3-Shelf Shelving Unit on
Wheels - Black
Contents:
Make sure that the package contains the following parts:
Part
Qty.
A
3
B
4
C
4
D
2
E
2
F
1
G
TOP
12
H
8
Note: Discard the protective covers
H
. These are used to separate the shelves for
shipping purposes.
Welcome Guide
•
English
I
4
4
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 1:
Setting Up the Product
T
OP
T
OP
T
OP
TOP
T
OP
C
D
E
E
D
F
G
G
A
H H
• Remove the protective covers
H
from the shelves
A
and dispose of them.
• Screw one wheel
D
/
E
into the bottom of each lower pole
C
and fasten it
using the wrench
F
. Position them as shown in the illustration.
• Attach one half of the plastic sleeve
G
to each lower pole. Then attach the other
half of the plastic sleeve to each lower pole, so both halves are connected with
each other. The arrow above the TOP marks on the plastic sleeves should point
upwards. Four plastic sleeves are necessary to support one shelf.
• If preferred,leveling feet can be used instead of wheel for a static shelving unit.
Remove all items from shelving units and disassemble shelving unit before switching
between wheel and leveling feet.
I
5
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 2:
Setting Up the Product
Brakes engaged
Brakes not engaged
G
G
D
E
D
C
A
• Put the first shelf
A
onto the poles
C
and lower it down until it rests on the
plastic sleeves
G
. Note: Poles connected to wheel with brakes should be
placed at the back, poles connected to wheel without brakes should be
placed at the front of the assembly (as shown above).
E
• Attach another set of plastic sleeves to each lower pole for the second shelf
from the bottom.
D
6
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 3:
Setting Up the Product
C
A
G
• Put the next shelf
A
onto the poles
C
and lower it down until it rests on the
plastic sleeves
G
.
7
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 4:
Setting Up the Product
B
B
C
C
• Screw the upper poles
B
onto the lower poles
C
in a clockwise direction.
8
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 5:
Setting Up the Product
B
E
• Attach one set of plastic sleeves
E
to the upper poles
B
.
Put the last shelf
A
onto the poles
B
and lower it down until it rests on the
plastic sleeves
E
.
•
A
Cleaning and Maintenance
• Wipe with a dry cloth as needed to remove dust and dirt.
• Avoid contact with corrosive substances like acids, alkaline or similar
substances.
Safety and Compliance
• Warning: Do not let children climb on or play with the unit.
• Handle with care.
• For ease and efficiency, the product should be assembled by two adults.
• Regularly check if all screw connections are tight and if all shelves are attached
in a stable way.
• To avoid scratching the floor, assemble the shelving unit on a soft surface such
as a carpet.
• Warning: Make sure not to drill into water or electricity lines when securing the
shelving unit on the wall.
Use a wire tracer and/or a water pipe finder if necessary.
• Load the unit evenly and place the heaviest items on the lower shelves.
Maximum Load US Standard Metric
Shelving unit with wheel
Static 220 lbs 100 kg
In motion 150 lbs 68 kg
One single shelf with wheel 73 lbs 33 kg
Shelving unit with leveling feet Static 750 lbs 340 kg
Static 250 lbs 113.6 kgOne single shelf with leveling feet
