OWNER’S MANUAL
Mini Hi-Fi
System
Please read this manual carefully before operating
your set and retain it for future reference.
MODEL
CM4560 (CM4560, CMS4550F, CMS4550W)
*MFL69348128*
www.lg.com
Copyright © 2017 LG Electronics. All Rights Reserved
1 Getting Started
Getting Started 3
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sufcient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing) instructions
in the literature accompanying the
product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of
the product and to protect it from over heating.
The openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance, contact
an authorized service center.
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try
to open the enclosure.
CAUTION concerning the Power cord
Most appliances recommend they should be placed
upon a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an exact
replacement part by an authorized service center.
Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention to
plugs, wall outlets, and the point where the cord exits
the appliance. The Power Plug is the disconnecting
device. In case of an emergency, the Power Plug must
remain readily accessible.
Getting Started4
Getting Started
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the battery
from the equipment: Remove the old battery
or battery pack, follow the steps in reverse order
than the assembly. To prevent contamination of
the environment and bring on possible threat
to human and animal health, the old battery or
the battery put it in the appropriate container at
designated collection points. Do not dispose of
batteries or battery together with other waste. It is
recommended that you use local, free reimbursement
systems batteries and accumulators. The battery
shall not be exposed to excessive heat such as
sunshine, re or the like.
CAUTION: The apparatus should not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, should be placed on the
apparatus.
CAUTION: Do not use high voltage products around
this product. (ex. Electrical swatter) This product may
malfunction due to electrical shock.
CAUTION: No naked ame sources, such as lighted
candles, should be placed on the apparatus.
Getting Started 5
Getting Started
1
Symbols
~
Refers to alternating current(AC).
0
Refers to direct current(DC).
Refers to class II equipment.
1
Refers to stand-by.
!
Refers to “ON” (power).
Refers to dangerous voltage.
Table of Contents6
Table of Contents
1 Getting Started
3 Safety Information
8 Unique Features
9 Playable file Requirement
9 – Music file requirement
9 – Compatible USB Devices
9 – USB device requirement
10 Remote control
12 Front panel
14 Rear Panel
2 Connecting
15 Connecting to speakers
15 – Attaching the speakers to the unit
15 – Attaching the subwoofer to the unit
16 Optional Equipment Connection
16 – Antenna Connection
16 – USB Connection
17 – AUX IN Connection
17 – PORT. IN Connection
17 – Listening to the sound from your external
device
3 Operating
18 Basic Operations
18 – CD/USB Operations
18 – Auto Play
19 Other Operations
19 – Programmed Playback
19 – Deleting Programmed list
19 – Displaying file information (ID3 TAG)
20 – Searching for a folder and an MP3/WMA
file
20 – Deleting an MP3/WMA file
21 – Turn off the sound temporarily
21 – DEMO
21 – AUTO DJ playback
22 Using a BLUETOOTH® wireless technology
22 – Listening to music stored on the
BLUETOOTH devices
24 Using the Music Flow Bluetooth App
24 – About “Music Flow Bluetooth” App
24 – Install “Music Flow Bluetooth” App onto
Your Bluetooth Device
26 Radio Operations
26 – Listening to the radio
26 – Improving poor FM reception
26 – Presetting the Radio Stations
26 – Deleting all the saved stations
26 – Seeing information about a Radio station
27 Sound adjustment
27 – Setting the surround mode
28 Advanced Operations
28 – Recording to USB
28 – To select recording bit rate and speed
29 – USB copying
30 Setting the Clock
30 – Setting the Clock through
“Music Flow Bluetooth” App
30 – Using your player as an alarm clock
31 – Sleep Timer Setting
31 – Dimmer
31 – Auto power down
32 – AUTO POWER On
32 – Auto function change
33 LG Sound Sync
34 WIRELESS PARTY LINK Connection
Getting Started8
Getting Started
1
Unique Features
BLUETOOTH®
Listens to music stored on your Bluetooth device.
Portable In
Listens to music from your portable device. (MP3,
Notebook, etc.)
AUTO DJ
Blends the end of one song into the beginning of
another for seamless playback.
USB Direct Recording
Records music to your USB device.
Music Flow Bluetooth
Music Flow Bluetooth is an app designed to let you
take control of some of LG’s latest Audio devices.
Refer to page 24-25
LG Sound Sync
Controls volume level of this unit by the remote
control of your LG TV that is compatible with LG
Sound Sync.
Playable file
Requirement
Music file requirement
MP3/WMA le compatibility with this unit is limited
as follows.
y Sampling frequency : within 32 to 48 kHz (MP3),
within 32 to 48 kHz (WMA)
y Bit rate : within 32 to 320 kbps (MP3),
40 to 192 kbps (WMA)
y Maximum les : Data CD : 999 / USB : 2,000
y Maximum folders : Data CD : 99 / USB : 200
y File extensions : “.mp3”/“.wma”
y Certain MP3/WMA les may not be played
depending on the type or format of the le.
y CD-ROM le format : ISO 9660/JOLIET
y We recommend that you use Easy-CD Creator,
which creates an ISO 9660 le system.
The DTS is not supported. In case of DTS audio
format, audio is not output.
You have to set the disc format option to [Mastered]
in order to make the discs compatible with the LG
players when formatting rewritable discs. When
setting the option to Live File System, you cannot use
it on LG players.
(Mastered/Live File System : Disc format system for
Windows Vista)
Getting Started 9
Getting Started
1
Compatible USB Devices
y MP3 Player : Flash type MP3 player.
y USB Flash Drive :
Devices that support USB2.0 or USB1.1.
y The USB function of this unit does not support all
USB devices.
USB device requirement
y Devices which require additional program
installation when you have connected it to a
computer, are not supported.
y Do not extract the USB device while in operation.
y For a large capacity USB, it may take longer than a
few minute to be searched.
y To prevent data loss, back up all data.
y If you use a USB extension cable or USB hub, the
USB device is not recognized.
y Using NTFS le system is not supported.
(Only FAT(16/32) le system is supported.)
y This unit recognizes up to 2,000 les.
y External HDD, Card readers, Locked devices, or
hard type USB devices are not supported.
y USB port of the unit cannot be connected to PC.
The unit cannot be used as a storage device.
y Some USB may not work with this unit.
Getting Started10
Getting Started
1
Remote control
Replacement of battery
(R03)
(R03)
Remove the battery cover on the rear of the remote
control, and insert the battery with 4 and 5
matched correctly.
• • • • • • • • • • • • • • a • • • • • • • • • • • • •
1 (Standby) : Switches the unit ON or OFF.
B (Open/Close) : Opens and closes the disc tray.
VOL (Volume) +/- : Adjusts speaker volume.
F (Function) : Selects the function and input source.
(Mute) : Mutes the sound.
PRESET·FOLDER W/S :
- Searches for a folder of MP3/WMA les. When
a CD/USB containing MP3/WMA les in several
folders is being played, press PRESET
·
FOLDER
W/S to select the folder you want to play.
- Chooses a preset number for a radio station.
PROGRAM/MEMORY :
- Stores radio stations.
- Deletes all the saved stations.
- Creates a programmed list you want to listen to.
AUTO DJ : Selects the AUTO DJ mode. (For more
information refer to page 21)
DELETE :
- Deletes MP3/WMA les. (USB only)
- Deletes a song on the programmed list.
Getting Started 11
Getting Started
1
• • • • • • • • • • • • • • b • • • • • • • • • • • • •
REPEAT : Listens to your tracks/les repeatedly or
randomly.
C/V (Skip/Search) :
- Skips fast backward or forward.
- Searches for a section within a track/le.
TUNING -/+ : Selects the radio station.
Z (Stop) :
- Stops playback or recording.
- Cancels DELETE function.
d/M (Play/Pause) :
- Starts or pauses playback.
- Selects STEREO/MONO.
SOUND EFFECT : Chooses sound impressions.
REGION EQ : Chooses region equalizer.
INFO :
- Sees informations about your music. An MP3 le
often come with ID3 tag. The tag gives the Title,
Artist, Album or Time information.
- Sees the name of connected all Bluetooth device
in Bluetooth mode.
- In status of WIRELESS PARTY LINK Connection,
device name of SLAVE unit appears in the
MASTER unit and device name of MASTER unit
appears in the SLAVE unit.
• • • • • • • • • • • • • • c • • • • • • • • • • • • •
0 to 9 numerical buttons : Selects numbered tracks,
les, or preset number.
CLOCK : Sets a clock and checks a time.
ALARM : With the ALARM function you can turn CD,
USB play and Tuner reception on at a desired time.
• • • • • • • • • • • • • • d • • • • • • • • • • • • •
SLEEP : Sets the system to turn off automatically at
a specified time.
(Dimmer : The display window will be darkened by
half.)
RDS/SET :
- RDS (Radio Data System).
- Conrms the clock and the alarm setting.
PTY : Searches radio stations by radio type.
USB REC : USB direct recording.
Getting Started12
Getting Started
1
Front panel
a
b
c
d
e
f
g
h
i
j
k
l
m
n
p
o
Getting Started 13
Getting Started
1
a Display window
b USB 1 / USB 2
Plays the audio les by connecting the USB
device.
USB REC.
Records to USB.
c 1/! (Standby/On)
Switches the unit ON or OFF.
d I (Stop)
Stops playback or recording.
e AUTO DJ
Selects the AUTO DJ mode.
(For more information refer to page 21)
f Y (Skip/Search)
- Searches backward.
- Skips to the previous track/le.
g DEMO/RDS
- Shows demo mode.
- RDS (Radio Data System)
h PORT. (Portable) IN
i Disc tray
j F (Function) / WIRELESS LINK
- Selects the function and input source.
- Press and hold for 3 seconds to select
WIRELESS PARTY LINK mode.
k T (Play/Pause) ST./MO. (Stereo/Mono)
- Starts or pauses playback.
- Selects Stereo/Mono.
l REGION EQ
Chooses region equalizer.
m U (Skip/Search)
- Searches forward.
- Skips to the next track/le.
n BASS BLAST
Selects BASS effect directly.
o MASTER VOLUME
Adjusts volume of speaker.
p R (Open/Close)
Opens or closes the disc tray.
Getting Started14
Getting Started
1
Rear Panel
a POWER IN
b AUX IN (L/R) connectors
c ANTENNA (FM)
d SPEAKERS terminal/cord
a
b
c
d
POWER IN
2 Connecting
Connecting 15
Connecting
2
Connecting to speakers
Attaching the speakers to the
unit
To connect the cable to the unit, press each plastic
nger pad to open the connection terminals on the
unit. Insert the wire and release the nger pad.
Connect the black of each wire to the terminals
marked - (minus) and the other end to the terminals
marked + (plus).
Attaching the subwoofer to the
unit
Connect a woofer cord to the player.
When connecting a woofer cord to the player, insert
the connector until it clicks.
y Be careful to make sure children do not put
their hands or any objects into the *speaker
duct.
* Speaker duct : A hole for plentiful bass
sound on speaker cabinet (enclosure)
y The speakers contain magnet parts, so color
irregularity may occur on the TV screen or PC
monitor screen. Please use the speakers far
away from either TV screen or PC monitor.
y Use the speaker supplied with this unit
only. Using any other speaker may cause
malfunction.
y Do not connect any other speaker except
subwoofer speaker to the subwoofer
connection terminal on the rear of the unit.
>
Caution
Connecting16
Connecting
2
Optional Equipment
Connection
Antenna Connection
Connect the supplied FM antenna for listening to
the radio.
Connect the antenna to the antenna port on the
back of the unit. Be sure to extend the FM wire
antenna fully.
FM antenna
USB Connection
Connect a USB device (or MP3 player, etc.) to the
USB ports on the unit.
Removing the USB Device from the unit.
1. Choose a different function/mode or
press Z on the remote control or I on
the unit twice in a row.
2. Remove the USB device from the unit.
,
Note
Connecting 17
Connecting
2
AUX IN Connection
Connect an output of auxiliary device (Camcorder, TV,
Player, etc) to the AUX IN(L/R) connector.
If your device has only one output for audio(mono),
connect it to the left (white) audio jack on the unit.
Red
White
To the audio output jacks
of your component
(Camcorder, TV, Player, etc.)
PORT. IN Connection
Connect an output (earphone or line out) of portable
device (MP3 or PMP etc.) to the PORT. IN connector.
PORT.IN
Listening to the sound from your
external device
The unit can be used to play the sound from many
types of external device.
1. Connect the external device to the AUX IN(L/R)
or PORT. IN connector of the unit.
2. Turn the power on by pressing 1 on the remote
control or 1/! on the unit.
3. Select the AUX or PORTABLE function by
pressing F on the remote control or
F / WIRELESS LINK on the unit.
4. Turn on the external device and start playing it.
Automatically switches to the PORTABLE
function when you connect the portable device
to the PORT. IN connector.
,
Note
3 Operating
Operating18
Operating
3
Basic Operations
CD/USB Operations
1. Insert the disc by pressing B on the remote
control or R on the unit
Or connect the USB device to the USB port.
2. Select CD or USB function by pressing F on the
remote control or F / WIRELESS LINK on the
unit.
To Do this
Stop
Press Z on the remote control or
I on the unit.
Playback
Press d/M on the remote control or
T on the unit.
Pause
During playback, press d/M on the
remote control or T on the unit.
Searching
for a section
within
a track/le
Press and hold C/V on the
remote control or Y/U on the
unit during playback and release it at
the point you want to listen to.
Selecting
a track/le
directly
Press 0 to 9 numerical buttons on
the remote control to go to the
desired le or track directly.
Skipping to
the next/
previous
track/le
- In stop status,
Press C/V on the remote
control or Y/U on the unit to
go to the next/previous track/le.
- During playback,
press V on the remote control or
U on the unit to go to the next
track/le.
Playing less than 2 seconds, press
C on the remote control or Y
on the unit to go to the previous
track/le.
Playing after 3 seconds, press C
on the remote control or Y on
the unit to go to the beginning of
the track/le.
Playing
repeatedly or
randomly
Press REPEAT on the remote
control repeatedly. Refer to the note
for details about the display change.
y The display changes in the following order.
USB MP3/WMA CD AUDIO CD
RPT 1
RPT*DIR
RPT ALL
RANDOM
OFF
RPT 1
RPT DIR
RPT ALL
RANDOM
OFF
RPT 1
-
RPT ALL
RANDOM
OFF
*DIR : Directory
y When you play Program list, only RPT 1 and
RPT ALL are available.
y Even after restarting the unit or switching
one function to another, you can listen to
music from the point where it’s last been
played.
y If you leave the disc tray open for 5 minutes,
it will close automatically.
,
Note
Auto Play
AUDIO/MP3/WMA CD is played automatically after
disc tray is open and then closed.
Automatically switches to the CD function if disc
tray is open and then closed when there is no disc in
tray.
Operating 19
Operating
3
Other Operations
Programmed Playback
The program function enables you to store your
favorite les from any disc or USB device.
A program can contain 20 tracks/les for each
media. Possible to save a total of 60 tracks/les.
1. Press PROGRAM/MEMORY on the remote
control in stop status.
2. Press C/V on the remote control to select
a track/file.
3. Press PROGRAM/MEMORY on the remote
control to save and select a next track/file.
4. Repeat steps 2 - 3 to store other tracks/files.
(You can modify the list by pressing
PRESET·FOLDER W/S on the remote control
to select the program number.)
5. Press PROGRAM/MEMORY on the remote
control once again.
To play the programmed list, press d/M on the
remote control after you make the list.
When making or modifying the programmed
list, REPEAT mode is off.
,
Note
Deleting Programmed list
Deleting function only works in the edit mode.
1. Press PROGRAM/MEMORY on the remote
control in stop status.
2. Select a song by pressing PROGRAM/MEMORY
or PRESET·FOLDER W/S on the remote control
repeatedly.
3. Press DELETE on the remote control while a
song is selected.
y Programmed list is cleared in the case below.
- Removing the disc or the USB device.
- Deleting music les in the USB device.
- Unplugging the Power Cord.
y Program is switched off in the case below.
- Changing to a different function.
- Turning off and on the unit.
- Operating the numeric buttons on the
remote control.
,
Note
Displaying file information (ID3
TAG)
While playing an MP3 le containing le information,
you can display the information by pressing INFO on
the remote control.
Operating20
Operating
3
Searching for a folder and an
MP3/WMA file
1. Press PRESET·FOLDER W/S on the remote
control repeatedly until a desired file appears in
the display window.
2. Press d/M on the remote control or T on the
unit to play it. The first file of the folder will be
played.
y USB/CD Folders/Files are recognized as
below.
FOLDER1
ROOT
FOLDER3
FOLDER4
FOLDER2
FOLDER7
FOLDER8
FOLDER5
FOLDER6
FILE 5
FILE 6
FILE 7
FILE 8
FILE 9
FILE 10
FILE 3
FILE 4
FILE 11
FILE 12
FILE 13
FILE 14
FILE 1
FILE 2
FOLDER
FILE
y If there is no le in a folder, the folder will not
appear.
y Folders will be presented as the following
order;
ROOT
FOLDER 1 FOLDER 3
FOLDER 7 FOLDER 8 FOLDER 5
FOLDER 6
y File will be played from $ le No.1 to $ le
No.14 one by one.
y Files and folders will be presented in order
recorded and may be presented differently
according to the record circumstances.
y *ROOT : The rst screen you can see when a
computer recognize the USB/CD is “ROOT”.
,
Note
Deleting an MP3/WMA file
You can delete le, folder or format by pressing
DELETE on the remote control. This function is
supported only in stop status. (USB only)
1. - Select the file you want to delete and press
DELETE on the remote control.
- Select the folder you want to delete by pressing
PRESET·FOLDER W/Son the remote control
and press DELETE on the remote control.
- Press and hold DELETE on the remote control
to format the USB device.
Or
Press DELETE on the remote control repeatedly
during selecting the MP3/WMA file.
The display changes in the following order.
- DEL FILE : Deletes file
- DEL DIR : Deletes folder
- FORMAT : Formats USB
2. To delete file/folder or format, press d/M
on the remote control or T on the unit.
If you want to exit the current mode,
press Z on the remote control or I on the unit.
y Do not extract the USB device during
operation. (play, delete, etc.)
y Regular back up is recommended to prevent
data loss.
y The delete function may not be supported
according to the USB status.
>
Caution
Operating 21
Operating
3
Turn off the sound temporarily
Press on the remote control to mute your sound.
You can mute your unit, for example, to answer the
telephone, the “MUTE” will appear in the display
window.
To cancel it, press on the remote control again or
change the volume level.
DEMO
In the power off state, press DEMO/RDS on the
unit once. The unit will power on and display each
function in the display window. To cancel the DEMO
function, press DEMO/RDS on the unit once more.
y While in DEMO, this unit will keep DEMO
status even if you unplug the power cord
connection.
y You can enjoy other functions during the
DEMO, the DEMO will temporarily pause.
- Without input key in 10 sec, the DEMO
will play back automatically.
,
Note
AUTO DJ playback
Auto DJ blends the end of one song into the
beginning of another for seamless playback. It
equalizes volume across tracks for uninterrupted
playback.
Press AUTO DJ on the remote control or unit
repeatedly, the display changes as followings.
RANDOM (AUTO DJ RANDOM) -> RPT (AUTO DJ
SEQUENTIAL) -> (AUTO DJ OFF)
Mode
Display
Window
Description
OFF
-
(AUTO DJ OFF)
-
RANDOM
RANDOM
(AUTO DJ
RANDOM)
The music is played
randomly on this
mode.
REPEAT
RPT
(AUTO DJ
SEQUENTIAL)
The music is played
repeatedly on this
mode.
y AUTO DJ mode does not support searching
for a section within a track/le or to play
repeatedly or randomly.
y If you move to other functions or stop the
music using I on the unit (or Z on the
remote control) on AUTO DJ mode, AUTO DJ
will be disable.
y AUTO DJ is not supported in the music le
whose length is less than 60 seconds.
y During recording, AUTO DJ is not available.
y Only AUTO DJ SEQUENTIAL is selected when
played programmed list.
,
Note
Operating22
Operating
3
Using a BLUETOOTH®
wireless technology
About BLUETOOTH
Bluetooth is wireless communication technology for
short range connection.
The sound may be interrupted when the connection
has interference from other electronic devices or you
connect a Bluetooth device from a different room.
Connecting individual devices under Bluetooth
wireless technology does not incur any charges. A
mobile phone with Bluetooth wireless technology
can be operated via the Cascade if the connection
was made via Bluetooth wireless technology.
Available Devices : Mobile phone, MP3, Laptop, PDA.
BLUETOOTH Profiles
In order to use Bluetooth wireless technology,
devices must be able to interpret certain proles.This
unit is compatible with following prole.
A2DP (Advanced Audio Distribution Prole)
Codec : SBC
Listening to music stored on the
BLUETOOTH devices
Pairing your unit and BLUETOOTH
device
Before you start the pairing procedure, make
sure the Bluetooth feature is activated on your
Bluetooth device. Refer to your Bluetooth device’s
user guide. Once a pairing operation is performed, it
does not need to be performed again.
1. Turn on the unit.
2. Operate the Bluetooth device and perform the
pairing operation. When searching for this unit
with the Bluetooth device, a list of the devices
found may appear in the Bluetooth device
display depending on the type of Bluetooth
device. Your unit appears as “LG CM4560(XX)”.
y XX means the last two digits of
Bluetooth address. For example, if your
unit has a Bluetooth address such as
9C:02:98:4A:F7:08, you will see
“LG
CM4560(08)
”
on your Bluetooth device.
y Depending on the Bluetooth device type,
some devices may have a different pairing
process. Enter the PIN code (0000) as
needed.
y You can connect this unit with up to 3
Bluetooth devices simultaneously using the
same method as described above, only in the
Bluetooth function.
y The multi pairing connection is only
supported on Android or iOS devices. (Multi
pairing connection may not be supported
depending on the connected device
specications.)
y Removable/detachable Bluetooth device
(Ex : Dongle etc.) will not support multi
pairing.
,
Note
Operating 23
Operating
3
3. When this unit is successfully connected with
your Bluetooth device, “PAIRED” appears on the
display window and change to Bluetooth device
name soon. Then “BT” will appear on the display
window.
y “PAIRED” will momentarily appear on the
display when you connect other devices for
multi pairing
y If the device name is unavailable, “_” will be
displayed.
,
Note
4. Listen to music.
To play a music stored on your Bluetooth device,
refer to your Bluetooth device’s user guide.
y When using Bluetooth technology, you have
to make a connection between the unit and
the Bluetooth device as close as possible and
keep the distance.
However, it may not work well in certain
situations as described below:
- There is a obstacle between the unit and
the Bluetooth device.
- There is a device using same frequency
with Bluetooth technology such as a
medical equipment, a microwave or a
wireless LAN device.
y You should connect your Bluetooth device to
this unit again when you restart it.
y Even if this unit connected up to 3 Bluetooth
devices in the Bluetooth mode, you can play
and control music by using only one of the
connected devices.
,
Note
Controls connected Bluetooth device
You can control connected Bluetooth device by the
unit; play, pause, stop, skip.
y Only Android OS and iOS is available to use
this function.
y This function may not be supported
depending on the Bluetooth device, or
operated differently.
,
Note
y When this unit connected with multiple
Bluetooth devices, only one device which
you are playing keeps Bluetooth connection
when you change the function to the others.
y The sound may be interrupted when the
connection has interference from other
electronic devices.
y Depending on the type of the device, you may
not be able to use the Bluetooth function.
y You can enjoy wireless system using phone,
MP3, Notebook, etc.
y The more distance between the unit and
the Bluetooth device, the lower the sound
quality becomes.
y Bluetooth connection will be disconnected
when the unit is turned off or the Bluetooth
device gets far from the unit.
y When Bluetooth connection is disconnected,
connect the Bluetooth device to the unit
again.
y When a Bluetooth device is not connected,
“BT READY” appears on the display window.
y When you use Bluetooth function,
adjust the volume to a proper level on the
Bluetooth device.
y If it is not in Bluetooth function, only one
device can be connected.
y If a Bluetooth device is connected when
using LG TV, LG TV is disconnected and the
Bluetooth device is connected.
y When you connect Bluetooth device (iOS
device etc.) to this unit or operate the device,
the volume level can be synchronized with
each other.
,
Note
Operating24
Operating
3
Using the Music Flow
Bluetooth App
y Only Android OS is available to use “Music
Flow Bluetooth” app with this unit.
y It is recommended to use the latest version
of app.
,
Note
About “Music Flow Bluetooth”
App
“Music Flow Bluetooth” app brings a suite of new
features to this unit.
To enjoy more features, you are recommended to
download and install free “Music Flow Bluetooth”
app.
Here is introduce a few of the many features of
“Music Flow Bluetooth” app.
Multi Juke box : Your entertainment increases three
fold when you connect up to 3 Bluetooth phones at
the same time. Play music from all three phone and
create a customized playlist from all the phones.
Install “Music Flow Bluetooth”
App onto Your Bluetooth Device
There are two ways to install “Music Flow Bluetooth”
App onto your Bluetooth device.
Install “Music Flow Bluetooth” App
through QR code
1. Install “Music Flow Bluetooth” app through QR
code. Use the scanning software to scan the QR
code.
(Android OS)
2. Tap an icon for installation.
3. Tap an icon for downloading.
y Make sure that your Bluetooth device is
connected to the Internet.
y Make sure that your Bluetooth device
has a scanning software application. If you
don’t have one, download one from “Google
Android Market (Google Play Store)”.
y Depending on area, QR code may not work.
,
Note
Install “Music Flow Bluetooth” App
through “Google Android Market
(Google Play Store)”
1. Tap the “Google Android Market (Google Play
Store)” icon.
2. In the search bar, type in the “Music Flow
Bluetooth” and search it.
3. In the search result list, find and tap
“Music Flow Bluetooth” to start downloading
Bluetooth app.
4. Tap an icon for installation.
5. Tap an icon for downloading.
y Make sure that your Bluetooth device is
connected to the Internet.
y Make sure that your Bluetooth device is
equipped with “Google Android Market
(Google Play Store)”.
,
Note
Operating 25
Operating
3
Activate Bluetooth with
“Music Flow Bluetooth” App
“Music Flow Bluetooth” app helps to connect your
Bluetooth device to this unit.
1. Tap “Music Flow Bluetooth” app icon on the home
screen to open “Music Flow Bluetooth” app, and
go to the main menu.
2. Tap [Menu] and select the unit you want.
3. If you want to get more information to operate,
tap [Help] on the [Setting] menu.
.
y “Music Flow Bluetooth ” app will be available
in the software version as follow;
- Android O/S : Ver 4.0.3 (or later)
y If you use “Music Flow Bluetooth” app for
operation, there would be some differences
between “Music Flow Bluetooth” app and
the supplied remote control. Use the supplied
remote control as necessary.
y Depending on the Bluetooth device, “Music
Flow Bluetooth ” app may not work.
y After connection of “Music Flow Bluetooth”
app, music may be output from your device. In
this case, try connecting procedure again.
y If you operate the other applications or
change the settings on your Bluetooth
device while using “Music Flow Bluetooth”
app, “Music Flow Bluetooth” app may operate
abnormally.
y When “Music Flow Bluetooth” app operates
abnormally, check your Bluetooth device and
the connection of “Music Flow Bluetooth” app
and then try to connect again.
y Depending on the smart phone's operating
system, you have some differences for “Music
Flow Bluetooth” operation.
y Check Bluetooth setting on your Bluetooth
device if “Music Flow Bluetooth” App
connection does not work well.
,
Note
Operating26
Operating
3
Radio Operations
Be sure that FM antenna is connected.
(Refer to page 16)
Listening to the radio
1. Press F on the remote control or
F / WIRELESS LINK on the unit until FM appears
in the display window.
The last received station is tuned in.
2. Auto tuning :
Press and hold TUNING -/+ on the remote
control or Y/U on the unit for about two
seconds until the frequency indication starts to
change, then release. Scanning stops when the
unit tunes in a station.
Or
Manual tuning :
Press TUNING -/+ on the remote control or
Y/U on the unit repeatedly.
3. Adjust the volume by rotating volume knob on
the unit or by pressing VOL +/- on the remote
control repeatedly.
Improving poor FM reception
Press T on the unit or d/M on the remote control.
This will change the Tuner from stereo to mono and
usually improve the reception.
Presetting the Radio Stations
You can preset 50 stations for FM.
Before tuning, make sure to turn down the volume.
1. Press F on the remote control or
F / WIRELESS LINK on the unit until FM appears
in the display window.
2. Select the desired frequency by pressing
TUNING -/+ on the remote control or
Y/U on the unit.
3. Press PROGRAM/MEMORY on the remote control.
A preset number will blink in the display window.
4. Press PRESET·FOLDER W/S on the remote
control to select the preset number you want.
5. Press PROGRAM/MEMORY on the remote
control. The station is stored.
6. Repeat steps 2 to 5 to store other stations.
7. To listen to a preset station, press
PRESET·FOLDER W/S or 0 to 9 numerical
buttons on the remote control.
Deleting all the saved stations
1. Press and hold PROGRAM/MEMORY on the
remote control for two seconds.
“ERASEALL” will flash up on the unit display.
2. Press PROGRAM/MEMORY on the remote
control to erase all the saved radio stations.
Seeing information about a
Radio station
The FM tuner is supplied with the RDS (Radio Data
System) facility. This shows information about the
zradio station being listened to. Press RDS/SET
on the remote control or DEMO/RDS on the unit
repeatedly to cycle through the various data types:
PS (Programme Service Name)
The name of the channel will appear in
the display.
PTY (Programme Type Recognition)
The programme type (e.g. Jazz or News)
will appear in the display.
RT (Radio Text)
A text message contains special
information from the broadcast station.
This text may scroll across the display.
CT (Time controlled by the channel)
This shows the time as broadcast by the
station.
You can search the radio stations by programme
type by pressing RDS/SET on the remote control
or DEMO/RDS on the unit. The display will show
the last PTY in use. Press PTY one or more times
to select your preferred programme type. Press
and hold TUNING -/+. The tuner will search
automatically. When a station is found, the search
will stop.
Operating 27
Operating
3
Sound adjustment
Setting the surround mode
This system has a number of pre-set surround sound
elds. The displayed items for the equalizer may be
different depending on sound sources and effects.
You can select a desired sound mode by using
SOUND EFFECT on the remote control.
On Display Description
POP
CLASSIC
JAZZ
ROCK
This program lends
an enthusiastic
atmosphere to the
sound, giving you the
feeling you are at an
actual rock, pop, jazz or
classic concert.
BASS
Reinforces the treble,
bass and surround
sound effect.
FOOT BALL
You can enjoy the
sound effect FOOTBALL
STADIUM.
STANDARD
You can enjoy optimized
sound.
You can select a desired sound mode by using
REGION EQ.
On Display Region Description
FUNK, REGUETON,
SAMBA, BANDA,
MERENGUE, AXE,
SALSA, SERTANEJ,
CUMBIA, TECNO BR,
FORRO
Latin
America
Optimized
sound effect
for the
music genre
preferred in
each region.
ARABIC Middle East
DANGDUT Indonesia
AFRO Africa
INDIA India
y On some speakers, sound may not be heard
or heard in low sound depending on the
sound mode.
y By pressing BASS BLAST on the unit, you
can enjoy bass sound effect.
,
Note
Operating28
Operating
3
Advanced Operations
Recording to USB
You can record a various sound source to USB.
(CD, USB, AUX, PORTABLE, FM)
1. Connect the USB device to the unit.
2. Select a function by pressing F on the remote
control or F / WIRELESS LINK on the unit.
One track/file recording - You can record to USB
after playing a track/file you want.
All tracks/files recording - You can record to USB
after full stop status.
Programmed list recording - After showing the
programmed list, you can record it to USB.
(Refer to page 19)
3. Start the recording by pressing USB REC on the
remote control or USB REC. on the unit.
- If you connect both USB1 and USB2, press
USB REC on the remote control or
USB REC. on the unit when USB1 or
USB2 which you want to record blinks in the
display window.
4. To stop recording, press Z on the remote control
or I on the unit.
Pausing recording
During recording, press d/M on the remote control
or T on the unit to pause recording. Press it again
to restart recording.
(Only AUX, PORTABLE, FM)
To select recording bit rate and
speed
1. Press USB REC on the remote control or
USB REC. on the unit for longer than 3
seconds.
2. Use C/V on the remote control or
Y/U on the unit to select the bit rate.
3. Press USB REC on the remote control or
USB REC. on the unit again to select the
recording speed.
4. Press C/V on the remote control or
Y/U on the unit to select a desired
recording speed : (AUDIO CD only)
X1 SPEED
- You can listen to music while recording it.
X2 SPEED
- You can just record the music file.
5. Press USB REC on the remote control or
USB REC. on the unit to finish the setting.
Operating 29
Operating
3
USB copying
You can copy various sound source in USB1 to USB2
on USB function.
1. Connect USB device including desired sound files
to USB1 and select USB1 function.
2. Connect another USB device to USB2.
3. Start the recording by pressing USB REC on the
remote control or USB REC. on the unit.
4. To stop recording, press Z on the remote control
or I on the unit.
The making of unauthorized copies of
copy-protected material, including computer
programs, les, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offense.
This equipment should not be used for such
purposes.
Be responsible
Respect copyrights
y You can check the recording percentage rate
for the USB record on the display window
during the recording.
(MP3/WMA le or Audio CD Only)
y During recording MP3/WMA, there is no sound.
y When you stop recording during playback,
the le that has been recorded at that time
will be stored. (Except MP3/WMA les)
y Do not remove the USB device or turn off
the unit during USB recording. If does not, an
incomplete le may be made and not deleted
on PC.
y If USB recording does not work, the message
like “NO USB”, “ERROR”, “USB FULL”, “NOT
SUPPORT” or “FILE MAX” is displayed on the
display window.
y Multi card reader device or External HDD can
not be used for USB recording.
y A le is recorded by about 512 Mbyte when
you record for a long term.
y You may not store more than 2,000 les.
y You can not record in AUTO DJ mode.
y In case of the unsupported MP3/WMA le,
the le recording may be stopped.
y It’ll be stored as follows.
AUDIO CD MP3/WMA
The other source* Tuner
* : AUX and the like.
Tuner : The current recording frequency is
shown.
,
Note
Operating30
Operating
3
Setting the Clock
1. Turn the unit on.
2. Press and hold CLOCK on the remote control.
3. Select time mode by pressing C/V on the
remote control.
- AM 12:00 (for an AM and PM display) or 0:00
(for a 24 hour display)
4. Press RDS/SET on the remote control to confirm
your selection.
5. Select the hours by pressing C/V on the
remote control.
6. Press RDS/SET on the remote control.
7. Select the minutes by pressing C/V on
the remote control.
8. Press RDS/SET on the remote control.
Setting the Clock through
“Music Flow Bluetooth” App
Install “Music Flow Bluetooth” app on your Android
device. (Refer to page 24)
Your unit’s clock will be automatically synchronized
with your device by activating Bluetooth connection
through “Music Flow Bluetooth” app.
Using your player as an alarm
clock
1. Turn the unit on.
2. Press and hold ALARM on the remote control.
3. Press C/V on the remote control to
change the hours and minutes and press
RDS/SET on the remote control to save.
4. Press C/V on the remote control to
select function and press RDS/SET on the
remote control to save.
- Press C/V to select a memory No. when
you select Tuner and then, press RDS/SET on
the remote control. If there is no memory No.,
this step is skipped.
5. Press C/V on the remote control to
change the volume and press RDS/SET on the
remote control to save. The clock icon “(“
shows that the alarm is set.
y If you set the clock time, you can check the
time by pressing CLOCK on the remote
control even when the player is turned off.
y You can set alarm after you set the clock
time.
y If you set the clock time and alarm, you can
check the alarm icon “(“ and alarm setting
information by pressing ALARM on the
remote control even when the unit is turned
of f.
y You can select ALARM on/off mode by
pressing ALARM on the remote control.
,
Note
Operating 31
Operating
3
Sleep Timer Setting
Press SLEEP on the remote control repeatedly to
select delay time between 10 and 180 minutes.
After the delay time, the unit will be turned off.
To cancel the sleep function, press SLEEP on the
remote control repeatedly until “SLEEP 10” appears,
and then press SLEEP on the remote control once
again while “SLEEP 10” is displayed.
y You can check the remaining time before the
unit is turned off.
y Press SLEEP on the remote control. The
remaining time appears in the display
window.
,
Note
Dimmer
Press SLEEP on the remote control once. The display
window will be darkened by half. To cancel it, press
SLEEP on the remote control repeatedly until dim off.
All the LED turns off when Dimmer is being
operated.
,
Note
Auto power down
This unit will turn itself off to save electricity in the
case were the main unit is not connected to an
external device and is not used for 20 minutes.
The unit will also turn itself off after six hours if the
Main unit has been connected to another device
using the analog inputs.
Auto power down function is applied to only
MASTER unit in case of WIRELESS PARTY LINK
connection. In case of SLAVE unit, Auto power down
is available after disconnection SLAVE unit and
MASTER unit.
How to disconnect the wireless
network connection or the wireless
device
Turn off the unit by pressing the power button for
more than 5 seconds.
Operating32
Operating
3
AUTO POWER On
This unit automatically turns on by an input source :
LG TV or Bluetooth
If you try to connect your Bluetooth device, this unit
turns on and connect your Bluetooth device. You
can play your music.
y Depending on the connected device, this
function may not operate.
y Depending on the connected device, the unit
turns on but Bluetooth function may not be
connected.
y If you disconnect Bluetooth connection by
this unit, some Bluetooth devices try to
connect to the unit continually. Therefore it is
recommended to disconnect the connection
before turning off the unit.
y If you try to connect to the “Music Flow
Bluetooth” app, Bluetooth function of this
unit is turned on.
y If you turn on the unit using LG TV or
Bluetooth function, proper function of this
unit is turned on.
y If you have already paired with this unit,
automatically this unit can turn on by an
input source when this unit is turned off.
y If you turn off the unit by pressing the power
button for more than 5 seconds, AUTO
POWER On function is disabled.
To activate it, turn on the unit.
,
Note
Auto function change
This unit recognizes input signals such as Bluetooth
and LG TV or connected portable device, and then
changes suitable function automatically.
When you try to connect Bluetooth
device
When you try to connect your Bluetooth device to
this unit, Bluetooth function is selected. Play your
music on the Bluetooth device.
When PORT.IN connection is
connected
When you connect the portable device to the
PORT.IN connector, PORTABLE function is selected.
Play your music on the portable device.
When LG TV is connected
When you turn on your LG TV connected by LG
Sound Sync, this unit changes the function to LG TV.
You can hear the sound from your TV.
y This function is not available during recording
or deleting.
y This function only works with devices that
were previously connected.
,
Note
Operating 33
Operating
3
LG Sound Sync
You can control some functions of this unit by
your TV’s remote control with LG Sound Sync. It is
compatible with LG TV that supports LG Sound Sync.
Make sure your TV has the LG Sound Sync logo.
Controllable function by LG TV’s remote control :
Volume up/down, mute
Refer to the TV’s instruction manual for the details of
LG Sound Sync.
1. Turn on the unit by pressing 1 on the remote
control or 1/! on the unit.
2. Press F on the remote control or F / WIRELESS
LINK on the unit. until LG TV function is selected.
3. Set up the sound output of TV to listen to the
sound through this unit :
TV setting menu [ [Sound] [ [TV Sound
output] [ [LG Sound Sync (Wireless)]
“PAIRED” appears on the display window for
about 3 seconds and then you can see “LG TV”
on the display window if connecting normally
between this unit and your TV.
y You can also use the remote control of this
unit while using LG Sound Sync. If you use TV's
remote control again, the unit synchronizes
with the TV.
y If the connection fails, check the conditions of
this unit and your TV : power, function.
y Make sure of the condition of this unit and the
connection in the cases below when using LG
Sound Sync.
- Turned off the unit.
- Changing the function to the others.
- Disconnecting the wireless connection
caused by interference or a distance.
y The amount of time to turn off this unit is
different depending on your TV.
y Details of TV setting menu vary depending on
the manufacturers or models of your TV.
y If you connect LG Sound Sync when “Music
Flow Bluetooth“ app is connected, control
through the app is available.
y If you turned off the unit directly by pressing
1 on the remote control or 1/! on the unit,
LG Sound Sync will be disconnected. To use
this function again, you should reconnect the
TV and the unit.
y If an LG TV is connected when using
Bluetooth, Bluetooth is disconnected and
the LG TV is connected.
y If you try to change the function on using
the LG TV function, volume will be changed
according to the LG TV volume level.
y The volume may be increased when the TV
and this unit is connected by LG Sound Sync.
Decrease the TV volume and then connect
with this unit.
,
Note
Operating34
Operating
3
WIRELESS PARTY LINK
Connection
The output sound of (MASTER) unit is expanded
to (SLAVE) unit.
It is compatible with unit that supports WIRELESS
PARTY LINK.
The name of function about sound expansion
between the compatible products wired or wirelessly
was changed to PARTY LINK or WIRELESS PARTY
LINK.
1. Press and hold F / WIRELESS LINK on the
unit for 3 seconds. PARTY LINK MODE SELECT
appears in the display window.
2. Press Y/U on the unit to select MASTER
or SLAVE.
- unit : Selects MASTER.
- unit : Selects SLAVE.
Two units try to connect with each other.
3. When this unit is successfully connected each
other, “Slave Device Name CONNECTED” appears
in the MASTER unit. “CONNECTED TO Master
Device Name” appears in the SLAVE unit and
change to SLAVE soon.
y If you using the LG Sound Sync, this function
is not available. If you connect the LG TV
function, “NOT SUPPORT” appears in the
display window.
y When WIRELESS PARTY LINK is
disconnected, SLAVE unit is changed to BT
function.
y If the connection is failed, “FAILED” appears in
the display window.
y Mute function is synchronized with each
other.
y WIRELESS PARTY LINK connection will be
disconnected when you turn off the unit or
press and hold F / WIRELESS LINK on the
unit for 3 seconds.
y Sound of MASTER unit and SLAVE unit may
be different depending on playback status
or source.
y Check the folloywing information when
connecting to Bluetooth.
- You can connect only one Bluetooth
device in the MASTER unit. you cannot
connect Bluetooth device to the SLAVE
unit.
- WIRELESS PARTY LINK connection is
only supported on Android or iOS devices.
(WIRELESS PARTY LINK connection
may not be supported depending on the
connected device specications or OS.)
- Removable/detachable Bluetooth
devices (ex. Dongle etc.) will not support
WIRELESS PARTY LINK connection.
- When WIRELESS PARTY LINK is
connected, Bluetooth connection is not
available in status of recording or deleting.
,
Note
4 Troubleshooting
Troubleshooting 35
Troubleshooting
4
Troubleshooting
Problem Cause & Correction
The unit does not work
properly.
y Turn off the power of this unit and the connected external device (TV, Woofer,
DVD-player, Amplier, etc.) and turn it on again.
y Disconnect the power cord of this unit and the connected external device (TV,
Woofer, DVD-player, Amplier, etc.) and then try connecting again.
y Previous setting may not be saved when device power is shut off.
No Power.
y The power cord is not plugged in. Plug in the power cord.
y Check whether electricity failed. Check the condition by operating other
electronic devices.
No sound.
y Check whether you select right function.
Press function button and check the selected function.
y Check to see if the Speakers are connected correctly. Speaker cables connected
correctly.
The unit does not start
playback.
y An unplayable disc is inserted. Insert a playable disc.
y No disc is inserted. Insert a disc.
y The disc is dirty. Clean the disc. (Refer to page 38)
y The disc is inserted upside down. Place the disc with the label or printed side
facing upwards.
Radio stations cannot be
tuned in properly.
y The antenna is positioned or connected poorly. Connect the antenna securely.
y The signal strength of the radio station is too weak. Tune to the station manually.
y No stations have been preset or preset stations have been cleared. (when being
tuned by scanning preset channels) Preset some radio stations, see page 26
for details.
The remote control does
not work properly.
y The remote control is too far from the unit. Operate the remote control within
about 23 ft (7 m).
y There is an obstacle in the path of the remote control and the unit. Remove the
obstacle.
y The batteries in the remote control are exhausted. Replace the batteries with
new ones.
LG Sound Sync does not
work.
y Check whether your LG TV supports LG Sound Sync.
y Check connection of LG Sound Sync.
y Check sound setting of your TV and this unit.
5 Appendix
Appendix36
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption
Refer to the main label on the unit.
Networked standby : 0.5 W
(If all network ports are activated.)
Dimensions (W x H x D) Approx. 206 mm x 308 mm x 284 mm
Net Weight Approx. 3 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Inputs
Analog audio in (AUX IN) 2.0 Vrms (1 kHz, 0 dB), 75 Ω, RCA jack (L, R)
Portable in (PORT. IN) 1.2 Vrms (3.5 mm stereo jack) x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 100 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 75 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total 700 W
Front 230 W X 2 (3 Ω at 1 kHz, 20 % THD)
Subwoofer 240 W (3 Ω at 60 Hz, 20 % THD)
Appendix 37
Appendix
5
Speaker specifications
Front speaker
Type 2 Way 2 Speaker
Impedance 3 Ω
Rated Input Power 230 W
Max. Input power 460 W
Net Dimensions (W x H x D) Approx. 266 mm x 306 mm x 263 mm
Net Weight Approx. 3.1 kg
Subwoofer speaker
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 240 W
Max. Input power 480 W
Net Dimensions (W x H x D) Approx. 266 mm x 306 mm x 324 mm
Net Weight Approx. 4.7 kg
y Design and specications are subject to change without notice.
Appendix38
Appendix
5
Maintenance
Handling the Unit
When shipping the unit
Please save the original shipping carton and packing
materials. If you need to ship the unit, for maximum
protection, re-pack the unit as it was originally
packed at the factory.
Keeping the exterior surfaces clean
Do not use volatile liquids such as insecticide spray
near the unit.
Wiping with strong pressure may damage the
surface.
Do not leave rubber or plastic products in contact
with the unit for a long period of time.
Cleaning the unit
To clean the player, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not use
strong solvents such as alcohol, benzine, or thinner,
as these might damage the surface of the unit.
Maintaining the Unit
The unit is a high-tech, precision device. If the optical
pick-up lens and disc drive parts are dirty or worn,
the picture quality could be diminished. For details,
please contact your nearest authorized service
center.
Notes on Discs
Handling Discs
Never stick paper or tape on the disc.
Storing Discs
After playing, store the disc in its case. Do not
expose the disc to direct sunlight or sources of heat
and never leave it in a parked car exposed to direct
sunlight.
Cleaning Discs
Do not use strong solvents such as alcohol, benzine,
thinner, commercially available cleaners, or anti-static
spray intended for old vinyl records.
Trademarks and
Licenses
The Bluetooth® word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such
marks by LG Electronics is under license.
Other trademarks and trade names are those of
their respective owners.
