Euromaid F54EW 54cm Freestanding Electric Oven/Stove User Manual

Euromaid

price, quality, performance

Front Control Models

White F54CW F54EW F54RW F54GW FD54CW FD54EW FD54RW

S/Steel F54CS F54ES F54RS F54GS FD54CS FD54ES FD54RS

Rear Control Models

White R54CW R54EW R54RW

540mm Separate Grill Upright Cooker

USER MANUAL

Conditions of use .........................................................................................................................3

Safety precautions ....................................................................................................................... 3

Other important safety information ............................................................................................3

Warnings for use of grill, oven, and appliance hob ..................................................................4

Disposal of packaging ...............................................................................................................4

Installation, cleaning and servicing ...........................................................................................5

Product description .....................................................................................................................6

First time use of the appliance ...................................................................................................9

Using the oven ...........................................................................................................................10

Using the grill ..............................................................................................................................14

Using the hotplates of your cooker ..........................................................................................15

Using the hotplate gas burners ................................................................................................17

Fitting oven accessories and cleaning ....................................................................................18

Solving problems ........................................................................................................................22

Installing cooker – power connections ....................................................................................23

Installing the gas cooker ...........................................................................................................24

Testing the operation of the gas cooker .................................................................................. 26

Installing your new cooker.........................................................................................................27

Technical speciﬁcations ............................................................................................................30

Notes ...........................................................................................................................................33

Contents

Safety precautions

• Thisapplianceisnotintendedforusebypersons

(includingchildren)withreducedphysical,sensory

ormentalcapabilities,orlackofexperience

andknowledge,unlesstheyhavebeengiven

supervisionorinstructionconcerninguseofthe

appliancebyapersonresponsiblefortheirsafety.

• Warning–ensurethatnodownwardpressureis

appliedtotheovendoorwhenopen.Inparticular,

DONOTALLOWachildtoclimbontoopenoven

door

• Warning-accessiblepartscanbecomehotduring

use,especiallytheovendoor.Toavoidburns,

youngchildrenMUSTBEKEPTAWAY.

• Youngchildrenshouldbesupervisedtoensurethey

donotplaywiththisappliance.

• Duringusethisappliancebecomeshot.Care

shouldbetakentoavoidtouchinghotexternaland

internalsurfaceswheninuse.Useovengloves.

• Thecooktopareaincludingtheentirehobwill

becomeveryhotwheninuse.CareMUSTBE

TAKENwhenusingthispartoftheappliance.

• Installcooker,shelvingandttingsinaccordance

withthisManual.

• Ensureallspeciedvents,openingsandairspaces

arenotblocked.

 Accordingtotheelectricalsafetyregulations

theapplianceequipmentmustbeproperly

earthed.



Donotusecorrosivecleanerse.g.oven

cleanersthatcontaincausticsoda.

 Thisappliancemustnotbeusedasaspace

heater.

 Donotobstructtheventilationslotsonfront

orbackofappliance.

 Donotremoveanylabelsoruseabrasive/

corrosivecleanerson.

WerecommendthatyoureadtheinstructionsinthisManualcarefullybeforeuseforthebestperformanceandto

extendthelifeofyourappliance,asitwillprovideyouwithalltheinstructionsyourequiretoensureitssafeinstallation,

useandmaintenance.AlwayskeepthisManualclosetohandsinceyoumayneedtorefertoitinthefuture.Thank

you.

Conditions of use

Thisapplianceisintendedtobeusedfordomesticuse,notcommercialuse.

• Toensureyoursafety,allelectricappliancesshould

onlybeinstalledorservicedbyqualiedpersons.If

thesupplycordisdamaged,itmustbereplaceda

serviceagentorsimilarlyqualiedpersoninorderto

avoidahazard.

• ImportantNotice-ThisUprightCookermust

bettedsecurelyusingthesupplDonotspray

aerosolsinthevicinityofthisappliancewhileitisin

operation.

• Donotstoreammablematerialsintheapplianceor

nearthisappliance.

• Donotoperateanygasapplianceifthesmellofgas

persists.

• Donotmodifythisappliance.

• Appliancemustbeinstalledaccordingtocurrent

lawsandregulationsbyqualiedtradesmen/

Installers.

• GasmodelsareNOTAPPROVEDforinstallationin

marinecraft,caravansormobilehomes.

TheManufacturersandImporters/Distributors

andRetailersshallnotbeliabletoanylegalliability,

personalinjuryandpropertydamagedueto

incorrectoperationorincorrectInstallation.

Euromaid 540mm Upright Cooker CONDITIONS OF USE 3

Other important safety information

4 Euromaid 540mm Upright Cooker WARNINGS FOR USE OF GRILL, OVEN, AND APPLIANCE HOB

Warnings for use of grill, oven, and

appliance hob

Grill warnings

• DONOTleavegrillonunattended.

• DONOTcoverthegrilltraywirerackwithfoil.

• Tryingtogrillfoodmorethan25mmthickunder

grillcanbearehazard.Trimexcessfatfromfatty

meats,suchasporkandlamb.

• Fatleftonagrilltrayisarehazard!Keepgrillclean

andturnoffgrillimmediatelyafteruseandleave

draweropenforafewminutestocoolgrillarea.

Oven warnings

• DONOTpushdownorapplyanyweightonopen

ovendoor.

• DONOTplacedishesonopendoorofoven

• DONOTlineovenwithfoilorplaceanythingonthe

bottomoftheovenwhilebakingtoavoidpermanent

damage,astrappedheatwillcrackorcrazethe

enamelooroftheovencavityliner.

• Useofoliveoilandotherpoly-unsaturatedoils

(vegetableoils)whenroastinguncoveredfood

causesdepositsinsidetheovenwhicharevery

difculttoremove.

• Ifyouhaveanuprightcookerwithagasoventhat

doesnotlightwithinaboutin5-8seconds,allow1

minuteforgastodisperseclearbeforetryingagain.

Hotplate and burner warnings

• DONOTallowpotstoboildry,asdamageto

hotplatemayresult.

• DONOToperatehotplatesorburnerswithouta

pot,frypanetc.

• DONOTallowcookwaretooverhanghobonto

adjacentbenchtops,thiswillcausescorchingto

thebenchtopsurface.

• Gasmodels:Ensureburnercapsandcrownsare

intheircorrectpositiontoavoiddamagetothese

parts

Ceramic hotplate warnings

• DONOTplaceheatresistantmats,wirematsor

aluminumfoilunderpotsorpans.

• DONOTcookfooddirectlyontheceramicglass

surface.

• DONOTuseroundbottomwoksorsimilarutensils

whichcouldleadtooverheatingofhotplatesand

possibledamagetothecookingsurface.Cookware

usedshouldhavecompletelyatbases.

• Ensurecookwarestatesitissuitableforuseon

ceramicglass.Somealuminiumandcopperbased

cookwarecancauseminorpittingoftheceramic

glasssurface.

• DONOTusetheceramiccooktopasextrabench

spaceorasacuttingboard.

• AVOIDdroppingheavyobjectsontotheceramic

glasssurfaceasdamagecanoccur

• Immediatelycleanglasswhensugaryliquidshave

spilteg.stewedfruit,jam,meltedsugar.

Disposal of packaging

Pleaserecyclethecardboard,andalsoanypolystyrenepackagingwherepossible.

• Anauthorisedpersonmustinstallthisappliance.

(CerticateofCompliancetoberetained).

• Beforeusingtheappliance,ensurethatallpacking

materialsareremovedfromtheappliance.

• Inordertoavoidanypotentialhazard,the

InstallationInstructionsmustbefollowed.

• Inordertoavoidaccidentaltippingoftheappliance

(forexample,byachildclimbingontotheopen

ovendoor),theantitiltbracketandstabilitybolt

mustbeinstalledpropoerlyandsecurelytotheoor.

• Wheretheapplianceisinstallednexttocabinets,

thecabinetmaterialmustbecapableof

withstanding85º.

• Onlyauthorisedpersonnelshouldcarryout

servicing(CerticateofCompliancetoberetained).

• WARNING-Alwaysensuretheapplianceis

switchedoffbeforecleaningoranymaintenanceis

carriedoutsuchaschangingoflightglobes.

• DONOTuseabravisetypecleanerorcausticsoda-

basedcleaners.Usingwarmsoapywaterafterthe

appliancehascooledsomewhat,followedbyadry

clothissuitable.

• DONOTusesharpmetalscraperstocleanoven

doorastheycanscratchthesurface,whichmay

resultinshatteringoftheglass.

• DONOTusesteamcleanersasamethodtoclean

thisappliance.

• Alwayscleantheapplianceimmediatelyafterany

foodspillage.

• Tobeservicedonlybyanauthorizedperson.

• Appliancesrequiringconnectionto220-240Vand

mustbeearthed.

• GasmodelsareNOTAPPROVEDforinstallationin

marinecraft,caravansormobilehomes.

Installation, cleaning and servicing

Euromaid 540mm Upright Cooker INSTALLATION, CLEANING AND SERVICING 5

Description of cooker with separate grill

and rear controls

 1.Hob(Solid,coilandceramic)

 2.Heatshield(coilelementmodelsonly)

 3.Telescopicrunner

 4.Grilldrawer

 5.Ovenshelf(2supplied)

 6.Enamelledovenbakingtray(1supplied)

 7.Oveninnerdoorglass

 8.Ovendoor

 9.Controlpanel

10.Grillelement(insidecompartment)

11.Grilltraywirerackinsert(reversibletoadjustheight)

12.Enamelledgrilltray(1supplied)

13.Fan&elementcover

14.Ovenrearfanforcedelement

15.Hiddenovenbaseelement

16.Rearadjustableantislipfeet(2)

17.Antitiltoorbracket

18.Kickpanel(stabilityboltlocatedbehindkickpanel)

19.Frontadjustableantislipfeet(2)

6 Euromaid 540mm Upright Cooker PRODUCT DESCRIPTION

Product description (Rear Control Models)

Description of cooker with separate grill

and front controls

 1.Hob(Solid,coil,ceramicandgas).Gasmodel

suppliedwithcastirontrivetsandWOKadapter.

 2.GasModel-Wokburner(1)(highlighted)with

removablecap,distributor,otherburners(2xsemi

rapid,1xauxiliiary).

 3.Controlpanel

 4.Telescopicrunner

 5.Grilldrawer

 6.Ovenshelf(2supplied)

 7.Enamelledovenbakingtray(1supplied)

 8.Oveninnerdoorglass

 9.Ovendoor

10.Rearsplashback(1supplied)

11.Grillelement(insidecompartment)

12.Grilltraywirerackinsert(reversibletoadjustheight)

13.Enamelledgrilltray(1supplied)

14.Fan&elementcover

15.Ovenrearfanforcedelement

16.Hiddenovenbaseelement

17.Rearadjustableantislipfeet(2)

18.Antitiltoorbracket

19.Kickpanel(stabilityboltlocatedbehindkickpanel)

20.Frontadjustableantislipfeet(2)

7 Euromaid 540mm Upright Cooker PRODUCT DESCRIPTION

Product description (Front Control Models)

 4.Grilltemperaturecontrolknob

• Adjustsgrillingtemperature.

 5.Oventemperaturecontrolknob

• Adjustsoventemperature.

 6.Functionswitchcontrolknob

• Setsovenfunction/mode.

 7.120MinuteRingerTimer(Somemodelsttedwith3

buttonclockwithdigitaldisplay)

• Sets“reminder”alarmcount-downtime,orif

ovenisbeingused,thecookingtimeuntiloven

switchesOFF.

NOTE:Thegasburnercontrolknobshavetobe

helddownforapproximately5secondstoignite.

Grill

Oven Function

Timer

2 3

4 5 6

Description of gas cooktop model front

panel controls only

1. Hotplateelements/burnerscontrolknobs

• Setselementsorburnerscookingtemperature.

 2.Grillindicatorlamp

• Comesonwhengrillisbelowsettemperature,

cyclesonandoffduringgrilling.

 3.Ovenindicatorlamp

• Lampisonwhenovenelementisheatingup

oven,thencyclesonandof.

Gas F54GW/F54GS

Grill

Oven Function

Timer

2 3 4

5 6 7 8

Grill Oven

Function

2 3

5 6 7 10

Grill

Oven Function

Timer

2 3 4

5 6 7

Grill

Oven Function

2 3 4

5 6 7 1

 1.Radiant(solidorcoil)HotplateControlKnob-can

berotatedineitherdirection

• Adjuststemperatureofhotplate.

 2.HotplateIndicatorLamp(wheretted)

• Comesonwhenahotplateisturnedon.

 3.GrillIndicatorLamp

• Comesonwhengrillisbelowsettemperature,

cyclesonandoffduringgrilling.

 4.OvenIndicatorLamp

• Lampisonwhenovenelementisheatingup

oven,thencyclesonandoff.

 5.GrillTemperatureControlKnob

• Adjustsgrillingtemperature.

 6.OvenTemperatureControlKnob

• Adjustsoventemperature.

Product description (control panels)

Grill

Oven Function

Timer

3 4

5 6 7 8

Grill Oven

Function

Timer

3 4

5 6 7 8

Controls

Front control panel models

 7.FunctionswitchControlKnob

• Setsovenfunction/mode.

 8.120MinuteRingerTimer(wheretted)

• Sets“reminder”alarmcount-downtimeorif

ovenisbeingused,switchesovenOFFafter

cookingtimesethasended.

 9.CeramicCooktopControlKnob

• Adjuststemperatureofceramiccooktop.

Canberotatedineitherdirection.

10.ProgrammableClock(wheretted)

• Setscookingremindertimes.

• Setsautomaticcookingdurationandstoptime

NOTE:Clocktimemustbesetbeforeovencan

operate.

Euromaid 540mm Upright Cooker PRODUCT SPECIFICATION 8

Rear control models

Solid F54EW/F54ES

Coil F54RW/F54RS

Solid FD54EW/FD54ES

Coil FD54RW/FD54RS

CeramicF54CW/F54CS CeramicFD54CW/FD54CS

Solid R54EW/R54ES

Coil R54RW/R54RS

CeramicR54CW/R54CS

Fitting oven shelves

• Ensureshelforientationiscorrect(referpicture).

• Theshelfhasasafetybarttedtoreducetherisk

ofdishesslidingofftheshelf,thisistherearofthe

shelf

• Slideintoovenatanangleuntilraisedbackofshelf

ispastthestoponsiderunners.

• Lowerfrontofshelfandpushinuntilstopis

reached.

• NOTE:Thetopledgeisnotashelfposition

Oven shelf positions

• Themainovenhas5shelfpositionstochossefrom.

Position1isthepositionatthebottomoftheoven

andposition5islocatedatthehighestpointofthe

oven

• The5positionsideracksystemcanhouseboththe

standardovenshelvesandbakingtray.

Preparing your appliance for the

ﬁrst time

• Pleasewipeouttheoveninteriorpriortooperation

withwarmsoapywaterandpolishdrywithasoft

cleancloth.

• Newappliancescanhaveanodourduringrst

operationfromcomponentsmanufacturedwiththe

aidofoils.Itisrecommendedto‘runin’youroven

beforeyoucookforthersttime.Runtheanempty

ovenat180°Cforapproximately1to2hours.

Ensurethattheroomiswellventilated.

• Pleaseinstallovenfurnitureasoutlinedinthe

“FittingOvenAccessoriesandCleaning”section.

• Ifyourapplianceisttedwithsolidhotplates,turn

heatsettingtohighfor3minutestofullyharden

thecoating.Whencooled,applyathincoatingof

cookingoiltosealthesurface.

• Thegrillelementmayhaveoilsleftonthegrillduring

manufacture.Beforeyoucookonthegrillforthe

rsttime,turnonfor15minuteswith10mmof

waterinthebottomofthegrilldish.

120 Minute Timer models

Ifyouruprightcookeristtedwitha120minutetimer

youmustselectacookingtimeorturntheknob

clockwisetothe‘ ’symboltooperate.Ifeitherof

thesearenotselectedtheovenwillnotheat.

Digital Timer with 3 buttons

Ifyouhavepurchasedamodelttedwitha3button

programmabletimer,youmustsetthetimeofday

beforeyoucanoperateyourappliance.

• Aftertheappliancehasbeenelectricallyconnected

“00.00”willbedisplayedandthe“ ”willash.

• Tosetthetimeofday,pressthe“–”or“+”buttons.

15secondsafterthelastchange,the“ ”will

disappear,conrmingthetimehasbeenset.

NOTE:Theclockhasa24-hourdisplay

Euromaid 540mm Upright Cooker FIRST TIME USE OF THE APPLIANCE 9

First time use of the appliance

Timer

Level 5

Level 4

Level 2

Level 3

Level 1

BottomElementwithFan(Pizza)Cooking“



”

Thebottomheatingelementandthefancomeon.

Suitableforpastries,pizzas,cakesandpuddingsin

bakingtinsormoulds

Donotuselowestshelfposition

Fan-forcedCooking“



”

Therearcircularheatingelementandthefancomeon

tomakeheatdistributedmoreuniformlythroughoutthe

oven.Idealforcookingonmorethanonelevelatatime.

Thismodeisidealforgeneralpurposecookingsuchas

bakingcakes,mufnsandroastingmeat.Cookion

multipleshelfpositionsatthesametime.

DefrostingMode“



”

Onlythefanoperates.Itislocatedonthebackof

theoven,causingmakestheairtocirculateatroom

temperaturearoundthefood.Thisisrecommendedfor

thedefrostingofalltypesoffood,butinparticularfor

delicatetypesoffoodwhichdonotrequiresubsequent

cooking,suchasforexample:icecreamcakes,cream

orcustarddesserts,fruitcakes.Byusingthismode,the

defrostingtimeisapproximatelyhalved.

2) Oven Temperature (thermostat) Knob

• Selectionofcookingtemperatureiscarriedout

byturningtheknobclockwisetotherequired

temperature,between60ºCtoMAX.

• Iftheapplianceiselectricthe“ovenindicatorlamp”

willcomeonwhentheovenisheatingup.When

itgoesoutitmeansthatitreachestherequired

temperature.Theovenindicatorlampgoing‘on&

off’duringuseisthennormal.Thismeansthatoven

temperatureisbeingconstantlymaintainedatthe

selectedlevel.

Oven safety warnings

• Alwaysfollowtheinstructionsforputtingtheshelves

andsideracksintotheoven,toavoidaccidents.

• DONOTlinetheovenwithfoil,itwilldamagethe

enamelcoating.

• DONOTplacecookwareoranythingelseonthe

bottomofovenastrappedheatwilldamagethe

ovenenamelcoating.

• DONOTtouchthehotsurfacesorheatingelements

insidetheoven.

• DONOTusetheovendoorasashelf.

• DONOTpushdownorsitontheopenovendoor.

• DONOTplaceshelvesontopofuppermostshelf

runnerastherearenostopsforshelfwithdrawal.

Operation

Set: 1) Oven Function 2) Temperature

3) Cooking time

1) Oven Function Knob

Descriptionofeachovenfunction(mode)

Lamp“



”

Thelampoftheovenison.Noheatingelementsareon.

Conventionalcooking/nofan

(useshiddenbottomelement)“



”

Suitableforcakes,biscuits,slowcookingandideal

forblindbaking.Goodforslowcookingatlower

tempeartures(below150degreescelcius).

Donotuselowestshelfpositionasbaseoffoodcan

burnasitisclosetotheelement.

Using the oven

Function

Oven

10 Euromaid 540mm Upright Cooker USING THE OVEN

Starting-upprocedure

Afterpoweron,thescreenwilldisplay“00:00”and

“ ”clockindicatorwillbeon.

Timeofdaysettingprocedure

NOTE:Digital clock is displayed in 24 hour format

When“ ”clockindicatorandhourindicationare

ashing,press“+”upkeyor“–”downkeytoselecta

numbervaluefrom(0-23)forthehourtime,thenpress

“ ”setkeytochangetotheminutesetting.Whilst

ashingpress‘+‘upkeyor‘-“downkeytoselecta

numbervaluefrom(0-59)fortheminutetime.The

“ ”clockindicatorwillremainashingfor15

secondsoncethetimeissetandneitherofthe“+”up

keyor“–”downkeysandpressedagainwhilstashing

Durationtimersettingprocedure

Press“ ”selectionbutton3timesuntil“ ”heating

indicatorisashing,thenpress“+”upkeyorthe“–”

downkeytoselectthecookingdurationtimeinhours.

Thenpressthe“ ”selectionbuttontoenterthe

cookingdurationtimeinminutessetting.The

“ ”heatingindicatorwillremainashingfor15

secondsoncethecookingdurationtimeissetand

neitherofthe“+”upkeyor“–”downkeysare

pressedagainwhilstashing.

Alternativelypressthe“ ”selectionbuttonandthe

ovenwillstartcookingimmediately

Ifdurationtimersettingdoesneedtoexceed59

minutestheninitiallythe“ ”selectionbuttonshould

bepressed4timesinsteadof3tobypassthehour

durationselection.

Audible‘EndofCooking’buzzer

Thebuzzerwillsoundforup60secondsattheendof

thecookingtimedurationthathasbeensethasbeen

reached.The“00:00”displayand“ ”heating

indicationwillashforthisperiodunlessthe“

”selectionbuttonispressed.Theclockwillreturnto

thetimeofdaydisplaywheneitheroftheabovetow

actionsoccur.

Remarks

• Ifyoupress“+”upkeyor“–”downkeyformore

than3seconds,thevaluewillchangequickly.

• WhensettingtheTimeofDayorDurationTimerthe

“:”doesnotblinkalthoughwillblinkwhenineither

eithernormalTimeofDaymodeorDurationTimer

isdisplayed.

3) Set Cooking Time

■

120MinuteRingerTimerwith“OvenON/OFF”

• OperatingovenwithoutTimer-Turnknob

counterclockwiseto“ ”symbol.Theovenwill

operatewithuseofthetimerfunction.

• OperatingovenusingtheTimer-Tosetthetimer,

simplyturntheknobclockwisetotherequired

numberofminutes.Thetimerwillautomaticallyshut

downtheovenafterthesetminutesandthetimer

willringatthesametime.

•

NOTE:Foranytimebelowfteenminutesturntheknob

pastthefteenthenturnitbacktotherequirednumber

ofminutes.Whenthetimerreturnstozero,thetimer

givesashortring.

■

ProgrammableClock(somemodelsonly)

1 Heatingindication

2 Clockindication

3 Hourindication

4 Secondindication

5 Minuteindication

6 Up

7 Set

8 Down

Using the oven

Euromaid 540mm Upright Cooker USING THE OVEN 11

3 4 5

6 7 8

Timer

Oven cooking guide

Thefollowingcookingguideisintendedasaroughguideonly.Youmayberequiredtosetoven10-20degreesabove

orbelowthisguidetogettheresultyouwant.Alsoadjustmentsmaybeneededtothecookingtimetosuitpersonal

expectations.IfyouarenewtousingaFanForcedovenItisadvisabletomaketheseadjustmentsuntilyougetto

knowthewayyoorovenperforms.Iffollowingcookbookrecipesorpre-packagedgoodsyoushouldreadcarefully

theircookingtimesguidelines.

Forbestresultswhenbaking,preheatyourovenfor15-20minutes.

Food

Conventional Oven / Pizza Fan forced mode

Time in

minutes

Temperature (ºC) Oven shelf

position

Temperature(ºC) Oven shelf

position

Plainorfruitscones 200 Any 10-15

Rolledbiscuits 170 2-3 150 Any 10-15

Spoonedbiscuits 190 2-3 180 Any 12-15

Shortbreadbiscuits 160 2-3 150 Any 30-35

Hardindividualmeringues 110 2 100 Any 90

Softindividualmeringues 180 2 165 Any 15-20

Pavlova 110 2 100 Any 75

Pattycakes 190 2-3 170 Any 15-20

Sponge 180 2-3 170 Any 20-30

Plainbuttercake 180 2 170 Any 25-40

Richfruitcake 140 2 130 Any 180

Shortcrustcornishpasty 180-200 2* 160 Any 40-45

Shortcrustcustardtart 180-220 2* 170-200 Any 20-30

Creampuffs 210 2 200 Any 25-30

Yeastbread 210 2* 200 Any 25-30

Pizza 215 2* 205 Any 12-20

*Whenusingyoucoulduseposition3oftheoven

Meat/Poultry/Fish Fan Forced - Rec. Temp (ºC) Minutes per kilogram

Beef

Rare 180 35-40

Medium 180 45-50

Welldone 180 55-60

Lamb

Medium 180 40

Welldone 180 60

Veal 170 60

Pork 200 60

Chicken 180 45-60

Duck 180 60-70

Turkey 180

40–45(lessthan10kg)

35–40(morethan10kg)

Fish 160-170 20

Using the oven

12 Euromaid 540mm Upright Cooker USING THE OVEN

Understanding cooking problems

Problem Causes What to do

Unevencooking

Incorrectshelfposition Selectshelfthatputsfoodincentreofoven

Oventraytoolarge Removeoventray.Usesmallertraysordishes

Traysnotincentre Puttraysincentre

Ovenfancausingunevenbrowningorsmall

cakestoleanover

Rotatefoodduringcooking,oruseConventional

Mode(i.e.nofan)

Bakedproductstoo

brownontop

Ovennotpreheated Preheattheoven

Bakingtinstoolarge(diameter)forrecipe Usecorrectsizetins

Fan-forcedmodewithoventemperaturetoo

high

Checkrecipe.Reduceoventemperatureby

10–20ormore

Cookingtimetoolong Nexttime,shortencookingtime

Bakingtinsnotevenlyspaced Staggerbakingtinsatleast3cmbetweentinsand

theovenwalls

Itemstobecookedarenotevenlysizedor

spacedontrays

Makeintosamesizeandshapeandspread

evenlyovertrays

Bakedproductstoo

brownonbottom

Bakingtinstoolarge(diameter) Usecorrectsizetins

Bakingtinsaredarkmetalorglass Changetoshiny,lighttinsorlowerthe

temperatureby10°-20C

Foodtoolowinoven Cookoneshelfhigher

Ovendooropenedtoofrequentlyduring

baking

Don’topentheovendooruntilatleasthalfthe

cookingtimehaspassed

Bakingtemperaturetoohigh Lowerthetemperature

Oventrayblockingheat(belowthermostat) Usehighershelfpositionforoventray

Cakeshaveacracked

thickcrust

Bakingtemperaturetoohigh Lowerthetemperature

Foodtoolowinoven Cookoneshelfhigher

Cakebatterovermixed Mixjustlongenoughtocombinetheingredients

Bakingtintoodeeporwrongsize Checksizeoftinanduserecommendedsize

Bakingtinsdark Changetoshinylighttins

Bakedproductsarepale,

atandundercooked

Bakingtemperaturetoolow Raisethetemperature

Foodtoolowinoven Cookoneshelfhigher

Bakingtimetooshort Increasecookingtime

Incorrectbakingtinsize Usecorrectsizetin

Cakesfallenincentre

Bakingtemperaturetoolow Raisethetemperature

Bakingtimetooshort Increasecookingtime

Proportionsofingredientsincorrectforrecipe Checkrecipe

Openingdoortooearlyduringbaking Donotopendooruntilthelastquarterof

cookingtime

Roastmeatandpotatoes

notbrowninginfanoven

Poorhotaircirculation Elevatefoodontoaracktoallowaircirculation

Oventemperatureistoolow Increasetemperatureto200-220

Notlongenoughinoven Continuecookingforanother15+minutes

NOTE:Condensationonovendoorisnormal,especiallywhenkitcheniscold

Alsospacingandsizeoffoodontraysandthenumberofbakingdishesintheovencanaffectaircirculation.

Using the oven

Euromaid 540mm Upright Cooker USING THE OVEN 13

Using the grill

• Ensuregrillwirerackisturnedoverto‘high’position

intheenamelgrilltrayfortoast,foodlessthan

20mmthick,orturnedoverto‘low’positionfor

food20-30mmthick.

• Turnthegrillcontrolknobtoadjustthetemperature

togetthedesiredresult.Eg,toast4or5,meat6or

• Ensurethattheenamelledgrilltrayispositioned

correctlyonthepinslocatedonthetelescopic

siderunners.Insertthegrillrackinsert,choosing

heightlevelrequiredforfoodbeinggrilled,intothe

enamelledgrilltrayandclosethegrilldrawerfully.

• Preheatthegrill.After3minutes,openthegrill

drawerandplacefoodontogrillrackinsert.

• Closethegrilldrawer.

• Intheprocessofgrilling,slideoutthegrilldrawer

every1minutetocheckprogressoftoast,every

2-3minutesformeats..

Handling grilling problems

Problem Causes What to do

Grilledmeats

burnton

outsideand

rawincentre

Meattoo

closetogrill

Useinvertedwirerack

insertand/orreduce

temperaturesetting

Excessgrill

smoke

Build-upof

fatsingrill

Cleangrillenamelled

trayandwirerackafter

everyuse

Trimfatfrommeatprior

tocooking

Grilledsteaks

andchops

curling

Cutslitsintofatwith

knifetowardsmeator

removeallfatpriorto

grilling

Grill safety warnings

• Alwaysturnoffthegrillimmediatelyafteryouhave

nishedcookingandpulldraweroutorremove

grilltrayotherwisefatleftinthetrayinthehotgrill

compartmentwillcontinuetosmokeorcouldcatch

re.

• Washgrilltray&grillinsertaftereveryuse.

• Grillinsertrackcanbeinverted…..toprovide2

differentsettingsforthedistancefromtopoffoodto

thegrillelement.

• DONOTlinethegrillrackwithfoil.

• DONOTleavethegrillunattendedandcheck

progressofcookingevery1–2minutes(especially

bread).

• DONOTtrytogrillplacefoodmorethan25mm

thick.Foodmaycatchre.Trimexcessfatfrom

fattytypemeatstoreduceanyriskofre.

• Donotstoreammablematerialsnearthegrill.

Grill information

• Thegrillfunctionissuitablefortendercutsof

meat,steak,chops,sausages,sh,bread,cheese

toastiesandotherquick-cookingfoods.

• Preheatfor3minutes.

• Placefoodoncethegrillchamberafetrpre-heating

isnished

• Thegrilldrawerdoormustbeclosedduringgrilling.

Using the grill

14 Euromaid 540mm Upright Cooker USING THE GRILL

Grill

Using the hotplates of your electric

cooker

Checkthehotplatesonyourcookeragainstthe

diagramsbelowbeforeyouuseyourcookerfortherst

time.

Radiant hotplates

• Thehigh-speedradianthotplatesheatrapidlyfrom

acoldstart.

• Theradiantelementscanbeunpluggedandthe

trimringscanberemovedforcleaningthespillage

bowls

Hotplates safety warnings

• DONOTusepotsandpanswhichareunsteady,as

thesecouldoverbalance.

• DONOTusematsorheatdiffusersontopof

hotplates.Thesewillcauseatemperaturebuild-up

whichcandamagethecooktop.

• DONOTturnonhotplatesifthereisnopotorpan

onhotplateoriftheydonotcontainfoodorliquids

inthem.

• DONOTletcookingpotsoverhangsidesorfrontof

hobastheycanradiatetoomuchheatontocontrol

knobsorbenchtopsurfaces.

Ceramic hotplates

• DONOTuseiftheceramicglasstopiscrackedor

broken.

• DONOTleavealuminiumfoilonthehotceramic

hotplates(permanentdamagewilloccur)

NOTE:Storedheatinthehotplatecanbeusedfor

thelastfewminutesofcooking.Simplyturnoffthe

control.

Choosing Cooking Pots

Lookatthisdiagrambelowwhichshowsyouwhich

cookingpotandpanstouseonthehotplatesand

whichonesthatshouldnotbeused.

• Alwaysusepotsandpanswithatbottoms.

Unevenorthinbottomswillwasteenergyandcook

slowly.

• Alwaysusepotsandpanswhichareslightlylarger

thanthehotplate.Smallpanswasteenergy.

• Alwaysputdrypotsandpansonthehotplates.

• Donotusepotsandpanswhicharetoolarge.Pans

whichoverhangthehotplatemorethan50mmcan

damagethehoborsurroundingsurfaces.

Using the hotplates of your cooker

Euromaid 540mm Upright Cooker USING THE HOTPLATES OF YOUR COOKER 15

Ceramic hotplates

• DONOTusethecooktopiftheglassiscracked.

Contacttheservicedepartmentimmediatelyto

havethisrepaired.

• Theceramiccooktopismadefromceramicglass,

atough,durablematerialthatwithstandsheating

andcoolingwithoutbreaking.

• However,itmustberememberedthatasitisglass,

itmaybreak.

• Thesmoothglasssurfacehasapatterntoshow

wheretheelementsundertheglassarelocated.

• Whenahotplateison,thehotsurfacewarning

lightwillcomeon.Afterswitchingoff,thislight

willcontinuetoglowuntilthetemperatureofthe

hotplatedropsbelow60°C.

Care of ceramic glass surface

• Ensurethatspillsfromsugarysubstancesare

cleanedassoonaspossibleafterspillageassugar

candamagetheceramicglasssurfaceovertime.

• Aglassscrapershouldbeusedtoremoveburnt

onandverystubbornspillscreatedduringcooking,

Warmsoapywater,followedbywipingwithadry

softclothisnefordailycleaning.

• Periodiccare,approximatelyonceamonth,should

becarriedontheceramicglasssurface.We

recommendtheuseofHillmark‘Cerapol’ceramic

cooktopcleanertoremovestubbornstains.

• Tomaintainandprotecttheceramicglasssurface

overtimeHillmark‘Ceraseal’ceramiccooktop

protectorisrecommended.Thissiliconbased

productcreatesathinlmoftheceramicglass

surface.

• Scratchescanappearontheglasssurfacealthough

donoteffecttheuseofthecooktop.

Solid hotplates

• Thestrongsolid-casthotplatesgivewidecontact

forfast,efcientcooking.

• Thehotplatesaresealedallaroundwhichmeans

thatspiltliquidsdonotgounderthehotplates.

Before ﬁrst use

• Thetopsurfaceofthehotplatesaresealedwitha

heatresistantcoating.Beforeusingforthersttime

thehotplatesshouldbeheatedforashortperiod

withoutapantohardentheprotectivecoating.

• Turntheheatsettingtohighforapprox.3minutes

tofullyhardenthecoating.Whenthehotplateshave

cooledapplyathincoatingofcookingoiltothe

hotplatetosealandprotectthesurface.

Care of the hotplates

• Ensurethatspillsfromoilandwaterarecleaned

oncehotplatesarecoolenoughtodoso.Ifwater

remainsonthehotplates,rustspotsmayappear

overtime.

• Overtime,thehotplatescandiscolourfromspills

duringcooking.WerecommendtouseHillmark

‘ShineOn’hotplateprotector,onaregularbasis

toextendthelifeofthehotplatesandreducethe

riskofrustingasthisformsaprotectivewaterproof

coatingonthehotplates.Thiscanbepurchased

frommajorhardwareoutletsandsupermarkets.

Using the hotplates of your cooker

16 Euromaid 540mm Upright Cooker USING THE HOTPLATES OF YOUR COOKER

Hotplate Ignition

Tolightthesehotplates:

1. Choosethehotplateyouwanttouse.

2. Pushinburnercontrolknobandrotateto“ ”.

3. Holdcontrolknobfor2-3seconds,themrelease

androtateknobtoadjusttheameheight.Ifame

goesout,theknobwasnotheldinforsuffcient

time;repeatstep2.

Burner

1. Wokburner

• Usedforfastheating.

• UsedwithWOK,largesizepotsandpans.

• ForroundedbottomwoksuseWOKadapter.

2. SmallBurner

• Usedforsimmering.

• Usedwithsmallpotsandpans.

3. Semi-rapidBurner

• Usedfornormalcooking.

• Usedwithmiddlesizepotsandpans.

Toconservegas,placethepancentrallyovertheburner

andadjusttheamesothatitdoesnotgopastthe

edgesofthecookware.

The hob control knobs

Thesymbolsonthecontrolknobsmeanthefollowing:

● Nogasow



Maximumgasow

 Minimumgasow

Alloperatingpositionsmustbesetbetweenthe

maximumandminimumowsettings,andnever

betweenthemaximumsettingandtheclosedposition.

Introduction to the burner

A Burnercap

B Ignitionplug

C Thermocouple

D Wokburnercap

Using the hotplate gas burners

Euromaid 540mm Upright Cooker USING THE HOTPLATE BURNERS OF YOUR GAS COOKER 17

Solid hotplates

• Fornormalcleaninguseamoistcloth.

• Forverydirtyhotplatesuseanycommercial

cleanser.

• Aftercleaning,removeanycleanserremainingand

drythehotplatecompletelybyrunningtheelement

forashortperiod.

• Overtime,thehotplatescandiscolourfromspills

duringcooking.WerecommendtouseHillmark

‘ShineOn’hotplateprotector,onaregularbasis

toextendthelifeofthehotplatesandreducethe

riskofrustingasthisformsaprotectivewaterproof

coatingonthehotplates..

• Permanentheat-discolourationofthetrimringis

normal.

Ceramic hotplates

• Removeallspiltfoodwiththerazorbladescraper

suppliedwhilethehotplateisstillwarmturnedoff)–

NOTHOT.

• Ifaluminiumfoil,plasticitemsorfoodswithahigh

sugarcontentmeltontoglass,usetherazorblade

scrapertoremoveimmediatelybeforethehotplate

hascooled,otherwisepittingofthesurfacemay

occur.Highsugarcontentfoodsincludejam,fruit,

carrots,tomatoesandpeas.

• Whentheceramichotplatehascooled,wipeclean

withdishwashingdetergentonadampcloth.

NOTE:Donotuseabrasivespongesorscourers,

ovenspraysorstainremoversonceramic

hotplates.Thesemaydamage,scratchorstainthe

ceramiccooktop.Anypitting,stainingorscratching

willnotbecoveredbywarranty.

Safety warnings about cleaning

• Alwaysmakesurethatthecookeristurnedoff

beforecleaning.

• Alwayscleancookerimmediatelyafteruse.

• Useofsteamcleanersisprohibitedtocleanthis

applaince.

• Donotusecaustic-basedcleaners.Thesewill

damagealuminumparts,andremoveenamelgloss.

Cleaning the enamel

• Keepenamelcleanbywipingitwithasoftcloth

dippedinwarmsoapywater.

• Rubdifcultstainswithanylonscourerorcreamed

powdercleanser.

• Donotuseabrasivecleaners,drypowdercleaners,

steelwoolorwaxpolishes.

• Ifyouuseanovencleaner,thenfollowthe

instructionsontheproductcarefully.

Cleaning the control panel

• Makesurecontrolknobsareinoffposition.

• Cleanthecontrolpanelbywipingitwithasoftcloth

dippedinwarmsoapywaterandsqueezeddry.

• Takecarewhencleaningaroundknobstoensure

printingoncontrolpanelisnotremoved,thiscan

occurifabrasivecleanersareused,therefore,

shouldnotusedatall.

Cleaning the electric cook top

Radiant hotplates

Thesecoiledhotplatesareselfcleaning.Tocleanthe

trimrings,liftfrontofelementandremovetrimring.

Thenwashinwarm,soapywater.Tocleanthespillage

bowl,liftelementandpulloutofsocket.Remove

spillagebowlandwashinwarmsoapywater

DONOTPUTELEMENTSINWATER!

Fitting oven accessories and cleaning

18 Euromaid 540mm Upright Cooker FITTING OVEN ACCESSORIES AND CLEANING

Euromaid 540mm Upright Cooker FITTING OVEN ACCESSORIES AND CLEANING 19

Reﬁtting the burner crowns and caps

• Theburnercrownmustbettedcorrectlyintothe

burnercupordamagewilloccurduringoperation.

• Todothis,ensurethatthe2ribsoneithersideof

thesparkplugholearepositionedintothe2slots

ontheburnercup.(Seegure2).

• Theburnercapissimplypositionedoverthetopof

theburnercrown.

NOTE:Whentheburneriscorrectlytteditwillsit

levelonthehob.

Ifignitionisdifcultorfailsaftercleaning,orthe

amesarenotevenaroundtheburner,theneither

burnerpartsarenotdry/partshavenotbeen

positionedcorrectlyorincorrectcapistted.

Cleaning the grill compartment

• Lifttheenamelledgrilltrayout.

• Cleanthesidesanbottomofcompartmentwithhot

soapywater.

 Ifstrongeractionisneededuseanonabrasive

cleanerappliedwithanylonscourer.

Cleaning the Oven

• Openthedoorfully.

• Removeovenshelvesandsideracks.

• Cleaninhotsoapywater.

• Thoroughlydrywithasoftclothtoremoveexcess

waterthatmaybepresent.

Cleaning the Gas Hob

Removing the trivets (Refer Figure 1)

• Thetrivetslocateintherecessedareaofthehob.

• Theycanberemovedforcleaningbycarefullylifting

themfromthehob.

• Cleanbywashinginwarmsoapywater.Dry

thoroughly.

• Takecarewhenreplacingthetrivetsasdropping

themontothehobmaydamagetheenamelled

surface.

Removing the burner partss (Refer Figure 2)

• Theburnercapsandcrownsareremovablefor

cleaning.

• Flameportblockageshouldberemovedbymeans

ofamatchstickorbrush.

• Ifthecaps,crownsandcupsareheavilysoiled,use

anon-abrasivecleaningcompound.

• Donotcleanthemwithabrasiveorcaustictype

cleaners,orputinadishwasherastheywillbe

damaged.

Fitting oven accessories and cleaning

Figure1

Figure2

20 Euromaid 540mm Upright Cooker FITTING OVEN ACCESSORIES AND CLEANING

Cleaning the oven door / How to remove the oven doors

Foramorethoroughclean,youcanremoveanddisassembletheovendoor.Proceedasfollows:

• Openthedoortothefullextent(g.1)

• OpentheleverAcompletelyontheleftandrighthinges(g.2)

• Holdthedoorasshownin(g.3)approximatley30degreeangleupwards

• Gentlyclosethedoor(g.3)untilleftandrighthingeleversA(g.2)arehookedtopartB(g.2)ofthedoor

• WithdrawthehingehooksfromtheirlocationfollowingarrowC(g.4)

• Restthedooronasoftsurface,toreduceriskofdamagetothedoor

• Toreplacethedoor,repeattheabovestepsinreverseorder

Removing the Inner Pane of Glass

• TripleGlazedovendoor:Removethetopframe(G)byunscrewingthe2screws,locatedontheleftandrightsides

• Gentlypullouttheinnerpaneofglass(g.2).Alsoremovethecentrepaneofdoorglass,notshownhere.

• Cleantheglasspaneswithanappropriatecleaner.Drythoroughly,andplaceonasoftsurface.

• Nowyoucanalsocleantheinsideoftheouterglass.

Cleaning the door glass

• Cleantheglassdoorusingnon-abrasiveproductsorspongesanddryitwithasoftcloth.

• Donotusetheovenwithouttheinnerdoorpanesttedcorrectly.Whenre-ttinginnerglassdoorpanesensure

theygobackinfacingthesamewaytheycameout.Thedoorsarecoatedwithaveryslightreectivecoatingto

reecttheheatbackintotheovencavityandkeeptheouterdoorcoolertotouch.

• Donotuseharshabrasivecleanersorsharpmetalscraperstocleantheovendoorglasssincetheycanscratch

thesurface,whichmayresultinshatteringoftheglass.

Fitting oven accessories and cleaning

Fig. 1

Fig. 2

Euromaid 540mm Upright Cooker FITTING OVEN ACCESSORIES AND CLEANING 21

Replacing the Oven Lamp

• Disconnecttheovenfromthepowersupplyatthe

fuse-boxbymeansoftheswitchusedtoconnect

theappliancetotheelectricalmainsorunplugthe

applianceifagasmodel.

• Removetheglasscoverofthelamp-holderby

rotatinganti-clockwise.Beawarethattheglass

maybedifculttoremoveifthereisabuildupofoil

andgreasecreatedduringcooking.Inthiscasethe

glassmayneedtobecleanedwithhotsoapywater

tobreakthisbuildup.

• Removethelampandreplacewithalampresistant

tohightemperatures(300ºC)withthefollowing

characteristics:

• Voltage:220-240V

• Wattage:25W

• Type:E14

 Replacetheglasscover.Reconnecttheappliance

tothemainspowersupply.

Fitting oven accessories and cleaning

22 Euromaid 540mm Upright Cooker SOLVING PROBLEMS

Ifyouhaveaproblemwithyourappliance,checkthetablebelowbeforecallingservice.Youmaybeabletoavoida

servicecallbyandavoidunnecessaryinconvenienceandexpense.

Forcookingproblems,refertoHandlingBakingProblems.

Problem Causes What to do

Nosparkobtainedwhen

gasburnerknobis

pushed/turned

Powernotturnedonorconnected Switchonelectricity

Householdfuseblown Checkfuses

Circuitbreakertripped Checkcircuitbreaker

Sparkplugiswetordirty Dryorcleansparkplug

Burnerwillnotlighteven

thoughsparkcanbe

seen/heard

Gassupplyvalveisturnedoff Turnongassupply

burnercrown&capnotpositionedcorrectly Removepartsandretcarefully

Portblockageinignitionarea Makesurethatportsandignitionareaarecleananddry

Ovenorgrillnotworking

DigitalClocknotsetproperly Refertodigitaltimerinstructions

120minTimernotin“Manual”position Referto120mintimerinstructions

Powernotturnedon Switchonelectricity

Householdfuseblown Checkfuses

Controlsincorrectlyset Resetcontrols

Circuitbreakertripped Checkcircuitbreaker

Ovenlightnotworking

Powernotturnedon Switchonelectricity

Householdfuseblown Checkfuses

Circuitbreakertripped Checkcircuitbreaker

Lampblownorlooseinsocket Replaceortightenglobe

‘Ovenheating’indicator

lampdoesnotgoOFF

Nofaultifyouareusingtemps>180with

conventionalorpizzamodeslected,thisisnormal

Itcantakealongtime(50-70minsormore)fortheoven

indicatorlmaptogoOFF/startcycling.

Ovennothotenough

Heatescapingthroughincorrectly

sealeddoor

Checkshelvesordishesarenotpreventingdoorclosing

properly,Checkthatdooristtedproperlyafterdoorremoval

forcleaning

Doorsealiswornorhasmoved Replacesealorretit

Digitaltimerdisplay

ashing

Powerfailureorinterruption Resettimeofday

Householdfuseblownorpower

supplyisoff

Checkfuses,powersupply

Unitsmokingwhenrst

used

Protectiveoilsbeingremoved Thisisnormal

Odouronrstuseof

oven

Thisisnormal

Allow1–4hoursforodourtodissipate(openallwindows)

120minutetimerbuzzer

notaudible

Timernotwoundsufciently Turntimerknobpast15minutemark

Thenturntotherequirednumberofminutes

Ovenshelftight Ovenshelfnotinsertedcorrectly,maybeupside

downorbacktofront

Removeshelfandinsertasperdiagram

Clockdisplayoff Householdfuseblownorpower

supplyisoff

Checkfuses,powersupply

NOTE:Onlyservicecentersshouldcarryoutservicing.Otherwisewarrantymaybevoid.

Solving Problems

Euromaid 540mm Upright Cooker INSTALLING COOKER – POWER CONNECTIONS 23

Fitting on a Power Supply Cable

WARNING: Installtion MUST ONLY be carried out by a qualiﬁed approved installer, ie. an Electrician.

Connectingappropriatepowersupply`terminalboard/connectorblock:

NOTE: REFER to TECHNICAL tables at the rear of this manual for correct rating for your

corresponding model purchased.

• Usingascrewdriver,prizeopentabsoftheTerminalboardcover.

• Removethewireclampscrew.

• Fastenthewiresbeneaththecorrespondingscrewheads,usingbrass‘bridge’forsinglephasesupply.

• Fastencableclampandclosethecoveroftheterminalboard.

• TheACpowersupplyshouldbe220-240V,50Hz.Forelectriccookers,theminimum45Afuse,oratleast45Aa

distributioncircuitbreaker.Forgascookers,theminimum20Afuse,oratleast20Acircuitbreaker.

WARNING:Connectthepowercordmustbeinaccordancewiththeinstructionslistedinthetablebelow

Connection mode

L1 L2 N E

1N~ Min6 — Min6 Min6

2N~ Min1.5 Min2.5 Min6 Min6

Connecting the supply cable to the mains

Installanapprovedcircuitbreakerwithaminimumcontactopeningof3mm,betweentheapplianceandthemains

fusebox.Thecircuitbreakershouldbesizedaccordingtotheloadandshouldcomplywithcurrentregulations(the

earthwireshouldnotbeinterruptedbythecircuitbreaker).

Thesupplycableshouldbepositionedsothatitdoesnotreachatemperatureofmorethan50ºCwithrespecttothe

roomtemperature,anywherealongitslengthBeforeswitchingfuseONinmeter-boxcheck:

• Earthcontinuity.Theelectricalsafetyofthisappliancecanonlybeguaranteedifthecookeriscorrectlyinstalled

andearthed,incompliancewithregulationsonelectricalinstallations.

• Theelectricalcapacityofthesystemandsocketswillsupportthemaximumpoweroftheappliance,asindicated

onthedataplate

• Gotosection19“Installingyournewcooker”

NOTE:AllUprightcookersmustcomplytolocalregulationstoAustralianStanadrdAS/NZS3000:2007

guidelines.QualiedElectricianwillhaveacopyoftheseguidesthatMUSTbeadheredto.

Installing cooker – power connections

Wire cross-sectional

area (mm

)

24 Euromaid 540mm Upright Cooker INSTALLING THE GAS COOKER

Gas connection

A Inletpipejoint

B Gasket

C Stableunion

Procedure

Maketheconnectiontothegassystemusingarigid

metalpipeandregulationunions,orwithastainless

steelhosecomplyingwiththelocalstandard.Ifmetal

hosesareused,takecarethattheydonotcomeinto

contactwithmobilepartsandarenotcrushed.

Whenmakingtheconnection,takecarenottoapply

stressesofanykindtotheappliance.

Readthesepointsbeforeconnectingtothegassupply;

• Thegasconnectionpointisa1/2”BSPexternal

threadlocatedattherearoftheapplianceasshown

intheRearView.

• Aregulatorissuppliedfornaturalgasappliances

whichmustbettedinthesupplylinetothe

appliance.ForLPGthesuppliedbrassTestPoint

Adapter/Fittingmustbettedtothesupplyline.

• Itisrecommendedtottheregulatorortestpoint

ttingtotheapplianceconnectionpoint,thent

eitherhardpipingoraexibleconnectionfrom

theregulatorortestpointttingtoconsumerhard

piping.Ensureinstallationallowswithdrawalof

appliance.ForexiblehoseinstallationAS/NZS

5601.1clauses5.9and6.10.1.9mustbefollowed.

Unpacking

Donotttheburnercrowns,burnercapsandtrivets

untilafterthecookerhasbeeninstalled.

Checking gas pressures

Beforeinstallationcheckthatthecookerissuitablefor

thegassupply.Todothischeckthegastypeonthe

cartonstickeroronthedataplatebehindthebottomof

theovendoor.Ifthecookerisrequiredtobeusedwith

LPG,thesuppliedconversionkitmustbeused.

Thefollowingshowsthesupplyandoperating

pressuresforvariousgassupplies.

Operatepressureatappliancetestpoint:

1.00KPa(Naturalgas);N2.75KPa(UniversalLPGgas)

Thefollowingtableshowstheinjectorsizesforeach

burner.

Injector Natural gas Universal LPG

Auxiliaryburner 0.93mm 0.57mm

Semi-rapidBurner 1.16mm 0.71mm

TripleringBurner 1.75mm 1.10mm

Connection to the gas supply

■

ThegasConnectionmustbemadeinaccordance

withthelocalstandards.

 Wheninstalling,tasafetytapattheendofthe

pipeline.Theapplianceleavesthefactorytested

andsetforthetypeofgasindicatedonthe

plateinsidethebottomguard,closetothegas

connectionpipe.Makesurethatthetypeofgasto

besuppliedtotheapplianceisthesameasthat

shownontheplate.

■

Formaximumefciencyandminimumconsumption,

makesurethatthegassupplypressurecomplies

withthevaluesshowninthegasusedisdifferent

fromthatspecied(orvariable).asuitablepressure

regulatormustbeinstalledonthesupplypipeline.

Installing the gas cooker

Euromaid 540mm Upright Cooker INSTALLING THE GAS COOKER 25

Operation on Natural Gas

ReadthesepointsaboutoperationonNG/SNGandlookcarefullyatthediagram:

• Theapplianceregulatorprovidedmustbeorientatedtogiveaccessthemanometertestpoint.

• Thearrowshowingthedirectionoftheowmustbefacingthecorrectwayfromgassourceintothecooker.

• Theregulatorhasa1/2”BSPinternalthreadatinletandoutlet

Operation on Universal LPG

Aninletttingwithpressuretestpointisprovided.Theinletttinghas1/2"BSPinternalthreadforbothinletandoutlet.

Theinletttingmustbeorientatedsothatthepressuretestpointisaccessible.



Whentheinstallationiscomplete,alwayscheckthatalltheunionsareabsolutelytightusingasoapysolution.

Neveruseaametomakethischeck.

Installing the gas cooker

BackofCooker

TestPoint

26 Euromaid 540mm Upright Cooker TESTING THE OPERATION OF THE GAS COOKER

Iftheregulatorappearstonotbeperforming

satisfactorilythencheckthefollowingpoints.

■

Iftheoutletpressureisconsistentlytoolowthenthe

inletpressuremaybetoolowandadjustmentofan

upstreamregulatormaybeneeded,oranupstream

regulatororvalvewithinsufcientowcapacitymay

bepresentinthegassupplyline.Ifthisissuspected

thenitmaybenecessarytorepeatthechecks

whilstmeasuringboththeinletandoutletpressure

todetermineiftheinletpressureisintherange

1.13–5kPa.

■

Checkthattheregulatorhasbeenttedtothegas

supplylineinthecorrectorientation,thearrowon

thebaseofthebodyindicatesthedirectionofgas

ow.Oncethesecheckshavebeencompleted,if

theregulatorstillfailstoperforminasatisfactory

manneritshouldbereplaced.

Testing the cooker features

Observetheameappearanceoneachburner.Ifitis

muchsmallerorlargerthanexpected,thentheinjector

sizeneedschecking.

Whenmaximumameappearanceiscorrect,then

checktheturn-downsettingoneachburner.Ifthe

settingsappeartobeincorrect,proceedasfollows:

• Adjustthebypassscrewmountedonthebodyof

eachhotplatecontrolcock.Thisisaccessiblewhen

thecontrolknobandthecontrolpanelareremoved.

• Checktheignitiononallburnersbothseparately

andincombination.

• Checktheoperationoftheelectricalcomponents,if

applicable.

• Ifyouaresatisedthatthecookerisoperating

correctly,thenturnitoffandshowthecustomer

howtouseit.Makesureyouaskthecustomerto

operatetheclockandcontrols.

NOTE:Ifthecookercannotbeadjustedtoperform

correctly,theninformthecustomeroftheproblem

andputawarningnoticeonthecooker.Ifthe

problemisdangerous,thendisconnectthecooker.

Ifthereisafault,thenthecustomershouldbe

advisedtocontactthemanufacturer’slocalservice

organisationortheretailer.

NOTE:Youmusttestthecookerafterinstallation,

beforeyouhanditovertothecustomer.Youmust

haveamanometerandaconnectingtube.

Checking gas supply

• Checkthemanometerzeropointiscorrect.

• Connectthemanometertothecookerpressuretest

point.ThisislocatedontheNGregulatororLPG

inlettting.

• Turnonthegassupplyandtheelectricity(if

applicable)andtrytoignitethegas.

 NOTE:Itwilltakeadditionaltimetolightthegas

forthersttimeasairneedstobepurgedfromthe

pipes.

• Checktheoperatingpressurefortheparticulargas

type(seetable).

For LPG cookers

Adjustorreplacetheregulatoronthegasbottleif

necessary(thismayberemotefromthecooker).

For Natural Gas cookers

■

Regulatorsaresuppliedpre-adjustedand

conguredbythecomponentmakerforusewith

NaturalGas.Theapplianceinstallerisnotrequired

tomakeanadjustmenttoobtainthecorrectoutlet

pressuresetting.

■

Anarrowonthebaseoftheregulatorindicates

thedirectionofgasowwhentheinletandoutlet

oftheregulatorareorientatedcorrectly.Whenthe

regulatorhasbeenttedcheckforleaksfromthe

connectionswithsoapywater.

Checking the Function of the Regulator

Withtheapplianceoperatingchecktheoutletpressure:

■

Whenallburnersoftheapplianceareoperatingat

maximum,

■

Whenthesmallestburneroftheapplianceis

operatingatminimum.

Undertheseconditionstheoutletpressureshouldnot

varyfromthenominaloutletpressureof1.0kPabymore

than±20%ofthenominaloutletpressure(±0.20kPafor

NaturalGas).

Testing the operation of the gas cooker

Euromaid 540mm Upright Cooker INSTALLING YOUR NEW COOKER 27

Unpacking and installation Instructions

for Installer

Unpacking

• Pleasechecktheproductandmakesurethatthere

isnodamage.

• ReadtherelevantInstallationSectionsofthis

ManualrelatingtoyourModelandtypeofcooker.

• Conrmthatproductiscompatiblewithavailable

electrical/gassupply.Ensureproposedinstallation

positiondoesnotconictwithInstallationSections.

• Checktheattachmentpackingingoodcondition,

completeaccessories.

• UsescrewdrivertoremoveAnti-tiltoorbracket

screwedontotherearofthecooker.

Safety warnings about installation

• ThecookerMUSTBEinstalledandservicedonlyby

anauthorisedperson.

• Acerticateofcompliancemustbesuppliedby

installerandistobekeptbythecustomer.

• Thepackingmaterialsmustberemovedbeforeyou

installthecooker.

• Youmustfollowtheinstallationinstructionsinthis

booklet.

• ThesurroundingkitchencabinetsMUSTBEableto

withstand95°C.Wewillnotacceptresponsibility

fordamagecausedbyinstallationintokitchen

cabinetswhichcannotwithstand95°C.

• Theappliancemustnotbeinstalledinacorner.It

mustbeinstalledatleast100mmfromthesidewall.

• Theexiblepipeforgasmodelsmusthavesufcient

loopssothecookercanbemovedforservice.

• Thevents;openingsandairspacesMUSTNOTbe

blocked.

• Theanti-tiltoorbracketmustbeinstalledtoavoid

accidentaltipping.

• Thestabilityboltmustbeinstalledtoavoid

accidentalmoving.

• Youmustnotpullthecookerbythedoorhandles.

• Powersocket,ifprovidedforgasmodels,and

electricityisolationswitchforelectricmodelsand

gasmodelswithouta20Aplug,istobeinstalled

inanaccessiblepositionnearthecooker(butnot

behindcooker).

• Ifthesupplycordorcableisdamaged,itmustbe

replacedbyanapprovedserviceagentorasimilarly

qualiedpersoninordertoavoidahazard.

Installing your new cooker

Packagingof

Frontcontrolmodels

Packagingof

Rearcontrolmodels

28 Euromaid 540mm Upright Cooker INSTALLING YOUR NEW COOKER

Frontcontrolmodels-gas



The installation of splash back

• Totsplashback,alignthe2tabsofthesplash

backwiththecorrespondingholesinthehoband

pushdownwards.

• Fitscrews.

Rearcontrolmodels

Locating the cooker

Studythediagramsbelowtobesureofthedimensions

requiredtolocatethecookersafely.Makesurethat

thetopofthecookerisatleast10mmhigherthanthe

levelofthebenchtops.Unscrewlevelinglegsbyabout

10mmtogiveclearancetotheanti-tiltoorbracket.

Theappliancehasbeendesignedtotina550mm

widegapinkitchencabinets.Thecookermayalsobe

installedattheendofalineofbenchesorwithafree

spaceoneitherside.

NOTE:Toensurecookerstability,boththeanti-tilt

oorbracketandanti-movement/stabilitybolt(this

isttedtothecookerduringandlocatedbehindthe

kickpanel)mustbeinstalledonallcookers(electric

andgas).

Installing your new cooker

Euromaid 540mm Upright Cooker INSTALLING YOUR NEW COOKER 29

Installing your new cooker

Kick Panel

Stability

Bolt

Stability

Bolt Bracket

Stability Bolt

Hole in Floor

Installation Sequence

• Determinepositionofcookerandant-tiltoor

bracket.

• Markpositionofholesthatneedtobedrilledinto

oor.

• Drillholeswithcorrecttypedrillsuitableforoor

type.

• Securelyxtheanti-tiltplatetotheoorwith

appropriatefasteners.

• Stabilityboltisttedduringproductiontofrontof

cookerbehindkickpanel.Removedoorfromoven,

unscrewkickpanelfromthetopandremovekick

paneltolocatestabilitybolt.

25mm from side of

bracket on both sides

to cupboards or walls

• Repositionthecookerbackintotheanti-tiltoor

bracketandthenmarkthepositionforholeinoor

tohousethestabilitybolt.

• Pullthecookerbackoutanddrilltheboltlocation

hole.Usea10mmmasonryorwooddrill,

dependingonoortype.Whendrillingintoconcrete

ensureaminimumholedepthof30mm.

• Repositionthecookerbackintotheanti-tiltplate,

aligningthestabilityboltbracketwiththe10mm

drilledhole.Thenremovetapefromstabilitybolt

andslidetheboltthroughthebracketandintothe

hole.

• ConnectElectricitysupply/gassupplybutdonot

turnonuntilinstallationiscompleted.

• Slidethecookerbackintotheanti-tiltplatesothat

rearcoverrestsagainsttherearwall.Thencheck

theheightandlevelofthecooker.

 Ifrequired,pullthecookerbackoutandadjustthe

levelingfeetasrequired.

30 Euromaid 540mm Upright Cooker TECHNICAL SPECIFICATIONS

Technical speciﬁcations

Model R54EW

ovencapacity(L) 83

grillcapacity(L) 20

voltage(v) 220-240

frequency(Hz) 50/60

circuitbreaker(A)

(8.67kW) 36.125Amp

ovenpower(W) 1710-2030

grillpower(W) 1650-1800

Hobspower(W) 5000

productdimension(mm) 540*630*1140

packagesize(mm) 636*740*1200

gross/netweight(kg) 64.5/55

Model R54RW

ovencapacity(L) 83

grillcapacity(L) 20

voltage(v) 220-240

frequency(Hz) 50/60

circuitbreaker(A)

(9.37kW) 39.04Amp

ovenpower(W) 1710-2030

grillpower(W) 1650-1800

hobpower(W) 6000

productdimension(mm) 540*630*1140

packagesize(mm) 636*740*1200

gross/netweight(kg) 63.5/54

Model R54CW

ovencapacity(L) 83

grillcapacity(L) 20

voltage(v) 220-240

frequency(Hz) 50/60

circuitbreaker(A)

(9.07kW) 37.79Amp

ovenpower(W) 1710-2030

grillpower(W) 1650-1800

hobpower(W) 5400

productdimension(mm) 540*630*1140

packagesize(mm) 636*740*1200

gross/netweight(kg) 65.5/56

Model F54GW, F54GS

ovencapacity(L) 83

grillcapacity(L) 20

voltage(v) 220-240

frequency(Hz) 50/60

circuitbreaker(A)

(3.65kW) 15.2Amp

ovenpower(W) 1710-2030

grillpower(W) 1650-1800

burnerpower(W)

(NG/LPG 29.88 mj/h)8300

productdimension(mm) 540*630*910

packagesize(mm) 636*740*976

gross/netweight(Kg) 57/49.5

Model F54EW, F54ES

ovencapacity(L) 83

grillcapacity(L) 20

voltage(v) 220-240

frequency(Hz) 50/60

circuitbreaker(A)

(8.67kW) 36.125Amp

ovenpower(W) 1710-2030

grillpower(W) 1650-1800

hobpower(KW) 5000

productdimension(mm) 540*630*910

packagesize(mm) 636*740*976

gross/netweight(Kg) 63/55.5

Model F54RW, F54RS

ovencapacity(L) 83

grillcapacity(L) 20

voltage(v) 220-240

frequency(Hz) 50/60

circuitbreaker(A)

(9.37kW) 39.04Amp

ovenpower(W) 1710-2030

grillpower(W) 1650-1800

hobpower(W) 6000

productdimension(mm) 540*630*910

packagesize(mm) 636*740*976

gross/netweight(Kg) 60/52.5

Technical speciﬁcations

Euromaid 540mm Upright Cooker TECHNICAL SPECIFICATIONS 31

Model F54CW, F54CS

ovencapacity(L) 83

grillcapacity(L) 20

voltage(v) 220-240

frequency(Hz) 50/60

circuitbreaker(A)

(9.07kW) 37.79Amp

ovenpower(W) 1710-2030

grillpower(W) 1650-1800

hobpower(W) 5400

productdimension(mm) 540*630*910

packagesize(mm) 636*740*976

gross/netweight(kg) 63.5/56

Technical speciﬁcations

32 Euromaid 540mm Upright Cooker TECHNICAL SPECIFICATIONS

Notes

Euromaid 540mm Upright Cooker NOTES 33

Euromaid

price, quality, performance

Euromaid F54EW 54cm Freestanding Electric Oven/Stove

Product's Documents

User Manual

Specifications

Euromaid F54EW Questions and Answers

Related Products

Euromaid EFF54SS 54cm Freestanding Electric Oven/Stove

Euromaid F54RW 54cm Freestanding Electric Oven/Stove

Euromaid R54CW 54cm Freestanding Electric Oven/Stove

Euromaid CS50 Freestanding Electric Oven/Stove

Euromaid CUF54 Freestanding Electric Oven/Stove

Euromaid CDDW60 Freestanding Electric Oven/Stove
