6.0 cu. ft. Double Oven Gas Range
WGG745S0F
Key Features & Benefits
Capacity
Upper Oven 2.1 cu. ft.
Lower Oven 3.9 cu. ft.
General Features & Properties
SpeedHeat
™
Burner
Center Oval Burner
Convection Conversion
Temperature Sensor
Rapid Preheat (Lower Oven Only)
SteamClean Option
6.0 cu. ft. Capacity
Dishwasher-Safe Knobs
Electrical Details
Amps 15
Volts 120
Certifications
ADA Compliant Yes
Star-K Certied/Kosher Yes
Technical Details
Fuel Type Gas
Range Type
Freestanding
Double Oven
Oven Cooking System
Upper—
Thermal
Lower—True
Convection
Number of Oven Racks
Up p e r—1
Lower—2
Cleaning Type Self-Cleaning
Number of Burners 5
Burner Type
Sealed
Burners
Burner Power
(2) 5000 BTU
(1) 7350 BTU
(1) 10,000 BTU
(1) 16,000 BTU
Dimensions
Product Dimensions
(H x W x D)
47-1/8" x
29-15/16" x
28-1/2"
Depth with Door Open 90° 46"
Reference Material
Dimension Guide
Install Guide
Use & Care Guide
Warranty
Stainless Steel
WGG745S0FS
Also available in:
White Ice
WGG745S0FH
Black Ice
WGG745S0FE
Frozen Bake
™
Technology
Cook frozen favorites faster with
preprogrammed settings that automatically
adjust cooking times.
EZ-2-Lift
™
Hinged Cast-Iron Grates
Wipe up the cooktop without removing the
grates thanks to a hinged design that makes
cleaning simple.
True Convection Cooking
Cooks foods fast by using a third element
plus a fan to distribute hot air evenly over,
under and around food.
NOTE: Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specications subject to
change without notice.
