95164K
DISCOVERY i-1000
NATURAL GAS
CONVERSION KIT
Suits Discovery Series (2002 onwards)
Kit includes:
1 x NG Hose and Regulator (Sold separately in USA)
5 x 1.9mm Injectors Hex N/G M5 Thread (code: 040145)
1 x 1.7mm Injector Hex N/G M5 Thread (code: 040170)
1 x NG Label (code: 020404) SL4000 Series
95170K and 95170SL
SIGNATURE 3000S AND
SL4000 NATURAL GAS
CONVERSION KIT
Suits the following BeefEater models:
Signature S-3000 Series (August 2002 onwards)
Balcony Series (August 2002 onwards)
Kit includes:
1 x N/G Hose and regulator (Sold separately in USA)
6 x 2.10mm Hex Head N/G injectors M5 Thread
1 x Pilot jet Injector 0.95mm 040259
– previously 95170SL only
(Not required for Signature 3000S)
1 x NG Label (code: 020404)
BBQ AND SIDE BURNER
GAS CONVERSION INSTRUCTIONS
95167
SIGNATURE 3000E
NATURAL GAS
CONVERSION KIT
Suits models from 2011 onwards
Kit includes:
1 x Label “NATURAL GAS” Black 020404
5 x Injector NG 2.10 mm M6 040178
1 x Injector NG 2.10 mm M5 040168
1 x Nat/Gas Hose & Reg PVC 750mm 95162
(Sold separately in USA)
Important Safety Instructions
WARNING
WARNING
All service to the appliance must be undertaken by a
qualified gas service agent.
Do not smoke or use a naked flame within the vicinity of the
appliance or gas line when performing gas conversion or
service of any kind.
Always carry out a gas leak test after any work has been
carried out on the appliance.
If your barbecue is fitted with an optional side burner, gas
conversion must be carried out at the same time.
Always use the correct size socket spanner / wrench to
remove or replace the gas injectors. Do not use pliers or
any other type of tool that may squeeze the head of the gas
injector. This may cause the gas orifice to change shape
thereby adversely affecting the gas flow to each burner.
Gas injectors are made of brass and have a fine thread which
must be treated with care when being handled. Remove and
replace injectors with care.
