User Manual Frigidaire FGHB2866PE gallery 27.2 cu. ft. French Door Refrigerator

Most Multi-Door refrigerators are equipped with shelves that are supported at the back of the refrigerator.

To adjust your shelves, remove all items from shelf / shelves.

Lift the front edge up, pull the shelf out and replace the shelf by inserting the hooks at the rear of the shelf into the wall bracket.

Lower the shelf into the desired slot and lock into position Some models have glass shelves that slide out for easy access. The shelves slide out independently of their mounting brackets, just pull the front of the shelf forward. Shelves can be extended as far as the stopper will allow but are not removable from their mounting brackets.

Our door bins (vary by model) are removable for easy cleaning but some of them have fixed positions while others can be adjusted.

To change the position of an adjustable door bin simply remove all items from the bin, grip the bin firmly with both hands and lift it upward or side-to-side (depending on bin type). Next, remove the bin and place the bin just above the desired position.

Finally, lower the bin onto supports until it's locked in place and place bin liner into bin (if removed).

Most French-Door refrigerators are equipped with shelves that are supported at the back of the refrigerator. To adjust your shelves, remove all items from shelf / shelves and lift the front edge up. Next, pull the shelf out and replace the shelf by inserting the hooks at the rear of the shelf into the wall bracket. Lower the shelf into the desired slot and lock into position.

Some models have glass shelves that slide out for easy access. The shelves slide out independently of their mounting brackets, just pull the front of the shelf forward. Shelves can be extended as far as the stopper will allow but are not removable from their mounting brackets. Our door bins (vary by model) are removable for easy cleaning but some of them have fixed positions while others can be adjusted.

To change the position of an adjustable door bin simply remove all items from the bin and then grip the bin firmly with both hands and lift it upward. Next, remove the bin and place it just above the desired position. Then, lower the bin onto the supports until it's locked in place and place the bin liner into bin (if removed).

To remove your upper freezer basket, find the side where the basket frame is aligned to the clip opening (either left or right side). If not aligned on either side, push the basket sideways until it is aligned by grabbing the basket wire frame close to the frontal clip and pull it up to take the basket frame out. Grab the basket frame close to the rear clip and pull up until it comes out of the clip.

Once one side of the basket is off the clips and retainers, slide the basket sideways until the other side of the frame is aligned with the clip openings on the opposite side of the freezer. In the same way, pull the basket frame from the frontal and rear clips until it is out of the clips. Remove the basket and reverse the steps to reinstall.

Depending on your model, there are various features and functions available on your French-Door. It is always recommended to check out your Owner’s Manual for more descriptions of these features.

Press OPTIONS to illuminate the center of your display – this will show you the available features and functions.

Use the UP or DOWN key to scroll through the menu that appears in the center of your display.

To change a setting to ON or OFF, press the +; then press SET to select. When selection is made, go back and press OPTIONS to save.

Setting the humidity control on your crisper drawers is not hard but we often forget what the best setting is based on the food type. Here are some helpful tips:

Leafy vegetables keep best when stored with the humidity control set on HIGH, or in a drawer without a humidity control. This keeps incoming air to a minimum and maintains maximum moisture.
Non-leafy vegetables and fruits still in their skin should be stored with the humidity control set on LOW. It’s best to wash items and remove any excess water before placing in the crisper drawers.
Items with strong odors or high moisture content should be wrapped before storing.
If you have a refrigerator model with the Auto CrispSealTM Drawer, they are equipped with an auto humidity control on the side of each crisper under the humidity control cover. Good news – no settings needed!
