Vizio D39h-D0 Television D Series User Manual

Model D39h-D0

USER MANUAL

VIZIO

Table Of Contents

Getting to Know Your TV .............................................7

Inspecting the Package Contents ......................................................7

Installing the TV ..................................................................................8

Installing the TV Stand ....................................................................8

Installing the TV on a Wall ...............................................................9

Front Panel ..........................................................................................10

Rear Panel ...........................................................................................11

Remote Control Front .........................................................................12

Replacing the Batteries ...................................................................12

Connecting Your Devices .............................................13

Connecting A Device ...........................................................................13

Connecting A Device - Audio & Video Cable Types...........................14

Connecting an Audio Device ..............................................................15

Connecting An Audio Device - Audio Cable Types ............................16

Connecting an Audio Device - ARC ....................................................17

Connecting to Your Network..............................................................18

Completing The First-Time Setup ...............................19

Using the On-Screen Menu .........................................22

Navigating the On-Screen Menu ........................................................22

Changing the Input Source ................................................................22

Changing the Screen Aspect Ratio .....................................................23

Viewing Video with the Menu Open ..................................................24

Adjusting the Picture Settings ............................................................25

Adjusting More Picture Settings .....................................................26

Adjusting the Color Temperature ...................................................26

Adjusting the Picture Mode Edit Settings ......................................27

Saving a Custom Picture Mode .......................................................27

Locking/Unlocking a Custom Picture Mode ...................................27

Deleting a Custom Picture Mode ....................................................28

Resetting a Picture Mode ................................................................28

Adjusting the Color Tuner Settings ................................................29

Adjusting the Audio Settings ..............................................................31

Changing the Equalizer Settings .....................................................31

Deleting the Custom Audio Mode ..................................................32

Setting Timers .....................................................................................33

Setting the Sleep Timer ...................................................................33

6HWWLQJWKH$XWR3RZHU2΍)HDWXUH ...............................................33

Enabling the Screen Saver ..............................................................33

Blanking the Screen .........................................................................33

Using the Network Connection Menu ...............................................34

Connecting to a Wireless Network .................................................34

Changing the Manual Setup Settings .............................................34

Finding MAC Addresses for Network Setup ...................................34

Connecting to a Hidden Network ...................................................35

Setting Up Channels ...........................................................................36

Selecting a Channel Source .............................................................36

Scanning for Channels ....................................................................36

Adding New Channels .....................................................................36

Skipping Channels ...........................................................................37

Listening to Alternate Audio ..............................................................38

Changing the Analog Audio Language ...........................................38

Setting Up Closed Captioning ............................................................39

Changing the Appearance of Digital Closed Captions ..................39

Renaming Devices on the Input Menu ..............................................41

Changing the TV Settings ...................................................................42

Viewing System Information ...........................................................42

Changing the On-Screen Menu Language .....................................42

Setting the Time and Local Settings ...............................................43

Using the Parental Controls ............................................................43

Accessing the Parental Controls Menu ..........................................43

Enabling or Disabling Program Ratings .........................................43

Locking and Unlocking Channels ....................................................43

Blocking and Unblocking Content by Rating .................................44

Changing the Parental Control PIN ................................................44

Resetting the Content Locks ...........................................................44

Changing the View Mode Settings ..................................................44

Changing the DLNA Name of Your TV ............................................45

Adjusting the CEC Settings ..............................................................45

7XUQLQJWKH3RZHUΖQGLFDWRU2QRU2΍ ..........................................45

Using the Reset & Admin Menu .........................................................46

Restoring the TV to Factory Default Settings .................................46

Enabling and Disabling Smart Interactivity ....................................46

Using the Guided Setup Menu ........................................................47

Using the Info Window .......................................................................47

Using the USB Media Player ........................................48

Preparing Your USB Drive to Play USB Media ...............................48

Playing USB Media ...........................................................................48

Removing the USB Drive from the TV ............................................48

Using VIZIO Internet Apps Plus

(V.I.A. Plus) .............52

Using the Fullscreen V.I.A. Apps Window ..........................................53

Fullscreen V.I.A. Plus Apps Window Overview ..................................54

Customizing the V.I.A. Plus Apps Window ........................................55

Adding an App to the My Apps Tab ................................................55

Deleting an App from the My Apps Tab .........................................55

Moving an App in My Apps .............................................................55

Troubleshooting & Technical Support ........................57

6SHFLȴFDWLRQV ...............................................................61

Regulatory Information ...............................................62

Limited Warranty .........................................................63

Mexico Limited Warranty ............................................65

Legal Information.........................................................67

6DIHW\&HUWLȴFDWLRQ

iii

THANK YOU FOR CHOOSING VIZIO

And congratulations on your new VIZIO HDTV.

To get the most out of your new VIZIO product, read these

instructions before using your product and retain them for future

reference. Be sure to inspect the package contents to ensure there

are no missing or damaged parts.

PRODUCT REGISTRATION

To purchase or inquire about accessories and installation services

for your VIZIO product, visit our website at www.VIZIO.com or call

toll free at (877) 698-4946.

We recommend that you register your VIZIO product at

www.VIZIO.com

Extended Warranties

For peace of mind, and to protect your investment beyond the

VWDQGDUGZDUUDQW\9Ζ=Ζ2R΍HUVRQVLWHH[WHQGHGZDUUDQW\VHUYLFH

plans. These plans provide additional coverage during the standard

ZDUUDQW\ SHULRG7RSXUFKDVHDQH[WHQGHGZDUUDQW\ VHUYLFHSODQ

visit www.VIZIO.com.

WHEN READING THIS MANUAL

When you see this symbol, please read the

accompanying important warning or notice. It is

intended to alert you to the presence of important

operating instructions.

IMPORTANT SAFETY INSTRUCTIONS

<RXU 79 LV GHVLJQHGDQG PDQXIDFWXUHG WR RSHUDWH ZLWKLQ GHȴQHG

GHVLJQOLPLWV0LVXVHPD\UHVXOWLQHOHFWULFVKRFNRUȴUH7RSUHYHQW

your TV from being damaged, the following instructions should be

observed for the installation, use, and maintenance of your TV.

Read the following safety instructions before operating your TV.

Keep these instructions in a safe place for future reference.

• To reduce the risk of electric shock or component damage,

VZLWFKR΍WKHSRZHUEHIRUHFRQQHFWLQJRWKHUFRPSRQHQWV

to your TV.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat

UHJLVWHUVVWRYHVRURWKHUDSSDUDWXVLQFOXGLQJDPSOLȴHUV

that produce heat.

• Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the

third prong are provided for your safety. If the provided

SOXJGRHVQRWȴWLQWR\RXURXWOHWFRQVXOWDQHOHFWULFLDQIRU

replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point

ZKHUHWKH\H[LWIURPWKHDSSDUDWXV

• 2QO\XVHDWWDFKPHQWVDFFHVVRULHVVSHFLȴHGE\WKH

manufacturer.

• Use only with the cart, stand, tripod, bracket,

RU WDEOH VSHFLȴHG E\ WKH PDQXIDFWXUHU RU

sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when

unused for long periods of time.

• 5HIHUDOOVHUYLFLQJWRTXDOLȴHGVHUYLFHSHUVRQQHO6HUYLFLQJ

is required when the apparatus has been damaged in any

way, such as the power-supply cord or plug is damaged,

liquid has been spilled or objects have fallen into the

DSSDUDWXVWKHDSSDUDWXVKDVEHHQH[SRVHGWRUDLQRU

moisture, does not operate normally, or has been dropped.

• Unplug the power cord before cleaning your TV.

• When moving your TV from an area of low temperature to

an area of high temperature, condensation may form in the

housing. Wait before turning on your TV to avoid causing

ȴUHHOHFWULFVKRFNRUFRPSRQHQWGDPDJH

• A distance of at least three feet should be maintained

between your TV and any heat source, such as a radiator,

KHDWHURYHQDPSOLȴHUHWF'RQRWLQVWDOO\RXU79FORVHWR

smoke. Operating your TV close to smoke or moisture may

FDXVHȴUHRUHOHFWULFVKRFN

• 6ORWVDQGRSHQLQJVLQWKHEDFNDQGERWWRPRIWKHFDELQHW

are provided for ventilation. To ensure reliable operation of

your TV and to protect it from overheating, be sure these

openings are not blocked or covered. Do not place your

TV in a bookcase or cabinet unless proper ventilation is

provided.

• Never push any object into the slots and openings on your

TV cabinet. Do not place any objects on the top of your TV.

'RLQJVRFRXOGVKRUWFLUFXLWSDUWVFDXVLQJDȴUHRUHOHFWULF

shock. Never spill liquids on your TV.

• Your TV should be operated only from the type of power

source indicated on the label. If you are not sure of the type

of power supplied to your home, consult your dealer or

local power company.



When you see this symbol, please read the

accompanying helpful tip.

• Do not apply pressure or throw objects at your TV. This may

compromise the integrity of the display. The manufacturer’s

warranty does not cover user abuse or improper

installations.

• 7KHSRZHUFRUGPXVWEHUHSODFHGZKHQXVLQJGL΍HUHQW

YROWDJHWKDQWKHYROWDJHVSHFLȴHG)RUPRUHLQIRUPDWLRQ

contact your dealer.

• :KHQFRQQHFWHGWRDSRZHURXWOHWSRZHULVDOZD\VȵRZLQJ

into your TV. To totally disconnect power, unplug the power

cord.

• 7KHOLJKWQLQJȵDVKZLWKDUURZKHDGV\PEROZLWKLQDQ

equilateral triangle is intended to alert the user to the

presence of un-isolated, dangerous voltage within the

LQVLGHRI\RXU79WKDWPD\EHRIVXɝFLHQWPDJQLWXGHWR

constitute a risk of electric shock to persons.

• 'RQRWRYHUORDGSRZHUVWULSVDQGH[WHQVLRQFRUGV

2YHUORDGLQJFDQUHVXOWLQȴUHRUHOHFWULFVKRFN

• The wall socket should be installed near your TV and easily

accessible.

• Only power of the marked voltage can be used for your TV.

$Q\RWKHUYROWDJHWKDQWKHVSHFLȴHGYROWDJHPD\FDXVHȴUH

or electric shock.

• Do not touch the power cord during lightning. To avoid

electric shock, avoid handling the power cord during

electrical storms.

• Unplug your TV during a lightning storm or when it will not

be used for long period of time. This will protect your TV

from damage due to power surges.

• Do not attempt to repair or service your TV yourself.

2SHQLQJRUUHPRYLQJWKHEDFNFRYHUPD\H[SRVH\RXWR

high voltages, electric shock, and other hazards. If repair

is required, contact your dealer and refer all servicing to

TXDOLȴHGVHUYLFHSHUVRQQHO

• :$51Ζ1*.HHS\RXU79DZD\IURPPRLVWXUH'RQRWH[SRVH

your TV to rain or moisture. If water penetrates into your TV,

unplug the power cord and contact your dealer. Continuous

XVHLQWKLVFDVHPD\UHVXOWLQȴUHRUHOHFWULFVKRFN

• Do not use your TV if any abnormality occurs. If any smoke

or odor becomes apparent, unplug the power cord and

contact your dealer immediately. Do not try to repair your

TV yourself.

• Avoid using dropped or damaged appliances. If your TV

is dropped and the housing is damaged, the internal

components may function abnormally. Unplug the power

cord immediately and contact your dealer for repair.

&RQWLQXHGXVHRI\RXU79PD\FDXVHȴUHRUHOHFWULFVKRFN

• Do not install your TV in an area with heavy dust or high

humidity. Operating your TV in environments with heavy

GXVWRUKLJKKXPLGLW\PD\FDXVHȴUHRUHOHFWULFVKRFN

• Follow instructions for moving your TV. Ensure that the

power cord and any other cables are unplugged before

moving your TV.

• When unplugging your TV, hold the AC/DC power adapter,

not the cord. Pulling on the power cord may damage the

ZLUHVLQVLGHWKHFRUGDQGFDXVHȴUHRUHOHFWULFVKRFN:KHQ

\RXU79ZLOOQRWEHXVHGIRUDQH[WHQGHGSHULRGRIWLPH

unplug the power cord.

• To reduce risk of electric shock, do not touch the connector

with wet hands.

• Insert batteries in accordance with instructions. Incorrect

polarities may cause the batteries to leak which can

damage the remote control or injure the operator. Do not

H[SRVHEDWWHULHVWRH[FHVVLYHKHDWVXFKDVVXQVKLQHȴUHRU

the like.

• If any of the following occurs, contact the dealer:

- The power cord fails or frays.

- Liquid sprays or any object drops into your TV.

<RXU79LVH[SRVHGWRUDLQRURWKHUPRLVWXUH

- Your TV is dropped or damaged in any way.

- The performance of your TV changes substantially.

• 7KLVDSSDUDWXVVKDOOQRWEHH[SRVHGWRGULSSLQJRU

VSODVKLQJDQGQRREMHFWVȴOOHGZLWKOLTXLGVVXFKDVYDVHV

shall be placed on the apparatus.

• The mains plug or appliance coupler is used as the

disconnect device, the disconnect device shall remain

readily operable.

• CAUTION - These servicing instructions are for use by

TXDOLȴHGVHUYLFHSHUVRQQHORQO\7RUHGXFHWKHULVNRI

electric shock, do not perform any servicing other than

that contained in the operating instructions unless you are

TXDOLȴHGWRGRVR

• TKHOLJKWQLQJȵDVKZLWKDUURZKHDGV\PEROZLWKLQDQ

equilateral triangle is intended to alert the user to the

SUHVHQFHRIXQLQVXODWHG'$1*(528692/7$*(ZLWKLQWKH

SURGXFWȇVHQFORVXUHWKDWPD\EHRIVXɝFLHQWPDJQLWXGHWR

constitute a risk of electrical shock to persons.

• :$51Ζ1*([SRVXUHWRORXGVRXQGVFDQGDPDJH\RXU

hearing causing hearing loss and tinnitus (ringing or

EX]]LQJLQWKHHDUVbZLWKFRQWLQXHGH[SRVXUHWRbORXG

noises, ears may become accustomed to the sound level,

which may result in permanent damage to hearing without

any noticeable discomfort.

• Install the TV where it cannot be pulled, pushed or knocked

over.

• Do not allow children to hang onto the product.

• 6WRUHWKHDFFHVVRULHVUHPRWHEDWWHULHVHWFLQDORFDWLRQ

safely out of the reach of children.

• The American Academy of Pediatrics discourages television

viewing for children younger than two years of age.

Ground Clamp

Antenna Lead In Wire

Antenna Discharge Unit

1(&6HFWLRQ

Grounding Conductors

1(&6HFWLRQ

Ground Clamps

3RZHU6HUYLFH*URXQGLQJ(OHFWURGH6\VWHP

1(&$57SDUW+

(OHFWULF6HUYLFH(TXLSPHQW

TELEVISION ANTENNA CONNECTION

PROTECTION

If an outside antenna/satellite dish or cable system is to be

connected to the TV, make sure that the antenna or cable system

is electrically grounded to provide some protection against voltage

surges and static charges.

$UWLFOHRIWKH1DWLRQDO(OHFWULFDO&RGH$16Ζ1)36$SURYLGHV

information with regard to proper grounding of the mast and

supporting structure, grounding of the lead-in wire to an antenna

discharge unit, size of the grounding conductors, location of

antenna discharge unit, connection to grounding electrodes, and

requirements of the grounding electrode.

Lightning Protection

For added protection of the TV during a lightning storm or when it

is left unattended or unused for long periods of time, unplug the TV

from the wall outlet and disconnect the antenna or cable system.

Power Lines

Do not locate the antenna near overhead light or power circuits, or

where it could fall into such power lines or circuits. Remember, the

VFUHHQRIWKHFRD[LDOFDEOHLVLQWHQGHGWREHFRQQHFWHGWRHDUWKLQ

the building installation.

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of Dolby

Laboratories.

+'0Ζ WKH +'0Ζ ORJR DQG +LJK'HȴQLWLRQ 0XOWLPHGLD

Interface are trademarks or registered trademarks of

HDMI Licensing LLC.

)RU'76SDWHQWVVHHKWWSSDWHQWVGWVFRP

0DQXIDFWXUHGXQGHUOLFHQVHIURP'76/LFHQVLQJ/LPLWHG

'76 WKH 6\PERO  '76 DQG WKH 6\PERO WRJHWKHU DUH

UHJLVWHUHG WUDGHPDUNV DQG '76 6WXGLR 6RXQG LV D

WUDGHPDUNRI'76ΖQFk'76ΖQF$OO5LJKWV5HVHUYHG

7KLV SURGXFW TXDOLȴHV IRU (1(5*< 67$5 LQ WKH ȊIDFWRU\

default” settings ans this is the setting in which power

savings will be achieved. Changing the factory default

picture settings or enabling other features will increase

SRZHUFRQVXPSWLRQWKDWFRXOGH[FHHGWKHOLPLWVQHFHVVDU\

WRTXDOLI\IRU(1(5*<67$5UDWLQJ)RUPRUHLQIRUPDWLRQ

RQWKH(1(5*<67$5SURJUDPUHIHUWRHQHUJ\VWDUJRY

INSPECTING THE PACKAGE CONTENTS

Before installing your new TV, take a moment to inspect the package

contents. Use the images below to ensure nothing is missing or

damaged.

Getting to Know Your TV

PACKAGE CONTENTS

Power CordVIZIO LED HDTV Remote Control

with Batteries

2 x Quick Start Guides

(1 English, 1 French-Spanish)

4 x M4 Phillips

Screws

TV Stands

INSTALLING THE TV

After removing the TV from the box and inspecting the package

contents you can begin installing the TV. Your TV can be installed in

two ways:

• 2QDȵDWVXUIDFHXVLQJWKHLQFOXGHGVWDQG

• On a wall, using a VESA-standard wall mount (not included)

Installing the TV Stand

Your TV includes a stand designed to support the weight of the TV

and keep it from falling over. However, the TV can still fall over if:

• It is placed on an uneven, unstable, or non-level surface

• It is pushed, pulled, or otherwise improperly moved

• If an earthquake occurs and the TV is not properly secured

3ODFHWKH79VFUHHQGRZQRQDFOHDQȵDWVXUIDFH7RSUHYHQW

scratches or damage to the screen, place the TV on a soft surface,

such as carpet, rug, or blanket.

To install the stands:

1. Insert the stands into the base of the TV.

2. Secure each stand to the TV with two (2) Phillips screws (included).

Insert the screws into the back of the TV and tighten them using a

Phillips screwdriver.

3. :KHQ\RXDUHȴQLVKHGSODFHWKH79RQDVWDEOHOHYHOVXUIDFH

It is recommended that two people take part in the

base installation.

Note:b7KHLPDJHVKRZQKHUHLVIRULOOXVWUDWLYHSXUSRVHVRQO\DQGPD\EHVXEMHFWWRFKDQJHb

The actual number of ports and their locations may vary, depending on the model.

Installing the TV on a Wall

To mount your TV on a wall, you will need a wall mount. Consult the

LQIRUPDWLRQEHORZWRȴQGWKHDSSURSULDWHPRXQWIRU\RXU79PRGHO

Be sure the mount you choose is capable of supporting the weight of

the TV. After you have determined that you have the correct mount

for your TV, you can begin the installation.

To install your TV on a wall:

1. Disconnect any cables connected to your TV.

2. 3ODFHWKH79IDFHGRZQRQDFOHDQȵDWVWDEOHVXUIDFH%HVXUH

the surface is clear of debris that can scratch or damage the TV.

3. Remove the stands by loosening and removing

the screws.

4. Attach your TV and wall mount to the wall, carefully following the

instructions that came with your mount. Use only with a UL-listed

wall mount bracket rated for the weight/load of this TV.

For some wall mounts, you may want to use cables

with right-angle connectors. This allows the TV to rest

closer to the wall.

WALL-MOUNT SCREW LOCATIONS

D39h-D0

Screw Size: M4

Hole Pattern: 100mm (V) x 100mm (H)

Weight w/o

Stand:

14.55 lbs

Installing a TV on a wall requires lifting. To prevent

LQMXU\RUGDPDJHWRWKH79DVNVRPHRQHWRKHOS\RX

FRONT PANEL

REMOTE SENSOR & POWER INDICATOR

When using the remote, aim it directly at this sensor.

7KHSRZHULQGLFDWRUȵDVKHVRQZKHQWKH79WXUQVRQWKHQJRHVRXWDIWHUVHYHUDOVHFRQGV

To keep the power indicator on as long as the TV is on, see

7XUQLQJWKH3RZHUΖQGLFDWRU2QRU2΍RQSDJH

REAR PANEL

Ethernet - Connect an Ethernet cable from home network.

Coaxial - Connect a coaxial cable from cable, satellite, or antenna.

Optical Audio Out - Connect an optical/SPDIF audio device, such as home audio receiver.

Stereo Audio Out - Connect an RCA audio device, such as sound bar.

Component/Composite - Connect a component or composite device.

USB - Connect a USB thumb drive to play photo, music, or video.

HDMI - Connect an HDMI device.

Power3UHVVWRWXUQRQWKH793UHVVDQGKROGWRWXUQWKH79R΍

Input - Press once to access the input menu.

Note:b7KHLPDJHVKRZQKHUHLVIRULOOXVWUDWLYHSXUSRVHVRQO\DQGPD\EHVXEMHFWWRFKDQJHb

The actual number of ports and their locations may vary, depending on the model.

REMOTE CONTROL

APP LAUNCHER

Quickly launch the pictured App.

INPUT

Change the currently

displayed input.

NUMBER PAD

Manually enter a channel.

WIDE

Change the display mode.

ARROW

Navigate the on-screen menu.

POWER

7XUQ792QRU2΍

INFO

Display the info window.

Display the on-screen menu.

GUIDE

Display the info window.

PIC

Opens the Picture Mode menu.

V BUTTON

Open the VIZIO Internet Apps

Plus

(V.I.A. Plus) dock.

CHANNEL UP/DOWN

Change the channel.

LAST

Return to the channel last viewed.

DASH

Use with number pad to manually

enter a digital sub-channel.

(For example, 18-4 or 18-5.)

ENTER

&RQȴUPFKDQQHORUSDVVFRGH

entered using the Number Pad.

A/V CONTROLS

Control the USB media player and

streaming video playback.

CLOSED CAPTIONS

7XUQFORVHGFDSWLRQV2QDQG2΍

EXIT

Close the on-screen menu.

VOLUME UP/DOWN

Increase or decrease loudness

of the audio.

Select the highlighted option.

BACK

Go to the previous on-screen menu.

MUTE

7XUQWKHDXGLRR΍RURQ

Replacing the Batteries

1. Remove the battery cover by pressing down on the arrow

markings and sliding out.

2. Insert two batteries into the remote control. Make sure that

the (+) and (-) symbols on the batteries match the (+) and (-)

symbols inside the battery compartment.

3. Replace the battery cover.

2Connecting Your Devices

CONNECTING A DEVICE

Your TV can be used to display output from most devices.

1. Verify that your device has a video port that matches an

available port on the TV (HDMI, Component, etc.).

2. 7XUQWKH79DQG\RXUGHYLFHR΍

3. Connect the appropriate cable (not included) to the TV and the

device.

4. Turn the TV and your device on. Set the TV’s input to match the

connection you used (HDMI-1, HDMI-2, etc.).

GOOD

AV CABLE

• ANALOG

• SD VIDEO (480i)

• STEREO AUDIO

BETTER

COAXIAL CABLE

• ANALOG/DIGITAL

• HD VIDEO (1080i)

• STEREO/HD AUDIO

BEST

HDMI (HDMI 1-2)

• DIGITAL

• HD VIDEO (1080p)

• HD AUDIO

BETTER

COMPONENT CABLE

• ANALOG

• HD VIDEO (1080p)

• STEREO AUDIO

Maximum Resolution

* Recommended for use with high-performance devices only

Note:

7KHLPDJHVKRZQKHUHLVIRULOOXVWUDWLYHSXUSRVHVRQO\DQGPD\EHVXEMHFWWRFKDQJHb

The actual number of ports and their locations may vary, depending on the model.

CONNECTING A DEVICE - AUDIO & VIDEO CABLE TYPES

AV CABLE

AV cables (or Composite cables) are the

traditional way of connecting your devices to

your TV. Video signals are sent over the yellow

connector while audio is sent over the red and

white connectors.

• Video Resolutions up to 480i

• Analog Connection

• Audio and Video Signals

GOOD

Y/V L R

COAXIAL CABLE

Coaxial cables are the traditional way of

connecting antennas and cable television

signals to your TV. Coaxial cables carry both

audio and video signals through a single

connector.

• HD Video Resolutions up to 1080i

• Analog Connection

• Audio and Video Signals

BETTER

Coaxial

COMPONENT CABLE

Component cables are designed to carry high

GHȴQLWLRQ YLGHR VLJQDOV DORQJ ZLWK DGGLWLRQDO

audio connections. Colors are delivered with color

LQIRUPDWLRQ VSOLW XS WKUHH GL΍HUHQW ZD\V RYHU

three connectors for video (separated into Red,

Blue and Green signals) and the left and right

audio connectors (Red and White).

• HD Video Resolutions up to 1080p

• Analog Connection

• Audio and Video Signals

HDMI CABLE

HDMI is the intelligent, all-digital interface that

delivers both dazzling quality and unmatched ease

of use. HDMI technology transmits crystal-clear

digital video along with multi-channel surround

audio. HDMI-connected devices have the ability

to automatically adjust themselves for optimal

viewing.

• HD Video Resolutions up to 1080p

• HD Audio

• Digital Connection

• Audio and Video Signals

BETTER

R L Pr/Cr Pb/Cb Y

HDMI

BEST

CONNECTING AN AUDIO DEVICE

Your TV can output sound to an audio device, such as a receiver or

sound bar.

1. Verify that your device has an audio port that matches an

available port on the TV (Optical, RCA, or HDMI).

2. 7XUQWKH79DQG\RXUDXGLRGHYLFHR΍

3. Connect the appropriate cable (not included) to the TV and the

device.

4. Turn the TV and your device on.

Home Audio Receiver VIZIO Sound Bar

BEST

HDMI CABLE

• ARC 2-WAY COMMUNICATION

• 2.0-5.1 DIGITAL AUDIO

• PCM, DTS, DOLBY DIGITAL

BETTER

OPTICAL/SPDIF CABLE

• PCM STREAM

• DOLBY DIGITAL 5.1 CHANNEL

• DTS 5.1 CHANNEL

Note:

7KHLPDJHVKRZQKHUHLVIRULOOXVWUDWLYHSXUSRVHVRQO\DQGPD\EHVXEMHFWWRFKDQJHb

The actual number of ports and their locations may vary, depending on the model.

GOOD

RCA CABLE

• ANALOG STEREO CONNECTION

• 2.0 CHANNEL

CONNECTING AN AUDIO DEVICE - AUDIO CABLE TYPES

RCA CABLE

RCA cables (or Composite cables) are the

traditional way of connecting your devices to your

audio device. Audio signals are sent over the red

and white connectors.

• Quality Stereo Connection

• 2.0 Channel

• Analog Connection

• Audio Signal Only

OPTICAL/SPDIF CABLE

Optical/SPDIF cables transmit audio signals as

pulses of light through a cable made of plastic

ȴEHUV $XGLR VLJQDOV DUH GLJLWDOO\ WUDQVPLWWHG

between devices.

• PCM Stream (Lossless)

• Dolby Digital 5.1 Channel

• DTS 5.1 Channel

• Digital Connection

• Audio Signal Only

HDMI CABLE

HDMI technology transmits crystal-clear digital

multi-channel surround audio through a single

HDMI cable. Audio Return Channel-enabled

(ARC) TVs allow audio to be sent over an already

connected HDMI cable, eliminating the need for

a separate audio cable. See Connecting an Audio

Device - ARC on page 17.

• ARC 2-way Communication

(Auto setup)

• PCM, DTS, Dolby Digital

• 2.0 - 5.1 Scaleable Lossless

Digital Audio Connection

• Audio and Video Signals

GOOD

L R

BETTER

Optical/SPDIF

BEST

HDMI

CONNECTING AN AUDIO DEVICE - ARC

Your Home Audio Receiver

Without HDMI ARC

Without an HDMI ARC setup, your TV will transmit audio signal

from the built-in tuner and VIA apps to your home audio receiver

through a separate audio connection.

HDMI Cable

Your Blu-Ray Player

RCA (Audio)

Your Home Audio Receiver

With HDMI ARC

With an HDMI ARC setup, the audio connection between your

TV and Home Audio Receiver can be removed. The HDMI cable

will transmit audio signal to and from your TV with an all-digital

audio/video connection.

HDMI Cable

Your Blu-Ray Player

VIZIO Internet Apps Plus®

Built-In Tuner

VIZIO Internet Apps Plus®

Built-In Tuner

Your TV

CONNECTING TO YOUR NETWORK

Your TV is Internet-ready. It can be connected to your home network

with a Wired or Wireless connection.

Connecting to a Wired Network (Best)

1. Connect an Ethernet cable to your router and to the Ethernet

port on the back of the TV. See below.

2. 8VHWKH*XLGHG1HWZRUN6HWXSWRFRQȴJXUHWKH796HH

Using

Guided Setup on page 48

Connecting to a Wireless Network

1. Ensure you have a router or modem broadcasting as

high-speed wireless signal (802.11n recommended).

2. 8VHWKH*XLGHG1HWZRUN6HWXSWRFRQȴJXUHWKH796HH

Using

Guided Setup on page 48.

Router / ModemEthernet Cable

Note:

7KHLPDJHVKRZQKHUHLVIRULOOXVWUDWLYHSXUSRVHVRQO\DQGPD\EHVXEMHFWWRFKDQJHb

The actual number of ports and their locations may vary, depending on the model.

3Completing The First-Time Setup

The first time you turn on the TV, the Setup App will guide

you through each of the steps necessary to get your TV

ready for use.

Before you begin the first-time setup:

• Your TV should be installed and the power cord

should be connected to an electrical outlet.

• Your devices should be connected.

• If you have a wireless network, have the network

password ready.

• If you are connecting to your network with an

Ethernet cable, connect it to the Ethernet port on

the TV.

Choose your mode.

Select Store Demo for in-store display.

Select Home Use for in-home use.

Seleccione "Home Use" para Modo de Casa o "Store Demo" para Demostración en la Tienda.

Choisissez "Home Use" pour le Mode Domicile ou "Store Demo" pour la Démo en Magasin.

Store Demo Home Use

Press the Power button on the remote. The TV

powers on and the Setup App starts.

Use the Arrow buttons on the remote to

highlight Home Use and press OK.

To complete the first-time setup:

Use the Arrow buttons on the remote to highlight

your language of preference and press OK.

Use the Arrow buttons on the remote to

highlight your country, and then press OK.

Select the name of your wireless network from the

list of available networks and press OK.

Enter the network password using the on-screen

keyboard, then highlight Connect and press OK.

Use the Arrow and OK buttons on the remote to

review the Terms Of Service and Privacy Policy.

:KHQ\RXDUHȴQLVKHGKLJKOLJKWI Accept

and press OK.

Enter your E-mail Address, First Name, Last

Name, and Zip Code using the on-screen

keyboard.

Highlight Next and press OK.

Select your time zone and press OK.

If the TV Signal channel scan screen appears, the

TV will need to scan for channels, which takes

several minutes.

Use the arrow buttons on the remote to highlight

Begin Scan and press OK.

Otherwise, use the Arrow and OK buttons on

the remote to select the input your TV source

is connected to.

:KHQ\RXDUHȴQLVKHGWKHPHVVDJH

“Setup is complete.” will appear.

The First-Time Setup is complete.

Use the Arrow buttons on the remote to highlight

your TV source and press OK.

If you have cable TV, select whether you have

a cable box or if you connect the TV directly

to a cable from the wall.

Note: Number of ports may differ by TV.

CHANGING THE INPUT SOURCE

External devices such as DVD players, Blu-ray Players, and video

game consoles can be connected to your TV. To use one of these

GHYLFHVZLWK\RXU79\RXPXVWȴUVWFKDQJHWKHLQSXWVRXUFHXVLQJ

the Input menu.

To change the input source:

1. Press the INPUT button on

the remote. The Input menu is

displayed.

2. Use the Up/Down Arrow

buttons or the INPUT button on

the remote to highlight the input

you wish to view and press OK.

The selected input is displayed.

You can change the input names that appear on the

Input menu to make your devices easy to recognize. See

Renaming Devices on the Input Menu

on page 41 for

more information.

Note: Inputs may vary by TV.

Using the On-Screen Menu

Your TV features an easy-to-use on-screen menu.

To open the on-screen menu, press the MENU button on the remote.

You can also open the on-screen menu by pressing the VIA button

and selecting HDTV Settings from the VIA Dock, then pressing OK.

From this menu, you can:

• Adjust the Picture settings

• Adjust the Audio settings

• Setting the Sleep Timers

• Adjust the Network settings

• Adjust the Channel settings

• Set up Closed Captioning

• Name Inputs

• Adjust TV settings

• Access the Guided Setup

• View the User Manual

VIZIO

TV SETTINGS


Audio

Timers

Network

Channels

Closed Captions

Devices

System

Guided Setup

User Manual

NAVIGATING THE ON-SCREEN MENU

To open the on-screen menu, press

the MENU button on the remote.

Use the Arrow buttons to highlight

a menu option, and press the OK

button to select that option.

While navigating the on-screen menu, you can

press the BACK button at any time to return to the

previous menu screen. The EXIT button will close the

on-screen menu.

COMP

HDMI-1

HDMI-2

HDMI-4

Input Name

HDMI-3

HDMI-5

CHANGING THE SCREEN ASPECT RATIO

7KH 79 FDQ GLVSOD\ LPDJHV LQ IRXU GL΍HUHQW PRGHV 1RUPDO

Panoramic, Wide, and Zoom. Each mode displays the picture

GL΍HUHQWO\

Some programs have black bars on the top or sides of the picture

so that the picture keeps its original shape. Examples include

wide-screen movies and older television programs.

To change the screen aspect ratio:

1. Press the WIDE button on the

remote.

2. Use the Arrow buttons to

highlight the aspect ratio you

wish to view and press OK.

• Normal preserves the content’s

original aspect ratio and size.

• 6WDQGDUG'HȴQLWLRQ (480i and

480p—old TV programs) - Since

the 4:3 aspect ratio is not large

HQRXJKWRȴOOWKH79ȇVVFUHHQ

black bars are added to the left

and right of the display image.

• SDQGL+' - Fills a 720p or 1080p screen.

• SDQGL+' - Fills a 720p or 1080p screen.

• 3DQRUDPLF stretches a 4:3 aspect ratio picture to the left

and right edges of the screen. The center of the image is

not stretched, but the sides of the image are extremely

stretched. If you are watching widescreen (1.85:1 or 2.35:1)

content with black bars on the top and bottom, the black

bars will still appear on the top and bottom of the display

image.

• 6WDQGDUG'HȴQLWLRQ (480i and 480p) - Fills the screen

from the left to right edges.

• SDQGL - Not available.

• SDQGL - Not available.

Panoramic

Wide

Zoom

Normal

Stretch

Wide

Zoom

Normal

Note: Aspect ratio settings may

vary by Input source.

• :LGH stretches a 4:3 aspect ratio picture to the edges of

the screen. Since the picture is being stretched, the display

LPDJHPD\DSSHDUGLVWRUWHGȃȴJXUHVDSSHDUVKRUWDQGIDW

If the program is already formatted for widescreen viewing

(1.85:1 or 2.35:1), then black bars will appear on the top

and bottom of the display image.

• Zoom expands images evenly in all directions (33% taller

DQGZLGHUZLWKEODFNEDUVWRȴWWKHVFUHHQ$S

LPDJHZLOOȴOODSVFUHHQ

• 6WDQGDUG'HȴQLWLRQ - Not available.

• SDQGL+' - Fills a 1080p screen

• SDQGL - Not available.

VIEWING VIDEO WITH THE MENU OPEN

When the on-screen menu opens, it covers the left-hand portion of

WKHSLFWXUH7KHSLFWXUHFDQEHGLVSOD\HGLQWKUHHGL΍HUHQWZD\V

• Viewport7KHHQWLUHSLFWXUHLVUHVL]HGWRȴWLQWRWKHVSDFH

to the right of the menu

• Overlay - The picture stays in its normal postion and the

menu covers the left-hand portion of the picture. (The picture

is full-sized)

• Centered Overlay - The picture is full-sized and centered in

the area next to the menu, so that the right and left edges

DUHFXWR΍

To change the position of the picture while the on-screen menu is

displayed:

1. Use the Arrow buttons on the

remote to highlight

Resize

Video.

2. Press OK to cycle through the

three display methods.

3. Press the Up Arrow button on

the remote to the menu.

VIZIO


Picture Mode Standard

Auto Brightness Control Medium

Backlight 85

Brightness 50

Contrast 50

Color 59

Tint 0

Sharpness 9

More Picture

Picture Mode EDIT

Color Calibration

CENTERED OVERLAY

OVERLAY

VIZIO

VIEWPORT


Picture Mode Standard

Auto Brightness Control Off

Backlight 85

Brightness 50

Contrast 50

Color 59

Tint 0

Sharpness 9

More Picture

Picture Mode Edit

Color Calibration

VIZIO


Picture Mode Standard

Auto Brightness Control Off

Backlight 85

Brightness 50

Contrast 50

Color 59

Tint 0

Sharpness 9

More Picture

Picture Mode Edit

Color Calibration


Picture Mode Standard

Auto Brightness Control Off

Backlight 85

Brightness 50

Contrast 50

Color 59

Tint 0

Sharpness 9

More Picture

Picture Mode Edit

Color Calibration

3. Use the Arrow buttons on the

remote to highlight Picture

Mode, then use the Left/Right

Arrow buttons to change the

picture mode:

• Standard mode sets the

picture settings to the

default settings.

• Calibrated mode sets the

picture settings to values

ideal for watching TV in a

brightly-lit room.

• Calibrated Dark mode sets

the picture settings to values

ideal for watching TV in a

dark room.

• Vivid mode sets the picture

settings to values that

produce a brighter, more

vivid picture.

• Game mode reduces

throughput delays and

optimizes the picture settings

for displaying game console

output.

• Computer mode optimizes the picture settings for

displaying computer output.

ADJUSTING THE PICTURE SETTINGS

Your TV display can be adjusted to suit your preferences and viewing

conditions.

To adjust the picture settings:

1. Press the MENU button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight Picture and

press OK. The PICTURE menu is displayed.

If you’ve changes to the settings for a picture mode, an

asterisks appears after its name (see

Saving a Custom

Picture Mode

on page 27).

VIZIO


Picture Mode Standard

Auto Brightness Control Medium

Backlight 85

Brightness 50

Contrast 50

Color 59

Tint 0

Sharpness 9

More Picture

Picture Mode Edit

Color Calibration

4. To manually change each of the picture settings, use the Up/

Down Arrow buttons on the remote to highlight that picture

setting, then use the Left/Right Arrow buttons to adjust the

setting:

• Auto Brightness Control - The auto brightness control detects

the light levels in the room and automatically adjusts the

backlight for the best picture. Select 2΍, Low, Medium, or

High.

• Backlight$GMXVWVWKH/('EULJKWQHVVWRD΍HFWWKHRYHUDOO

brilliance of the picture. Backlight cannot be adjusted when

starting from some picture modes.

• Brightness - Adjusts the black level of the picture. When this

setting is too low, the picture may be too dark to distinguish

details. When this setting is too high, the picture may appear

faded or washed out.

• Contrast - Adjusts the white level of the picture. When this

setting is too low, the picture may appear dark. When this

setting is too high, the picture may appear faded or washed

RXWΖIWKHVHWWLQJLVWRRKLJKRUWRRORZGHWDLOPD\EHGLɝFXOW

to distinguish in dark or bright areas of the picture.

• Color - Adjusts the intensity of the picture colors.

• Tint - Adjusts the hue of the picture. This setting is useful in

DGMXVWLQJWKHȵHVKWRQHVLQWKHSLFWXUHΖIȵHVKDSSHDUVWRR

orange, reduce the level of color before adjusting tint.

• Sharpness - Adjusts the edge sharpness of picture elements.

ΖWFDQEHXVHGWRVKDUSHQQRQ+'KLJKGHȴQLWLRQFRQWHQW

however, it will not produce detail that does not otherwise

exist.

5. :KHQ\RXKDYHȴQLVKHGDGMXVWLQJWKHSLFWXUHVHWWLQJVSUHVV

the EXIT button on the remote.

Adjusting More Picture Settings

To adjust more picture settings:

1. From the PICTURE menu, use the

Arrow buttons to highlight More

Picture, and then press OK.

2. Use the Arrow buttons to

highlight the setting you wish

to adjust, then press the Left/

Right Arrow buttons to change

the setting:

• Color Temperature -

See

Adjusting the Color

Temperature on page

26this page.

• Black Detail - Adjusts the

average brightness of the

picture to compensate for

large areas of brightness.

Select 2΍, Low, Medium, or

High.

• Backlight Control -

Dynamically improves the

contrast ration og the picture

by adjusting the backlight.

Select On or 2΍.

• Reduce Noise — Opens a sub-menu with two settings:

Reduce

• Signal Noise - Diminishes artifacts in the image

caused by the digitizing of image motion content.

Select 2΍, Low, Medium, or High.

• Reduce Block Noise - Reduces pixelation and

GLVWRUWLRQIRUPSHJȴOHV6HOHFW2΍, Low, Medium,

or High.

• Game Low Latency - Select On to reduce video delay (lag)

when gaming.

• Picture Size & Position - Highlight Picture Size & Position

and press OK. The PICTURE SIZE & POSITION menu is

displayed.

• Picture Size: Increase or decrease the vertical and

horizontal size of the displayed picture. Use the Left/

Right Arrow buttons to adjust the horizontal size of the

displayed picture. Use the Up/Down Arrow buttons to

adjust the vertical size of the displayed picture. Press the

OK EXWWRQZKHQ\RXDUHȴQLVKHG

• Picture Position: Adjust the vertical and horizontal

positions of the picture to ensure the image is centered

DQGFRPSOHWHO\ȴOOVWKHVFUHHQ8VHWKHLeft/Right

Arrow buttons to adjust the horizontal position of the

displayed picture. Use the Up/Down Arrow buttons to

adjust the vertical position of the displayed picture. Press

the OK EXWWRQZKHQ\RXDUHȴQLVKHG

• Film Mode2SWLPL]HVWKHSLFWXUHIRUZDWFKLQJȴOP6HOHFW

Auto or 2΍.

• Gamma - Set the shape of the Gamma curve. Use lower

Gamma values for bright room conditions, and higher

values when it’s dark.

3. :KHQ\RXKDYHȴQLVKHGDGMXVWLQJ0RUH3LFWXUH6HWWLQJVSUHVVWKH

EXIT button on the remote.

VIZIO

MORE PICTURE

Color Temperature Cool

Black Detail Medium

Backlight Control On

Reduce Signal Noise Off

Game Low Latency Off

Picture Size & Position

Film Mode Auto

Gamma 2.1

Adjusting the Color Temperature

Adjusting the color temperature changes the white balance of the

picture.

To adjust the color temperature:

1. From the MORE PICTURE menu,

use the Arrow buttons to

highlight Color Temperature,

and then press OK.

2. Use the Arrow buttons on the

remote to highlight a color

temperature preset and then

press OK.

• Normal is optimized for

television viewing.

• Cool produces a blue-hued

picture.

• Computer optimizes the

picture for use as a

PC monitor.

3. :KHQ\RXKDYHȴQLVKHG

adusting the color temperature,

press the EXIT button on the

remote.

VIZIO

COLOR TEMPERATURE

Normal

Cool

Computer

Adjusting the Picture Mode Edit Settings

Picture Mode Edit Settings allow you to make precise adjustments

to the picture and to create picture modes to save groups of picture

settings.

To adjust the Picture Mode Edit settings:

1. From the PICTURE menu, use the

Arrow buttons to highlight Picture

Mode Edit, and then press OK.

The PICTURE MODE EDIT menu is

displayed.

2. Use the Arrow buttons to

highlight the setting you wish to

adjust, then press OK to change

the setting:

• Save Picture Mode - Save a

custom picture mode.

• Lock Picture Mode - Prevent

changes to custom picture

modes.

• Unlock Picture Mode - Allow

changes to custom picture

modes. (Available after a custom

picture mode is locked)

• Delete Picture Mode - Delete

a custom picture mode. Inputs

assigned to that custom picture

mode will be set to Calibrated

picture mode. (Available after a

custom picture mode is saved)

• Reset Picture Mode

†

- Reset

the picture mode settings to

factory default values.

VIZIO

PICTURE MODE EDIT - Vivid*

Save Picture Mode

Lock Picture Mode

Reset Picture Mode - Vivid*

* Not available on HDMI input 5.

†

Only available on customized preset modes.

‡

Only available on HDMI input.

VIZIO

PICTURE MODE EDIT - MyMode

Save Picture Mode

Unlock Picture Mode

Delete Picture Mode - MyMode

Locking/Unlocking a Custom Picture Mode

Custom picture modes can be locked/unlocked with a unique PIN to

prevent accidental changes to their settings.

To lock all custom picture modes:

1. From the PICTURE MODE EDIT

menu, use the Arrow buttons

to highlight Lock Picture

Mode, and then press OK. The

LOCK PICTURE MODE menu is

displayed.

2. Use the Number Pad on your

remote to enter a unique 4-digit

PIN.

3. Highlight Save and press OK.

4. Press the EXIT button to exit the

menu screens.

To unlock all custom picture modes:

1. From the PICTURE MODE EDIT

menu, use the Arrow buttons

to highlight Unlock Picture

Mode, and then press OK. The

UNLOCK PICTURE MODE menu

is displayed.

2. Use the Number Pad on your remote to enter your 4-digit PIN.

3. Make any desired changes to the picture modes.

4. Relock the picture modes, if desired. You must create a new

4-digit PIN.

5. Press the EXIT button to exit the menu screens.

VIZIO

LOCK PICTURE MODE

Create a picture control PIN to prevent

changes to all custom picture modes.

Save

Create a 4 digit passcode using the num-

ber keys on the remote.

Saving a Custom Picture Mode

Custom picture modes allow you to save a group of custom settings

for various viewing conditions and video sources.

• Changes made while on any preset picture mode will add an

asterisk on the top right corner of the preset mode.

• The custom picture mode is not automatically saved.

To save a custom picture mode:

1. From the PICTURE MODE EDIT

menu, use the Arrow buttons

to highlight Save Picture

Mode, and then press OK. The

SAVE PICTURE MODE menu is

displayed.

2. Use either the on-screen

keyboard or keyboard on your

remote control to enter a name

for your custom picture mode.

3. Highlight Save and press OK.

4. Press the EXIT button to exit the

menu screens.

VIZIO

SAVE PICTURE MODE

Custom1_

Save

a b c d e f g h i

j k l m n o p q r

s t u v w x y z 0

1 2 3 4 5 6 7 8 9

.@# .com Space

äêí

Deleting a Custom Picture Mode

Custom picture modes that are no longer needed can be deleted.

To delete a custom picture mode:

1. From the PICTURE MODE EDIT menu,

use the Arrow buttons to highlight

Delete Picture Mode, and then

press OK. The DELETE PICTURE

MODE window is displayed.

2. Use the Left/Right Arrow buttons to highlight Delete and press

OK.

3. Press the EXIT button to exit the menu screens.

Resetting a Picture Mode

A preset picture mode that has been edited can be restored to the

factory default settings.

To reset a customized preset picture mode:

1. From the PICTURE MODE EDIT menu,

use the Arrow buttons to highlight

Reset Picture Mode, and then

press OK. The RESET PICTURE MODE

window is displayed.

2. Use the Left/Right Arrow buttons to highlight Reset and press OK.

3. Press the EXIT button to exit the menu screens.

Inputs assigned to a deleted custom picture mode

become assigned to the

Calibrated

picture mode.

To delete the user created Custom 1 picture mode,

select the Delete button.

Delete

Cancel

Select Reset to restore Standard

picture mode to factory defaults.

Reset

Cancel

7RWXUQFRORUFKDQQHOVR΍DQGRQ

1. From the COLOR CALIBRATION menu, use the Arrow buttons

to highlight Color Tuner, and then press OK. The Color Tuner

menu is displayed.

2. Use the Arrow buttons on the remote to highlight Red, Green,

or Blue.

3. Press the OKEXWWRQWRWXUQWKHFRORUFKDQQHOR΍RURQ$Q;

DSSHDUVRYHUDFRORUFKDQQHOWKDWKDVEHHQWXUQHGR΍

4. Use the Arrow buttons to highlight another color channel to

WXUQR΍RURQ2QO\WZRFRORUFKDQQHOVFDQEHWXUQHGR΍DWWKH

same time.

5. :KHQ\RXDUHȴQLVKHGZLWKWKHFRORUFKDQQHOVSUHVVWKHEXIT

button.

Color Tuner

Red Green Blue Cyan Magenta Yellow

Hue 0 0 0 0 25 -14

Saturation -1 5 -4 0 -2 0

Brightness -24 0 -22 0 0 0

Offset 0 0 0

Gain 0 0 0

To adjust the 11 Point White Balance settings:

1. From the Color Tuner menu, use the Arrow buttons to

highlight Color Tuner, and then press the Left/Right Arrow

buttons until the 11 Point White Balance menu is displayed.

2. Use the Arrow buttons on the remote to highlight the Gain

and Color values you wish to adjust. Press the OK button and

use the Left/Right Arrow buttons to adjust the value. When

\RXDUHȴQLVKHGSUHVVWKHOK button to save the setting.

3. :KHQ\RXDUHȴQLVKHGSUHVVWKHEXIT button.

11 Point White Balance

Gain Red Green Blue

5% 0 0 0

Adjusting the Color Tuner Settings

The Color Tuner settings allow you to adjust the HSB color and 11

SRLQWZKLWHEDODQFHWXUQFRORUFKDQQHOVR΍IRUWHVWLQJDQGGLVSOD\

FRORUEDUȵDWDQGUDPSWHVWSDWWHUQV

To adjust the HSB color settings:

1. From the COLOR CALIBRATION menu, use the Arrow buttons

to highlight Color Tuner, and then press OK. The Color Tuner

menu is displayed.

2. Use the Arrow buttons on the remote to highlight the Hue,

Saturation, Brightness, 2΍VHW, or Gain of the color you wish

to adjust. Press the OK button.

3. Use the Left/Right Arrow buttons to adjust the value. When

\RXDUHȴQLVKHGSUHVVWKHOK button to save the setting.

4. :KHQ\RXDUHȴQLVKHGDGMXVWLQJWKHFRORUWXQHUVHWWLQJVSUHVV

the EXIT button.

Color Tuner

Red Green Blue Cyan Magenta Yellow

Hue 0 0 0 0 25 -14

Saturation -1 5 -4 0 -2 0

Brightness -24 0 -22 0 0 0

Offset 0 0 0

Gain 0 0 0

The Color Tuner, 11 Point White Balance, and test

patterns allow technicians to manually calibrate the TV.

Calibration requires specialized training, an input with

precisely set colors, and a specialized light meter.

To show or hide the Flat Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to

highlight Color Tuner, and then press the Left/Right Arrow

buttons until the Flat Test Pattern menu is displayed.

Flat Test Pattern

Off

2. Use the Arrow buttons on the remote to highlight 2΍. Use the

Left/Right Arrow buttons to select the percentage brightness

IRUWKHȵDWWHVWSDWWHUQSelecting a percentage immediately

VKRZVWKHȵDWSDWWHUQDWWKDWbrightness.

—or—

To disable the Flat Test Pattern, use the Left/Right Arrow

buttons to highlight 2΍.

3. :KHQ\RXDUHȴQLVKHGSUHVVWKHEXIT button.

To show or hide the Ramp Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to

highlight Color Tuner, and then press the Left/Right Arrow

buttons until the Ramp Test Pattern menu is displayed.

2. Use the Arrow buttons on the remote to highlight 2΍. Use the

Left/Right Arrow buttons to select the color for the ramp test

pattern. Selecting a color immediately shows that color ramp.

—or—

To hide the Ramp Test Pattern, use the Left/Right Arrow

buttons to highlight 2΍.

3. :KHQ\RXDUHȴQLVKHGSUHVVWKHEXIT button.

Ramp Test Pattern

Off

To show or hide the Color Bar Test Pattern:

1. From the Color Tuner menu, use the Arrow buttons to

highlight Color Tuner, and then press the Left/Right Arrow

buttons until the Color Bar Test Pattern menu is displayed.

Color Bar Test Pattern

Off

2. Use the Arrow buttons on the remote to highlight 2΍. Use the

Left/Right Arrow buttons to highlight On to show the Color

Bar Pattern.

—or—

To hide the Color Bar Test Pattern, use the Left/Right Arrow

buttons to highlight 2΍.

3. :KHQ\RXDUHȴQLVKHGSUHVVWKHEXIT button.

ADJUSTING THE AUDIO SETTINGS

To adjust the audio settings:

1. Press the MENU button on the

remote. The on-screen menu

is displayed.

2. Use the Arrow buttons on the

remote to highlight Audio and

press OK. The AUDIO menu

is displayed.

3. Use the Arrow buttons to

highlight the setting you wish

to adjust, then press Left/

Right Arrow buttons to change

the setting:

• TV Speakers - Turns the

EXLOWLQVSHDNHUV2QRU2΍

• Surround Sound - Surround sound uses DTS TruSurround

™

to deliver an immersive surround sound experience from

the TV’s internal speakers. TruSurround completes the

entertainment experience by providing deep, rich bass and

by delivering crisp details and clear, intelligible dialog. Select

On or 2΍.

• Volume Leveling - Volume leveling uses DTS TruVolume

™

to maintain consistent volume levels during transitions

between program content, AV formats, and input sources.

Select On or 2΍. In a few cases, volume leveling may

DUWLȴFLDOO\ VXSSUHVV YROXPH LQFUHDVHVPDNLQJ LW GLɝFXOW WR

KHDU GLDORJ RUȵDWWHQLQJVXGGHQQRLVHV ΖI WKLVRFFXUVWXUQ

YROXPHOHYHOLQJR΍

• Balance - Adjusts the loudness of the audio output from the

left and right speakers.

VIZIO

AUDIO

TV Speakers On

Surround Sound On

Volume Leveling On

Balance 0

Lip Sync 0

Digital Audio Out PCM

Analog Audio Out Fixed

Equalizer

Delete Audio Mode

When the TV speakers are set to On, DTS signals

cannot be passed through digital audio outputs.

• Lip Sync - Adjusts the synchronization between the display

image and the accompanying audio track.

• Digital Audio Out - Changes the type of processing for

digital audio out and HDMI ARC output when connected to a

home theater audio system. Select PCM or Bitstream.

• Analog Audio Out - Sets the volume control properties for

the RCA connector when connected to a home theater audio

system. Select Variable if you are controlling the volume with

the TV’s volume controls, or select Fixed if an external audio

device (sound bar or AV receiver) will control the volume.

• Equalizer  $GMXVWV WKH ERRVW RU DWWHQXDWLRQ RI GL΍HUHQW

frequencies using either preset or custom settings. See

Changing the Equalizer Settings on page 31

• Delete Audio Mode - Deletes a custom audio mode created

using the Equalizer Settings. See

Deleting the Custom Audio

Mode on page 32.

4. :KHQ\RXKDYHȴQLVKHGDGMXVWLQJWKHDXGLRVHWWLQJVSUHVVWKH

EXIT button on the remote.

You must select Bitstream for audio with more than

two channels (3.0, 5.0, or 5.1, for example).

Changing the Equalizer Settings

The graphic equalizer has several pre-set modes and allows you to

create one custom mode.

To select a pre-set audio mode:

1. Press the MENU button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight Audio and

press OK. The AUDIO menu is displayed.

3. Use the Arrow buttons to highlight Equalizer and press OK. The

Audio Mode and equalizer settings screen appears.

4. Use the Left and Right Arrow buttons to select an audio mode.

7KHHTXDOL]HUEDUVFKDQJHWRUHȵHFWWKHPRGH

5. Press the EXIT button on the remote.

To create, modify, or replace the single custom equalizer setting:

1. Press the MENU button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight Audio and

press OK. The AUDIO menu is displayed.

3. Use the Arrow buttons to highlight Equalizer and press OK. The

Audio Mode and equalizer settings screen appears.

4. Use the Left and Right Arrow buttons to select any audio mode

as a starting point.

5. Use the Arrow buttons to highlight a frequency and then press

OK.

6. Use the Up and Down Arrow buttons to adjust the boost (up)

and attenuation (down) for the frequency.

7. Use the Left and Right Arrow buttons to select another

frequency, if desired, and adjust it.

8. Press the EXIT button on the remote.

Deleting the Custom Audio Mode

To delete the custom audio mode that has been created:

1. Press the MENU button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight Audio and

press OK. The AUDIO menu is displayed.

3. Use the Arrow buttons to highlight Delete Audio Mode and

press OK. The TV displays, “To delete the user created custom

audio mode, select the Delete button.”

4. Highlight Delete and press OK.

5. Press the EXIT button on the remote.

SETTING TIMERS

Setting the Sleep Timer

:KHQDFWLYDWHGWKH79ȇVVOHHSWLPHUZLOOWXUQWKH79R΍DIWHUDVHW

period of time.

1. Press the MENU button on the

remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the

remote to highlight Timers and

press OK. The TIMERS menu is

displayed.

3. Use the Left/Right Arrow

buttons on the remote to

highlight the period of time after

which you want the TV to go to

sleep: 30, 60, 90, 120, or 180

minutes. If you don’t want the

sleep timer to activate, change

the setting to 2΍.

4. :KHQ\RXKDYHȴQLVKHGVHWWLQJ

the sleep timer, press the EXIT

button on the remote.

VIZIO

TIMERS

Sleep Timer Off

Auto Power Off 10 minutes

Screen Saver Off

Blank Screen

6HWWLQJWKH$XWR3RZHU2΍)HDWXUH

7R KHOS VDYH HQHUJ\ \RXU 79 LV VHW E\ GHIDXOW WR WXUQ R΍ DIWHU

10 minutes without a video or audio signal. This feature can be

deactivated.

7RVHWWKH$XWR3RZHU2΍IHDWXUH

1. From the TIMERS menu, use the Up/Down Arrow buttons on

the remote to highlight $XWR3RZHU2΍.

2. Use the Left/Right Arrow buttons on the remote to change

ZKHWKHUWKH79ZLOOWXUQR΍ ΖI\RXGRQȇWZDQWWKH79WRWXUQR΍

when there is no signal, change the setting to 2΍. Otherwise,

select 10 minutes.

3. :KHQ\RXKDYHȴQLVKHGVHWWLQJWKHDXWRSRZHUR΍WLPHSUHVV

the EXIT button on the remote.

Enabling the Screen Saver

If there is no on-screen content or static content when audio is

VWUHDPLQJ WKH EDFNOLJKW LV WXUQHG R΍ VDYLQJ HQHUJ\ <RX FDQ VHW

the time before the screen saver begins.

To set the Screen Saver:

1. From the TIMERS menu, use the Up/Down Arrow buttons on

the remote to highlight Screen Saver.

2. Use the Left/Right Arrow buttons on the remote to change

the time before the screen saver begins. If you don’t want the

screen saver to be active, change the setting to 2΍. Otherwise,

select 2, 10, or 20 minutes.

3. :KHQ\RXKDYHȴQLVKHGVHWWLQJWKHVFUHHQVDYHUWLPHSUHVV

the EXIT button on the remote.

Blanking the Screen

You can blank the screen while there is audio streaming. This

feature helps save energy and the life of the screen.

To blank the screen:

1. From the TIMERS menu, use the Up/Down Arrow buttons on

the remote to highlight Blank Screen and press OK.

To Exit the Screen Saver

Press any button other than the Volume and Mute

buttons on the remote to exit the screen saver.

To Exit the Blank Screen

Press any button other than the Volume and Mute

buttons on the remote to exit the blank screen.

USING THE NETWORK CONNECTION MENU

Your TV is Internet-ready, featuring both an Ethernet port and

built-in high-speed Wireless-N.

Connecting to a Wireless Network

To connect to a wireless network whose network name (SSID) is

being broadcast:

If your TV is connected to a network with an Ethernet

cable, you will not see the wireless network connection

menu. You must disconnect the Ethernet cable to set

up a wireless network connection.

1. Press the MENU button on the

remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the

remote to highlight Network

and press OK. The NETWORK

menu is displayed.

3. If you do not see your wireless

network displayed, highlight

More Access Points and press

OK. The WIRELESS ACCESS

POINTS menu, which is a list of

available wireless networks, is

displayed.

4. Highlight the name of your

wireless network (this is the

network’s SSID) and press OK.

5. Using the on-screeen keyboard,

enter your network’s password,

then highlight Connect and

press OK.

6. Press the EXIT button on the remote.

VIZIO

NETWORK

Wired Connection Disconnected

Wireless Access Points

More Access Points

WPS

Manual Setup

Hidden Network

Test Connection

Changing the Manual Setup Settings

$GYDQFHGXVHUVFDQȴQHWXQHWKHQHWZRUNVHWWLQJVXVLQJWKH0DQXDO

Setup feature.

To change advanced network settings:

1. From the NETWORK menu,

highlight Manual Setup and

press OK. The MANUAL SETUP

menu is displayed.

2. To change the settings manually,

use the Arrow buttons on the

remote to highlight DHCP and

then use the Left/Right Arrow

buttons to change the setting to

2΍.

3. Use the Arrow and OK buttons

to adjust each setting:

• IP Address - The IP address

assigned to the TV.

• Subnet Mask - The subnet

mask.

• Default Gateway - Your

network’s default gateway

address.

• Pref. DNS Server - Your

preferred domain name

server address.

• Alt. DNS Server - Your alternate domain name server

address.

4. Use the Arrow buttons on the remote to highlight Save and

press OK.

5. Press the EXIT button on the remote.

VIZIO

MANUAL SETUP

DHCP Off

IP Address ____.____.____.____

Subnet Mask ____.____.____.____

Default

Gateway ____.____.____.____

Pref. DNS

Server ____.____.____.____

Alt. DNS

Server ____.____.____.____

RJ45 MAC 0:0:0:0:0:0

Wireless MAC 0:0:0:0:0:0

Save

Cancel

Finding MAC Addresses for Network Setup

The security settings on your router may require you to enter the

TV's MAC address in the router's settings.

7RȴQGWKH79V0$&DGGUHVV

1. From the NETWORK menu, highlight Manual Setup and press

OK. The MANUAL SETUP menu is displayed.

2. Find the MAC address for the TV at the bottom of the list. The

MAC addresses for the connections in use are displayed:

• RJ45 MAC - The Ethernet or RJ45 MAC address may be

needed to set up your network when you have connected

the TV to your network with an Ethernet (Cat 5) cable.

• Wireless MAC - The Wireless (WiFi) MAC address may be

needed to connect your TV to your network with WiFi.

Connecting to a Hidden Network

To connect to a wireless network whose network name (SSID) is not

being broadcast:

1. From the NETWORK menu,

highlight Hidden Network and

press OK. The ENTER ACCESS

POINT NAME screen is displayed.

2. Using the on-screen keyboard,

enter your network’s name

(SSID), then highlight Connect

and press OK.

3. Using the on-screen keyboard,

enter your network’s password,

then highlight Connect and

press OK.

4. Press the EXIT button on the

remote.

VIZIO

ENTER ACCESS POINT NAME

Enter your access point name. This

is used to connect to an access

point with a hidden SSID.

a b c d e f g h i

j k l m n o p q r

s t u v w x y z 0

1 2 3 4 5 6 7 8 9

.@# .com Space

Connect

Testing Your Network Connection

To test your network connection:

1. From the NETWORK menu, highlight Test Connection and

press OK.

2. The TEST CONNECTION screen displays the connection

method, network name, signal strength, and download speed

of your network connection.

3. Press the EXIT button on the remote.

äêí

Selecting a Channel Source

Select the type of tuner input you will be using. You can select either

Antenna (Over-the-air) or Cable (Out-of-the-wall) connections.

1. From the CHANNELS menu, highlight Channel Source and

press OK. The CHANNEL SOURCE menu displays.

2. Highlight Antenna or Cable and press OK. Press EXIT.

Scanning for Channels

The TV may need to scan for channels before it can display programs

and their associated information. A channel scan is required for

free over-the-air channels (using an antenna) and cable channels

from an out-of-the-wall connection (without a cable box). Moving

WKH79WRDQDUHDZLWKGL΍HUHQWFKDQQHOVUHTXLUHVWKH79WRVFDQIRU

channels again.

To perform an Auto Channel Scan:

1. From the CHANNELS menu,

highlight Find Channels, and

press OK. The auto channel scan

begins.

2. Wait until the channel scan is

100% complete. Highlight Done

and press OK.

3. Press the EXIT button on the

remote.

If the channel scan is cancelled,

the channels that were already

discovered are retained. A new

channel scan will clear all channels.

SETTING UP CHANNELS

You can use the TV’s Channels menu to:

• Select a Channel Source

• Find Channels

• Perform a Partial Channel Scan

• Manually Add Channels

• Select channels to skip

VIZIO

CHANNELS

Channels not searched

Channel Source Cable

Find Channel

Partial Channel Search

Add Analog Channel

Skip Channel

Analog Audio Stereo

Digital Language English

VIZIO

FIND CHANNELS

Channels Found

Digital: 0

Analog: 19

18% Complete

Cancel

Cancel the channel scan.

Adding New Channels

Occasionally, you may need to add a new range of channels or

add a new analog channel. You can do this by using the Partial

Channel Search and Add Analog Channel options. This is quicker

than scanning all possible channels.

To add a range of new channels:

1. From the CHANNELS menu, highlight Partial Channel Search,

and press OK. The PARTIAL CHANNEL SEARCH menu is

displayed.

2. Highlight Scan Mode and select the type of channel you are

adding: Analog, Digital, or Analog/Digital.

3. Highlight From Channel and enter the channel where you

want to begin the scan. (Use the Left Arrow button to

backspace. Use the Number Pad on the remote to enter the

channel.)

4. Highlight To Channel and enter the channel where you want

to end the scan. (Use the Left Arrow button to backspace. Use

the Number Pad on the remote to enter the channel.)

5. Highlight Start and press OK. The partial channel search

begins.

6. Wait until the partial channel search is 100% complete.

Highlight Done and press OK.

7. Press the EXIT button on the remote.

To add a single new analog channel:

1. From the CHANNELS menu,

highlight Add Analog Channel

and press OK. The ADD ANALOG

CHANNEL menu is displayed.

2. Highlight Enter Channel # and

use the Number Pad on the

remote to enter the number of

the channel you are adding.

3. Highlight Add Channel and

press OK. The TV scans for the

channel.

4. When the TV is done scanning

for the channel, press the EXIT

button on the remote.

VIZIO

ADD ANALOG CHANNEL

Enter Channel

Add Channel

Skipping Channels

$IWHUDFKDQQHOVFDQLVFRPSOHWHG\RXPD\ȴQGWKDWVRPHFKDQQHOV

are too weak to watch comfortably. There may also be some

channels you do not want to view. You can remove these channels

from the TV’s memory with the Skip Channel feature.

Channels that have been removed with the Skip

Channel feature can still be viewed if the channel

is entered using the Number Pad. If you wish to

completely block a channel from being viewed, use the

parental controls. See

Locking and Unlocking Channels

on page 43.

To remove a channel:

1. From the CHANNELS menu,

highlight Skip Channel, and

press OK. The SKIP CHANNEL

menu is displayed.

2. For each channel you wish to

remove, use the Up/Down

Arrow buttons on the remote to

highlight the channel and press

OK. A

3 appears to the right of

each channel you select.

3. When you have selected all

of the channels you wish to

remove, press the EXIT button

on the remote.

VIZIO

SKIP CHANNEL

Test 0

Test 1

1-2

Test 2

Test 3

2-2

Test 4

2-3

Test 5

LISTENING TO ALTERNATE AUDIO

Changing the Analog Audio Language

Some analog over-the-air (free) and cable channels broadcast

programs in more than one language. The TV’s Analog Audio

feature allows you to listen to audio in an alternate language using

Secondary Audio Programming (SAP).

Not all programs are broadcast in SAP. The Analog

Audio Language feature only works when the program

being viewed is being broadcast with Secondary Audio

Programming.

To use the Analog Audio feature:

1. From the CHANNELS menu,

highlight Analog Audio and

press OK. The ANALOG AUDIO

menu is displayed.

2. Select Stereo, SAP (secondary

audio programming), or Mono.

Press OK.

3. Press the EXIT button on the

remote.

VIZIO

ANALOG AUDIO

Stereo

SAP

Mono

To use the Digital Language feature:

1. From the CHANNELS menu,

highlight Digital Language

and press OK. The DIGITAL

LANGUAGE menu is displayed.

2. Select your preferred language:

English, Español or Français.

Press OK.

3. Press the EXIT button on the

remote.

VIZIO

DIGITAL LANGUAGE

English

Español

Français

SETTING UP CLOSED CAPTIONING

Your TV can display closed captions for programs that include them.

Closed captions display a transcription of a program’s dialogue.

To activate or deactivate closed captions:

1. Press the MENU button on the

remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the

remote to highlight Closed

Captions and press OK. The

CLOSED CAPTIONS menu is

displayed.

3. Use the Arrow buttons on the

remote to highlight Closed

Captions and then use the Left/

Right Arrow buttons to select

On or 2΍.

4. Use the Arrow buttons on

the remote to highlight either

Analog or Digital Closed

Captions.

5. Use the Left/Right Arrow

buttons on the remote to select

the caption channel you wish to

display, then press EXIT.

If the program you are viewing is not being broadcast

with closed captions, the TV will not display them.

VIZIO

CLOSED CAPTIONS

Closed Captions Off

Analog Closed Captions CC1

Digital Closed Captions CS1

Digital Style

The Closed Captions menu does not appear when an

HDMI input is selected.

Changing the Appearance of Digital Closed Captions

Digital closed captions can be displayed according to your

preference. See the diagram on the next page for an explanation of

the parts of the closed caption area.

To change the appearance of digital closed captions:

1. From the CLOSED CAPTIONS

menu, use the Arrow buttons to

highlight Digital Style and press

OK.

2. Use the Left/Right Arrow

buttons on the remote to select

Custom. The DIGITAL STYLE

menu appears as shown.

3. Use the Up/Down Arrow

buttons on the remote to

highlight the setting you wish to

change, then use the Left/Right

Arrow buttons to change the

setting:

• Caption Style - Choose

As Broadcast to keep

default settings or Custom

to manually change each

setting.

• Text Style - Change the

font used for the closed

captioning text.

• Text Size - Make the text larger or smaller.

• Text Color - Change the color of the text.

• Text Opacity - Change the transparency of the text.

• Text Edges&KDQJHWKHH΍HFWVDWWKHHGJHVRIWKHWH[W

such as raising the edges or adding drop shadows.

• Text Edges Color - Change the color of the text edge

H΍HFWV

VIZIO

DIGITAL STYLE

Caption Style

Custom

Text Style

As Broadcast

Text Size

Large

Text Color

Green

Text Opacity

As Broadcast

Text Edges

As Broadcast

Text Edges Color

As Broadcast

Background Color

Black

Background Opacity

As Broadcast

Window Color

Red

Window Opacity

As Broadcast

• Background Color - Change the color of the background

directly behind the text.

• Background Opacity - Change the transparency of the

background directly behind the text.

• Window Color - Change the color of the closed captioning

box.

• Window Opacity - Change the opacity of the closed

captioning box.

4. :KHQ\RXDUHVDWLVȴHGZLWKWKHDSSHDUDQFHRIWKHFORVHG

captions, press the EXIT button on the remote.

Typical choices include:

• Opaque background, transparent window—Only a strip of

background appears behind the text, expanding as the text

appears. This is the typical "As Broadcast" mode.

• Opaque background and window in the same color—When

WH[WDSSHDUVWKHHQWLUHOLQHȴOOVZLWKFRORUDWRQFH

In the example below, the closed caption text is green, the

background is black, and the window is red.

CLOSED CAPTIONS SCREEN LAYOUT

Text

Window

Background

&/26('&$37Ζ217(;76$03/(

RENAMING DEVICES ON THE INPUT MENU

You can rename the inputs to make them easier to recognize on

the Input menu. For example, if you have a DVD player connected

to the Component input, you can rename that input to display “DVD

Player.” See

Changing the Input Source on page 22

To change the name of an input:

1. Press the MENU button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight Devices and

press OK. The DEVICES menu is displayed.

3. Highlight the input device that you want to rename and press

OK.

4. To use a preset input name:

a. Highlight the Input Port row and press OK.

b. Highlight the input name you want to use and press OK.

—or—

To enter a custom name:

a. Enter your custom label using the on-screen keyboard.

b. Highlight OK and press OK.

c. The Input Name changes to show the custom name that

you created.

5. :KHQ\RXKDYHȴQLVKHGQDPLQJ\RXULQSXWSUHVVWKHEXIT

button on the remote.

VIZIO

NAME INPUT

HDMI-1 DVD

DVD_

Cancel

Select the input name from a list

of common device names (Blu-ray,

Cable Box, DVD, etc).

a b c d e f g h i

j k l m n o p q r

s t u v w x y z 0

1 2 3 4 5 6 7 8 9

.@# .com Space

Input Port

Custom Name

Input Name

äêí

CHANGING THE TV SETTINGS

Using the System menu, you can:

• View system information

• Change the on-screen menu

language

• Set time zone and local

settings

• Set up parental controls

• Resize the video size

• Change the TV’s DLNA Name

• Adjust wide mode

• Adjust the CEC settings

• Adjust when the power

indicator is illuminated

• Reset the TV settings & set

up administrative controls

VIZIO

SYSTEM

System Information

Menu Language English

Time & Local Settings

Parental Controls

View Mode Overlay

Wide

TV Name VIZIOTV

CEC

Power Indicator Off

Reset & Admin

View status information for the TV,

current input and your network.

Viewing System Information

To view technical data and status information about your TV and

network connection:

1. Press the MENU button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight System and

press OK. The SYSTEM menu is displayed.

3. Highlight System Information and press OK.

4. Use the Up/Down Arrow buttons to scroll through the system

information.

5. :KHQ\RXDUHȴQLVKHGUHYLHZLQJWKHV\VWHPLQIRUPDWLRQSUHVV

the EXIT button on the remote.

Changing the On-Screen Menu Language

<RXU79FDQGLVSOD\WKHRQVFUHHQPHQXLQGL΍HUHQWODQJXDJHV

To change the on-screen menu language:

1. Press the MENU button on the

remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the

remote to highlight System and

press OK. The SYSTEM menu is

displayed.

3. Use the Arrow buttons on

the remote to highlight Menu

Language and press OK. The

MENU LANGUAGE menu is

displayed.

4. Highlight your preferred

language (English, Español, or

Français) and press OK.

5. Press the EXIT button on the

remote.

VIZIO

MENU LANGUAGE

English

Español

Français

Enabling or Disabling Program Ratings

To manage program content according to its rating, you must

enable the Program Rating feature.

To enable or disable the Program Rating feature:

1. From the PARENTAL CONTROLS menu, highlight Locks and

press OK. The LOCKS menu is displayed.

2. Select On or 2΍ and press OK.

Locking and Unlocking Channels

When a channel is locked, it will be inaccessible. Locking a channel

is a good way to prevent children from viewing inappropriate

material.

To lock or unlock a channel:

1. From the PARENTAL CONTROLS menu, highlight Channel

Locks and press OK. The CHANNEL LOCKS menu is displayed.

2. Highlight the channel you want to lock or unlock and press OK.

3. When a channel is

locked

, the Lock icon appears locked.

The channel is not accessible unless the parental PIN is

entered.

4. When a channel is

unlocked

, the Lock icon appears

unlocked. The channel is accessible.

Using the Parental Controls

The TV’s parental controls allow you to prevent the TV from

displaying certain channels or programs without a password.

The Parental Controls menu only appears when:

• You are using the tuner to receive your TV signals, such as

when you are using an antenna for Over-the-Air signals or

when connected to cable TV directly from the wall (no cable

box).

• You have a device connected using a composite video cable

or a coaxial cable, such as a VCR, satellite or cable box, or

DVR.

Other devices have their own parental control settings.

Accessing the Parental Controls Menu

To access the Parental Controls menu:

1. Press the MENU button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight System and

press OK. The SYSTEM menu is displayed.

3. Use the Arrow buttons on the remote to highlight Parental

Controls and press OK.

4. Enter your parental PIN. If you have not set a PIN, enter the

default, 0000. The PARENTAL CONTROLS menu is displayed.

To set a custom parental passcode, see

Changing the

Parental Control PIN

on page 44.

Setting the Time and Local Settings

To ensure the correct time is displayed when you press the INFO

button, set the TV’s time zone:

1. Press the MENU button on the

remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the

remote to highlight System and

press OK. The SYSTEM menu is

displayed.

3. Use the Arrow buttons on the

remote to highlight Time &

Local Settings and press OK.

The menu headed by the local

date and time is displayed.

4. Highlight Time Zone and press

OK. The TIME ZONE menu is

displayed.

5. Highlight your time zone and press OK.

6. Highlight Daylight Saving Time and press OK. The DAYLIGHT

SAVING TIME menu is displayed. Choose On if it is currently

Daylight Savings Time, 2΍ if it is Standard Time, or Auto to

have the system automatically detect Daylight Savings Settings.

7. If you are in the United States, highlight Zip Code. Enter your Zip

code using the keypad on the remote, then press OK. Zip codes

are often used by V.I.A. Plus Apps to give you the most accurate

location-based information, such as weather or news.

8. Highlight Country and press OK. The COUNTRY menu is

displayed.

9. Highlight your country and press OK.

10. Press the EXIT button on the remote.

VIZ

June 11, 2015 11:48AM

Time Zone Paciﬁc (-8)

Daylight Savings Time Auto

Zip Code 12345

Country USA

Resetting the Content Locks

To reset the content locks to the factory-default settings:

1. From the PARENTAL CONTROLS menu, highlight Reset Locks

and press OK. The TV displays, “Select Reset to restore Parental

Controls to factory defaults.”

2. Highlight Reset and press OK.

Changing the Parental Control PIN

If you use the parental controls, you should change the PIN to

prevent children from accessing inappropriate material.

To change the parental control PIN:

1. From the PARENTAL CONTROLS menu, highlight Change PIN

and press OK. The CHANGE PIN menu is displayed.

2. In the NEW PINȴHOGXVHWKHNumber Pad on the remote to

enter your new 4-digit parental control PIN.

3. In the CONFIRM PINȴHOGXVHWKHNumber Pad on the remote

to re-enter your new 4-digit parental control PIN.

4. Write down your new parental control PIN and save it in a

secure location.

5. Press the EXIT button on the remote.

Blocking and Unblocking Content by Rating

A channel may sometimes broadcast programs that are meant for

children, and at other times broadcast programs that are meant

for mature audiences. You may not want to block the channel

completely using a channel lock, but you may wish to block certain

programs from being viewed.

When this is the case, you can use the TV’s Rating Block feature to

block content based on its rating.

)RUDOLVWRIFRQWHQWUDWLQJVDQGWKHLUGHȴQLWLRQVYLVLW

www.tvguidelines.org.

To block or unblock content by its rating:

1. From the PARENTAL CONTROLS menu, highlight the content

type you want to adjust and press OK:

USA TV - USA television program broadcasts.

USA Movie - USA movie broadcasts.

Canadian English - Canadian English television program

broadcasts.

Canadian French - Canadian French television program

broadcasts.

2. For each rating type you want to block or unblock, use the

Up/Down and Left/Right Arrow buttons on the remote to

highlight the rating type and press OK.

3. When the rating type is blocked, the Lock icon appears

locked. Content with this rating and all higher ratings cannot

be viewed.

4. When the rating type is unblocked, the Lock icon appears

unlocked. Content with this rating and all lower ratings can be

viewed.

If you want to block all unrated content, highlight Block

Unrated Shows and use the Arrow buttons on the remote to

select On.

5. :KHQ\RXDUHȴQLVKHGDGMXVWLQJWKHUDWLQJOHYHOEORFNVSUHVV

the EXIT button on the remote.

Changing the View Mode Settings

<RXFDQUHVL]HWKHYLGHRFRQWHQWWRȴWZKLOHWKHPHQXLVRSHQ

To change the view mode settings:

1. Press the MENU button on the

remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the

remote to highlight System and

press OK. The SYSTEM menu is

displayed.

3. Use the Arrow buttons on the

remote to highlight View Mode

and press OK. The VIEW MODE

menu is displayed.

4. Highlight Viewport, Overlay,

or Centered Overlay and press

OK.

• Viewport - The entire picture

is visible in the space to the

right of the menu.

• Overlay - The left-hand

portion of the picture

covered by the menu.

• Centered Overlay7KHSLFWXUHH[WHQGVR΍RIWKHULJKW

side of the screen.

5. Press the EXIT button on the remote. See

Viewing Video with

the Menu Open

on page 24 for an alternate way of resizing

the video content.

VIZIO

VIEW MODE

Viewport

Overlay

Centered Overlay

7XUQLQJWKH3RZHUΖQGLFDWRU2QRU2΍

The Power Indicator on the front of your TV normally does not glow

when the TV is on. You can change this setting if you prefer the light

to be on.

7RWXUQWKH3RZHUΖQGLFDWRU/LJKW2QRU2΍

1. Press the MENU button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight System and

press OK. The SYSTEM menu is displayed.

3. Highlight Power Indicator and press OK.

4. Use the Up/Down Arrow buttons to select On or 2΍, then

press OK.

Adjusting the CEC Settings

The CEC function on your TV enables you to control devices

connected to HDMI (ARC) input with the included remote, without

any programming. Using CEC, your VIZIO TV remote can control:

• 3RZHU2Q2΍

• Volume

• Mute

Not all HDMI devices support CEC. See your device’s

user manual for details.

To enable, disable, or adjust CEC settings:

1. Set up your audio device and connect it to the HDMI-1(HDMI

Arc) input on the TV

2. On your audio device, select the HDMI ARC input

3. Press the MENU button on the remote. The on-screen menu is

displayed.

4. Use the Arrow buttons on the remote to highlight System and

press OK. The SYSTEM menu is displayed.

5. Use the Arrow buttons on the remote to highlight CEC and

press OK. The CEC menu is displayed.

6. Highligh CEC and press OK. Select a setting and then press OK.

• CEC - To use CEC, you must select Enable.

• Device Discovery - To determain if your device is

connected and supports CEC, select Device Discovery and

then press OK.

7. Press the EXIT button on the remote.

Changing the DLNA Name of Your TV

Enter a custom DNLA name for your TV (Up to 10 characters

ORQJ'1/$DOORZV\RXU79WRGLVSOD\FRQWHQWIURP'1/$FHUWLȴHG

computers, cameras, tablets, and smartphones.

To create a custom name for your TV:

1. Press the MENU button on the

remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the

remote to highlight System and

press OK. The SYSTEM menu is

displayed.

3. Use the Arrow buttons on the

remote to highlight TV Name

and press OK. The TV NAME

menu is displayed.

4. Use either the on-screen

keyboard or keyboard on your

remote control to enter a name

for your TV (the name can be up

to 10 characters long).

:KHQ\RXDUHȴQLVKHGKLJKOLJKW

OK and press the OK button.

5. Press the EXIT button on the remote.

VIZIO

TV NAME

VIZIOTV_

Cancel

a b c d e f g h i

j k l m n o p q r

s t u v w x y z 0

1 2 3 4 5 6 7 8 9

.@# .com Space

äêí

5. If you have changed the default parental control PIN, enter it

now.

The TV displays, “Select Reset to restore all TV settings to

factory defaults and clear all account information.”

6. Highlight Reset and press OK.

7. :DLWIRUWKH79WRWXUQR΍7KH79ZLOOWXUQEDFNRQVKRUWO\

afterward and the Setup App will begin.

USING THE RESET & ADMIN MENU

You can use the TV’s Reset & Admin menu to restore the TV to its

factory default settings.

Restoring the TV to Factory Default Settings

All of the on-screen menu settings can be reset to the factory

defaults.

If you restore the TV to the factory default settings, all

changes you have made to the settings will be lost!

This includes any V.I.A. Plus Apps that you have added

and any changes you have made to the settings for

those Apps.

To restore the TV to its factory default settings:

1. Press the MENU button on the

remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the

remote to highlight System and

press OK. The SYSTEM menu is

displayed.

3. Highlight Reset & Admin and

press OK. The RESET & ADMIN

menu is displayed.

4. Highlight Reset TV to Factory

Defaults and press OK.

VIZIO

RESET & ADMIN

Reset TV to Factory Defaults

VIZIO Privacy Policy

Smart Interactivity On

Store Demo

Enabling and Disabling Smart Interactivity

Your TV can display program-realted information as part of the

broadcast. To enable or disable Smart Interactivity:

1. Press the MENU button on the remote. The on-screen menu is

displayed.

2. Use the Arrow buttons on the remote to highlight System and

press OK. The SYSTEM menu is displayed.

3. Highlight Reset & Admin and press OK. The RESET & ADMIN

menu is displayed.

4. Highlight Smart Interactivity and press OK.

5. Select On or 2΍ and press OK.

6. Press the EXIT button on the remote.

USING THE GUIDED SETUP MENU

Using Guided Setup

The TV’s Setup App can be used to easily set up the TV channel or to

connect the TV with your network.

To use guided setup:

1. Press the MENU button on the

remote. The on-screen menu is

displayed.

2. Highlight Guided Setup and

press OK.

3. Highlight the guided setup you

want to use and press OK:

• Channel Setup - Set up the

TV channel.

• Network Setup - Connect

the TV to the Internet using

your network.

4. Follow the on-screen

LQVWUXFWLRQV:KHQȴQLVKHG

press the EXIT button on the

remote.

VIZIO

GUIDED SETUP

Channel Setup

Network Setup

USING THE INFO WINDOW

The Info Window can be displayed by pressing the INFO or GUIDE

button on the remote:

• Press the INFO or GUIDE button one time to display

channel, input, and display information.

• Press the INFO or GUIDE button two times to display the

program title, program rating, audio information, and the

start and end times of the program.

DIGITAL EPISODE GUIDE & INFO WINDOW

Oliver’s Holiday Surprise

1080p 6:15pm

11:00AM - 12:00PM

TV-PG-V

Dolby D Stereo

Oliver wakes up one morning only to discover that his pals are missing. In this

hour-long holiday special, Oliver goes on a journey in search of his pals. Who

knows what he’ll encounter on the way?

Program Description

Program Title/Rating Information

Network/Display Information

28-1

KCET-HD

Normal

Channel/Input Information

5Using the USB Media Player

Preparing Your USB Drive to Play USB Media

7RSOD\86%PHGLD\RXPXVWȴUVWVDYH\RXUȴOHVRQWRD86%WKXPE

GULYH

• 7KH86%WKXPEGULYHPXVWEHIRUPDWWHGDV)$7

• )LOHVRQWKH86%WKXPEGULYHPXVWHQGLQDVXSSRUWHGȴOH

H[WHQVLRQPSMSJHWF

• 7KHSOD\HULVQRWGHVLJQHGWRSOD\PHGLDIURPH[WHUQDOKDUG

GULYHV03SOD\HUVFDPHUDVRUVPDUWSKRQHV

Playing USB Media

7RSOD\\RXU86%PHGLD

 &RQQHFW\RXU86%WKXPEGULYHWRWKH86%SRUWRQWKHVLGHRI

WKH79

 3UHVVWKHV buttonRQWKHUHPRWH



 8VHWKHArrowEXWWRQVWRKLJKOLJKWWKHMultimediaDSSLQWKH

9Ζ$3OXV'RFNDQGSUHVVOK7KHKLJKOLJKWHG$SSLVLQWKH

FHQWHURIWKHGRFN

 8VHWKHArrowEXWWRQVWRKLJKOLJKWWKH86%GULYHIURPWKHOLVW

DQGSUHVVOK

 8VHWKHArrowEXWWRQVWRKLJKOLJKWWKHW\SHRIPHGLDWR

GLVSOD\Music, VideoRUPhotoDQGSUHVVOK

 8VHWKHArrowEXWWRQVWRKLJKOLJKWWKHȴOH\RXZDQWWRGLVSOD\

3UHVVOK0XVLFRUYLGHRȴOHVSOD\SKRWRVGLVSOD\

<RXFDQGLVSOD\\RXUSKRWRVLQIXOOVFUHHQ6HOHFWWKH

SKRWRSUHVVOKWKHQKLJKOLJKWFullscreenDQGSUHVV

OK

Removing the USB Drive from the TV

7RVDIHO\UHPRYH\RXU86%GULYHIURPWKH79

 7XUQR΍WKH79

 'LVFRQQHFW\RXU86%WKXPEGULYHIURPWKH86%SRUWRQWKH

VLGHRIWKH79

'RQRWUHPRYHWKH86%WKXPEGULYHZKLOHWKH79LVRQ

'RLQJVRPD\GDPDJHWKHGULYH

Using the USB Media Player

7KH86%0HGLD3OD\HUDOORZV\RXWRFRQQHFWD86%WKXPEGULYHWR

\RXU79DQGSOD\PXVLFYLGHRRUSKRWRV

1RWH

7KHLPDJHVKRZQKHUHLVIRULOOXVWUDWLYHSXUSRVHVRQO\DQGPD\EHVXEMHFWWRFKDQJHb

7KHDFWXDOQXPEHURISRUWVDQGWKHLUORFDWLRQVPD\YDU\GHSHQGLQJRQWKHPRGHO

Browse Photos

Artist A-Z

View:

Sort:

Music

MyFlashDrive\Audio\root\My Music

USB1: MyFlashDrive

My Music

Page 1 of 1

VIZIO

Album Art

ΖILQFOXGHGRQWKH86%

WKXPEGULYHDQGDVVRFLDWHG

ZLWK\RXUPXVLFWKHDOEXP

DUWZLOOGLVSOD\KHUH

Progress Bar

'LVSOD\VWKHGXUDWLRQRIWKHFXUUHQW-

O\SOD\LQJVRQJ7KHEOXHEDUZLOO

OHQJWKHQDVWKHVRQJSURJUHVVHV

Page Information

ΖI\RXU86%WKXPEGULYHKDVPRUH

ȴOHVWKDQFDQEHGLVSOD\HGRQD

VLQJOHVFUHHQWKHSDJHLQIRUPDWLRQLV

GLVSOD\HGKHUH

Now Playing Information

'LVSOD\VVRQJWLWOHDOEXPWLWOHDQGDUWLVWQDPH

Connected

Sources

'LVSOD\V

FRQQHFWHG86%

GHYLFHV

Current Folder

Playback Controls

8VHWRFRQWURODXGLR

SOD\EDFN+LJKOLJKW3OD\

3DXVH3UHYLRXVRU1H[W

DQGSUHVVOK

Toggle Music/Photos

Toggle between

viewing all content

and only viewing

folders.

MUSIC PLAYER

All

Sort by Album/Artist/

Track

Fab Apple Dream

On January Mix Comp

By Oliver

00:04:00 00:04:46

Track Album Artist Duration

Starry Summer

Summer Mix

JCheesy

2:42

Downspin

JCheesy 6:20

Mango Dream

Oliver 8:46

Crystal Waters

The Dash

4:21

Smooth Waves

Rio Steve 7:58

Back Button

+LJKOLJKWWKLVEXWWRQDQG

SUHVVOKWRUHWXUQWR

WKHSUHYLRXVVFUHHQ

Folder Contents/

Playlist

7KLVDUHDGLVSOD\V

WKHFRQWHQWVRIWKH

FXUUHQWO\VHOHFWHG

IROGHU<RXFDQEURZVH

ȴOHVDQGIROGHUVXVLQJ

WKHArrowDQGOK

EXWWRQVRQWKHUHPRWH

Summer Mix

Beach Mix

Breezy Mix

Date New-Old

View:

Sort:

Video

MyFlashDrive\Video\root\My Videos

USB1: MyFlashDrive

My Videos

Page 1 of 1

VIZIO

Page Information

ΖI\RXU86%WKXPEGULYHKDVPRUH

ȴOHVWKDQFDQEHGLVSOD\HGRQD

VLQJOHVFUHHQWKHSDJHLQIRUPDWLRQLV

GLVSOD\HGKHUH

Connected

Sources

'LVSOD\V

FRQQHFWHG86%

GHYLFHV

Current Folder

View All or

View Folders

VIDEO PLAYER

Folders

File Date Duration#

Family Vacation - California

- 00:23:431

26th Birthday Party

- 00:38:182

Summer 2012

- 00:41:083

Greatest Trip Ever

- 00:05:324

Folder Contents/

Playlist

7KLVDUHDGLVSOD\V

WKHFRQWHQWVRIWKH

FXUUHQWO\VHOHFWHG

IROGHU<RXFDQ

EURZVHDPRQJȴOHV

XVLQJWKHArrowDQG

OKEXWWRQVRQWKH

UHPRWH

Back Button

+LJKOLJKWWKLVEXWWRQDQG

SUHVVOKWRUHWXUQWR

WKHSUHYLRXVVFUHHQ

Sort by Date

or File Name

Start Slideshow

Name A-Z

Thumbnails

Settings

View:

Sort:


VIZIO_2GB\Photo\root

File Name: D 1920x1080

Resolution: 1920x1080

Size: 1607270KB

USB1:


root

B.jpg C.jpg


E.jpg F.jpg


H.jpg I.jpg

Page 1 of 1

VIZIO

Current Folder

'LVSOD\VWKHIROGHUSDWK

Back Button

+LJKOLJKWDQGSUHVVOKWRUHWXUQWROHIWFROXPQ

Connected

Sources

'LVSOD\V

FRQQHFWHG86%

GHYLFHV

Current Folder

View Thumbnails/Folders

Adjust Slideshow Settings

Start Fullscreen

Slideshow

PHOTO VIEWER

Browse Music

View Music Files

Back Button

+LJKOLJKWWKLVEXWWRQDQG

SUHVVOKWRUHWXUQWR

WKHSUHYLRXVVFUHHQ

Folder Contents

7KLVDUHDGLVSOD\VWKH

FRQWHQWVRIWKHFXUUHQWO\

VHOHFWHGIROGHU<RXFDQ

EURZVHȴOHVDQGIROGHUV

XVLQJWKHArrowDQGOK

EXWWRQVRQWKHUHPRWH

Page Information

ΖI\RXU86%WKXPEGULYHKDVPRUH

ȴOHVWKDQFDQEHGLVSOD\HGRQD

VLQJOHVFUHHQWKHSDJHLQIRUPDWLRQLV

GLVSOD\HGKHUH

Photo Information

'LVSOD\VWKHQDPH

UHVROXWLRQDQGȴOH

VL]HRIWKHVHOHFWHG

SKRWR

Sort by Date

or File Name

6Using VIZIO Internet Apps Plus

(V.I.A. Plus)

VIZIO Internet Apps Plus

(V.I.A. Plus) delivers popular online content

to your TV. V.I.A. Plus features a selection of Apps that allow you to

watch movies and TV shows, listen to music, get weather and news

information, and more–all on demand.

A high-speed Internet connection is required to receive

product updates and to access online content.

See

Using the Network Connection Menu on page 34

if your TV is

not yet connected to your home network.

USING THE V.I.A. PLUS APP DOCK

The V.I.A. Plus App Dock is where all of your V.I.A. Apps are accessed.

To launch an App from the Dock:

1. Press the V Button on the remote.

2. Highlight a V.I.A. Plus App by

scrolling left and right using the

Left/Right Arrow buttons on

the remote. (The highlighted App

is in the center of the dock.)

3. Press the OK button on the

remote to launch the App.

Using the App Launcher Keys

Using the App Launcher Keys on the

remote launch the apps pictured

on the buttons. Pressing the App

Launcher Key will also turn the TV on

LILWLVR΍

7KH VSHFLȴF DSSV RQ WKH $SS

Launcher keys vary from model to

model.

V Button

App Launcher Buttons

Note: App location, appearance, and availability subject to change without notice.

V.I.A. Plus App Dock

My Apps Tab

Displays the apps

installed on your

TV.

Installed Apps

The Apps displayed

here are also

available in the V.I.A.

Plus App Dock.

App Store Tabs

Browse through Apps

on these tabs to run

them and add them

to your My Apps tab.

USING THE FULLSCREEN V.I.A. APPS WINDOW

The Fullscreen V.I.A. Plus Apps window allows you to add and store

$SSV  7KH $SSV RQ WKH ȴUVW SDJH DUH GLVSOD\HG LQ WKH 'RFN DQG

Apps on additional pages can be moved to the Dock.

To open the Fullscreen V.I.A. Plus Apps Window:

1. Press the V Button on the remote twice.

2. Highlight an App by using the Arrow buttons on the remote.

3. Press the OK button on the remote to launch the App.

4. To exit from an open App or to close the App Dock, press the

Exit button on the remote.

Note: App location, appearance, and availability subject to change without notice.

FULLSCREEN V.I.A. PLUS APPS WINDOW

OVERVIEW

The Fullscreen V.I.A. Plus Apps Window allows you to add, delete

and organize your Apps. The My Apps tab displays Apps that

DUH DOUHDG\ LQVWDOOHG RQ \RXU 79  7KH $SSV RQ WKH ȴUVW SDJH DUH

displayed in the V.I.A. Plus App Dock.

The following tabs are located at the top of your Fullscreen V.I.A.

Plus Apps Window:

• My Apps: Displays apps that are installed on your TV.

• Featured: Displays apps that are recommended by Yahoo!

• Latest: Displays apps that were most recently added to the

library of apps.

• All Apps: Displays every app that is available for download.

• Categories: Displays apps sorted into categories: Spotlight,

Yahoo!, Weather, News and Finance, Movies and TV, Photos

and Video, Sports, Music, Social, Information, Fun and

Games, Shopping, and Local TV.

• Settings (

): Displays App software information and

development settings.

Apps with a small lock icon in the right-hand corner

cannot be deleted.

You can also preview Apps without installing them.

Simply highlight the App you wish to preview and press

OK to open it.

Note: App location, appearance, and availability subject to change without notice.

CUSTOMIZING THE V.I.A. PLUS APPS WINDOW

You can add, delete, and move apps around on your My Apps tab

for a custom look and feel.

Adding an App to the My Apps Tab

To add an app to your TV:

1. Use the Arrow buttons on the remote to highlight one of the

App Store tabs (Featured, Latest, All Apps, or Categories).

2. Use the Arrow buttons to highlight the app you wish to add.

3. Press and hold the OK button until [

App Name

]

has been

added to your My Apps list

appears.

Once the app has been installed, a star appears in the top right-hand

corner of the app icon as shown below.

Moving an App in My Apps

You can organize your Apps on your My Apps tab by moving them

where you want.

To move the Apps on your My Apps tab:

1. Use the Arrow buttons on the remote to highlight the app you

wish to move.

2. Press and hold the OK button. The following options appear:

Star

Note: App location, appearance, and availability subject to change without notice.

Deleting an App from the My Apps Tab

To delete an app from your TV:

1. Use the Arrow buttons on the remote to highlight the App you

wish to delete.

2. Press and hold the OK button. The following options appear:

3. Press OK to delete the app. The following dialog box appears:

4. Use the Left/Right Arrow buttons to select Delete and press OK.

The App is removed from your My Apps tab.

Note: App location, appearance, and availability subject to change without notice.

2QO\WKH$SSVRQWKHȴUVWSDJHDSSHDULQWKH'RFN

3. Use the Arrow buttons to move the app to the desired location

and press OK to place the app. When you can move the app, it

appears as shown below.

Note: App location, appearance, and availability subject to change without notice.

Cursor showing the location that the

app will move to

ATroubleshooting & Technical Support

Find help with:

• New Product Setup

• Connecting Your Devices

• Technical Problems

• Product Updates

• And More

You can also contact our

award-winning support team at:

Phone:

(877) 698-4946 (TOLL-FREE)

Hours Of Operation:

Monday - Friday: 7

(CST)

Saturday - Sunday: 9

(CST)

Live Chat

Support Available

Do You Have Questions? Find Answers At

SUPPORT.VIZIO.COM

Take A Moment To Register Your Product At

VIZIO.COM/PRODUCT-REGISTRATION

Customized Support

Get assistance quickly with your information on-hand.

News & Offers

Take advantage of the latest news and special offers from VIZIO.

Safety & Satisfaction

Stay up to date with important product updates and notifications.

Why Register?

The remote is not responding.

• Make sure the batteries are properly inserted matching

the - and + symbols.

• Replace the batteries with fresh ones.

The TV displays “No Signal.”

• Press the INPUT button on the remote control to select a

GL΍HUHQWLQSXWVRXUFH

• If you are using cable TV or antenna connected directly to

the TV, scan for channels. See

Scanning for Channels on

page 36

There is no power.

• Ensure the TV is plugged into a working electrical outlet.

• Ensure the power cable is securely attached to the TV.

• Press the Power/Standby button on the remote or on the

back of the TV to turn the TV on.

The power is on, but there is no image on the screen.

• Ensure all cables are securely attached to the TV.

• (QVXUHDOOGHYLFHVDUHFRQQHFWHGFRUUHFWO\'HYLFHVGL΍HU

see your device’s user manual for details.

• Adjust Brightness, Contrast, or Backlight. See

Adjusting

the Picture Settings on page 25

• Press the INPUT button on the remote to select a

GL΍HUHQWLQSXWVRXUFH

There is no sound.

• Press Volume Up on the remote control.

• Press the MUTEEXWWRQRQWKHUHPRWHWRHQVXUHPXWHLVR΍

• Check the audio settings. See

Adjusting the Audio Settings

on page 31.

• Check the audio connections of external devices (Blu-ray

player, game console, cable/satellite box) that are

connected to the TV.

• If you are using an antenna, the signal strength of the

channel may be low. Ensure your antenna is connected

securely to the TV and move the antenna around the

room or close to a window for the best signal.

7KHVRXQGLVȵDWRUGLDORJLVQRWDXGLEOH

• 7XUQR΍9ROXPH/HYHOLQJ6HH

Adjusting the Audio Settings

on page 31

The colors on the TV don’t look right.

• Adjust the Color and Tint settings in the Picture menu. See

Adjusting the Picture Settings on page 25

• Select a pre-set picture mode. See

Adjusting the Picture

Settings on page 25

. VIZIO recommends selecting

Calibrated.

• Check all cables to ensure they are securely attached.

The buttons on the remote aren’t working.

• Ensure you are only pressing one button at a time.

• Point the remote directly at the TV when pressing a button.

• Replace the remote batteries with new ones. See

Replacing the Batteries on page 12.

The image quality is not good.

• )RUWKHEHVWLPDJHTXDOLW\YLHZKLJKGHȴQLWLRQSURJUDPV

using digital sources. Connect your devices with HDMI

cables.

• If you are using an antenna, the signal strength of the

channel may be low. Ensure your antenna is connected

securely to the TV and move the antenna around the

room or close to a window for the best signal.

The picture is distorted.

• Move the TV away from electrical appliances, cars, and

ȵXRUHVFHQWOLJKWV

• Ensure all cables are securely attached.

The display image does not cover the entire screen.

• If you are using TV, AV, or Component with 480i input,

press the button on the remote to change the screen

mode.

The TV has pixels (dots) that are always dark.

• Your HD TV is precision-manufactured using an extremely

high level of technology. However, sometimes pixels may

not display correctly. These types of occurrences are

inherent to this type of product and do not constitute a

defective product.

The V.I.A. Plus Apps are not working

• Be sure your TV is connected to the internet. See

Using

the Network Connection Menu on page 34

. Instructions

for testing your connection are on page 33.

• Restart the App by pressing the EXIT button to close the

App, then open the App.

• Reboot your TV by pressing the POWER button on the

remote, then turn it back on.

I see “noise” or static on the screen.

• When your TV’s digital capabilities exceed a digital

broadcast signal, the signal is up-converted (improved) to

match your TV’s display capabilities. This up-converting

can sometimes cause irregularities in the image.

• If you are using an antenna, the signal strength of the

channel may be low. Ensure your antenna is connected

securely to the TV and move the antenna around the

room or close to a window for the best signal.

When I change input source, the display image changes size.

• The TV remembers the viewing mode on each input

source. If the viewing mode on the new input source

GL΍HUVIURPWKHRQHRQWKHLQSXWVRXUFH\RXVZLWFKIURP

WKHGL΍HUHQFHPD\EHQRWLFHDEOH

• See

Changing the Screen Aspect Ratio on page 23

B6SHFLȴFDWLRQV

D39h-D0

6FUHHQ6L]H 39"

9LHZDEOH$UHD 38.50"

'LPHQVLRQVZ6WDQG

ZR6WDQG

34.75” x 22.68” x 8.27”

34.75” x 20.51” x 2.91”

:HLJKWZ6WDQG

ZR6WDQG

15 lbs

14.55 lbs

/&'%DFNOLJKW Full-Array LED

$FWLYH/('=RQHV 2 Zones

5HIUHVK5DWH +](΍HFWLYH5HIUHVK5DWH

&OHDU$FWLRQ N/A

0D[LPXP5HVROXWLRQ 1366 x 768 (HD)

'\QDPLF&RQWUDVW5DWLR 2,000,000:1

3L[HO3LWFK 0.62475mm (H) X 0.62475mm (V)

9LHZLQJ$QJOH 178° (H) / 178° (V)

+'0ΖΖQSXWV 2

&RPSRQHQW9LGHRΖQSXWV 1

&RPSRVLWHΖQSXWV 6KDUHGZLWK&RPSRQHQW

5)$QWHQQDΖQSXW 1

86%3RUW 1

(WKHUQHW 1

$XGLR2XWSXWV 5&$$QDORJ6WHUHR2XWSXW2SWLFDO'LJLWDO

26'/DQJXDJH (QJOLVK)UHQFK6SDQLVK

$PELHQW/LJKW6HQVRU N/A

D39h-D0

5HPRWH&RQWURO0RGHO ;57

&HUWLȴFDWLRQV

&6$86&6$)&&&ODVV%+'0ΖD&(&$5&'ROE\'LJLWDO

Plus

9ROWDJH5DQJH ɋ9#ɋ+]

3RZHU&RQVXPSWLRQ ɋ:

6WDQGE\3RZHU :

=HUR%ULJKW3L[HO*XDUDQWHH Yes

DRegulatory Information

FCC Class B Radio Interference Statement

NOTE: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy,

and if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning

WKHHTXLSPHQWR΍DQGRQWKHXVHULVHQFRXUDJHGWRWU\WRFRUUHFW

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• &RQQHFWWKHHTXLSPHQWLQWRDQRXWOHWRQDFLUFXLWGL΍HUHQWIURP

that to which the receiver is connected.

• Consult the dealer or an experienced radio/Display technician for

help.

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

Notice

7KHFKDQJHVRUPRGLȴFDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\

responsible for compliance could void the user’s authority to

operate the equipment.

Shielded interface cables and AC power cord, if any, must be used

in order to comply with the emission limits.

The manufacturer is not responsible for any radio or Display

LQWHUIHUHQFH FDXVHG E\ XQDXWKRUL]HG PRGLȴFDWLRQ WR WKLV

equipment. It is the responsibilities of the user to correct such

interference.

FCC Warning

&KDQJHV RU PRGLȴFDWLRQV QRW H[SUHVVO\ DSSURYHG E\ WKH SDUW\

responsible for compliance with the FCC Rules could void the user’s

authority to operate this equipment.

Caution

Always use an AC/DC power adapter that is properly grounded. Use

the AC cords listed below for each area.

Canada Notice for License-Exempt Radio Apparatus

This device complies with Industry Canada’s license-exempt RSSs.

Operation is subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.

This device operates on a no-protection no-interference basis.

Should the user seek to obtain protection from other radio services

operating in the same TV bands, a radio license is required. Please

consult Industry Canada’s document CPC-2-1-28, Optional Licensing

for Low-Power Radio Apparatus in the TV Bands, for details.

Cet appareil est conforme aux CNR exempts de licence d’Industrie

Canada. . Son fonctionnement est sujet aux deux conditions

suivantes:

1. le dispositif ne doit pas produire de brouillage préjudiciable,

2. ce dispositif doit accepter tout brouillage reçu, y compris un

brouillage susceptible de provoquer un fonctionnement indésirable

Cet appareil fonctionne sur une base sans protection et sans

interférence. Dans le cas où l’utilisateur cherche à obtenir de

la protection des autres services de radio fonctionnant sur les

mêmes bandes TV, aucune license est requise. Veuillez consulter le

document CPC-2-1-28 d’Industrie Canada, License optionnelle pour

les appareils radio de faible puissance, pour plus de détails.

Industry Canada Class B emission compliance statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme

NMB-003 du Canada.

Declaración de México:

La operación de este equipo está sujeta a las siguientes dos

condiciones: (1) es posible que este equipo o dispositivo no cause

interferencia perjudicial y (2) este equipo o dispositivo debe

aceptar cualquier interferencia, incluyendo la que pueda causar su

operación no deseada.

CLimited Warranty

UNITED STATES AND CANADA

BY USING YOUR VIZIO PRODUCT YOU AGREE TO BE BOUND BY ALL

THE TERMS OF THIS WARRANTY. BEFORE USING YOUR VIZIO PRODUCT,

PLEASE READ THIS WARRANTY CAREFULLY. IF YOU DO NOT AGREE TO

THE TERMS OF THIS WARRANTY, DO NOT USE THE VIZIO PRODUCT AND,

WITHIN THIRTY (30) DAYS OF THE DATE OF PURCHASE, RETURN IT FOR

A REFUND TO THE AUTHORIZED RETAILER WHERE YOU PURCHASED IT.

This warranty contains a binding arbitration agreement and a class action

waiver for United States residents. If you live in the United States, the

ELQGLQJDUELWUDWLRQDJUHHPHQWDQGFODVVDFWLRQZDLYHUD΍HFW\RXUULJKWV

under this warranty. Please read the text under the section titled “Binding

Arbitration Agreement; Class Action Waiver (U.S. Residents Only)”

carefully.

How Long This Warranty Lasts

For non-commercial use, VIZIO warrants the product on the terms set

forth below for one (1) year from the date of original purchase. For

commercial use, VIZIO warrants this product on the terms set forth below

for ninety (90) days from the date of original purchase.

What This Warranty Covers

VIZIO warrants the product against defects in materials and workmanship

when the product is used normally in accordance with VIZIO’s user guides

and manuals.

Except where restricted by law, this warranty applies only to the original

purchaser of a new product. The purchase must have been made from an

authorized retailer in the United States (including Puerto Rico) or Canada.

The product must also be located in the country where it was purchased

at the time of warranty service.

Zero Bright Pixel Defect Guarantee (Displays Only)

Your product may qualify for a warranty against “zero bright pixel” defects

for the duration of the warranty on select new product purchases. To

determine if this guarantee applies to your product, refer to the model’s

product information page at www.vizio.com, look for the “zero bright

pixel” guarantee on the box, or contact VIZIO Technical Support at the

email address or telephone number below.

How to Get Service

Before obtaining warranty service, you may visit www.vizio.com for

additional help and troubleshooting. To obtain warranty service, contact

VIZIO Technical Support via email at TechSupport@VIZIO.com or via

phone at 877 MY VIZIO (877-698-4946). The VIZIO Technical Support

hours are 6:00AM to 9:00PM Monday through Friday and 7:00AM to

306DWXUGD\DQG6XQGD\3DFLȴF7LPH

Your Obligations Before Service

You must obtain pre-authorization before sending your product to a

VIZIO service center. You may be required to supply a purchase receipt

(or copy) to show that the product is within the warranty period.

When you return a product to a VIZIO service center, you must ship the

SURGXFWLQLWVRULJLQDO SDFNDJLQJRULQSDFNDJLQJWKDWD΍RUGV DQHTXDO

degree of protection. VIZIO Technical Support will provide instructions for

packing and shipping the product to the VIZIO service center.

ALL USER DATA AND DOWNLOADED APPLICATIONS STORED ON A

PRODUCT WILL BE DELETED IN THE COURSE OF SOME IN-HOME AND ALL

SHIP-IN WARRANTY SERVICE. If this occurs, your product will be restored

to its original state. You will be responsible for restoring all applicable user

data and downloaded applications. Recovery and reinstallation of user

data and downloaded applications is not covered under this warranty.

In order to protect your personal information, VIZIO recommends that

you always clear all personal information from the product before it is

serviced, regardless of the servicer.

VIZIO’s Responsibilities

If VIZIO determines that a product is covered by this warranty, VIZIO will

(at its option) repair or replace it, or refund the purchase price to you.

There will be no charge for parts or labor during the warranty period.

5HSODFHPHQWSDUWVPD\EHQHZRUUHFHUWLȴHGDW9Ζ=Ζ2ȇVRSWLRQDQGVROH

discretion. Replacement parts and VIZIO’s labor are warranted for the

remaining portion of the original warranty or for ninety (90) days from

warranty service, whichever is longer.

Types of Service

Displays that are 32 inches or larger will usually be serviced in-home.

In-home service requires complete and easy access to the product and

does not include de-installation or re-installation of the product. In-home

service is subject to availability. VIZIO will provide other service options

when in-home service is not available.

All other VIZIO products must be sent to a VIZIO service center to obtain

warranty service. VIZIO is not responsible for transportation costs to the

service center, but VIZIO will cover return shipping to the customer.

What This Warranty Does Not Cover

This warranty does not cover: (a) cosmetic damage; (b) normal wear and

tear; (c) improper operation; (d) improper voltage supply or power surges;

(e) signal issues; (f) damage from shipping; (g) acts of God; (h) customer

PLVXVHPRGLȴFDWLRQVRUDGMXVWPHQWVLLQVWDOODWLRQVHWXSRUUHSDLUV

attempted by anyone other than by a VIZIO authorized service center;

(j) products with unreadable or removed serial numbers; (k) products

requiring routine maintenance; or (l) products sold “AS IS”, “CLEARANCE”,

“FACTORY RECERTIFIED”, or by a non-authorized reseller.

:KDWWR'RΖI<RX$UH1RW6DWLVȴHG:LWK6HUYLFH

If you feel VIZIO has not met its obligations under this warranty, you may

attempt to resolve the issue informally with VIZIO. If you are unable to

UHVROYHWKHLVVXHLQIRUPDOO\DQGZLVKWRȴOHDIRUPDOFODLPDJDLQVW9Ζ=Ζ2

and if you are a resident of the United States, you must submit your claim

to binding arbitration according to the procedures described below,

unless an exception applies. Submitting a claim to binding arbitration

means that you do not have the right to have your claim heard by a judge

or jury. Instead your claim will be heard by a neutral arbitrator.

Binding Arbitration Agreement; Class Action Waiver (U.S. Residents

Only)

UNLESS YOU HAVE BROUGHT AN ELIGIBLE CLAIM IN SMALL CLAIMS

COURT OR HAVE OPTED OUT AS DESCRIBED BELOW, ANY CONTROVERSY

OR CLAIM RELATING IN ANY WAY TO YOUR VIZIO PRODUCT, INCLUDING

ANY CONTROVERSY OR CLAIM ARISING OUT OF OR RELATING TO THIS

WARRANTY, A BREACH OF THIS WARRANTY, OR THE VIZIO PRODUCT’S

SALE, CONDITION OR PERFORMANCE, WILL BE SETTLED BY BINDING

ARBITRATION ADMINISTERED BY THE AMERICAN ARBITRATION

ASSOCIATION AND CONDUCTED BY A SINGLE ARBITRATOR APPOINTED

BY THE AMERICAN ARBITRATION ASSOCIATION, IN ACCORDANCE WITH

ITS COMMERCIAL ARBITRATION RULES AND ITS SUPPLEMENTARY

PROCEDURES FOR CONSUMER-RELATED DISPUTES. You may learn more

about the American Arbitration Association and its rules for arbitration

by visiting www.adr.org or by calling 800-778-7879. Since this warranty

concerns a transaction in interstate or international commerce, the

Federal Arbitration Act will apply.

7KHȴOLQJIHHVWREHJLQDQGFDUU\RXWDUELWUDWLRQZLOOEHVKDUHGEHWZHHQ

you and VIZIO, but in no event will your fees ever exceed the amount

allowable by the American Arbitration Association, at which point VIZIO

will cover all additional administrative fees and expenses. VIZIO waives its

right to recover attorneys’ fees in connection with any arbitration under

this warranty. If you are the prevailing party in an arbitration to which

the Supplementary Procedures for Consumer-Related Disputes applies,

then you are entitled to recover attorneys’ fees as the arbitrator may

determine.

The dispute will be governed by the laws of the state or territory in which

you resided at the time of your purchase (if in the United States). The

place of arbitration will be Irvine, California, or your county of residence

(if in the United States). The arbitrator will have no authority to award

punitive or other damages not measured by the prevailing party’s actual

damages, except as may be required by statute. The arbitrator will not

award consequential damages, and any award will be limited to monetary

damages and will include no equitable relief, injunction, or direction to

any party other than the direction to pay a monetary amount. Judgment

RQWKHDZDUGUHQGHUHGE\WKHDUELWUDWRUZLOOEHELQGLQJDQGȴQDOH[FHSW

for any right of appeal provided by the Federal Arbitration Act, and may

be entered in any court having jurisdiction. Except as may be required by

law, neither you nor VIZIO nor an arbitrator may disclose the existence,

content, or results of any arbitration under this warranty without the

prior written consent of you and VIZIO.

ANY DISPUTE, WHETHER IN ARBITRATION, IN COURT, OR OTHERWISE,

WILL BE CONDUCTED SOLELY ON AN INDIVIDUAL BASIS. VIZIO AND YOU

AGREE THAT NO PARTY WILL HAVE THE RIGHT OR AUTHORITY FOR ANY

DISPUTE TO BE ARBITRATED AS A CLASS ACTION, A PRIVATE ATTORNEY

GENERAL ACTION, OR IN ANY OTHER PROCEEDING IN WHICH EITHER

PARTY ACTS OR PROPOSES TO ACT IN A REPRESENTATIVE CAPACITY.

NO ARBITRATION OR PROCEEDING WILL BE JOINED, CONSOLIDATED,

OR COMBINED WITH ANOTHER ARBITRATION OR PROCEEDING

WITHOUT THE PRIOR WRITTEN CONSENT OF ALL PARTIES TO ANY SUCH

ARBITRATION OR PROCEEDING.

Exceptions to Binding Arbitration Agreement and Class Action Waiver

IF YOU DO NOT WISH TO BE BOUND BY THE BINDING ARBITRATION

AGREEMENT AND CLASS ACTION WAIVER, THEN: (1) you must notify

VIZIO in writing within sixty (60) days of the date that you purchased the

SURGXFW\RXUZULWWHQQRWLȴFDWLRQPXVWEHPDLOHGWR9Ζ=Ζ2DW7HVOD

ΖUYLQH&$$WWQ/HJDO'HSDUWPHQWDQG\RXUZULWWHQQRWLȴFDWLRQ

must include (a) your name, (b) your address, (c) the date you purchased

the product, and (d) a clear statement that you wish to opt out of the

binding arbitration agreement and class action waiver.

In addition, you may pursue a claim in small claims court in your county of

residence (if in the United States) or in Orange County, California. In such

case the provisions of the section titled “Binding Arbitration Agreement;

Class Action Waiver (U.S. Residents)” will not apply.

Exclusions and Limitations

TO THE GREATEST EXTENT PERMITTED BY APPLICABLE LAW, THERE ARE

NO EXPRESS WARRANTIES OTHER THAN THOSE DESCRIBED ABOVE.

ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WILL BE

LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE.

SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS ON HOW

LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY

NOT APPLY TO YOU.

VIZIO WILL NOT BE RESPONSIBLE FOR LOSS OF USE, LOSS OF

INFORMATION OR DATA, COMMERCIAL LOSS, LOST REVENUE OR

LOST PROFITS, OR OTHER INDIRECT, SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES, EVEN IF VIZIO HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES, AND EVEN IF THE REMEDY FAILS OF ITS

ESSENTIAL PURPOSE. SOME STATES AND PROVINCES DO NOT ALLOW

THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL

DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY

TO YOU.

IN LIEU OF ANY OTHER REMEDY FOR ANY AND ALL LOSSES AND DAMAGES

RESULTING FROM ANY CAUSE WHATSOEVER (INCLUDING VIZIO’S

NEGLIGENCE, ALLEGED DAMAGE, OR DEFECTIVE GOODS, NO MATTER

WHETHER SUCH DEFECTS ARE DISCOVERABLE OR LATENT), VIZIO MAY,

AT ITS SOLE AND EXCLUSIVE OPTION AND IN ITS DISCRETION, REPAIR

OR REPLACE YOUR PRODUCT, OR REFUND ITS PURCHASE PRICE. AS

NOTED, SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION

OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE

ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

How the Law Applies

7KLVZDUUDQW\JLYHV\RXVSHFLȴFOHJDOULJKWVDQG\RXPD\DOVRKDYHRWKHU

rights, which vary from state to state and province to province. This

warranty applies to the greatest extent permitted by applicable law.

General

No employee or agent of VIZIO may modify this warranty. If any term of this

warranty, other than the class action waiver, is found to be unenforceable,

that term will be severed from this warranty and all other terms will

UHPDLQLQH΍HFWΖIWKHFODVVDFWLRQZDLYHULVIRXQGWREHXQHQIRUFHDEOH

then the entire section titled “Binding Arbitration Agreement; Class Action

Waiver (U.S. Residents Only)” will not apply. This warranty applies to the

maximum extent not prohibited by law.

Changes to Warranty

7KLVZDUUDQW\PD\FKDQJHZLWKRXWQRWLFHEXWDQ\FKDQJHZLOOQRWD΍HFW

your original warranty. Check www.vizio.com for the most current version.

VIZIO PRODUCT, PLEASE READ THIS WARRANTY CAREFULLY. IF YOU

DO NOT AGREE TO THE TERMS OF THIS WARRANTY, DO NOT USE

THE VIZIO PRODUCT AND, WITHIN THIRTY (30) DAYS OF THE DATE

OF PURCHASE, RETURN IT FOR A REFUND TO THE AUTHORIZED

RETAILER WHERE YOU PURCHASED IT.

Warrantor

The warrantor under this warranty is VIZIO Sales & Marketing

Mexico S. de R.L. de C.V.

How Long This Warranty Lasts

For non-commercial use, VIZIO warrants the product on the terms

set forth below for one (1) year from the date of original purchase.

For commercial use, VIZIO warrants this product on the terms set

forth below for ninety (90) days from the date of original purchase.

What This Warranty Covers

VIZIO warrants the product against defects in materials and

workmanship when the product is used normally in accordance

with VIZIO’s user guides and manuals.

Except where restricted by law, this warranty applies only to the

original purchaser of a new product. The purchase must have been

made from an authorized retailer in Mexico. The product must also

be located in Mexico at the time of warranty service.

Zero Bright Pixel Defect Guarantee (Displays Only)

Your product may qualify for a warranty against “zero bright pixel”

defects for the duration of the warranty on select new product

purchases. To determine if this guarantee applies to your product,

refer to the model’s product information page at www.vizio.mx,

look for the “zero bright pixel” guarantee on the box, or contact

VIZIO Technical Support at the email address or telephone number

below.

How to Get Service

Before obtaining warranty service, you may visit www.vizio.

mx for additional help and troubleshooting. To obtain warranty

service, contact VIZIO Technical Support via email at serviciovizio@

warrantyserviceslatinamerica.com or via phone at 01-800-801-

0096 or 001-855-472-7444. The VIZIO Technical Support hours are

9:00AM to 6:00PM Monday through Friday, Central Standard Time.

Your Obligations Before Service

You must obtain pre-authorization before sending your product to

a VIZIO service center. You may be required to supply a purchase

receipt (or copy) to show that the product is within the warranty

period.

When you return a product to a VIZIO service center, you must ship

WKHSURGXFW LQLWVRULJLQDOSDFNDJLQJRULQSDFNDJLQJWKDWD΍RUGV

an equal degree of protection. VIZIO Technical Support will provide

instructions for packing and shipping the product to the VIZIO

service center.

ALL USER DATA AND DOWNLOADED APPLICATIONS STORED ON

A PRODUCT WILL BE DELETED IN THE COURSE OF SOME IN-HOME

AND ALL SHIP-IN WARRANTY SERVICE. If this occurs, your product will

be restored to its original state. You will be responsible for restoring

all applicable user data and downloaded applications. Recovery

and reinstallation of user data and downloaded applications is

not covered under this warranty. In order to protect your personal

information, VIZIO recommends that you always clear all personal

information from the product before it is serviced, regardless of

the servicer.

VIZIO’s Responsibilities

If VIZIO determines that a product is covered by this warranty, VIZIO

will (at its option) repair or replace it, or refund the purchase price to

you. There will be no charge for parts or labor during the warranty

SHULRG 5HSODFHPHQW SDUWV PD\ EH QHZ RU UHFHUWLȴHG DW 9Ζ=Ζ2ȇV

option and sole discretion. Replacement parts and VIZIO’s labor are

warranted for the remaining portion of the original warranty or for

ninety (90) days from warranty service, whichever is longer.

Types of Service

Displays that are 32 inches or larger will usually be serviced in-

home. In-home service requires complete and easy access to the

product and does not include de-installation or re-installation of

the product. In-home service is subject to availability. VIZIO will

provide other service options when in-home service is not available.

All other VIZIO products must be sent to a VIZIO service center to

obtain warranty service. VIZIO is not responsible for transportation

costs to the service center, but VIZIO will cover return shipping to

the customer.

What This Warranty Does Not Cover

This warranty does not cover: (a) cosmetic damage; (b) normal

wear and tear; (c) improper operation; (d) improper voltage supply

or power surges; (e) signal issues; (f) damage from shipping; (g)

DFWV RI*RG K FXVWRPHUPLVXVHPRGLȴFDWLRQVRUDGMXVWPHQWV

(i) installation, set-up, or repairs attempted by anyone other than

by a VIZIO authorized service center; (j) products with unreadable

or removed serial numbers; (k) products requiring routine

maintenance; or (l) products sold “AS IS”, “CLEARANCE”, “FACTORY

RECERTIFIED”, or by a non-authorized reseller.

:KDWWR'RΖI<RX$UH1RW6DWLVȴHG:LWK6HUYLFH

If you feel VIZIO has not met its obligations under this warranty,

you may attempt to resolve the issue informally with VIZIO. If you

DUHXQDEOHWRUHVROYHWKHLVVXHLQIRUPDOO\DQGZLVKWRȴOHDIRUPDO

claim against VIZIO, you may do so.

Exclusions and Limitations

TO THE GREATEST EXTENT PERMITTED BY APPLICABLE LAW, THERE

ARE NO EXPRESS WARRANTIES OTHER THAN THOSE DESCRIBED

ABOVE. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED

WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, WILL BE LIMITED IN DURATION TO THE WARRANTY

PERIOD SET FORTH ABOVE. SOME STATES AND PROVINCES DO

NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY

LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

VIZIO WILL NOT BE RESPONSIBLE FOR LOSS OF USE, LOSS OF

INFORMATION OR DATA, COMMERCIAL LOSS, LOST REVENUE OR

LOST PROFITS, OR OTHER INDIRECT, SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES, EVEN IF VIZIO HAS BEEN ADVISED OF

Mexico Limited Warranty

THE POSSIBILITY OF SUCH DAMAGES, AND EVEN IF THE REMEDY

FAILS OF ITS ESSENTIAL PURPOSE. SOME STATES AND PROVINCES

DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR

EXCLUSION MAY NOT APPLY TO YOU.

IN LIEU OF ANY OTHER REMEDY FOR ANY AND ALL LOSSES AND

DAMAGES RESULTING FROM ANY CAUSE WHATSOEVER (INCLUDING

VIZIO’S NEGLIGENCE, ALLEGED DAMAGE, OR DEFECTIVE GOODS,

NO MATTER WHETHER SUCH DEFECTS ARE DISCOVERABLE OR

LATENT), VIZIO MAY, AT ITS SOLE AND EXCLUSIVE OPTION AND IN

ITS DISCRETION, REPAIR OR REPLACE YOUR PRODUCT, OR REFUND

ITS PURCHASE PRICE. AS NOTED, SOME STATES AND PROVINCES

DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR

EXCLUSION MAY NOT APPLY TO YOU.

How the Law Applies

7KLV ZDUUDQW\ JLYHV \RX VSHFLȴF OHJDO ULJKWV DQG \RX PD\ DOVR

have other rights, which vary from state to state and province to

province. This warranty applies to the greatest extent permitted by

applicable law.

General

No employee or agent of VIZIO may modify this warranty. If any

term of this warranty is found to be unenforceable, that term will

be severed from this warranty and all other terms will remain in

H΍HFW7KLVZDUUDQW\DSSOLHVWRWKHPD[LPXPH[WHQWQRWSURKLELWHG

by law.

Changes to Warranty

This warranty may change without notice, but any change will not

D΍HFW \RXU RULJLQDO ZDUUDQW\ &KHFN ZZZYL]LRP[ IRU WKH PRVW

current version.

INFORMATION EXCLUSIVELY FOR MEXICO

To make a warranty claim, or to obtain parts, components, supplies

and accessories, you may contact the importer of record, the

warranty service provider, or the establishment from whom you

purchased the VIZIO product.

Importer of Record

VIZIO Sales & Marketing Mexico S. de R.L. de C.V.

PRESIDENTE MASARYK 111 PISO 1

COL. POLANCO V SECCIÓN

DELEGACION MIGUEL HIDALGO, MEXICO D.F. 11560

Warranty Service Provider

Warranty Support LATAM SA de C.V.

Calle Nubes No. 412

Col. Jardines del Moral

Leon Gto. Mexico, C.P. 37160

01-800-801-0096 or 001-855-472-7444

Date of purchase:

Model:

Brand:

To make a warranty claim, present your product and either this

warranty, duly stamped by the establishment from whom you

purchased the VIZIO product, or a valid invoice or receipt showing

the date of purchase.

Under the terms of this warranty, VIZIO or its representative must

exchange parts and components of the product and include labor

and shipping expenses of the product on which this warranty is

valid, within the service network, at no cost to the consumer.

VIZIO is not obligated to honor the warranty in the following cases.

(a) When the product has been used under other than normal

conditions.

(b) When the product has not been operated according to the

accompanying instructions for use.

authorized by VIZIO or the respective seller.

DLegal Information

Software Licenses

All software is provided subject to a software license agreement(s)

and you agree that you will be bound by such license agreement(s)

in addition to these terms. Your use of this product is subject to VIZIO’s

at http://www.vizio.com/privacy.

Export Regulations

Customer acknowledges that the VIZIO products, which include

technology and software, are subject to customs and export control

laws in the United States (“US”). The products may also be subject to

the customs and export control laws and regulations of the country

in which the products are manufactured and/or received.

Internet Connectivity

Network conditions, environmental and other factors may negatively

D΍HFWFRQQHFWLYLW\DQGWKHUHVXOWLQJYLGHRTXDOLW\LIDQ\

The applications and content of the applications pictured herein or

described in accompanying documentation may only be available

LQ FHUWDLQ FRXQWULHV RU ODQJXDJHV PD\ UHTXLUH DGGLWLRQDO IHHV

or subscription charges, and may be subject to future updates,

PRGLȴFDWLRQV RU GLVFRQWLQXDWLRQ ZLWKRXW QRWLFH 9Ζ=Ζ2 KDV QR

control over third party applications or content and assumes

no responsibility for the availability or interruption of such

applications or content. Additional third party terms, conditions and

restrictions apply. Information in this Quick Start Guide is subject

to change without notice. To review the most updated version

of this Quick Start Guide and the associated User Manual, go to

http://www.vizio.com.

This Quick Start Guide may not be copied in whole or in part

without the written permission of VIZIO, Inc. VIZIO, Inc. has made

UHDVRQDEOH H΍RUWV WR HQVXUH WKH DFFXUDF\ RI WKH LQIRUPDWLRQ

SURYLGHGKHUHLQ$OOSURGXFWVSHFLȴFDWLRQVIXQFWLRQDOLW\IHDWXUHV

FRQȴJXUDWLRQVSHUIRUPDQFHGHVLJQDQGRWKHUSURGXFWLQIRUPDWLRQ

described herein are subject to change without notice. VIZIO, Inc.

is not responsible for typographical, technical, or descriptive errors.

VIZIO, the VIZIO logo, the V logo, and other terms and phrases are

trademarks or registered trademarks of VIZIO, Inc.

+'0Ζ+'0Ζ+LJK'HȴQLWLRQ0XOWLPHGLDΖQWHUIDFHDQGWKH+'0Ζ

Logo are trademarks or registered trademarks of HDMI Licensing

LLC.

The Bluetooth® word mark and logos are registered trademarks

owned by Bluetooth SIG, Inc. Used under license.

For DTS patents, see http://patents.dts.com. Manufactured under

license from DTS Licensing Limited. DTS, the Symbol, & DTS and

the Symbol together are registered trademarks, and DTS Studio

Dolby and the double-D symbol are registered trademarks of

Dolby Laboratories.

Other names of companies, products, and services used in this

Quick Start Guide may be trademarks, trade names or service marks

of others and VIZIO, Inc. dis- claims any interest in trademarks, trade

names or service marks other than its own. Mention of non-VIZIO

products is for informational purposes only.

Caution: $YRLG H[SRVLQJ D GULYH WR PDJQHWLF ȴHOGV

6HFXULW\ GHYLFHV ZLWK PDJQHWLF ȴHOGV PD\ LQFOXGH

airport walk-through devices and security wands.

Airport conveyor belts or similar security devices that

check carry-on luggage generally use X-rays and should

not cause magnetic damage to drives.

If you are traveling internationally, check the customs regulations

for device use for each country you will visit, and check the power

FRUGDQGDGDSWHUUHTXLUHPHQWVIRUHDFKORFDWLRQLQZKLFK\RXSODQ

WRXVHWKHFRPSXWHUDVYROWDJHIUHTXHQF\DQGSOXJFRQȴJXUDWLRQV

may vary.

Warning:7RUHGXFHULVNRIHOHFWULFVKRFNȴUHRU

damage to your device or other property, do not

attempt to power the device with a voltage converter

kit sold

for appliances.

Battery Disposal

Caution: Battery cells may explode. Do not dispose of

WKHEDWWHU\LQDȴUHRUZLWKRUGLQDU\KRXVHKROGZDVWH

Dispose of batteries promptly. Replace the battery

RQO\ ZLWK WKH VDPH RU HTXLYDOHQW W\SH RI EDWWHU\

recommended by VIZIO.

11062015AD-US-NC

Vizio D39h-D0 Television D Series

Product's Documents

User Manual

Specifications

Vizio D39h-D0 Questions and Answers

#1 Is resolution 1080 ?

#2 Does this tv have an audio optical cable output to connect with surround sound or external speakers?

Related Products

Vizio Television E Series E420VP

Vizio Television E Series E370VP

Vizio Television E Series E320ME

Vizio Television M Series M320SR

Vizio Television E Series E551VA

Vizio Television E Series E552VL
