The washer dryer was tested before leaving the factory.
Toâremove any water left over from testing procedures, the
first cycle should be carried out without any laundry with
Fluff Clean
programme. aPage 6: Before using for the
first time
Programme selector for switching the
machine on and off and for selecting the
programme. Can be rotated in either
direction.
Detailed programme overview. aPage 7/8
Detergent drawer with
compartments I, II, ~
Sort and load the laundry (drying)
Only dry laundry that is labelled with the following care symbols:
( = tumble-dry at normal heat setting (Intensive Dry).
'c= tumble-dry at low heat setting (Gentle Dry).
The following textiles should not be tumble-dried:
) = do not tumble-dry care symbol.
Woollens or items containing wool. Risk of shrinking!
Delicate fabric (silk, synthetic net curtain). Risk of creasing!
Items containing foam rubber or similar material.
Items which have been treated with flammable solvents, such as stain
removers, petrol, paint thinners. Explosion hazard!
Items still containing hair lacquer or similar substances.
Dangerous vapours!
Do not exceed the maximum drying load. aPage 7
Display panel/
Option buttons/
Additional functions
Sort and load the laundry
Observe the care information provided by the manufacturer.
Sort according to the information on the care labels.
Sort according to type, colour, soiling and temperature.
Remove any foreign objects risk of rusting.
Do not exceed the maximum load. aPage 7
If drying programme selected. aPage 4: Sort and load the laundry (drying)
Observe the instructions in the Important information section. aPage 6
Load both large and small items of washing.
Close the washer dryer door. Take care not to trap any items of clothing between the
loading door and rubber seal.
Add detergent and care product
Add the appropriate dose according to: Amount of washing, soiling, water hardness
(ask your water supply company) and manufacturers instructions.
Models without insert for liquid detergent: pour liquid detergent into an appropriate
dispenser and place in the drum.
Use commercially available low foam detergents for washer dryer only.
During operation: close the detergent drawer!
Correct installation according to separate Installation
and maintenance instructions.
Check the machine
Never switch on a damaged machine!
Inform your customer service!
Insert mains plug
With dry hands only!
Take hold of the plug only!
Turn on the tap
At the end of the drying programme there is an
automatic cleaning fluff process, turn on the water
tap even if a drying programme is selected.
Provide good ventilation
Good ventilation is required to extract air produced
during drying.
Keep the installation room well ventilated.
Clean the air inlet filter regularly.
Do not block the air inlet and/or air outlet.
Compartment II: Detergent for the main wash, water softener,
bleach, stain remover
Your washer dryer
Preparation
Before using for the first time aPage 6
Set and adjust the programme
Turn the programme selector to desired washing
programme. aPage 7: Programme overview
Use option buttons and additional functions. aPage 9/10
All buttons are sensitive and a gentle touch is adequate!
If you press and hold the
S(Temp.), (Finish in) or (Spin) option buttons,
the setting options automatically scroll through.
If washing and drying without interruption is desired (only possible for Cottons,
Cottons Eco, Mixed Load, Easy-Carecand PowerWash 60):
Activate auto drying function by touching 7(Dry) button.aPage 10
Do not exceed the maximum load for the drying function. aPage 7
Select maximun selectable spin speed of washing programme to ensure the drying
result.
Select Start/Stop
... Washing/Washing + Drying
1
Compartment ~: Fabric softener
Compartment I: Detergent for pre-wash
Intended use
ʋFor domestic use only.
ʋFor the washing of machine-washable fabrics in a detergent
solution.
ʋTo be operated with cold mains water and commercially available
low foam detergents and care products which are suitable for use
in front loaded washer dryer.
Do not leave children unattended near the washer dryer.
Keep pets away from the washer dryer!
The washer dryer is not to be used by children or persons
not familiar with the operating instructions.
Install and operate the washer dryer in a room with a drain.
In order to ensure your safety, you must plug the cable into
a socket which has a reliable earth connection.
Removing laundry
Open washer dryer door and remove laundry.
Leave the washer dryer door and detergent drawer open so that any residual
water can evaporate!
Turn off the tap
Not required for Aqua-Stop models. aInstallation maintenance instructions,
Page 9
Switch off
Set programme selector toOff.
... Drying
Drying
Washing
Washing + Drying without interruption
1
Set and adjust the drying programme
Turn the programme selector to Intensive Dry or Gentle Dry.
aPage 7: Programme overview
2
Select Start/Stop
2
Programme selector
Programme ended when ...
... Start/Stop indicator light goes out and or (if was selected, no
final spin/drain) appears on the display field, the buzzer sounds. Set volume
ofâbuzzer.
aPage 10
If was selected, and is displayed, touch the Start/Stopbutton.
The programme continues with draining the water and spinning the laundry
(the default spin speed can be changed in advance).
If you only want to drain the water, touch the Start/
Stop button again when the
spinning starts. The programme is paused and the door lock is released. You
can remove the laundry.
If appears and drying symbolc7 flashes on the display field
a high drum
temperature. Cool-down programme is running until drum is cooled down.
Ifand
appears alternately.aPage 11: Information on the display
Change the programme ...
If you have selected the wrong programme by mistake:
Reselect the washing/drying programme.
If required, adjust the programme setting and/or select additional functions.
aPage 9/10
Select Start/Stop.
Pause the programme ...
Touch the Start/Stop button.
Follow the instructions in the display field: when lights up and
appears in the display, the door can be opened. If required, add/remove
aâlaundry item; If and are displayed alternately, the door cannot
be opened due to a high water level in drum or a high temperature.
Touch Start/Stop button to continue the programme.
The pause function cannot be activated during drying phase.
... or terminate the programme
Washing programmes with high temperature:
Cool down laundry: Select Rinse, touch Start/Stop.
Washing programmes at lower temperature:
Select Spin, touch Start/Stop.
Drying programme:
Select Intensive Dry or Gentle Dry, touch 7c(Dry)
option button,
set 15âminutes drying time, then touch
Start/Stop button.
Important information
Washing drying preparing/Protecting the laundry and the machine
Empty pockets.
Look out for metal items (paperclips, etc.).
Trousers, knitwear and knitted textiles, e.g. Jersey garments, T-shirts or sweatshirts should
be turned inside out.
Ensure that underwired bras are machine washable.
Wash delicates in a net/bag (tights, curtains, underwired bras).
Fasten zips, do up any buttons.
Brush sand out of pockets and collars.
Remove curtain hooks or place curtains in a net/bag.
Use only tumble-dry textiles if you select drying.
Before tumble-drying, handwash items should be spun using the appropriate spin speed.
Remove as much water as possible before tumble-drying. Recommended spin speed for
cottons is more than 1000 rpm; for easy-care is more than 800 rpm.
In order to ensure uniform drying, sort the items according to fabric type and degree
ofâdrying required.
Items which require ironing do not have to be ironed immediately after being tumble-dried.
It is a good idea to fold or roll them together for a while, so that any remaining moisture
isâevenly distributed.
To achieve good drying performance, dry quilt covers, terry towels or other large textile
items individually. Terry towels not more than 4 pieces (or 3 kg).
Before using for the first time
Do not put any laundry in the washer dryer. Turn on the tap, pour ½ measuring cup
of detergent into dispenser II. Set the Fluff Clean 40 °C programme and select
Start/Stop.
At the end of the programme, set the programme selector to
Off.
Laundry with different degrees of soiling
Wash new items separately.
Light Do not prewash.
If required, pretreat stains. Select Cottons Eco programme
or â(intensive) additional function.
Heavy Load less laundry. Prewash.
If required, pretreat stains. Select Cottons Eco programme
or (intensive) additional function.
Soaking
Load laundry of the same colour.
Pour soaking agent/detergent into dispenser II according to the manufacturer's instructions.
Set Cottons 30 °C programme and select Start/Stop.
After approx. 10 minutes, select Start/Stop. After the required soaking time, reselect
Start/Stop if the programme is to be continued or change the programme.
Starching
Laundry must not be treated with fabric softener.
Starching is possible in all wash programmes using liquid starch. Pour the starch into the
fabric softener compartment according to the manufacturer's instructions (if necessary clean
it first).
Dyeing/bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel.
Always follow the dye manufacturer's instructions. Do not bleach laundry in the washing
machine.
Start/
Stop
Door handle
Serviceflap
Drum
Air inlet
Air outlet (rear side)
Protection of the environment/
Conservation tips
Load the maximum amount of laundry to wash or dry for the
particular programme. aPage 7: Programme overview
Wash normally soiled laundry without prewash.
Select Cottons Eco 60 °C and additional
â(Intensive)
function to obtain good cleaning results with significantly
lower energy consumption.
Dose the detergent according to the manufacturers
instructions and water hardness.
If the laundry is then to be dried in the appliance, select the
highest selectable spin speed because the more water that
is spun out of the appliance, the less time and energy isâ
required to dry it.
Keep the installation room well ventilated, clean the air inlet
filter regularly.
Installation and maintenance instructions. aPage 9
Please do not dry dripping-wet laundry.
Waste of time and energy!
Congratulations You have opted for a modern, high-quality
domestic appliance manufactured by NEFF. The washer dryer
isâdistinguished by its economical use of water and energy.
Each appliance which leaves our factory is inspected thoroughly
toâensure that it functions properly and is in perfect condition.
For further information about products, accessories, spare parts and
services visit our web site: http://www.neff-international.com or
contact our after-sales service centres.
You can find the contact details for your nearest after-sales service
here or in the after-sales service directory (depending on model).
GB 0844 8928989 Calls from a BT landline will be charged at up to
3 pence per minute. A call set-up fee of up to 6 pence may apply.
3
The default drying mode is , inâthis mode the drying time is
automatically adjusted to the load amount to obtain cupboard dried
laundry ready to fold and stack in the cupboard. You can change
the drying mode to in order to obtain extra dry laundry, or
time dry and define the drying time by touching the 7 (Dry) button,
to estimate or select drying duration. aPage 8: Drying table
All buttons are sensitive and a gentle touch is adequate!
If you press and hold the (Finish in) option buttons,
theâsetting options automatically scroll through.
Control panel
Contents
ʋIntended use........................................................................................ 1
ʋPreparation ...................................................................................... 1/2
ʋPreparation Washing or Washing + Drying ...........................2/3/4
ʋPreparation Drying .....................................................................2/3/4
ʋSet and adjust the programme................................................3/4/5
ʋAfter washing/drying.......................................................................... 5
ʋImportant information......................................................................... 6
ʋProgramme overview ......................................................................... 7
ʋDrying table ......................................................................................... 8
ʋConsumption values .......................................................................... 8
ʋDisplay and Option buttons .............................................................. 9
ʋAdditional functions and Individual settings ................................10
ʋInformation on the display ..............................................................11
ʋSafety instructions ............................................................................11
ʋWhat to do if ...............................................................................12/13
ʋEmergency release ..........................................................................13
1 2 3 4
5 6
Display panel/
Option buttons/
Additional functions
Read these instructions before switching on the washer dryer.
Also follow the separate installation instructions.
Observe the safety instructions on page 11.
7
Programme overview (see also the information on page 9,10)
Programmes °C
max. load
(kg)*
Type of laundry
Additional functions; information
Cottons
: 90
7.0/
4.0 **
Hard-wearing textiles, heat-resistant textiles made of cotton or linen
(Prewash), (Water plus), (Less Iron),
(Intensive)
Cottons Eco
: 60
Hard-wearing textiles made of cotton or linen
Sensitive : 60 7.0 Hard-wearing fabrics made of cotton or lineln
(Prewash), (Water plus), (Less Iron),
(Intensive)
for particularly sensitive skin, longer washing at the selected
temperature, higher water level, extra rinse
PowerWash 60 : 60 4.0/4.0 ** Hard-wearing textiles made of cotton or blended fabric
Time-controlled programme, 60 minutes.
Short programme for normally soiled laundry.
Easy-Care
: 60 3.5/2.5 **
Easy-Care textiles made of cotton, linen, synthetic fibres or blended
fabrics
(Prewash), (Water plus), (Less Iron)
Mixed Load
Textiles made of cotton and easy-care textiles
(Prewash), (Water plus), (Less Iron),
(Intensive)
different types of textiles which can be washed together
Delicates Silk c
: 40 2.0
For delicate, washable textiles, e.g.made of silk, satin, synthetic
fibres or blended fabrics
(Prewash), (Water plus), (Less Iron)
gentle spin between the rinse cycles only
üWool Hand or machine washable wool or rich-wool textiles
particularly gentle wash programme to prevent
shrinkage of laundry, longer breaks during the
programme (fabrics rest in the detergent solution)
Rapid 15
Easy-Care textiles made of cotton, linen, synthetic fibres or blended
fabrics
short programme, approx. 15 minutes, suitable for lightly
soiled laundry
Fluff Clean
: , 40, 90 0
Drum clean programme. 90°C= antibacterial programme, pour no detergent; 40°C= antibacterial programme for use with special
washing machine cleaning detergent; : = fluff rinsing programme to remove fluff accumulated in the tub during tumble drying.
Rinse
7.0
(Water plus), (Less Iron)
Spin
Washable textiles
(Less Iron)
Drain
Intensive Dry
4.0
Cotton/coloureds textiles, dry at normal heat setting
Gentle Dry
2.5
Easy care textiles, dry at low heat setting
The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load and select additional function, e.g. (Intensive).
* Max. load according toEN50229. Values in red: Max load for drying; Values in black: Max load for washing.
** If washing and drying without interruption is desired. The subsequent auto dry programme for Cottons, Cottons Eco and PowerWash 60 is Intensive Dry,
for Easy-Care and Mixed Load is Gentle Dry.
For further information and a selection of our products
go to our web site: http://www.neff-international.com
or contact our customer service centres
Constructa-Neff-Vertriebs-GmbH
Carl -Wery-Str.34
D-81739 Munich/Germany
V7446X0GB 9000599956
1210
Loading ...
Loading ...
Loading ...
