Please read this manual carefully before operating
your set and retain it for future reference.
BH9220BW (BH9220BW, S92B1-S, S92T1-C, S92B1-W, T2, W2)
BH9420PW (BH9420PW, S92T1-S, S92B1-S, S92T1-C, S92T1-W, T2, W2)
BH9520TW (BH9520TW, S92T1-S/W, S92T1-C, T2, W2)
OWNER’S MANUAL
SMART Blu-ray™
Home Theater System
1 Getting Started
Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION : CLASS 1M VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN. DO NOT VIEW DIRECTLY
WITH OPTICAL INSTRUMENTS
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.
Getting Started 3
Getting Started
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
FCC Compliance Statement
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment o and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
y
Reorient or relocate the receiving antenna.
y
Increase the separation between the equipment
and receiver.
y
Connect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
y
Consult the dealer or an experienced radio/TV
technician for help.
CAUTION: Any changes or modications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.
FCC RF Radiation Exposure Statement : This
equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated
with minimum distance 20 cm between the
radiator and your body. End users must follow the
specic operating instructions for satisfying RF
exposure compliance. This transmitter must not be
co-located or operating in conjunction with any
other antenna or transmitter.
CAUTION: Regulations of the FCC and FAA prohibit
airborne operation of radio-frequency wireless
devices because their signals could interfere with
critical aircraft instruments.
Responsible Party :
LG Electronics USA, Inc.1000 Sylvan Avenue
Englewood Clis, NJ 07632
TEL. : +1-800-243-0000
Getting Started4
Getting Started
1
Notes on Copyrights
y
Because AACS (Advanced Access Content
System) is approved as content protection
system for Blu-ray Disc format, similar to use of
CSS (Content Scramble System) for DVD format,
certain restrictions are imposed on playback,
analog signal output, etc., of AACS protected
contents. The operation of this product and
restrictions on this product may vary depending
on your time of purchase as those restrictions
may be adopted and/or changed by AACS after
the production of this product.
y
Furthermore, BD-ROM Mark and BD+ are
additionally used as content protection systems
for Blu-ray Disc format, which imposes certain
restrictions including playback restrictions for
BD-ROM Mark and/or BD+ protected contents.
To obtain additional information on AACS, BD-
ROM Mark, BD+, or this product, please contact
an authorized Customer Service Centre.
y
Many BD-ROM/DVD discs are encoded with
copy protection. Because of this, you should only
connect your player directly to your TV, not to a
VCR. Connecting to a VCR results in a distorted
picture from copy-protected discs.
y
This product incorporates copyright protection
technology that is protected by U.S. patents
and other intellectual property rights. Use of
this copyright protection technology must be
authorized by Rovi, and is intended for home and
other limited viewing uses only unless otherwise
authorized by Rovi. Reverse engineering or
disassembly is prohibited.
y
Under the U.S. Copyright laws and Copyright
laws of other countries, unauthorized recording,
use, display, distribution, or revision of television
programs, videotapes, BD-ROM discs, DVDs, CDs
and other materials may subject you to civil and/
or criminal liability.
y
Watching a 3D content for a long period
time may cause dizziness or tiredness.
y
It is not recommended to watch a movie
in 3D mode for inrm, child and pregnant
woman.
y
If you are experiencing headache, tiredness
or dizziness while viewing contents in 3D,
it is strongly recommended to stop the
playback and rest until you feel normal.
>
Caution
Getting Started 5
Getting Started
1
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand,
tripod, bracket, or table
specified by the manufacturer,
or sold with the apparatus.
When a cart is used, use
caution when moving the cart/
apparatus combination to avoid injury from tip-
over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Table of Contents6
Table of Contents
1 Getting Started
2 Safety Information
8 Introduction
8 – Playable Discs and symbols used in
this manual
9 – About the “7” Symbol Display
9 – Compatibility Notes
10 – File requirement
11 – AVCHD (Advanced Video Codec High
Definition)
12 – About DLNA
12 – Certain System Requirements
12 – Regional Code
13 Remote control
14 Front panel
15 Rear panel
2 Connecting
16 Positioning the system
17 Speaker Connection
17 – Attaching the speakers to the player
18 – Wireless speakers connection
20 Connecting to Your TV
20 – HDMI Connection
21 – What is SIMPLINK?
21 – ARC (Audio Return Channel) function
22 – Video Connection
22 – Resolution Setting
23 Antenna connection
24 Connections with external device
24 – AUX Connection
24 – PORT. IN connection
25 – OPTICAL IN connection
25 – HDMI IN 1/2 connection
26 Connecting to your Home Network
26 – Wired network connection
27 – Wired Network Setup
28 – Wireless Network Connection
28 – Wireless Network Setup
31 USB device connection
31 – Playback content in the USB device
3 System Setting
32 Settings
32 – Initial Setup
34 – Adjust the Setup Settings
34 – [DISPLAY] Menu
36 – [LANGUAGE] Menu
36 – [AUDIO] Menu
38 – [LOCK] Menu
39 – [NETWORK] Menu
40 – [OTHERS] Menu
41 Sound Effect
41 Sound Zoom Effect (4.1 CH or 2.1 CH)
4 Operating
42 General Playback
42 – Using [HOME] menu
42 – Playing a Disc
42 – Playing a file on a disc/USB device
43 – Playing Blu-ray 3D disc
43 – Enjoying BD-Live™
44 – Playing a file on a network server
44 – Wi-Fi Direct™ Connection
46 – Basic operations for video and audio
content
47 – Basic operations for photo content
47 – Using the disc menu
47 – Resume playback
47 – Last Scene Memory
48 Advanced Playback
48 – Repeat Playback
48 – Repeating a specific portion
48 – Viewing content information
49 – Changing content list view
49 – Selecting a subtitle file
50 – Options while viewing a photo
50 – Listening to music while slide show
51 On-Screen display
51 – Displaying content information on-
screen
52 – Playing from selected time
52 – Selecting a subtitle language
52 – Hearing a different audio
52 – Watching from a different angle
53 – Changing the TV Aspect Ratio
53 – Changing subtitle code page
Table of Contents 7
1
2
3
4
5
6
53 – Changing the Picture Mode
54 Audio CD Recording
55 Playing the iPod
55 – Enjoying iPod on the screen
55 – Enjoying the iPod IN mode
57 Radio Operations
57 – Listening to the radio
57 – Presetting the Radio Stations
57 – Deleting a saved station
57 – Deleting all the saved stations
57 – Improving poor FM reception
58 Using the Premium
58 Using the LG Apps
59 – Signing in
59 – Managing my Apps
59 – Searching online content
60 Using Bluetooth technology
60 – Listening to music stored on the
Bluetooth devices
5 Troubleshooting
62 Troubleshooting
62 – General
63 – Network
64 – Picture
64 – Sound
64 – Customer Support
64 – Open source software notice
6 Appendix
65 Controlling a TV with the Supplied
Remote Control
65 – Setting up the remote to control your
TV
66 Network Software Update
66 – Network update notification
66 – Software Update
68 About Nero MediaHome 4 Essentials
68 – System Requirements
69 – Installing Nero MediaHome 4
Essentials
69 – Sharing files and folders
70 Area Code List
71 Language code List
72 Trademarks and Licenses
74 Audio Output Specifications
75 Specifications
79 Maintenance
79 – Handling the Unit
79 – Notes on Discs
80 Important Information Relating to
Network Services
Getting Started8
Getting Started
1
Introduction
Playable Discs and symbols used in this manual
Media/Term Logo Symbol Description
Blu-Ray
e
y
Discs such as movies that can be purchased or
rented.
y
“Blu-ray 3D” discs and “Blu-ray 3D ONLY” discs.
y
BD-R/RE discs that are recorded in BDAV format.
y
u
i
y
BD-R/RE discs that contain Movie, Music or
Photo les.
y
ISO 9660+JOLIET, UDF and UDF Bridge format
DVD-ROM
DVD-R
DVD-RW
DVD+R
DVD+RW
(12 cm)
r
y
Discs such as movies that can be purchased or
rented.
y
Movie mode and nalized only
y
Supports the dual layer disc also
o
Finalized AVCHD format
y
u
i
y
DVD±R/RW discs that contain Movie, Music or
Photo les.
y
ISO 9660+JOLIET, UDF and UDF Bridge format
DVD-RW
(VR)
(12 cm)
r
VR mode and nalized only
Audio CD
(12 cm)
t
Audio CD
CD-R/RW
(12 cm)
y
u
i
y
CD-R/RW discs that contain Movie, Music or
Photo les.
y
ISO 9660+JOLIET, UDF and UDF Bridge format
Note –
,
Indicates special notes and operating features.
Caution –
>
Indicates cautions for preventing possible
damages from abuse.
Getting Started 9
Getting Started
1
y
Depending on the conditions of the
recording equipment or the CD-R/RW (or
DVD±R/RW) disc itself, some CD-R/RW (or
DVD±R/RW) discs cannot be played on the
unit.
y
Depending on the recording software & the
nalization, some recorded discs (CD-R/RW,
DVD±R/RW, BD-R/RE) may not be playable.
y
BD-R/RE, DVD±R/RW and CD-R/RW discs
recorded using a personal computer or a
DVD or CD Recorder may not play if the
disc is damaged or dirty, or if there is dirt or
condensation on the player’s lens.
y
If you record a disc using a personal
computer, even if it is recorded in a
compatible format, there are cases in which
it may not play because of the settings of
the application software used to create the
disc. (Check with the software publisher for
more detailed information.)
y
This player requires discs and recordings to
meet certain technical standards in order to
achieve optimal playback quality.
y
Pre-recorded DVDs are automatically set to
these standards. There are many dierent
types of recordable disc formats (including
CD-R containing MP3 or WMA les) and
these require certain pre-existing conditions
to ensure compatible playback.
y
Customers should note that permission
is required in order to download MP3 /
WMA les and music from the Internet.
Our company has no right to grant such
permission. Permission should always be
sought from the copyright owner.
y
You have to set the disc format option
to [Mastered] in order to make the discs
compatible with the LG players when
formatting rewritable discs. When setting
the option to Live System, you cannot use
it on LG player. (Mastered/Live File System :
Disc format system for windows Vista)
,
Note
About the “
7
” Symbol Display
“
7
” may appear on your TV display during
operation and indicates that the function explained
in this owner’s manual is not available on that
specic media.
Compatibility Notes
y
Because BD-ROM is a new format, certain disc,
digital connection and other compatibility issues
are possible. If you experience compatibility
problems, please contact an authorized
Customer Service Center.
y
This unit allows you to enjoy functions such
as picture-in-picture, secondary audio and
Virtual packages, etc., with BD-ROM supporting
BONUSVIEW (BD-ROM version 2 Prole 1 version
1.1). Secondary video and audio can be played
from a disc compatible with the picture-in-
picture function. For the playback method, refer
to the instructions in the disc.
y
Viewing high-denition content and up-
converting standard DVD content may require a
HDMI-capable input or HDCP-capable DVI input
on your display device.
y
Some BD-ROM and DVD discs may restrict the
use of some operation commands or features.
y
You can use a USB device to store some disc
related information, including downloaded on-
line content. The disc you are using will control
how long this information is retained.
Getting Started10
Getting Started
1
File requirement
Movie files
File
Location
File
Extension
Codec Format Audio Format Subtitle
Disc,
USB
“.avi”, “.mpg”,
“.mpeg”, “.mkv”,
“.mp4”, “.asf”,
“.wmv”, “.m4v”
(DRM free),
“.vob”, “.3gp”
XVID, MPEG1 SS,
H.264/MPEG-4 AVC,
MPEG2 PS, MPEG2 TS,
VC-1 SM (WMV3)
Dolby Digital,
DTS, MP3,
WMA, AAC,
AC3
SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt),
MicroDVD (.sub/.txt), VobSub
(.sub), SubViewer 1.0 (.sub),
SubViewer 2.0 (.sub/.txt), TMPlayer
(.txt), DVD Subtitle System (.txt)
DLNA
“.avi”, “.mpg”,
“.mpeg”, “.mkv”,
“.mp4”, “.asf”,
“.wmv”, ".m4v
(DRM free)
XVID, MPEG1 SS,
H.264/MPEG-4 AVC,
MPEG2 PS, MPEG2 TS,
VC-1 SM (WMV3)
Dolby Digital,
DTS, MP3,
WMA, AAC,
AC3
SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt),
MicroDVD (.sub/.txt), SubViewer
1.0 (.sub), SubViewer 2.0 (.sub/.
txt), TMPlayer (.txt), DVD Subtitle
System (.txt)
Music files
File
Location
File
Extension
Sampling Frequency Bitrate Note
Disc,
USB
“mp3”, “.wma”,
“.wav”, “.m4a”
(DRM free),
“.ac”
within 32 - 48 kHz
(WMA), within 16 - 48
kHz (MP3)
within 32 - 192
kbps (WMA), within
32 - 320 kbps (MP3)
Some wav les are
not supported on this
player.
DLNA
“mp3”, “.wma”,
“.wav”, “.m4a”
(DRM free)
within 32 - 48 kHz
(WMA), within 16 - 48
kHz (MP3)
within 32 - 192
kbps (WMA), within
32 - 320 kbps (MP3)
Some wav les are
not supported on this
player.
Photo files
File
Location
File
Extension
Recommended
Size
Note
Disc,
USB,
DLNA
“.jpg”, “.jpeg”,
“.png”, “.gif”
Less than 4,000 x 3,000 x 24 bit/pixel
Less than 3,000 x 3,000 x 32 bit/pixel
Progressive and lossless
compression photo image les
are not supported.
y
Supplied bundle DLNA server for Macintosh edition has limitations in le compatibility, such as ASF, WMA
and WMV.
Getting Started 11
Getting Started
1
y
The le name is limited to 180 characters.
y
Maximum les/folder: Less than 2 000
(total number of les and folders)
y
Depending on the size and number of the
les, it may take several minutes to read the
contents on the media.
y
File compatibility may dier depending on
the server.
y
Because the compatibility on DLNA server
are tested on the bundle DLNA server
(Nero MediaHome 4 Essentials Windows
edition) environment, le requirements and
playback functions may dier depending on
media servers.
y
The le requirements on page 10 are
not always compatible. There may have
some restrictions by le features and media
server’s ability.
y
Playing a movie subtitle les are only
available on share folder of a PC or DLNA
media server created by supplied Nero
MediaHome 4 Essentials software on this
player package.
y
The les from removable media such as USB
drive, DVD-drive etc. on your media server
may not be shared properly.
y
This unit cannot support the ID3 Tag
embedded MP3 le.
y
The total playback time of audio le
indicated on the screen may not correct for
VBR les.
y
HD movie les contained on the CD/DVD or
USB 1.0/1.1 may not played properly.
Blu-ray Disc or USB 2.0 are recommended to
play back HD movie les.
y
This player supports H.264/MPEG-4 AVC
prole Main, High at Level 4.1. For a le
with higher level, the warning message will
appear on the screen.
y
This player does not support les that are
recorded with GMC
*
1
or Qpel
*
2
.
*1 GMC – Global Motion Compensation
*2 Qpel – Quarter pixel
,
Note
y
A “avi” le which is encoded “WMV 9 codec”
is not supported.
y
This player supports UTF-8 les even it
contains Unicode subtitle contents. This
player can not support the pure Unicode
subtitle les.
y
Depending on the types of le or ways of
recording, it may not play back.
y
A disc which was recorded by multi-session
on normal PC is not supported on this
player.
y
To be playback a movie le, movie le name
and Subtitle le name must be the same.
y
If video codec is MPEG2 TS or MPEG2 PS,
subtitle does not play back.
y
The total playback time of music le
indicated on the screen may not correct for
VBR les.
,
Note
AVCHD (Advanced Video
Codec High Definition)
y
This player can playback AVCHD format discs.
These discs are normally recorded and used in
camcorders.
y
The AVCHD format is a high denition digital
video camera format.
y
The MPEG-4 AVC/H.264 format is capable of
compressing images at higher eciency than
that of the conventional image compressing
format.
y
This player can playback AVCHD discs using
“x.v.Color” format.
y
Some AVCHD format discs may not play
depending on the recording condition.
y
AVCHD format discs need to be nalized.
y
“x.v.Color” oers a wider color range than normal
DVD camcorder discs.
Getting Started12
Getting Started
1
About DLNA
This Player is a DLNA Certied digital media player
that can display and play movie, photo and music
content from your DLNA-compatible digital media
server (PC and Consumer Electronics).
The Digital Living Network Alliance (DLNA) is a
cross-industry organization of consumer electronics,
computing industry and mobile device companies.
Digital Living provides consumers with easy sharing
of digital media through your home network.
The DLNA certication logo makes it easy
to nd products that comply with the DLNA
Interoperability Guidelines. This unit complies with
DLNA Interoperability Guidelines v1.5.
When a PC running DLNA server software or
other DLNA compatible device is connected to
this player, some setting changes of software or
other devices may be required. Please refer to the
operating instructions for the software or device for
more information.
Certain System Requirements
For high denition video playback:
y
High denition display that has HDMI input jack.
y
BD-ROM disc with high denition content.
y
HDMI or HDCP capable DVI input on your display
device is required for some content (as specied
by disc authors).
Regional Code
This unit has a regional code printed on the rear of
the unit. This unit can play only BD-ROM or DVD
discs labeled same as the rear of the unit or “ALL”.
Getting Started 13
Getting Started
1
Remote control
Battery Installation
Remove the battery cover on the
rear of the Remote Control, and
insert two R03 (size AAA) batteries
with
4
and
5
matched correctly.
• • • • • •
a
• • • • • •
1
(POWER): Switches the player
ON or OFF.
B
(OPEN/CLOSE): Ejects a disc.
FUNCTION: Changes input mode.
0-9 numerical buttons: Selects
numbered options in a menu.
CLEAR: Removes a mark on the
search menu or a number when
setting the password.
REPEAT (
h
): Repeats a desired
section or sequence.
• • • • • •
b
• • • • •
c/v
(SCAN): Searches
backward or forward.
C/V
(SKIP): Goes to the
next or previous chapter / track /
le.
Z
(STOP): Stops playback.
d
(PLAY): Starts playback.
M
(PAUSE): Pauses playback.
SPEAKER LEVEL: Sets the sound
level of desired speaker.
SOUND EFFECT: Selects a sound
eect mode.
VOL +/-: Adjusts speaker volume.
OPTICAL: Changes input mode to
optical directly.
MUTE: Mute the unit.
• • • • • •
c
• • • • •
HOME ( ): Displays or exits the
[Home Menu].
SOUND ZOOM : Selects a Sound
Zoom eect mode.
INFO/MENU (
m
): Displays or
exits On-Screen Display.
Direction buttons: Selects an
option in the menu.
PRESET +/-: Selects programme
of Radio.
TUNING +/-: Tunes in the desired
radio station.
ENTER (
b
): Acknowledges menu
selection.
BACK (
1
): Exits the menu or
returns to the previous screen.
TITLE/POP-UP: Displays the DVD
title menu or BD-ROM’s pop-up
menu, if available.
DISC MENU: Accesses menu on a
disc.
• • • • • •
d
• • • • •
Colored (R, G, Y, B) buttons:
- Use to navigate BD-ROM menus.
They are also used for [MOVIE],
[PHOTO], [MUSIC], [Premium] and
[LG Apps] menu.
- B button: Selects mono/ stereo
in FM mode.
SUBTITLE: Selects a subtitle
language.
AUDIO: Selects an audio language
or audio channel.
SLEEP: Sets a certain period of
time after which the unit will
switch to o.
X
REC : Records an audio CD.
TV Control Buttons: See page
65.
Getting Started14
Getting Started
1
Front panel
a
Disc Slot
b
Display Window
c
Remote Sensor
d
PORT. IN
e
iPod/ iPhone/ iPad/ USB Port
f
Operation buttons
R
(OPEN/CLOSE)
T
(PLAY / PAUSE)
I
(STOP)
F (Function)
Changes the input source or function.
VOL. -/+
1
(POWER)
Precautions in using the touch buttons
y
Use the touch buttons with clean and dry
hands.
- In a humid environment, wipe out any
moisture on the touch buttons before
using.
y
Do not press the touch buttons hard to
make it work.
- If you apply too much strength, it can
damage the sensor of the touch buttons.
y
Touch the button that you want to work in
order to operate the function correctly.
y
Be careful not to have any conductive
material such as metallic object on the
touch buttons. It can cause malfunctions.
>
Caution
Getting Started 15
Getting Started
1
Rear panel
a
AC power cord
b
Speakers connectors
c
Cooling Fan
d
OPTICAL IN
e
WIRELESS connector
f
Antenna Connector
g
AUX (L/R) INPUT
h
LAN port
i
HDMI IN 1/2
j
HDMI OUT TO TV
k
VIDEO OUT
2 Connecting
Connecting16
Connecting
2
Positioning the system
The following illustration shows an example of
positioning the system. Note that the illustrations
in these instructions dier from the actual unit for
explanation purposes.
For the best possible surround sound, all the
speakers other than the subwoofer should be
placed at the same distance from the listening
position (
A
B
D
D
E
E
F
F
A
A
A
A
A
G
G
C
C
A
B
A
).
A
B
D
D
E
E
F
F
A
A
A
A
A
G
G
C
C
A
B
A
A
B
D
D
E
E
F
F
A
A
A
A
A
G
G
C
C
A
B
A
Front left speaker (L)/
A
B
D
D
E
E
F
F
A
A
A
A
A
G
G
C
C
A
B
A
Front right speaker (R):
Place the front speakers to the sides of the monitor
or screen and as ush with the screen surface as
possible.
A
B
D
D
E
E
F
F
A
A
A
A
A
G
G
C
C
A
B
A
Center speaker:
Place the center speaker above or below the
monitor or screen.
A
B
D
D
E
E
F
F
A
A
A
A
A
G
G
C
C
A
B
A
Surround left speaker (L)/
A
B
D
D
E
E
F
F
A
A
A
A
A
G
G
C
C
A
B
A
Surround right speaker (R):
Place these speakers behind your listening position,
facing slightly inwards.
A
B
D
D
E
E
F
F
A
A
A
A
A
G
G
C
C
A
B
A
Subwoofer:
The position of the subwoofer is not so critical,
because low bass sounds are not highly directional.
But it is better to place the subwoofer near the
front speakers. Turn it slightly toward the center of
the room to reduce the wall reections.
A
B
D
D
E
E
F
F
A
A
A
A
A
G
G
C
C
A
B
A
Unit
y
Be careful to make sure children not to put
their hands or any objects into the *speaker
duct.
*Speaker duct: A hole for plentiful bass
sound on speaker cabinet (enclosure).
y
Place the center speaker at a safe distance
from the child’s reach.
Otherwise it may result in the speaker falling
down and causing personal injury and/or
property damage.
y
The speakers contain magnetic parts, so
colour irregularity may occur on the CRT
TV screen or PC monitor screen. Please use
the speakers away from the TV screen or PC
monitor screen.
y
Before using the subwoofer, remove the
protective vinyl.
y
This product is specially designed to
produce the eect of the 3D Sound.
Other speakers may not operate normally
when connected.
>
Caution
Connecting 17
Connecting
2
Speaker Connection
Attaching the speakers to the
player
1. Connect speaker cords to the player.
Each speaker connector is color-coded.
Use matching color connector for
corresponding speakers. When connecting
speaker cords to the player, insert the connector
until it clicks.
Connector
color
Speaker Position
Green Center Center
Orange Subwoofer Any front position
Red Front right Front right
White Front left Front left
2. Connect the speaker cord to the connector on
the speaker.
Connecting18
Connecting
2
Wireless speakers connection
LED indicator of wireless receiver
LED Color Operation
Blue or yellow The wireless receiver is receiving
the signal of the wireless TX.
Red The Wireless Receiver is in
standby mode.
O (No
display)
The power cord of wireless
receiver is disconnected.
Setting up the wireless receiver for
the first time
1. Connect the Wireless Receiver and the rear
speaker (right, left) with the speaker cables.
Color Speaker Position
Grey Rear Rear right
Blue Rear Rear left
2. Connect the power cord of the Wireless
Receiver to the outlet.
3. Turn off the unit and insert the Wireless TX into
the WIRELESS connector on the rear of the unit.
Line
4. Turn on the main unit: The main unit and
wireless receiver will be automatically
connected.
y
Insert the Wireless TX with the marked
“Wireless TX" facing upwards to rear on the
unit.
y
Insert the Wireless TX to the line on the
Wireless TX into the WIRELESS connector on
the rear of the unit.
y
Do not insert a wireless dongle other than
the Wireless TX dongle dedicated for the
product. The product might be damaged or
it may not be removed easily.
>
Caution
Manually pairing wireless receiver
When your connection is not completed, you can
see the red LED on the wireless receiver and rear
speakers are not made sound. To solve the problem,
follow the below steps.
1. Press and hold
I
STOP button on the unit
and
MUTE button on the remote control
simultaneously.
- Displays the “REMATE”.
2. Press PAIRING on back of the wireless receiver.
- The blue or yellow LED will flicker
3. Turn off and on the unit.
- If you see “blue or yellow” LED, it’ s successful.
4. If you don’t see “blue or yellow” LED, try again
Step 1 - Step 3.
Connecting 19
Connecting
2
About Ferrite Core (for EMI only)
Be sure to attach the ferrite core to the power cord
(for connecting to this unit and wireless receiver).
This ferrite core can reduce noises.
How to attach the ferrite core
1. Press the stopper [a] of the ferrite core to open.
2. Wind the power cord on the wireless receiver
once on the ferrite core.
3. Close the ferrite core until it clicks.
Refer to the fig.3 and comment.
2 Connecting
About Ferrite Core (for EMI only)
Be sure to attach the ferrite core to the speaker
cable. This ferrite core can reduce noises.
How to attach the ferrite core
1. Press the stopper [a] of the ferrite core to open.
2. Wind the power code of the unit
once
on
the ferrite
core.
3. Close the ferrite core until it clicks.
Refer to the g.3 and comment.
(g.3)
y
If there is a strong electromagnetic wave
product nearby, interference may occur. Put
the unit (Wireless Receiver and main unit)
away from there.
y
If there is no audio signal for longer than
10 minutes, the Wireless Receiver will
automatically switch to standby mode. In
power saving mode, both LEDs will turn red.
LEDs will turn blue or yellow when there is
any audio signal back.
y
If you operate main unit then wireless
speakers (rear speakers) sound within a few
seconds in standby mode.
y
Set the distance between this unit and
Wireless Receiver within 10 m (32 ft.).
y
Optimum performance can be
implemented only when the Wireless TX
and the Wireless Receiver within distance
of 2 m (6 ft.) to 10 m (32 ft.) is used since
communication failure may occur if longer
distance is used.
y
Be sure to match the speaker cable to the
appropriate terminal on the components:
+ to + and – to –. If the cables are reversed,
the sound will be distorted and will lack
bass.
y
It takes a few seconds (and may take longer)
for the Wireless TX and Wireless Receiver to
communicate with each other.
y
Use the rear speaker at least 30 cm (11 inch)
away from either TV screen or PC monitor.
,
Note
Connecting20
Connecting
2
Connecting to Your TV
Make one of the following connections, depending
on the capabilities of your existing equipment.
y
HDMI connection (page 20)
y
Video connection (page 22)
y
Depending on your TV and other
equipment you wish to connect, there are
various ways you could connect the player.
Use only one of the connections described
in this manual.
y
Please refer to the manuals of your TV,
stereo system or other devices as necessary
to make the best connections.
y
Make sure the player is connected directly
to the TV. Tune the TV to the correct video
input channel.
y
Do not connect your player via your VCR.
The image could be distorted by the copy
protection system.
,
Note
HDMI Connection
If you have a HDMI TV or monitor, you can connect
it to this player using a HDMI cable (Type A, High
speed HDMI™ cable with Ethernet). Connect the
HDMI jack on the player to the HDMI jack on a
HDMI compatible TV or monitor.
Rear of the unit
TV
HDMI
cable
Set the TV’s source to HDMI (refer to TV’s Owner’s
manual).
Additional Information for HDMI
y
When you connect a HDMI or DVI compatible
device make sure of the following:
-
Try switching o the HDMI/DVI device and
this player. Next, switch on the HDMI/DVI
device and leave it for around 30 seconds,
then switch on this player.
-
The connected device’s video input is set
correctly for this unit.
-
The connected device is compatible with
720x480p, 1280x720p, 1920x1080i or
1920x1080p video input.
y
Not all HDCP-compatible HDMI or DVI devices
will work with this player.
-
The picture will not be displayed properly
with non-HDCP device.
Connecting 21
Connecting
2
y
If a connected HDMI device does not accept
the audio output of the player, the HDMI
device’s audio sound may be distorted or
may not output.
y
When you use HDMI connection, you can
change the resolution for the HDMI output.
(Refer to “Resolution Setting” on page 22.)
y
Select the type of video output from the
HDMI OUT jack using [HDMI Color Setting]
option on the [Setup] menu (see page
35).
y
Changing the resolution when the
connection has already been established
may result in malfunctions. To solve the
problem, turn o the player and then turn it
on again.
y
When the HDMI connection with HDCP
is not veried, TV screen is changed to
black screen. In this case, check the HDMI
connection, or disconnect the HDMI cable.
y
If there are noises or lines on the screen,
please check the HDMI cable (length is
generally limited to 4.5 m(15 ft.)).
,
Note
What is SIMPLINK?
Some functions of this unit are controlled by the
TV’s remote control when this unit and LG TV’s with
SIMPLINK are connected through HDMI connection.
Controllable functions by LG TV’s remote control;
Play, Pause, Scan, Skip, Stop, Power O, etc.
Refer to the TV owner’s manual for the details of
SIMPLINK function.
LG TV’s with SIMPLINK function has the logo as
shown above.
Depending on the disc type or playing status,
some SIMPLINK operation may dier from your
purpose or not work.
,
Note
ARC (Audio Return Channel)
function
The ARC function enables an HDMI capable TV to
send the audio stream to HDMI OUT of this player.
To use this function:
-
Your TV must support the HDMI-CEC and ARC
function and the HDMI-CEC and ARC must be
set to On.
-
The setting method of HDMI-CEC and ARC may
dier depending on the TV. For details about
ARC function, refer to your TV manual.
-
You must use the HDMI cable (Type A, High
Speed HDMI™ cable with Ethernet).
-
You must connect with the HDMI IN that
supports the ARC function using the HDMI OUT
on this player.
-
You can connect only one Home Theater to TV
compatible with ARC.
22
Connecting
2
Connecting
Video Connection
Connect the VIDEO OUT jack on the player to the
video in jack on the TV using a video cable. You can
hear the sound through the system’s speakers.
Rear of the unit
TV
Video cable
Resolution Setting
The player provides several output resolutions for
HDMI OUT jack. You can change the resolution
using [Setup] menu.
1.
Press HOME ( ).
2. Use
A/D
to select the [Setup] and press ENTER
(
b
). The [Setup] menu appears.
3.
Use
W/S
to select [DISPLAY] option then
press
D
to move to the second level.
4.
Use
W/S
to select the [Resolution] option
then press ENTER (
b
) to move to the third level.
5. Use
W/S
to select the desired resolution then
press ENTER (
b
) to confirm your selection.
Connecting 23
Connecting
2
y
If your TV does not accept the resolution
you have set on the player, you can set
resolution to 480p as follows:
1. Press HOME (
) to disappear the HOME
menu.
2 Press
Z
(STOP) for more than 5 seconds.
y
When you set the resolution to 480i with
HDMI connection, actual resolution is
outputted to 480p.
y
If you select a resolution manually and then
connect the HDMI jack to TV and your TV
does not accept it, the resolution setting is
set to [Auto].
y
If you select a resolution that your TV
does not accept, the warning message
will appear. After resolution change,
if you cannot see the screen, please
wait 20 seconds and the resolution will
automatically revert back to the previous
resolution.
y
The 1080p video output frame rate may
be automatically set to either 24 Hz or
60 Hz depending both on the capability
and preference of the connected TV and
based on the native video frame rate of the
content on the BD-ROM disc.
y
The resolution of the VIDEO OUT jack is
always outputted at 480i resolution.
,
Note
Antenna connection
Connect the supplied antenna for listening to the
radio.
Rear of the unit
After connecting the FM wire antenna, keep
it as horizontal as possible. Be sure to fully
extend the FM wire antenna.
,
Note
Connecting24
Connecting
2
Connections with
external device
AUX Connection
You can enjoy the sound from an external
component through the speakers of this system.
Connect the analog audio output jacks of your
component into the AUX L/R (INPUT) on this unit.
And then select the [AUX] option by pressing
FUNCTION and ENTER (
b
).
You can also use the F (Function) button on the
front panel to select the input mode.
To the audio output jacks
of your component
(TV, VCR, etc.)
Rear of the unit
Red
White
PORT. IN connection
You can enjoy the sound from your portable audio
player through the speakers of this system.
Connect the headphones (or line out ) jack of the
portable audio player into the PORT. IN socket of
this unit. And then select the [PORTABLE] option by
pressing FUNCTION and ENTER (
b
).
You can also use the F (Function) button on the
front panel to select the input mode.
MP3 player, etc...
Connecting 25
Connecting
2
OPTICAL IN connection
You can enjoy the sound from your component
with a digital optical connection through the
speakers of this system.
Connect the optical output jack of your component
into the OPTICAL IN jack on the unit. And then
select the [OPTICAL] option by pressing FUNCTION
and ENTER (
b
). Or press OPTICAL to select directly.
You can also use the F (Function) button on the
front panel to select the input mode.
To the digital
optical output jack
of your component
Rear of the unit
HDMI IN 1/2 connection
You can enjoy the pictures and sound from your
component through this connection.
Connect the HDMI OUT jack of your component
into the HDMI IN 1 or 2 jack on this unit. And
then select the [HDMI IN 1/2] option by pressing
FUNCTION and ENTER (
b
).
You can also use the F (Function) button on the
front panel to select the input mode.
To the HDMI
OUT jack of your
component
(set-top box, digital
satellite receiver,
video game
machine, etc.)
Rear of the unit
y
You cannot change the video resolution in
the HDMI IN 1/2 mode. Change the video
resolution of the connected component.
y
If the video output signal is abnormal when
your personal computer is connected to
HDMI IN 1/2 jack, change the resolution
of your personal computer to 480p, 720p,
1080i or 1080p.
y
The video signal from the HDMI input
cannot be output from the component or
composite video outputs.
y
The player sends audio from the HDMI
inputs to both the HDMI output and to the
unit’s speakers.
,
Note
Connecting26
Connecting
2
Connecting to your
Home Network
This player can be connected to a local area
network (LAN) via the LAN port on the rear panel or
the internal wireless module.
By connecting the unit to a broadband home
network, you have access to services such as
software updates, BD-LIVE interactivity and on-line
content services.
Wired network connection
Using a wired network provides the best
performance, because the attached devices
connect directly to the network and are not subject
to radio frequency interference.
Please refer to the documentation for your network
device for further instructions.
Connect the player’s LAN port to the corresponding
port on your Modem or Router using a
commercially available LAN or Ethernet cable.
y
When plugging or unplugging the LAN
cable, hold the plug portion of the cable.
When unplugging, do not pull on the LAN
cable but unplug while pressing down on
the lock.
y
Do not connect a modular phone cable to
the LAN port.
y
Since there are various connection
congurations, please follow the
specications of your telecommunication
carrier or internet service provider.
y
If you want to access content from DLNA
servers, this player must be connected to
the same local area network with them via a
router.
y
To set your PC as a DLNA server, install the
supplied Nero MediaHome 4 on your PC.
(see page 68)
,
Note
Rear of the unit
Router
Broadband
service
DLNA certied servers
Connecting 27
Connecting
2
Wired Network Setup
If there is a DHCP server on the local area network
(LAN) via wired connection, this player will
automatically be allocated an IP address. After
making the physical connection, a small number of
home networks may require the player’s network
setting to be adjusted. Adjust the [NETWORK]
setting as follow.
Preparation
Before setting the wired network, you need to
connect the broadband internet to your home
network.
1. Select [Connection Setting] option in the
[Setup] menu then press ENTER (
b
).
2. Read the preparations for the network settings
and then press ENTER (
b
) while [Start] is
highlighted.
Network will automatically be connected to the
unit.
Advanced Setting
If you want to set the network settings manually,
use
W/S
to select [Advanced Setting] on the
[Network Setting] menu and press ENTER (
b
).
1. Use
W/S
to select [Wired] and press ENTER
(
b
).
2. Use
W/S/A/D
to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.
If there is no DHCP server on the network and
you want to set the IP address manually, select
[Static] then set [IP Address], [Subnet Mask],
[Gateway] and [DNS Server] using
W/S/A/D
and numerical buttons. If you
make a mistake while entering a number, press
CLEAR to clear the highlighted part.
,
Note
3. Select [Next] and press ENTER (
b
) to apply
network settings.
Network connection status is displayed on the
screen.
4. Press ENTER (
b
) while [Close] is highlighted to
finish the wired network settings.
Connecting28
Connecting
2
Wireless Network Connection
Another connection option is to use an Access Point
or a wireless router. The network conguration and
connection method may vary depending on the
equipment in use and the network environment.
Wireless
Communication
DLNA certied servers
Access Point or
Wireless Router
Broadband
service
Refer to the setup instructions supplied with
your access point or wireless router for detailed
connection steps and network settings.
For best performance, a direct wired connection
from this player to your home network’s router or
cable/DSL modem is always the best option.
If you do chose to use the wireless option, note that
performance can sometimes be aected by other
electronic devices in the home.
Wireless Network Setup
For the wireless network connection, the player
needs to be set up for network communication.
This adjustment can be done from the [Setup]
menu. Adjust the [NETWORK] setting as follow.
Setting up the access point or the wireless router
is required before connecting the player to the
network.
Preparation
Before setting the wireless network, you need
to:
-
connect the broadband internet to the
wireless home network.
-
set the access point or wireless router.
-
note the SSID and security code of the
network.
1. Select [Connection Setting] option in the
[Setup] menu then press ENTER (
b
).
2. Read the preparations for the network settings
and then press ENTER (
b
) while [Start] is
highlighted.
If wired network is not connected to the unit, all
available networks are displayed on the screen.
3. Use
W/S
to select a desired SSID of wireless
network and press ENTER (
b
).
If you have security on your access point, you
need to input the security code as necessary.
Connecting 29
Connecting
2
y
WEP security mode generally have 4 keys
available on an access point setting. If your
access point or wireless router use WEP
security, enter the security code of the key
“No.1” to connect on your home network.
y
An Access Point is a device that allows you
to connect to your home network wirelessly.
,
Note
4. Use
W/S/A/D
to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.
If there is no DHCP server on the network and
you want to set the IP address manually, select
[Static] then set [IP Address], [Subnet Mask],
[Gateway] and [DNS Server] using
W/S/A/D
and numerical buttons. If you
make a mistake while entering a number, press
CLEAR to clear the highlighted part.
,
Note
5. Select [Next] and press ENTER (
b
) to apply
network settings.
Network connection status is displayed on the
screen.
6. Select [Close] and press ENTER (
b
) to complete
the network connection.
Advanced Setting
If you want to set the network settings manually,
use
W/S
to select [Advanced Setting] on the
[Network Setting] menu and press ENTER (
b
).
1. Use
W/S
to select [Wireless] and press ENTER
(
b
).
[AP List] - Scans all available access points or
wireless routers within range and display them
as a list.
[Network name (SSID)] – Your access point
may not be broadcasting its network name
(SSID). Check your access point settings through
your computer and either set your access
point to broadcast SSID, or manually enter the
network name in [Network name(SSID)].
[PBC] – If your access point or wireless
router that supports the PBC (Push Button
Configuration) method, select this option and
press the Push Button on your access point
within 120 counts. You do not need to know the
network name (SSID) and security code of your
access point.
[PIN] – If your access point supports the PIN
Code configuration method based on WPS(Wi-
Fi Protected Setup), select this option and
note the code number on the screen. And
then, enter the PIN number on a setting menu
of your access point to connect. Refer to the
documentation for your network device.
2. Follow the instructions of each connection
method on the screen.
To use PBC and PIN network connection,
security mode of your access point must be
set to OPEN or AES.
,
Note
Connecting30
Connecting
2
Notes on Network Connection:
y
Many network connection problems during
set up can often be xed by re-setting the
router or modem. After connecting the player
to the home network, quickly power o and/
or disconnect the power cable of the home
network router or cable modem. Then power on
and/or connect the power cable again.
y
Depending on the internet service provider (ISP),
the number of devices that can receive internet
service may be limited by the applicable terms
of service. For details, contact your ISP.
y
Our company is not responsible for any
malfunction of the player and/or the internet
connection feature due to communication
errors/malfunctions associated with your
broadband internet connection, or other
connected equipment.
y
The features of BD-ROM discs made available
through the Internet Connection feature are not
created or provided by our company, and our
company is not responsible for their functionality
or continued availability. Some disc related
material available by the Internet Connection
may not be compatible with this player. If you
have questions about such content, please
contact the producer of the disc.
y
Some internet contents may require a higher
bandwidth connection.
y
Even if the player is properly connected and
congured, some internet contents may not
operate properly because of internet congestion,
the quality or bandwidth of your internet service,
or problems at the provider of the content.
y
Some internet connection operations may not
be possible due to certain restrictions set by the
Internet service provider (ISP) supplying your
broadband Internet connection.
y
Any fees charged by an ISP including, without
limitation, connection charges are your
responsibility.
y
A 10 Base-T or 100 Base-TX LAN port is required
for wired connection to this player. If your
internet service does not allow for such a
connection, you will not be able to connect the
player.
y
You must use a Router to use xDSL service.
y
A DSL modem is required to use DSL service and
a cable modem is required to use cable modem
service. Depending on the access method of and
subscriber agreement with your ISP, you may not
be able to use the internet connection feature
contained in this player or you may be limited
to the number of devices you can connect at
the same time. (If your ISP limits subscription to
one device, this player may not be allowed to
connect when a PC is already connected.)
y
The use of a “Router” may not be allowed or its
usage may be limited depending on the policies
and restrictions of your ISP. For details, contact
your ISP directly.
y
The wireless network operate at 2.4GHz
radio frequencies that are also used by other
household devices such as cordless telephone,
Bluetooth® devices, microwave oven, and can be
aected by interference from them.
y
Turn o all unused network equipment in
your local home network. Some devices may
generate network trac.
y
For the purpose of the better transmission,
placing the player from the access point as close
as possible.
y
In some instances, placing the access point or
wireless router at least 0.45 m (1.5 ft.) above the
oor may improve the reception.
y
Move closer to the access point if possible or re-
orient the player so there is nothing between it
and the access point.
y
The reception quality over wireless depends on
many factors such as type of the access point,
distance between the player and access point,
and the location of the player.
y
Set your access point or wireless router to
Infrastructure mode. Ad-hoc mode is not
supported.
Connecting 31
Connecting
2
USB device connection
This player can play movie, music and photo les
contained in the USB device.
Playback content in the USB
device
1. Insert a USB device to the USB port until it fits
into place.
When you connect the USB device on the HOME
menu, the player plays a music le contained in the
USB storage device automatically. If the USB storage
device is containing various types of les, a menu
for the le type selection will appear.
File loading may takes few minutes depending on
the number of content stored in the USB storage
device. Press ENTER (
b
) while [Cancel] is selected
to stop loading.
2. Press HOME ( ).
3. Select [Movie], [Photo] or [Music] using
A/D
,
and press ENTER (
b
).
4. Select the [USB] option using
W/S
, and press
ENTER (
b
).
5. Select a file using
W/S/A/D
, and press
PLAY or ENTER (
b
) to play the file.
6. Withdraw the USB device carefully.
y
This player supports USB ash drive/external
HDD formatted in FAT16, FAT32 and NTFS
when accessing les (music, photo, movie).
However, for BD-Live, only FAT16 and FAT32
formats are supported. Use the USB ash
drive/external HDD formatted in either
FAT16 or FAT32 when using BD-Live.
y
The USB device can be used for the local
storage for enjoying BD-LIVE discs with
Internet.
y
This unit can support up to 4 partitions of
the USB device.
y
Do not extract the USB device during
operation (play, etc.).
y
A USB device which requires additional
program installation when you have
connected it to a computer, is not
supported.
y
USB device: USB device that supports
USB1.1 and USB2.0.
y
Movie, music and photo les can be played.
For details of operations on each le, refer to
relevant pages.
y
Regular back up is recommended to
prevent data loss.
y
If you use a USB extension cable, USB HUB
or USB Multi-reader, the USB device may not
be recognized.
y
Some USB device may not work with this
unit.
y
Digital camera and mobile phone are not
supported.
y
USB Port of the unit cannot be connected
to PC. The unit cannot be used as a storage
device.
,
Note
3 System Setting
System Setting32
System Setting
3
Settings
Initial Setup
When you turn on the unit for the rst time, the
initial setup wizard appears on the screen. Set the
display language, network settings and speaker
setup on the initial setup wizard.
1. Press
1
(POWER).
The initial setup wizard appears on the screen.
2. Use
W/S/A/D
to select a display language
and press ENTER (
b
).
3. Read and prepare the preparations for the
network settings and then press ENTER (
b
)
while [Start] is highlighted.
If wired network is connected , the network
connection setting will automatically be
finished.
4. All available networks are displayed on the
screen. Use
W/S
to select [Wired Network]
or desired SSID of wireless network and press
ENTER (
b
).
If you have security on your access point, you
need to input the security code as necessary.
5. Use
W/S/A/D
to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.
System Setting 33
System Setting
3
6. Select [Next] and press ENTER (
b
) to apply
network settings.
Network connection status is displayed on the
screen.
For details on network settings, refer to
"Connecting to your Home Network" on page
26.
7. Select [Next] and press ENTER (
b
).
Read and prepare the preparations for the
wireless speaker setting.
8. Select [Next] and press ENTER (
b
).
9. Press ENTER (
b
) to verify the test tone signals of
the speakers.
After verifying the test tone signals, press ENTER
(
b
) while [Stop] is highlighted.
Select [Next] and press ENTER (
b
).
10. Check all the settings that you have set in the
previous steps.
Press ENTER (
b
) while [Finish] is highlighted
to finish the initial setup settings. If there is any
settings to be changed, use
A/D
to select
[Previous] and press ENTER (
b
).
System Setting34
System Setting
3
Adjust the Setup Settings
You can change the settings of the player in the
[Setup] menu.
1. Press HOME ( ).
2. Use
A/D
to select the [Setup] and press
ENTER (
b
). The [Setup] menu appears.
3. Use
W/S
to select the first setup option, and
press
D
to move to the second level.
4. Use
W/S
to select a second setup option, and
press ENTER (
b
) to move to the third level.
5. Use
W/S
to select a desired setting, and press
ENTER (
b
) to confirm your selection.
[DISPLAY] Menu
TV Aspect Ratio
Select a TV aspect ratio option according to your TV
type.
[4:3 Letter Box]
Select when a standard 4:3 TV is connected.
Displays theatrical images with masking bars
above and below the picture.
[4:3 Pan Scan]
Select when a standard 4:3 TV is connected.
Displays pictures cropped to ll your TV screen.
Both sides of the picture are cut o.
[16:9 Original]
Select when a 16:9 wide TV is connected. The
4:3 picture is displayed with an original 4:3
aspect ratio, with black bars appearing at the
left and right sides.
[16:9 Full]
Select when a 16:9 wide TV is connected. The
4:3 picture is adjusted horizontally (in a linear
proportion) to ll the entire screen.
You cannot select [4:3 Letter Box] and
[4:3 Pan Scan] option when the resolution is
set to higher than 720p.
,
Note
35
System Setting
3
Resolution
Sets the output resolution of the HDMI video signal.
Refer to page 22 for details about the resolution
setting.
[Auto]
If the HDMI OUT jack is connected to
TVs providing display information (EDID),
automatically selects the resolution best suited
to the connected TV.
[1080p]
Outputs 1080 lines of progressive video.
[1080i]
Outputs 1080 lines of interlaced video.
[720p]
Outputs 720 lines of progressive video.
[480p]
Outputs 480 lines of progressive video.
[480i]
Outputs 480 lines of interlaced video.
1080p Display Mode
When the resolution is set to 1080p, select
[24 Hz] for smooth presentation of lm material
(1080p/24 Hz) with a HDMI-equipped display
compatible with 1080p/24 Hz input.
y
When you select [24 Hz], you may
experience some picture disturbance when
the video switches video and lm material.
In this case, select [60 Hz].
y
Even when [1080p Display Mode] is set to
[24 Hz], if your TV is not compatible with
1080p/24 Hz, the actual frame frequency of
the video output will be 60 Hz to match the
video source format.
,
Note
HDMI Color Setting
Select the type of output from the HDMI OUT jack.
For this setting, please refer to the manuals of your
display device.
[YCbCr]
Select when connecting to a HDMI display
device.
[RGB]
Select when connecting to a DVI display
device.
3D Mode
Select the type of output mode for Blu-ray 3D disc
playback.
[O ]
Blu-ray 3D disc playback will output as 2D
mode like a normal BD-ROM disc playback.
[On]
Blu-ray 3D disc playback will output as 3D
mode.
Wallpaper
Changes the background of the initial screen.
Home Menu Guide
This function allows you to display or delete the
guide bubble on the Home Menu. Set this option
to [On] for displaying guide.
System Setting
System Setting36
System Setting
3
[LANGUAGE] Menu
Display Menu
Select a language for the [Setup] menu and on-
screen display.
Disc Menu/Disc Audio/
Disc Subtitle
Select the language you prefer for the audio track
(disc audio), subtitles, and the disc menu.
[Original]
Refers to the original language in which the
disc was recorded.
[Other]
Press ENTER (
b
) to select another language.
Use number buttons then press ENTER (
b
)
to enter the corresponding 4-digit number
according to the language code list on page
71.
[O] (Disc Subtitle only)
Turn o Subtitle.
Depending on the disc, your language setting
may not work.
,
Note
[AUDIO] Menu
Each disc has a variety of audio output options. Set
the player’s Audio options according to the type of
audio system you use.
Since many factors aect the type of audio
output, see “Audio Output Specications” on
page 74 for details.
,
Note
Digital Output
[PCM Stereo] (HDMI only)
Select if you connect this unit’s HDMI OUT jack
to a device with two-channel digital stereo
decoder.
[PCM Multi-Ch] (HDMI only)
Select if you connect this unit’s HDMI OUT jack
to a device with multi-channel digital decoder.
[DTS Re-Encode] (HDMI only)
Select if you connect this unit’s HDMI OUT jack
to a device with DTS decoder.
[BitStream] (HDMI only)
Select if you connect this unit’s HDMI OUT jack
to a device with LPCM, Dolby Digital, Dolby
Digital Plus, Dolby TrueHD, DTS and DTS-HD
decoder.
y
When [Digital Output] option is set to [PCM
Multi-Ch], the audio may output as PCM
Stereo if the PCM Multi-Ch information is
not detected from HDMI device with EDID.
y
If the [Digital Output] option is set to [DTS
Re-Encode], the DTS Re-Encode audio is
outputted for BD-ROM discs with secondary
audio and the original audio is outputted
for the other discs (like [BitStream]).
y
This setting is not available on the input
signal from an external device.
,
Note
System Setting 37
System Setting
3
Speaker Setup
To obtain the best possible sound, use the speaker
setup display to specify the volume of the speakers
you have connected and their distance from your
listening position. Use the test to adjust the volume
of the speakers to the same level.
[Speaker]
Select a speaker that you want to adjust.
[Volume]
Adjust the output level of each speaker.
[Distance]
Adjust the distance between each speaker and
the listening position.
[Test/ Stop test tone]
The speakers will emit a test tone.
[OK]
Conrms the setting.
[Cancel]
Cancels the setting.
HD AV Sync
Sometimes Digital TV encounters a delay between
picture and sound. If this happens you can
compensate by setting a delay on the sound so
that it eectively ‘waits’ for the picture to arrive: this
is called HD AV Sync. Use
W
S
to scroll up and
down through the delay amount, which you can
set at anything between 0 and 300 ms.
DRC (Dynamic Range Control)
This function allows you to listen to a movie at a
lower volume without losing clarity of sound.
[O ]
Turns o this function.
[On]
Compress the dynamic range of the Dolby
Digital, Dolby Digital Plus or Dolby TrueHD
audio output.
[Auto]
The dynamic range of the Dolby TrueHD audio
output is specied by itself.
And the dynamic range of the Dolby Digital
and Dolby Digital Plus are operated as same as
the [On] mode.
The DRC setting can be changed only when a
disc is not inserted or the unit is in complete
stop mode.
,
Note
Connect wireless speakers
When the unit is manufactured, the ID is already
set. If interference occurs or you use a new wireless
unit, an ID should be set again.
System Setting38
System Setting
3
[LOCK] Menu
The [LOCK] settings aect only BD-ROM and DVD
playback.
To access the any features in [LOCK] settings, you
must enter the 4-digit security code you have
created.
If you have not entered a password yet, you are
prompted to do so. Enter a 4-digit password twice,
and press ENTER (
b
) to create a new password.
Password
You can create or change the password.
[None]
Enter a 4-digit password twice, and press
ENTER (
b
) to create a new password.
[Change]
Enter the current password and press ENTER
(
b
). Enter a 4-digit password twice, and press
ENTER (
b
) to create a new password.
If you forget your password
If you forget your password, you can clear it using
the following steps:
1. Remove any disc that might be in the player.
2. Select [Password] option in the [Setup] menu.
3. Use Number buttons to enter “210499”. The
password is cleared.
If you make a mistake before pressing ENTER
(
b
), press CLEAR. Then input the correct
password.
,
Note
DVD Rating
Blocks playback of rated DVD based on their
content. (Not all discs are rated.)
[Rating 1-8]
Rating one (1) has the most restrictions and
rating eight (8) is the least restrictive.
[Unlock]
If you select [Unlock], parental control is not
active and the disc plays in full.
Blu-ray Disc Rating
Set an age limit of BD-ROM play. Use number
buttons to input an age limit for BD-ROM viewing.
[255]
All BD-ROM can be played.
[0-254]
Prohibits play of BD-ROM with corresponding
ratings recorded on them.
y
The [Blu-ray Disc Rating] will be applied
only for the BD disc that containing the
Advanced Rating Control.
y
For the region using MPAA rating level, refer
to the table below as an example.
Blu-ray Disc Rating MPAA Rating
0 G
8 PG
13 PG-13
17 R
18 NC-17
255 Not restricted
,
Note
Area Code
Enter the code of the area whose standards were
used to rate the DVD video disc, based on the list
on page 70.
System Setting 39
System Setting
3
[NETWORK] Menu
The [NETWORK] settings are needed to use the
software update, BD Live and on-line content
services.
Connection Setting
If your home network environment is ready to
connect the player, the player needs to be set the
wired or wireless network connection for network
communication. (See “Connecting to your Home
Network” on page 26.)
Connection Status
If you want to check the network status on this
player, select the [Connection Status] options and
press ENTER (
b
) to check whether a connection
to the network and the internet have been
established.
BD-LIVE connection
You can restrict Internet access when BD-LIVE
functions are used.
[Permitted]
Internet access is permitted for all BD-LIVE
contents.
[Partially permitted]
Internet access is permitted only for BD-
LIVE contents which have content owner
certicates. Internet access and AACS Online
functions are prohibited for all BD-LIVE
contents without a certicate.
[Prohibited]
Internet access is prohibited for all BD-LIVE
contents.
Netflix
[Netix ESN]
Display its unique Netix ESN (Electronic Serial
Number) that allows you to use the Netix
streaming.
[Deactivate Netix]
Deactivates your player. To activate the Netix
again, contact to the service provider.
Deactivate Vudu
You can deactivate your player from your Vudu
account. It is recommended that you do this if you
give your player to someone else who should not
share your Vudu account.
Premium/LG Apps
[Country Setting]
Select your area for displaying proper services
and contents on the [Premium] and [LG Apps]
feature.
Device Name
You can make a network name using virtual
keyboard. This player will be recognised by the
name you are entering on your home network.
Wi-Fi Direct
This player is a Wi-Fi Direct™ certied device. Wi-Fi
Direct™ is the technology that devices to connect
each other without connecting to an Access point
or a router. Set this option to [On] for activating
the Wi-Fi Direct™ mode. Refer to page 44 for the
device connection.
System Setting40
System Setting
3
[OTHERS] Menu
Network Play
This function allows you to control the playback
of media streamed from DLNA media server by a
DLNA certied smartphone. Most DLNA certied
smartphone has a function to control the playback
media on your home network. Set this option to
[On] for allowing your smartphone to control this
unit. Refer to instructions of your DLNA certied
smartphone or the application for more detailed
information.
y
This unit and the DLNA Certied Smartphone
must be connected to the same network.
y
To use the [Network Play] function using a
DLNA certied smartphone, press HOME
(
) to display the home menu before
connecting to this unit.
y
While controlling the unit using the [Network
Play] function, the remote control may not work.
y
Available le formats described on page
10 are not always supported on [Network
Play] function.
,
Note
Auto Power Off
The screen saver appears when you leave the
player in Stop mode for about ve minutes. If
you set this option to [On], the unit automatically
turns o within 20 minutes since the Screen Saver
is displayed. Set this option to [O] to leave the
screen saver until the unit is operated by the user.
Depending on the function, this function may
not be available.
,
Note
Initialize
[Factory Set]
You can reset the player to its original factory
settings.
[Blu-ray Storage Clear]
Initializes the BD-Live contents from the
connected USB storage.
If you reset the player to its original factory
settings using [Factory Set] option, you have
to set all the activation for the on-line services
and network settings again.
,
Note
Software
[Information]
Displays the current software version.
[Update]
You can update the software by connecting
the unit directly to the software update server
(see page 66).
Disclaimer Notice
Press ENTER (
b
) to view the notice of Network
Service Disclaimer.
System Setting 41
System Setting
3
Sound Effect
You can select a suitable sound mode. Press SOUND
EFFECT repeatedly until the desired mode appears
on the front panel display or the TV screen. The
displayed items for the equalizer maybe dierent
depending on sound sources and eects.
[Natural Plus]: You can enjoy the natural sound
eect same as 5.1 channel.
[Natural]: You can enjoy comfortable and natural
sound.
[Bypass]: Software with multichannel surround
audio signals is played according to the way it was
recorded.
[Bass Blast]: Reinforce the bass sound eect from
front left and right speaker and subwoofer.
[Clear Voice]: This mode makes voice sound clear,
improving the quality of voice sound.
[Game]: You can enjoy more virtual sound while
playing video games.
[Night]: This may be useful when you want to
watch movies at low volumes late at night.
[Up Scaler]: When listening to MP3 les or other
compressed music, you can enhance the sound.
This mode is available only to 2 channel sources.
[Loudness]: Improves bass and treble sound.
[User EQ]: You can adjust the sound by raising or
lowering the level of specic frequency.
3D Sound Effect
3D Sound features deliver sound not only towards
the front or rear but also to the top, creating a
wider spot so you can enjoy more immersive and
cinematic surround sound.
[3D Music]: This mode delivers outstanding
surround sound, providing a concert hall-like music
experience in your home.
[3D Movie]: This mode delivers outstanding
surround sound, providing a theater-like movie
experience in your home.
Setting the [User EQ]
1. Use
W/S
to select the desired frequency.
2. Use
A/D
to select the desired level.
Select [Cancel] option then press ENTER (
b
) to
cancel the setting.
Select [Reset] option then press ENTER (
b
) to reset
the all adjustments.
Sound Zoom Effect
(4.1 CH or 2.1 CH)
1. Press SOUND ZOOM.
2. Press SOUND ZOOM repeatedly to select the
desired mode.
[Auto] : Switches to the optimum level of
the sound zoom for watching a 3D content
automatically.
[Manual] : When watching a 3D or 2D content,
you can adjust the level of sound zoom using
W/S
.
4 Operating
Operating42
Operating
4
General Playback
Using [HOME] menu
The home menu appears when you press HOME
(
). Use
W/S/A/D
to select a category and
press ENTER (
b
).
k
Depending on the region, [LG Apps] service
and [Search] function may not be available
at the moment. The service may become
available in these regions through at software
update later.
,
Note
a
[Music] - Plays audio contents.
b
[Movie] - Plays video contents.
c
[Photo] - Plays photo contents.
d
[Premium] - Displays the Premium Home
screen.
e
[LG Apps] - Displays the [LG Apps] screen.
f
[Input] - Changes input mode.
g
[Setup] - Adjusts the system settings.
h
[Search] - Searching an on-line content by
inputting a keyword on the search menu.
i
[LG Apps] - Displays the [LG Apps] screen.
j
[Favorite Apps] - Shortcut for user’s favorite
Apps.
k
[My Apps] - Displays the My Apps screen.
Playing a Disc
erot
1. Insert a disc in the disc slot.
For the most Audio CD, BD-ROM and
DVD-ROM discs, playback starts automatically.
2. Press HOME ( ).
3. Select [Movie] or [Music] using
A/D
, and press
ENTER (
b
).
4. Select [Blu-ray Disc], [DVD], [VR] or [Audio]
option using
W/S
, and press ENTER (
b
).
y
Playback functions described in this manual
are not always available in every les and
media. Some functions can be restricted
depending on many factors.
y
Depending on the BD-ROM titles, a USB
device connection may be needed for the
proper playback.
y
Unnalized DVD VR format discs may not be
played in this player.
y
Some DVD-VR discs are made with CPRM
data by DVD RECORDER. This unit cannot
support these kinds of discs.
,
Note
Playing a file on a disc/USB
device
yui
This player can play movie, music and photo les
contained in the disc or USB device.
1. Insert a data disc in the disc slot or connect a
USB device.
2. Press HOME ( ).
3. Select [Movie], [Photo] or [Music] using
A/D
,
and press ENTER (
b
).
4. Select [Data] or [USB] option using
W/S
, and
press ENTER (
b
).
5. Select a file using
W/S/A/D
, and press
d
(PLAY) or ENTER (
b
) to play the file.
Operating 43
Operating
4
Playing Blu-ray 3D disc
e
This player can play the Blu-ray 3D discs which
contains separate views for the left and right eyes.
Preparation
In order to playback Blu-ray 3D title in
stereoscopic 3D mode, you need to:
y
Check your TV is 3D capable and has HDMI
input(s).
y
Wear 3D glasses to enjoy the 3D experience
if it is necessary.
y
Check whether the BD-ROM title is the Blu-
ray 3D disc or not.
y
Connect an HDMI cable (High Speed HDMI™
Cable with Ethernet) between the player’s
HDMI output and TV’s HDMI input.
1. Press HOME ( ), and set the [3D Mode] option
on the [Setup] menu to [On] (page 35).
2. Insert a disc in the disc slot.
The playback starts automatically.
3. Refer to the owner’s manual of your 3D-ready
TV for the further instruction.
You may need to adjust the display settings and
focus on your TV’s setting for the improved 3D
eect.
y
Watching a 3D content for a long period
time may cause dizziness or tiredness.
y
It is not recommended to watch a movie
in 3D mode for inrm, child and pregnant
woman.
y
If you are experiencing headache, tiredness
or dizziness while viewing contents in 3D,
it is strongly recommended to stop the
playback and rest until you feel normal.
>
Caution
Enjoying BD-Live™
e
BD-ROM supporting BD-Live that has a network
extension function allows you to enjoy more
functions such as downloading new movie trailers
by connecting this unit to the internet.
1. Check the network connection and settings
(page 26).
2. Insert a USB storage device to the USB port on
the front panel.
A USB storage device is needed to download
bonus content.
3. Press HOME ( ), and set the [BD-LIVE
connection] option on the [Setup] menu (page
39).
Depending on a disc, the BD-Live function may
not be operated if [BD-LIVE connection] option
is set to [Partially Permitted].
4. Insert a BD-ROM with BD-Live.
The operations are dier depending on the disc.
Refer to the manual supplied with the disc.
Do not extract the connected USB device
while content is being downloaded or a Blu-
ray disc is still in the disc slot. Doing so may
damage the connected USB device and BD-
Live features may not operate properly with
the damaged USB device anymore. If the
connected USB device seems damaged from
such an action, you can format the connected
USB device from the PC and reuse it with this
player.
>
Caution
y
Some BD-Live contents may be restrictively
accessed in some territories by contents
provider’s own decision.
y
It may take up to several minutes to load
and start enjoying BD-Live contents.
,
Note
Operating44
Operating
4
Playing a file on a network
server
yui
This player can play video, audio and photo les
located in a DLNA server through your home
network.
1. Check the network connection and settings
(page 26).
2. Press HOME ( ).
3. Select [Movie], [Photo] or [Music] using
A/D
,
and press ENTER (
b
).
4. Select a DLNA media server on the list using
W/S
, and press ENTER (
b
).
If you want to rescan available media server,
press the green (G) colored button.
5. Select a le using
W/S/A/D
, and press
ENTER (
b
) to play the le.
y
The le requirements are described on page
10.
y
The thumbnail of the unplayable les can
be displayed, but those cannot be played
on this player.
y
The subtitle le name and movie le name
have to be the same and located at the
same folder.
y
The playback and operating quality may be
aected by your home network condition.
y
You may experience connection problems
depending on your server’s environment.
y
To set your PC as a DLNA server, install the
supplied Nero MediaHome 4 on your PC.
(see page 68)
,
Note
Wi-Fi Direct™ Connection
Connecting to a Wi-Fi Direct™
certified device
yui
This player can play movie, music and photo les
located in a Wi-Fi Direct™ certied device. The Wi-Fi
Direct™ technology make the player to be directely
connected to a Wi-Fi Direct™ certied device
without connecting to a network device such as an
access point.
1. Set the [Wi-Fi Direct] option on the [Setup]
menu to [On] (page 39).
2. Press HOME ( ).
3. Select [Movie], [Photo] or [Music] using
A/D
,
and press ENTER (
b
).
4. Select [Wi-Fi Direct] option using
W/S
, and
press ENTER (
b
).
5. Select a Wi-Fi Direct™ device on the list using
W/S
, and press ENTER (
b
).
Wi-Fi Direct™ connection will be automatically
proceeded.
If the Wi-Fi Direct™ device supports the PIN
Code configuration method based on WPS(Wi-
Fi Protected Setup), select a device on the list
and press yellow (Y) coloured button. Note the
PIN number on the screen. And then, enter the
PIN number on a setting menu of the device to
connect.
If you want to rescan available Wi-Fi Direct™
device, press the green (G) coloured button.
Operating 45
Operating
4
When you connect this unit from other Wi-Fi
Direct™ devices, PIN connection method is not
available.
,
Note
6. Select a server that shared from the connected
Wi-Fi Direct™ device using
W/S
, and press
ENTER (
b
) to navigate the server.
To select a server from the device list, files or
folders must be shared by DLNA server from the
connected Wi-Fi Direct™ device.
7. Select a le using
W/S/A/D
, and press
ENTER (
b
) to play the le.
y
For the purpose of the better transmission,
placing the player from the Wi-Fi Direct™
certied server as close as possible.
y
This unit can connect only 1 device at a
time. Multiple connection is not available.
y
If you try to connect wireless network while
a device is connected by Wi-Fi Direct™
function , Wi-Fi Direct™ connection will be
force disconnected.
y
If this player and a Wi-Fi Direct™ device
are connected to the different local area
network, Wi-Fi Direct™ connection may not
available.
y
If a Wi-Fi Direct™ certified device is not in
Wi-Fi direct standby mode, this product
can’t find the device.
y
This product cannot connect to a
Wi-Fi direct™ device which is in Group
Owner mode.
,
Note
Connecting to a Wi-Fi available
devices
yui
This player can connect to a general Wi-Fi device
using Wi-Fi Direct™ function.
1. Set the [Wi-Fi Direct] option on the [Setup]
menu to [On] (page 39).
2. Press HOME ( ).
3. Select [Movie], [Photo] or [Music] using
A/D
,
and press ENTER (
b
).
4. Select [Wi-Fi Direct] option using
W/S
, and
press ENTER (
b
).
5. Press red (R) coloured button to display the
[SSID], [Security Option] and [Encryption] of the
player.
6. On your Wi-Fi device, make a network
connection to this player, using [Network name
(SSID)], [Security Option] and [Encryption] at
step 5 above.
7. Press BACK (
1
) twice to display the device list.
Operating46
Operating
4
8. Select a server that shared from the connected
Wi-Fi device using
W/S
, and press ENTER (
b
)
to navigate the server.
To select a server from the device list, les or
folders must be shared by DLNA server from the
connected device.
9. Select a le using
W/S/A/D
, and press
ENTER (
b
) to play the le.
In case of connection to a Wi-Fi equipped
device, PIN connection does not work.
,
Note
Basic operations for video and
audio content
To stop playback
Press
Z
(STOP) while playback.
To pause playback
Press
M
(PAUSE) while playback.
Press
d
(PLAY) to resume playback.
To play frame-by-frame (Video)
Press
M
(PAUSE) while movie playback.
Press
M
(PAUSE) repeatedly to play Frame-by-Frame
playback.
To scan forward or backward
Press
c
or
v
to play fast forward or fast reverse
during playback.
You can change the various playback speeds by
pressing
c
or
v
repeatedly.
To slow down the playing speed
While the playback is paused, press
v
repeatedly
to play various speeds of slow motion.
To skip to the next/previous
chapter/track/file
During playback, press
C
or
V
to go to the
next chapter/track/le or to return to the beginning
of the current chapter/track/le.
Press
C
twice briey to step back to the previous
chapter/track/le.
In the le list menu of a server, there may have
many types of contents in a folder together. In this
case, press
C
or
V
to go to the previous or
next content with same type.
Operating 47
Operating
4
Basic operations for photo
content
To play a slide show
Press
d
(PLAY) to start slide show.
To stop a slide show
Press
Z
(STOP) while slide show.
To pause a slide show
Press
M
(PAUSE) while slide show.
Press
d
(PLAY) to re-start the slide show.
To skip to the next/previous photo
While viewing a photo in full screen, press
A
or
D
to go to the previous or next photo.
Using the disc menu
ero
To display the disc menu
The menu screen may be displayed rst after
loading a disc which contains a menu. If you want
to display the disc menu while playback, press DISC
MENU.
Use
W/S/A/D
buttons to navigate through
menu items.
To display the Pop-up menu
Some BD-ROM discs contain Pop-up menu that
appears while playback.
Press TITLE/POPUP while playback, and use
W/S/
A/D
buttons to navigate through menu items.
Resume playback
eroyt
u
The unit records the point where you pressed the
Z
(STOP) depending on the disc.
If “
MZ
(Resume Stop)” appears on the screen briey,
press
d
(PLAY) to resume playback (from the scene
point).
If you press
Z
(STOP) twice or unload the disc,
“
Z
(Complete Stop)” appears on the screen. The unit
will clear the stopped point.
y
The resume point may be cleared when a
button is pressed (for example;
1
(POWER),
B
(OPEN/CLOSE), etc).
y
On BD-ROM discs with BD-J, the resume
playback function does not work.
y
If you press
Z
(STOP) once during BD-ROM
interactive title playback, the unit will be in
Complete Stop mode .
,
Note
Last Scene Memory
er
This unit memorizes the last scene from the last disc
that is viewed. The last scene remains in memory
even if you remove the disc from the unit or switch
o the unit. If you load a disc that has the scene
memorized, the scene is automatically recalled.
y
Last Scene Memory function for a previous
disc is erased once a dierent disc is played.
y
This function may not work depending on
the disc.
y
On BD-ROM discs with BD-J, the last scene
memory function does not work.
y
This unit does not memorize settings of
a disc if you switch o the unit before
commencing to play it.
,
Note
48
Operating
4
Operating
Advanced Playback
Repeat Playback
erotu
y
During playback, press REPEAT (
h
) repeatedly to
select a desired repeat mode.
Blu-ray Disc / DVD / Movie les
j
A- – Selected portion will be repeated continually.
j
Chapter – The current chapter will be played
back repeatedly.
j
Title – The current title will be played back
repeatedly.
j
All – All the tracks or les will be played back
repeatedly.
To return to normal playback, press REPEAT (
h
)
repeatedly to select [O ].
Audio CDs/Music les
;
Track– The current track or le will be played
back repeatedly.
:
All – All the tracks or les will be played back
repeatedly.
l
– The tracks or les will be played back in
random order.
l:
All – All the tracks or les will be played
back repeatedly in random order.
k
A-B – Selected portion will be repeated
continually. (Audio CD only)
To return to normal playback, press CLEAR.
y
If you press
V
once during Repeat
Chapter/Track playback, the repeat playback
cancels.
y
This function may not work on some disc or
title.
,
Note
Repeating a specific portion
eroty
This player can repeat a portion you have selected.
1. While playback, press REPEAT (
h
) to select
[A-] at the beginning of the portion you wish to
repeat.
2. Press ENTER (
b
) at the end of the portion. Your
selected portion will be repeated continually.
3. To return to normal playback, press REPEAT
(
h
) repeatedly to select [O ].
y
You cannot select a portion less than 3
seconds.
y
This function may not work on some disc or
title.
,
Note
Viewing content information
y
The player can display the content information.
1. Select a le using
W/S/A/D
.
2. Press INFO/MENU (
m
) to display the option
menu.
3. Select the [Information] option using
W/S
,
and press ENTER (
b
).
The le information appears on the screen.
While movie playback, you can display the le
information by pressing TITLE/POPUP.
The information displayed on the screen
may not correct comparing actual content
information.
,
Note
Operating 49
Operating
4
Changing content list view
yui
On the [Movie], [Music] or [Photo] menu, you can
change the content list view.
Method 1
Press red (R) colored button repeatedly.
Method 2
1. On the content list, press INFO/MENU (
m
) to
display the option menu.
2. Use
W/S
to select the [View Change] option.
3. Press ENTER (
b
) to change the content list
view.
Selecting a subtitle file
y
If the subtitle le name is dierent from the movie
le name, you need to select the subtitle le on the
[Movie] menu before playing the movie.
1. Use
W/S/A/D
to select the subtitle le you
wish to play in the [Movie] menu.
2. Press ENTER (
b
).
Press ENTER (
b
) again to deselect the subtitle
le. Selected subtitle le will be displayed when
you play the movie le.
y
If you press
Z
(STOP) while playback, the
subtitle selection is cancelled.
y
This function is not available for playing le
on a server via home network.
,
Note
Operating50
Operating
4
Options while viewing a photo
i
You can use various options during viewing a
photo in full screen.
1. While viewing a photo in full screen, press INFO/
MENU (
m
) to display the option menu.
2. Select an option using
W/S
.
a Current photo/Total number of photos
– Use
A/D
to view previous/next photo.
b Slide Show – Press ENTER (
b
) to start or
pause slide show.
c Music Select – Select the background
music for the slide show (page 50).
d Music –Press ENTER (
b
) to start or pause
background music.
e Rotate – Press ENTER (
b
) to rotate the
photo clockwise.
f Zoom – Press ENTER (
b
) to display the
[Zoom] menu.
g Eect – Use
A/D
to select a transition
effect between photos in a slide show.
h Speed – Use
A/D
to select a delaying
speed between photos in a slide show.
3. Press BACK (
1
) to exit the option menu.
Listening to music while slide
show
i
You can display photo les while listening to music
les.
1. While viewing a photo in full screen, press INFO/
MENU (
m
) to display the option menu.
2. Use
W/S
to select [Music Select] option, and
press ENTER (
b
) to display the [Music Select]
menu.
3. Use
W/S
to select a device, and press ENTER
(
b
).
Device that you can select are differ depending
on the location of the photo file you are
displaying in full screen.
Photo location Available Device
Disc, USB Disc, USB
DLNA server DLNA server
4. Use
W/S
to select a file or a folder you wish to
play.
Select
g
and press ENTER (
b
) to display the
upper directory.
When selecting music le from a server, folder
selection is not available. Only le selection is
available.
,
Note
5. Use
D
to select [OK], and press ENTER (
b
) to
complete music selection.
Operating 51
Operating
4
On-Screen display
You can display and adjust various information and
settings about the content.
Displaying content information
on-screen
eroy
1. While playback, press INFO/MENU (
m
) to show
various playback information.
a Title – current title number/total number of
titles
b Chapter – current chapter number/total
number of chapters
c Time – elapsed playing time/total playback
time
d Audio – selected audio language or channel
e Subtitle – selected subtitle.
f Angle – selected angle/total number of
angles
g TV Aspect Ratio – selected TV aspect Ratio
h Picture Mode – selected picture mode
2. Select an option using
W/S
.
3. Use
A/D
to adjust the selected option value.
4. Press BACK (
1
) to exit the On-Screen display.
y
If no button is pressed for a few seconds,
the on-screen display disappears.
y
A title number cannot be selected on some
discs.
y
Available items may dier depending on
discs or titles.
y
If an interactive Blu-ray Disc is playing back,
some setting information is displayed on
the screen but prohibited to be changed.
,
Note
Operating52
Operating
4
Playing from selected time
eroy
1. Press INFO/MENU (
m
) during playback. The
time search box shows the elapsed playing
time.
2. Select the [Time] option and then input the
required start time in hours, minutes, and
seconds from left to right.
For example, to nd a scene at 2 hours, 10
minutes, and 20 seconds, enter “21020”.
Press
A/D
to skip the playback 60 seconds
forward or backward.
3. Press ENTER (
b
) to start playback from selected
time.
y
This function may not work on some disc or
titles.
y
This function may not work depending on
the le type and ability of the DLNA server.
,
Note
Selecting a subtitle language
eroy
1. During playback, press INFO/MENU (
m
) to
display the On-Screen display.
2. Use
W/S
to select the [Subtitle] option.
3. Use
A/D
to select desired subtitle language.
4. Press BACK (
1
) to exit the On-Screen display.
y
Some discs allow you to change subtitle
selections only via the disc menu. If this is
the case, press TITLE/POPUP or DISC MENU
button and choose the appropriate subtitle
from the selections on the disc menu.
y
You can select the [Subtitle] option on the
On-Screen display directely by pressing
SUBTITLE button.
,
Note
Hearing a different audio
eroy
1. During playback, press INFO/MENU (
m
) to
display the On-Screen display.
2. Use
W/S
to select the [Audio] option.
3. Use
A/D
to select desired audio language,
audio track or audio channel.
y
Some discs allow you to change audio
selections only via the disc menu. In this
case, press TITLE/POP-UP or DISC MENU
button and choose the appropriate audio
from the selections on the disc menu.
y
Immediately after you have switched sound,
there may be a temporary discrepancy
between the display and actual sound.
y
On BD-ROM disc, the multi audio format
(5.1CH or 7.1CH) is displayed with [MultiCH]
in the on-screen display.
y
You can select the [Audio] option on the
On-Screen display directely by pressing
AUDIO button.
,
Note
Watching from a different
angle
er
If the disc contains scenes recorded at dierent
camera angles, you can change to a dierent
camera angle during playback.
1. During playback, press INFO/MENU (
m
) to
display the On-Screen display.
2. Use
W/S
to select the [Angle] option.
3. Use
A/D
to select desired angle.
4. Press BACK (
1
) to exit the On-Screen display.
Operating 53
Operating
4
Changing the TV Aspect Ratio
eoy
You can change the TV aspect ratio setting while
playback.
1. During playback, press INFO/MENU (
m
) to
display the On-Screen display.
2. Use
W/S
to select the [TV Aspect Ratio]
option.
3. Use
A/D
to select desired option.
4. Press BACK (
1
) to exit the On-Screen display.
Even if you change the value of the [TV Aspect
Ratio] option in On-Screen display, the [TV
Aspect Ratio] option in the [Setup] menu is
not changed.
,
Note
Changing subtitle code page
y
If the subtitle is displayed in broken letter, you can
change the subtitle code page to view the subtitle
le properly.
1. During playback, press INFO/MENU (
m
) to
display the playback menu.
2. Use
W/S
to select the [Code Page] option.
3. Use
A/D
to select desired code option.
4. Press BACK (
1
) to exit the On-Screen display.
Changing the Picture Mode
eroy
You can change the [Picture mode] option while
playback.
1. During playback, press INFO/MENU (
m
) to
display the On-Screen display.
2. Use
W/S
to select the [Picture Mode] option.
3. Use
A/D
to select desired option.
4. Press BACK (
1
) to exit the On-Screen display.
Setting the [User] option
1. During playback, press INFO/MENU (
m
) to
display the On-Screen display.
2. Use
W/S
to select the [Picture Mode] option.
3. Use
A/D
to select the [User setting] option,
and press ENTER (
b
).
4. Use
W/S/A/D
to adjust the [Picture Mode]
options.
Select [Default] option then press ENTER (
b
) to
reset the all video adjustments.
5. Use
W/S/A/D
to select the [Close] option,
and press ENTER (
b
) to nish setting.
Operating54
Operating
4
Audio CD Recording
You can record one desired track or all of the tracks
in Audio CD to a USB storage device.
1. Insert a USB storage device to the USB port on
the front panel.
2. Press
B
(OPEN/CLOSE), and place an Audio CD
on the disc tray.
Press
B
(OPEN/CLOSE) to close the disc tray.
The playback starts automatically.
3. Press INFO/MENU (
m
) to display the option
menu.
Or
Press
X
REC button on the remote control.
You can record all musics in the audio CD.
4. Use
W/S
to select [CD Recording] option, and
press ENTER (
b
).
5. Use
W/S
to select a track you wish to copy on
the menu, and press ENTER (
b
).
Repeat this step to select tracks as many as you
can.
Selects all the tracks on an
Audio CD.
Selects an encoding option
from the pop-up menu
(128kbps, 192kbps or 320kbps).
Cancels the recording and
returns to the previous screen.
6. Use
W/S/A/D
to select [Start], and press
ENTER (
b
).
7. Use
W/S/A/D
to select a destination folder
to be copied.
If you want to create a new folder, use
W/S/A/D
to select [New Folder] and press
ENTER (
b
).
Enter a folder name using virtual keyboard, and
press ENTER (
b
) while [OK] is selected.
8. Use
W/S/A/D
to select [OK], and press
ENTER (
b
) to start Audio CD recording.
If you want to stop in progressing Audio CD
recording, press ENTER (
b
) while [Cancel] is
highlighted.
9. A message appears when Audio CD recording is
completed. Press ENTER (
b
) to check the audio
le created in the destination folder.
y
The table below shows the average
recording time from an music track with 4
minutes of playback time to a audio le with
192 kbps as an example.
stop mode while playback
1 min. 4 min.
y
Recording times in the table above are
approximate.
y
Actual recording time for USB storage
device varies depending on the USB storage
device’s ability.
y
Make sure that there is minimum of 50 MB
free space is needed when recording into
the USB storage device.
y
The length of the audio should be longer
than 20 seconds for the proper recording.
y
Do not turn o this player or extract the
connected USB storage device during Audio
CD recording.
,
Note
The recording or copying features on this
player are provided for your personal and non-
commercial use. The making of unauthorized
copies of copy-protected material, including
computer programs, les, broadcasts and
sound recordings, may be an infringement of
copyrights and constitute a criminal oense.
This equipment should not be used for
such purposes. LG expressly disclaims any
responsibility for illegal distribution or use of
unauthorized content in commercial purpose.
Be Responsible
Respect Copyrights
>
Caution
Operating 55
Operating
4
Playing the iPod
You can enjoy the sound with your iPod. For details
about iPod, refer to the iPod’s User Guide.
Preparation
Before connecting the iPod, turn this unit o and
reduce the volume of this unit to its minimum.
Use the iPod cable supplied with your iPod.
,
Note
1. Connect the iPod to the USB port.
If you turn this unit on, your iPod is
automatically turned on and recharging starts.
When you connect the iPod on the HOME
menu, the player plays a music automatically.
2. Select a le using
W/S/A/D
, and press
ENTER (
b
) to play the le.
Enjoying iPod on the screen
1. Connect the iPod to the USB port.
2. Press HOME ( ).
3. Select [Music] using
A/D
, and press ENTER
(
b
).
If you connected the other device
(CD or USB), select the iPod on the menu.
4. Select a content using
W/S/A/D
, and
press ENTER (
b
) to play.
Power scroll
You can search easily a content by power scroll
on the screen.
Press REPEAT (
h
) to select a desired repeat
mode :Track (
;
), All (
:
), Shuffle All (
l
:
),
Shuffle (
l
), Off (No display)
If the iPod’s OSD language is selected to
simple chinese, the power scroll function is not
operated correctly.
,
Note
Enjoying the iPod IN mode
You can operate your iPod by using the supplied
remote control and controls on your iPod.
1. Connect the iPod to the USB port.
If you turn this unit on, your iPod is
automatically turned on and recharging starts.
2. Press FUNCTION to select iPod IN mode.
W/S/A/D
Selects an option in the menu.
ENTER (
b
) Starts playback the music.
M
or
d
(PLAY)
To pause while it is playing. To
resume playing, press
M
or
d
(PLAY) again.
(Press and hold)
c
/
v
Fast-forward or rewind a song
C
/
V
Skip the playback forward or
backward .
Operating56
Operating
4
y
An error message “CHECK” or “Connected
iPod model is not supported.” appears when:
-
your iPod is not available for the function
to be operated.
y
An error message “CHECK” or “Please update
your iPod’s software.” appears when:
-
your iPod has an old software version.
/
Update your iPod software to latest
version.
y
If this unit displays an error message, follow
the message. An error message “CHECK” or
“Please check your iPod.” appears when:
-
the communication between this unit
and your iPod is failed.
/
Connect & reconnect your iPod in this
unit.
-
your iPod is not connected rmly.
-
this unit recognises your iPod as
unknown device.
y
Your iPod is exceptionally low on power.
/
The battery needs to be charged.
/
If you charge the battery while iPod
is extremely low in power, it may take
longer to charge.
y
Compatibility with your iPod may vary
depending on the type of your iPod.
y
iPod touch, iPhone and iPad have any
dierence in operation other than iPod.
You may need any additional control to use
them with this unit. (e.g. “slide to unlock”)
y
If you use an application, make a call, or
send and receive SMS text message, etc. on
iPod touch, iPhone or iPad, disconnect it
from to the USB port of this unit and then
use it.
y
Depending on your iPod’s software version,
it may not be possible to control your iPod
from this unit. We recommend installing the
latest software version.
y
This unit supports the models as follows.
- iPad nano 2G, 3G, 4G, 5G, 6G
- iPod classic
- iPod touch 1G, 2G, 3G, 4G
- iPhone 3G, 3GS, 4, 4S
- iPad, iPad2
y
If you have a problem with your iPod, please
visit www.apple.com/support/ipod.
,
Note
Operating 57
Operating
4
Radio Operations
Be sure that the antennas are connected.
(Refer to the page 23)
Listening to the radio
1. Press FUNCTION until TUNER (FM) appears in
the display window. The last received station is
tuned in.
2. Press and hold TUNING (-/+) for about two
seconds until the frequency indication starts to
change. Scanning stops when the unit tunes in
a station. Or Press TUNING (-/+) repeatedly.
3. Adjust the volume by pressing VOL (+/-).
Presetting the Radio Stations
You can preset 50 stations for FM.
Before tuning, make sure that you have turned
down the volume.
1. Press FUNCTION until the TUNER (FM) appears
in the display window.
2. Select the desired frequency by using TUNING
(-/+).
3. Press ENTER (
b
) a preset number will ash in
the display window.
4. Press PRESET (-/+) to select the preset number
you want.
5. Press ENTER (
b
). The station is stored.
6. Repeat the steps 2 to 5 to store other stations.
Deleting a saved station
1. Press PRESET (- / +) to select a preset number
you want to delete.
2. Press CLEAR, the preset number will blink in the
display window.
3. Press CLEAR again, to delete the selected preset
number.
Deleting all the saved stations
Press and hold CLEAR for two seconds.
“ERASE ALL” will ash up. Press CLEAR again. Then all
the saved stations are deleted.
Improving poor FM reception
Press B (blue) (MONO/STEREO) colored button on
the remote control. This will change the tuner from
stereo to mono and usually improve the reception.
Operating58
Operating
4
Using the Premium
You can use various content services via Internet
with the Premium feature.
1. Check the network connection and settings
(page 26).
2. Press HOME ( ).
3. Select the [Premium] using
A/D
, and press
ENTER (
b
).
4. Select an on-line service using
W/S/A/D
,
and press ENTER (
b
).
y
Detailed information of each service,
contact to the content provider or visit
suppot link of the service.
y
The content of Premium services and
service related information, including user
interface, is subject to changes. Please refer
to the web site of each service for most up-
to-date information.
y
Using Premium features with wireless
network connection may result in improper
streaming speed by interference from
household devices that are using radio
frequencies.
y
When you are rst time to access [Premium]
or [LG Apps] feature, current country setting
appears. If you want to change the country
setting, select [EDIT] and press ENTER (
b
).
,
Note
Using the LG Apps
You can use the LG application services on
this player via Internet. You can easily nd and
download various applications from LG App store.
Depending on the region, the LG Apps service
may not be available at the moment. The
service will become available in these regions
through at software update.
1. Check the network connection and settings
(page 26).
2. Press HOME ( ).
3. Select the [LG Apps] using
A/D
, and press
ENTER (
b
).
4. Select a category using
A/D
, and press ENTER
(
b
).
5. Use
W/S/A/D
to select an application, and
press ENTER (
b
) to display the information.
6. Press ENTER (
b
) while [Install] icon is
highlighted. The application will be installed to
the player.
To install an application to the player, user
needs to sign in. Refer to page 59 for more
information of signning in.
7. Press yellow (Y) colored button to display the
[My Apps] screen.
8. Select the installed application and press ENTER
(
b
) to excute it.
To install a paid application, you need to be
a paid member. Visit www.lgappstv.com for
more information.
,
Note
Operating 59
Operating
4
Signing in
To use the [LG Apps] feature, you need to sign in
with your account.
1. On the [LG Apps] or [My Apps] screen, press red
(R) colored button.
2. Fill the [ID] and [Password] field using the virtual
keyboard.
If you do not have an account, press red (R)
colored button to register.
3. Use
W/S/A/D
to select [OK], and press
ENTER (
b
) to sign in with your account.
If you select the [Auto Sign In] check box,
your ID and password are remembered and
automatically signed in without entering them.
y
If you want to sign in with other account,
press red (R) colored button on [LG Apps] or
[My Apps] screen, and select [Change User]
option.
y
To view the information of your account and
applications, press red (R) colored button on
[LG Apps] or [My Apps] screen, and select
[Account Setting] option.
,
Note
Managing my Apps
You can move or delete an installed application in
the [My Apps] menu.
Move an application
1. Select an application, and press green (G)
colored button to display the options.
2. Use
W/S
to select [Move], and press
ENTER(
b
).
3. Use
W/S/A/D
to select a position you want
to move to, and press ENTER (
b
).
Delete an application
1. Select an application, and press green (G)
colored button to display the options.
2. Use
W/S
to select [Delete], and press
ENTER(
b
).
3. Use
A/D
to select [Yes], and press ENTER (
b
)
to confirm.
Searching online content
If you are having diculties nding specic content
from online services, you can use the all-in-one
search function by entering keywords in the
[Search] menu.
1
. Press HOME ( ).
2. Select the [Search] on the launcher bar using
W/S/A/D
, and press ENTER (
b
).
The [Search] menu appears on the screen with
virtual keyboard.
3. Use
W/S/A/D
to select letters then press
ENTER (
b
) to confirm your selection on the
virtual keyboard.
4. When you finish entering the keyword, select
[OK] and press ENTER (
b
) to display search
result.
5. Use
W/S/A/D
to select a desired content,
and press ENTER (
b
) to move to the selected
content directly.
The [Search] function does not search content
in every online services. It works only in certain
online services.
,
Note
Operating60
Operating
4
Using Bluetooth
technology
About Bluetooth
Bluetooth® is wireless communication technology
for short range connection.
The available range is within 10 meters.
(The sound may be interrupted when the
connection interfered by the other electronic wave
or you connect the bluetooth in the other rooms.)
Connecting individual devices under
Bluetooth® wireless technology does not incur any
charges. A mobile phone with
Bluetooth® wireless technology can be operated
via the Cascade if the connection was made via
Bluetooth® wireless technology.
Available Devices : Mobile phone, MP3, Laptop,
PDA (This units be supported the Stereo Headset.)
Bluetooth Profiles
In order to use Bluetooth wireless technology,
devices must be able to interpret certain profiles.
This unit is compatible with following profile.
A2DP (Advanced Audio Distribution Profile)
Listening to music stored on
the Bluetooth devices
Pairing your unit and Bluetooth
device
Before you start the pairing procedure, make
sure the Bluetooth feature is turned on in to your
Bluetooth device. Refer to your Bluetooth device’s
user guide. Once a pairing operation is performed,
it does not need to be performed again.
1. Select the Bluetooth function by using the
FUNCTION.
Appears “BT READY” in display window.
2. Operate the Bluetooth device and perform the
pairing operation. When searching for this unit
with the Bluetooth device, a list of the devices
found may appear in the Bluetooth device
display depending on the type of Bluetooth
device.Your unit appears as “LG Audio”.
3. When this unit successfully paired with your
Bluetooth device, Bluetooth LED of this unit
lights up and "BTPAIRED" appears in the display
window.
Depending on the Bluetooth device type,
some device have a dierent pairing way.
,
Note
4. Listen to music.
To play a music stored on your Bluetooth device,
refer to your Bluetooth device’s user guide.
If you change the function of the unit, the
Bluetooth function is disconnected, operate
pairing again.
,
Note
Operating 61
Operating
4
y
The sound may be interrupted when
the connection interfered by the other
electronic wave.
y
You cannot control the Bluetooth device
with this unit.
y
Pairing is limited one Bluetooth device per
one unit and multi-pairing is not supported.
y
Although the distance between your
Bluetooth and the set is less than 10m, there
are obstacles between both, your Bluetooth
device cannot be connected.
y
Depending on the type of the device,
you may not be able to use the Bluetooth
function.
y
When not connected the Bluetooth, “BT
READY” appears on the display window.
y
The Electrical malfunction due to devices
using same frequency such as Medical
equipment, Microwaves or wireless
LAN devices, the connection will be
disconnected.
y
When someone stands and interrupts
communication between Bluetooth device
and the player, the connection will be
disconnected.
y
If the gotten away of the distance between
Bluetooth and the unit, the sound quality
is lower and lower the connection will
disconnect when the space between the
Bluetooth and the unit gets out of the
operating range of Bluetooth.
y
The device with Bluetooth wireless
technology is disconnected, if you turn o
the main unit or put the device away from
the main unit more than 10m.
,
Note
5 Troubleshooting
Troubleshooting62
Troubleshooting
5
Troubleshooting
General
Symptom Cause & Solution
The Power does not turned on.
y
Plug the power cord into the wall outlet securely.
The unit does not start
playback.
y
Insert a playable disc. (Check the disc type, color system, and regional
code.)
y
Insert the disc with the playback side down.
y
Clean the disc.
y
Cancel the Rating function or change the rating level.
The angle cannot be changed.
y
Multi-angles are not recorded on the DVD Video being played.
Cannot play movie, photo or
music les.
y
The les are not recorded in a format that the unit can play.
y
The unit does not support the codec of the movie le.
The remote control does not
work properly.
y
The remote control is not pointed at the remote sensor of the unit.
y
The remote control is too far from the unit.
y
There is an obstacle in the path of the remote control and the unit.
y
The batteries in the remote control are exhausted.
The unit is plugged in, but the
power will not turn on or o.
You can reset the unit as follows.
y
Unplug the power cord, wait at least ve seconds, and then plug it in
again.
The unit is not operating
normally.
Troubleshooting 63
Troubleshooting
5
Network
Symptom Cause & Solution
BD-Live feature does not work.
y
The connected USB storage may not have enough space. Connect
the USB storage with at least 1GB free space.
y
Ensure that the unit is correctly connected to the local area network
and can access the internet (see page 26).
y
Your broadband speed may not fast enough to use the BD-LIVE
features. Contact your Internet Service Provider (ISP) and increase the
broadband speed is recommended.
y
The [BD-LIVE connection] option in the [Setup] menu is set to
[Prohibited]. Set the option to [Permitted].
Streaming video services (such
as YouTube™, etc.) are often
stopped or “buer” during
playback.
y
Your broadband service speed may not be fast enough to stream
video services. Contact your Internet Service Provider (ISP) and
increase the broadband speed is recommended.
Shared folder or les from your
PC or a Media servers are not
displayed on the device list.
y
The rewall or anti-virus software on your media server is running.
Turn o the rewall or anti-virus software running on your media
server.
y
The player is not connected to the local area network that your media
server is connected.
Cannot connect the player to
the access point or wireless
LAN router.
y
The wireless communication may be interrupted from household
devices that are using radio frequencies. Move the player away from
them.
Access point is not displayed
on the “Access point name” list.
y
The access point or wireless LAN router may not broadcast its SSID.
Set your access point to broadcast its SSID through your computer.
y
Your network device such as access point may not set with available
frequency range and channel that this player can support.
Try setting the frequency range and channel on the network device
setting.
Troubleshooting64
Troubleshooting
5
Symptom Cause & Solution
There is no picture.
y
Select the appropriate video input mode on the TV so the picture
from the unit appears on the TV screen.
y
Connect the video connection securely.
y
Check the [HDMI Color Setting] in the [Setup] menu is set to the
appropriate item that conforms to your video connection.
y
Your TV may not support the resolution you have set on the player.
Change the resolution that your TV accepts.
y
The player’s HDMI OUT jack is connected to a DVI device that does
not support copyright protection.
Picture noise appears
y
You are playing a disc recorded in a colour system that is dierent
from your TV.
y
Set the resolution which your TV accepts.
Blu-ray 3D disc playback does
not output 3D views.
y
Connect the player to your TV with HDMI cable (Type A, High Speed
HDMI™ Cable with Ethernet).
y
Your TV may not support “HDMI 3D mandatory format”.
y
The [3D Mode] option in the [Setup] menu is set to [O ].
Set the option to [On].
Sound
Symptom Cause & Solution
There is no sound or the sound
is distorted.
y
The unit is in scan, slow motion, or pause mode.
y
The sound volume is low.
y
Check the speaker cable connection. (page 17)
Customer Support
You can update the Player using the latest software to enhance the products operation and/or add new
features. To obtain the latest software for this player (if updates have been made), please visit
http://www.lg.com/global/support or contact LG Electronics customer care centre.
Open source software notice
To obtain the corresponding source code under GPL, LGPL, MPL and other open source licenses, please
visit http://opensource.lge.com. All referred license terms, warranty disclaimers and copyright notices are
available to download with the source code.
6 Appendix
Appendix 65
Appendix
6
Controlling a TV with
the Supplied Remote
Control
You can control your TV using the buttons below.
By pressing You can
1
(TV POWER) Turn the TV on or o.
AV/INPUT
Switch the TV’s input source
between the TV and other
input sources.
PR/CH
W/S
Scan up or down through
memorized channels.
VOL +/– Adjust the volume of the TV
Depending on the unit being connected, you
may not be able to control your TV using some
of the buttons.
,
Note
Setting up the remote to
control your TV
You can operate your TV with the supplied remote
control.
If your TV is listed in the table below, set the
appropriate manufacturer code.
1. While holding down
1
(TV POWER) button,
and press the manufacturer code for your
TV with the numerical buttons (see the table
below).
Manufacturer Code Number
LG 1(Default), 2
Zenith 1, 3, 4
GoldStar 1, 2
Samsung 6, 7
Sony 8, 9
Hitachi 4
2. Release the
1
(TV POWER) button to complete
setting.
Depending on your TV, some or all buttons may not
function on the TV, even after entering the correct
manufacturer code. When you replace the batteries
of the remote, the code number you have set may
be reset to the default setting. Set the appropriate
code number again.
Appendix66
Appendix
6
Network Software
Update
Network update notification
From time to time, performance improvements
and/or additional features or services may be
made available to units that are connected to a
broadband home network. If there is new software
available and the unit is connected to a broadband
home network, the player will inform you about the
update as follows.
Option 1:
1. The update menu will appear on the screen
when you turn off the player.
2. Use
A/D
to select a desired option and then
press ENTER (
b
).
[OK] Starts the software update.
[Cancel] Exits the update menu and turns
the power o.
Option 2:
If the software update is available from the update
server, the “Update” icon appears in the Home
menu. Press blue (B) colored button to start the
update procedure.
Software Update
You can update the player using the latest software
to enhance the products operation and/or add
new features. You can update the software by
connecting the unit directly to the software update
server.
y
Before updating the software in your player,
remove any disc and USB Device from the
player.
y
Before updating the software in your player,
turn the player o and then turn it back on.
y
During the software update procedure,
do not turn o the player or disconnect
AC power, or do not press any button.
y
If you cancel the update, turn o the power
and turn it on for stable performance.
y
This unit cannot be updated to previous
software version.
,
Note
1. Check the network connection and settings
(page 26).
2. Select [Software] option in the [Setup] menu
then press ENTER (
b
).
3. Select [Update] option, and press ENTER (
b
).
The player will check for the newest update.
y
Pressing ENTER (
b
) while checking for the
update will end the process.
y
If there is no update available, the Message,
“No update is found.” appears. Press ENTER
(
b
) to return to the [Home Menu].
,
Note
Appendix 67
Appendix
6
4. If newer version exists, the message “Do you
want to download it?” appears.
5. Select [OK] to start update. (Selecting [Cancel]
will end the update.)
6. The player starts downloading the newest
update from the server. (Downloading will
takes several minutes depending on your home
network condition)
7. When downloading is completed, the message,
“Download is complete. Do you want to
update?” appears.
8. Select [OK] to start updating. (Selecting [Cancel]
will end the update and downloaded file will
not be re-usable. To update software the next
time, the software update procedure has to be
started from the beginning again.)
Do not turn o the power during the software
update.
>
Caution
9. When update is completed, the power will be
turned automatically in a few seconds.
10. Turn the power back on. The system now
operates with the new version.
The Software Update function may not
work properly depending on your internet
environment. In this case, you can obtain
the latest software from the authorized LG
Electronics Service Centre then update your
player. Refer to “Customer Support” on page
64.
,
Note
Appendix68
Appendix
6
About Nero
MediaHome 4
Essentials
Nero MediaHome 4 Essentials is a software for
sharing movie, music and photo les stored on your
computer to this player as a DLNA-compatiable
digital media server.
y
The Nero MediaHome 4 Essentials CD-
ROM is designed for PCs and should not
be inserted in this player or in any product
other than a PC.
y
The supplied Nero MediaHome 4 Essentials
CD-ROM is a customized software edition
only for sharing les and folders to this
player.
y
The supplied Nero MediaHome 4 Essentials
software does not support following
functions: Transcoding, Remote UI, TV
control, Internet services and Apple iTunes
y
The supplied Nero MediaHome 4 Essentials
software can be downloaded at http://www.
lg.com/global/support. Find the download
link on the web page of this product.
y
This manual explains operations with
the English version of Nero MediaHome
4 Essentials as examples. Follow the
explanation referring to the actual
operations of your language version.
,
Note
System Requirements
Windows PC
y
Windows® XP (Service Pack 2 or higher), Windows
Vista® (no Service Pack required), Windows® 7
(no Service Pack required), Windows® XP Media
Center Edition 2005 (Service Pack 2 or higher),
Windows Server® 2003
y
Windows Vista® 64-bit edition (application runs
in 32-bit mode)
y
Windows® 7 64-bit edition (application runs in
32-bit mode)
y
Hard drive space: 200 MB hard drive space for a
typical installation of Nero MediaHome stand-
alone
y
1.2 GHz Intel® Pentium® III or AMD
Sempron™ 2200+ processors
y
Memory: 256 MB RAM
y
Graphics card with at least 32 MB video memory,
minimum resolution of 800 x 600 pixels, and 16-
bit color settings
y
Windows® Internet Explorer® 6.0 or higher
y
DirectX® 9.0c revision 30 (August 2006) or higher
y
Network environment: 100 Mb Ethernet, WLAN
Macintosh
y
Mac OS X 10.5 (Leopard) or 10.6 (Snow Leopard)
y
Macintosh computer with an Intel x86 processor
y
Hard drive space: 200 MB hard drive space for a
typical installation of Nero MediaHome stand-
alone
y
Memory: 256 MB RAM
Appendix 69
Appendix
6
Installing Nero MediaHome 4
Essentials
Windows
Start up your computer, and insert the supplied CD-
ROM disc into your computer’s CD-ROM drive. An
installation wizard will walk you through the quick
and uncomplicated installation process. To install
Nero MediaHome 4 Essentials, proceed as follows:
1. Close all Microsoft Windows programs and exit
any anti-virus software that may be running.
2. Insert the supplied CD-ROM disc into your
computer’s CD-ROM drive.
3. Click [Nero MediaHome 4 Essentials].
4. Click [Run] to start installation.
5. Click [Nero MediaHome 4 Essentials]. The
installation is prepared and the installation
wizard appears.
6. Click the [Next] button to display the serial
number input screen. Click [Next] to go to the
next step.
7. If you accept all conditions, click [I accept
the License Conditions] check box and click
[Next]. Installation is not possible without this
agreement.
8. Click [Typical] and click [Next]. The installation
process is started.
9. If you want to take part in the anonymous
collection of data, select the check box and click
the [Next] button.
10. Click the [Exit] button to complete the
installation.
Mac OS X
1. Start up your computer, and insert the supplied
CD-ROM disc into your computer’s CD-ROM
drive.
2. Browse the CD-ROM drive and open the
“MediaHome_4_Essentials_MAC” folder.
3. Double-click the “Nero MediaHome.dmg” image
le. The Nero MediaHome window is opened.
4. In the Nero MediaHome window, drag the Nero
MediaHome icon either to the Applications
folder within the window or to any other
desired location.
5. You can now start the application by double-
clicking the Nero MediaHome icon in the
location you dragged it to.
Sharing files and folders
On your computer, you must share the folder
contained movie, music and/or photo content to
play them on this player.
This parts explains the procedure for selecting the
shared folders on your computer.
1. Double-click the “Nero MediaHome 4 Essentials”
icon.
2. Click [Network] icon on the left and dene your
network name in the [Network name] eld. The
Network name you enter will be recognized by
your player.
3. Click [Shares] icon on the left.
4. Click [Local Folders] tab on the [Shares] screen.
5. Click [Add] icon to open the [Browse Folder]
window.
6. Select the folder containing the les you want
to share. The selected folder is added to the list
of shared folders.
7. Click [Start Server] icon to start the server.
y
If the shared folders or les are not displayed
on the player, click the folder on the [Local
Folders] tab and click [Rescan Folder] at the
[More] button.
y
Visit www.nero.com for more information
and software tools
,
Note
Appendix70
Appendix
6
Area Code List
Choose an area code from this list.
Area Code Area Code Area Code Area Code
Afghanistan AF
Argentina AR
Australia AU
Austria AT
Belgium BE
Bhutan BT
Bolivia BO
Brazil BR
Cambodia KH
Canada CA
Chile CL
China CN
Colombia CO
Congo CG
Costa Rica CR
Croatia HR
Czech Republic CZ
Denmark DK
Ecuador EC
Egypt EG
El Salvador SV
Ethiopia ET
Fiji FJ
Finland FI
France FR
Germany DE
Great Britain GB
Greece GR
Greenland GL
Hong Kong HK
Hungary HU
India IN
Indonesia ID
Israel IL
Italy IT
Jamaica JM
Japan JP
Kenya KE
Kuwait KW
Libya LY
Luxembourg LU
Malaysia MY
Maldives MV
Mexico MX
Monaco MC
Mongolia MN
Morocco MA
Nepal NP
Netherlands NL
Antilles AN
New Zealand NZ
Nigeria NG
Norway NO
Oman OM
Pakistan PK
Panama PA
Paraguay PY
Philippines PH
Poland PL
Portugal PT
Romania RO
Russian
Federation RU
Saudi Arabia SA
Senegal SN
Singapore SG
Slovak Republic SK
Slovenia SI
South Africa ZA
South Korea KR
Spain ES
Sri Lanka LK
Sweden SE
Switzerland CH
Taiwan TW
Thailand TH
Turkey TR
Uganda UG
Ukraine UA
United States US
Uruguay UY
Uzbekistan UZ
Vietnam VN
Zimbabwe ZW
Appendix 71
Appendix
6
Language code List
Use this list to input your desired language for the following initial settings: [Disc Audio],
[Disc Subtitle] and [Disc Menu].
Language Code Language Code Language Code Language Code
Afar 6565
Afrikaans 6570
Albanian 8381
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Aymara 6588
Azerbaijani 6590
Bashkir 6665
Basque 6985
Bengali; Bangla 6678
Bhutani 6890
Bihari 6672
Breton 6682
Bulgarian 6671
Burmese 7789
Byelorussian 6669
Chinese 9072
Croatian 7282
Czech 6783
Danish 6865
Dutch 7876
English 6978
Esperanto 6979
Estonian 6984
Faroese 7079
Fiji 7074
Finnish 7073
French 7082
Frisian 7089
Galician 7176
Georgian 7565
German 6869
Greek 6976
Greenlandic 7576
Guarani 7178
Gujarati 7185
Hausa 7265
Hebrew 7387
Hindi 7273
Hungarian 7285
Icelandic 7383
Indonesian 7378
Interlingua 7365
Irish 7165
Italian 7384
Japanese 7465
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kirghiz 7589
Korean 7579
Kurdish 7585
Laotian 7679
Latin 7665
Latvian, Lettish 7686
Lingala 7678
Lithuanian 7684
Macedonian 7775
Malagasy 7771
Malay 7783
Malayalam 7776
Maori 7773
Marathi 7782
Moldavian 7779
Mongolian 7778
Nauru 7865
Nepali 7869
Norwegian 7879
Oriya 7982
Panjabi 8065
Pashto, Pushto 8083
Persian 7065
Polish 8076
Portuguese 8084
Quechua 8185
Rhaeto-Romance 8277
Rumanian 8279
Russian 8285
Samoan 8377
Sanskrit 8365
Scots Gaelic 7168
Serbian 8382
Serbo-Croatian 8372
Shona 8378
Sindhi 8368
Singhalese 8373
Slovak 8375
Slovenian 8376
Spanish 6983
Sudanese 8385
Swahili 8387
Swedish 8386
Tagalog 8476
Tajik 8471
Tamil 8465
Telugu 8469
Thai 8472
Tonga 8479
Turkish 8482
Turkmen 8475
Twi 8487
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapük 8679
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 7473
Yoruba 8979
Zulu 9085
Appendix72
Appendix
6
Trademarks and
Licenses
Blu-ray Disc™, Blu-ray™, Blu-ray 3D™, BD-Live™,
BONUSVIEW™ and the logos are trademarks of
the Blu-ray Disc Association.
“DVD Logo” is a trademark of DVD Format/Logo
Licensing Corporation.
Java is a trademark of Oracle and/or its aliates.
HDMI, the HDMI logo and High-Denition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC in the United
States and other countries.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
DLNA®, the DLNA Logo and DLNA CERTIFIED® are
trademarks, service marks, or certication marks
of the Digital Living Network Alliance.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535;
7,392,195; 7,272,567; 7,333,929; 7,212,872 & other
U.S. and worldwide patents issued & pending.
DTS-HD, the Symbol, & DTS-HD and the Symbol
together are registered trademarks & DTS-HD
Master Audio | Essential is a trademark of DTS,
Inc. Product includes software. © DTS, Inc. All
Rights Reserved.
The Wi-Fi CERTIFIED Logo is a certication mark
of the Wi-Fi Alliance.
The Wi-Fi Protected Setup Mark is a trademark of
the Wi-Fi Alliance.
“AVCHD” and the “AVCHD” logo are trademarks of
Panasonic Corporation and Sony Corporation.
“Made for iPod,” “Made for iPhone,” and “Made for
iPad” mean that an electronic accessory has been
designed to connect specically to iPod, iPhone,
or iPad, respectively, and has been certied
by the developer to meet Apple performance
standards. Apple is not responsible for the
operation of this device or its compliance with
safety and regulatory standards. Please note that
the use of this accessory with iPod, iPhone, or
iPad may aect wireless performance.
Appendix 73
Appendix
6
Bluetooth® wireless technology is a system which
allows radio contact between electronic devices
within a max. range of 10 meters.
Connecting individual devices under Bluetooth®
wireless technology does not incur any charges.
A mobile phone with Bluetooth® wireless tech-
nology can be operated via the Cascade if the
connection was made via Bluetooth® wireless
technology.
The Bluetooth® word mark and logos are owned
by the Bluetooth® SIG, Inc. and any use of such
marks by LG Electronics is under license.
Other trademarks and trade names are those of
their respective owners.
Cinavia Notice
This product uses Cinavia technology to limit the
use of unauthorized copies of some commercially-
produced lm and videos and their soundtracks.
When a prohibited use of an unauthorized copy is
detected, a message will be displayed and playback
or copying will be interrupted.
More information about Cinavia technology
is provided at the Cinavia Online Consumer
Information Center at http://www.cinavia.com. To
request additional information about Cinavia by
mail, send a postcard with your mailing address
to: Cinavia Consumer Information Center, P.O. Box
86851, San Diego, CA, 92138, USA.
This product incorporates proprietary technology
under license from Verance Corporation and is
protected by U.S. Patent 7,369,677 and other U.S.
and worldwide patents issued and pending as well
as copyright and trade secret protection for certain
aspects of such technology. Cinavia is a trademark
of Verance Corporation. Copyright 2004-2010
Verance Corporation. All rights reserved by Verance.
Reverse engineering or disassembly is prohibited.
Appendix74
Appendix
6
Audio Output Specifications
Jack/Setting
Source
HDMI OUT
PCM Stereo PCM
Multi-Ch
DTS Re-encode
*
3
BitStream
*
1
*
2
Dolby Digital PCM 2ch PCM 5.1ch DTS Dolby Digital
Dolby Digital Plus PCM 2ch PCM 5.1ch DTS Dolby Digital Plus
Dolby TrueHD PCM 2ch PCM 5.1ch DTS Dolby TrueHD
DTS PCM 2ch PCM 5.1ch DTS DTS
DTS-HD PCM 2ch PCM 5.1ch DTS DTS-HD
Linear PCM 2ch PCM 2ch PCM 2ch DTS Linear PCM 2ch
Linear PCM 5.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 5.1ch
Linear PCM 7.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 7.1ch
*1 The secondary and interactive audio may not
be included in the output bitstream if [Digital
Output] option is set to [BitStream]. (Except
LPCM Codec : the output always include
interactive and secondary audio.)
*2 This player automatically selects the HDMI audio
according to the decoding capability of the
connected HDMI device even though [Digital
Output] option is set to [BitStream].
*3 If the [Digital Output] option is set to [DTS re-
encode], the audio output is limited to 48 kHz
and 5.1Ch. If the [Digital Output] option is set
to [DTS re-encode], the DTS Re-encode audio
is outputted for BD-ROM discs, and the original
audio is outputted for the other discs (like
[BitStream]).
y
The audio is outputted as PCM 48 kHz/16 bit for
MP3/WMA le and PCM 44.1kHz/16 bit for Audio
CD while playback.
y
With digital audio connection (HDMI OUT),
Disc Menu button sounds of BD-ROM may not
be heard if the [Digital Output] option is set to
[BitStream].
y
If the audio format of the digital output does
not match the capabilities of your receiver, the
receiver will produce a strong, distorted sound or
no sound at all.
y
Multi-channel Digital Surround Sound via digital
connection can only be obtained if your receiver
is equipped with a Digital Multi-channel decoder.
y
This setting is not available on the input signal
from an external device.
Appendix 75
Appendix
6
Specifications
General
Power requirements Refer to main label on the rear panel.
Power consumption Refer to main label on the rear panel.
Dimensions (W x H x D) Approx. 440 x 65 x 297 mm (17.3 x 2.5 x 11.6 inches)
Net Weight (Approx.) 3.3 kg (7.2 lbs)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Inputs/Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
HDMI IN/OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1
PORT. IN 0.5 Vrms (3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplier
Power output (4 Ω/ 3 Ω), (RMS), THD 10 %
Total 1100 W
Front 140 W x 2
Center 140 W
Rear 180 W x 2
Sub-Woofer 180 W (Passive)
3D Eect -Left 70 W
3D Eect -Right 70 W
Wireless receiver
Power requirements Refer to main label on the wireless receiver
Power consumption Refer to main label on the wireless receiver
External dimensions (WxHxD) 60 X 220 X 175 mm (2.3 x 8.6 x 6.8 inches)
Net Weight 0.9 kg (1.9 lbs)
Appendix76
Appendix
6
System
Laser Semiconductor laser
Wavelength 405 nm / 650 nm
Signal system Standard NTSC color TV system
Frequency response 20 Hz to 18 kHz (48 kHz, 96 kHz, 192 kHz sampling)
Harmonic distortion Less than 0.05 %
Dynamic range More than 80 dB
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna)
Integrated IEEE 802.11n (2.4 GHz band) wireless networking access,
compatible with 802.11b/g Wi-Fi networks.
Bus Power Supply (USB) DC 5 V
0
2.1 A
Speakers (BH9520TW)
Front speaker (Left/ Right)
Type 2 Way 3 Speaker Max. Input power 280 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
280 x 1330 x 280 mm
(11 x 52.3 x 11 inches)
Input Power 140 W Net Weight 5.5 Kg (12.1 lbs)
Rear speaker (Left/ Right)
Type 2 Way 3 Speaker Max. Input power 360 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
280 x 1330 x 280 mm
(11 x 52.3 x 11 inches)
Input Power 180 W Net Weight 5.5 Kg (12.1 lbs)
Center speaker
Type 2 Way 3 speaker Max. Input power 280 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
412 x 82 x 73 mm
(16.2 x 3.2 x 2.8 inches)
Input Power 140 W Net Weight 1.4 kg (3 lbs)
Subwoofer
Type 1 Way 1 Speaker Max. Input power 360 W
Impedance Rated 3 Ω
Net Dimensions
(W x H x D)
251 x 336 x 347 mm
(9.8 x 13.2 x 13.6 inches)
Input Power 180 W Net Weight 6.3 Kg (13.8 lbs)
Top speaker (Front left and Front right speakers)
Type 1 Way 2 Speaker Max. Input power 140 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
Built in Front speaker
Input Power 70 W Net Weight
Appendix 77
Appendix
6
Speakers (BH9420PW)
Front speaker (Left/ Right)
Type 2 Way 3 Speaker Max. Input power 280 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
280 x 1330 x 280 mm
(11 x 52.3 x 11 inches)
Input Power 140 W Net Weight 5.5 Kg (12.1 lbs)
Rear speaker (Left/ Right)
Type 2 Way 2 Speaker Max. Input power 360 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
88 x 292 x 86 mm
(3.4 x 11.4 x 3.3 inches)
Input Power 180 W Net Weight 1.4 Kg (3 lbs)
Center speaker
Type 2 Way 3 speaker Max. Input power 280 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
412 x 82 x 73 mm
(16.2 x 3.2 x 2.8 inches)
Input Power 140 W Net Weight 1.4 kg (3 lbs)
Subwoofer
Type 1 Way 1 Speaker Max. Input power 360 W
Impedance Rated 3 Ω
Net Dimensions
(W x H x D)
251 x 336 x 347 mm
(9.8 x 13.2 x 13.6 inches)
Input Power 180 W Net Weight 6.3 Kg (13.8 lbs)
Top speaker (Front left and Front right speakers)
Type 1 Way 2 Speaker Max. Input power 140 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
Built in Front speaker
Input Power 70 W Net Weight
Appendix78
Appendix
6
Speakers (BH9220BW)
Front speaker (Left/ Right)
Type 2 Way 2 Speaker Max. Input power 280 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
88 x 292 x 86 mm
(3.4 x 11.4 x 3.3 inches)
Input Power 140 W Net Weight 1.4 Kg (3 lbs)
Rear speaker (Left/ Right)
Type 2 Way 2 Speaker Max. Input power 360 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
88 x 292 x 86 mm
(3.4 x 11.4 x 3.3 inches)
Input Power 180 W Net Weight 1.4 Kg (3 lbs)
Center speaker
Type 2 Way 3 speaker Max. Input power 280 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
412 x 82 x 73 mm
(16.2 x 3.2 x 2.8 inches)
Input Power 140 W Net Weight 1.4 kg (3 lbs)
Subwoofer
Type 1 Way 1 Speaker Max. Input power 360 W
Impedance Rated 3 Ω
Net Dimensions
(W x H x D)
251 x 336 x 302 mm
(9.8 x 13.2 x 11.8 inches)
Input Power 180 W Net Weight 6.0 Kg (13.2 lbs)
Top speaker (Front left and Front right speakers)
Type 1 Way 2 Speaker Max. Input power 140 W
Impedance Rated 4 Ω
Net Dimensions
(W x H x D)
Built in Front speaker
Input Power 70 W Net Weight
y
Design and specications are subject to change without notice.
Appendix 79
Appendix
6
Maintenance
Handling the Unit
When shipping the unit
Please save the original shipping carton and
packing materials. If you need to ship the unit, for
maximum protection, re-pack the unit as it was
originally packed at the factory.
Keeping the exterior surfaces clean
Cleaning the unit
To clean the player, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not
use strong solvents such as alcohol, benzine, or
thinner, as these might damage the surface of the
unit.
y
Do not use volatile liquids such as insecticide
spray near the unit.
y
Wiping with strong pressure may damage the
surface.
y
Do not leave rubber or plastic products in
contact with the unit for a long period of time.
Maintaining the Unit
The unit is a high-tech, precision device. If the
optical pick-up lens and disc drive parts are dirty
or worn, the picture quality could be diminished.
For details, please contact your nearest authorized
service center.
Notes on Discs
Handling Discs
Do not touch the playback side of the disc. Hold
the disc by the edges so that ngerprints do not
get on the surface. Never stick paper or tape on the
disc.
Storing Discs
After playing, store the disc in its case. Do not
expose the disc to direct sunlight or sources of heat
and never leave it in a parked car exposed to direct
sunlight.
Cleaning Discs
Fingerprints and dust on the disc can cause poor
picture quality and sound distortion. Before playing,
clean the disc with a clean cloth. Wipe the disc from
the center to out.
Do not use strong solvents such as alcohol,
benzine, thinner, commercially available cleaners,
or anti-static spray intended for older vinyl records.
Appendix80
Appendix
6
Important Information
Relating to Network
Services
All information, data, documents, communications,
downloads, les, text, images, photographs,
graphics, videos, webcasts, publications, tools,
resources, software, code, programs, applets,
widgets, applications, products and other content
(“Content”) and all services and oerings (“Services”)
provided or made available by or through any
third party (each a “Service Provider”) is the sole
responsibility of the Service Provider from whom it
originated.
The availability of and access to Content and
Services furnished by the Service Provider through
the LGE Device are subject to change at any time,
without prior notice, including, but not limited to
the suspension, removal or cessation of all or any
part of the Content or Services.
Should you have any inquiry or problem related
to the Content or Services, you may refer to the
Service Provider’s website for the most up-to-
date information. LGE is neither responsible nor
liable for customer service related to the Content
and Services. Any question or request for service
relating to the Content or Services should be made
directly to the respective Content and Service
Providers.
Please note that LGE is not responsible for any
Content or Services provided by the Service
Provider or any changes to, removal of, or cessation
of such Content or Services and does not warrant
or guaranty the availability of or access to such
Content or Services.
Appendix 81
Appendix
6
