Before using the appliance carefully read Health and Safety guide.
APPLIANCE
PRODUCT DESCRIPTION
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.hotpoint.eu/register
You can download the Safety Instructions and the
Use and Care Guide, by visiting our website
docs.hotpoint.eu and following the Instructions on
the back of this booklet.
1. Upper rack
2. Foldable aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Cutlery basket
7. Lower spray arm
8. Filter Assembly
9. Salt reservoir
10. Detergent and Rinse Aid dispensers
11. Rating plate
12. Control panel
0000 000 00000
Service:
1
2
3
4
5
6
7
9
8
1011
12
3
1
2
8
13
14
5
4
6
7 11 12
9
10
3 ’’
1. On-O/Reset button with indicator light
2. Program selection button with indicator light
3. Half Load button with indicator light / Key lock
4. Eco program indicator light
5. Key lock indicator light
6. Display
7. Program number and remaining time indicator
DAILY REFERENCE
GUIDE
CONTROL PANEL
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid rell indicator light
11. Salt rell indicator light
12. Tablet (Tab) button with indicator light
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
