iNSTALLATiON AND SERVICE MUST BE PERFORMED BY A QUALiFiED
iNSTALLER, iMPORTANT: SAVE FOR LOCAL ELECTRICAL iNSPECTOR'S USE.
READ AND SAVE THESE iNSTRUCTiONS FOR FUTURE REFERENCE.
FOR YOUR SAFETY: Do nat store or use gasollne or other flammable
vapors and liquids in the vicinity of this or any other appliance.
Your new wall oven has been designed to fit a limited variety of cutout sizes to make
the jab of installlng easier. The first step of your installatlan should be to measure your
current cutout dimensions and compare them to the cutout dimensions chart below far
your model. You may find lltfle or no cabinet work being necessary.
United States
Canada
Do not remove spacers (if equipped) on the side walls and/or an the back of the
built-ln oven. These spacers center the oven in the space provided. The oven must be centered to
prevent excess heat bulldup that may result in heat damage or fire.
NOTES:
1. Base must be capable of supporting 150 pounds (68 kg) for 27" models and
200 pounds (90 kg) for 30" models.
2. Allow at least 21" (53.3cm) clearance in front of oven for door 1" (2.5cm)
depth when it is open. Min.
3. Dimension G (cutout depth) is critical ._L
to the proper installation of the built-
in oven. If the oven decorative trim
does not butt against the cabinet, or if I H
noise is heard on convection models, B |
verify dimension G to assure it is the I
required depth, t
4. For a cutout height greater
than 2713/|6" (70.6cm) add ......._ 31"*
i, . . .---'"
one 2 (5cm) wide wood shim Doc)rOpen
of appropriate height to each
(see note 2
side of the opening under the
appliance side rails.
Suggested distance from floor
is 31" (78.7cm).
Minimum required distance is4 1/2"(11.4cm)
Figure 1
27" and 30" Single Wall Ovens (Double ovens see Figure 2)
2" (5 crn) Wide Wood
Spacer if Needed
27" (68.6cm) 27 (68.6) 29t/16 (73.8) 24s/8 (62.5) 241/2 (62.2)
30" (76.2cm) 30 (76.2) 29t/16 (73.8) 28t/4 (71.8) 241/2 (62.2)
CUTOUT DIMENSIONS AND CABINET WIDTH
F H
MODEL G (rain.) I
Min. Max. Min. Max.
27" (68.6cm) 247/8 (63.2) 251/4 (64.1) 231/2 (59.7) 275/_ (69.4) 281/2 (72.4) 271/8 (68.9) Min.
30" (76.2cm) 281/2 (72.4) 29 (73.7) 231/2 (59.7) 275/_ (69.4) 281/2 (72.4) 301/8 (76.5) Min.
Aii dimensions are in inches (cm).
Printed in Canada
P/N 318206000 (1106) Rev. A
English - pages 1-8
Espa_ol - p6ginas 9-16
