OWNER’S MANUAL
LED LCD TV
Please read this manual carefully before operating your set and retain it
for future reference.
P/NO : MFL67468132 (1202-REV02)
LM6200 series
LM6210 series
LM6250 series
LM6400 series
LM6450 series
LM6700 series
LM7600 series
MFL67468132_00.indb 1 2012-02-07 �� 1:40:18
2
ENG
ENGLISH
LICENSES
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
ABOUT DIVX VIDEO: DivX
®
is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified
®
device that plays
DivX video. Visit divx.com for more information and software tools to convert your
files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified
®
device must be registered
in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section in your device setup menu. Go to
vod.divx.com for more information on how to complete your registration.
“DivX Certified
®
to play DivX
®
video up to HD 1080p, including premium content.”
“DivX
®
, DivX Certified
®
and associated logos are trademarks of Rovi Corporation
or its subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274”
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380;
6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol
& DTS and the Symbol together are registered trademarks & DTS 2.0+Digital
Out is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights
Reserved.
MFL67468132_00.indb 2 2012-02-07 �� 1:40:19
3
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak performance
of your product.
TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be
of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
- TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
WARNING/CAUTION
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a dry cloth.
Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet (Can differ by country).
MFL67468132_00.indb 3 2012-02-07 �� 1:40:20
4
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
Only use attachments/accessories specified
by the manufacturer.
Use only with a cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Unplug this apparatus during lightning
storms or when unused for long periods of
time.
Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Never touch this apparatus or antenna during
a thunder or lightning storm.
When mounting a TV on the wall, make sure
not to install the TV by hanging the power
and signal cables on the back of the TV.
Do not allow an impact shock or any objects
to fall into the product, and do not drop
anything onto the screen.
Keep the packing anti-moisture material or
vinyl packing out of the reach of children.
Anti-moisture material is harmful if
swallowed. If swallowed by mistake, force
the patient to vomit and visit the nearest
hospital. Additionally, vinyl packing can
cause suffocation. Keep it out of the reach of
children.
CAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be
placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that
appliance and has no additional outlets or
branch circuits. Check the specification page
of this owner’s manual to be certain. Do not
connect too many appliances to the same
AC power outlet as this could result in fire or
electric shock. Do not overload wall outlets.
Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your appliance, and
if its appearance indicates damage or
deterioration, unplug it, discontinue use of
the appliance, and have the cord replaced
with an exact replacement part by an
authorized service. Protect the power cord
from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where
the cord exits the appliance. Do not move
the TV with the power cord plugged in. Do
not use a damaged or loose power cord. Be
sure do grasp the plug when unplugging the
power cord. Do not pull on the power cord
to unplug the TV.
MFL67468132_00.indb 4 2012-02-07 �� 1:40:22
5
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
Do not stick metal objects or any other
conductive material into the power cord. Do
not touch the end of the power cord while it
is plugged in.
Warning
- To reduce the risk of fire or
electrical shock, do not expose this product
to rain, moisture or other liquids. Do not
touch the TV with wet hands. Do not install
this product near flammable objects such
as gasoline or candles, or expose the TV to
direct air conditioning.
Do not expose to dripping or splashing and
do not place objects filled with liquids, such
as vases, cups, etc. on or over the apparatus
(e.g. on shelves above the unit).
Grounding
(Except for devices which are not grounded.)
Ensure that you connect the earth ground
wire to prevent possible electric shock
(i.e. a TV with a three-prong grounded AC
plug must be connected to a three-prong
grounded AC outlet). If grounding methods
are not possible, have a qualified electrician
install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone
wires, lightening rods, or gas pipes.
Short-circuit Breaker
Power Supply
DISCONNECTING DEVICE FROM MAINS
Mains plug is the disconnecting device. The
plug must remain readily operable.
As long as this unit is connected to the AC
wall outlet, it is not disconnected from the
AC power source even if the unit is turned
off.
Do not attempt to modify this product in any
way without written authorization from LG
Electronics. Unauthorized modification could
void the user’s authority to operate this
product.
ANTENNAS Outdoor antenna grounding
(Can differ by country):
If an outdoor antenna is installed, follow
the precautions below. An outdoor antenna
system should not be located in the vicinity
of overhead power lines or other electric light
or power circuits, or where it can come in
contact with such power lines or circuits as
death or serious injury can occur. Be sure the
antenna system is grounded so as to provide
some protection against voltage surges
and built-up static charges. Section 810 of
the National Electrical Code (NEC) in the
U.S.A. provides information with respect to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
NEC: National Electrical Code
Ground Clamp
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Electric Service
Equipment
Ground Clamp
Cleaning
When cleaning, unplug the power cord and
wipe gently with a soft cloth to prevent
scratching. Do not spray water or other
liquids directly on the TV as electric shock
may occur. Do not clean with chemicals
such as alcohol, thinners or benzine.
Moving
Make sure the product is turned off,
unplugged and all cables have been
removed. It may take 2 or more people to
carry larger TVs. Do not press or put stress
on the front panel of the TV.
MFL67468132_00.indb 5 2012-02-07 �� 1:40:23
6
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
Ventilation
Install your TV where there is proper
ventilation. Do not install in a confined
space such as a bookcase. Do not cover the
product with cloth or other materials while
plugged. Do not install in excessively dusty
places.
If you smell smoke or other odors coming
from the TV, unplug the power cord and
contact an authorized service center.
Do not press strongly upon the panel with
your hand or a sharp object such as a nail,
pencil or pen, or make a scratch on it.
Keep the product away from direct sunlight.
Dot Defect
The Plasma or LCD panel is a high
technology product with resolution of two
million to six million pixels. In a very few
cases, you could see fine dots on the screen
while you’re viewing the TV. Those dots
are deactivated pixels and do not affect the
performance and reliability of the TV.
Generated Sound
“Cracking” noise: A cracking noise that
occurs when watching or turning off the TV
is generated by plastic thermal contraction
due to temperature and humidity. This noise
is common for products where thermal
deformation is required.
Electrical circuit humming/panel buzzing: A
low level noise is generated from a high-
speed switching circuit, which supplies a
large amount of current to operate a product.
It varies depending on the product.
This generated sound does not affect the
performance and reliability of the product.
Take care not to touch the ventilation
openings. When watching the TV for a long
period, the ventilation openings may become
hot. This does not affect the performance of
the product or cause defects in the product
If the TV feels cold to the touch, there may
be a small “flicker” when it is turned on. This
is normal, there is nothing wrong with TV.
Some minute dot defects may be visible on
the screen, appearing as tiny red, green, or
blue spots. However, they have no adverse
effect on the TV’s performance. Avoid
touching the LCD screen or holding your
finger(s) against it for long periods of time.
Doing so may produce some temporary
distortion effects on the screen.
DISPOSAL (Hg lamp only used in LCD TVs)
The fluorescent lamp used in this product contains
a small amount of mercury. Do not dispose of this
product with general household waste. Disposal of
this product must be carried out in accordance to
the regulations of your local authority.
Preventing “Image burn” or “Burn-in” on your TV screen
If a fixed image displays on the TV screen for
a long period of time, it will be imprinted and
become a permanent disfigurement on the
screen. This is “image burn” or “burn-in” and
not covered by the warranty.
If the aspect ratio of the TV is set to 4:3 for a
long period of time, image burn may occur on
the letterboxed area of the screen.
Avoid displaying a fixed image on the TV screen
for a long period of time (2 or more hours for
LCD, 1 or more hours for the Plasma TV) to
prevent image burn.
For USA and Canada
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the
National Electric Code (U.S.A.). The code provides
guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected
to the grounding system of the building, as close
to the point of the cable entry as practical.
MFL67468132_00.indb 6 2012-02-07 �� 1:40:23
7
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
Viewing 3D Imaging (For 3D models)
WARNING
Viewing Environment
Viewing Time
- When watching 3D contents, take 5 - 15 minute breaks every hour. Viewing 3D contents for a long
period of time may cause headache, dizziness, fatigue or eye strain.
Viewing Age
Infants / Children
- Usage/ Viewing 3D contents for children under the age of 5 are prohibited.
- Children under the age of 10 may overreact and become overly excited because their vision is in
development (for example: trying to touch the screen or trying to jump into it. Special monitoring and
extra attention is required for children watching 3D contents.
- Children have greater binocular disparity of 3D presentations than adults because the distance
between the eyes is shorter than one of adults. Therefore they will perceive more stereoscopic depth
compared to adults for the same 3D image.
Teenagers
- Teenagers under the age of 19 may be stimulated to light coming from 3D videos. Advise them not to
watch 3D videos for a long time when they are tired.
Elderly
- The elderly may perceive less of a 3D effect than the youth. Do not sit closer to the TV than the
recommended distance.
Those that have a photosensitive seizure or chronic illness
Some users may experience a seizure or other abnormal symptoms when they are exposed to a
flashing light or particular pattern from 3D contents.
Do not watch 3D videos if you feel nausea, are pregnant and/ or have a chronic illness such as
epilepsy, cardiac disorder, or blood pressure disease, etc.
3D Contents are not recommended to those who suffer from stereo blindness or stereo anomaly.
Double images or discomfort in viewing may be experienced.
If you have strabismus (cross-eyed), amblyopia (weak eyesight) or astigmatism, you may have trouble
sensing depth and easily feel fatigue due to double images. It is advised to take frequent breaks than
the average adult.
If your eyesight varies between your right and left eye, revise your eyesight prior to watching 3D
contents.
Symptoms which require discontinuation or refraining from watching 3D contents
Do not watch 3D contents when you feel fatigue from lack of sleep, overwork or drinking.
When these symptoms are experienced, stop using/watching 3D contents and get enough rest until
the symptom subsides.
- Consult your doctor when the symptoms persist. Symptoms may include headache, eyeball pain,
dizziness, nausea, palpitation, blurriness, discomfort, double image, visual inconvenience or fatigue.
MFL67468132_00.indb 7 2012-02-07 �� 1:40:23
8
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
Viewing Environment
Viewing Distance
- Maintain a distance of at least twice the screen diagonal length when watching 3D contents. If you
feel discomfort in viewing 3D contents, move further away from the TV.
Viewing Position (Only for SG Mode)
- Face the center of the screen at eye level with the head looking straight ahead. Otherwise, you may
not be able to view 3D contents properly.
Cautions when using the 3D glasses
Make sure to use LG 3D glasses. Otherwise, you may not be able to view 3D videos properly.
Do not use 3D glasses instead of your normal glasses, sunglasses or protective goggles.
Using modified 3D glasses may cause eye strain or image distortion.
Do not keep your 3D glasses in extremely high or low temperatures. It will cause deformation.
The 3D glasses are fragile and are easy to be scratched. Always use a soft, clean piece of cloth when
wiping the lenses. Do not scratch the lenses of the 3D glasses with sharp objects or clean/wipe
them with chemicals.
When watching 3D videos under fluorescent lights or with three wave length lamps, you may
experience the screen blinking. When this occurs, turn the light off or turn it down. (Only for SG
mode)
Other electronic or communication devices should be turned off or put away from the TV because it
can cause interference and prevent the 3D function from working properly. (Only for SG mode)
When you watch TV lying down, 3D images may look darker or invisible. (Only for SG mode)
MFL67468132_00.indb 8 2012-02-07 �� 1:40:23
9
ENG
ENGLISH
TABLE OF CONTENTS
TABLE OF CONTENTS
2 LICENSES
3 IMPORTANT SAFETY INSTRUCTIONS
7 Viewing 3D Imaging (For 3D models)
9 TABLE OF CONTENTS
10 INSTALLATION PROCEDURE
10 ASSEMBLING AND PREPARING
10 Unpacking
12 Optional Extras
13 Parts and buttons
15 Lifting and moving the TV
16 Setting up the TV
16 - Attaching the stand
17 - Mounting on a table
18 - Mounting on a wall
19 - Tidying cables
20 MAKING CONNECTIONS
20 Connecting to an antenna or cable
21 Connecting to a HD receiver, DVD, or VCR
player
21 - HDMI Connection
22 - DVI to HDMI Connection
23 - Component Connection
24 - Composite Connection
25 Connecting to a PC
25 - HDMI Connection, DVI to HDMI Connec-
tion or RGB Connection
27 Connecting to an Audio System
27 - Digital Optical Audio Connection
28 Connecting to a USB
29 REMOTE CONTROL
29 Magic Remote Control Functions
30 - Registering Magic Remote Control
30 - How to use Magic Remote Control
30 - Precautions to Take when Using the
Magic Remote Control
31 WATCHING TV
31 Turning the TV on for the first time
32 USING THE USER GUIDE
33 TROUBLESHOOTING
33 OPEN SOURCE SOFTWARE NOTICE
34 SPECIFICATIONS
40 MAINTENANCE
40 Cleaning Your TV
40 - Screen, frame, cabinet and stand
40 - Power cord
NOTE
Image shown may differ from your TV.
Your TV’s OSD (On Screen Display) may
differ slightly from that shown in this manual.
The available menus and options may differ
from the input source or product model that
you are using.
New features may be added to this TV in the
future.
MFL67468132_00.indb 9 2012-02-07 �� 1:40:23
10
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
INSTALLATION PROCEDURE
1
Open the package and make sure all the accessories are included.
2
Attach the stand to the TV set.
3
Connect an external device to the TV set.
4
Make sure the network connection is available.
You can use the TV network functions only when the network connection is made.
NOTE
The items supplied with your product may vary depending on the model.
Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39
inches) thick and 18 mm (0.7 inches) width.
Use an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit
into your TV's USB port.
B
A
A
B
*A 10 mm (0.39 inches)
*B
18 mm (0.7 inches)
CAUTION
Do not use any unapproved items to ensure the safety and product life span.
Any damages or injuries by using unapproved items are not covered by the warranty.
In case of some models, the thin film on screen is a part of TV, So don’t take it off.
MFL67468132_00.indb 10 2012-02-07 �� 1:40:24
11
ENG
ENGLISH
ASSEMBLING AND PREPARING
Magic Remote Control,
Batteries (AA)
(See p.29)
Owner’s manual Cable holder
(Depending on model)
(See p.19)
Stand Screws
8 EA, M4 x 20
(See p.16)
Composite video cable
(See p.24)
Component video cable
(See p.23)
Cinema 3D Glasses
The number of 3D glasses
may differ depending on the
model or country.
Stand Body
(See p.16)
Stand Base
(See p.16)
Polishing cloth
(Depending on model)
Use this to remove dust
from the cabinet.
Power Cord
(Depending on model)
Wall mount inner spacers
4 EA
(Depending on model)
(See p.19)
Desk-mount Screw
2 EA
(Depending on model)
(See p.17)
Bracket Screw
M4 x 8, 2 EA
(Depending on model)
Desk-mount Cable
2 EA
(Depending on model)
MFL67468132_00.indb 11 2012-02-07 �� 1:40:25
12
ENG
ENGLISH
ASSEMBLING AND PREPARING
AG-F3**
Cinema 3D Glasses
The model name
or design may be
changed manufacturer’s
circumstances or policies.
AN-MR300
Magic Remote Control
Optional Extras
Optional extras can be changed or modified for quality improvement without any notification.
Contact your dealer to buy these items.
These devices only work with certain models.
MFL67468132_00.indb 12 2012-02-07 �� 1:40:25
13
ENG
ENGLISH
ASSEMBLING AND PREPARING
Parts and buttons
LAN
(PC)
RGB IN
(RGB/HDMI-PC)
AUDIO
IN IN OUT
OPTICAL
DIGITAL
AUDIO
H/P
IN/OUT
(RGB)
AV1
IN
HDD IN USB Hub
USB Appps
USB IN
11(ARC) 2 3 4(PC) 2
USB IN
3
ANTENNA
/CABLE
13/18V
700mA MAx
LNB IN
Satellite
IN
COMPONENT
AV
PR
PB Y
VIDEO
AUDIO
SETTINGS
INPUT
OK
Speakers
Screen
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
Buttons
Power indicator
Remote control and
intelligent sensors
1
Button Description
^
v
Scrolls through the saved channels.
+ - Adjusts the volume level.
✔
OK Selects the highlighted menu option or confirms an input.
S
SETTINGS Accesses the main menu, or saves your input and exits the menus.
INPUT
Changes the input source.
( / I)
Turns the power on or off.
For LM6400/6450/6700/7600 series
MFL67468132_00.indb 13 2012-02-07 �� 1:40:26
14
ENG
ENGLISH
ASSEMBLING AND PREPARING
SETTINGS
INPUT
OK
Speakers
Screen
Touch buttons
2
Power indicator
Remote control and
intelligent sensors
1
For LM6200/6210/6250 series
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
Touch Button Description
H
Scrolls through the saved channels.
H
Adjusts the volume level.
OK
⊙
Selects the highlighted menu option or confirms an input.
SETTINGS Accesses the main menu, or saves your input and exits the menus.
INPUT Changes the input source.
/
I
Turns the power on or off.
MFL67468132_00.indb 14 2012-02-07 �� 1:40:26
15
ENG
ENGLISH
ASSEMBLING AND PREPARING
Lifting and moving the TV
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for safe transportation regardless of
its type and size.
CAUTION
Avoid touching the screen at all times, as
this may result in damage to the screen.
It is recommended to move the TV in the
box or packing material that the TV originally
came in.
Before moving or lifting the TV, disconnect
the power cord and all cables.
When holding the TV, the screen should face
away from you to avoid damage.
Hold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
When transporting a large TV, there should
be at least 2 people.
When transporting the TV by hand, hold the
TV as shown in the following illustration.
When transporting the TV, do not expose the
TV to jolts or excessive vibration.
When transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.
MFL67468132_00.indb 15 2012-02-07 �� 1:40:27
16
ENG
ENGLISH
ASSEMBLING AND PREPARING
Setting up the TV
Put your TV on a pedestal stand and mount the TV on a table or wall.
Attaching the stand
3
2
4
5
CAUTION
When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
Tighten the screws firmly to prevent the
TV from tilting forward.
1
Front
M4 x 20
4 EA
Stand Body
Stand Base
Top View
Protection pad
(Depending on model)
M4 x 20
4 EA
Wrapping bag (Depending on model)
MFL67468132_00.indb 16 2012-02-07 �� 1:40:28
17
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a table
1
Lift and tilt the TV into its upright position on a
table.
- Leave a 10 cm (4 inches) (minimum) space
from the wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
(4 inches)
2
Connect the power cord to a wall outlet.
CAUTION
Do not place the TV near or on sources
of heat, as this may result in fire or other
damage.
Securing the TV to a table
(Depending on model)
Fix the TV to a table to prevent from tilting
forward, damage, and potential injury.
1
Connect the Desk-mount Cables to the Stand
Base using the Bracket Screws.
2
Fix the Desk-mount Cables to a table using the
Desk-mount Screws.
3
Once the TV is fixed, move the table close to
the wall. Children may go in, causing injuries.
M4 x 8
2 EA
WARNING
To prevent TV from falling over, the TV
should be securely attached to the floor/wall
per installation instructions. Tipping, shaking,
or rocking the TV may cause injury.
Adjusting the angle of the TV to suit view
Swivel 10±2 degrees to the left or right and adjust
the angle of the TV to suit your view.
10 210 2
NOTE
When adjusting the angle of the TV, watch
out for your fingers.
»
Personal injury may occur if hands or fingers are
pinched. If the product is tilted too much, it may fall,
causing damage or injury.
MFL67468132_00.indb 17 2012-02-07 �� 1:40:29
18
ENG
ENGLISH
ASSEMBLING AND PREPARING
Securing the TV to a wall (optional)
1
Insert and tighten the eye-bolts, or TV brackets
and bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts
position, remove the bolts first.
2
Mount the wall brackets with the bolts to the
wall.
Match the location of the wall bracket and the
eye-bolts on the rear of the TV.
3
Connect the eye-bolts and wall brackets tightly
with a sturdy rope.
Make sure to keep the rope horizontal with the
flat surface.
CAUTION
Make sure that children do not climb on or
hang on the TV.
NOTE
Use a platform or cabinet that is strong and
large enough to support the TV securely.
Brackets, bolts and ropes are optional. You
can obtain additional accessories from your
local dealer.
Mounting on a wall
Attach an optional wall mount bracket at the rear
of the TV carefully and install the wall mount
bracket on a solid wall perpendicular to the
floor. When you attach the TV to other building
materials, please contact qualified personnel.
LG recommends that wall mounting be performed
by a qualified professional installer.
10 cm
10 cm
10 cm
10 cm
(4 inches)
Make sure to use screws and wall mount
bracket that meet the VESA standard. Standard
dimensions for the wall mount kits are described
in the following table.
Model 32/37LM6200
42/47/55LM6200
42/47/55LM6250
47/55LM6400
60LM6450
42/47/55LM6700
47/55LM7600
VESA 200 x 200 400 x 400
Standard screw M6 M6
Number of screws 4 4
Wall mount bracket
(optional)
LSW200BX,
LSW200BXG
LSW400BX,
LSW400BXG
MFL67468132_00.indb 18 2012-02-07 �� 1:40:30
19
ENG
ENGLISH
ASSEMBLING AND PREPARING
CAUTION
Disconnect the power first, and then move
or install the TV. Otherwise electric shock
may occur.
If you install the TV on a ceiling or slanted
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and contact
the local dealer or qualified personnel.
Do not over tighten the screws as this may
cause damage to the TV and void your
warranty.
Use the screws and wall mounts that meet
the VESA standard. Any damages or injuries
by misuse or using an improper accessory
are not covered by the warranty.
NOTE
Use the screws that are listed on the VESA
standard screw specifications.
The wall mount kit includes an installation
manual and necessary parts.
The wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
The length of screws may differ depending
on the wall mount. Make sure to use the
proper length.
For more information, refer to the manual
supplied with the wall mount.
When attaching a third-party wall mounting
bracket to the TV, insert the wall mount
inner spacers into the TV wall mount holes
to move your TV in vertical angle. Please
make sure not to use the spacers for LG wall
mounting bracket.
Wall Mount Inner Spacer
Tidying cables
1
Gather and bind the cables with the cable
holder.
Cable holder
2
Fix the cable management clip firmly to the TV.
Cable management clip
Do not move the TV by holding the cable
holder and power cord holder, as the cable
holders may break, and injuries and damage
to the TV may occur.
CAUTION
MFL67468132_00.indb 19 2012-02-07 �� 1:40:31
20
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to an antenna or cable
Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations may
differ from the actual items and a RF cable is optional.
NOTE
Use a signal splitter to use more than 2 TVs.
Visit http://lgknowledgebase.com for more
information about the antenna and cable
connection. Search for antenna.
CAUTION
Make sure not to bend the copper wire of
the RF cable.
Copper wire
Complete all connections between devices,
and then connect the power cord to the
power outlet to prevent damage to your TV.
ANTENNA / CABLE
VHF Antenna
UHF Antenna
Antenna
Terminal
Coaxial (75Ω)
MAKING CONNECTIONS
Connect various external devices to the TV and switch input modes to select an external device. For more
information on external device’s connection, refer to the manual provided with each device.
Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC,
gaming devices, and other external devices.
NOTE
If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input cable
to the TV through a DVD recorder or VCR. For more information on recording, refer to the manual
provided with the connected device.
The external device connection may differ from the model.
Connect external devices to the TV regardless of the order of the TV port.
If you connect a gaming device to the TV, use the cable supplied with the gaming device.
Refer to the external equipment’s manual for operating instructions.
MFL67468132_00.indb 20 2012-02-07 �� 1:40:31
21
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to a HD receiver, DVD, or VCR player
Connect a HD receiver, DVD, or VCR player to the TV and select an appropriate input mode.
HDMI Connection
HDMI is the best way to connect a device.
Transmits the digital video and audio signals from an external device to the TV. Connect the external device
and the TV with the HDMI cable as shown in the following illustration.
NOTE
Use the latest High Speed HDMI™ Cable with CEC (Customer Electronics Control) function.
High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.
ARC (Audio Return Channel)
When connected with a high-speed
HDMI cable, digital audio can be sent to a
compactible device without an additional
optical audio cable.
ARC is only supported on the HDMI input
1 (ARC) port. An external audio device that
supports ARC should be connected to
HDMI 1 if you wish to use ARC.
HDMI
2 3 1
(ARC)
4
(PC)
IN
DVD/ Blu-Ray / HD Cable Box / HD STB
Choose any HDMI input port to connect.
It does not matter which port you use.
(*Not Provided)
NOTE
DTV Audio Supported Codec: MPEG, Dolby
Digital
HDMI Audio Supporeted Format: Dolby
Digital, PCM (Up to 192 KHz, 32k/44.1k/48k/
88k/96k/176k/192k) -> Not supported DTS.
MFL67468132_00.indb 21 2012-02-07 �� 1:40:32
22
ENG
ENGLISH
MAKING CONNECTIONS
AUDIO OUT
DVI OUT
4
(PC)
IN
(RGB/HDMI-PC)
AUDIO
(RGB/HDMI-PC)
AUDIO
DVI to HDMI Connection
Transmits the digital video signal from an external device to the TV. Connect the external device and the
TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an
audio cable.
(*Not Provided)
(*Not Provided)
DVD/ Blu-Ray / HD Cable Box
MFL67468132_00.indb 22 2012-02-07 �� 1:40:32
23
ENG
ENGLISH
MAKING CONNECTIONS
VIDEO
AUDIO
L R
IN
COMPONENT
AV
PR
PB Y
AUDIO
VIDEO
Component Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external device
and the TV with a component cable as shown in the following illustration.
NOTE
If cables are installed incorrectly, it could cause the image to display in black and white or with
distorted color.
Check to ensure each cable is matched with the corresponding color connection.
DVD/ Blu-Ray / HD Cable Box
(*Not Provided)
(*Not Provided)
GREEN
RED
BLUE
GREEN
RED
BLUE
GREEN
RED
BLUE
WHITE
RED
YELLOW
WHITE
RED
WHITE
RED
(Use the composite video cable provided.)
(Use the component video cable provided.)
GREENYELLOW
MFL67468132_00.indb 23 2012-02-07 �� 1:40:32
24
ENG
ENGLISH
MAKING CONNECTIONS
Composite Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external device
and the TV with the composite cable as shown in the following illustration.
NOTE
Check to ensure each cable is matched with the corresponding color connection.
VIDEO
MONO
( )
AUDIOL R
IN
COMPONENT
AV
PR
P
B
Y
AUDIO
VIDEO
VCR / DVD/ Blu-Ray / HD Cable Box
(*Not Provided)
YELLOW
WHITE
RED
YELLOW
WHITE
RED
YELLOW
WHITE
RED
(Use the composite video cable provided.)
YELLOW
MFL67468132_00.indb 24 2012-02-07 �� 1:40:32
25
ENG
ENGLISH
MAKING CONNECTIONS
RGB OUT (PC)
AUDIO OUT
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
HDMI
AUDIO OUT
DVI OUT
2 3 1
(ARC)
4
(PC)
IN
4
(PC)
IN
(RGB/HDMI-PC)
AUDIO
(RGB/HDMI-PC)
AUDIO
Connecting to a PC
NOTE
It is recommended to use the HDMI connection for the best image quality.
Depending on the graphics card, DOS mode video may not work if a HDMI to DVI Cable is in use.
In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or
brightness. If noise is present, change the PC output to another resolution, change the refresh rate to
another rate or adjust the brightness and contrast on the PICTURE menu until the picture is clear.
The synchronization input form for Horizontal and Vertical frequencies is separate.
Depending on the graphics card, some resolution settings may not allow the image to be positioned
on the screen properly.
HDMI Connection, DVI to HDMI Connection or RGB Connection
Choose method A, B, or C to make connection.
Method A: HDMI Connection
(*Not Provided)
PC
Choose any HDMI input port to connect.
It is recommended to connect the DVI-HDMI
to HDMI IN 4.
MFL67468132_00.indb 25 2012-02-07 �� 1:40:33
26
ENG
ENGLISH
MAKING CONNECTIONS
Method B: DVI to HDMI Connection
Method C: RGB Connection
RGB OUT (PC)
AUDIO OUT
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
HDMI
AUDIO OUT
DVI OUT
2 3 1
(ARC)
4
(PC)
IN
4
(PC)
IN
(RGB/HDMI-PC)
AUDIO
(RGB/HDMI-PC)
AUDIO
(*Not Provided)
(*Not Provided)
PC
RGB OUT (PC)
AUDIO OUT
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
(PC)
RGB
(RGB/HDMI-PC)
AUDIO
HDMI
AUDIO OUT
DVI OUT
2 3 1
(ARC)
4
(PC)
IN
4
(PC)
IN
(RGB/HDMI-PC)
AUDIO
(RGB/HDMI-PC)
AUDIO
(*Not Provided)
PC
(*Not Provided)
MFL67468132_00.indb 26 2012-02-07 �� 1:40:33
27
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to an Audio System
You may use an optional external audio system instead of the built-in speaker.
NOTE
If you use an optional external audio device instead of the built-in speaker, set the TV speaker feature
to off.
Digital Optical Audio Connection
Transmits a digital audio signal from the TV to an external device. Connect the external device and the TV
with the optical audio cable as shown in the following illustration.
NOTE
Do not look into the optical output port. Looking at the laser beam may damage your vision.
Audio with ACP (Audio Copy Protection) function may block digital audio output.
Digital Audio System
(*Not Provided)
OPTICAL AUDIO IN
OUT
OPTICAL
DIGITAL
AUDIO
MFL67468132_00.indb 27 2012-02-07 �� 1:40:34
28
ENG
ENGLISH
MAKING CONNECTIONS
USB Hub USB Apps
HDD IN
1
2
3
USB IN
USB
(*Not Provided)
Choose any USB input port to connect.
It does not matter which port you use.
Connecting to a USB
Connect a USB storage device such as a USB flash memory, external hard drive, or a USB memory card
reader to the TV and access the Smart Share menu to use various multimedia files.
NOTE
To store apps on a USB storage device, make sure that it is connected to the USB IN 3 USB Apps
port.
To use a USB Hub device, make sure that it is connected to the USB IN 2 USB port.
Some USB Hubs may not work. If a USB device connected using a USB Hub is not detected, connect
it to the USB port on the TV directly.
MFL67468132_00.indb 28 2012-02-07 �� 1:40:34
29
ENG
ENGLISH
REMOTE CONTROL
REMOTE CONTROL
Magic Remote Control Functions
When the message “Magic remote control battery is low. Change the battery.” is
displayed, replace the battery.
To replace batteries, open the battery cover, replace batteries (1.5 V AA) matching
and ends to the label inside the compartment, and close the battery cover. Be
sure to point the remote control at the remote control sensor on the TV.
To remove the batteries, perform the installation actions in reverse.
Do not mix old and new batteries, as this may damage the remote control.
CAUTION
Make sure to point the remote control at the remote control sensor on the TV.
(POWER
)
Turns the TV on or off.
Pointer (RF & Bluetooth transmitter)
Blinks the light when operating.
HOMEBACK
VOL CH
My APPS
HOME
Accesses the Home menu.
Navigation buttons
(up/down/left/right)
Scrolls through menus or options.
HOMEBACK
VOL CH
My APPS
BACK
Returns to the previous level.
+ VOL -
Adjusts the volume level.
^
CH
v
Scrolls through the saved channels.
HOMEBACK
VOL CH
My APPS
(MUTE)
Mutes all sounds.
HOMEBACK
VOL CH
My APPS
MY APPS
Shows the list of Apps.
Q.MENU
Accesses the quick menu.
Wheel (OK)
Selects menus or options and confirms
your input;
Scrolls through the saved channels.
If you press the navigation button while
moving the pointer on the screen,
the pointer disappears, and the Magic
remote control works as a regular
remote control.
To display the pointer again, shake the
Magic remote control from side to side.
3D
Uses for viewing 3D video.
1
If you press the
Wheel (OK)
button on the Magic
remote control, the following screen appears.
Shows information about the current program
and screen.
2
If you press the
Wheel (OK)
button on the Magic
remote control, the following screen appears.
Set the channel you want.
You can press the CH button on the remote
control to set the channel.
3
You can select My apps Menu.
11
-1
Brief Info Title Test...
Info.
ꘄ
11:40 AM
TV
i
1
2
3
MFL67468132_00.indb 29 2012-02-07 �� 1:40:35
30
ENG
ENGLISH
REMOTE CONTROL
Registering Magic Remote Control
The Magic remote Control operates by pairing with
your TV. Once you purchased the TV, please
register the Magic remote control as follows;
How to register the Magic Remote Control
HOMEBACK
VOL CH
My APPS
To register the remote control, press
the
Wheel (OK)
button on the remote
control.
How to Re-register the Magic Remote Control
after Registration Failure
BACK
HOMEBACK
VOL CH
My APPS
HOMEBACK
VOL CH
My APPS
HOME
1 Press and hold the
BACK
HOMEBACK
VOL CH
My APPS
and
HOME
HOMEBACK
VOL CH
My APPS
buttons together for 5
seconds to reset, then register it
by following “How to register the
Magic remote control” above. (Once
the reset is complete, the light on
the Pointer blinks.)
2 To re-register the Magic remote
control, press and hold the
BACK
HOMEBACK
VOL CH
My APPS
button for 5 seconds toward the TV.
(Once the reset is complete, the
light on the Pointer blinks.)
How to use Magic Remote
Control
1 If the pointer disappears, move
the remote control slightly to left
or right. Then, it will automatically
appear on the screen.
»
If the pointer has not been used
for a certain period of time, it
will disappear.
2 You can move the pointer by
aiming the Pointer Receiver of
the remote control at your TV
then move it left, right, up or
down.
»
If the pointer does not work
properly, leave the remote
control for 10 seconds then use
it again.
Precautions to Take when Using
the Magic Remote Control
Use the remote control within the maximum
communication distance (10 m, 32.8ft).
Using the remote control beyond this
distance, or with an object obstructing it,
may cause a communication failure.
A communication failure may occur due to
nearby devices. Electrical devices such as
a microwave oven or wireless LAN product
may cause interference, as these use the
same bandwidth (2.4 GHz) as the Magic
Remote Control.
The Magic Remote Control may be damaged
or may malfunction if it is dropped or
receives a heavy impact.
Take care not to bump into nearby furniture
or other people when using the Magic
Remote Control.
Manufacturer and installer cannot provide
service related to human safety as the
applicable wireless device has possibility of
electric wave interference.
It is recommended that an Access Point (AP)
be located more than 1 m (3.28 ft) away
from the TV. If the AP is installed closer than
1 m (3.28 ft), the magic remote control may
not perform as expected due to frequency
interference.
MFL67468132_00.indb 30 2012-02-07 �� 1:40:35
31
ENG
ENGLISH
WATCHING TV
NOTE
Select
Home*
when prompted.
Store*
mode puts the TV in demo mode.
If you select
Store*
, the any customized
settings will switch back to the default
settings of
Store*
in 5 minutes.
The Standby light feature is disabled in
Store Demo mode.
4
When the basic settings are complete,
press the
Wheel (OK)
button.
NOTE
If you do not complete the Initial setting,
it will appear whenever the TV turns on.
Disconnect the power cord from the
power outlet when you do not use the
TV for a long period of time.
5
To turn the TV off, press the power button on
the remote control.
WATCHING TV
Turning the TV on for the first
time
When you turn the TV on for the first time, the
Initial setting screen appears. Select a language
and customize the basic settings.
1
Connect the power cord to a power outlet.
2
In Standby mode, press the power button on
the remote control to turn the TV on.
The Initial setting screen appears if you turn
the TV on for the first time.
NOTE
You can also access
Initial Setting
by
accessing
OPTION
in the main menu.
3
Follow the on-screen instructions to customize
your TV settings according to your preferences.
Language Selection*
Selects a language to
display.
Using the Magic remote
control
Sets the Magic remote
contol.
Enviroment Selection
Select
Home*
for the
home environment.
Time Zone Setting
Selects the time zone
and daylight saving.
(Depending on country)
Network Connection
Sets your network to
enable network-related
features on the TV.
Auto Tuning
Scans and saves available
channels automatically.
Auto Energy Saving
mode Setting
Selects Auto Energy
Saving mode.
3D-On-Start Setting
Selects 3D-On-Start
option. (For 3D TV)
Setting is completed.
Confirms the setting
options.
MFL67468132_00.indb 31 2012-02-07 �� 1:40:35
32
ENG
ENGLISH
WATCHING TV
USING THE USER
GUIDE
User Guide allows you to more easily access the
detailed TV information.
1
Press the
HOME
button to access the HOME
menu.
2
Select User Guide and press the
Wheel (OK)
button.
Input List Settings Live TV
Search
Internet
3D
LG Smart W
TV Guide User Guide
Ch. List
User Guide
1
3
4
2
User Guide
OPTION
CHANNEL Setting
PICTURE,SOUND setting
Advanced Function
LG Smart Function
To use input device
To set time options
To set language
Disabled Assistance
To set Magic remote control
To set TV lock options
To use Energy Saving feature
Information
Index
1
Shows the current channel.
2
Allows to select the category you want.
3
Allows to select the item you want.
You can use
ꕌ
/
ꕍ
to move between pages.
4
Allows to browse the description of the
function you want from the index.
1
2
3
User Guide
CHANNEL Setting
PICTURE,SOUND setting
OPTION
Advanced Function
LG Smart Function
Information
Try Now
Close
Zoom In
3
Try Now
Close
Zoom Out
1
Shows the description of the selected menu.
You can use
ꕌ
/
ꕍ
to move between pages.
2
Moves to the selected menu directly from
the User Guide.
3
Zooms in or out the screen.
MFL67468132_00.indb 32 2012-02-07 �� 1:40:37
33
ENG
ENGLISH
TROUBLESHOOTING
TROUBLESHOOTING
General
Problem Solution
Cannot control the TV with the
remote control.
Check the remote control sensor on the product and try again.
Check if there is any obstacle between the product and the remote control.
Check if the batteries are still working and properly installed (
to , to ).
No image display and no sound is
produced.
Check if the product is turned on.
Check if the power cord is connected to a wall outlet.
Check if there is a problem in the wall outlet by connecting other products.
The TV turns off suddenly.
Check the power control settings. The power supply may be interrupted.
Check if the Auto sleep feature is activated in the Time settings.
If there is no signal while the TV is on, the TV will turn off automatically after
15 minutes of inactivity.
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of media, shipping and handling) upon email request to
[email protected]. This offer is valid for three (3) years from the date on which you purchased the
product.
MFL67468132_00.indb 33 2012-02-07 �� 1:40:37
34
ENG
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Power requirement USA, Canada, Mexico: AC 120 V ~ 50 / 60 Hz
Other Country: AC 100 - 240 V ~ 50 / 60 Hz
Television System NTSC-M, ATSC, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
External Antenna Impedance
75
Ω
Environment
condition
Operating
Temperature
0 - 40 °C
Operating Humidity Less than 80 %
Storage Temperature -20 - 60 °C
Storage Humidity Less than 85 %
MODELS
32LM6200
(32LM6200-UE)
Dimensions
(Width x Height x
Depth)
With stand 746.0 mm x 528.0 mm x 225.0 mm
(29.4 inch x 20.7 inch x 8.8 inch)
Without stand 746.0 mm x 462.0 mm x 35.5 mm
(29.4 inch x 18.2 inch x 1.4 inch)
Weight With stand 10.0 kg (22.0 lbs)
Without stand 8.5 kg (18.7 lbs)
Current Value / Power consumption 0.8 A / 80 W
MODELS
42LM6200
(42LM6200-UE)
47LM6200
(47LM6200-UE)
47LM6210
(47LM6250-UD)
47LM6250
(47LM6250-UD)
Dimensions
(Width x Height x
Depth)
With stand
979.0 mm x 670.0 mm x 263.0 mm
(38.5 inch x 26.3 inch x 10.3 inch)
1089.0 mm x 730.0 mm x 263.0 mm
(42.8 inch x 28.7 inch x 10.3 inch)
Without stand
979.0 mm x 594.0 mm x 35.5 mm
(38.5 inch x 23.3 inch x 1.3 inch)
1089.0 mm x 655.0 mm x 35.5 mm
(42.8 inch x 25.7 inch x 1.3 inch)
Weight With stand 15.3 kg (33.7 lbs) 17.8 kg (39.2 lbs)
Without stand 13.1 kg (28.8 lbs) 15.6 kg (34.3 lbs)
Current Value / Power consumption 1.0 A / 100 W 1.2 A / 120 W
MFL67468132_00.indb 34 2012-02-07 �� 1:40:37
35
ENG
ENGLISH
SPECIFICATIONS
MODELS
55LM6200
(55LM6200-UE)
55LM6210
(55LM6210-UD)
55LM6250
(55LM6250-UD)
Dimensions
(Width x Height x
Depth)
With stand
1263.0 mm x 830.0 mm x 331.0 mm
(49.7 inch x 32.6 inch x 13.0 inch)
Without stand
1263.0 mm x 754.0 mm x 35.5 mm
(49.7 inch x 29.6 inch x 1.3 inch)
Weight With stand 25.7 kg (56.6 lbs)
Without stand 21.9 kg (48.2 lbs)
Current Value / Power consumption 1.5 A / 150 W
MODELS
47LM6400
(47LM6400-UA)
55LM6400
(55LM6400-UA)
Dimensions
(Width x Height x
Depth)
With stand
1073.0 mm x 705.0 mm x 263.0 mm
(42.2 inch x 27.7 inch x 10.3 inch)
1263.0 mm x 830.0 mm x 331.0 mm
(49.7 inch x 32.6 inch x 13.0 inch)
Without stand
1073.0 mm x 639.0 mm x 35.2 mm
(42.2 inch x 25.1 inch x 1.3 inch)
1263.0 mm x 754.0 mm x 35.5 mm
(49.7 inch x 29.6 inch x 1.3 inch)
Weight With stand 16.8 kg (37.0 lbs) 25.7 kg (56.6 lbs)
Without stand 14.7 kg (32.4 lbs) 21.9 kg (48.2 lbs)
Current Value / Power consumption 1.1 A / 110 W 1.4 A / 140 W
MODELS
60LM6450
(60LM6450-UA)
Dimensions
(Width x Height x
Depth)
With stand 1391.0 mm x 889.0 mm x 315 mm
(54.7 inch x 35.0 inch x 12.4 inch)
Without stand 1391.0 mm x 821.0 mm x 43.2 mm
(54.7 inch x 32.3 inch x 1.7 inch)
Weight With stand 32.0 kg (70.5 lbs)
Without stand 28.2 kg (46.9 lbs)
Current Value / Power consumption 1.6 A / 160 W
MFL67468132_00.indb 35 2012-02-07 �� 1:40:37
36
ENG
ENGLISH
SPECIFICATIONS
MODELS
42LM6700
(42LM6700-UA)
47LM6700
(47LM6700-UA)
Dimensions
(Width x Height x
Depth)
With stand
953.0 mm x 636.0 mm x 263.0 mm
(37.5 inch x 25.0 inch x 10.3 inch)
1063.0 mm x 701.0 mm x 263.0 mm
(46.1 inch x 30.3 inch x 11.4 inch)
Without stand
953.0 mm x 566.0 mm x 33.4 mm
(37.5 inch x 22.2 inch x 1.3 inch)
1063.0 mm x 628.0 mm x 33.4 mm
(46.1 inch x 28.0 inch x 1.3 inch)
Weight With stand 14.8 kg (32.6 lbs) 17.5 kg (38.5 lbs)
Without stand 12.6 kg (27.7 lbs) 15.3 kg (33.7 lbs)
Current Value / Power consumption 1.0 A / 100 W 1.1 A / 110 W
MODELS
55LM6700
(55LM6700-UA)
Dimensions
(Width x Height x
Depth)
With stand 1232.0 mm x 795.0 mm x 331.0 mm
(48.5 inch x 31.2 inch x 13.0 inch)
Without stand 1232.0 mm x 723.0 mm x 33.6 mm
(48.5 inch x 28.4 inch x 1.3 inch)
Weight With stand 25.0 kg (55.1 lbs)
Without stand 21.3 kg (46.9 lbs)
Current Value / Power consumption 1.2 A / 120 W
MODELS
47LM7600
(47LM7600-UA)
55LM7600
(55LM7600-UA)
Dimensions
(Width x Height x
Depth)
With stand
1063.0 mm x 701.0 mm x 263.0 mm
(46.1 inch x 30.3 inch x 11.4 inch)
1232.0 mm x 795.0 mm x 331.0 mm
(48.5 inch x 31.2 inch x 13.0 inch)
Without stand
1063.0 mm x 628.0 mm x 33.4 mm
(46.1 inch x 28.0 inch x 1.3 inch)
1232.0 mm x 723.0 mm x 33.6 mm
(48.5 inch x 28.4 inch x 1.3 inch)
Weight With stand 17.5 kg (38.5 lbs) 25.0 kg (55.1 lbs)
Without stand 15.6 kg (34.3 lbs) 21.3 kg (46.9 lbs)
Current Value / Power consumption 1.3 A / 130 W 1.6 A / 160 W
MFL67468132_00.indb 36 2012-02-07 �� 1:40:38
37
ENG
ENGLISH
SPECIFICATIONS
Wireless LAN for Broadband/DLNA Adaptor SPEC
This device only works with compatible LG TV.
Standard
IEEE802.11a/b/g/n
Frequency Range
2402 to 2483 MHz
5150 to 5250 MHz
5725 to 5850 MHz
Modulation
CCK / OFDM / MIMO
Output Power
(Typical)
802.11a: 14 dBm
802.11b: 17 dBm
802.11g: 14 dBm
802.11n: 13 dBm
Data rate
802.11a/g: 54 Mbps
802.11b: 11 Mbps
802.11n: 300 Mbps
Antenna Gain
(Typical)
2402 to 2483 MHz: 1.17 dBi
5150 to 5250 MHz: 4.67 dBi
5725 to 5850 MHz: 3.30 dBi
Occupied bandwidth
802.11a/b/g: HT20
802.11n: HT20/40
Because band channel used by the country could
be different, the user can not change or adjust the
operating frequency and this product is set for the
regional frequency table.
FCC ID of Wi-Fi module inside TV
FCC ID: BEJTWFMB003D
RF module (BM-LDS302) specification
For TV By using a 2.4 GHz bandwidth radio
frequency(RF).
Output: 10 dBm or lower
Maximum Communication Distance: Line of
Open Sight approx. 10 m (30 ft)
Bandwidth: 2.4 GHz (2.400 GHz ~ 2.4835 GHz)
Transfer Rate: 3 Mbps
FCC ID of RF module inside TV
FCC ID: BEJLDS302
HDMI/DVI-DTV supported mode
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency
(Hz)
720X480
31.469
31.5
59.94
60
1280X720
44.96
45
59.94
60
1920X1080
33.72
33.75
26.97
27
33.716
33.75
67.43
67.5
59.94
60
23.97
24
29.976
30.00
59.94
60
Component port connecting information
Component ports on the
TV
Y P
B
P
R
Video output ports
on DVD player
Y P
B
P
R
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
Signal Component
480i O
480p O
720p/1080i O
1080p
O
(60 Hz only)
MFL67468132_00.indb 37 2012-02-07 �� 1:40:38
38
ENG
ENGLISH
SPECIFICATIONS
3D supported mode
Video, which is input as below media contents is switched into the 3D screen automatically.
The method for 3D digital broadcast may differ depending on the signal environment. If video is not
switched automatically into 3D, manually convert the settings to view 3D images.
3D supported mode automatically
Input
Signal
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Playable 3D video format
HDMI
640 X 480
31.469 / 31.5
59.94 / 60
Top & Bottom,
Side by Side(Half), Side by Side(Full)
62.938 / 63
Frame Packing, Line Alternative
480p
31.469 / 31.5
Top & Bottom,
Side by Side(Half), Side by Side(Full)
62.938 / 63
Frame Packing, Line Alternative
720p
44.96 / 45 59.94 / 60
Top & Bottom,
Side by Side(Half), Side by Side(Full)
89.91 / 90 59.94 / 60 Frame Packing, Line Alternative
1080i
33.72 / 33.75 59.94 / 60
Top & Bottom,
Side by Side(Half), Side by Side(Full)
67.5 59.94 / 60 Frame Packing, Line Alternative
1080p
26.97 / 27 23.97 / 24
Top & Bottom,
Side by Side(Half), Side by Side(Full)
28.125 25
33.72 / 33.75 29.976 / 30
43.94 / 54 23.97 / 24
Frame Packing, Line Alternative56.25 25
67.432 / 67.5 29.976 / 30
67.432 / 67.5 59.94 / 60
Top & Bottom, Side by Side(Half)
USB
1080p 33.75 30
Side by Side(Half), Top & Bottom,
Checker Board, MPO(Photo)
DLNA
1080p 33.75 30
Side by Side(Half), Top & Bottom,
Checker Board
Signal Playable 3D video format
DTV
Frame Compatible Side by Side(Half), Top & Bottom
MFL67468132_00.indb 38 2012-02-07 �� 1:40:38
39
ENG
ENGLISH
SPECIFICATIONS
For models supporting WiDi, you can set the 3D mode in the same way as in RGB (PC) mode.
3D supported mode manually
Input Signal
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Playable 3D video format
HDMI-DTV
720p 45.00 60
2D to 3D, Side by Side(Half), Top & Bottom,
Single Frame Sequential
1080i 33.75 60
2D to 3D, Side by Side(Half), Top & Bottom
1080p
27.00 24
2D to 3D, Side by Side(Half), Top & Bottom,
Checker Board
28.12 25
33.75 30
67.50 60
2D to 3D, Side by Side(Half), Top & Bottom,
Checker Board, Single Frame Sequential,
Row Interleaving, Column Interleaving
HDMI-PC
1024x768 48.36
60
2D to 3D, Side by Side(Half), Top & Bottom
1360x768 47.71
1920x1080 67.50
2D to 3D, Side by Side(Half), Top & Bottom,
Checker Board, Single Frame Sequential,
Row Interleaving, Column Interleaving
Others - -
2D to 3D
RGB-PC
1024x768 48.36
60
2D to 3D, Side by Side(Half), Top & Bottom
1360x768 47.71
1920x1080 67.50
Others - -
2D to 3D
Component
720p 45.00 60
2D to 3D, Side by Side(Half), Top & Bottom
1080i 33.75 60
1080p
27.00 24
28.12 25
33.75 30
67.50 60
Others - -
2D to 3D
USB
1080p 33.75 30
2D to 3D, Side by Side(Half),Top & Bottom,
Checker Board, Row Interleaving, Column
Interleaving(Photo : Side by Side(Half),
Top & Bottom)
DLNA
1080p 33.75 30
Signal
Playable 3D video format
DTV
HD
2D to 3D, Side by Side(Half), Top & Bottom
SD
2D to 3D
MFL67468132_00.indb 39 2012-02-07 �� 1:40:38
40
ENG
ENGLISH
MAINTENANCE
MAINTENANCE
Cleaning Your TV
Clean your TV regularly to keep the best
performance and to extend the product lifespan.
CAUTION
Make sure to turn the power off and
disconnect the power cord and all other
cables first.
When the TV is left unattended and unused
for a long time, disconnect the power cord
from the wall outlet to prevent possible
damage from lightning or power surges.
Screen, frame, cabinet and stand
To remove dust or light dirt, wipe the surface with
a dry, clean, and soft cloth.
To remove major dirt, wipe the surface with a
soft cloth dampened in clean water or a diluted
mild detergent. Then wipe immediately with a dry
cloth.
CAUTION
Do not push, rub, or hit the surface with
your fingernail or a sharp object, as this may
result in scratches on the screen and image
distortions.
Do not use any chemicals, such as waxes,
benzene, alcohol, thinners, insecticides, air
fresheners, lubricants, as these may damage
the screen’s finish and cause discoloration.
Do not spray liquid onto the surface. If water
enters the TV, it may result in fire, electric
shock, or malfunction.
Power cord
Remove the accumulated dust or dirt on the
power cord regularly.
MFL67468132_00.indb 40 2012-02-07 �� 1:40:38
MFL67468132_00.indb 41 2012-02-07 �� 1:40:38
MFL67468132_00.indb 42 2012-02-07 �� 1:40:38
CHILD SAFETY:
It Makes A Difference How and Where
You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product,
please keep these safety tips in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and
larger flat panel displays are popular purchases. However, flat panel
displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
Flat panel displays that are inappropriately situated on dressers,
bookcases, shelves, desks, speakers, chests or carts may fall over and
cause injury.
THIS MANUFACURER CARES!
The consumer electronics industry is committed to making home
entertainment enjoyable and safe.
TUNE INTO SAFETY
O n e s i z e do e s N O T f i t a l l . Fo l l o w t h e m a n u f a c t u r e r ’ s
recommendations for the safe installation and use of your flat panel
display.
Carefully read and understand all enclosed instructions for proper use
of this product.
Don’t allow children to climb on or play with furniture and television
sets.
Don’t allow place flat panel displays on furniture that can easily be
used as steps, such as a chest of drawers.
Remember that children can become excited while watching
a program, especially on a “larger than life” flat panel display.
Care should be taken to place or install the display where it cannot be
pushed, pulled over, or knocked down.
Care should be taken to route all cords and cables connected to the
flat panel display so that they cannot be pulled or grabbed by curious
children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT
YOUR FLAT PANEL DISPLAY, ALWAYS:
Use a mount tha t has been recommended by th e display
ma nufa cturer a nd/o r lis ted b y an i ndep endent labor ato ry
(such as UL, CSA, ETL).
Follow all instructions supplied by the display and wall mount
manufacturers.
If you have any doubts about your ability to safely install your flat
panel display, contact your retailer about professional installation.
Make sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted
to walls with steel studs or old cinder block construction.
If you are unsure, contact a professional installer.
A m i n imu m of t w o peo p l e are r equi r e d for i n sta l l a t i o n.
Flat panel displays can be heavy
MFL67468132_00.indb 43 2012-02-07 �� 1:40:38
The model and serial number of the TV is
located on the back and/or one side of the TV.
Record it below should you ever need service.
MODEL
SERIAL
This product qualifies for ENERGY STAR in the
“factory default (Home Use)” setting.
Changing the factory default settings or enabling other
features may increase power consumption that could
exceed the limits necessary to quality for ENERGY STAR.
1-800-243-0000
1-888-865-3026
1-888-542-2623
USA, Consumer User
USA, Commercial User
CANADA
Register your product Online!
LG Customer Information Center
For inquires or comments, visit www.lg.com or call;
(For LM6200/LM6700/LM7600 series USA, Canada, Mexico)
www.lg.com
MFL67468132_00.indb 44 2012-02-07 �� 1:40:39
