Blomberg WMD24400W 24'' Front Loading Automatic Washer-Dryer User Manual

WMD24400W

Front-Loading Automatic

Washer-Dryer

Owner’s Guide & Installation

Instructions

To prevent accidents and machine damage, read these

instructions before installation or use. Use the washer-dryer

only as instructed in this owner’s guide and installation

instructions included with your product. Keep this guide for

future reference

As an ENERGY STAR® partner,

BLOMBERG has determined that this

product meets the ENERGY STAR®

guidelines for energy efficiency.

2 / English

Front-Loading Automatic Washer-Dryer

Please read this guide first!

Dear Customer,

We hope that your product which has been manufactured in modern

facilities and passed through a strict quality control procedure will give

you the best results.

Therefore, we advise you to read through this document carefully

before using your product and keep it for future reference.

This guide will…

…help you use your washer-dryer in a fast and safe way.

• Pleasereadtheguidebeforeinstallingandstartingyourwasher-

dryer.

• Particularlyfollowtheinstructionsrelatedtosafety.

• Keepthisguidewithineasyreach.Youmayneeditinthefuture.

• Pleasereadalladditionaldocumentssuppliedwiththiswasher-

dryer.

Pleasenotethatthisowner’sguide&installationinstructionsmaybe

applicable for several other models. Differences between models will

be identified in the guide.

Owner’s Guide & Installation Instructions

3 / English

Explanation of symbols

Throughout this guide the following symbols are used:

CAUTION

• Important information or useful hints about usage.

WARNING

• Warning for hazardous situations with regard to life and property.

WARNING

• Warning for electrical shock

•Allergy UK, is the brand of British Allergy Association. Their

main endorsement is the ‚Seal of Approval‘. When you see

a product with this logo on it, you have the reassurance the

product has been scientifically tested to prove it is efficient

at reducing/removing allergens from the environment

of allergy and asthma sufferers or the products have

significantly reduced allergen/chemical content.

If you have questions, call:

Call Center (toll free number)

1-800-459-9848 (USA)

or send e-mail to:

[email protected]

For the list of dealers/retailers, distributors and authorized service

agents, visit:http://www.blombergappliances.com

Pleasefillintheinformationbelowforfuturereference.

Model no.:

Serial no.:

Purchasedate:

4 / English

Front-Loading Automatic Washer-Dryer

TABLE OF CONTENTS

1 Your Washer-dryer 6

Overview .......................................................6

Specifications ....................................................8

2 Important Safety Instructions 9

3 Installation Instructions 14

The Right Location of Installation ....................................14

Installation Clearances ............................................15

Allowable Clearances for Undercounter Installation.......................16

Allowable Clearances for Closet Installation ............................16

Removing packaging reinforcement ..................................17

Removing shipping bolts ..........................................18

Leveling the product..............................................19

Electrical Connection .............................................19

Powersupplyandcircuit ..........................................21

Water Supply Connection..........................................22

Drainage.......................................................24

Installation Checklist ..............................................25

Transportation ..................................................25

Disposal Information..............................................26

Appliance Disposal ...............................................26

4 Operating Instructions 27

First Use.......................................................27

Laundry Tips ...................................................28

Preparingthelaundry .............................................30

Loading the washer ..............................................31

Detergent Use ..................................................32

Detergent Quantity ...............................................33

Detergent Dispenser..............................................34

(II) Main Wash Detergent Compartment ...............................35

Liquid Fabric Softener Compartment .................................35

Using liquid detergents ............................................36

(I) Liquid Chlorine Bleach Compartment ...............................36

Water Consumption ..............................................37

5 Selecting a Program and Operating Your Washer-Dryer 38

Control panel ...................................................38

Display symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Preparingthemachine ............................................39

Programandconsumptiontable ....................................40

Selecting the washing program .....................................42

Owner’s Guide & Installation Instructions

5 / English

TABLE OF CONTENTS

Washing programs ..............................................42

Temperature selection ............................................47

Spin speed selection .............................................48

Drying programs.................................................51

Washing and drying programs ......................................52

Auxiliary function selection .........................................54

Drying steps ....................................................56

Time display ....................................................57

End Time ......................................................57

6 Preparation 59

Starting the program .............................................59

Loading door locking system .......................................60

Adding or taking out laundry........................................60

Changing the selections after program has started .......................61

Child Lock .....................................................62

Cancelling the program ...........................................64

Re-spinning the laundry ...........................................64

End of program .................................................65

Energy saving mode..............................................65

7 User maintenance instructions 66

Cleaning detergent dispenser .......................................66

Cleaning the door seal ............................................67

Cleaning the drum ...............................................67

Cleaning the outer cabinet and control panel ...........................68

Cleaning the water inlet strainers ....................................68

Cleaning the drain pump filter ......................................69

Descaling the washer-dryer ........................................71

8 Troubleshooting 72

9 WARRANTY STATEMENT FOR THE BLOMBERG CLOTHES

WASHER-DRYER 87

10 HOW TO GET SERVICE 88

6 / English

Front-Loading Automatic Washer-Dryer

1 Your Washer-dryer

Overview

1-Powercable

2- Top panel

3- Control panel

4- Drain hose

5- Loading door

6- Filter cap

7- Adjustable feet

8- Detergent drawer

Owner’s Guide & Installation Instructions

7 / English

Your Washer-Dryer

Package contents

Powercable

Water discharge hose

Transit bolts

Mains water inlet hose

Liquid detergent container (*)

User manual

Plasticpluggroup

CAUTION

• Figures in this manual are schematic and may not match the

product exactly.

(*) This may be supplied with the machine depending on the model of your

product.

8 / English

Front-Loading Automatic Washer-Dryer

Your Washer-Dryer

Specifications

Specifications of this appliance may change without notice to improve

the quality of the product. Figures in this guide are schematic and

may not match your product exactly.

Values stated on the product labels or in the documentation

accompanying it are obtained in laboratory in accordance with the

relevant standards. Depending on operational and environmental

conditions of the appliance, these values may vary.

Front Loading Automatic

Washer-Dryer

Models WMD24400W

Height (in) / (cm) 33.1 / 84

Width (in) / (cm) 23.6 / 60

Depth (in) / (cm) 23.2 / 59

Net Weight (lbs) / (kg) 158.7 / 72

Electricity (V/Hz.) 208-240 / 60

Total Current (A) 10

TotalPower(W) 2000-2350

Spinning cycle (rpm max.) 1400

Water pressure (psi) / (bar) (15-145) / (1-10)

Drain height (ft.) / (m.) 4.9 / 1.5

Declared capacity (cu. Ft.) 2.5

Rated capacity-Washing (lbs)/(kg) 17.6 / 8

Rated capacity-Drying (lbs)/(kg) 11.0 / 5

Owner’s Guide & Installation Instructions

9 / English

2 Important Safety Instructions

WARNING

• To reduce the risk of fire, electric shock or injury to persons while

using your appliance follow basic safety precautions, including

the following:

• Readallinstructionsbeforeusingthewasher-dryer.

• Donotwashordryarticlesthathavebeenpreviouslycleaned

in, washed in, soaked in, or spotted with gasoline, dry-cleaning

solvents, or other flammable or explosive substances (acetone,

alcohol, kerosene, some liquid household cleaners, some spot

removers, turpentine, waxes and wax removers) as they give off

vapors that could ignite or explode.

• Donotaddgasoline,dry-cleaningsolvents,orotherflammableor

explosive substances to the wash water. These substances give off

vapors that could ignite or explode.

• Undercertainconditions,hydrogengasmaybeproducedina

hot-water system that has not been used for 2 weeks or more.

HYDROGENGASISEXPLOSIVE.Ifthehot-watersystemhasnot

been used for such a period, before using a washing machine, turn

on all hot-water faucets and let the water flow from each for several

minutes. This will release any accumulated hydrogen gas. As the

gas is flammable, do not smoke or use an open flame during this

time.

• Donotallowchildrentoplayonorintheappliance.Close

supervision of children is necessary when the appliance is used

near children.

• Beforetheapplianceisremovedfromserviceordiscarded,remove

the door and the power cord / main plug to prevent accidents.

• Donotreachintotheapplianceifthedrumismoving.Waituntilthe

drum has completely stopped before opening the door.

• Donotinstallorstorethisappliancewhereitwillbeexposedtothe

weather and direct sunlight.

• Donottamperwithcontrols.

10 / English

Front-Loading Automatic Washer-Dryer

Important Safety Instructions

• Donotrepairorreplaceanypartoftheapplianceorattemptany

servicing unless specifically recommended in the user-maintenance

instructions or in published user-repair instructions that you

understand and have the skills to carry out.

• Thisappliancemustonlybeusedforthepurposeofwashing,

rinsing and spinning machine-washable items using laundry

additives that are suitable for use in washers . The appliance

manufacturer cannot be held responsible for damage caused by

improper or unintended use of the appliance.

• Onlydetergents,softenersandadditivessuitableforusein

HE (High-efficiency) washers may be used. Always follow the

instructions and information given by the laundry detergent

manufacturers when using these products.

• Alwaysfollowthefabriccareinstructionsofgarmentmanufacturers.

• Donottouchthedoorglasswhilerunningathightemperatures.

Danger of burning!

• Donotsitontopoftheproduct.

• Donotclimbontotheproduct.

• Destroytheshippingcarton,plasticbagandotherpacking

materials after the product is unpacked. Keep children away from

these packing materials. Danger of suffocation from plastic sheets

and cartons!

• Donotmixchlorinebleachwithammoniaoracidssuchasvinegar

and/or rust remover when washing. This mixture can produce

hazardous fume which may cause death.

• Donotoperatethisapplianceifitisdamaged,malfunctioning,

partially disassembled, or has missing or broken parts, including a

damaged cord or plug.

Owner’s Guide & Installation Instructions

11 / English

Important Safety Instructions

• Storelaundrydetergentsandadditivesinacool,dryplaceout

of children’s reach due to danger of chemical poisoning and skin

irritation. Follow the manufacturers’ instructions when using laundry

products.

• Donotwashordryfiberglassmaterials.Smallparticlescanstickto

fabrics while running and may lead to skin irritation.

• Donotwashordryitemsstainedwithvegetableoil,cookingoil

or petroleum. These items may contain some flammable oils after

laundering and the fabric may smoke or catch fire by itself.

• Besuretounplugthepowercablebeforeattemptingmaintenance

or cleaning of your appliance to minimize the risk of electric shock.

Always unplug the cable by grasping the plug, not the cord.

• Donotusewethandswhenplugging/unpluggingthepowercable.

• Checkthewaterinletanddrainhoseconnectionsregularlyforany

leakage. Hoses should be replaced every 5 years.

• Donotleavetheproductdooropentopreventchildrenhurt

themselves by hanging on the door or going inside the drum.

• Becarefulwhentheapplianceisdraininghotwater.Dangerof

burning!

• Attheendofawashingday,turnoffthewaterfaucetstoprevent

any leakage that may occur due to a faulty condition of the

appliance.

• Checktheapplianceandinlethoseconnectionsforwaterleakage

after each use. If there is leakage, turn off the appliance and water

faucets and call service.

• Donotmachinewashordryitemshavinglargeorheavymetalparts

such as buttons or buckles. These items could severely damage the

appliance.

• Alwaysbesuretoemptyallforeignmaterialsfromthepocketsof

your clothing as small items such as coins, pins etc. could severely

damage the appliance.

• Donotinstallandoperatetheapplianceinplacesexposedto

temperatures below freezing. Frozen water may cause severe

damage by bursting hoses and pump.

12 / English

Front-Loading Automatic Washer-Dryer

Important Safety Instructions

• Makesurethatshippingboltsareremovedbeforeyouoperatethe

product. If service is required as a result of not removing the bolts, it

will not be covered by the warranty.

• Makesurethatthedrumisemptybeforeyouloadtheproduct.

• Donotstoreanduseanyflammableandcombustiblesubstances

such as lint, paper and chemicals near the appliance.

• Alwaysfollowthemanufacturer’sinstructionswhenyouareusing

a descaling agent. Be sure that descaling agent contains rust-

protective materials and rinse the washer a few times thoroughly

after the descaling process (See, Descaling the washer).

• Installandoperatetheproductonasolidfloortopreventvibration

or movement. It is not recommended to install and operate the

product on wooden floor or on a carpet.

• Theratedvoltageofyourwasheris208/240V,soitshouldnotbe

directly connected to the wall power of 110/120V.

• Ifanabnormalsoundisheardwhilerunning,refertothe

“Troubleshooting” of this guide.

• Callserviceforcheckinganypossibledamageorfaultifthe

appliance is dropped or bumped.

• Theendofdrainhoseshouldnotcontactthedischargewaterin

any way as this might cause siphoning of water.

• Alwaysleavethepropertyaftercheckingthattheprogramcycleis

completed and the product is turned off.

• Damagedorwornpowercordsandplugsmustonlybereplacedby

a Blomberg Service technician.

• Neveruseanextensioncordoradaptertoconnecttheapplianceto

the electrical power due to the risk of electric shock and/or fire.

• Allbrokenandfaultycomponents,panelsandpartsmustonlybe

replaced with original Blomberg spare parts by a Blomberg Service

technician.

• Donotforcetheproduct’sdoortoopenwhenitislocked.Thedoor

must be closed any time during the program cycle.

Owner’s Guide & Installation Instructions

13 / English

Important Safety Instructions

• Donotusefabricsoftenersorproductstoreducestaticunless

recommended by the manufacturers of the fabric softener product.

• Donotuseheattodryarticlescontainingfoamrubberorsimilarly

textured rubber-like materials.

• Donotplaceitemsexposedtocookingoilsinyourdryer.Items

contaminated with cooking oils may contribute to a chemical

reaction that could cause a load to catch fire. To reduce the risk of

fire due to contaminated loads, the final part of a tumble dryer cycle

occurs without heat (cool down period). Avoid stopping a tumble

dryer before the end of the drying cycle unless all items are quickly

removed and spread out so that the heat is dissipated.

• Checkthedrainpumpfilteroccasionallytoremovecoins,buttons

and such small objects.

• Alwaysdrainoffthewatercompletelybeforecleaningthepump

filter, before transporting the product, when there is a danger of

frost and when there is a power failure (For emergency draining, See

User maintenance instructions).

• Alwaysbesurethattheproducthasbeenproperlyinstalledby

licensed personnel, water and electrical connections and grounding

conform to all relevant codes and requirements.

• Thismanualdoesnotcovereverypossibleconditionandsituation

that may occur. Use common sense and caution when installing,

operating, and maintaining any appliance.

WARNING

• This product may contain chemicals known to the state of

California to cause cancer or birth defects or other reproductive

harm.

SAVE THESE INSTRUCTIONS

Always follow the instructions on this user guide. If you aren’t sure

how to perform them, please call Customer Service for assistance

and scheduling service.

14 / English

Front-Loading Automatic Washer-Dryer

3 Installation Instructions

Read this first !

Install the clothes dryer according to the manufacturer’s instructions

and local codes.

This product can be individually installed in free-standing and built-

in installations. Before you install your appliance, read the following

instructions completely and carefully:

• Savetheseinstructionsforfuturereference.

• Thisappliancemustbeproperlyinstalledandgroundedbyqualified

and skilled technicians in accordance with all local codes and

ordinances and the latest edition of the National Electrical Code,

ANSI/NFPA70.

• Properinstallationofthisapplianceistheresponsibilityofthe

owner and failure due to improper installation is not covered by the

warranty.

The Right Location of Installation

Youcaninstallyourproductinabasement,closetorinalaundry

room if the location has proper drainage, plumbing and power supply

system. Always follow these instructions for installation:

• Donotinstallorstorethisappliancewhereitwillbeexposedto

the weather, rain, damp places, water and direct sunlight. The

ambient temperature must be higher than 60°F (15.6°C) for proper

operation. Installation location must have the proper ventilation.

• Donotstoreanduseanyflammableandcombustiblesubstances

such as lint, paper, curtains, gasoline, coal and liquid or vapor

chemicals near the appliance.

• Installandoperatetheproduct on a strong solid concrete floor to

prevent vibration, noise or movement in case of load unbalance.

The floor must have sufficient load carrying capacity and the

product must be leveled properly before the operation.

Owner’s Guide & Installation Instructions

15 / English

Installation Instructions

• Itisnotrecommendedtoinstallandoperatetheproduct on a

wooden floor or soft floor. If you have to install your product on a

wooden or frame construction floor, the floor must be reinforced

properly and the product must be located in the corner of the room

if possible.

• Neverplaceyourproduct on a carpet. This prevents air circulation.

The electrical components of the machine may overheat and cause

damage.

• Donotstandapplianceonthepowercable.

• Donotinstallandoperateyourproduct in ambient temperatures

lower than 32˚F (0˚C). Controls may stop working properly in such

condition.

• Ifthereisdangeroffrost,drainallremainingwaterinpumpand

hoses since it may freeze and cause damage by bursting them (see

“Cleaning the drain pump filter”).

Installation Clearances

CAUTION

• The installation location must be large enough for the product

door to be fully opened for loading.

• The installation location must be large enough for ease of

operation, maintenance and service.

• Ensure there is min 1/2” of clearance on each side of the product

to allow slight sideways movement during washing and spin

drying.

16 / English

Front-Loading Automatic Washer-Dryer

Installation Instructions

Allowable Clearances for Undercounter Installation

The dimensions are for the recommended spacing. Counter depth

should be 23.5-24.5”(60-62 cm).

Custom undercounter installation – Washer-Dryer only

Allowable Clearances for Closet Installation

When installed in closet:

Sides, Rear, Front 1/2 in. (1.27 cm), Top= 1 in. (2.54 cm)

Closet door ventilation requirement: A louver having minimum 23 in2

(148 cm2) air opening located at 3 in (7.62 cm) from the bottom of

closet door.

Owner’s Guide & Installation Instructions

17 / English

Installation Instructions

Removing packaging reinforcement

Tilt the product to remove the packaging reinforcement. Remove the

packaging reinforcement by pulling the ribbon.

18 / English

Front-Loading Automatic Washer-Dryer

Installation Instructions

Removing shipping bolts

WARNING

• Shipping bolts must be removed before operating the product!

Otherwise, the appliance will be damaged seriously!

1.Loosen all the bolts with a spanner wrench until they rotate freely.

2.Remove the shipping bolts by turning them gently.

3.Bolt hole covers (supplied in the bag with the owner’s guide)

are fitted into the holes on the rear panel with a special lock

mechanism. To fit the cover, first insert it into the hole and then

rotate it counterclockwise with a screwdriver until it is locked. To

unlock, apply the procedure in reverse.

CAUTION

• Keep the shipping bolts in a safe place to reuse when the product

needs to be moved again in the future.

• Never move the appliance without shipping bolts properly fixed in

place!

Owner’s Guide & Installation Instructions

19 / English

Installation Instructions

Leveling the product

WARNING

• Do not use any tools to loosen the lock nuts. Otherwise, they

can be damaged.

1.Manually (by hand) loosen the lock nuts on the feet.

2.Adjust them until the washer stands level and firmly.

3.Important: Tighten all lock nuts up again.

Electrical Connection

Grounding Instructions

This appliance must be grounded. In the event of malfunction or

breakdown, grounding will reduce the risk of electric shock by

providing a path of least resistance for electric current. This appliance

is equipped with a cord having an equipment-grounding conductor

and a grounding plug. The plug must be plugged into an appropriate

outlet that is properly installed and grounded in accordance with all

local codes and ordinances and the latest edition of the National

ElectricalCode,ANSI/NFPA70.

20 / English

Front-Loading Automatic Washer-Dryer

Installation Instructions

WARNING

• Improper connection of the equipment-grounding conductor can

result in a risk of electric shock. Check with a qualified electrician

or serviceman if you are in doubt as to whether the appliance is

properly grounded.

• Do not modify the plug provided with the appliance – if it will

not fit the outlet, have a proper outlet installed by a qualified

electrician.

• Be sure that the power cord is always accessible by the user

after the appliance is installed.

• Never use an extension cord or adapter to connect the appliance

to the electrical power due to the risk of electric shock and/or

fire.

• It is the personal responsibility and obligation of the appliance

owner to provide a proper and grounded outlet installed by a

qualified electrician.

• Never use a damaged power cord since there is a risk of electric

shock and/or fire.

• The damaged power cord must be replaced by a qualified

electrician as soon as possible.

• Do not use wet hands when plugging/unplugging the power

cable.

• Electrical supply voltage must conform to the voltage

specifications (208-240V, 60Hz) located on the appliance.

• Only one appliance must be connected to a properly grounded

individual branch circuit outlet.

• Be sure to unplug the power cable before attempting

maintenance or cleaning of your appliance to minimize the risk of

electric shock. Always unplug the cable by grasping the plug, not

the cord.

• Do not use wet hands when plugging/unplugging the power

cable.

Owner’s Guide & Installation Instructions

21 / English

Installation Instructions

Power supply and circuit

Important:

• Wallpowerconnectionshouldcomplywithnationalregulations.

• Thewiringfortheelectricaloutletcircuitmustbesufficienttomeet

theappliancerequirements.UseofaGroudFaultCircuitInterrupter

(GFCI)isrecommended.

• Thevoltageandmaximumtotalcurrentarespecifiedinthesection

“Specifications”.

• Theappliancemustnotbedirectlyconnectedtothewallpowerin

case of absence of junction box.

• Connectionviaextensioncordsormulti-plugsshouldnotbemade.

WARNING

• A damaged power cable must be replaced by a qualified

electrician.

• The appliance must not be operated unless it is repaired! There

is the risk of electric shock!

15 Amp. Fuse or circuit breaker, 208-240 volt, 60 Hz, grounded,

alternating current

Properlygrounded4-prongreceptacleistobelocatedsothepower

supply cord is accessible when the product is in installed position.

(A) After the shipping bolts hole covers are

fitted in the holes, the power supply hole cover

(supplied in the bag with the owner’ guide) has

to be fitted to the hole.

22 / English

Front-Loading Automatic Washer-Dryer

Installation Instructions

Water Supply Connection

Yourproductcomeswithbothcoldandhotwaterconnections.

Connect the blue marked cold water supply hose to the cold water

inlet valve/faucet and the red marked hot water intake hose to the

hot water inlet valve/faucet. Screw the connecting bolts by hand and

tighten the connection properly using a plier. Over tightening may

cause damage on bolted connection.

WARNING

• Be sure that the water connection of this product is handled by a

qualified service technician or a plumber.

The product has two bolted ½’’ water supply hoses and ¾’’ female

hose connections that can be connected to ¾’’ hot and cold water

faucets.

WARNING

• Be sure that there are rubber seals located on the hose

connections. These seals and adjustable bolts ensure a safe

connection without leaking. After the water connection is done,

turn on both water faucets slowly and completely to check any

water leaks.

• Be sure that water supply hoses are not crushed and they have

no kinking, bulges or cuts before the water connection.

Owner’s Guide & Installation Instructions

23 / English

Installation Instructions

The water pressure must be between 15-145 psi (1-10 bar) for the

proper operation of this washer. 1 bar corresponds to more than 2.1

gallons (8 liters) per minute flow rate with a fully open faucet. Water

inlet hoses and valves should withstand a water pressure of 145

psi (10 bar) at maximum. If the pressure is higher than 145 psi, a

pressure-reducing valve must be installed before the water inlet. If the

water pressure is lower than 15 psi (1 bar), water fill time may extend

or water inlet valve may shut off completely.

•Hot water supply temperature must not exceed 140˚F (60˚C). (Ideally

120˚F (48˚C))

• Donotconnectthewashertoanunpressurizedwaterboilersince

water pressure may not be adequate for proper operation.

• Donotremovethefilterslocatedonthewatersupplyhoses(on

faucet/hose and hose/inlet valve connections).

• Alwaysusegenuine“Blomberg”watersupplyhoseswhen

connecting with this product. Old or worn-out hoses must not be

reused. It is not advised to extend inlet or drain hoses, if necessary

consult your dealer or technical service about hose extensions.

• Hotandcoldwaterfaucetsmustalwaysbeeasilyaccessibletothe

user.

• Attheendofawashingday,turnoffwaterfaucetstopreventany

leakage or water damage that may occur due to a faulty condition

of the appliance.

• Checktheapplianceandinlethoseconnectionsforwaterleakage

after each use. If there is leakage, turn off the appliance and water

faucets and call service.

• Checkthewaterinletanddrainhoseconnectionsregularlyforany

leakage. Hoses should be replaced every 5 years.

• Ifthereisnohotwatersupply,hotwatervalvemustbeconnected

to a cold water faucet nevertheless. Both water valves should be

connected to water supply for proper operation of your washer.

24 / English

Front-Loading Automatic Washer-Dryer

Installation Instructions

Drainage

WARNING

• Drain hose should not be bent. Be sure that there are no kinks or

cuts on it.

• Drain hose outlet must not contact the drained water.

Drain hose may be connected into a sink, into the drain of a sink, to a

standpipe and floor drain.

• Whenconnectingintoasink,thedrainhoseshouldbeplacedatthe

edge of the sink and secured with the hose guide supplied by the

manufacturer. Additionally, the guided hose may be tied to the water

faucet with a strap for extra security.

• Drainhosemaybeconnectedintothedrainofasink.Besurethat

the connection is safe and not leaking. An additional clip etc can be

used for safe connection.

• Drainhosemayalsobeconnectedtoaminimum1.26in(32mm)

diameter stand pipe.

• Besuretosecurethedrainhosetightlytothepipe(standpipe,

drain pipe/edge of the sink) with a strap etc.

• Thehoseshouldbeplacedbetween16and39in.(40and100cm)

from the floor level

• Ifyouhavefloordrainsystem,youcanplacethedrainhoseinthe

hole located on the floor.

Owner’s Guide & Installation Instructions

25 / English

Installation Instructions

Installation Checklist

• Waterinlethoseandaccessorybagsmustberemovedfromthe

drum.

• Transportation/shippingboltsmustberemoved.

• Product must be properly leveled by using the adjustable feet.

• Waterinlethoseisconnectedtothewaterfaucet,securedand

checked for any leaks by turning on faucet.

• Draininstallationisdoneproperlyanddrainhoseischeckedand

secured to prevent any flooding.

• Product has to be plugged to a properly grounded live wall power

outlet.

• Besurethatpoweroutlet,waterfaucetsanddrainoutletmustbe

always accessible to the user.

Transportation

Before you transport the product, you should carry out the following:

1.Turn off both water faucets.

2.Before you disconnect the water inlet hoses, decrease the pressure

inside hoses by turning on the product choosing any wash

program.AssoonastheStart/Pause/Cancelledstartsblinking,

turnofftheappliance.Youmaysecurelydisconnectinlethoses

without any water gush.

3.Disconnect the drain hose and hang it on the back plate by inserting

into the holder plastic brackets.

4.Unplug the power cord and hang it on the back plate properly.

5.Remove bolt hole covers and reinstall shipping bolts to their places.

Youcanapplytheprocedureinchapter“Removingshippingbolts”

in reverse to accomplish this.

6.Be sure that rubber bushes are properly located in holes and bolts

are screwed back tightly for secure transportation of the appliance.

26 / English

Front-Loading Automatic Washer-Dryer

Installation Instructions

Disposal Information

Packing Disposal

WARNING

• Packingmaterialsoftheappliancearepotentiallydangerousfor

children. Materials such as plastic bags, films or wrappings must

be kept away from children or disposed properly to prevent the

danger of suffocation.

CAUTION

• Packingmaterialsaremadeofbiodegradableandrecyclable

substances.Youshouldconsultyourlocalauthorityordealer

about the environmental-friendly disposal of the packaging of

your appliance.

Appliance Disposal

WARNING

• Be sure to unplug the power cable, cut off the plug and disable

the door lock before you dispose your old appliance. Otherwise

there is a risk of injury for children and pets.

CAUTION

• Oldappliancescontainmanyrecyclableparts.Youshould

consult your local environmental authority about a proper

disposal. A proper disposal enables recycling therefore protects

the environment.

Owner’s Guide & Installation Instructions

27 / English

4 Operating Instructions

First Use

WARNING

• To reduce the risk of fire, electric shock, or injury to persons, read

theIMPORTANTSAFETYINSTRUCTIONSbeforeoperatingthis

appliance.

Before the first use,

• Besurethattheproduct is installed properly by a qualified installer

or service technician in accordance with all national and local codes

and requirements.

• Readallinstructionscarefullybeforeusingthewasher.

• Checkthatshippingboltsarecompletelyremoved.

• Besurethatthelocationofinstallationhasproperelectricalsupply

voltage and plumbing system needed for the operation of the

appliance.

• Turnonbothwaterfaucetsandbesurethattherearenoleakson

hose-faucet connection points or on hoses themselves.

• Checkthatthedrumisempty.

28 / English

Front-Loading Automatic Washer-Dryer

Operating Instructions

• Turnontheproduct, choose “"Tub Clean"” cycle on the program

selector knob and start the washer as empty and without any

laundry additives. When the cycle is finished, your product is ready

for subsequent uses.

WARNING

• Be sure that siiica gel package, which is located inside the drum,

hasbeenremovedfromthedrumbeforethefirstuse.Granules

in this package do not contain poisonous or harmful materials.

It is not a detergent and it is not adible. Do not swallow. Do not

use for any purpose. Throw into the recycle bin together with this

package before the first usage of the product.

Laundry Tips

Sorting the laundry

CAUTION

• Always follow the fabric care instructions of garment

manufacturers. These instructions would give you proper

guidance on suitable wash and drying cycles, operating

temperatures and bleach usage.

Owner’s Guide & Installation Instructions

29 / English

Operating Instructions

LAUNDRY WASH SYMBOLS

Machine

Wash

Symbols

Normal wash

No Iron

Sensitive-

Delicate

wash

Hand wash

Not washable

No Spin

WASH

Water

Temperatures

Maximum

C 70

C 60

C 50

C 40

C 30

Symbol(s)

lll

l l

lll l l l

Drying

Symbols

Suitable for

dryer

No Iron

Sensitive /

Delicate dry

Do not dry

with dryer

Do not dry

Do not dry-

clean

DRYING

Drying

Settings

At any temperature

At high temperature

At medium

temperature

At low temperature

Without heating

Hang to dry

Lay to dry

Hang wet to dry

Lay in shadow

to dry

Dry-cleanable

Iron -

IRON

Dry or Steam

Iron at high

temperature

Iron at medium

temperature

Iron at low

temperature

Do not iron

Iron without

steam

Maximum temperature

200

C 150

C 110

All bleaches are allowed

Bleach (sodium

hypochlorite)

can be used

Bleach is not

allowed

Only bleaches without

chlorine are allowed

BLEACH

CAUTION

• Wash “machine washable” or “hand washable” labelled products

only with an appropriate program. Dry these type of clothes by

hanging or laying down. Do not dry them in the machine.

30 / English

Front-Loading Automatic Washer-Dryer

Operating Instructions

Sort the laundry according to the following fabric types, color groups

and wash them separately:

 •Whiteandcolorfastfabrics

 •Non-fast,coloredfabrics

 •Permanentpressitems(mensshirt,dresspants,poly-cottonblends)

 •Delicatefabrics(silk,rayonetc.)

 •Woolens(onlywashwoolensthatarelabeled“machinewashable”

or “hand washable”

 •Handknits(Theyshouldbeplacedinsideoutinthewasher)

CAUTION

• Do not wash dark colors with light colors and whites. Color items

may bleed and white and light colored items may be discolored.

Avoid extended contact of damp clothes before or after washing

to prevent dye transfer.

• Wash heavily and lightly soiled items separately.

• Lint producers (towels, linen etc) and lint collectors (easy care,

permanent press) should be washed separately. Lint producers

should be washed inside-out.

Preparing the laundry

• Itemsoflaundrywithmetalparts(e.g.underwirebras,beltbuckles,

metal buttons) will damage the drum. Remove metal parts of place

the items in a cloth bag, pillow case, or something similar.

• Removeanynon-washableitemsandaccessoriesfromlaundry

before washing.

• Emptypockets,removeallforeignobjects(e.g.coins,pens,paper

clips). If possible: Turn pockets inside out and brush.

• Placesmallitemsoflaundry(e.g.tights)inaclothbag,pillowcase

or something similar. This can also help you to avoid searching for

lost socks.

• Handlecurtainsspecialcare.Removenon-stainlesscurtainrunners

andleadtape.Placerunnersthatcan’tberemovedinaclothbag,

pillow case or something similar.

Owner’s Guide & Installation Instructions

31 / English

Operating Instructions

• Heavystainsshouldbepretreatedwithsoapywaterappropriately

before washing (Do not rub or scratch the stained area). If in doubt,

check with a pharmacist or dry-cleaner.

• Useonlydyes/discoloringandanti-scalingagentssuitablefor

machine wash. Make sure to follow the instructions on the package.

Loading the washer

Maximum load capacity depends on the fabric type of laundry, soiling

amount of laundry and program cycle you wish to use.

CAUTION

• Do not exceed the maximum load capacity of the selected

program cycle. Washing results are adversely affected by an

overloaded drum. Overloading may also cause wrinkling and

abrasion on clothes.

Make sure power button is off before loading the machine. To load

the machine,

• Pullthedoorhandle.

• Placelaundryitemslooselyinthedrum.

• Mixsmallandlargeitemsforanevenloaddistribution.Largeitems

should be loaded first. Large items should not be more than half of

the total wash load.

• Ifyouputawashbagornetwhichisfilledwithsmallitemsinthe

drum, put an additional wash bag to prevent load unbalance. Both

wash bags should have the same amount of items to provide an

even load distribution.

• Beforewashingasingleorafewitemssuchasapillow,ateddy

bear, a single or a pair of shirts, sweat shirts etc, put some

additional items in the drum for better load distribution and spinning.

• Makesurethatthereisnoclothingobstructingthedoororcaught

between the door and rubber seal.

• Pushtheloadingdoorfirmlyandmakesurethatthedoorhasbeen

closed properly (especially if you load the machine with full load or

big items).

32 / English

Front-Loading Automatic Washer-Dryer

Operating Instructions

• Incasethedoorisnotlocked,doorledremainsoff.Inthatcase,

door should be opened and closed again firmly until the door led

lights up.

• Ifthedoorisnotclosedcompletely,themachinewillnotstart.This

is a safety precaution. The front door is locked until end of the

selected program and it can not be opened untill the door led on

the panel is off following the end of the program.

• Unloadthewasheditemsjustaftertheprogramcyclehasfinished.

Delay of unloading may cause wrinkling and unwanted odor on

laundry.

• Checktoseeanysmallmetalitemssuchaspins,coinsetcleftin

rubber seal while unloading the machine. Any residual metal items

may cause rusting on the rubber seal.

• Ifthereisanywaterleftinrubberseal,removewithasoftcloth.

Detergent Use

About Detergent

CAUTION

• YourproductisdesignedtouseonlyHE(highefficiency)

detergents.Youshouldalwayslookforthefollowingsymbolon

the label of detergents:

If you use a non-HE detergent with this product, high sudsing will

occur. High sudsing will decrease tumble action effectiveness,

washing and rinsing performance worsen. Suds may flow out of

detergent dispenser giving damage to your product.

CAUTION

• The detergents labeled as “HE compatible” may also lead to high

sudsing and inefficient tumble action. Don’t use such detergents.

Owner’s Guide & Installation Instructions

33 / English

Operating Instructions

Always follow the instructions and information given by laundry

detergent manufacturers when using these products.

WARNING

• Store laundry detergents and additives in a cool, dry place out of

children’s reach due to danger of chemical poisoning and skin

irritation.

Detergent Quantity

The amount of washing detergent to use depends on the amount of

laundry, the degree of soiling and water hardness.

For small amounts of laundry or only slight soiling use accordingly

less detergent.

Too much detergent causes an excessive amount of foaming, bad

washing and rinsing results and a strain on water resources.

Too little washing detergent causes laundry to turn grey and

calcification of the machine. Recommended amount of powder

detergent is max. 1/3 cup (80 ml). Recommended amount of liquid

detergent is max. 1/4 cup (60 ml).

Light soiling

No visible stains or soiling

Normal soiling

A few visible light stains or soiling

Heavy soiling

Highly visible stains or soiling

34 / English

Front-Loading Automatic Washer-Dryer

Operating Instructions

Detergent Dispenser

Detergent dispenser of your product has three separate

compartments for main wash detergent, fabric softener and liquid

bleach. Each of these laundry additives are automatically dispensed

at appropriate time during wash program.

CAUTION

• Do not put laundry additives directly in the wash drum. Always

use the detergent dispenser.

• After adding laundry additives do not close the drawer too quickly.

This may cause early dispensing of the additives thus poor wash

results and fabric damage.

• Do not open the drawer during wash program (except for addition

of liquid main wash detergent at the beginning of main wash

water intake).

Dispenser compartments are as follows:

-left compartment numbered as “II” (main wash compartment)

-middle compartment marked as “ ” (liquid fabric softener

compartment)

-right compartment numbered as “I” (liquid chlorine bleach

compartment)

Owner’s Guide & Installation Instructions

35 / English

Operating Instructions

(II) Main Wash Detergent Compartment

Add HE (High efficiency) powder detergent to this compartment

numbered as “II” before starting the wash program.

Use the detergent manufacturer’s dosing cup and follow the

instructions on the package.

If you use a liquid detergent, be sure to use a HE (High efficiency)

detergent and add detergent directly to main wash compartment

before operating your machine. If you observe liquid detergent stains

on washed items, it is recommended for subsequent wash cycles

that you should add liquid detergent during first water intake.

Color-safe bleach in powder or liquid form may be added into main

wash detergent compartment with main wash detergent. Be sure to

use main wash detergent and color-safe bleach in same form (either

powder or liquid) when adding into main wash compartment.

Liquid Fabric Softener Compartment

Add the recommended amount of liquid fabric softener to the middle

compartment marked as “” and dilute it with warm water to the

maximum fill line.

CAUTION

• Especially concentrated fabric softeners must be diluted with

warm water otherwise siphon may be clogged in time.

Do not fill the fabric softener above the maximum fill line as any

excess amount will mix into the wash water and you will have to re-fill

the compartment. Do not pour the softener directly onto laundry, it

may cause stains.

Liquid fabric softener is automatically dispensed during the final rinse

of wash program.

36 / English

Front-Loading Automatic Washer-Dryer

Operating Instructions

Using liquid detergents

If the product contains a liquid detergent cup:

• Makesurethatyouhaveplacedtheliquiddetergentcupin

compartment no. “2”.

• Iftheliquiddetergenthaslostitsfluidity,diluteitwithwaterbefore

putting in the detergent cup.

If the product does not contain a liquid detergent cup:

• Donotuseliquiddetergentfortheprewashinaprogramwith

prewash.

• LiquiddetergentstainsyourclotheswhenusedwithDelayedStart

function. If you are going to use the Delayed Start function, do not

use liquid detergent.

(I) Liquid Chlorine Bleach Compartment

Add liquid chlorine bleach to the right compartment numbered as

“I”. Measure 1/3 cup (80 ml) of bleach and pour it into the special

container located in the right compartment of the dispenser. This

container ensures dispensing and dilution of bleach during the first

rinse of wash cycle. There is a maximum fill line on the container. Do

not exceed the maximum fill line to prevent early dispensing. Early

dispensing may damage your clothes.

Owner’s Guide & Installation Instructions

37 / English

Operating Instructions

CAUTION

• Be sure that bleach container is present in the right compartment

ofdispenserbeforeyouaddliquidbleachingagent.You

may remove bleach container if you would not use bleach.

However do not put any other laundry additives to the empty

compartment.

• Be sure to choose extra rinse option if you are using bleach in

wash program. Bleach must be rinsed from laundry properly

otherwise it may cause skin irritation.

Bleach is automatically dispensed and diluted during the first rinse of

wash program.

WARNING

• BleachmayonlybeusedinRegular/CottonandPermanent

Presscycles.Don’tusebleachwithdelicates,handwashables

or wools, it will lead to clothes damage.

• The liquid bleach cup insert must be removed if not using liquid

bleach to avoid water leaking from the dispenser.

Water Consumption

Yourclotheswasherautomaticallyadjuststhewaterconsumption

according to load amount. This feature ensures high wash

performance results with efficient water and energy consumption.

38 / English

Front-Loading Automatic Washer-Dryer

5 Selecting a Program and Operating Your

Washer-Dryer

Control panel

1-Programselectionknob

2 - Temperature selection lights

3 - Spin speed selection lights

4 - Display

5-DryingProgramLights

6 - On / Off button

7-Start/Pausebutton

8 - End Time Adjustment button

9 - Drying Level Adjustment button

10 - Auxiliary Function buttons

11 - Spin Speed Adjustment button

12 - Temperature Adjustment button

13-ProgramSelectionlights

1 2 3 4 5 6

789101112

Owner’s Guide & Installation Instructions

39 / English

Selecting a Program and Operating Your Washer-Dryer

Display symbols

a b c d e

a- Washing indicator

b - Rinsing indicator

c - Spinning indicator

d- Drying indicator

e- End indicator

f- No Water indicator

g - Duration Information display

h- Loading Door Lock indicator

i- Child Lock indicator

Preparing the machine

1. Check if the hoses are connected tightly.

2.Pluginyourmachine.

3. Turn the tap on completely.

4.Placethelaundryinthemachine.

5. Add detergent and fabric softener.

40 / English

Front-Loading Automatic Washer-Dryer

Selecting a Program and Operating Your Washer-Dryer

Program and consumption table

(for washing)

Program

Load Capacity

Water Consumption (lt)

Energy Consumption (kWh)

Min Spin Speed

Max Spin Speed

Heavy Soil

Soak

Extra Rinse

Drying

Selectable

Temperature Range

Normal / Regular

Cotton

Extra Hot

1/2

Load

30 0,65

EXTRA

HIGH

EXTRA

HIGH

• • • • TAP COLD EXTRA HOT

Perm Press HOT

1/2

Load

70 1,00 NO SPIN HIGH • • • • TAP COLD HOT

Hand Wash /

Wool

WARMER

1/5

Load

50 0,55 NO SPIN HIGH • TAP COLD WARMER

Quick Wash 25’ WARM

1/2

Load

30 0.2 NO SPIN HIGH • TAP COLD WARM

Heavy Duty EXTRA HOT

Full

Load

60 1,00 NO SPIN

EXTRA

HIGH

* • • TAP COLD EXTRA HOT

Delicates & Dark WARMER

1/4

Load

55 0,35 NO SPIN HIGH • TAP COLD WARMER

Tub Sanitize EXTRA HOT - 75 2,20 LOW LOW EXTRA HOT EXTRA HOT

Jogging Wear WARMER

1/2

Load

65 0,65 NO SPIN HIGH • TAP COLD WARMER

Down Wear HOT

1/4

Load

72 0.65 NO SPIN HIGH • • TAP COLD HOT

•:Selectable.

* : Automatically selected, no cancelling.

Owner’s Guide & Installation Instructions

41 / English

Selecting a Program and Operating Your Washer-Dryer

CAUTION

• The auxiliary functions in the table may vary according to the model

of your machine.

• Water and power consumption may vary subject to the changes

in water pressure, water hardness and temperature, ambient

temperature, type and amount of laundry, selection of auxiliary

functions and spin speed, and changes in mains voltage.

• Youcanseethewashingtimeoftheprogramyouhaveselectedon

the display of the machine. It is normal that small differences may

occur between the time shown on the display and the real washing

time.

• “Selection patterns for auxiliary functions can be changed by the

manufacturer. New selection patterns can be added or removed.”

• “The spin speed of your machine may vary according to the

program; this spin speed cannot exceed the max. spin speed of

your machine.”

42 / English

Front-Loading Automatic Washer-Dryer

Selecting a Program and Operating Your Washer-Dryer

Selecting the washing program

1. Determine the program suitable for the type, quantity and

soilinglevelofthelaundryinaccordancewiththe"Programand

consumption table".

2. Select the desired program with the Program Selection knob.

CAUTION

• Programsarelimitedwiththehighestspinspeedappropriatefor

that particular type of fabric.

• When selecting a program, always consider the type of fabric,

colour, soiling level and permissible water temperature.

• Always select the lowest appropriate temperature. Higher

temperature means higher electricity consumption.

Washing programs

Depending on the type of fabric, use the following main programs.

CAUTION

• Youcansetyoumachinetoswitchtodryingstepattheend

of washing cycle by pressing the Drying button after you have

selected the washing program for your laundry. Each time you

press the button, info line shows at which step the drying process

will take place and the relevant symbol will turn on. If you want,

by continuing to press the button, you can perform drying for the

maximum period of time allowed by the machine for drying.

• Symbols in the display are schematic and may not match the

product exactly.

• When you will perform washing and drying by using the Drying

function of your machine, load maximum 5 kg of laundry into the

machine. If you load excessively, your laundry will not dry and

machine will operate for a long time and consume more energy.

Owner’s Guide & Installation Instructions

43 / English

Selecting a Program and Operating Your Washer-Dryer

• Normal / Regular Cotton

Youcanwashyourdurablewhiteandcolorfastitemswith

this cycle. Washes with vigorous tumbling movements. It is

recommended for your cotton or linen items (such as bed sheets,

pillowcases,jeans,towels, bathrobes,garments, T-shirts,sweat-shirts

,etc.).Youcanselectwashtemperatureaccordingtocarelabelof

items. Heavy soil should be chosen for items that need extra hygiene

such as baby clothes, kitchen towels and garments.

CAUTION

• Youcandryyourlaundryafterthewashingcyclewithoutany

interruption (automatic or timed drying can be performed after

washing). For this, you must also select the Drying function before

starting the washing program.

• According to the drying selections which you will add to the

washing programs, you can see when the program will end on the

display of the machine.

• If you don't want drying to take place after the program you have

selected, press and hold the Drying auxiliary function button until

the Drying light is turned off.

44 / English

Front-Loading Automatic Washer-Dryer

Program and consumption table

• Perm Press

Youcanwashyoureasycareitemsonthiscycle.Washeswith

gentler tumbling movements and in shorter washing cycles. It is

recommended for your cotton, synthetic or blended items (such

asshirts,pants,wrinkle-freeitems,etc.).Youcanselectwash

temperature according to care label of items.

CAUTION

• Youcandryyourlaundryafterthewashingcyclewithoutany

interruption (automatic or timed drying can be performed after

washing). For this, you must also select the Drying function before

starting the washing program.

• According to the drying selections which you will add to the

washing programs, you can see when the program will end on the

display of the machine.

• If you don't want drying to take place after the program you have

selected, press and hold the Drying auxiliary function button until

the Drying light is turned off.

• Hand Wash / Wool

Youcanwashyourwoolen/delicateclothesthatbear“handwash

only” labels for which hand wash is recommended on this program.

It washes the laundry with very tender washing movements without

damaging your clothes.

“The wool wash cycle of this machine has been approved by The

Woolmark Company for the washing of machine washable wool products

provided that the products are washed according to the instructions

on the garment label and those issued by the manufacturer of this

washing machine. M1527.”

“In UK, Eire, Hong Kong and India the Woolmark trade mark is a

Certification trade mark.”

CAUTION

• Drying function cannot be selected for the woollen wash program.

Owner’s Guide & Installation Instructions

45 / English

Program and consumption table

• Quick Wash 25’

Use to wash your lightly soiled and unstained, small amount of cotton

laundry in 25 minutes.

CAUTION

• Youcandryyourlaundryafterthewashingcyclewithoutany

interruption (automatic or timed drying can be performed after

washing). For this, you must also select the Drying function before

starting the washing program.

• According to the drying selections which you will add to the

washing programs, you can see when the program will end on the

display of the machine.

• If you don't want drying to take place after the program you have

selected, press and hold the Drying auxiliary function button until

the Drying light is turned off.

• Heavy Duty

Use to wash your heavily soiled, durable cotton and linen laundry.

Heavy Soil option is automatically selected for a perfect cleansing.

Heavy Soil option prolonges heating step and addes extra rinsing.

CAUTION

• Youcandryyourlaundryafterthewashingcyclewithoutany

interruption (automatic or timed drying can be performed after

washing). For this, you must also select the Drying function before

starting the washing program.

• According to the drying selections which you will add to the

washing programs, you can see when the program will end on the

display of the machine.

• If you don't want drying to take place after the program you have

selected, press and hold the Drying auxiliary function button until

the Drying light is turned off.

46 / English

Front-Loading Automatic Washer-Dryer

Program and consumption table

• Delicates&Dark

Use this program to protect the colour of your dark-coloured and

delicate garments. It has more sensitive tumbling movements and

does not do intermediate spinning compared to the permanent

program. It may be used for coloured cotton, synthetic or blended

clothes for which sensitive washing is recommended.

• Rinse

Use when you want to rinse or starch separately.

• Spin & Drain

Use to drain the water in the machine.

• Tub Sanitize

Use regularly (once in every 1-2 months) to clean the drum and

provide the required maitenance. Run the program without any

laundry in the machine. To obtain better results, put powder limescale

remover for washing machines into detergent compartment nr. “2”.

When the program is over, leave the loading door ajar so that the

inside of the machine dries.

CAUTION

• This is not a washing program. It is a maintenance program.

• Do not run the program when there is something in the machine.

If you try to do so, the machine detects that there is a load inside

and aborts the program

• Jogging Wear

This program is used to wash half capacity of normally or lightly soiled

daily cotton, synthetics or blended clothes. e.g.: daily clothes and

sportswear that have been used only once.

• Down Wear

Use this program to wash your coats, vest, jackets etc. containing

feathers with a “machine-washable” label on them. Thanks to special

spinning profiles, it is ensured that the water reaches the air gaps

amongst the feathers.

Owner’s Guide & Installation Instructions

47 / English

Selecting a Program and Operating Your Washer-Dryer

Temperature selection

Whenever a new program is selected, the recommended temperature

for the program appears on the temperature indicator. It is possible

that the recommended temperature value is not the maximum

temperature that can be selected for the current program.

PresstheTemperature Adjustment button to change the

temperature.

CAUTION

• Temperature Adjustment button works only backwards. For

example, when you want to select 60

C when the display shows

C you need to press the button for several times until you

reach 60

C by going backwards from 40

• If you scroll to Cold Wash option and press Temperature Adjustment

button again, the recommended maximum temperature for the

selectedprogramisdisplayed.PresstheTemperatureAdjustment

button again to decrease the temperature.

Finally, Cold light indicating the cold wash option appears on the

display.

Youcanalsochangethetemperatureafterthewashinghasstarted.

Youcanselectthedesiredtemperatureafterwashingstartsbutyou

must do this before heating step starts.

48 / English

Front-Loading Automatic Washer-Dryer

Selecting a Program and Operating Your Washer-Dryer

Spin speed selection

Whenever a new program is selected, the spin speed recommended

for the selected program is displayed on the Spin Speed indicator.

CAUTION

• It is possible that the recommended spin speed value is not the

maximum spin speed that can be selected for the current program.

PresstheSpin Speed Adjustment button to change the spin

speed. Spin speed decreases gradually.

Then, depending on the model of the product, "Rinse Hold" and "No

Spin" options appear on the display.

CAUTION

• Spin Speed Adjustment button works only backwards. For

example, when you want to select 1000 rpm when the display

shows 800 rpm, you need to press the button for several times

until you reach 1000 rpm by going backwards from 800 rpm.

• Rinse Hold option is indicated with “ ” symbol and No Spin option

is indicated with “ ” symbol.

Owner’s Guide & Installation Instructions

49 / English

Selecting a Program and Operating Your Washer-Dryer

If you want to spin your laundry after the Rinse Hold function:

- Adjust the Spin Speed.

-PressStart / Pause / Cancel button. The program resumes.

Machine drains the water and spins the laundry.

If you want to drain the water at the end of the program without

spinning, use No Spin function.

CAUTION

• In programs that do not allow spin speed adjustment, when Spin

Speed adjustment button is pressed, spin speed light does not

change and the buzzer is heard.

YoucanalsochangetheSpinSpeedafterthewashingstarts.You

can select spin speed by pressing spin speed adjustment button after

washing has started but before the spinning step.

Auxiliary function selection for drying

When a new program is selected, press Auxiliary Function Selection

button to adjust the drying option that is suitable for the selected

washing program.

CAUTION

• In programs that do not allow drying adjustment, when Drying

auxiliary function button is pressed drying light does not change

and the buzzer is heard.

• Only for drying programs, press Auxiliary Function Selection button

to adjust the suitable drying option.

50 / English

Front-Loading Automatic Washer-Dryer

Selecting a Program and Operating Your Washer-Dryer

Program and consumption table

(for drying)

•:Selectable

* : Automatically selected, not cancellable.

Program

Load Capacity

Water Cosnumption(lt)

Energy Consumption(kWh)

Min Spin Speed

Max Spin Speed

Heavy Soil

Soak

Extra Rinse

Drying

More Dry

Normal Dry

Damp Dry

Time dry

Selectable

Temperature

Range

Cotton Dry -

1/2

Load

50 3,25

EXTRA

HIGH

EXTRA

HIGH

* • • • • - -

Perm Press Dry -

1/3

Load

45 2,10

SPIN

* • • • - -

Baby Sanitize

Wash&Dry

Hot

1/4

Load

145 3,80

EXTRA

HIGH

EXTRA

HIGH

* * • • • • WARM

EXTRA

HOT

Wash&Dry Hot

1/2

Load

95 5,00

EXTRA

HIGH

EXTRA

HIGH

* • • • •

TAP

COLD

HOT

Wash&Wear Warm

1/16

Load

35 0,60 HIGH HIGH • * •

TAP

COLD

WARM

Wash&Wear Warm

1/8

Load

45 1,10 HIGH HIGH • * •

TAP

COLD

WARM

Owner’s Guide & Installation Instructions

51 / English

Selecting a Program and Operating Your Washer-Dryer

Drying programs

WARNING

• Machine cleans the lint coming off the laundry automatically during

the drying cycle. Machine uses water during drying. For this

reason, water tap of the machine should be open also in the drying

programs.

• When a new program is selected, press Auxiliary Function Selection

button to adjust the drying option that is suitable for the selected

washing program.

CAUTION

• Dryingprogramscontainspinningstep.Yourmachineperforms

this process in order to shorten the drying time. When drying is

selected, spin speed setting is in Maximum spin speed range.

• In programs that do not allow drying adjustment, when Drying

auxiliary function button is pressed drying light does not change

and the buzzer is heard.

• Only for drying programs, press Auxiliary Function Selection button

to adjust the suitable drying option.

• While there is a water cut, both washing and drying could not be

performed.

• Perm Press Dry

Use to dry damp synthetic laundry equivalent to 3 kg dry weight. This

program performs drying only.

CAUTION

• For the dry weights of the laundry, see Section 4, Step 4.5

52 / English

Front-Loading Automatic Washer-Dryer

Selecting a Program and Operating Your Washer-Dryer

• Cotton Dry

Use to dry damp cotton laundry equivalent to 5 kg dry weight. This

program performs drying only.

CAUTION

• In order to dry the laundry which contains only towels and

bathrobes, load 4 kg laundry maximum.

• For the dry weights of the laundry, see Section 4, Step 4.5

Washing and drying programs

WARNING

• Machine cleans the lint coming off the laundry automatically during

the drying cycle. Machine uses water during drying. For this

reason, water tap of the machine should be open also in the drying

programs.

• Wash & Dry

Use to wash cotton laundry up to 5 kg and dry it right after the

washing cycle without making any other selection.

CAUTION

• When this program is selected, external Drying auxiliary function

cannot be selected.

In 5kgWash&5 kg Dry program, it is recommended to load laundry

until the level indicated in the above figure for ideal drying conditions

(you will see the level arrow when you open the loading door).

Owner’s Guide & Installation Instructions

53 / English

Selecting a Program and Operating Your Washer-Dryer

• Wash & Wear

Use to wash and dry 0.5 kg laundry (2 shirts) in 40 minutes or 1 kg

laundry (5 shirts) in 60 minutes.

CAUTION

• Wash&Wearprogramisintendedtoquicklywashanddrythedaily

clothes which were worn for a short period of time and are not

soiled. This program is suitable for the laundry which contains thin-

texture and can dry quickly. (shirts, t-shirts)

• Other drying options or programs should be used for the thick

texture laundry which take longer to dry.

• Baby Sanitize Wash&Dry

Use to wash and then immediately dry your laundry up to 2 kg which

requires an anti-allergic and hygienic washing (baby clothes, bed

sheets, bedding, underpants, etc. cotton items).

CAUTION

• BabyProtect+programistestedandapprovedby“TheBritish

Allergy Foundation” (Allergy UK) in United Kingdom.

54 / English

Front-Loading Automatic Washer-Dryer

Selecting a Program and Operating Your Washer-Dryer

Auxiliary function selection

Select the desired auxiliary functions before starting the program.

Whenever a program is selected, lights of the auxiliary functions that

can be selected together with that program illuminate.

CAUTION

• Light of the auxiliary function that cannot be selected with the

selected program does not illuminate. When you press the buttons

of these auxiliary functions, buzzer is heard and selection is

prohibited.

If the wash cycle has reached a point where you cannot select the

auxiliary function, the function cannot be selected.

CAUTION

• Some functions cannot be selected together. If a second auxiliary

function conflicting with the first one is selected before starting

the machine, the function selected first will be cancelled and the

second auxiliary function selection will remain active. For example,

if you want to select Quick Wash after you have selected the

Prewash,PrewashwillbecancelledandQuickWashwillremain

active.

• An auxiliary function that is not compatible with the program cannot

beselected.(See"Programandconsumptiontable")

• Some programs have auxiliary functions that must be operated

with the selected program. Those functions cannot be cancelled.

Auxiliary function light is already selected.

Owner’s Guide & Installation Instructions

55 / English

Selecting a Program and Operating Your Washer-Dryer

CAUTION

• If the selected dampness level (Iron Dry, Wardrobe Dry, Extra

Wardrobe Dry) cannot be reached at the end of the drying cycle,

your machine will extend the program duration automatically.

Programwilllastlonger.

• If Timed-Drying is selected, program is finished at the end of the

drying period even if the laundry does not get dry.

• If the selected dampness level (Iron Dry, Wardrobe Dry, Extra

Wardrobe Dry) is reached during drying cycle, or extra dryness is

detected in the timed-drying options, program will take a shorter

time. Time decrease will be shown on the display.

• Heavy Soil

This function increases washing times for heavily soiled items for

better wash results.

• Soak

This function is used for heavily soiled items when you want to

pretreat them before washing. Laundry is soaked in a relatively high

amountofwarmwater.YoucanusefullloadandHE“Highefficiency”

detergent for soaking. Use 1/3-1/2 of the recommended detergent

dosage for the load amount to be soaked.

• Extra Rinse

When this function is selected, you can increase the number of

current rinsing steps. Thus, sensitive skins’ risk of being affected by

the remaining detergent on the clothes will be decreased.

CAUTION

• Pressingforthefirsttimewilladdsinglerinse,asecondpresswill

add double rinse. The third press will cancel it.

• Drying

This function enables drying of the laundry after washing. Check

with which programs this auxiliary function can be selected, from the

program table.

56 / English

Front-Loading Automatic Washer-Dryer

Selecting a Program and Operating Your Washer-Dryer

Drying steps

Damp Dry

Drying is performed until the drying level reaches Iron Dry step.

Normal Dry

Drying is performed until the drying level reaches Wardrobe Dry step.

More Dry

Drying is performed until the drying level reaches Extra Wardrobe Dry

step.

CAUTION

• Dryness level may change according to the mixture, material types,

amount and dampness level of the laundry.

• Items which contain accessories such as lace, tulle, stones, beads,

spacer, wire, etc. and high silk-content items should not be dried in

the machine.

Time based drying-minutes (Time dry)

In order to reach the desired drying level at low temperature, you

select any of 30, 90 and 150 minutes of drying periods.

CAUTION

• When drying small amount of laundry (up to maximum 2 pieces),

timed-drying steps in the Cottons or Synthetics drying programs

should be selected.

• If the laundry is not at the desired dryness level at the end of

the drying program, timed-drying can be selected to finish the

process.

• When this function is selected, machine performs drying for the

adjusted time irrespective of the drying level.

Owner’s Guide & Installation Instructions

57 / English

Selecting a Program and Operating Your Washer-Dryer

Time display

Remaining time for the completion of the program while it is running is

displayed as “01:30” in hours and minutes format.

CAUTION

• Programtimemaydifferfromthevaluesinsection"Programand

consumption table" depending on the water pressure, water

hardness and temperature, ambient temperature, amount and the

type of laundry, auxiliary functions selected and the changes at the

mains voltage.

End Time

With the End Time function, the startup of the program can be

delayed up to 24 hours. After pressing End Time button, the

program's estimated ending time is displayed. If the End Time is

adjusted, End Time light illuminates.

In order for the End Time function is activated and the program is

completed at the end of the specified time, you must press Start /

Pause button after adjusting the time. Start / Pause button stops

flashing and remains illuminated continuously.

58 / English

Front-Loading Automatic Washer-Dryer

Selecting a Program and Operating Your Washer-Dryer

If you want to cancel End Time function, press End Time button until

the End Time light turns off or press On / Off button to turn off and

on the machine.

1. Open the loading door, place the laundry and put detergent, etc.

2. Select the washing program, temperature, spin speed and, if

required, the auxiliary functions.

3. Set the end time of your choice by pressing the End Time button.

End Time light is illuminated.

4.PressStart / Pause button. Time countdown starts. “:” symbol in

the middle of the end time on the display starts flashing.

CAUTION

• Do not use liquid detergents when you activate End Time function!

There is the risk of staining of the clothes.

• Door keeps locked during the End Time countdown period. In

order to unlock the door, machine should be switched to the

pause mode by pressing the program start/pause button. At the

end of the countdown, End Time indicator turns off, washing cycle

starts and the time of the selected program appears on the display.

• When the End Time selection is completed, the time appearing on

the display consists of end time plus the duration of the selected

program.

Owner’s Guide & Installation Instructions

59 / English

6 Preparation

1. Turn on both hot and cold water faucets fully. Check and be sure

the water connection is tight.

2.Placethelaundryinthedrum.

3. Add laundry additives (e.g. detergent, fabric softener,bleach).

Starting the program

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

8.5

10.5

Malzeme rengi ARC 716

Colour of material is ARC 716

%DVN×UHQJL3DQWRQH&

3ULQWLQJFRORULV3DQWRQH&

INLAY STOCK NO:

2846559001

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

1. Close the door

2.PressStart/Pausebuttontostarttheprogram.

3.ThelightofStart/Pausebuttonwhichwasflashingstartsto

illuminate steadily now, indicating that the program has started.

4. Loading door is locked. “Locking the Door” appears on the display

when the door is being locked.

CAUTION

• BeforepressingtheStart/Pausebuttonpleaseensurethatthe

frontdoorhasbeenclosedproperly.OtherwiseStart/Pause

button should be pressed again to start the program

• If no program is started or no key is pressed within 10 minutes during

the program selection process, the product will turn off automatically.

The display and all indicators will turn off.

• If you press the On / Off button, the program information set as

default will be displayed.

60 / English

Front-Loading Automatic Washer-Dryer

Preparation

Loading door locking system

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

8.5

10.5

Malzeme rengi ARC 716

Colour of material is ARC 716

%DVN×UHQJL3DQWRQH&

3ULQWLQJFRORULV3DQWRQH&

INLAY STOCK NO:

2846559001

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

There is a locking system on the loading door of the machine that

prevents opening of the loading door in cases when the water level is

unsuitable for door opening.

“Loading door locked” light in the panel turns on when the loading

door is locked.

Adding or taking out laundry

This is only possible under the following conditions:

• During time delay,

CAUTION

• Youmaynotaddorremovelaundryduringthetimedelay(untilthe

program starts).

• At the beginning of a washing cycle,

CAUTION

• Washer allows adding more laundry during a future step only if

the water level is low enough to open the loading door or if the

temperature in the washer is low

1.PresstheStart/Pausebuttontoswitchtheproducttopause

mode. The program follow-up light of the relevant step during which

the machine was switched into the pause mode will flash.

2. Wait until the Loading Door can be opened.

3. Open the Loading Door and add or take out the laundry.

4. Close the Loading Door.

Owner’s Guide & Installation Instructions

61 / English

Preparation

5. Make changes in auxiliary functions, temperature and speed

settings if necessary.

6.PresstheStart/Pausebuttontothenrestarttheproduct.

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

30’

8.5

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

30’

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

8.5

2846559001

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

90’

20°

30’

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

90’

20°

30’

Changing the selections after program has started

Adding laundry after the program has started:

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

8.5

10.5

Malzeme rengi ARC 716

Colour of material is ARC 716

%DVN×UHQJL3DQWRQH&

3ULQWLQJFRORULV3DQWRQH&

INLAY STOCK NO:

2846559001

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

If the water level in the machine is suitable when you press Start /

Pause button, “Loading door locked” light on the panel is turned off.

If the water level in the machine is not suitable when you press Start /

Pause button, the panel will indicate that the loading door is locked.

Switching the machine to pause mode:

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

8.5

10.5

Malzeme rengi ARC 716

Colour of material is ARC 716

%DVN×UHQJL3DQWRQH&

3ULQWLQJFRORULV3DQWRQH&

INLAY STOCK NO:

2846559001

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

PresstheStart / Pause button to switch the machine to pause

mode.

62 / English

Front-Loading Automatic Washer-Dryer

Preparation

Changing the program selection after program has started:

Changing the program is not allowed when a program is already

running.

If you turn the Program Selection knob while the program is

running, buzzer is heard and change is prohibited.

Youcanselectthenewprogramafterswitchingthecurrentprogram

to pause mode.

CAUTION

• The newly selected program starts from beginning.

Changing the auxiliary function, spin speed and temperature

Depending on the step the program has reached, you can cancel or

select auxiliary functions. See, “Auxiliary function selection”.

Also, you can change the spin speed, temperature and drying

settings. See, “Spin speed selection” and “Temperature selection”.

CAUTION

• The loading door will not open if the water temperature in the

machine is high or the water level is above the loading door

baseline.

Child Lock

Use Child Lock function to prevent children from tampering with the

machine. Thus you can avoid any changes in a running program.

CAUTION

• YoucanswitchthemachineonandoffwithOn/Offbuttonwhen

the Child Lock is active. When you switch on the machine again,

program will resume from where it has stopped.

• Machine will give an audio alarm when the buttons are pressed if

the child lock is active.

Owner’s Guide & Installation Instructions

63 / English

Preparation

To activate the child lock:

Press and hold 2nd and 3rd auxiliary function buttons for 3

seconds. After the countdown as “Child Lock 3-2-1” on the display

isover,“ChildLockEnabled”appearsonthedisplay.Youcanrelease

2nd and 3rd Auxiliary Function buttons when this warning is

displayed.

To deactivate the child lock:

Press and hold 2nd and 3rd auxiliary function buttons for 3

seconds. After the countdown as “Child Lock 3-2-1” on the display

is over, “Child Lock Enabled” is turned off on the display.

64 / English

Front-Loading Automatic Washer-Dryer

Preparation

Cancelling the program

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

8.5

10.5

Malzeme rengi ARC 716

Colour of material is ARC 716

%DVN×UHQJL3DQWRQH&

3ULQWLQJFRORULV3DQWRQH&

INLAY STOCK NO:

2846559001

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

The program is cancelled when the machine is turned off and on

again.PressandholdOn / Off button for 3 seconds. After the

countdown as “3-2-1” on the display is over, the machine turns off.

CAUTION

• If you press On / Off button when the Child Lock is active, the

programwillnotbecancelled.Youshouldcancelthechildlock

first. Countdown as "3-2-1" appears on the display.

• If you want to open the loading door after you have cancelled the

program but it is not possible to open the loading door since the

water level in the machine is above the loading door baseline, then

turntheProgramSelectionknobtoPump+Spinprogramanddrain

the water in the machine.

Re-spinning the laundry

The control system for an unbalanced load can pause the spinning

in cases when the distribution of the laundry in the drum is not

balanced.

If you want to re-spin the clothes:

1. Rearrange the previously placed clothes in the drum.

2. Select the spin program.

3. Adjust the spin speed.

Owner’s Guide & Installation Instructions

65 / English

Preparation

End of program

WhentheprogramisovertheEndofProgramindicatorilluminates

and a buzzer is heard.

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

8.5

10.5

Malzeme rengi ARC 716

Colour of material is ARC 716

%DVN×UHQJL3DQWRQH&

3ULQWLQJFRORULV3DQWRQH&

INLAY STOCK NO:

2846559001

1400

800

1000

600

150’

Ütü Kuruluğu

Dolap Kuruluğu

Extra Kurutma

90’

20°

30’

If you do not press any button for 2 minutes, the machine will switch

to standby mode. Display and all indicators are turned off.

IfyoupressanybuttonorturntheProgramSelectionknobwhenthe

machine is in standby mode, program steps that are completed will

appear on the display.

Energy saving mode

After you switch on your machine with On-Off button, if no program is

started or no other procedure is performed at the selection step or no

action is taken within approx. 2 minutes after the selected program

ends, your machine will switch to energy saving mode automatically.

Also, if your product has a display that shows program time, this

displaywillbecompletelyturnedoff.IfyouturntheProgramSelection

knob or touch any button, lights and display will switch back to

previous condition. The selections which you make when exiting from

theenergyefficiencymaychange.Pleasecheckthecorrectness

of your selections before starting the program. If necessary, please

make your settings again.This is not an error.

CAUTION

• This is a feature of this product, and not an error.

66 / English

Front-Loading Automatic Washer-Dryer

7 User maintenance instructions

WARNING

• Be sure to unplug the power cable before attempting

maintenance or cleaning of your appliance to minimize the risk of

electric shock.

Cleaning detergent dispenser

Remove any powder/liquid residue buildup in the dispenser drawer.

To do this;

1.Pressthedottedpointonthesiphonofthesoftenercompartment

and pull towards yourself until the it is removed from the dispenser.

CAUTION

• If more than a normal amount of water and softener/bleach mixture

starts to gather in the dispenser compartments, dispenser must

be cleaned.

2. Wash the dispenser drawer, liquid chlorine bleach container and

siphon of softener under running warm water in a sink etc. Wear

protective gloves or use an appropriate brush or sponge to avoid

touching the detergent residues in the drawer when cleaning.

3. Replace the drawer into its housing after cleaning. Check if the

siphon and container are in their original locations.

Owner’s Guide & Installation Instructions

67 / English

User maintenance instructions

Cleaning the door seal

Be sure to check the rubber door seal after unloading your washer.

Pullthesealbacktosearchforanyforeignobjects.Residualmetal

objects such as pins and coins may form rust stains on rubber seal,

and cause the seal to leak.

Wipe the stained areas with soapy water using a damp cloth. Then

wipe with a dry cloth properly. Do not use an abrasive scrubbing

agent when cleaning rubber seal.

Cleaning the drum

Check the wash drum for any foreign objects after unloading your

washer. Residual metal objects such as pins and coins may form

rust stains on drum surface and your clothes. Do not use abrasive

materials while cleaning the inner surface of the drum. Use soapy

water with a damp cloth to wipe the inner surface, then dry it and

leave the door open to let inside dry properly.

"Tub Clean" cycle with extra rinse option should be used for

monthly cleaning of drum. To carry out this procedure select "Tub Clean"

Program.

68 / English

Front-Loading Automatic Washer-Dryer

User maintenance instructions

Cleaning the outer cabinet and control panel

When necessary:

• Wipetheexteriorpanelsofyourmachinewithsoapywaterormild

detergent. Dry it with a soft cloth.

• Useonlyasoftanddampclothtocleanthecontrolpanel.

CAUTION

• Never use a sponge or scrubbing material. These will damage the

painted and plastic parts.

Cleaning the water inlet strainers

There is a strainer at the end of each water inlet valve at the back side

of the machine and also at the end of each water inlet hose where

they are connected to the faucets. These strainers prevent the foreign

substances and dirt in the water to enter into the machine. Strainers

should be cleaned from time to time.

• Closethewaterfaucets.

• Removethenutsofthewaterinlethosestocleanthe

surfaces of the strainers on the water inlet valves with

an appropriate brush.

• Ifthestrainersareverydirty,youcanpullthemoutby

means of pliers and clean them.

• Takeoutthestrainersontheflatendsofthewater

inlet hoses together with the rubber seals and clean

thoroughly under running water.

• Replacetherubbersealsandstrainerscarefullyandtightenthe

hose nuts by hand.

Owner’s Guide & Installation Instructions

69 / English

User maintenance instructions

Cleaning the drain pump filter

Filter system in your machine prevents solid items such as buttons,

coins and fabric fibers clogging the pump impeller during discharging

of the washing water. Thus, a good water discharge is achieved and

the pump life is extended.

• Ifyourmachinefailstodrainthewater,thepumpfiltermaybe

clogged.Youmayhavetocleanitoccasionallytopreventany

clogging. Water must be drained completely to clean the pump

filter.

In addition, water may have to be drained off completely in the

following cases:

• beforetransportingtheappliance(e.g.whenmoving)

• whenthereisadangeroffrost

In order to clean the dirty filter and discharge the water:

1. Disconnect or unplug the machine from the power supply.

WARNING

• There may be water at 158F (70°C) in the drum. Therefore, the

filter must be cleaned only after the inside water is cooled down to

avoid hazard of scalding.

2. Open the filter cover.

70 / English

Front-Loading Automatic Washer-Dryer

User maintenance instructions

3. Follow the below procedures in order to drain water.

If the product does not have an emergency water drain hose, in

order to drain the water:

a. In order to collect the water to flow out of the filter, place a large

vessel in front of the filter.

b. Turn and loosen the pump filter until water starts to flow

(counterclockwise). Fill the flowing water into the container you

have placed in front of the filter. Always keep a piece of cloth

handy to absorb any spilled water.

c When the water inside the product is finished, take out the filter

completely by turning it.

4. Clean any residues inside the filter as well as fibers, if any, around

the pump impeller region.

5. Replace the filter.

6. If the filter cap is composed of two pieces, close the filter cap by

pressing on the tab. If it is one piece, seat the tabs in the lower part

into place first, and then press the upper part to close.

Owner’s Guide & Installation Instructions

71 / English

User maintenance instructions

Descaling the washer-dryer

Hard water can cause scale build-up inside the drum and other parts

of your machine in time. Scaling may lead to some serious problems

such as clogging in hoses, heater or pump failure eventually.

To prevent scaling, wash drum should be cleaned frequently. Do not

use abrasive materials such as metal wool while cleaning the drum.

Take the manufacturer’s instructions into account if you are using a

descaling agent. Descaling agents may contain materials that are

hazardous for washer components. Use descaling agents compatible

for use in clothes washers.

When using a powder descaling agent, add 1 cup to the main wash

compartment of the dispenser and run a regular hot cycle (with extra

rinse) without any clothes and detergents.

72 / English

Front-Loading Automatic Washer-Dryer

8 Troubleshooting

Problem Reason Solution

A program

cannot be

started or

selected.

The product may have

switched to self protection

mode due to a supply problem

(line voltage, water pressure,

etc.).

* PressandholdtheOn/

Off button for 3 seconds to

reset the product to factory

settings. (See "Canceling the

program")

There is water

inside the

product.

Some water might have

remained in the product due to

the quality control processes

in the production.

* This is not a failure; water is

not harmful to the product.

Machine does

not fill with water

or wash after

the program was

selected and the

“Start/Pause/

Cancel” button

was pressed.

Faucets may be turned off. * Open the water faucets fully.

Water inlet hose may be

folded.

* Check the water inlet hose

and straighten if necessary.

Water inlet strainers might be

clogged.

* Clean the water inlet

strainers.

Is there power at the outlet?

* Call an electrician and have

the power outlet / circuit

breaker / fuse checked.

Machine might be unplugged.

* Plugthepowercordtoalive

electrical outlet.

Drain hose may be folded.

* Check the drain hose and

straighten if necessary.

Machine may be in handwash,

wools or soak cycle.

* Wait for a short time and

tumbling will start.

Drain pump filter or drain itself

may be clogged.

* Clean the drain pump filter

(See “User maintenance

instructions” ). If the house

drain pipes are clogged, call

a plumber for assistance.

Door may not be closed

properly.

* Close the loading door.

Machine does

not drain water /

machine drains

water slowly.

Drain hose may be folded. * Check the drain hose and

straighten if necessary.

Drain pump filter or drain itself

may be clogged.

* Clean the drain pump filter

(See “User maintenance

instructions” ). If the house

drain pipes are clogged, call

a plumber for assistance.

Owner’s Guide & Installation Instructions

73 / English

Troubleshooting

Problem Reason Solution

Product vibrates

or makes noise.

Product might be standing

unbalanced.

* Stablize the product by

adjusting the feet.

A hard substance might have

entered into the pump filter.

* Clean the pump filter.

Transportation safety bolts are

not removed.

* Remove the transportation

safety bolts.

Laundry quantity in the

product might be too little.

* Add more laundry to the

product.

Excessive laundry might be

loaded in the product.

* Take out some of the laundry

from the product or distribute

the load by hand to balance

it evenly in the product.

Product might be leaning on a

rigid item.

* Make sure that the product is

not leaning on anything.

There is water

leaking from the

bottom of the

machine.

Inlet hose connections may be

leaking.

* Be sure the strainers and

rubber seals of the water

inlet hoses are solid and

securely fitted.

End of the drain hose may be

loosely inserted into the waste

pipe or sink.

* Tightly attach the drain hose

to the waste pipe or sink

(See “Installation Instructions,

Drainage”).

House drain may be clogged.

* If the house drain pipes are

clogged, call a plumber for

assistance.

Filter cap of the drain pump

may not be properly fitted.

* Make sure that the pump

filter cap is tightly closed.

Hose connections inside the

machine may be leaking.

* Internal hose connections

(e.g. dispenser hoses, drain

system) should be checked

by a service technician.

Product stopped

shortly after the

program started.

The machine might have

stopped temporarily due to

low voltage.

* Productwillresumerunning

when the voltage is restored

to a normal level.

74 / English

Front-Loading Automatic Washer-Dryer

Troubleshooting

Problem Reason Solution

Product directly

discharges the

water it takes in.

Draining hose might not be at

an adequate height.

* Connect the water draining

hose as described in the

operation manual.

No water can be

seen in the drum

during washing.

Water is inside the invisible

part of the product.

* This is not a failure.

Loading door

cannot be

opened.

The cover lock is activated due

to the water level inside the

product.

* Drain the water by running

thePumporSpinprogram.

Washer might be heating up

the water or it may be at the

spinning cycle.

* Wait until the process is over.

Due to electrical safety

mechanism, the door can only

be opened a few minutes after

the program has stopped.

* Wait until the process is over.

Child lock is engaged. Door

lock will be deactivated a

couple of minutes after the

program has come to an end.

* Wait for a couple of minutes

for deactivation of the door

lock.

If the door can not be opened

after minimum ten minutes

the program has stopped ,

machine should be switched

off pressing on/off button.

* If the situation remains,

call the qualified service

technician.

Owner’s Guide & Installation Instructions

75 / English

Troubleshooting

Problem Reason Solution

Washing takes

longer than

specified in the

manual.(*)

Water pressure is low. * Productwaitsuntiltaking

in an adequate amount

of water to prevent poor

washing quality due to the

decreased amount of water.

Therefore, the washing time

extends.

Supply voltage might be low. * Washing time is prolonged to

avoid poor washing results

when the supply voltage is

low.

Input temperature of the water

might be low.

* Required time to heat up

the water extends in cold

seasons. Also, washing time

can be lengthened to avoid

poor washing results.

Number of rinse cycles and/

or amount of rinse water might

have increased.

* Productincreasesthe

amount of rinse water when

good rinsing is needed and

adds an extra rinsing step if

necessary.

Excessive foam might have

occurred and the automatic

foam absorption system might

have been activated due to too

much detergent.

* Use the recommended

amount of detergent.

There may be an imbalance of

load in the drum.

* The automatic spin

correction system might have

been activated due to the

unbalanced distribution of

the laundry in the drum.

76 / English

Front-Loading Automatic Washer-Dryer

Troubleshooting

Problem Reason Solution

Program time

does not

countdown. (On

models with

display) (*)

Timer may stop during water

intake.

* Timer indicator will not

countdown until the product

takes in an adequate amount

of water. The product will

wait until there is a sufficient

amount of water to avoid

poor washing results due to

lack of water. Timer indicator

will resume countdown after

this.

Timer may stop during the

heating step.

* Timer indicator will not

countdown until the product

reaches the selected

temperature.

Timer may stop during

spinning step.

* The automatic unbalanced

load detection system might

be activated due to the

unbalanced distribution of

laundry in the product.

Product does

not switch to

spinning step. (*)

There might be an unbalanced

load in the product.

* The automatic unbalanced

load detection system might

be activated due to the

unbalanced distribution of

laundry in the product.

The product will not spin

if water is not drained

completely.

* Check the filter and the

draining hose.

Excessive foam might have

occurred and automatic foam

absorption system might have

been activated due to too

much detergent.

* Use recommended amount

of detergent.

“No spin” setting may be

adjusted.

* See “Spin Speed Selection”.

Drain pump filter or drain itself

may be clogged.

* Clean the drain pump filter

(See “User maintenance

instructions” ). If the house

drain pipes are clogged, call

a plumber for assistance.

Owner’s Guide & Installation Instructions

77 / English

Troubleshooting

Problem Reason Solution

Washing

performance is

poor: Laundry

turns

Grey. (**)

Insufficient amount of

detergent has been used over

a long period of time.

* Use the recommended

amount of detergent

appropriate for water

hardness and type of laundry.

Washing was made at low

temperatures for a long time.

* Select the proper

temperature for the type of

laundry to be washed.

Insufficient amount of

detergent is used with hard

water.

* Using insufficient amount of

detergent with hard water

causes the soil to stick on

the cloth and this turns the

cloth grey over time. It is

difficult to eliminate greying

once it happens. Use the

recommended amount of

detergent appropriate for

water hardness and the type

of laundry.

Excessive amount of detergent

was used.

* Use the recommended

amount of detergent

appropriate for water

hardness and type of laundry.

Washing

performance

is poor: Stains

persist or the

laundry is not

whitened. (**)

Insufficient amount of

detergent is used.

* Use the recommended

amount of detergent

appropriate for water

hardness and the type of

laundry.

Excessive laundry was loaded

in.

* Do not load the product to

excess. Load with amounts

recommended in the

"Programandconsumption

table".

Wrong program and

temperature were selected.

* Select the proper program

and temperature for the

laundry to be washed.

Wrong type of detergent is

used.

* Use detergent appropriate

for the product.

Excessive amount of detergent

was used.

* Putthedetergentinthe

correct compartment. Do not

mix the bleaching agent and

the detergent.

78 / English

Front-Loading Automatic Washer-Dryer

Troubleshooting

Problem Reason Solution

Washing

performance

is poor: Stains

could not

be removed.

Laundry could

not be whitened.

Wrong program cycle and

temperature might have been

selected.

* Select the proper program

cycle and temperature for the

laundry to be washed (See

“LaundryTips”&“Program

Cycle Selection”).

Using insufficient amount of

detergent.

* Use the recommended

amount of HE detergent

appropriate for water

hardness and soil level of

laundry.

Using wrong type of detergent.

* Use liquid detergent for

cold wash cycle for good

wash results. Use proper

detergents recommended for

wools, handwashable and

delicate items.

Mixing different sorts of items.

* Sort the laundry according to

care labels and user manual

(See “Laundry Tips”).

Mixing different types of

laundry additives.

* Putthedetergentinthe

correct compartment of

dispenser (See “Detergent

Dispenser”).

* Do not mix detergent with

bleaching agent or fabric

softener.

Excessive laundry may be

loaded into washer.

* Do not load the washer in

excess.

Detergent

residue left on

the laundry.

Excessive laundry might have

been loaded in.

* Do not load the washer in

excess.

Wrong program cycle and

temperature might have been

selected.

* Select the proper program

cycle and temperature for the

laundry to be washed (See

“LaundryTips”&“Program

Cycle Selection”).

Using powder or granular

detergents in cold water

washing may leave residue on

wash load.

* Use a liquid detergent when

washing in cold water.

Use proper detergents

recommended for wools,

handwashable and delicate

items.

Owner’s Guide & Installation Instructions

79 / English

Troubleshooting

Problem Reason Solution

Washing

performance

is poor: Oily

stains appear on

laundry.

Oily accumulations of prior

wash cycles on the drum may

have stuck to the laundry.

* Washer must be operated

empty at “Tub Sanitize” cycle

with detergent.

The detergent may have

been placed into the wrong

compartment; the detergent

may be mixed with the

softener.

* Softener should not come

into contact with detergent

when being added.

Washing

performance

is poor:

Clothes smell

unpleasant. (**)

Odours and bacteria layers are

formed on the drum as a result

of continuous washing at lower

temperatures and/or in short

programs.

* Leave the detergent drawer

as well as the loading door

of the product ajar after each

washing. Thus, a humid

environment favorable for

bacteria cannot develop in

the machine.

Color of the

clothes is faded.

(**)

Excessive laundry was loaded

in.

* Do not load the product to

excess.

Detergent in use is damp. * Keep detergents closed

in an environment free

of humidity and do not

expose them to excessive

temperatures.

Exposure of laundry to

undiluted liquid chlorine

bleach.

* Do not pour undiluted

liquid bleach onto laundry.

Always pour it into bleach

compartment of the

dispenser prior to beginning

of the wash cycle .

* Do not overfill the bleach

compartment. Fill up to max

line at the most.

A higher temperature is

selected.

* Select the proper program

and temperature according

to the type and soiling

degree of the laundry.

80 / English

Front-Loading Automatic Washer-Dryer

Troubleshooting

Problem Reason Solution

Rinsing

performance is

poor.

Intermediate spins may be

skipped.

* There may be an imbalance

of laundry in the machine.

The laundry in the drum

may be tangled up too

much. Laundry should be

rearranged and re-spun. No

spinning is performed when

the laundry is not evenly

distributed in the drum to

prevent any damage to

the appliance and to its

environment.

The amount and storage

conditions of the detergent

used might not be appropriate.

* Store detergents in a cool

and dry place. Do not

keep them under high

temperatures.

Not using HE detergent * Use HE detergent.

Using excessive amount of

detergent

* Reduce the amount of

detergent.

Drain hose may be folded.

* Check the drain hose and

straighten if necessary.

Drain pump filter or drain itself

may be clogged.

* Clean the drain pump filter

(See “User maintenance

instructions” ). If the house

drain pipes are clogged, call

a plumber for assistance.

Laundry became

stiff after

washing. (**)

Insufficient amount of

detergent is used.

* Using an insufficient amount

of detergent for the water

hardness can cause the

laundry to become stiff

over time. Use appropriate

amount of detergent

according to the water

hardness.

Detergent is put in the wrong

compartment.

* If detergent is put in the

prewash compartment when

the prewash cycle is not

selected, the product can

take this detergent during the

rinsingorsoftenerstep.Put

the detergent in the correct

compartment.

Detergent might be mixed with

the softener.

* Do not mix the softener with

detergent. Wash and clean

the dispenser with hot water.

Owner’s Guide & Installation Instructions

81 / English

Troubleshooting

Problem Reason Solution

Laundry does

not smell like the

softener. (**)

Detergent is put in the wrong

compartment.

* If detergent is put in the

prewash compartment

when the prewash cycle is

not selected, the product

can take this detergent

during the rinsing or softener

step. Wash and clean the

dispenserwithhotwater.Put

the detergent in the correct

compartment.

Detergent might be mixed with

the softener.

* Do not mix the softener with

detergent. Wash and clean

the dispenser with hot water.

Softener might have been

released early.

* Youmayhaveaddedtoo

much softener beyond max

fill line.

* The detergent dispenser

might be problematic. Water

may be siphoned (pulling

the softener into the washer

early) during the fill or rinse

cycles.

* There might be problems

with the water inlet valves.

Detergent

residue in

the detergent

drawer. (**)

Detergent is put in a wet

drawer.

* Dry the detergent drawer

before putting in detergent.

Detergent has gotten damp. * Keep detergents closed in an

environment free of humidity

and do not expose them to

excessive temperatures.

Water pressure is low. * Check the water pressure.

The detergent in the main

wash compartment got wet

while taking in the prewash

water. Holes of the detergent

compartment are blocked.

* Check the holes and clean if

they are clogged.

There is a problem with the

detergent drawer valves.

* Call the Authorized Service

Agent.

Detergent might be mixed with

the softener.

* Do not mix the softener with

detergent. Wash and clean

the dispenser with hot water.

Regular drum cleaning is not

performed.

* Clean the drum regularly. For

this procedure, please see

"Cleaning the loading door

and the drum".

82 / English

Front-Loading Automatic Washer-Dryer

Troubleshooting

Problem Reason Solution

Too much foam

forms inside the

product. (**)

Not using HE detergent * Use HE detergent.

Excessive amount of detergent

is used.

* Use only a sufficient amount

of detergent.

Detergent was stored under

improper conditions.

* Store detergent in a closed

and dry location. Do not

store in excessively hot

places.

Some meshed laundry such

as tulle may cause too much

foam because of their texture.

* Use smaller amounts of

detergent for this type of

item.

Detergent is put in the wrong

compartment.

* Putthedetergentinthe

correct compartment.

Softener is being taken early

by the product.

* There may be problem in

the valves or detergent

dispenser. Call the

Authorized Service Agent.

Foam is

overflowing from

the detergent

drawer /

Machine is

completely full

of suds.

Not using HE detergent /

Using excessive amount of

detergent

* Push“Start/Pause/Cancel”

button. Mix 2 cups of water

with 1-2 tablespoon of

fabric softener and pour it

into detergent dispenser.

Push“Start/Pause/

Cancel” button again.

Use proper amount of HE

detergent next time you

operate the washer.

* Use detergent suitable for

the programs and maximum

loads indicated in the

“Programandconsumption

table”. When you use

additional chemicals (stain

removers, bleaches, etc.),

reduce the amount of

detergent.

Owner’s Guide & Installation Instructions

83 / English

Troubleshooting

Problem Reason Solution

Load is still too

soapy / Machine

is full of suds

at the end of

program.

Not using HE detergent /

Using excessive amount of

detergent

* Do not unload the machine.

Operate a quick wash cycle

(e.g. Delicates, Wools)

without any detergent.

Add 1-2 tablespoon of

fabric softener into main

wash compartment of

detergent dispenser

during water intake.

Use proper amount of HE

detergent next time you

operate the machine.

Laundry remains

wet at the end of

the program. (*)

Excessive foam might have

occurred and automatic foam

absorption system might have

been activated due to too

much detergent.

* Use the recommended

amount of detergent.

Unbalance detection due to

small amount of laundry inside

the drum and/or uneven load

distribution.

* Add more laundry (e.g. a

few additional towels) to the

drum and start a “Spin” or

“Spin&Drain”cycle.

Poor spinning results due to

not using HE detergent / using

excessive amount of detergent

* Use proper amount of HE

detergent.

Washer fills with

water when

a process is

cancelled.

There may be hot water inside

washer.

* For safety reasons, water

should be cycled in and out

a couple times.

Time delay

function does

not work.

Door may not be closed

properly.

* Close the loading door.

The door will not

lock/door led

remains OFF.

Door is not properly closed/

Door hinge is not aligned with

lock switch.

* Check for excessive laundry

avoiding the door to be

closed.Pushand/orshutthe

loading door firmly until it is

properly closed.

84 / English

Front-Loading Automatic Washer-Dryer

Troubleshooting

Problem Reason Solution

Clothes get

tangled up too

much in the

drum when

washing.

Excessive laundry might have

been loaded in.

* Do not load the machine in

excess.

Washing many items of the

same type or size of clothes

together.

* Load the wash drum with

items of different sizes.

Load is wrinkled.

Delay in unloading the

machine.

* Unload the machine as soon

as the wash cycle ends.

Wrong program cycle might

have been selected.

* Select the proper program

cycle for the laundry to

be washed (See “Laundry

Tips”&“ProgramCycle

Selection”).

Excessive laundry might have

been loaded in.

* Do not load the machine in

excess.

Machine does

work. Nothing is

displayed on the

screen.

The plug might not be plugged

in the wall power outlet.

* Check the plug.

Fuse may have blown.

* Check the fuse / circuit

breaker.

Power may be cut off. * Check the supply power.

Owner’s Guide & Installation Instructions

85 / English

Troubleshooting

Problem Reason Solution

Drying lasts too

long.

Excessive laundry loaded. * Do not load the machine in

excess.

Laundry is not spun enough. * Spin at a higher spin speed

in washing step in the Dryer-

Washing Machine.

Tap is turned off. * Turn on the taps.

Laundry is still

damp after drying.

An appropriate program

according to laundry type

might is not selected.

* Check care labels on clothes

and select an appropriate

program or use timed

programs in addition.

Excessive laundry loaded.

* Do not load the machine in

excess.

Laundry is not spun enough.

* Spin at a higher spin speed

in washing step in the Dryer-

Washing Machine.

Machine does

not start or

program cannot

be started.

Power cable is not connected.

* Make sure the power cable is

connected.

Program is not set or Start /

Pause / Cancel button is not

pressed.

* Make sure the program is

set and it is not in Stand-by

mode.

Child lock enabled. * Disable Child lock.

Laundry is

shrunken,

pale, matted or

damaged.

An appropriate program

according to laundry type is

not selected.

* Check care labels on clothes

and select an appropriate

program or use timed

programsinaddition.You

must not dry clothes that are

not suitable for drying.

Machine does

not dry.

Laundry is not dried or drying

step is not enabled.

* Check if drying function is

selected after the selected

washing program.

86 / English

Front-Loading Automatic Washer-Dryer

Troubleshooting

Problem Reason Solution

Loading door

cannot be

opened.

Your machine’s door is not

opened for safety reasons.

* If door locked indicator is still

active on display after drying,

machine keeps the loading

door locked until it cools for

your safety.

(*) The product does not switch to the spinning step when the laundry is not

evenly distributed in the drum to prevent any damage to the product and to

its surroundings. Laundry should be rearranged and re-spun.

(**) Regular drum cleaning is not performed. Clean the drum regularly. See

“Cleaning the loading door and the drum”

CAUTION

• If you cannot eliminate the problem despite following the

instructions in this section, consult your dealer or the Authorized

Service Agent. Never try to repair a nonfunctional product

yourself.

Owner’s Guide & Installation Instructions

87 / English

9 WARRANTY STATEMENT FOR THE BLOMBERG

CLOTHES WASHER-DRYER

The warranties provided by Blomberg in these statements only apply to Blomberg washer-dryer sold to the original purchaser

or homeowner in the US and Canada. The warranty is not transferable. To obtain warranty service, please contact our nearest

distributor as listed by state. You will need your product model number, serial number, retailer name and address, where purchased

and purchase date / installation date. This warranty gives you specific legal rights, and you may also have other rights which vary

from state to state.

1 year * limited warranty from date of first installation Blomberg will repair or replace at no cost to the consumer any defective

parts of the machine if used under normal household conditions (warranty is void if the product is used commercially e.g., bed +

breakfast, nursing home etc.). Service must also be performed by an authorized Blomberg service agency. (Cosmetic defects must

be reported within 10 business days from installation)

2 year * ++ limited warranty from date of first installation (Parts only) Blomberg will repair or replace any parts at no cost to the

consumer if material defects

or workmanship have caused the damage or failure of these components. Again the appliance must have been used under normal

household conditions and not commercially as stated above (Labor charges are the responsibility of the consumer)

5 year * ++ limited warranty from date of first installation (parts only 2-5 years) Blomberg will repair or replace any circuit boards

or machine drum (excluding any plastic attachments) at no cost to the consumer if material defects or workmanship have caused

the damage or failure of these components. The product must have been used under normal household conditions and not

commercially (Labor charges are the responsibility of the consumer)

Lifetime limited warranty from date of first installation * ++ (parts only) Blomberg will repair or replace to the original owner the

stainless steel drum if rust through occurs under normal household use and normal water conditions (no excessive chlorine).

Blomberg may, at its option, also replace the whole product with the same and/or equivalent model with equal or better

functionality if the original model is no longer available. (Labor, removal and installation charges are the responsibility of the

consumer.)

Disclaimers of warranties and exclusions:

Warranty does not cover service costs by an authorized service agent to correct installation, electrical and plumbing problems or

educational instruction on the use of the product. The warranty also does not cover defects or damage caused by an act of god

(such as storms, floods, fires, mudslides, etc.), damage cause by use of the product for purposes other than those for which it was

designed, misuse, abuse, accident, alteration, improper installation, maintenance, travel fees, service calls outside normal service

hours, unauthorized service work or work.

This product is fully tested and went through official quality assurance inspections before leaving the original manufacturing site.

Warranty terms for this Blomberg household appliance is not valid if the product is altered, tampered, modifed, additional parts

assembled, fixed and re-packed by an authorized distributor, servicer, a third party retailer, reseller or by any other unauthorized

person(s)”

TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESSED AND IMPLIED WARRANTIES,

INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. BLOMBERG

UNDERTAKES NO RESPONSIBILITY FOR THE QUALITY OF THIS PRODUCT EXCEPT AS OTHERWISE PROVIDED IN THIS WARRANTY

STATEMENT. BLOMBERG ASSUMES NO RESPONSIBILITY THAT THE PRODUCT WILL BE FIT FOR ANY PARTICULAR PURPOSE FOR

WHICH YOU MAY BE BUYING THIS PRODUCT, EXCEPT AS OTHERWISE PROVIDED IN THIS WARRANTY STATEMENT.

Blomberg does not assume any responsibility for incidental or consequential damages. Such damages include, but are not limited

to, loss of profits, loss of savings or revenue, loss of use of the product or any associated equipment, cost of capital, cost of any

substitute equipment, facilities or services, downtime, the claims of third parties, and injury to property. Some states do not allow

the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusion may not apply to you.

* installation date shall refer to either purchase date or 5 business days after delivery of the product to the home, whichever is

later.

++Parts replaced will assume the identity of the original parts + their original warranty.

No Other Warranties. This Warranty Statement is the complete and exclusive warranty from the manufacturer. No employee of

Blomberg or any other party is authorized to make any warranty in addition to those made in this Warranty Statement.

88 / English

Front-Loading Automatic Washer-Dryer

10 HOW TO GET SERVICE

PleasecontacttheDistributorforyourstateaslistedonthe

Distributor Contact List, or call our Toll Free Number at 1 800 459

9848 for direction to an Authorized Blomberg Service Agent.

www.blomberginternational.com

[email protected]

2820525511_EN / 11-04-18.(14:40)

Document Number :

Blomberg WMD24400W 24'' Front Loading Automatic Washer-Dryer

Product's Documents

Owner’s Guide & Installation Instructions

Specifications

Blomberg WMD24400W Questions and Answers

Related Products

Blomberg LRF854311 Washer Dryer 8kg / 5kg Capacity

Blomberg LRF1854311W Washer Dryer With 8kg / 5kg Capacity

Blomberg LRF1854310 Washer Dryer

Blomberg LRI1854110 Integrated Washer Dryer 8kg / 5kg Capacity

Blomberg LRI1854111 Integrated Washer Dryer 8kg / 5kg Capacity

Blomberg LRI1854310 Integrated Washer Dryer with 8kg / 5kg Capacity
