Refrigerator
User manual
RS58K*/RS62K*
Free Standing Appliance
Untitled-30 1 7/17/2017 5:03:56 PM
English2
Contents
Contents
Safety information 3
Important safety symbols and precautions: 5
Severe warning signs for transportation and site 6
Critical installation warnings 7
Installation cautions 10
Critical usage warnings 11
Usage cautions 16
Cleaning cautions 19
Critical disposal warnings 21
Additional tips for proper usage 22
Saving Energy Tips 23
This appliance is intended to be used in household and similar applications such as 23
Instructions about the WEEE 24
Installation 25
Refrigerator at a glance 25
Step-by-step installation 28
Door removal for entrance 36
Operations 41
Feature panel 41
Temperature settings 45
Special features 46
Maintenance 53
Handle and care 53
Cleaning 57
Replacement 58
Troubleshooting 60
General 60
Untitled-30 2 7/17/2017 5:03:56 PM
English 3
Safety information
• Before using your new Samsung Refrigerator, please read this
manual thoroughly to ensure that you know how to operate the
features and functions that your new appliance offers safely and
efciently.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory, or mental capabilities,
or those who lack experience and knowledge, unless they have
been given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• Warnings and Important Safety Instructions in this manual do not
cover all possible conditions and situations that may occur.
It is your responsibility to use common sense, caution, and care
when installing, maintaining, and operating your appliance.
• Because these following operating instructions cover various
models, the characteristics of your refrigerator may differ slightly
from those described in this manual and not all warning signs may
be applicable. If you have any questions or concerns, contact your
nearest service center or nd help and information online at www.
samsung.com.
• R-600a or R-134a is used as a refrigerant. Check the compressor
label on the rear of the appliance or the rating label inside the
fridge to see which refrigerant is used for your refrigerator. When
this product contains ammable gas (Refrigerant R-600a), contact
your local authority in regard to safe disposal of this product.
Safety information
Untitled-30 3 7/17/2017 5:03:56 PM
Safety information
English4
Safety information
• In order to avoid the creation of a ammable gas-air mixture
if a leak in the refrigerating circuit occurs, the size of the room
in which the appliance may be sited depends on the amount of
refrigerant used.
• Never start up an appliance showing any signs of damage. If in
doubt, consult your dealer. The room must be 1 m³ in size for
every 8 g of R-600a refrigerant inside the appliance.
The amount of refrigerant in your particular appliance is shown on
the identication plate inside the appliance.
• Refrigerant squirting out of the pipes could ignite or cause an eye
injury. When refrigerant leaks from the pipe, avoid any naked
ames and move anything ammable away from the product and
ventilate the room immediately.
- Failing to do so may result in re or explosion.
Untitled-30 4 7/17/2017 5:03:56 PM
English 5
Safety information
Important safety symbols and precautions:
Please follow all safety instructions in this manual. This manual uses the following safety
symbols.
WARNING
Hazards or unsafe practices that may result in severe personal injury,
property damage, and/or death.
CAUTION
Hazards or unsafe practices that may result in severe personal injury
and/or property damage.
NOTE
Useful information that helps users understand or benet from the
refrigerator.
These warning signs are here to prevent injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe place for future reference.
Untitled-30 5 7/17/2017 5:03:56 PM
Safety information
English6
Safety information
Severe warning signs for transportation and site
WARNING
• When transporting and installing the appliance,care should be
taken to ensure that no parts of the refrigerating circuit are
damaged.
- Refrigerant leaking from the pipe work could ignite or cause
an eye injury. If a leak is detected, avoid any naked ames
or potential sources of ignition and air the room in which the
appliance is standing for several minutes.
- This appliance contains a small amount of isobutane refrigerant
(R-600a), a natural gas with high environmental compatibility
that is, however, also combustible. When transporting and
installing the appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
• When transporting and installing the refrigerator, do not touch the
water hose on the back side of the refrigerator.
- This may damage the refrigerator and as a result the water
dispenser can not be used.
Untitled-30 6 7/17/2017 5:03:56 PM
English 7
Safety information
Critical installation warnings
WARNING
• Do not install the refrigerator in a damp location or place where it
may come in contact with water.
- Deteriorated insulation on electrical parts may cause an electric
shock or re.
• Do not place this refrigerator in direct sunlight or expose it to the
heat from stoves, room heaters, or other appliances.
• Do not plug several appliances into the same multiple power strip.
The refrigerator should always be plugged into its own individual
electrical outlet which has a voltage rating that matches the
voltage listed on the refrigerator’s rating plate.
- This provides the best performance and also prevents
overloading of house wiring circuits, which could cause a re
hazard from overheated wires.
• If the wall socket is loose, do not insert the power plug.
- There is a risk of electric shock of re.
• Do not use a power cord that has cracks or abrasion damage along
its length or at either end.
• Do not bend the power cord excessively or place heavy objects on
it.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place a heavy
object on the power cord, insert the power cord between objects,
or push the power cord into the space behind the appliance.
• When moving the refrigerator, be careful not to roll over or
damage the power cord.
- This may result in an electric shock or re.
Untitled-30 7 7/17/2017 5:03:56 PM
Safety information
English8
Safety information
• Never unplug your refrigerator by pulling on the power cord.
Always grip the plug rmly and pull straight out from the outlet.
- Damage to the cord may cause a short-circuit, re, and/or
electric shock.
• Do not use aerosols near the refrigerator.
- Using aerosols near the refrigerator may cause an explosion or
re.
• Do not install this appliance near a heater or inammable material.
• Do not install this appliance in a location where gas may leak.
- This may result in an electric shock or re.
• This refrigerator must be properly located and installed in
accordance with the instructions in this manual before you use it.
• Connect the power plug in the proper position with the cord
hanging down.
- If you connect the power plug upside down, the wire can get
cut off and cause a re or electric shock.
• Make sure that the power plug is not crushed or damaged by the
back of the refrigerator.
• Keep the packing materials out of reach of children.
- There is a risk of death from suffocation if a child puts the
packing materials on his or her head.
• The appliance must be positioned so that the plug is accessible
after installation.
- Failing to do so may result in an electric shock or re due to
electric leakage.
• Do not install this appliance in a humid, oily or dusty location, in a
location exposed to direct sunlight and water (rain drops).
- Deteriorated insulation of electrical parts may cause an electric
shock or re.
Untitled-30 8 7/17/2017 5:03:56 PM
English 9
Safety information
• If any dust or water is in the refrigerator, pull out power plug and
contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not stand on top of the appliance or place objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals,
metal objects, etc.) on the appliance.
- This may result in an electric shock, re, problems with the
product, or injury.
• You need to remove all the protective plastic lm before you
initially plug the product in.
• Children should be supervised to ensure that they do not play with
the snap rings used for door adjustment or the water tube clips.
- There is risk of death by suffocation if a child swallows a snap
ring or water tube clip. Keep the snap rings and water tube clips
out of children’s reach.
• The refrigerator must be safely grounded.
- Always make sure that you have grounded the refrigerator
before attempting to investigate or repair any part of the
appliance. Power leakages can cause severe electric shock.
• Never use gas pipes, telephone lines, or other potential lightning
attractors as an electrical ground.
- You must ground the refrigerator to prevent any power
leakages or electric shocks caused by current leakage from the
refrigerator.
- This may result in an electric shock, re, explosion, or problems
with the product.
• Plug the power plug into the wall socket rmly. Do not use a
damaged power plug, damaged power cord, or loose wall socket.
- This may result in an electric shock or re.
Untitled-30 9 7/17/2017 5:03:56 PM
Safety information
English10
Safety information
• If the power cord is damaged, have it replaced immediately by the
manufacturer or one of its service agents.
• The fuse on the refrigerator must be changed by a qualied
technician or service company.
- Failing to do so may result in an electric shock or personal
injury.
Installation cautions
CAUTION
• Allow sufcient space around the refrigerator and install it on a
at surface.
- If your refrigerator is not level, cooling efciency and durability
can be declined.
- Keep the ventilation space in the appliance enclosure or
mounting structure clear of obstructions.
• Allow the appliance to stand for 2 hours before loading foods after
installation and turning on.
• We strongly recommend you have a qualied technician or service
company install the refrigerator.
- Failing to do so may result in an electric shock, re, explosion,
problems with the product, or injury.
Untitled-30 10 7/17/2017 5:03:56 PM
English 11
Safety information
Critical usage warnings
WARNING
• Do not insert the power plug into a wall socket with wet hands.
- This may result in an electric shock.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles may fall and
cause personal injury and/or material damage.
• Do not insert hands, feet or metal objects (such as chopsticks, etc.)
into the bottom or the back of the refrigerator.
- This may result in an electric shock or injury.
- Any sharp edges may cause a personal injury.
• Do not touch the inside walls of the freezer or products stored in
the freezer with wet hands.
- This may cause frostbite.
• Do not put a container lled with water on the refrigerator.
- If spilled, there is a risk of re or electric shock.
• Do not keep volatile or ammable objects or substances (benzene,
thinner, propane gas, alcohol, ether, LP gas, and other such
products) in the refrigerator.
- This refrigerator is for storing food only.
- This may result in re or explosion.
• Children should be supervised to ensure that they do not play with
the appliance.
- Keep ngers out of “pinch point” areas. Clearances between the
doors and cabinet are necessarily small. Be careful when you
open the doors if children are in the area.
• Do not let children hang on the door or door bins. A serious injury
may occur.
• Do not let children go inside the refrigerator. They could become
trapped.
Untitled-30 11 7/17/2017 5:03:56 PM
Safety information
English12
Safety information
• Do not insert your hands into the bottom area under the appliance.
- Any sharp edges may cause personal injury.
• Do not store pharmaceutical products, scientic materials, or
temperature sensitive products in the refrigerator.
- Products that require strict temperature controls must not be
stored in the refrigerator.
• Do not place or use electrical appliance inside the refrigerator/
freezer, unless they are of a type recommended by the
manufacturer.
• If you smell pharmaceutical or smoke, pull out power plug
immediately and contact your Samsung Electronics service center.
• If any dust or water is in Refrigerator, pull out power plug and
contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not let children step on a drawer.
- The drawer may break and cause them to slip.
• Do not leave the doors of the refrigerator open while the
refrigerator is unattended and do not let children enter inside the
refrigerator.
• Do not allow babies or children go inside the drawer.
- It can cause death from suffocation by entrapment or personal
injury.
• Do not overll the refrigerator with food.
- When you open the door, an item may fall out and cause
personal injury or material damage.
• Do not spray volatile material such as insecticide onto the surface
of the appliance.
- As well as being harmful to humans, it may also result in an
electric shock, re, or problems with the product.
Untitled-30 12 7/17/2017 5:03:57 PM
English 13
Safety information
• Never put ngers or other objects into the water dispenser hole,
ice chute and ice maker bucket.
- It may cause a personal injury or material damage.
• Do not use or place any substances sensitive to temperature such
as ammable sprays, ammable objects, dry ice, medicine, or
chemicals near or inside of the refrigerator.
• Do not use a hair dryer to dry the inside of the refrigerator. Do
not place a lighted candle in the refrigerator for removing bad
odours.
- This may result in an electric shock or re.
• Fill the water tank, ice tray and water cubes only with potable
water (mineral water or puried water).
- Do not ll the tank with tea, juice or sports drink, this may
damage the refrigerator.
• Do not stand on top of the appliance or place objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals,
metal objects, etc.) on the appliance. This may result in an electric
shock, re, problems with the product, or injury. Do not put a
container lled with water on the appliance.
- If spilled, there is a risk of re or electric shock.
• Do not use mechanical devices or any other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not damage the refrigerant circuit.
• Never stare directly at the UV LED lamp for long periods of time.
- This may result in eye strain due to the ultraviolet rays.
• Do not put fridge shelf in upside down. Shelf stopper could not
work.
- It may cause a personal injury because of glass shelf drop.
Untitled-30 13 7/17/2017 5:03:57 PM
Safety information
English14
Safety information
• Keep ngers out of “pinch point” areas. Clearances between the
doors and cabinet are necessarily small. Be careful when you open
the doors if children are in the area.
• If a gas leak is detected, avoid any naked ames or potential
sources of ignition, and air the room in which the appliance is
standing for several minutes.
- Do not touch the appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in explosion or re.
• Use only the LED Lamps provided by the manufacturer or its
service agents.
• Bottles should be stored tightly together so that they do not fall
out.
• This product is intended only for the storage of food in a domestic
environment.
• Never put ngers or other objects into the water dispenser hole,
ice chute and ice maker bucket.
- It may cause a personal injury or material damage.
• Do not attempt to repair, disassemble, or modify the refrigerator
yourself.
• Do not use any fuse (such as cooper, steel wire, etc.) other than a
standard fuse.
• If your refrigerator needs to be repaired or reinstalled, contact
your nearest service center.
- Failing to do so may result in an electric shock, re, problems
with the product, or injury.
• If the interior or exterior LED lamp has gone out, contact your
nearest service center.
Untitled-30 14 7/17/2017 5:03:57 PM
English 15
Safety information
• If the refrigerator emits a burning smell or smoke, unplug the
refrigerator immediately and contact your Samsung Electronics
service center.
- Failing to do so may result in an electric or re hazards.
• Pull the power plug out of the socket before changing the interior
lamps of the refrigerator.
- Otherwise, there is a risk of electric shock.
• If you experience difculty changing a non-LED light, contact a
Samsung service center.
• If the product is equipped with LED lamps, do not disassemble the
Lamp Covers and LED lamps yourself.
- Contact a Samsung service center.
• Plug the power plug into the wall socket rmly.
• Do not use a damaged power plug, damaged power cord or loose
wall socket.
- This may result in an electric shock or re.
Untitled-30 15 7/17/2017 5:03:57 PM
Safety information
English16
Safety information
Usage cautions
CAUTION
• Do not re-freeze frozen foods that have thawed completely. Do
not place carbonated or zzy drinks in the freezer compartment.
Do not put bottles or glass containers in the freezer.
- When the contents freeze, the glass may break and cause
personal injury.
• Use only the ice maker provided with the refrigerator.
• Have the refrigerator’s water supply connected only to a potable
water supply. To operate the ice maker properly, water pressure of
20 ~ 125 psi (138 ~ 862 kPa) is required. If you will be away from
home for a long period of time (on vacation, for example) and
won’t be using the water or ice dispensers, close the water valve.
- Otherwise, water leakage may occur.
• If you won’t be using the refrigerator for a very long period of
time, (3 weeks or more) empty the refrigerator including the ice
bucket, unplug it, close the water valve, wipe excess moisture
from the inside walls, and leave the doors open to prevent odors
and mold.
• To get the best performance from the product:
- Do not place food too close to the vents at the rear of the
refrigerator as this can obstruct free air circulation in the
refrigerator compartment.
- Wrap food up properly or place it in airtight containers before
putting it into the refrigerator.
- Do not place glass bottles or carbonated beverages into the
freezer. They can freeze and break. Broken beverage containers
can cause injury.
- Please observe maximum storage times and expiration dates of
frozen goods.
Untitled-30 16 7/17/2017 5:03:57 PM
English 17
Safety information
- There is no need to disconnect the refrigerator from the power
supply if you will be away for less than three weeks. However,
if you will be away for more than three weeks, remove all the
food and ice in the ice bucket, unplug the refrigerator, close the
water valve, wipe excess moisture from the inside walls, and
leave the doors open to prevent odors and mold.
• Do not place glass or bottles or carbonated beverages into the
freezer.
- The container may freeze and break, and this may result in
injury.
• Do not place carbonated or zzy drinks in the freezer
compartment. Do not put bottles or glass containers in the freezer.
- When the contents freeze, the glass may break and cause
personal injury and property damage.
• Service Warranty and Modication.
- Any changes or modications performed by a 3rd party on this
nished appliance are not covered under Samsung warranty
service, nor is Samsung responsible for safety issues that result
from 3rd party modications.
• Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a plastic bag, the
refrigerator can be over cooled. If a cooling period lasts too
long, the water lter may break and cause water leakage.
• Use only the ice-maker provided with the refrigerator.
• Wipe excess moisture from the inside and leave the doors open.
- Otherwise, odor and mold may develop.
• If the refrigerator is disconnected from the power supply, you
should wait for at least ve minutes before plugging it back in.
Untitled-30 17 7/17/2017 5:03:57 PM
Safety information
English18
Safety information
• If you have a long vacation planned or do not intend to use the
refrigerator for a long period of time, (3 weeks or more) empty the
refrigerator including the ice bucket, pull out the power plug, close
the water valve, wipe excess moisture from the inside walls, and
leave the doors open to prevent odors and mold.
• When the refrigerator got wet by water, pull out the power plug
and contact your Samsung Electronics service center.
• Do not strike or apply excessive force to any glass surface.
- Broken glass may result in a personal injury and/or property
damage.
• Fill the water tank and ice cube trays with potable water only (tap
water, mineral water, or puried water).
- Do not ll the tank with tea or a sports drink. This may damage
the refrigerator.
• Be careful that your ngers are not caught in.
• If the refrigerator is ooded, make sure to contact your nearest
service center.
- There is a risk of electric shock or re.
• Do not keep vegetable oil in your refrigerator’s door bins. The oil
can solidify, making it foul-tasting and difcult to use. In addition,
the open container can leak and the leaked oil can cause the door
bin to crack. After opening an oil container, it is best to keep the
container in a cool and shaded place such as a cupboard or pantry.
- Examples of vegetable oil: olive oil, corn oil, grape-seed oil, etc.
Untitled-30 18 7/17/2017 5:03:57 PM
English 19
Safety information
Cleaning cautions
CAUTION
• Do not spray water directly on the inside or outside the
refrigerator.
- There is a risk of re or electric shock.
• Do not use a hair dryer to dry the inside of the refrigerator.
• Do not place a lighted candle in the refrigerator to remove bad
odors.
- This may result in an electric shock or re.
• Do not spray cleaning products directly on the display.
- Printed letters on the display may come off.
• If any foreign substance such as water has entered the appliance,
unplug the power plug and contact your nearest service center.
- Failing to do so may result in an electric shock or re.
• Use a clean, dry cloth to remove any foreign matter or dust from
the power plug blades. Do not use a wet or damp cloth when
cleaning the plug.
- Otherwise, there is a risk of re or electric shock.
• Do not clean the appliance by spraying water directly onto it.
• Do not use benzene, thinner, or Clorox, Chloride for cleaning.
- They may damage the surface of the appliance and may cause a
re.
• Never put ngers or other objects into the dispenser hole.
- It may cause a personal injury or material damage.
• Before cleaning or performing maintenance, unplug the appliance
from the wall socket.
- Failing to do so may result in an electric shock or re.
• Use a clean sponge or soft cloth and a mild detergent in warm
water to clean the refrigerator.
Untitled-30 19 7/17/2017 5:03:57 PM
Safety information
English20
Safety information
• Do not use abrasive or harsh cleansers such as window sprays,
scouring cleansers, ammable uids, muriatic acid, cleaning
waxes, concentrated detergents, bleaches, or cleansers containing
petroleum products on exterior surfaces (doors and cabinet),
plastic parts, door and interior liners, and gaskets.
- These can scratch or damage the material.
• Do not clean glass shelves or covers with warm water when they
are cold. Glass shelves and covers may break if exposed to sudden
temperature changes or impacts such as bumping or dropping.
Untitled-30 20 7/17/2017 5:03:57 PM
English 21
Safety information
Critical disposal warnings
WARNING
• Please dispose of the packaging material from this product in an
environmentally friendly manner.
• Ensure that none of the pipes on the back of the refrigerator are
damaged prior to disposal.
• R-600a or R-134a is used as a refrigerant. Check the compressor
label on the rear of the appliance or the rating label inside the
fridge to see which refrigerant is used for your refrigerator. If this
refrigerator contains ammable gas (Refrigerant R-600a), contact
your local authority in regard to safe disposal of this product.
• When disposing of this refrigerator, remove the door/door seals
and door latch so that small children or animals cannot become
trapped inside. Children should be supervised to ensure that they
do not play with the appliance. If trapped inside, a child may get
hurt or suffocate to death.
- If trapped inside, the child may become injury and suffocate to
death.
• Cyclopentane is used in the insulation. The gases in the insulation
material require a special disposal procedure. Please contact your
local authorities in regard to the environmentally safe disposal of
this product.
• Keep all packaging materials well out of the reach of children, as
packaging materials can be dangerous to children.
- If a child places a bag over his or her head, the child could
suffocate.
Untitled-30 21 7/17/2017 5:03:57 PM
Safety information
English22
Safety information
Additional tips for proper usage
• In the event of a power failure, call the local ofce of your electric
company and ask how long the failure is going to last.
- Most power failures that are corrected in an hour or two will
not affect your refrigerator temperatures. However, you should
minimize the number of door openings while the power is off.
- Should the power failure last more than 24 hours, remove and
discard all frozen food.
• The refrigerator might not operate consistently (frozen contents
can thaw or temperatures can become too warm in the frozen
food compartment) if sited for an extended period of time in a
location where ambient air temperatures are constantly below the
temperatures for which the appliance is designed.
• In case of particular foods, keeping it under refrigeration can have
a bad effect on preservation due to its properties.
• Your appliance is frost free, which means there is no need
to manually defrost your appliance. This will be carried out
automatically.
• Temperature rise during defrosting complies with ISO
requirements. If you want to prevent an undue rise in the
temperature of frozen food while the appliance defrosts, wrap the
frozen food in several layers of newspaper.
• Do not re-freeze frozen foods that have thawed completely.
• The temperature of two star section (sections) or compartment
(compartments) which have two star symbol (
) is slightly higher
than other freezer compartment (compartments).
The two star section (sections) or compartment (compartments) is
(are) based on the instruction and/or the condition as delivered.
Untitled-30 22 7/17/2017 5:03:57 PM
English 23
Safety information
Saving Energy Tips
• Install the appliance in a cool, dry room with adequate ventilation.
Ensure that it is not exposed to direct sunlight and never put it
near a direct source of heat (a radiator, for example).
• Not to block any vents and grilles is recommended for energy
efciency.
• Allow warm food to cool down before placing it in the appliance.
• Put frozen food in the refrigerator to thaw. You can then use
the low temperatures of the frozen products to cool food in the
refrigerator.
• Do not keep the door of the refrigerator open for too long when
putting food in or taking food out. The shorter the time the door is
open, the less frost build-up you’ll have in the freezer.
• It is recommended to install the refrigerator with clearance to the
back and sides. This will help reduce power consumption and keep
your energy bills lower.
• For the most efcient use of energy, please keep the all inner
ttings such as baskets, drawers, shelves on the position supplied
by manufacturer.
This appliance is intended to be used in household and similar
applications such as
• staff kitchen areas in shops, ofces and other working
environments;
• farm houses and by clients in hotels, motels and other residential
type environments;
• bed and breakfast type environments;
• catering and similar non-retail applications.
Untitled-30 23 7/17/2017 5:03:57 PM
Safety information
English24
Safety information
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic
Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates
that the product and its electronic accessories (e.g. charger,
headset, USB cable) should not be disposed of with other
household waste at the end of their working life. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from
other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government ofce, for details
of where and how they can take these items for environmentally
safe recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product and its
electronic accessories should not be mixed with other commercial
wastes for disposal.
For information on Samsung’s environmental commitments and
product specic regulatory obligations e.g. REACH visit: samsung.
com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/
data_corner.html
(For products sold in European countries only)
Untitled-30 24 7/17/2017 5:03:57 PM
English 25
Installation
Follow these instructions carefully to ensure a proper installation of this refrigerator and
to prevent accidents before using it.
WARNING
• Use the refrigerator only for its intended purpose as described in this manual.
• Any servicing must be performed by a qualied technician.
• Dispose of the product packaging material in compliance with the local regulations.
• To prevent electric shock, unplug the power cord before servicing or replacements.
Refrigerator at a glance
The actual appearance of your refrigerator may differ, depending on the model and the
country.
RS58*
09
01
02
03
06
07
12
05
08
10
11
04
Installation
Untitled-30 25 7/17/2017 5:03:58 PM
Installation
English26
Installation
RS62*
11
10
04
08
05
03
01
13
02
01 Freezer shelves 02 Multipurpose freezer
guard
03 Dried food and meat
storage bin
04 Refrigerator guard 05 Refrigerator shelves 06 Vegetable bin
07 Multipurpose bin 08 Egg container 09 Ice maker bucket **
10 Moving tray * 11 Anti-bacteria lter * 12 Water lter **
13 Ice tray
* Applicable models only
** Dispenser models only
NOTE
The design of the egg container may differ with the model.
CAUTION
• Do not put the moving tray in the freezer when lled with water. Water freezes and
the moving tray breaks.
Untitled-30 26 7/17/2017 5:03:59 PM
English 27
Installation
Untitled-30 27 7/17/2017 5:03:59 PM
Installation
English28
Installation
Step-by-step installation
STEP 1 Select a site
Site requirements:
• Solid, level surface without carpeting or ooring that may obstruct ventilation
• Away from direct sunlight
• Adequate room for opening and closing the door
• Away from a heat source
• Room for maintenance and servicing
• Temperature range: between 5 °C and 43 °C
Effective temperature range
The refrigerator is designed to operate normally in the temperature range specied by its
class rating.
Class Symbol
Ambient Temperature range (°C)
IEC 62552 (ISO 15502) ISO 8561
Extended Temperate SN +10 to +32 +10 to +32
Temperate N +16 to +32 +16 to +32
Subtropical ST +16 to +38 +18 to +38
Tropical T +16 to +43 +18 to +43
NOTE
The cooling performance and power consumption of the refrigerator may be affected
by the ambient temperature, the door-opening frequency, and the location of the
refrigerator. We recommend adjusting the temperature settings as appropriate.
Untitled-30 28 7/17/2017 5:03:59 PM
English 29
Installation
Clearance
See the pictures and table below for space requirements for installation.
A
B
C
D
Depth “A” 721
Width “B” 908
Height “C” 1796
Overall Height “D” 1825
(unit: mm)
01
02 02
04
05
06
07
08
03
01 50 mm
02 165°
03 519 mm
04 1742 mm
05 610 mm
06 908 mm
07 31 mm
08 1345 mm
NOTE
The measurements in the above table may differ, depending on the measuring method.
Untitled-30 29 7/17/2017 5:03:59 PM
Installation
English30
Installation
STEP 2 Flooring
• The surface to install the refrigerator
must support a fully loaded refrigerator.
• To protect the oor, put a large piece
of cardboard on each leg of the
refrigerator.
• Once the refrigerator is in its nal
position, do not move it unless
necessary to protect the oor. If you
have to, use a thick paper or cloth such
as old carpets along the movement
path.
NOTE
If the refrigerator cannot pass through the entrance due to its size, see the Door removal
for entrance section in the Maintenance chapter.
Untitled-30 30 7/17/2017 5:03:59 PM
English 31
Installation
STEP 3 Adjust the levelling feet
CAUTION
• The refrigerator must be levelled on a at, solid oor. Failing to do so can cause
damage to the refrigerator or physical injury.
• Levelling must be performed with an empty refrigerator. Make sure no food items
remain inside the refrigerator.
• For safety reasons, adjust the front side a little higher than the rear side.
The refrigerator can be levelled using the front legs that have a special screw (leveller) for
levelling purposes. Use a at-head screwdriver for levelling.
To adjust the height of the freezer side:
Insert a at-head screwdriver into the
leveller of the freezer-side front leg. Turn
the leveller clockwise to raise, or turn it
counter clockwise to lower.
To adjust the height of the fridge side:
Insert a at-head screwdriver into the
leveller of the fridge-side front leg. Turn
the leveller clockwise to raise, or turn it
counter clockwise to lower.
Untitled-30 31 7/17/2017 5:03:59 PM
Installation
English32
Installation
STEP 4 Adjust the door height as well as the door gap
To adjust the height of a door
The height of a door can be adjusted using the clamp nut and the height nut on the front
bottom of each door.
B
A
1. Open the door to adjust, and locate the
two nuts (A) and (B) on the front bottom
of the door.
A
2. With the provided spanner, turn the
clamp nut (A) clockwise to loosen. Then,
open the door, and do the following
inside the door.
- To raise the door, turn the height nut
(B) counter clockwise.
- To lower the door, turn the height
nut (B) clockwise.
A
3. When complete, tighten the clamp nut
(A) by turning it counter clockwise.
Untitled-30 32 7/17/2017 5:04:00 PM
English 33
Installation
To correct the gap between a door and the refrigerator unit
The gap can be adjusted manually using
the gap bolt on the top rear side of each
door.
A
1. To adjust the gap, do the following:
- To widen the gap, turn the gap bolt
(A) clockwise.
- To narrow the gap, turn the gap bolt
(A) counter clockwise.
B
2. When the gap is corrected, tighten the
locking nut (B) by turning it clockwise.
Untitled-30 33 7/17/2017 5:04:01 PM
Installation
English34
Installation
STEP 5 Connect to a water source
CAUTION
• The water line must be connected by a qualied technician.
• The warranty for your refrigerator does not cover the water line installation. The
water line installation will be performed at your own costs unless the installation fee is
included in the retailer’s price.
• Samsung takes no responsibility for the water line installation. If water leaks occur,
contact the installer of the water line.
To connect the cold water pipe to the water ltering hose
CAUTION
• Make sure the water ltering hose is connected to a cold, potable water source pipe.
Connecting to the hot water pipe may cause the purier to malfunction.
1
A
B
A
A. Close Main Water pipe
B. No gap
1. Shut off the water supply by closing the
main water valve.
2. Locate the cold, potable water pipe (1).
3. Follow the Water Line Installation to
connect to the water pipe.
4. When connection is complete, open the
main water valve and dispense about
3 liters of water. This is to remove
impurities inside the pipe.
Untitled-30 34 7/17/2017 5:04:01 PM
English 35
Installation
To connect the water ltering hose to the water line
Remove cap
a
a
A
B
03
a
A. Water Line from unit
B. Water Line from Kit
1. Loosen and remove the compression
nut (a) from the water line of the
refrigerator, and insert it to the water
ltering hose.
2. Tighten up the compression nut (a) to
connect the water ltering hose and the
water line.
3. Open the main water valve and check
for any leaks.
4. If there are no leaks, dispense about a
3 liters of water before actually using
the refrigerator to remove impurities
inside the water ltering system.
To repair the water line
CAUTION
The waterline must be repaired by a qualied professional. If you encounter a water leak,
contact a local Samsung service centre or the installer of the waterline.
STEP 6 Initial settings
By completing the following steps, the refrigerator should be fully functioning.
1. Plug the power cord into the wall socket to turn the refrigerator on.
2. Open the door, and check if the interior light lights up.
3. Set the temperature to the coldest, and wait for about an hour. Then, the freezer will be
slightly chilled, and the motor will run smoothly.
4. Wait until the refrigerator reaches the set temperature. Now the refrigerator is ready
for use.
STEP 7 Final check
When installation is complete, conrm that:
• The refrigerator is plugged into an electrical outlet and grounded properly.
• The refrigerator is installed on a at, level surface with a reasonable clearance from the
wall or the cabinet.
• The refrigerator is level and is sitting rmly on the oor.
• The door opens and closes freely, and the interior light turns on automatically when
you open the door.
Untitled-30 35 7/17/2017 5:04:01 PM
Installation
English36
Installation
Door removal for entrance
If the refrigerator cannot pass through the entrance due to its size, follow these
instructions:
Tools required (not provided)
These tools are used for removing the doors.
Philips screwdriver Flat-heat
screwdriver
Socket spanner
(10 mm)
Allen spanner
(5 mm)
Disconnect the water line
1. From the bottom rear side of the
refrigerator, pull out the water line to
the front.
NOTE
The refrigerator’s water line is a water
circulation line that connects between the
water pipe from the water source and the
hoses from the water ltering system of
the refrigerator.
B
A
2. To disconnect the hoses, press and hold
the transparent coupler (A) and detach
the water hose (B).
CAUTION
Do not apply excessive force to the
coupler. It may break.
Untitled-30 36 7/17/2017 5:04:02 PM
English 37
Installation
Detach the doors
CAUTION
The door may fall off or over and damage itself during any of these steps. To prevent an
accident, use extreme caution when performing these steps.
A
A
1. Use a Philips screwdriver to unscrew
the hinge covers (A) on the top of each
door.
2. Open the doors to loosen the hinges
and remove the hinge covers. Once the
covers are removed, close the doors.
3. Disconnect the electrical harness.
B
C
4. Unscrew the hinge screws (B) counter
clockwise, and remove the upper hinge
(C). Be careful as the door can fall on
you, causing physical injury.
Untitled-30 37 7/17/2017 5:04:03 PM
Installation
English38
Installation
C
5. Remove the hinges (C) on both sides.
6. Gently lift up the doors one by one to
remove. Use caution as the door may
fall off or over.
Reconnect the water hoses
Once the refrigerator has passed through the entrance, reconnect the water hoses and
insert the provided clips (x2) to tighten the coupler.
A
B
A. Center of transparent coupler
B. Clip A (1/4”) (6.35 mm)
CAUTION
• Make sure the water hoses are
connected with matching colours.
• To prevent water leaks, each water
hose must be inserted fully to the
centre of the transparent coupler and
then must be clipped.
Untitled-30 38 7/17/2017 5:04:03 PM
English 39
Installation
Reattach the doors
CAUTION
• Before reattaching the doors, make sure all the electrical connectors are properly
connected.
• The freezer door must be reattached before the fridge door.
1. Hold the freezer door and hook to the
hinge at the bottom of the refrigerator.
A
2. On the top side, insert the hinge (A) into
the hinge slot.
B
C
D
3. Insert the upper hinge shaft (B) into
the hinge hole (C). Make sure the hinge
shaft is straight so that all screw holes
are fully revealed. Then, tighten the
hinge screws (D) clockwise.
Untitled-30 39 7/17/2017 5:04:04 PM
Installation
English40
Installation
4. Connect the electrical harness.
5. Insert the hinge covers with the front
sides rst, and then tighten the screws.
Use a Philips screwdriver for this step.
Untitled-30 40 7/17/2017 5:04:04 PM
English 41
Operations
Feature panel
01
04
03
07
01 04
05
02
03
07
08 09
06
01 04
05
02
03
07
08 09
RS62* RS58*
01 Freezer / Power Freezer 02 Lighting / °C °F 03 Vacation
04 Fridge / Power Cool 05 Door Alarm 06 Filter *
07 Control Lock 08 Water / Filter Reset* 09 Cube/Crushed Ice / Ice
Maker Off
* Applicable models only
Operations
Untitled-30 41 7/17/2017 5:04:04 PM
Operations
English42
Operations
01 Freezer / Power Freeze (3 sec)
Freezer
The Freezer button can be used to set the freezer temperature, or to
activate Power Freeze. Available temperatures are between -15 °C
(5 °F) and -23 °C (-8 °F).
Power Freeze
Power Freeze speeds up the freezing process at maximum fan speed.
The freezer keeps running at full speed for several hours and then
returns to the previous temperature.
• To activate Power Freeze, press and hold Freezer for 3 seconds.
The corresponding indicator (
) lights up, and the refrigerator will
speed up the freezing process for you.
• To deactivate, press and hold Freezer for 3 seconds again. The
freezer returns to the previous temperature setting.
• To freeze large amounts of food, activate Power Freeze for at least
24 hours before putting food in the freezer.
NOTE
Using Power Freeze increases power consumption. Make sure you turn
it off and return to the previous temperature if you do not intend to
use it.
02 Lighting / °C °F (3 sec)
The Lighting button can be used to switch the temperature scale between Celsius and
Fahrenheit. To switch the temperature scale, press and hold Lighting for 3 seconds to
change the current temperature scale.
03 Vacation
Vacation
The Vacation button can be used to activate/deactivate Vacation mode.
If you are going on vacation or a business trip, or if you do not intend
to use the refrigerator for an extended time, use the Vacation feature.
Press and hold Vacation for 3 seconds to turn off the fridge operation
with the Vacation indicator (
) on.
NOTE
It is strongly recommended to empty the fridge compartment and
make sure the door is closed.
Untitled-30 42 7/17/2017 5:04:04 PM
English 43
Operations
04 Fridge / Power Cool (3 sec)
The Fridge button can be used to set the fridge temperature, or to activate/deactivate
Power Cool.
Fridge
You can manually adjust the cooling temperature for the fridge. Keep
pressing Fridge to cycle through the temperature bar, and select a
desired temperature between 1 °C (34 °F) and 7 °C (44 °F).
Power Cool
Power Cool speeds up the cooling process at maximum fan speed.
This is useful to quickly cool food that spoils quickly, or after the door
is left open for some time. The fridge keeps running at full speed for
several hours and then returns to the previous temperature.
Press and hold Power Cool for 3 seconds.
05 Door Alarm
Door Alarm
You can set the alarm for a reminder. If the door is left open for more
than 2 minutes, the alarm will sound with the alarm indicator ( )
blinking. The alarm is enabled by factory default. To disable the alarm,
press Door Alarm. To enable, press Door Alarm again.
06 Filter
The lter lifecycle will be reset and the lter indicator turns off. The icon will blink red for
several seconds when you open or close the door.
Untitled-30 43 7/17/2017 5:04:05 PM
Operations
English44
Operations
07 Control Lock (3 sec)
Control Lock
To activate the Control Lock, press and hold Control Lock for 3
seconds. The controls on the display are disabled, and the dispenser
does not operate even if you push the lever. To deactivate, press and
hold again for 3 seconds.
08 Water / Filter Reset (3 sec)
The Water button can be used to dispense water, or to reset the water lter.
Dispensing Press Water to dispense water. In this mode, no ice will be dispensed.
Filter Reset
After about 6 months (approximately 300 gallons) of using the original
water lter, the Filter indicator turns red to remind you that the lter
needs to be replaced. If this happens, replace the lter, and press and
hold Filter Reset for 3 seconds.
NOTE
Some regional areas have relatively large amounts of lime contained
in the water. This may reduce the lifecycle of the lter. In these areas,
you will have to replace the water lter more often than specied
above.
09 Cubed/Crushed Ice / Ice Maker Off (3 sec)
Cubed/Crushed
Ice
You can select an ice type. Press the button to toggle between the
cubed and crushed ice types. The corresponding indicator turns on.
Ice Maker Off
To disable ice making, press and hold for 3 seconds. In this mode, ice
making is disabled even if you press Cubed/Crushed Ice.
Untitled-30 44 7/17/2017 5:04:05 PM
English 45
Operations
Temperature settings
To ensure optimal performance, we recommend setting the temperature to -19 °C (-2 °F)
for the freezer, and 3 °C (37 °F) for the fridge.
Freezer
The freezer temperature can be adjusted
between -23 °C (-9 °F) and -15 °C (5 °F).
To change the temperature, keep pressing
Freezer until a desired temperature is
selected. The temperature changes by
1 scale unit.
• Recommended: -19 °C (-2 °F)
NOTE
Ice cream may melt at -15 °C (5 °F).
Fridge
The fridge temperature can be adjusted
between 1 °C (34 °F) and 7 °C (44 °F).
To change the temperature, keep pressing
Fridge until a desired temperature is
selected. The temperature changes by
1 scale unit.
• Recommended: 3 °C (37 °F)
The temperature of the freezer or fridge may rise if you open the door frequently, or a
large amount of food is put in the refrigerator. If this happens, the temperature display
blinks until the refrigerator returns to the specied temperature settings.
NOTE
If this blinking continues, disconnect the power cord and restart the refrigerator after
10 minutes.
Untitled-30 45 7/17/2017 5:04:05 PM
Operations
English46
Operations
Special features
The refrigerator features user-oriented devices that you can use to benet from.
Water dispenser (applicable models only)
With the water dispenser, you can dispense water without opening the fridge door.
WaterCubed Crushed Ice Maker Off
Basically, the water dispenser offers
3 options: chilled water, cubed ice, and
crushed ice. If you do not want to dispense
ice, press Ice Maker Off.
With the Ice Maker enabled,
1. Press to select the ice type.
2. Put a water glass on the dispenser lever
and push it. Ice will be dispensed from
the dispenser.
3. Press to select the water.
4. Then, put the glass on the dispenser
lever and push it. Water will be
dispensed from the dispenser.
NOTE
• To prevent spills, wait 2 seconds before removing the glass after dispensing.
• The dispenser will stop dispensing if you keep pushing the dispenser lever for about
1 minute. To dispense more water, release and push the lever again.
• Make sure the glass is in line with the dispenser to prevent the dispensed water from
spilling out.
• If you do not use the water dispenser for 2-3 days, the dispensed water may have an
abnormal smell or taste. This is not a system failure. Discard the rst 1-2 glasses of
water.
Untitled-30 46 7/17/2017 5:04:05 PM
English 47
Operations
To ll the water tank
For rst-time use, clean the inner side of
the water tank and dry well.
1. Hold both handgrips on the front of the
tank, and slide out as shown.
A B
2. Open the front lid (A) of the cover or
the entire cover (B) and ll the tank
with a max of 5 liters water.
CAUTION
Do not exceed the max line. Water
overows.
3. Reinsert the water tank and t into the
dispenser mechanism. Make sure the
front side (with the front lid) of the tank
faces to the front.
CAUTION
• Make sure the water tank ts into the shelf. Otherwise, the water tank may not operate
properly.
• Do not use the refrigerator without inserting the water tank. This may decrease the
cooling performance.
• Fill the tank only with potable water such as mineral or puried water. Do not use
other liquid.
• Use caution when moving a lled tank. Physical injury may occur if the tank is
dropped.
• Do not try to disassemble the internal pump yourself. If the internal pump is damaged
or disconnected from the water tank, the dispenser does not operate.
For rst-time use
• Push the dispenser lever for 10 seconds to emit air from the hoses of the water supply
system.
• Discard the rst six glasses of water to remove impurities in the water supply system.
Untitled-30 47 7/17/2017 5:04:06 PM
Operations
English48
Operations
To dispense water
Put a glass under the water outlet, and gently push against the dispenser lever with the
glass.
CAUTION
• Make sure the glass is in line with the dispenser to prevent the dispensed water from
spilling out.
• If you do not use the water dispenser for 2-3 days, the dispensed water may have an
abnormal smell or taste. This is not a system failure. Discard the rst 1-2 glasses of
water.
Ice making (applicable models only)
The refrigerator has a built-in ice maker that automatically dispenses ice so that you can
enjoy ltered water with cubed or crushed ice to your preference.
C
B
A
If ice does not dispense, rst check the ice
maker if it makes ice properly.
To check the ice maker
1. Gently hold the icemaker bucket (B)
with both hands and remove it from the
ice chute (A).
2. Check the icemaker bucket if it contains
ice as appropriate.
3. Then, hold the icemaker cover (C) and
slightly lift up to remove.
D
4. Press Test (D) on the side of the ice
maker. You will hear a chime (ding-
dong) at the press of the button.
5. You will hear another chime if the ice
maker operates properly.
NOTE
If this symptom continues, contact the
waterline installer or a local Samsung
service centre.
CAUTION
• Do not press the button repeatedly after the ice tray is lled with ice or water. Water
may overow or ice may be jammed.
Untitled-30 48 7/17/2017 5:04:06 PM
English 49
Operations
• When the refrigerator recovers power supply after a power failure, the icemaker
bucket may contain a mix of melted and jammed ice cubes, resulting in a system
failure. To prevent this, make sure to empty the icemaker bucket before using the
refrigerator.
• To prevent dropping the icemaker bucket, make sure to use both hands when removing
or reinserting the icemaker bucket.
• Do not let children hang on or play with the ice dispenser or the icemaker bucket.
Children may get hurt.
• Do not put ngers or other objects into the dispenser hole or the ice chute. This may
cause physical injury or property damage.
NOTE
• If you remove the icemaker bucket, the Ice Maker Off indicator (
) will blink.
• Removal of the icemaker bucket does not affect the thermal and mechanical
performance of the refrigerator.
• The declared freezer volume is based on use of the freezer guide after the ice maker,
snack bin, and upper drawer are removed.
Untitled-30 49 7/17/2017 5:04:07 PM
Operations
English50
Operations
To secure more storage space (applicable models only)
A
B
C
C
If you do not use the ice maker and need
more storage space, remove the icemaker
bucket (A) and the snack bin. Then, insert
the freezer guide (B) into the icemaker
bucket’s place. To secure more room,
remove the freezer’s upper drawer (C).
Icemaker bucket
If you do not dispense ice for an extended
period, ice may form clumps inside the
bucket. If this happens, remove and empty
the icemaker bucket.
1. To remove the icemaker bucket, gently
lift it up and pull out slowly while
holding the handgrips with both hands.
2. Remove and empty the icemaker
bucket.
Untitled-30 50 7/17/2017 5:04:07 PM
English 51
Operations
3. When done, turn the gear handle on the
rear of the bucket by 90°, and then put
the bucket back into position. Make sure
the bucket is inserted properly until you
hear a clicking sound.
4. Press and hold Ice Maker Off for 3
seconds to reset the icemaker.
CAUTION
• Do not apply excessive force to the
bucket cover. The cover may break.
• Do not close the door hard. Water may
spill over the ice maker.
• To prevent injury, make sure to clean
up any ice or water that has fallen on
the oor.
• To prevent accidents or injury, do
not let children play with the water
dispenser or the ice maker.
• Do not put your hand or an object into
the ice chute. This may cause physical
injury or product damage.
NOTE
• If the Ice Maker Off indicator (
) blinks, remove and reinsert the icemaker bucket.
Make sure it is reinserted properly.
• Any sound from the ice maker is normal, which outputs during the ice making process.
• While the door is open, neither the ice maker nor the water dispenser operates.
Water pressure
If you want to check how much water ows into the ice tray, follow these steps.
Untitled-30 51 7/17/2017 5:04:07 PM
Operations
English52
Operations
A
B
1. Gently lift up the icemaker cover (A) to
remove.
2. Press Test (B) on the side of the
icemaker. Normally, the ice cube
container lls with water in a few
minutes.
3. If the water level is lower than
expected, check the water pressure of
the water supply line from the water
source. This is not a system failure.
CAUTION
• Do not press Test repeatedly when the tray is lled with water. Water may overow or
ice may be jammed.
• Make sure the icemaker bucket is inserted properly. Otherwise, the ice maker will not
operate.
Smart Eco (applicable models only)
A
B
C
The Smart Eco system intelligently
controls the refrigerator according to
the operating environment in order to
keep food fresh using 4 sensors that are
located on both the inner and outer sides
of the refrigerator. This smart system also
monitors usage patterns and the operating
status to save power consumption.
A. External temperature sensor
B. External humidity sensor
C. Internal temperature sensors
Untitled-30 52 7/17/2017 5:04:08 PM
English 53
Maintenance
Handle and care
Shelves (fridge/freezer)
Rear
1
• To remove a shelf, fully open the
corresponding door. Hold the front of
the shelf and gently lift up and slide
out.
• If the door cannot fully open, slide out
the shelf half way to the front and turn
it over to remove.
2
3
CAUTION
• The shelf must be inserted correctly. Do
not insert upside down.
• Glass containers may scratch the
surface of glass shelves.
Moving tray shelf (fridge/freezer)
• To remove the shelf, hold the bottom
side of the shelf and gently lift up and
pull out.
NOTE
Do not hold the front side of the shelf to
pull out. The shelf does not loosen on the
front side.
Maintenance
Untitled-30 53 7/17/2017 5:04:08 PM
Maintenance
English54
Maintenance
Door guard
To remove a door guard, hold the front
sides of the bin and gently lift up to
remove.
Drawers
Gently lift up the front of the drawer and
slide out.
Untitled-30 54 7/17/2017 5:04:09 PM
English 55
Maintenance
Vegetable bin / Dry bins
To remove the vegetable bin from the
fridge or the dry bin from the freezer.
1. First, remove surrounding multipurpose
bins if necessary.
A
2. If your refrigerator is provided with
a cover (A) for the vegetable/dry bin,
remove the cover. For this, slide out the
cover while holding down the clips on
either side of the cover.
3. Gently pull out the vegetable/dry bin.
Untitled-30 55 7/17/2017 5:04:09 PM
Maintenance
English56
Maintenance
Sealing guard (applicable models only)
To remove the sealing guard
Gently lift up the guard, and then pull it to
the front while holding the bottom side.
To reinsert the sealing guard
1. Put the guard on the front of the
housing. And then, insert the guard by
lowering it.
2. Press both hooks on the guard to lock
the guard. When the guard is locked
properly, you will hear a clicking sound.
CAUTION
• Make sure the sealing guard is locked rmly. Otherwise, the guard may cause noise
when you open or close the door.
Untitled-30 56 7/17/2017 5:04:10 PM
English 57
Maintenance
Icemaker bucket
To remove the icemaker bucket, see the Diagnosis section on page 50.
Cleaning
Interior and exterior
WARNING
• Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning
purposes. They may damage the surface of the refrigerator and cause a re.
• Do not spray water onto the refrigerator. This may cause electric shock.
• Do not put ngers or other objects into the dispenser hole.
Regularly use a dry cloth to remove all foreign substances such as dust or water from the
power plug terminals and contact points.
1. Unplug the power cord.
2. Use a moistened, soft, lint-free cloth or paper towel to clean the refrigerator’s interior
and exterior.
3. When done, use a dry cloth or paper towel to dry well.
4. Plug in the power cord.
Untitled-30 57 7/17/2017 5:04:10 PM
Maintenance
English58
Maintenance
Replacement
Water lter (applicable models only)
WARNING
• Do not use third-party water lters. Use only Samsung-provided or -approved lters.
• Unapproved lters may leak and damage the refrigerator, causing electric shock.
Samsung holds no responsibility for any damage that may occur from use of third-
party water lters.
The lter indicator (
) turns red as a reminder that lets you know it is time to replace the
water lter.
1. Turn the knob of the lter cartridge
counter clockwise by 90 degrees. The
lter cartridge will be unlocked.
2. Pull out the cartridge.
3. Insert a new lter cartridge. Use only
Samsung-provided or -approved lters.
Untitled-30 58 7/17/2017 5:04:10 PM
English 59
Maintenance
4. Turn the cartridge knob clockwise to
lock into place.
5. Press and hold Filter Reset on the
feature panel for 3 seconds to reset the
lter lifecycle. The lter indicator (
)
turns off.
6. When replacing is complete, ush 4
liters of water to remove impurities
from the water line. See the Flushing
section for more information.
NOTE
• A newly installed lter may cause the water dispenser to spurt water briey. This is
because air has entered the waterline.
• This replacement process may involve the refrigerator to drip water onto the oor. If
this happens, wipe up with dry cloths.
Reverse osmosis water ltration system
The water pressure of the water supply system to a reverse osmosis water ltration
system must be between 35 psi and 120 psi (241 kPa and 827 kPa).
The water pressure of the reverse osmosis water ltration system to the refrigerator’s
cold water line must be at least 40 psi (276 kPa). If the water pressure is below the
specied:
• Check to see whether the sediment lter in the reverse osmosis system is blocked.
Replace the lter if necessary.
• Rell the water tank in the reverse osmosis system with water.
• If your refrigerator has a water lter, it may further reduce the water pressure when
used in conjunction with a reverse osmosis system. Remove the water lter.
For more information or servicing, contact a licensed plumbing professional.
Ordering a new lter
To purchase a new water lter, contact a local Samsung service centre.
Lamps and anti-bacteria lter
Neither lamps nor the anti-bacteria lter are user-serviceable. Do not attempt to replace
them yourself. To replace them, contact a local Samsung service centre.
Untitled-30 59 7/17/2017 5:04:10 PM
English60
Troubleshooting
If you encounter an abnormal situation with the refrigerator, rst check the table below
and try the suggestions.
General
Symptom Action
Does not operate or
cool.
• Make sure the power cord is connected properly.
• Make sure the temperature control is set correctly. Try
setting to a lower temperature.
• Make sure to keep the refrigerator away from direct sunlight
or a heat source. Failing to do so may affect the cooling
performance.
• Make sure the refrigerator has enough room from the rear
and side walls or the cabinet. Failing to do so may affect the
cooling performance.
• Too much food may block the ventilation of the refrigerator.
To keep the refrigerator in normal operation, do not put too
much food inside.
Food in the fridge
freezes.
• Check if the temperature control is set to the lowest
temperature. If so, change to a higher or the optimal
temperature.
• This happens if the ambient temperature is too low. Set the
temperature higher.
• Check if food containing a high portion of water is put in the
coldest area of the fridge or near the cooling vent. If this
happens, move the food to other shelves in the fridge.
Emits noises.
• Make sure the refrigerator is installed on a stable, at
surface.
• Make sure the refrigerator has enough room from the rear
and side walls or the cabinet.
• Make sure to keep the refrigerator from impurities or foreign
objects inside or underneath.
• The refrigerator may produce a ticking sound from inside,
which occurs when the various accessories contract or
expand. This is not a system failure.
Troubleshooting
Untitled-30 60 7/17/2017 5:04:11 PM
English 61
Troubleshooting
Symptom Action
The front corners
and sides become
warm and form
condensation.
• To prevent condensation from forming, the refrigerator
has heat-proof piping in the front corners. If the ambient
temperature rises, this equipment may not work effectively.
This is not a system failure.
• Make sure the door is closed properly. Condensation may
form if you leave the door open for some time.
• Condensation may form on the exterior surface of the
refrigerator if humid air comes into contact with the cool
surface of the refrigerator.
The ice maker does
not make ice.
• You must wait for 12 hours until the refrigerator makes ice.
• Make sure the ice maker is not stopped while making ice.
• Make sure the water tank is lled with water.
• Check if the icemaker bucket contains ice clumps. In this case,
empty the icemaker bucket and try again.
The water dispenser
is not functioning.
• Check if the water tank is frozen. If so, select a higher fridge
temperature.
• Make sure the water tank is lled with water.
• Make sure the water tank is installed properly.
• Make sure the water lter is installed properly.
Produces a bubbling
sound.
• The refrigerator makes this sound during the cooling process,
which is normal.
A bad smell comes
from inside the
refrigerator.
• Check for any spoiled food. We recommend cleaning the
refrigerator on a regular basis and remove any spoiled or
suspect food items.
• Make sure strong smelling food is wrapped up airtight.
Frost forms on the
interior walls.
• Make sure no food blocks the vents of the refrigerator. It is
also important to arrange food items evenly for ventilation.
• Make sure the door is closed properly.
Condensation forms
on the interior walls
or around vegetables.
• This happens when food containing a high portion of water is
stored uncovered, or the door has been left open for a while.
• Make sure food is covered or put in sealed containers.
Untitled-30 61 7/17/2017 5:04:11 PM
Troubleshooting
English62
Troubleshooting
Symptom Action
Ice maker does not
supply Ice cubes.
Check the following:
• Push the water dispenser lever to check the water supply.
• Push the ice dispenser lever to check the operation of the
auger motor in the ice maker assembly.
• Check if there are any objects that obstruct the auger motor
from running. If found, remove the objects and clear the
motor area.
• If the ice maker has not been used for an extended time, the
icemaker bucket may contain ice chunk that obstructs the
auger motor from running properly. In this case, remove and
empty the icemaker bucket, and try dispensing ice.
Untitled-30 62 7/17/2017 5:04:11 PM
Memo
Untitled-30 63 7/17/2017 5:04:11 PM
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the
SAMSUNG customer care center.
Country Contact Center Web Site
NEW ZEALAND 0800 726 786 www.samsung.com/nz/support
INDIA
1800 40 SAMSUNG (1800 40 7267864)
(Toll-Free)
www.samsung.com/in/support
MALAYSIA
1800-88-9999
603-77137477 (Overseas contact)
www.samsung.com/my/support
PHILIPPINES
1-800-10-726-7864 [ PLDT Toll Free ]
1-800-8-726-7864 [ Globe Landline and
Mobile ]
02-422-2111 [ Standard Landline ]
www.samsung.com/ph/support
SINGAPORE 1800-SAMSUNG (726-7864) www.samsung.com/sg/support
PANAMA 800-0101
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/support
UK 0330 SAMSUNG (7267864) www.samsung.com/uk/support
IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support
MYANMAR +95-1-2399-888 www.samsung.com/th/support
SRI LANKA
0117540540
0115900000
www.samsung.com/support
DA68-03412J-04
Untitled-30 64 7/17/2017 5:04:11 PM
