INSTALLATION INSTRUCTIONS
30" GAS SLIDE-IN RANGE
Printed in United States
Important Notes to the Installer
1. Read all instructions contained in these installation
instructions before installing range.
2. Remove all packing material from the oven and the
drawer compartments before connecting the gas and
the electrical supply to the range.
3. Observe all governing codes and ordinances.
4. Be sure to leave these instructions with the
consumer.
5. Note: For operation at 2000 ft. elevations above see
level, appliance rating shall be reduced by 4 percent
for each additional 1000 ft.
Important Note to the Consumer
Keep these instructions with your owner's guide for
future reference.
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Table of Contents
Important Safety Instructions .......................................... 2
Product & Cabinet Dimensions....................................3-4
To Avoid Breakage .......................................................... 5
Before Starting................................................................ 6
Cabinet Construction ................................................... 6-7
Provide an Adequate Gas Supply................................... 7
Seal the Openings .......................................................... 7
Connect the Range to the Gas Supply ........................7-8
LP/Propane Gas Conversion .......................................... 8
Electrical Requirements.................................................. 8
Moving the Appliance for servicing and Cleaning ........... 8
Anti-Tip Brackets Installation ..................................... 9-10
Range Installation ..........................................................11
Leveling the Range....................................................... 12
Decorative Rear Trim Installation ................................. 12
Check Operation......................................................13-14
When All Hookups are Complete.................................. 14
Model and Serial Number Location .............................. 14
Before You Call for Service........................................... 14
If the information in this manual is not followed exactly, a re or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETY:
— Do not store or use gasoline or other ammable vapors and liquids in
the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier, call the re department.
— Installation and service must be performed by a qualied installer,
service agency or the gas supplier.
P/N 809018301 (1507) Rev. A
English – pages 1-14; Spanish - pages 15-28; French – pages 29-43
Appliances Installed in the state of
Massachusetts:
This Appliance can only be installed in the state of
Massachusetts by a Massachusetts licensed plumber or
gastter.
This appliance must be installed with a three (3) foot / 36
in. long exible gas connector.
A"T" handle type manual gas valve must be installed in
the gas supply line to this appliance.
Cold temperature can damage the
electronic control. When using the appliance for the
rst time, or when the appliance has not been used
for an extended period, be certain the unit has been
in temperatures above 32°F (0°C) for at least 3 hours
before turning on the power to the appliance.
United States
Canada
Refer to your serial
plate for applicable
agency certication.
