Basic Owner’s Manual
4K Video Camera
Model No.
HC-WXF991
HC-VX981
Please read these instructions carefully before using this product, and save this manual for future
use.
More detailed operating instructions are available in “Owner’s Manual
(PDF format)”. To read it, download it from the website.
https://eww.pavc.panasonic.co.jp/hdw/oi/WXF990/
≥ Click the desired language.
SQT1152
until
2016/2/28
Register online at
http://shop.panasonic.com/support
(U.S. customers only)
If you have any questions, visit :
U.S.A. : http://shop.panasonic.com/support
Canada : www.panasonic.ca/english/support
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 1 ページ ２０１６年１月７日 木曜日 午前１０時３０分
2
SQT1152 (ENG)
Dear Customer,
Thank you for choosing Panasonic!
You have purchased one of the most
sophisticated and reliable products on the
market today. Used properly, we’re sure it
will bring you and your family years of
enjoyment. Please take time to fill in the
information on the right.
The serial number is on the tag located on
the back of your camera. Be sure to retain
this manual as your convenient camera
information source.
Safety Precautions
WARNING:
To reduce the risk of fire, electric shock or product damage,
≥ Do not expose this unit to rain, moisture, dripping or splashing.
≥ Do not place objects filled with liquids, such as vases, on this unit.
≥ Use only the recommended accessories.
≥ Do not remove covers.
≥ Do not repair this unit by yourself. Refer servicing to qualified service personnel.
CAUTION!
To reduce the risk of fire, electric shock or product damage,
≥ Do not install or place this unit in a bookcase, built-in cabinet or in another confined space.
Ensure this unit is well ventilated.
≥ Do not obstruct this unit’s ventilation openings with newspapers, tablecloths, curtains, and
similar items.
≥ Do not place sources of naked flames, such as lighted candles, on this unit.
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
U.S.A./CANADA CONSUMERS: ATTENTION:
A lithium ion battery that is recyclable powers the product
you have purchased. Please call 1-800-8-BATTERY for
information on how to recycle this battery.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 2 ページ ２０１６年１月７日 木曜日 午前１０時３０分
3
(ENG) SQT1152
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
THE FOLLOWING APPLIES ONLY IN CANADA.
Certification and Compliance
See Camcorder for the certification and compliance mark specific to that device.
1Touch .
2 Touch [SETUP].
3 Touch [Approved Regulations]
.
FCC Note:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
≥ Reorient or relocate the receiving antenna.
≥ Increase the separation between the equipment and receiver.
≥ Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
≥ Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, follow the attached installation
instructions and use only shielded interface cables with ferrite
core when connecting to computer or peripheral devices.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Declaration of Conformity
Trade Name: Panasonic
Model No.: HC-WXF991/HC-VX981
Responsible Party: Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
Support Contact: http://shop.panasonic.com/support
CAN ICES-3(B)/NMB-3(B)
MENU
HC-WXF991
HC-VX981
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 3 ページ ２０１６年１月７日 木曜日 午前１０時３０分
4
SQT1152 (ENG)
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
THE FOLLOWING APPLIES ONLY IN CANADA.
Contains FCC ID: VPYLBVX532
FCC CAUTION
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to
OET65.
This equipment has very low levels of RF energy that are deemed to comply without testing of
specific absorption ratio (SAR).
Contains IC: 772C-LBVX604
This device complies with Industry Canada’s licence-exempt
RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of the device.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules.
This equipment has very low levels of RF energy that are deemed to comply without testing of
specific absorption ratio (SAR).
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 4 ページ ２０１６年１月７日 木曜日 午前１０時３０分
5
(ENG) SQT1152
IMPORTANT SAFETY
INSTRUCTIONS
Read these operating instructions carefully before using the unit. Follow the safety instructions on
the unit and the applicable safety instructions listed below. Keep these operating instructions handy
for future reference.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8) Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding-type plug
has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete
outlet.
10) Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories
specified by the manufacturer.
12) Use only with the
cart, stand, tripod,
bracket, or table
specified by the
manufacturer, or
sold with the
apparatus. When a
cart is used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 5 ページ ２０１６年１月７日 木曜日 午前１０時３０分
6
SQT1152 (ENG)
∫ Concerning the battery
∫ Product Identification Marking
Conforms to UL STD 60065.
Certified to CAN/CSA STD C22.2 No.60065.
AC adaptor
This AC adaptor operates on AC between 110 V and 240 V.
But
≥ In the U.S.A. and Canada, the AC adaptor must be connected to a 120 V AC power supply only.
≥ When connecting to an AC supply outside of the U.S.A. or Canada, use a plug adaptor to suit
the AC outlet configuration.
The power plug is the disconnecting device. Install this unit so that the power plug can be
unplugged from the socket outlet immediately.
Battery pack (Lithium ion battery pack)
≥ Use the specified unit to recharge the battery pack.
≥ Do not use the battery pack with equipment other than the specified unit.
≥ Do not get dirt, sand, liquids, or other foreign matter on the terminals.
≥ Do not touch the plug terminals (i and j) with metal objects.
≥ Do not disassemble, remodel, heat or throw into fire.
If any electrolyte should come into contact with your hands or clothes, wash it off thoroughly with
water.
If any electrolyte should come into contact with your eyes, never rub the eyes. Rinse eyes
thoroughly with water, and then consult a doctor.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 oC (140 oF) or incinerate.
CAUTION
≥ Danger of explosion if battery is incorrectly replaced. Replace only with the type
recommended by the manufacturer.
≥ When disposing of the batteries, please contact your local authorities or dealer and ask for the
correct method of disposal.
Product Location
4K Video Camera Battery holder
AC adaptor Bottom
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 6 ページ ２０１６年１月７日 木曜日 午前１０時３０分
7
(ENG) SQT1152
∫ Cautions for use
Keep this unit as far away as possible from
electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
≥ If you use this unit on top of or near a TV, the
pictures and/or sound on this unit may be
disrupted by electromagnetic wave radiation.
≥ Do not use this unit near cell phones because
doing so may result in noise adversely
affecting the pictures and/or sound.
≥ Recorded data may be damaged, or pictures
may be distorted, by strong magnetic fields
created by speakers or large motors.
≥ Electromagnetic wave radiation generated by
microprocessors may adversely affect this
unit, disturbing the pictures and/or sound.
≥ If this unit is adversely affected by
electromagnetic equipment and stops
functioning properly, turn this unit off and
remove the battery or disconnect AC adaptor.
Then reinsert the battery or reconnect AC
adaptor and turn this unit on.
Do not use this unit near radio transmitters
or high-voltage lines.
≥ If you record near radio transmitters or
high-voltage lines, the recorded pictures and/
or sound may be adversely affected.
About connecting to a PC
≥ Do not use any other USB cables except the
supplied one.
About connecting to a TV
≥ Do not use any other HDMI micro cables
except the supplied one.
Make sure to use the supplied cords and
cables. If you use optional accessories, use
the cords and the cables supplied with them.
Do not extend the cords and the cables.
Do not spray insecticides or volatile
chemicals onto the unit.
≥
If the unit is sprayed with such chemicals, its body
may be marred and the surface finish may peel off.
≥ Do not leave rubber or plastic products in
contact with the unit for a long time.
Cleaning
≥ Before cleaning, detach the battery or pull the
AC adaptor from the AC outlet, and then wipe
the unit with a soft, dry cloth.
≥
If the unit is very dirty, dip a cloth in water and
squeeze firmly, and then wipe the unit with the
damp cloth. Next, dry the unit with a dry cloth.
≥
Use of benzine, paint thinner, alcohol, or
dishwashing liquid may alter the camera body or
peel the surface finish. Do not use these solvents.
≥ When using a chemical dust cloth, follow the
instructions that came with the cloth.
When you are not going to use the unit for
an extended time
≥ When storing the unit in a cupboard or
cabinet, it is recommended that you place a
desiccant (silica gel) in with it.
Be sure to detach the battery after use.
≥ If the battery is left attached, a minute amount
of current continues to flow even if the unit is
off. Keeping the unit in this state may result in
over discharge of the battery. This may result
in you not being able to use the battery even
after it is charged.
≥ The battery should be stored in a cool place
free from humidity, with as constant
temperature as possible. (Recommended
temperature: 15 oC to 25 oC (59 oF to 77 oF),
Recommended humidity: 40%RH to 60%RH)
≥ To store the battery for a long period of time,
we recommend you charge it once every year
and store it again after you have completely
used up the charged capacity.
If the operating time is very short even after
the battery has been recharged, the battery
has worn out. Please purchase a new battery.
About the SD card
≥ When the card access lamp is lit, do not:
j Remove the SD card
j Turn the unit off
j Insert and remove the USB cable
j Expose the unit to vibrations or shock
The unit and the SD card become warm
during use. This is not a malfunction.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 7 ページ ２０１６年１月７日 木曜日 午前１０時３０分
8
SQT1152 (ENG)
(For the )
About the accessory shoe cover
≥ Close accessory shoe
cover A when not using
the accessory shoe.
≥ For details about
accessory shoe cover,
refer to the Owner’s
Manual (PDF format).
∫ About the recording format for
recording motion pictures
≥ Motion pictures recorded with other
devices are not supported by this unit.
You can select from AVCHD
*1
, 4K MP4
*2
,
MP4
*2
, iFrame
*2
or 24p
*2
recording formats to
record motion pictures using this unit.
*1 It is compatible with the AVCHD
Progressive (1080/60p).
*2 It is not compatible with motion pictures
recorded in AVCHD format.
AVCHD:
It is suitable for viewing on a high-definition TV
or for saving to disc
*3
.
*3 The following methods are available for
saving an image recorded in 1080/60p:
j Copy the image to a disc using the
HD Writer AE 5.3.
j
Copy the image to a Panasonic Blu-ray disc
recorder that supports AVCHD Progressive.
4K MP4:
This is a recording format suitable for editing images.
This format can record 4K motion pictures (3840
k
2160/
30p), which deliver a resolution four times higher than
that of full high-definition motion pictures.
MP4:
This is a recording format suitable for playing
back or editing on a PC.
iFrame:
This is a recording format suitable for playing
back or editing on a Mac (iMovie etc.).
24p:
This allows you to record images similar to
those shot on a roll of cinema film.
Images can be recorded as 4K motion pictures
(3840k2160/24p) or in high-definition picture
quality (1920k1080/24p).
∫
Indemnity about recorded content
Panasonic does not accept any responsibility for
damages directly or indirectly due to any type of
problems that result in loss of recording or edited
content, and does not guarantee any content if
recording or editing does not work properly.
Likewise, the above also applies in a case where
any type of repair is made to the unit.
∫ About Condensation
(When the lens, the viewfinder
or LCD Monitor is fogged up)
Condensation occurs when there is a change in
temperature or humidity, such as when the unit is taken
from outside or a cold room to a warm room. Please be
careful, as it may cause the lens, the viewfinder or LCD
monitor to become soiled, moldy, or damaged.
When taking the unit to a place which has a
different temperature, if the unit is accustomed
to the room temperature of the destination for
about one hour, condensation can be
prevented. (When the difference in temperature
is severe, place the unit in a plastic bag or the
like, remove air from the bag, and seal the bag.)
When condensation has occurred, remove the
battery and/or the AC adapter and leave the
unit like that for about one hour. When the unit
becomes accustomed to the surrounding
temperature, fogginess will disappear naturally.
∫ Cards that you can use with
this unit
SD Memory Card, SDHC Memory Card and
SDXC Memory Card
≥
4 GB or more Memory Cards that do not have
the SDHC logo or 48 GB or more Memory
Cards that do not have the SDXC logo are not
based on SD Memory Card Specifications.
≥
Refer to page 16 for more details on SD cards.
∫ For the purposes of this
owner’s manual
≥
SD Memory Card, SDHC Memory Card and SDXC
Memory Card are referred to as the “SD card”.
≥ The smartphone and tablet are indicated as
“smartphone”.
≥ Function that can be used for Motion Picture
Recording Mode:
Function that can be used for Still Picture
Recording Mode:
WXF991
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 8 ページ ２０１６年１月７日 木曜日 午前１０時３０分
9
(ENG) SQT1152
≥ Function that can be used for the Playback
Mode:
Function that can be used for the Playback
Mode (motion pictures only):
Function that can be used for the Playback
Mode (still pictures only):
≥ Scene(s) recorded in the recording format
[AVCHD]: “AVCHD scene(s)”
≥ Scene(s) recorded in the recording format
[4K MP4] and scene(s) recorded in 4K
PHOTO mode: “4K MP4 scene(s)”
≥ Scene(s) recorded in the recording format
[MP4/iFrame] and scene(s) saved in
MP4 (1920k1080/30p), MP4 (1280k720/
30p) or MP4 (640k360/30p): “MP4/iFrame
scene(s)”
≥ Scene(s) recorded in the recording mode
[iFrame]: “iFrame scene(s)”
≥ Scene(s) recorded in the recording format
[24p]: “24p scene(s)”
≥
Scene(s) containing only the Main Camera’s
image that was recorded separately from a
simultaneously recorded normal scene when
[Backup for Twin Camera] was set to [ON]:
“
Scene(s) recorded as Backup for Twin Camera
”
≥ Pages for reference are indicated by an
arrow, for example: l 00
≥ Model numbers are abbreviated as follows in
this owner’s manual:
∫ Installing HD Writer AE 5.3
∫ Downloading the Owner’s
Manual (PDF format)
You can check the URL and QR code of the
website where you can download the Owner’s
Manual (PDF format) in [ONLINE MANUAL] in
the Setup menu.
≥
Touch (left side)/ (right side) of
on the Touch Menu to display . (
l
22)
1Touch .
2 Touch [SETUP].
3 Touch [ONLINE MANUAL].
4 Touch the access method you
want to check.
≥ You will need Adobe Reader to browse or
print the Owner’s Manual (PDF format).
You can download and install a version of
Adobe Reader that you can use with your OS
from the following website. (As of November
2015)
http://www.adobe.com/products/acrobat/
readstep2.html
Model number
Abbreviation used in this
owner’s manual
HC-WXF991 [WXF991]
HC-VX981 [VX981]
This owner’s manual is designed for use with
models and . Pictures may be
slightly different from the original.
≥ The illustrations used in this owner’s manual
show model , however, parts of the
explanation refer to different models.
≥ Depending on the model, some functions
are not available.
≥ and correspond to Wi-Fi
®
functions.
≥ Features may vary, so please read carefully.
≥ Not all models may be available depending
on the region of purchase.
WXF991
VX981
WXF991
VX981
WXF991
WXF991
VX981
Check the website below to download/install
the software.
≥ The software is available for download until
the end of March 2019.
http://panasonic.jp/support/global/cs/soft/
download/f_ae53.html
[URL display]:
Displays the URL of the website on the LCD
monitor of this unit.
[USB connect]:
Displays the website on a PC connected to
this unit with the USB cable. Click [OIBOOK],
which will be displayed on the PC.
[QR code]:
Displays the QR code of the website on the
LCD monitor of this unit.
MENU
MENU
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 9 ページ ２０１６年１月７日 木曜日 午前１０時３０分
10
SQT1152 (ENG)
Accessories.................................................. 11
Preparation
Power supply................................................ 12
Inserting/removing the battery ............... 12
Charging the battery .............................. 13
Charging and recording time ................. 14
Recording to a card ..................................... 16
Cards that you can use with this unit ..... 16
Inserting/removing an SD card .............. 17
Turning the unit on/off................................. 18
Selecting a mode ......................................... 19
Switching this unit between Recording
Mode and Playback Mode ..................... 19
Switching this unit between Motion
Picture Recording Mode and Still Picture
Recording Mode .................................... 19
LCD monitor/viewfinder .............................. 21
How to use the touch screen ................. 21
Viewfinder adjustment [WXF991] ......... 22
About the Touch Menu........................... 22
Setting date and time................................... 23
Setting your home region for the first
time................................................................ 24
Basic
Changing the Recording Mode................... 25
Recording motion pictures .........................26
Recording still pictures ............................... 26
Recording with the Sub Camera
(Twin Camera) [WXF991] ............................. 27
Motion picture/Still picture playback ......... 28
Watching Video/Pictures on your TV ..... 29
Using the menu screen ............................... 30
Language selection ............................... 30
Formatting ............................................. 30
Wi-Fi
What you can do with the Wi-Fi
®
function .........................................................31
[Link to Cell] .................................................32
Install the “Image App”........................... 32
Preparations before using
[Link to Cell] ........................................... 33
Using [Link to Cell] with a direct
connection.............................................. 34
About [Link to Cell]................................. 35
Wireless Twin/Multi-Camera function.........36
Others
Troubleshooting ...........................................37
About copyright ...........................................39
Specifications...............................................41
Optional accessories ...................................44
Limited Warranty (ONLY FOR U.S.A.).........45
Warranty (For Canadian Customers)..........47
Contents
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 10 ページ ２０１６年１月７日 木曜日 午前１０時３０分
11
(ENG) SQT1152
Check the accessories before using this unit.
Keep the accessories out of reach of children to prevent swallowing.
Product numbers correct as of Nov. 2015. These may be subject to change.
(For U.S.A. only)
If accessories are lost, customers can visit us at http://shop.panasonic.com/support
for further information about obtaining replacement parts.
Accessories
Battery pack
VW-VBT190
HDMI micro cable
K1HY19YY0038
AC adaptor
VSK0815F
Shoe adaptor
VYC1055-A
Not supplied
DC cable
K2GHYYS00002
Lens hood
SYK0602
≥ For details on how to
attach the lens hood,
refer to the Owner’s
Manual (PDF format).
USB cable
K1HY04YY0106
K2KYYYY00236
VX981
WXF991
WXF991
VX981
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 11 ページ ２０１６年１月７日 木曜日 午前１０時３０分
12
SQT1152 (ENG)
∫ About batteries that you can use with this unit
The battery that can be used with this unit is VW-VBT190/VW-VBT380.
≥ The unit has a function for distinguishing batteries which can be used safely. The
dedicated battery (VW-VBT190/VW-VBT380) supports this function. The only batteries
suitable for use with this unit are genuine Panasonic products and batteries manufactured
by other companies and certified by Panasonic. Panasonic cannot in any way guarantee
the quality, performance or safety of batteries which have been manufactured by other
companies and are not genuine Panasonic products.
Inserting/removing the battery
≥ Press the power button to turn off the unit. (l 18)
Install the battery by inserting it in the direction shown in the figure.
Preparation
Power supply
It has been found that counterfeit battery packs which look very similar to the genuine
product are made available to purchase in some markets. Some of these battery packs
are not adequately protected with internal protection to meet the requirements of
appropriate safety standards. There is a possibility that these battery packs may lead to
fire or explosion. Please be advised that we are not liable for any accident or failure
occurring as a result of use of a counterfeit battery pack. To ensure that safe products are
used we would recommend that a genuine Panasonic battery pack is used.
Removing the battery
Be sure to hold down the power button until the status
indicator goes off. Then remove the battery while
supporting the unit to prevent it from dropping.
Move the battery release lever in the direction
indicated by the arrow and remove the battery
when unlocked.
ャモヵヵ
A Battery holder
Insert the battery until it clicks
and locks.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 12 ページ ２０１６年１月７日 木曜日 午前１０時３０分
13
(ENG) SQT1152
Charging the battery
The unit is in the standby condition when the AC adaptor is connected. The primary circuit is always
“live” as long as the AC adaptor is connected to an electrical outlet.
Important:
≥ Do not use the AC adaptor/DC cable with any other equipment as it is designed only for
this unit. Also, do not use the AC adaptor/DC cable from other equipment with this unit.
≥ The battery will not be charged if the unit is turned on.
≥ It is recommended to charge the battery in a temperature between 10 oC and 30 oC (50 oF
and 86 oF). (The battery temperature should also be the same.)
A DC input terminal
1 Connect the DC cable to the AC adaptor and to the DC input terminal of this
unit.
≥ Insert the plugs as far as they will go.
2 Insert the AC adaptor into an AC outlet.
≥ The status indicator will flash red at an interval of approximately 2 seconds (approximately
1 second on, approximately 1 second off), indicating that charging has begun.
It will turn off when the charging is completed. (l 18)
∫ Connecting to the AC outlet
It is possible to use this unit with power supplied from the AC outlet by turning on the unit with the
AC adaptor connected.
Even when you use the AC adaptor for recording images, keep the battery connected.
This allows you to continue the recording even if a power failure occurs or the AC adaptor is
unplugged from the AC outlet by accident.
∫ To charge by connecting to other device
It is possible to charge by connecting to other device with the USB cable (supplied).
≥ Do not use any other DC cables except the supplied one.
≥ Do not use any other AC adaptors except the supplied one.
≥ We recommend using Panasonic batteries (l 12).
≥ If you use other batteries, we cannot guarantee the quality of this product.
≥ Do not heat or expose to flame.
≥ Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with
doors and windows closed.
When this unit is purchased, the battery is not charged. Charge the battery fully before
using this unit for the first time.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 13 ページ ２０１６年１月７日 木曜日 午前１０時３０分
14
SQT1152 (ENG)
Charging and recording time
∫ Charging/Recording time
≥ Temperature: 25 oC (77 oF)/humidity: 60%RH
≥ When using the LCD monitor
≥ The indicated charging time is for when the battery has been discharged completely.
Charging time and recordable time vary depending on the usage conditions such as high/
low temperature.
≥ Charging times in parentheses are when charging from the USB terminal.
≥ Maximum continuous recordable times and actual recordable times in round parentheses are the
values when the viewfinder is used.
≥
Maximum continuous recordable times and actual recordable times in square parentheses are the
values when recording is performed with the Sub Camera in combination with the LCD monitor
*
.
* These include times when is displayed on the screen.
For the [WXF991]
Battery model
number
[Voltage/Capacity
(minimum)]
Charging
time
Recording
format
Recording
mode
Maximum
continuous
recordable
time
Actual
recordable
time
Supplied battery/
VW-VBT190
(optional)
[3.6 V/1940 mAh]
2h20min
(5h20min)
[4K MP4] [2160]
1h25min
(1h30min)
[1h5min]
45 min
(45 min)
[35 min]
[MP4/
iFrame]
[1080/50M],
[1080/28M]
1h40min
(1h45min)
[1h15min]
50 min
(55 min)
[40 min]
[720]
2h
(2h5min)
[1h25min]
1h
(1 h 5 min)
[45 min]
[iFrame]
2h
(2h10min)
[1h30min]
[AVCHD]
[1080/60p],
[PH]
1h40min
(1h45min)
[1h15min]
50 min
(55 min)
[40 min]
[HA], [HG]
1h40min
(1h50min)
[1h15min]
[HE]
1h40min
(1h50min)
[1h20min]
[24p]
[2160/24p]
1h35min
(1h40min)
50 min
(50 min)
[1080/24p]
2h
(2h10min)
1h
(1 h 5 min)
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 14 ページ ２０１６年１月７日 木曜日 午前１０時３０分
15
(ENG) SQT1152
≥ “h” is an abbreviation for hour, “min” for minute and “s” for second.
≥ These times are approximations.
≥ The actual recordable time refers to the recordable time when repeatedly starting/stopping
recording, turning the unit on/off, moving the zoom lever etc.
∫ Battery capacity indication
The battery capacity indication is displayed on the LCD monitor.
≥ If there is less than 3 minutes remaining, then will become red. If the battery discharges,
then will flash. Recharge the battery or replace it with a fully charged battery.
For the [VX981]
Battery model
number
[Voltage/Capacity
(minimum)]
Charging
time
Recording
format
Recording
mode
Maximum
continuous
recordable
time
Actual
recordable
time
Supplied battery/
VW-VBT190
(optional)
[3.6 V/1940 mAh]
2h20min
(5h20min)
[4K MP4] [2160] 1 h 25 min 45 min
[MP4/
iFrame]
[1080/50M],
[1080/28M]
1h35min 50min
[720],
[iFrame]
1h50min 55min
[AVCHD]
[1080/60p] 1 h 35 min
50 min
[PH], [HA],
[HG], [HE]
1h40min
[24p]
[2160/24p] 1 h 35 min 50 min
[1080/24p] 2 h 1 h
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 15 ページ ２０１６年１月７日 木曜日 午前１０時３０分
16
SQT1152 (ENG)
The unit can record still pictures or motion pictures to an SD card. To record to an SD card, read the
following.
Cards that you can use with this unit
∫ About the Speed Class ratings for recording motion pictures
Depending on [REC MODE] and [REC FORMAT], the required card differs.
Use a card that meets the following ratings of the SD Speed Class. Use of a non-compatible
card may cause recording to stop suddenly.
≥ SD Speed Class is the speed standards regarding continuous writing. To check the class, see the
labelled side, etc. of the card.
≥ In the following situations, you need an SD card conforming to Class 10 of the SD Speed
Class Rating to record motion pictures.
Use of a non-compatible card may cause recording to stop suddenly.
j FULL HD Slow Motion Video Mode
j 4K Photo Mode
j When [Backup for Twin Camera] is set to [ON]
j (For the )
Slow & Quick Video Mode
Preparation
Recording to a card
Card type Capacity
SD Memory Card 512 MB to 2 GB
SDHC Memory Card 4GB to 32GB
SDXC Memory Card 48 GB to 128 GB
≥ Please check the latest information on the support website below.
http://panasonic.jp/support/global/cs/e_cam
(This website is in English only.)
≥ We do not guarantee the operation of SD cards other than the ones above.
≥ Operation is not guaranteed for all SD cards.
≥ Keep the Memory Card out of reach of children to prevent swallowing.
Recording formats Recording modes Speed Class ratings Label examples
4K MP4 [2160]
Class 10
24p All
MP4/iFrame
[1080/50M]
[1080/28M], [720],
[iFrame]
Class 4 or more
AVCHD All
WXF991
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 16 ページ ２０１６年１月７日 木曜日 午前１０時３０分
17
(ENG) SQT1152
Inserting/removing an SD card
When using an SD card not from Panasonic, or one previously used on other equipment, for the first
time on this unit, format the SD card. (l 30) When the SD card is formatted, all of the recorded data
is deleted. Once the data is deleted, it cannot be restored.
Caution:
Check that the access lamp has gone off.
Access lamp [ACCESS] A
≥ When this unit is accessing the SD card, the access lamp lights up.
1 Open the SD card cover and insert (remove) the SD card into (from) the
card slot B.
≥ Face the label side C in the direction shown in the illustration and press it straight in as far as
it will go.
≥ Press the center of the SD card and then pull it straight out.
2 Securely close the SD card cover.
≥ Securely close it until it clicks.
WXF991
VX981
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 17 ページ ２０１６年１月７日 木曜日 午前１０時３０分
18
SQT1152 (ENG)
You can turn the unit on and off using the power button or by opening and closing the LCD monitor.
Open the LCD monitor and press the power button to turn on the unit.
A The status indicator lights on.
The unit is turned on when the LCD monitor is opened, and unit is turned off when it is closed.
≥ (For the )
j You can also turn the unit on and off using the viewfinder.
j The unit will not turn off unless the LCD monitor is closed and the viewfinder is retracted.
j When the viewfinder is extended, opening the LCD monitor turns off the viewfinder and turns
on the LCD monitor.
∫ Overheat detection
When the internal temperature of the unit rises during use, a message will be displayed. When this
happens, the unit will turn off automatically a few minutes later.
≥ Wait until the temperature has dropped before resuming use.
If you try to use the Wi-Fi function while the internal temperature of this unit is high, a message will
be displayed. When this happens, the Wi-Fi function is disabled.
≥ Wait until the temperature has dropped before resuming use.
Preparation
Turning the unit on/off
Turning the unit on and off with the power button
To turn off the unit
Hold down the power button until the status indicator goes off.
WXF991
VX981
WXF991
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 18 ページ ２０１６年１月７日 木曜日 午前１０時３０分
19
(ENG) SQT1152
You can switch this unit between Recording Mode (Motion Picture Recording Mode/Still Picture
Recording Mode) and Playback Mode by pressing the recording/playback button.
If you touch the recording mode switching icon in Recording Mode, this unit can be switched
between Motion Picture Recording Mode and Still Picture Recording Mode.
≥ (For the )
In Recording Mode, pressing the recording mode selector button allows you to switch between
Motion Picture Recording Mode, 4K Photo Mode and Still Picture Recording Mode.
Switching this unit between Recording Mode and
Playback Mode
Switching this unit between Motion Picture Recording
Mode and Still Picture Recording Mode
* Still Picture Recording Mode is selected in the following situations:
j When the Wireless Twin Camera function is in use
j When [REC FORMAT] is set to [24p]
j Night Mode
Preparation
Selecting a mode
Motion Picture Recording Mode (l 26) Recording motion pictures.
Still Picture Recording Mode (l 26) Recording still pictures.
Playback Mode (l 28) Motion picture/Still picture playback.
Pressing a button to switch between Motion Picture Recording Mode
and Still Picture Recording Mode [WXF991]
WXF991
Recording/playback button
Press the button to switch this unit between
Recording Mode and Playback Mode.
≥ When you turn on this unit, it starts up in
Recording Mode.
バフレチヱラヰヵヰバ
Recording mode selector button
Each time you press this button, the Recording Mode
switches in the following order:
Motion Picture Recording Mode # 4K Photo Mode* #
Still Picture Recording Mode
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 19 ページ ２０１６年１月７日 木曜日 午前１０時３０分
20
SQT1152 (ENG)
Touch the recording mode switching icon displayed on the LCD monitor (touch screen) to switch this
unit between Motion Picture Recording Mode and Still Picture Recording Mode.
1 Press the recording/playback button to
switch this unit to Recording Mode.
≥
The recording mode switching icon
A
is displayed on the screen.
2 Touch the recording mode switching icon.
≥ Refer to page 21 for touch screen operation.
To display the recording mode switching icon
Display of the recording mode switching icon will disappear when no touch operation is performed
for a specific period of time. To display it again, touch the screen.
≥ The recording mode selector button and the recording mode switching icon are disabled when
the Wireless Multi-Camera function is enabled.
≥ If the recording start/stop button is pressed in Still Picture Recording Mode or Playback Mode,
this unit will be switched to Motion Picture Recording Mode. During motion picture/still picture
playback or in other conditions, even if the recording start/stop button is pressed, the recording
mode may not be switched.
≥ When you switch between Motion Picture Recording Mode, 4K Photo Mode and Still Picture
Recording Mode, settings used in the original recording mode may not be maintained. (l 25)
Touching an icon to switch between Motion Picture Recording Mode
and Still Picture Recording Mode
Motion Picture Recording Mode
Still Picture Recording Mode
(Motion Picture Recording Mode)
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 20 ページ ２０１６年１月７日 木曜日 午前１０時３０分
21
(ENG) SQT1152
How to use the touch screen
You can operate by directly touching the LCD monitor (touch screen) with your finger.
∫ Touch
Touch and release the touch screen to select icon or picture.
≥ Touch the center of the icon.
≥ Touching the touch screen will not operate while you are
touching another part of the touch screen.
∫ Slide while touching
Move your finger while pressing on the touch screen.
∫ About the operation icons
///:
Touch when changing a page or performing settings.
:
Touch to return to the previous screen.
≥ (For the )
When the viewfinder is in use, on-screen icons will be displayed but disabled.
Open the LCD monitor to touch them.
Preparation
LCD monitor/viewfinder
WXF991
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 21 ページ ２０１６年１月７日 木曜日 午前１０時３０分
22
SQT1152 (ENG)
Viewfinder adjustment [WXF991]
∫ Diopter adjustment
Adjust to make the image clear by
rotating the diopter adjustment dial.
≥ Extend the viewfinder and close the LCD
monitor to turn on the viewfinder.
≥ The viewfinder can be raised up to
approximately 60 o A.
≥ When moving the viewfinder, be careful not to
catch your fingers.
∫ About the eye cup
If you remove the eye cup B, rotate it
anti-clockwise by 180 o and re-attach it,
you can also use it with your left eye. For information on how to attach and
remove the eye cup, refer to the Owner's Manual (PDF format).
≥ Keep the eye cup out of reach of children to prevent swallowing.
About the Touch Menu
Touch (left side)/ (right side) of on
the Touch Menu to switch the operation
icons.
≥ It is also possible to switch the operation icons by
sliding the Touch Menu right or left while touching it.
∫ To display the Touch Menu
A Touch Menu
T
W
Display of the Touch Menu will disappear when no
touch operation is performed for a specific period of
time during recording of motion picture/still picture. To
display it again, touch .
≥ Do not touch on the LCD monitor with hard pointed
tips, such as ball point pens.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 22 ページ ２０１６年１月７日 木曜日 午前１０時３０分
23
(ENG) SQT1152
The clock is not set at the time of purchase. Make sure to set the clock.
≥ When you turn on this unit, the message “Set home region and date/time.” may be
displayed. Select [YES], and follow the steps below to make these settings:
j Step 2 of “Setting your home region for the first time”
j Steps 2–3 of “Setting date and time”
1 Select the menu. (l 30)
2 Touch the date or time to be set, then set the desired value using /.
A Displaying the World Time setting:
[HOME]/ [DESTINATION]
≥ The year can be set between 2000 and 2039.
3 Touch [ENTER].
≥ Touch [EXIT] to complete the setting.
Preparation
Setting date and time
: [SETUP] # [CLOCK SET]
MENU
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 23 ページ ２０１６年１月７日 木曜日 午前１０時３０分
24
SQT1152 (ENG)
You can set your home region in [SET WORLD TIME].
1 Select the menu. (l 30)
≥ A message will be displayed. Touch [ENTER].
2 Touch / to select your home
region and touch [ENTER].
≥ When the clock is not set, the current time is
displayed as “--:----”.
≥ For information on how to change your home region or set the region of your travel destination,
refer to the Owner’s Manual (PDF format).
Preparation
Setting your home region for the first
time
: [SETUP] # [SET WORLD TIME]
MENU
A The current time
B The time difference from GMT
(Greenwich Mean Time)
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 24 ページ ２０１６年１月７日 木曜日 午前１０時３０分
25
(ENG) SQT1152
1 Touch the Recording Mode button icon.
2 Touch the desired Recording Mode button icon.
*1 In Motion Picture Recording Mode only
*2 In Still Picture Recording Mode only
*3 only
*4 only
Basic
Changing the Recording Mode
Mode Effect
*1
*2
Intelligent Auto
You can switch the mode to the Intelligent Auto Mode,
which optimizes settings to the recording environment
you are in.
*1
*2
Intelligent Auto Plus
You can add manually-adjusted brightness and color
balance settings to the Intelligent Auto Mode, and record.
*1
Creative Control
You can record motion pictures with added effects.
*1
HDR Movie
You can minimize the loss of gradations in bright areas
and dark areas when, for example, the contrast between
the background and the subject is large.
Scene Mode
This option allows this unit to automatically adjust the
shutter speed and aperture, etc. according to the scene
you want to record.
Manual
You can set the shutter speed, focus, White Balance and
brightness (iris/gain).
*1, 3
Cinema Like Effect
You can record images with cinematic effects.
*1, 4
FULL HD Slow
Motion Video
You can record slow motion pictures.
*1
4K Photo
You can record motion pictures optimized for capturing
still pictures from 4K motion pictures.
*2
Stop Motion
Animation Assist
You can set a recorded still picture as the background,
and record the next picture while looking at that recorded
picture as the background.
MENU
MNL
WXF991
VX981
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 25 ページ ２０１６年１月７日 木曜日 午前１０時３０分
26
SQT1152 (ENG)
1 Open the LCD monitor or extend the
viewfinder to switch to Motion
Picture Recording Mode. (l 19)
2 Press the recording start/stop button
to start recording.
3 Press the recording start/stop button
again to pause recording.
≥ Recording can also be started/stopped by
touching the recording button icon.
1 Open the LCD monitor or extend the
viewfinder to switch to Still Picture
Recording Mode. (l 19)
2 Press the button halfway. (For
Auto Focus only)
3 Press the button fully.
Basic
Recording motion pictures
Basic
Recording still pictures
A Recording button icon
B When you begin recording, ; changes
to ¥.
T
W
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 26 ページ ２０１６年１月７日 木曜日 午前１０時３０分
27
(ENG) SQT1152
Using the Sub Camera and the Main Camera, you can record two
images simultaneously. (Twin Camera)
Use the Sub Camera to enjoy recording yourself, a family member
next to you or scenery different from that seen from the Main
Camera.
A Sub Camera
B Sub Window
≥ The image of the Sub Camera is displayed on the Sub Window.
1 Rotate the Sub Camera.
≥ When you rotate the Sub camera from a position in the
range C (0e to approximately 30e) to a position in the range
D (approximately 30e to 270e), the Sub Window is
displayed on the LCD monitor.
≥
If the Sub Window does not appear, touch to display it.
≥ When the Sub Camera is in use, you cannot start up the
Wireless Twin Camera function with (startup icon for
Wireless Twin Camera/disconnect icon for Wireless Twin/
Multi-Camera).
2 Start recording.
≥ Rotate the Sub Camera to the desired position.
≥ The Sub Camera works in Auto Focus, which adjusts
focus automatically.
≥ Normally, hold this unit as shown in the illustration when
recording.
≥ When the LCD monitor is either closed or closed with the screen facing outward, the Sub Camera
does not work. The Sub Window will be displayed if you open the LCD monitor again.
Basic
Recording with the Sub Camera
(Twin Camera)
[WXF991]
Recording a family
member next to you
Recording scenery Recording yourself
≥ Recording only with the Sub Camera is not possible.
≥ An image recorded with the Main Camera and the Sub Camera’s image displayed on the
Sub Window are recorded as a single scene or still picture. When you play back such a
scene or still picture, it is not possible to delete only the Sub Window image or hide it.
≥ The minimum focus distance of the Sub Camera is approximately 30cm (12q).
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 27 ページ ２０１６年１月７日 木曜日 午前１０時３０分
28
SQT1152 (ENG)
1 Set this unit to Playback Mode (l 19).
2 Touch the play mode select icon A (l 22).
≥ You can also set by touching , selecting [VIDEO SETUP]
or [PICT. SETUP] # [MEDIA, VIDEO/PICTURE]. (l 30)
3 Select the still picture C or the recording
format of the motion picture D you wish to
play back.
≥ Touch [Enter].
≥
If you touch [4K MP4], its recording mode icon
B
will be
displayed on the thumbnail screen. ( )
≥ If you touch , scenes recorded as Backup for Twin Camera will be displayed. The recording
mode icon ( ) will be displayed on the thumbnail screen, and each thumbnail will be
displayed with one of the following icons:
j AVCHD [PH] scenes recorded as Backup for Twin Camera:
j AVCHD [HA] scenes recorded as Backup for Twin Camera:
j AVCHD [HG] scenes recorded as Backup for Twin Camera:
j AVCHD [HE] scenes recorded as Backup for Twin Camera:
4 (When [MP4/iFrame], [AVCHD] or [24p] is touched)
Touch the desired recording format for playback.
≥ When [MP4/iFrame] is selected
≥ When [AVCHD] is selected
≥ When [24p] is selected
≥ The recording mode icon B is displayed in the thumbnail display when the item is touched.
j When an item in [MP4/iFrame] is selected:
, (Red), (Red), (Red), (Red),
j When an item in [AVCHD] is selected:
, ,
j When an item in [24p] is selected:
(Red), (Red)
Basic
Motion picture/Still picture playback
[ALL MP4/iFrame]/[1080/60p]/[1080/30p]/[720/30p]/[360/30p]/[iFrame]
[ALL AVCHD]/[1080/60p]/[1080/60i]
[2160/24p]/[1080/24p]
ALL
MENU
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 28 ページ ２０１６年１月７日 木曜日 午前１０時３０分
29
(ENG) SQT1152
≥ The following icons are displayed on thumbnails when [ALL MP4/iFrame] is touched:
≥ is displayed on the thumbnails of MP4 [1080/50M] scenes when [1080/60p] in [MP4/iFrame]
is touched.
≥ The following icons are displayed on thumbnails when [ALL AVCHD] or [1080/60i] is touched:
5 Touch the scene or the still picture to be played back.
≥ To display the next (previous) page:
j Slide the thumbnail display upward (downward) while touching it.
j Switch the Touch Menu, and then touch (up) / (down) on the thumbnail scroll
lever.
6 Select the playback operation by touching
the operation icon.
≥ Operation icons and screen display will disappear when
no touch operation is performed for a specific period of
time. To display them again, touch the screen.
≥ Touch 1/; to start/pause playback of motion pictures.
Watching Video/Pictures on your TV
j MP4 [1080/60p] scene: (Blue) (Recording mode [1080/50M])
(Recording mode [1080/28M])
j MP4 [1080/30p] scene:
j MP4 [720/30p] scene:
j MP4 [360/30p] scene:
j iFrame scene:
j AVCHD [1080/60p] scene:
j AVCHD [PH] scene:
j AVCHD [HA] scene:
j AVCHD [HG] scene:
j AVCHD [HE] scene:
Connect this unit to a TV using an HDMI micro cable (supplied) or a Composite
video cable (commercially-available).
A HDMI micro connector [HDMI]
≥ Be sure to connect to the HDMI terminal. (Insert the
connector with the arrow side facing down.)
B A/V connector [A/V]
0h01m30s
0h01m30s
0h01m30s
Operation icon
モバヷ
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 29 ページ ２０１６年１月７日 木曜日 午前１０時３０分
30
SQT1152 (ENG)
≥ Touch (left side)/ (right side) of on the Touch Menu to display . (l 22)
1 Touch .
2 Touch the top menu A.
3 Touch the submenu B.
≥ Next (previous) page is displayed by touching
/.
4 Touch the desired item to enter the
setting.
5 Touch [EXIT] to exit the menu
setting.
∫ About guide display
After touching , touching the submenus
and items will cause function descriptions and
settings confirmation messages to appear.
≥ After the messages have been displayed, the
guide display is canceled.
Language selection
You can select the language on the screen
display and the menu screen.
Formatting
Please be aware that if a medium is formatted,
then all the data recorded on the medium will be
erased and cannot be restored. Back up
important data on a PC, DVD disc etc.
* Displayed when connecting a USB HDD.
(Refer to the Owner’s Manual (PDF format))
≥ Media selection screen is not displayed when
the USB HDD is not connected. Touch [YES].
≥ Do not format an SD card using any other
equipment such as a PC. The card may
not be used on this unit.
Basic
Using the menu screen
MENU
MENU
MENU
: [SETUP] # [LANGUAGE] #
desired language
: [SETUP] # [FORMAT MEDIA] #
desired media
[SD CARD]/[HDD]
*
MENU
MENU
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 30 ページ ２０１６年１月７日 木曜日 午前１０時３０分
31
(ENG) SQT1152
This unit offers the following Wi-Fi functions when used in combination with another Wi-Fi
compatible device.
Before using any of these Wi-Fi functions, check the settings of your device and get it ready for use.
This Basic Owner’s Manual describes the procedure for using [Link to Cell] to provide a Wi-Fi
connection example.
∫ This unit is WPS-compatible
WPS (Wi-Fi Protected Setup™) is a function that allows you to easily set up a connection with a
wireless LAN device and make security-related settings.
≥ For details on how to use those Wi-Fi functions and set up a connection, refer to the Owner’s
Manual (PDF format).
Wi-Fi
What you can do with the Wi-Fi
®
function
[TWIN CAMERA]
You can display the image transmitted from a Wireless Sub Camera
connected via Wi-Fi on this unit’s Sub Window and record it
simultaneously with the Main Camera’s image. (l 36)
[Multi Camera]
Connecting multiple smartphones to this unit via Wi-Fi allows you to
simultaneously display two Sub Windows and record images in them.
Up to three smartphones can be connected simultaneously.
[Link to Cell]
Using a smartphone, you can perform record/playback operations from a
remote location or upload motion pictures and still pictures recorded in
this unit on SNS (Social Networking Service). (l 32)
[Baby Monitor]
You can use your smartphone to check on your baby being monitored by
this unit when you are in another room. The smartphone and this unit can
be used like radio transceivers, allowing the users to have a conversation
by taking turns. This unit can also send a notification to the smartphone
whenever the baby cries.
[Home Cam]
You can confirm the recording screen of this unit from outside using a
smartphone.
[DLNA Play]
Connecting this unit to a DLNA-compatible TV via Wi-Fi, you can play
back scenes and still pictures on the TV.
[Live Cast]
You can broadcast motion pictures of this unit live by setting up a link
between the “LUMIX CLUB” and USTREAM.
[Copy]
By setting up a Wi-Fi communication between this unit and a PC, you can
copy scenes and still pictures recorded with this unit to the PC.
[History]
Each use of a Wi-Fi function is stored in the Wi-Fi connection history.
Connecting from the history allows you to easily set up a connection
using the previous connection settings.
≥ Records of Wi-Fi connections made with the Wireless Multi-Camera
function are not saved.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 31 ページ ２０１６年１月７日 木曜日 午前１０時３０分
32
SQT1152 (ENG)
∫ Before using [Link to Cell]
Install the “Image App”
* The supported OS version are current as of November 2015 and subject to change.
≥ Use the latest version.
≥ Refer to [Help] in the “Image App” menu about how to operate.
≥ The service may not be able to be used properly depending on the type of smartphone being
used. For information on the “Image App”, check the support website below.
http://panasonic.jp/support/global/cs/e_cam
(This Site is English only.)
≥ When downloading the app on a mobile network, high packet communication fees may be
incurred depending on the details of your contract.
Wi-Fi
[Link to Cell]
≥ You need to turn on the Wi-Fi function of your smartphone.
≥ Do not remove the SD card during remote operations.
Caution:
Be sure to pay special attention to the privacy, the likeness rights, etc. of the subject when you use
this function. Use at your own risk.
About the “Image App”
The “Image App” is an application provided by Panasonic.
For Android™ apps For iOS apps
OS Android 4.0 or later
*
iOS 7.0 or later
*
Installation
procedure
1 Connect your Android
device to a network.
2 Select “Google Play™
Store”.
3 Enter “Panasonic Image
App” into the search
box.
4 Select “Panasonic
Image App” and install
it.
≥ The icon will be added
to the menu.
1 Connect your iOS
device to a network.
2 Select “App Store
SM
”.
3 Enter “Panasonic Image
App” into the search
box.
4 Select “Panasonic
Image App” and install
it.
≥ The icon will be added
to the menu.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 32 ページ ２０１６年１月７日 木曜日 午前１０時３０分
33
(ENG) SQT1152
Preparations before using [Link to Cell]
Install the “Image App”. (l 32)
Setting up a direct connection between this unit and the smartphone when
[Direct Connection Password] is set to [OFF] (l 34)
≥ The default setting for [Direct Connection Password] is [OFF].
1 Check if the wireless access point is compatible with IEEE802.11b/g/n.
2 Set up a Wi-Fi connection between this unit and the wireless access point.
≥ For information on how to connect this unit and a wireless access point, refer to the Owner’s
Manual (PDF format).
Setting up a direct Wi-Fi connection between this unit and a
smartphone
Setting up a Wi-Fi connection via a wireless access point
Image App
Image App
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 33 ページ ２０１６年１月７日 木曜日 午前１０時３０分
34
SQT1152 (ENG)
Using [Link to Cell] with a direct connection
5 When the Wi-Fi connection is complete, press the home button on the
smartphone and start up the smartphone application “Image App”.
≥
Transmission speed may decrease, or may not be usable depending on the environment it is used in.
≥ For details on how to set up a connection with [Direct Connection Password] set to [ON], refer to
the Owner’s Manual (PDF format).
≥ If you cannot connect this unit and the smartphone, refer to the following:
j Check the Wi-Fi settings of the smartphone to see if the SSID of this unit is selected so that a
Wi-Fi connection will be made from the smartphone to this unit.
j Make sure the smartphone is not connected to the wireless access point. If it is connected to
the wireless access point, change the Wi-Fi access point using the smartphone’s Wi-Fi set up.
≥ Please refer to the operating instruction of the device in use for details about the setting of the
wireless access point or smartphone.
Setting up a direct connection between this unit and the smartphone
when [Direct Connection Password] is set to [OFF]
1 Press Wi-Fi button on this unit and touch [Wi-Fi
Setup].
2 Touch [Direct Connection].
≥ This unit will go into connection standby with the smartphone.
≥ The SSID of this unit is displayed on the screen of this unit.
3 Turn on the Wi-Fi function in the smartphone’s
setup menu.
4 On the smartphone’s Wi-Fi setting screen, select
the SSID displayed on this unit.
≥ It may take time to complete the Wi-Fi connection.
6 (If this is the first time the smartphone is connecting
to this unit)
Confirm the message “Connect this
smartphone?”, and touch [YES] on the screen of
this unit.
≥ When the connection to this unit is complete, the image from
this unit is displayed on the smartphone screen.
Control this unit remotely with the smartphone.
2/2
A [Wi-Fi Setup]
B [EXIT]
Wi-Fi
Wi-Fi
C [Device Name]
D [YES]
E Message
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 34 ページ ２０１６年１月７日 木曜日 午前１０時３０分
35
(ENG) SQT1152
About [Link to Cell]
Smartphone screen shots are example displayed in Motion Picture Recording Mode and Playback
Mode.
≥ Depending on your OS or the version of the smartphone application “Image App”, the screens
may differ from the ones above.
Screen display during remote operations
Recording screen
1 Recording media/remaining recordable time
2 Remaining battery power of this unit
3 Zoom
4 Photoshot button
5 Menu display
6 Playback mode button
7 Remote control button
8 Recording start/stop button
9 Motion Picture Recording Mode/Still Picture Recording
Mode toggle button
: Name of the connected device
Playback screen
1 Camera function button
2 Number of scenes
3 Remaining battery power of this unit
4 Delete
5 Upload
6 Copy
7 Name of the connected device
8 Scene information display
XXXXXXXXX
XXXXXXXXX
R 1h 20min
XXXXXXXXX
1/16
AVCHD_0001
2016/12/15 15:30:50
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 35 ページ ２０１６年１月７日 木曜日 午前１０時３０分
36
SQT1152 (ENG)
When this unit and one or more smartphones are connected via Wi-Fi, you can display the image
transmitted from the smartphone on this unit’s Sub Window and record it simultaneously with the
Main Camera’s image. (Wireless Twin/Multi-Camera)
* only
Use your Wireless Sub Camera to enjoy recording your own face or any scenery different from what
is being recorded with the Main Camera.
∫ Wireless Twin Camera function
∫ Wireless Multi-Camera function (l 31)
≥ For information on how to connect this unit and a smartphone and other details, refer to
the Owner’s Manual (PDF format).
Wi-Fi
Wireless Twin/Multi-Camera function
≥ In this owner’s manual, a function that displays an image from one smartphone in one Sub
Window is referred to as “Wireless Twin Camera”, and a function that displays images
from up to three smartphones and the Sub Camera of this unit* in two Sub Windows is
referred to as “Wireless Multi-Camera”.
For information on non-smartphone devices that support the Wireless Sub Camera
function and the procedures for using them, check the support website below. (As of
November 2015)
http://panasonic.jp/support/global/cs/e_cam
WXF991
A Smartphone (Wireless Sub Camera)
B This unit (Main Camera)
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 36 ページ ２０１６年１月７日 木曜日 午前１０時３０分
37
(ENG) SQT1152
∫ It is not a malfunction in following cases
Others
Troubleshooting
A clicking sound is heard
when the unit is shaken.
≥ This is the sound of the lens moving and is not a defect.
This sound will no longer be heard when the unit is turned on
and set this unit to the Motion Picture Recording Mode or Still
Picture Recording Mode.
Object seems to be
warped.
≥ Object seems to be warped slightly when the object moves
across the image very fast, but this is because the unit is
using MOS for the image sensor. This is not a malfunction.
The lens, the viewfinder or
LCD monitor fog up.
≥ This is due to condensation. It is not a malfunction. Please
refer to page 8.
Power
Problem Check points
This unit cannot be turned
on.
This unit does not stay on
long enough.
Battery runs down quickly.
≥ Charge the battery again to ensure it is sufficiently charged.
(l 13)
≥ In cold places, the battery using time becomes shorter.
≥ The battery has a limited life. If the operating time is still too
short even after the battery is fully charged, the battery has
worn out and needs to be replaced.
This unit cannot be
operated though it is
turned on.
This unit does not operate
normally.
≥ Remove the battery or AC adaptor, wait about 1 minute and
then reconnect the battery or AC adaptor. Then about
1 minute later, turn on the unit again. (Conducting the above
operation while the media is being accessed may damage the
data on the media.)
≥ If normal operation is still not restored, detach the power
connected, and consult the dealer who you purchased this
unit from.
“ERROR OCCURRED.
PLEASE TURN UNIT OFF,
THEN TURN ON AGAIN.”
is displayed.
≥ The unit has automatically detected an error. Restart the unit
by turning the unit off and on.
≥ The unit will be turned off in about 1 minute if the unit is not
turned off and on.
≥ Repair is needed if it is repeatedly displayed even if it is
restarted. Detach the power connected, and consult the
dealer who you purchased this unit from. Do not attempt to
repair the unit by yourself.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 37 ページ ２０１６年１月７日 木曜日 午前１０時３０分
38
SQT1152 (ENG)
Please refer to “Owner’s Manual (PDF format)” for details.
Recording
Problem Check points
Color or brightness of the
image changes, or you
may see horizontal bars in
the image.
The LCD monitor flickers
indoors.
≥ Color or brightness of the image may change, or you may see
horizontal bars in the image when the object is recorded
under fluorescent light, mercury light or sodium light, etc., but
this is not a malfunction.
≥ In Motion Picture Recording Mode, record in Intelligent Auto
Mode/Intelligent Auto Plus Mode or set the shutter speed as
follows:
j When [REC FORMAT] is set to [24p]:
Set to 1/50 seconds in areas where the power supply
frequency is 50 Hz, or 1/60 seconds in areas where the
frequency is 60 Hz.
j When [REC FORMAT] is set to a setting other than [24p]:
Set to 1/100 seconds in areas where the power supply
frequency is 50 Hz, or 1/60 seconds in areas where the
frequency is 60 Hz.
≥ In Still Picture Recording Mode, this will not affect the
recorded image.
≥ In the following cases, setting the shutter speed to
1/120 seconds reduces the intensity of the problem:
j In FULL HD Slow Motion Mode
j (For the )
Slow & Quick Video Mode
Playback
Problem Check points
Scenes/still pictures
cannot be played back.
≥ Any scenes/still pictures where the thumbnails are displayed
as cannot be played back.
WXF991
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 38 ページ ２０１６年１月７日 木曜日 午前１０時３０分
39
(ENG) SQT1152
∫
Carefully observe copyright laws
Whatever you have recorded and created
can be used for your personal entertainment
only. Under copyright laws, other materials
cannot be used without obtaining
permission from the holders of the
copyrights.
∫ Licenses
≥ SDXC Logo is a trademark of SD-3C, LLC.
≥ “AVCHD”, “AVCHD Progressive” and the
“AVCHD Progressive” logo are trademarks of
Panasonic Corporation and Sony
Corporation.
≥ Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
≥ The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing, LLC in the United States and other
countries.
≥ x.v.Color
™
is a trademark.
≥ LEICA is a registered trademark of Leica
Microsystems IR GmbH and DICOMAR is a
registered trademark of Leica Camera AG.
≥ iMovie, Final Cut Pro, Mac and OS X are
trademarks of Apple Inc. registered in the
U.S. and other countries.
≥ App Store is a service mark of Apple Inc.
≥ Android and Google Play are trademarks or
registered trademarks of Google Inc.
≥ The Wi-Fi CERTIFIED
™
Logo is a
certification mark of Wi-Fi Alliance
®
.
≥ The Wi-Fi Protected Setup
™
Identifier mark is
a certification mark of Wi-Fi Alliance
®
.
≥
“Wi-Fi
®
” is a registered trademark of Wi-Fi Alliance
®
.
≥ “Wi-Fi Protected Setup
™
”, “WPA
™
”, and
“WPA2
™
” are trademarks of Wi-Fi Alliance
®
.
≥
DLNA, the DLNA Logo and DLNA CERTIFIED
are trademarks, service marks, or certification
marks of the Digital Living Network Alliance.
≥ QR Code is a registered trademark of
DENSO WAVE INCORPORATED.
≥ Other names of systems and products
mentioned in these instructions are usually
the registered trademarks or trademarks of
the manufacturers who developed the system
or product concerned.
This product is licensed under the AVC Patent
Portfolio License for the personal use of a
consumer or other uses in which it does not
receive remuneration to (i) encode video in
compliance with the AVC Standard (“AVC
Video”) and/or (ii) decode AVC Video that was
encoded by a consumer engaged in a personal
activity and/or was obtained from a video
provider licensed to provide AVC Video. No
license is granted or shall be implied for any
other use. Additional information may be
obtained from MPEG LA, L.L.C.
See http://www.mpegla.com
Others
About copyright
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 39 ページ ２０１６年１月７日 木曜日 午前１０時３０分
40
SQT1152 (ENG)
This product incorporates the following software:
(1) the software developed independently by or for Panasonic Corporation,
(2) the software owned by third party and licensed to Panasonic Corporation,
(3) the software licensed under the GNU General Public License, Version 2.0 (GPL V2.0),
(4) the software licensed under the GNU LESSER General Public License, Version 2.1 (LGPL V2.1),
and/or
(5) open source software other than the software licensed under the GPL V2.0 and/or LGPL V2.1.
The software categorized as (3) - (5) are distributed in the hope that it will be useful, but WITHOUT
ANY WARRANTY, without even the implied warranty of MERCHANTABILITY or FITNESS FOR A
PARTICULAR PURPOSE. Refer to the detailed terms and conditions thereof, which can be
displayed by following the procedure described in [SOFTWARE INFO] under “Using the Setup
Menu” in the Owner’s Manual (PDF format).
At least three (3) years from delivery of this product, Panasonic will give to any third party who
contacts us at the contact information provided below, for a charge no more than our cost of
physically performing source code distribution, a complete machine-readable copy of the
corresponding source code covered under GPL V2.0 or LGPL V2.1, as well as the respective
copyright notice thereof.
Contact Information: oss-cd-reque[email protected]nic.com
The source code and the copyright notice are also available for free in our website below.
http://panasonic.net/avc/oss/index.html
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 40 ページ ２０１６年１月７日 木曜日 午前１０時３０分
41
(ENG) SQT1152
4K Video Camera
Information for your safety
Others
Specifications
*1 When [REC FORMAT] is set to [4K MP4],
or when [REC FORMAT] is set to [24p]
with [REC MODE] set to [2160/24p]
*2 When [REC FORMAT] is set to
[AVCHD] or [MP4/iFrame], or when
[REC FORMAT] is set to [24p] with
[REC MODE] set to [1080/24p]
*3 When Level Shot Function is set to
normal or off
*4 When Level Shot Function is set to off
Power source:
DC 5.0 V (When using AC adaptor)
DC 3.6 V (When using battery)
Power consumption:
Recording;
6.6 W (When using the viewfinder)
7.8 W (When using the LCD monitor)
Charging; 7.7 W
Recording; 7.1 W
Charging; 7.7 W
Motion picture recording format:
[4K MP4], [MP4/iFrame], [24p];
MPEG-4 AVC file format compliant (.MP4)
[AVCHD];
AVCHD format version 2.0 compliant
(AVCHD Progressive)
Motion picture compression:
MPEG-4 AVC/H.264
Audio compression:
[4K MP4], [MP4/iFrame], [24p];
AAC/2 ch
[AVCHD];
Dolby
®
Digital/5.1 ch (built-in microphone),
2 ch (built-in microphone/external
microphone)
WXF991
VX981
Recording mode and transfer rate:
[4K MP4];
[2160];
Maximum 72 Mbps (VBR)
[MP4/iFrame]
[1080/50M];
Maximum 50 Mbps (VBR)
[1080/28M];
Maximum 28 Mbps (VBR)
[720];
Average 9 Mbps (VBR)
[iFrame];
Maximum 28 Mbps (VBR)
[AVCHD]
[1080/60p];
Maximum 28 Mbps (VBR)
[PH];
Maximum 24 Mbps (VBR)
[HA];
Average 17 Mbps (VBR)
[HG];
Average 13 Mbps (VBR)
[HE];
Average 5 Mbps (VBR)
[24p]
[2160/24p];
Maximum 72 Mbps (VBR)
[1080/24p];
Maximum 50 Mbps (VBR)
Refer to the owner’s manual (PDF format) for the
picture size and recordable time of a motion picture.
Still picture recording format:
JPEG (Design rule for Camera File system,
based on Exif 2.2 standard)
Refer to the owner’s manual (PDF format)
for picture size of a still picture and number
of recordable pictures.
Recording media:
SD Memory Card
SDHC Memory Card
SDXC Memory Card
Refer to page 16 for details on SD cards
usable in this unit.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 41 ページ ２０１６年１月７日 木曜日 午前１０時３０分
42
SQT1152 (ENG)
Image sensor:
1/2.3 z 1MOS image sensor
Total; 18910 K
Effective pixels;
Motion picture; 8290 K (16:9)
*1
,
6100 K (16:9)
*2, 3
Still picture; 8290 K (16:9), 6220 K (4:3),
7000 K (3:2)
Lens:
Auto Iris, 20k optical zoom, F1.8 to F3.6
Focal length;
4.08 mm to 81.6 mm
(Full range AF)
35 mm equivalent;
Motion picture;
30.8 mm to 626 mm (16:9)
*1, 4
,
37.0 mm to 752 mm (16:9)
*2, 3
Still picture;
30.8 mm to 626 mm (16:9),
37.6 mm to 752.8 mm (4:3),
34.5 mm to 690.3 mm (3:2)
Minimum focus distance;
Normal; Approx. 3.0 cm (1.2q) (Wide)/
Approx. 1.5 m (4.9 feet) (Tele)
Intelligent Auto Macro;
Approx. 1 cm (0.4q) (Wide)
Filter diameter:
49 mm
Zoom:
20k optical zoom, 25k
*1
/40k
*2
i.Zoom,
60k/1500k digital zoom
Image stabilizer function:
Optical (Hybrid Optical Image Stabilizer,
Active Mode (Rotation correction), Optical
Image Stabilizer Lock function)
Level Shot Function:
Off/Normal/Strong
Creative Control:
[Miniature Effect]/[Silent movie]/[8mm movie]/
[
Time Lapse Rec
]
HDR movie:
Low/High
Monitor:
3.0z wide LCD monitor (Approx. 460 K dots)
Viewfinder:
0.24z wide EVF (Approx. 1550 K dots
equivalent)
WXF991
Microphone:
5.1 channel surround microphone/
Zoom microphone/Focus microphone/
Stereo microphone
Minimum required illumination:
Approx. 2 lx (1/30 with Low Light Mode in the
Scene Mode)
Approx. 1 lx with the Night Mode ([COLOR])
function
0 lx with the Night Mode ([Infrared]) function
AV connector video output level:
1.0 Vp-p, 75 h, NTSC system
HDMI micro connector video output level:
HDMI™ (x.v.Color™) 2160p/1080p/1080i/480p
AV connector audio output level (Line):
251 mV, 600 h, 2 ch
Headphone output:
85 mV, 32 h (Stereo mini jack)
HDMI micro connector audio output level:
[4K MP4], [MP4/iFrame], [24p];
Linear PCM
[AVCHD];
Dolby Digital/Linear PCM
MIC input:
j60 dBV (Mic sensitivity j40 dB equivalent,
0dB=1V/Pa, 1kHz)
(Stereo mini jack)
USB:
Reader function
SD card; Read only (No copyright
protection support)
Hi-Speed USB (USB 2.0), USB terminal
Type micro AB
USB host function (for USB HDD)
Battery charging function (Charges from
USB terminal when the main unit is off)
Dimensions:
68.0 mm (W)k78 mm (H)k163 mm (D)
[2.677 q (W)k3.071 q (H)k6.417 q (D)]
(including projecting parts)
65.0 mm (W)k73 mm (H)k139 mm (D)
[2.559 q (W)k2.874 q (H)k5.472 q (D)]
(including projecting parts)
[with battery (supplied)]:
65.0 mm (W)k73 mm (H)k141 mm (D)
[2.559 q (W)k2.874 q (H)k5.551 q (D)]
(including projecting parts)
WXF991
VX981
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 42 ページ ２０１６年１月７日 木曜日 午前１０時３０分
43
(ENG) SQT1152
Sub Camera
AC adaptor
Information for your safety
Mass (Weight):
Approx. 403
g (Approx. 0.888 lbs.)
[without battery (supplied) and an SD card
(optional)]
Approx. 351
g (Approx. 0.774 lbs.)
[without battery (supplied) and an SD card
(optional)]
Mass (Weight) in operation:
Approx. 448
g (Approx. 0.988 lbs.)
[with battery (supplied) and an SD card
(optional)]
Approx. 396
g (Approx. 0.873 lbs.)
[with battery (supplied) and an SD card
(optional)]
Operating temperature:
0°Cto40°C (32°Fto104°F)
Operating humidity:
10%RH to 80%RH
Battery operation time:
See page 14
Wireless transmitter:
Compliance standard; IEEE802.11b/g/n
Frequency range used;
Central frequency 2412 MHz to 2462 MHz [11ch]
Encryption method; Wi-Fi compliant WPA™/
WPA2™/WEP
Access method; Infrastructure mode
Image sensor:
1/4z 1MOS image sensor
Total; 5270 K
Lens:
F2.2
Focal length;
3.54 mm
35 mm equivalent (Motion picture);
37.2 mm
Minimum focus distance;
Approx. 30 cm
WXF991
VX981
WXF991
VX981
WXF991
Power source:
AC 110 V to 240 V, 50/60 Hz
AC input:
0.25 A
DC output:
DC 5.0 V, 1.8 A
Dimensions:
66.4 mm (W)k58.5 mm (H)k31 mm (D)
[2.62 q (W)k2.30 q (H)k1.22 q (D)]
Mass (Weight):
Approx. 60
g (Approx. 0.132 lbs.)
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 43 ページ ２０１６年１月７日 木曜日 午前１０時３０分
44
SQT1152 (ENG)
Some optional accessories may not be available in some countries.
*1 Please refer to page 14, concerning the battery charging time and available recording time.
*2 Set the video light setting to [OFF].
*3 Only available for .
(For U.S.A. only)
To order optional accessories please visit http://shop.panasonic.com
or your local Photo Specialty Dealer.
NOTE:
Accessories and/or model numbers may vary by country. Please consult your local dealer.
Product numbers correct as of Nov. 2015. These may be subject to change.
Others
Optional accessories
Accessory No. Figure Description
VW-BC10PP Battery charger
VW-VBT190
*1
Rechargeable Lithium Ion Battery
Pack
VW-VBT380 Rechargeable Lithium Ion Battery
Pack
VW-W4907H
*2
Wide conversion lens
VW-LF49N
*2
Filter kit
VW-VMS10PP Stereo microphone
VW-ACT190PP
*3
Accessory kit
VW-ACT380PP Accessory kit
VW-LED1PP LED Video Light
VW-CTR1PP Remote Pan Tilt Cradle
VX981
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 44 ページ ２０１６年１月７日 木曜日 午前１０時３０分
45
(ENG) SQT1152
Others
Limited Warranty
(ONLY FOR U.S.A.)
Panasonic ProductsLimited Warranty
Limited Warranty Coverage (For USA Only)
If your product does not work properly because of a defect in materials or workmanship,
Panasonic Corporation of North America (referred to as “the warrantor”) will, for the length of the
period indicated on the chart below, which starts with the date of original purchase
(“warranty period”), at its option either (a) repair your product with new or refurbished parts,
(b) replace it with a new or a refurbished equivalent value product, or (c) refund your purchase price.
The decision to repair, replace or refund will be made by the warrantor.
Product or Part Name Parts Labor
1 Year 90 Days4K Video Camera
All included Accessories
(Except Non-Rechargeable Batteries)
90 Days
10 Days
Not Applicable
Only Non-Rechargeable Batteries
Not Applicable
During the “Labor” warranty period there will be no charge for labor. During the “Parts” warranty
period, there will be no charge for parts. This Limited Warranty excludes both parts and labor for
non-rechargeable batteries, antennas, and cosmetic parts (cabinet). This warranty only applies
to products purchased and serviced in the United States. This warranty is extended only to
the original purchaser of a new product which was not sold “as is”.
Mail-In Service--Online Repair Request
Online Repair Request
To submit a new repair request and for quick repair status visit our Web Site at
http://shop.panasonic.com/support.
When shipping the unit, carefully pack, include all supplied accessories listed in the Owner’s
Manual, and send it prepaid, adequately insured and packed well in a carton box. When shipping
Lithium Ion batteries please visit our Web Site at http://shop.panasonic.com/support as Panasonic
is committed to providing the most up to date information. Include a letter detailing the complaint,
a return address and provide a daytime phone number where you can be reached.
A valid registered receipt is required under the Limited Warranty.
IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE PURCHASER WILL BE
REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE INDICATING DATE
OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE. CUSTOMER WILL BE
CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF
PURCHASE.
Limited Warranty Limits And Exclusions
This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER
normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which
occurred in shipment, or failures which are caused by products not supplied by the warrantor, or failures which
result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation,
set-up adjustments, misadjustment of consumer controls, improper maintenance, power line surge, lightning
damage, modification, introduction of sand, humidity or liquids, commercial use such as hotel, office,
restaurant, or other business or rental use of the product, or service by anyone other than a Factory Service
Center or other Authorized Servicer, or damage that is attributable to acts of God.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 45 ページ ２０１６年１月７日 木曜日 午前１０時３０分
46
SQT1152 (ENG)
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED WARRANTY
COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING
FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY.
(As examples, this excludes damages for lost time, travel to and from the servicer, loss of or damage to media
or images, data or other memory or recorded content. The items listed are not exclusive, but for illustration only.)
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF
MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or
limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary from state
to state. If a problem with this product develops during or after the warranty period, you may contact
your dealer or Service Center. If the problem is not handled to your satisfaction, then write to:
Consumer Affairs Department
Panasonic Corporation of North America
661 Independence Pkwy
Chesapeake, VA 23320
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE
YOUR RESPONSIBILITY.
As of July 2015
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 46 ページ ２０１６年１月７日 木曜日 午前１０時３０分
47
(ENG) SQT1152
Others
Warranty (For Canadian Customers)
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
PANASONIC PRODUCT – LIMITED WARRANTY
Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship under
normal use and for a period as stated below from the date of original purchase agrees to, at its option
either (a) repair your product with new or refurbished parts, (b) replace it with a new or a refurbished
equivalent value product, or (c) refund your purchase price. The decision to repair, replace or refund will
be made by Panasonic Canada Inc.
Camcorder Products - One (1) year, parts and labour
This warranty is given only to the original purchaser, or the person for whom it was purchased as a gift, of a Panasonic brand product
mentioned above sold by an authorized Panasonic dealer in Canada and purchased and used in Canada, which product was not sold
“as is”, and which product was delivered to you in new condition in the original packaging.
IN ORDER TO BE ELIGIBLE TO RECEIVE WARRANTY SERVICE HEREUNDER, A PURCHASE
RECEIPT OR OTHER PROOF OF DATE OF ORIGINAL PURCHASE, SHOWING AMOUNT PAID AND
PLACE OF PURCHASE IS REQUIRED
LIMITATIONS AND EXCLUSIONS
This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER
normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which occurred in
shipment, or failures which are caused by products not supplied by Panasonic Canada Inc., or failures which result
from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments,
misadjustment of consumer controls, improper maintenance, improper batteries, power line surge, lightning damage,
modification, introduction of sand, humidity or liquids, commercial use such as hotel, office, restaurant, or other
business or rental use of the product, or service by anyone other than an Authorized Servicer, or damage that is
attributable to acts of God.
Dry cell batteries are also excluded from coverage under this warranty. Rechargeable batteries are
warranted for ninety (90) days from date of original purchase.
THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR ANY
SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT
OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY.
(As examples, this warranty
excludes damages for lost time, travel to and from the Authorized Servicer, loss of or damage to media or images, data or other
memory or recorded content. This list of items is not exhaustive, but for illustration only.)
In certain instances, some jurisdictions do not allow the exclusion or limitation of incidental or
consequential damages, or the exclusion of implied warranties, so the above limitations and exclusions
may not be applicable. This warranty gives you specific legal rights and you may have other rights which
vary depending on your province or territory.
WARRANTY SERVICE
For product operation, repairs and information assistance, please visit our Support page:
www.panasonic.ca/english/support
IF YOU SHIP THE PRODUCT TO A SERVICENTRE
Carefully pack and send prepaid, adequately insured and preferably in the original carton.
Include details of the defect claimed, and proof of date of original purchase.
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 47 ページ ２０１６年１月７日 木曜日 午前１０時３０分
Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario, L4W 2T3
© Panasonic Corporation 2015
Printed in Malaysia
http://shop.panasonic.com
www.panasonic.com
Simplified-HC-WXF991&VX981_PP-SQT1152_eng.book 48 ページ ２０１６年１月７日 木曜日 午前１０時３０分
