[en] Instruction manual
Table of contents
[en] Instruction manual
( Important safety information 5
] Causes of damage 7
7 Environmental protection 7
* Getting to know your appliance 8
_ Accessories 10
K Before using for the first time 12
1 Operating the appliance 13
O Time-setting options 15
A Childproof lock 16
Q Basic settings 17
n Baking and roasting assistant 18
@ Meat thermometer 19
F Sabbath mode 20
D Cleaning agent 21
. Cleaning function 22
p Rails 24
q Appliance door 25
3 Trouble shooting 28
4 Customer service 29
J Tested for you in our cooking studio 30
8 Intended use
Intended use
( Important safety information
Important safety information
General information
: Warning
Risk of fire!
: Warning
Risk of burns!
: Warning
Risk of scalding!
: Warning
Risk of injury!
: Warning
Risk of electric shock!
: Warning
Hazard due to magnetism!
Halogen lamp
: Warning
Risk of electric shock!
Meat thermometer
: Warning
Risk of electric shock!
Cleaning function
: Warning
Risk of fire!
: Warning
Risk of serious damage to health!
: Warning
Risk of burns!
] Causes of damage
Causes of damage
General information
Caution!
7 Environmental protection
Environmental protection
Saving energy
Environmentally-friendly disposal
* Getting to know your appliance
Getting to know your appliance
Note:
Control panel
Controls
Touch buttons
Touch button
Use
FullTouch TFT display
Direction
Use
Main menu
Menu
Use
Menu for the types of heating
Type of heating
Temperature
Use
--------
Cooking compartment functions
Opening the appliance door
Interior lighting
Note:
Cooling fan
Caution!
Note:
_ Accessories
Accessories
Accessories included
Note:
Inserting accessories
: Warning
Risk of burns!
Locking function
Changing the shelf position for the telescopic rail
Removing the bar
1. Push the bar towards the back ‚ until it can be pulled out upwards ƒ (Fig. !).
2. Unhook the bar at the back and remove it (Fig. ").
Fitting the bar
1. Fit the bar at the back (Fig. !).
2. Push the bar towards the back ‚ and down ƒ onto the pin „ (Fig. ").
3. Ensure that the hook is hooked onto the pin „ (Fig. #).
Combining accessories
Optional accessories
Note:
Accessories
Order number
K Before using for the first time
Before using for the first time
Initial use
Setting the language
1. Touch the bottom line.
2. Swipe to the left or right to select the required language.
3. Touch the top line.
Setting the time
1. Touch "Clock".
2. Touch the bottom line.
3. Swipe to the left or right to select the current hour.
4. Touch "Minutes".
5. Swipe to the left or right to select the current minute.
6. Touch the 8 symbol to apply the setting.
Setting the date
1. Touch "Date".
2. Touch the bottom line.
3. Swipe to the left or right to select the current day.
4. Touch "Month".
5. Swipe to the left or right to select the current month.
6. Touch "Year".
7. Swipe to the left or right to select the current year.
8. Touch the 8 symbol to apply the setting.
9. Touch the 8 symbol to complete the initial use.
Notes
Cleaning the cooking compartment
1. Remove the accessories from the cooking compartment.
2. Remove leftover packaging, such as polystyrene pellets, from the cooking compartment.
3. Before heating the appliance, wipe the smooth surfaces in the cooking compartment with a soft, wet cloth.
4. Use the # touch button to switch on the appliance.
5. Set the heating type and temperature, then start the appliance operation. ~ "Setting and starting the appliance operation" on page 13
Settings
6. Keep the kitchen ventilated while the appliance is heating up.
7. Use the # touch button to switch off the appliance after the indicated cooking time.
8. Wait until the cooking compartment has cooled down.
9. Clean the smooth surfaces with soapy water and a dish cloth.
Cleaning the accessories
1 Operating the appliance
Operating the appliance
Switching the appliance on and off
Display
Temperature
Notes
Setting and starting the appliance operation
1. Touch the # touch button to switch on the appliance.
2. Swipe to the left or right to select the type of heating.
3. Touch the bottom line.
4. Swipe to the left or right to select the temperature.
5. Touch the # touch button to start the appliance operation.
Note:
Default values
Heating bar
Run time
Displaying the current temperature
Further information
Changing or cancelling the appliance operation
Changing the appliance operation
1. Use the # button to stop the operation.
2. Tap the line for the setting that should be changed.
3. Swipe to the left or right to change the setting.
4. Use the # touch button to start the changed operation.
Notes
Note:
Heating up the appliance quickly
Function
Type of heating
Place the food in the cooking compartment
Notes
Activating the "Rapid heat-up" function
1. Set top/bottom heating ƒ and the temperature.
Note:
2. Touch the # touch button to start the appliance operation.
3. Touch the ° touch button to activate the "Rapid heat-up" function.
4. Once the set temperature has been reached, the "Rapid heat-up" function switches itself off automatically. The ° symbol disappears from the display. Place the food in the cooking compartment
Activating the "PowerBoost" function
1. Set CircoTherm hot air ‚ or the bread baking setting … and the temperature.
Note:
2. Place the food on a single level in the cooking compartment.
3. Touch the # touch button to start the appliance operation.
4. Touch the ° touch button to activate the "PowerBoost" function.
O Time-setting options
Time-setting options
Time-setting option
Use
Note:
Showing and hiding the time-setting options
Note:
Setting the timer
1. Touch the 0 touch button.
2. Swipe to the left or right to select the duration.
Note:
3. Touch the 0 touch button.
Note:
Setting the cooking time
1. Touch the # touch button.
2. Set the type of heating and temperature.
3. Touch the 0 touch button.
4. Swipe to the left or right to select the cooking time.
5. Touch the # touch button to start the set cooking time.
Start delay – "Ready at"
Notes
1. Place the food on an appropriate accessory, slide it into the cooking compartment and close the appliance door.
2. Touch the # touch button.
3. Set the type of heating and temperature.
4. Touch the 0 touch button.
5. Swipe to the left or right to select the cooking time.
6. Touch "* Ready at".
7. Swipe to the left to select the end time.
8. Touch the # touch button.
Checking, changing or deleting settings
1. Touch the 0 field.
2. Touch the time-setting option.
3. If required, swipe to the left or right in the touch display to change the settings. To delete a time- setting option, set "- - : - -".
A Childproof lock
Childproof lock
Lock
Activate/deactivate
Note:
Automatic childproof lock
Activation
1. Touch the ± touch button.
2. Touch the 0 touch button.
3. Swipe to the left or right to select "MyProfile".
4. Touch the bottom line.
5. Swipe to the left or right to select the "Automatic childproof lock".
6. Touch the bottom line.
7. Swipe to the left or right to select "Activated".
8. Touch the 0 touch button.
9. Touch "Save".
Cancelling
1. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
2. Touch the ± touch button.
3. Switch on the required appliance operation.
Deactivation
1. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
2. Touch the ± touch button.
3. Touch the 0 touch button.
4. Swipe to the left or right to select "MyProfile".
5. Touch the bottom line.
6. Touch the top line.
7. Swipe to the left or right to select the "Automatic childproof lock".
8. Touch the bottom line.
9. Swipe to the left or right to select "Deactivated".
10. Touch the 0 touch button.
11. Touch "Save".
12. Touch the ± touch button.
One-time childproof lock
Activating and deactivating
1. Press and hold the 0 touch button until "Childproof lock activated" appears on the display.
2. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
Q Basic settings
Basic settings
Changing MyProfile
1. Touch the # touch button.
2. Touch the 0 touch button.
3. Swipe to the left or right to select "MyProfile 4".
4. Touch the bottom line.
5. Swipe to the left or right to select the required setting.
6. Touch the bottom line.
7. Swipe to the left or right to select the required setting.
8. Touch the 0 touch button.
9. Touch "Save".
List of basic settings
Setting
Selection
Setting favourites
Note:
1. Touch the # touch button.
2. Touch the 0 touch button.
3. Swipe to the left or right to select "MyProfile 4".
4. Touch the bottom line.
5. Swipe to the left or right to select "Favourites".
6. Touch the bottom line.
7. Swipe to the left or right to select the required type of heating.
8. Touch "Activated" or "Deactivated".
9. Touch the 0 touch button.
10. Touch "Save".
n Baking and roasting assistant
Baking and roasting assistant
Information on the settings
Selecting and setting food
1. Touch the # touch button to switch on the appliance.
2. Touch the 0 touch button.
3. Swipe to the left or right to select "Baking and roasting assistant".
4. Touch the bottom line.
5. Touch the required category.
6. Swipe to the left or right to select the required dish.
7. Touch the required dish.
8. You can change the recommended settings if you wish. To do this, touch "Adjust" in the bottom line.
9. Touch the # touch button to start the appliance operation.
Continue cooking
1. Touch "Continue cooking".
2. If necessary, adjust the recommended setting.
3. Touch the # touch button to start "Continue cooking".
Cancelling
Switching off the appliance
@ Meat thermometer
Meat thermometer
Suitable types of heating
Notes
Inserting the meat thermometer into the food
Note:
Caution!
Core temperatures of different foods
Food
Core temperature in °C
Setting and starting the appliance operation
: Warning
Risk of burns!
: Warning
Risk of electric shock!
Notes
1. Insert the meat thermometer in the socket on the left- hand side of the cooking compartment.
2. Close the appliance door.
Caution!
3. Touch the # touch button.
4. Set the type of heating.
Note:
5. Touch the cooking compartment temperature on the left in the bottom line.
6. Swipe to the left or right to select the required cooking compartment temperature.
7. Touch the 8 symbol to apply the setting.
8. Touch the ¥ core temperature on the right in the bottom line.
9. Swipe to the left or right to select the required core temperature.
10. Touch the # touch button.
Changing or cancelling the appliance operation
1. Touch the cooking compartment temperature or core temperature twice.
2. Swipe to the left or right to change the temperature.
3. Touch the 8 symbol to apply the setting.
1. Touch the 3 touch button to end the signal.
2. Use the # touch button to switch off the appliance.
3. Using an oven glove, unplug the meat thermometer from the socket.
F Sabbath mode
Sabbath mode
Starting the Sabbath mode
1. Touch the # touch button.
2. Swipe to the left or right to select the "Sabbath mode".
3. Touch the temperature in the bottom line.
4. Swipe to the left or right to select the required temperature.
5. Touch the 8 symbol to apply the setting.
6. Touch the + duration in the bottom line.
7. Swipe to the left or right to select the required duration.
8. Touch the 8 symbol to apply the setting.
9. Touch the # touch button.
Notes
Cancelling Sabbath mode
D Cleaning agent
Cleaning agent
Suitable cleaning agents
Caution!
Risk of surface damage
Tip:
: Warning
Risk of burns!
Area
Cleaning
Notes
Keeping the appliance clean
Tips
. Cleaning function
Cleaning function
Self-cleaning
Setting
Cleaning level
Duration
Note:
: Warning
Risk of burns!
Prior to initiating the cleaning function
Note:
: Warning
Risk of fire!
: Warning
Risk of serious damage to health!
Starting
1. Touch the # touch button.
2. Touch the 0 touch button.
3. Swipe to the left or right to select "Pyrolytic self- cleaning ˜".
4. Touch the bottom line.
5. Swipe to the left or right to select the cleaning level.
Note:
6. Touch the bottom line.
7. Touch the # touch button.
Note:
Cancelling
Finishing
Once the cleaning function has ended
EasyClean
: Warning
Risk of scalding!
Starting
Notes
1. Remove the accessories from the cooking compartment.
2. Mix a drop of washing-up liquid into 0.4 litres of water (do not use distilled water) and pour it onto the centre of the cooking compartment floor.
3. Touch the # touch button.
4. Touch the 0 touch button.
5. Swipe to the left or right to select "EasyClean š".
6. Touch the bottom line.
7. Touch the # touch button.
Finishing
Final cleaning
1. Open the appliance door and remove the remaining water with an absorbent sponge cloth.
2. Clean the smooth surfaces in the cooking compartment with a dish cloth or a soft brush. Stubborn residues can be removed using a stainless steel scouring pad.
3. Remove limescale with a cloth soaked in vinegar. Then wipe with clean water and rub dry with a soft cloth (including under the door seal).
4. Use the # touch button to switch off the appliance.
5. Leave the appliance door ajar in the locking position (approx. 30°) for approx. 1 hour to allow the enamel surfaces in the cooking compartment to dry. Alternatively, you can also run the rapid drying function for the cooking compartment.
Running the rapid drying function for the cooking compartment
1. After the cleaning aid process has finished, leave the appliance door ajar in the locking position (approx. 30°).
2. Touch the # touch button.
3. Start CircoTherm hot air at 50 °C.
4. After 5 minutes, switch off the appliance and close the appliance door.
Removing heavy deposits of dirt
p Rails
Rails
Detaching and refitting the rails
: Warning
Risk of burns!
Detaching the rails
1. Lift the rail slightly at the front ‚ and detach it ƒ (do not hold by the accessory holders or the telescopic shelf) (figure !).
2. Then pull the whole rail towards you and take it out (figure ").
Attaching the rails
1. First, insert the rail in the middle of the rear socket ‚, until the rail rests against the cooking compartment wall, and push it back ƒ (figure !).
2. Then insert the rail into the front socket „, until the rail also rests against the cooking compartment wall here, and press it downwards … (figure ").
q Appliance door
Appliance door
Removing and fitting the appliance door
: Warning
Risk of injury!
: Warning
Risk of injury!
Removing the appliance door
1. Open the left- and right-hand hinge lock (Fig. !).
Tip:
2. Open the appliance door a little (Fig. %).
3. Using a coin, fully turn both the left- and right-hand locks on the inside of the appliance at the bottom (Fig. &).
4. Close the appliance door a little, until you feel the locks engage.
5. Lift the door handle slightly on the left- and right- hand side using both thumbs ‚ and pull the appliance door out upwards ƒ (Fig. ').
6. Lay the appliance door on an even, soft and clean surface.
Fitting the appliance door
1. Fit the appliance door (Fig. !).
2. Fit the appliance door in the left and right-hand guide rollers simultaneously (Fig. ").
3. Turn the door handle upwards slightly ‚ so that the appliance door slides downwards fully ƒ (Fig. #).
4. Use a coin to release both locks on the appliance door (Fig. $).
5. Open the appliance door a little wider and then close it.
: Warning
Risk of injury from hinge locks which have not been properly closed!
6. Close the left- and right-hand hinge locks (Fig. %).
Removing and installing the door panels
: Warning
Risk of injury!
Removal
Note:
1. Remove the appliance door.
2. Lay the appliance door with the front side facing down on an even, soft and clean surface.
3. Push on the left- and right-hand side on the outside of the appliance door until the inner glass is released on both sides (Fig. !).
4. Carefully lift the inner glass and remove it in the direction of the arrow (Fig. ").
5. Push the intermediate panel downwards in the ‚ area, carefully lift the ƒ holder until it can be pulled out (Fig. #).
6. Lift the first and second intermediate panels from below (Fig. $) and remove them in the direction of the arrow (Fig. %).
7. If required, remove the spacers (Fig. &) and seals (Fig. ') for cleaning.
8. Clean the door panels on both sides with glass cleaner and a soft cloth.
: Warning
Risk of injury!
9. Dry and refit the door panels.
Installation
Note:
1. Insert the intermediate glass so that the ‚ arrow is facing upwards on the right-hand side (Fig. !).
2. Check the fit of the four spacers and two seals on the intermediate panel:
3. Insert the intermediate panel with the seals and spacers. The arrow on the intermediate panel must line up with the arrow on the frame (Fig. $).
4. Insert the second intermediate panel without the seals and spacers and push it in the direction of the arrow until it is fitted in the frame. The arrow on the intermediate panel must line up with the arrow on the frame (Fig. %).
5. Push the intermediate panel downwards in the ƒ area, insert the „ holder at an angle and push down until it locks into place (Fig. &).
6. Insert the inner glass into the mounting rail … at an angle towards the back (Fig. ().
7. Push the inner glass downwards until it locks into place (Fig. )).
3 Trouble shooting
Trouble shooting
Tip:
: Warning
Risk of electric shock!
Fault table
: Warning
Risk of electric shock!
Fault
Possible cause
Notes/remedy
--------
Maximum operating time exceeded
Replacing the bulb in the top of the cooking compartment
: Warning
Risk of electric shock!
: Warning
Risk of burns!
1. Place a tea towel in the cold cooking compartment to prevent damage.
2. Turn the glass cover anti-clockwise to remove it (figure !).
3. Pull out the bulb – do not turn it (figure "). Insert the new bulb, making sure that the pins are in the correct position. Push the bulb in firmly.
4. Screw the glass cover back in.
5. Remove the tea towel and switch on the circuit breaker.
Glass cover
4 Customer service
Customer service
E number and FD number
To book an engineer visit and product advice
J Tested for you in our cooking studio
Tested for you in our cooking studio
Note:
Silicone moulds
Baking
Shelf positions
Accessories
Recommended setting values
Note:
Dish
Accessories/cookware
Shelf position
Type of heating
Temperature in °C
Cooking time in mins.
Tips on baking
Roasting and braising
Roasting on the wire rack
Roasting and braising in cookware
Meat thermometer
Recommended setting values
Dish
Accessories/cookware
Shelf position
Type of heating
Temperature in °C
Cooking time in mins.
Tips on roasting and braising
Grilling
Grilling with circo-roasting
Roasting on the wire rack
Roasting in cookware
Grilling flat pieces
Grilling
Note:
Notes
Meat thermometer
Recommended setting values
Dish
Accessories
Shelf position
Type of heating
Temperature in °C
Cooking time in mins.
Convenience products
Tips
Shelf positions
Accessories
Recommended setting values
Note:
Dish
Accessories/cookware
Shelf position
Type of heating
Temperature in °C
Cooking time in mins.
Yogurt
Preparing yogurt
1. Heat 1 litre of milk (3.5 % fat) to 90 °C on the hob and then cool down to 40 °C.
2. Stir in 150 g (chilled) yogurt.
3. Pour into cups or small jars and cover with cling film.
4. Place the cups or jars onto the cooking compartment floor and use the settings indicated in the table.
5. After preparation, leave the yogurt to cool in the refrigerator.
Dish
Cookware
Shelf position
Type of heating
Temperature in °C
Cooking time in hours
Save energy with Eco heating types
Accessories
Recommended setting values
Note:
Dish
Accessories/cookware
Shelf position
Type of heating
Temperature in °C
Cooking time in mins.
Acrylamide in foodstuffs
Tips for keeping acrylamide to a minimum
Slow cook
Note:
Cookware
Recommended setting values
Dish
Cookware
Shelf position
Type of heating
Searing time in mins.
Temperature in °C
Cooking time in mins.
Tips for slow cooking
Drying
Recommended setting values
Fruit, vegetables and herbs
Accessories
Type of heating
Temperature in °C
Cooking time in hours
Preserving
: Warning
Risk of injury!
Jars
Preparing fruit and vegetables
Ending the preserving process
Recommended setting values
Preserving
Cookware
Shelf position
Type of heating
Temperature in °C
Cooking time in mins.
Allowing the dough to prove at dough proving setting
Caution!
Surface damage
Recommended setting values
Dish
Accessories/cookware
Shelf position
Type of heating
Step
Temperature in °C
Cooking time in mins.
Defrosting
Recommended setting values
Tip:
Dish
Accessories
Shelf position
Type of heating
Temperature in °C
Cooking time in mins.
Keeping warm
Test dishes
Baking
Notes
Dish
Accessories
Shelf position
Type of heating
Temperature in °C
Cooking time in mins.
Grilling
Dish
Accessories
Shelf position
Type of heating
Temperature in °C
Cooking time in mins.
Page 1/48
Page 1
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7
Page 8
Page 9
Page 10
Page 11
Page 12
Page 13
Page 14
Page 15
Page 16
Page 17
Page 18
Page 19
Page 20
Page 21
Page 22
Page 23
Page 24
Page 25
Page 26
Page 27
Page 28
Page 29
Page 30
Page 31
Page 32
Page 33
Page 34
Page 35
Page 36
Page 37
Page 38
Page 39
Page 40
Page 41
Page 42
Page 43
Page 44
Page 45
Page 46
Page 47
Page 48
Contents
Table of Contents
Search
Previous
Next
Troubleshooting
Bookmarks
[en]
INSTRUCTION MANUAL
Built-in oven
B58CT28.0B
Loading ...
Loading ...
Loading ...
File type: PDF
File name: 46321186_b58ct28n0b-01.pdf
File size: 2.76 MB
File Language: English
Pages: 48
Author: Neff
Published:
2020-05-27
Updated: 2023-09-04
Download File
Other documents for Neff B58CT28N0B/01
The following documents are available:
User Manual
User Manual - (English)
Read Online
|
Download pdf
Photos
Photos:
View Photos
Specifications
Brand:
Neff
Model: B58CT28N0B/01
Category:
Ovens
See other models:
S24M57N3EU/01
T26BR46N0
D64QFM1N0B/01
B1624S0/03
D72E34N0/03
Related Products
Neff B17CR32N1B
Neff B58CT28N0B/08
Neff B58CT64N0B/01
Neff B58VT28N0B
Neff B58CT64N0B/08
Neff B57CR22N0B/01
Neff B58CT68H0B
Neff B57CR22N0B/08
Neff V6320X1GB/06
Neff U1GCC0AN0B
Neff U1ACI5HN0B
Neff U1ACE5H0B
Neff D64AFM1N0B
Neff T26CS49S0
Neff D65BMP5N0B
Table of Contents
×
[en] Instruction manual
1
Table of contents
3
[en] Instruction manual
3
( Important safety information 5
3
] Causes of damage 7
3
7 Environmental protection 7
3
* Getting to know your appliance 8
3
_ Accessories 10
3
K Before using for the first time 12
3
1 Operating the appliance 13
3
O Time-setting options 15
3
A Childproof lock 16
3
Q Basic settings 17
3
n Baking and roasting assistant 18
3
@ Meat thermometer 19
3
F Sabbath mode 20
3
D Cleaning agent 21
3
. Cleaning function 22
3
p Rails 24
3
q Appliance door 25
3
3 Trouble shooting 28
3
4 Customer service 29
3
J Tested for you in our cooking studio 30
4
8 Intended use
4
Intended use
4
( Important safety information
5
Important safety information
5
General information
5
: Warning
5
Risk of fire!
5
: Warning
5
Risk of burns!
5
: Warning
5
Risk of scalding!
5
: Warning
5
Risk of injury!
5
: Warning
5
Risk of electric shock!
5
: Warning
6
Hazard due to magnetism!
6
Halogen lamp
6
: Warning
6
Risk of electric shock!
6
Meat thermometer
6
: Warning
6
Risk of electric shock!
6
Cleaning function
6
: Warning
6
Risk of fire!
6
: Warning
6
Risk of serious damage to health!
6
: Warning
6
Risk of burns!
6
] Causes of damage
7
Causes of damage
7
General information
7
Caution!
7
7 Environmental protection
7
Environmental protection
7
Saving energy
7
Environmentally-friendly disposal
7
* Getting to know your appliance
8
Getting to know your appliance
8
Note:
8
Control panel
8
Controls
8
Touch buttons
8
Touch button
8
Use
8
FullTouch TFT display
8
Direction
8
Use
8
Main menu
9
Menu
9
Use
9
Menu for the types of heating
9
Type of heating
9
Temperature
9
Use
9
--------
9
Cooking compartment functions
10
Opening the appliance door
10
Interior lighting
10
Note:
10
Cooling fan
10
Caution!
10
Note:
10
_ Accessories
10
Accessories
10
Accessories included
10
Note:
10
Inserting accessories
10
: Warning
10
Risk of burns!
10
Locking function
11
Changing the shelf position for the telescopic rail
11
Removing the bar
11
1. Push the bar towards the back ‚ until it can be pulled out upwards ƒ (Fig. !).
11
2. Unhook the bar at the back and remove it (Fig. ").
11
Fitting the bar
11
1. Fit the bar at the back (Fig. !).
11
2. Push the bar towards the back ‚ and down ƒ onto the pin „ (Fig. ").
11
3. Ensure that the hook is hooked onto the pin „ (Fig. #).
11
Combining accessories
11
Optional accessories
12
Note:
12
Accessories
12
Order number
12
K Before using for the first time
12
Before using for the first time
12
Initial use
12
Setting the language
12
1. Touch the bottom line.
12
2. Swipe to the left or right to select the required language.
12
3. Touch the top line.
12
Setting the time
12
1. Touch "Clock".
12
2. Touch the bottom line.
12
3. Swipe to the left or right to select the current hour.
12
4. Touch "Minutes".
12
5. Swipe to the left or right to select the current minute.
12
6. Touch the 8 symbol to apply the setting.
12
Setting the date
12
1. Touch "Date".
12
2. Touch the bottom line.
12
3. Swipe to the left or right to select the current day.
12
4. Touch "Month".
12
5. Swipe to the left or right to select the current month.
12
6. Touch "Year".
12
7. Swipe to the left or right to select the current year.
12
8. Touch the 8 symbol to apply the setting.
12
9. Touch the 8 symbol to complete the initial use.
12
Notes
12
Cleaning the cooking compartment
13
1. Remove the accessories from the cooking compartment.
13
2. Remove leftover packaging, such as polystyrene pellets, from the cooking compartment.
13
3. Before heating the appliance, wipe the smooth surfaces in the cooking compartment with a soft, wet cloth.
13
4. Use the # touch button to switch on the appliance.
13
5. Set the heating type and temperature, then start the appliance operation. ~ "Setting and starting the appliance operation" on page 13
13
Settings
13
6. Keep the kitchen ventilated while the appliance is heating up.
13
7. Use the # touch button to switch off the appliance after the indicated cooking time.
13
8. Wait until the cooking compartment has cooled down.
13
9. Clean the smooth surfaces with soapy water and a dish cloth.
13
Cleaning the accessories
13
1 Operating the appliance
13
Operating the appliance
13
Switching the appliance on and off
13
Display
13
Temperature
13
Notes
13
Setting and starting the appliance operation
13
1. Touch the # touch button to switch on the appliance.
13
2. Swipe to the left or right to select the type of heating.
13
3. Touch the bottom line.
13
4. Swipe to the left or right to select the temperature.
14
5. Touch the # touch button to start the appliance operation.
14
Note:
14
Default values
14
Heating bar
14
Run time
14
Displaying the current temperature
14
Further information
14
Changing or cancelling the appliance operation
14
Changing the appliance operation
14
1. Use the # button to stop the operation.
14
2. Tap the line for the setting that should be changed.
14
3. Swipe to the left or right to change the setting.
14
4. Use the # touch button to start the changed operation.
14
Notes
14
Note:
14
Heating up the appliance quickly
14
Function
14
Type of heating
14
Place the food in the cooking compartment
14
Notes
14
Activating the "Rapid heat-up" function
14
1. Set top/bottom heating ƒ and the temperature.
14
Note:
14
2. Touch the # touch button to start the appliance operation.
14
3. Touch the ° touch button to activate the "Rapid heat-up" function.
14
4. Once the set temperature has been reached, the "Rapid heat-up" function switches itself off automatically. The ° symbol disappears from the display. Place the food in the cooking compartment
14
Activating the "PowerBoost" function
14
1. Set CircoTherm hot air ‚ or the bread baking setting … and the temperature.
14
Note:
14
2. Place the food on a single level in the cooking compartment.
14
3. Touch the # touch button to start the appliance operation.
14
4. Touch the ° touch button to activate the "PowerBoost" function.
14
O Time-setting options
15
Time-setting options
15
Time-setting option
15
Use
15
Note:
15
Showing and hiding the time-setting options
15
Note:
15
Setting the timer
15
1. Touch the 0 touch button.
15
2. Swipe to the left or right to select the duration.
15
Note:
15
3. Touch the 0 touch button.
15
Note:
15
Setting the cooking time
15
1. Touch the # touch button.
15
2. Set the type of heating and temperature.
15
3. Touch the 0 touch button.
15
4. Swipe to the left or right to select the cooking time.
15
5. Touch the # touch button to start the set cooking time.
15
Start delay – "Ready at"
15
Notes
15
1. Place the food on an appropriate accessory, slide it into the cooking compartment and close the appliance door.
15
2. Touch the # touch button.
15
3. Set the type of heating and temperature.
15
4. Touch the 0 touch button.
15
5. Swipe to the left or right to select the cooking time.
15
6. Touch "* Ready at".
15
7. Swipe to the left to select the end time.
15
8. Touch the # touch button.
15
Checking, changing or deleting settings
15
1. Touch the 0 field.
15
2. Touch the time-setting option.
15
3. If required, swipe to the left or right in the touch display to change the settings. To delete a time- setting option, set "- - : - -".
15
A Childproof lock
16
Childproof lock
16
Lock
16
Activate/deactivate
16
Note:
16
Automatic childproof lock
16
Activation
16
1. Touch the ± touch button.
16
2. Touch the 0 touch button.
16
3. Swipe to the left or right to select "MyProfile".
16
4. Touch the bottom line.
16
5. Swipe to the left or right to select the "Automatic childproof lock".
16
6. Touch the bottom line.
16
7. Swipe to the left or right to select "Activated".
16
8. Touch the 0 touch button.
16
9. Touch "Save".
16
Cancelling
16
1. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
16
2. Touch the ± touch button.
16
3. Switch on the required appliance operation.
16
Deactivation
16
1. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
16
2. Touch the ± touch button.
16
3. Touch the 0 touch button.
16
4. Swipe to the left or right to select "MyProfile".
16
5. Touch the bottom line.
16
6. Touch the top line.
16
7. Swipe to the left or right to select the "Automatic childproof lock".
16
8. Touch the bottom line.
16
9. Swipe to the left or right to select "Deactivated".
16
10. Touch the 0 touch button.
16
11. Touch "Save".
16
12. Touch the ± touch button.
16
One-time childproof lock
16
Activating and deactivating
16
1. Press and hold the 0 touch button until "Childproof lock activated" appears on the display.
16
2. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
16
Q Basic settings
17
Basic settings
17
Changing MyProfile
17
1. Touch the # touch button.
17
2. Touch the 0 touch button.
17
3. Swipe to the left or right to select "MyProfile 4".
17
4. Touch the bottom line.
17
5. Swipe to the left or right to select the required setting.
17
6. Touch the bottom line.
17
7. Swipe to the left or right to select the required setting.
17
8. Touch the 0 touch button.
17
9. Touch "Save".
17
List of basic settings
17
Setting
17
Selection
17
Setting favourites
17
Note:
17
1. Touch the # touch button.
17
2. Touch the 0 touch button.
17
3. Swipe to the left or right to select "MyProfile 4".
17
4. Touch the bottom line.
17
5. Swipe to the left or right to select "Favourites".
17
6. Touch the bottom line.
17
7. Swipe to the left or right to select the required type of heating.
17
8. Touch "Activated" or "Deactivated".
17
9. Touch the 0 touch button.
17
10. Touch "Save".
17
n Baking and roasting assistant
18
Baking and roasting assistant
18
Information on the settings
18
Selecting and setting food
18
1. Touch the # touch button to switch on the appliance.
18
2. Touch the 0 touch button.
18
3. Swipe to the left or right to select "Baking and roasting assistant".
18
4. Touch the bottom line.
18
5. Touch the required category.
18
6. Swipe to the left or right to select the required dish.
18
7. Touch the required dish.
18
8. You can change the recommended settings if you wish. To do this, touch "Adjust" in the bottom line.
18
9. Touch the # touch button to start the appliance operation.
18
Continue cooking
18
1. Touch "Continue cooking".
18
2. If necessary, adjust the recommended setting.
18
3. Touch the # touch button to start "Continue cooking".
18
Cancelling
18
Switching off the appliance
18
@ Meat thermometer
19
Meat thermometer
19
Suitable types of heating
19
Notes
19
Inserting the meat thermometer into the food
19
Note:
19
Caution!
19
Core temperatures of different foods
19
Food
19
Core temperature in °C
19
Setting and starting the appliance operation
20
: Warning
20
Risk of burns!
20
: Warning
20
Risk of electric shock!
20
Notes
20
1. Insert the meat thermometer in the socket on the left- hand side of the cooking compartment.
20
2. Close the appliance door.
20
Caution!
20
3. Touch the # touch button.
20
4. Set the type of heating.
20
Note:
20
5. Touch the cooking compartment temperature on the left in the bottom line.
20
6. Swipe to the left or right to select the required cooking compartment temperature.
20
7. Touch the 8 symbol to apply the setting.
20
8. Touch the ¥ core temperature on the right in the bottom line.
20
9. Swipe to the left or right to select the required core temperature.
20
10. Touch the # touch button.
20
Changing or cancelling the appliance operation
20
1. Touch the cooking compartment temperature or core temperature twice.
20
2. Swipe to the left or right to change the temperature.
20
3. Touch the 8 symbol to apply the setting.
20
1. Touch the 3 touch button to end the signal.
20
2. Use the # touch button to switch off the appliance.
20
3. Using an oven glove, unplug the meat thermometer from the socket.
20
F Sabbath mode
20
Sabbath mode
20
Starting the Sabbath mode
20
1. Touch the # touch button.
20
2. Swipe to the left or right to select the "Sabbath mode".
20
3. Touch the temperature in the bottom line.
20
4. Swipe to the left or right to select the required temperature.
20
5. Touch the 8 symbol to apply the setting.
20
6. Touch the + duration in the bottom line.
20
7. Swipe to the left or right to select the required duration.
20
8. Touch the 8 symbol to apply the setting.
20
9. Touch the # touch button.
20
Notes
20
Cancelling Sabbath mode
20
D Cleaning agent
21
Cleaning agent
21
Suitable cleaning agents
21
Caution!
21
Risk of surface damage
21
Tip:
21
: Warning
21
Risk of burns!
21
Area
21
Cleaning
21
Notes
22
Keeping the appliance clean
22
Tips
22
. Cleaning function
22
Cleaning function
22
Self-cleaning
22
Setting
22
Cleaning level
22
Duration
22
Note:
22
: Warning
22
Risk of burns!
22
Prior to initiating the cleaning function
23
Note:
23
: Warning
23
Risk of fire!
23
: Warning
23
Risk of serious damage to health!
23
Starting
23
1. Touch the # touch button.
23
2. Touch the 0 touch button.
23
3. Swipe to the left or right to select "Pyrolytic self- cleaning ˜".
23
4. Touch the bottom line.
23
5. Swipe to the left or right to select the cleaning level.
23
Note:
23
6. Touch the bottom line.
23
7. Touch the # touch button.
23
Note:
23
Cancelling
23
Finishing
23
Once the cleaning function has ended
23
EasyClean
23
: Warning
23
Risk of scalding!
23
Starting
23
Notes
23
1. Remove the accessories from the cooking compartment.
23
2. Mix a drop of washing-up liquid into 0.4 litres of water (do not use distilled water) and pour it onto the centre of the cooking compartment floor.
23
3. Touch the # touch button.
23
4. Touch the 0 touch button.
23
5. Swipe to the left or right to select "EasyClean š".
23
6. Touch the bottom line.
23
7. Touch the # touch button.
23
Finishing
23
Final cleaning
24
1. Open the appliance door and remove the remaining water with an absorbent sponge cloth.
24
2. Clean the smooth surfaces in the cooking compartment with a dish cloth or a soft brush. Stubborn residues can be removed using a stainless steel scouring pad.
24
3. Remove limescale with a cloth soaked in vinegar. Then wipe with clean water and rub dry with a soft cloth (including under the door seal).
24
4. Use the # touch button to switch off the appliance.
24
5. Leave the appliance door ajar in the locking position (approx. 30°) for approx. 1 hour to allow the enamel surfaces in the cooking compartment to dry. Alternatively, you can also run the rapid drying function for the cooking compartment.
24
Running the rapid drying function for the cooking compartment
24
1. After the cleaning aid process has finished, leave the appliance door ajar in the locking position (approx. 30°).
24
2. Touch the # touch button.
24
3. Start CircoTherm hot air at 50 °C.
24
4. After 5 minutes, switch off the appliance and close the appliance door.
24
Removing heavy deposits of dirt
24
p Rails
24
Rails
24
Detaching and refitting the rails
24
: Warning
24
Risk of burns!
24
Detaching the rails
24
1. Lift the rail slightly at the front ‚ and detach it ƒ (do not hold by the accessory holders or the telescopic shelf) (figure !).
24
2. Then pull the whole rail towards you and take it out (figure ").
24
Attaching the rails
24
1. First, insert the rail in the middle of the rear socket ‚, until the rail rests against the cooking compartment wall, and push it back ƒ (figure !).
24
2. Then insert the rail into the front socket „, until the rail also rests against the cooking compartment wall here, and press it downwards … (figure ").
24
q Appliance door
25
Appliance door
25
Removing and fitting the appliance door
25
: Warning
25
Risk of injury!
25
: Warning
25
Risk of injury!
25
Removing the appliance door
25
1. Open the left- and right-hand hinge lock (Fig. !).
25
Tip:
25
2. Open the appliance door a little (Fig. %).
25
3. Using a coin, fully turn both the left- and right-hand locks on the inside of the appliance at the bottom (Fig. &).
25
4. Close the appliance door a little, until you feel the locks engage.
25
5. Lift the door handle slightly on the left- and right- hand side using both thumbs ‚ and pull the appliance door out upwards ƒ (Fig. ').
25
6. Lay the appliance door on an even, soft and clean surface.
25
Fitting the appliance door
25
1. Fit the appliance door (Fig. !).
25
2. Fit the appliance door in the left and right-hand guide rollers simultaneously (Fig. ").
25
3. Turn the door handle upwards slightly ‚ so that the appliance door slides downwards fully ƒ (Fig. #).
25
4. Use a coin to release both locks on the appliance door (Fig. $).
26
5. Open the appliance door a little wider and then close it.
26
: Warning
26
Risk of injury from hinge locks which have not been properly closed!
26
6. Close the left- and right-hand hinge locks (Fig. %).
26
Removing and installing the door panels
26
: Warning
26
Risk of injury!
26
Removal
26
Note:
26
1. Remove the appliance door.
26
2. Lay the appliance door with the front side facing down on an even, soft and clean surface.
26
3. Push on the left- and right-hand side on the outside of the appliance door until the inner glass is released on both sides (Fig. !).
26
4. Carefully lift the inner glass and remove it in the direction of the arrow (Fig. ").
26
5. Push the intermediate panel downwards in the ‚ area, carefully lift the ƒ holder until it can be pulled out (Fig. #).
26
6. Lift the first and second intermediate panels from below (Fig. $) and remove them in the direction of the arrow (Fig. %).
26
7. If required, remove the spacers (Fig. &) and seals (Fig. ') for cleaning.
26
8. Clean the door panels on both sides with glass cleaner and a soft cloth.
26
: Warning
26
Risk of injury!
26
9. Dry and refit the door panels.
26
Installation
27
Note:
27
1. Insert the intermediate glass so that the ‚ arrow is facing upwards on the right-hand side (Fig. !).
27
2. Check the fit of the four spacers and two seals on the intermediate panel:
27
3. Insert the intermediate panel with the seals and spacers. The arrow on the intermediate panel must line up with the arrow on the frame (Fig. $).
27
4. Insert the second intermediate panel without the seals and spacers and push it in the direction of the arrow until it is fitted in the frame. The arrow on the intermediate panel must line up with the arrow on the frame (Fig. %).
27
5. Push the intermediate panel downwards in the ƒ area, insert the „ holder at an angle and push down until it locks into place (Fig. &).
27
6. Insert the inner glass into the mounting rail … at an angle towards the back (Fig. ().
27
7. Push the inner glass downwards until it locks into place (Fig. )).
27
3 Trouble shooting
28
Trouble shooting
28
Tip:
28
: Warning
28
Risk of electric shock!
28
Fault table
28
: Warning
28
Risk of electric shock!
28
Fault
28
Possible cause
28
Notes/remedy
28
--------
28
Maximum operating time exceeded
28
Replacing the bulb in the top of the cooking compartment
29
: Warning
29
Risk of electric shock!
29
: Warning
29
Risk of burns!
29
1. Place a tea towel in the cold cooking compartment to prevent damage.
29
2. Turn the glass cover anti-clockwise to remove it (figure !).
29
3. Pull out the bulb – do not turn it (figure "). Insert the new bulb, making sure that the pins are in the correct position. Push the bulb in firmly.
29
4. Screw the glass cover back in.
29
5. Remove the tea towel and switch on the circuit breaker.
29
Glass cover
29
4 Customer service
29
Customer service
29
E number and FD number
29
To book an engineer visit and product advice
29
J Tested for you in our cooking studio
30
Tested for you in our cooking studio
30
Note:
30
Silicone moulds
30
Baking
30
Shelf positions
30
Accessories
30
Recommended setting values
30
Note:
30
Dish
31
Accessories/cookware
31
Shelf position
31
Type of heating
31
Temperature in °C
31
Cooking time in mins.
31
Tips on baking
32
Roasting and braising
33
Roasting on the wire rack
33
Roasting and braising in cookware
33
Meat thermometer
33
Recommended setting values
33
Dish
34
Accessories/cookware
34
Shelf position
34
Type of heating
34
Temperature in °C
34
Cooking time in mins.
34
Tips on roasting and braising
35
Grilling
35
Grilling with circo-roasting
35
Roasting on the wire rack
35
Roasting in cookware
35
Grilling flat pieces
36
Grilling
36
Note:
36
Notes
36
Meat thermometer
36
Recommended setting values
36
Dish
37
Accessories
37
Shelf position
37
Type of heating
37
Temperature in °C
37
Cooking time in mins.
37
Convenience products
38
Tips
38
Shelf positions
38
Accessories
38
Recommended setting values
38
Note:
38
Dish
39
Accessories/cookware
39
Shelf position
39
Type of heating
39
Temperature in °C
39
Cooking time in mins.
39
Yogurt
39
Preparing yogurt
39
1. Heat 1 litre of milk (3.5 % fat) to 90 °C on the hob and then cool down to 40 °C.
39
2. Stir in 150 g (chilled) yogurt.
39
3. Pour into cups or small jars and cover with cling film.
39
4. Place the cups or jars onto the cooking compartment floor and use the settings indicated in the table.
39
5. After preparation, leave the yogurt to cool in the refrigerator.
39
Dish
39
Cookware
39
Shelf position
39
Type of heating
39
Temperature in °C
39
Cooking time in hours
39
Save energy with Eco heating types
40
Accessories
40
Recommended setting values
40
Note:
40
Dish
40
Accessories/cookware
40
Shelf position
40
Type of heating
40
Temperature in °C
40
Cooking time in mins.
40
Acrylamide in foodstuffs
41
Tips for keeping acrylamide to a minimum
41
Slow cook
41
Note:
41
Cookware
41
Recommended setting values
42
Dish
42
Cookware
42
Shelf position
42
Type of heating
42
Searing time in mins.
42
Temperature in °C
42
Cooking time in mins.
42
Tips for slow cooking
42
Drying
43
Recommended setting values
43
Fruit, vegetables and herbs
43
Accessories
43
Type of heating
43
Temperature in °C
43
Cooking time in hours
43
Preserving
43
: Warning
43
Risk of injury!
43
Jars
43
Preparing fruit and vegetables
43
Ending the preserving process
43
Recommended setting values
44
Preserving
44
Cookware
44
Shelf position
44
Type of heating
44
Temperature in °C
44
Cooking time in mins.
44
Allowing the dough to prove at dough proving setting
44
Caution!
44
Surface damage
44
Recommended setting values
45
Dish
45
Accessories/cookware
45
Shelf position
45
Type of heating
45
Step
45
Temperature in °C
45
Cooking time in mins.
45
Defrosting
45
Recommended setting values
45
Tip:
45
Dish
45
Accessories
45
Shelf position
45
Type of heating
45
Temperature in °C
45
Cooking time in mins.
45
Keeping warm
45
Test dishes
45
Baking
45
Notes
46
Dish
46
Accessories
46
Shelf position
46
Type of heating
46
Temperature in °C
46
Cooking time in mins.
46
Grilling
46
Dish
46
Accessories
46
Shelf position
46
Type of heating
46
Temperature in °C
46
Cooking time in mins.
46
Search:
×
Search
