EN
1
DAILY REFERENCE
GUIDE
Before using the appliance carefully read Health and Safety guide.
APPLIANCE
PRODUCT DESCRIPTION
CONTROL PANEL
1. On-O/Reset button with indicator light
2. Program selection button with indicator light
3. Zone Wash 3D button with indicator light / Key lock
4. Eco program indicator light
5. Key lock indicator light
6. Display
7. Program number and remaining time indicator
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid rell indicator light
11. Salt rell indicator light
12. Short Time button with indicator light / Tablet (Tab)
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
3
1
2
8
13
1454 6 7 10 11 129
THANK YOU FOR BUYING A HOTPOINT ARISTON
PRODUCT. In order to receive a more complete assi-
stance, please register your appliance on:
www.hotpoint.eu/register
You can download the Safety Instructions and the
Use and Care Guide, by visiting our website docs.
hotpoint.eu and following the Instructions on the
back of this booklet.
1. Upper rack
2. Foldable aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Cutlery basket
7. Lower spray arm
8. Filter Assembly
9. Salt reservoir
10. Detergent and Rinse Aid dispensers
11. Rating plate
12. Control panel
0000 000 00000
Service:
1
2
3
4
5
6
10
12
7
11
9
8
