LG Electronics LGAS990 The first Quad HD smartphone in the User Manual

MFL69169901 (1.0)

ENGLISH

ESPAÑOL

LG and the LG logo are registered trademarks of LG Corp.

All other trademarks are the property of their respective

owners.

Important Customer Information

When using this product, the safety precautions below must be taken to

avoid possible legal liabilities and damages.

Retain and follow all product safety and operating instructions. Observe all

warnings in the product operating instructions. To reduce the risk of bodily

injury, electric shock, ﬁre, and damage to the equipment, observe the

following precautions.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the

designated battery or power supply unit. Other usage may be dangerous

and will invalidate any approval given to this product.

SAFETY PRECAUTIONS FOR PROPER GROUNDING

INSTALLATION

CAUTION: Connecting to improperly grounded equipment can result in an

electric shock to your device. This product is equipped with a USB cable for

connecting to a desktop or notebook computer. Be sure your computer is

properly grounded (earthed) before connecting this product to the

computer. The power supply cord of a desktop or notebook computer has

an equipment-grounding conductor and a grounding plug. The plug must be

plugged into an appropriate outlet which is properly installed and grounded

in accordance with all local codes and ordinances.

SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT

Use the correct external power source

A product should be operated only from the type of power source indicated

on the electrical ratings label. If you are not sure of the type of power

source required, consult your authorized service provider or local power

company. For a product that operates from battery power or other sources,

refer to the operating instructions that are included with the product.

Important Customer Information

Handle battery packs carefully

This product contains a Li-ion battery. There is a risk of ﬁre and burns if the

battery pack is handled improperly. Do not attempt to open or service the

battery pack. Do not disassemble, crush, puncture, short external contacts

or circuits, dispose of in ﬁre or water, or expose a battery pack to

temperatures higher than 60°C (140°F).

WARNING: Danger of explosion if battery is incorrectly replaced. To

reduce risk of ﬁre or burns, do not disassemble, crush, puncture, short

external contacts, expose to temperature above 60°C (140°F), or

dispose of in ﬁre or water. Replace only with speciﬁed batteries.

Recycle or dispose of used batteries according to the local regulations

or reference guide supplied with your product.

Take extra precautions

l Keep the battery or device dry and away from water or any liquid as it

may cause a short circuit.

Keep metal objects away so they don’t come in contact with the battery

or its connectors as it may lead to short circuit during operation.

l The phone should be only connected to products that bear the USB-IF

logo or have completed the USB-IF compliance program.

l Do not use a battery that appears damaged, deformed, or discolored, or

one that has any rust on its casing, overheats, or emits a foul odor.

l Always keep the battery out of the reach of babies and small children, to

avoid swallowing of the battery. Consult a doctor immediately if the

battery is swallowed.

l Only use the battery with a charging system that has been qualiﬁed with

the system per this standard, IEEE-Std-1725-200x. Use of an unqualiﬁed

battery or charger may present a risk of ﬁre, explosion, leakage or other

hazard.

l Replace the battery only with another battery that has been qualiﬁed

with the system per this standard, IEEE-Std-1725-200x. Use of an

unqualiﬁed battery may present a risk of ﬁre, explosion, leakage or other

hazard.

Important Customer Information

l Avoid dropping the phone or battery. If the phone or battery is dropped,

especially on a hard surface, and the user suspects damage, take it to a

service center for inspection.

l If the battery leaks:

Do not allow the leaking ﬂuid to come in contact with skin or clothing. If

contact occurs, ﬂush the affected area immediately with clean water and

seek medical advice.

Do not allow the leaking ﬂuid to come in contact with eyes. If contact

occurs, DO NOT rub; rinse with clean water immediately and seek

medical advice.

Take extra precautions to keep a leaking battery away from ﬁre as there

is a danger of ignition or explosion.

SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT

Keep this product away from excessive moisture and extreme

temperatures. Do not leave the product or its battery inside a vehicle or in

places where the temperature may exceed 140°F (60°C), such as on a car

dashboard, window sill, or behind glass that is exposed to direct sunlight or

strong ultraviolet light for extended periods of time. This may damage the

product, overheat the battery, or pose a risk to the vehicle.

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones or

headphones are used at high volume for prolonged periods of time.

SAFETY IN AIRCRAFT

Due to the possible interference caused by this product to an aircraft’s

navigation system and its communications network, using this device’s

phone function on board an airplane is against the law in most countries. If

you want to use this device when its use is restricted on board an aircraft,

remember to switch to Airplane Mode which turns off RF functions that

could cause interference.

Important Customer Information

ENVIRONMENT RESTRICTIONS

Do not use this product in gas stations, fuel depots, chemical plants or

where blasting operations are in progress, or in potentially explosive

atmospheres such as fueling areas, fuel storehouses, below deck on boats,

chemical plants, fuel or chemical transfer or storage facilities, and areas

where the air contains chemicals or particles, such as grain, dust, or metal

powders. Please be aware that sparks in such areas could cause an

explosion or ﬁre resulting in bodily injury or even death.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where

ﬂammable materials exist, the product should be turned off and the user

should obey all signs and instructions. Sparks in such areas could cause an

explosion or ﬁre resulting in bodily injury or even death. Users are advised

not to use the equipment at refueling points such as service or gas

stations, and are reminded of the need to observe restrictions on the use of

radio equipment in fuel depots, chemical plants, or where blasting

operations are in progress. Areas with a potentially explosive atmosphere

are often, but not always, clearly marked. These include fueling areas,

below deck on boats, fuel or chemical transfer or storage facilities, and

areas where the air contains chemicals or particles, such as grain, dust, or

metal powders.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use communication services

with handheld devices, except in the case of emergency. In some

countries, using hands-free devices as an alternative is allowed.

Important Customer Information

SAFETY PRECAUTIONS FOR RF EXPOSURE

l Avoid using your phone near metal structures (for example, the steel

frame of a building).

l Avoid using your phone near strong electromagnetic sources, such as

microwave ovens, sound speakers, TV and radio.

l Use only original manufacturer-approved accessories, or accessories that

do not contain any metal.

l Use of non-original manufacturer-approved accessories may violate your

local RF exposure guidelines and should be avoided.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this

device is prohibited in most hospitals and medical clinics.

If you use any personal medical device(s), consult the manufacturer of your

device(s) to determine if the device(s) are adequately shielded from

external RF energy. Your physician may be able to assist you in obtaining

this information. Turn your phone OFF in health care facilities when any

regulations posted in these areas instruct you to do so. Hospitals or health

care facilities may be using equipment that could be sensitive to external

RF energy.

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the

event of such interference, you may want to consult your service provider,

or call the customer service line to discuss alternatives.

Important Customer Information

NON-IONIZING RADIATION

Your device has an internal antenna. This product should be operated in its

normal-use position to ensure the radiative performance and safety from

interference. As with other mobile radio transmitting equipment, users are

advised that for satisfactory operation of the equipment and for personal

safety, it is recommended that no part of the human body be allowed to

come too close to the antenna during operation of the equipment.

Use only

the supplied integral antenna. Use of unauthorized or modiﬁed antennas may

impair call quality and damage the phone, causing loss of performance and

SAR levels exceeding the recommended limits as well as result in non-

compliance with local regulatory requirements in your country.

To assure

optimal phone performance and ensure human exposure to RF energy is

within the guidelines set forth in the relevant standards, always use your

device only in its normal-use position. Contact with the antenna area may

impair call quality and cause your device to operate at a higher power level

than needed. Avoiding contact with the antenna area when the phone is IN

USE optimizes the antenna performance and the battery life.

HAC

This phone has been tested and rated for use with hearing aids for some of

the wireless technologies that it uses. However, there may be some newer

wireless technologies used in this phone that have not been tested yet for

use with hearing aids. It is important to try the different features of this

phone thoroughly and in different locations, using your hearing aid or

cochlear implant, to determine if you hear any interfering noise. Consult

your service provider or the manufacturer of this phone for information on

hearing aid compatibility. If you have questions about return or exchange

policies, consult your service provider or phone retailer.

Important Customer Information..........................................................3

Table of Contents ...................................................................................9

Technical Details ................................................................................... 10

The Basics ............................................................................................. 15

Connecting to Networks and Devices ................................................39

Calls ...................................................................................................... 43

Web ........................................................................................................53

Communication ....................................................................................57

Entertainment ...................................................................................... 64

Tools ...................................................................................................... 80

Settings .................................................................................................94

Safety ....................................................................................................114

Specifications ..................................................................................... 139

LIMITED WARRANTY STATEMENT ................................................140

Index ....................................................................................................144

Table of Contents

Cautions

The user interface of Google applications (Google Search, Google Maps,

Navigation, etc.) can vary depending on its software version.

Locations are inaccurate when GPS and Wi-Fi are not set to On.

With the Android operating system, some available Play Store

applications only operate correctly with phones that have a speciﬁc

screen resolution. Please be advised that some of the applications on

the Play Store may not be available for your phone due to an LCD

resolution requirement that does not match your phone. In addition,

please be aware that 3rd party applications with programming defects

may cause issues with your phone, including lock-ups and resets.

Technical Details

CDMA

Standard

Designator Description

Basic Air

Interface

TIA/EIA-95A

TSB-74

ANSI J-STD-008

TIA/EIA-IS2000

CDMA Dual-Mode Air Interface

14.4kbps Radio Link Protocol and

Inter-band Operations

IS-95 Adapted for PCS Frequency Band

CDMA2000 1xRTT Air Interface

Network

TIA/EIA/IS-634

TIA/EIA/IS-651

TIA/EIA/IS-41-C

TIA/EIA/IS-124

MAS-BS

PCSC-RS

Intersystem Operations

Non-Signaling Data Communications

Technical Details

Service

TIA/EIA/IS-96-B

TIA/EIA/IS-637

TIA/EIA/IS-657

IS-801

TIA/EIA/

IS-707-A

Speech CODEC

Short Message Service

Packet Data

Position Determination Service (gpsOne)

High Speed Packet Data

1x EV-DO

Interface

TIA/EIA/IS-856

TIA/EIA/IS-878

TIA/EIA/IS-866

TIA/EIA/IS-890

CDMA2000 High Rate Packet Data Air

Interface

1x EV-DO Inter-Operability Speciﬁcation

for HRPD Access Network Interfaces

Recommended Minimum Performance

Standards for HRPD High Rate Packet

Data Access Terminal

Test Application Speciﬁcation (TAS) for

High Rate Packet Data Air Interface

LTE Standard Designator Description

Basic

Air Interface

TS 36.101

TS 36.104

Evolved Universal Terrestrial Radio

Access (E-UTRA);

User Equipment (UE) radio

transmission and reception

Evolved Universal Terrestrial Radio

Access (E-UTRA);

Base Station (BS) radio transmission

and reception

Technical Details

Conformance

Test

TS 36.521-1

TS 36.521-2

TS 36.521-3

Evolved Universal Terrestrial Radio

Access (E-UTRA);

User Equipment (UE) conformance

speciﬁcation;

Radio transmission and reception;

Part 1: Conformance testing

Evolved Universal Terrestrial Radio

Access (E-UTRA);

User Equipment (UE) conformance

speciﬁcation;

Radio transmission and reception;

Part 2: Implementation Conformance

Statement (ICS)

Evolved Universal Terrestrial Radio

Access (E-UTRA);

User Equipment (UE) conformance

speciﬁcation;

Radio transmission and reception;

Part 3: Radio Resource Management

(RRM) conformance testing

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the

United States, with its action in Report and Order FCC 96-326, adopted an

updated safety standard for human exposure to Radio Frequency (RF)

electromagnetic energy emitted by FCC regulated transmitters. Those

guidelines are consistent with the safety standard previously set by both

U.S. and international standards bodies. The design of this phone complies

with the FCC guidelines and those international standards.

Technical Details

Part 15.19 statement

This device complies with part15 of the FCC rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

Part 15.21 statement

Changes or modiﬁcations that are not expressly approved by the

manufacturer for compliance could void the user’s authority to operate the

equipment.

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

The LG G3 operates on 4G network, based on Long Term Evolution (LTE)

technology and Mobile Broadband 4G networks in the United States*.

Now you can connect easily at high speeds to the Internet, your corporate

Intranet, and your email while you’re away from the ofﬁce.

* Service not available everywhere.

Technical Details

* Information subject to change.

Wi-Fi Caution

This device is capable of operating in 802.11a/n/ac mode. For 802.11a/n/ac

devices operating in the frequency range of 5.15 – 5.25 GHz, they are

restricted for indoor operations to reduce any potential harmful interference

for Mobile Satellite Services (MSS) in the US. Wi-Fi Access Points that are

capable of allowing your device to operate in 802.11a/n/ac mode(5.15 –

5.25 GHz band) are optimized for indoor use only. If your Wi-Fi network is

capable of operating in this mode, please restrict your Wi-Fi use indoors to

not violate federal regulations to protect Mobile Satellite Services.

The Basics

Phone Overview

Front View

Proximity

Sensor

QuickTap Bar

Back Key

Home Key

Recent Apps Key

Home Screen

Earpiece

Front Camera

Notiﬁcation LED

NOTES • All screen shots in this guide are simulated. Actual displays may vary.

• Instructions to perform tasks in this guide are based on the default settings and may

change depending on the mode and software version on your phone.

1. Proximity Sensor Senses proximity toward other objects (such as your

head) so that tap commands are not accidentally activated (during a call

or when carried inside a pocket.

It also employs an ambient sensor which measures the surrounding

light and adjusts the LCD brightness to provide a vivid screen.

NOTE Don't block the sensor or near the sensor to avoid problems with the touchscreen.

2. Notiﬁcation LED Flashes to alert you for notiﬁcations (e.g., incoming

call, new text message, screen unlock, etc.).

3. Front Camera Use to take pictures and record videos of yourself.

You can also use this for video chatting. Keep it clean for optimal

performance.

4. QuickTap Bar Provides icons for quick, one-touch access to the

Applications screen and the apps you use most often.

5. Back Key Tap this Touch Key (in the Touch Keys bar) to return to the

previous screen or close pop-up items (such as menus, dialog boxes,

and the on-screen keyboard). Touch and hold it to access the Dual

window function which allows you to use two apps at the same time.

6. Home Key Tap this Touch Key (in the Touch Keys bar) to return to the

Home screen (or your default Home screen panel from any of the Home

screen extension panels). Touch and hold it to access Google Now.

7. Recent Apps Key Tap this Touch Key (in the Touch Keys bar) to display

recently used apps. Touch and hold this key to open an Options menu

with options that affect the current screen or app. This only applies

when available, depending on the screen or app.

8. Home Screen Displays all of the items needed to operate your phone

including icons for app access, widgets, and the Status Bar (with status

icons) allowing simple touch access to all of its functions and features.

WARNING! Placing a heavy object on the phone or sitting on it can damage the LCD and

touchscreen functions.

9. Earpiece Lets you hear callers and automated prompts.

Rear View

Rear Camera

LED Flash

Volume Buttons

Power/Lock

Button

Laser Detection

Auto-focus

NFC Touch Point

Speaker

10. Rear Camera Use to take photos and record videos. Keep it clean for

optimal performance.

11. Laser Detection Auto-focus Detects the distance between the rear

camera lens and nearby objects using laser technology. This feature

The Basics

helps the camera to focus quickly and accurately at short or long

distances.

NOTE Don't cover the Proximity Sensor and Laser Detection Auto-focus with a protection

ﬁlm, pouch, or protection case not authorized by LG as they may cause the device to

malfunction.

12. Power/Lock Button Press to turn off the screen backlight and lock the

screen, or turn the screen backlight back on. Press and hold to turn the

phone on/off, restart it, and activate/deactivate Airplane mode.

13. NFC Touch Point Tap the back of your phone to an NFC tag or another

NFC compatible device in this location to transfer data between them.

14. Speaker Use to listen to audio (e.g., music, videos, sound clips,

speakerphone, etc.) from the rear speaker instead of the earpiece.

15. Volume Buttons Press to adjust the ringer, the media volumes, or the

in-call volume during a call.

TIPS • With the screen backlight off (asleep), you can press and hold the Volume Down

Button

to activate the Camera app.

• With the screen backlight off (asleep), you can press and hold the Volume Up Button

to access the QuickMemo+ app.

16. LED Flash Brightens up the captured image or recorded video when

you turn on the ﬂash.

Top and Bottom View

USB/Charger

Port

Microphone

3.5mm

Headset Jack

IR (Infrared)

LED

17. IR (Infrared) LED Uses infrared to communicate with devices using the

QuickRemote app.

18. Microphone Transmits your voice to the other caller. It's also used for

voice-activated functions.

The Basics

19. 3.5mm Headset Jack Allows you to plug in an optional headset for

convenient, hands-free conversations. You can also plug in headphones

to listen to music.

20. Microphone Transmits your voice to the other caller. It's also used for

voice-activated functions.

21. USB/Charger Port Allows you to connect the phone and the USB Cable

for use with the Charger Adapter, or other compatible accessories.

NOTE You may purchase a separate fast data cable from LG to enjoy higher data transfer speed

with compatible devices (e.g., laptop).

Setting Up Your Phone

Step 1. Remove the Back Cover

Insert your ﬁngernail into the slot located on the lower left of the back

cover and lift the cover up gently.

The Basics

Step 2. Insert the Battery

Insert the battery in its compartment, making sure to align the gold

contacts. Press down gently to secure the battery.

Step 3. Replace the Back Cover

Place the cover over the back of the phone, then press down along the

edges to secure the cover.

Step 4. Charge the Phone

Before turning on your phone, fully charge the battery. Be sure to use the

USB Cable and Charger Adapter that came with your phone. Correctly

orient the USB Cable plug before inserting it in the USB/Charger Port to

avoid damage to your phone. See Charging the Phone on page 23 for

more information.

The Basics

NOTE It’s important to fully charge the battery before initial use of the phone to maximize the

battery's lifetime.

Removing the Battery

Removing the battery

Insert your ﬁngernail into the slot located on the lower left of the back cover

and lift the cover up gently.

2. Use the ﬁngertip cutout at the bottom of the battery compartment to lift the

battery out.

The Basics

Inserting and Removing the SIM card and microSD card

SIM/SD slot location

SIM Slot

MicroSD Slot

Inserting the SIM card

Before you can start exploring your new phone, you’ll need to set it up. To

insert the SIM card:

1. Remove the back cover and the battery.

2. Locate the slot for the SIM card (the lower of the two slots above the

upper-right corner of the battery compartment) and gently side the SIM

card in to insert it.

Removing the SIM card

If you need to replace your SIM card, refer to the following instructions.

1. Turn the phone off, then remove the back cover and the battery (as

demonstrated in the previous instructions).

2. Locate the slot for the SIM card (the lower of the two slots above the

upper-right corner of the battery compartment) and gently slide the SIM

card out to remove it.

The Basics

CAUTION If a microSD card is inserted in your phone, please remove it from the upper slot

before trying to remove the SIM card.

Inserting the microSD card

1. Remove the back cover (as demonstrated in the previous instructions)

and locate the dual slot just above the upper-right corner of the battery

compartment. (microSD is inscribed near the slot opening.)

2. Position the microSD card (sold separately) with the label side facing

up and the gold contacts toward the slot, then carefully slide it into the

upper slot until it's secured in place.

NOTE The microSD card can be easily damaged by improper operation. Please be careful when

inserting, removing, or handling it.

This device supports up to a 2TB microSD card.

To unmount the microSD card

It’s important to unmount the microSD card prior to removing it from the

phone to avoid damage to it or the data saved on the card.

1. From the Home screen, touch and hold the Recent Apps Key

(in the

Touch Keys bar) > System settings > General tab > Storage.

2. Tap Unmount SD card.

The Basics

To remove the microSD card

1. Unmount the microSD card.

From the Home screen, touch and hold the Recent Apps Key

(in

the Touch Keys bar) > System settings > General tab > Storage >

Unmount SD card.

2. Remove the back cover and locate the microSD card slot (as

demonstrated in the previous instructions).

3. Carefully pull the microSD card out to remove it.

Charging the Phone

Your phone comes with a USB Cable and a Charger Adapter which connect

together to charge your phone. Correctly orient the USB Cable plug before

inserting it in the USB/Charger Port to avoid damaging your phone.

NOTE Please only use an approved charging accessory to charge your LG phone. Improper

handling of the USB/Charger Port, as well as the use of an incompatible charger, may

cause damage to your phone and void the warranty.

1. Correctly orient the USB Cable with the Charger Adapter, and connect

them. As shown below, both the USB logo on the USB Cable and the

LG logo on the adapter will face toward you.

USB Cable Charger Adapter

2. The USB/Charger Port is located at the bottom of the phone. Correctly

orient the cable's plug with the port before plugging it in. As shown

below, the USB logo on the cable will face upward.

3. Plug the Charger Adapter into an electrical outlet to begin charging.

The Basics

Charging with the USB Cable

NOTE

Make sure to correctly orient the cable's

plug with the port before plugging it in.

When the phone is facing upward, the USB

logo on the cable will also face upward.

USB Cable

You can use your computer to charge your phone. To be able to charge with

the USB Cable, you need to have the necessary USB drivers installed on

your PC ﬁrst. Connect one end of the USB Cable to the USB/Charger Port

on your phone (as shown above) and connect the other end to a USB port

on your PC. It’s best to use the rear USB port when connecting to a desktop

PC. The USB hub should be powered by an external power source.

NOTE You may experience a slower charging rate when charging from your computer.

Turning the Phone On and Off

Turning the phone on

Press and hold the Power/Lock Button

on the back of the phone for

a couple of seconds until the screen turns on.

Turning the phone off

1. Press and hold the Power/Lock Button on the back of the phone

until the Phone options menu appears.

2. Tap Power off in the Phone options menu.

3. Tap OK to conﬁrm that you want to turn off the phone.

Turning the screen on using the Knock Code feature

If your Lock screen unlock sequence is set to a Knock Code, tap your

Knock Code on the darkened screen to automatically turn the screen on

and unlock it at the same time.

TIP When the screen is in time-out and a Knock Code is set, pressing the Power/Lock

The Basics

Button (on the back of the phone) displays the Lock screen (e.g., to check the time).

You can tap your Knock Code to unlock the screen or turn the screen back off by

pressing the Power/Lock Button

again (or double-tap the Status Bar).

NOTES

• If you enter incorrect Knock Code 5 times consecutively, you will be required to enter

the backup PIN you have set.

• Use a ﬁngertip instead of a ﬁngernail to tap the screen to turn the screen on.

•

If Knock Code isn't your unlock sequence, the Knock Code feature isn't activated, and

you can use the KnockON feature by double-tapping the screen.

Setting up the Knock Code feature

1. From the Home screen, touch and hold the Recent Apps Key (in the

Touch Keys bar) > Lock screen settings.

2. Tap Select screen lock > Knock Code.

3. Tap the squares in a pattern (from 3 to 8 taps) to set your Knock Code,

then tap Continue, enter it again, then Conﬁrm.

Turning the screen on using the KnockON feature

The KnockON feature allows you to turn the screen on or off easily by

double tapping the screen.

Quickly double-tap the center of the screen to turn the screen on.

Quickly double-tap the Status Bar, an empty area on the Home screen,

or the Lock screen to turn the screen off.

NOTES • When turning the screen on (using the KnockON feature or your Knock Code), avoid

covering the proximity sensor. Doing so will not allow you to turn the screen on.

• While Knock Code is in use, double-tapping the screen while it's off will turn it on and

display the Knock Code grid to allow you to enter your Knock Code.

To unlock the phone

If you don’t use the phone for a while, the screen and backlight will turn off

to conserve battery power. To unlock the phone’s default Lock screen:

1. Turn the screen on.

Press the Power/Lock Button

(on the back of the phone). The

default Lock screen will appear.

NOTE Avoid covering the proximity sensor when turning the screen on. Doing so immediately

turns the screen off.

The Basics

Quickly double-tap the center of the screen (KnockON).

NOTE If you set up a Knock Code in the Screen lock setting, you can tap your sequence to turn

the screen on and unlock the screen at the same time.

2. From the center of the screen, swipe in any direction to unlock it.

To use a shortcut, swipe the shortcut icon (at the bottom of the

screen) in any direction. The screen will unlock and launch the app.

NOTE The default Lock screen simply locks the screen to prevent unintentional actions. For

more security to guard against unauthorized use, you can set an unlock requirement

(such as a knock code, pattern, PIN, password, or face recognition) that will need to be

entered to unlock it.

Phone’s Status Icons

The Status Bar appears at the top of every screen. It displays icons

indicating that you’ve received notiﬁcations (on the left) and icons indicating

the phone’s status (on the right), along with the current time.

Notiﬁcation icons Status icons

If you have more notiﬁcations than can ﬁt in the Status Bar, the More

notiﬁcations icon

is displayed as an indicator to open the Notiﬁcations

panel to view them all.

The following icons may appear in the Status Bar.

Call icons

In call Missed call

Speakerphone is on Microphone is muted

Sound icons

Silent mode is activated Vibrate mode is activated

Music is playing

The Basics

Network icons

3G connection 3G in use

4G LTE connection 4G LTE in use

Wi-Fi connection Signal strength

No signal Roaming

Network Extender No SIM card

Unknown SIM card Airplane mode is activated

GPS is on App update available

App update successful Downloading

Uploading Download successful

Emergency Alert

Connectivity icons

Syncing Problem with sign-in or sync

Mobile Hotspot is on USB connected

Bluetooth connection Mobile Broadband connection

Bluetooth headset full battery Bluetooth is on

NFC is on

Bluetooth headset low

battery

Headset with microphone is

connected

Headset is connected

Internal storage is full

Email and Messaging icons

New email New Gmail message

New text or multimedia

message

New voicemail

The Basics

Email not sent Message not sent

New Hangouts message

Calendar and Alarm icons

Alarm is set Upcoming event

Battery icons

Full battery Charging battery

Low battery Empty battery

Not Charging

Other icons

More notiﬁcations available Screenshot captured

The Basics

Getting to Know the Home Screen

The Home screen is your starting point to access all of the features on your

phone using simple motions on the touchscreen. It’s comprised of multiple

panels (swipe horizontally to switch). You can customize all of your Home

screen panels with app shortcuts, icons, widgets, and other features.

Status Bar

Shows device status

information, including the

time, signal strength, battery

status, and notiﬁcation icons.

App Icon

Tap an icon (app, widget,

folder, etc.) to open and

use it.

QuickTap Bar

Icons that provide easy, one-

touch access to the functions

used most often.

Apps Screen Icon

Tap here to open the Applications

screen to view all of your installed

apps.

Touch Keys

Displayed on all screens, these keys

allow you to easily navigate within

the device software.

QuickTap bar icons

The QuickTap bar is located on all of your Home screen panels (at the

bottom of the screen in portrait view) to allow quick and easy navigation to

the apps you use most often. The following ﬁve icons are included in the

QuickTap bar.

: Opens the Phone app which displays the dialpad so you can dial a

number not stored in your phone’s memory. It also provides additional

tabs at the top of the screen to access your Call logs, Contacts,

Favorites, and Groups.

: Opens the Contacts app which displays the names and numbers

stored in your phone’s memory. It also provides additional tabs at the

top of the screen to access the dialpad, your Call logs, Favorites, and

Groups.

: Opens the Apps screen which displays phone options and apps. It also

provides a Widget tab, a Search icon

, and a Menu options icon at

the top of the screen.

The Basics

: Opens the Browser app to access the web browser.

: Opens the Messaging app so you can send and view text and

multimedia messages.

Touch Keys

The Touch Keys are displayed in a bar at the bottom of all of the screens to

provide easy navigation within the device software.

NOTE The Touch Keys are displayed along the right side of the screen when the phone is held

horizontally. If you don't see the keys, drag upward from the bottom of the screen to

redisplay them.

Back Key: Tap to back up one step at a time and close on-screen items

such as pop-up messages, the on-screen keyboard, etc. Touch and hold

the Back Key to activate Dual window mode which allows you to open

two apps at the same time.

Home Key: Tap to immediately return to the Home screen. Touch and

hold to access Google Now.

Recent Apps Key: Tap to display the apps you recently used. Touch and

hold to access available options for the current screen or app.

Touchscreen

Your touchscreen provides an excellent way to interact with and use your

Android™ phone. With the touch of your ﬁnger, you can download and use

available apps, make menu selections, and access data saved to your

phone.

The following terms are used for describing the different available actions

using the touchscreen:

Touch or tap A single ﬁnger touch selects items. For example, tap an

icon (e.g., an app, widget, or folder), tap words (e.g., menu selection or to

answer an on-screen question), or touch letters and numbers to type.

NOTE Don't press too hard on the touchscreen. It's sensitive enough to detect a light, ﬁrm tap.

Touch and hold Touch and hold an item on the screen by touching it and

not lifting your ﬁnger until an action occurs. For example, to open a

The Basics

Context menu for editing a contact, touch and hold a contact entry until

the menu pops up.

Drag Touch and hold an item for a moment and then, without lifting your

ﬁnger, move your ﬁnger on the screen until you reach the target position.

For example, you can drag items on the Home screen to reposition them.

Swipe, slide, or ﬂick Move your ﬁnger quickly across the surface of the

screen, without pausing when you ﬁrst touch it (so you don’t drag an item

instead). For example, you can browse through the different Home

screens by swiping from left to right (and vice versa), slide the screen up

or down to scroll a list, or remove an app from the Recent apps screen by

ﬂicking its graphic off the screen.

Double-tap Tap the screen twice quickly to zoom, highlight text, or turn

the screen on/off. For example, quickly double-tap a section of a web

page to zoom that section to ﬁt the width of the screen and control the

zoom in Maps and in other apps. Double-tap a word to highlight it.

Double-tap can also activate the KnockON feature to turn the touchscreen

on or off.

NOTE The Accessibility settings shortcuts and Touch zoom accessibility features use a

triple-tap. Double-tap also activates a new event in the Calendar app.

Pinch-to-zoom Use your index ﬁnger and thumb in a pinch motion (to

zoom out) or spread motion (to zoom in) when using Chrome, a map,

photos, the rear camera lens, the Contacts list, the Favorites list, the

Groups list, the Messaging list, and a music list. Spread apart to make

screen information larger (easier to see and read), or pinch together to

view more area and information. The pinch gesture also changes the

Home screen. Pinch in on the Home screen to change to mini panel view,

then spread apart to return to the normal Home screen view. Spread apart

on the normal Home screen to hide all of your Home screen items, then

pinch in to redisplay them.

Rotate the screen From many apps and menus, the orientation of the

screen adjusts to the phone’s physical orientation by rotating the screen.

You can deactivate this function in the Display settings menu.

The Basics

Capturing the screen Press and hold the Volume Down Button and

the Power/Lock Button

on the back of the phone at the same time to

capture the current image on the screen. The captured image is saved in

the Screenshots folder of the Gallery.

NOTE You cannot capture an image from some videos and apps.

The Smart screen feature

The Smart screen feature keeps the phone from activating screen time-out

when it detects your eyes looking at the screen. When you turn this feature

on, you can set a shorter screen time-out to conserve your battery power,

but still allow you to view a screen for a longer period of time without

having to touch it to keep it activated.

To turn this feature on, from the Home screen, touch and hold the Recent

Apps Key

(in the Touch Keys bar) > System settings > Display tab >

checkmark the Smart screen checkbox.

NOTES The following situations may prevent these features from functioning properly:

• When the phone is in the dark or against bright light.

• When the camera lens can’t detect the location of your eyes.

• When the front camera is used at the same time with other apps.

Hardware button control mode

If your phone display is damaged or broken, you can answer an incoming

call, or turn off an alarm using the hardware buttons on the back of the

phone.

Answer a call: Press both Volume Buttons at the same time.

Stop an alarm: When an alarm rings, press and hold either of the

Volume Buttons to stop the alarm. Press either Volume Button once to

snooze the alarm.

To activate Hardware key control mode

1. Turn your phone off.

2. Press and hold the Power/Lock Button

and both of the Volume

The Basics

Buttons (on the back of the phone) at the same time for more than 6

seconds to enter Hardware key control mode.

3. Press the Volume Buttons

to scroll to Mode ON, Mode OFF, or

Cancel, then press the Power/Lock Button to conﬁrm.

NOTE If you use your phone with a broken display glass, your phone may incur additional

damage or cause injury. Make sure to visit an LG authorized service center to get your

phone repaired.

Working with Menus

Options menus

Options menus contain tools that apply to the activities of the current

screen or app, not to any speciﬁc item on the screen. To open the available

Options menu, tap the Menu icon

(at the upper-right corner of the

screen). To open the Options menu on the Home screen, touch and hold

the Recent Apps Key (in the Touch Keys bar at the bottom of the screen).

Context menus

Context menus contain options that apply to a speciﬁc item on the screen.

To open a Context menu, touch and hold an item on the screen. Not all

items have Context menus. If you touch and hold an item that has no

Context menu, nothing will happen.

Managing Notifications

Notiﬁcation icons report the arrival of new messages, calendar events,

alarms, as well as ongoing events, such as when you’re in a call.

When you receive a notiﬁcation, the notiﬁcation icon will be displayed in the

Status Bar. You can open the Notiﬁcations panel to view a list of all of your

recent notiﬁcations. Depending on your settings, you may hear a

notiﬁcation sound, and/or see a notiﬁcation light (at the upper-left corner of

the phone), and/or the phone may vibrate.

To open the Notifications panel

Touch and drag the Status Bar to the bottom of the screen.

The Basics

The Notiﬁcations panel displays a list of your current notiﬁcations, organized

into ongoing and event-based notiﬁcations. It also includes a Quick Settings

icon bar (at the top of the panel) to allow you to quickly and easily change

commonly used settings.

NOTE You can also access the complete Settings menu from this panel by tapping the Settings

icon

(at the upper-right corner of the screen).

Tap a notiﬁcation to open it.

Quick Settings Bar

Flick right or left to scroll

through the list and tap an

icon to change its setting.

Settings menu icon

Clear Button

Tap here to clear your list of

event-based notiﬁcations.

To respond to a notification

1. Open the Notiﬁcations panel. Your current notiﬁcations are listed in the

panel, each with a brief description.

2. Tap a notiﬁcation to view it.

The Notiﬁcations panel will close and the app that corresponds to your

selection will open. For example, new voicemail notiﬁcations dial your

voicemail box and Gmail notiﬁcations open the Gmail app so you can

read your new messages.

To clear all notifications

1. Open the Notiﬁcations panel.

2. Tap the Clear button

(on the right side of the screen).

All event-based notiﬁcations will be cleared; ongoing notiﬁcations will

remain in the list.

The Basics

To close the Notifications panel

Touch and drag the handle at the bottom of the Notiﬁcations panel to the

top of the screen, ﬂick the Notiﬁcations panel handle upward, or just tap

the Back Key

(in the Touch Keys bar).

The panel will also close when you touch a notiﬁcation.

NOTE When you open the Notiﬁcations panel from the Lock screen, the Touch Keys bar is not

displayed at the bottom of the screen. Drag or ﬂick the handle upward to close it.

Setting your Lock screen

There are several Lock screen types allowing you to lock your phone so

that only you can unlock it to make calls, access your data, buy apps, and

prevent unauthorized use.

Setting a Screen Lock for the First Time

1. From the Home screen, touch and hold the Recent Apps Key (in the

Touch Keys bar) > Lock screen settings.

2. Tap Select screen lock.

3. Tap None, Swipe, Knock Code, Pattern, PIN, or Password.

None: No Lock screen is enabled so the screen will never be locked

from use.

Swipe: A swipe motion in any direction on the touchscreen will unlock

the screen. This is the default Lock screen that simply guards against

unintentional actions.

Knock Code: Unlocks the screen by tapping a sequence on the screen’s

2x2 grid. (The 2x2 grid that you used while setting up a Knock Code

won’t be displayed by default. However, the grid will be displayed if you

have failed to enter incorrect knock codes 5 times consecutively.) The

ﬁrst time you set a Knock code, you’ll see a tutorial with instructions on

how to create it. Tap a sequence on the 2x2 grid (from 3 to 8 taps), then

tap Continue. Tap your sequence again and tap Conﬁrm.

NOTE You're prompted to create a Backup PIN as a safety measure in case you forget your

Knock code unlock sequence.

Pattern: Unlocks the screen using a pattern you draw with your ﬁnger.

The Basics

The ﬁrst time you set an unlock pattern, you’ll see a tutorial with

instructions on how to create it. Read the tutorial, then tap Next. Draw

your pattern (connect at least 4 dots) and tap Continue. Then redraw

your pattern and tap Conﬁrm.

NOTE You're prompted to create a Backup PIN as a safety measure in case you forget your

unlock pattern sequence.

PIN Unlocks the screen with a number sequence. Enter a PIN (at least 4

digits) and tap Continue. Reenter your PIN and tap OK to conﬁrm it.

Password Unlocks the screen with an alphanumeric sequence. Enter a

password (at least 4 characters) and tap Continue. Re-enter your

password and tap OK to conﬁrm it.

From then on, any time you want to unlock the screen, you’ll need to

perform the unlock action you set (swipe, Knock Code, pattern, PIN, or

password) to gain access to it.

Factory Data Reset

When you can’t recall your Unlock Pattern, PIN, or Password:

If you logged into a Google account on the phone and failed to use the

correct pattern 5 times, tap Forgot pattern? You will be required to sign in

with your Google account and prompted to create a new unlock pattern.

If you have set a backup PIN, you can unlock the screen with keying in the

backup PIN.

If you haven’t created a Google account on the phone and you forgot your

PIN, Password, and the backup PIN, you need to perform a hard reset.

CAUTION If you perform a hard reset, all user applications and user data will be deleted. Please

remember to back up any important data before performing a hard reset.

Read ALL steps before attempting.

1. Turn the phone off.

2. Press and hold the following keys at the same time: Volume Down

Button

+ Power/Lock Button on the back of the phone.

3. Release only the Power/Lock Button

when the LG logo is displayed,

then immediately press and hold the Power/Lock Button again.

The Basics

4. Release all keys when the Factory data reset is displayed.

5. Press the Volume Buttons

to highlight Yes in gray, then press the

Power/Lock Button to continue.

6. Press the Volume Buttons

to highlight Yes in gray, then press the

Power/Lock Button once more to conﬁrm.

7. Your device will perform a factory reset.

Guest Mode

Use Guest mode when you let someone else use your phone. They’ll only

be able to use the apps that you’ve selected. Once you set it up, you can

easily put your phone in Guest mode by accessing the Lock screen and

drawing the guest pattern that you set, which is different from your normal

unlock pattern. It also supports Knock Code, PIN, and Password.

NOTE Guests can also use apps that your selected apps are linked to.

Setting up Guest mode

1. From the Home screen, touch and hold the Recent Apps Key (in the

Touch Keys bar) > System settings > General tab > Guest mode.

2. Tap Lock screen type, then set the pattern you want to use to put your

device in Guest mode.

If your Lock screen isn’t set to an unlock sequence, you’ll be

prompted to enter an unlock sequence for yourself before you’re

prompted to enter an unlock sequence for your Guest mode.

3. Tap Allowed app to view which apps can be accessed in Guest mode.

Checkmark the apps that you want to allow to be accessed in Guest

mode.

Remove checkmarks from the apps to hide in Guest mode.

Tap the Back Key

(in the Touch Keys bar) when all of the

checkboxes are set as you want.

4. Tap the Guest mode switch

(in the upper-right corner of the screen)

to turn it on (or off).

The Basics

Using Guest mode

After you’ve set up and enabled Guest mode, lock the screen, then access

the Lock screen (press the Power/Lock Button

on the back of the

phone or use the KnockON feature). Enter your Guest mode screen lock.

The Guest mode Home screen is displayed with only the apps you’ve

selected for guest access. To exit Guest mode, simply access the Lock

screen again and enter your normal unlock screen lock.

Your Google Account

You must sign into a Google Account to use Gmail, Hangouts, Google

Calendar, and other Google apps; to download apps from Play Store; to

back up your settings to Google servers; and to take advantage of other

Google services on your phone.

IMPORTANT

• If you don’t sign into a Google Account during setup, you're prompted to sign in or to

create a Google Account the ﬁrst time you start an app that requires one, such as

Gmail or Play Store.

• When you sign in, you’re prompted to enter your username and password using the

on-screen keyboard.

• After you sign in, your contacts, Gmail messages, Calendar events, and other

information from these apps and services on the web are synchronized with your

phone.

• If you have an enterprise account through your company or other organization, your IT

department may have special instructions on how to sign in to that account.

Connecting to Networks and Devices

Connecting to Mobile Networks

When you buy your phone and sign up for service, your phone is conﬁgured

to use your provider’s mobile networks for voice calls and for transmitting

data.

Different locations may have different mobile networks available.

Initially, your phone is conﬁgured to use the fastest mobile network

available for data. You can also conﬁgure your phone to access a different

set of networks entirely, or to behave in speciﬁc ways when roaming.

The following icons in the Status Bar indicate which kind of data network

you’re connected to and the network signal strength.

Connected to the 4G network (LTE).

Connected to the EVDO network (EVDO revA).

Signal strength - the more bars that are lit, the stronger the

wireless signal.

Connected to another wireless service provider’s network

(roaming).

When connected to slower networks, you may want to postpone using

your phone for data-intensive tasks until you’re connected to a faster

network again or ﬁnd a Wi-Fi network to connect to.

To disable data when roaming

You can prevent your phone from transmitting data over other carriers’

mobile networks when you leave an area that’s covered by your carrier’s

networks. You can still transmit data with a Wi-Fi connection when Global

data roaming access is restricted. This is useful for controlling expenses if

your cell plan doesn’t include data roaming.

1. From the Home screen, touch and hold the Recent Apps Key

(in the

Touch Keys bar) > System settings > Networks tab > Tethering &

networks > Mobile networks.

2. Tap the Data roaming check box to remove the check mark and disable

data services while roaming.

Connecting to Networks and Devices

Connecting to Wi-Fi Networks

Wi-Fi is a wireless networking technology that can provide Internet access

at distances of up to 100 meters, depending on the Wi-Fi router and your

surroundings.

To use Wi-Fi on your phone, you must connect to a wireless access point.

Some access points are open and you can simply connect to them. Others

are hidden or implement other security features, so you must conﬁgure

your phone so it can connect to them.

Turn off Wi-Fi when you’re not using it, to extend the life of your battery.

When you connect to a Wi-Fi network, the phone obtains a network

address and other information it needs from the network, using the DHCP

protocol. To conﬁgure the phone with a static IP address and other

advanced settings, from the Wi-Fi settings screen, touch and hold the

connected network. Tap Modify network in the Context menu that

appears, then checkmark the Show advanced options checkbox.

To turn Wi-Fi on and connect to a Wi-Fi network

1. From the Home screen, touch and hold the Recent Apps Key

(in the

Touch Keys bar) > System settings > Networks tab > Wi-Fi.

If the Wi-Fi switch

is off (gray icon), tap it to turn on Wi-Fi (On

turns blue), your phone scans for available Wi-Fi networks.

2. Tap a network, then tap Connect to connect to it.

If the network is open, you can connect to the network directly by

tapping the network name.

If the network is secured, you’ll be prompted to enter a password

(Ask your network administrator for details).

When you’re connected to a network, you can tap the network name

in the Wi-Fi settings screen for details about the speed, security, and

related settings.

Connecting to Networks and Devices

USB Connection

USB connection is a feature that allows your phone to connect to a PC

using a USB Cable.

Using the Status Bar to change the connection mode setting

The Status Bar displays the USB connection icon, when connected via

USB.

When connected via USB, the current USB connection mode also appears

on the Notiﬁcations panel. Tap the connection setting to display a screen

where you can change the USB connection mode.

1. Connect the phone to your PC via a USB cable.

2. Open the Notiﬁcations Panel and tap the current USB connection type.

Then tap Media device (MTP) or Send images (PTP) to connect to the

PC.

Tap Charge phone to use only the charging function and not the USB

function. It also allows you to safely disconnect your phone from your

PC.

NOTE The MTP driver may not be installed on your PC by default. The driver is dependent on

the PC's versions of Windows® and Windows Media Player (WMP).

SmartShare

You can use the SmartShare function to conveniently view photos and play

videos (the Gallery app) and listen to music (the Music app).

To enjoy SmartShare

You can stream multimedia content on your phone to another device and

also send ﬁles to it.

Play: You can stream your content via TV, Bluetooth speaker, etc.

Beam: You can send your content to Bluetooth devices or SmartShare

Beam-supported LG phones.

NOTE SmartShare requires both Wi-Fi and Bluetooth networks, so when you access

SmartShare, they'll turn on automatically.

Connecting to Networks and Devices

3. Access the app that has the content you want to use with SmartShare,

then tap the SmartShare icon , or the Menu icon (at the upper-

right corner of the screen) > SmartShare.

4. Tap Play or Beam.

5. Select the DLNA connected device you want to use. Tap Rescan to ﬁnd

the device.

To enjoy content from nearby devices on your phone

You can play content saved to nearby devices on your phone. Your nearby

devices must be supported by the DLNA function.

To set nearby devices

1. Ensure that your phone and the nearby devices are connected to the

same Wi-Fi network.

2. Set the DLNA device to enable sharing.

Calls

Placing and Ending Calls

The Phone app allows you to dial phone numbers manually or make calls

from your phone’s memory. Manually dial calls using the Dial tab. Dial from

your phone’s memory using the Call logs tab, the Contacts tab, the

Favorites tab, or the Groups tab.

To open the Phone app

From the Home screen, tap the Phone icon

(in the QuickTap bar).

Phone app tabs

The Phone app tabs (Dial, Call logs, Contacts, Favorites, and Groups) are

at the top of the screen.

Moving between the Phone app tabs

Tap any of the Phone app tabs (Dial, Call logs, Contacts, Favorites, and

Groups) at the top of the screen to view that tab. You can also ﬂick

horizontally on the screen to scroll to the other tabs. The current tab is

displayed in white.

Modifying the Phone app tabs

You can rearrange the order of the Phone app tabs and/or delete the

Favorites and Groups tabs.

1. From the Home screen, tap the Phone icon

(in the QuickTap bar).

2. Tap the Menu icon

(at the upper-right corner of the screen), then tap

Edit tabs.

Drag a tab handle

to move it to the position where you want it in

the list.

Tap the Favorites or Groups checkbox (checkmark displays the tab,

no checkmark deletes it from the Phone app tabs bar).

3. When you're ﬁnished making changes, tap Save (at the bottom of the

screen).

Calls

To place a call by dialing

1. From the Home screen, tap the Phone icon (in the QuickTap bar) to

open the Dial tab of the Phone app.

2. Use the dialpad to enter the number you want to call.

If you enter a wrong number, tap the Delete Key

to erase digits

one by one.

To erase the entire number, touch and hold the Delete Key

To dial an international number, touch and hold

to enter the plus (

+ ) symbol. Then enter the international preﬁx for the country,

followed by the full phone number.

3. Tap the Call Key

(on the dialpad) to dial the number that you entered.

Press the Volume Buttons (on the back of the phone) to adjust the

call volume.

Use the on-screen buttons to enter additional numbers, place the call

on hold to take another incoming call, add another call, use the

speakerphone, end the call, and other options.

You can use other phone features while the call is underway. If you

open another app, the Call icon

appears in the Status Bar for the

duration of the call.

NOTE If you opened other apps while on a call, you'll need to return to the Call screen to end

the call. To return to the Call screen, you can tap the Home Key

(in the Touch Keys

bar), then tap the Phone icon

(in the QuickTap bar), or tap the call timer (at the

upper-left corner of the Home screen). You can also drag the Status Bar down and tap

the Call notiﬁcation on the Notiﬁcations panel.

To end a call

Simply tap the End button

on the Call screen to end the call.

If you accessed other device functions while the call was in progress, there

are several ways to return to the Call screen to end the call.

Tap the Home Key

(in the Touch Keys bar), tap the Phone icon (in

the QuickTap bar), then tap the End button on the Call screen.

Tap the Home Key

(in the Touch Keys bar), tap the Call icon (at the

Calls

upper-left corner of the Home screen), then tap the End button on

the Call screen.

Drag the Status Bar down and tap END CALL.

NOTE You can also press the Power/Lock Button (on the back of the phone) to end the

call, if you activated this feature in the Call settings menu.

Calling numbers in your phone’s memory

You can place calls using information stored in your phone. Anywhere you

see a Call icon

next to a number, tap it to automatically dial it.

Speed dialing

If you set up Speed dials in the Contacts app, you can dial a number by

simply touching and holding the Speed dial number on the dialpad.

From the Home screen, tap the Phone icon

(in the QuickTap bar),

then touch and hold the Speed dial number.

Direct dialing

A Direct dial widget is like a speed dial button on your Home screen. Tap it

to automatically call the number you set (for example, your home phone

number).

To place a Direct dial widget on your Home screen

1. Touch and hold an empty area on your Home screen.

2. Tap the Widgets tab (at the bottom of the screen) > Direct dial.

3. Tap the contact in your Contacts list.

TIP You can change the look of each Direct dial widget for easy identiﬁcation. Touch, hold,

and release the Direct Dial widget, then tap it. Select a theme icon or a photo icon, then

tap OK.

Calls

Answering or Rejecting Calls

When you receive a phone call, the Incoming call screen opens with the

caller ID and any additional information about the caller that you’ve saved in

the Contacts list. All incoming calls are recorded in the Call logs tab.

To answer a call

Simply swipe the Answer icon

in any direction to answer the call.

If you were already on a call, swipe the Answer icon

in any

directions, which places the ﬁrst call on hold and connects the new call.

NOTE To silence the incoming call ringer, press either of the Volume Buttons (on the back of

the phone).

To ignore a call and divert it to voicemail

Simply swipe the Decline icon

in any direction to ignore the call.

The caller is sent directly to your voicemail box to leave a message.

NOTE To silence the ringer, press either of the Volume Buttons (on the back of the phone).

To ignore a call and send a text message

When you receive an incoming call, swipe the Decline with message

icon

in any direction.

Tap the text message you want to send in place of answering the call.

NOTE This feature can only be used to send a message to another mobile phone. It's not

applicable to incoming landline calls.

Working With the Call Logs Tab

The Call logs tab records all of the calls you’ve dialed, received, or missed.

It offers a convenient way to redial a number, return a call, or add a number

to your Contacts.

To open the Call logs tab

From the Home screen, tap the Phone icon

(in the QuickTap bar),

then tap the Call logs tab (at the top of the screen).

The Call logs tab lists your calls chronologically by phone number. The

Calls

number in parenthesis indicates the number of calls recorded for that

phone number.

Viewing call entry details

Open the Call logs tab, then tap an entry to view all of the entries for that

phone number. Calls are listed chronologically and each one includes the

call type (received

, dialed , and missed ), the date, and the time of

the call.

Filtering your list of calls

To view a speciﬁc call list, from the Call logs tab, tap the Menu icon (at

the upper-right corner of the screen), then tap Filter. Tap the call type you

want to view.

Tap the Back Key

(in the Touch Keys bar) to return to the Call logs tab

screen.

To dial a number in the Call logs tab

From the Call logs tab, tap the Call icon

at the right of the call entry.

From the Call logs tab, tap the image to the left of the call entry to view

all of the contact’s numbers saved in your phone’s memory. Tap a phone

number to dial it.

TIP You can edit a phone number in the Call logs tab before you place the call (e.g., to insert

an area code when you're traveling). Touch and hold the entry, then tap Edit number

before call in the Context menu. Edit the number as necessary, then tap the Call icon

on the keypad.

To add a number from the Call logs tab to your Contacts

1. Open the Call logs tab, then touch and hold the call entry.

2. Tap Add to Contacts in the Context menu.

3. Tap New contact or Update contact and save it as necessary.

Clearing your Call logs

You can delete the entire list of recent calls at once or selectively delete

entries.

Calls

1. Open the Call logs tab.

2. Tap the Menu icon

(at the upper-right corner of the screen).

Tap Delete to select entries to remove from the list. Checkmark the

entries to delete, tap Delete, then Yes.

Tap Delete all to remove all of the entries from the list. Tap Ye s to

conﬁrm you want to Clear (at the bottom of the screen), the entire list.

NOTE You can also select a speciﬁc number to be deleted. Touch and hold an entry in the Call

logs list to open its Context menu. Tap Delete all logs of this number, then tap Ye s to

conﬁrm.

Calling Your Contacts

Instead of manually dialing phone numbers using the dialpad, you can use

your Contacts list to dial quickly and easily. You can also quickly call a

contact using Quick Contact or Direct dial icons that you placed on your

Home screen.

If you have contacts on the web, they’re synchronized with your phone

when you ﬁrst synchronize with your Google™ Account.

To call a contact

1. From the Home screen, tap the Contacts icon (in the QuickTap bar).

2. Tap the contact you want to call.

3. Tap the contact’s phone number you want to call.

To call a favorite contact

1. From the Home screen, tap the Contacts icon (in the QuickTap bar),

then tap the Favorites tab (at the top of the screen).

2. Tap the contact you want to call.

3. Tap the contact’s phone number you want to call.

Instant List

Instant list is displayed on the Dial tab to help you use the information

stored in your phone without needing to search for it ﬁrst. Once you begin

Calls

entering numbers, Instant list displays entries from your Contacts list or

Recent calls that match the sequence you entered.

Sequence matches

Your phone searches for the entered sequence anywhere in the number;

beginning, end, or anywhere in-between. The matching number sequence

is displayed within the number in blue text. The name and type of number

(i.e., Mobile, Work, etc.) associated with the number you entered is

displayed above the dialpad. When there are multiple matches, the Instant

list displays the number of matches in your phone’s memory. Tap the

Instant list icon

on the right side of the screen to view the entire list of

matching entries. Tap Cancel (at the bottom of the list) to close the list.

Selecting an Instant list entry

Tap an entry in the Instant list to insert it on the dialpad and tap the Call

Key

(on the dialpad) to dial it.

Options During a Call

To mute the microphone

Tap the Mute button

on the Call screen.

The button is blue when the microphone is muted.

When viewing the Call screen, you can unmute the microphone by

tapping the Mute button

again.

The microphone is unmuted automatically when the call ends.

To turn the speakerphone on or off

Tap the Speaker button

on the Call screen.

The button is blue when the speakerphone is on.

When viewing the Call screen, you can turn the speakerphone off by

tapping the Speaker button

again.

The speakerphone is turned off automatically when the call ends.

Calls

WARNING!

To avoid damage to your hearing, don't hold the phone against your ear when the

speakerphone is turned on.

To switch between a Bluetooth headset and the phone

When a Bluetooth headset is paired and connected to your phone, you can

conduct calls on the headset for hands-free conversation. During a call, you

can opt to use the Bluetooth headset or just the phone.

Tap the Bluetooth button

on the Call screen to switch the call from

the phone to the Bluetooth device, or vice versa.

Managing Multiple Calls

Contact your wireless service provider to ﬁnd out which call services are

supported.

To switch between current calls

Tap the Swap calls button

on the Call screen.

The current call will be placed on hold and you’ll be connected with the

other call.

To set up a conference call

Contact your wireless service provider to ﬁnd out whether they support

conference calls and how many participants you can include.

1. Place a call to the ﬁrst participant.

2. When you’re connected, the Menu icon

> Add call.

3. Enter a phone number on the dialpad.

Use the Phone app tabs (at the top of the screen) to select a saved

number.

Use the keys on the dialpad to manually enter a number.

4. Tap the Call Key

(on the dialpad) to place the call.

Calls

5. After you’re connected, tap the Merge calls button (on the Call

screen). The participant is added to the conference call.

Listening to Your Voicemail

When you have a new voicemail message, the Voicemail notiﬁcation icon

appears in the Status Bar. If you haven’t set up your voicemail number,

or if you need to change it, you can do that in the Call settings.

To listen to your Voicemail

Open the Notiﬁcations panel and tap New voicemail.

From the Home screen, tap the Phone icon

(in the QuickTap bar),

then tap and hold the key (on the dialpad).

To set up your Voicemail

Typically, your carrier’s voicemail system guides you through the process of

listening to and managing your voicemail. The ﬁrst time you call your

voicemail, it also guides you through the process of recording greetings,

setting a password, etc.

1. From the Home screen, tap the Phone icon

(in the QuickTap bar).

2. Tap and hold the

key (on the dialpad) to dial your voice mailbox.

3. Follow the setup tutorial.

Enter a password.

Record a voice signature and greetings for your voice mailbox.

Airplane mode

Some locations may require you to turn off your phone’s wireless

connections by placing your phone in Airplane mode.

Press and hold the Power/Lock Button

(on the back of the phone),

then tap Turn on Airplane mode in the Phone Options menu that

appears.

Calls

From the Home screen, touch and hold the Recent Apps Key

(in the

Touch Keys bar) > System settings > Networks tab > the Airplane

mode switch (on the right side of the screen).

Drag the Status Bar downward, then tap Airplane mode

(in the

Quick settings bar at the top of the screen).

NOTE Each of these access methods toggles the setting on and off.

Web

Browser

Use this application to browse the Internet. Browser gives you a fast,

full-color world of games, music, news, sports, entertainment and much

more, right on your mobile phone wherever you are and whatever you

enjoy.

NOTE Additional charges apply when connecting to these services and downloading content.

Check data charges with your network provider.

1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > Browser .

Using the Web toolbar

If the toolbar is not displayed, scroll to the top of the page to display it.

Tap to go back one page.

Tap to go forward one page, to the page you connected to after the

current one. This is the opposite of what happens when you tap ,

which takes you to the previous page.

Tap to go to the Home page.

Tap to add a new window.

Tap to access bookmarks.

Viewing webpages

Tap the address ﬁeld, enter the web address and tap Go.

Opening a page

1. To go to new page, tap > .

2. To go to another webpage, tap

, scroll up or down, and tap the page

to select it.

Searching the web by voice

Tap the address ﬁeld, tap , speak a keyword, and then select one of the

suggested keywords that appear.

NOTE This feature may not be available depending on the region or service provider.

Web

Bookmarks

To bookmark the current webpage, tap

> Add to bookmarks > OK.

To open a bookmarked webpage, tap

and select one.

History

Tap > History to open a webpage from the list of recently-visited

webpages. To clear all history, tap

> Yes .

Chrome

The Chrome app allows you to access the Internet from your phone.

Access and selections within this feature are dependent upon your service

provider. For speciﬁc information on Internet access through your phone,

contact your service provider.

NOTES • You may incur additional charges for accessing the web and downloading media. For

details, contact your service provider.

• Chrome may differ from this user guide due to updates via Play Store.

Browse web pages

1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > Chrome or tap Chrome (in the

QuickTap bar) on the Home screen.

2. Tap the URL input ﬁeld to access a speciﬁc web page. Enter the web

address (URL) of the web page, then tap

(on the on-screen

keyboard).

3. Tap the Menu icon

(at the upper-right corner of the screen) to access

the Chrome Options menu.

Web

Maps

The Maps app allows you to ﬁnd places and get directions.

To open the Maps app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > the Maps icon .

My Location

Tap to access various features

on Google Maps.

Maps navigation

Tap the Maps menu

to access Your places, Explore nearby, Trafﬁc,

Public transit, Bicycling, Satellite, Terrain, Google Earth, Tips and

Tricks, Settings, Help, and Send feedback.

Drag across the screen to move across a displayed map.

Pinch-to-zoom to zoom in or out of the map view.

Maps icons

Tap to open the keyboard to enter your search request.

Red markers indicate search matches.

Tap a marker to open a dialog box that contains a label and additional

location information. You can save the location as a favorite, share the

location, and save the map to use ofﬂine.

Web

Tap to get directions to a destination.

Use the starting point to insert My Location or select from the recent

history.

Get directions by Car

, Transit , Walking , or Biking .

Once starting and destination points are entered, you can tap the

reverse icon

(on the right side of the screen] to reverse the

directions.

Tap to access map layers, Settings, Help, Send feedback, and Tips and

Tricks.

Tap to display your current location on the map.

Communication

Contacts

The Contacts app allows you to store names, phone numbers, and other

information in your phone’s memory. Entries are listed alphabetically. You

can scroll through the list, or tap the Favorites tab or Groups tab (at the top

of the screen).

Use the Contacts app to add, view, and communicate with your friends,

acquaintances, and associates.

To open your Contacts app

From the Home screen, tap the Contacts icon

(in the QuickTap bar).

NOTE You can also tap the Contacts tab (at the top of the screen) from the Phone app.

If you have a new phone and haven’t added any contacts yet, the Contacts

app will display hints on how to start adding contacts to your phone.

Contacts list

When you open the Contacts app, your contacts list is displayed. The

alphabet is displayed vertically along the right side of the screen with a blue

bar that indicates where you are in the list.

Adding Contacts

You can add contacts on your phone and synchronize them with the

contacts in your Google™ Account, Microsoft Exchange account, or other

accounts that support syncing contacts.

Since your contacts can come from a variety of sources, the Contacts app

attempts to join new information with existing similar contact entries, to

create a single entry. You can also manage that process manually by joining

or splitting entries.

To add a new contact

1. Open the Contacts app.

2. Tap the New contact icon

(to the right of the search box).

3. If you have more than one account with contacts, select the account

Communication

where you want to save the contact by tapping the Accounts ﬁeld (at

the top of the screen).

NOTE To change the account later, edit the entry, tap the account (at the top of the screen),

then tap the account you want it assigned to.

4. Enter the contact’s name.

5. Tap a category of contact information, such as phone number or email

address, to enter that kind of information about your contact.

Tap a category’s Add new icon

to add more than one entry for that

category. For example, in the phone number category, enter a work

number and add a home number. Tap the label ﬁeld to the right of the

entered information to open a drop-down menu of preset labels. For

example, HOME or WORK for a phone number.

Tap Add another ﬁeld

(at the bottom of the screen), to add

additional ﬁelds including Phonetic name, Organization, IM, Notes,

Nickname, Website, and Events.

6. Personalize the contact entry.

Set a ringtone to identify calls from this contact.

Set the color of the notiﬁcation LED (located at the upper-left corner

of your phone) to identify notiﬁcations from this contact.

Tap the Picture frame icon

to select a picture to identify the name

in your list of contacts and in other apps.

7. When you’re ﬁnished, tap Save.

Setting Speed Dial

1. Open the Contacts app, then tap the Menu icon (at the upper-right

corner of the screen).

2. Tap Speed dial.

3. Tap the speed dial number to assign.

4. Tap the Contact entry. If the contact has multiple phone numbers, tap

the one you want to set as a speed dial.

Communication

Messaging

Two apps are preloaded on your phone that allow you to send messages.

The Messaging app

and the Hangouts app . You can set any of these

as your default messaging app.

To open the Messaging app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Messaging .

NOTE You must set the Messaging app as the default messaging app in order to use it. From

the Home screen, tap the Apps icon

> Settings > General tab > Default

message app > Messaging.

Using the Messaging app

To use the Messaging features, open the Messaging app, tap the

information box (at the top of the screen) to set it as your default

messaging app, then Tap OK.

Tap the New message icon

(at the top right of the screen) to start a

new text or multimedia message.

Tap an existing message thread to open it.

NOTE Pinch in (or spread apart) on your list of messages to resize it for easier viewing or

navigation.

To delete a message thread from the Messaging window

1. Touch and hold the message thread.

2. Tap Delete in the Context menu that opens.

3. Tap Ye s to conﬁrm you want to delete the message thread.

To send a text message

1. Open the Messaging app (set it as your default messaging app, if

necessary), then tap the New message icon (at the top right of the

screen).

Communication

2. Enter the recipient(s) in the To box.

Tap the Contacts icon

(to the right of the To box), then select one

or more entries from your Contacts list.

Enter a name or number, then select a suggestion from your Contacts

list (displayed below the To box).

Enter a number manually for phone numbers not in your Contacts list.

3. Tap the text ﬁeld, then enter your message.

A character counter is displayed to the right of the message ﬁeld to let

you know how many more characters you can type and also the number

of pages in the message.

If you tap the Back Key

(in the Touch Keys bar) while composing a

message, it’s automatically saved as a draft. The Draft icon on the

right side of the message thread indicates a pending draft message to

the recipient. Tap the message to resume composing it.

4. Tap the Send button (on the right side of the screen) to send the

message.

Your message is displayed and responses appear in the same window,

creating a message thread with that contact.

The Email app allows you to read email form services other than Gmail. The

following account types are supported: Microsoft Exchange and other

accounts.

To open the Email app

From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > Email

or tap the Email icon directly from

the Home screen.

The ﬁrst time you open the Email app, a setup wizard opens to help you

add an email account. After the initial setup, the Email app displays the

contents of your Inbox.

Communication

The Accounts list

The Accounts list displays all of your email accounts.

Open the Email app. Tap the Accounts List icon

(at the top of the

screen) to display a drop-down list of all of your email accounts.

Each account in the Accounts list displays the number of unread mail.

Tap an account to view its Inbox.

Every account is categorized by a vertical color bar assigned to each

account. Each color bar is located on the left side of the account name at

accounts list.

NOTE Every emails are classiﬁed by a vertical color bar. The color bar has a same color for the

same account and is located on the left side of the each email message in the emails

list.

Using the Email app

Tap the Compose icon

(at the upper-right corner of the screen) to

compose a new message.

Tap the Accounts List icon

(at the top of the screen) to switch

between your email accounts.

Tap the checkbox next to a message, then you can tap Mark as read/

unread, Move to, or Delete (at the bottom of the screen).

Tap the Select all icon

(at the upper-left corner of the screen) to

select all of your messages. Then you can tap Mark as read/unread,

Move to, or Delete (at the bottom of the screen).

Tap the Favorite icon

next to an email message to designate it as an

important or favorite message.

Touch and hold an email entry to open a Context menu to access Reply,

Reply all, Forward, Delete, Move to, Mark as read/unread (read

messages have a gray background).

Tap the Menu icon

(at the upper-right corner of the screen) to open

the Options menu to access QSlide, Refresh, Folders, Sort by,

Downloads, and Settings.

Communication

Gmail

When you open the Gmail app, the most recent conversations are

displayed at the top of your Inbox list. All of your conversations are

displayed in your Inbox unless you delete, archive, or ﬁlter them.

To open the Gmail app

From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > Google folder

> Gmail or tap Google

folder

> Gmail on the Home screen.

Your Gmail Inbox

The current Google Account is displayed in the header at the top of the

Inbox. If you have more than one account, you can switch accounts to view

the messages in each Inbox.

Conversations with new messages are displayed with bold subject lines. To

read a message in a conversation, tap its subject line text.

A gray background indicates a read message.

The letter icon (or contact photo) next to a Gmail message allows you to

select it and choose an action from the icons at the top of the screen.

The Favorite icon

next to a Gmail message allows you to designate it as

a favorite message.

Gmail Inbox icons

Use the following icons (in the header at the top of the screen) while

viewing your Gmail Inbox:

Accounts and labels: Tap to change to another account or label,

access settings and help, or send feedback to Google.

Compose: Tap to begin a new Gmail message.

Search: Tap to search within your Gmail messages.

NOTE You can drag the screen downward to refresh and check for new email.

Communication

Hangouts

Use the Hangouts app to have real-time text conversations with your

friends.

To Open the Hangouts app

From the Home screen, tap Google folder

> Hangouts .

To sign out of Hangouts

From your chatting list, tap the Menu icon

(at the upper-right corner

of the screen) > Settings > tap your account > Sign out.

Chatting with Friends

1. From the Home screen, tap Google folder > Hangouts .

2. Tap the New icon

to view the contacts from all of the Google

Accounts you’ve added (at the top of the screen).

Tap the name of the person in your contacts list. If your friend is not

yet on Hangouts, your friend will receive an SMS inviting them to

Hangouts.

Tap the text ﬁeld to enter a name, email, number, or circle.

3. Enter your message.

NOTE Before you enter the text for your message, you can tap the Attach icon (to the right

of the message) to attach a photo, video, or location.

4. Tap the Send icon (on the right side of the message).

NOTE You can tap the call icon (at the top of the screen) to call the friend, or tap the video

icon

to start a video chat with your friend.

Camera and Video

You can use the Camera app to take and share pictures and videos. Your

phone comes with a 13 megapixel camera that lets you capture sharp

pictures and videos. It has many state-of-the-art features such as laser

auto-focus, dual camera mode, still photo capture while recording video,

and much more. These features will allow you to easily and creatively

capture your world.

NOTE Be sure to clean the protective lens cover with a microﬁber cloth before taking pictures.

A lens cover with smudges from ﬁngers can cause blurry pictures with a "halo" effect.

Class 10 microSD cards should be used for storing recorded HD/UHD videos in the

memory card.

To open the Camera app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Camera .

Tap Camera

from the Home screen.

With the backlight off, touch and hold the Volume Down Button

(on

the back of the phone).

TIP If you’ve set your phone to use the Swipe unlock method, from the Lock screen, simply

press the Power/Lock Button

(on the back of the phone), then drag the Camera

icon

upward to open the Camera app.

Entertainment

Getting to know the viewfinder

Lens Swap – Tap to swap between the rear camera lens and the front camera lens.

Record Button – Tap to start recording a video.

Capture Button – Tap to take a photo.

Back – Tap to close the current menu or exit the

Camera app.

Gallery – Tap to access your Gallery.

Flash – Tap to turn the ﬂash On , Off , or set it to Auto .

Options – Tap to display and hide the camera options on the screen.

Settings – Tap to adjust the camera and video settings.

Mode – Tap to set how the shot will be taken: Auto, Magic focus, Panorama, or Dual.

Taking Pictures

Taking pictures with your phone’s built-in camera is as simple as choosing a

subject, pointing the lens, and tapping a button icon. When you take a

picture, the Multi-point Auto-focus (AF) function operates automatically to

allow you to see a clear image.

To take a picture:

1. From the Home screen, tap Camera .

2. Frame your subject on the screen.

A square around the subject indicates that the camera has focused.

Place two ﬁngers on the screen and spread them apart to zoom in (a

zoom bar indicates the zoom level) and pinch in to zoom back out.

3. Tap the Capture button

. You can also just tap on the focus squares on

the screen or tap the subject to take the picture. Your picture will be

automatically saved to the Gallery.

NOTE The captured image retains the orientation in which it was taken. If you hold the phone

both vertically and horizontally to take pictures, you'll need to rotate the phone to view

full screen images in the Gallery app.

TIP While viewing a photo, you can tap the Menu icon

(at the upper-right corner of the

screen), then tap Rotate right/left to manually change its orientation.

Entertainment

Record Videos

In addition to taking pictures, you can record, view, and send videos with

your phone’s built-in video camera.

1. From the Home screen, tap Camera

2. Frame your subject on the screen.

3. Tap the Options icon

, then tap the Record button to start

recording the video.

The length of the recording is displayed at the upper-left corner of the

screen.

You can tap the Capture button

to take pictures while you’re

recording video.

You can use the pinch gesture to use the dynamic zoom feature while

you’re recording video. Spread your ﬁngers on the screen to zoom in

and pinch to zoom back out.

You can tap the Pause button

to pause your video recording. Then,

resume your recording by tapping the Record button

4. Tap the Stop button

to stop recording. Your video will be

automatically saved to the Gallery.

Camera and Video Settings

Open the Camera app, tap , then tap each of the following icons to

adjust the settings to your preferences.

NOTE Some settings will display an information pop-up the ﬁrst time you select icon.

Flash

: Tap to turn the ﬂash On , Off , or set it to Auto .

Lens swap

: Tap to swap between the rear camera lens and the front

camera lens.

Mode

: Tap to set the capture mode. Choose from Auto, Magic

focus, Panorama, and Dual.

Auto: Captures an auto photo shot.

Magic focus: Allows you to change the focus after taking a photo.

Entertainment

After taking the photo, tap the Thumbnail , tap an object or adjust

handler to change focus, then tap the Save

Panorama: Creates a wide photo of a panoramic view. Hold the

phone, tap the Capture button to start and slowly sweep the camera

across the scene.

Dual: Captures a photo or records a video using both the front and

rear camera lens at the same time. Touch and hold the small image

window to resize or move it.

Settings

: Tap to adjust the following camera and video settings.

Dynamic tone (HDR): Combines photos taken at multiple exposures

into one optimal photo to get a better photo in tricky lighting

situations.

Image/Video size: Sets the ﬁle size of your pictures and videos.

Choose from 13M 4160x3120, W10M 4160x2340, 9M 3120x3120,

and 3M 2048x1536 for pictures. Choose from UHD 3840x2160, FHD

1920x1080, HD 1280x720, and 120HD Slow Motion for videos.

Voice shutter: Allows you to take pictures with voice commands.

When On, you just say “Cheese”, “Smile”, “Whiskey”, “Kimchi”,

or “LG” to take a picture. Choose from On

or Off .

Timer: Sets your camera’s timer. This is ideal if you want to be a part

of the picture or video. Choose from Off

, 3 seconds , or 10

seconds

Grid: Sets an overlay grid on the viewﬁnder to help you take better

pictures and videos by allowing you to align your subject with the

horizontal or vertical lines. Choose from On

or Off .

Storage: Sets the storage location for your pictures and videos.

Choose IN (internal memory) or SD (memory card).

NOTE This option will be shown when you insert a microSD card into the phone.

Help: Displays a quick guide so you can learn how each camera

function works.

Entertainment

Gesture shot

The Gesture shot feature allows you to take a picture with a hand gesture

using the front camera.

To take a photo with a gesture

1. Activate the front camera lens.

2. Raise your hand, with an open palm, until the front camera detects it (a

box appears on the screen).

3. Make a ﬁst to start a countdown before the shot is taken (allowing you

time to position yourself).

NOTE You can also take a photo by making a ﬁst, then opening your palm.

8X Zooming

You can change the zoom level for your photos using the pinch-to-zoom

feature. Spread your ﬁngers on the screen to zoom in and pinch in to zoom

back out.

This feature gives you the ability to zoom up to 8 times the normal view.

NOTE Use a steady hand. This feature does not work with some functions. Objects can be

overlapped when taking a picture of fast-moving subjects.

View Your Pictures

The Gallery is where you can access your stored camera images. You can

view them in a slideshow, share them with your friends, as well as delete

and edit them.

1. From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Gallery .

Entertainment

2. Select an album and tap an image to view your picture.

Gallery Options

The Gallery app presents all of the pictures and videos stored in your

phone, including those you’ve taken with the Camera app and those you

downloaded from the web or other locations.

1. From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Gallery to view the images stored your

phone’s internal memory and on a MicroSD card (external storage).

Drag up or down to view more albums.

2. Tap an album to open it and view its contents. (The pictures and videos

in the album are displayed in chronological order.)

3. The following options are available.

Camera: Opens the Camera.

Share: Allows you to select one (or more) photos to share. Tap

Share (at the bottom of the screen) to open the available sharing

options (such as Messaging or Bluetooth).

Delete: Allows you to select one (or more) photos to delete. Tap

Delete (at the bottom of the screen) to delete the selected

picture(s).

Menu: Opens the albums Options menu which includes Move,

Copy, Make collage, Lock, Slideshow, Rotate left, and Rotate

right.

Tap a picture in an album then tap the Menu icon

(at the

upper-right corner of the screen) to open its Options menu which

includes the following options: SmartShare, Set image as, Move,

Copy, Copy to Clip Tray, Lock, Slideshow, Rotate left, Rotate

right, Crop, Add location, Rename, Print, and Details.

Tap a picture in an album, then tap the Favorite icon

(at the top

left of the picture) to mark it as a favorite.

Tap the Back Key

(in the Touch Keys bar) to return to the

previous screen.

Entertainment

Assign Pictures

After taking a picture, assign it as a picture ID for a Contacts entry or as the

background image (wallpaper) for your Home screen or Lock screen.

1. From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Gallery .

2. Tap an album and tap an image to view it.

3. With the picture displayed, tap the Menu icon

(at the upper-right

corner of the screen) > Set image as.

4. Select an option.

Contact photo to assign the picture to a Contact entry as a picture ID.

Tap an entry from Contacts, crop the image, then tap OK (at the

upper-left corner of the screen) to assign the picture.

Home screen wallpaper to assign the picture as a background

image, crop the image and tap OK to assign the picture.

Lock screen wallpaper to assign the picture as a background image

for your Lock screen.

Wallpaper to assign the picture as a background image, crop the

image and tap SET WALLPAPER to assign the picture.

Dual Mode Feature

The Dual Mode feature allows you to take a picture or record video with the

front and rear camera lens at the same time. A smaller image window

overlays the main image (similar to picture-in-picture). You can resize and

move the overlay image window, as well as swap the lens for either view.

1. From the Home screen, tap Camera

2. Tap the Mode icon

> the Dual icon .

Drag the overlay window to move it where you want it on the screen.

Touch and hold the overlay window to resize it.

Tap the overlay window to switch its lens.

Tap the Capture button

to take a dual photo.

Entertainment

Tap the Record button to record video, then tap the Stop button

to stop dual recording.

Video Options

The Gallery is where you can access your stored video images. You can

view them, share them with your friends, as well as delete and edit them.

1. From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Gallery to view the videos stored in your

phone’s internal memory, microSD card (external memory).

Scroll up or down to view more albums.

2. Tap an album to open it and view its contents. (The pictures and videos

in the album are displayed in chronological order.)

3. Tap a video to view it. You can access the following optins:

QSlide

: Enables an overlay on your phone’s display for easy

multitasking.

SmartShare

: Shares media ﬁles with DLNA certiﬁed devices.

: Tap to access Screen ratio, Subtitles, Share, Trim,

Settings, and Details.

Screen shot

: Captures a screen shot while playing a video.

NOTE Tap > Settings > Screenshot > On.

Volume : Tap to display the Volume slider bar, then adjust the

playback volume on the slider bar.

Lock/Unlock

: Locks the touch keys to prevent unintentional

touches.

Entertainment

NOTE While playing a video, slide the left side of the screen up or down to adjust the screen

brightness. You can also slide the right side of the screen up or down to adjust the

volume. Press the Volume Buttons(on the back of the phone) to adjust the volume.

While playing a video, tap the timeline point to preview that portion of the video via a

small screen. Tap the small screen to jump to that part of the video. While playing a

video, slide your ﬁnger from left to right (or vice versa) to fast-forward and rewind. The

recording retains the orientation in which it was taken. If you hold the phone both

vertically and horizontally to take pictures and record video, you'll need to rotate the

phone to view full screen images in the Gallery app.

To share a video

1. Open an album to view its contents, then tap the Share icon (at the

top of the Gallery screen).

2. Checkmark the video(s) you want to share, tap Share (at the bottom of

the screen), select how to share the ﬁle(s), then complete as necessary.

To delete a video

1. Open an album to view its contents, then tap the Delete icon (at the

top of the Gallery screen).

2. Checkmark the video(s) you want to delete, tap Delete (at the bottom of

the screen), then tap Yes to conﬁrm.

Live Zoom

Live Zoom allows you to zoom in or zoom out on a portion of a video while

it’s being played to make the desired section appear larger or smaller.

While viewing a video, use your index ﬁnger and thumb in a pinching or

spreading motion on the touchscreen to zoom in or out.

NOTE You don't need to press too hard; the touchscreen is sensitive enough to pick up a light,

but ﬁrm touch.

Entertainment

Dual Play

Dual Play connects two devices using a wired (Slimport-HDMI) cable or a

wireless connection (Miracast) allowing you to view content on a different

screen. The connectable device can be a TV or a monitor supported by an

HDMI cable or Miracast. Viewable content can come from the Gallery app

however not all videos are supported by Dual Play.

To start Dual Play, tap the Home Key

(in the Touch Key bar) once when

the two devices are connected and their displays are a different status (i.e.

the monitor is playing a video and your phone’s video app is displaying an

empty screen).

NOTE Dual Play operates at 1280X720 or higher display resolution.

Gallery

Open the Gallery app to view albums of your pictures and videos.

To open the Gallery app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Gallery .

Viewing your albums

The Gallery app presents all of the pictures and videos stored in your

phone, including those you’ve taken with the Camera app and those you

downloaded from the web or other locations. When another app saves a

picture, it automatically creates a download folder to contain the picture

(e.g., capturing a screen shot creates the Screenshot folder).

Tap an album to open it and view its contents.

Tap a picture or video in an album to view it.

Tap the Menu icon

(at the upper-right corner of the screen) to open

the Options menu to access New album, Delete, Hide/Show album,

Settings, and Help.

Tap the Camera icon

to return to the Camera app.

Tap Albums (in the upper-left corner of the screen) to open the Gallery

Entertainment

menu to access Albums, Favorites, Videos, All ﬁles, Nearby devices,

and Cloud.

To share an album

You can share the entire contents of one or more albums or individual

images or videos from an album.

1. From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Gallery .

2. Touch and hold the desired album, tap Share, select the app to use to

share your images, then complete the sending method as necessary.

Play Store

Play Store allows you to browse and search for free and paid apps.

To open the Play Store app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Play Store or tap Play Store on the

Home screen.

To get help with Play Store

Play Store Help web pages are available from all of the Play Store screens.

Tap

(at the upper-left corner of the screen), then tap Help & Feedback.

The Chrome app opens to the Play Store Help page, with links to many

help topics.

To open a screen with details about an app

At any time while browsing in Play Store, tap an app to open its details

screen.

The App details screens include a description, ratings, reviews,

comments, and related information about the app. From this screen, you

can download, install, uninstall, rate the app, and more.

Entertainment

Music

Transferring Music Files to Your Phone

The Music app plays audio ﬁles that are stored in your phone’s memory.

Copy audio ﬁles from your computer onto your phone before you open the

Music app.

NOTE The LG USB driver needs to be installed on your PC before connecting your phone to

transfer music.

To copy music files into your phone

1. Connect the phone to your computer with a USB Cable. If the default

connection mode is not set to Media device (MTP), open the

Notiﬁcations panel and tap the USB connection type, then tap Media

device (MTP). Your computer will prompt you with different actions to

take. Choose to open the folder to view ﬁles.

2. Use the computer to copy music and other audio ﬁles into the folder

that you created on the phone.

3. To disconnect your phone, open the Notiﬁcations panel and tap the USB

connection type, then tap Charge phone. Then disconnect the USB

Cable from the phone.

To play music

1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > Music .

2. Select a music category tab at the top of the Music Library screen.

3. Tap the song you want to play.

Entertainment

Music Player Control Icons

Tap here to restart, pause,

play, or skip.

Audio Effects Icon

Tap here to apply audio

effects to the song.

Volume Icon

Tap here the adjust the

Music Player volume.

Playback Screen

NOTE While viewing a list of tracks in an album, tap the Menu icon

(at the upper-right

corner of the screen), then tap Shufﬂe all to play all of the songs in the album in a

shufﬂed order.

To return to the Playback screen

From a Music playlist screen, tap the currently playing song at the

bottom of the screen.

From any other app, open the Notiﬁcations panel and tap the ongoing

music notiﬁcation.

To control playback

The Playback screen contains several icons that you can tap to control the

playback of songs, albums, and playlists:

Tap to pause playback.

Tap to resume playback.

Tap to skip to the next track in the album, playlist, or shufﬂe. Touch and hold to fast

forward.

Tap to restart the current track or skip to the previous track in the album, playlist, or

shufﬂe. Touch and hold to rewind.

Tap to display the Volume slider bar, then adjust the playback volume on the bar.

Tap to set audio effects.

Entertainment

Tap to open the Options menu. Choose from Search, Add to playlist, Delete, Share,

Set as ringtone, Music video, Details, Settings, and Help.

Tap to open the current playlist.

Tap to add the song to your favorites.

Tap to play the current playlist in shufﬂe mode (tracks are played in random order).

Tap to toggle through the repeat modes. Choose from Repeating all songs ,

Repeating current song

, and Repeat off .

Tap to share your music via the SmartShare function.

YouTube™

Opening YouTube and Watching Videos

You can browse, search for, view, upload, and rank YouTube videos on your

phone with the YouTube app.

To open the YouTube app

From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > YouTube

Search for and tap a video to watch it.

Tap the Menu icon

(at the upper-right corner of the screen) for the

YouTube Options menu (Settings, Help & feedback, and Sign in/out).

Tap the YouTube icon

(at the upper-left corner of the screen) to

access other YouTube options.

QSlide

The QSlide function enables an overlay window on your phone’s display for

easy multitasking. QSlide displays a small app window on the screen that

can be moved, resized, or made transparent. QSlide windows can be

opened from the QSlide apps bar on the Notiﬁcations panel, or directly

from the apps that support the QSlide function.

Entertainment

QSlide icons on the Notifications panel

QSlide app icons are displayed in a bar on the Notiﬁcations panel below the

Quick settings bar. These icons provide a quick, convenient way to multi-

task on the same screen (similar to picture-in-picture on a TV).

Tap to exit the QSlide function and view the app in full screen.

Slide to adjust the transparency.

Tap to exit the QSlide function.

NOTE The QSlide function can support up to two windows at the same time.

To open a QSlide window

Open the Notiﬁcations panel, tap , then tap the desired app in the QSlide

apps bar.

While using an app that supports QSlide, tap the QSlide icon

Using QSlide

The QSlide function opens the associated app in a window in the

foreground, allowing you to access other apps in the background. It’s

displayed continuously on the screen until you close it.

Entertainment

Drag the QSlide title bar to move it on the screen.

Drag the bottom right corner of the QSlide window to resize it.

Move the circle on the slider bar

to the left to make it transparent.

This will allow you to interact with items underneath the transparent

QSlide window. Move the slider back to the right to use the QSlide

window again.

Tap the QSlide icon

(at the upper-left corner of the title bar) to open

the app in full screen view. To go back to QSlide view, tap the QSlide

icon (at the top of the screen).

Tap the Close icon

(at the upper-right corner of the title bar) to close

the QSlide window.

Customizing the QSlide apps bar icons

You can set the order of the icons displayed in the QSlide apps bar, as well

as which icons are displayed.

1. Open the Notiﬁcations panel and swipe to the left on the QSlide apps

bar (if necessary), then tap the Edit icon

Drag one of the icon handles

at the right side of the screen to

move its icon to another position in the QSlide apps bar.

Checkmark the icons you want to display and remove the checkmark

for the ones you want to remove.

2. Tap the Back Key

(in the Touch Keys bar) to return to the Notiﬁcations

panel.

Dual window

The Dual window feature splits the screen to enable multi-tasking, drag and

drop interaction, auto-linking and recently used apps.

To activate the Dual window function

1. From the Home screen, touch and hold the Recent Apps Key (in the

Touch Keys bar) > System settings > General tab > Dual window.

2. Tap the Dual window switch

(at the top of the screen) to toggle it

On or Off.

Checkmark the Split view checkbox to automatically open the Dual

window function when you tap a link on the full screen or tap an email

attachment.

Using the Dual window function

1. Touch and hold the Back Key (in the Touch Keys bar) to split the

screen.

2. Tap the app icon you want to use. The ﬁrst app you tap opens in a

window at the top of the screen. The second app opens in the bottom

window.

3. Tap a window to select and use it.

A blue box appears around the selected window with a blue semi-

circle handle between the windows.

Drag the blue handle to change the window sizes (one larger and one

smaller).

4. Tap the blue handle

to access the Dual window options.

Tap the Swap icon

to switch (ﬂip) the app positions.

Tap the View app list icon

to redisplay the apps list so you can

change the app for the selected window.

Tap the Open full screen icon

to open the selected app in full

screen. Drag the blue handle (up or down depending on the selected

window) to return to Dual window.

Tools

Tap the Close icon to close the selected window.

QuickMemo+

The QuickMemo+ feature allows you to create memos and capture screen

shots. You can use QuickMemo+ to easily and efﬁciently create memos

during a call, with a saved picture, or on the current phone screen.

To create a memo

Drag the Status Bar downward, then tap the QuickMemo+ icon

the Quick Settings bar.

2. Use the memo

options at the top of

the screen (e.g., pen

type and color) to

create your memo.

3. When your memo is

complete, tap the Save

icon

(in the toolbar at

the top of the screen) to

save it to your Gallery or

QuickMemo+.

1. Drag the Status Bar

downward then tap the

QuickMemo+ icon

NOTE Please use a ﬁngertip (not your ﬁngernail or any other rigid object) while using the

QuickMemo+ feature to avoid scratching your phone's touchscreen.

Capturing a screen shot for your QuickMemo+

1. Access the screen you want to capture (for example, access the Maps

app to capture a street location to help with directions).

2. Drag the Status Bar down, then tap the QuickMemo+ icon

on the

Quick Settings Bar.

Tools

3. Use the toolbar options (at the top of the screen) to create your memo

on the captured screen.

4. Tap the Save icon

(in the upper-right corner of the screen), then

select to save it in the Gallery app or QuickMemo+ app.

Using QuickMemo+ toolbar options

The QuickMemo+ toolbar options (at the top of the screen) allow you to

easily create memos. Tap the memo options bar tab

to access the

QuickMemo+ toolbar icons, and tap it again to hide them.

Undo: Tap to undo the most recent action.

Redo: Tap to redo the most recently deleted action.

Text: Tap to type text in your memo.

Pen: Tap to select the pen type and color. Tap the memo background

to close the pen selection.

Erase: Tap to use the eraser to erase pen marks from the memo.

Save: Tap to save the memo you’ve created to your Gallery or

QuickMemo+ app.

Menu: Tap to share the memo with others via any of the available

apps or change the background paper style.

QuickMemo+ Menu Options

From the QuickMemo+ screen, tap the Menu icon

(at the upper-right

corner of the screen) to access Share and Paper style.

Tap Share, then compete the sharing method as necessary to share

your memo .

Tap Paper style to set the paper background for your memo, then tap

OK.

To Exit the QuickMemo+ feature

Tap the Back Key (in the Touch Keys bar) to exit the QuickMemo+

feature.

Tools

Viewing saved memos

Memos are saved in the Gallery app or QuickMemo+ app.

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Gallery , then tap the QuickMemo+ album.

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > the QuickMemo+ icon , then tap the your

memo.

Capturing a screen shot without using QuickMemo+

To capture a screen shot without the QuickMemo+ feature, press both the

Power/Lock Button

(on the back of the phone) and the Volume Down

Button (on the back of the phone) at the same time. The captured image is

automatically saved in the Gallery app in the Screenshots folder.

QuickRemote

QuickRemote turns your phone into a Universal Remote for your home TV,

set top box, and audio system.

NOTE QuickRemote may not be available for some devices.

To open the QuickRemote app and set up your QuickRemote

1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > QuickRemote .

2. Tap the room displayed at the upper-left corner of the screen to select

its location. Choose from Living room, Bedroom, Kitchen, Den, and

Ofﬁce.

3. Tap the Add icon

(at the top right of the screen).

4. Tap the device you want to set for the remote, then tap the name of the

device’s manufacturer.

Use the letters along the right side of the screen to jump directly to

that letter in the list.

5. Continue your remote set up by following the on-screen instructions to

conﬁgure the device.

Tools

NOTE It's important to point the IR (infrared) sensor on your phone directly at the device you

are conﬁguring.

Set up from the Notifications panel

You can also perform the initial set up of your QuickRemote from the

Notiﬁcations panel. Swipe the Status Bar downward, tap the QuickRemote

icon

(in the Quick Settings bar, if necessary), tap ADD REMOTE in the

dialog box, then continue set up as necessary.

After initial setup, to set up additional devices from the Notiﬁcations panel,

tap the Full-screen icon

(at the lower-right corner of the remote display),

then tap the Add icon

(at the top right of the QuickRemote screen).

Using QuickRemote

1. Swipe the Status Bar downward, then tap the QuickRemote icon (in

the Quick Settings bar, if necessary) to open a QuickRemote bar with all

of the remotes you set up.

2. Select the remote you want by tapping the remote name at the top of

the QuickRemote bar.

3. Tap the buttons on the displayed remote.

NOTES •Tap the Full-screen icon (at the lower-right corner of the remote display) to view the

QuickRemote in full screen.

•When adding a remote control for a TV, QuickRemote could use the INPUT button to

conﬁgure the appropriate remote control. When conﬁguring the INPUT button, the

input source for the TV could be changed. To reset the input source of your TV, tap the

INPUT button on the QuickRemote several times (depending on the number of devices

connected to the TV).

QuickRemote options

You can edit your QuickRemote bar by tapping the Edit icon (at the top

right of the QuickRemote bar. Drag a remote handle

to move it to

another position on the bar.

To access the QuickRemote Options menu, tap the Menu icon

(at the

upper-right corner of the screen) to select Magic Remote setting (only for

LG TVs), Edit remote name, Learn remote, Move remote, Delete

remote, Settings, and Help. Tap the Back Key

(in the Touch Keys bar) to

exit the Options menu.

Tools

Customizable remote

You can create your own personalized universal remote and choose where

to place all of the buttons.

1. From the Home screen tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > QuickRemote .

2. Tap the Add icon

(at the top right of the screen) > Universal remote.

3. Enter the Remote name, then tap OK.

4. Swipe to the left and right and place the buttons you want on the

remote in the desired locations, then tap Next (at the bottom of the

screen).

5. Program your customized remote using your original remote.

Face the IR sensors toward each other, about 4 inches apart.

Tap the button (on your customized remote) to learned.

Press and hold the corresponding button (on your original remote) for

two seconds.

Using the Magic Remote feature

Magic Remote controls the TV using a Touchpad and Smart Text (keyboard).

Magic Remote is compatible only with LG Smart TVs released in 2012 and

after.

1. Select the remote you want, then tap the Menu icon

(at the upper-

right corner of the screen) > Magic Remote setting.

2. Tap the Supported models button and check whether your TV supports

this feature.

Tools

3. Connect your phone and LG Smart TV to the same Wi-Fi network.

4. Select the device and enter the certiﬁcate number in your phone.

Touchpad: Moves the TV pointer with the touchpad.

Smart Text: Provides a keypad when typing text.

Calendar

Viewing Your Calendar

The Calendar app allows you to track your schedule of events (that you

created or that you’ve been invited to), organized by day, week, month,

year, or agenda.

When you ﬁrst set up your phone, you conﬁgured it to use an existing

Google Account or you created a new account. The ﬁrst time you open the

Calendar app on your phone, it displays any existing calendar events from

your Google Account on the web.

To open the Calendar app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Calendar .

Events from each account you’ve added to your phone and conﬁgured to

synchronize calendars is displayed in your Calendar.

Events from each calendar account are displayed in a different color.

To change your calendar view

No matter where you are in the Calendar app, you can easily switch

calendar views. Simply tap the upper left corner of the Calendar title bar to

display a drop-down menu of calendar views. Tap Day, Week, Month, Year,

or Agenda.

Calendar title bar icons

Tap the QSlide icon

to open the Month calendar view in a QSlide

window.

Tools

Tap the Current date icon

to immediately jump back to the current

date in the calendar you’re viewing.

Tap the Add icon

to add a new event to any of your accounts.

Calculator

The Calculator app allows you to perform mathematical calculations using a

standard calculator or a scientiﬁc calculator.

To open and use the Calculator

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Calculator .

Tap the calculator keys to enter numbers and arithmetic operators on the

calculator’s display, just like you would use a normal calculator.

Tap the Delete Key

to delete the last number or operator you entered.

Tap the Clear Key

to clear the calculator’s display.

Tap anywhere within the calculator’s display to place the cursor within

the calculation.

Touch and hold the calculator’s display to open a Context menu where

you can copy what you’ve entered to use it in other apps. The context

menu can include: Select all, Copy, Cut, Paste, Clip Tray, and Text

Link.

To open the Scientiﬁc calculator, tap the Menu icon

(at the upper-right

corner of the screen), then tap Scientiﬁc calculator. To return to the

Basic calculator, tap the Menu icon (at the upper-right corner of the

screen), then tap Basic calculator.

Tap the Menu icon

(at the upper-right corner of the screen) >

Calculation history to view your previous calculations. You can tap an

entry to calculate it again or edit it.

Tap the QSlide icon

(at the top right of the screen) to use the

Calculator in a QSlide window.

Tools

Clock

You use the Clock app to access the Alarms, Timer, World clock, and

Stopwatch functions. Access these functions by tapping the tabs across

the top of the screen, or swiping horizontally across the screen.

To open the Clock app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Clock .

Setting and Activating Alarms

The Alarms tab allows you to set varying alarm clocks. You can set an alarm

by modifying an existing alarm or by adding a new one. After you’ve

created one or more alarms, you can easily activate or deactivate an alarm

by tapping its Alarm icon

to toggle it on (blue) or off (gray).

1. From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Clock .

2. Tap the Alarms tab (at the top of the screen), if necessary.

3. Tap the New alarm icon

(at the top of the screen) to add a new

alarm, tap an alarm time to modify that alarm, or tap a current alarm icon

(on the right side of the screen) to activate an existing alarm (blue

indicates it’s set).

To set an alarm

1. Open the Clock app, then access the Alarms tab.

NOTE The ﬁrst time you access your alarms (or when there are no alarms created), an alarm

image is displayed in the middle of the screen. Tap it to set up your ﬁrst alarm.

2. Tap the New alarm icon (at the top right of the screen) to create an

alarm, or tap an existing alarm to modify and set it.

3. Scroll the time wheel to set the alarm time (Hour and Minute) and the

time of day (AM or PM).

4. Tap the day(s) when you want the alarm to sound in the Repeat ﬁeld. If

you don’t tap the Repeat setting, the alarm sounds only the one day you

set it.

Tools

5. Tap Snooze duration to set the amount of time to wait before sounding

the alarm again if it's not dismissed. You can set the alarm to ring

repeatedly from 5 minutes up to 1 hour.

6. Tap Alarm with vibration to checkmark the setting and have the phone

vibrate, in addition to playing the alarm sound.

7. Tap Alarm sound to set the sound notiﬁcation. Tap Alarm tone or

Music, select the sound for the alarm, then tap OK. The ringtone plays

brieﬂy when you select it.

8. Slide the button on the Alarm volume slider to the right to increase the

alarm volume and to the left to decrease it. The alarm sound plays to

help you determine the volume you want.

9. Tap Auto app starter to set the app you want to automatically open

when you stop the alarm, then tap OK.

10. Tap Puzzle lock to checkmark the setting, which requires you to wake

up enough to solve a simple puzzle to dismiss the alarm.

11. Tap Memo to enter information about the alarm. For example, to identify

when to use it (e.g., class day).

12. When you’re ﬁnished, tap Save (at the bottom of the screen) to save

and activate the alarm.

Alarm Settings

To access the Alarm settings, from the Alarms tab, tap the Menu icon

(at the upper-right corner of the screen), then tap Settings. The Alarm

settings include Volume button behavior and Puzzle lock.

When the alarm sounds

Tap Dismiss to stop the alarm.

Tap Snooze to stop the alarm for the snooze duration you set. If set, use

the gesture feature of simply turning the phone over to stop or snooze

the alarm.

Tools

Setting the Timer

The Timer tab can be used to alert you with an audible signal when a set

amount of time has passed.

1. Open the Clock app, then select the Timer tab.

2. Set the time on the digital timer. Tap the Hour, Minute, and/or Second

ﬁeld(s) then enter the numbers as necessary.

NOTE If you don't need to change the Timer settings, just tap the green Start button on the

time keypad to start the timer immediately.

3. Tap the Menu icon (at the upper-right corner of the screen) >

Settings to set Vibration, Alert sound, and Alert volume for the timer.

4. Tap the green Start button (at the bottom of the screen) to begin the

time countdown.

5. Once the alarm sounds, tap the red Stop button (at the bottom of the

screen) to stop the timer.

Setting the World Clock

The World clock tab allows you to set up a list of cities to easily check

current times in other time zones with a quick glance.

1. Open the Clock app, then select the World clock tab.

2. Tap the New city icon

(at the upper-right corner of the screen), search

through the available cities, then tap the one you want.

NOTE The ﬁrst time you access the World clock tab, a globe image is displayed in the middle

of the screen. Tap it to add the ﬁrst city to your list.

Using the Stopwatch

The Stopwatch tab allows you to use your phone as a Stopwatch.

1. Open the Clock app, then select the Stopwatch tab.

2. Tap the green Start button (at the bottom of the screen) to start timing

and tap the red Stop button to stop the time.

You can use the Lap function by tapping the Lap button to record

multiple milestone times within the same timing session.

Tools

3. Tap the Reset button to reset the Stopwatch or tap the green Resume

button to continue monitoring time.

Voice Command

You can use the Voice Command app to perform phone functions using

your voice.

To open the Voice Command app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

App tab (if necessary) > Voice Command .

Voice Search

You can also use the Voice Search app to perform phone functions using

your voice.

To open the Voice Command app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

App tab (if necessary) > Google folder > Voice Search .

Voice Recorder

The Voice Recorder app records audible ﬁles for you to use in a variety of

ways. Use them to simply remind you about something you don’t want to

forget (like a grocery list) or record sound effects that you can attach to a

message.

Record a Voice Memo

1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > Voice Recorder .

2. Tap the Record button

(at the bottom center of the screen) to start

recording.

3. Speak into the microphone.

Tools

4. When you’re ﬁnished, tap the Stop button (at the bottom right of the

screen).

The recording is automatically saved to your recordings list.

File Manager

Use the File Manager app to manage your folders and ﬁles stored in your

phone.

File Manager makes it easy to view and manage your ﬁles. Simply tap a ﬁle

type (All ﬁles, Music ﬁles, Image ﬁles, Video ﬁles, Document ﬁles, or Cloud

storage), then tap on the necessary folders to ﬁnd your ﬁles.

To open the File Manager app

From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > File Manager

File Manager Options

Open the File Manager app, tap All ﬁles, then tap the Internal storage or

SD card folder to access to the following File Manager options (at the

bottom of the screen):

: Allows you to create a new folder.

: Allows you to move ﬁles and folders to another folder.

: Allows you to copy ﬁles and folders to another folder.

: Allows you to delete ﬁles and folders.

: Allows you to access additional options.

Tools

Tasks

The Tasks app can be synchronized with your MS Exchange account. You

can create a task, revise it, and delete it using your phone, or from MS

Outlook or MS Ofﬁce Outlook Web Access.

To synchronize MS Exchange

1. From the Home screen, touch and hold the Recent Apps Key (in the

Touch Keys bar) > System settings > General tab > Accounts & sync

> Add account (under the Accounts section).

2. Tap Microsoft Exchange, then sign-in using your email address and

password.

3. Checkmark the Sync Tasks checkbox.

To add Tasks

1. From the Home screen, tap the Apps icon (in the QuickTap bar) > the

Apps tab (if necessary) > Tasks .

2. Tap the Add new task icon

(at the top of the screen).

3. Enter the Subject, Start date, Due date, Description, Repeat, and

Reminder.

4. Tap Save.

Settings

The Settings app contains most of the tools for customizing and conﬁguring

your phone. All of the settings in the Settings app are described in this

section.

To open the Settings app

From the Home screen, tap the Apps icon

(in the QuickTap bar) > the

Apps tab (if necessary) > Settings .

From the Home screen, touch and hold the Recent Apps Key

(in the

Touch Keys bar) > System settings.

Viewing Settings categories

The settings are grouped into categories.

List view displays each category (4) in capital letters followed by its

related settings. Scroll up and down through the screen.

Tab view displays each category (4) in tabs (at the top of the screen) that

include its related settings. Swipe to the left or right to switch between

tabs or tap a tab to select it.

1. From the Home screen, touch and hold the Recent Apps Key

(in the

Touch Keys bar) > System settings.

2. Tap the Menu icon

(at the upper-right corner of the screen) > Switch

to tab view (or Switch to list view).

NOTE Instructions to perform tasks in this guide are based on the default Tab view setting.

Networks

Airplane mode

Tap the Airplane mode switch to toggle it On or Off. On disables all

wireless connections.

Settings

Wi-Fi

Tap the Wi-Fi switch to toggle it On or Off. On connects to a Wi-Fi

network (from your list of available, detected networks). Tap Wi-Fi to

access the following settings to manage your Wi-Fi connection(s):

WI-FI NETWORKS

The list of all of the Wi-Fi networks that are within access range. Tap one to

access it.

Tap the Menu icon

(at the upper-right corner of the Wi-Fi menu screen)

to access the following options.

Add Wi-Fi: Tap to enter a Wi-Fi name (SSID), choose the Security and

enter the Password to manually add Wi-Fi networks.

Saved Wi-Fi: Tap to show the Wi-Fi networks you have saved.

Advanced Wi-Fi: Accesses the following advanced Wi-Fi settings.

Wi-Fi notiﬁcation: Checkmark to notify if Wi-Fi networks are available

nearby or when your device is connected to a Wi-Fi network.

Sort list by: Sets how your Wi-Fi networks are listed. Choose Signal

strength or Alphabetical order.

Keep Wi-Fi on when screen is off: Sets the Wi-Fi status when the

screen is off. Choose from Yes, Only when plugged in, and No.

Allow Wi-Fi scanning: Checkmark to let Google’s location service and

other apps scan for networks, even when Wi-Fi is off.

Switch to mobile data: Checkmark to switch automatically to mobile

data when internet unavailable via Wi-Fi.

Wi-Fi Direct: Allows direct connection with Wi-Fi devices without any

access point.

Connect by WPS button: Information to connect to a secured Wi-Fi

network with a WPS button.

Connect by WPS PIN: Information to connect to a secured Wi-Fi

network with a WPS PIN.

Install certiﬁcates: Allows you to install certiﬁcates from storage.

Settings

MAC address: Displays your phone’s MAC address (which may need to

be entered in the router to connect to some wireless networks with

MAC ﬁlters).

IP address: Displays your phone’s IP address.

Interactive tutorial: Displays information about the Wi-Fi features and

settings in an interactive tutorial.

NOTE Tap Search (at the bottom of the screen) to search for in-range Wi-Fi networks.

Bluetooth

Tap the Bluetooth switch to toggle it On or Off. On allows you to pair

and connect with other Bluetooth devices. Turn it on and tap Bluetooth to

use and manage your Bluetooth devices.

G3: Checkmark to allow other Bluetooth devices to see your phone for

pairing and connection.

AVAILABLE DEVICES

The list of all of the available in-range Bluetooth devices.

NOTE Tap Search for devices (at the bottom of the screen) to search for in-range Bluetooth

devices.

Mobile data

Tap the Mobile data switch to toggle it On or Off. Off disconnects you

from the mobile network so you can't use the Internet unless you use a

Wi-Fi connection. This allows you to manage your mobile data usage. Tap

Mobile data to access the following settings to manage your mobile data

usage:

Limit mobile data usage Checkmark to limit your mobile data. Your

mobile data connection will be disabled when you reach the limit you

set. Set your data usage limit by dragging the red line on the graph

provided.

Data usage cycle: Displays your current data usage cycle. Tap the date

to change the cycle date.

Data usage graph: Displays your data usage on a graph.

Settings

Data usage applications: Apps are displayed with their data usage on a

bar graph. Tap one to see more detailed information.

Call

Voicemail: Sets up your standard voicemail settings.

Auto retry: Sets the amount of time to wait before automatically

redialing a call that failed to connect. Choose from Off, 10 sec, 30 sec,

and 60 sec.

Incoming voice call pop-up: Checkmark to display an an incoming call

pop-up when an app is in use. Use the pop-up to Answer, Decline, or

Decline with message.

Decline with message: Sets the Ignore with message icon on the

Incoming Call screen which allows you to ignore an incoming call and

respond to the caller with a speciﬁed Quick text message instead. Tap to

manage your Quick text messages. Tap the New icon

to create a

new quick message, tap a message to edit it, or tap the Delete icon

to delete a message.

Privacy keeper: Sets whether the phone displays the caller’s information

when you receive a call. Choose from Hide all info., Show number

only, and Show caller info.

Auto answer: Allows you to answer calls automatically when using

hands-free mode.

TTY mode: Sets the TTY mode to communicate with other TTY devices.

Hearing aids: Tap to place the checkmark to turn on hearing aid

compatibility.

Voice enhancement: Checkmark to enhance voice clarity in noisy

environments, allowing you to hear more clearly.

Save unknown numbers: Allows you to save unknown numbers to

your contacts after a call.

Power key ends call: Checkmark to allow you to end voice calls by

pressing the Power/Lock Button

(on the back of the phone) instead

of returning to the Call screen to end the call.

Settings

DTMF tones: Sets the length of the DTMF tones. Choose Normal or

Long.

Call restrictions: Allows you to restrict incoming or outgoing calls.

Call duration: Tap to check call duration(s).

Voice privacy: Checkmark to enable enhanced privacy mode.

Share & connect

NFC: Tap the NFC switch to toggle it On or Off. On allows you to

send or receive ﬁles simply by bringing your phone and another data-

compatible device together (typically within 20 mm of each other) at the

NFC touchpoint. NFC (Near Field Communication) establishes radio

communication between smartphones and similar devices. NFC will be

turned off automatically when airplane mode activated. Tap NFC to

access the following settings:

Tap & pay: When NFC is turned on, you can use the Tap & pay

feature to pay for items just by touching your phone to a reader at a

Tag reading: When reading a tag via NFC, you can hear the alert

sound.

Android Beam: Tap the Android Beam switch

to toggle it On or Off.

On allows you to beam app content or ﬁles to other mobile devices by

holding them close together. Tap Android Beam to view information on

how to use this feature.

SmartShare Beam: Allows you to receive multimedia content via

SmartShare Beam from another LG phone or tablet.

Media server: Tap to share media content with nearby device via DLNA.

Miracast: Tap the Miracast switch

to toggle it On or Off. On allows

you to wirelessly mirror your phone screen and sound onto a Miracast

dongle or TV. Tap Miracast to access your list of available devices. Tap

Search for devices or Help (at the bottom of the screen) to refresh the

device list or view help information.

Settings

Tethering & networks

Tethering allows you to connect other devices to your phone’s internet

connection and select your connection method.

USB tethering: Tap the USB tethering switch

to toggle it On or Off.

On allows you to share your phone’s mobile data connection using a

USB connection. This setting is grayed-out if not connected via USB.

Wi-Fi hotspot: Tap the Wi-Fi hotspot switch

to toggle it On or Off.

On allows you to use your device as a Wi-Fi hotspot for other devices to

use your mobile network connection. Tap Wi-Fi hotspot to manage

access to your Wi-Fi hotspot. Connected devices are listed at the bottom

of the screen.

Help: Displays information regarding USB tethering and Wi-Fi hotspot.

Mobile networks: Sets up options for mobile data, data roaming,

network mode, and CDMA roaming mode.

VPN: Sets up and manages Virtual Private Networks (VPNs).

NOTE Tap the Menu icon (at the upper-right corner of the screen) to access additional

settings. From the VPN setting, it accesses Always-on VPN.

Sound

Sound proﬁle: Sets the Silent mode to Sound, Vibrate only, or Do not

disturb.

Volume: Sets individual volume levels for phone Ringtone, Notiﬁcation

sound, Touch feedback & system, and Music, video, games, and other

media. Move the slider button on each volume bar to set its volume.

Vibrate strength: Allows you to set the vibration strength for calls,

notiﬁcations, and touch feedback.

Ringtone: Sets the ringtone for calls. You can also add a ringtone by

tapping the New icon

(at the upper-right corner of the screen).

Notiﬁcation sound: Sets the sound for notiﬁcations. You can also add a

notiﬁcation sound by tapping the New icon

(at the upper-right corner

of the screen).

Sound with vibration: Checkmark to set the phone to vibrate in addition

to the ringtone when you receive calls.

100

Settings

Vibration type: Sets the incoming call vibration options. Choose from

Long Lasting, Rapid, Short repeated, Standard, and Ticktock. Tap the

New icon (at the upper-right corner of the screen) to create your own

vibration pattern.

Do not disturb: Allows you to set a schedule when to prevent

interruptions from notiﬁcations. You can set to allow certain features to

interrupt when Priority only is set.

Lock screen: Allows you to choose if you want to show or hide

notiﬁcations on the lock screen.

Apps: Allows you to prevent apps from displaying notiﬁcations or set

apps to show notiﬁcations with priority when Do not disturb is set to

Priority only.

Vibrate on tap: Checkmark to vibrate when you touch the screen (e.g.,

touch keys and make selections).

Sound effects: Tap to set dial pad touch tones, touch sounds, screen

lock sound, or emergency tone.

Message/call voice notiﬁcations: Tap the Message/call voice

notiﬁcations switch

to toggle it On or Off. On allows your phone to

automatically read your incoming calls and/or messages out loud.

Checkmark Calls for caller information, Messages for sender

information, and Read messages for message content. You can also set

the readout language.

Display

Home screen

Select Home: Sets the layout of the Home screen. Choose Home

(standard Android layout) or EasyHome (simpliﬁed version for users less

familiar with Android navigation).

Smart Bulletin: Tap the Smart Bulletin switch

to toggle it On or Off.

On displays an additional Home screen panel with customized

information. Choose if you want to display LG Health and Smart Tips.

Wallpaper: Allows you to set the Home screen wallpaper. Choose from

Wallpaper gallery, Gallery, Live wallpapers, Multi-photo, and Photos.

101

Settings

Screen swipe effect: Allows you to set the effect used when you swipe

to change to another Home screen panel. Choose from Slide, Breeze,

Accordion, Panorama, Carousel, Layer, and Domino.

Allow Home screen looping: Checkmark to allow continuous Home

screen scrolling (loop back to the ﬁrst screen after the last screen).

Home backup & restore: Allows you to back up and restore your Home

screen app layouts and wallpapers.

Help: Displays help information regarding the Home screen.

Lock screen

Select screen lock: Sets how to secure your phone from unintentional

and/or unauthorized use. Choose from None, Swipe, Knock Code,

Pattern, PIN, and Password.

Smart Lock: Allows you to conﬁgure your phone to stay unlocked when

you have a trusted Bluetooth device connected to it, when it’s in a

familiar location, like your home or work, or when it recognizes your

face.

Screen swipe effect: Sets the screen swipe effect options. Choose

from Light particle, Vector circle, Mosaic, and Soda.

Wallpaper: Sets your Lock screen wallpaper. Select it from Gallery or

Wallpaper gallery.

Shortcuts: Allows you to change the shortcuts at the bottom of the

Swipe Lock screen.

Weather animation: Checkmark to show weather animation for your

current location or primary city set in Weather based on automatic data

updates.

Contact info for lost phone: Tap to show contact info on the Lock

screen in the event the phone is lost.

Lock timer: Sets the amount of time before the screen automatically

locks after the screen backlight turns off (times-out due to inactivity).

Power button instantly locks: Checkmark to instantly lock the screen

when the Power/Lock Button is pressed. This setting overrides the

Security lock timer setting.

102

Settings

Home touch buttons

Button combination: Drag the icons to rearrange the home touch

buttons.

Color: Sets the color for the home touch buttons.

Hide Home touch buttons: Choose to show or hide the home touch

buttons while using apps.

Font type

Sets the type of font used for the phone and menus.

Font size

Sets the size of the font displayed in the phone and menus.

Brightness

Adjust the screen brightness by using the slider. Tap Auto to set the

brightness to automatically change.

Notification LED

Select which type of notiﬁcations to display the LED light.

Auto-rotate screen

Set to switch orientation automatically when you rotate the phone.

Screen timeout

Set the time delay before the screen automatically turns off.

Smart screen

Checkmark to keep the screen from timing-out when the phone detects

your eyes looking at the screen.

Screen-off effect

Sets the effect seen when you turn off the screen. Choose from Retro TV,

Black hole, and Fade out.

103

Settings

Daydream

Tap the Daydream switch to toggle it On or Off. On allows the set

screensaver to be displayed when the phone is sleeping while docked and/

or charging. Choose Clock or Google Photos.

General

Language & input

Use the Language & input menu to select the language for the text on y

our phone and for conﬁguring the on-screen keyboard. You can also

manage your language dictionary for personal words that you’ve added.

Language: Sets the language to use on your device.

Default: Sets the default on-screen keyboard to use when entering text.

LG Keyboard: Checkmark to select the LG Keyboard to enter data.

Google voice typing: Checkmark to select Google voice typing to enter

data. Tap the Settings icon

to change the Google voice settings.

Voice Search: Sets voice search options.

Text-to-speech output: Sets the preferred speech engine and speech

rate (very slow to very fast). Also plays a short demonstration of speech

synthesis and displays the language status.

Pointer speed: Sets the pointer speed on a slide bar.

Location

Use the Location access menu to set your preferences for using and

sharing your location when you search for information and use location-

based apps, such as Maps.

Tap the Location switch

(at the upper-right corner of the screen) to

enable sharing of your location.

Accounts & sync

Use the Accounts & sync settings menu to add, remove, and manage your

Google and other supported accounts. You also use these settings to

104

Settings

control how and whether all applications send, receive, and sync data on

their own schedules and whether all applications can synchronize user data

automatically. Gmail, Calendar, and other applications may also have their

own settings to control how they synchronize data; see the sections on

those applications for details. Tap Add account to add new account.

Cloud

Using Content from the Cloud

You can use content from the cloud (i.e., Dropbox) in the Gallery and

Music apps.

Using the Cloud

NOTE The supported features may vary depending on the cloud Retrieving data may take some

time depending on the cloud.

1. Select Cloud in the Gallery and Music apps.

2. Select the cloud what you want to use and log in.

3. You can use the content of the cloud after logging in.

4. Set the cloud settings to select the app th use the cloud.

Accessibility

Improves accessibility for users who have impaired vision, hearing, or

reduced dexterity.

TalkBack: Tap the TalkBack switch

(at the upper-right corner of the

screen) to toggle it On or Off. On allows you to set up the TalkBack

function which assists people with impaired vision by providing verbal

feedback. Tap Settings (at the bottom of the screen) to adjust the

TalkBack settings.

When TalkBack is turned on, the touchscreen settings require the user

to ﬁrst tap an item they want to select, and then double tap the item

again in order to access this feature.

NOTE Passwords can be heard as they are entered when headsets are connected to the phone

unless settings are changed to read passwords aloud without a headset.

Font size: Sets the font size. Choose from Minimum, Small, Medium,

105

Settings

Large, Very large, and Maximum.

Invert colors: Checkmark to invert the screen color contrast for people

with difﬁculty perceiving colors.

Color adjustment: Tap the Color adjustment switch

(at the upper-

right corner of the screen) to toggle it On or Off. On allows you to adjust

contrast and hue by dragging your ﬁnger across the screen.

Touch zoom: Tap the Touch zoom switch

(at the upper-right corner

of the screen) to toggle it On or Off. On allows you to zoom in and out

by triple-tapping the screen.

Message/call voice notiﬁcations: Tap the Voice notiﬁcations switch

(at the upper-right corner of the screen) to toggle it On or Off. On allows

you to hear automatic spoken alerts for incoming calls and messages.

Calls: Checkmark to read caller information out loud.

Messages: Checkmark to read sender information out loud.

Read messages: Checkmark to read messages out loud.

Message/call voice notiﬁcations language: Tap to set Text-to-

speech output.

Screen shade: Checkmark to dim the screen’s backlight for a darker

contrast.

Accessibility shortcut: Open accessibility options quickly on any screen.

Text-to-speech output: Tap to customize text-to-speech (TTS) settings.

Audio type: Sets the audio type. Choose Mono or Stereo.

Sound balance: Routes the sound through both the right and left

channel when a headset is connected. To manually set the audio route,

move the slider on the sound balance slide bar to set it.

Notiﬁcation LED: Tap the Notiﬁcation LED switch

(at the upper-right

corner of the screen) to toggle it On or Off. On activates the LED light

for incoming calls and notiﬁcations.

Flash alerts: Checkmark to allow a ﬂash to blink for incoming calls and

notiﬁcations.

106

Settings

Call reject message: Checkmark to send a message customized for

those with hearing impairments when a call is rejected.

Turn off all sounds: Checkmark to turn off all sounds.

Captions: Tap the Captions switch

(at the upper-right corner of the

screen) to toggle it On or Off. On customizes caption settings for those

with hearing impairments. Set Language, Font size, and Caption style.

Touch feedback time: Sets the touch feedback. Choose from Short,

Medium, and Long.

Touch assistant: Provide a touch board with easy use for general

buttons or gestures to access in short. Tap the Touch assistant switch

to toggle it On or Off. On allows you to replace the hardware keys

with a Touch assistant board that is displayed on the touchscreen. Tap

the Touch assistant icon to be able to tap its Power button, Home

button, Volume down button, Volume up button, and the 1/2 (page)

button (Screen capture button, Accessibility button, Voice Mate

button, and Pinch button). Draw a “C” (“call”) on the board to

automatically display the Dial tab. Draw an “M” on the board to

automatically display the Messaging app. Draw a “W” (“web”) on the

board to automatically launch the Chrome app. Draw an “S” (“Settings”)

on the board to automatically display the settings app. Draw an “L”

(“Lock screen”) on the board to lock the screen. Draw an “e” (“Email”)

on the board to automatically display the Email app.

Screen timeout: Sets the screen timeout. Choose from 15 sec, 30 sec,

1 min, 2 min, 5 min, 10 min, 15 min, and Keep screen turned on.

Touch control areas: Tap the Touch control areas switch

(at the

upper-right corner of the screen) to toggle it On or Off. On allows you to

select an area of the screen to limit touch control. Press the Volume

Down Button and tap the Home Key at the same time to activate and

deactivate this feature.

Auto-rotate screen: Checkmark to allow the phone to rotate the screen

depending on the phone orientation (portrait or landscape).

Password voice conﬁmation: Checkmark so that your phone can read

passwords you enter.

Power key ends call: Checkmark so that you can end voice calls by

pressing the Power/Lock Button

(on the back of the phone). When

107

Settings

enabled, pressing the Power/Lock Button during a call does not lock the

screen.

Accessibility settings shortcut: Sets quick, easy access to selected

features when you triple-tap the Home Key

(in the Touch Keys bar).

Choose from Off, Show all, TalkBack, Invert colors, Touch assistant,

and Accessibility settings.

One-touch input: Checkmark to enable one-touch input. It allows each

ﬁnger touch to enter letter or character on the LG keyboard.

Switch Access: Set to control your device using conﬁgurable key

combinations.

One-handed operation

Dial keypad: Checkmark to enable you to move the dial keypad to the

right or left side of the touchscreen. Simply tap the arrow to move it to

one side or the other.

LG keyboard: Checkmark to enable you to move the keyboard to the

right or left side of the touchscreen. Simply tap the arrow to move it to

one side or the other.

Lock screen: Checkmark to enable you to move the PIN Lock screen

keypad to the right or left side of the touchscreen. Simply tap the arrow

to move it to one side or the other.

Help: Displays information regarding one-handed operation.

Shortcut key

Tap the Shortcut key switch (at the upper-right corner of the screen) to

toggle it On or Off. On allows quick access to apps by pressing and holding

the Volume Buttons (on the back of the phone) when the screen is off or

locked. Press and hold the Volume Up Button to access QuickMemo+.

Press and hold the Volume Down Button access the Camera app.

Security

Use the Security menu to conﬁgure how to help secure your phone and its

data.

108

Settings

Content lock: Select lock types to lock ﬁles in the Gallery app. Choose

Password or Pattern.

Encrypt phone: Allows you to encrypt data on the phone for security.

Each time you turn on your phone, a PIN or password will be required to

decrypt your data.

Encrypt SD card storage: Allows you to encrypt of decrypt external SD

card data. Encrypted data is not accessible to other devices.

Set up SIM card lock: Allows you to set a PIN to be required to use the

phone. You can also change the PIN after setting it.

Password typing visible: Checkmark to brieﬂy show each character of

the password as you type so that you can see what you enter.

Phone administrators: Displays the list of administrators, allowing you

to deactivate device administrators.

Unknown sources: Checkmark to allow installation of non-Play Store

apps.

Verify apps: Checkmark to disallow or warn before installation of apps

that may cause harm to your phone.

Storage type: Displays the current storage type for credentials (e.g.,

Hardware-backed).

Trusted credentials: Allows apps to access your phone’s encrypted

store of secure certiﬁcates, related passwords, and other credentials.

The screen has a System tab and a User tab. Credential storage is used

to establish some kinds of VPN and Wi-Fi connections. This setting is

dimmed if you haven’t set a password to secure your credential storage.

Install from storage: Allows you to install a secure certiﬁcate from

storage.

Clear credentials: Deletes all secure certiﬁcates and related credentials

and erases the secure storage’s own password. Your’re prompted to

conﬁrm you want to clear this data.

Trust agents: View or deactivate Trust agents, which allows you to

select which apps to use without having to unlock the screen.

109

Settings

Screen pin: This feature allows you to lock your device so that the

current user can only access the pinned app. This is useful for users with

children.

Guest mode

Use Guest mode when you let someone else use your phone. They’ll only

be able to use the apps that you’ve selected. Once you set it up, you can

easily put your phone in Guest mode by drawing a speciﬁed guest screen

lock on the Lock screen that you set, which is different from your normal

screen lock.

Guest mode: Tap the switch (at the upper-right corner of the screen) to

toggle Guest mode On or Off. On allows you to put your phone in Guest

mode from the Lock screen.

Allowed app: Tap to select the apps available in Guest mode.

Wallpaper: Sets the background (wallpaper) for your Guest mode Lock

screen.

Lock screen type: Tap to create the screen lock sequence for Guest

mode.

Help: Displays information regarding Guest mode.

Gestures

Answer an incoming call: During an incoming call, bring the phone to

your ear to answer the call. If the proximity sensor is covered by an item,

such as a phone case, it may cause incorrect action.

Fade out ringtone: You can set the phone to fade out the ringtone by

picking up it from the ﬂat surface during the incoming call. If proximity

sensor is covered by anything, such as a phone case, it may cause

incorrect action.

Silence incoming calls: You can set the phone to silence incoming calls

by just ﬂipping the phone.

Snooze or stop alarm: You can set the phone to snooze or stop the

alarm by just ﬂipping the phone.

Pause video: You can set the phone to pause the video by just ﬂipping

the phone.

110

Settings

Help: Allows you to view help information for the available gestures.

Motion sensor calibration: Improves the accuracy of the tilt and speed

of the sensor.

QuickCircle case

Select apps: Sets the apps that can be used directly in the case’s

window without opening the case.

Auto-unlock: Checkmark to automatically unlock the screen when you

open the case and the screen lock is set to swipe.

Help: Displays QuickCircle case information.

Dual window

Split view: Checkmark to automatically open the Dual window feature

when you tap a link on the full screen or tap an email attachment

(images only).

Help: Displays help information about using the Dual window feature.

Date & time

Auto-date & time: Checkmark to use the network-provided date and

time.

Auto-time zone: Checkmark to use the network-provided time zone.

Set date: Tap to manually set the date to use for your phone. This

setting is grayed-out when the Auto-date & time setting is

checkmarked.

Set time: Tap to manually set the time to use for your phone. This

setting is grayed-out when the Auto-date & time setting is

checkmarked.

Select time zone: Tap to select select a time zone other than the one

provided by the network. This setting is grayed-out when the Auto-time

zone setting is checkmarked.

Use 24-hour format: Checkmark to display the time using the 24-hour

time format (for example, 13:00 instead of 1:00 pm).

111

Settings

Select date format: Sets the format for displaying dates.

Storage

Use the Storage menu to monitor the used and available space in your

phone.

INTERNAL STORAGE

Total space: Displays the total amount of space in the phone’s memory.

It’s listed in Gigabytes and also on a colored bar graph with a color-

coordinated list of the apps as well as the amount of space they use.

Remaining memory space is gray-colored.

SD CARD

Total space: Displays the total amount of your external memory.

Available: Displays the amount of space available in your external

memory.

Mount/Unmount SD card: Allows your phone to recognize your

microSD card and release it to safely remove your microSD card.

Erase SD card: Erases all of the data stored on your microSD card.

Battery

The Battery charge information is displayed on a battery graphic along with

the percentage of the remaining charge and its status.

Touch the Battery charge icon to display the Battery use screen to see the

battery usage level and battery use details. It displays which components

and apps are using the most battery power. Tap one of the entries to see

more detailed information.

Smart cleaning

This menu shows the space in use and free space in your phone. Tap (at

the upper-right corner of the screen), then tap Settings to set the

notiﬁcation interval and idle time period. Tap a folder, then tap Clean (at the

bottom of the screen) to clear the ﬁles in that folder to optimize space.

112

Settings

Apps

Use the Application manager menu to view details about the apps installed

on your phone, manage their data, and force them to stop.

Swipe left and right to select one of the three tabs across the top of the

screen to view detailed information for DOWNLOADED, ON SD CARD,

RUNNING, and ALL apps. Tap an entry to view more information, tap Stop

(or Force stop), then OK to stop an app from running.

Default message app

This feature allows you to choose what application to use as your default

messaging application.

Backup & reset

This menu allows you to back up and/or erase your data.

Back up my data: Checkmark to backup app data, Wi-Fi passwords, and

other settings to Google servers.

Backup account: Sets the account to backup.

Automatic restore: Checkmark to allow the phone to automatically

restore backed up settings and data when an app is reinstalled on the

phone.

LG Backup service: Allows you to backup and restore your phone’s

data. You can also schedule backups.

Factory data reset: Allows you to erase all of the data on the phone.

Read the warning, then tap Reset phone at the bottom of the screen,

then tap Erase everything to conﬁrm.

Printing

Cloud Print: Tap the Cloud Print switch (at the top of the screen) to

toggle it On or Off. On searches for printers and allows you to select a

printer via the Cloud feature.

113

Settings

About phone

This menu allows you to manage your software updates and view various

information relating to your device.

Phone name: Tap to edit your phone name.

Update Center: Check updates for apps and software provided by LG

Electronics.

Network: Displays your Network, Signal strength, Mobile network type,

Service state, Roaming, Mobile network state, IP address.

Status: Displays your phone number, MIN, MEID HEX, MEID DEC, IMEI,

PRL Version, ICCID.

Battery: Displays Battery status, Battery level, and Battery use.

Hardware info: Display Model number, Up time, Wi-Fi MAC address,

Blutooth address.

Software info: Displays Android version, Baseband version, Kernel

version, Build number, Software version, and SCR version.

Legal info: Displays open source licenses, Google legal information, and

Legal Documents for LG Software.

Patent information: Displays LG patent information.

114

WARNING: This product contains chemicals known to the State of

California to cause cancer and birth defects or other reproductive harm.

Wash hands after handling.

TIA Safety Information

The following is the complete TIA Safety Information for wireless handheld

phones.

Exposure to Radio Frequency Signal

Your wireless handheld portable phone is a low power radio transmitter and

receiver. When ON, it receives and sends out Radio Frequency (RF) signals.

In August, 1996, the Federal Communications Commissions (FCC) adopted

RF exposure guidelines with safety levels for handheld wireless phones.

Those guidelines are consistent with the safety standards previously set by

both U.S. and international standards bodies:

ANSI C95.1 (1992) *

NCRP Report 86 (1986)

ICNIRP (1996)

*American National Standards Institute; National Council on Radiation

Protection and Measurements; International Commission on Non-

Ionizing Radiation Protection

Those standards were based on comprehensive and periodic evaluations of

the relevant scientiﬁc literature. For example, over 120 scientists,

engineers, and physicians from universities, government health agencies,

and industry reviewed the available body of research to develop the ANSI

Standard (C95.1).

The design of your phone complies with the FCC guidelines (and those

standards).

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized

antennas, modiﬁcations, or attachments could damage the phone and may

violate FCC regulations.

Safety

115

Safety

Phone Operation

NORMAL POSITION: Hold the phone as you would any other telephone

with the antenna pointed up and over your shoulder.

Tips on Efﬁcient Operation

For your phone to operate most efﬁciently:

Don’t touch the antenna unnecessarily when the phone is in use. Contact

with the antenna affects call quality and may cause the phone to operate at

a higher power level than otherwise needed.

Driving

Check the laws and regulations on the use of wireless phones in the areas

where you drive and always obey them. Also, if using your phone while

driving, please observe the following:

l Give full attention to driving -- driving safely is your ﬁrst responsibility;

l Use hands-free operation, if available;

l Pull off the road and park before making or answering a call if driving

conditions or the law require it.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However,

certain electronic equipment may not be shielded against the RF signals

from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends that a

minimum separation of six (6) inches be maintained between a handheld

wireless phone and a pacemaker to avoid potential interference with the

pacemaker. These recommendations are consistent with the independent

research by and recommendations of Wireless Technology Research.

Persons with pacemakers:

l Should ALWAYS keep the phone more than six (6) inches from their

pacemaker when the phone is turned ON;

116

Safety

l Should not carry the phone in a breast pocket;

l Should use the ear opposite the pacemaker to minimize the potential for

interference;

l Should turn the phone OFF immediately if there is any reason to suspect

that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the

event of such interference, you may want to consult your service provider

(or call the customer service line to discuss alternatives).

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of

your device to determine if it is adequately shielded from external RF

energy. Your physician may be able to assist you in obtaining this

information.

Health Care Facilities

Turn your phone OFF in health care facilities when any regulations posted in

these areas instruct you to do so. Hospitals or health care facilities may use

equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded

electronic systems in motor vehicles. Check with the manufacturer or its

representative regarding your vehicle. You should also consult the

manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

FCC regulations prohibit using your phone while in the air. Switch OFF your

phone before boarding an aircraft.

117

Safety

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in

a “blasting area” or in areas posted: “Turn off two-way radio”. Obey all

signs and instructions.

Potentially Explosive Atmosphere

Turn your phone OFF when in any area with a potentially explosive

atmosphere and obey all signs and instructions. Sparks in such areas could

cause an explosion or ﬁre resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always

marked clearly. Potential areas may include: fueling areas (such as gasoline

stations); below deck on boats; fuel or chemical transfer or storage

facilities; vehicles using liqueﬁed petroleum gas (such as propane or

butane); areas where the air contains chemicals or particles (such as grain,

dust, or metal powders); and any other area where you would normally be

advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

An air bag inﬂates with great force. DO NOT place objects, including either

installed or portable wireless equipment, in the area over the air bag or in

the air bag deployment area. If in-vehicle wireless equipment is improperly

installed and the air bag inﬂates, serious injury could result.

Safety Information

Please read and observe the following information for safe and proper use

of your phone and to prevent damage.

Violation of the instructions may cause minor or serious damage

to the product.

Charger and Adapter Safety

l The charger and adapter are intended for indoor use only.

l Insert the battery pack charger vertically into the wall power socket.

l Only use the approved battery charger. Otherwise, you may cause

118

Safety

serious damage to your phone.

l Use the correct adapter for your phone when using the battery pack

charger abroad.

Battery Information and Care

l Always unplug the charger from the wall socket after the phone is fully

charged to save unnecessary power consumption of the charger.

l Please read the manual of proper installation and removal of the battery.

l Please read the manual of speciﬁed charger about charging method.

l Do not damage the power cord by bending, twisting, or heating. Do not

use the plug if it is loose as it may cause electric shock or ﬁre. Do not

place any heavy items on the power cord. Do not allow the power cord

to be crimped as it may cause electric shock or ﬁre.

l Unplug the power cord prior to cleaning your phone, and clean the power

plug pin when it’s dirty. When using the power plug, ensure that it’s ﬁrmly

connected. If not, it may cause excessive heat or ﬁre. If you put your

phone in a pocket or bag without covering the receptacle of the phone

(power plug pin), metallic articles (such as a coin, paperclip or pen) may

short-circuit the phone. Always cover the receptacle when not in use.

l Recharge the battery after long periods of non-use to maximize battery

life. Battery life will vary due to usage pattern and environmental

conditions.

l Please use only an LG-approved charging accessory to charge your LG

phone. Improper handling of the charging port, as well as the use of an

incompatible charger, may cause damage to your phone and void the

warranty.

l Charging temperature range is regulated between 32°F (0°C) and 113°F

(45°C). Do not charge the battery out of recommended temperature

range. Charging out of recommended range might cause the generating

heat or serious damage of battery. And also, it might cause the

deterioration of battery’s characteristics and cycle life.

l Do not use or leave the battery under the blazing sun or in heated car by

sunshine. The battery may generate heat, smoke or ﬂame. And also, it

might cause the deterioration of battery’s characteristics or cycle life.

119

Safety

l The battery pack has protection circuit to avoid the danger. Do not use

nearby the place where generates static electricity more than 100V

which gives damage to the protection circuit. If the protection circuit

were broken, the battery would generate smoke, rupture or ﬂame.

l When the battery has rust, bad smell or something abnormal at ﬁrst-

time-using, do not use the equipment and go to bring the battery to the

shop which it was bought.

l In case younger children use the battery, their parents should teach

them how to use batteries according to the manual with care.

l If the skin or cloth is smeared with liquid from the battery, wash with

fresh water. It may cause the skin inﬂammation. Remove and do not use

the battery.

l Do not handle the phone with wet hands while it is being charged. It

may cause an electric shock or seriously damage your phone.

l Do not place or answer calls while charging the phone as it may short-

circuit the phone and/or cause electric shock or ﬁre.

l The charger and adapter are intended for indoor use only.

l Insert the battery pack charger vertically into the wall power socket.

l Only use the LG-approved battery charger. Otherwise, you may cause

serious damage to your phone and risk of overheating, ﬁre or explosion

may occur.

l Use the correct adapter for your phone when using the battery pack

charger abroad.

l Talking on your phone for a long period of time may reduce call quality

due to heat generated during use.

l Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or

detergents to clean your phone. This could cause a ﬁre. Do not place or

answer calls while charging the phone as it may short-circuit the phone

and/or cause electric shock or ﬁre. Don’t short-circuit the battery.

Metallic articles such as a coin, paperclip or pen in your pocket or bag

may short-circuit the + and – terminals of the battery (metal strips on the

battery) upon moving. Short-circuit of the terminal may damage the

battery and cause an explosion.

120

Safety

l Never use and unapproved battery since this could damage the phone

and/or battery and could cause the battery to explode. Only use the

batteries and chargers provided by LG. The warranty will not be applied

to products provided by other suppliers. Only authorized personnel

should service the phone and its accessories. Faulty installation or

service may result in accidents and consequently invalidate the warranty.

Explosion, Shock, and Fire Hazards

l Do not put your phone in a place subject to excessive dust and keep the

minimum required distance between the power cord and heat sources.

l Unplug the power cord prior to cleaning your phone, and clean the

power plug pin when it’s dirty.

l When using the power plug, ensure that it’s ﬁrmly connected. If not, it

may cause excessive heat or ﬁre.

l If you put your phone in a pocket or bag without covering the receptacle

of the phone (power plug pin), metallic articles (such as a coin, paperclip

or pen) may short-circuit the phone. Always cover the receptacle when

not in use.

l Don’t short-circuit the battery. Metallic articles such as a coin, paperclip

or pen in your pocket or bag may short-circuit the + and – terminals of

the battery (metal strips on the battery) upon moving. Short-circuit of the

terminal may damage the battery and cause an explosion.

General Notice

l Using a damaged battery or placing a battery in your mouth may cause

serious injury.

l Do not place items containing magnetic components such as a credit

card, phone card, bank book, or subway ticket near your phone. The

magnetism of the phone may damage the data stored in the magnetic

strip.

l Talking on your phone for a long period of time may reduce call quality

due to heat generated during use.

l When the phone is not used for a long period time, store it in a safe

place with the power cord unplugged.

121

Safety

l Using the phone in proximity to receiving equipment (i.e., TV or radio)

may cause interference to the phone.

l Do not use the phone if the antenna is damaged. If a damaged antenna

contacts skin, it may cause a slight burn. Please contact an LG

Authorized Service Center to replace the damaged antenna.

l Do not immerse your phone in water. If this happens, turn it off

immediately and remove the battery. If the phone does not work, take it

to an LG Authorized Service Center.

l Do not paint your phone.

l The data saved in your phone might be deleted due to careless use,

repair of the phone, or upgrade of the software. Please backup your

important phone numbers. (Ringtones, text messages, voice messages,

photos, and videos could also be deleted.) The manufacturer is not liable

for damage due to the loss of data.

l When you use the phone in public places, set the ringtone to vibration so

you don’t disturb others.

l Do not turn your phone on or off when putting it to your ear.

l Use accessories, such as earphones and headsets, with caution. Ensure

that cables are tucked away safely and do not touch the antenna

unnecessarily.

l Do not use your device for long periods of time while a part of your body

is making direct contact with it. The temperature of the product may

increase during normal operation and this may result in harming or

burning your skin.

Caution:

Avoid potential hearing loss.

Prolonged exposure to loud sounds (including music) is the most common

cause of preventable hearing loss. Some scientiﬁc research suggests that

using portable audio devices, such as portable music players and cellular

telephones, at high volume settings for long durations may lead to

permanent noise induced hearing loss. This includes the use of

122

Safety

headphones (including headsets, earbuds and Bluetooth

or other wireless

devices). Exposure to very loud sound has also been associated in some

studies with tinnitus (a ringing in the ear), hypersensitivity to sound and

distorted hearing. Individual susceptibility to noise-induced hearing loss and

other potential hearing problems varies.

The amount of sound produced by a portable audio device varies depending

on the nature of the sound, the device, the device settings and the

headphones. You should follow some commonsense recommendations

when using any portable audio device:

l Set the volume in a quiet environment and select the lowest volume at

which you can hear adequately.

l When using headphones, turn the volume down if you cannot hear the

people speaking near you or if the person sitting next to you can hear

what you are listening to.

l Do not turn the volume up to block out noisy surroundings. If you choose

to listen to your portable device in a noisy environment, use noise-

cancelling headphones to block out background environmental noise.

l Limit the amount of time you listen. As the volume increases, less time

is required before your hearing could be affected.

l Avoid using headphones after exposure to extremely loud noises, such as

rock concerts, that might cause temporary hearing loss. Temporary

hearing loss might cause unsafe volumes to sound normal.

l Do not listen at any volume that causes you discomfort. If you

experience ringing in your ears, hear mufﬂed speech or experience any

temporary hearing difﬁculty after listening to your portable audio device,

discontinue use and consult your doctor.

You can obtain additional information on this subject from the following

sources:

American Academy of Audiology

11730 Plaza American Drive, Suite 300

Reston, VA 20190

123

Safety

Voice: (800) 222-2336

Email: info@audiology.org

Internet: www.audiology.org

National Institute on Deafness and Other Communication

Disorders

National Institutes of Health

31 Center Drive, MSC 2320

Bethesda, MD USA 20892-2320

Voice: (301) 496-7243

Email: [email protected]

Internet: http://www.nidcd.nih.gov/health/hearing

National Institute for Occupational Safety and Health

Hubert H. Humphrey Bldg.

200 Independence Ave., SW

Washington, DC 20201

Voice: 1-800-35-NIOSH (1-800-356-4674)

Internet: http://www.cdc.gov/niosh/topics/noise/default.html

124

Safety

FDA Consumer Update

The U.S. Food and Drug Administration’s Center for Devices

and Radiological Health Consumer Update on Mobile

Phones:

1. Do wireless phones pose a health hazard?

The available scientiﬁc evidence does not show that any health problems are

associated with using wireless phones. There is no proof, however, that

wireless phones are absolutely safe. Wireless phones emit low levels of Radio

Frequency (RF) energy in the microwave range while being used. They also

emit very low levels of RF when in standby mode. Whereas high levels of RF

can produce health effects (by heating tissue), exposure to low level RF that

does not produce heating effects causes no known adverse health effects.

Many studies of low level RF exposures have not found any biological effects.

Some studies have suggested that some biological effects may occur, but such

ﬁndings have not been conﬁrmed by additional research. In some cases, other

researchers have had difﬁculty in reproducing those studies, or in determining

the reasons for inconsistent results.

2. What is the FDA’s role concerning the safety of wireless phones?

Under the law, the FDA does not review the safety of radiation-emitting

consumer products such as wireless phones before they can be sold, as it

does with new drugs or medical devices. However, the agency has

authority to take action if wireless phones are shown to emit Radio

Frequency (RF) energy at a level that is hazardous to the user. In such a

case, the FDA could require the manufacturers of wireless phones to notify

users of the health hazard and to repair, replace, or recall the phones so

that the hazard no longer exists.

Although the existing scientiﬁc data does not justify FDA regulatory actions,

the FDA has urged the wireless phone industry to take a number of steps,

including the following:

l Support needed research into possible biological effects of RF of the

type emitted by wireless phones;

l Design wireless phones in a way that minimizes any RF exposure to the

125

Safety

user that is not necessary for device function; and

l Cooperate in providing users of wireless phones with the best possible

information on possible effects of wireless phone use on human health.

The FDA belongs to an interagency working group of the federal agencies

that have responsibility for different aspects of RF safety to ensure

coordinated efforts at the federal level. The following agencies belong to

this working group:

l National Institute for Occupational Safety and Health

l Environmental Protection Agency

l Occupational Safety and Health Administration

l National Telecommunications and Information Administration

The National Institutes of Health participates in some interagency working

group activities, as well.

The FDA shares regulatory responsibilities for wireless phones with the

Federal Communications Commission (FCC). All phones that are sold in the

United States must comply with FCC safety guidelines that limit RF

exposure. The FCC relies on the FDA and other health agencies for safety

questions about wireless phones.

The FCC also regulates the base stations that the wireless phone networks

rely upon. While these base stations operate at higher power than do the

wireless phones themselves, the RF exposures that people get from these

base stations are typically thousands of times lower than those they can

get from wireless phones. Base stations are thus not the subject of the

safety questions discussed in this document.

3. What kinds of phones are the subject of this update?

The term “wireless phone” refers here to handheld wireless phones with

built-in antennas, often called “cell”, “mobile”, or “PCS” phones. These

types of wireless phones can expose the user to measurable Radio

Frequency (RF) energy because of the short distance between the phone

and the user’s head.

These RF exposures are limited by FCC safety guidelines that were

126

Safety

developed with the advice of the FDA and other federal health and safety

agencies. When the phone is located at greater distances from the user,

the exposure to RF is drastically lower because a person’s RF exposure

decreases rapidly with increasing distance from the source. The so-called

“cordless phones,” which have a base unit connected to the telephone

wiring in a house, typically operate at far lower power levels, and thus

produce RF exposures far below the FCC safety limits.

4. What are the results of the research done already?

The research done thus far has produced conﬂicting results, and many

studies have suffered from ﬂaws in their research methods. Animal

experiments investigating the effects of Radio Frequency (RF) energy

exposures characteristic of wireless phones have yielded conﬂicting results

that often cannot be repeated in other laboratories. A few animal studies,

however, have suggested that low levels of RF could accelerate the

development of cancer in laboratory animals. However, many of the studies

that showed increased tumor development used animals that had been

genetically engineered or treated with cancer-causing chemicals so as to be

pre-disposed to develop cancer in the absence of RF exposure. Other

studies exposed the animals to RF for up to 22 hours per day. These

conditions are not similar to the conditions under which people use

wireless phones, so we do not know with certainty what the results of

such studies mean for human health. Three large epidemiology studies

have been published since December 2000. Between them, the studies

investigated any possible association between the use of wireless phones

and primary brain cancer, glioma, meningioma, or acoustic neuroma,

tumors of the brain or salivary gland, leukemia, or other cancers. None of

the studies demonstrated the existence of any harmful health effects from

wireless phone RF exposures. However, none of the studies can answer

questions about long-term exposures, since the average period of phone

use in these studies was around three years.

5. What research is needed to decide whether RF exposure from

wireless phones poses a health risk?

A combination of laboratory studies and epidemiological studies of people

actually using wireless phones would provide some of the data that are

127

Safety

needed. Lifetime animal exposure studies could be completed in a few

years. However, very large numbers of animals would be needed to provide

reliable proof of a cancer promoting effect, if one exists. Epidemiological

studies can provide data that is directly applicable to human populations,

but ten or more years follow-up may be needed to provide answers about

some health effects, such as cancer. This is because the interval between

the time of exposure to a cancer-causing agent and the time tumors

develop - if they do - may be many, many years. The interpretation of

epidemiological studies is hampered by difﬁculties in measuring actual RF

exposure during day-to-day use of wireless phones. Many factors affect

this measurement, such as the angle at which the phone is held, or which

model of phone is used.

6. What is the FDA doing to ﬁnd out more about the possible

health effects of wireless phone RF?

The FDA is working with the U.S. National Toxicology Program and with

groups of investigators around the world to ensure that high priority animal

studies are conducted to address important questions about the effects of

exposure to Radio Frequency (RF) energy.

The FDA has been a leading participant in the World Health Organization

International Electro Magnetic Fields (EMF) Project since its inception in

1996. An inﬂuential result of this work has been the development of a

detailed agenda of research needs that has driven the establishment of

new research programs around the world. The project has also helped

develop a series of public information documents on EMF issues.

The FDA and the Cellular Telecommunications & Internet Association (CTIA)

have a formal Cooperative Research And Development Agreement

(CRADA) to do research on wireless phone safety. The FDA provides the

scientiﬁc oversight, obtaining input from experts in government, industry,

and academic organizations. CTIA-funded research is conducted through

contracts with independent investigators. The initial research will include

both laboratory studies and studies of wireless phone users. The CRADA

will also include a broad assessment of additional research needs in the

context of the latest research developments around the world.

128

Safety

7. How can I ﬁnd out how much Radio Frequency energy exposure

I can get by using my wireless phone?

All phones sold in the United States must comply with Federal

Communications Commission (FCC) guidelines that limit Radio Frequency

(RF) energy exposures. The FCC established these guidelines in

consultation with the FDA and the other federal health and safety agencies.

The FCC limit for RF exposure from wireless phones is set at a Speciﬁc

Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC limit

is consistent with the safety standards developed by the Institute of

Electrical and Electronic Engineering (IEEE) and the National Council on

Radiation Protection and Measurement. The exposure limit takes into

consideration the body’s ability to remove heat from the tissues that absorb

energy from the wireless phone and is set well below levels known to have

effects. Manufacturers of wireless phones must report the RF exposure

level for each model of phone to the FCC. The FCC website (http://www.

fcc.gov/cgb/cellular.html) gives directions for locating the FCC identiﬁcation

number on your phone so you can ﬁnd your phone’s RF exposure level in

the online listing.

8. What has the FDA done to measure the Radio Frequency energy

coming from wireless phones?

The Institute of Electrical and Electronic Engineers (IEEE) is developing a

technical standard for measuring the Radio Frequency (RF) energy

exposure from wireless phones and other wireless handsets with the

participation and leadership of FDA scientists and engineers. The standard,

“Recommended Practice for Determining the Spatial-Peak Speciﬁc

Absorption Rate (SAR) in the Human Body Due to Wireless

Communications Devices: Experimental Techniques”, sets forth the ﬁrst

consistent test methodology for measuring the rate at which RF is

deposited in the heads of wireless phone users. The test method uses a

tissue-simulating model of the human head. Standardized SAR test

methodology is expected to greatly improve the consistency of

measurements made at different laboratories on the same phone. SAR is

the measurement of the amount of energy absorbed in tissue, either by the

whole body or a small part of the body. It is measured in watts/kg (or

129

Safety

milliwatts/g) of matter. This measurement is used to determine whether a

wireless phone complies with safety guidelines.

9. What steps can I take to reduce my exposure to Radio

Frequency energy from my wireless phone?

If there is a risk from these products - and at this point we do not know that

there is - it is probably very small. But if you are concerned about avoiding even

potential risks, you can take a few simple steps to minimize your exposure to

Radio Frequency (RF) energy. Since time is a key factor in how much exposure a

person receives, reducing the amount of time spent using a wireless phone will

reduce RF exposure. If you must conduct extended conversations by wireless

phone every day, you could place more distance between your body and the

source of the RF, since the exposure level drops off dramatically with distance.

For example, you could use a headset and carry the wireless phone away from

your body or use a wireless phone connected to a remote antenna. Again, the

scientiﬁc data does not demonstrate that wireless phones are harmful. But if you

are concerned about the RF exposure from these products, you can use

measures like those described above to reduce your RF exposure from wireless

phone use.

10. What about children using wireless phones?

The scientiﬁc evidence does not show a danger to users of wireless

phones, including children and teenagers. If you want to take steps to

lower exposure to Radio Frequency (RF) energy, the measures described

above would apply to children and teenagers using wireless phones.

Reducing the time of wireless phone use and increasing the distance

between the user and the RF source will reduce RF exposure.

Some groups sponsored by other national governments have advised that

children be discouraged from using wireless phones at all. For example, the

government in the United Kingdom distributed leaﬂets containing such a

recommendation in December 2000. They noted that no evidence exists

that using a wireless phone causes brain tumors or other ill effects. Their

recommendation to limit wireless phone use by children was strictly

precautionary; it was not based on scientiﬁc evidence that any health

hazard exists.

130

Safety

11. What about wireless phone interference with medical

equipment?

Radio Frequency (RF) energy from wireless phones can interact with some

electronic devices. For this reason, the FDA helped develop a detailed test

method to measure Electro Magnetic Interference (EMI) of implanted

cardiac pacemakers and deﬁbrillators from wireless telephones. This test

method is now part of a standard sponsored by the Association for the

Advancement of Medical Instrumentation (AAMI). The ﬁnal draft, a joint

effort by the FDA, medical device manufacturers, and many other groups,

was completed in late 2000. This standard will allow manufacturers to

ensure that cardiac pacemakers and deﬁbrillators are safe from wireless

phone EMI.

The FDA has tested hearing aids for interference from handheld wireless

phones and helped develop a voluntary standard sponsored by the Institute

of Electrical and Electronic Engineers (IEEE). This standard speciﬁes test

methods and performance requirements for hearing aids and wireless

phones so that no interference occurs when a person uses a “compatible”

phone and a “compatible” hearing aid at the same time. This standard was

approved by the IEEE in 2000.

The FDA continues to monitor the use of wireless phones for possible

interactions with other medical devices. Should harmful interference be

found to occur, the FDA will conduct testing to assess the interference and

work to resolve the problem.

12. Where can I ﬁnd additional information?

For additional information, please refer to the following resources:

FDA web page on wireless phones (http://www.fda.gov/cellphones/)

Federal Communications Commission (FCC) RF Safety Program

(http://www.fcc.gov/oet/rfsafety)

International Commission on Non-lonizing Radiation Protection

(http://www.icnirp.de)

131

Safety

World Health Organization (WHO) International EMF Project

(http://www.who.int/emf)

National Radiological Protection Board (UK)

(http://www.hpa.org.uk/radiation/)

10 Driver Safety Tips

Your wireless phone gives you the powerful ability to communicate by

voice almost anywhere, anytime. An important responsibility accompanies

the beneﬁts of wireless phones, one that every user must uphold.

When operating a car, driving is your ﬁrst responsibility. When using your

wireless phone behind the wheel of a car, practice good common sense

and remember the following tips:

1. Get to know your wireless phone and its features such as speed dial and

redial. Carefully read your instruction manual and learn to take advantage

of valuable features most phones offer, including automatic redial and

memory. Also, work to memorize the phone keypad so you can use the

speed dial function without taking your attention off the road.

2. When available, use a hands-free device. A number of hands-free

wireless phone accessories are readily available today. Whether you

choose an installed mounted device for your wireless phone or a speaker

phone accessory, take advantage of these devices if available to you.

3. Make sure you place your wireless phone within easy reach and where

you can reach it without removing your eyes from the road. If you get an

incoming call at an inconvenient time, if possible, let your voicemail

answer it for you.

4. Suspend conversations during hazardous driving conditions or situations.

Let the person you are speaking with know you are driving; if necessary,

suspend the call in heavy trafﬁc or hazardous weather conditions. Rain,

sleet, snow, and ice can be hazardous, but so is heavy trafﬁc. As a driver,

your ﬁrst responsibility is to pay attention to the road.

5. Don’t take notes or look up phone numbers while driving. If you are

reading an address book or business card, or writing a “to-do” list while

132

Safety

driving a car, you are not watching where you are going. It is common

sense. Do not get caught in a dangerous situation because you are

reading or writing and not paying attention to the road or nearby vehicles.

6. Dial sensibly and assess the trafﬁc; if possible, place calls when you are

not moving or before pulling into trafﬁc. Try to plan your calls before you

begin your trip or attempt to coincide your calls with times you may be

stopped at a stop sign, red light, or otherwise stationary. But if you need

to dial while driving, follow this simple tip - dial only a few numbers,

check the road and your mirrors, then continue.

7. Do not engage in stressful or emotional conversations that may be

distracting. Stressful or emotional conversations and driving do not mix;

they are distracting and even dangerous when you are behind the wheel

of a car. Make people you are talking with aware you are driving and if

necessary, suspend conversations which have the potential to divert

your attention from the road.

8. Use your wireless phone to call for help. Your wireless phone is one of

the greatest tools you can own to protect yourself and your family in

dangerous situations -- with your phone at your side, help is only three

numbers away. Dial 911 or other local emergency number in the case of

ﬁre, trafﬁc accident, road hazard, or medical emergency. Remember, it’s

a free call on your wireless phone!

9. Use your wireless phone to help others in emergencies. Your wireless

phone provides you a perfect opportunity to be a “Good Samaritan” in

your community. If you see an auto accident, crime in progress or other

serious emergency where lives are in danger, call 911 or other local

emergency number, as you would want others to do for you.

10. Call roadside assistance or a special wireless non-emergency

assistance number when necessary. Certain situations you encounter

while driving may require attention, but are not urgent enough to merit a

call for emergency services. But you can still use your wireless phone to

lend a hand. If you see a broken-down vehicle posing no serious hazard,

a broken trafﬁc signal, a minor trafﬁc accident where no one appears

injured or a vehicle you know to be stolen, call roadside assistance or

other special non-emergency wireless number.

The above tips are meant as general guidelines. Before deciding to use

133

Safety

your mobile device while operating a vehicle, it is recommended that you

consult your applicable jurisdiction’s local laws or other regulations

regarding such use. Such laws or other regulations may prohibit or

otherwise restrict the manner in which a driver may use his or her phone

while operating a vehicle.

Consumer Information on SAR

(Speciﬁc Absorption Rate)

This model phone meets the Government’s requirements for exposure to

radio waves. Your wireless phone is a radio transmitter and receiver. It is

designed and manufactured not to exceed the emission limits for exposure

to radiofrequency (RF) energy set by the Federal Communications

Commission (FCC) of the U.S. Government. These FCC exposure limits are

derived from the recommendations of two expert organizations, the

National Counsel on Radiation Protection and Measurement (NCRP) and

the Institute of Electrical and Electronics Engineers (IEEE). In both cases,

the recommendations were developed by scientiﬁc and engineering

experts drawn from industry, government, and academia after extensive

reviews of the scientiﬁc literature related to the biological effects of RF

energy.

The exposure limit for wireless mobile phones employs a unit of measurement

known as the Speciﬁc Absorption Rate, or SAR. The SAR is a measure of the

rate of absorption of RF energy by the human body expressed in units of watts

per kilogram (W/kg). The FCC requires wireless phones to comply with a safety

limit of 1.6 watts per kilogram (1.6 W/kg). The FCC exposure limit incorporates a

substantial margin of safety to give additional protection to the public and to

account for any variations in measurements.

Tests for SAR are conducted using standard operating positions speciﬁed

by the FCC with the phone transmitting at its highest certiﬁed power level

in all tested frequency bands. Although SAR is determined at the highest

certiﬁed power level, the actual SAR level of the phone while operating can

be well below the maximum value. Because the phone is designed to

operate at multiple power levels to use only the power required to reach

134

Safety

the network, in general, the closer you are to a wireless base station

antenna, the lower the power output.

Before a phone model is available for sale to the public, it must be tested

and certiﬁed to the FCC that it does not exceed the limit established by the

government adopted requirement for safe exposure. The tests are

performed in positions and locations (e.g., at the ear and worn on the body)

as required by the FCC for each model.

This device was tested for typical body-worn operations with the back of the

phone kept 0.39 inches (1.0 cm) between the user’s body and the back of

the phone. To comply with FCC RF exposure requirements, a minimum

separation distance of 0.39 inches (1.0 cm) must be maintained between

the user’s body and the back of the phone. Any belt-clips, holsters, and

similar accessories containing metallic components may not be used.

Body-worn accessories that cannot maintain 0.39 inches (1.0 cm) separation

distance between the user’s body and the back of the phone, and have not

been tested for typical body-worn operations may not comply with FCC RF

exposure limits and should be avoided.

The FCC has granted an Equipment Authorization for this model phone with

all reported SAR levels evaluated as in compliance with the FCC RF

emission guidelines.

The highest SAR value for this model phone when tested for use at the ear

is 0.43 W/kg and when worn on the body, as described in this user’s

manual, is 0.85 W/kg (body-worn/hotspot measurement differ among

phone models, depending upon available accessories and FCC

requirements). While there may be differences between SAR levels of

various phones and at various positions, they all meet the government

requirement for safe exposure.

SAR information on this model phone is on ﬁle with the FCC and can be

found under the Display Grant section of http://www.fcc.gov/oet/ea/fccid/

after searching on FCC ID ZNFUS990.

To ﬁnd information that pertains to a particular model phone, this site uses

the phone FCC ID number which is usually printed somewhere on the case

of the phone. Sometimes it may be necessary to remove the battery pack

135

Safety

to ﬁnd the number. Once you have the FCC ID number for a particular

phone, follow the instructions on the website and it should provide values

for typical or maximum SAR for a particular phone.

Additional information on Speciﬁc Absorption Rates (SAR) can be found on

the Cellular Telecommunications Industry Association (CTIA) website at

http://www.ctia.org/

*In the United States and Canada, the SAR limit for mobile phones used by

the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The

standard incorporates a substantial margin of safety to give additional

protection for the public and to account for any variations in measurements.

FCC Hearing-Aid Compatibility (HAC) Regulations

for Wireless Devices

On July 10, 2003, the U.S. Federal Communications Commission (FCC)

Report and Order in WT Docket 01-309 modiﬁed the exception of wireless

phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to require

digital wireless phones be compatible with hearing-aids. The intent of the

HAC Act is to ensure reasonable access to telecommunications services for

persons with hearing disabilities.

While some wireless phones are used near some hearing devices (hearing

aids and cochlear implants), users may detect a buzzing, humming, or

whining noise. Some hearing devices are more immune than others to this

interference noise, and phones also vary in the amount of interference they

generate.

The wireless telephone industry has developed a rating system for wireless

phones, to assist hearing device users to ﬁnd phones that may be compatible

with their hearing devices. Not all phones have been rated. Phones that are

rated have the rating on their box or a label located on the box.

The ratings are not guarantees. Results will vary depending on the user’s

hearing device and hearing loss. If your hearing device happens to be

vulnerable to interference, you may not be able to use a rated phone

successfully. Trying out the phone with your hearing device is the best way

to evaluate it for your personal needs.

136

Safety

M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to

generate less interference to hearing devices than phones that are not

labeled. M4 is the better/higher of the two ratings.

T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to

generate less interference to hearing devices than phones that are not

labeled. T4 is the better/ higher of the two ratings.

Hearing devices may also be rated. Your hearing device manufacturer or

hearing health professional may help you ﬁnd this rating. Higher ratings mean

that the hearing device is relatively immune to interference noise. The

hearing aid and wireless phone rating values are then added together. A sum

of 5 is considered acceptable for normal use. A sum of 6 is considered for

best use.

In the example to the left, if a hearing aid

meets the M2 level rating and the wireless

phone meets the M3 level rating, the sum

of the two values equal M5. This should

provide the hearing aid user with “normal usage” while using their hearing

aid with the particular wireless phone. “Normal usage” in this context is

deﬁned as a signal quality that’s acceptable for normal operation.

The M mark is intended to be synonymous with the U mark. The T mark is

intended to be synonymous with the UT mark. The M and T marks are

recommended by the Alliance for Telecommunications Industries Solutions

(ATIS). The U and UT marks are referenced in Section 20.19 of the FCC

Rules. The HAC rating and measurement procedure are described in the

American National Standards Institute (ANSI) C63.19 standard.

To enter that the Hearing Aid Compatibility rating for your phone is

maintained, secondary transmitters such as Bluetooth and WLAN

components must be disabled during a call.

Wireless Phones and Hearing Aid Accessibility

http://www.accesswireless.org/

Gallaudet University, RERC

http://tap.gallaudet.edu/Voice/

137

Safety

FCC Hearing Aid Compatibility and Volume Control

http://www.fcc.gov/cgb/dro/hearing.html

The Hearing Aid Compatibility FCC Order

http://hraunfoss.fcc.gov/edocs_public/attachmatch/FCC-03-168A1.pdf

Hearing Loss Association of America [HLAA]

http://hearingloss.org/content/telephones-and-mobile-devices

138

Safety

Laser Safety Statement

CDRH Compliance

THIS PRODUCT COMPLIES WITH APPLICABLE REQUIREMENT OF

THE DHHS PERFORMANCE STANDARD FOR LASER PRODUCT, 21

CFR SUBCHAPTER J.

Caution!

This product employs a laser system. To ensure proper use of this

product, please read this owner’s manual carefully and retain for

future reference. Should the unit require maintenance, contact an

authorised service center.

Use of controls, adjustments, or the performance of procedures

other than those speciﬁed herein may result in hazardous radiation

exposure.

To prevent direct exposure to laser beam, do not try to open the

enclosure or make direct contact with the laser.

Instructions for Wireless Charger

Be sure to use a wireless charger that is genuine or

compatibilitycertiﬁed (by WPC Qi standards).

(Wireless charger is sold separately.)

139

DivX Mobile

ABOUT DIVX VIDEO: DivX

is a digital video format created by DivX, LLC,

a subsidiary of Rovi Corporation. This is an ofﬁcial DivX Certiﬁed

device

that has passed rigorous testing to verify that it plays DivX video.

Visit divx.com for more information and software tools to convert your ﬁles

into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certiﬁed

device must be

registered in order to play purchased DivX Video-on-Demand (VOD) movies.

To obtain your registration code, locate the DivX VOD section in your device

setup menu. Go to vod. divx.com for more information on how to complete

your registration.

DivX Certiﬁed

to play DivX

video up to HD 720p, including premium

content. DivX

, DivX Certiﬁed

and associated logos are trademarks of

Rovi Corporation or its subsidiaries and are used under license.

Dolby Digital Plus License Notice

Manufactured under license from Dolby Laboratories. Dolby, Dolby Digital

Plus, and the double-D symbol are trademarks of Dolby Laboratories.

Notice: Open Source Software

To obtain the source code under GPL, LGPL, MPL, and other open

source licenses, that is contained in this product, please visit

http://opensource.lge.com.

In addition to the source code, all referred license terms, warranty

disclaimers and copyright notices are available for download.

LG Electronics will also provide open source code to you on CD-ROM for

a charge covering the cost of performing such distribution (such as the

cost of media, shipping, and handling) upon email request to

[email protected]. This offer is valid for three (3) years from the date

on which you purchased the product.

Specifications

140

1. WHAT THIS WARRANTY COVERS:

LG offers you a limited warranty that the enclosed subscriber unit and its

enclosed accessories will be free from defects in material and

workmanship, according to the following terms and conditions:

(1) The limited warranty for the product extends for TWELVE (12) MONTHS

beginning on the date of purchase of the product with valid proof of

purchase, or absent valid proof of purchase, FIFTEEN (15) MONTHS

from date of manufacture as determined by the unit’s manufacture date

code.

(2) The limited warranty extends only to the original purchaser of the

product and is not assignable or transferable to any subsequent

purchaser/end user.

(3) This warranty is good only to the original purchaser of the product during

the warranty period as long as it is in the U.S., including Alaska, Hawaii,

U.S. Territories and Canada.

(4) The external housing and cosmetic parts shall be free of defects at the

time of shipment and, therefore, shall not be covered under these

limited warranty terms.

(5) Upon request from LG, the consumer must provide information to

reasonably prove the date of purchase.

(6) The customer shall bear the cost of shipping the product to the

Customer Service Department of LG. LG shall bear the cost of shipping

the product back to the consumer after the completion of service under

this limited warranty.

2. WHAT THIS WARRANTY DOES NOT COVER:

(1) Defects or damages resulting from use of the product in other than its

normal and customary manner.

(2) Defects or damages from abnormal use, abnormal conditions, improper

storage, exposure to moisture or dampness, unauthorized modiﬁcations,

unauthorized connections, unauthorized repair, misuse, neglect, abuse,

accident, alteration, improper installation, or other acts which are not the

fault of LG, including damage caused by shipping, blown fuses, spills of

food or liquid.

(3) Breakage or damage to antennas unless caused directly by defects in

material or workmanship.

(4) That the Customer Service Department at LG was not notiﬁed by

consumer of the alleged defect or malfunction of the product during the

applicable limited warranty period.

LIMITED WARRANTY STATEMENT

141

LIMITED WARRANTY STATEMENT

(5) Products which have had the serial number removed or made illegible.

(6) This limited warranty is in lieu of all other warranties, express or implied

either in fact or by operations of law, statutory or otherwise, including,

but not limited to any implied warranty of marketability or ﬁtness for a

particular use.

(7) Damage resulting from use of non LG approved accessories.

(8) All plastic surfaces and all other externally exposed parts that are

scratched or damaged due to normal customer use.

(9) Products operated outside published maximum ratings.

(10) Products used or obtained in a rental program.

(11) Consumables (such as fuses).

3. WHAT LG WILL DO:

LG will, at its sole option, either repair, replace or refund the purchase price

of any unit that does not conform to this limited warranty. LG may choose

at its option to use functionally equivalent re-conditioned, refurbished or

new units or parts or any units. In addition, LG will not re-install or back-up

any data, applications or software that you have added to your phone. It is

therefore recommended that you back-up any such data or information

prior to sending the unit to LG to avoid the permanent loss of such

information.

4. STATE LAW RIGHTS:

No other express warranty is applicable to this product. THE DURATION OF

ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF

MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS

WARRANTY HEREIN. LG SHALL NOT BE LIABLE FOR THE LOSS OF THE

USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER

DAMAGES, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE

OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF

ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED

WARRANTY OF MARKETABILITY APPLICABLE TO THIS PRODUCT.

Some states do not allow the exclusive limitation of incidental or

consequential damages or limitations on how long an implied warranty

lasts; so these limitations or exclusions may not apply to you. This warranty

gives you speciﬁc legal rights and you may also have other rights which

142

LIMITED WARRANTY STATEMENT

vary from state to state.

5. HOW TO GET WARRANTY SERVICE:

If you experience any problems with either the Bluetooth headset or the

mobile handset, in each case as may be covered by this limited warranty,

you need only return the affected device. For example, if a problem exists

with the Bluetooth headset, please DO NOT return your mobile handset

with the headset. Likewise, if a problem exists with the mobile handset,

please DO NOT return the Bluetooth Headset with the handset.

To obtain warranty service, please call or fax to the following telephone

numbers from anywhere in the continental United States:

Tel. 1-800-793-8896 or Fax. 1-800-448-4026

Or visit http://us.lgservice.com. Correspondence may also be mailed to:

LG Electronics Service- Mobile Handsets, P.O. Box 240007, Huntsville, AL

35824

DO NOT RETURN YOUR PRODUCT TO THE ABOVE ADDRESS.

Please call or write for the location of the LG authorized service center

nearest you and for the procedures for obtaining warranty claims.

143

LIMITED WARRANTY STATEMENT

7.11 Warranty Laws

The following laws govern warranties that arise in retail sales of consumer

goods:

• The California Song-Beverly Consumer Warranty Act [CC §§1790 et seq],

• The California Uniform Commercial Code, Division Two [Com C §§2101

et seq], and

• The federal Magnuson-Moss Warranty Federal Trade Commission

Improvement Act [15 USC §§2301 et seq; 16 CFR Parts 701– 703]. A

typical Magnuson-Moss Act warranty is a written promise that the

product is free of defects or a written promise to refund, repair, or

replace defective goods. [See 15 USC §2301(6).] Remedies include

damages for failing to honor a written warranty or service contract or for

violating disclosure provisions. [See 15 USC §2310(d).] Except for some

labeling and disclosure requirements, the federal Act does not preempt

state law. [See 15 USC §2311.]

The Consumer Warranty Act does not affect the rights and obligations of

parties under the state Uniform Commercial Code, except the provisions of

the Act prevail over provisions of the Commercial Code when they conﬂict.

[CC §1790.3.]

For purposes of small claims actions, this course will focus on rights and

duties under the state laws.

144

Numbers

10 Driver Safety Tips

131

Adding Contacts 57

Answering or

Rejecting Calls 46

Calculator 87

Calendar 86

Calling Your Contacts

Camera and Video

Cautions 10

Charge the Phone

Charging the Phone

Chrome 54

Clock 88

Connecting to

Mobile Networks 39

Connecting to

Networks and

Devices 39

Connecting to Wi-Fi

Networks 40

Consumer

Information on SAR

133

Contacts 57

Display 100

Dual Play 73

Dual window 80

ELECTRICAL

SAFETY 3

Email 60

FCC Hearing-Aid

Compatibility (HAC)

Regulations for

Wireless Devices

135

FDA Consumer

Update 124

File Manager 92

Gallery 73

Getting to Know the

Home Screen 29

Gmail 62

Guest Mode 37

Hangouts 63

Hardware key control

mode 32

Important Customer

Information 3

Insert the Battery 19

Listening to Your

Voicemail 51

Managing Multiple

Calls 50

Managing

Notiﬁcations 33

Index

145

Index

Maps 55

Messaging 59

Music 75

Networks 94

Opening YouTube

and Watching Videos

Options During a Call

Phone Overview 15

Phone’s Status Icons

Placing and Ending

Calls 43

Play Store 74

QSlide 77

QSlide icons on the

Notiﬁcations panel

QuickMemo+ 81

QuickRemote 83

Record Videos 66

Remove the Back

Cover 18

Removing the

Battery and SIM

Card 20

Replace the Back

Cover 19

Safety Information

117

Setting and

Activating Alarms 88

Settings 94

Setting the Timer 90

Setting the World

Clock 90

Setting Up Your

Phone 18

Setting your Lock

screen 35

Sound 99

Taking Pictures 65

Tasks 93

TIA Safety

Information 114

Touchscreen 30

Transferring Music

Files to Your Phone

Turning the Phone

On and Off 24

USB Connection 41

Using SmartShare

Using the Magic

Remote feature 85

Using the Stopwatch

Viewing 86

Voice Command 91

Voice Recorder 91

Voice Search 91

146

Index

Working with Menus

Working With the

Recent Tab 46

Your Google Account

YouTube™ 77

LG Electronics LGAS990 The first Quad HD smartphone in the US will give your best moments a stage to shine. When it comes to your life and your needs, simple is the new smart.

Product's Documents

User Manual

Specifications

LG Electronics LGAS990 Questions and Answers

Related Products

LG Electronics AS985 The First Quad Hd Smartphone In The Us Will Give Your Best Moments A Stage To Shine. When It Comes To Your Life And Your Needs, Simple Is The New Smart.

LG Electronics LGAS985 The first Quad HD smartphone in the US will give your best moments a stage to shine. When it comes to your life and your needs, simple is the new smart.

LG Electronics D851TN The First Quad Hd Smartphone In The Us Will Give Your Best Moments A Stage To Shine. When It Comes To Your Life And Your Needs, Simple Is The New Smart.

LG Electronics LGD851TN The first Quad HD smartphone in the US will give your best moments a stage to shine. When it comes to your life and your needs, simple is the new smart.

LG Electronics LGUS990 The First Quad Hd Smartphone In The Us Will Give Your Best Moments A Stage To Shine. When It Comes To Your Life And Your Needs, Simple Is The New Smart.

LG Electronics LGD851WH The first Quad HD smartphone in the US will give your best moments a stage to shine. When it comes to your life and your needs, simple is the new smart.
