Stack Bracket Kit
GEFLSTACK
Installation
Instructions
FOR YOUR SAFETY:
WARNING
• Electric Shock Hazard. Disconnect power
before installing. Failure to do so could
result in serious injury or death.
• Potential Personal Injury. More than two
people are recommended to lift the dryer
into position because of its weight and
size. Failure to do so could result in
personal injury or death.
• Avoid Tipping and Rupture of Utility
Services. Dryer must be securely attached
to the washer. DO NOT place the washer on
top of the dryer. Failure to do so could
result in personal injury/death or property
damage.
• Mobile Home or Manufactured Home
Installation – Stacking of a gas dryer is not
permitted in a mobile home or
manufactured home.
175D1807P598
49-90330
05-07 JR
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
•
IMPORTANT – Save these
instructions for local electrical
inspector’s use.
•
IMPORTANT – Observe all
governing codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions
for future reference.
• Installation must be performed by a
qualified installer.
• Proper installation is the responsibility of
the installer.
MINIMUM CLEARANCE OTHER
THAN ALCOVE OR CLOSET
INSTALLATION
Minimum clearance to combustible surfaces
and for air opening are: 0″ both sides and 1″
rear. Consideration must be given to provide
adequate clearance for installation and
service.
ALCOVE OR CLOSET INSTALLATION
• If your dryer is approved for installation in
an alcove or closet, it will be stated on a
label on the dryer back.
• The dryer MUST be vented to the outdoors.
Refer to dryer Installation Instructions for
details.
• Minimum clearance between dryer cabinet
and adjacent walls or other surfaces is:
0″ either side
3″ front and rear
• Minimum vertical space from floor to
overhead cabinets, ceiling, etc. is 43″
without pedestal, 55″ with pedestal and
84″ stacked.
• Closet doors must be louvered or otherwise
ventilated and must contain a minimum of
60 square inches of open area equally
distributed. If the closet contains both a
washer and a dryer, doors must contain a
minimum of 120 square inches of open
area equally distributed.
