5-Shelf Shelving Unit - Chrome
Unité De Rayonnage à 5 Étagères - Chromée
Regal mit 5 Regalböden - Verchromt
Scaffale a 5 Ripiani - Cromato
Módulo De 5 Estantes - Cromo
5段 シェルフユニット、
クローム
5层置物架 - 铬合金
B01M0A4B9M
English Français Deutsch Italiano Español
日本語 中文
English ........................................... 3
Français ....................................... 15
Deutsch ........................................ 27
Italiano ......................................... 39
Español ........................................ 51
日本語 ........................................... 63
中文 .............................................. 75
3
English Français Deutsch Italiano Español
日本語 中文
5-Shelf Shelving Unit - Chrome
Contents:
Make sure that the package contains the following parts:
Part
Qty.
A
5
B
4
C
4
D
4
E
T
OP
20
F
16
G
1
Note: Discard the protective covers
F
. These are used to separate the shelves for
shipping purposes.
Welcome Guide
•
English
G1-1pc
G2-1pc
G3-2pcs
G4-2pcs
G5-1pc
FURNITURE TIPPING RESTRAINT
4
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 1:
Setting Up the Product
TOP
T
O
P
T
OP
TOP
TOP
A F F
C
E
D
E
• Remove the protective covers
F
from the shelves
A
and dispose of them.
•
Screw one foot
D
onto the bottom of each lower pole
C
in a counter-clockwise direction.
• Attach one half of the plastic sleeve
E
to each lower pole. Then attach the other
half of the plastic sleeve to each lower pole, so both halves are connected with
each other. The arrow above the TOP marks on the plastic sleeves should point
upwards. Four plastic sleeves are necessary to support one shelf.
5
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 2:
Setting Up the Product
E
E
A
C
• Put the first shelf
A
onto the poles
C
and lower it down until it rests on the
plastic sleeves
E
.
• Attach another set of plastic sleeves to each lower pole for the second shelf
from the bottom.
6
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 3:
Setting Up the Product
C
E
A
• Put the next shelf
A
onto the poles
C
and lower it down until it rests on the
plastic sleeves
E
.
7
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 4:
Setting Up the Product
B
B
C
C
• Screw the upper poles
B
onto the lower poles
C
in a clockwise direction.
8
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 5:
Setting Up the Product
B
E
• Attach one set of plastic sleeves
E
to the upper poles
B
.
9
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 6:
Setting Up the Product
E
E
B
A
• Put the next shelf
A
onto the poles
B
and lower it down until it rests on the
plastic sleeves
E
.
• Attach another set of plastic sleeves to the upper poles.
10
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 7:
Setting Up the Product
E
E
B
A
• Put the next shelf
A
onto the poles
B
and lower it down until it rests on the
plastic sleeves
E
.
• Attach the last set of plastic sleeves near the top of the upper poles.
11
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 8:
Setting Up the Product
A
E
B
G
• Put the last shelf
A
onto the poles
B
and lower it down until it rests on the
plastic sleeves
E
. Place cardboard over the corners of each shelf and gently tap
down with a rubber mallet (or similar tool) until the shelf is level.
• To improve stability (if needed), drill two tiny holes (Ø 4 mm) into the wall and
insert the dowels
G
. Secure the shelf to the wall by installing the Furniture Tipping
Please read the instructions and install the tipping restraint. The shelf is now
sec
Restraint hardware. The full instructions are inside the hardware bags.
Wall
12
English Français Deutsch Italiano Español
日本語 中文
Cleaning and Maintenance
• Wipe with a dry cloth as needed to remove dust and dirt.
• Avoid contact with corrosive substances like acids, alkaline or similar
substances.
Safety and Compliance
• Warning: Do not let children climb on or play with the unit.
• Handle with care.
• For ease and efficiency, the product should be assembled by two adults.
• Regularly check if all screw connections are tight and if all shelves are attached
in a stable way.
• To avoid scratching the floor, assemble the shelving unit on a soft surface such
as a carpet.
• Warning: Make sure not to drill into water or electricity lines when securing the
shelving unit on the wall.
Use a wire tracer and/or a water pipe finder if necessary.
• Load the unit evenly and place the heaviest items on the lower shelves.
Maximum Load US Standard Metric
Shelving unit 1750 lbs 795 kg
One single shelf 350 lbs 159 kg
13
English Français Deutsch Italiano Español
日本語 中文
Warranty Information
To obtain a copy of the warranty for this product:
Visit amazon.com/AmazonBasics/Warranty
— or —
Contact Customer Service at 1-866-216-1072
14
English Français Deutsch Italiano Español
日本語 中文
Feedback
Love it? Hate it?
Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products that live up to
your high standards. We encourage you to write a review sharing your experiences
with the product.
Please visit: amazon.com/review/review-your-purchases#
For further services:
Visit amazon.com/gp/help/customer/contact-us
— or —
Contact Customer Service at 1-866-216-1072
