GNE60120X
GNE61520DX
GNE58820DX
EN
Please read this manual before using the product!
Dear Customer,
We'd like you to make the best use of our product, which has been manufactured in modern facilities
with care and meticulous quality controls.
Thus, we advice you to read the entire user manual before you use the product. In case the product
changes hands, do not forget to hand the guide to its new owner along with the product.
This guide will help you use the product quickly and safely.
• Please read the user guide carefully before installing and operating the product.
• Always observe the applicable safety instructions.
• Keep the user guide within easy reach for future use.
• Please read any other documents provided with the product.
Keep in mind that this user guide may apply to several product models. The guide clearly indicates any
variations of different models.
C
Important information and useful
tips.
A
Risk of life and property.
B
Risk of electric shock.
The product’s packaging is
made of recyclable materials,
in accordance with the National
Environment Legislation.
2 / 31 EN
Refrigerator / User Manual
1 Safety and environment instructions 3
1.1. General safety. . . . . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning. . . . . . . . . . . . . . . . . . . . . . . . 4
1.1.2 For models with water dispenser . . . . . . . . 5
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . . . . 5
1.3. Child safety. . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4. Compliance with WEEE Directive and
Disposing of the Waste Product . . . . . . . . . 5
1.5. Compliance with RoHS Directive . . . . . . . . . 6
1.6. Package information . . . . . . . . . . . . . . . . . . 6
2 Refrigerator 7
3 Installation 8
3.1. Right place for installation . . . . . . . . . . . . . . 8
3.2. Attaching the plastic wedges . . . . . . . . . . . . 8
3.3. Adjusting the stands . . . . . . . . . . . . . . . . . . 9
3.4. Power connection . . . . . . . . . . . . . . . . . . . . 9
3.5. Water connection . . . . . . . . . . . . . . . . . . . . 9
3.6. Connecting water hose to the product . . . . 10
3.7. Connecting to water mains . . . . . . . . . . . . 10
3.8. For products using water carboy . . . . . . . . 11
3.9 Water filter . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.9.1. Fixing external filter on the wall (Optional) 12
3.9.2. Internal filter . . . . . . . . . . . . . . . . . . . . . 13
4 Preparation 15
4.1. What to do for energy saving. . . . . . . . . . . 15
4.2. First use . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5 Using the product 16
5.1. Indicator panel . . . . . . . . . . . . . . . . . . . . . 16
5.2. Zero degree compartment. . . . . . . . . . . . . 23
5.3. Vegetable bin . . . . . . . . . . . . . . . . . . . . 23
5.4. Blue light . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.5. Description and cleaning of odour filter . . . 23
5.6. Telescopic drawer . . . . . . . . . . . . . . . . . . 24
5.7. Ionizer . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.8. Ice box . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.9. Ice maker . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.10. Movable middle section . . . . . . . . . . . . . 25
5.11. Ice container . . . . . . . . . . . . . . . . . . . . . . 25
5.12. Humidity controlled crisper . . . . . . . . . . . . 26
5.13. Freezing fresh food . . . . . . . . . . . . . . . . . 27
5.14. Recommendations for storing frozen foods 27
5.15. Deep freezer details . . . . . . . . . . . . . . . . . 27
5.16. Placing the food. . . . . . . . . . . . . . . . . . . . 28
5.17. Door open alert . . . . . . . . . . . . . . . . . . . . 28
5.18. Interior light . . . . . . . . . . . . . . . . . . . . . . . 28
6 Maintenance and cleaning 29
6.1. Preventing malodour . . . . . . . . . . . . . . . . . 29
6.2. Protecting plastic surfaces . . . . . . . . . . . . 29
7 Troubleshooting 30
3 / 31 EN
Refrigerator / User Manual
1 Safety and environment instructions
This section provides the safety
instructions necessary to prevent
the risk of injury and material
damage. Failure to observe these
instructions will invalidate all
types of product warranty.
1.1. General safety
• This product should not be
used by persons with physical,
sensory and mental disabilities,
without sufficient knowledge
and experience or by children.
The device can only be
used by such persons under
supervision and instruction of
a person responsible for their
safety. Children should not be
allowed to play with this device.
• In case of malfunction, unplug
the device.
• After unplugging, wait at least
5 minutes before plugging in
again.
• Unplug the product when not in
use.
• Do not touch the plug with wet
hands! Do not pull the cable to
plug off, always hold the plug.
• Wipe the power plug’s tip with
a dry cloth before plugging in.
• Do not plug in the refrigerator if
the socket is loose.
• Unplug the product during
installation, maintenance,
cleaning and repair.
• If the product will not be used
for a while, unplug the product
and remove any food inside.
• Do not use the product when
the compartment with circuit
cards located on the upper
back part of the product
(electrical card box cover) (1) is
open.
1
1
• Do not use steam or steamed
cleaning materials for cleaning
the refrigerator and melting the
ice inside. Steam may contact
the electrified areas and cause
short circuit or electric shock!
• Do not wash the product by
spraying or pouring water on it!
Danger of electric shock!
• In case of malfunction, do not
use the product, as it may
cause electric shock. Contact
4 / 31 EN
Refrigerator / User Manual
Safety and environment instructions
the authorized service before
doing anything.
• Plug the product into an
earthed socket. Earthing
must be done by a qualified
electrician.
• If the product has LED type
lighting, contact the authorized
service for replacing or in case
of any problem.
• Do not touch frozen food with
wet hands! It may adhere to
your hands!
• Do not place liquids in bottles
and cans into the freezer
compartment. They may burst
out!
• Place liquids in upright position
after tightly closing the lid.
• Do not spray flammable
substances near the product,
as it may burn or explode.
• Do not keep flammable
materials and products with
flammable gas (sprays, etc.) in
the refrigerator.
• Do not place containers
holding liquids on top of the
product. Splashing water on
an electrified part may cause
electric shock and risk of fire.
• Exposing the product to rain,
snow, sunlight and wind will
cause electrical danger. When
relocating the product, do not
pull by holding the door handle.
The handle may come off.
• Take care to avoid trapping any
part of your hands or body in
any of the moving parts inside
the product.
• Do not step or lean on the door,
drawers and similar parts of
the refrigerator. This will cause
the product to fall down and
cause damage to the parts.
• Take care not to trap the power
cable.
1.1.1 HC warning
If the product comprises a cooling
system using R600a gas, take
care to avoid damaging the
cooling system and its pipe while
using and moving the product.
This gas is flammable. If the
cooling system is damaged, keep
the product away from sources
of fire and ventilate the room
immediately.
5 / 31 EN
Refrigerator / User Manual
Safety and environment instructions
C
The label on the inner
left side indicates the
type of gas used in the
product.
1.1.2 For models with
water dispenser
• Pressure for cold water inlet
shall be maximum 120 psi (8
bar). If your water pressure
exceeds 80 psi (5.5 bar), use a
pressure limiting valve in your
mains system. If you do not
know how to check your water
pressure, ask for the help of a
professional plumber.
• If there is risk of water hammer
effect in your installation,
always use a water hammer
prevention equipment in
your installation. Consult
Professional plumbers is you
are not sure that there is no
water hammer effect in your
installation.
• Do not install on the hot water
inlet. Take precautions against
of the risk of freezing of the
hoses. Water temperature
operating interval shall be 33°F
(0.6°C) minimum and 100°F
(38°C) maximum.
• Use drinking water only.
1.2. Intended use
• This product is designed for
home use. It is not intended for
commercial use.
• The product should be used to
store food and beverages only.
• Do not keep sensitive
products requiring controlled
temperatures (vaccines,
heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes no
responsibility for any damage
due to misuse or mishandling.
1.3. Child safety
• Keep packaging materials out
of children’s reach.
• Do not allow the children to
play with the product.
• If the product’s door comprises
a lock, keep the key out of
children’s reach.
1.4. Compliance with WEEE Directive
and Disposing of the Waste Product
This product complies with EU WEEE
Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and
electronic equipment (WEEE).
6 / 31 EN
Refrigerator / User Manual
Safety and environment instructions
This product has been manufactured
with high quality parts and materials
which can be reused and are suitable
for recycling. Do not dispose of the
waste product with normal domestic
and other wastes at the end of its
service life. Take it to the collection
center for the recycling of electrical and
electronic equipment. Please consult your local
authorities to learn about these collection
centers.
1.5. Compliance with RoHS Directive
• This product complies with EU WEEE Directive
(2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
1.6. Package information
• Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.
7 / 31 EN
Refrigerator / User Manual
*1
*3
*2
*5
*6
7
*8
9
4
A
B
2 Refrigerator
C
*Optional: Figures in this user guide are schematic and may not exactly match your product. If your
product does not comprise the relevant parts, the information pertains to other models.
A- Cooler compartment
B- Freezer compartment
1. Butter-cheese shelf
2. Cooler compartment shelves
3. Shelter wire
4. Frozen food storing compartments
5. Vegetable bins
6. Breakfast compartment
7. Odour filter
8. Adjustable glass shelves
9. Fan
8 / 31 EN
Refrigerator / User Manual
3 Installation
3.1. Right place for installation
Contact the Authorized Service for the product's
installation. To ready the product for installation,
see the information in the user guide and make
sure the electric and water utilities are as required.
If not, call an electrician and plumber to arrange
the utilities as necessary.
B
WARNING: The manufacturer assumes
no responsibility for any damage caused
by the work carried out by unauthorized
persons.
B
WARNING: The product’s power cable
must be unplugged during installation.
Failure to do so may result in death or
serious injuries!
A
WARNING: If the door span is too narrow
for the product to pass, remove the door
and turn the product sideways; if this does
not work, contact the authorized service.
•Placetheproductonaflatsurfacetoavoid
vibration.
•Placetheproductatleast30cmawayfromthe
heater, stove and similar sources of heat and at
least 5 cm away from electric ovens.
•Donotexposetheproducttodirectsunlightor
keep in damp environments.
•Theproductrequiresadequateaircirculationto
function efficiently. If the product will be placed
in an alcove, remember to leave at least 5 cm
distance between the product and the ceiling
and the walls.
•Donotinstalltheproductinenvironmentswith
temperatures below -5°C.
3.2. Attaching the plastic wedges
Use the plastic wedges provided with the product
to provide sufficient space for air circulation
between the product and the wall.
1.
To attach the wedges, remove the screws on the
product and use the screws provided with the wedges.
2.
Attach 2 plastic wedges on the ventilation cover as
shown in the figure.
9 / 31 EN
Refrigerator / User Manual
Installation
3.3. Adjusting the stands
If the product is not in balanced position, adjust the
front adjustable stands by rotating right or left.
3.4. Power connection
A
WARNING: Do not use extension or
multi sockets in power connection.
B
WARNING: Damaged power cable
must be replaced by Authorized
Service.
C
When placing two coolers in adjacent
position, leave at least 4 cm distance
between the two units.
• Our firm will not assume responsibility for any
damages due to usage without earthing and
power connection in compliance with national
regulations.
• The power cable plug must be easily
accessible after installation.
• Connect the refrigerator to an earthed socket
with 220-240V/50 Hz voltage. The socket must
comprise a 10-16A fuse.
• Do not use multi-group plug with or without
extension cable between the wall socket and
the refrigerator.
3.5. Water connection
(Optional)
A
WARNING: Unplug the product and
the water pump (if available) during
connection.
The product’s water mains, filter and carboy
connections must be rendered by authorized
service.
The product can be connected to a carboy or
directly to the water mains, depending on the
model. To establish the connection, the water hose
must first be connected to the product.
Check to see the following parts are supplied with
your product’s model:
3
1
4
2
*5
1. Connector (1 piece): Used to attach the water
hose to the rear of the product.
2. Hose clip (3 pieces): Used to fix the water
hose on the wall.
3. Water hose (1 piece, 5 meter diameter 1/4
inches): Used for the water connection.
4. Faucet adapter (1 piece): Comprises a porous
filter, used for connection to the cold water
mains.
5. Water filter (1 piece *Optional): Used to
connect the mains water to the product. Water
filter is not required if carboy connection is
available.
10 / 31 EN
Refrigerator / User Manual
Installation
3.6. Connecting water
hose to the product
To connect the water hose to the product,
follow the instructions below.
1. Remove the connector on the hose nozzle
adaptor in the back of the product and run the
hose through the connector.
2. Push the water hose down tightly and connect
to the hose nozzle adaptor.
3. Tighten the connector manually to fix on the
hose nozzle adaptor. You may also tighten the
connector using a pipe wrench or pliers.
3.7. Connecting to water mains
(Optional)
To use the product by connecting to the cold water
mains, a standard 1/2” valve connector must be
installed to the cold water mains in your home. If
the connector is not available or if you are unsure,
consult a qualified plumber.
1. Detach the connector (1) from the faucet
adaptor (2).
1
23
2. Connect the faucet adaptor to the water mains
valve.
3. Attach the connector around the water hose.
11 / 31 EN
Refrigerator / User Manual
Installation
4. Attach the connector into the faucet adaptor
and tighten by hand / tool.
5. To avoid damaging, shifting or accidentally
disconnecting the hose, use the clips provided
to fix the water hose appropriately.
A
WARNING:After turning the faucet on,
make sure there is no water leak on
either end of the water hose. In case of
leakage, turn the valve off and tighten all
connections using a pipe wrench or pliers.
3.8. For products using water carboy
(Optional)
To use a carboy for the product’s water
connection, the water pump recommended by the
authorized service must be used.
1. Connect one end of the water hose provided
with the pump to the product (see 3. 6) and
follow the instructions below.
2. Connect the other end of the water hose to
the water pump by pushing the hose into the
pump’s hose inlet.
3. Place and fasten the pump hose inside the
carboy.
4. Once the connection is established, plug in
and start the water pump.
C
Please wait 2-3 minutes after starting the
pump to achieve the desired efficiency.
C
See also the pump’s user guide for water
connection.
C
When using carboy, water filter is not
required.
3.9 Water filter
(Optional)
The product may have internal or external filter,
depending on the model. To attach the water filter,
follow the instructions below.
12 / 31 EN
Refrigerator / User Manual
Installation
3.9.1. Fixing external filter
on the wall (Optional)
A
WARNING: Do not fix the filter on the
product.
Check to see the following parts are supplied with
your product’s model:
1
2
3
4
5
6
1. Connector (1 piece): Used to attach the water
hose to the rear of the product.
2. Faucet adapter (1 piece): Used for connection
to the cold water mains.
3. Porous filter (1 piece)
4. Hose clip (3 pieces): Used to fix the water
hose on the wall.
5. Filter connecting apparatus (2 pieces): Used to
fix the filter on the wall.
6. Water filter (1 piece): Used to connect the
mains water to the product. Water filter is not
required if carboy connection is available.
1. Connect the faucet adaptor to the water mains
valve.
2. Determine the location to fix the external filter.
Fix the filter’s connecting apparatus (5) on the
wall.
3. Attach the filter in upright position on the filter
connecting apparatus, as indicated on the
label. ( 6 ).
4. Attach the water hose extending from the top
of the filter to the product’s water connection
adaptor (see. 3 6).
13 / 31 EN
Refrigerator / User Manual
Installation
After the connection is established, it should look
like the figure below.
Water line:
Carboy line:
3.9.2. Internal filter
The internal filter provided with the product is
not installed upon delivery; please follow the
instructions below to install the filter.
1. “Ice Off ” indicator must be active while
installing the filter. Switch the ON-OFF
indicator using the “Ice” button on the screen.
2. Remove the vegetable bin (a) to access the
water filter.
a a
14 / 31 EN
Refrigerator / User Manual
Installation
3. Remove the water filter by-pass cover by
pulling.
C
A few drops of water may flow out after
removing the cover; this is normal.
4. Place the water filter cover into the
mechanism and push to lock in place.
5. Push the “Ice” button on the screen again to
cancel the “Ice Off ” mode.
C
The water filter will clear certain foreign
particles in the water. It will not clear the
microorganisms in the water.
C
The filter replacement period of your
product is 6 months.
15 / 31 EN
Refrigerator / User Manual
4 Preparation
4.1. What to do for energy saving
A
Connecting the product to electronic
energy-saving systems is harmful, as it
may damage the product.
• Do not keep the refrigerator doors open for
long periods.
• Do not place hot food or beverages into the
refrigerator.
• Do not overfill the refrigerator; blocking the
internal air flow will reduce cooling capacity.
• To be able store maximum food in the freezer
compartment of your refrigerator, the upper
drawers have to be removed and placed on
top of wire rack. The net volume and energy
consumption values specified in the energy
label of the refrigerator was tested after
removing the freezer compartment’s upper
shelf and the ice container which can easily
be removed manually. Using the lower drawer
while loading is highly recommended.
• Depending on the product’s features;
defrosting frozen foods in the cooler
compartment will ensure energy saving and
preserve food quality.
• Make sure the foods are not in contact with
the cooler compartment temperature sensor
described below.
• Food must be stored in drawers inside the
cooler compartment in order to provide energy
saving and preserve the food in a better
ambient.
• Prevent direct contact between the
temperature sensor in the freezer compartment
and the food packages. Energy consumption
may increase in case of a contact with the
sensor.
4.2. First use
Before using your refrigerator, make sure the
necessary preparations are made in line with
the instructions in “Safety and environment
instructions” and “Installation” sections.
• Keep the product running with no food inside
for 6 hours and do not open the door, unless
absolutely necessary.
C
A sound will be heard when the
compressor is engaged. It is normal to
hear sound even when the compressor is
inactive, due to the compressed liquids and
gasses in the cooling system.
C
It is normal for the front edges of the
refrigerator to be warm. These areas are
designed to warm up in order to prevent
condensation.
C
In some models, indicator panel is dimmed
automatically 5 minutes after the door is
closed. It will be activated again when the
door is opened or any key is pressed.
16 / 31 EN
Refrigerator / User Manual
C
*Optional: The figures in this user guide are intended as drafts and may not perfectly match your
product. If your product does not comprise the relevant parts, the information pertains to other models.
5 Using the product
5.1. Indicator panel
Indicator panels may vary depending on the model of your product.
Audio and visual functions of the indicator panel will assist in using the refrigerator.
45
7
6
8
9
1
2
3
1. Cooler compartment indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature adjustment button
6. Compartment selection button
7. Freezer compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
17 / 31 EN
Refrigerator / User Manual
Using the product
1. Cooler compartment indicator
The cooler compartment light will turn on when
adjusting the cooler compartment temperature.
2. Error status indicator
This sensor will activate if the refrigerator is not
cooling adequately or in case of sensor fault. When
this indicator is active, the freezer compartment
temperature indicator will display "E" and the
cooler compartment temperature indicator will
display "1, 2, 3..." etc. numbers. The numbers on
the indicator serve to inform the service personnel
about the fault. ( )
3. Temperature indicator
Indicates the temperature of the freezer and cooler
compartments.
4. Vacation function button
To activate this function, press and hold the
Vacation button for 3 seconds. When the Vacation
function is active, the cooler compartment
temperature indicator displays the inscription
"- -" and no cooling process will be active in
the cooling compartment. This function is not
suitable to keep food in the cooler compartment.
Other compartments will remain cooled with the
respective temperature set for each compartment.
Push the Vacation button ( ) again to cancel
this function.
5. Temperature adjustment button
Respective compartment's temperature varies in
-24°C... -18°C and 8°C...1°C ranges. ( )
6. Compartment selection button
Use the refrigerator compartment selection
button to toggle between the cooler and freezer
compartments. ( )
7. Freezer compartment indicator
The freezer compartment light will turn on when
adjusting the freezer compartment temperature.
8. Economy mode indicator
Indicates the refrigerator is running on energy-
saving mode. This indicator will be active when the
temperature in the freezer compartment is set to
-18°C. ( )
9. Vacation function indicator
Indicates the vacation function is active. ( )
18 / 31 EN
Refrigerator / User Manual
Using the product
C
*Optional: The figures in this user guide are intended as drafts and may not perfectly match your
product. If your product does not comprise the relevant parts, the information pertains to other models.
Indicator panel
This touch-control indicator panel allows you to set the temperature without opening the door of your
refrigerator. Just touch the relevant button with your finger to set the temperature.
1
1
2
2
3
45
6.2
6.1
789
10
3(*)
11
10
4
5
6789
1- Economic use
2- High temperature / fault alert
3- Rapid cooling
4- Vacation function
5- Cooler compartment temperature setting
6- Energy saving (display off)/ Alarm off warning
7- Keypad lock
8- Eco-fuzzy
9- Freezer compartment temperature setting
10- Rapid freezing
19 / 31 EN
Refrigerator / User Manual
Using the product
1. Economic use
This sign will light up when the freezer compart-
ment is set to -18°C', the most economical
setting. ( ) Economic use indicator will turn off
when rapid cooling or rapid freezing function is
selected.
2. High temperature / fault alert
This indicator ( ) will light up in case of temper-
ature faults or fault alerts. If you see this indicator
is lit up, please see the "recommended solutions
for problems" section in this guide.
3. Rapid cooling
When the rapid cooling function is turned on, the rapid
cool indicator will light up ( ) and the cooler com-
partment temperature indicator will display the value 1.
Push the Rapid cool button again to cancel this func-
tion. The Rapid cool indicator will turn off and return
to normal setting. The rapid cooling function will be
automatically cancelled after 1 hour, unless cancelled
by the user. Too cool a large amount of fresh food,
press the rapid cool button before placing the food in
the cooler compartment.
4. Vacation function
To activate the Vacation function, press the button
number (4) for ( ) 3 seconds; this will activate
the vacation mode indicator ( ). When the
Vacation function is active, the cooler compartment
temperature indicator displays the inscription
"- -" and no cooling process will be active in
the cooling compartment. This function is not
suitable to keep food in the cooler compartment.
Other compartments will remain cooled with the
respective temperature set for each compartment.
Push the vacation function button again to
cancel this function
5. Cooler compartment temperature setting
After pressing the button number (5), the
cooler compartment temperature can be set to
8,7,6,5,4,3,2 and 1 respectively. ( )
6. 1 Energy saving (display off)
Pressing this button ( ) will light up the energy
saving sign ( ) and the Energy-saving function
will activate. Activating the energy-saving function
will turn off all other signs on the display. When
the energy-saving function is active, pressing any
button or opening the door will deactivate the
energy-saving function and the display signals will
return to normal. Pressing this button ( ) again
will turn off the energy-saving sign and deactivate
the energy-saving function.
6.2.Alarm off warning:
In case of power failure/high temperature alarm,
after checking the food located in the freezer
compartment press the alarm off button to clear
the warning.
7. Keypad lock
Press the keypad lock button ( ) simultaneously
for 3 seconds. The keypad lock sign
( ) will light up and the keypad lock will be
activated. The buttons will be inactive when the
Keypad lock is activated. Press the Keypad lock
button again simultaneously for 3 seconds. The
keypad lock sign will turn off and the keypad lock
mode will be disengaged.
Press the keypad lock button ( ) to prevent
changing the refrigerator's temperature settings.
8. Eco-fuzzy
To activate the eco-fuzzy function, press and hold
the eco-fuzzy button for 1 second. When this
function is active, the freezer will switch to the
economic mode after at least 6 hours and the
economic use indicator will light up. To deactivate
the ( ) eco-fuzzy function, press and hold the
eco-fuzzy function button for 3 seconds.
The indicator will light up after 6 hours when the
eco-fuzzy function is active.
20 / 31 EN
Refrigerator / User Manual
Using the product
9. Freezer compartment temperature setting
The temperature in the freezer compartment is ad-
justable. Pressing the button number (9) will enable
the freezer compartment temperature to be set at
-18,-19, -20, -21, -22, -23 and -24. ( )
10. Rapid freezing
For rapid freezing, press the button number (10);
this will activate the rapid freezing indicator ( ).
When the rapid freezing function is turned on, the
rapid freeze indicator will light up and the freezer
compartment temperature indicator will display
the value -27. Press the Rapid freeze button (
) again to cancel this function. The Rapid freeze
indicator will turn off and return to normal setting.
The rapid freezing function will be automatically
cancelled after 24 hours, unless cancelled by the
user. To freeze a large amount of fresh food, press
the rapid freeze button before placing the food in
the freezer compartment.
21 / 31 EN
Refrigerator / User Manual
Using the product
C
*Optional: The figures in this user guide are intended as drafts and may not perfectly match your
product. If your product does not comprise the relevant parts, the information pertains to other models.
1. Freezer compartment temperature setting
2. Economy mode
3. Error status
4. Cooler compartment temperature setting
5. Rapid cooling
6. Vacation function
7. Keypad lock / filter replacing alert cancellation
8. Ice making on/off
9. Display on/off
10. Autoeco
11. Rapid freezing
1
1
2
2
3
45
6.2
6.1
789
10
3(*)
11
10
4
5
6789
22 / 31 EN
Refrigerator / User Manual
Using the product
1. Freezer compartment temperature setting
Pressing the button ( ) number (1) will enable
the freezer compartment temperature to be set at
-18,-19,-20,-21 ,-22,-23,-24,-18...
2. Economy mode
Indicates the refrigerator is running on energy-
saving mode. This indicator will be active when
the freezer compartment temperature is set at -18
or the energy-saving cooling is engaged by eco-
extra function. ( )
3. Error status
This sign will activate if the refrigerator is not
cooling adequately or in case of sensor fault. ( )
When this indicator is activated, the freezer
compartment temperature indicator will display "E"
and the cooler compartment temperature indicator
will display "1, 2, 3..." etc. numbers. The numbers
on the indicator serve to inform the service
personnel about the fault.
4. Cooler compartment temperature setting
After pressing the button ( ) number (4), the
cooler compartment temperature can be set to
8,7,6,5,4,3,2... respectively.
5. Rapid cooling
For rapid cooling, press the button number (5); this
will activate the rapid cooling indicator ( ).
Press this button again to deactivate this function.
Use this function when placing fresh foods into
the cooler compartment or to rapidly cool the
food items. When this function is activated, the
refrigerator will be engaged for 1 hour.
6. Vacation function
When the Vacation function ( ) is active, the
cooler compartment temperature indicator displays
the inscription "- -" and no cooling process
will be active in the cooling compartment. This
function is not suitable to keep food in the cooler
compartment. Other compartments will remain
cooled with the respective temperature set for
each compartment.
Press the vacation function button again to
cancel this function. ( )
7. Keypad lock / Keypad lock / filter replacing
alert cancellation
Press keypad lock button ( ) to activate the
keypad lock. You may also use this function to
prevent changing the refrigerator's temperature
settings. The refrigerator's filter must be replaced
every 6 months. If you follow the instructions in
the section 5.2, the refrigerator will automatically
calculate the remaining period and the filter
replacing alert indicator ( ) will light up when
filter expires.
Press and hold the button ( ) for 3 seconds to
turn off the filter alert light.
8. Ice making on/off
Press the button ( ) number (9) to cancel (
) or activate ( ) ice-making.
9. Display on/off
Press the button number (10) to cancel (
) or activate ( ) display on/
off.
10. Autoeco
Press the auto eco button
( ), number (11), for 3 seconds to activate this
function. If the door remains closed for a long time
when this function is activated, the cooler section
will switch to economic mode. Press the button
again to deactivate this function.
The indicator will light up after 6 hours when the
auto eco function is active. ( )
11. Rapid freezing
Press the button
( ) number (12) for rapid freezing. Press the
button again to deactivate the function.
23 / 31 EN
Refrigerator / User Manual
Using the product
5.2. Zero degree compartment
(Optional)
Use this compartment to keep delicatessen
at lower temperatures or meat products for
immediate consumption. Do not place fruits and
vegetables in this compartment.
You can expand the product's internal volume by
removing any of the zero degree compartments.
To remove the compartment, simply pull forth, lift
up and pull out.
5.3. Vegetable bin
The refrigerator's vegetable bin is designed to
keep vegetables fresh by preserving humidity.
For this purpose, the overall cold air circulation
is intensified in the vegetable bin. Keep fruits
and vegetables in this compartment. Keep the
greenleaved vegetables and fruits separately to
prolong their life.
5.4. Blue light
(This feature is optional)
Beko Active Fresh Blue Light TM technology
ensures that the process of photosynthesis
continues in the refrigerator prolonging the storage
life of fresh fruit and vegetables while
maintaining their natural flavours and nutrition.
5.5. Description and
cleaning of odour filter
(Optional)
Odor filter prevents unpleasant odour build-up in
your product.
1. Pull the cover into which the odour filter is
installed downwards from the front section and
remove as illustrated.
2. Leave the filter under sunlight for one day. Filter
will be cleaned during this time.
3. Install the filter back to its place.
C
Odor filter must be cleaned once in a year.
24 / 31 EN
Refrigerator / User Manual
Using the product
5.6. Telescopic drawer
Pay attention not to squeeze any parts of your
body such as hands, feet and etc. between the
movable parts while the drawer is in use in order
to avoid any injury.
You can remove the partition in the drawer as
illustrated when you want to clean it.
You can remove the drawers only for cleaning.
It is not possible to group the drawers in their
places after loading them with food when they are
removed.
5.7. Ionizer
(Optional)
The ionizer system in the cooler compartment’s
air duct serves to ionize the air. The negative
ion emissions will eliminate bacteria and other
molecules causing odour in the air.
5.8. Ice box
(Optional)
Please read the warnings carefully on the ice con-
tainer. The ice container is used for ice collection
poured ice machine. Do not put water in it to make
ice as it may break. The ice container is not used
for storing foods.
Warning: Do not change the location of the ice
container.
5.9. Ice maker
(Optional)
The ice machine is nonremovable. There must be
ice container at the bottom of the ice machine.
25 / 31 EN
Refrigerator / User Manual
Using the product
5.10. Movable middle section
Movable middle section is intended to prevent
the cold air inside your refrigerator from escaping
outside.
Sealing is provided when the gaskets on the door
presses on the surface of the movable middle
section while the cooler compartment doors are
closed.
Another reason that your refrigerator is equipped
with a movable middle section is that it increases
the net volume of the cooler compartment.Standard
middle sections occupy some non-usable volume in
the refrigerator.
Movable middle section is closed when the left
door of the cooler compartment is closed.
It must not be opened manually. It moves under the
guidance of the plastic part on the body while the
door is closed.
5.11. Ice container
(Optional)
Ice container allows you to obtain ice from the
product easily.
Using the ice container
1. Remove the ice container from the freezer
compartment.
2. Fill the ice container with water.
3. Place the ice container in the freezer
compartment. About two hours later, the ice is
ready.
4. Remove the ice container from the freezer
compartment and bend it over the service plate.
Ice cubes will easily fall down to the service plate.
26 / 31 EN
Refrigerator / User Manual
Using the product
5.12. Humidity controlled crisper
(FreSHelf)
(This feature is optional)
Humidity rates of the vegetables and fruit are
kept under control with the feature of humidity-
controlled crisper and the food is ensured to stay
fresh for longer.
We recommend you to place the leafy vegetables
such as lettuce, spinach and the vegetables
which are sensitive to humidity loss, in a hori-
zontal manner as much as possible inside the
crisper, not on their roots in a vertical position.
While the vegetables are being placed, specific
gravity of the vegetables should be taken into
consideration. Heavy and hard vegetables should
be put at the bottom of the crisper and the
lightweight and soft vegetables should be placed
over.
Never leave the vegetables inside the crisper in
their bags. If the vegetables are left inside their
bags, this will cause them to decompose in a
short period of time. In case contacting with
other vegetables is not preferred for hygiene
concerns, use a perforated paper and other
similar packaging materials instead of a bag.
Do not place together the pear, apricot, peach,
etc. and apple in particular which have a high
level of generation of ethylene gas in the same
crisper with the other vegetables and fruit. The
ethylene gas which is emitted by these fruit may
cause the other fruit to ripen faster and decom-
pose in a shorter time.
27 / 31 EN
Refrigerator / User Manual
Using the product
5.13. Freezing fresh food
• To preserve food quality, the food items placed
in the freezer compartment must be frozen as
quickly as possible, use the rapid freezing for
this.
• Freezing the food items when fresh will extend
the storage time in the freezer compartment.
• Pack the food items in air-tight packs and seal
tightly.
• Make sure the food items are packed before
putting in the freezer. Use freezer holders,
tinfoil and damp-proof paper, plastic bag
or similar packaging materials instead of
traditional packaging paper.
• Mark each food pack by writing the date on the
package before freezing. This will allow you to
determine the freshness of each pack every
time the freezer is opened. Keep the earlier
food items in the front to ensure they are used
first.
• Frozen food items must be used immediately
after defrosting and should not be frozen again.
• Do not froze large quantities of food at once.
Freezer
Compartment
Setting
Cooler
compartment
Setting
Descriptions
-18°C 4°C This is the default, recommended setting.
-20,-22 or
-24°C
4°C
These settings are recommended for ambient temperatures
exceeding 30°C.
Rapid Freeze 4°C
Use this to freeze food items in a short time. The product will reset
to previous settings when the process is completed.
-18°C or colder 2°C
Use these settings if you believe the cooler compartment is not cold
enough due to ambient temperature or frequently opening the door.
5.14. Recommendations for
storing frozen foods
The compartment must be set to at least -18°C.
1. Place the food items in the freezer as quickly
as possible to avoid defrosting.
2. Before freezing, check the “Expiry Date” on
the package to make sure it is not expired.
3. Make sure the food’s packaging is not
damaged.
5.15. Deep freezer details
As per the IEC 62552 standards, the freezer must
have the capacity to freeze 4.5 kg of food items at
-18°C or lower temperatures in 24 hours for each
100 litres of freezer compartment volume.
Food items can only be preserved for extended
periods at or below temperature of -18°C .
You can keep the foods fresh for months (in deep
freezer at or below temperatures of 18°C ).
The food items to be frozen must not contact
the already-frozen food inside to avoid partial
defrosting.
28 / 31 EN
Refrigerator / User Manual
Using the product
Boil the vegetables and filter the water to extend
the frozen storage time. Place the food in air-tight
packages after filtering and place in the freezer.
Bananas, tomatoes, lettuce, celery, boiled eggs,
potatoes and similar food items should not be
frozen. When these foods are frozen, only their
nutritional value and taste shall be affected
negatively. They shall not be spoiled so that they
would create a risk for human health.
5.16. Placing the food
Freezer
compartment
shelves
Various frozen foods including
meat, fish, ice cream,
vegetables etc.
Cooler
compartment
shelves
Food items inside pots, capped
plate and capped cases, eggs
(in capped case)
Cooler
compartment
door shelves
Small and packed food or
beverages
Vegetable bin Fruits and vegetables
Fresh food
compartment
Delicatessen (breakfast food,
meat products to be consumed
in short notice)
5.17. Door open alert
(Optional)
An audible alert will be heard if the product's door
remains open for 1 minute. The audible alert will
stop when the door is closed or any button on the
display (if available) is pressed.
5.18. Interior light
Interior light uses a LED type lamp. Contact the
authorized service for any problems with this lamp.
Interior light used in this product is not intended
for home lighting and not suitable for such
purposes. Interior lights in cooler or freezer
compartments are intended to help safe and
convenient food placement into the refrigerator.
The lamp(s) used in this appliance is not suitable
for household room illumination. The intended
purpose of this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer in a safe and
comfortable way.
29 / 31 EN
Refrigerator / User Manual
6 Maintenance and cleaning
Cleaning the product regularly will prolong its
service life.
B
WARNING: Disconnect the power before
cleaning the refrigerator.
• Do not use sharp and abrasive tools, soap,
house cleaning materials, detergents, gas,
gasoline, varnish and similar substances for
cleaning.
• Melt a teaspoonful of carbonate in the water.
Moisten a piece of cloth in the water and wring
out. Wipe the device with this cloth and dry off
thoroughly.
• Take care to keep water away from the lamp’s
cover and other electrical parts.
• Clean the door using a wet cloth. Remove all
items inside to detach the door and chassis
shelves. Lift the door shelves up to detach.
Clean and dry the shelves, then attach back in
place by sliding from above.
• Do not use chloric water or cleaning products
on the exterior surface and chrome-coated
parts of the product. Chlorine will cause rust on
such metallic surfaces.
• Do not use sharp, abrasive tools, soap,
household cleaning agents, detergents,
kerosene, fuel oil, varnish etc. to prevent
removal and deformation of the prints on the
plastic part. Use lukewarm water and a soft
cloth for cleaning and then wipe it dry.
6.1. Preventing malodour
The product is manufactured free of any
odorous materials. However, keeping the food in
inappropriate sections and improper cleaning of
internal surfaces may lead to malodour.
To avoid this, clean the inside with carbonated
water every 15 days.
• Keep the foods in sealed holders.
Microorganisms may spread out of unsealed
food items and cause malodour.
• Do not keep expired and spoilt foods in the
refrigerator.
6.2. Protecting plastic surfaces
Oil spilled on plastic surfaces may damage the
surface and must be cleaned immediately with
warm water.
30 / 31 EN
Refrigerator / User Manual
7 Troubleshooting
Check this list before contacting the service. Doing so will save you time and money. This list includes
frequent complaints that are not related to faulty workmanship or materials. Certain features mentioned
herein may not apply to your product.
The refrigerator is not working.
• The power plug is not fully settled. >>> Plug it in to settle completely into the socket.
• The fuse connected to the socket powering the product or the main fuse is blown. >>> Check the
fuses.
Condensation on the side wall of the cooler compartment (MULTI ZONE, COOL, CONTROL and FLEXI ZONE).
• The environment is too cold. >>> Do not install the product in environments with temperatures
below -5°C.
• The door is opened too frequently >>> Take care not to open the product’s door too frequently.
• The environment is too humid. >>> Do not install the product in humid environments.
• Foods containing liquids are kept in unsealed holders. >>> Keep the foods containing liquids in
sealed holders.
• The product’s door is left open. >>> Do not keep the product’s door open for long periods.
• The thermostat is set to too low temperature. >>> Set the thermostat to appropriate temperature.
Compressor is not working.
• In case of sudden power failure or pulling the power plug off and putting back on, the gas pressure
in the product’s cooling system is not balanced, which triggers the compressor thermic safeguard.
The product will restart after approximately 6 minutes. If the product does not restart after this
period, contact the service.
• Defrosting is active. >>> This is normal for a fully-automatic defrosting product. The defrosting is
carried out periodically.
• The product is not plugged in. >>> Make sure the power cord is plugged in.
• The temperature setting is incorrect. >>> Select the appropriate temperature setting.
• The power is out. >>> The product will continue to operate normally once the power is restored.
The refrigerator's operating noise is increasing while in use.
• The product’s operating performance may vary depending on the ambient temperature variations.
This is normal and not a malfunction.
The refrigerator runs too often or for too long.
31 / 31 EN
Refrigerator / User Manual
Troubleshooting
• The new product may be larger than the previous one. Larger products will run for longer periods.
• The room temperature may be high. >>> The product will normally run for long periods in higher
room temperature.
• The product may have been recently plugged in or a new food item is placed inside. >>> The
product will take longer to reach the set temperature when recently plugged in or a new food item
is placed inside. This is normal.
• Large quantities of hot food may have been recently placed into the product. >>> Do not place hot
food into the product.
• The doors were opened frequently or kept open for long periods. >>> The warm air moving inside
will cause the product to run longer. Do not open the doors too frequently.
• The freezer or cooler door may be ajar. >>> Check that the doors are fully closed.
• The product may be set to temperature too low. >>> Set the temperature to a higher degree and
wait for the product to reach the adjusted temperature.
• The cooler or freezer door washer may be dirty, worn out, broken or not properly settled. >>>
Clean or replace the washer. Damaged / torn door washer will cause the product to run for longer
periods to preserve the current temperature.
The freezer temperature is very low, but the cooler temperature is adequate.
• The freezer compartment temperature is set to a very low degree. >>> Set the freezer
compartment temperature to a higher degree and check again.
The cooler temperature is very low, but the freezer temperature is adequate.
• The cooler compartment temperature is set to a very low degree. >>> Set the freezer
compartment temperature to a higher degree and check again.
The food items kept in cooler compartment drawers are frozen.
• The cooler compartment temperature is set to a very low degree. >>> Set the freezer
compartment temperature to a higher degree and check again.
The temperature in the cooler or the freezer is too high.
• The cooler compartment temperature is set to a very high degree. >>> Temperature setting of the
cooler compartment has an effect on the temperature in the freezer compartment. Wait until the
temperature of relevant parts reach the sufficient level by changing the temperature of cooler or
freezer compartments.
• The doors were opened frequently or kept open for long periods. >>> Do not open the doors too
frequently.
• The door may be ajar. >>> Fully close the door.
• The product may have been recently plugged in or a new food item is placed inside. >>> This is
normal. The product will take longer to reach the set temperature when recently plugged in or a
new food item is placed inside.
• Large quantities of hot food may have been recently placed into the product. >>> Do not place hot
food into the product.
Shaking or noise.
32 / 31 EN
Refrigerator / User Manual
Troubleshooting
• The ground is not level or durable. >>> If the product is shaking when moved slowly, adjust
the stands to balance the product. Also make sure the ground is sufficiently durable to bear the
product.
• Any items placed on the product may cause noise. >>> Remove any items placed on the product.
The product is making noise of liquid flowing, spraying etc.
• The product’s operating principles involve liquid and gas flows. >>> This is normal and not a
malfunction.
There is sound of wind blowing coming from the product.
• The product uses a fan for the cooling process. This is normal and not a malfunction.
There is condensation on the product's internal walls.
• Hot or humid weather will increase icing and condensation. This is normal and not a malfunction.
• The doors were opened frequently or kept open for long periods. >>> Do not open the doors too
frequently; if open, close the door.
• The door may be ajar. >>> Fully close the door.
There is condensation on the product's exterior or between the doors.
• The ambient weather may be humid, this is quite normal in humid weather. >>> The condensation
will dissipate when the humidity is reduced.
The interior smells bad.
•Theproductisnotcleanedregularly.>>>Cleantheinteriorregularlyusingsponge,warmwaterand
carbonated water.
•Certainholdersandpackagingmaterialsmaycauseodour.>>>Useholdersandpackaging
materials without free of odour.
•Thefoodswereplacedinunsealedholders.>>>Keepthefoodsinsealedholders.Micro-organisms
may spread out of unsealed food items and cause malodour. Remove any expired or spoilt foods
from the product.
The door is not closing.
• Food packages may be blocking the door. >>> Relocate any items blocking the doors.
• The product is not standing in full upright position on the ground. >>> Adjust the stands to balance
the product.
• The ground is not level or durable. >>> Make sure the ground is level and sufficiently durable to
bear the product.
The vegetable bin is jammed.
• The food items may be in contact with the upper section of the drawer. >>> Reorganize the food
items in the drawer.
A
WARNING: If the problem persists after following the instructions in this section, contact your vendor
or an Authorised Service. Do not try to repair the product.
www.beko.com.tr
www.beko.com
.au
57 6047 0000/AH
