HTB5544D
Manuel d’utilisation 105User manual 15
Manual del usuario 57
EN: For further assistance, call the customer support service in your country.
• To obtain assistance in the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands, contact
Philips Customer Care Center at 1-866-310-0744
• To obtain assistance in Mexico, contact Philips Customer Care Center at 01 800 839 1989;
Mexico city: 5887-9736
ES: Para obtener mas informacion, llame al servicio de soporte al cliente de su pais.
• Para obtener asistencia en los Estados Unidos, en Canada, Puerto Rico o en las Islas Virgenes de los Estados
Unidos, comuniquese con Centro de atencion al cliente de Philips al 1-866-310-0744
• Solo para Mexico CENTRO DE ATENCION A CLIENTES LADA, 01 800 839 1989 Solo Para Mexico;
Mexico city: 5887-9736
FR: Pour obtenir de l’aide supplementaire, communiquez avec le centre de service a la clientele de votre pays.
• Pour obtenir de l’aide aux Etats-Unis, au Canada, a Puerto Rico ou aux lles Vierges americaines, communiquez
avec le centre de service a la clientele Philips au : 1-866-310-0744
• Pour obtenir l’aide au Mexique, entrez en contact avec le centre de soin de client de Philips a 01 800 839 1989;
Mexico city: 5887-9736
For product support, visit
Para obtener asistencia técnica, visite
Pour en savoir plus sur l’assistance sur les produits, visitez le site
www.hd.philips.com
P&F USA, Inc.
HTB5544D_F7_UM_V1.0.indb 1 2013/5/24 11:46:25
2x
2x
2x
8x
2x
FM Antenna
User manual
EN Before using your product, read all accompanying
safety information
ES Antes de usar el producto, consulte la información
de seguridad que se encuentra adjunta
FR-CA Avant d’utiliser votre produit, prenez le temps de lire
toute l’information de sécurité connexe
1
2
4x
For Product recycling information, please visit - www.recycle.philips.com
Para obtener información de productos de reciclaje, por favor visite - www.recycle.philips.com
Pour tout renseignement sur le recyclage des produits, veuillez visiter - www.recycle.philips.com
HTB5544D_F7_UM_V1.0.indb 2 2013/5/24 11:46:26
2x
2x
2x
8x
2x
FM Antenna
User manual
1
2
4x
EN Mount stand to the speakers
ES Montaje de los altavoces con base o soporte
FR-CA Montez les haut-parleurs sur pied.
1
HTB5544D_F7_UM_V1.0.indb 3 2013/5/24 11:46:26
SUB
WOOFER
FRONT
LEFT
FRONT
CENTER
FRONT
RIGHT
FRONT
LEFT
FRONT
RIGHT
FRONT
CENTER
REAR
RIGHT
REAR
LEFT
FRONT
CENTER
FRONT
RIGHT
FRONT
LEFT
SUB
WOOFER
REAR
RIGHT
REAR
LEFT
SUB-
WOOFER
REAR
RIGHT
REAR
LEFT
3
4
5
1x
HTB5544D_F7_UM_V1.0.indb 4 2013/5/24 11:46:27
SUB
WOOFER
FRONT
LEFT
FRONT
CENTER
FRONT
RIGHT
FRONT
LEFT
FRONT
RIGHT
FRONT
CENTER
REAR
RIGHT
REAR
LEFT
FRONT
CENTER
FRONT
RIGHT
FRONT
LEFT
SUB
WOOFER
REAR
RIGHT
REAR
LEFT
SUB-
WOOFER
REAR
RIGHT
REAR
LEFT
EN Connect the home theater
ES C o nexión del Home Theater
FR-CA B r anchez le cinéma maison
2
3
4
5
1x
HTB5544D_F7_UM_V1.0.indb 5 2013/5/24 11:46:27
X
DIGITAL IN
OPTICAL
OPTICAL OUT
HDMI
OPTICAL
HDMI
HDMI IN
HDMI OUT (ARC) TO TV
HDMI IN (ARC)
HDMI ARC
HDMI + OPTICAL
HDMI OUT (ARC) TO TV
EN Connect to TV in one of these ways
ES C o necte la Home Theater a la TV de una de las
siguientes formas
FR-CA L e branchement du cinéma maison au téléviseur
peut se faire des façons suivantes
3
HDMI IN
DIGITAL IN
COAXIAL
COAXIAL OUT
HDMI
COAXIAL
AUDIO L/R HDMI
HDMI + COAXIAL
HDMI IN
HDMI + AUDIO L/R
HDMI OUT (ARC) TO TV
HDMI OUT (ARC) TO TV
L
R
AUDIO IN
L R
AUDIO OUT
HTB5544D_F7_UM_V1.0.indb 6 2013/5/24 11:46:29
DIGITAL IN
OPTICAL
OPTICAL OUT
HDMI
OPTICAL
HDMI
HDMI IN
HDMI OUT (ARC) TO TV
HDMI IN (ARC)
HDMI ARC
HDMI + OPTICAL
HDMI OUT (ARC) TO TV
HDMI IN
DIGITAL IN
COAXIAL
COAXIAL OUT
HDMI
COAXIAL
AUDIO L/R HDMI
HDMI + COAXIAL
HDMI IN
HDMI + AUDIO L/R
HDMI OUT (ARC) TO TV
HDMI OUT (ARC) TO TV
L
R
AUDIO IN
L R
AUDIO OUT
HTB5544D_F7_UM_V1.0.indb 7 2013/5/24 11:46:30
HDMI IN
HDMI
HDMI OUT (ARC)
TO TV
HDMI IN 1 HDMI IN 2
HDMI IN (ARC)
EN Connect with other HDMI devices
ES Conecte con otros dispositivos HDMI
FR-CA Connectez l’appareil à d’autres périphériques HDMI
4
2
3
1
HTB5544D_F7_UM_V1.0.indb 8 2013/5/24 11:46:30
X
2
3
1
EN Switch on the home theater
ES E n cendido del Home Theater
FR-CA A l lumez le cinéma maison
5
HTB5544D_F7_UM_V1.0.indb 9 2013/5/24 11:46:31
X
HDMI
TV
1
HOME THEATER
HOME THEATERHOME THEATER
3
2
Français (Canada)
Español (México)
EN Complete the rst time setup
ES P r oceso de con guración inicial
FR-CA E f fectuez la première con guration
6
3
1
3 sec
2
2
1
3
HTB5544D_F7_UM_V1.0.indb 10 2013/5/24 11:46:32
X
HDMI
TV
1
HOME THEATER
HOME THEATERHOME THEATER
3
2
Français (Canada)
Español (México)
3
1
3 sec
2
2
1
3
EN Use your home theater
ES U s o del sistema de Home Theater
FR-CA U t ilisez votre cinéma maison
7
HTB5544D_F7_UM_V1.0.indb 11 2013/5/24 11:46:32
X
AUDIO IN
2
1
1
3.5MM
STEREO
USB
2
3
1
LAN
LAN
1
2
3
HTB5544D_F7_UM_V1.0.indb 12 2013/5/24 11:46:33
X
AUDIO IN
2
1
1
3.5MM
STEREO
USB
2
3
1
LAN
LAN
1
2
3
HTB5544D_F7_UM_V1.0.indb 13 2013/5/24 11:46:34
HTB5544D_F7_UM_V1.0.indb 14 2013/5/24 11:46:34
15
English
EN
Contents
1 Important 16
Important safety instructions 16
Care for your product 17
Care of the environment 18
3D health warning 18
Help and support 18
2 Your home theater 19
Main unit 19
Remote control 19
Connectors 20
3 Connect and set up 22
Connect speakers 22
Connect to TV 23
Connect digital devices through HDMI 24
Connect audio from TV and other
devices 24
Set up speakers 25
Set up EasyLink (HDMI-CEC control) 25
Connect and set up a home network 27
4 Use your home theater 28
Access the home menu 28
Discs 29
Play audio through Bluetooth 30
Data les 31
USB storage devices 32
Audio, video, and picture options 32
Radio 33
MP3 player 34
iPod or iPhone 35
Enjoy Internet services 35
Netix 35
VUDU 35
Browse PC through DLNA 36
Choose sound 38
5 Change settings 39
Language settings 39
Picture and video settings 40
Audio settings 40
Parental control settings 40
Display settings 40
Energy saving settings 41
Speaker settings 41
Restore default settings 41
6 Update software 42
Check software version 42
Update software through USB 42
Update software through the Internet 43
7 Productspecications 43
8 Troubleshooting 47
9 Notice 50
Copyright 50
Notice of compliance 50
Open source software 51
Trademarks 51
10 Language code 53
11 Index 54
HTB5544D_F7_UM_V1.0.indb 15 2013/5/24 11:46:34
16
EN
1 Important
Read and understand all instructions before you
use your product. If damage is caused by failure
to follow instructions, the warranty does not
apply.
Important safety instructions
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources
such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that
produce heat.
• Do not defeat the safety purpose of
the polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety. If the provided
plug does not t into your outlet, consult
an electrician for replacement of the
obsolete outlet.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories
specied by the manufacturer.
• Use only with the cart, stand, tripod,
bracket or table specied by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
• Unplug this apparatus during lightning
storm or when unused for long periods of
time.
• Refer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• Battery usage CAUTION - To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries when the unit is not
used for a long time.
• The batteries shall not be exposed to
excessive heat such as sunshine, re or
the like.
• Perchlorate Material - special handling
may apply. See www.dtsc.ca.gov/
hazardouswaste/perchlorate.
• The product/remote control may contain
a coin/button type battery, which can be
swallowed. Keep the battery out of reach
of children at all times! If swallowed, the
battery can cause serious injury or death.
Severe internal burns can occur within two
hours of ingestion.
HTB5544D_F7_UM_V1.0.indb 16 2013/5/24 11:46:36
17
English
EN
• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure after
you replace the battery.
• If the battery compartment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.
• Apparatus shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on
the apparatus (for example. liquid lled
objects, lighted candles).
• This apparatus may contain lead and
mercury. Dispose according to local, State
or Federal laws. For disposal or recycling
information, please contact your local
authorities. For additional assistance on
recycling options, please contact www.
mygreenelectronics.com or www.eiae.org
or www.recycle.philips.com.
• Where the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Do not place this apparatus on the
furniture that is capable of being tilted by a
child and an adult leaning, pulling, standing
or climbing on it. A falling apparatus can
cause serious injury or even death.
• This apparatus should not be placed in a
built-in installation such as a bookcase or
rack unless proper ventilation is provided.
Make sure to leave a space of 7.8 inches
(20cm) or more around this apparatus.
• Caution - Use of controls or adjustments
or performance of procedures other
than those specied herein may result in
hazardous radiation exposure.
Class II equipment symbol
This symbol indicates that the unit has a double
insulation system.
This 'bolt of lightning' indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The 'exclamation point' calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of re or
electric shock, this apparatus should not be
exposed to rain or moisture and objects lled
with liquids, such as vases, should not be placed
on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Care for your product
• Do not insert any objects other than discs
into the disc compartment.
• Do not insert warped or cracked discs into
the disc compartment.
• Remove discs from the disc compartment
if you are not using the product for an
extended period of time.
• Use only microber cloth to clean the
product.
HTB5544D_F7_UM_V1.0.indb 17 2013/5/24 11:46:36
18
EN
Care of the environment
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused. Please
visit www.recycle.philips.com for additional
information on a recycling center in your area.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on
the environment and human health.
The batteries supplied do not contain the heavy
metals mercury and cadmium. Nevertheless,
in many areas batteries may not be disposed
of with your household waste. Please ensure
you dispose of batteries according to local
regulations.
For perchlorate material, special handling may
apply. Visit www.dtsc.ca.gov/hazardouswaste/
perchlorate.
3D health warning
If you or your family has a history of epilepsy
or photosensitive seizures, consult a medical
professional before exposing yourself to ashing
light sources, rapid image sequences or 3D
viewing.
To avoid discomfort such as dizziness, headache
or disorientation, we recommend not watching
3D for extended periods of time. If you
experience any discomfort, stop watching
3D and do not immediately engage in any
potentially hazardous activity (for example
driving a car) until your symptoms have
disappeared. If symptoms persist, do not resume
watching 3D without consulting a medical
professional rst.
Parents should monitor their children during
3D viewing and ensure they do not experience
any discomfort as mentioned above. Watching
3D is not recommended for children under six
years of age as their visual system is not fully
developed yet.
Help and support
Philips provides extensive online support. Visit
our website at www.philips.com/support to:
• download the complete user manual
• print the quick start guide
• watch video tutorials (available only for
selected models)
• nd answers to frequently answered
questions (FAQs)
• email us a question
• chat with our support representative.
Follow the instructions on the website to select
your language, and then enter your product
model number.
Alternatively, you can contact Philips Consumer
Care in your country. Before you contact
Philips, note down the model number and
serial number of your product. You can nd this
information on the back or bottom of your
product.
HTB5544D_F7_UM_V1.0.indb 18 2013/5/24 11:46:37
19
English
EN
2 Your home
theater
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers(e.g. notication
of product software upgrade), register your
product at www.philips.com/welcome.
Main unit
This section includes an overview of the main
unit.
a (Open/Close)
Open or close the disc compartment.
b (Play/Pause)
Start, pause or resume play.
c (Stop)
Stop play.
d SOURCE
Select an audio, video, radio source or
Bluetooth mode for the home theater.
e +/- (Volume)
Increase or decrease volume.
f (Standby-On)
Switch the home theater on or to standby.
Remote control
This section includes an overview of the
remote control.
fa b c de
a (Standby-On)
• Switch the home theater on or to
standby.
• When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.
b (Home)
Access the home menu.
c DISC/POP-UP MENU
• Switch to disc source.
• Access or exit the disc menu when
you play a disc.
d NETFLIX
Access online videos and TV episodes from
Netix.
a
b
c
d
e
f
g
i
j
k
l
m
n
w
v
u
t
s
r
q
p
o
h
HTB5544D_F7_UM_V1.0.indb 19 2013/5/24 11:46:38
20
EN
e BACK
• Return to a previous menu screen.
• In radio mode, press and hold to erase
the current preset radio stations.
f Navigation buttons
• Navigate menus.
• In radio mode, press left or right to
start auto search.
• In radio mode, press up or down to
tune the radio frequency.
g OK
Conrm an entry or selection.
h / (Previous/Next)
• Skip to the previous or next track,
chapter or le.
• In radio mode, select a preset radio
station.
i (Stop) / (Eject/Open/Close)
• Stop play.
• Press and hold for three seconds to
open or close the disc compartment,
or eject the disc.
j / (Fast Backward / Fast Forward)
Search backwards or forward. Press
repeatedly to change the search speed.
k +/- (Volume)
Increase or decrease volume.
l SOUND SETTINGS
Access or exit sound options.
m Alphanumeric buttons
Enter values or letters (using SMS style
entry).
n REPEAT
Select or turn off repeat mode.
o VUDU
Access online videos from VUDU.
p TOP MENU
Access the main menu of a disc.
q OPTIONS
• Access more play options while playing
a disc or a USB storage device.
• In radio mode, set a radio station.
r (Play)
Start or resume play.
s (Pause)
Pause play.
t (Mute)
Mute or restore volume.
u AUDIO
Select an audio language or channel.
v SUBTITLE
Select subtitle language for video.
w Color buttons: Select tasks or options for
Blu-ray discs.
iPod/iPhone: Select iPod/iPhone source.
RADIO: Switch to FM radio.
SOURCE: Select an audio input source or
Bluetooth mode.
Note
• Selection of radio or a source is inactivated when you
play BD-Java or access Internet services.
Connectors
This section includes an overview of the
connectors available on your home theater.
Front connectors
a AUDIO-IN
Audio input from an MP3 player (3.5mm
jack).
b iPod/iPhone (USB)
ab
iPod/iPhone
HTB5544D_F7_UM_V1.0.indb 20 2013/5/24 11:46:39
21
English
EN
• Audio, video or picture input from a
USB storage device.
• Connect to an iPod or iPhone.
• Access BD-Live
Rear connectors
a AC MAINS
Fixed AC power cable.
b SPEAKERS
Connect to the supplied speakers and
subwoofer.
c Wireless Rear Audio (optional)
This connection function is not available on
this model.
d DIGITAL IN-COAXIAL
Connect to a coaxial audio output on the
TV or a digital device.
e AUDIO IN-AUX
Connect to an analog audio output on the
TV or an analog device.
f HDMI IN1 / HDMI IN2
Connect to the HDMI output on a digital
device.
g (USB)
Audio, video or picture input from a USB
storage device.
h VIDEO OUT
Connect to the composite video input on
the TV.
i DIGITAL IN-OPTICAL
Connect to an optical audio output on the
TV or a digital device.
j HDMI OUT (ARC)
Connect to the HDMI input on the TV.
h
ijk
l
k LAN
Connect to the LAN input on a
broadband modem or router.
l FM ANTENNA
Connect to the supplied FM antenna.
HTB5544D_F7_UM_V1.0.indb 21 2013/5/24 11:46:40
22
EN
3 Connect and set
up
This section helps you connect your home
theater to a TV and other devices, and then set
it up.
For information about the basic connections
of your home theater and accessories, see the
quick start guide.
Note
• For identication and supply ratings, see the type plate
at the back or bottom of the product.
• Before you make or change any connections, make sure
that all devices are disconnected from the power outlet.
Connect speakers
The speaker cables are color-coded for easy
connection. To connect a speaker to your home
theater, match the color on the speaker cable to
the color on the connector.
Speaker position plays a critical role in setting
up a surround sound effect. For best effect,
position all the speakers towards the seating
position and place them close to your ear level
(seated).
Note
• Surround sound depends on factors such as room
shape and size, type of wall and ceiling, windows and
reective surfaces, and speaker acoustics. Experiment
with the speaker positions to nd the optimum setting
for you.
Follow these general guidelines for speakers
placement.
1 Seating position:
This is the center of your listening area.
2 FRONT CENTER (front center) speaker:
Place the center speaker directly in front of
the seating position, either above or below
your TV.
3 FRONT LEFT (front left) and FRONT
RIGHT (front right) speakers:
Place the left and right speakers in the
front, and at equal distance from the center
speaker. Make sure that the left, right, and
the center speakers are at equal distance
from your seating position.
4 REAR LEFT (rear left) and REAR RIGHT
(rear right) speakers:
Place the rear surround speakers to the
left and right side of your seating position,
either in line with it or slightly behind it.
SUB
WOOFER
FRONT
LEFT
FRONT
CENTER
FRONT
RIGHT
REAR
RIGHT
REAR
LEFT
HTB5544D_F7_UM_V1.0.indb 22 2013/5/24 11:46:40
23
English
EN
5 SUBWOOFER (subwoofer):
Place the subwoofer at least one meter
to the left or right of the TV. Leave about
10-centimeter clearance from the wall.
Connect to TV
Connect your home theater to a TV to watch
videos. You can listen to the TV audio through
your home theater speakers.
Use the best quality connection available on
your home theater and TV.
Option 1: Connect to TV through
HDMI (ARC)
Best quality video
Your home theater supports HDMI version
with Audio Return Channel (ARC). If your TV
is HDMI ARC compliant, you can hear the TV
audio through your home theater by using a
single HDMI cable.
1 Using a High Speed HDMI cable, connect
the HDMI OUT (ARC) connector on
your home theater to the HDMI ARC
connector on the TV.
• The HDMI ARC connector on the TV
might be labeled differently. For details,
see the TV user manual.
2 On your TV, turn on HDMI-CEC
operations. For details, see the TV user
manual.
• HDMI-CEC is a feature that enables
CEC compliant devices that are
connected through HDMI to be
controlled by a single remote control,
TV
such as volume control for both the
TV and the home theater. (see 'Set
up EasyLink (HDMI-CEC control)' on
page 25)
3 If you cannot hear the TV audio through
your home theater, set up the audio
manually. (see 'Set up the audio' on page
26)
Option 2: Connect to TV through
standard HDMI
Best quality video
If your TV is not HDMI ARC compliant, connect
your home theater to the TV through a
standard HDMI connection.
1 Using a High Speed HDMI cable, connect
the HDMI OUT (ARC) connector on your
home theater to the HDMI connector on
the TV.
2 Connect an audio cable to hear the TV
audio through your home theater (see
'Connect audio from TV and other devices'
on page 24).
3 On your TV, turn on HDMI-CEC
operations. For details, see the TV user
manual.
• HDMI-CEC is a feature that enables
CEC compliant devices that are
connected through HDMI to be
controlled by a single remote control,
such as volume control for both the
TV and the home theater. (see 'Set
up EasyLink (HDMI-CEC control)' on
page 25)
TV
HTB5544D_F7_UM_V1.0.indb 23 2013/5/24 11:46:41
24
EN
4 If you cannot hear the TV audio through
your home theater, set up the audio
manually. (see 'Set up the audio' on page
26)
Note
• If your TV has a DVI connector, you can use an HDMI/
DVI adapter to connect to TV. However, some of the
features may not be available.
Option 3: Connect to the TV through
composite video
Basic quality video
If your TV does not have HDMI connectors, use
a composite video connection. A composite
connection does not support high-denition
video.
1 Using a composite video cable, connect
the VIDEO OUT connector on your
home theater to the VIDEO IN connector
on the TV.
• The composite video connector might
be labeled AV IN, COMPOSITE, or
BASEBAND.
2 Connect an audio cable to hear the TV
audio through your home theater (see
'Connect audio from TV and other devices'
on page 24).
3 When you watch TV programs, press
SOURCE on your home theater
repeatedly to select the correct audio
input.
4 When you watch videos, switch your TV to
the correct video input. For details, see the
TV user manual.
TV
Connect digital devices
through HDMI
Connect a digital device such as a set-top box,
games console, or camcorder to your home
theater through a single HDMI connection.
When you connect the devices in this way and
play a le or game, the
• video is automatically displayed on your
TV, and
• audio is automatically played on your home
theater.
1 Using a High Speed HDMI cable, connect
the HDMI OUT connector on your digital
device to the HDMI IN 1/2 on your home
theater.
2 Connect your home theater to TV through
HDMI OUT (ARC).
• If the TV is not HDMI CEC compliant,
select the correct video input on your
TV.
3 On the connected device, turn on HDMI-
CEC operations. For details, see the user
manual of the device.
• If you cannot hear the digital device
audio through your home theater, set
up the audio manually. (see 'Set up the
audio' on page 26)
• You can also press SOURCE on your
home theater repeatedly to select the
correct HDMI input.
Connect audio from TV and
other devices
Play audio from TV or other devices through
your home theater speakers.
Use the best quality connection available on
your TV, home theater, and other devices.
HTB5544D_F7_UM_V1.0.indb 24 2013/5/24 11:46:41
25
English
EN
Note
• When your home theater and TV are connected
through HDMI ARC, an audio connection is not
required (see 'Option 1: Connect to TV through HDMI
(ARC)' on page 23).
Option 1: Connect audio through a
digital optical cable
Best quality audio
1 Using an optical cable, connect the
OPTICAL connector on your home
theater to the OPTICAL OUT connector
on the TV or other device.
• The digital optical connector might be
labeled SPDIF or SPDIF OUT.
Option 2: Connect audio through a
digital coaxial cable
Good quality audio
1 Using a coaxial cable, connect the
COAXIAL connector on your home
theater to the COAXIAL/DIGITAL OUT
connector on the TV or other device.
• The digital coaxial connector might be
labeled DIGITAL AUDIO OUT.
TV
Option 3: Connect audio through
analog audio cables
Basic quality audio
1 Using an analog cable, connect the AUX
connectors on your home theater to the
AUDIO OUT connectors on the TV or
other device.
Set up speakers
Set up the speakers manually to experience
customized surround sound.
Before you start
Make the necessary connections described in
the quick start guide, and then switch the TV to
the correct source for your home theater.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio] > [Speaker Setup].
4 Enter the distance for each speaker, and
then listen to the test tones and change
the volume. Experiment with the speaker
positions to nd the ideal setting.
Set up EasyLink (HDMI-CEC
control)
This home theater supports Philips EasyLink,
which uses the HDMI-CEC (Consumer
Electronics Control) protocol. EasyLink-
VCR
HTB5544D_F7_UM_V1.0.indb 25 2013/5/24 11:46:42
26
EN
compliant devices that are connected through
HDMI can be controlled by a single remote
control.
Note
• Depending on the manufacturer, HDMI-CEC is known
by many names. For information on your device, see
the user manual of the device.
• Philips does not guarantee 100% interoperability with
all HDMI-CEC devices.
Before you start
• Connect your home theater to the HDMI-
CEC compliant device through HDMI
connection.
• Make the necessary connections described
in the quick start guide, and then switch
the TV to the correct source for your
home theater.
Enable EasyLink
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [EasyLink] > [EasyLink] > [On] .
4 On your TV and other connected devices,
turn on HDMI-CEC control. For details, see
the user manual of the TV or other devices.
• On your TV, set the audio output to
'Amplier' (instead of TV speakers).
For details, see the TV user manual.
EasyLink controls
With EasyLink, you can control your home
theater, TV, and other connected HDMI-CEC
compliant devices with a single remote control.
• [One Touch Play] (One-touch play): When
a video disc is in the disc compartment,
press (Play) to wake up the TV from
standby, and then play a disc.
• [One Touch Standby] (One-touch
standby): If one-touch standby is enabled,
your home theater can switch to standby
with the remote control of the TV or other
HDMI-CEC devices.
• [System Audio Control] (System audio
control): If system audio control is enabled,
the audio of the connected device is
output through your home theater
speakers automatically when you play the
device.
• [Audio Input Mapping] (Audio input
mapping):If system audio control does not
work, map the connected device to the
correct audio input connector on your
home theater. (see 'Set up the audio' on
page 26)
Note
• To change the EasyLink control settings, press
(Home), select [Setup] > [EasyLink].
Set up the audio
If you cannot hear the audio output of a
connected device through your home theater
speakers, do the following:
• Check that you have enabled EasyLink
on all the devices, (see 'Set up EasyLink
(HDMI-CEC control)' on page 25) and
• on your TV, set the audio output to
"Amplier" (instead of TV speakers). For
details, see the TV user manual, and
• setup the EasyLink audio control.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [EasyLink] > [System Audio
Control] > [On].
• To play the audio from the TV
speakers, select [Off], and skip the
following steps.
4 Select [EasyLink] > [Audio Input
Mapping].
5 Follow the onscreen instructions to map
the connected device to the audio inputs
on your home theater.
HTB5544D_F7_UM_V1.0.indb 26 2013/5/24 11:46:42
27
English
EN
• If you connect your home theater
to the TV through an HDMI ARC
connection, make sure that the TV
audio is mapped to the ARC input on
your home theater.
Connect and set up a home
network
Connect your home theater to a network
router for a network setup, and enjoy:
• Streamed multimedia content (see 'Browse
PC through DLNA' on page 36)
• Enjoy Internet services (see 'Enjoy Internet
services' on page 35)
• BD Live applications (see 'BD-Live on Blu-
ray' on page 30)
• Software update (see 'Update software
through the Internet' on page 43)
Caution
• Familiarize yourself with the network router, media
server software and networking principles. If necessary,
read documentation that accompanies the network
components. Philips is not responsible for lost, damaged,
or corrupt data.
Before you start
• For Internet services and software updates,
make sure that the network router has
access to the Internet with high-speed
connection and is not restricted by
rewalls or other security systems.
• Make the necessary connections described
in the quick start guide, and then switch
the TV to the correct source for your
home theater.
Set up the wired network
What you need
• A network cable (RJ45 straight cable).
• A network router (with DHCP enabled).
1 Using a network cable, connect the LAN
connector on your home theater to the
network router.
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Network] > [Network
installation] > [Wired (Ethernet)].
5 Follow the onscreen instructions to
complete the setup.
• If connection fails, select [Retry], and
then press OK.
6 Select [Finish], and then press OK to exit.
• To view the network settings, select
[Setup] > [Network] > [View
network settings].
Set up the wireless network
Your home theater has a built-in Wi-Fi for easy
access to a wireless network.
What you need
• A network router (with DHCP enabled).
For best wireless performance, coverage,
and compatibility, use 802.11n router.
LAN
www
HTB5544D_F7_UM_V1.0.indb 27 2013/5/24 11:46:42
28
EN
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Network] > [Network
installation] > [Wireless (Wi-Fi)], and
then press OK.
4 Follow the onscreen instructions to select
and set up the wireless network.
• If connection fails, select [Retry], and
then press OK.
5 Select [Finish], and then press OK to exit.
• To view the network settings, select
[Setup] > [Network] > [View
wireless settings].
www
4 Use your home
theater
This section helps you use the home theater to
play media from a wide range of sources.
Before you start
• Make the necessary connections described
in the quick start guide and the user
manual.
• Complete the rst-time setup. First-time
setup appears when you turn on your
home theater for the rst time or if you do
not complete the setup.
• Switch the TV to the correct source for
your home theater (for example, HDMI,
AV IN).
Access the home menu
The home menu provides easy access to
connected devices, setup and other useful
features in your home theater.
1 Press (Home).
» The home menu is displayed.
2 Press the Navigation buttons and OK to
select the following:
• [play Disc]: Start disc play.
• [browse USB]: Access the USB
content browser.
• [YouTube]: Access YouTube service.
• [Netix]: Access Netix service.
• [VUDU]: Access VUDU service.
• [Picasa]: Access Picasa web albums.
• [Pandora]: Access Internet radio
service
• [iPod Music]: Access music les from
iPod or iPhone.
• [browse PC]: Access the computer
content browser.
HTB5544D_F7_UM_V1.0.indb 28 2013/5/24 11:46:43
29
English
EN
• [HDMI 1]: Select the digital device
connected to HDMI IN 1 on your
home theater.
• [HDMI 2]: Select the digital device
connected to HDMI IN 2 on your
home theater.
• [Setup]: Access menus to change video,
audio and other settings.
• [AccuWeather]: Access online weather
forecasting service worldwide.
3 Press (Home) to exit.
Discs
Your home theater can play DVDs, VCDs, CDs,
and Blu-ray discs. It can also play discs that
you’ve made at home, such as CD-R discs of
photos, videos, and music.
1 Insert a disc into the home theater.
2 If the disc does not play automatically, press
DISC or select [play Disc] from the home
menu.
3 Use the remote control to control play
(see 'Play buttons' on page 29).
• It is normal to hear a little noise when
you play a Blu-ray disc. This does not
mean that your home theater is faulty.
Play buttons
Button Action
Navigation
buttons
Navigate menus.
Up/Down: Rotate the picture
clockwise or counter-clockwise.
OK Conrm an entry or selection.
(Play) Start or resume play.
Pause play.
/ Stop play.
Press and hold for three seconds
to open or close the disc
compartment.
/ Skip to the previous or next track,
chapter or le.
/ Search fast backwards or forward.
When a video is paused, search
slow backwards or forward.
REPEAT Select or turn off repeat mode.
SUBTITLE Select subtitle language for video.
DISC/
POP-UP
MENU
Access or exit the disc menu.
OPTIONS Access the advanced options
when you play your audio, video,
or media les (see 'Audio, video,
and picture options' on page 32).
Synchronize picture and sound
If the audio and video are not synchronized,
delay the audio to match the video.
1 Press .
2 Select AUD SYNC, and then press OK.
3 Press the Navigation buttons (up/down)
to synchronize the audio with the video.
4 Press OK to conrm.
Play Blu-ray 3D disc
Your home theater can play Blu-ray 3D video.
Read the 3D health warning before playing a
3D disc.
What you need
• A 3D TV
• A pair of 3D glasses that are compatible
with your 3D TV
• A 3D Blu-ray video
• A high speed HDMI cable
1 Using the high speed HDMI cable, connect
your home theater to a 3D compatible TV.
2 Make sure that the 3D video setting is
enabled. Press (Home), select [Setup] >
[Video] > [Watch 3D video] > [Auto].
• To play 3D discs in 2D mode, select
[Off].
HTB5544D_F7_UM_V1.0.indb 29 2013/5/24 11:46:43
30
EN
3 Play a Blu-ray 3D disc and put on the 3D
glasses.
• During video search and in certain play
modes, the video is displayed in 2D.
The video display returns to 3D when
you resume play.
Note
• To avoid ickering, change the brightness of the display.
Bonus View on Blu-ray
On Blu-ray discs that support the Bonus View,
enjoy extra content such as commentaries in a
small screen window. Bonus View is also known
as picture-in-picture.
1 Enable Bonus View in the Blu-ray disc
menu.
2 While you play the movie, press
OPTIONS.
» The options menu is displayed.
3 Select [PIP selection] > [PIP].
• Depending on the video, PIP menu [1]
or [2] is displayed.
• To disable Bonus View, select [Off].
4 Select [2nd audio language] or [2nd
Subtitle Language].
5 Select the language, and then press OK.
BD-Live on Blu-ray
Access additional features on the Blu-ray discs
with BD-Live content, such as internet chats
with the director, the latest movie trailers,
games, wallpaper, and ringtones.
BD-Live services and content vary from disc to
disc.
What you need
• Blu-ray disc with BD-Live content
• a USB storage device, with at least 1 GB of
memory
1 Connect your home theater to a home
network with Internet access (see
'Connect and set up a home network' on
page 27).
2 Connect a USB storage device to the
(USB) connector at the front of your
home theater for BD-Live download.
3 Press (Home) and select [Setup] >
[Advanced] > [BD-Live security] > [Off].
• To disable BD-Live, select [On].
4 Select the BD-Live icon in the disc menu,
and then press OK.
» BD-Live starts to load. The loading
time depends on the disc and your
internet connection.
5 Press the Navigation buttons to navigate
BD-Live, and then press OK to select an
option.
Note
• To clear the memory on the storage device, press
(Home), select [Setup] > [Advanced] > [Clear
memory].
Play audio through Bluetooth
Through Bluetooth, connect the home theater
with your Bluetooth device (such as an iPad,
iPhone, iPod touch, Android phone, or laptop),
and then you can listen to the audio les stored
on the device through your home theater
speakers.
What you need
• A Bluetooth device which supports
Bluetooth prole A2DP, and with Bluetooth
version as 2.1 + EDR.
• The operational range between the
home theater and a Bluetooth device is
approximately 10 meters (30 feet).
1 Press SOURCE repeatedly to select
Bluetooth mode.
» BT is displayed on the display panel.
HTB5544D_F7_UM_V1.0.indb 30 2013/5/24 11:46:43
31
English
EN
2 On the Bluetooth device, switch on
Bluetooth, search for and select the name
of your home theater to start connection
(see the user manual of the Bluetooth
device on how to enable Bluetooth).
• If prompted for a password, enter
"0000".
3 Wait until BT_READY is displayed on the
display panel.
» When the Bluetooth connection
succeeds, BT_READY is displayed on
the display panel.
» If the connection fails, BT on the
display panel is still displayed.
4 Select and play audio les or music on
your Bluetooth device.
• During play, if a call is coming, music
play is paused.
• If music streaming is interrupted, place
the Bluetooth device closer to the
home theater.
5 To exit Bluetooth, select other source.
• When your switch back to Bluetooth
mode, Bluetooth connection remains
active.
Note
• The music streaming may be interrupted by obstacles
between the device and home theater, such as wall,
metallic casing that covers the device, or other devices
nearby that operate in the same frequency.
• If you want to connect your home theater with another
Bluetooth device, press and hold on the remote
control (or on the main unit) to disable the
currently connected Bluetooth device.
• Philips does not guarantee 100% compatibility with all
Bluetooth devices.
Datales
Your home theater can play pictures, audio and
video les contained in a disc or a USB storage
device. Before you play a le, check that the le
format is supported by your home theater (see
'File formats' on page 43).
1 Play the les from a disc or USB storage
device.
2 To stop play, press .
• To resume the video from where you
stopped, press (Play).
• To play the video from the start, press
OK.
Note
• To play DivX DRM protected les, connect your home
theater to a TV through an HDMI cable.
Subtitles
If your video has subtitles in multiple languages,
select a subtitle language.
Note
• Make sure that the subtitle le has the exact same
name as the video le. For example, if the video le is
named 'movie.avi', name the subtitle le as 'movie.srt'
or 'movie.sub'.
• Your home theater supports the following le formats:
.srt, .sub, .txt, .ssa, .ass, smi, and .sami. If the subtitles do
not appear correctly, change the character set.
1 While playing video, press SUBTITLE to
select a language.
2 For DivX videos, if the subtitles do not
appear correctly, continue the following
steps to change the character set.
3 Press OPTIONS.
» The options menu is displayed.
4 Select [Character set], and then select a
character set that supports the subtitle.
HTB5544D_F7_UM_V1.0.indb 31 2013/5/24 11:46:43
32
EN
Europe, India, LATAM, and Russia
Character
Set
Language
[Standard] English, Albanian, Danish,
Dutch, Finnish, French, Gaelic,
German, Italian, Kurdish (Latin),
Norwegian, Portuguese, Spanish,
Swedish and Turkish
[Central
Europe]
Albanian, Croat, Czech, Dutch,
English, German, Hungarian, Irish,
Polish, Romanian, Slovak, Slovene
and Serbian
[Cyrillic] Bulgarian, Belorussian, English,
Macedonian, Moldavian, Russian,
Serbian and Ukrainian
[Greek] Greek
[Baltic] Estonian, Latvian and Lithuanian
VOD code for DivX
Before you purchase DivX videos and play
them on your home theater, register the home
theater on www.divx.com using the DivX VOD
code.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [DivX
®
VOD Code].
» The DivX VOD registration code for
your home theater is displayed.
USB storage devices
Enjoy pictures, audio, and video stored on a
USB storage device such as an MP4 player or
digital camera.
What you need
• A USB storage device that is formatted for
FAT or NTFS le systems, and complies
with the Mass Storage Class.
• A media le in one of the supported le
formats (see 'File formats' on page 43).
Note
• If you use a USB extension cable, USB HUB, or USB
multi-reader, the USB storage device may not be
recognized.
1 Connect a USB storage device to the
(USB) connector on your home theater.
2 Press (Home).
3 Select [browse USB], and then press OK.
» A content browser is displayed.
4 Select a le, and then press OK.
5 Press the play buttons to control play (see
'Play buttons' on page 29).
Audio, video, and picture
options
Use advanced features when you play pictures,
audio and video les from a disc or a USB
storage device.
Audio options
While playing audio, repeat an audio track, a
disc, or a folder.
1 Press OPTIONS repeatedly to cycle
through the following functions:
• Repeat the current track or le.
• Repeat all the tracks on the disc or the
folder.
• Turn off the repeat mode.
Video options
While watching video, select options such
as subtitles, audio language, time search, and
picture settings. Depending on the video source,
some options are not available.
1 Press OPTIONS.
» The video options menu is displayed.
2 Press the Navigation buttons and OK to
select and change:
HTB5544D_F7_UM_V1.0.indb 32 2013/5/24 11:46:43
33
English
EN
• [Info]: Display information about what
is playing.
• [Audio language]: Select audio
language for video.
• [Subtitle Language]: Select subtitle
language for video.
• [Subtitle shift]: Change the subtitle
position on the screen.
• [Character set]: Select a character set
that supports the DivX subtitle.
• [Time search]: Skip to a specic part
of the video by entering the time of
the scene.
• [2nd audio language]: Select the
second audio language for Blu-ray
video.
• [2nd Subtitle Language]: Select the
second subtitle language for Blu-ray
video.
• [Titles]: Select a specic title.
• [Chapters]: Select a specic chapter.
• [Angle list]: Select a different camera
angle.
• [Menus]: Display the disc menu.
• [PIP selection]: Display Picture-in-
Picture window when playing a Blu-ray
disc that supports the Bonus View.
• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Repeat]: Repeat a chapter or title.
• [Repeat A-B]: Mark two points within a
chapter or track to repeat play, or turn
off the repeat mode.
• [Picture settings]: Select a predened
color setting.
Picture options
While viewing a picture, zoom into the picture,
rotate it, add animation to a slideshow, and
change the picture settings.
1 Press OPTIONS.
» The picture options menu appears.
2 Press the Navigation buttons and OK to
select and change the following settings:
• [Info]: Display picture information.
• [Rotate +90]: Rotate the picture 90
degree clockwise.
• [Rotate -90]: Rotate the picture 90
degree counter-clockwise.
• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Duration per slide]: Select the display
speed for each picture in a slide show.
• [Slide animation]: Select animation for
the slide show.
• [Picture settings]: Select a predened
color setting.
• [Repeat]: Repeat a selected folder.
Musical slideshow
If the picture and audio les are from the same
disc or USB storage device, you can create a
musical slideshow.
1 Select an audio track, and then press OK.
2 Press BACK, and go to the picture
folder.
3 Select a picture, and then press (Play) to
start the slideshow.
4 Press to stop slideshow.
5 Press again to stop music.
Note
• Make sure that the picture and audio formats are
supported by your home theater (see 'File formats' on
page 43).
Radio
Listen to FM radio on your home theater, and
store up to 40 radio stations.
HTB5544D_F7_UM_V1.0.indb 33 2013/5/24 11:46:44
34
EN
Note
• AM and digital radio are not supported.
• If no stereo signal is detected, you are prompted to
install the radio stations again.
1 Connect the FM antenna to the FM
ANTENNA on your home theater.
• For the best reception, place the
antenna away from your TV or other
sources of radiation.
2 Press RADIO on the remote control to
switch to radio source.
» If you have already installed the radio
stations, the last channel that you
listened to is played.
» If you have not installed any radio
stations, the message AUTO
INSTALL...PRESS PLAY appears on
the display panel. Press (Play) to
install radio stations.
3 Use the remote control to listen or to
change radio stations.
Play buttons
Button Action
/
or
Alphanumeric
buttons
Select a preset radio station.
Navigation
buttons
Left/Right: Search for a radio
station.
Up/Down: Fine tune a radio
frequency.
Press to stop the installation
of radio stations.
BACK Press and hold to erase the
preset radio station.
OPTIONS Manual:
1) Press OPTIONS. 2) Press
/ to select your preset.
3) Press OPTIONS again to
store the radio station.
Automatic: Press and hold for
three seconds to reinstall the
radio stations.
SUBTITLE Toggle between the stereo
and mono sounds.
Tuning grid
In some countries, you can toggle the FM tuning
grid between 50 kHz and 100 kHz.
1 Press RADIO on the remote control to
switch to radio source.
2 Press .
3 Press and hold (Play) to toggle between
50 kHz or 100 kHz.
MP3 player
Connect a MP3 player to play audio les.
What you need
• An MP3 player.
• A 3.5mm stereo audio cable.
1 Using the 3.5mm stereo audio cable,
connect the MP3 player to the AUDIO-IN
connector on your home theater.
• If you use 6.5mm stereo audio cable,
connect the MP3 player to your
home theater using a 3.5mm - 6.5mm
converter jack.
2 Press SOURCE repeatedly until AUDIO-
IN appears on the display panel.
3 Press the buttons on the MP3 player to
select and play audio les.
HTB5544D_F7_UM_V1.0.indb 34 2013/5/24 11:46:44
35
English
EN
iPod or iPhone
Through the home theater, you can play audio
les from your iPod or iPhone.
1 With an iPod/iPhone USB cable, connect
your iPod or iPhone to the iPod/iPhone
(USB) connector at the side panel of your
home theater.
2 Press iPod/iPhone on the home theater
remote control.
• Charge your iPod/iPhone while the
home theater is in iPod/iPhone mode.
3 Browse your iPod or iPhone screen to
select the music.
4 Play the music on your iPod or iPhone.
» The music is heard on your home
theater.
Note
• The USB connector at the back of the home theater is
500mA and not for Apple devices.
• A device with more than 500mA cannot be charged via
the USB connector at the back of the home theater.
Enjoy Internet services
With the home theater, you can access online
services, such as movies, pictures and music.
What you need
• A high-speed Internet connection to the
home theater. (see 'Connect and set up a
home network' on page 27)
1 Press (Home)
» The home menu is displayed.
2 Select an Internet service, and press OK.
• [Netix]: an online subscription service
streaming movies & TV episodes over
the Internet
• [YouTube]: a video-sharing service
• [Picasa]: an online photo album
• [VUDU]: an online movie service
• [Pandora]: an Internet radio service
• [AccuWeather]: an online weather
forecasting service worldwide
Netix
With the home theater, you can stream movies
and TV episodes from Netix to your TV over
the Internet. Netix provides online video rental
service.
1 Connect the home theater to the Internet
(see 'Connect and set up a home network'
on page 27).
2 Press (Home), select [Netix], and press
OK.
» The Netix page is displayed on the
TV screen.
3 Use the remote control to browse Netix,
and select a video to play.
• To exit Netix, press (Home).
Note
• For more detailed information on the Netix service,
visit www.netix.com on your computer.
• Netix customer service may ask you the ESN
(electronic serial number) of this player during
troubleshooting. To display the ESN, press (Home),
and select [Setup] > [Advanced] > [NetixESN].
VUDU
With the home theater, you can stream videos
from VUDU to your TV over the Internet.
VUDU provides on-demand videos which
you can rent or purchase, and rich Internet
applications.
1 Connect the home theater to the Internet
(see 'Connect and set up a home network'
on page 27).
2 Press (Home), select [VUDU], and press
OK.
HTB5544D_F7_UM_V1.0.indb 35 2013/5/24 11:46:44
36
EN
» The VUDU page is displayed on the
TV screen.
3 Use the remote control to browse VUDU,
and select a video to play.
• To exit Vudu, press (Home).
Note
• For more detailed information on the VUDU service,
visit www.vudu.com on your computer.
Browse PC through DLNA
Access and play the pictures, audio and video
les from a computer or media server on the
home network through your home theater.
Before you start
• Install a DLNA-compliant media server
application on your device. Make sure that
you download an application that works
best for you. For example,
• Windows Media Player 11 or higher
for PC
• Twonky Media Server for Mac or PC
• Enable media sharing of les. For ease of
use, we have included the steps for the
following applications:
• Windows Media Player 11 (see
'Microsoft Windows Media Player 11'
on page 36)
• Windows Media Player 12 (see
'Microsoft Windows Media Player 12'
on page 37)
• Twonky Media for Mac (see 'Macintosh
OS X Twonky Media (v4.4.2)' on page
37)
Note
• For additional help on these applications or other
media servers, check the user manual of the media
server software software.
Set up media server software
To enable media sharing, set up the media
server software.
Before you start
• Connect your home theater to a home
network. For better video quality, use wired
connection whenever possible.
• Connect the computer and other DLNA-
compatible devices to the same home
network.
• Make sure that your PC rewall allows
you to run Media Player programs (or
the rewall’s exemption list has the media
server software included).
• Switch on your computer and the router.
Microsoft Windows Media Player 11
1 Start Windows Media Player on your PC.
2 Click the Library tab, and then select
Media Sharing.
3 The rst time you select Media Sharing on
your PC,a pop-up screen appears. Check
the Share my media box and click OK.
» The Media Sharing screen is displayed.
4 In the Media Sharing screen, make sure
that you see a device marked as Unknown
Device.
» If you don't see an unknown device
after a minute or so, check that
your PC rewall is not blocking the
connection.
5 Select the unknown device and click Allow.
» A green tick appears next to the
device.
6 By default, Windows Media Player shares
from these folders: My Music, My Pictures,
and My Videos. If your les are in other
folders, select Library > Add to Library.
» The Add to Library screen is displayed.
• If necessary, select Advanced options
to display a list of monitored folders.
7 Select My folders and those of others I
can access, and then click Add.
HTB5544D_F7_UM_V1.0.indb 36 2013/5/24 11:46:44
37
English
EN
8 Follow the onscreen instructions to add
the other folders that contain your media
les.
Microsoft Windows Media Player 12
1 Start Windows Media Player on your PC.
2 In Windows Media Player, click the Stream
tab, and then select Turn on media
streaming.
» The Media streaming options screen
is displayed.
3 Click Turn on media streaming.
» You return to Windows Media Player
screen.
4 Click the Stream tab and select More
streaming options.
» The Media streaming options screen
is displayed.
5 Make sure that you see a media program
in the Local network screen.
» If you don't see a media program,
check that your PC rewall is not
blocking the connection.
6 Select the media program and click
Allowed.
» A green arrow appears next to the
media program.
7 By default, Windows Media Player shares
from these folders: My Music, My Pictures,
and My Videos. If your les are in other
folders, click the Organize tab and select
Manage libraries > Music.
» The Music Library Locations screen is
displayed.
8 Follow the onscreen instructions to add
the other folders that contain your media
les.
Macintosh OS X Twonky Media (v4.4.2)
1 Visit www.twonkymedia.com to purchase
the software, or download a free 30-day
trial to your Macintosh.
2 Start Twonky Media on the Macintosh.
3 In the Twonky Media Server screen, select
Basic Setup and First Steps.
» The First steps screen is displayed.
4 Type a name for your media server, and
then click Save changes.
5 Back in the Twonky Media screen, select
Basic Setup and Sharing.
» The Sharing screen is displayed.
6 Browse and select folders to share, and
then select Save Changes.
» Your Macintosh rescans the folders
automatically so that they are ready to
share.
PlaylesfromyourPC
Note
• Before you play multimedia content from the computer,
make sure that the home theater is connected to
the home network, and the media server software is
properly set up.
1 Press (Home).
2 Select [browse PC], and then press OK.
» A content browser is displayed.
3 Select a device on the network.
» The folders in the selected device are
displayed. Depending on the media
server, the folder names may vary.
• If you cannot see the folders, check
that you have enabled media sharing
on the selected device so that the
content is available for sharing.
4 Select a le, and then press OK.
• Some media les may not play due
to compatibility issues. Check the le
formats supported by your home
theater.
5 Press the play buttons to control play (see
'Play buttons' on page 29).
HTB5544D_F7_UM_V1.0.indb 37 2013/5/24 11:46:44
38
EN
Choose sound
This section helps you choose the ideal sound
for your video or music.
1 Press .
2 Press the Navigation buttons (left/right) to
access the sound options on the display.
Sound
options
Description
[Surround] Select surround sound or stereo
sound.
[Sound] Select a sound mode.
[Audio
sync]
Delay the audio to match the
video.
[Auto
volume]
Reduce sudden changes in
volume, for example, during TV
commercials.
3 Select an option, and then press OK.
4 Press BACK to exit.
• If you do not press a button within a
minute, the menu exits automatically.
Surround sound mode
Experience an immersive audio experience with
surround sound modes.
1 Press .
2 Select [Surround], and then press OK.
3 Press the Navigation buttons (up/down)
to select a setting from your display:
• [Auto]: Surround sound based on the
audio stream.
• [Multi-channel]: Traditional 5.1
channel for a more relaxing cinematic
experience.
• [5-channel stereo]: Enhanced stereo
sound. Ideal for party music.
• [Stereo]: 2-channel stereo sound. Ideal
for listening to music.
4 Press OK to conrm.
Sound mode
Select predened sound modes to suit your
video or music.
1 Make sure that audio post processing is
enabled at the speakers (see 'Speaker
settings' on page 41).
2 Press .
3 Select [Sound], and then press OK.
4 Press the Navigation buttons (up/down)
to select a setting on the display:
• [Auto]: Automatically select a sound
setting based on the sound stream.
• [Balanced]: Experience the original
sound of your movies and music,
without added sound effects.
• [Powerful]: Enjoy thrilling arcade
sounds, ideal for action-packed videos
and loud parties.
• [Bright]: Spice up your dull movies and
music with added sound effects.
• [Clear]: Hear every detail in your
music and clear voices in your movies.
• [Warm]: Experience spoken words
and music vocals in comfort.
• [Personal]: Personalize the sound
based on your preferences.
5 Press OK to conrm.
Equalizer
Change the high frequency (treble), mid
frequency (mid), and low frequency (bass)
settings of the home theater.
1 Press .
2 Select [Sound] > [Personal], and then
press Navigation buttons (right).
3 Press the Navigation buttons (up/down)
to change bass, mid or treble frequency.
4 Press OK to conrm.
Auto volume
Turn on auto volume to reduce sudden changes
in volume, for example, during TV commercials.
HTB5544D_F7_UM_V1.0.indb 38 2013/5/24 11:46:45
39
English
EN
1 Press .
2 Select [Auto volume], and then press OK.
3 Press the Navigation buttons (up/down)
to select [On] or [Off].
4 Press OK to conrm.
5 Change settings
The home theater settings are already
congured for optimal performance. Unless
you have a reason to change a setting, we
recommend that you keep the default setting.
Note
• You cannot change a setting that is grayed out.
• To return to the previous menu, press BACK. To
exit the menu, press (Home).
Language settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Menu language]: Select a display
language for menu.
• [Audio]: Select an audio language for
discs.
• [Subtitle]: Select a subtitle language
for discs.
• [Disc menu]: Select a menu language
for discs.
Note
• If your preferred disc language is not available, select
[Others] from the list, and enter the 4-digit language
code found at the end of this user manual (see
'Language code' on page 53).
• If you select a language that is not available on a disc,
the home theater uses the default language of the disc.
HTB5544D_F7_UM_V1.0.indb 39 2013/5/24 11:46:45
40
EN
Picture and video settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Video], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Tv type]: If the video does not appear
correctly, select a TV type (color
system).
• [TV display]: Select a picture format to
t the TV screen.
• [HDMI video]: Select the resolution of
video signal that is output from HDMI
OUT (ARC) on your home theater.
To enjoy the selected resolution,
make sure that your TV supports the
selected resolution.
• [HDMI Deep Color]: Recreate the
natural world on your TV screen by
displaying vivid images using billion
colors. Your home theater must be
connected to a Deep Color enabled
TV through an HDMI cable.
• [Picture settings]: Select pre dened
color settings for the video display.
• [Watch 3D video]: Set HDMI video to
support 3D or 2D video.
• [Closed Caption]: Turn on or off the
display of sound effects in subtitles
(applicable only when a disc and a TV
support this feature).
Note
• If you change a setting, make sure that the TV supports
the new setting.
Audio settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Night mode]: For quiet listening,
decrease the volume of loud sounds
on your home theater. Night mode
is only available in DVDs and Blu-ray
discs with Dolby Digital, Dolby Digital
Plus, and Dolby True HD soundtracks.
• [HDMI Audio]: Set the HDMI audio
output from your TV, or disable HDMI
audio output from the TV.
• [Speaker Setup]: Set up speakers for
best surround sound experience.
• [Default sound settings]: Restore
the equalizer settings of all the sound
modes to the default values.
Parental control settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Change Password]: Set or change
your password for parental control
access. If you do not have a password
or have forgotten your password, enter
0000.
• [Parental control]: Restrict access
to discs that are recorded with age
ratings. To play all discs, irrespective of
the ratings, select 8 or [Off].
Display settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
HTB5544D_F7_UM_V1.0.indb 40 2013/5/24 11:46:45
41
English
EN
• [Auto subtitle shift]: Enable or disable
automatic repositioning of subtitles on
TVs that support this feature.
• [Display panel]: Set the brightness of
the home theater front panel display.
• [VCD PBC]: Enable or disable the
content menu navigation of VCD and
SVCD discs with Play Back Control
feature.
Energy saving settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Screen saver]: Switch the home
theater to screen saver mode after 10
minutes of inactivity.
• [Auto standby]: Switch the home
theater to standby after 30 minutes of
inactivity. This timer works only when a
disc or USB play is paused or stopped.
• [Sleep timer]: Set the duration of the
sleep timer so that the home theater is
switched to standby after the specied
period.
Speaker settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Enhanced audio]: Select [On] to
enable audio post processing at the
speaker and enable karaoke settings
(if your product supports Karaoke).
To play the original audio of the disc,
select [Off].
Tip
• Enable audio post processing before you select a
predened sound mode (see 'Sound mode' on page
38).
Restore default settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Restore default
settings], and then press OK.
4 Select [OK], and then press OK to
conrm.
» Your home theater is reset to its
default settings except for some
settings such as parental control and
DivX VOD registration code.
HTB5544D_F7_UM_V1.0.indb 41 2013/5/24 11:46:45
42
EN
6 Update software
Philips continually tries to improve its products.
To get the best features and support, update
your home theater with the latest software.
Compare the version of your current software
with the latest version on www.philips.com/
support. If the current version is lower than the
latest version available on the Philips support
website, upgrade your home theater with the
latest software.
Caution
• Do not install a lower version of software than the
current version installed on your product. Philips is not
liable for problems caused due to software downgrade.
Check software version
Check the version of the current software
installed on your home theater.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Version
information].
» The software version is displayed.
Update software through
USB
What you need
• A USB ash drive that is FAT or NTFS-
formatted, with at least 256MB of memory.
Do not use a USB hard drive.
• A computer with Internet access.
• An archive utility that supports the ZIP le
format.
Step 1: Download the latest software
1 Connect a USB ash drive to your
computer.
2 In your web browser, go to www.philips.
com/support.
3 At the Philips Support website, nd your
product and locate the Software and
drivers.
» The software update is available as a
zip le.
4 Save the zip le in the root directory of
your USB ash drive.
5 Use the archive utility to extract the
software update le in the root directory.
» The les are extracted under the
UPG_ALL folder of your USB ash
drive.
6 Disconnect the USB ash drive from your
computer.
Step 2: Update the software
Caution
• Do not switch off the home theater or remove the
USB ash drive during the update.
1 Connect the USB ash drive containing the
downloaded le to your home theater.
• Make sure that the disc compartment
is closed and no disc inside.
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Advanced] > [Software update]
> [USB].
5 Follow the onscreen instructions to
conrm the update.
» Update process takes about 5 minutes
to complete.
HTB5544D_F7_UM_V1.0.indb 42 2013/5/24 11:46:45
43
English
EN
Update software through the
Internet
1 Connect your home theater to a home
network with a high-speed Internet access
(see 'Connect and set up a home network'
on page 27).
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Advanced] > [Software update] >
[Network].
» If an upgrade media is detected, you
are prompted to start or cancel the
update.
» Downloading of the upgrading le may
take long, depending on your home
network condition.
5 Follow the onscreen instructions to
conrm the update.
» Update process takes about 5 minutes
to complete.
» Once complete, the home theater
automatically switches off and restarts.
If it does not, disconnect the power
cord for a few seconds and then
reconnect it.
7 Product
specifications
Note
• Specications and design are subject to change without
notice.
Region codes
The type plate on the back or bottom of the
home theater shows which regions it supports.
Media formats
• AVCHD, BD, BD-R/ BD-RE, BD-Video,
DVD-Video, DVD+R/+RW, DVD-R/-RW,
DVD+R/-R DL, CD-R/CD-RW, Audio CD,
Video CD/SVCD, Picture les, MP3 media,
WMA media, DivX Plus HD media, USB
storage device
File formats
• Audio:
• .aac, .mka, .mp3, .wma, .wav, .mp4, .m4a,
.ac, .ogg
• .ra (Available only in Asia Pacic and
China)
• Video:
• .avi, .divx, .mp4, .m4v, .mkv, .asf, .m2ts,
.mpg, .mpeg, .v, .3gp
• .rmvb, .rm, .rv (Available only in Asia
Pacic and China)
• Picture: .jpg, .jpeg, .jpe, .gif, .png
Country
DVD BD
USA, Canada
AA
1
HTB5544D_F7_UM_V1.0.indb 43 2013/5/24 11:46:46
44
EN
Bluetooth
• Bluetooth proles: A2DP
• Bluetooth version: 2.1 + EDR
Audio formats
Your home theater supports the following
audio les.
(.ralesaresupportedonlyinAsiaPacicand
China)
Extension Container Audio
codec
Bit rate
.mp3 MP3 MP3 Upto 320
kbps
.wma ASF WMA Upto 192
kbps
.aac AAC AAC ,
HE-
AAC
Upto 192
kbps
.wav WAV PCM 27.648
Mbps
.m4a MKV AAC 192 kbps
.mka MKA PCM 27.648
Mbps
Dolby
Digital
640 kbps
DTS
core
1.54 Mbps
MPEG 912 kbps
MP3 Upto 320
kbps
WMA Upto 192
kbps
AAC ,
HE-
AAC
Upto 192
kbps
.ra RM AAC,
HE-
AAC
Upto 192
kbps
Cook 96469 bps
.ac FLAC FLAC Upto 24
bps
.ogg OGG Vorbis Variable
bit rate,
maximum
block size
4096
MP3 Upto 320
kbps
Video formats
If you have a high denition TV, your home
theater allows you to play your video les with:
• Resolution: 1920 x 1080 pixels at
• Frame rate: 6 ~ 30 frames per second.
.avilesinAVIcontainer
Audio
codec
Video codec Bit rate
PCM,
Dolby
Digital,
DTS core,
MP3,
WMA
DivX 3.11, DivX 4.x,
DivX 5.x, DivX 6.x
10 Mbps
max
MPEG 1, MPEG 2 40 Mbps
MPEG 4 SP / ASP 38.4
Mbps
H.264/AVC upto
25 Mbps
WMV9 45 Mbps
.divxlesinAVIcontainer
Audio codec Video codec Bit rate
PCM, Dolby
Digital, MP3,
WMA
DivX 3.11,
DivX 4.x, DivX 5.x,
DivX 6.x
10
Mbps
max
.mp4or.m4vlesinMP4container
Audio codec Video codec Bit rate
Dolby Digital,
MPEG, MP3,
AAC, HE-AAC,
DD+
MPEG 1,
MPEG 2
40 Mbps
HTB5544D_F7_UM_V1.0.indb 44 2013/5/24 11:46:46
45
English
EN
Audio codec Video codec Bit rate
MPEG 4 ASP 38.4
Mbps
H.264/AVC
25 Mbps
.mkvlesinMKVcontainer
Audio codec Video codec Bit rate
PCM, Dolby
Digital, DTS core,
MPEG, MP3,
WMA, AAC, HE-
AAC, DD+
DivX Plus HD 30 Mbps
MPEG 1,
MPEG 2
40 Mbps
MPEG 4 ASP 38.4
Mbps
H.264/AVC
25 Mbps
WMV9 45 Mbps
.m2tslesinMKVcontainer
Audio codec Video codec Bit rate
PCM, Dolby Digital,
DTS core, MPEG,
MP3, WMA, AAC,
HE-AAC, DD+
MPEG 1,
MPEG 2
40 Mbps
MPEG 4 ASP 38.4
Mbps
H.264/AVC
25 Mbps
WMV9 45 Mbps
.asflesinASFcontainer
Audio codec Video codec Bit rate
Dolby Digital,
MP3, WMA,
DD+
MPEG 4 ASP 38.4 Mbps
H.264/AVC
25 Mbps
WMV9 45 Mbps
.mpgand.mpeglesinPScontainer
Audio codec Video codec Bit rate
PCM, DTS core,
MPEG, MP3
MPEG 1,
MPEG 2
40
Mbps
.vlesinFLVcontainer
Audio
codec
Video codec Bit rate
MP3,
AAC
H.264/AVC upto
25 Mbps
H.263 38.4 Mbps
.3gplesin3GPcontainer
Audio
codec
Video codec Bit rate
AAC, HE-
AAC
MPEG 4 ASP 38.4 Mbps
H.264/AVC upto
25 Mbps
max
.rm,.rv,and.rmvblesinRMcontainer
(AvailableonlyinAsiaPacicandChina)
Audio codec Video codec Bit rate
AAC, COOK RV30, RV40 40 Mbps
Amplier
• FTC total output power: 360 W
• Front/rear speakers: 60 W (1% THD, 4
ohm, 200 Hz - 20 kHz)
• Center speaker: 60 W (1% THD, 4
ohm, 200 Hz - 20 kHz)
• Subwoofer: 60 W (1% THD, 8 ohm,
40 Hz - 100 Hz)
• Total output power: 1000W RMS
(30% THD)
• Frequency response: 20 Hz-20 kHz /
±3 dB
• Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)
• Input sensitivity:
• AUX: 2 V
• AUDIO IN: 1 V
HTB5544D_F7_UM_V1.0.indb 45 2013/5/24 11:46:46
46
EN
Video
• Signal system: PAL / NTSC
• HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p24
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
• Sampling frequency:
• MP3: 32 kHz, 44.1 kHz, 48 kHz
• WMA: 44.1 kHz, 48 kHz
• Constant bit rate:
• MP3: 32 kbps - 320 kbps
• WMA: 48 kbps - 192 kbps
Radio
• Tuning range:
• Europe/Russia/China: FM 87.5-108
MHz (50 kHz)
• Asia Pacic/Latin America: FM 87.5-108
MHz (50/100 kHz)
• Signal-to-noise ratio: FM 50 dB
• Frequency response: FM 180 Hz-12.5 kHz
/ ±3 dB
USB
• Compatibility: Hi-Speed USB (2.0)
• Class support: USB Mass Storage Class
(MSC)
• File system: FAT16, FAT32, NTFS
• USB connector:
• Front panel: 5V , 1A
• Rear panel: 5V , 500mA
Main unit
• Power supply: 120V~, 60 Hz
• Power consumption: 160 W
• Standby power consumption: ≤ 0.5 W
• Dimensions (WxHxD):
435 x 58 x 280 mm/ 17.4” x 2.3” x 11.2”
• Weight: 2.66 kg/ 5.85 lbs
Subwoofer
• Output power: 166 W RMS (30% THD)
• Impedance: 4 ohm
• Speaker drivers: 165 mm (6.5") woofer
• Dimensions (WxHxD):
228.8 x 293 x 310 mm/ 9.2” x 11.7” x 12.4”
• Weight: 4 kg/ 8.8 lbs
• Cable length: 3 m/ 9.8 ft.
Speakers
Center speaker:
• Output power: 166 W RMS (30% THD)
• Speaker impedance: 4 ohm
• Speaker drivers: 1 x 78 mm (3") full range
• Dimensions (WxHxD):
314 x 111 x 83 mm/ 12.6” x 4.4” x 3.3”
• Weight: 1 kg/ 2.2 lbs
• Cable length: 2 m/ 6.6 ft.
Front/Rear speaker:
• Output power: 4 x 166 W RMS (30% THD)
• Speaker impedance: 4 ohm
• Speaker drivers: 1 x 78 mm (3") full range
• Dimensions (WxHxD):
250 x 1179 x 250 mm/ 10” x 47.2” x 10”
(front);
100 x 191 x 125 mm/ 4” x 7.6” x 5” (rear)
• Weight:
3.6 kg (7.9 lbs) /each (front);
0.61 kg (1.3 lbs) /each (rear)
• Cable length:
4 m/ 13 ft. (front); 10 m/ 32.8 ft. (rear)
Remote control batteries
• 2 x AAA-R03-1.5 V
Laser
• Laser Type (Diode): InGaN/AIGaN (BD),
AIGaInP (DVD/CD)
• Wave length: 405 +7 nm/-7 nm (BD),
655 +10 nm/-10 nm (DVD),
790 +10 nm/-20 nm (CD)
• Output power (Max. ratings): 20 mW
(BD), 6 mW (DVD), 7 mW (CD)
HTB5544D_F7_UM_V1.0.indb 46 2013/5/24 11:46:46
47
English
EN
8 Troubleshooting
Warning
• Risk of electric shock. Never remove the casing of the
product.
To keep the warranty valid, never try to repair
the product yourself.
If you have problems using this product, check
the following points before you request service.
If you still have a problem, get support at www.
philips.com/support.
Main unit
The buttons on the home theater do not
work.
• Disconnect the home theater from the
power supply for a few minutes, then
reconnect.
• Make sure that the touch buttons surface
is not in contact with any conductive
material, like water drop, metal, etc.
No picture.
• Make sure that the TV is switched to the
correct source for the home theater.
No picture on a TV connected through HDMI.
• Make sure that you use a High Speed
HDMI cable to connect the home theater
and TV. Some Standard HDMI cables do
not display properly for some images, 3D
video, or Deep Color.
• Make sure that the HDMI cable is not
faulty. If it is faulty, replace it with a new
cable.
• Press (Home) and then 731 on the
remote control to restore the default
picture resolution.
• Change the HDMI video setting, or wait
for 10 seconds for auto recovery (see
'Picture and video settings' on page 40).
Discdoesnotplayhigh-denitionvideo.
• Make sure that the disc contains high-
denition video.
• Make sure that the TV supports high-
denition video.
• Use an HDMI cable to connect to the TV.
Sound
No sound from home theater speakers.
• Connect the audio cable from your home
theater to your TV or other devices.
However, you do not need a separate
audio connection when:
• the home theater and TV are
connected through an HDMI ARC
connection, or
• a device is connected to the HDMI IN
connector on your home theater.
• Set up the audio for the connected device
(see 'Set up the audio' on page 26).
• Reset your home theater to its factory
settings (see 'Restore default settings' on
page 41), and then switch it off and switch
on again.
• On your home theater, press SOURCE
repeatedly to select the correct audio
input.
Distorted sound or echo.
• If you play audio from the TV through the
home theater, make sure that the TV is
muted.
Audio and video are not synchronized.
• 1) Press . 2) Press the Navigation
buttons (left/right) to select AUD
SYNC, and then press OK. 3) Press
the Navigation buttons (up/down) to
synchronize the audio with the video.
HTB5544D_F7_UM_V1.0.indb 47 2013/5/24 11:46:46
48
EN
Play
Cannot play a disc.
• Clean the disc.
• Make sure that the home theater supports
the type of disc (see 'Media formats' on
page 43).
• Make sure that the home theater supports
the region code of the disc (see 'Region
codes' on page 43).
• If the disc is a DVD±RW or DVD±R disc,
make sure that it is nalized.
CannotplayaDivXle.
• Make sure that the DivX le is encoded
according to the 'Home Theater Prole'
with the DivX encoder.
• Make sure that the DivX le is complete.
DivX do not display correctly.
• Make sure that the subtitle le name is
the same as the movie le name (see
'Subtitles' on page 31).
• Select the correct character set: 1) Press
OPTIONS. 2) Select [Character set]. 3)
Select the supported character set. 4)
Press OK.
Cannot read the contents of a USB storage
device.
• Make sure that the format of the USB
storage device is compatible with the
home theater.
• Make sure that the le system on the USB
storage device is supported by the home
theater.
'No entry' or 'x' sign appears on the TV.
• The operation is not possible.
EasyLink does not work.
• Make sure that the home theater is
connected to a Philips brand EasyLink TV,
and the EasyLink option is turned on (see
'Set up EasyLink (HDMI-CEC control)' on
page 25).
• For TVs from different manufacturers, the
HDMI CEC could be called differently.
Check theTV user manual on how to
enable it.
When you switch on the TV, the home theater
automatically switches on.
• This behavior is normal when you are using
Philips EasyLink (HDMI-CEC). To make the
home theater work independently, switch
off EasyLink.
Cannot access BD-Live features.
• Make sure that the home theater is
connected to the network. Use a wired
network connection (see 'Set up the wired
network' on page 27), or wireless network
connection (see 'Set up the wireless
network' on page 27).
• Make sure that the network is set up.
Use a wired network installation (see 'Set
up the wired network' on page 27), or
wireless network installation (see 'Set up
the wireless network' on page 27).
• Make sure that the Blu-ray disc supports
BD-Live features.
• Clear memory storage (see 'BD-Live on
Blu-ray' on page 30).
My 3D video played in 2D mode.
• Make sure that your home theater is
connected to a 3D TV through an HDMI
cable.
• Make sure that the disc is a Blu-ray 3D disc,
and the Blu-ray 3D video option is on (see
'BD-Live on Blu-ray' on page 30).
TV screen is black when you play a Blu-ray 3D
video or a DivX copy protected video.
• Make sure that the home theater is
connected to the TV through an HDMI
cable.
• Switch to the correct HDMI source on
the TV.
Cannot download video from an online video
store.
• Make sure that your home theater is
connected to the TV through an HDMI
cable.
HTB5544D_F7_UM_V1.0.indb 48 2013/5/24 11:46:46
49
English
EN
• Make sure that the USB storage device
is formatted, has enough memory to
download the video.
• Make sure that you have paid for the video,
and it is within the rental period.
• Make sure that the network connection
is good. Use a wired network connection
(see 'Set up the wired network' on page
27), or a wireless network connection (see
'Set up the wireless network' on page 27).
• Visit the video store website for more
information.
Bluetooth
A device cannot connect with the home
theater.
• The device does not support the
compatible proles required for the home
theater.
• You have not enabled the Bluetooth
function of the device. See the user manual
of the device on how to enable the
function.
• The device is not correctly connected.
Connect the device correctly. (see 'Play
audio through Bluetooth' on page 30)
• The home theater is already connected
with another Bluetooth device. Disconnect
the connected device, then try again.
Quality of audio play from a connected
Bluetooth device is poor.
• The Bluetooth reception is poor. Move
the device closer to the home theater, or
remove any obstacle between the device
and the home theater.
The connected Bluetooth device connects and
disconnects constantly.
• The Bluetooth reception is poor. Move
the device closer to the home theater, or
remove any obstacle between the device
and the home theater.
• Turn off Wi-Fi function on the Bluetooth
device to avoid interference.
• For some Bluetooth, the Bluetooth
connection can be deactivated
automatically to save power. This does
not indicate any malfunction of the home
theater.
Network
Wireless network distorted or not found.
• Make sure that the wireless network is
not disturbed by microwave ovens, DECT
phones, or other neighboring Wi-Fi devices.
• Place the wireless router and the home
theater within ve meters of each other.
• If the wireless network does not work
properly, try a wired network installation
(see 'Set up the wired network' on page
27).
HTB5544D_F7_UM_V1.0.indb 49 2013/5/24 11:46:46
50
EN
9 Notice
This section contains the legal and trademark
notices.
Copyright
This item incorporates copy protection
technology that is protected by U.S. patents
and other intellectual property rights of
Rovi Corporation. Reverse engineering and
disassembly are prohibited.
This product incorporates proprietary
technology under license from Verance
Corporation and is protected by U.S. Patent
7,369,677 and other U.S. and worldwide
patents issued and pending as well as copyright
and trade secret protection for certain aspects
of such technology. Cinavia is a trademark of
Verance Corporation. Copyright 2004-2010
Verance Corporation. All rights reserved by
Verance. Reverse engineering or disassembly is
prohibited.
Cinavia notice
This product uses Cinavia technology to
limit the use of unauthorized copies of some
commercially-produced lm and videos and
their soundtracks. When a prohibited use of an
unauthorized copy is detected, a message will
be displayed and playback or copying will be
interrupted.
More information about Cinavia technology
is provided at the Cinavia Online Consumer
Information Center at http://www.cinavia.com.
To request additional information about Cinavia
by mail, send a postcard with your mailing
address to: Cinavia Consumer Information
Center, P.O. Box 86851, San Diego, CA, 92138,
USA.
Notice of compliance
The device complies with the FCC rules, Part
15 and with 21 CFR 1040.10.Operation is
subject to the following two conditions:
a This device may not cause harmful
interference, and
b This device must accept any interference
received, including interference that may
cause undesired operation.
FCC rules
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy
and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
FCC Radiation Exposure Statement:This
equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated with a minimum distance of
20cm between the radiator and your body.
This transmitter must not be co-located or
HTB5544D_F7_UM_V1.0.indb 50 2013/5/24 11:46:47
51
English
EN
operated in conjunction with any other antenna
or transmitter.
Warning: Changes or modications made to
this equipment not expressly approved by
Philips may void the FCC authorization to
operate this equipment.
Model number: PHILIPS HTB5544D/F7
Trade Name: Philips
Responsible Party:P&F USA, Inc. PO Box 2248
Alpharetta, GA 30023-2248; 1-866-310-0744
Canada:
This Class B digital apparatus complies with
Canadian ICES-003.
This device complies with Industry Canada
RSS-210. Operation is subject to the following
two conditions: (1) this device may not cause
interference, and (2) this device must accept
any interference, including interference that may
cause undesired operation of the device.
The device meets the exemption from the
routine evaluation limits in section 2.5 of RSS
102 and compliance with RSS-102 RF exposure,
users can obtain Canadian information on RF
exposure and compliance.
This transmitter must not be co-located or
operating in conjunction with any other antenna
or transmitter. This equipment should be
installed and operated with a minimum distance
of 20 centimeters between the radiator and
your body.
Open source software
Open source software
Philips Electronics Hong Kong Ltd. hereby offers
to deliver, upon request, a copy of the complete
corresponding source code for the copyrighted
open source software packages used in this
product for which such offer is requested by
the respective licenses.
This offer is valid up to three years after
product purchase to anyone in receipt of this
information. To obtain source code, please
contact [email protected]. If you prefer
not to use email or if you do not receive
conrmation receipt within a week after mailing
to this email address, please write to "Open
Source Team, Philips Intellectual Property &
Standards, P.O. Box 220, 5600 AE Eindhoven,
The Netherlands." If you do not receive timely
conrmation of your letter, please email to the
email address above.
Trademarks
"Blu-ray 3D " and "Blu-ray 3D " logo are
trademarks of Blu-ray Disc Association.
'DVD Video' is a trademark of DVD Format/
Logo Licensing Corporation.
Java and all other Java trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and/or
other countries.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535;
7,392,195; 7,272,567; 7,333,929; 7,212,872
& other U.S. and worldwide patents issued
& pending. DTS-HD, the Symbol, & DTS-
HD and the Symbol together are registered
trademarks & DTS-HD Master Audio | Essential
is a trademark of DTS, Inc. Product includes
software. DTS, Inc. All Rights Reserved.
HTB5544D_F7_UM_V1.0.indb 51 2013/5/24 11:46:48
52
EN
Manufactured under license from Dolby
Laboratories. Dolby, Pro Logic, and the
double-D symbol are trademarks of Dolby
Laboratories.
DivX , DivX Certied , DivX Plus HD
and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used
under license.
ABOUT DIVX VIDEO: DivX is a digital video
format created by DivX, LLC, a subsidiary
of Rovi Corporation. This is an ofcial DivX
Certied device that plays DivX video. Visit
divx.com for more information and software
tools to convert your les into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivX Certied device must be registered
in order to play purchased DivX Video-on-
Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section
in your device setup menu. Go to vod.divx.com
for more information on how to complete your
registration.
DivX Certied to play DivX and DivX Plus
HD (H.264/MKV) video up to 1080p HD
including premium content.
The terms HDMI and HDMI High-Denition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
The Bluetooth word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Philips
is under license. Other trademarks and trade
names are those of their respective owners.
Netix and the Netix logo are trademarks or
registered trademarks of Netix, Inc.
Vudu is a trademark of VUDU, Inc.
CLASS 1
LASER PRODUCT
HTB5544D_F7_UM_V1.0.indb 52 2013/5/24 11:46:49
53
English
EN
10 Language code
Abkhazian 6566
Afar 6565
Afrikaans 6570
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Avestan 6569
Aymara 6589
Azerhaijani 6590
Bahasa Melayu 7783
Bashkir 6665
Belarusian 6669
Bengali 6678
Bihari 6672
Bislama 6673
Bokmål, Norwegian 7866
Bosanski 6683
Brezhoneg 6682
Bulgarian 6671
Burmese 7789
Castellano, Español 6983
Catalán 6765
Chamorro 6772
Chechen 6769
Chewa; Chichewa; Nyanja 7889
9072
Chuang; Zhuang 9065
Church Slavic; Slavonic 6785
Chuvash 6786
Corsican 6779
Česky 6783
Dansk 6865
Deutsch 6869
Dzongkha 6890
English 6978
Esperanto 6979
Estonian 6984
Euskara 6985
6976
Faroese 7079
Français 7082
Frysk 7089
Fijian 7074
Gaelic; Scottish Gaelic 7168
Gallegan 7176
Georgian 7565
Gikuyu; Kikuyu 7573
Guarani 7178
Gujarati 7185
Hausa 7265
Herero 7290
Hindi 7273
Hiri Motu 7279
Hrwatski 6779
Ido 7379
Interlingua (International)7365
Interlingue 7365
Inuktitut 7385
Inupiaq 7375
Irish 7165
Íslenska 7383
Italiano 7384
Ivrit 7269
Japanese 7465
Javanese 7486
Kalaallisut 7576
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kernewek 7587
Khmer 7577
Kinyarwanda 8287
Kirghiz 7589
Komi 7586
Korean 7579
Kuanyama; Kwanyama 7574
Kurdish 7585
Lao 7679
Latina 7665
Latvian 7686
Letzeburgesch; 7666
Limburgan; Limburger 7673
Lingala 7678
Lithuanian 7684
Luxembourgish; 7666
Macedonian 7775
Malagasy 7771
Magyar 7285
Malayalam 7776
Maltese 7784
Manx 7186
Maori 7773
Marathi 7782
Marshallese 7772
Moldavian 7779
Mongolian 7778
Nauru 7865
Navaho; Navajo 7886
Ndebele, North 7868
Ndebele, South 7882
Ndonga 7871
Nederlands 7876
Nepali 7869
Norsk 7879
Northern Sami 8369
North Ndebele 7868
Norwegian Nynorsk; 7878
Occitan; Provencal 7967
Old Bulgarian; Old Slavonic 6785
Oriya 7982
Oromo 7977
Ossetian; Ossetic 7983
Pali 8073
Panjabi 8065
Persian 7065
Polski 8076
Po
rtuguês 8084
Pushto 8083
Russian 8285
Quechua 8185
Raeto-Romance 8277
Romanian 8279
Rundi 8278
Samoan 8377
Sango 8371
Sanskrit 8365
Sardinian 8367
Serbian 8382
Shona 8378
Shqip 8381
Sindhi 8368
Sinhalese 8373
Slovensky 8373
Slovenian 8376
Somali 8379
Sotho; Southern 8384
South Ndebele 7882
Sundanese 8385
Suomi 7073
Swahili 8387
Swati 8383
Svenska 8386
Tagalog 8476
Tahitian 8489
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
To nga (Tonga Islands) 8479
Tsonga 8483
Tswana 8478
Türkçe 8482
Tu rkmen 8475
Tw i 8487
Uighur 8571
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapuk 8679
Walloon 8765
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 8973
Yo ruba 8979
Zulu 9085
Ё᭛
HTB5544D_F7_UM_V1.0.indb 53 2013/5/24 11:46:50
54
EN
11 Index
2
2nd audio language 30
2nd subtitle language 30
3
3D disc in 2D mode 29
3D safety 18
3D video 29
5
5.1 speakers 22
A
advanced settings 41
amplier 45
audio connection (analog cable) 25
audio connection (HDMI ARC) 23
audio formats 44
audio from other devices 24
audio language 39
audio options 32
audio post processing 41
audio settings 40
auto standby 41
auto subtitle shift 40
auto volume 38
B
batteries 46
BD-Live 30
Blu-ray 29
Bonus View 30
brightness 40
C
change password 40
character set 31
clear BD-Live memory 30
connect a digital device (HDMI) 24
connect to TV 23
connectors 20
control buttons (disc) 29
control buttons (USB) 29
customer support 18
D
datales 31
deep color 40
default settings 41
disc language 39
disc menu 39
display panel 40
DivX 31
E
Easylink (HDMI-CEC) 25
eject disc 19
enhanced audio 41
F
factory settings 41
FAQs 18
leformats 43
H
HDMI ARC 23
HDMI audio 40
HDMI-CEC 25
home menu 28
home network 27
I
internet 27
iPod or iPhone 35
L
language code 53
M
main unit 19
manual setup 25
HTB5544D_F7_UM_V1.0.indb 54 2013/5/24 11:46:50
55
English
EN
media formats 43
media sharing 36
menu language 39
musical slideshows 33
N
network 27
night mode 40
O
one-touch play 26
one-touch standby 26
options 32
P
parental control 40
PBC (play back control) 40
picture options 33
picture resolution 40
picture settings 40
picture-in-picture 30
play disc 29
play from iPod 35
play from PC 37
play USB storage device 32
power settings 41
predenedsoundmode 38
preference 39
R
region codes 43
remote control 19
repeat 32
S
shufe 32
sleep timer 41
slide animation 33
software update 42
software version 42
sound 38
speaker position 22
speaker setup 25
speakerspecications 43
subtitle language 39
subtitle position 40
surround sound 38
synchronize picture and sound 29
T
troubleshooting (network) 49
troubleshooting (picture) 47
troubleshooting (play) 48
troubleshooting (sound) 47
tuning grid 34
U
update software (through Internet) 43
USB storage device 32
user manual 18
V
VCD 40
video connection (composite video) 24
video connection (HDMI ARC) 23
video connection (standard HDMI) 23
video formats 46
video options 32
video settings 40
VOD code (DivX) 32
W
watch 3D 29
wired network 27
wireless network 27
HTB5544D_F7_UM_V1.0.indb 55 2013/5/24 11:46:50
56
P&F USA Inc. PO Box 2248 Alpharetta, GA 30023-2248
ONE (1) YEAR LIMITED WARRANTY
WARRANTY COVERAGE:
This warranty obligation is limited to the terms set forth
below.
WHO IS COVERED:
This product is warranted to the original purchaser or the per-
son receiving the product as a gift against defects in materials and
workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original
sales receipt showing the product name and the purchase date
from an authorized retailer is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material
or workmanship occurs and a valid claim is received within
the Warranty Period. At its option, the company will either (1)
repair the product at no charge, using new or refurbished
replacement parts, or (2) exchange the product with a product
that is new or which has been manufactured from new, or ser-
viceable used parts and is at least functionally equivalent or most
comparable to the original product in current inventory,
or (3) refund the original purchase price of the product.
The company warrants replacement products or parts provided
under this warranty against defects in materials and workmanship
from the date of the replacement or repair for ninety (90) days
or for the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product or
part is exchanged, any replacement item becomes your property
and the replaced item becomes the company property. When a
refund is given, your product becomes the company property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements
can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMI-
TATIONS:
This Limited Warranty applies only to the new products that
can be identified by the trademark, trade name, or logo affixed
to it. This Limited Warranty does not apply to any non-Philips
hardware product or any software, even if packaged or sold
with the product. Non-Philips manufacturers, suppliers, or
publishers may provide a separate warranty for their own
products packaged with the bundled product.
The company is not liable for any damage to or loss of any ,
programs data, or other information stored on any media
contained within the product, or any non-Philips product or part
not covered by this warranty. Recovery or reinstallation of
programs, data or other information is not covered under this
Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-Philips product, (b)
to damage caused by service performed by anyone other than
an Authorized Service Location, (c) to a product or
a part that has been modified without written permission,
or (d) if any serial number has been removed or defaced,
or (e) product, accessories or consumables sold “AS IS”
without warranty of any kind by including refurbished Philips
product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
• Shipping charges to return defective product.
• Labor charges for installation or setup of the product, adjust-
ment of customer controls on the product, and installation or
repair of antenna/signal source systems outside of the product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary con-
tent for extended periods, product cosmetic appearance items
due to normal wear and tear, unauthorized repair or other
cause not within the control of the company.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage from mishandled shipments or transit accidents when
returning product.
• A product that requires modification or adaptation to enable
it to operate in any country other than the country for which
it was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE IN THE U.S.A., CANADA,
PUERTO RICO, OR U.S. VIRGIN ISLANDS…
Contact Customer Care Center at:
1-866-310-0744
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CON-
SUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDEN-
TAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD-
UCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
Some states do not allow the exclusions or limitation of inciden-
tal or consequential damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or exclusions may
not apply to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
HTB5544D_F7_UM_V1.0.indb 56 2013/5/24 11:46:50
Specifications are subject to change without notice
© 2013 Koninklijke Philips Electronics N.V.
All rights reserved.
HTB5544D_F7_UM_V1.0
P&F USA, Inc.
PO Box 2248 Alpharetta, GA 30023-2248
HTB5544D_F7_UM_V1.0.indb 152 2013/5/24 11:47:22
