Unpacking the unit.

  1. Remove the exhaust tube from its storage under the rear air outlet. Replace the rear air outlet.
  2. Install the exhaust tube by rotating it clockwise onto the rear air outlet. Please ensure it is fully inserted before use.

Locating the unit.

  • Install the portable air conditioner in a flat location with adequate space to ensure the air inlets and outlets will not be blocked.
  • Keep a minimum clearance of 50cm from walls and other objects. Locate the unit to allow the exhaust pipe and drain hose to reach a suitable window, as shown.
  • Avoid sharp bends or kinks in the exhaust pipe.
  • The optional adjustable window slider is included to ensure the exhaust pipe is held in place (in the window) and prevents expelled hot air re-entering the room.
  • The appliance should not be used in damp areas such as a laundry or bathroom.
  • Do not place the unit where it will be in direct sunlight as it may overheat and turn off


Air filters: The air filters located on the rear of the unit can be removed simply by pulling the filter frame slightly out and then across to the side.

Cabinet: Wipe with a damp cloth and polish with a soft cloth

Care of the Unit

  1. Only plug the unit into a suitable 220-240V~ 50Hz AC 10 AMP power supply.
  2. Hold the plug when unplugging the unit, never pull on the cord.
  3. Do not place the unit in direct sunlight. This can fade the plastic case.
  4. Do not operate the unit in a confined space.
  5. Do not place objects on top of the unit. This blocks the air outlet.
  6. Do not place the unit where the air inlets or outlets may be blocked by curtains or furniture.
  7. Keep the filters clean.


The air conditioner does not operate.

  • Connect to a functioning power supply socket and switch on.
  • Empty the internal water container
  • Press the POWER button to deactivate the TIMER function

The air conditioner is noisy: Place the air conditioner on an even, solid surface.

The compressor does not work.

  • Wait 30 minutes until the temperature has decreased, then turn the air conditioner on again.
  • Note: Compressor operation begins 3 minutes after the unit is switched on


Tags: Dimplex Air Conditioners User Manuals, Dimplex Air Conditioners Use Manual, Dimplex Reverse Cycle, Dimplex Heater, Dimplex Eco Heater Manual, Dimplex Eco Heater, Dimplex Dcss24

Dimplex DC10RC | File type: PDF | Filename: dc10rc.pdf | Size: 3.34 MB | Language: English

Download User Manual

Product Infomation and Reviews - DC10RC photo

DC10RC Photo

T: @manualsFile

Dimplex DC10RC Questions and Answers

Is this an actual aircon or an evaporative system?
This particular unit is listed as a portable air-conditioner however it does come equipped with a "Self-Evaporative system" meaning that no hose or drip tray is required. If you have any questions, please feel free to contact our customer service team 24 hours a day, 7 days a week.

What is the noise level?
Unfortunately this is not a specification that has been tested by the manufacturer.

What does the unit and packaging weigh? I am considering purchase but would need to fly it to where it would be used.
The unit itself is 28kg but unfortunately we don't have access to the packaging weight. We could assume the total weight would be under 30kg. A reminder also that warranty for this products is only valid in AU / NZ.

Too use the cooling function do you have to attach/use a window connection hose/duct? Or does it operate free-standing so you can you keep your windows closed?
While this aircon does use a self-evaporative system, which means it doesn’t require a drip tray or drain hose, it does require its exhaust hose to be attached to a nearby window. A window kit is included to fit both sash and sliding windows.
