KOFDP40X
EN Oven User Manual
CONTENTS
1. SAFETY INFORMATION....................................................................................2
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 7
4. CONTROL PANEL............................................................................................. 8
5. BEFORE FIRST USE......................................................................................... 9
6. DAILY USE......................................................................................................... 9
7. CLOCK FUNCTIONS....................................................................................... 11
8. USING THE ACCESSORIES........................................................................... 13
9. ADDITIONAL FUNCTIONS.............................................................................. 15
10. HINTS AND TIPS........................................................................................... 16
11. CARE AND CLEANING..................................................................................30
12. TROUBLESHOOTING....................................................................................33
13. ENERGY EFFICIENCY.................................................................................. 35
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.electrolux.com/support
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
www.electrolux.com2
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
Children of less than 8 years of age and persons with
very extensive and complex disabilities shall be kept
away from the appliance unless continuously
supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• WARNING: Keep children and pets away from the
appliance when it operates or when it cools down.
Accessible parts become hot during use.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
• Only a qualified person must install this appliance and
replace the cable.
• Do not use the appliance before installing it in the
built-in structure.
• Disconnect the appliance from the power supply
before carrying out any maintenance.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
ENGLISH 3
• The means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
• WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
• Always use oven gloves to remove or put in
accessories or ovenware.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can
scratch the surface, which may result in shattering of
the glass.
• Excessive spillage must be removed before the
pyrolytic cleaning. Remove all parts from the oven.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• Keep the minimum distance from
other appliances and units.
• Before mounting the appliance, check
if the oven door opens without
restraint.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
• The built-in unit must meet the
stability requirements of DIN 68930.
Cabinet minimum
height (Cabinet un‐
der the worktop
minimum height)
578 (600) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of
the appliance
594 mm
www.electrolux.com4
Height of the back
of the appliance
576 mm
Width of the front of
the appliance
595 mm
Width of the back of
the appliance
559 mm
Depth of the appli‐
ance
567 mm
Built in depth of the
appliance
546 mm
Depth with open
door
1027 mm
Ventilation opening
minimum size.
Opening placed on
the bottom rear side
560 x 20 mm
Mounting screws 4 x 25 mm
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door or the
niche below the appliance, especially
when it operates or the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• Fully close the appliance door before
you connect the mains plug to the
mains socket.
• This appliance is supplied without a
main plug and a main cable.
2.3 Use
WARNING!
Risk of injury, burns and
electric shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and
air.
ENGLISH 5
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make
sure the door is never closed when
the appliance operates. Heat and
moisture can build up behind a closed
furniture panel and cause subsequent
damage to the appliance, the housing
unit or the floor. Do not close the
furniture panel until the appliance has
cooled down completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
• If you use an oven spray, follow the
safety instructions on its packaging.
2.5 Pyrolytic cleaning
WARNING!
Risk of Injury / Fires /
Chemical Emissions
(Fumes) in Pyrolytic Mode.
• Before carrying out a Pyrolitic self-
cleaning function or the First Use
please remove from the oven cavity:
– any excess food residues, oil or
grease spills / deposits.
– any removable objects (including
shelves, side rails etc., provided
with the product) particularly any
non-stick pots, pans, trays,
utensils etc.
• Read carefully all the instructions for
Pyrolytic cleaning.
• Keep children away from the
appliance while the Pyrolytic cleaning
operates.
The appliance becomes very hot and
hot air is released from the front
cooling vents.
• Pyrolytic cleaning is a high
temperature operation that can
release fumes from cooking residues
and construction materials, as such
consumers are strongly advised to:
– provide good ventilation during
and after each Pyrolytic cleaning.
www.electrolux.com6
– provide good ventilation during
and after the first use at maximum
temperature operation.
• Unlike all humans, some birds and
reptiles can be extremely sensitive to
potential fumes emitted during the
cleaning process of all Pyrolytic
Ovens.
– Remove any pets (especially
birds) from the vicinity of the
appliance location during and
after the Pyrolytic cleaning and
first use maximum temperature
operation to a well ventilated
area.
• Small pets can also be highly
sensitive to the localized temperature
changes in the vicinity of all Pyrolytic
Ovens when the Pyrolytic self
cleaning program is in operation.
• Non-stick surfaces on pots, pans,
trays, utensils etc., can be damaged
by the high temperature Pyrolytic
cleaning operation of all Pyrolytic
Ovens and can be also a source for
low level harmful fumes.
• Fumes released from all Pyrolytic
Ovens / Cooking Residues as
described are not harmful to humans,
including children, or persons with
medical conditions.
2.6 Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
• Use only lamps with the same
specifications.
2.7 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.8 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
3. PRODUCT DESCRIPTION
3.1 General overview
7
9
8
41 2 3 5 6
1
2
3
4
5
11
10
1
Control panel
2
Knob for the heating functions
3
Power lamp / symbol
4
Display
5
Control knob (for the temperature)
6
Temperature indicator / symbol
7
Heating element
8
Lamp
9
Fan
10
Shelf support, removable
ENGLISH 7
11
Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Trivet
For roasting and grilling.
Use the trivet only with the
Grill- / Roasting pan.
4. CONTROL PANEL
4.1 Retractable knobs
To use the appliance press the knob.
The knob comes out.
4.2 Sensor fields / Buttons
To set the MINUTE MINDER. Hold it for more than 3
seconds to turn on or turn off the oven lamp.
To set a clock function.
To check the oven temperature or the temperature of
the core temperature sensor (if applicable). Use only
while a heating function operates.
4.3 Display
A B
DG EF C
A. Timer / Temperature
B. Heat-up and residual heat indicator
C. Food Sensor (selected models only)
D. Door lock (selected models only)
E. Hours / minutes
F. Demo Mode
G. Clock functions
www.electrolux.com8
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
Set the time before you use the oven.
5.1 Initial Cleaning
Step 1 Step 2 Step 3
Remove all accessories
and removable shelf sup‐
ports from the oven.
Clean the oven and the ac‐
cessories with a soft cloth,
warm water and a mild de‐
tergent.
Place the accessories and
the removable shelf sup‐
ports in the oven.
5.2 Initial preheating
Preheat the empty oven before the first use.
Step 1 Remove all accessories and removable shelf supports from the oven.
Step 2
Set the maximum temperature for the function: .
Let the oven operate for 1 h.
Step 3
Set the maximum temperature for the function: .
Let the oven operate for 15 min.
The oven can emit an odour and smoke during preheating. Make sure that the
room is ventilated.
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 How to set: Heating
function
Step 1 Turn the knob for the heat‐
ing functions to select a
heating function.
Step 2 Turn the control knob to se‐
lect the temperature.
Step 3 When the cooking ends,
turn the knobs to the off po‐
sition to turn off the oven.
6.2 Fast Heat Up
The fast heat up decreases the heat up
time.
Do not put food in the oven
when the Fast heat up
operates.
1. Turn the knob for the oven functions
to set the fast heat up.
ENGLISH 9
2. Turn the knob for the temperature to
set the temperature.
The signal sounds when the oven is at
the set temperature.
3. Set an oven function.
6.3 Heat-up indicator
When the oven function operates, the
bars in the display appear one by one
when the temperature in the oven
increases, and disappear when it
decreases.
6.4 Heating functions
Heating
function
Application
Off position
The oven is off.
Fast Heat Up
To decrease the heat-
up time.
True Fan
Cooking
To bake on up to three
shelf positions at the
same time and to dry
food.
Set the temperature 20
- 40 °C lower than for
Conventional Cooking.
Pizza Func‐
tion
To bake pizza. To make
intensive browning and
a crispy bottom.
Conventional
Cooking
To bake and roast food
on one shelf position.
Bottom Heat
To bake cakes with
crispy bottom and to
preserve food.
Defrost
To defrost food (vegeta‐
bles and fruit). The de‐
frosting time depends
on the amount and size
of the frozen food.
Heating
function
Application
Moist Baking
This function is de‐
signed to save energy
during cooking. When
you use this function,
the temperature in the
cavity may differ from
the set temperature.
The residual heat is
used. The heating pow‐
er may be reduced. For
more information refer
to "Daily Use" chapter,
Notes on: Moist Baking.
Grill
To grill thin pieces of
food and to toast bread.
Turbo Grilling
To roast large meat
joints or poultry with
bones on one shelf po‐
sition. To make gratins
and to brown.
Pyrolysis
To turn on the pyrolytic
cleaning of the oven.
The lamp may turn off
automatically at a
temperature below 60 °C
during some oven functions.
6.5 Notes on: Moist Baking
This function was used to comply with
the energy efficiency class and
ecodesign requirements according to EU
65/2014 and EU 66/2014. Tests
according to EN 60350-1.
The oven door should be closed during
cooking so that the function is not
interrupted and the oven operates with
the highest energy efficiency possible.
When you use this function the lamp
automatically turns off after 30 sec.
For the cooking instructions refer to
"Hints and tips" chapter, Moist Baking.
For general energy saving
recommendations refer to "Energy
Efficiency" chapter, Energy Saving.
www.electrolux.com10
7. CLOCK FUNCTIONS
7.1 Clock functions table
Clock function Application
Time of Day
To show or change the time of day. You can change
the time of day only when the oven is off.
Duration
To set the length of cooking. Use only when a heat‐
ing function is set.
End Time
To set the oven turn-off time. Use only when a heat‐
ing function is set.
Time Delay
Combination of functions: Duration, End Time.
Minute Minder
To set a countdown time. This function has no effect
on the operation of the oven.
Minute Minder - can be set at any time, also if the
oven is off.
7.2 How to set: Time of day
After the first connection to the mains,
wait until the display shows: hr, 12:00.
12 - flashes.
Step 1 Turn the knob for the temperature to set the hour.
Step 2
- press to confirm.
The display shows the set hour and: min. 00 - flashes.
Step 3 Turn the knob for the temperature to set the minutes.
Step 4
- press to confirm.
The display shows the set time.
- press repeatedly to change the time of day. - flashes in the display.
7.3 How to set function:
Duration
Step 1 Set a heating function.
Step 2
- press repeatedly. - starts to flash.
Step 3
Turn the control knob to set the minutes. - press to confirm.
ENGLISH 11
Step 4
Turn the knob for the temperature to set the hour. - press to confirm.
When the set time ends the signal sounds for 2 min. Time setting flashes
in the display. The oven turns off automatically.
Step 5 Press any button to stop the signal.
Step 6 Turn the knobs to the off position.
7.4 How to set function: End
Time
Step 1 Set a heating function.
Step 2
- press repeatedly. - starts to flash.
Step 3
Turn the knob for the temperature to set the hour. - press to confirm.
Step 4
Turn the knob for the temperature to set the minutes. - press to con‐
firm.
At the set end time the signal sounds for 2 min. The time setting flashes
in the display. The oven turns off automatically.
Step 5 Press any button to stop the signal.
Step 6 Turn the knobs to the off position.
7.5 How to set function: Time
Delay
Step 1 Set a heating function.
Step 2
- press repeatedly. - starts to flash.
Step 3 Turn the knob for the temperature to set the minutes for the function: Du‐
ration.
Press: .
Step 4 Turn the knob for the temperature to set the hour for the function: Dura‐
tion.
Press: .
The display shows: .
Step 5 Turn the knob for the temperature to set the hour for the function: End
Time.
Press: .
Step 6 Turn the knob for the temperature to set the minutes for the function: End
Time.
Press: .
www.electrolux.com12
The display shows: the set temperature, , .
Oven turns on automatically later on, works for the set Duration time and stops at the
set End Time.
At the set End Time the signal sounds for 2 min. The time setting flashes in the dis‐
play. The oven turns off.
Step 7 Press any button to stop the signal.
Step 8 Turn the knobs to the off position.
7.6 How to set function: Minute
Minder
Minute minder can be both set when the
oven is turned on and off.
Step 1
- press repeatedly. , 00 - flash.
Step 2 Turn the knob for the temperature to set the seconds and then the mi‐
nutes.
When the time you set is longer than 60 min, hr flashes.
Step 3 Set the hours.
Minute Minder - starts automatically after 5 sec.
After 90% of the set time the signal sounds.
Step 4
When the set time ends the signal sounds for 2 min. 00:00, - flash.
Press any button to stop the signal.
8. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
8.1 Inserting accessories
A small indentation at the top increases
safety. The indentations are also anti-tip
devices. The high rim around the shelf
prevents cookware from slipping of the
shelf.
ENGLISH 13
Wire shelf:
Push the shelf between the guide
bars of the shelf support.
Deep pan:
Push the tray between the guide bars
of the shelf support.
Wire shelf, Deep pan:
Push the tray between the guide bars
of the shelf support and the wire shelf
on the guide bars above.
8.2 Trivet and Grill- / Roasting pan
Step 1 Put the trivet into a deep pan.
Step 2 Put the deep pan on the recommended shelf position.
Roasting larger pieces of meat or
poultry on one shelf position.
Grilling and toasting thin pieces of
food in large quantities.
www.electrolux.com14
Make sure the supports of the wire shelf
point up.
Make sure the supports of the wire shelf
point down.
9. ADDITIONAL FUNCTIONS
9.1 How to use: Child lock
When the function is on the oven cannot
be turned on accidentally.
Step 1 Ensure the knob for the
heating functions is in the
off position.
Step 2
, - press and hold at
the same time for 2 sec.
The signal sounds. SAFE , - appear
on the display. The door is locked.
To turn off the Child Lock, repeat the
step 2.
9.2 How to use: function lock
You can turn on the function only when
the oven works. When the function is on
the temperature and time settings cannot
be changed accidentally.
Step 1 Set an oven function.
Step 2
, - press and hold at
the same time for 2 sec.
The signal sounds. Loc ap‐
pears on the display for 5
sec.
To turn off the Function Lock, repeat
step 2.
Loc appears on the display when you
turn the control knob or press any button
when the Function lock is on. When you
turn the knob for the oven functions, the
oven stops.
When you turn off the oven while the
Function Lock is on, the Function Lock
switches automatically to the Child Lock.
Refer to "Additional functions" chapter,
Using the Child Lock.
9.3 Residual heat indicator
When you turn off the oven, the display
shows the residual heat indicator if
the temperature in the oven is more than
40 °C.Turn the knob for the temperature
left or right to check the oven
temperature.
9.4 Automatic switch-off
For safety reasons the oven turns off
after some time, if a heating function
works and you do not change any
settings.
(°C) (h)
30 - 115 12.5
120 - 195 8.5
200 - 245 5.5
250 - maximum 3
After an automatic switch-off, turn the
knobs to the off position.
ENGLISH 15
The Automatic switch-off does not work
with the functions: Light, Duration, End
Time.
9.5 Cooling fan
When the oven operates, the cooling fan
turns on automatically to keep the
surfaces of the oven cool. If you turn off
the oven, the cooling fan can continue to
operate until the oven cools down.
10. HINTS AND TIPS
Refer to Safety chapters.
10.1 Cooking recommendations
The temperature and cooking times in the tables are guidelines only. They depend
on the recipes and the quality and quantity of the ingredients used.
Your oven may bake or roast differently to the oven you had before. The tables be‐
low show recommended settings for temperature, cooking time and shelf position for
specific types of the food.
If you cannot find the settings for a special recipe, look for the similar one.
10.2 Baking
For the first baking, use the lower
temperature.
You can extend the baking time by 10 –
15 minutes if you bake cakes on more
than one shelf position.
Cakes and pastries at different heights
do not always brown equally. There is no
need to change the temperature setting if
an unequal browning occurs. The
differences equalize during baking.
Trays in the oven can distort during
baking. When the trays are cold again,
the distortions disappear.
10.3 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake
is not baked sufficient‐
ly.
The shelf position is incor‐
rect.
Put the cake on a lower shelf.
The cake sinks and
becomes soggy or
streaky.
The oven temperature is
too high.
Next time set slightly lower
oven temperature.
The oven temperature is
too high and the baking
time is too short.
Next time set a longer baking
time and lower oven tempera‐
ture.
www.electrolux.com16
Baking results Possible cause Remedy
The cake is too dry. The oven temperature is
too low.
Next time set higher oven tem‐
perature.
The baking time is too
long.
Next time set shorter baking
time.
The cake bakes un‐
evenly.
The oven temperature is
too high and the baking
time is too short.
Next time set a longer baking
time and lower oven tempera‐
ture.
The cake batter is not
evenly distributed.
Next time spread the cake bat‐
ter evenly on the baking tray.
The cake is not ready
in the baking time
specified in a recipe.
The oven temperature is
too low.
Next time set a slightly higher
oven temperature.
10.4 Baking on one shelf level
BAKING IN
TINS
(°C) (min)
Flan base -
short pastry,
preheat the
empty oven
True Fan Cooking 170 - 180 10 - 25 2
Flan base -
sponge cake
mixture
True Fan Cooking 150 - 170 20 - 25 2
Ring cake /
Brioche
True Fan Cooking 150 - 160 50 - 70 1
Madeira
cake / Fruit
cakes
True Fan Cooking 140 - 160 70 - 90 1
Cheesecake Conventional Cook‐
ing
170 - 190 60 - 90 1
Use the third shelf position.
Use the function: True Fan Cooking.
Use a baking tray.
CAKES / PASTRIES /
BREADS (°C) (min)
Cake with crumble topping 150 - 160 20 - 40
ENGLISH 17
CAKES / PASTRIES /
BREADS (°C) (min)
Fruit flans (made of yeast dough /
sponge cake mixture), use a deep pan
150 35 - 55
Fruit flans made of short pastry 160 - 170 40 - 80
Preheat the empty oven.
Use the function: Conventional Cooking.
Use a baking tray.
CAKES /
PASTRIES /
BREADS
(°C) (min)
Swiss roll 180 - 200 10 - 20 3
Rye bread: first: 230 20 1
then: 160 - 180 30 - 60
Buttered almond
cake / Sugar cakes
190 - 210 20 - 30 3
Cream puffs /
Eclairs
190 - 210 20 - 35 3
Plaited bread /
Bread crown
170 - 190 30 - 40 3
Fruit flans (made of
yeast dough /
sponge cake mix‐
ture), use a deep
pan
170 35 - 55 3
Yeast cakes with
delicate toppings
(e.g. quark, cream,
custard)
160 - 180 40 - 80 3
Christstollen 160 - 180 50 - 70 2
Use the third shelf position.
BISCUITS
(°C) (min)
Short pastry biscuits True Fan Cooking 150 - 160 10 - 20
www.electrolux.com18
BISCUITS
(°C) (min)
Rolls, preheat the
empty oven
True Fan Cooking 160 10 - 25
Biscuits made of
sponge cake mixture
True Fan Cooking 150 - 160 15 - 20
Puff pastries, preheat
the empty oven
True Fan Cooking 170 - 180 20 - 30
Biscuits made of yeast
dough
True Fan Cooking 150 - 160 20 - 40
Macaroons True Fan Cooking 100 - 120 30 - 50
Pastries made of egg
white / Meringues
True Fan Cooking 80 - 100 120 - 150
Rolls, preheat the
empty oven
Conventional
Cooking
190 - 210 10 - 25
10.5 Bakes and gratins
Use the first shelf position.
(°C) (min)
Baguettes topped
with melted cheese
True Fan Cooking 160 - 170 15 - 30
Vegetables au gratin,
preheat the empty
oven
Turbo Grilling 160 - 170 15 - 30
Lasagne Conventional Cooking 180 - 200 25 - 40
Fish bakes Conventional Cooking 180 - 200 30 - 60
Stuffed vegetables True Fan Cooking 160 - 170 30 - 60
Sweet bakes Conventional Cooking 180 - 200 40 - 60
Pasta bake Conventional Cooking 180 - 200 45 - 60
10.6 Multilevel Baking
Use the function: True Fan Cooking.
Use the baking trays.
ENGLISH 19
CAKES /
PASTRIES (°C) (min)
2 positions
Cream puffs /
Eclairs, preheat the
empty oven
160 - 180 25 - 45 1 / 4
Dry streusel cake 150 - 160 30 - 45 1 / 4
BIS‐
CUITS /
SMALL
CAKES / PAS‐
TRIES /
ROLLS
(°C) (min)
2 positions 3 positions
Rolls 180 20 - 30 1 / 4 -
Short pastry
biscuits
150 - 160 20 - 40 1 / 4 1 / 3 / 5
Biscuits made
of sponge cake
mixture
160 - 170 25 - 40 1 / 4 -
Puff pastries,
preheat the
empty oven
170 - 180 30 - 50 1 / 4 -
Biscuits made
of yeast dough
160 - 170 30 - 60 1 / 4 -
Macaroons 100 - 120 40 - 80 1 / 4 -
Biscuits made
of egg white /
Meringues
80 - 100 130 - 170 1 / 4 -
10.7 Tips on Roasting
Use heat-resistant ovenware.
Roast lean meat covered (you can use
aluminium foil).
Roast large meat joints directly in the tray
or on the wire shelf placed above the
tray.
Put some water in the tray to prevent
dripping fat from burning.
Turn the roast after 1/2 - 2/3 of the
cooking time.
Roast meat and fish in large pieces (1 kg
or more).
Baste meat joints with their own juice
several times during roasting.
10.8 Roasting
Use the first shelf position.
www.electrolux.com20
BEEF
(°C) (min)
Pot roast 1 - 1.5 kg Conventional
Cooking
230 120 - 150
Roast beef or fillet,
rare, preheat the
empty oven
per cm of
thickness
Turbo Grilling 190 - 200 5 - 6
Roast beef or fillet,
medium, preheat
the empty oven
per cm of
thickness
Turbo Grilling 180 - 190 6 - 8
Roast beef or fillet,
well done, preheat
the empty oven
per cm of
thickness
Turbo Grilling 170 - 180 8 - 10
PORK
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Shoulder / Neck / Ham
joint
1 - 1.5 160 - 180 90 - 120
Chops / Spare rib 1 - 1.5 170 - 180 60 - 90
Meatloaf 0.75 - 1 160 - 170 50 - 60
Pork knuckle, pre‐
cooked
0.75 - 1 150 - 170 90 - 120
VEAL
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Roast veal 1 160 - 180 90 - 120
ENGLISH 21
VEAL
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Veal knuckle 1.5 - 2 160 - 180 120 - 150
LAMB
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Lamb leg / Roast
lamb
1 - 1.5 150 - 170 100 - 120
Lamb saddle 1 - 1.5 160 - 180 40 - 60
GAME
Use the function: Conventional Cooking.
(kg)
(°C) (min)
Saddle / Hare leg,
preheat the empty
oven
up to 1 230 30 - 40
Venison saddle 1.5 - 2 210 - 220 35 - 40
Haunch of venison 1.5 - 2 180 - 200 60 - 90
www.electrolux.com22
POULTRY
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Poultry, portions 0.2 - 0.25 each 200 - 220 30 - 50
Chicken, half 0.4 - 0.5 each 190 - 210 35 - 50
Chicken, poulard 1 - 1.5 190 - 210 50 - 70
Duck 1.5 - 2 180 - 200 80 - 100
Goose 3.5 - 5 160 - 180 120 - 180
Turkey 2.5 - 3.5 160 - 180 120 - 150
Turkey 4 - 6 140 - 160 150 - 240
FISH (STEAMED)
Use the function: Conventional Cooking.
(kg)
(°C) (min)
Whole fish 1 - 1.5 210 - 220 40 - 60
10.9 Crispy baking with: Pizza
Function
PIZZA
Use the first shelf position.
(°C) (min)
Tarts 180 - 200 40 - 55
Spinach
flan
160 - 180 45 - 60
PIZZA
Use the first shelf position.
(°C) (min)
Quiche lor‐
raine /
Swiss flan
170 - 190 45 - 55
Cheese‐
cake
140 - 160 60 - 90
ENGLISH 23
PIZZA
Use the first shelf position.
(°C) (min)
Vegetable
pie
160 - 180 50 - 60
PIZZA
Preheat the empty oven before
cooking.
Use the second shelf position.
(°C) (min)
Pizza, thin
crust, use a
deep pan
200 - 230 15 - 20
Pizza, thick
crust
180 - 200 20 - 30
PIZZA
Preheat the empty oven before
cooking.
Use the second shelf position.
(°C) (min)
Unleavened
bread
230 - 250 10 - 20
Puff pastry
flan
160 - 180 45 - 55
Flammku‐
chen
230 - 250 12 - 20
Pierogi 180 - 200 15 - 25
10.10 Grill
Preheat the empty oven before cooking.
Grill only thin pieces of meat or fish.
Put a pan on the first shelf position to
collect fat.
GRILL
Use the function: Grill
(°C) (min)
1st side
(min)
2nd side
Roast beef 210 - 230 30 - 40 30 - 40 2
Beef fillet 230 20 - 30 20 - 30 3
Pork loin 210 - 230 30 - 40 30 - 40 2
Veal loin 210 - 230 30 - 40 30 - 40 2
www.electrolux.com24
GRILL
Use the function: Grill
(°C) (min)
1st side
(min)
2nd side
Lamb saddle 210 - 230 25 - 35 20 - 25 3
Whole fish, 0.5
kg - 1 kg
210 - 230 15 - 30 15 - 30 3 / 4
10.11 Frozen Foods
DEFROSTING
Use the function: True Fan Cooking.
(°C) (min)
Pizza, frozen 200 - 220 15 - 25 2
Pizza American, frozen 190 - 210 20 - 25 2
Pizza, chilled 210 - 230 13 - 25 2
Pizza snacks, frozen 180 - 200 15 - 30 2
French fries, thin 200 - 220 20 - 30 3
French fries, thick 200 - 220 25 - 35 3
Wedges / Croquettes 220 - 230 20 - 35 3
Hash browns 210 - 230 20 - 30 3
Lasagne / Cannelloni,
fresh
170 - 190 35 - 45 2
Lasagne / Cannelloni,
frozen
160 - 180 40 - 60 2
Baked cheese 170 - 190 20 - 30 3
Chicken wings 190 - 210 20 - 30 2
ENGLISH 25
10.12 Defrost
Remove the food packaging and put the
food on a plate.
Do not cover the food, as this can extend
the defrost time.
For large portions of food place an
upturned empty plate on the bottom of
the oven cavity. Put the food in a deep
dish and set it on top of the plate inside
the oven. Remove the shelf supports if
necessary.
Use the first shelf position.
(kg)
(min)
Defrosting
time
(min)
Further de‐
frosting time
Chicken 1 100 - 140 20 - 30 Turn halfway
through.
Meat 1 100 - 140 20 - 30 Turn halfway
through.
Trout 0.15 25 - 35 10 - 15 -
Strawberries 0.3 30 - 40 10 - 20 -
Butter 0.25 30 - 40 10 - 15 -
Cream 2 x 0.2 80 - 100 10 - 15 Whip the cream
when still slightly
frozen in places.
Gateau 1.4 60 60 -
10.13 Preserving
Use the function Bottom Heat.
Use only preserve jars of the same
dimensions available on the market.
Do not use jars with twist-off and bayonet
type lids or metal tins.
Use the first shelf position.
Put no more than six one-litre preserve
jars on the baking tray.
Fill the jars equally and close with a
clamp.
The jars cannot touch each other.
Put approximately 1/2 litre of water into
the baking tray to give sufficient moisture
in the oven.
When the liquid in the jars starts to
simmer (after approximately 35 - 60
minutes with one-litre jars), stop the oven
or decrease the temperature to 100 °C
(see the table).
Set the temperature to 160 - 170 °C.
SOFT FRUIT
(min)
Cooking time
until simmering
Strawberries / Blue‐
berries / Raspber‐
ries / Ripe goose‐
berries
35 - 45
www.electrolux.com26
STONE
FRUIT
(min)
Cooking
time until
simmering
(min)
Continue
to cook at
100 °C
Peaches /
Quinces /
Plums
35 - 45 10 - 15
VEGETA‐
BLES
(min)
Cooking
time until
simmering
(min)
Continue
to cook at
100 °C
Carrots 50 - 60 5 - 10
Cucumbers 50 - 60 -
Mixed pick‐
les
50 - 60 5 - 10
Kohlrabi /
Peas / As‐
paragus
50 - 60 15 - 20
10.14 Dehydrating - True Fan
Cooking
Cover trays with grease proof paper or
baking parchment.
For a better result, stop the oven halfway
through the drying time, open the door
and let it cool down for one night to
complete the drying.
For 1 tray use the third shelf position.
For 2 trays use the first and fourth shelf
position.
VEGETA‐
BLES (°C) (h)
Beans 60 - 70 6 - 8
Peppers 60 - 70 5 - 6
Vegetables for
soup
60 - 70 5 - 6
Mushrooms 50 - 60 6 - 8
Herbs 40 - 50 2 - 3
Set the temperature to 60 - 70 °C.
FRUIT
(h)
Plums 8 - 10
Apricots 8 - 10
Apple slices 6 - 8
Pears 6 - 9
10.15 Moist Baking - recommended accessories
Use the dark and non-reflective tins and containers. They have better heat absorption
than the light colour and reflective dishes.
Pizza pan
Baking dish
Ramekins
Flan base tin
Dark, non-reflective
28 cm diameter
Dark, non-reflective
26 cm diameter
Ceramic
8 cm diame‐
ter, 5 cm
height
Dark, non-reflective
28 cm diameter
ENGLISH 27
10.16 Moist Baking
For the best results follow suggestions
listed in the table below.
Use the third shelf position.
(°C) (min)
Pasta gratin 200 - 220 45 - 55
Potato gratin 180 - 200 70 - 85
Moussaka 170 - 190 70 - 95
Lasagne 180 - 200 75 - 90
Cannelloni 180 - 200 70 - 85
Bread pudding 190 - 200 55 - 70
Rice pudding 170 - 190 45 - 60
Apple cake, made of sponge cake mix‐
ture (round cake tin)
160 - 170 70 - 80
White bread 190 - 200 55 - 70
10.17 Information for test
institutes
Tests according to: EN 60350, IEC
60350.
BAKING ON ONE LEVEL. Baking in tins
(°C) (min)
Fatless sponge cake True Fan Cooking 140 - 150 35 - 50 2
Fatless sponge cake Conventional
Cooking
160 35 - 50 2
Apple pie, 2 tins Ø20
cm
True Fan Cooking 160 60 - 90 2
Apple pie, 2 tins Ø20
cm
Conventional
Cooking
180 70 - 90 1
www.electrolux.com28
BAKING ON ONE LEVEL. Biscuits
Use the third shelf position.
(°C) (min)
Short bread / Pastry
strips
True Fan Cooking 140 25 - 40
Short bread / Pastry
strips, preheat the empty
oven
Conventional Cooking 160 20 - 30
Small cakes, 20 per tray,
preheat the empty oven
True Fan Cooking 150 20 - 35
Small cakes, 20 per tray,
preheat the empty oven
Conventional Cooking 170 20 - 30
MULTILEVEL BAKING. Biscuits
(°C) (min)
Short bread / Pastry
strips
True Fan Cooking 140 25 - 45 1 / 4
Small cakes, 20 per
tray, preheat the empty
oven
True Fan Cooking 150 23 - 40 1 / 4
Fatless sponge cake True Fan Cooking 160 35 - 50 1 / 4
GRILL
Preheat the empty oven for 5 minutes.
Grill with the maximum temperature setting.
(min)
Toast Grill 1 - 3 5
ENGLISH 29
GRILL
Preheat the empty oven for 5 minutes.
Grill with the maximum temperature setting.
(min)
Beef steak, turn halfway
through
Grill 24 - 30 4
11. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
11.1 Notes on cleaning
Cleaning
Agents
Clean the front of the oven with a soft cloth with warm water and a
mild detergent.
Use a cleaning solution to clean metal surfaces.
Clean stains with a mild detergent.
Everyday
Use
Clean the cavity after each use. Fat accumulation or other residue
may cause fire.
Do not store the food in the oven for longer than 20 minutes. Dry the
cavity with a soft cloth after each use.
Accessories
Clean all accessories after each use and let them dry. Use a soft
cloth with warm water and a mild detergent. Do not clean the acces‐
sories in a dishwasher.
Do not clean the non-stick accessories using abrasive cleaner or
sharp-edged objects.
11.2 How to remove: Shelf
supports
Remove the shelf supports to clean the
oven.
www.electrolux.com30
Step 1 Turn off the oven and wait
until it is cold.
Step 2 Pull the front of the shelf
support away from the side
wall.
Step 3 Pull the rear end of the shelf
support away from the side
wall and remove it.
2
1
Step 4 Install the shelf supports in
the opposite sequence.
11.3 How to use: Pyrolytic
cleaning
Clean the oven with pyrolytic cleaning.
WARNING!
There is a risk of burns.
CAUTION!
If there are other appliances
installed in the same
cabinet, do not use them at
the same time as this
function. It can cause
damage to the oven.
Before the pyrolytic cleaning:
Turn off the oven and
wait until it is cold.
Remove all accessories
and removable shelf sup‐
ports.
Clean the oven floor and the
inner door glass with warm
water, a soft cloth and a mild
detergent.
Step 1
Set the function: . - flashes.
Step 2 Turn the control knob (for the temperature) to set the cleaning mode.
Option Cleaning mode Duration
P1 Light cleaning 1 h 30 min
P2 Normal cleaning 3 h
Step 3
- press to start the cleaning.
Step 4 After cleaning, turn the knob for the heating functions to the off position.
During the cleaning the oven lamp is off. The oven door stays locked. When the
oven is cold, the door unlocks.
When the oven is at the set temperature, the door locks. Until the door unlocks the
display shows: the bars of the heat indicator, .
ENGLISH 31
When the cleaning ends:
Turn off the oven and
wait until it is cold.
Clean the cavity with a soft
cloth.
Remove the residue from the
bottom of the cavity.
11.4 Cleaning reminder
The oven reminds you when to clean the
oven with: pyrolytic cleaning.
PYR - flashes in the display for 10 sec
after each activation and deactivation of
the oven.
, - press at the same time to
turn off the reminder.
11.5 How to remove and install:
Door
You can remove the door and the
internal glass panels to clean it. The
number of glass panels is different for
different models.
WARNING!
The door is heavy.
CAUTION!
Carefully handle the glass,
especially around the edges
of the front panel. The glass
can break.
Step 1 Fully open the door.
A
A
Step 2 Lift and press the clamp‐
ing levers (A) on the two
door hinges.
Step 3 Close the oven door to the first opening position (approximately 70° an‐
gle). Hold the door at both sides and pull it away from the oven at an up‐
wards angle. Put the door with the outer side down on a soft cloth on a
stable surface.
Step 4 Hold the door trim (B) on
the top edge of the door at
the two sides and push in‐
wards to release the clip
seal.
1
2
B
Step 5 Pull the door trim to the
front to remove it.
Step 6 Hold the door glass pan‐
els on their top edge one
by one and pull them up
out of the guide.
www.electrolux.com32
Step 7 Clean the glass panel with
water and soap. Dry the
glass panel carefully. Do
not clean the glass panels
in the dishwasher.
Step 8 After cleaning, do the
above steps in the oppo‐
site sequence.
Step 9 Install the smaller panel first, then the larger and the door.
11.6 How to replace: Lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
Before you replace the lamp:
Step 1 Step 2 Step 3
Turn off the oven. Wait un‐
til the oven is cold.
Disconnect the oven from
the mains.
Put a cloth on the bottom
of the cavity.
Top lamp
Step 1 Turn the glass cover to remove
it.
Step 2 Clean the glass cover.
Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp.
Step 4 Install the glass cover.
12. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
12.1 What to do if...
In any cases not included in this table
please contact with an Authorised
Service Centre.
The oven does not turn on or
does not heat up
Problem Check if...
ENGLISH 33
The oven does not turn on or
does not heat up
You cannot acti‐
vate or operate the
oven.
The oven is cor‐
rectly connected to
an electrical sup‐
ply.
The oven does not
heat up.
The automatic
switch-off is deacti‐
vated.
The oven does not
heat up.
The oven door is
closed.
The oven does not
heat up.
The fuse is blown.
The oven does not
heat up.
The Child Lock is
off.
Components
Problem Check if...
The lamp is turned
off.
Moist Baking - is
turned on.
The lamp does not
work.
The lamp is burnt
out.
Error codes
The display
shows...
Check if...
C3 The oven door is
closed or the door
lock is not broken.
F102 The oven door is
closed.
F102 The door lock is
not broken.
12:00 There was a power
cut. Set the time of
day.
Error codes
If the display shows an error code that
is not in this table turn the house fuse
off and on to restart the oven. If the er‐
ror code recurs contact an Authorised
Service Centre.
Other problems
Problem Check if...
The appliance is
activated and does
not heat up. The
fan does not oper‐
ate. The display
shows "Demo".
The Demo Mode is
deactivated:
1. Tur off the
oven.
2. , , -
press and hold
at the same
time.
3. The first digit
on the display
and Demo
flash.
4. Turn the knob
for tempera‐
ture to enter
the code:
2468. Press:
. The next
digit flashes.
12.2 Service data
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre.
The necessary data for the service
centre is on the rating plate. The rating
plate is on the front frame of the oven
cavity. Do not remove the rating plate
from the oven cavity.
www.electrolux.com34
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
13. ENERGY EFFICIENCY
13.1 Product Information and Product Information Sheet*
Supplier's name Electrolux
Model identification KOFDP40X 944184906
Energy Efficiency Index 81.2
Energy efficiency class A+
Energy consumption with a standard load, con‐
ventional mode
1.09 kWh/cycle
Energy consumption with a standard load, fan-
forced mode
0.69 kWh/cycle
Number of cavities 1
Heat source Electricity
Volume 71 l
Type of oven Built-In Oven
Mass 34.0 kg
* For European Union according to EU Regulations 65/2014 and 66/2014.
For Republic of Belarus according to STB 2478-2017, Appendix G; STB 2477-2017,
Annexes A and B.
For Ukraine according to 568/32020.
Energy efficiency class is not applicable for Russia.
EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam
ovens and grills - Methods for measuring performance.
13.2 Energy saving
The oven has features which
help you save energy during
everyday cooking.
Make sure that the oven door is closed
when the oven operates. Do not open
the oven door too often during cooking.
Keep the door gasket clean and make
sure it is well fixed in its position.
Use metal cookware to improve energy
saving.
When possible, do not preheat the oven
before cooking.
Keep breaks between baking as short as
possible when you prepare a few dishes
at one time.
Cooking with fan
When possible, use the cooking
functions with fan to save energy.
ENGLISH 35
Residual heat
If a programme with the Duration or End
Time selection is activated and the
cooking time is longer than 30 min, the
heating elements automatically turn off
earlier in some oven functions.
The fan and lamp continue to operate.
When you turn off the oven, the display
shows the residual heat. You can use
that heat to keep the food warm.
When the cooking duration is longer than
30 min, reduce the oven temperature to
minimum 3 - 10 min before the end of
cooking. The residual heat inside the
oven will continue to cook.
Use the residual heat to warm up other
dishes.
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep a
meal warm. The residual heat indicator
or temperature appears on the display.
Cooking with the lamp off
Turn off the lamp during cooking. Turn it
on only when you need it.
Moist Baking
Function designed to save energy during
cooking.
When you use this function the lamp
automatically turns off after 30 sec. You
may turn on the lamp again but this
action will reduce the expected energy
savings.
14. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
www.electrolux.com36
www.electrolux.com/shop
867352940-B-512020
