User Manual Samsung NE58H9970WS/AC Range

• Owner's manual - (English, French, Spanish)

User Guide Samsung NE58H9970WS/AC Range

Table of contents

• IMPORTANT SAFETY
• INSTRUCTIONS
• Important safety instructions
• INTRODUCING YOUR NEW
• RANGE
• Overview
• What’s included with your range
• BEFORE YOU BEGIN
• Before you begin
• GETTING STARTED
• Setting the clock
• Control panel display modes
• Turning the oven light on and off
• Control lockout
• Setting the kitchen timer
• INDUCTION COOKTOP
• COOKING
• About induction cooktop cooking
• How to set the appliance for
• cooktop cooking
• Before using the cooktop
• Cookware for induction cooking
• zones
• Use the correct size cookware
• Size of pans
• Operating noises
• Using suitable induction cookware
• Temperature detection

Before a self-cleaning cycle

• We recommend venting your kitchen by opening a window or using a ventilation fan or hood during the self-cleaning cycle

• Remove the wire rack, broil pan, broil pan insert, all cookware, and any aluminum foil from the oven.

• Wipe up debris from the oven bottom. (Fig. 1)

• The silver-colored oven racks can be selfcleaned, but they will darken, lose their luster, and become hard to slide.

• Residue on the front frame of the range and outside the gasket on the door will need to be cleaned by hand. Clean these areas with hot water, soap-filled steel-wool pads, or cleansers such as Soft Scrub. Rinse well with clean water and dry.

• Do not clean the gasket. The fiberglass material of the oven door gasket cannot withstand abrasion. It is essential for the gasket to remain intact. If you notice it becoming worn or frayed, replace it. (Fig. 2)

• Make sure the oven light bulb cover is in place and the oven light is off.

How to delay the start of self-cleaning

1. Press Self Clean. Select the desired self-clean time by pressing Self Clean.

2. Press Delay Start.

3. Enter the time you want the clean cycle to start.

4. Press START SET. The display will show delay start, self clean, and the Lock icon. The motor-driven door lock will engage automatically.

5. The Self-Cleaning cycle will turn on automatically at the set time.

After a self-cleaning cycle

• You may notice some white ash in the oven. Wipe it up with a damp cloth after the oven cools. (If white spots remain, remove them with a soap-filled steel wool pad and rinse thoroughly with a vinegar and water mixture.)

• If the oven is not clean after one cycle, repeat the cycle.

• You cannot set the oven for cooking until the oven is cool enough for the door to unlock.
