DRAWN CHECKED APPROVED
Jeong Su Jin
12.03.07
Bae Tae Ho
12.03.07
KIM J. O.
12.03.07
Model LS3500 BRAND
Suffix LGEUS Product Name
1. Model Description
LG
Part No.
LS3500-UA
1. Trim Size (Format) : 182mm x 257 mm (B5)
2 Printing Colors
• Cover : 1 COLOR (BLACK)
• Inside : 1 COLOR (BLACK)
3. Stock (Paper)
• Cover : Coated paper , S/White 150 g/㎡
• Inside : Uncoated paper , Wood-Free Paper (백상지) 60 g/㎡
4. Printing Method : Off set
5. Bindery : Saddle stitch
6. Language : English (1)
7. Number of pages : 44
“This part contains Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,
2. Printing Specification
MFL67468111
(1206-REV06)
Owner'sManualSpecification
N
June/11/2012 Hong Yu Ri EKLC600631
June/04/2012 Hong Yu Ri EKLC600108
Mar./07/2012 Jeong Su Jin EKLC300479
Feb./13/2012 Jeong Su Jin EKLC201263
Feb./01/2012 Jeong Su Jin EKLC200003
Jan./11/2012 Jeong Su Jin EKLC100279
Rev. No. MM/DD/Y
Y
Si
g
nature Chan
g
e No.
Update manual contents for Main Production
Change Contents
3. Printing Specification
To Add a model on the Manual
Details should be followed Eco-SCM management standard[LG(56)-A-2524].
Especially, Part should be followed and controlled the following specification.
(1)Eco-hazardous substances test report should be submitted when Part certification test and First Mass Production.
(2) Especially, Don’t use or contain lead(Pb) and cadmium(Cd) in ink.
(1) Origin Notification
* LGERS : Printed in Mexico * LGEND : Printed in China * LGEVN : Printed in Vietnam * LGEMA : Printed in Poland
* LGEAZ : Printed in Brazil * LGEIL : Printed in India * LGEEG : Printed in Egypt * LGEWR : Printed in Poland
* LGESP : Printed in Brazil * LGEIN : Printed in Indonesia * LGERA : Printed in Russia
* LGESY : Printed in China * LGETH : Printed in Thailand * LGEAK : Printed in Kazakhstan
To Add a model on the Manual (32LS3410-UB)
Change the size of screws
Add the CS461 and LS3510 series in manual
Revise the manual because current rating of 32LS3400 was changed.
4. Changes
N
O
T
E
1
2
3
4
5
6
7
8
9
g
g
g
