 ~ 1
m c key code
xb*
xy*
0 ~ 1
15. PIP Position k q 0 ~ 3
16. Treble k r 0 ~ 64
17. Bass k s 0 ~ 64
18. Balance k t 0 ~ 64
19 .
Color Temperature
k u 0 ~ 3
20. Red adjustment k v 0 ~ C8
21. Green adjustment k w 0 ~ C8
22. Blue adjustment k $ 0 ~ C8
23. PIP Input Source k y 0 ~ 3
24. ISM Method j p *
25. Low Power j q 0 ~ 1
26. Orbiter Time
jr1
~
FE
Setting
27. Orbiter Pixel
js1
~
3
Setting
APPENDIX
146
APPENDIX
Transmission / Receiving Protocol
Transmission
[Command 1] : First command to control the set.
(j, k, m or x)
[Command 2] : Second command to control the set.
[Set ID] : You can adjust the set ID to choose desired TV ID
number in Setup menu. Adjustment range is 1
~ 99.
When selecting Set ID ‘0’, every connected the TV
is controlled. Set ID is indicated as decimal
(
1
~
99
)
on menu and as Hexa decimal
(
0x0~ 0x63
)
on
transmission/receiving protocol.
[DATA] : To transmit command data.
Transmit ‘FF’ data to read status of command.
[Cr] : Carriage Return
ASCII code ‘0x0D’
[ ] : ASCII code ‘space (0x20)’
*In this model, TV will not send the status during the standby
mode.
OK Acknowledgement
The TV transmits ACK (acknowledgement) based on this
format when receiving normal data. At this time, if the data
is data read mode, it indicates present status data. If the
data is data write mode, it returns the data of the PC com-
puter.
*in this model, TV will not send the status during the standby
mode.
*data format
[command 2] : use as command.
[Set ID] : use the small character, if set ID is 10, it will send
the ‘0’,’a’
[Data] : use the small character, if data is 0xab, it will send
the ‘a’, ‘b’
[OK] : use the large character
*in this model, TV will send the echo, CR, LF with ack mes-
sage.
When it send the power on ack message, it will be like below.
Ex) ka 01 01(CR)(LF)a 01 OK01x(CR)(LF)
[Command1][Command2][ ][Set ID][ ][Data][Cr]
[Command2][ ][Set ID][ ][OK][Data][x]
Error Acknowledgement
The TV transmits ACK (acknowledgement) based on this
format when receiving abnormal data from non-viable func-
tions or communication errors.
Data1: Illegal Code
Data2: Not supported function
Data3: Wait more time
*in this model, TV will not send the status during
the standby mode.
*data format
[command 2] : use as command.
[Set ID] : use the small character, if set ID is 10, it
will send the ‘0’,’a’
[Data] : use the small character, if data is 0xab, it
will send the ‘a’, ‘b’
[NG] : use the large character
*in this model, TV will send the echo, CR, LF with
ack message.
When it send the power on ack message, it will be
like below.
Ex) ka 01 01(CR)(LF)a 01 NG01x(CR)(LF)
[Command2][ ][Set ID][ ][NG][Data][x]
APPENDIX
147
01. Power (Command2:a)
To control Power On/Off of the TV.
Transmission [k][a][ ][Set ID][ ][Data][Cr]
Data 0 : Power Off Data 1 : Power On
Acknowledgement [a][ ][Set ID][ ][OK/NG][Data][x]
* In a like manner, if other functions transmit ‘FF’ data
based on this format, Acknowledgement data feedback
presents status about each function.
* Note: In this model, TV will send the Acknowledge
after power on processing completion.
There might be a time delay between command and
acknowledge.
02. Input Select (Command2:b) (Main Picture Input)
To select input source for the TV.
Transmission [k][b][ ][Set ID][ ][Data][Cr]
Data 0: DTV Data 1: Analog
Data 2: AV1 Data 3: AV2
Data 4: Component 1 Data 5: Component 2
Data 6: RGB-DTV Data 7: RGB-PC
Data 8: HDMI1/DVI Data 9: HDMI2
Acknowledgement [b][ ][Set ID][ ][OK/NG][Data][x]
03. Aspect Ratio (Command2:c) (Main picture format)
To adjust the screen format.
You can also adjust the screen format using the RATIO
button on remote control or in the Option menu.
Transmission [k][c][ ][Set ID][ ][Data][Cr]
Data 1: 4:3 5: Zoom 2
2: 16:9 6: Set by program
3: Horizon 10: Cinema Zoom (1)
4: Zoom 1
1F: Cinema Zoom (16)
Acknowledgement [c][ ][Set ID][ ][OK/NG][Data][x]
04. Screen Mute (Command2:d)
To select screen mute on/off.
Transmission [k][d][ ][Set ID][ ][Data][Cr]
Data 0 : Screen mute off (Picture on)
Data 1 : Screen mute on (Picture off)
Acknowledgement [d][ ][Set ID][ ][OK/NG][Data][x]
05. Volume Mute (Command2:e)
To control volume mute on/off.
You can also adjust mute using the MUTE button on
remote control.
Transmission [k][e][ ][Set ID][ ][Data][Cr]
Data 0 : Volume mute off (Volume on)
Data 1 : Volume mute on (Volume off)
Acknowledgement [e][ ][Set ID][ ][OK/NG][Data][x]
06. Volume Control (Command2:f)
To adjust volume.
You can also adjust volume with the volume buttons on
remote control.
Transmission [k][f][ ][Set ID][ ][Data][Cr]
Data Min : 0 ~ Max : 64
Refer to ‘Real data mapping 1’ as shown below.
Acknowledgement [f][ ][Set ID][ ][OK/NG][Data][x]
07. Contrast (Command2:g)
To adjust screen contrast.
You can also adjust contrast in the Video menu.
Transmission [k][g][ ][Set ID][ ][Data][Cr]
Data Min : 0 ~ Max : 64
*Refer to ‘Real data mapping 1’ as shown below.
Acknowledgement [g][ ][Set ID][ ][OK/NG][Data][x]
08. Brightness (Command2:h)
To adjust screen brightness.
You can also adjust brightness in the Video menu.
Transmission [k][h][ ][Set ID][ ][Data][Cr]
Data Min : 0 ~ Max : 64(*transmit by Hexadecimal code)
*Refer to ‘Real data mapping 1’ as shown below.
Acknowledgement [h][ ][Set ID][ ][OK/NG][Data][x]
*Real data mapping 1
0 : Step 0
A : Step 10 (SET ID 10)
F : Step 15 (SET ID 15)
10 : Step 16 (SET ID 16)
63 : Step 99 (SET ID 99)
64 : Step 100
09. Color (Command2:i)
To adjust the screen color.
You can also adjust color in the Video menu.
Transmission [k][i][ ][Set ID][ ][Data][Cr]
Data Min : 0 ~ Max : 64
*Refer to ‘Real data mapping 1’. See page 147.
Acknowledgement [i][ ][Set ID][ ][OK/NG][Data][x]
APPENDIX
148
APPENDIX
10. Tint (Command2:j)
To adjust the screen tint.
You can also adjust tint in the Video menu.
Transmission [k][j][ ][Set ID][ ][Data][Cr]
Data Red : 0 ~ Green : 64
*Refer to ‘Real data mapping 1’. See page 147.
Acknowledgement [ j ][ ][Set ID][ ][OK/NG][Data][x]
11. Sharpness (Command2:k)
To adjust the screen sharpness.
You can also adjust sharpness in the Video menu.
Transmission [k][k][ ][Set ID][ ][Data][Cr]
Data Min: 0 ~ Max: 64
*Refer to ‘Real data mapping 1’. See page 147.
Acknowledgement [k][ ][Set ID][ ][OK/NG][Data][x]
12. OSD Select (Command2:l)
To select OSD (On Screen Display) on/off.
Transmission [k][l][ ][Set ID][ ][Data][Cr]
Data 0: OSD off Data 1: OSD on
Acknowledgement [l][ ][Set ID][ ][OK/NG][Data][x]
13. Remote Control Lock Mode (Command2:m)
To lock the remote control and the front panel controls
on the set.
Transmission [k][m][ ][Set ID][ ][Data][Cr]
Data 0: Lock off Data 1: Lock on
Acknowledgement [m][ ][Set ID][ ][OK/NG][Data][x]
If you’re not using the remote control and front panel
controls on the TV, use this mode. When main power is
on/off, remote control lock is released.
14. PIP / POP / Twin Picture (Command2:n)
To control the PIP (Picture-in-Picture)/POP/Twin pic-
ture. You can also control the PIP/POP/Twin picture
using the PIP button on the remote control.
Transmission [k][n][ ][Set ID][ ][Data][Cr]
Data 0:Off 2: Twin Picture
1: PIP 5: POP4(POP Scan)
Acknowledgement [n][ ][Set ID][ ][OK/NG][Data][x]
15. PIP Position (Command2:q)
To select sub picture position for PIP.
Transmission [k][q][ ][Set ID][ ][Data][Cr]
Data 0: Right down on screen
Data 1: Left down on screen
Data 2: Left up on screen
Data 3: Right up on screen
Acknowledgement [q][ ][Set ID][ ][OK/NG][Data][x]
16. Treble (Command2:r)
To adjust treble.
You can also adjust treble in the Audio menu.
Transmission [k][r][ ][Set ID][ ][Data][Cr]
Data Min: 0 ~ Max: 64(*transmit by Hexadecimal code)
*Refer to ‘Real data mapping 1’. See page 147.
Acknowledgement [r][ ][Set ID][ ][OK/NG][Data][x]
17. Bass (Command2:s)
To adjust bass.
You can also adjust bass in the Audio menu.
Transmission [k][s][ ][Set ID][ ][Data][Cr]
Data Min: 0 ~ Max: 64(*transmit by Hexadecimal code)
*Refer to ‘Real data mapping 1’. See page 147.
Acknowledgement [s][ ][Set ID][ ][OK/NG][Data][x]
18. Balance (Command2:t)
To adjust balance.
You can also adjust balance in the Audio menu.
Transmission [k][t][ ][Set ID][ ][Data][Cr]
Data Min: 0 ~ Max: 64(*transmit by Hexadecimal code)
*Refer to ‘Real data mapping 1’. See page 147.
Acknowledgement [t][ ][Set ID][ ][OK/NG][Data][x]
19. Color Temperature (Command2:u)
To adjust color temperature.
You can also adjust color temperature in the Video
menu.
Transmission [k][u][ ][Set ID][ ][Data][Cr]
Data 0: Medium 1: Cool 2: Warm 3: User
Acknowledgement [u][ ][Set ID][ ][OK/NG][Data][x]
20. Red adjustment(Command:v)
To adjust red in color temperature
Transmission [k][v][ ][Set ID][][Data][Cr]
Data Min:0 ~ Max:C8
*Refer to "Real data mapping 2". See page 149.
Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x]
APPENDIX
149
21. Green adjustment(Command:w)
To adjust green in color temperature.
Transmission [k][w][ ][Set ID][][Data][Cr]
Max:C8
*Refer to "Real data mapping 2". See page 149.
Acknowledgement [w][ ][Set ID][ ][OK/NG][Data][x]
22. Blue adjustment(Command:$)
To adjust blue in color temperature.
Transmission [k][$][ ][Set ID][][Data][Cr]
Data Min:0 ~ Max:C8
*Refer to "Real data mapping 2". See page 149.
Acknowledgement [$][ ][Set ID][][OK/NG][Data][x]]
*Real data mapping 2
0 : -20
5 : -19
A : -18
5F: -1
64: 0
69: +1
C3 : +19
C8 : +20
23. PIP Input Select (Command2:y)
To select input source for sub picture in PIP/Twin
picture mode.
Transmission [k][y][ ][Set ID][ ][Data][Cr]
Data 0: DTV 1: Analog
2: AV1 3: AV2
Acknowledgement [y][ ][Set ID][ ][OK/NG][Data][x]
24. ISM Method/Orbiter (Command2:p)
To avoid having a fixed image remain on screen.
Transmission [ j ][p][ ][Set ID][ ][Data][Cr]
Data 1: Inversion 2: Orbiter
4: White Wash 8: Normal
Acknowledgement [p][ ][Set ID][ ][OK/NG][Data][x]
25. Low Power (Command2:q)
To control the low power function on/off.
Transmission [ j ][q][ ][Set ID][ ][Data][Cr]
Data 0: low power off
1: low power on
Acknowledgement [q][ ][Set ID][ ][OK/NG][Data][x]
26. Orbiter Time Setting (Command2:r)
To adjust orbiter operation time term.
Transmission [ j ][r][ ][Set ID][ ][Data][Cr]
Data Min: 1~ Max: FE(*transmit by Hexadecimal code)
Unit: Second
Acknowledgement [r][ ][Set ID][ ][OK/NG][Data][x]
27. Orbiter Pixel Setting (Command2:s)
To adjust pixel number in orbiter function.
Transmission [ j ][s][ ][Set ID][ ][Data][Cr]
Data Min: 1~ Max: 3
Acknowledgement [s][ ][Set ID][ ][OK/NG][Data][x]
28. Tune Command (Command: m a)
To tune channel to following physical/major/minor num
ber.
Transmission [m][a][ ][Set ID][ ][Data0][ ][Data1]
[ ][Data2][ ][Data3][ ][Data4][ ][Data5][Cr]
Data 0: Physical Channel Number(Transmit by
Hexadecimal code)
NTSC air:02~45
NTSC cable: 01, 0E~7D
ATSC air:01~45
ATSC cable:01~87
Data1,Data2: Major Channel Number (two part) /
Channel Number (One part)
Data1: High byte
Data2: Low byte
Two part channel number:
Major number-Minor number
One part channel number:
If the channel band is ATSC digital cable, it can
be used. In case of using one part channel num-
ber, minor channel does not need.
Data3, Data 4: Minor Channel Number
Data3: High byte , Data4: Low byte
APPENDIX
150
APPENDIX
Data5:
All data are transmitted by Hexadecimal code
* Two/One part Channel: 6th bit
This bit is used in a cable-ready system.
* Using physical channel: 5th bit
If the channel band is NTSC air or NTSC cable, channel
tuning can be done by only physical channel. In this
case, using physical channel bit must be low(0).
But if the channel band is ATSC air or ATSC cable, there
are two cases that physical channel enable or disable.
If the physical channel sending is meaningful, you should
set this bit low(0). If the physical channel sending is
meaningless, you should set this bit high(1).
Example)
1. Analog channel: NTSC cable, channel number(35),
main picture Command: ma 00 23 xx xx xx xx 01
attribute(0x01): main picture, two part(it’s not
mandatory), using physical channel, NTSC cable ‘xx’
data: don’t care major and minor channel number in
case analog channel tuning.
2. Digital channel: ATSC air, channel number(don’t know
physical channel, major(30), minor(3)), sub picture
Command: ma 00 xx 00 1E 00 03 A2
attribute(0xA2): sub picture, two part, not using
physical channel, ATSC air ‘xx’ data: don’t care analog
channel number in case digital channel tuning.
3. Digital channel: ATSC air, channel number(physi-
cal(20),major(20), minor(3)), sub picture Command:
ma 00 14 00 14 00 03 82
attribute(0x82): sub picture, two part, using physical
channel, ATSC air.
Acknowledgement[a][ ][Set ID][ ][OK][Data0][Data1]
[Data2][Data3][Data4][x][a][ ][Set ID]
[ ][NG][Data0][x]
29. Channel Add/Del (Command: m b)
To add and delete the channels
Transmission [m][b][ ][Set ID][ ][Data][Cr]
Data 0: Channel Delete Data 1: Channel Add
Acknowledgement [b][ ][Set ID][ ][OK/NG][Data][x]
30. Key (Command: m c)
To send IR remote key code.
Transmission [m][c][ ][Set ID][ ][Data][Cr]s
Data Key code: Refer to page 142.
Acknowledgement [c][ ][Set ID][ ][OK/NG][Data][x]
31. Input select(Command: x b) (Main Picture Input)
To select input source for TV.
Transmission [x][b][][Set ID][][Data][Cr]
Data 00 : DTV (Antenna) Data 01 : DTV (Cable)
Data 10 : Analog (Antenna) Data 11 : Analog (Cable)
Data 20 : AV1 Data 21 : AV2
Data 40 : Component 1 Data 41 : Component 2
Data 50 : RGB DTV Data 60 : RGB PC
Data 90 : HDMI1/DVI Data 91 : HDMI2
Acknowledgement [b][ ][Set ID][ ][OK/NG][Data][x]
32. PIP Input Select(Command: x y)
To adjust input source for sub picture in PIP mode.
Transmission [x][y][][Set ID][][Data][Cr]
Data 00 : DTV (Antenna)
Data 01 : DTV (Cable)
Data 10 : Analog (Antenna)
Data 11 : Analog (Cable)
Data 20 : AV1
Data 21 : AV2
Acknowledgement [y][][Set ID][][OK/NG][Data][x]
Step
NTSC Air
NTSC Cable
ATSC Air
ATSC Cable_std
ATSC Cable_hrc
ATSC Cable_irc
ATSC cable_auto
Reserved
...
Reserved
1
0
0
1
1
0
0
1
1
x
1
2
0
0
0
0
1
1
1
1
x
1
3
0
0
0
0
0
0
0
0
x
1
4
x
x
x
x
x
x
x
x
x
x
Reserved
5
0
1
Use
No Use
Using Physical
Channel
6
0
1
Two
One
Two/One
Part Channel
7
0
1
Main
Sub
Main/Sub
0
0
1
0
1
0
1
0
1
x
1
